TI-Nspire™ Navigator™
Installation Guide
_____________________________________________
Write the System ID number here.
The number is printed inside the case for the CD.
Important Information
Texas Instruments makes no warranty, either express or implied,
including but not limited to any implied warranties of merchantability
and fitness for a particular purpose, regarding any programs or book
materials and makes such materials available solely on an "as-is" basis. In
no event shall Texas Instruments be liable to anyone for special,
collateral, incidental, or consequential damages in connection with or
arising out of the purchase or use of these materials, and the sole and
exclusive liability of Texas Instruments, regardless of the form of action,
shall not exceed the purchase price of this product. Moreover, Texas
Instruments shall not be liable for any claim of any kind whatsoever
against the use of these materials by any other party.
Copyright © 2006, 2008 Texas Instruments Incorporated.
Microsoft® and Windows® are trademarks of their owners.
Regulatory Information
USA FCC Information Concerning Radio Frequency
Interference
Product Name:
TI-Nspire™ Navigator™ Wireless
Cradle
Product Name:
TI-Navigator™ Access Point
Model Number/Name: NAV-AP-US
FCC ID: V7R-TINAVWC
FCC ID: V7R-TINAVAP
Federal Communication Commission Interference
Statement
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference
ii
will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: The TI-Navigator™ access point and the TI-Nspire™
Navigator™ wireless cradle comply with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) These devices
may not cause harmful interference, and (2) these devices must accept
any interference received, including interference that may cause
undesired operation.
RF Radiation Exposure and Hazard Statement:
To ensure compliance with FCC RF exposure requirements, the
TI-Navigator™ access point must be installed in a location such that the
antenna of the device will be greater than 20 cm (8 in.) away from all
persons. Using higher gain antennas and types of antennas not covered
under the FCC certification of this product is not allowed. Installers of the
radio and end users of the product must adhere to the installation
instructions provided in this manual.
This transmitter must not be co-located or operating in conjunction with
any other antenna or transmitter.
Non-modification Statement:
Use only the integral antenna supplied by the manufacturer when
operating these devices. Unauthorized antennas, modifications, or
attachments could damage the TI-Navigator™ access point or TI-Nspire™
Navigator™ wireless cradle and violate FCC regulations. Any changes or
modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate this equipment.
Deployment Statement:
This product is certified for indoor deployment only. Do not install or use
this product outdoors.
iii
Canadian IC Information
Product Name:
TI-Nspire™ Navigator™ Wireless
Cradle
Product Name:
TI-Navigator™ Access Point
Model Number/Name: NAV-AP-US
IC ID: 451E-TINAVWC
IC ID: 451E-TINAVAP
Industry Canada Statement:
Operation is subject to the following two conditions in Canada:
1. these devices may not cause interference, and
2. these devices must accept any interference, including interference
that may cause undesired operation of the device
To prevent radio interference to the licensed service (i.e. co-channel
Mobile Satellite systems) these devices areintended to be operated
indoors and away from windows to provide maximum shielding.
Equipment (or its transmit antenna) that is installed outdoors is subject
to licensing and not supported by the TI-Navigator™ access point or
TI-Nspire™ Navigator™ wireless cradle.
European Union and European Free Trade
Association (EFTA) Regulatory Compliance
This equipment may be operated in the countries that comprise the
member countries of the European Union and the European Free Trade
Association. These countries, listed in the following paragraph, are
referred to as The European Community throughout this document:
AUSTRIA, DENMARK, FINLAND, FRANCE, GERMANY, ITALY,
NETHERLANDS, PORTUGAL, SPAIN, SWEDEN, UNITED KINGDOM,
NORWAY, SWITZERLAND
The TI-Navigator™ access point communicates with either a TI-Navigator
network hub or TI-Nspire™ Navigator™ wireless cradle via a wireless
802.11b/g link to provide wireless local area networking (WLAN)
capabilities and with a personal computer using a standard USB cable.
The TI-Navigator access point includes one 802.11a and one 802.11b/g
radio. In the current model, NAV-AP-US, the 802.11a radio is disabled at
the factory and via software preventing it from being configured and
used when installed at an end user facility
iv
Declaration of Conformity
Marking by this symbol:
indicates compliance with the Essential Requirements of the R&TTE
Directive of the European Union (1999/5/EC).
This equipment meets the following conformance standards:
Safety: EN 60950-1:2001 + A11:2004
EMC: EN 55022:2006, EN 55024:1998 + A1:2001 + A2:2003, EN 301-489-1
v1.7.1, EN 301-489-17 v1.3.2, CISPR22:1997, CISPR24
Including: EN 61000-3-2, -3-3, -4-2, -4-3, -4-4, -4-5, -4-6 and -4-11. The
product is also licensed as required for additional country specific
standards as required for the International Marketplace.
Radio: EN 300-328 v.1.7.1 (2006-10)
Electromagnetic compatibility and Radio spectrum Matters (ERM);
Wideband transmission systems; Data transmission equipment operating
in the 2,4 GHz ISM band and using wide band modulation techniques.
Certifications are harmonized to the EN standards covering essential
requirements under article 3.2 of the R&TTE Directive. Compliance
includes testing with the supplied integral antenna.
SAR: EN 50385:2002
European Community Declaration of Conformity
Hereby, Texas Instruments declares that the TI-Navigator™ access point
and TI-Nspire™ Navigator™ wireless cradle are in compliance with the
essential requirements and other relevant provisions of Directive
1999/5/EC.
English Hereby, Texas Instruments declares that the
TI-Navigator™ access point and TI-Nspire™
Navigator™ wireless cradle are in compliance
with the essential requirements and other
relevant provisions of Directive 1999/5/EC.
The Declaration of Conformity may be consulted
in the Product Stewardship page at
education.ti.com.
v
Dansk Undertegnede Texas Instruments erklærer
herved, at følgende udstyr TI-Navigator™ access
point overholder de væsentlige krav og øvrige
relevante krav i direktiv 1999/5/EF.
Overensstemmelsesdirektivet (Declaration of
Conformity) kan findes på Product Stewardship
siden på
education.ti.com.
Norsk Texas Instruments erklærer herved at utstyret
TI-Navigator™ access point er i samsvar med de
grunnleggende krav og øvrige relevante krav i
direktiv 1999/5/EF.
Samsvarserklæringen kan konsulteres på
produktforvaltningssiden (Product Stewardship)
education.ti.com.
på
Suomi Texas Instruments vakuuttaa täten että
TI-Navigator™ access point tyyppinen laite on
direktiivin 1999/5/EY oleellisten vaatimusten ja
sitä koskevien direktiivin muiden ehtojen
mukainen.
Vaatimustenmukaisuusvakuutus on saatavilla
tuotteen ympäristövaikutuksen sivulta
osoitteessa
education.ti.com.
Français Par la présente Texas Instruments déclare que
l'appareil TI-Navigator™ access point est
conforme aux exigences essentielles et aux autres
dispositions pertinentes de la directive 1999/5/CE.
La déclaration de conformité peut être consultée
sur le site education.ti.com à la page
Responsabilité Produit (Product Stewardship)
Deutsch Hiermit erklärt Texas Instruments, dass sich das
Gerät TI-Navigator™ access point in
Übereinstimmung mit den grundlegenden
Anforderungen und den übrigen einschlägigen
Bestimmungen der Richtlinie 1999/5/EG befindet.
Die Konformitätserklärung ist unter
Produktbetreuung (Product Stewardship) bei
education.ti.com einzusehen.
vi
Italiano Con la presente Texas Instruments dichiara che
questo TI-Navigator™ access point è conforme ai
requisiti essenziali ed alle altre disposizioni
pertinenti stabilite dalla direttiva 1999/5/CE.
La dichiarazione di conformità può essere
consultata sulla pagina Product Stewardship del
education.ti.com.
sito
Nederlands Hierbij verklaart Texas Instruments dat het
toestel TI-Navigator™ access point in
overeenstemming is met de essentiële eisen en
de andere relevante bepalingen van richtlijn
1999/5/EG.
De verklaring van overeenstemming kan worden
geraadpleegd op de pagina Product Stewardship
(Productverantwoordelijkheid) op
education.ti.com.
Português Texas Instruments declara que este
TI-Navigator™ access point está conforme com os
requisitos essenciais e outras disposições da
Directiva 1999/5/CE.
Pode-se consultar a Declaração de Conformidade
na página de Gestão de Produto, (Product
Stewardship) no sítio
education.ti.com.
Español Por medio de la presente Texas Instruments
declara que el TI-Navigator™ access point
cumple con los requisitos esenciales y
cualesquiera otras disposiciones aplicables o
exigibles de la Directiva 1999/5/CE.
La Declaración de Conformidad puede
consultarse en la página de Administración de
Productos (Product Stewardship) en
education.ti.com.
Svenska Härmed intygar Texas Instruments att denna
TTI-Navigator™ access point står I
överensstämmelse med de väsentliga
egenskapskrav och övriga relevanta
bestämmelser som framgår av direktiv 1999/5/EG.
Förenlighetsdeklarationen kan konsulteras på
Produktförvaltningssidan (Product Stewardship)
education.ti.com.
på
vii
Countries of Operation and Restrictions of Use in the
European Community
Operation Using the 2.400 to 2.4835 GHz Channels in the
European Community
The installer and/or end user should use the configuration utility
provided with this product to verify the current channel of operation, the
expected transmit power level, and to confirm that the device is
operating in conformance with the spectrum usage rules for the selected
European Community country. If operation is occurring outside of
the allowable channels as indicated in this guide, then operation
of the product must cease immediately and the installer must
consult with the local technical support staff responsible for the
wireless network.
These devices are intended to be operated in all countries of the
European Community. Additional restrictions of use for the
TI-Navigator™ access point within the European Community countries in
the 2.400 to 2.4835 GHz band are listed below.
• The frequencies associated with channels 1 to 13 in the 2.400 to
2.4835 GHz band are allowed to be used either indoors or outdoors
in all countries of the European Community, except where noted
below:
• In Greece, Italy, Latvia, and Spain the end-user must apply for a
license from the national spectrum authority to operate this device
outdoors. Please consult the TI Navigator User's Guide for further
information regarding restrictions and operating conditions for
outdoor configurations.
• In France, the following operation is permitted:
– Outdoor operation is only permitted using the 2.400 - 2.454 GHz
band, which includes channels 1 to 7, at a maximum EIRP of 100
mW (20 dBm).
– Outdoor operation is permitted in the 2.400 to 2.4835 GHz band
on channels 1 to 13 at a maximum EIRP of 10 mW (10 dBm).
– Indoor operation is permitted in the 2.400 to 2.4835 GHz band
on channels 1 to 13 at a maximum EIRP of 100 mW (20 dBm).
Warning Statements
Warning! Install the TI-Navigator™ access point in such a manner as to
maintain a minimum of 20 cm (7.9 inches) separation distance between
the radiating element(s) and all persons. This safety warning conforms to
FCC radio frequency exposure limits.
viii
Warning! Do not touch or move the TI-Navigator™ access point when
the antennas are transmitting or receiving.
Warning! The TI-Navigator access point and TI-Nspire™ Navigator™
wireless cradle are intended for indoor use only. Do not install the device
nor operate it outdoors.
Warning! Intentional radiators, such as the TI-Navigator access point
and TI-Nspire™ Navigator™ wireless cradle, are not intended to be
operated with any antenna(s) other than those furnished by Texas
Instruments. An intentional radiator may only be operated with the
antenna(s) with which it is authorized.
Warning! The TI-Navigator access point radio(s) are disabled by default
and can be enabled only by the system administrator using the
Management software application.
Warning! The radio frequency band, operating channels, and transmit
power depend on the country of operation specified by the system
administrator during setup and configuration using the Management
software.
Warning! Only qualified personnel must perform installation. Read and
follow all warning notices and instructions marked on the product or
included in the documentation.
ix
x
Contents
Important Information................................................................... ii
Regulatory Information ................................................................. ii
USA FCC Information Concerning Radio Frequency Interferenceii
Federal Communication Commission Interference Statement
ii
IMPORTANT NOTE:
FCC Radiation Exposure Statement:....................................... iii
Canadian IC Information............................................................... iv
Industry Canada Statement................................................... iv
IMPORTANT NOTE:
Canada IC Radiation Exposure Statement: ............................ iv
Europe — EU Declaration of Conformity..................................... iv
Restrictions ............................................................................. vi
Canada — Industry Canada (IC)............................................. vi
Exposure to Radio Frequency Radiation............................... vi
Overview......................................................................................... 1
System requirements...................................................................... 2
Minimum system requirements.............................................. 2
Other requirements ................................................................ 2
Unpacking the boxes...................................................................... 3
Classroom kit ........................................................................... 4
Student kit (up to 15 students) ..............................................5
Individual kit............................................................................ 5
Charging the wireless cradles........................................................ 5
Checking the LEDs................................................................... 7
Before you begin............................................................................ 7
Installing .................................................................................. 7
Activating the software.......................................................... 9
Setting up your TI-Nspire™ Navigator™ network the first time ..
11
Before you begin................................................................... 11
Connecting the cables to the access point .......................... 12
Starting the wizard ............................................................... 12
Installing the calculator operating system.................................. 14
Connecting the calculators to the wireless cradles.................... 17
Installing software Apps on the calculators ............................... 18
Required ................................................................................ 18
Optional................................................................................. 19
Technical information .................................................................. 20
Wireless access point.............................................................20
Wireless network information .............................................20
Access point LEDs .................................................................. 21
Battery information for wireless cradles ............................. 21
vii
Storing the wireless cradles ..................................................21
Removing the battery pack...................................................21
Wireless Cradle LEDs..............................................................22
Troubleshooting............................................................................24
Lost connections....................................................................24
Calculator device not responding.........................................24
Messages ................................................................................25
.......................................................................................................29
Texas Instruments Support and Service .......................................55
For general information .......................................................55
For TI-Navigator™ technical questions ................................55
For product (hardware) service.............................................55
Battery Precautions for Calculators.............................................56
Battery Precautions for Rechargeable Battery Packs..................57
Storage...................................................................................57
viii
Overview
The TI-Nspire™ Navigator™ classroom learning system from Texas
Instruments can help you:
• Assess student understanding.
• Verify that students are on task.
• Use classroom results to engage students.
• Get immediate feedback from your students to promote student
achievement.
The system is composed of two parts, hardware and software. The
hardware creates a wireless communications network so that your
computer can communicate with your students’ TI-Nspire™ and TI-Nspire
CAS handhelds. The software contains a number of tools to enhance your
classroom, including:
• Quick Poll. Lets you send polls to your students, receive the
students’ responses to the polls, and review the poll results with your
students.
• Screen Capture. Lets you capture your students’ calculator screens.
• Transfer tools. Multiple tools that let you send, collect, and delete
data files on your students’ calculators.
You can obtain educational content on the Web at TI’s Activities
Exchange (education.ti.com/activities.) Or, using the tools on the product
CD, you can create your own:
• StudyCard™ stacks
• CellSheet™ application variables
• TI NoteFolio™ Creator text files that you transfer to TI calculators
• TImeSpan™ Creator timelines of chronological events that can be
viewed on a TI calculator
• Data sets (lists, matrices, and so on)
There are several ways to learn to set up and use the TI-Navigator™
system:
•The Getting Started poster—a short version of the setup process with
fewer details.
•The Installation Guide (this book, provided in both printed and PDF
formats)—complete setup details, troubleshooting, and technical
information.
1
•The TI-Nspire™ Navigator™ Guidebook (provided in both printed
and PDF formats)—after you install the TI-Nspire™ Navigator™
software on your computer, you can use the book or PDF file as a
reference for the software tools.
The process of unpacking the equipment, setting up the hardware, and
installing the software will probably require about two hours of your
time.
System requirements
Minimum system requirements
• Windows® Vista Ultimate, Home, Business, or Pro installed;
Windows® XP Professional with Service Pack 1, 2, or 3 installed; or
Windows® 2000 with Service Pack 4 installed.
• 900 MHz Pentium-compatible CPU (1.2 GHz recommended)
• Video adapter set at 1024 x 768 screen resolution
• 256 MB RAM (512 MB recommended)
• Approximately 500 MB of available hard-disk space (to install
TI-Navigator™ and Network Manager) (Since Class Analysis and
Learning Check Creator were taken out, we probably need less
space?)
• CD-ROM drive
• Available USB 2.0 (Hi-Speed USB) port on the computer
• Internet Explorer version 5.5 or higher (installed and operational)
Other requirements
• The TI-Nspire™ Navigator™ system communicates with the TI-Nspire
and TI-Nspire CAS learning handhelds. Your school or your students
may already own these. Handhelds are not included with the
TI-Nspire Navigator system.
• The latest operating system (1.3) must be installed on each handheld
used with the TI-Nspire Navigator system. These operating systems
are included on the CD and are available at education.ti.com/latest.
• The TI-Nspire Computer Link software must be installed on your
computer to download the latest operating system to your
handheld. The TI-Nspire Computer Link software is available at
education.ti.com.
• A USB cable is required to connect the TI-Nspire and TI-Nspire CAS
handhelds to the computer. The USB cable is not included with the
TI-Nspire Navigator system.
2
Unpacking the boxes
The TI-Nspire™ Navigator™ product consists of one classroom kit and a
combination of student kits and individual kits, depending on your
specific order. Each kit is packaged separately. If necessary, you can
purchase additional kits to accommodate as many as 40 students.
1. Determine which kits you have received.
2. Unpack the items from the packing materials.
3. Identify each item, and check the items against the following lists to
make sure your order is complete.
3
Loading...
