Texas instruments TMS320C28341, TMS320C28345, TMS320C28344, TMS320C28346, TMS320C28342 Data Manual
...
TMS320C28346, TMS320C28345, TMS320C28344
TMS320C28343, TMS320C28342, TMS320C28341
Delfino Microcontrollers
Data Manual
PRODUCTION DATA information is current as of publication date.
Products conform to specifications per the terms of the Texas
Instruments standard warranty. Production processing does not
necessarily include testing of all parameters.
Literature Number: SPRS516B
March 2009–Revised July 2010
TMS320C28346, TMS320C28345, TMS320C28344
TMS320C28343, TMS320C28342, TMS320C28341
SPRS516B–MARCH 2009–REVISED JULY 2010
www.ti.com
Contents
1 TMS320C2834x ( Delfino™) MCUs ....................................................................................... 11
1.1 Overview .................................................................................................................... 11
1.2 Features .................................................................................................................... 11
1.3 Getting Started ............................................................................................................. 12
2 Introduction ...................................................................................................................... 13
2.1 Pin Assignments ........................................................................................................... 16
2.2 Signal Descriptions ........................................................................................................ 24
3 Functional Overview .......................................................................................................... 35
3.1 Memory Maps .............................................................................................................. 36
3.2 Brief Descriptions .......................................................................................................... 41
3.2.1 C28x CPU ....................................................................................................... 41
3.2.2 Memory Bus (Harvard Bus Architecture) .................................................................... 41
3.2.3 Peripheral Bus .................................................................................................. 41
3.2.4 Real-Time JTAG and Analysis ................................................................................ 42
3.2.5 External Interface (XINTF) .................................................................................... 42
3.2.6 M0, M1 SARAMs ............................................................................................... 42
3.2.7 L0, L1, L2, L3, L4, L5, L6, L7 , H0, H1, H2, H3, H4, H5 SARAMs ....................................... 42
3.2.8 Boot ROM ....................................................................................................... 43
3.2.9 Security .......................................................................................................... 43
3.2.10 Peripheral Interrupt Expansion (PIE) Block ................................................................. 44
3.2.11 External Interrupts (XINT1–XINT7, XNMI) .................................................................. 44
3.2.12 Oscillator and PLL .............................................................................................. 44
3.2.13 Watchdog ........................................................................................................ 44
3.2.14 Peripheral Clocking ............................................................................................. 44
3.2.15 Low-Power Modes .............................................................................................. 44
3.2.16 Peripheral Frames 0, 1, 2, 3 (PFn) ........................................................................... 45
3.2.17 General-Purpose Input/Output (GPIO) Multiplexer ......................................................... 45
3.2.18 32-Bit CPU-Timers (0, 1, 2) ................................................................................... 45
3.2.19 Control Peripherals ............................................................................................. 46
3.2.20 Serial Port Peripherals ......................................................................................... 46
3.3 Register Map ............................................................................................................... 47
3.4 Device Emulation Registers .............................................................................................. 48
3.5 Interrupts .................................................................................................................... 49
3.5.1 External Interrupts .............................................................................................. 53
3.6 System Control ............................................................................................................ 54
3.6.1 OSC and PLL Block ............................................................................................ 55
3.6.1.1 External Reference Oscillator Clock Option .................................................... 57
3.6.1.2 PLL-Based Clock Module ......................................................................... 58
3.6.1.3 Loss of Input Clock ................................................................................ 59
3.6.2 Watchdog Block ................................................................................................. 60
3.7 Low-Power Modes Block ................................................................................................. 61
4 Peripherals ....................................................................................................................... 62
4.1 DMA Overview ............................................................................................................. 62
4.2 32-Bit CPU-Timers 0/1/2 ................................................................................................. 64
4.3 Enhanced PWM Modules (ePWM1/2/3/4/5/6 /7/8/9) ................................................................. 66
2 Contents Copyright © 2009–2010, Texas Instruments Incorporated
TMS320C28346, TMS320C28345, TMS320C28344
TMS320C28343, TMS320C28342, TMS320C28341
www.ti.com
4.4 High-Resolution PWM (HRPWM) ....................................................................................... 70
4.5 Enhanced CAP Modules (eCAP1/2/3/4/5/6) ........................................................................... 71
4.6 Enhanced QEP Modules (eQEP1/2 /3) ................................................................................. 73
4.7 External ADC Interface ................................................................................................... 75
4.8 Multichannel Buffered Serial Port (McBSP) Module .................................................................. 76
4.9 Enhanced Controller Area Network (eCAN) Modules (eCAN-A and eCAN-B) .................................... 79
4.10 Serial Communications Interface (SCI) Modules (SCI-A, SCI-B, SCI-C) .......................................... 85
4.11 Serial Peripheral Interface (SPI) Module (SPI-A , SPI-D) ............................................................ 89
4.12 Inter-Integrated Circuit (I2C) ............................................................................................. 92
4.13 GPIO MUX ................................................................................................................. 93
4.14 External Interface (XINTF) .............................................................................................. 100
SPRS516B–MARCH 2009–REVISED JULY 2010
5 Device Support ................................................................................................................ 102
5.1 Device and Development Support Tool Nomenclature ............................................................. 102
5.2 Documentation Support ................................................................................................. 104
6 Electrical Specifications ................................................................................................... 108
6.1 Absolute Maximum Ratings ............................................................................................. 108
6.2 Recommended Operating Conditions ................................................................................. 109
6.3 Electrical Characteristics ................................................................................................ 109
6.4 Current Consumption .................................................................................................... 110
6.4.1 Reducing Current Consumption ............................................................................. 112
6.5 Thermal Design Considerations ........................................................................................ 114
6.6 Emulator Connection Without Signal Buffering for the MCU ....................................................... 114
6.7 Timing Parameter Symbology .......................................................................................... 115
6.7.1 General Notes on Timing Parameters ...................................................................... 115
6.7.2 Test Load Circuit .............................................................................................. 115
6.7.3 Device Clock Table ........................................................................................... 116
6.8 Clock Requirements and Characteristics ............................................................................. 118
6.9 Power Sequencing ....................................................................................................... 119
6.9.1 Power Management and Supervisory Circuit Solutions .................................................. 120
6.10 General-Purpose Input/Output (GPIO) ................................................................................ 123
6.10.1 GPIO - Output Timing ........................................................................................ 123
6.10.2 GPIO - Input Timing .......................................................................................... 124
6.10.3 Sampling Window Width for Input Signals ................................................................. 125
6.10.4 Low-Power Mode Wakeup Timing .......................................................................... 126
6.11 Enhanced Control Peripherals ......................................................................................... 129
6.11.1 Enhanced Pulse Width Modulator (ePWM) Timing ....................................................... 129
6.11.2 Trip-Zone Input Timing ....................................................................................... 129
6.11.3 Enhanced Capture (eCAP) Timing ......................................................................... 130
6.11.4 Enhanced Quadrature Encoder Pulse (eQEP) Timing ................................................... 130
6.11.5 ADC Start-of-Conversion Timing ............................................................................ 131
6.12 External Interrupt Timing ................................................................................................ 131
6.13 I2C Electrical Specification and Timing ............................................................................... 132
6.14 Serial Peripheral Interface (SPI) Timing .............................................................................. 132
6.14.1 Master Mode Timing .......................................................................................... 132
6.14.2 SPI Slave Mode Timing ...................................................................................... 137
6.15 External Interface (XINTF) Timing ..................................................................................... 140
6.15.1 USEREADY = 0 ............................................................................................... 140
Copyright © 2009–2010, Texas Instruments Incorporated Contents 3
TMS320C28346, TMS320C28345, TMS320C28344
TMS320C28343, TMS320C28342, TMS320C28341
SPRS516B–MARCH 2009–REVISED JULY 2010
6.15.2 Synchronous Mode (USEREADY = 1, READYMODE = 0) ............................................. 141
6.15.3 Asynchronous Mode (USEREADY = 1, READYMODE = 1) ............................................ 142
6.15.4 XINTF Signal Alignment to XCLKOUT ..................................................................... 144
6.15.5 External Interface Read Timing ............................................................................. 145
6.15.6 External Interface Write Timing ............................................................................. 147
6.15.7 External Interface Ready-on-Read Timing With One External Wait State ............................ 149
6.15.8 External Interface Ready-on-Write Timing With One External Wait State ............................. 152
6.15.9 XHOLD and XHOLDA Timing ............................................................................... 155
6.16 Multichannel Buffered Serial Port (McBSP) Timing ................................................................. 157
6.16.1 McBSP Transmit and Receive Timing ...................................................................... 157
6.16.2 McBSP as SPI Master or Slave Timing .................................................................... 160
www.ti.com
7 Revision History .............................................................................................................. 164
8 Thermal/Mechanical Data .................................................................................................. 165
4 Contents Copyright © 2009–2010, Texas Instruments Incorporated
TMS320C28346, TMS320C28345, TMS320C28344
TMS320C28343, TMS320C28342, TMS320C28341
www.ti.com
SPRS516B–MARCH 2009–REVISED JULY 2010
List of Figures
2-1 C2834x 179-Ball ZHH MicroStar BGA™ Upper Left Quadrant (Bottom VIew) .......................................... 17
2-2 C2834x 179-Ball ZHH MicroStar BGA™ Upper Right Quadrant (Bottom View)......................................... 18
2-3 C2834x 179-Ball ZHH MicroStar BGA™ Lower Left Quadrant (Bottom View)........................................... 19
2-4 C2834x 179-Ball ZHH MicroStar BGA™ Lower Right Quadrant (Bottom View)......................................... 20
2-5 C2834x 256-Ball ZFE Plastic BGA Upper Left Quadrant (Bottom View) ................................................. 21
2-6 C2834x 256-Ball ZFE Plastic BGA Upper Right Quadrant (Bottom View) ............................................... 22
2-7 C2834x 256-Ball ZFE Plastic BGA Lower Left Quadrant (Bottom View) ................................................. 23
2-8 C2834x 256-Ball ZFE Plastic BGA Lower Right Quadrant (Bottom View) ............................................... 23
3-1 Functional Block Diagram ...................................................................................................... 36
3-2 C28346/C28345 Memory Map ................................................................................................. 38
3-3 C28344/C28343 Memory Map ................................................................................................. 39
3-4 C28342, C28341 Memory Map ................................................................................................ 40
3-5 External and PIE Interrupt Sources............................................................................................ 50
3-6 External Interrupts................................................................................................................ 50
3-7 Multiplexing of Interrupts Using the PIE Block ............................................................................... 51
3-8 Clock and Reset Domains ...................................................................................................... 54
3-9 OSC and PLL Block Diagram................................................................................................... 55
3-10 Using a 3.3-V External Oscillator............................................................................................... 56
3-11 Using a 1. 8-V External Oscillator.............................................................................................. 56
3-12 Using the Internal Oscillator .................................................................................................... 56
3-13 Watchdog Module................................................................................................................ 60
4-1 DMA Functional Block Diagram ................................................................................................ 63
4-2 CPU-Timers....................................................................................................................... 64
4-3 CPU-Timer Interrupt Signals and Output Signal ............................................................................. 64
4-4 Generation of SOC Pulses to the External ADC Module ................................................................... 66
4-5 ePWM Submodules Showing Critical Internal Signal Interconnections................................................... 69
4-6 eCAP Functional Block Diagram ............................................................................................... 71
4-7 eQEP Functional Block Diagram............................................................................................... 73
4-8 External ADC Interface .......................................................................................................... 75
4-9 McBSP Module .................................................................................................................. 77
4-10 eCAN Block Diagram and Interface Circuit ................................................................................... 80
4-11 eCAN-A Memory Map ........................................................................................................... 82
4-12 eCAN-B Memory Map ........................................................................................................... 83
4-13 Serial Communications Interface (SCI) Module Block Diagram............................................................ 88
4-14 SPI Module Block Diagram (Slave Mode) .................................................................................... 91
4-15 I2C Peripheral Module Interfaces .............................................................................................. 92
4-16 GPIO MUX Block Diagram...................................................................................................... 94
4-17 Qualification Using Sampling Window......................................................................................... 99
4-18 External Interface Block Diagram............................................................................................. 100
4-19 Typical 16-bit Data Bus XINTF Connections................................................................................ 101
4-20 Typical 32-bit Data Bus XINTF Connections................................................................................ 101
5-1 Example of C2834x Device Nomenclature.................................................................................. 103
6-1 Temperature Versus Leakage Current (Typical)............................................................................ 112
6-2 Emulator Connection Without Signal Buffering for the MCU ............................................................. 114
6-3 3.3-V Test Load Circuit......................................................................................................... 115
6-4 Clock Timing..................................................................................................................... 118
6-5 Power-on Reset ................................................................................................................. 121
Copyright © 2009–2010, Texas Instruments Incorporated List of Figures 5
TMS320C28346, TMS320C28345, TMS320C28344
TMS320C28343, TMS320C28342, TMS320C28341
SPRS516B–MARCH 2009–REVISED JULY 2010
6-6 Warm Reset ..................................................................................................................... 122
6-7 Example of Effect of Writing Into PLLCR Register ......................................................................... 123
6-8 General-Purpose Output Timing.............................................................................................. 124
6-9 Sampling Mode ................................................................................................................. 124
6-10 General-Purpose Input Timing................................................................................................ 125
6-11 IDLE Entry and Exit Timing.................................................................................................... 126
6-12 STANDBY Entry and Exit Timing Diagram.................................................................................. 127
6-13 HALT Wake-Up Using GPIOn................................................................................................. 128
6-14 PWM Hi-Z Characteristics..................................................................................................... 129
6-15 ADCSOCAO or ADCSOCBO Timing ........................................................................................ 131
6-16 External Interrupt Timing....................................................................................................... 131
6-17 SPI Master Mode External Timing (Clock Phase = 0) ..................................................................... 134
6-18 SPI Master Mode External Timing (Clock Phase = 1) ..................................................................... 136
6-19 SPI Slave Mode External Timing (Clock Phase = 0)....................................................................... 138
6-20 SPI Slave Mode External Timing (Clock Phase = 1)....................................................................... 139
6-21 Relationship Between XTIMCLK and SYSCLKOUT ....................................................................... 143
6-22 Example Read Access......................................................................................................... 146
6-23 Example Write Access......................................................................................................... 148
6-24 Example Read With Synchronous XREADY Access ...................................................................... 150
6-25 Example Read With Asynchronous XREADY Access..................................................................... 151
6-26 Write With Synchronous XREADY Access.................................................................................. 153
6-27 Write With Asynchronous XREADY Access ................................................................................ 154
6-28 External Interface Hold Waveform............................................................................................ 156
6-29 McBSP Receive Timing........................................................................................................ 159
6-30 McBSP Transmit Timing....................................................................................................... 159
6-31 McBSP Timing as SPI Master or Slave: CLKSTP = 10b, CLKXP = 0................................................... 160
6-32 McBSP Timing as SPI Master or Slave: CLKSTP = 11b, CLKXP = 0................................................... 161
6-33 McBSP Timing as SPI Master or Slave: CLKSTP = 10b, CLKXP = 1................................................... 162
6-34 McBSP Timing as SPI Master or Slave: CLKSTP = 11b, CLKXP = 1................................................... 163
www.ti.com
6 List of Figures Copyright © 2009–2010, Texas Instruments Incorporated
TMS320C28346, TMS320C28345, TMS320C28344
TMS320C28343, TMS320C28342, TMS320C28341
www.ti.com
SPRS516B–MARCH 2009–REVISED JULY 2010
List of Tables
2-1 C2834x Hardware Features .................................................................................................... 14
2-2 Signal Descriptions............................................................................................................... 24
3-1 Wait-states ........................................................................................................................ 40
3-2 Boot Mode Selection............................................................................................................. 43
3-3 Peripheral Frame 0 Registers .................................................................................................. 47
3-4 Peripheral Frame 1 Registers .................................................................................................. 47
3-5 Peripheral Frame 2 Registers .................................................................................................. 48
3-6 Peripheral Frame 3 Registers .................................................................................................. 48
3-7 Device Emulation Registers..................................................................................................... 48
3-8 PIE Peripheral Interrupts ....................................................................................................... 51
3-9 PIE Configuration and Control Registers...................................................................................... 52
3-10 External Interrupt Registers..................................................................................................... 53
3-11 PLL, Clocking, Watchdog, and Low-Power Mode Registers ............................................................... 55
3-12 PLL Settings ...................................................................................................................... 58
3-13 CLKIN Divide Options ........................................................................................................... 58
3-14 Possible PLL Configuration Modes ............................................................................................ 59
3-15 Low-Power Modes ............................................................................................................... 61
4-1 CPU-Timers 0, 1, 2 Configuration and Control Registers................................................................... 65
4-2 ePWM1-4 Control and Status Registers ...................................................................................... 67
4-3 ePWM5-9 Control and Status Registers ...................................................................................... 68
4-4 eCAP Control and Status Registers ........................................................................................... 72
4-5 eQEP Control and Status Registers ........................................................................................... 74
4-6 External ADC Interface Registers ............................................................................................. 75
4-7 McBSP Register Summary...................................................................................................... 78
4-8 3.3-V eCAN Transceivers ...................................................................................................... 81
4-9 CAN Register Map .............................................................................................................. 84
4-10 SCI-A Registers .................................................................................................................. 86
4-11 SCI-B Registers .................................................................................................................. 86
4-12 SCI-C Registers ................................................................................................................. 87
4-13 SPI-A Registers................................................................................................................... 90
4-14 SPI-D Registers .................................................................................................................. 90
4-15 I2C-A Registers................................................................................................................... 93
4-16 GPIO Registers .................................................................................................................. 95
4-17 GPIO-A Mux Peripheral Selection Matrix .................................................................................... 96
4-18 GPIO-B Mux Peripheral Selection Matrix .................................................................................... 97
4-19 GPIO-C Mux Peripheral Selection Matrix .................................................................................... 98
4-20 XINTF Configuration and Control Register Mapping....................................................................... 101
5-1 TMS320x2834x Delfino Peripheral Selection Guide ....................................................................... 104
6-1 TMS320C28346/C28344 Current Consumption by Power-Supply Pins at 300-MHz SYSCLKOUT................. 110
6-2 TMS320C28345/C28343 Current Consumption by Power-Supply Pins at 200-MHz SYSCLKOUT................. 111
6-3 Typical Current Consumption by Various Peripherals .................................................................... 113
6-4 Clocking and Nomenclature (300-MHz Devices) ........................................................................... 116
6-5 Clocking and Nomenclature (200-MHz Devices) ........................................................................... 117
6-6 XCLKIN/X1 Timing Requirements – PLL Enabled ......................................................................... 118
6-7 XCLKIN/X1 Timing Requirements – PLL Disabled ........................................................................ 118
6-8 XCLKOUT Switching Characteristics (PLL Bypassed or Enabled) ...................................................... 118
6-9 Power Management and Supervisory Circuit Solutions ................................................................... 120
Copyright © 2009–2010, Texas Instruments Incorporated List of Tables 7
TMS320C28346, TMS320C28345, TMS320C28344
TMS320C28343, TMS320C28342, TMS320C28341
SPRS516B–MARCH 2009–REVISED JULY 2010
6-10 Reset (XRS) Timing Requirements .......................................................................................... 122
6-11 General-Purpose Output Switching Characteristics........................................................................ 123
6-12 General-Purpose Input Timing Requirements .............................................................................. 124
6-13 IDLE Mode Timing Requirements ........................................................................................... 126
6-14 IDLE Mode Switching Characteristics ....................................................................................... 126
6-15 STANDBY Mode Timing Requirements ..................................................................................... 127
6-16 STANDBY Mode Switching Characteristics ................................................................................ 127
6-17 HALT Mode Timing Requirements ........................................................................................... 128
6-18 HALT Mode Switching Characteristics ...................................................................................... 128
6-19 ePWM Timing Requirements ................................................................................................. 129
6-20 ePWM Switching Characteristics ............................................................................................ 129
6-21 Trip-Zone Input Timing Requirements ...................................................................................... 129
6-22 High-Resolution PWM Characteristics at SYSCLKOUT = ( 150– 300 MHz) ........................................... 130
6-23 Enhanced Capture (eCAP) Timing Requirement .......................................................................... 130
6-24 eCAP Switching Characteristics ............................................................................................. 130
6-25 Enhanced Quadrature Encoder Pulse (eQEP) Timing Requirements .................................................. 130
6-26 eQEP Switching Characteristics ............................................................................................. 130
6-27 External ADC Start-of-Conversion Switching Characteristics............................................................. 131
6-28 External Interrupt Timing Requirements .................................................................................... 131
6-29 External Interrupt Switching Characteristics ................................................................................ 131
6-30 I2C Timing ...................................................................................................................... 132
6-31 SPI Master Mode External Timing (Clock Phase = 0) .................................................................... 133
6-32 SPI Master Mode External Timing (Clock Phase = 1) .................................................................... 135
6-33 SPI Slave Mode External Timing (Clock Phase = 0) ...................................................................... 137
6-34 SPI Slave Mode External Timing (Clock Phase = 1) ...................................................................... 139
6-35 Relationship Between Parameters Configured in XTIMING and Duration of Pulse ................................... 140
6-36 XINTF Clock Configurations for SYSCLKOUT = 300 MHz ............................................................... 143
6-37 External Interface Read Timing Requirements ............................................................................. 145
6-38 External Interface Read Switching Characteristics......................................................................... 145
6-39 External Interface Write Switching Characteristics......................................................................... 147
6-40 External Interface Read Switching Characteristics (Ready-on-Read, 1 Wait State)................................... 149
6-41 External Interface Read Timing Requirements (Ready-on-Read, 1 Wait State) ....................................... 149
6-42 Synchronous XREADY Timing Requirements (Ready-on-Read, 1 Wait State) ....................................... 149
6-43 Asynchronous XREADY Timing Requirements (Ready-on-Read, 1 Wait State)....................................... 149
6-44 External Interface Write Switching Characteristics (Ready-on-Write, 1 Wait State) ................................... 152
6-45 Synchronous XREADY Timing Requirements (Ready-on-Write, 1 Wait State) ....................................... 152
6-46 Asynchronous XREADY Timing Requirements (Ready-on-Write, 1 Wait State) ...................................... 152
6-47 XHOLD/XHOLDA Timing Requirements .................................................................................... 155
6-48 McBSP Timing Requirements ................................................................................................ 157
6-49 McBSP Switching Characteristics ........................................................................................... 158
6-50 McBSP as SPI Master or Slave Timing Requirements (CLKSTP = 10b, CLKXP = 0) ................................ 160
6-51 McBSP as SPI Master or Slave Switching Characteristics (CLKSTP = 10b, CLKXP = 0)............................ 160
6-52 McBSP as SPI Master or Slave Timing Requirements (CLKSTP = 11b, CLKXP = 0) ................................ 161
6-53 McBSP as SPI Master or Slave Switching Characteristics (CLKSTP = 11b, CLKXP = 0)............................ 161
6-54 McBSP as SPI Master or Slave Timing Requirements (CLKSTP = 10b, CLKXP = 1) ................................ 162
6-55 McBSP as SPI Master or Slave Switching Characteristics (CLKSTP = 10b, CLKXP = 1)............................ 162
6-56 McBSP as SPI Master or Slave Timing Requirements (CLKSTP = 11b, CLKXP = 1) ................................ 163
6-57 McBSP as SPI Master or Slave Switching Characteristics (CLKSTP = 11b, CLKXP = 1) ........................... 163
www.ti.com
8 List of Tables Copyright © 2009–2010, Texas Instruments Incorporated
TMS320C28346, TMS320C28345, TMS320C28344
TMS320C28343, TMS320C28342, TMS320C28341
www.ti.com
8-1 Thermal Model 179-Ball ZHH Results ....................................................................................... 165
8-2 Thermal Model 256-Ball ZFE Results ....................................................................................... 165
SPRS516B–MARCH 2009–REVISED JULY 2010
Copyright © 2009–2010, Texas Instruments Incorporated List of Tables 9
TMS320C28346, TMS320C28345, TMS320C28344
TMS320C28343, TMS320C28342, TMS320C28341
SPRS516B–MARCH 2009–REVISED JULY 2010
www.ti.com
10 List of Tables Copyright © 2009–2010, Texas Instruments Incorporated
TMS320C28346, TMS320C28345, TMS320C28344
TMS320C28343, TMS320C28342, TMS320C28341
www.ti.com
SPRS516B–MARCH 2009–REVISED JULY 2010
Delfino Microcontrollers
Check for Samples: TMS320C28346, TMS320C28345, TMS320C28344, TMS320C28343, TMS320C28342, TMS320C28341
1 TMS320C2834x ( Delfino™) MCUs
1.1 Overview
The TMS320C2834x (C2834x) Delfino™ microcontroller (MCU) devices build on TI's existing F2833x
high-performance floating-point microcontrollers. The C2834x delivers up to 300 MHz of floating-point
performance, and has up to 516KB of on-chip RAM. Designed for real-time control applications, the
C2834x is based on the C28x™ core, making it code-compatible with all C28x microcontrollers. The
on-chip peripherals and low-latency core make the C2834x an excellent solution for performance-hungry
real-time control applications.
1.2 Features
1234
• High-Performance Static CMOS Technology
– Up to 300 MHz (3.33-ns Cycle Time)
– 1.1-V/1.2-V Core, 3.3-V I/O , 1.8-V
PLL/Oscillator Design
• High-Performance 32-Bit CPU (TMS320C28x)
– IEEE-754 Single-Precision Floating-Point
Unit (FPU)
– 16 x 16 and 32 x 32 MAC Operations
– 16 x 16 Dual MAC
– Harvard Bus Architecture
– Fast Interrupt Response and Processing
– Code-Efficient (in C/C++ and Assembly)
• Six-Channel DMA Controller (for McBSP,
XINTF, and SARAM)
• 16-Bit or 32-Bit External Interface (XINTF)
– Over 2M x 16 Address Reach
• On-Chip Memory
– Up to 258K x 16 SARAM
– 8K x 16 Boot ROM
• Clock and System Control
– Dynamic PLL Ratio Changes Supported
– On-Chip Oscillator
– Watchdog Timer Module
• Peripheral Interrupt Expansion (PIE) Block That
Supports All 64 Peripheral Interrupts
• Enhanced Control Peripherals
– Eighteen Enhanced Pulse Width Modulator
(ePWM) Outputs
• Dedicated 16-Bit Time-Based Counter
With Period and Frequency Control
• Single-Edge, Dual-Edge Symmetric, or
Dual-Edge Asymmetric Outputs
• Dead-Band Generation
• PWM Chopping by High-Frequency
Carrier
• Trip Zone Input
• Up to 9 HRPWM Outputs With 55-ps MEP
Resolution at VDD= 1.1 V (65 ps at 1.2 V)
– Six 32-Bit Enhanced Capture (eCAP)
Modules
• Configurable as 3 Capture Inputs or
3 Auxiliary Pulse Width Modulator
Outputs
• Single-Shot Capture of up to Four Event
Time-Stamps
– Three 32-Bit Quadrature Encoder Pulse
(QEP) Modules
– Six 32-Bit Timers/Nine 16-Bit Timers
• Three 32-Bit CPU Timers
• Serial Port Peripherals
– Up to 2 CAN Modules
– Up to 3 SCI (UART) Modules
– Up to 2 McBSP Modules (Configurable as
SPI)
– Up to 2 SPI Module s
– One Inter-Integrated-Circuit (I2C) Bus
• External ADC Interface
• Up to 88 Individually Programmable,
Multiplexed GPIO Pins With Input Filtering
• Advanced Emulation Features
– Analysis and Breakpoint Functions
– Real-Time Debug via Hardware
1
Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of Texas
Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.
2Delfino, MicroStar BGA, C28x, TMS320C54x, TMS320C55x, Code Composer Studio, TMS320C28x are trademarks of Texas Instruments.
31-Wire is a registered trademark of Maxim Integrated Products, Inc.
4All other trademarks are the property of their respective owners.
PRODUCTION DATA information is current as of publication date.
Products conform to specifications per the terms of the Texas
Instruments standard warranty. Production processing does not
necessarily include testing of all parameters.
Copyright © 2009–2010, Texas Instruments Incorporated
TMS320C28346, TMS320C28345, TMS320C28344
TMS320C28343, TMS320C28342, TMS320C28341
SPRS516B–MARCH 2009–REVISED JULY 2010
• 2834x Package Options: • Community Resources
– MicroStar BGA™ (ZHH) – TI E2E Community
– Plastic BGA (ZFE) – TI Embedded Processors Wiki
1.3 Getting Started
This section gives a brief overview of the steps to take when first developing for a C28x device. For more
detail on each of these steps, see the following:
• Getting Started With TMS320C28x Digital Signal Controllers (literature number SPRAAM0).
• C2000 Getting Started Website (http://www.ti.com/c2000getstarted)
• TMS320F28x Development and Experimenter's Kits (http://www.ti.com/f28xkits)
www.ti.com
12 TMS320C2834x ( Delfino™) MCUs Copyright © 2009–2010, Texas Instruments Incorporated
Submit Documentation Feedback
Product Folder Link(s): TMS320C28346, TMS320C28345, TMS320C28344 TMS320C28343, TMS320C28342,
TMS320C28341
TMS320C28346, TMS320C28345, TMS320C28344
TMS320C28343, TMS320C28342, TMS320C28341
www.ti.com
2 Introduction
The TMS320C28346, TMS320C28345, TMS320C28344, TMS320C28343, TMS320C28342, and
TMS320C28341 devices, members of the Delfino™ MCU generation, are highly integrated,
high-performance solutions for demanding control applications.
Throughout this document, the devices are abbreviated as C28346, C28345, C28344, C28343, C28342,
and C28341, respectively. Table 2-1 provides a summary of features for each device.
SPRS516B–MARCH 2009–REVISED JULY 2010
Copyright © 2009–2010, Texas Instruments Incorporated Introduction 13
Submit Documentation Feedback
Product Folder Link(s): TMS320C28346, TMS320C28345, TMS320C28344 TMS320C28343, TMS320C28342,
TMS320C28341
TMS320C28346, TMS320C28345, TMS320C28344
TMS320C28343, TMS320C28342, TMS320C28341
SPRS516B–MARCH 2009–REVISED JULY 2010
www.ti.com
Table 2-1. C2834x Hardware Features
FEATURE TYPE
Package Type –
Instruction cycle – 3.33 ns 5 ns 3.33 ns 5 ns 3.33 ns 5 ns
Floating-point unit – Yes Yes Yes Yes Yes Yes
Single-access RAM (SARAM) (16-bit word) – 258K 258K 130K 130K 98K 98K
Code security for on-chip SARAM blocks – No
Boot ROM (8K x 16) – Yes Yes Yes Yes Yes Yes
16-/32-bit External Interface (XINTF) 1 Yes Yes Yes Yes Yes Yes
6-channel Direct Memory Access (DMA) 0 Yes Yes Yes Yes Yes Yes
PWM outputs 0
HRPWM channels 0 3A/4A/5A/6A/ 3A/4A/5A/6A/ 3A/4A/5A/6A/ 3A/4A/5A/6A/
32-bit Capture inputs or auxiliary PWM outputs 0 6 6 6 6 4 4
32-bit QEP channels (four inputs/channel) 0 3 3 3 3 2 2
Watchdog timer – Yes Yes Yes Yes Yes Yes
External ADC Interface – Yes Yes Yes Yes Yes Yes
32-bit CPU timers – 3 3 3 3 3 3
Multichannel Buffered Serial Port (McBSP)/SPI 1 2 2 2 2 1 1
Serial Peripheral Interface (SPI) 0 2 2 2 2 2 2
Serial Communications Interface (SCI) 0 3 3 3 3 3 3
Enhanced Controller Area Network (eCAN) 0 2 2 2 2 2 2
Inter-Integrated Circuit (I2C) 0 1 1 1 1 1 1
General-Purpose Input/Output (GPIO) pins
(shared)
External interrupts – 8 8 8 8 8 8
(1)
– 88 88 88 88 88 88
(1) A type change represents a major functional feature difference in a peripheral module. Within a peripheral type, there may be minor differences between devices that do not affect the
basic functionality of the module. These device-specific differences are listed in the TMS320x28xx, 28xxx DSP Peripheral Reference Guide (literature number SPRU566) and in the
peripheral reference guides.
(2) TMX samples will come with the ZEP designator. The designator will change to ZFE after TMS.
(3) Custom secure versions of these devices are available. See Section 3.2.9, Security, for more details.
C28346 C28345 C28344 C28343 C28342 C28341
(300 MHz) (200 MHz) (300 MHz) (200 MHz) (300 MHz) (200 MHz)
256-Ball ZFE 256-Ball ZFE 179-Ball ZHH 256-Ball ZFE 256-Ball ZFE 179-Ball ZHH 256-Ball ZFE 256-Ball ZFE 179-Ball ZHH
(2)
PBGA
(3)
ePWM1/2/3/ ePWM1/2/3/ ePWM1/2/3/ ePWM1/2/3/ ePWM1/2/3/ ePWM1/2/3/
4/5/6/7/8/9 4/5/6/7/8/9 4/5/6/7/8/9 4/5/6/7/8/9 4/5/6 4/5/6
ePWM1A/2A/ ePWM1A/2A/ ePWM1A/2A/ ePWM1A/2A/
7A/8A/9A 7A/8A/9A 7A/8A/9A 7A/8A/9A
PBGA
(2)
BGA PBGA
(3)
No
(2)
(3)
No
PBGA
(2)
BGA PBGA
(3)
No
(2)
(3)
No
ePWM1A/2A/ ePWM1A/2A/
3A/4A/5A/6A 3A/4A/5A/6A
PBGA
(2)
(3)
No
BGA
14 Introduction Copyright © 2009–2010, Texas Instruments Incorporated
Submit Documentation Feedback
Product Folder Link(s): TMS320C28346, TMS320C28345, TMS320C28344 TMS320C28343, TMS320C28342,
TMS320C28341
TMS320C28346, TMS320C28345, TMS320C28344
TMS320C28343, TMS320C28342, TMS320C28341
www.ti.com
SPRS516B–MARCH 2009–REVISED JULY 2010
Table 2-1. C2834x Hardware Features (continued)
FEATURE TYPE
T: –40°C to 105°C – ZFE ZFE ZHH ZFE ZFE ZHH ZFE ZFE ZHH
Temperature S: –40°C to 125°C – ZFE ZFE – ZFE ZFE – ZFE ZFE –
options
Product status
Q: –40°C to 125°C
(Q100 qualification)
(1)
(1)
– ZFE ZFE – ZFE ZFE – ZFE ZFE –
– TMS TMS TMS TMS TMS TMS
(1) See Section 5.1 for descriptions of device stages.
C28346 C28345 C28344 C28343 C28342 C28341
(300 MHz) (200 MHz) (300 MHz) (200 MHz) (300 MHz) (200 MHz)
Copyright © 2009–2010, Texas Instruments Incorporated Introduction 15
Submit Documentation Feedback
Product Folder Link(s): TMS320C28346, TMS320C28345, TMS320C28344 TMS320C28343, TMS320C28342,
TMS320C28341
EXTSOC3B
GPIO19/
/
SCIRXDB/
CANTXA
SPISTEA
GPIO23/
EQEP1I/
MFSXA/
SCIRXDB
GPIO24/
ECAP1/
EQEP2A/
MDXB
EXTSOC1A
EXTSOC2A EXTSOC1B
GPIO21/
EQEP1B/
MDRA/
CANRXB
GPIO20/
EQEP1A/
MDXA/
CANTXB
P P
N N
M M
L L
GPIO18/
SPICLKA/
SCITXDB/
CANRXA
TDI
GPIO16/
SPISIMOA/
CANTXB/
TZ5
GPIO12/
/
CANTXB/
MDXB
TZ1
EXTSOC3A
K K
J J
H H
1 2 3 4 5
6 7
TDO
V
SS
1 2
3
4
5 6
7
EXTSOC2B
TRST
GPIO17/
SPISOMIA/
CANRXB/
TZ6
GPIO13/
/
CANRXB/
MDRB
TZ2
GPIO15/
/ /
SCIRXDB/
MFSXB
TZ4XHOLDA
GPIO25/
ECAP2/
EQEP2B/
MDRB
GPIO22/
EQEP1S/
MCLKXA/
SCITXDB
EXTADCCLK
V
DD
V
SS
V
SS
V
DDIO
V
DDIO
V
SS
GPIO11/
EPWM6B/
SCIRXDB/
ECAP4
V
DD
V
DD
V
DD
V
SS
V
DDIO
GPIO14/
/ /
SCITXDB/
MCLKXB
TZ3XHOLD
V
DD
V
DD
V
SS
V
DDIO
GPIO26/
ECAP3/
EQEP2I/
MCLKXB
GPIO27/
ECAP4/
EQEP2S/
MFSXB
GPIO33/
SCLA/
EPWMSYNCO/
ADCSOCBO
GPIO32/
SDAA/
EPWMSYNCI/
ADCSOCAO
TMS320C28346, TMS320C28345, TMS320C28344
TMS320C28343, TMS320C28342, TMS320C28341
SPRS516B–MARCH 2009–REVISED JULY 2010
2.1 Pin Assignments
The 179-ball ZHH ball grid array (BGA) terminal assignments are shown in Figure 2-1 through Figure 2-4.
The 256-ball ZFE plastic ball grid array (PBGA) terminal assignments are shown in Figure 2-5 through
Figure 2-8. Table 2-2 describes the function(s) of each pin.
www.ti.com
Figure 2-1. C2834x 179-Ball ZHH MicroStar BGA™ Upper Left Quadrant (Bottom VIew)
16 Introduction Copyright © 2009–2010, Texas Instruments Incorporated
Product Folder Link(s): TMS320C28346, TMS320C28345, TMS320C28344 TMS320C28343, TMS320C28342,
Submit Documentation Feedback
TMS320C28341
GPIO49/
ECAP6/
XD30/
SPISOMID
V
DDIO
GPIO54/
SPISIMOA/
XD25/
EQEP3A
GPIO59/
MFSRA/
XD20/
EPWM7B
GPIO55/
SPISOMIA/
XD24/
EQEP3B
GPIO60/
MCLKRB/
XD19/
EPWM8A
V
SS
EMU1
GPIO /
MFSRB/
XD18/
EPWM8B
61
GPIO70/
XD9
TCK
V
DD
EMU0
8 9
10 11 12 13 14
PP
NN
MM
LL
KK
JJ
HH
GPIO63/
SCITXDC/
XD16/
EPWM9B
GPIO68/
XD11
V
SS
XRSIO
GPIO65/
XD14
V
SS
8 9 10
11 12
13
14
XRS
V
SS
TMS
V
DD
GPIO67/
XD12
GPIO66/
XD13
GPIO62/
SCIRXDC/
XD17/
EPWM9A
V
DD
GPIO57/
/
XD22/
EQEP3I
SPISTEA
GPIO50/
EQEP1A/
XD29/
SPICLKD
GPIO51/
EQEP1B/
XD28/
SPISTED
V
SS
V
DDIO
V
DD
V
SS
V
DD
GPIO64/
XD15
GPIO48/
ECAP5/
XD31/
SPISIMOD
GPIO52/
EQEP1S/
XD27
GPIO53/
EQEP1I/
XD26
GPIO56/
SPICLKA/
XD23/
EQEP3S
GPIO58/
MCLKRA/
XD21/
EPWM7A
V
DDIO
V
DDIO
V
DD
GPIO69/
XD10
TMS320C28346, TMS320C28345, TMS320C28344
TMS320C28343, TMS320C28342, TMS320C28341
www.ti.com
SPRS516B–MARCH 2009–REVISED JULY 2010
Figure 2-2. C2834x 179-Ball ZHH MicroStar BGA™ Upper Right Quadrant (Bottom View)
Copyright © 2009–2010, Texas Instruments Incorporated Introduction 17
Submit Documentation Feedback
Product Folder Link(s): TMS320C28346, TMS320C28345, TMS320C28344 TMS320C28343, TMS320C28342,
TMS320C28341
GPIO9/
EPWM5B/
SCITXDB/
ECAP3
GPIO10/
EPWM6A/
CANRXB/
ADCSOCBO
GPIO8/
EPWM5A/
CANTXB/
ADCSOCAO
V
SS
GPIO80/
XA8
GPIO7/
EPWM4B/
MCLKRA/
ECAP2
V
DD
GPIO4/
EPWM3A
GPIO5/
EPWM3B/
MFSRA/
ECAP1
GPIO3/
EPWM2B/
ECAP5/
MCLKRB
GPIO46/
XA6
V
DD
V
SS
V
DDIO
GPIO85/
XA13
GPIO84/
XA12
G
F
E
D
GPIO1/
EPWM1B/
ECAP6/
MFSRB
GPIO30/
CANRXA/
XA18
GPIO29/
SCITXDA/
XA19
V
DD
GPIO81/
XA9
GPIO0/
EPWM1A
GPIO31/
CANTXA/
XA17
GPIO87/
XA15
V
DDIO
GPIO83/
XA11
GPIO39/
XA16
GPIO86/
XA14
V
SS
C
B
A
1 2 3 4 5 6 7
G
F
E
D
C
B
A
V
DD18
V
DD
V
DDIO
V
DD
V
SS
V
SS
GPIO82/
XA10
1 2 3 4 5
6 7
V
SS
V
DD
V
DDIO
GPIO6/
EPWM4A/
EPWMSYNCI/
EPWMSYNCO
GPIO2/
EPWM2A
V
DD
GPIO47/
XA7
V
DDIO
TMS320C28346, TMS320C28345, TMS320C28344
TMS320C28343, TMS320C28342, TMS320C28341
SPRS516B–MARCH 2009–REVISED JULY 2010
www.ti.com
Figure 2-3. C2834x 179-Ball ZHH MicroStar BGA™ Lower Left Quadrant (Bottom View)
18 Introduction Copyright © 2009–2010, Texas Instruments Incorporated
Product Folder Link(s): TMS320C28346, TMS320C28345, TMS320C28344 TMS320C28343, TMS320C28342,
Submit Documentation Feedback
TMS320C28341
GPIO71/
XD8
GPIO72/
XD7
GPIO73/
XD6
GPIO35/
SCITXDA/
XR/W
GPIO34/
ECAP1
XREADY
GPIO75/
XD4
GPIO77/
XD2
V
SS
XCLKIN
GPIO41/
XA1
GPIO38/
XWE0
G
F
E
D
X1
GPIO36/
SCIRXDA/
XZCS0
GPIO40/
XA0
GPIO44/
XA4
GPIO78/
XD1
C
B
A
8 9 10 11 12 13 14
G
F
E
D
C
B
A
XCLKOUT
XRD
X2
V
SS
V
DDIO
8 9
10 11 12 13 14
V
DD18
V
DD
GPIO79/
XD0
V
DD
V
SS
V
SSK
V
DDIO
GPIO45/
XA5
GPIO42/
XA2
GPIO43/
XA3
V
DD
GPIO28/
SCIRXDA/
XZCS6
GPIO74/
XD5
XWE1
V
SS
GPIO76/
XD3
V
SS
V
DD
V
SS
V
DDIO
GPIO37/
ECAP2/
XZCS7
V
DD
V
SS
V
DDIO
TMS320C28346, TMS320C28345, TMS320C28344
TMS320C28343, TMS320C28342, TMS320C28341
www.ti.com
SPRS516B–MARCH 2009–REVISED JULY 2010
Figure 2-4. C2834x 179-Ball ZHH MicroStar BGA™ Lower Right Quadrant (Bottom View)
Copyright © 2009–2010, Texas Instruments Incorporated Introduction 19
Product Folder Link(s): TMS320C28346, TMS320C28345, TMS320C28344 TMS320C28343, TMS320C28342,
Submit Documentation Feedback
TMS320C28341
V
SS
1
T
V
SS
2
R
V
SS
V
DDIO
P
V
DD
3 4 5 6 7 8
V
SS
V
SS
N
V
SS
V
DDIO
V
DDIO
V
SS
M
V
DDIO
V
SS
V
DD
V
DD
V
DD
L
V
DDIO
V
DD
V
SS
V
SS
V
SS
K
V
SS
V
DD
V
SS
V
SS
V
SS
V
SS
J
V
DDIO
V
DD
V
SS
V
SS
V
SS
GPIO19/
/
SCIRXDB/
CANTXA
SPISTEA
GPIO33/
SCLA/
EPWMSYNCO/
ADCSOCBO
GPIO21/
EQEP1B/
MDRA/
CANRXB
GPIO23/
EQEP1I/
MFSXA/
SCIRXDB
GPIO22/
EQEP1S/
MCLKXA/
SCITXDB
GPIO20/
EQEP1A/
MDXA/
CANTXB
GPIO32/
SDAA/
EPWMSYNCI/
ADCSOCAO
GPIO27/
ECAP4/
EQEP2S/
MFSXB
GPIO26/
ECAP3/
EQEP2I/
MCLKXB
GPIO25/
ECAP2/
EQEP2B/
MDRB
GPIO24/
ECAP1/
EQEP2A/
MDXB
TDI
EXTSOC3A
EXTADCCLK
EXTSOC2B
TRST
EXTSOC3B
EXTSOC2A
TDO
GPIO17/
SPISOMIA/
CANRXB/
TZ6
GPIO15/
/ /
SCIRXDB/
MFSXB
TZ4XHOLDA
V
DDIO
GPIO14/
/ /
SCITXDB/
MCLKXB
TZ3XHOLD
GPIO13/
/
CANRXB/
MDRB
TZ2
GPIO16/
SPISIMOA/
CANTXB/
TZ5
GPIO18/
SPICLKA/
SCITXDB/
CANRXA
EXTSOC1A EXTSOC1B
V
DD
V
DDIO
V
SS
V
DD
TMS320C28346, TMS320C28345, TMS320C28344
TMS320C28343, TMS320C28342, TMS320C28341
SPRS516B–MARCH 2009–REVISED JULY 2010
www.ti.com
Figure 2-5. C2834x 256-Ball ZFE Plastic BGA Upper Left Quadrant (Bottom View)
Submit Documentation Feedback
20 Introduction Copyright © 2009–2010, Texas Instruments Incorporated
Product Folder Link(s): TMS320C28346, TMS320C28345, TMS320C28344 TMS320C28343, TMS320C28342,
TMS320C28341
V
DDIO
9
T
V
SS
10
R
P
11 12
GPIO58/
MCLKRA/
XD21/
EPWM7A
13 14 15 16
GPIO64/
XD15
GPIO59/
MFSRA/
XD20/
EPWM7B
GPIO57/
/
XD22/
EQEP3I
SPISTEA
GPIO56/
SPICLKA/
XD23/
EQEP3S
N
V
SS
V
SS
V
DDIO
V
DDIO
M
V
SS
L
V
DD
V
DDIO
TCK
K
V
SS
J
GPIO63/
SCITXDC/
XD16/
EPWM9B
GPIO60/
MCLKRB/
XD19/
EPWM8A
V
DD
V
SS
V
SS
GPIO68/
XD11
GPIO66/
XD13
GPIO61/
MFSRB/
XD18/
EPWM8B
V
SS
V
SS
GPIO65/
XD14
GPIO69/
XD10
GPIO67/
XD12
GPIO62/
SCIRXDC/
XD17/
EPWM9A
V
DDIO
V
SS
V
SS
V
DDIO
GPIO53/
EQEP1I/
XD26
GPIO55/
SPISOMIA/
XD24/
EQEP3B
GPIO54/
SPISIMOA/
XD25/
EQEP3A
V
DD
V
DD
V
DD
V
DDIO
GPIO50/
EQEP1A/
XD29/
SPICLKD
GPIO52/
EQEP1S/
XD27
GPIO51/
EQEP1B/
XD28/
SPISTED
V
SS
V
SS
V
SS
GPIO49/
ECAP6/
XD30/
SPISOMID
GPIO48/
ECAP5/
XD31/
SPISIMOD
V
SS
V
SS
V
DD
V
SS
XRS
EMU0
EMU1
V
SS
V
SS
V
SS
V
DD
V
SS
TMS
V
DDIO
XRSIO
TMS320C28346, TMS320C28345, TMS320C28344
TMS320C28343, TMS320C28342, TMS320C28341
www.ti.com
SPRS516B–MARCH 2009–REVISED JULY 2010
Figure 2-6. C2834x 256-Ball ZFE Plastic BGA Upper Right Quadrant (Bottom View)
Copyright © 2009–2010, Texas Instruments Incorporated Introduction 21
Submit Documentation Feedback
Product Folder Link(s): TMS320C28346, TMS320C28345, TMS320C28344 TMS320C28343, TMS320C28342,
TMS320C28341
V
SSK
1
H
2
X1
G
V
DD18
F
3 4 5 6 7 8
GPIO81/
XA9
GPIO82/
XA10
E
GPIO84/
XA12
GPIO85/
XA13
D
GPIO39/
XA16
C
V
DDIO
GPIO31/
CANTXA/
XA17
B
V
SS
GPIO30/
CANRXA/
XA18
A
V
DD
GPIO46/
XA6
GPIO47/
XA7
V
DDIO
V
DD
V
SS
V
SS
V
SS
GPIO80/
XA8
V
SS
V
DD
V
SS
V
SS
V
SS
GPIO83/
XA11
V
DDIO
V
DD
V
SS
V
SS
V
SS
GPIO86/
XA14
V
DDIO
V
SS
V
DD
V
DD
V
DD
GPIO87/
XA15
V
SS
V
SS
V
DDIO
V
DDIO
V
SS
V
SS
V
SS
V
SS
GPIO6/
EPWM4A/
EPWMSYNCI/
EPWMSYNCO
GPIO3/
EPWM2B/
ECAP5/
MCLKRB
GPIO12/
/
CANTXB/
MDXB
TZ1
GPIO9/
EPWM5B/
SCITXDB/
ECAP3
V
SS
GPIO0/
EPWM1A
GPIO2/
EPWM2A
GPIO5/
EPWM3B/
MFSRA/
ECAP1
GPIO8/
EPWM5A/
CANTXB/
ADCSOCAO
GPIO11/
EPWM6B/
SCIRXDB/
ECAP4
V
SS
V
SS
GPIO29/
SCITXDA/
XA19
GPIO1/
EPWM1B/
ECAP6/
MFSRB
GPIO4/
EPWM3A
GPIO7/
EPWM4B/
MCLKRA/
ECAP2
GPIO10/
EPWM6A/
CANRXB/
ADCSOCBO
TMS320C28346, TMS320C28345, TMS320C28344
TMS320C28343, TMS320C28342, TMS320C28341
SPRS516B–MARCH 2009–REVISED JULY 2010
www.ti.com
Figure 2-7. C2834x 256-Ball ZFE Plastic BGA Lower Left Quadrant (Bottom View)
22 Introduction Copyright © 2009–2010, Texas Instruments Incorporated
Product Folder Link(s): TMS320C28346, TMS320C28345, TMS320C28344 TMS320C28343, TMS320C28342,
Submit Documentation Feedback
TMS320C28341
9
H
V
SS
10
G
F
11 12 13 14 15 16
E
C
B
A
D
V
SS
V
SS
V
SS
V
DD
V
SS
V
SS
V
SS
V
DD
V
SS
V
SS
V
SS
V
SS
V
DD
V
DDIO
V
DD
V
DD
V
DD
V
SS
V
DDIO
V
DD18
V
SS
V
DDIO
V
DDIO
V
SS
V
SS
V
DD
V
SS
V
DDIO
V
SS
V
SS
V
DDIO
V
SS
V
SS
GPIO36/
SCIRXDA/
XZCS0
V
SS
GPIO38/
XWE0
V
SS
XRD
GPIO77/
XD2
GPIO74/
XD5
GPIO71/
XD8
GPIO34/
ECAP1/
XREADY
GPIO78/
XD1
GPIO75/
XD4
GPIO72/
XD7
GPIO28/
SCIRXDA/
XZCS6
GPIO37/
ECAP2/
XZCS7
GPIO41/
XA1
GPIO43/
XA3
GPIO35/
SCITXDA/
XR/W
X2
XCLKIN
GPIO40/
XA0
GPIO42/
XA2
GPIO44/
XA4
GPIO45/
XA5
XCLKOUT
GPIO79/
XD0
GPIO76/
XD3
GPIO73/
XD6
GPIO70/
XD9
XWE1
V
SS
TMS320C28346, TMS320C28345, TMS320C28344
TMS320C28343, TMS320C28342, TMS320C28341
www.ti.com
SPRS516B–MARCH 2009–REVISED JULY 2010
Figure 2-8. C2834x 256-Ball ZFE Plastic BGA Lower Right Quadrant (Bottom View)
Copyright © 2009–2010, Texas Instruments Incorporated Introduction 23
Product Folder Link(s): TMS320C28346, TMS320C28345, TMS320C28344 TMS320C28343, TMS320C28342,
Submit Documentation Feedback
TMS320C28341
TMS320C28346, TMS320C28345, TMS320C28344
TMS320C28343, TMS320C28342, TMS320C28341
SPRS516B–MARCH 2009–REVISED JULY 2010
2.2 Signal Descriptions
Table 2-2 describes the signals. The GPIO function (shown in Italics) is the default at reset. The peripheral
signals that are listed under them are alternate functions. Some peripheral functions may not be available
in all devices. See Table 2-1 for details. Inputs are not 5-V tolerant. All XINTF pins have a drive strength
of 4 mA (typical). All GPIO pins are I/O/Z, 4-mA drive typical and have an internal pullup, which can be
selectively enabled/disabled on a per-pin basis. This feature only applies to the GPIO pins. The pullups on
GPIO0–GPIO11 and GPIO58–GPIO63 pins are not enabled at reset. The pullups on GPIO12–GPIO57
and GPIO64–GPIO87 are enabled upon reset.
Table 2-2. Signal Descriptions
NAME DESCRIPTION
TRST
TCK
TMS
TDI
TDO
EMU0
EMU1
XCLKOUT
XCLKIN the X1 pin must be tied to V
X1
X2
ZHH ZFE
BALL # BALL #
JTAG
M7 R8 JTAG test reset with internal pulldown. TRST, when driven high, gives the scan system control of
P9 T11 JTAG test clock. An external pullup resistor is required on this pin. A 2.2-kΩ resistor generally offers
M8 P9 JTAG test-mode select (TMS) with internal pullup. This serial control input is clocked into the TAP
L6 T8 JTAG test data input (TDI) with internal pullup. TDI is clocked into the selected register (instruction
N7 P8 JTAG scan out, test data output (TDO). The contents of the selected register (instruction or data)
N9 P10 Emulator pin 0. When TRST is driven high, this pin is used as an interrupt to or from the emulator
L9 R10 Emulator pin 1. When TRST is driven high, this pin is used as an interrupt to or from the emulator
B14 D16 Output clock derived from SYSCLKOUT. XCLKOUT is either the same frequency, one-half the
D9 A12 External Oscillator Input. This pin is to feed a clock from an external 3.3-V oscillator. In this case,
C8 A7 Internal/External Oscillator Input. To use the internal oscillator, a quartz crystal may be connected
A8 A9 Internal Oscillator Output. A quartz crystal may be connected across X1 and X2. If X2 is not used it
the operations of the device. If this signal is not connected or driven low, the device operates in its
functional mode, and the test reset signals are ignored.
NOTE: TRST is an active high test pin and must be maintained low at all times during normal
device operation. An external pulldown resistor is recommended on this pin. The value of this
resistor should be based on drive strength of the debugger pods applicable to the design. A 2.2-kΩ
resistor generally offers adequate protection. Since this is application-specific, it is recommended
that each target board be validated for proper operation of the debugger and the application. (I, ↓)
adequate protection.(I)
controller on the rising edge of TCK. (I, ↑)
or data) on a rising edge of TCK. (I, ↑)
are shifted out of TDO on the falling edge of TCK.
system and is defined as input/output through the JTAG scan. This pin is also used to put the
device into boundary-scan mode. With the EMU0 pin at a logic-high state and the EMU1 pin at a
logic-low state, a rising edge on the TRST pin would latch the device into boundary-scan mode.
NOTE: An external pullup resistor is recommended on this pin. The value of this resistor should be
based on the drive strength of the debugger pods applicable to the design. A 2.2-kΩ to 4.7-kΩ
resistor is generally adequate. Since this is application-specific, it is recommended that each target
board be validated for proper operation of the debugger and the application.
system and is defined as input/output through the JTAG scan. This pin is also used to put the
device into boundary-scan mode. With the EMU0 pin at a logic-high state and the EMU1 pin at a
logic-low state, a rising edge on the TRST pin would latch the device into boundary-scan mode.
NOTE: An external pullup resistor is recommended on this pin. The value of this resistor should be
based on the drive strength of the debugger pods applicable to the design. A 2.2-kΩ to 4.7-kΩ
resistor is generally adequate. Since this is application-specific, it is recommended that each target
board be validated for proper operation of the debugger and the application.
Clock
frequency, one-fourth the frequency, or one-eighth the frequency of SYSCLKOUT. This is controlled
by bit 19 (BY4CLKMODE), bits 18:16 (XTIMCLK), and bit 2 (CLKMODE) in the XINTCNF2 register.
At reset, XCLKOUT = SYSCLKOUT/8. The XCLKOUT signal can be turned off by setting
XINTCNF2[CLKOFF] to 1. Unlike other GPIO pins, the XCLKOUT pin is not placed in
high-impedance state during a reset.
. If a crystal/resonator is used (or if an external 1.8-V oscillator is
used to feed clock to X1 pin), this pin must be tied to VSS. (I)
across X1 and X2. The X1 pin is referenced to the 1.8-V core digital power supply. A 1.8-V external
oscillator may be connected to the X1 pin. In this case, the XCLKIN pin must be connected to VSS.
If a 3.3-V external oscillator is used with the XCLKIN pin, X1 must be tied to V
must be left unconnected. (O)
SSK
SSK
www.ti.com
. (I)
24 Introduction Copyright © 2009–2010, Texas Instruments Incorporated
Submit Documentation Feedback
Product Folder Link(s): TMS320C28346, TMS320C28345, TMS320C28344 TMS320C28343, TMS320C28342,
TMS320C28341
TMS320C28346, TMS320C28345, TMS320C28344
TMS320C28343, TMS320C28342, TMS320C28341
www.ti.com
SPRS516B–MARCH 2009–REVISED JULY 2010
Table 2-2. Signal Descriptions (continued)
NAME DESCRIPTION
XRS P8 T10
XRSIO N8 T9 low (reset), the level detected on this pin puts all output buffers on the device in high-impedance
EXTSOC1A N1 M2 External ADC SOC Group 1 A Output. Trigger for external ADC, this signal is logical OR of
EXTSOC1B M3 M3 External ADC SOC Group 1 B Output. Trigger for external ADC, this signal is logical OR of
EXTSOC2A M2 N1 External ADC SOC Group 2 A Output. Trigger for external ADC, this signal is logical OR of
EXTSOC2B P1 N2 External ADC SOC Group 2 B Output. Trigger for external ADC, this signal is logical OR of
EXTSOC3A N2 N3 External ADC SOC Group 3 A Output. Trigger for external ADC, this signal is logical OR of
EXTSOC3B P2 P2 External ADC SOC Group3 B Output. Trigger for external ADC, this signal is logical OR of
EXTADCCLK N3 R3 External ADC Clock Signal. Clock for external ADC support, derived from SYSCLK (O)
GPIO0 General purpose input/output 0 (I/O/Z)
EPWM1A Enhanced PWM1 Output A and HRPWM channel (O)
- -
- GPIO1 General purpose input/output 1 (I/O/Z)
EPWM1B Enhanced PWM1 Output B (O)
ECAP6 Enhanced Capture 6 input/output (I/O)
MFSRB McBSP-B receive frame synch (I/O)
GPIO2 General purpose input/output 2 (I/O/Z)
EPWM2A Enhanced PWM2 Output A and HRPWM channel (O)
- -
- GPIO3 General purpose input/output 3 (I/O/Z)
EPWM2B Enhanced PWM2 Output B (O)
ECAP5 Enhanced Capture 5 input/output (I/O)
MCLKRB McBSP-B receive clock (I/O)
GPIO4 General purpose input/output 4 (I/O/Z)
EPWM3A Enhanced PWM3 output A and HRPWM channel (O)
- -
- GPIO5 General purpose input/output 5 (I/O/Z)
EPWM3B Enhanced PWM3 output B (O)
MFSRA McBSP-A receive frame synch (I/O)
ECAP1 Enhanced Capture input/output 1 (I/O)
GPIO6 General purpose input/output 6 (I/O/Z)
EPWM4A Enhanced PWM4 output A and HRPWM channel (O)
EPWMSYNCI External ePWM sync pulse input (I)
EPWMSYNCO External ePWM sync pulse output (O)
GPIO7 General purpose input/output 7 (I/O/Z)
EPWM4B Enhanced PWM4 output B (O)
MCLKRA McBSP-A receive clock (I/O)
ECAP2 Enhanced capture input/output 2 (I/O)
ZHH ZFE
BALL # BALL #
Reset
Device Reset (in) and Watchdog Reset (out).
Device reset. XRS causes the device to terminate execution. The PC will point to the address
contained at the location 0x3FFFC0. When XRS is brought to a high level, execution begins at the
location pointed to by the PC. This pin is driven low by the MCU when a watchdog reset occurs.
During watchdog reset, the XRS pin is driven low for the watchdog reset duration of 512 OSCCLK
cycles. (I/OD, ↑)
The output buffer of this pin is an open-drain with an internal pullup. It is recommended that this pin
be driven by an open-drain device.
XRS I/O Control (I) - This pin must be connected to the XRS pin on the target board. When XRS is
mode.
External ADC Interface Signals
ePWM1/2/3 SOCA internal signals (O)
ePWM1/2/3 SOCB internal signals (O)
ePWM4/5/6 SOCA internal signals (O)
ePWM4/5/6 SOCB internal signals (O)
ePWM7/8/9 SOCA internal signals (O)
ePWM7/8/9 SOCB internal signals (O)
GPIO and Peripheral Signals
B1 D2
C1 E1
F5 E2
E4 E3
E2 F1
E3 F2
F3 F3
F2 G1
Copyright © 2009–2010, Texas Instruments Incorporated Introduction 25
Submit Documentation Feedback
Product Folder Link(s): TMS320C28346, TMS320C28345, TMS320C28344 TMS320C28343, TMS320C28342,
TMS320C28341
TMS320C28346, TMS320C28345, TMS320C28344
TMS320C28343, TMS320C28342, TMS320C28341
SPRS516B–MARCH 2009–REVISED JULY 2010
www.ti.com
Table 2-2. Signal Descriptions (continued)
NAME DESCRIPTION
GPIO8 General Purpose Input/Output 8 (I/O/Z)
EPWM5A Enhanced PWM5 output A and HRPWM channel (O)
CANTXB Enhanced CAN-B transmit (O)
ADCSOCAO ADC start-of-conversion A (O)
GPIO9 General purpose input/output 9 (I/O/Z)
EPWM5B Enhanced PWM5 output B (O)
SCITXDB SCI-B transmit data(O)
ECAP3 Enhanced capture input/output 3 (I/O)
GPIO10 General purpose input/output 10 (I/O/Z)
EPWM6A Enhanced PWM6 output A and HRPWM channel (O)
CANRXB Enhanced CAN-B receive (I)
ADCSOCBO ADC start-of-conversion B (O)
GPIO11 General purpose input/output 11 (I/O/Z)
EPWM6B Enhanced PWM6 output B (O)
SCIRXDB SCI-B receive data (I)
ECAP4 Enhanced CAP Input/Output 4 (I/O)
GPIO12 General purpose input/output 12 (I/O/Z)
TZ1 Trip Zone input 1 (I)
CANTXB Enhanced CAN-B transmit (O)
MDXB McBSP-B transmit serial data (O)
GPIO13 General purpose input/output 13 (I/O/Z)
TZ2 Trip Zone input 2 (I)
CANRXB Enhanced CAN-B receive (I)
MDRB McBSP-B receive serial data (I)
GPIO14 General purpose input/output 14 (I/O/Z)
TZ3/XHOLD XINTCNF2[HOLD] = 1. If this is not done, the XINTF bus will go into high impedance anytime TZ3
SCITXDB SCI-B Transmit (O)
MCLKXB McBSP-B transmit clock (I/O)
GPIO15 General purpose input/output 15 (I/O/Z)
TZ4/XHOLDA
SCIRXDB SCI-B receive (I)
MFSXB McBSP-B transmit frame synch (I/O)
GPIO16 General purpose input/output 16 (I/O/Z)
SPISIMOA SPI slave in, master out (I/O)
CANTXB Enhanced CAN-B transmit (O)
TZ5 Trip Zone input 5 (I)
GPIO17 General purpose input/output 17 (I/O/Z)
SPISOMIA SPI-A slave out, master in (I/O)
CANRXB Enhanced CAN-B receive (I)
TZ6 Trip zone input 6 (I)
GPIO18 General purpose input/output 18 (I/O/Z)
SPICLKA SPI-A clock input/output (I/O)
SCITXDB SCI-B transmit (O)
CANRXA Enhanced CAN-A receive (I)
GPIO19 General purpose input/output 19 (I/O/Z)
SPISTEA SPI-A slave transmit enable input/output (I/O)
SCIRXDB SCI-B receive (I)
CANTXA Enhanced CAN-A transmit (O)
ZHH ZFE
BALL # BALL #
G4 G2
G2 G3
G3 H1
H3 H2
H2 H3
H4 J2
Trip Zone input 3/External Hold Request. XHOLD, when active (low), requests the external interface
(XINTF) to release the external bus and place all buses and strobes into a high-impedance state. To
prevent this from happening when TZ3 signal goes active, disable this function by writing
H5 J3
K2 K2 active (low) when the XINTF has granted an XHOLD request. All XINTF buses and strobe signals
K4 L1
J5 L2
L1 M1
P3 T4
goes low. On the ePWM side, TZn signals are ignored by default, unless they are enabled by the
code. The XINTF will release the bus when any current access is complete and there are no
pending accesses on the XINTF. (I)
Trip Zone input 4/External Hold Acknowledge. The pin function for this option is based on the
direction chosen in the GPADIR register. If the pin is configured as an input, then TZ4 function is
chosen. If the pin is configured as an output, then XHOLDA function is chosen. XHOLDA is driven
will be in a high-impedance state. XHOLDA is released when the XHOLD signal is released.
External devices should only drive the external bus when XHOLDA is active (low). (I/O)
26 Introduction Copyright © 2009–2010, Texas Instruments Incorporated
Submit Documentation Feedback
Product Folder Link(s): TMS320C28346, TMS320C28345, TMS320C28344 TMS320C28343, TMS320C28342,
TMS320C28341
TMS320C28346, TMS320C28345, TMS320C28344
TMS320C28343, TMS320C28342, TMS320C28341
www.ti.com
Table 2-2. Signal Descriptions (continued)
NAME DESCRIPTION
GPIO20 General purpose input/output 20 (I/O/Z)
EQEP1A Enhanced QEP1 input A (I)
MDXA McBSP-A transmit serial data (O)
CANTXB Enhanced CAN-B transmit (O)
GPIO21 General purpose input/output 21 (I/O/Z)
EQEP1B Enhanced QEP1 input B (I)
MDRA McBSP-A receive serial data (I)
CANRXB Enhanced CAN-B receive (I)
GPIO22 General purpose input/output 22 (I/O/Z)
EQEP1S Enhanced QEP1 strobe (I/O)
MCLKXA McBSP-A transmit clock (I/O)
SCITXDB SCI-B transmit (O)
GPIO23 General purpose input/output 23 (I/O/Z)
EQEP1I Enhanced QEP1 index (I/O)
MFSXA McBSP-A transmit frame synch (I/O)
SCIRXDB SCI-B receive (I)
GPIO24 General purpose input/output 24 (I/O/Z)
ECAP1 Enhanced capture 1 (I/O)
EQEP2A Enhanced QEP2 input A (I)
MDXB McBSP-B transmit serial data (O)
GPIO25 General purpose input/output 25 (I/O/Z)
ECAP2 Enhanced capture 2 (I/O)
EQEP2B Enhanced QEP2 input B (I)
MDRB McBSP-B receive serial data (I)
GPIO26 General purpose input/output 26 (I/O/Z)
ECAP3 Enhanced capture 3 (I/O)
EQEP2I Enhanced QEP2 index (I/O)
MCLKXB McBSP-B transmit clock (I/O)
GPIO27 General purpose input/output 27 (I/O/Z)
ECAP4 Enhanced capture 4 (I/O)
EQEP2S Enhanced QEP2 strobe (I/O)
MFSXB McBSP-B transmit frame synch (I/O)
GPIO28 General purpose input/output 28 (I/O/Z)
SCIRXDA A12 B13 SCI receive data (I)
XZCS6 External Interface zone 6 chip select (O)
GPIO29 General purpose input/output 29. (I/O/Z)
SCITXDA C3 D1 SCI transmit data (O)
XA19 External Interface Address Line 19 (O)
GPIO30 General purpose input/output 30 (I/O/Z)
CANRXA C2 C2 Enhanced CAN-A receive (I)
XA18 External Interface Address Line 18 (O)
GPIO31 General purpose input/output 31 (I/O/Z)
CANTXA B2 B3 Enhanced CAN-A transmit (O)
XA17 External Interface Address Line 17 (O)
GPIO32 General purpose input/output 32 (I/O/Z)
SDAA I2C data open-drain bidirectional port (I/OD)
EPWMSYNCI Enhanced PWM external sync pulse input (I)
ADCSOCAO ADC start-of-conversion A (O)
GPIO33 General-Purpose Input/Output 33 (I/O/Z)
SCLA I2C clock open-drain bidirectional port (I/OD)
EPWMSYNCO Enhanced PWM external synch pulse output (O)
ADCSOCBO ADC start-of-conversion B (O)
GPIO34 General-Purpose Input/Output 34 (I/O/Z)
ECAP1 A13 B14 Enhanced Capture input/output 1 (I/O)
XREADY External Interface Ready signal
GPIO35 General-Purpose Input/Output 35 (I/O/Z)
SCITXDA B13 C15 SCI-A transmit data (O)
XR/W External Interface read, not write strobe
GPIO36 General-Purpose Input/Output 36 (I/O/Z)
SCIRXDA B12 A13 SCI-A receive data (I)
XZCS0 External Interface zone 0 chip select (O)
ZHH ZFE
BALL # BALL #
L4 R4
M4 T5
N4 R5
P4 P5
P5 T6
M5 R6
K6 P6
M6 T7
P6 R7
N6 P7
SPRS516B–MARCH 2009–REVISED JULY 2010
Copyright © 2009–2010, Texas Instruments Incorporated Introduction 27
Submit Documentation Feedback
Product Folder Link(s): TMS320C28346, TMS320C28345, TMS320C28344 TMS320C28343, TMS320C28342,
TMS320C28341
TMS320C28346, TMS320C28345, TMS320C28344
TMS320C28343, TMS320C28342, TMS320C28341
SPRS516B–MARCH 2009–REVISED JULY 2010
Table 2-2. Signal Descriptions (continued)
NAME DESCRIPTION
GPIO37 General-Purpose Input/Output 37 (I/O/Z)
ECAP2 D11 B12 Enhanced Capture input/output 2 (I/O)
XZCS7 External Interface zone 7 chip select (O)
GPIO38 General-Purpose Input/Output 38 (I/O/Z)
- C12 E15 XWE0 External Interface Write Enable 0 (O)
GPIO39 General-Purpose Input/Output 39 (I/O/Z)
- A2 B4 XA16 External Interface Address Line 16 (O)
GPIO40 General-Purpose Input/Output 40 (I/O/Z)
- E10 C12 XA0 External Interface Address Line 0
GPIO41 General-Purpose Input/Output 41 (I/O/Z)
- D10 B11 XA1 External Interface Address Line 1 (O)
GPIO42 General-Purpose Input/Output 42 (I/O/Z)
- B10 C11 XA2 External Interface Address Line 2 (O)
GPIO43 General-Purpose Input/Output 43 (I/O/Z)
- A10 B10 XA3 External Interface Address Line 3 (O)
GPIO44 General-Purpose Input/Output 44 (I/O/Z)
- A9 C10 XA4 External Interface Address Line 4 (O)
GPIO45 General-Purpose Input/Output 45 (I/O/Z)
- B9 C9 XA5 External Interface Address Line 5 (O)
GPIO46 General-Purpose Input/Output 46 (I/O/Z)
- E7 B8 XA6 External Interface Address Line 6 (O)
GPIO47 General-Purpose Input/Output 47 (I/O/Z)
- D6 C8 XA7 External Interface Address Line 7 (O)
GPIO48 General-Purpose Input/Output 48 (I/O/Z)
ECAP5 Enhanced Capture input/output 5 (I/O)
XD31 External Interface Data Line 31 (O)
SPISIMOD SPI-D slave in, master out (I/O)
GPIO49 General-Purpose Input/Output 49 (I/O/Z)
ECAP6 Enhanced Capture input/output 6 (I/O)
XD30 External Interface Data Line 30 (O)
SPISOMID SPI-D slave out, master in (I/O)
GPIO50 General-Purpose Input/Output 50 (I/O/Z)
EQEP1A Enhanced QEP 1input A (I)
XD29 External Interface Data Line 29 (O)
SPICLKD SPI-D Clock input/output (I/O)
GPIO51 General-Purpose Input/Output 51 (I/O/Z)
EQEP1B Enhanced QEP 1input B (I)
XD28 External Interface Data Line 28 (O)
SPISTED SPI-D slave transmit enable input/output (I/O)
GPIO52 General-Purpose Input/Output 52 (I/O/Z)
EQEP1S M11 P12 Enhanced QEP 1Strobe (I/O)
XD27 External Interface Data Line 27 (O)
GPIO53 General-Purpose Input/Output 53 (I/O/Z)
EQEP1I L11 T13 Enhanced QEP1 lndex (I/O)
XD26 External Interface Data Line 26 (O)
GPIO54 General-Purpose Input/Output 54 (I/O/Z)
SPISIMOA SPI-A slave in, master out (I/O)
XD25 External Interface Data Line 25 (O)
EQEP3A Enhanced QEP3 input A (I)
ZHH ZFE
BALL # BALL #
M10 R11
P10 P11
N10 T12
N11 R12
P12 R13
www.ti.com
28 Introduction Copyright © 2009–2010, Texas Instruments Incorporated
Submit Documentation Feedback
Product Folder Link(s): TMS320C28346, TMS320C28345, TMS320C28344 TMS320C28343, TMS320C28342,
TMS320C28341
TMS320C28346, TMS320C28345, TMS320C28344
TMS320C28343, TMS320C28342, TMS320C28341
www.ti.com
Table 2-2. Signal Descriptions (continued)
NAME DESCRIPTION
GPIO55 General-Purpose Input/Output 55 (I/O/Z)
SPISOMIA SPI-A slave out, master in (I/O)
XD24 External Interface Data Line 24 (O)
EQEP3B Enhanced QEP3 input B (I)
GPIO56 General-Purpose Input/Output 56 (I/O/Z)
SPICLKA SPI-A clock (I/O)
XD23 External Interface Data Line 23 (O)
EQEP3S Enhanced QEP3 strobe (I/O)
GPIO57 General-Purpose Input/Output 57 (I/O/Z)
SPISTEA SPI-A slave transmit enable (I/O)
XD22 External Interface Data Line 22 (O)
EQEP3I Enhanced QEP3 index (I/O)
GPIO58 General-Purpose Input/Output 58 (I/O/Z)
MCLKRA McBSP-A receive clock (I/O)
XD21 External Interface Data Line 21 (O)
EPWM7A Enhanced PWM 7 output A and HRPWM channel (O)
GPIO59 General-Purpose Input/Output 59 (I/O/Z)
MFSRA McBSP-A receive frame synch (I/O)
XD20 External Interface Data Line 20 (O)
EPWM7B Enhanced PWM 7 output B (O)
GPIO60 General-Purpose Input/Output 60 (I/O/Z)
MCLKRB McBSP-B receive clock (I/O)
XD19 External Interface Data Line 19 (O)
EPWM8A Enhanced PWM 8 output A and HRPWM channel (O)
GPIO61 General-Purpose Input/Output 61 (I/O/Z)
MFSRB McBSP-B receive frame synch (I/O)
XD18 External Interface Data Line 18 (O)
EPWM8B Enhanced PWM8 output B (O)
GPIO62 General-Purpose Input/Output 62 (I/O/Z)
SCIRXDC SCI-C receive data (I)
XD17 External Interface Data Line 17 (O)
EPWM9A Enhanced PWM9 output A and HRPWM channel (O)
GPIO63 General-Purpose Input/Output 63 (I/O/Z)
SCITXDC SCI-C transmit data (O)
XD16 External Interface Data Line 16 (O)
EPWM9B Enhanced PWM9 output B (O)
GPIO64 General-Purpose Input/Output 64 (I/O/Z)
- K12 L15 XD15 External Interface Data Line 15 (O)
GPIO65 General-Purpose Input/Output 65 (I/O/Z)
- K14 L14 XD14 External Interface Data Line 14 (O)
GPIO66 General-Purpose Input/Output 66 (I/O/Z)
- J11 K15 XD13 External Interface Data Line 13 (O)
GPIO67 General-Purpose Input/Output 67 (I/O/Z)
- J12 K14 XD12 External Interface Data Line 12 (O)
GPIO68 General-Purpose Input/Output 68 (I/O/Z)
- J13 J15 XD11 External Interface Data Line 11 (O)
GPIO69 General-Purpose Input/Output 69 (I/O/Z)
- H13 J14 XD10 External Interface Data Line 10 (O)
GPIO70 General-Purpose Input/Output 70 (I/O/Z)
- H12 H16 XD9 External Interface Data Line 9 (O)
GPIO71 General-Purpose Input/Output 71 (I/O/Z)
- G12 H15 XD8 External Interface Data Line 8 (O)
ZHH ZFE
BALL # BALL #
N12 P13
P13 R14
N13 P15
P14 N16
M13 N15
M14 M16
L12 M15
L13 M14
K13 L16
SPRS516B–MARCH 2009–REVISED JULY 2010
Copyright © 2009–2010, Texas Instruments Incorporated Introduction 29
Submit Documentation Feedback
Product Folder Link(s): TMS320C28346, TMS320C28345, TMS320C28344 TMS320C28343, TMS320C28342,
TMS320C28341
TMS320C28346, TMS320C28345, TMS320C28344
TMS320C28343, TMS320C28342, TMS320C28341
SPRS516B–MARCH 2009–REVISED JULY 2010
Table 2-2. Signal Descriptions (continued)
NAME DESCRIPTION
GPIO72 General-Purpose Input/Output 72 (I/O/Z)
- G13 H14 XD7 External Interface Data Line 7 (O)
GPIO73 General-Purpose Input/Output 73 (I/O/Z)
- F14 G16 XD6 External Interface Data Line 6 (O)
GPIO74 General-Purpose Input/Output 74 (I/O/Z)
- F13 G15 XD5 External Interface Data Line 5 (O)
GPIO75 General-Purpose Input/Output 75 (I/O/Z)
- F12 G14 XD4 External Interface Data Line 4 (O)
GPIO76 General-Purpose Input/Output 76 (I/O/Z)
- E13 F16 XD3 External Interface Data Line 3 (O)
GPIO77 General-Purpose Input/Output 77 (I/O/Z)
- E11 F15 XD2 External Interface Data Line 2 (O)
GPIO78 General-Purpose Input/Output 78 (I/O/Z)
- F10 F14 XD1 External Interface Data Line 1 (O)
GPIO79 General-Purpose Input/Output 79 (I/O/Z)
- C14 E16 XD0 External Interface Data Line 0 (O)
GPIO80 General-Purpose Input/Output 80 (I/O/Z)
- E6 B7 XA8 External Interface Address Line 8 (O)
GPIO81 General-Purpose Input/Output 81 (I/O/Z)
- C5 C7 XA9 External Interface Address Line 9 (O)
GPIO82 General-Purpose Input/Output 82 (I/O/Z)
- A5 B6 XA10 External Interface Address Line 10 (O)
GPIO83 General-Purpose Input/Output 83 (I/O/Z)
- B5 C6 XA11 External Interface Address Line 11 (O)
GPIO84 General-Purpose Input/Output 84 (I/O/Z)
- D5 A5 XA12 External Interface Address Line 12 (O)
GPIO85 General-Purpose Input/Output 85 (I/O/Z)
- D4 B5 XA13 External Interface Address Line 13 (O)
GPIO86 General-Purpose Input/Output 86 (I/O/Z)
- A3 C5 XA14 External Interface Address Line 14 (O)
GPIO87 General-Purpose Input/Output 87 (I/O/Z)
- B3 A4 XA15 External Interface Address Line 15 (O)
XRD A14 D15 External Interface Read Enable (O)
XWE1 C13 E14 External Memory Interface Write Enable for Upper 16-bits (O)
ZHH ZFE
BALL # BALL #
www.ti.com
30 Introduction Copyright © 2009–2010, Texas Instruments Incorporated
Submit Documentation Feedback
Product Folder Link(s): TMS320C28346, TMS320C28345, TMS320C28344 TMS320C28343, TMS320C28342,
TMS320C28341
