Texas Instruments SN65LVDS1DBVR, SN65LVDS1DBVT Datasheet

SN65LVDS1

HIGH-SPEED DIFFERENTIAL LINE DRIVER

SLLS373B – JULY 1999 – DECEMBER 1999

D

Meets or Exceeds ANSI TIA/EIA-644-1995
Standard

D

Designed for Signaling Rates up to
630 Mbps

D

Operates From a 2.4-V to 3.6-V Supply

D

Package in Small-Outline Transistor
Package

D

Bus-T erminal ESD Exceeds 15 kV

D

Low-Voltage Differential Signaling With
Typical Output Voltages of 350 mV and a
100-Ω Load

D

Propagation Delay Times, 1.7 ns Typical

D

Power Dissipation at 200 MHz, 25 mW
Typical

D

LVTTL Level is 5-V Tolerant

D

Driver is High Impedance With V

CC

description

The SN65L VDS1 is a single low-voltage dif feren­tial line driver in the small-outline transistor
package. The outputs comply with the TIA/
EIA-644 standard and provide a minimum
differential output voltage magnitude of 247 mV
into a 100-Ω load at signaling rates up to
630 Mbps.

< 1.5 V

logic diagram

SN65LVDS1

DBV PACKAGE

(TOP VIEW)

1

V

CC

GND

D

Z

5

5

2

3

4

4

Y

3

Z

Function Table

INPUT OUTPUTS

D
H

L

Open

YZ
H

L
L

D

Y

L
H
H

When used with an LVDS receiver (such as the SN65LVDT2) in a point-to-point connection; data or clocking
signals can be transmitted over printed-circuit board traces or cables at very high rates with very low
electromagnetic emissions and power consumption. The packaging, low power, low EMI, high ESD tolerance,
and wide supply voltage range make this device ideal for battery-powered applications.

The SN65LVDS1 is characterized for operation from –40°C to 85°C.

Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of
Texas Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.

PRODUCTION DATA information is current as of publication date.
Products conform to specifications per the terms of Texas Instruments
standard warranty. Production processing does not necessarily include
testing of all parameters.

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

Copyright  1999, Texas Instruments Incorporated

1

SN65LVDS1
HIGH-SPEED DIFFERENTIAL LINE DRIVER

SLLS373B – JULY 1999 – DECEMBER 1999

equivalent input and output schematic diagrams

V

CC

V

CC

D Input

50 Ω

7 V

300 kΩ

10 kΩ

absolute maximum ratings over operating free-air temperature (unless otherwise noted)

5 Ω

Y or Z
Output

7 V

†

Supply voltage range, VCC (see Note 1) –0.5 V to 4 V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Input voltage range (D) –0.5 V to 6 V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

(Y or Z) –0.5 V to 4 V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Electrostatic discharge: Y, Z, and GND (see Note 2) CLass 3, A:15 kV, B:600 V. . . . . . . . . . . . . . . . . . . . . . . .

Continuous total power dissipation See dissipation rating table. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Storage temperature range –65°C to 150°C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Lead temperature 1,6 mm (1/16 inch) from case for 10 seconds 250°C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

†

Stresses beyond those listed under “absolute maximum ratings” may cause permanent damage to the device. These are stress ratings only, and
functional operation of the device at these or any other conditions beyond those indicated under “recommended operating conditions” is not
implied. Exposure to absolute-maximum-rated conditions for extended periods may affect device reliability.

NOTES: 1. All voltage values, except differential I/O bus voltages are with respect to network ground terminal.

2. Tested in accordance with MIL-STD-883C Method 3015.7.

PACKAGE

DBV 385 mW 3.1 mW/°C 200 mW

†

This is the inverse of the junction-to-ambient thermal resistance when board-mounted (low-K) and with
no air flow.

TA ≤ 25°C

POWER RATING

recommended operating conditions

Supply voltage, V
High-level input voltage, V
Low-level input voltage, V
Operating free–air temperature, T

2

CC

IH

IL

A

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

DISSIPATION RATING TABLE

DERATING FACTOR

ABOVE TA = 25°C

†

TA = 85°C

POWER RATING

MIN NOM MAX UNIT

2.4 3.3 3.6 V
2 V

0.8 V

–40 85 °C

SN65LVDS1

R

100Ω

ICCSupply current

mA

IOSShort-circuit output current

mA

R

L

100Ω

R

L

100Ω

HIGH-SPEED DIFFERENTIAL LINE DRIVER

SLLS373B – JULY 1999 – DECEMBER 1999

electrical characteristics over recommended operating conditions (unless otherwise noted)

PARAMETER TEST CONDITIONS MIN TYP†MAX UNIT

VOD Differential output voltage magnitude

∆VOD
V

OC(SS)

∆V

OC(SS)

V

OC(PP)

I

IH

I

IL

I

O(OFF)

C

IN

†

All typical values are at 25°C and with a 3.3-V.

Change in differential output voltage magnitude between logic
states

Steady-state common-mode output voltage 1.125 1.375 V
Change in steady-state common-mode output voltage between

logic states
Peak-to-peak common-mode output voltage 25 100 mV

pp

High-level input current VIH = 5 V 2 20 µA
Low-level input current VIL = 0.8 V 2 10 µA

p

Power-off output current VCC = 0 V, VO = 3.6 V ±1 µA
Input capacitance 3 pF

=

L

See Figure 1

See Figure 2

VI = 0 V or VCC,
No load

VI = 0 V or VCC,
RL = 100Ω

VOY or VOZ = 0 V 3 10
VOD = 0 V 10

,

247 350 454
–50 50

–50 50 mV

2 4

5.5 8

mV

switching characteristics over recommended operating conditions, VCC = 3 V to 3.6 V (unless
otherwise noted)

PARAMETER TEST CONDITIONS MIN TYP‡MAX UNIT

t

PLH

t

PHL

t

r

t

f

t

sk(p)

‡

All typical values are at 25°C and with a 3.3-V.

§

t

sk(p)

Propagation delay time, low-to-high-level output 1.5 2.7 ns
Propagation delay time, high-to-low-level output
Differential output signal rise time
Differential output signal fall time
Pulse skew (|t

is the magnitude of the time difference between the high-to-low and low-to-high propagation delay times at an output.

pHL

– t

pLH

§

|)

=

=
CL = 10 pF,
See Figure 3

,

1.8 2.7 ns

0.6 1 ns

0.7 1 ns

0.3 ns

switching characteristics over recommended operating conditions, VCC = 2.4 to 2.7 V (unless
otherwise noted)

PARAMETER TEST CONDITIONS MIN TYP‡MAX UNIT

t

PLH

t

PHL

t

r

t

f

t

sk(p)

‡

All typical values are at 25°C and with a 3.3-V.

§

t

sk(p)

Propagation delay time, low-to-high-level output 1.7 3.1 ns
Propagation delay time, high-to-low-level output
Differential output signal rise time
Differential output signal fall time
Pulse skew (|t

is the magnitude of the time difference between the high-to-low and low-to-high propagation delay times at an output.

pHL

– t

pLH

§

|)

=

=
CL = 10 pF,
See Figure 3

,

2 3.1 ns

0.6 1 ns

0.7 1 ns

0.3 ns

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

3

SN65LVDS1
HIGH-SPEED DIFFERENTIAL LINE DRIVER

SLLS373B – JULY 1999 – DECEMBER 1999

PARAMETER MEASUREMENT INFORMATION

I

I

D

V

I

Figure 1. Driver Voltage and Current Definitions

Y

Z

I

I

OY

OZ

V

OD

V

OY

V

V

OZ

OC

VOY)

V

OZ

2

49.9 Ω, ±1% (2 Places)

Y

Input

Z

NOTE A: All input pulses are supplied by a generator having the following characteristics: tr or tf ≤ 1 ns, pulse repetition rate (PRR) = 0.5 Mpps,

pulse width = 500 ± 10 ns . CL includes instrumentation and fixture capacitance within 0,06 mm of the D.U.T. The measurement of
V

is made on test equipment with a –3 dB bandwidth of at least 300 MHz.

OC(PP)

50 pF

V

OC

V

I

V

I

V

OC(PP)

V

OC

1.4 V

1 V

V

OC(SS)

Figure 2. Test Circuit and Definitions for the Driver Common-Mode Output V oltage

4

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

Input

Output

t

PLH

HIGH-SPEED DIFFERENTIAL LINE DRIVER

PARAMETER MEASUREMENT INFORMATION

Y

Input

V

OD(H)

V

OD

Z

CL = 10 pF
(2 Places)

t

PHL

100 Ω
±1%

SN65LVDS1

SLLS373B – JULY 1999 – DECEMBER 1999

2 V

1.4 V or 1.2 V (see Note B)

0.8 V

100%
80%

0 V

V

OD(L)

20%
0%

t

f

NOTES: A. All input pulses are supplied by a generator having the following characteristics: tr or tf ≤ 1 ns, pulse repetition rate (PRR) = 50 Mpps,

pulse width = 10 ± 0.2 ns . CL includes instrumentation and fixture capacitance within 0,06 mm of the D.U.T.

B. This point is 1.4 V with VCC = 3.3 V or 1.2 V with VCC = 2.7 V

t

r

Figure 3. Test Circuit, Timing, and Voltage Definitions for the Differential Output Signal

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

5

SN65LVDS1
HIGH-SPEED DIFFERENTIAL LINE DRIVER

SLLS373B – JULY 1999 – DECEMBER 1999

TYPICAL CHARACTERISTICS

2.6

2.4

2.2

1.8

1.6

1.4

1.2

– High-to-Low Level Propagation Delay Time – ns

PHL

t

HIGH-TO-LOW LEVEL

PROPAGATION DELAY TIMES

vs

FREE-AIR TEMPERATURE

1.9

VCC = 2.4 V

VCC = 3 V

2

1

–20 0 40–40

TA – Free-Air Temperature – °C

20

VCC = 2.7 V

VCC = 3.3 V

VCC = 3.6 V

60 80 100

1.8

1.7

1.6

1.5

1.4

1.3

1.2

1.1

– Low-to-High Level Propagation Delay Time – ns

1

PLH

t

Figure 4

LOW-TO-HIGH LEVEL

PROPAGATION DELAY TIME

vs

FREE-AIR TEMPERATURE

VCC = 2.4 V

VCC = 3.6 V

VCC = 3 V

–20 0 40–40

TA – Free-Air Temperature – °C

20 60 80 100

Figure 5

VCC = 2.7 V

VCC = 3.3 V

6

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

SN65LVDS1

HIGH-SPEED DIFFERENTIAL LINE DRIVER

SLLS373B – JULY 1999 – DECEMBER 1999

MECHANICAL INFORMATION

DBV (R-PDSO-G5) PLASTIC SMALL-OUTLINE

0,95

1,45
0,95

3,00
2,80

45

31

0,05 MIN

0,50
0,30

1,70
1,50

M

0,20

3,00
2,60

Seating Plane

0,10

0,15 NOM

Gage Plane

0°–8°

0,25

0,55
0,35

NOTES: A. All linear dimensions are in millimeters.

B. This drawing is subject to change without notice.
C. Body dimensions do not include mold flash or protrusion.
D. Falls within JEDEC MO-178

4073253-4/E 05/99

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

7
