Product Name：
Lithium Manganese Dioxide Batteries

CHEMICAL SYSTEM:
Lithium Manganese Dioxide

Volts:
3 V

Size:
CR2025

Trade Mark:
JHT

Approximate Weight:

2.6 g

Designed for Recharge:
NO

Date of preparation:
Jan 01 2017

Company:
JHIH HONG TECHNOLOGY CO.,LTD.

Telephone Numbers:
[phone]

Address (Number, Street, City, State, and ZIP Code):
6F, No.15, Wu Chuan Road, Wu-Ku Industrial Park,
New Taipei 248

Fax Numbers:
[phone]

Ingredient

CAS NO.

Content (wt%)

Lithium

7439-93-2

1.85 (0.048 gram)

Propylene Carbonate

108-32-7

6.0

Manganese dioxide

1313-13-9

26.0

1,2-Dimethoxyethane

110-71-4

3.6

Lithium perchlorate

7791-03-9

1.1

Graphite

7782-42-5、1333-86-4

3.0

Polypropylene

9003-07-0

4.1

Stainless steel

7439-89-6

54.35

The batteries are exempt articles and are not subject to the OSHA Hazard Communication Standard
Requirement. This sheet is provided as technical information only. The information and
recommendations set forth are made in good faith and believed to be accurate as of the date of
preparation. However, JHIH HONG makes no warranty expressed or Implied.

MATERIAL SAFETY DATA SHEET

Section 1-Product and Company Identification

Section 2- Composition/Information on Ingredients

Section 3 – Hazards Identification

This contains lithium, organic solvent, and other combustible materials. For this reason, Improper handling
of the battery could lead to distortion, leakage*, overheating, explosion of fire and cause human injury or
equipment trouble. Please strictly observe safety instruction.
(*Leakage is defined as an unintended escape of liquid from a battery.)

Section 4 – First Aid Measures

None unless internal materials exposure. If contents are leaked out, observe following

Instructions

Inhalation Fumes can cause respiratory irritation . Remove to fresh air and consult a physician.

Skin Immediately flush skin plenty of water. If itch or irritation by chemical bum persists, consult a

physician.

Eyes Immediately flush eye with plenty of water for at least 15 minutes.

Consult a physician immediately

Ingestion If swallowing a battery, consult a physician immediately.

If contents come into mouth, immediately rinse by plenty of water and consult a physician.

Section 5-Fire Fighting Measures

Extinguishing Media Extinguisher of alkaline metal fire is effective.

Plenty of cold water is also effective to cool the surrounding area and control the spread

fire. But hydrogen gas may be evolved by the reaction of water and lithium and it can
form an explosive mixture. Therefore in the case that lots of lithium batteries are burning
in a confined space ,use a smothering agent.

Fire fighting procedure Use self-contained breathing apparatus and full protective gear not to inhale harmful

gas .

Section 6-Accidental Release Measures

Accidental Releases: Do not breathe vapors or touch liquid with bare hands (see section 4).

Waste Disposal Methods: Evacuate area. If possible, a trained person should attempt to stop or contain the leak by neutralizing
spill with soda lime or baking soda. A NIOSH Approved Acid Gas Filter Mask or Self-Contained Breathing Apparatus should
be worn. Seal leaking battery and soda lime or baking soda in a plastic bag and dispose of as hazardous waste.

Other: Follow North American Emergency Response Guide (NAERG)#138 for cells involved in an accident, cells that

have vented, or have exploded.

Section 7-Handling and Storage

1) Handling

Never swallow. Never reverse the positive and negative terminals when mounting . Never short-circuit the battery.
Never heat. Never expose to open flame. Never disassemble. Never weld the terminal or wire to the body of the battery
directly. Never touch the liquid leaked out of battery . Never bring fire close to battery liquid. Never keep in touch with
battery.

2) Storage

Never let the battery contact with water. Never store the battery in hot and high humid place. Don't push the battery
excessively and destroy the battery packaging, often wet and ventilating the dry place to keep in the normal atmospheric
temperature, find the unusual battery is dealt with in time
