MSP430xG461x

MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 201 1

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

D Low Supply-Voltage Range: 1.8 V to 3.6 V D Ultralow-Power Consumption:

− Active Mode: 400 μA at 1 MHz, 2.2 V

− Standby Mode: 1.3 μA

− Off Mode (RAM Retention): 0.22 μA

D Five Power-Saving Modes D Wake-Up From Standby Mode in Less

Than 6 μs

D 16-Bit RISC Architecture, Extended

Memory, 125-ns Instruction Cycle Time

D Three Channel Internal DMA D 12-Bit A/D Converter With Internal

Reference, Sample-and-Hold, and Autoscan Feature

D Three Configurable Operational Amplifiers D Dual 12-Bit Digital-to-Analog (D/A)

Converters With Synchronization

D 16-Bit Timer_A With Three

Capture/Compare Registers

D 16-Bit Timer_B With Seven

Capture/Compare-With-Shadow Registers

D On-Chip Comparator D Supply Voltage Supervisor/Monitor With

Programmable Level Detection

D Serial Communication Interface (USART1),

Select Asynchronous UART or Synchronous SPI by Software

D Universal Serial Communication Interface

− Enhanced UART Supporting Auto-Baudrate Detection

− IrDA Encoder and Decoder

− Synchronous SPI

− I2C

D Serial Onboard Programming,

Programmable Code Protection by Security Fuse

D Brownout Detector D Basic Timer With Real Time Clock Feature D Integrated LCD Driver up to 160 Segments

With Regulated Charge Pump

D Family Members Include:

− MSP430xG4616:

92KB+256B Flash or ROM Memory 4KB RAM

− MSP430xG4617:

92KB+256B Flash or ROM Memory, 8KB RAM

− MSP430xG4618:

116KB+256B Flash or ROM Memory, 8KB RAM

− MSP430xG4619:

120KB+256B Flash or ROM Memory, 4KB RAM

D For Complete Module Descriptions, See the

MSP430x4xx Family User’s Guide

(

literature number SLAU056

)

description

The Texas Instruments MSP430 family of ultralow-power microcontrollers consists of several devices featuring different sets of peripherals targeted for various applications. The architecture, combined with five low-power modes, is op t i m i zed to achieve extended battery life in portable measurement applications. The device features a powerful 16-bit RISC CPU, 16-bit registers, and constant generators that contribute to maximum code efficiency. The digitally controlled oscillator (DCO) allows wake-up from low-power modes to active mode in less than 6 μs.

The MSP430xG461x series are microcontroller configurations with two 16-bit timers, a high-performance 12-bit A/D converter, dual 12-bit D/A converters, three configurable operational amplifiers, one universal serial communication interface (USCI), one universal synchronous/asynchronous communication interface (USART), DMA, 80 I/O pins, and a liquid crystal display (LCD) driver with regulated charge pump.

Typical applications for this device include portable medical applications and e-meter applications.

This integrated circuit can be damaged by ESD. Texas Instruments recommends that all integrated circuits be handled with appropriate precautions. Failure to observe proper handling and installation procedures can cause damage. ESD damage can range from subtle performance degradation to complete device failure. Precision integrated circuits may be more susceptible to damage because very small parametric changes could cause the device not to meet its published specifications. These devices have limited built-in ESD protection.

PRODUCTION DATA information is current as of publication date. Products conform to specifications per the terms of Texas Instruments standard warranty. Production processing does not necessarily include testing of all parameters.

Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of Texas Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.

MSP430xG461x MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 2011

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

AVAILABLE OPTIONS

{

PACKAGED DEVICES

}

PLASTIC 100-PIN TQFP

(PZ)

PLASTIC 113-BALL BGA

(ZQW)

MSP430FG4616IPZ MSP430FG4616IZQW MSP430FG4617IPZ MSP430FG4617IZQW MSP430FG4618IPZ MSP430FG4618IZQW MSP430FG4619IPZ MSP430FG4619IZQW

−40°C to 85°C MSP430CG4616IPZ MSP430CG4616IZQW

MSP430CG4617IPZ MSP430CG4617IZQW MSP430CG4618IPZ MSP430CG4618IZQW MSP430CG4619IPZ MSP430CG4619IZQW

†

For the most current package and ordering information, see the Package Option Addendum at the end of this document, or see the TI web site at www.ti.com.

‡

Package drawings, thermal data, and symbolization are available at www.ti.com/packaging.

DEVELOPMENT TOOL SUPPORT

All MSP430 microcontrollers include an Embedded Emulation Module (EEM) allowing advanced debugging and programming through easy-to-use development tools. Recommended hardware options include:

D Debugging and Programming Interface

− MSP-FET430UIF (USB)

− MSP-FET430PIF (Parallel Port)

D Debugging and Programming Interface with Target Board

− MSP-FET430U100 (for PZ package)

D Standalone Target Board

− MSP-TS430PZ100 (for PZ package)

D Production Programmer

− MSP-GANG430

MSP430xG461x

MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 201 1

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

pin designation, MSP430xG461xIPZ

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25

100

75 74 73 72 71 70 69 68 67 66 65 64 63 62 61 60 59 58 57 56 55 54 53 52 51

P1.7/CA1

P6.1/A1/OA0O

P6.0/A0/OA0I0

RST/NMI

XT2IN

XT2OUT

P1.3/TBOUTH/SVSOUT

P1.4/TBCLK/SMCLK

P1.5/TACLK/ACLK

P1.6/CA0

P2.3/TB2

P9,2/S15

P9.1/S16

P9.0/S17

P8.5/S20

P8.0/S25

P7.7/S26

P7.6/S27

P7.5/S28

P7.4/S29

P7.2/UCA0SOMI/S31

P4.7/UCA0RXD/S34

P7.3/UCA0CLK/S30

P1.0/TA0

TDI/TCLK

TDO/TDI

P8.4/S21

SS1

P6.2/A2/OA0I1

P1.2/TA1

P8.1/S24

P4.6/UCA0TXD/S35

CC1

P6.3/A3/OA1O P6.4/A4/OA1I0 P6.5/A5/OA2O

P6.6/A6/DAC0/OA2I0

P6.7/A7/DAC1/SVSIN

VREF+

XIN

XOUT

VeREF+/DAC0

VREF−/VeREF−

P5.1/S0/A12/DAC1

P5.0/S1/A13/OA1I1

P10.7/S2/A14/OA2I1

P10.6/S3/A15

P10.5/S4 P10.4/S5 P10.3/S6 P10.2/S7 P10.1/S8 P10.0/S9 P9.7/S10 P9.6/S11 P9.5/S12 P9.4/S13

P2.4/UCA0TXD P2.5/UCA0RXD P2.6/CAOUT P2.7/ADC12CLK/DMAE0 P3.0/UCB0STE P3.1/UCB0SIMO/UCB0SDA P3.2/UCB0SOMI/UCB0SCL P3.3/UCB0CLK P3.4/TB3 P3.5/TB4 P3.6/TB5 P3.7/TB6 P4.0/UTXD1 P4.1/URXD1 DV

SS2

CC2

LCDCAP/R33 P5.7/R23 P5.6/LCDREF/R13 P5.5/R03 P5.4/COM3 P5.3/COM2 P5.2/COM1 COM0 P4.2/STE1/S39

P8.6/S19

P8.3/S22

P8.2/S23

P7.0/UCA0STE/S33

P7.1/UCA0SIMO/S32

P4.5/UCLK1/S36

P4.4/SOMI1/S37

P4.3/SIMO1/S38

CCAVSS

TCK

TMS

P1.1/TA0/MCLK

P2.0/TA2

P2.1/TB0

P2.2/TB1

MSP430xG4616IPZ MSP430xG4617IPZ MSP430xG4618IPZ MSP430xG4619IPZ

P9.3/S14

P8.7/S18

MSP430xG461x MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 2011

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

pin designation, MSP430xG461xIZQW (top view)

A B C D E F

K L

123456789101112

NOTE: For terminal assignments, see the MSP430xG461x Terminal Functions table.

MSP430xG461x

MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 201 1

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

functional block diagram

Oscillators

FLL+

RAM

4kB 8kB 8kB 4kB

Brownout

Protection

SVS/SVM

RST/NMI

DVCC1/2 DVSS1/2

MCLK

Watchdog

WDT+

15/16−Bit

Timer_A3

3CC

Registers

8MHz CPUX incl.16

Registers

XOUT/ XT2OUT

OA0, OA1,

OA2

3 Op Amps

Basic Timer

Real−Time

Clock

JTAG

Interface

LCD_A

160

Segments

1,2,3,4 Mux

Ports P1/P2

2x8 I/O

Interrupt

capability

USCI_A0:

UART,

IrDA, SPI

USCI_B0:

SPI,I2C

Comparator

Flash(FG) ROM(CG)

120kB 116kB

92kB 92kB

Hardware

Multiplier

MPY,

MPYS,

MAC,

MACS

Timer_B7

7CC

Registers,

Shadow

Reg

ADC12

12−Bit

Channels

DAC12

12−Bit

2Channels Voltage out

USART1

UART, SPI

DMA

Controller

3 Channels

Ports P3/P4 P5/P6

4x8 I/O

Ports

P7/P8

P9/P10

4x8/2x16 I/O

AVCC AVSS P1.x/P2.x

2x8

P3.x/P4.x P5.x/P6.x

4x8

P7.x/P8.x

P9.x/P10.x

4x8/2x16

XIN/

XT2IN

SMCLK

ACLK

MDB

MAB

Enhanced

Emulation

( FG only)

MSP430xG461x MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 2011

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

Terminal Functions

TERMINAL

NAME

NO.PZNO.

ZQW

I/O DESCRIPTION

CC1

1 A1 Digital supply voltage, positive terminal P6.3/A3/OA1O 2 B1 I/O General-purpose digital I/O / analog input a3—12-bit ADC / OA1 output P6.4/A4/OA1I0 3

I/O General-purpose digital I/O / analog input a4—12-bit ADC / OA1 input multiplexer

on +terminal and −terminal P6.5/A5/OA2O 4 C2 I/O General-purpose digital I/O / analog input a5—12-bit ADC / OA2 output P6.6/A6/DAC0/OA2I0 5

I/O General-purpose digital I/O / analog input a6—12-bit ADC / DAC12.0 output / OA2

input multiplexer on +terminal and −terminal P6.7/A7/DAC1/SVSIN 6 C3 I/O

General-purpose digital I/O / analog input a7—12-bit ADC / DAC12.1 output /

analog input to brownout, supply voltage supervisor V

REF+

7 D2 O Output of positive terminal of the reference voltage in the ADC XIN 8 D1 I Input port for crystal oscillator XT1. Standard or watch crystals can be connected. XOUT 9 E1 O Output terminal of crystal oscillator XT1 Ve

REF+

/DAC0 10 E2 I/O Input for an external reference voltage to the ADC / DAC12.0 output

REF−

/Ve

REF−

11 E4 I

Negative terminal for the ADC reference voltage for both sources, the internal reference voltage, or an external applied reference voltage

P5.1/S0/A12/DAC1 (see Note 1) 12 F1 I/O

General-purpose digital I/O / LCD segment output 0 / analog input a12 − 12−bit ADC / DAC12.1 output

P5.0/S1/A13/OA1I1 (see Note 1) 13 F2 I/O

General-purpose digital I/O / LCD segment output 1 / analog input a13 − 12−bit ADC/OA1 input multiplexer on +terminal and −terminal

P10.7/S2/A14/OA2I1 (see Note 1) 14 E5 I/O

General-purpose digital I/O / LCD segment output 2 / analog input a14 − 12−bit ADC/OA2 input multiplexer on +terminal and −terminal

P10.6/S3/A15 (see Note 1) 15 G1 I/O

General-purpose digital I/O / LCD segment output 3 / analog input a15 − 12−bit

ADC P10.5/S4 16 G2 I/O General-purpose digital I/O / LCD segment output 4 P10.4/S5 17 F4 I/O General-purpose digital I/O / LCD segment output 5 P10.3/S6 18 H1 I/O General-purpose digital I/O / LCD segment output 6 P10.2/S7 19 H2 I/O General-purpose digital I/O / LCD segment output 7 P10.1/S8 20 F5 I/O General-purpose digital I/O / LCD segment output 8 P10.0/S9 21 J1 I/O General-purpose digital I/O / LCD segment output 9 P9.7/S10 22 J2 I/O General-purpose digital I/O / LCD segment output 10 P9.6/S11 23 G4 I/O General-purpose digital I/O / LCD segment output 11 P9.5/S12 24 K1 I/O General-purpose digital I/O / LCD segment output 12 P9.4/S13 25 L1 I/O General-purpose digital I/O / LCD segment output 13 P9.3/S14 26 M2 I/O General-purpose digital I/O / LCD segment output 14 P9.2/S15 27 K2 I/O General-purpose digital I/O / LCD segment output 15 P9.1/S16 28 L3 I/O General-purpose digital I/O / LCD segment output 16 P9.0/S17 29 M3 I/O General-purpose digital I/O / LCD segment output 17 P8.7/S18 30 H4 I/O General-purpose digital I/O / LCD segment output 18 P8.6/S19 31 L4 I/O General-purpose digital I/O / LCD segment output 19 P8.5/S20 32 M4 I/O General-purpose digital I/O / LCD segment output 20 P8.4/S21 33 G5 I/O General-purpose digital I/O / LCD segment output 21 P8.3/S22 34 L5 I/O General-purpose digital I/O / LCD segment output 22

NOTES: 1. Segments S 0 through S3 are disabled when the LCD charge pump feature is enabled (LCDCPEN = 1) and cannot be used together

with the LCD charge pump. In addition, when using segments S0 through S3 with an external LCD voltage supply, V

LCD

≤ AVCC.

MSP430xG461x

MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 201 1

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

Terminal Functions (Continued)

TERMINAL

NAME

NO.PZNO.

ZQW

I/O DESCRIPTION

P8.2/S23 35 M5 I/O General-purpose digital I/O / LCD segment output 23 P8.1/S24 36 H5 I/O General-purpose digital I/O / LCD segment output 24 P8.0/S25 37 J5 I/O General-purpose digital I/O / LCD segment output 25 P7.7/S26 38 M6 I/O General-purpose digital I/O / LCD segment output 26 P7.6/S27 39 L6 I/O General-purpose digital I/O / LCD segment output 27 P7.5/S28 40 J6 I/O General-purpose digital I/O / LCD segment output 28 P7.4/S29 41 M7 I/O General-purpose digital I/O / LCD segment output 29

P7.3/UCA0CLK/S30 42 H6 I/O

General-purpose digital I/O / external clock input − USCI_A0/UART or SPI mode, clock output − USCI_A0/SPI mode / LCD segment 30

P7.2/UCA0SOMI/S31 43 L7 I/O

General-purpose digital I/O / slave out/master in of USCI_A0/SPI mode / LCD segment output 31

P7.1/UCA0SIMO/S32 44 M8 I/O

General-purpose digital I/O / slave in/master out of USCI_A0/SPI mode / LCD segment output 32

P7.0/UCA0STE/S33 45 L8 I/O

General-purpose digital I/O / slave transmit enable—USCI_A0/SPI mode / LCD segment output 33

P4.7/UCA0RXD/S34 46 J7 I/O

General-purpose digital I/O / receive data in − USCI_A0/UART or IrDA mode / LCD segment output 34

P4.6/UCA0TXD/S35 47 M9 I/O

General-purpose digital I/O / transmit data out − USCI_A0/UART or IrDA mode / LCD segment output 35

P4.5/UCLK1/S36 48 L9 I/O

General-purpose digital I/O / external clock input − USART1/UART or SPI mode, clock output − USART1/SPI MODE / LCD segment output 36

P4.4/SOMI1/S37 49 H7 I/O

General-purpose digital I/O / slave out/master in of USART1/SPI mode / LCD segment output 37

P4.3/SIMO1/S38 50 M10 I/O

General-purpose digital I/O / slave in/master out of USART1/SPI mode / LCD segment output 38

P4.2/STE1/S39 51 M11 I/O

General-purpose digit a l I / O / slave transmit enable—USART1/SPI mode / LCD segment

output 39 COM0 52 L10 O COM0−3 are used for LCD backplanes. P5.2/COM1 53 L12 I/O General-purpose digital I/O / common output, COM0−3 are used for LCD backplanes. P5.3/COM2 54 J8 I/O General-purpose digital I/O / common output, COM0−3 are used for LCD backplanes. P5.4/COM3 55 K12 I/O General-purpose digital I/O / common output, COM0−3 are used for LCD backplanes. P5.5/R03 56 K11 I/O General-purpose digital I/O / Input port of lowest analog LCD level (V5)

P5.6/LCDREF/R13 57 J12 I/O

General-purpose digital I/O / External reference voltage input for regulated LCD voltage

/ Input port of third most positive analog LCD level (V4 or V3) P5.7/R23 58 J11 I/O General-purpose digital I/O / Input port of second most positive analog LCD level (V2) LCDCAP/R33 59 H11 I LCD capacitor connection / Input/output port of most positive analog LCD level (V1) DV

CC2

60 H12 Digital supply voltage, positive terminal

SS2

61 G12 Digital supply voltage, negative terminal P4.1/URXD1 62 G11 I/O General-purpose digital I/O / receive data in—USART1/UART mode P4.0/UTXD1 63 H9 I/O General-purpose digital I/O / transmit data out—USART1/UART mode

P3.7/TB6 64 F12 I/O

General-purpose digital I/O / Timer_B7 CCR6. Capture: CCI6A/CCI6B input, compare: Out6 output

P3.6/TB5 65 F11 I/O

General-purpose digital I/O / Timer_B7 CCR5. Capture: CCI5A/CCI5B input, compare: Out5 output

P3.5/TB4 66 G9 I/O

General-purpose digital I/O / Timer_B7 CCR4. Capture: CCI4A/CCI4B input, compare: Out4 output

MSP430xG461x MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 2011

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

Terminal Functions (Continued)

TERMINAL

NAME

NO.PZNO.

ZQW

I/O DESCRIPTION

P3.4/TB3 67 E12 I/O

General-purpose digital I/O / T imer_B7 CCR3. Capture: CCI3A/CCI3B input, compare: Out3 output

P3.3/UCB0CLK 68 E11 I/O

General-purpose digital I/O / external clock input—USCI_B0/UART or SPI mode, clock output—USCI_B0/SPI mode

P3.2/UCB0SOMI/ UCB0SCL

69 F9 I/O

General-purpose digital I/O / slave out/master in of USCI_B0/SPI mode /I2C clock—USCI_B0/I2C mode

P3.1/UCB0SIMO/ UCB0SDA

70 D12 I/O

General-purpose digital I/O / slave in/master out of USCI_B0/SPI mode, I2C

data—USCI_B0/I2C mode P3.0/UCB0STE 71 D11 I/O General-purpose digital I/O / slave transmit enable—USCI_B0/SPI mode P2.7/ADC12CLK/

DMAE0

72 E9 I/O General-purpose digital I/O / conversion clock—12-bit ADC / DMA Channel 0 external trigger

P2.6/CAOUT 73 C12 I/O General-purpose digital I/O / Comparator_A output P2.5/UCA0RXD 74 C11 I/O General-purpose digital I/O / receive data in—USCI_A0/UART or IrDA mode P2.4/UCA0TXD 75 B12 I/O General-purpose digital I/O / transmit data out—USCI_A0/UART or IrDA mode

P2.3/TB2 76 A11 I/O

General-purpose digital I/O / T imer_B7 CCR2. Capture: CCI2A/CCI2B input, compare: Out2

output P2.2/TB1 77 E8 I/O

General-purpose digital I/O / Timer_B7 CCR1. Capture: CCI1A/CCI1B input, compare: Out1

output P2.1/TB0 78 D8 I/O

General-purpose digital I/O / Timer_B7 CCR0. Capture: CCI0A/CCI0B input, compare: Out0

output P2.0/TA2 79 A10 I/O General-purpose digital I/O / Timer_A Capture: CCI2A input, compare: Out2 output P1.7/CA1 80 B10 I/O General-purpose digital I/O / Comparator_A input P1.6/CA0 81 A9 I/O General-purpose digital I/O / Comparator_A input

P1.5/TACLK/ACLK 82 B9 I/O

General-purpose digital I/O / Timer_A, clock signal TACLK input / ACLK output (divided by

1, 2, 4, or 8) P1.4/TBCLK/SMCLK 83 B8 I/O

General-purpose digital I/O / input clock TBCLK—Timer_B7 / submain system clock SMCLK

output P1.3/TBOUTH/SVSOUT 84 A8 I/O

General-purpose digital I/O / switch all PWM digital output ports to high

impedance—Timer_B7 TB0 to TB6 / SVS: output of SVS comparator P1.2/TA1 85 D7 I/O General-purpose digital I/O / Timer_A, Capture: CCI1A input, compare: Out1 output

P1.1/TA0/MCLK 86 E7 I/O

General-purpose digital I/O / Timer_A. Capture: CCI0B input / MCLK output.

Note: TA0 is only an input on this pin / BSL receive P1.0/TA0 87 A7 I/O

General-purpose digital I/O / Timer_A. Capture: CCI0A input, compare: Out0 output / BSL

transmit XT2OUT 88 B7 O Output terminal of crystal oscillator XT2 XT2IN 89 B6 I Input port for crystal oscillator XT2. Only standard crystals can be connected. TDO/TDI 90 A6 I/O Test data output port. TDO/TDI data output or programming data input terminal TDI/TCLK 91 D6 I Test data input or test clock input. The device protection fuse is connected to TDI/TCLK. TMS 92 E6 I Test mode select. TMS is used as an input port for device programming and test. TCK 93 A5 I Test clock. TCK is the clock input port for device programming and test. RST/NMI 94 B5 I Reset input or nonmaskable interrupt input port

P6.0/A0/OA0I0 95 A4 I/O

General-purpose digital I/O / analog input a0—12-bit ADC / OA0 input multiplexer on

+ terminal and − terminal P6.1/A1/OA0O 96 D5 I/O General-purpose digital I/O / analog input a1—12-bit ADC / OA0 output

P6.2/A2/OA0I1 97 B4 I/O

General-purpose digital I/O / analog input a2—12-bit ADC / OA0 input multiplexer on

+ terminal and − terminal

MSP430xG461x

MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 201 1

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

Terminal Functions (Continued)

TERMINAL

NAME

NO.PZNO.

ZQW

I/O DESCRIPTION

98 A3

Analog supply voltage, negative terminal. Supplies SVS, brownout, oscillator , comparator_A, port 1

SS1

(see Note 1) 99 B3 Digital supply voltage, negative terminal

100 A2

Analog supply voltage, positive terminal. Supplies SVS, brownout, oscillator, comparator_A, port 1; must not power up prior to DV

CC1

/DV

CC2

NOTE 1: All unassigned ball locations on the ZQW package should be electrically tied to the ground supply. The shortest ground return path to

the device should be established via ball location B3.

General-Purpose Register

Program Counter

Stack Pointer

Status Register

Constant Generator

General-Purpose Register

PC/R0

SP/R1

SR/CG1/R2

CG2/R3

R12

R13

General-Purpose Register

R10

R11

General-Purpose Register

R14

R15

MSP430xG461x MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 2011

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

short-form description

CPU

The MSP430 CPU has a 16-bit RISC architecture that is highly transparent to the application. All operations, other than program-flow instructions, are performed as register operations in conjunction with seven addressing modes for source operand and four addressing modes for destination operand.

The CPU is integrated with 16 registers that provide reduced instruction execution time. The register-to-register operation execution time is one cycle of the CPU clock.

Four of the registers, R0 to R3, are dedicated as program counter, stack pointer, status register, and constant generator respectively. The remaining registers are general-purpose registers.

Peripherals are connected to the CPU using data, address, and control buses, and can be handled with all instructions.

The MSP430xG461x device family utilizes the MSP430X CPU and is completely backwards compatible with the MSP430 CPU. For a complete description of the MSP430X CPU, see the MSP430x4xx Family User’s Guide (SLAU056).

instruction set

The instruction set consists of the original 51 instructions with three formats and seven address modes and additional instructions for the expanded address range. Each instruction can operate on word and byte data. Table 1 shows examples of the three types of instruction formats; Table 2 shows the address modes.

MSP430xG461x

MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 201 1

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

Table 1. Instruction Word Formats

Dual operands, source-destination e.g., ADD R4,R5 R4 + R5 −−−> R5 Single operands, destination only e.g., CALL R8 PC −−>(TOS), R8−−> PC Relative jump, un/conditional e.g., JNE Jump-on-equal bit = 0

Table 2. Address Mode Descriptions

ADDRESS MODE S D SYNTAX EXAMPLE OPERATION

MOV Rs,Rd MOV R10,R11 R10 —> R11

Indexed F F MOV X(Rn),Y(Rm) MOV 2(R5),6(R6) M(2+R5)—> M(6+R6)

Symbolic (PC relative) F F MOV EDE,TONI M(EDE) —> M(TONI)

Absolute F F MOV & MEM, & TCDAT M(MEM) —> M(TCDAT)

Indirect F MOV @Rn,Y(Rm) MOV @R10,Tab(R6) M(R10) —> M(Tab+R6) Indirect

autoincrement

F MOV @Rn+,Rm MOV @R10+,R11

M(R10) —> R11 R10 + 2—> R10

Immediate F MOV #X,TONI MOV #45,TONI #45 —> M(TONI)

NOTE: S = source D = destination

MSP430xG461x MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 2011

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

operating modes

The MSP430 has one active mode and five software-selectable low-power modes of operation. An interrupt event can wake up the device from any of the five low-power modes, service the request, and restore back to the low-power mode on return from the interrupt program.

The following six operating modes can be configured by software:

D Active mode (AM)

− All clocks are active

D Low-power mode 0 (LPM0)

− CPU is disabled

− ACLK and SMCLK remain active. MCLK is disabled

− FLL+ loop control remains active

D Low-power mode 1 (LPM1)

− CPU is disabled

− FLL+ loop control is disabled

− ACLK and SMCLK remain active, MCLK is disabled

D Low-power mode 2 (LPM2)

− CPU is disabled

− MCLK, FLL+ loop control and DCOCLK are disabled

− DCO’s dc-generator remains enabled

− ACLK remains active

D Low-power mode 3 (LPM3)

− CPU is disabled

− MCLK, FLL+ loop control, and DCOCLK are disabled

− DCO’s dc-generator is disabled

− ACLK remains active

D Low-power mode 4 (LPM4)

− CPU is disabled

− ACLK is disabled

− MCLK, FLL+ loop control, and DCOCLK are disabled

− DCO’s dc-generator is disabled

− Crystal oscillator is stopped

MSP430xG461x

MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 201 1

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

interrupt vector addresses

The interrupt vectors and the power-up start address are located in the address range 0FFFFh to 0FFC0h. The vector contains the 16-bit address of the appropriate interrupt-handler instruction sequence.

Table 3. Interrupt Sources, Flags, and Vectors of MSP430xG461x Configurations

INTERRUPT SOURCE INTERRUPT FLAG SYSTEM INTERRUPT

WORD

ADDRESS

PRIORITY

Power-Up

External Reset

Watchdog

Flash Memory

WDTIFG

KEYV

(see Note 1 and 5)

Reset 0FFFEh 31, highest

NMI

Oscillator Fault

Flash Memory Access Violation

NMIIFG (see Notes 1 and 3)

OFIFG (see Notes 1 and 3)

ACCVIFG (see Notes 1, 2, and 5)

(Non)maskable (Non)maskable (Non)maskable

0FFFCh 30

Timer_B7 TBCCR0 CCIFG0 (see Note 2) Maskable 0FFFAh 29 Timer_B7

TBCCR1 CCIFG1 ... TBCCR6 CCIFG6,

TBIFG (see Notes 1 and 2)

Maskable 0FFF8h 28

Comparator_A CAIFG Maskable 0FFF6h 27

Watchdog Timer+ WDTIFG Maskable 0FFF4h 26

USCI_A0/USCI_B0 Receive UCA0RXIFG, UCB0RXIFG (see Note 1) Maskable 0FFF2h 25

USCI_A0/USCI_B0 Transmit UCA0TXIFG, UCB0TXIFG (see Note 1) Maskable 0FFF0h 24

ADC12 ADC12IFG (see Notes 1 and 2) Maskable 0FFEEh 23

Timer_A3 TACCR0 CCIFG0 (see Note 2) Maskable 0FFECh 22 Timer_A3

TACCR1 CCIFG1 and TACCR2 CCIFG2,

TAIFG (see Notes 1 and 2)

Maskable 0FFEAh 21

I/O Port P1 (Eight Flags) P1IFG.0 to P1IFG.7 (see Notes 1 and 2) Maskable 0FFE8h 20

USART1 Receive URXIFG1 Maskable 0FFE6h 19

USART1 Transmit UTXIFG1 Maskable 0FFE4h 18

I/O Port P2 (Eight Flags) P2IFG.0 to P2IFG.7 (see Notes 1 and 2) Maskable 0FFE2h 17

Basic Timer1/RTC BTIFG Maskable 0FFE0h 16

DMA DMA0IFG, DMA1IFG, DMA2IFG

(see Notes 1 and 2)

Maskable 0FFDEh 15

DAC12 DAC12.0IFG, DAC12.1IFG (see Notes 1 and 2) Maskable 0FFDCh 14

0FFDAh 13

Reserved Reserved (see Note 4)

... ...

Reserved

Reserved (see Note 4)

0FFC0h 0, lowest

NOTES: 1. Multiple source flags

2. Interrupt flags are located in the module.

3. A reset is generated if the CPU tries to fetch instructions from within the module register memory address range (0h to 01FFh). (Non)maskable: the individual interrupt-enable bit can disable an interrupt event, but the general-interrupt enable cannot disable it.

4. The interrupt vectors at addresses 0FFDAh to 0FFC0h are not used in this device and can be used for regular program code if necessary.

5. Access and key violations, KEYV and ACCVIFG, only applicable to F devices.

MSP430xG461x MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 2011

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

special function registers (SFRs)

The MSP430 SFRs are located in the lowest address space and are organized as byte mode registers. SFRs should be accessed with byte instructions.

interrupt enable 1 and 2

7654 0

OFIE WDTIE

321

rw–0 rw–0 rw–0

Address 0h ACCVIE NMIIE

rw–0

WDTIE Watchdog-timer interrupt enable. Inactive if watchdog mode is selected.

Active if watchdog timer is configured as a general-purpose timer. OFIE Oscillator-fault-interrupt enable NMIIE Nonmaskable-interrupt enable ACCVIE Flash access violation interrupt enable

7654 0321

Address 01h

rw–0

BTIE UTXIE1 URXIE1

rw–0 rw–0

UCA0TXIE UCA0RXIE

rw–0 rw–0

UCB0TXIE UCB0RXIE

rw–0 rw–0

UCA0RXIE USCI_A0 receive-interrupt enable UCA0TXIE USCI_A0 transmit-interrupt enable UCB0RXIE USCI_B0 receive-interrupt enable UCB0TXIE USCI_B0 transmit-interrupt enable URXIE1 USART1 UART and SPI receive-interrupt enable UTXIE1 USART1 UART and SPI transmit-interrupt enable BTIE Basic timer interrupt enable

MSP430xG461x

MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 201 1

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

interrupt flag register 1 and 2

7654 0

OFIFG WDTIFG

321

rw–0 rw–1 rw–(0)

Address 02h NMIIFG

WDTIFG: Set on watchdog timer overflow (in watchdog mode) or security key violation

Reset on V

power-on or a reset condition at the RST/NMI pin in reset mode OFIFG: Flag set on oscillator fault NMIIFG: Set via RST

/NMI pin

7654 0321

Address 03h

BTIFG

rw–0

UTXIFG1 URXIFG1

rw–1 rw–0

UCA0TXIFG UCA0RXIFG

rw–0 rw–0

UCB0TXIFG UCB0RXIFG rw–0 rw–0

UCA0RXIFG USCI_A0 receive-interrupt flag UCA0TXIFG USCI_A0 transmit-interrupt flag UCB0RXIFG USCI_B0 receive-interrupt flag UCB0TXIFG USCI_B0 transmit-interrupt flag URXIFG0: USART1: UART and SPI receive flag UTXIFG0: USART1: UART and SPI transmit flag BTIFG: Basic timer flag

module enable registers 1 and 2

7654 0321

Address 04h

7654 0

UTXE1

321

rw–0 rw–0

Address 05h

URXE1 USPIE1

URXE1: USART1: UART mode receive enable UTXE1: USART1: UART mode transmit enable USPIE1: USART1: SPI mode transmit and receive enable

Legend rw:

rw-0,1:

Bit can be read and written.

Bit can be read and written. It is Reset or Set by PUC.

Bit can be read and written. It is Reset or Set by POR.

rw-(0,1):

SFR bit is not present in device

MSP430xG461x MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 2011

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

memory organization

MSP430FG4616 MSP430FG4617 MSP430FG4618 MSP430FG4619

Memory Main: interrupt vector Main: code memory

Size Flash Flash

92KB

0FFFFh − 0FFC0h

018FFFh − 002100h

92KB

0FFFFh − 0FFC0h

019FFFh − 003100h

116KB

0FFFFh − 0FFC0h

01FFFFh − 003100h

120KB

0FFFFh − 0FFC0h

01FFFFh − 002100h

RAM (Total) Size 4KB

020FFh − 01100h

8KB

030FFh − 01100h

8KB

030FFh − 01100h

4KB

020FFh − 01100h

Extended Size 2KB

020FFh − 01900h

6KB

030FFh − 01900h

6KB

030FFh − 01900h

2KB

020FFh − 01900h

Mirrored Size 2KB

018FFh − 01100h

2KB

018FFh − 01100h

2KB

018FFh − 01100h

2KB

018FFh − 01100h

Information memory Size

Flash

256 Byte

010FFh − 01000h

256 Byte

010FFh − 01000h

256 Byte

010FFh − 01000h

256 Byte

010FFh − 01000h

Boot memory Size

ROM

1KB

0FFFh − 0C00h

1KB

0FFFh − 0C00h

1KB

0FFFh − 0C00h

1KB

0FFFh − 0C00h

RAM (mirrored at 018FFh − 01100h)

Size 2KB

09FFh − 0200h

2KB

09FFh − 0200h

2KB

09FFh − 0200h

2KB

09FFh − 0200h

Peripherals 16 bit

8 bit

8-bit SFR

01FFh − 0100h

0FFh − 010h

0Fh − 00h

01FFh − 0100h

0FFh − 010h

0Fh − 00h

01FFh − 0100h

0FFh − 010h

0Fh − 00h

01FFh − 0100h

0FFh − 010h

0Fh − 00h

MSP430CG4616 MSP430CG4617 MSP430CG4618 MSP430CG4619

Memory Main: interrupt vector Main: code memory

Size

ROM ROM

92KB

0FFFFh − 0FFC0h

018FFFh − 002100h

92KB

0FFFFh − 0FFC0h

019FFFh − 003100h

116KB

0FFFFh − 0FFC0h

01FFFFh − 003100h

120KB

0FFFFh − 0FFC0h

01FFFFh − 002100h

RAM (Total) Size 4KB

020FFh − 01100h

8KB

030FFh − 01100h

8KB

030FFh − 01100h

4KB

020FFh − 01100h

Extended Size 2KB

020FFh − 01900h

6KB

030FFh − 01900h

6KB

030FFh − 01900h

2KB

020FFh − 01900h

Mirrored Size 2KB

018FFh − 01100h

2KB

018FFh − 01100h

2KB

018FFh − 01100h

2KB

018FFh − 01100h

Information memory Size

ROM

256 Byte

010FFh − 01000h

256 Byte

010FFh − 01000h

256 Byte

010FFh − 01000h

256 Byte

010FFh − 01000h

Boot memory (Optional on CG)

Size

ROM

1KB

0FFFh − 0C00h

1KB

0FFFh − 0C00h

1KB

0FFFh − 0C00h

1KB

0FFFh − 0C00h

RAM (mirrored at 018FFh − 01100h)

Size 2KB

09FFh − 0200h

2KB

09FFh − 0200h

2KB

09FFh − 0200h

2KB

09FFh − 0200h

Peripherals 16 bit

8 bit

8-bit SFR

01FFh − 0100h

0FFh − 010h

0Fh − 00h

01FFh − 0100h

0FFh − 010h

0Fh − 00h

01FFh − 0100h

0FFh − 010h

0Fh − 00h

01FFh − 0100h

0FFh − 010h

0Fh − 00h

MSP430xG461x

MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 201 1

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

bootstrap loader (BSL)

The MSP430 BSL enables users to program the flash memory or RAM using a UART serial interface. Access to the MSP430 memory via the BSL is protected by user-defined password. A bootstrap loader security key is provided at address 0FFBEh to disable the BSL completely or to disable the erasure of the flash if an invalid password is supplied. The BSL is optional for ROM-based devices. For complete description of the features of the BSL and its implementation, see the application report Features of the MSP430 Bootstrap Loader, literature number SLAA089.

BSLKEY DESCRIPTION

00000h Erasure of flash disabled if an invalid password is supplied

0AA55h BSL disabled

any other value BSL enabled

BSL FUNCTION PZ/ZQW PACKAGE PINS

Data Transmit 87/A7 − P1.0

Data Receive 86/E7 − P1.1

flash memory

The flash memory can be programmed via the JT AG port, the bootstrap loader, or in system by the CPU. The CPU can perform single-byte and single-word writes to the flash memory. Features of the flash memory include:

D Flash memory has n segments of main memory and two segments of information memory (A and B) of

128 bytes each. Each segment in main memory is 512 bytes in size.

D Segments 0 to n may be erased in one step, or each segment may be individually erased. D Segments A and B can be erased individually, or as a group with segments 0 to n.

Segments A and B are also called information memory.

D New devices may have some bytes programmed in the information memory (needed for test during

manufacturing). The user should perform an erase of the information memory prior to the first use.

MSP430xG461x MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 2011

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

peripherals

Peripherals are connected to the CPU through data, address, and control buses and can be handled using all instructions. For complete module descriptions, see the MSP430x4xx Family User’s Guide (SLAU056).

DMA controller

The DMA controller allows movement of data from one memory address to another without CPU intervention. For example, the DMA controller can be used to move data from the ADC12 conversion memory to RAM. Using the DMA controller can increase the throughput of peripheral modules. The DMA controller reduces system power consumption by allowing the CPU to remain in sleep mode without having to awaken to move data to or from a peripheral.

oscillator and system clock

The clock system in the MSP430xG461x family of devices is supported by the FLL+ module, which includes support for a 32768-Hz watch crystal oscillator, an internal digitally controlled oscillator (DCO), and a high-frequency crystal oscillator. The FLL+ clock module is designed to meet the requirements of both low system cost and low power consumption. The FLL+ features digital frequency locked loop (FLL) hardware that, in conjunction with a digital modulator, stabilizes the DCO frequency to a programmable multiple of the watch crystal frequency. The internal DCO provides a fast turn-on clock source and stabilizes in less than 6 μs. The FLL+ module provides the following clock signals:

D Auxiliary clock (ACLK), sourced from a 32768-Hz watch crystal or a high frequency crystal D Main clock (MCLK), the system clock used by the CPU D Sub-Main clock (SMCLK), the subsystem clock used by the peripheral modules D ACLK/n, the buffered output of ACLK, ACLK/2, ACLK/4, or ACLK/8

brownout, supply voltage supervisor

The brownout circuit is implemented to provide the proper internal reset signal to the device during power-on and power-off. The supply voltage supervisor (SVS) circuitry detects if the supply voltage drops below a user selectable level and supports both supply voltage supervision (the device is automatically reset) and supply voltage monitoring (SVM, the device is not automatically reset).

The CPU begins code execution after the brownout circuit releases the device reset. However, V

may not

have ramped to V

CC(min)

at that time. The user must insure the default FLL+ settings are not changed until V

reaches V

CC(min)

. If desired, the SVS circuit can be used to determine when VCC reaches V

CC(min)

digital I/O

There are ten 8-bit I/O ports implemented—ports P1 through P10:

D All individual I/O bits are independently programmable. D Any combination of input, output, and interrupt conditions is possible. D Edge-selectable interrupt input capability for all the eight bits of ports P1 and P2. D Read/write access to port-control registers is supported by all instructions. D Ports P7/P8 and P9/P10 can be accessed word-wise as ports PA and PB respectively.

Basic Timer1 and Real-Time Clock

The Basic Timer1 has two independent 8-bit timers that can be cascaded to form a 16-bit timer/counter. Both timers can be read and written by software. Basic Timer1 is extended to provide an integrated real-time clock (RTC). An int e r n a l calendar compensates for months with less than 31 days and includes leap-year correction.

MSP430xG461x

MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 201 1

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

LCD_A drive with regulated charge pump

The LCD_A driver generates the segment and common signals required to drive an LCD display . The LCD_A controller has dedicated data memory to hold segment drive information. Common and segment signals are generated as defined by the mode. Static, 2-MUX, 3-MUX, and 4-MUX LCDs are supported by this peripheral. The module can provide a LCD voltage independent of the supply voltage with its integrated charge pump. Furthermore it is possible to control the level of the LCD voltage and, thus, contrast by software.

watchdog timer (WDT+)

The primary function of the WDT+ module is to perform a controlled system restart after a software problem occurs. If the selected time interval expires, a system reset is generated. If the watchdog function is not needed in an application, the module can be configured as an interval timer and can generate interrupts at selected time intervals.

universal serial communication interface (USCI)

The USCI modules are used for serial data communication. The USCI module supports synchronous communication protocols like SPI (3 or 4 pin), I2C and asynchronous communication protocols like UART, enhanced UART with automatic baudrate detection, and IrDA.

The USCI_A0 module provides support for SPI (3 or 4 pin), UART, enhanced UART and IrDA. The USCI_B0 module provides support for SPI (3 or 4 pin) and I2C.

USART1

The hardware universal synchronous/asynchronous receive transmit (USART) peripheral module is used for serial data communication. The USART supports synchronous SPI (3 or 4 pin) and asynchronous UART communication protocols, using double-buffered transmit and receive channels.

hardware multiplier

The multiplication operation is supported by a dedicated peripheral module. The module performs 16 16, 16 8, 8 16, and 8 8 bit operations. The module is capable of supporting signed and unsigned multiplication, as well as signed and unsigned multiply and accumulate operations. The result of an operation can be accessed immediately after the operands have been loaded into the peripheral registers. No additional clock cycles are required.

MSP430xG461x MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 2011

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

Timer_A3

Timer_A3 is a 16-bit timer/counter with three capture/compare registers. Timer_A3 can support multiple capture/compares, PWM outputs, and interval timing. Timer_A3 also has extensive interrupt capabilities. Interrupts may be generated from the counter on overflow conditions and from each of the capture/compare registers.

Timer_A3 Signal Connections

Input Pin Number

Device Input Module Input Module Module Output

Output Pin Number

PZ/ZQW

Device Input

Signal

Module Input

Name

Module

Block

Module Output

Signal

PZ/ZQW

82/B9 - P1.5 TACLK TACLK

ACLK ACLK

SMCLK SMCLK

Timer NA

82/B9 - P1.5 TACLK INCLK 87/A7 - P1.0 TA0 CCI0A

87/A7 - P1.0

86/E7 - P1.1 TA0 CCI0B

GND

CCR0 TA0

85/D7 - P1.2 TA1 CCI1A

85/D7 - P1.2

CAOUT (internal) CCI1B

ADC12 (internal)

GND

CCR1 TA1

79/A10 - P2.0 TA2 CCI2A

79/A10 - P2.0

ACLK (internal) CCI2B

GND

CCR2 TA2

MSP430xG461x

MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 201 1

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

Timer_B7

Timer_B7 is a 16-bit timer/counter with seven capture/compare registers. Timer_B7 can support multiple capture/compares, PWM outputs, and interval timing. Timer_B7 also has extensive interrupt capabilities. Interrupts may be generated from the counter on overflow conditions and from each of the capture/compare registers.

Timer_B7 Signal Connections

Input Pin Number

Device Input Module Input Module Module Output

Output Pin Number

PZ/ZQW

Device Input

Signal

Module Input

Name

Module

Block

Module Output

Signal

PZ/ZQW

83/B8 - P1.4 TBCLK TBCLK

ACLK ACLK

SMCLK SMCLK

Timer NA

83/B8 - P1.4 TBCLK INCLK 78/D8 - P2.1 TB0 CCI0A

78/D8 - P2.1

78/D8 - P2.1 TB0 CCI0B

ADC12 (internal)

GND

CCR0 TB0

77/E8 - P2.2 TB1 CCI1A

77/E8 - P2.2

77/E8 - P2.2 TB1 CCI1B

ADC12 (internal)

GND

CCR1 TB1

76/A11 - P2.3 TB2 CCI2A

76/A11 - P2.3

76/A11 - P2.3 TB2 CCI2B

GND

CCR2 TB2

67/E12 - P3.4 TB3 CCI3A

67/E12 - P3.4

67/E12 - P3.4 TB3 CCI3B

GND

CCR3 TB3

66/G9 - P3.5 TB4 CCI4A

66/G9 - P3.5

66/G9 - P3.5 TB4 CCI4B

GND

CCR4 TB4

65/F11 - P3.6 TB5 CCI5A

65/F11 - P3.6

65/F11 - P3.6 TB5 CCI5B

GND

CCR5 TB5

64/F12 - P3.7 TB6 CCI6A

64/F12 - P3.7

ACLK (internal) CCI6B

GND

CCR6 TB6

MSP430xG461x MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 2011

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

Comparator_A

The primary function of the comparator_A module is to support precision slope analog-to-digital conversions, battery-voltage supervision, and monitoring of external analog signals.

ADC12

The ADC12 module supports fast, 12-bit analog-to-digital conversions. The module implements a 12-bit SAR core, sample select control, reference generator and a 16 word conversion-and-control buffer. The conversion-and-control buffer allows up to 16 independent ADC samples to be converted and stored without any CPU intervention.

DAC12

The DAC12 module is a 12-bit, R-ladder, voltage output DAC. The DAC12 may be used in 8- or 12-bit mode, and may be used in conjunction with the DMA controller. When multiple DAC12 modules are present, they may be grouped together for synchronous operation.

The MSP430xG461x has three configurable low-current general-purpose operational amplifiers. Each OA input and output terminal is software-selectable and offer a flexible choice of connections for various applications. The OA op amps primarily support front-end analog signal conditioning prior to analog-to-digital conversion.

OA Signal Connections

Input Pin

Number

Device Input

Module Input

Module

Out

Device Out

Output Pin

Number

Signal Name Block

Output

Signal

Output

Signal

95 - P6.0 OA0I0 OA0I0

OA0O 96 - P6.1

97 - P6.2 OA0I1 OA0I1

OA0O ADC12 (internal)

DAC12_0OUT

(internal)

DAC12_0OUT

OA0 OA0OUT

DAC12_1OUT

(internal)

DAC12_1OUT

3 - P6.4 OA1I0 OA1I0

OA1O 2 - P6.3

13 - P5.0 OA1I1 OA1I1

OA1O 13- P5.0

DAC12_0OUT

(internal)

DAC12_0OUT

OA1 OA1OUT

OA1O ADC12 (internal)

DAC12_1OUT

(internal)

DAC12_1OUT

5 - P6.6 OA2I0 OA2I0

OA2O 4 - P6.5

14 - P10.7 OA2I1 OA2I1

OA2O 14 - P10.7

DAC12_0OUT

(internal)

DAC12_0OUT

OA2 OA2OUT

OA2O ADC12 (internal)

DAC12_1OUT

(internal)

DAC12_1OUT

MSP430xG461x

MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 201 1

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

peripheral file map

PERIPHERALS WITH WORD ACCESS

Watchdog+ Watchdog timer control WDTCTL 0120h Timer_B7

Capture/compare register 6 TBCCR6 019Eh

Capture/compare register 5 TBCCR5 019Ch Capture/compare register 4 TBCCR4 019Ah Capture/compare register 3 TBCCR3 0198h Capture/compare register 2 TBCCR2 0196h Capture/compare register 1 TBCCR1 0194h Capture/compare register 0 TBCCR0 0192h Timer_B register TBR 0190h Capture/compare control 6 TBCCTL6 018Eh Capture/compare control 5 TBCCTL5 018Ch Capture/compare control 4 TBCCTL4 018Ah Capture/compare control 3 TBCCTL3 0188h Capture/compare control 2 TBCCTL2 0186h Capture/compare control 1 TBCCTL1 0184h Capture/compare control 0 TBCCTL0 0182h Timer_B control TBCTL 0180h Timer_B interrupt vector TBIV 011Eh

Timer_A3

Capture/compare register 2 TACCR2 0176h

Capture/compare register 1 TACCR1 0174h Capture/compare register 0 TACCR0 0172h Timer_A register TAR 0170h Capture/compare control 2 TACCTL2 0166h Capture/compare control 1 TACCTL1 0164h Capture/compare control 0 TACCTL0 0162h Timer_A control TACTL 0160h Timer_A interrupt vector TAIV 012Eh

Hardware

Sum extend SUMEXT 013Eh

Multiplier

Result high word RESHI 013Ch Result low word RESLO 013Ah Second operand OP2 0138h Multiply signed + accumulate/operand1 MACS 0136h Multiply + accumulate/operand1 MAC 0134h Multiply signed/operand1 MPYS 0132h Multiply unsigned/operand1 MPY 0130h

Flash

Flash control 3 FCTL3 012Ch

(FG devices only)

Flash control 2 FCTL2 012Ah Flash control 1 FCTL1 0128h

MSP430xG461x MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 2011

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

peripheral file map (continued)

PERIPHERALS WITH WORD ACCESS (CONTINUED)

DMA

DMA module control 0 DMACTL0 0122h DMA module control 1 DMACTL1 0124h DMA interrupt vector DMAIV 0126h

DMA Channel 0

DMA channel 0 control DMA0CTL 01D0h DMA channel 0 source address DMA0SA 01D2h DMA channel 0 destination address DMA0DA 01D6h DMA channel 0 transfer size DMA0SZ 01DAh

DMA Channel 1

DMA channel 1 control DMA1CTL 01DCh DMA channel 1 source address DMA1SA 01DEh DMA channel 1 destination address DMA1DA 01E2h DMA channel 1 transfer size DMA1SZ 01E6h

DMA Channel 2

DMA channel 2 control DMA2CTL 01E8h DMA channel 2 source address DMA2SA 01EAh DMA channel 2 destination address DMA2DA 01EEh DMA channel 2 transfer size DMA2SZ 01F2h

MSP430xG461x

MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 201 1

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

peripheral file map (continued)

PERIPHERALS WITH WORD ACCESS (CONTINUED)

ADC12

Conversion memory 15 ADC12MEM15 015Eh

See also Peripherals

With Byte Access

Conversion memory 13 ADC12MEM13 015Ah

Conversion memory 12 ADC12MEM12 0158h Conversion memory 11 ADC12MEM11 0156h Conversion memory 10 ADC12MEM10 0154h Conversion memory 9 ADC12MEM9 0152h Conversion memory 8 ADC12MEM8 0150h Conversion memory 7 ADC12MEM7 014Eh Conversion memory 6 ADC12MEM6 014Ch Conversion memory 5 ADC12MEM5 014Ah Conversion memory 4 ADC12MEM4 0148h Conversion memory 3 ADC12MEM3 0146h Conversion memory 2 ADC12MEM2 0144h Conversion memory 1 ADC12MEM1 0142h Conversion memory 0 ADC12MEM0 0140h Interrupt-vector-word register ADC12IV 01A8h Inerrupt-enable register ADC12IE 01A6h Inerrupt-flag register ADC12IFG 01A4h Control register 1 ADC12CTL1 01A2h Control register 0 ADC12CTL0 01A0h

DAC12

DAC12_1 data DAC12_1DAT 01CAh DAC12_1 control DAC12_1CTL 01C2h DAC12_0 data DAC12_0DAT 01C8h DAC12_0 control DAC12_0CTL 01C0h

Port PA

Port PA selection PASEL 03Eh Port PA direction PADIR 03Ch Port PA output PAOUT 03Ah Port PA input PAIN 038h

Port PB

Port PB selection PBSEL 00Eh Port PB direction PBDIR 00Ch Port PB output PBOUT 00Ah Port PB input PBIN 008h

MSP430xG461x MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 2011

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

peripheral file map (continued)

PERIPHERALS WITH BYTE ACCESS

OA2 Operational Amplifier 2 control register 1

Operational Amplifier 2 control register 0

OA2CTL1 OA2CTL0

0C5h 0C4h

OA1 Operational Amplifier 1 control register 1

Operational Amplifier 1 control register 0

OA1CTL1 OA1CTL0

0C3h 0C2h

OA0 Operational Amplifier 0 control register 1

Operational Amplifier 0 control register 0

OA0CTL1 OA0CTL0

0C1h 0C0h

LCD_A LCD Voltage Control 1

LCD Voltage Control 0 LCD Voltage Port Control 1 LCD Voltage Port Control 0 LCD memory 20 : LCD memory 16 LCD memory 15 : LCD memory 1 LCD control and mode

LCDAVCTL1 LCDAVCTL0 LCDAPCTL1 LCDAPCTL0 LCDM20 : LCDM16 LCDM15 : LCDM1 LCDCTL

0AFh 0AEh 0ADh 0ACh 0A4h : 0A0h 09Fh : 091h 090h

ADC12

ADC memory-control register 15 ADC12MCTL15 08Fh

(Memory control

ADC memory-control register 14 ADC12MCTL14 08Eh

registers require byte

ADC memory-control register 13 ADC12MCTL13 08Dh

access

)

ADC memory-control register 12 ADC12MCTL12 08Ch ADC memory-control register 11 ADC12MCTL11 08Bh ADC memory-control register 10 ADC12MCTL10 08Ah ADC memory-control register 9 ADC12MCTL9 089h ADC memory-control register 8 ADC12MCTL8 088h ADC memory-control register 7 ADC12MCTL7 087h ADC memory-control register 6 ADC12MCTL6 086h ADC memory-control register 5 ADC12MCTL5 085h ADC memory-control register 4 ADC12MCTL4 084h ADC memory-control register 3 ADC12MCTL3 083h ADC memory-control register 2 ADC12MCTL2 082h ADC memory-control register 1 ADC12MCTL1 081h ADC memory-control register 0 ADC12MCTL0 080h

USART1

Transmit buffer U1TXBUF 07Fh Receive buffer U1RXBUF 07Eh Baud rate U1BR1 07Dh Baud rate U1BR0 07Ch Modulation control U1MCTL 07Bh Receive control U1RCTL 07Ah Transmit control U1TCTL 079h USART control U1CTL 078h

MSP430xG461x

MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 201 1

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

peripheral file map (continued)

PERIPHERALS WITH BYTE ACCESS (CONTINUED)

USCI

USCI I2C Slave Address UCBI2CSA 011Ah USCI I2C Own Address UCBI2COA 0118h USCI Synchronous Transmit Buffer UCBTXBUF 06Fh USCI Synchronous Receive Buffer UCBRXBUF 06Eh USCI Synchronous Status UCBSTAT 06Dh USCI I2C Interrupt Enable UCBI2CIE 06Ch USCI Synchronous Bit Rate 1 UCBBR1 06Bh USCI Synchronous Bit Rate 0 UCBBR0 06Ah USCI Synchronous Control 1 UCBCTL1 069h USCI Synchronous Control 0 UCBCTL0 068h USCI Transmit Buffer UCATXBUF 067h USCI Receive Buffer UCARXBUF 066h USCI Status UCASTAT 065h USCI Modulation Control UCAMCTL 064h USCI Baud Rate 1 UCABR1 063h USCI Baud Rate 0 UCABR0 062h USCI Control 1 UCACTL1 061h USCI Control 0 UCACTL0 060h USCI IrDA Receive Control UCAIRRCTL 05Fh USCI IrDA Transmit Control UCAIRTCTL 05Eh USCI LIN Control UCAABCTL 05Dh

Comparator_A

Comparator_A port disable CAPD 05Bh

Comparator_A control 2 CACTL2 05Ah Comparator_A control 1 CACTL1 059h

BrownOUT, SVS SVS control register (Reset by brownout signal) SVSCTL 056h FLL+Clock

FLL+ Control 1 FLL_CTL1 054h FLL+ Control 0 FLL_CTL0 053h System clock frequency control SCFQCTL 052h System clock frequency integrator SCFI1 051h System clock frequency integrator SCFI0 050h

RTC (Basic Timer 1)

Real Time Clock Year High Byte RTCYEARH 04Fh

()

Real Time Clock Year Low Byte RTCYEARL 04Eh Real Time Clock Month RTCMON 04Dh Real Time Clock Day of Month RTCDAY 04Ch Basic Timer1 Counter 2 BTCNT2 047h Basic Timer1 Counter 1 BTCNT1 046h Real Time Counter 4 (Real Time Clock Day of Week)

RTCNT4 (RTCDOW)

045h

Real Time Counter 3 (Real Time Clock Hour)

RTCNT3 (RTCHOUR)

044h

Real Time Counter 2 (Real Time Clock Minute)

RTCNT2 (RTCMIN)

043h

Real Time Counter 1 (Real Time Clock Second)

RTCNT1 (RTCSEC)

042h

Real Time Clock Control RTCCTL 041h Basic Timer1 Control BTCTL 040h

MSP430xG461x MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 2011

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

peripheral file map (continued)

PERIPHERALS WITH BYTE ACCESS (CONTINUED)

Port P10 Port P10 selection P10SEL 00Fh

Port P10 direction P10DIR 00Dh Port P10 output P10OUT 00Bh Port P10 input P10IN 009h

Port P9 Port P9 selection P9SEL 00Eh

Port P9 direction P9DIR 00Ch Port P9 output P9OUT 00Ah Port P9 input P9IN 008h

Port P8 Port P8 selection P8SEL 03Fh

Port P8 direction P8DIR 03Dh Port P8 output P8OUT 03Bh Port P8 input P8IN 039h

Port P7 Port P7 selection P7SEL 03Eh

Port P7 direction P7DIR 03Ch Port P7 output P7OUT 03Ah Port P7 input P7IN 038h

Port P6

Port P6 selection P6SEL 037h Port P6 direction P6DIR 036h Port P6 output P6OUT 035h Port P6 input P6IN 034h

Port P5

Port P5 selection P5SEL 033h Port P5 direction P5DIR 032h Port P5 output P5OUT 031h Port P5 input P5IN 030h

Port P4

Port P4 selection P4SEL 01Fh Port P4 direction P4DIR 01Eh Port P4 output P4OUT 01Dh Port P4 input P4IN 01Ch

Port P3

Port P3 selection P3SEL 01Bh Port P3 direction P3DIR 01Ah Port P3 output P3OUT 019h Port P3 input P3IN 018h

Port P2

Port P2 selection P2SEL 02Eh Port P2 interrupt enable P2IE 02Dh Port P2 interrupt-edge select P2IES 02Ch Port P2 interrupt flag P2IFG 02Bh Port P2 direction P2DIR 02Ah Port P2 output P2OUT 029h Port P2 input P2IN 028h

Port P1

Port P1 selection P1SEL 026h Port P1 interrupt enable P1IE 025h Port P1 interrupt-edge select P1IES 024h Port P1 interrupt flag P1IFG 023h Port P1 direction P1DIR 022h Port P1 output P1OUT 021h Port P1 input P1IN 020h

MSP430xG461x

MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 201 1

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

peripheral file map (continued)

PERIPHERALS WITH BYTE ACCESS (CONTINUED)

Special functions

SFR module enable 2 ME2 005h

SFR module enable 1 ME1 004h SFR interrupt flag 2 IFG2 003h SFR interrupt flag 1 IFG1 002h SFR interrupt enable 2 IE2 001h SFR interrupt enable 1 IE1 000h

MSP430xG461x MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 2011

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

absolute maximum ratings over operating free-air temperature (unless otherwise noted)

†

Voltage range applied at VCC to VSS −0.3 V to 4.1 V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Voltage range applied to any pin (see Note) −0.3 V to V

+ 0.3 V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Diode current at any device terminal . ±2 mA. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Storage temperature range, T

stg

: Unprogrammed device −55°C to 150°C. . . . . . . . . . . . . . . . . . . . . . . . . . . .

Programmed device −40°C to 85°C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

†

Stresses beyond those listed under “absolute maximum ratings” may cause permanent damage to the device. These are stress ratings only , a nd functional operation of the device at these or any other conditions beyond those indicated under “recommended operating conditions” is not implied. Exposure to absolute-maximum-rated conditions for extended periods may affect device reliability.

NOTE: All voltages referenced to V

SS.

The JT AG fuse-blow voltage, VFB, is allowed to exceed the absolute maximum rating. The voltage is applied

to the TDI/TCLK pin when blowing the JTAG fuse.

recommended operating conditions

MIN NOM MAX UNITS

Supply voltage during program execution (see Note 1), V

(AVCC = DV

CC1/2

= VCC)

MSP430xG461x 1.8 3.6 V

Supply voltage during flash memory programming (see Note 1), V

(AVCC = DV

CC1/2

= VCC)

MSP430FG461x 2.7 3.6 V

Supply voltage during program execution, SVS enabled and PORON = 1 (see Note 1 and Note 2), V

(AVCC = DV

CC1/2

= VCC)

MSP430xG461x 2 3.6 V

Supply voltage (see Note 1), V

(AVSS = DV

SS1/2

= VSS) 0 0 V

Operating free-air temperature range, T

MSP430xG461x −40 85 °C

LF selected, XTS_FLL = 0 Watch crystal 32.768

LFXT1 crystal frequency, f

(LFXT1)

XT1 selected, XTS_FLL = 1 Ceramic resonator 450 8000

kHz

(

see Note

XT1 selected, XTS_FLL = 1 Crystal 1000 8000

kHz

Ceramic resonator 450 8000

XT2 crystal frequency, f

(XT2)

Crystal 1000 8000

kHz

VCC = 1.8 V DC 3.0

Processor frequency (signal MCLK), f

(Sy

stem

)

VCC = 2.0 V DC 4.6

MHz

Processor frequency (signal MCLK), f

(System)

VCC = 3.6 V DC 8.0

MHz

NOTES: 1. It is recommended to power AVCC and DVCC from the same source. A maximum difference of 0.3 V between A VCC and DVCC can

be tolerated during power up and operation.

2. The minimum operating supply voltage is defined according to the trip point where POR is going active by decreasing the supply voltage. POR is going inactive when the supply voltage is raised above the minimum supply voltage plus the hysteresis of the SVS circuitry.

3. In LF mode, the LFXT1 oscillator requires a watch crystal. In XT1 mode, LFXT1 accepts a ceramic resonator or a crystal.

1.8 3.62.7 3

3.0 MHz

8.0 MHz

Supply Voltage − V

Supply voltage range, MSP430FG461x, during flash memory programming

Supply voltage range, MSP430xG461x, during program execution

2.0

4.6 MHz

System

(MHz)

Figure 1. Frequency vs Supply Voltage, Typical Characteristic

MSP430xG461x

MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 201 1

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

electrical characteristics over recommended operating free-air temperature (unless otherwise noted)

supply current into AVCC + DVCC excluding external current

PARAMETER TEST CONDITIONS MIN TYP MAX UNIT

Active mode (see Note 1 and Note 4)

VCC = 2.2 V 280 370

()

(MCLK)

= f

(SMCLK)

= 1 MHz,

= 32,768 Hz

CG461x

TA = −40°C to 85°C

VCC = 3 V 470 580

μA

(AM)

(ACLK)

= 32,

768 Hz

XTS=0, SELM=(0,1)

VCC = 2.2 V 400 480

(FG461x: Program executes from flash)

FG461x

TA = −40°C to 85°C

VCC = 3 V 600 740

μA

Low-power mode (LPM0) xG461x

VCC = 2.2 V 45 70

(LPM0)

Low power mode (LPM0)

(see Note 1 and Note 4)

xG461x

TA = −40°C to 85°C

VCC = 3 V 75 110

μA

Low-power mode (LPM2), f

= f

= 0 MHz,

VCC = 2.2 V 11 20

(LPM2)

(MCLK)

= f

(SMCLK)

= 0

MHz

(ACLK)

= 32,768 Hz, SCG0 = 0 (see Note 2 and

Note 4)

= −40°C to 85°C

VCC = 3 V 17 24

μA

TA = −40°C 1.3 4.0

Low-power mode (LPM3)

TA = 25°C

1.3 4.0

(MCLK)

(SMCLK)

= 0

MHz

(

ACLK

)

= 32,768 Hz, SCG0 = 1

= 60°C

VCC = 2.2 V

2.22 6.5

(ACLK)

32,768 Hz, SCG0 1

Basic Timer1 enabled, ACLK selected

TA = 85°C 6.5 15.0

(LPM3)

LCD_A enabled, LCDCPEN = 0;

TA = −40°C 1.9 5.0

μA

(static mode; f

LCD

(ACLK)

/32)

(see Note 2 and Note 3 and Note 4)

= 25°C

1.9 5.0

(see Note 2 and Note 3 and Note 4)

TA = 60°C

VCC = 3 V

2.5 7.5 TA = 85°C 7.5 18.0 TA = −40°C 1.5 5.5

Low-power mode (LPM3)

TA = 25°C

1.5 5.5

(MCLK)

(SMCLK)

= 0

MHz

(

ACLK

)

= 32,768 Hz, SCG0 = 1

= 60°C

VCC = 2.2 V

2.8 7.0

(ACLK)

32,768 Hz, SCG0 1

Basic Timer1 enabled, ACLK selected

TA = 85°C 7.2 17.0

(LPM3)

LCD_A enabled, LCDCPEN = 0;

−

TA = −40°C 2.5 6.5

μA

(4−mux mode; f

LCD

(ACLK)

/32)

(see Note 2 and Note 3 and Note 4)

= 25°C

2.5 6.5

(see Note 2 and Note 3 and Note 4)

TA = 60°C

VCC = 3 V

3.2 8.0 TA = 85°C 8.5 20.0 TA = −40°C 0.13 1.0 TA = 25°C

0.22 1.0

TA = 60°C

VCC = 2.2 V

0.9 2.5

ow-power mode

(LPM4)

= 0 MHz, f

= 0 MHz,

= 85°C 4.3 12.5

(LPM4)

(MCLK)

= 0

MHz, f

(SMCLK)

= 0

MHz

(ACLK)

= 0 Hz, SCG0 = 1

TA = −40°C 0.13 1.6

μA

(ACLK)

(see Note 2 and Note 4)

= 25°C

0.3 1.6 TA = 60°C

VCC = 3 V

1.1 3.0 TA = 85°C 5.0 15.0

NOTES: 1. Timer_B is clocked by f

(DCOCLK)

= f

(DCO)

= 1 MHz. All inputs are tied to 0 V or to VCC. Outputs do not source or sink any current.

2. All inputs are tied to 0 V or to V

. Outputs do not source or sink any current.

3. The LPM3 currents are characterized with a Micro Crystal CC4V−T1A (9 pF) crystal and OSCCAPx = 1h.

4. Current for brownout included.

Current consumption of active mode versus system frequency, F version:

(AM)

= I

(AM)

[1 MHz] × f

(System)

[MHz]

Current consumption of active mode versus supply voltage, F version:

(AM)

= I

(AM) [3 V]

+ 200 μA/V × (VCC – 3 V)

MSP430xG461x MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 2011

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

electrical characteristics over recommended operating free-air temperature (unless otherwise noted) (continued)

Schmitt-trigger inputs − Ports P1 to P10, RST/NMI, JTAG (TCK, TMS, TDI/TCLK, TDO/TDI)

PARAMETER TEST CONDITIONS MIN TYP MAX UNIT

VCC = 2.2 V 1.1 1.55

IT+

Positive-going input threshold voltage

= 3 V 1.5 1.98

VCC = 2.2 V 0.4 0.9

IT−

Negative-going input threshold voltage

= 3 V 0.9 1.3

VCC = 2.2 V 0.3 1.1

hys

Input voltage hysteresis (V

IT+

− V

IT−

)

VCC = 3 V 0.5 1

inputs Px.x, TAx, TBx

PARAMETER TEST CONDITIONS V

MIN TYP MAX UNIT

Port P1, P2: P1.x to P2.x, external trigger signal

2.2 V 62

(int)

External interrupt timing

Port P1, P2: P1.x to P2.x, external trigger signal

for the interrupt flag, (see Note 1)

3 V 50

Timer_A, Timer_B capture

TA0, TA1, TA2 2.2 V 62

(cap)

Timer_A, Timer_B capture

timing

TB0, TB1, TB2, TB3, TB4, TB5, TB6

3 V 50

(TAext)

Timer_A, Timer_B clock

2.2 V 8

(TBext)

frequency externally applied to pin

TACLK, TBCLK, INCLK: t

(H)

= t

(L)

3 V 10

MHz

(TAint)

Timer_A, Timer_B clock

2.2 V 8

(TBint)

Timer_A, Timer_B clock

frequency

SMCLK or ACLK signal selected

3 V 10

MHz

NOTES: 1. The external signal sets the interrupt flag every time the minimum t

(int)

parameters are met. It may be set even with trigger signals

shorter than t

(int)

leakage current − Ports P1 to P10 (see Note 1)

PARAMETER TEST CONDITIONS MIN TYP MAX UNIT

lkg(Px.y)

Leakage current

Port Px

(Px.y)

(see Note 2)

(1 ≤ x ≤ 10, 0 ≤ y ≤ 7)

VCC = 2.2 V/3 V ±50 nA

NOTES: 1. The leakage current is measured with VSS or VCC applied to the corresponding pin(s), unless otherwise noted.

2. The port pin must be selected as input.

MSP430xG461x

MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 201 1

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

electrical characteristics over recommended operating free-air temperature (unless otherwise noted) (continued)

outputs − Ports P1 to P10

PARAMETER TEST CONDITIONS MIN TYP MAX UNIT

OH(max)

= −1.5 mA, V

= 2.2 V, See Note 1 VCC−0.25 V

OH(max)

= −6 mA, V

= 2.2 V, See Note 2 VCC−0.6 V

High-level output voltage

OH(max)

= −1.5 mA, V

= 3 V, See Note 1 VCC−0.25 V

OH(max)

= −6 mA, V

= 3 V, See Note 2 VCC−0.6 V

OL(max)

= 1.5 mA, V

= 2.2 V, See Note 1 V

VSS+0.25

OL(max)

= 6 mA, V

= 2.2 V, See Note 2 V

VSS+0.6

Low-level output voltage

OL(max)

= 1.5 mA, V

= 3 V, See Note 1 V

VSS+0.25

OL(max)

= 6 mA, V

= 3 V, See Note 2 V

VSS+0.6

NOTES: 1. The maximum total current, I

OH(max)

and I

OL(max),

for all outputs combined, should not exceed ±12 mA to satisfy the maximum

specified voltage drop.

2. The maximum total current, I

OH(max)

and I

OL(max),

for all outputs combined, should not exceed ±48 mA to satisfy the maximum

specified voltage drop.

output frequency

PARAMETER TEST CONDITIONS MIN TYP MAX UNIT

CL = 20 pF,

= 2.2 V DC 10 MHz

(Px.y)

(1 ≤ x ≤ 10, 0 ≤ y ≤ 7)

= 20 pF,

= ±1.5 mA

= 3 V DC 12 MHz

(MCLK)

P1.1/TA0/MCLK,

(SMCLK)

P1.4/TBCLK/SMCLK,

= 20 pF

= 2.2 V 10 MHz

(ACLK)

P1.5/TACLK/ACLK

= 3 V DC 12 MHz

(ACLK)

= f

(LFXT1)

= f

(XT1)

40% 60%

P1.5/TACLK/ACLK

= 20 pF

(ACLK)

= f

(LFXT1)

= f

(LF)

30% 70%

VCC = 2.2 V / 3 V

(ACLK)

= f

(LFXT1)

50%

P1.1/TA0/MCLK

(MCLK)

= f

(XT1)

40% 60%

(Xdc)

Duty cycle of output frequency

P1.1/TA0/MCLK

= 20 pF,

= 2.2 V / 3 V

(MCLK)

= f

(DCOCLK)

50%−

15 ns

50%

50%+

15 ns

P1.4/TBCLK/SMCLK

(SMCLK)

= f

(XT2)

40% 60%

P1.4/TBCLK/SMCLK

= 20 pF,

= 2.2 V / 3 V

(SMCLK)

= f

(DCOCLK)

50%−

15 ns

50%

50%+

15 ns

MSP430xG461x MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 2011

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

electrical characteristics over recommended ranges of supply voltage and operating free-air temperature (unless otherwise noted) (continued)

typical characteristics − outputs

Figure 2

VOL − Low-Level Output Voltage − V

0.0

5.0

10.0

15.0

20.0

25.0

0.0 0.5 1.0 1.5 2.0 2.5

VCC = 2.2 V P2.0

TYPICAL LOW-LEVEL OUTPUT CURRENT

LOW-LEVEL OUTPUT VOLTAGE

TA = 25°C

TA = 85°C

I − Typical Low-Level Output Current − mA

Figure 3

VOL − Low-Level Output Voltage − V

0.0

10.0

20.0

30.0

40.0

50.0

0.0 0.5 1.0 1.5 2.0 2.5 3.0 3.5

VCC = 3 V P2.0

TYPICAL LOW-LEVEL OUTPUT CURRENT

LOW-LEVEL OUTPUT VOLTAGE

TA = 25°C

TA = 85°C

I − Typical Low-Level Output Current − mA

Figure 4

VOH − High-Level Output Voltage − V

−25.0

−20.0

−15.0

−10.0

−5.0

0.0

0.0 0.5 1.0 1.5 2.0 2.5

VCC = 2.2 V P2.0

TYPICAL HIGH-LEVEL OUTPUT CURRENT

HIGH-LEVEL OUTPUT VOLTAGE

TA = 25°C

TA = 85°C

I − Typical High-Level Output Current − mA

Figure 5

VOH − High-Level Output Voltage − V

−50.0

−40.0

−30.0

−20.0

−10.0

0.0

0.0 0.5 1.0 1.5 2.0 2.5 3.0 3.5

VCC = 3 V P2.0

TYPICAL HIGH-LEVEL OUTPUT CURRENT

HIGH-LEVEL OUTPUT VOLTAGE

TA = 25°C

TA = 85°C

I − Typical High-Level Output Current − mA

MSP430xG461x

MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 201 1

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

electrical characteristics over recommended operating free-air temperature (unless otherwise noted)

wake-up LPM3

PARAMETER TEST CONDITIONS MIN TYP MAX UNIT

f = 1 MHz 6

d(LPM3

)

Delay time

f = 2 MHz

= 2.2 V/3 V

μs

d(LPM3)

Delay time

f = 3 MHz

2.2 V/3 V

μs

RAM

PARAMETER TEST CONDITIONS MIN TYP MAX UNIT

VRAMh CPU halted (see Note 1) 1.6 V

NOTE 1: This parameter defines the minimum supply voltage when the data in program memory RAM remain unchanged. No program execution

should take place during this supply voltage condition.

MSP430xG461x MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 2011

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

electrical characteristics over recommended operating free-air temperature (unless otherwise noted) (continued)

LCD_A

PARAMETER TEST CONDITIONS

MIN TYP MAX UNIT

CC(LCD)

Supply voltage (see Note 2)

Charge pump enabled (LCDCPEN = 1; VLCDx > 0000)

2.2 3.6 V

CC(LCD)

Supply current (see Note 2 )

LCD(typ)

=3 V; LCDCPEN = 1, VLCDx= 1000; all segments on, f

LCD =

ACLK

/32, no LCD connected (see Note 4) T

= 25°C

2.2 V 3 μA

LCD

Capacitor on LCDCAP (see Note 1 and Note 3)

Charge pump enabled (LCDCPEN = 1; VLCDx > 0000)

4.7 μF

LCD

LCD frequency 1.1 kHz

VLCDx = 0000 V

VLCDx = 0001 2.60 VLCDx = 0010 2.66 VLCDx = 0011 2.72 VLCDx = 0100 2.78 VLCDx = 0101 2.84 VLCDx = 0110 2.90 VLCDx = 0111 2.96

LCD

LCD voltage (see Note 3)

VLCDx = 1000

3.02

VLCDx = 1001 3.08 VLCDx = 1010 3.14 VLCDx = 1011 3.20 VLCDx = 1100 3.26 VLCDx = 1101 3.32 VLCDx = 1110 3.38 VLCDx = 1111 3.44 3.60

LCD

LCD driver output impedance

LCD

=3 V; CPEN = 1;

VLCDx = 1000, I

LOAD

=  10 μΑ

2.2 V 10 kΩ

NOTES: 1. Enabling the internal charge pump with an external capacitor smaller than the minimum specified might damage the device.

2. Refer to the supply current specifications I

(LPM3)

for additional current specifications with the LCD_A module active.

3. Segments S 0 through S3 are disabled when the LCD charge pump feature is enabled (LCDCPEN = 1) and cannot be used together with the LCD charge pump. In addition, when using segments S0 through S3 with an external LCD voltage supply, V

LCD

≤ AVCC.

4. Connecting an actual display will increase the current consumption depending on the size of the LCD.

MSP430xG461x

MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 201 1

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

electrical characteristics over recommended operating free-air temperature (unless otherwise noted) (continued)

Comparator_A (see Note 1)

PARAMETER TEST CONDITIONS MIN TYP MAX UNIT

VCC = 2.2 V 25 40

(CC)

CAON=1, CARSEL=0, CAREF=0

VCC = 3 V 45 60

μA

CAON=1, CARSEL=0, CAREF=1/2/3,

VCC = 2.2 V 30 50

(Refladder/RefDiode)

No load at P1.6/CA0 and P1.7/CA1

VCC = 3 V 45 71

μA

(Ref025)

Voltage @ 0.25 VCCnode

PCA0=1, CARSEL=1, CAREF=1, No load at P1.6/CA0 and P1.7/CA1

VCC = 2.2 V / 3 V 0.23 0.24 0.25

(Ref050)

Voltage @ 0.5 VCCnode

PCA0=1, CARSEL=1, CAREF=2, No load at P1.6/CA0 and P1.7/CA1

VCC = 2.2V / 3 V 0.47 0.48 0.5

PCA0=1, CARSEL=1, CAREF=3,

VCC = 2.2 V 390 480 540

(RefVT)

No load at P1.6/CA0 and P1.7/CA1; T

= 85°C

VCC = 3 V 400 490 550

Common-mode input voltage range

CAON=1 VCC = 2.2 V / 3 V 0 VCC−1 V

Vp−V

Offset voltage See Note 2 VCC = 2.2 V / 3 V −30 30 mV

hys

Input hysteresis CAON = 1 VCC = 2.2 V / 3 V 0 0.7 1.4 mV

TA = 25°C,

VCC = 2.2 V 160 210 300

25 C

Overdrive 10 mV, without filter: CAF = 0

VCC = 3 V 80 150 240

(response LH)

TA = 25°C

VCC = 2.2 V 1.4 1.9 3.4

25 C

Overdrive 10 mV, with filter: CAF = 1

VCC = 3 V 0.9 1.5 2.6

μs

TA = 25°C

VCC = 2.2 V 130 210 300

25 C

Overdrive 10 mV, without filter: CAF = 0

VCC = 3 V 80 150 240

(response HL)

TA = 25°C,

VCC = 2.2 V 1.4 1.9 3.4

25 C

Overdrive 10 mV, with filter: CAF = 1

VCC = 3 V 0.9 1.5 2.6

μs

NOTES: 1. The leakage current for the Comparator_A terminals is identical to I

lkg(Px.x)

specification.

2. The input offset voltage can be cancelled by using the CAEX bit to invert the Comparator_A inputs on successive measurements. The two successive measurements are then summed together.

MSP430xG461x MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 2011

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

typical characteristics

TA − Free-Air Temperature − °C

400

450

500

550

600

650

−45 −25 −5 15 35 55 75 95

VCC = 3 V

Figure 6. V

(

RefVT

)

vs Temperature

REF

− Reference Voltage − mV

Typical

REFERENCE VOLTAGE

FREE-AIR TEMPERATURE

Figure 7. V

(

RefVT

)

vs Temperature

TA − Free-Air Temperature − °C

400

450

500

550

600

650

−45 −25 −5 15 35 55 75 95

VCC = 2.2 V

Typical

REFERENCE VOLTAGE

FREE-AIR TEMPERATURE

REF

− Reference Voltage − mV

CAON

V+

CAF

Low-Pass Filter

τ ≈ 2 μs

To Internal Modules

Set CAIFG Flag

CAOUT

V−

0 V

Figure 8. Block Diagram of Comparator_A Module

Overdrive

CAOUT

(response)

V+

V−

400 mV

Figure 9. Overdrive Definition

MSP430xG461x

MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 201 1

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

electrical characteristics over recommended operating free-air temperature (unless otherwise noted) (continued)

POR/brownout reset (BOR) (see Note 1)

PARAMETER TEST CONDITIONS MIN TYP MAX UNIT

d(BOR)

2000 μs

CC(start)

dVCC/dt ≤ 3 V/s (see Figure 10) 0.7 × V

(B_IT−)

Brownout

dVCC/dt ≤ 3 V/s (see Figure 10 through Figure 12) 1.79 V

hys(B_IT−)

(see Notes 2 and 3)

dVCC/dt ≤ 3 V/s (see Figure 10) 70 130 210 mV

(reset)

Pulse length needed at RST/NMI pin to accepted reset internally, V

= 2.2 V/3 V

2 μs

NOTES: 1. The current consumption of the brownout module is already included in the ICC current consumption data.

2. The voltage level V

(B_IT−)

+ V

hys(B_IT−)

is ≤ 1.89V.

3. During power up, the CPU begins code execution following a period of t

d(BOR)

after VCC = V

(B_IT−)

+ V

hys(B_IT−)

. The default

FLL+ settings must not be changed until V

≥ V

CC(min)

, where V

CC(min)

is the minimum supply voltage for the desired

operating frequency. See the MSP430x4xx Family User’s Guide for more information on the brownout/SVS circuit.

typical characteristics

d(BOR)

(B_IT−)

hys(B_IT−)

CC(start)

Figure 10. POR/Brownout Reset (BOR) vs Supply Voltage

CC(drop)

3 V

0.5

1.5

0.001 1 1000

Typical Conditions

1 ns 1 ns

tpw − Pulse Width − μst

− Pulse Width − μs

= 3 V

CC(drop)

− V

Figure 11. V

CC(drop)

Level With a Square Voltage Drop to Generate a POR/Brownout Signal

MSP430xG461x MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 2011

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

typical characteristics (continued)

0.5

1.5

CC(drop)

− Pulse Width − μs

CC(drop)

− V

3 V

0.001 1 1000

tpw − Pulse Width − μs

= t

Typical Conditions

= 3 V

Figure 12. V

CC(drop)

Level With a Triangle Voltage Drop to Generate a POR/Brownout Signal

electrical characteristics over recommended operating free-air temperature (unless otherwise noted)

SVS (supply voltage supervisor/monitor) (see Note 1)

PARAMETER TEST CONDITIONS MIN TYP MAX UNIT

dVCC/dt > 30 V/ms (see Figure 13) 5 150

(SVSR)

dVCC/dt ≤ 30 V/ms 2000

μs

d(SVSon)

SVS on, switch from VLD = 0 to VLD ≠ 0, VCC = 3 V 150 300 μs

settle

VLD ≠ 0

‡

12 μs

(SVSstart)

VLD ≠ 0, VCC/dt ≤ 3 V/s (see Figure 13) 1.55 1.7 V

VLD = 1 70 120 155 mV

hys(SVS_IT−

)

VCC/dt ≤ 3 V/s (see Figure 13)

VLD = 2 .. 14

(SVS_IT−)

x 0.001

(SVS_IT−)

x 0.016

hys(SVS_IT−)

VCC/dt ≤ 3 V/s (see Figure 13), external voltage applied on A7

VLD = 15 4.4 20 mV VLD = 1 1.8 1.9 2.05

VLD = 2 1.94 2.1 2.23 VLD = 3 2.05 2.2 2.35 VLD = 4 2.14 2.3 2.46 VLD = 5 2.24 2.4 2.58 VLD = 6 2.33 2.5 2.69 VLD = 7 2.46 2.65 2.84

VCC/dt ≤ 3 V/s (see Figure 13)

VLD = 8 2.58 2.8 2.97

(SVS_IT−)

VLD = 9 2.69 2.9 3.10

VLD = 10 2.83 3.05 3.26 VLD = 11 2.94 3.2 3.39 VLD = 12 3.11 3.35 3.58

†

VLD = 13 3.24 3.5 3.73

†

VLD = 14 3.43 3.7

†

3.96

†

VCC/dt ≤ 3 V/s (see Figure 13), external voltage applied on A7

VLD = 15 1.1 1.2 1.3

CC(SVS)

(see Note 1)

VLD ≠ 0, VCC = 2.2 V/3 V 10 15 μA

†

The recommended operating voltage range is limited to 3.6 V.

‡

settle

is the settling time that the comparator o/p needs to have a stable level after VLD is switched VLD ≠ 0 to a different VLD value somewhere

between 2 and 15. The overdrive is assumed to be > 50 mV.

NOTE 1: The current consumption of the SVS module is not included in the I

current consumption data.

MSP430xG461x

MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 201 1

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

typical characteristics

CC(start)

(B_IT−)

Brownout

Region

(SVSstart)

(SVS_IT−)

Software Sets VLD>0:

SVS is Active

d(SVSR)

undefined

hys(SVS_IT−)

d(BOR)

Brownout

d(SVSon)

d(BOR)

Set POR

Brown-

Out

Region

SVS Circuit is Active From VLD > to VCC < V(

B_IT−)

SVS

Out

hys(B_IT−)

Figure 13. SVS Reset (SVSR) vs Supply Voltage

0.5

1.5

1 ns 1 ns

− Pulse Width − μs

3 V

1 10 1000

t − Pulse Width − μs

100

3 V

= t

Rectangular Drop

Triangular Drop

CC(drop)

− V

CC(drop)

Figure 14. V

CC(drop)

With a Square Voltage Drop and a Triangle Voltage Drop to Generate an SVS Signal

MSP430xG461x MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 2011

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

electrical characteristics over recommended operating free-air temperature (unless otherwise noted)

DCO

PARAMETER TEST CONDITIONS V

MIN TYP MAX UNIT

(DCOCLK)

(DCO)

=01Eh, FN_8=FN_4=FN_3=FN_2=0, D = 2; DCOPLUS= 0 2.2 V/3 V 1 MHz

2.2 V 0.3 0.65 1.25

(DCO=2)

FN_8=FN_4=FN_3=FN_2=0 ; DCOPLUS = 1

3 V 0.3 0.7 1.3

MHz

2.2 V 2.5 5.6 10.5

(DCO=27)

FN_8=FN_4=FN_3=FN_2=0; DCOPLUS = 1

3 V 2.7 6.1 11.3

MHz

2.2 V 0.7 1.3 2.3

(DCO=2)

FN_8=FN_4=FN_3=0, FN_2=1; DCOPLUS = 1

3 V 0.8 1.5 2.5

MHz

2.2 V 5.7 10.8 18

(DCO=27)

FN_8=FN_4=FN_3=0, FN_2=1; DCOPLUS = 1

3 V 6.5 12.1 20

MHz

2.2 V 1.2 2 3

(DCO=2)

FN_8=FN_4=0, FN_3= 1, FN_2=x; DCOPLUS = 1

3 V 1.3 2.2 3.5

MHz

2.2 V 9 15.5 25

(DCO=27)

FN_8=FN_4=0, FN_3= 1, FN_2=x; DCOPLUS = 1

3 V 10.3 17.9 28.5

MHz

2.2 V 1.8 2.8 4.2

(DCO=2)

FN_8=0, FN_4= 1, FN_3= FN_2=x; DCOPLUS = 1

3 V 2.1 3.4 5.2

MHz

2.2 V 13.5 21.5 33

(DCO=27)

FN_8=0, FN_4=1, FN_3= FN_2=x; DCOPLUS = 1

3 V 16 26.6 41

MHz

2.2 V 2.8 4.2 6.2

(DCO=2)

FN_8=1, FN_4=FN_3=FN_2=x; DCOPLUS = 1

3 V 4.2 6.3 9.2

MHz

2.2 V 21 32 46

(DCO=27)

FN_8=1,FN_4=FN_3=FN_2=x; DCOPLUS = 1

3 V 30 46 70

MHz

Step size between adjacent DCO taps:

1 < TAP ≤ 20 1.06 1.11

Step size between adjacent DCO taps:

Sn = f

DCO(Tap n+1)

/ f

DCO(Tap n)

(see Figure 16 for taps 21 to 27)

TAP = 27 1.07 1.17

Temperature drift, ND = 01Eh, FN_8=FN_4=FN_3=FN_2=0

2.2 V –0.2 –0.3 –0.4

Temperature drift, N

(DCO)

01Eh, FN_8=FN_4=FN_3=FN_2=0

D = 2; DCOPLUS = 0

3 V –0.2 –0.3 –0.4

%/_C

Drift with VCC variation, N

(DCO)

= 01Eh, FN_8=FN_4=FN_3=FN_2=0

D = 2; DCOPLUS = 0

0 5 15 %/V

TA − °CVCC − V

(DCO)

(DCO205C)

(DCO)

(DCO3V)

1.8 3.02.4 3.6

1.0

20 6040 85

1.0

0−20−400

Figure 15. DCO Frequency vs Supply Voltage VCC and vs Ambient Temperature

MSP430xG461x

MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 201 1

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

electrical characteristics over recommended operating free-air temperature (unless otherwise noted) (continued)

12720

1.11

1.17

DCO Tap

- Stepsize Ratio between DCO Taps

Min

Max

1.07

1.06

Figure 16. DCO Tap Step Size

DCO Frequency Adjusted by Bits 2

to 25 in SCFI1 {N

{DCO}

}

FN_2=0 FN_3=0 FN_4=0 FN_8=0

FN_2=1 FN_3=0 FN_4=0 FN_8=0

FN_2=x FN_3=1 FN_4=0 FN_8=0

FN_2=x FN_3=x FN_4=1 FN_8=0

FN_2=x FN_3=x FN_4=x

FN_8=1

Legend

Tolerance at Tap 27

Tolerance at Tap 2

Overlapping DCO Ranges: Uninterrupted Frequency Range

(DCO)

Figure 17. Five Overlapping DCO Ranges Controlled by FN_x Bits

MSP430xG461x MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 2011

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

electrical characteristics over recommended operating free-air temperature (unless otherwise noted)

crystal oscillator, LFXT1 oscillator (see Notes 1 and 2)

PARAMETER TEST CONDITIONS MIN TYP MAX UNIT

OSCCAPx = 0h, VCC = 2.2 V / 3 V 0

Integrated input capacitance

OSCCAPx = 1h, V

= 2.2 V / 3 V 10

XIN

Integrated input capacitance

(see Note 4)

OSCCAPx = 2h, V

= 2.2 V / 3 V 14

OSCCAPx = 3h, VCC = 2.2 V / 3 V 18 OSCCAPx = 0h, VCC = 2.2 V / 3 V 0

Integrated output capacitance

OSCCAPx = 1h, V

= 2.2 V / 3 V 10

XOUT

Integrated output capacitance

(see Note 4)

OSCCAPx = 2h, V

= 2.2 V / 3 V 14

OSCCAPx = 3h, VCC = 2.2 V / 3 V 18

0.2×V

Input levels at XIN VCC = 2.2 V/3 V (see Note 3)

0.8×V

NOTES: 1. The parasitic capacitance from the package and board may be estimated to be 2 pF. The effective load capacitor for the crystal is

XINxCXOUT

) / (C

XIN

+ C

XOUT

). This is independent of XTS_FLL.

2. To improve EMI on the low-power LFXT1 oscillator , particularly in the LF mode (32 kHz), the following guidelines should be ob served.

− Keep the trace between the device and the crystal as short as possible.

− Design a good ground plane around the oscillator pins.

− Prevent crosstalk from other clock or data lines into oscillator pins XIN and XOUT.

− Avoid running PCB traces underneath or adjacent to the XIN and XOUT pins.

− Use assembly materials and praxis to avoid any parasitic load on the oscillator XIN and XOUT pins.

− If conformal coating is used, ensure that it does not induce capacitive/resistive leakage between the oscillator pins.

− Do not route the XOUT line to the JTAG header to support the serial programming adapter as shown in other

documentation. This signal is no longer required for the serial programming adapter.

3. Applies only when using an external logic-level clock source. XTS_FLL must be set. Not applicable when using a crystal or resonator.

4. External capacitance is recommended for precision real-time clock applications; OSCCAPx = 0h.

crystal oscillator, XT2 oscillator (see Note 1)

PARAMETER TEST CONDITIONS MIN NOM MAX UNIT

XT2IN

Integrated input capacitance VCC = 2.2 V/3 V 2 pF

XT2OUT

Integrated output capacitance VCC = 2.2 V/3 V 2 pF

0.2 × V

Input levels at XT2IN VCC = 2.2 V/3 V (see Note 2)

0.8 × V

NOTES: 1. The oscillator needs capacitors at both terminals, with values specified by the crystal manufacturer.

2. Applies only when using an external logic-level clock source. Not applicable when using a crystal or resonator.

MSP430xG461x

MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 201 1

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

electrical characteristics over recommended ranges of supply voltage and operating free-air temperature (unless otherwise noted) (continued)

USCI (UART mode)

PARAMETER TEST CONDITIONS VCC MIN TYP MAX UNIT

USCI

USCI input clock frequency

Internal: SMCLK, ACLK External: UCLK Duty Cycle = 50% ± 10%

SYSTEM

MHz

BITCLK

BITCLK clock frequency (equals Baudrate in MBaud)

2.2V /3 V 1 MHz

UART receive deglitch time

2.2 V 50 150 600

UART receive deglitch time

(see Note 1)

3 V 50 100 600

NOTE 1: Pulses on the UART receive input (UCxRX) shorter than the UART receive deglitch time are suppressed. To ensure that pulses are

correctly recognized their width should exceed the maximum specification of the deglitch time.

USCI (SPI master mode) (see Figure 18 and Figure 19)

PARAMETER TEST CONDITIONS VCC MIN TYP MAX UNIT

USCI

USCI input clock frequency

SMCLK, ACLK Duty Cycle = 50% ± 10%

SYSTEM

MHz

2.2 V 110

SU,MI

SOMI input data setup time

3 V 75

2.2 V 0

HD,MI

SOMI input data hold time

3 V 0

UCLK edge to SIMO valid;

2.2 V 30

VALID,MO

SIMO output data valid time

UCLK edge to SIMO valid;

CL = 20 pF

3 V 20

USCI (SPI slave mode) (see Figure 20 and Figure 21)

PARAMETER TEST CONDITIONS VCC MIN TYP MAX UNIT

STE,LEAD

STE lead time STE low to clock

2.2 V/3 V 50 ns

STE,LAG

STE lag time Last clock to STE high

2.2 V/3 V 10 ns

STE,ACC

STE access time STE low to SOMI data out

2.2 V/3 V 50 ns

STE,DIS

STE disable time STE high to SOMI high impedance

2.2 V/3 V 50 ns

2.2 V 20

SU,SI

SIMO input data setup time

3 V 15

2.2 V 10

HD,SI

SIMO input data hold time

3 V 10

UCLK edge to SOMI valid;

2.2 V 75 110

VALID,SO

SOMI output data valid time

UCLK edge to SOMI valid;

CL = 20 pF

3 V 50 75

MSP430xG461x MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 2011

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

electrical characteristics over recommended ranges of supply voltage and operating free-air temperature (unless otherwise noted) (continued)

UCLK

CKPL = 0

CKPL = 1

SIMO

1/f

UCxCLK

LOW/HIGHtLOW/HIGH

SOMI

SU,MI

HD,MI

VALID,MO

Figure 18. SPI Master Mode, CKPH = 0

UCLK

CKPL = 0

CKPL = 1

SIMO

1/f

UCxCLK

LOW/HIGHtLOW/HIGH

SOMI

SU,MI

HD,MI

VALID,MO

Figure 19. SPI Master Mode, CKPH = 1

MSP430xG461x

MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 201 1

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

electrical characteristics over recommended ranges of supply voltage and operating free-air temperature (unless otherwise noted) (continued)

STE

UCLK

CKPL = 0

CKPL = 1

SOMI

ACC

DIS

1/f

UCxCLK

LOW/HIGHtLOW/HIGH

SIMO

SU,SIMO

HD,SIMO

VALID,SOMI

STE,LEAD

STE,LAG

Figure 20. SPI Slave Mode, CKPH = 0

STE

UCLK

CKPL=0

CKPL=1

STE,LEAD

STE,LAG

ACC

DIS

LOW/HIGHtLOW/HIGH

SU,SI

HD,SI

VALID,SO

SOMI

SIMO

1/f

UCxCLK

Figure 21. SPI Slave Mode, CKPH = 1

MSP430xG461x MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 2011

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

electrical characteristics over recommended ranges of supply voltage and operating free-air temperature (unless otherwise noted) (continued)

USCI (I2C mode) (see Figure 22)

PARAMETER TEST CONDITIONS VCC MIN TYP MAX UNIT

USCI

USCI input clock frequency

Internal: SMCLK, ACLK External: UCLK Duty Cycle = 50% ± 10%

SYSTEM

MHz

SCL

SCL clock frequency 2.2 V/3 V 0 400 kHz

SCL

≤ 100kHz 2.2 V/3 V 4.0

HD,STA

Hold time (repeated) START

SCL

> 100kHz 2.2 V/3 V 0.6

μs

SCL

≤ 100kHz 2.2 V/3 V 4.7

SU,STA

Set−up time for a repeated START

SCL

> 100kHz 2.2 V/3 V 0.6

μs

HD,DAT

Data hold time 2.2 V/3 V 0 ns

SU,DAT

Data set−up time 2.2 V/3 V 250 ns

SU,STO

Set−up time for STOP 2.2 V/3 V 4.0 μs Pulse width of spikes suppressed b

2.2 V 50 150 600

Pulse width of spikes suppressed by

input filter

3 V 50 100 600

SDA

SCL

LOW

HD ,DAT

SU ,DAT

HD ,STA

SU ,STAtHD ,STA

HIGH

SU ,STO

BUF

Figure 22. I2C Mode Timing

USART1 (see Note 1)

PARAMETER TEST CONDITIONS MIN TYP MAX UNIT

VCC = 2.2 V, SYNC = 0, UART mode 200 430 800

(τ)

USART1 deglitch time

VCC = 3 V, SYNC = 0, UART mode 150 280 500

NOTE 1: The signal applied to the USART1 receive signal/terminal (URXD1) should meet the timing requirements of t

(τ

)

to ensure that the URXS

flip-flop is set. The URXS flip-flop is set with negative pulses meeting the minimum-timing condition of t

(τ

)

. The operating conditions to set the flag must be met independently from this timing constraint. The deglitch circuitry is active only on negative transitions on the URXD1 line.

MSP430xG461x

MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 201 1

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

electrical characteristics over recommended operating free-air temperature (unless otherwise noted) (continued)

12-bit ADC, power supply and input range conditions (see Note 1)

PARAMETER TEST CONDITIONS MIN TYP MAX UNIT

Analog supply voltage

AVCC and DVCC are connected together, AV

and DVSS are connected together,

(AVSS)

= V

(DVSS)

= 0 V

2.2 3.6 V

(P6.x/Ax)

Analog input voltage range (see Note 2)

All external Ax terminals. Analog inputs selected in ADC12MCTLx register and P6Sel.x=1, V

(AVSS)

≤ VAx ≤ V

(AVCC)

0 V

AVCC

Operating supply current

ADC12CLK

= 5.0 MHz,

VCC = 2.2 V 0.65 1.3

ADC12

into AVCC terminal (see Note 3)

ADC12ON = 1, REFON = 0, SHT0=0, SHT1=0, ADC12DIV=0

VCC = 3 V 0.8 1.6

Operating supply current

ADC12CLK

= 5.0 MHz, ADC12ON = 0, REFON = 1, REF2_5V = 1

VCC = 3 V 0.5 0.8 mA

REF+

into AVCC terminal (see Note 4)

ADC12CLK

= 5.0 MHz,

VCC = 2.2 V 0.5 0.8

(see Note 4)

ADC12ON = 0, REFON = 1, REF2_5V = 0

VCC = 3 V 0.5 0.8

Input capacitance

Only one terminal can be selected at one time, Ax

VCC = 2.2 V 40 pF

Input MUX ON resistance 0V ≤ VAx ≤ V

AVCC

VCC = 3 V 2000 Ω

NOTES: 1. The leakage current is defined in the leakage current table with Ax parameter.

2. The analog input voltage range must be within the selected reference voltage range V

R+

to VR− for valid conversion results.

3. The internal reference supply current is not included in current consumption parameter I

ADC12

4. The internal reference current is supplied via terminal AV

. Consumption is independent of the ADC12ON control bit, unless a

conversion is active. The REFON bit enables to settle the built-in reference before starting an A/D conversion.

12-bit ADC, external reference (see Note 1)

PARAMETER TEST CONDITIONS MIN TYP MAX UNIT

eREF+

Positive external reference voltage input

eREF+

> V

REF−/VeREF−

, (see Note 2) 1.4 V

AVCC

REF− /VeREF−

Negative external reference voltage input

eREF+

> V

REF−/VeREF−

, (see Note 3) 0 1.2 V

eREF+

−

REF−/VeREF−

)

Differential external reference voltage input

eREF+

> V

REF−/VeREF−

, (see Note 4) 1.4 V

AVCC

VeREF+

Input leakage current 0V ≤V

eREF+

≤ V

AVCC

VCC = 2.2 V/3 V ±1 μA

VREF−/VeREF−

Input leakage current 0V ≤ V

eREF−

≤ V

AVCC

VCC = 2.2 V/3 V ±1 μA

NOTES: 1. The external reference is used during conversion to charge and discharge the capacitance array. The input capacitance, CI, is also

the dynamic load for an external reference during conversion. The dynamic impedance of the reference supply should follow the recommendations on analog-source impedance to allow the charge to settle for 12-bit accuracy.

2. The accuracy limits the minimum positive external reference voltage. Lower reference voltage levels may be applied with reduced accuracy requirements.

3. The accuracy limits the maximum negative external reference voltage. Higher reference voltage levels may be applied with reduced accuracy requirements.

4. The accuracy limits minimum external differential reference voltage. Lower differential reference voltage levels may be applied with reduced accuracy requirements.

MSP430xG461x MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 2011

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

electrical characteristics over recommended operating free-air temperature (unless otherwise noted) (continued)

12-bit ADC, built-in reference

PARAMETER TEST CONDITIONS MIN NOM MAX UNIT

Positive built-in reference

REF2_5V = 1 for 2.5 V, I

VREF+

max ≤ I

VREF+

≤ I

VREF+

min

VCC = 3 V 2.4 2.5 2.6

REF+

Positive built in reference

voltage output

REF2_5V = 0 for 1.5 V, I

VREF+

max ≤ I

VREF+

≤ I

VREF+

min

2.2 V/3 V

1.44 1.5 1.56

REF2_5V = 0, I

VREF+

max ≤ I

VREF+

≤ I

VREF+

min 2.2

CC(min

)

minimum voltage

Positive built-in reference

REF2_5V = 1, I

VREF+

min ≥ I

VREF+

≥ −0.5mA 2.8

CC(min)

Positive built in reference

active

REF2_5V = 1, I

VREF+

min ≥ I

VREF+

≥ −1mA 2.9

Load current out of V

REF+

VCC = 2.2 V 0.01 −0.5

VREF+

Load current out of V

REF

terminal

VCC = 3 V 0.01 −1

VREF+

= 500 μA +/− 100 μA,

VCC = 2.2 V ±2

Load-current regulation

Analog input voltage ~0.75 V; REF2_5V = 0

VCC = 3 V ±2

LSB

L(VREF)+

Load current regulation

REF+

terminal

VREF+

= 500 μA ± 100 μA, Analog input voltage ~1.25 V, REF2_5V = 1

VCC = 3 V ±2 LSB

Load current regulation

VREF+

=100 μA → 900 μA,

DL(VREF) +

Load current regulation

REF+

terminal

VREF+

=5 μF, ax ~0.5 x V

REF+

Error of conversion result ≤ 1 LSB

VCC = 3 V 20 ns

VREF+

Capacitance at pin V

REF+

(see Note 1)

REFON =1, 0 mA ≤ I

VREF+

≤ I

VREF+

max

VCC =

2.2 V/3 V

5 10 μF

REF+

Temperature coefficient of built-in reference

VREF+

is a constant in the range of 0 mA ≤ I

VREF+

≤ 1 mA

VCC =

2.2 V/3 V

±100 ppm/°C

REFON

Settle time of internal reference voltage (see Figure 23 and Note 2)

VREF+

= 0.5 mA, C

VREF+

= 10 μF,

REF+

= 1.5 V, V

AVCC

= 2.2 V

17 ms

NOTES: 1. The internal buffer operational amplifier and the accuracy specifications require an external capacitor. All INL and DNL tests uses

two capacitors between pins V

REF+

and AVSS and V

REF−/VeREF−

and AVSS: 10 μF tantalum and 100 nF ceramic.

2. The condition is that the error in a conversion started after t

REFON

is less than ±0.5 LSB. The settling time depends on the external

capacitive load.

VREF+

1 μF

1 ms

10 ms

100 ms t

REFON

≈ .66 x C

VREF+

[ms] with C

VREF+

in μF

100 μF

10 μF

Figure 23. Typical Settling Time of Internal Reference t

REFON

vs External Capacitor on V

REF

MSP430xG461x

MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 201 1

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

−

10 μ F 100 nF

MSP430FG461x

−

10 μ F 100 nF

SS1/2

CC1/2

From

Power

Supply

Apply

External

Reference

−

Apply External Reference [V

eREF+

]

or Use Internal Reference [V

REF+

]

REF+

or V

eREF+

REF

−/V

eREF−

Figure 24. Supply Voltage and Reference Voltage Design V

REF−/VeREF−

External Supply

−

10 μ F 100 nF

MSP430FG461x

−

10 μ F 100 nF

SS1/2

CC1/2

From

Power

Supply

−

Apply External Reference [V

eREF+

]

or Use Internal Reference [V

REF+

]

REF+

or V

eREF+

REF−/VeREF−

Reference Is Internally Switched to AV

Figure 25. Supply Voltage and Reference Voltage Design V

REF−/VeREF−

= AVSS, Internally Connected

MSP430xG461x MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 2011

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

electrical characteristics over recommended operating free-air temperature (unless otherwise noted) (continued)

12-bit ADC, timing parameters

PARAMETER TEST CONDITIONS MIN NOM MAX UNIT

ADC12CLK

For specified performance of ADC12 linearity parameters

VCC = 2.2V/3 V 0.45 5 6.3 MHz

ADC12OSC

Internal ADC12 oscillator

ADC12DIV=0, f

ADC12CLK=fADC12OSC

VCC = 2.2 V/ 3 V 3.7 5 6.3 MHz

VREF+

≥ 5 μF, Internal oscillator,

ADC12OSC

= 3.7 MHz to 6.3 MHz

VCC = 2.2 V/ 3 V 2.06 3.51 μs

CONVERT

Conversion time

External f

ADC12CLK

from ACLK, MCLK, or SMCLK,

ADC12SSEL ≠ 0

13×ADC12DIV×

1/f

ADC12CLK

μs

ADC12ON

Turn on settling time of the ADC

(see Note 1) 100 ns R

= 400 Ω, R

= 1000 Ω,

VCC = 3 V 1220

Sample

Sampling time

= 30 pF, τ = [R

+ RI] x CI,

(see Note 2)

VCC = 2.2 V 1400

NOTES: 1. The condition is that the error in a conversion started after t

ADC12ON

is less than ±0.5 LSB. The reference and input signal are already

settled.

2. Approximately ten Tau (τ) are needed to get an error of less than ±0.5 LSB: t

Sample

= ln(2

n+1

) x (RS + RI) x CI+ 800 ns where n = ADC resolution = 12, RS = external source resistance.

12-bit ADC, linearity parameters

PARAMETER TEST CONDITIONS MIN NOM MAX UNIT

1.4 V ≤ (V

eREF+

− V

REF−/VeREF−

) min ≤ 1.6 V

VCC =

±2

EIIntegral linearity error

1.6 V < (V

eREF+

− V

REF−/VeREF−

) min ≤ [V

AVCC

]

2.2 V/3 V

±1.7

LSB

Differential linearity error

eREF+

− V

REF−/VeREF−)min

≤ (V

eREF+

− V

REF−/VeREF−

VREF+

= 10 μF (tantalum) and 100 nF (ceramic)

VCC =

2.2 V/3 V

±1 LSB

Offset error

eREF+

− V

REF−/VeREF−)min

≤ (V

eREF+

− V

REF−/VeREF−

Internal impedance of source R

< 100 Ω,

VREF+

= 10 μF (tantalum) and 100 nF (ceramic)

VCC =

2.2 V/3 V

±2 ±4 LSB

Gain error

eREF+

− V

REF−/VeREF−)min

≤ (V

eREF+

− V

REF−/VeREF−

VREF+

= 10 μF (tantalum) and 100 nF (ceramic)

VCC =

2.2 V/3 V

±1.1 ±2 LSB

Total unadjusted error

eREF+

− V

REF−/VeREF−)min

≤ (V

eREF+

− V

REF−/VeREF−

VREF+

= 10 μF (tantalum) and 100 nF (ceramic)

VCC =

2.2 V/3 V

±2 ±5 LSB

MSP430xG461x

MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 201 1

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

electrical characteristics over recommended operating free-air temperature (unless otherwise noted) (continued)

12-bit ADC, temperature sensor and built-in V

MID

PARAMETER

TEST CONDITIONS V

MIN NOM MAX UNIT

Operating supply current into REFON = 0, INCH = 0Ah,

2.2 V 40 120

SENSOR

Operating supply current into

AVCC terminal (see Note 1)

REFON = 0, INCH = 0Ah

ADC12ON=NA, T

= 25_C

3 V 60 160

μA

ADC12ON = 1, INCH = 0Ah, 2.2 V/

SENSOR

(see Note 2)

ADC12ON = 1, INCH = 0Ah

= 0°C

2.2 V/

3 V

986 mV

2.2 V/

SENSOR

ADC12ON = 1, INCH = 0Ah

2.2 V/

3 V

3.55±3% mV/°C

Sample time required if

ADC12ON = 1, INCH = 0Ah,

2.2 V 30

SENSOR(sample)

channel 10 is selected (see Note 3)

ADC12ON = 1, INCH = 0Ah

Error of conversion result ≤ 1 LSB

3 V 30

μs

Current into divider at

2.2 V NA

VMID

Current into divider at

channel 11 (see Note 4)

ADC12ON = 1, INCH = 0Bh

3 V NA

μA

ADC12ON = 1, INCH = 0Bh,

2.2 V 1.1 1.1±0.04

MID

AVCC divider at channel 11

ADC12ON = 1, INCH = 0Bh

MID

is ~0.5 x V

AVCC

3 V 1.5 1.50±0.04

Sample time required if

ADC12ON = 1, INCH = 0Bh,

2.2 V 1400

VMID(sample)

channel 11 is selected (see Note 5)

ADC12ON = 1, INCH = 0Bh

Error of conversion result ≤ 1 LSB

3 V 1220

NOTES: 1. The sensor current I

SENSOR

is consumed if (ADC12ON = 1 and REFON=1), or (ADC12ON=1 AND INCH=0Ah and sample signal

is high). When REFON = 1, I

SENSOR

is already included in I

REF+

2. The temperature sensor offset can be as much as ±20_C. A single-point calibration is recommended in order to minimize the offset error of the built-in temperature sensor.

3. The typical equivalent impedance of the sensor is 51 kΩ. The sample time required includes the sensor-on time t

SENSOR(on)

4. No additional current is needed. The V

MID

is used during sampling.

5. The on-time t

VMID(on)

is included in the sampling time t

VMID(sample)

; no additional on time is needed.

12-bit DAC, supply specifications

PARAMETER TEST CONDITIONS V

MIN TYP MAX UNIT

Analog supply voltage

CC =

DVCC,

= DVSS =0 V

2.20 3.60 V

DAC12AMPx=2, DAC12IR=0, DAC12_xDAT=0800h

50 110

Supply current:

DAC12AMPx=2, DAC12IR=1, DAC12_xDAT=0800h

, VeREF+=VREF+

= AV

50 110

Single DAC Channel (see Notes 1 and 2)

DAC12AMPx=5, DAC12IR=1, DAC12_xDAT=0800h, V

eREF+=VREF+

= AV

2.2 V/3 V 200 440

μA

DAC12AMPx=7, DAC12IR=1, DAC12_xDAT=0800h, V

eREF+=VREF+

= AV

700 1500

Power-supply

DAC12_xDAT = 800h, V

REF

= 1.5 V,

ΔAV

= 100mV

2.2 V

PSRR

rejection ratio (see Notes 3 and 4)

DAC12_xDAT = 800h, V

REF

= 1.5 V or 2.5 V,

ΔAV

= 100mV

3 V

70 dB

NOTES: 1. No load at the output pin, DAC12_0 or DAC12_1, assuming that the control bits for the shared pins are set properly.

2. Current into reference terminals not included. If DAC12IR = 1 current flows through the input divider; see Reference Input specifications.

3. PSRR = 20*log{ΔAV

/ΔV

DAC12_xOUT

4. V

REF

is applied externally. The internal reference is not used.

MSP430xG461x MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 2011

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

electrical characteristics over recommended operating free-air temperature (unless otherwise noted) (continued)

12-bit DAC, linearity specifications (see Figure 26)

PARAMETER TEST CONDITIONS V

MIN TYP MAX UNIT

Resolution (12-bit Monotonic) 12 bits

Integral nonlinearity

ref

= 1.5 V,

DAC12AMPx = 7, DAC12IR = 1

2.2 V

INL

Integral nonlinearity

(see Note 1)

ref

= 2.5 V,

DAC12AMPx = 7, DAC12IR = 1

3 V

±2.0 ±8.0 LSB

Differential nonlinearity

ref

= 1.5 V,

DAC12AMPx = 7, DAC12IR = 1

2.2 V

DNL

Differential nonlinearity

(see Note 1)

ref

= 2.5 V,

DAC12AMPx = 7, DAC12IR = 1

3 V

±0.4 ±1.0 LSB

Offset voltage without

ref

= 1.5 V,

DAC12AMPx = 7, DAC12IR = 1

2.2 V

calibration (see Notes 1, 2)

ref

= 2.5 V,

DAC12AMPx = 7, DAC12IR = 1

3 V

±21

Offset voltage with

ref

= 1.5 V,

DAC12AMPx = 7, DAC12IR = 1

2.2 V

calibration (see Notes 1, 2)

ref

= 2.5 V,

DAC12AMPx = 7, DAC12IR = 1

3 V

±2.5

E(O)/dT

Offset error temperature coefficient (see Note 1)

2.2 V/3 V ±30 μV/°C

REF

= 1.5 V 2.2 V

Gain error (see Note 1)

REF

= 2.5 V 3 V

±3.50 % FSR

E(G)/dT

Gain temperature coefficient (see Note 1)

2.2 V/3 V 10

ppm of

FSR/°C

DAC12AMPx = 2 100

Offset_Cal

Time for offset calibration

DAC12AMPx = 3,5

2.2 V/3 V

Offset_Cal

(see Note 3)

DAC12AMPx = 4,6,7

2.2 V/3 V

NOTES: 1. Parameters calculated from the best-fit curve from 0x0A to 0xFFF. The best-fit curve method is used to deliver coefficients “a” and

“b” of the first order equation: y = a + b*x. V

DAC12_xOUT

= EO + (1 + EG) * (V

eREF+

/4095) * DAC12_xDAT, DAC12IR = 1.

2. The offset calibration works on the output operational amplifier. Offset Calibration is triggered setting bit DAC12CALON

3. The offset calibration can be done if DAC12AMPx = {2, 3, 4, 5, 6, 7}. The output operational amplifier is switched off with DAC12AMPx = {0, 1}. It is recommended that the DAC12 module be configured prior to initiating calibration. Port activity during calibration may effect accuracy and is not recommended.

Positive

Negative

R+

Gain Error

Offset Error

DAC Code

DAC V

OUT

Ideal transfer function

Load

= 100pF

DAC Output

Figure 26. Linearity Test Load Conditions and Gain/Offset Definition

MSP430xG461x

MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 201 1

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

electrical characteristics over recommended operating free-air temperature (unless otherwise noted) (continued)

12-bit DAC, linearity specifications (continued)

DAC12_xDAT − Digital Code

−4

−3

−2

−1

0 512 1024 1536 2048 2560 3072 3584

VCC = 2.2 V, V

REF

= 1.5V DAC12AMPx = 7 DAC12IR = 1

TYPICAL INL ERROR

DIGITAL INPUT DATA

4095

INL − Integral Nonlinearity Error − LSB

DAC12_xDAT − Digital Code

−2.0

−1.5

−1.0

−0.5

0.0

0.5

1.0

1.5

2.0

0 512 1024 1536 2048 2560 3072 3584

VCC = 2.2 V, V

REF

= 1.5V DAC12AMPx = 7 DAC12IR = 1

TYPICAL DNL ERROR

DIGITAL INPUT DATA

4095

DNL − Differential Nonlinearity Error − LSB

MSP430xG461x MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 2011

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

electrical characteristics over recommended operating free-air temperature (unless otherwise noted) (continued)

12-bit DAC, output specifications

PARAMETER TEST CONDITIONS V

MIN TYP MAX UNIT

No Load, Ve

REF+

= AVCC, DAC12_xDAT = 0h, DAC12IR = 1, DAC12AMPx = 7

0 0.005

Output voltage ran

No Load, Ve

REF+

= AVCC, DAC12_xDAT = 0FFFh, DAC12IR = 1, DAC12AMPx = 7

AVCC−0.05 AV

range

(see Note 1, Figure 29)

Load

= 3 kΩ, Ve

REF+

= AVCC, DAC12_xDAT = 0h, DAC12IR = 1, DAC12AMPx = 7

2.2 V/3 V 0 0.1

Load

= 3 kΩ, Ve

REF+

= AVCC, DAC12_xDAT = 0FFFh, DAC12IR = 1, DAC12AMPx = 7

AVCC−0.13 AV

L(DAC12)

Max DAC12 load capacitance

2.2V/3V 100 pF

Max DAC12

2.2V −0.5 +0.5

L(DAC12)

Max DAC12

load current

3V −1.0 +1.0

Load

= 3 kΩ, V

O/P(DAC12)

< 0.3 V,

DAC12AMPx = 2, DAC12_xDAT = 0h

150 250

O/P(DAC12)

Output resistance (see Figure 29)

Load

= 3 kΩ,

O/P(DAC12)

> AVCC−0.3 V

DAC12_xDAT = 0FFFh

2.2 V/3 V

150 250

(g)

Load

= 3 kΩ,

0.3V ≤ V

O/P(DAC12)

≤ AVCC − 0.3V

1 4

NOTE 1: Data is valid after the offset calibration of the output amplifier.

O/P(DAC12_x)

Max

0.3 AV

AVCC −0.3V

OUT

Min

Load

= 100pF

Load

DAC12

O/P(DAC12_x)

Figure 29. DAC12_x Output Resistance Tests

MSP430xG461x

MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 201 1

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

electrical characteristics over recommended operating free-air temperature (unless otherwise noted)

12-bit DAC, reference input specifications

PARAMETER TEST CONDITIONS V

MIN TYP MAX UNIT

Reference input

DAC12IR=0 (see Notes 1 and 2)

AVCC/3 AVCC+0.2

REF+

Reference input

voltage range

DAC12IR=1 (see Notes 3 and 4)

2.2 V/3 V AVcc AVcc+0.2

DAC12_0 IR=DAC12_1 IR =0 20 MΩ DAC12_0 IR=1, DAC12_1 IR = 0

(VREF+)

, Reference input

DAC12_0 IR=0, DAC12_1 IR = 1

40 48 56

(VREF+)

(VeREF+)

resistance

DAC12_0 IR=DAC12_1 IR =1, DAC12_0 SREFx = DAC12_1 SREFx (see Note 5)

2.2 V/3 V

20 24 28

kΩ

NOTES: 1. For a full-scale output, the reference input voltage can be as high as 1/3 of the maximum output voltage swing (AVCC).

2. The maximum voltage applied at reference input voltage terminal Ve

REF+

= [AVCC − V

E(O)

] / [3*(1 + EG)].

3. For a full-scale output, the reference input voltage can be as high as the maximum output voltage swing (AV

4. The maximum voltage applied at reference input voltage terminal Ve

REF+

= [AVCC − V

E(O)

] / (1 + EG).

5. When DAC12IR = 1 and DAC12SREFx = 0 or 1 for both channels, the reference input resistive dividers for each DAC are in parallel reducing the reference input resistance.

12-bit DAC, dynamic specifications; V

ref

= VCC, DAC12IR = 1 (see Figure 30 and Figure 31)

PARAMETER TEST CONDITIONS V

MIN TYP MAX UNIT

DAC12_xDAT = 800h,

DAC12AMPx = 0 → {2, 3, 4} 60 120

DAC12

DAC12_xDAT = 800h

Error

V(O)

< ±0.5 LSB

DAC12AMPx = 0 → {5, 6}

2.2 V/3 V

15 30

μs

on-time

Error

V(O)

±0.5 LSB

(see Note 1,Figure 30)

DAC12AMPx = 0 → 7

2.2 V/3 V

6 12

μs

DAC12AMPx = 2 100 200

S(FS

)

Settling time,

DAC12_xDAT =

DAC12AMPx = 3,5

2.2 V/3 V

40 80

μs

S(FS)

full-scale 80h→ F7Fh→ 80h

DAC12AMPx = 4,6,7

2.2 V/3 V

15 30

μs

DAC12_xDAT =

DAC12AMPx = 2 5

S(C-C

)

Settling time,

DAC12_xDAT =

3F8h→ 408h→ 3F8h

DAC12AMPx = 3,5

2.2 V/3 V

μs

S(C-C)

code to code

3F8h→ 408h→ 3F8h

BF8h→ C08h→ BF8h

DAC12AMPx = 4,6,7

2.2 V/3 V

μs

DAC12_xDAT =

DAC12AMPx = 2 0.05 0.12

SR Slew rate

DAC12_xDAT =

80h→ F7Fh→ 80h

DAC12AMPx = 3,5

2.2 V/3 V

0.35 0.7

V/μs

Slew rate

80h→ F7Fh→ 80h

(see Note 2)

DAC12AMPx = 4,6,7

2.2 V/3 V

1.5 2.7

V/μs

DAC12AMPx = 2 600

Glitch energy, full-scale

DAC12_xDAT =

DAC12AMPx = 3,5

2.2 V/3 V

150

nV-s

Glitch energy, full scale

80h→ F7Fh→ 80h

DAC12AMPx = 4,6,7

2.2 V/3 V

nV s

NOTES: 1. R

Load

and C

Load

connected to AVSS (not AVCC/2) in Figure 30.

2. Slew rate applies to output voltage steps >= 200mV.

Load

= 100pF

DAC Output

O/P(DAC12.x)

Load

Conversion 1 Conversion 2

OUT

Conversion 3

Glitch

Energy

+/− 1/2 LSB

settleLH

settleHL

= 3 kΩ

Figure 30. Settling Time and Glitch Energy Testing

MSP430xG461x MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 2011

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

electrical characteristics over recommended operating free-air temperature (unless otherwise noted)

Conversion 1 Conversion 2

OUT

Conversion 3

10%

SRLH

SRHL

90%

10%

90%

Figure 31. Slew Rate Testing

12-bit DAC, dynamic specifications continued (T

= 25°C unless otherwise noted)

PARAMETER TEST CONDITIONS V

MIN TYP MAX UNIT

DAC12AMPx = {2, 3, 4}, DAC12SREFx = 2, DAC12IR = 1, DAC12_xDAT = 800h

−3dB

3-dB bandwidth, V

=1.5V, VAC=0.1V

DAC12AMPx = {5, 6}, DAC12SREFx = 2, DAC12IR = 1, DAC12_xDAT = 800h

2.2 V/3 V

180

kHz

(see Figure 32)

DAC12AMPx = 7, DAC12SREFx = 2, DAC12IR = 1, DAC12_xDAT = 800h

550

DAC12_0DAT = 800h, No Load, DAC12_1DAT = 80h<−>F7Fh, R

Load

= 3kΩ

DAC12_1OUT

= 10kHz @ 50/50 duty cycle

−80

Channel-to-channel crosstalk (see Note 1 and Figure 33)

DAC12_0DAT = 80h<−>F7Fh, R

Load

= 3kΩ, DAC12_1DAT = 800h, No Load, f

DAC12_0OUT

= 10kHz @ 50/50 duty cycle

2.2 V/3 V

−80

NOTE 1: R

LOAD

= 3 kΩ, C

LOAD

= 100 pF

REF+

AC DC

Load

= 100pF

Load

DAC12_x

DACx

= 3 kΩ

Figure 32. Test Conditions for 3-dB Bandwidth Specification

DAC12_xDAT 080h

OUT

Toggle

7F7h

DAC12_yOUT

080h 7F7h 080h

DAC12_xOUT

REF+

Load

= 100pF

Load

DAC12_1

Load

= 100pF

Load

DAC12_0

DAC0

DAC1

Figure 33. Crosstalk Test Conditions

MSP430xG461x

MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 201 1

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

electrical characteristics over recommended operating free-air temperature (unless otherwise noted)

operational amplifier OA, supply specifications

PARAMETER TEST CONDITIONS V

MIN TYP MAX UNIT

Supply voltage — 2.2 3.6 V

Fast Mode,

Fast Mode

OARRIP = 1 (rail-to-rail mode off)

180 290

Medium Mode,

Medium Mode

OARRIP = 1 (rail-to-rail mode off)

110 190

Supply current

Slow Mode, OARRIP = 1 (rail-to-rail mode off)

50 80

Supply current

(see Note 1)

Fast Mode,

2.2 V/3 V

μA

(see Note 1)

Fast Mode

OARRIP = 0 (rail-to-rail mode on)

300 490

Medium Mode,

Medium Mode

OARRIP = 0 (rail-to-rail mode on)

190 350

Slow Mode,

Slow Mode

OARRIP = 0 (rail-to-rail mode on)

90 190

PSRR Power supply rejection ratio Non-inverting 2.2 V/3 V 70 dB

NOTE 1: P6SEL.x = 1 for each corresponding pin when used in OA input or OA output mode.

MSP430xG461x MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 2011

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

operational amplifier OA, input/output specifications

PARAMETER TEST CONDITIONS V

MIN TYP MAX UNIT

OARRIP = 1 (rail-to-rail mode off) −0.1 VCC−1.2

I/P

Voltage supply, I/P

OARRIP = 0 (rail-to-rail mode on)

—

−0.1 VCC+0.1

Input leakage current, I/P

TA = −40 to +55_C −5 ±0.5 5

Ikg

Input leakage current, I/P

(see Notes 1 and 2)

TA = +55 to +85_C

—

−20 ±5 20

Fast Mode 50 Medium Mode

V(I/P

)

= 1 kHz

Slow Mode

V(I/P)

kHz

140

Voltage noise density, I/P

Fast Mode

—

nV/√Hz

Medium Mode

V(I/P

)

= 10 kHz

Slow Mode

V(I/P)

kHz

Offset voltage, I/P 2.2 V/3 V ±10 mV Offset temperature drift, I/P see Note 3 2.2 V/3 V ±10 μV/°C Offset voltage drift

with supply, I/P

0.3V ≤ VIN ≤ VCC−0.3V ΔV

≤ ± 10%, TA = 25°C

2.2 V/3 V ±1.5 mV/V

Fast Mode, I

SOURCE

≤ −500μA 2.2 V VCC−0.2 V

High-level output voltage, O/P

Slow Mode,I

SOURCE

≤ −150μA 3 V VCC−0.1 V

Fast Mode, I

SOURCE

≤ +500μA 2.2 V V

0.2

Low-level output voltage, O/P

Slow Mode,I

SOURCE

≤ +150μA 3 V V

0.1

Load

= 3 kΩ, C

Load

= 50pF, OARRIP = 0 (rail-to-rail mode on), V

O/P(OAx)

< 0.2 V

150 250

O/P

(OAx

)

Output Resistance (see Figure 34 and Note 4)

Load

= 3 kΩ, C

Load

= 50pF, OARRIP = 0 (rail-to-rail mode on), V

O/P(OAx)

> AVCC − 0.2 V

2.2 V/3 V

150 250

Load

= 3 kΩ, C

Load

= 50pF, OARRIP = 0 (rail-to-rail mode on),

0.2 V ≤ V

O/P(OAx)

≤ AVCC − 0.2 V

0.1 4

CMRR Common-mode rejection ratio Non-inverting 2.2 V/3 V 70 dB

NOTES: 1. ESD damage can degrade input current leakage.

2. The input bias current is overridden by the input leakage current.

3. Calculated using the box method.

4. Specification valid for voltage-follower OAx configuration.

MSP430xG461x

MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 201 1

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

electrical characteristics over recommended operating free-air temperature (unless otherwise noted)

O/P(OAx)

Max

0.2V

AVCC −0.2V

OUT

Min

Load

OAx

O/P(OAx)

Figure 34. OAx Output Resistance Tests

operational amplifier OA, dynamic specifications

PARAMETER TEST CONDITIONS V

MIN TYP MAX UNIT

Fast Mode — 1.2

SR Slew rate

Medium Mode — 0.8

V/μs

Slew rate

Slow Mode — 0.3

V/μs

Open-loop voltage gain — 100 dB

Phase margin CL = 50 pF — 60 deg Gain margin CL = 50 pF — 20 dB

Non−inverting, Fast Mode, RL = 47kΩ, CL = 50pF 2.2

Gain-bandwidth product

GBW

(see Figure 35

Non−inverting, Medium Mode, RL =300kΩ, CL = 50pF 2.2 V/3 V 1.4 MHz

GBW

(see Figure 35 a

Fir

2.2 V/3 V

MHz

and Figure 36)

Non−inverting, Slow Mode, RL =300kΩ, CL = 50pF 0.5

en(on)

Enable time on ton, non-inverting, Gain = 1 2.2 V/3 V 10 20 μs

en(off)

Enable time off 2.2 V/3 V 1 μs

Figure 35

Input Frequency − kHz

−80

−60

−40

−20

100

120

140

TYPICAL OPEN-LOOP GAIN vs FREQUENCY

Slow Mode

Fast Mode

Gain − dB

Medium Mode

0.001 0.01 0.1 1 10 100 1000 10000

Figure 36

Input Frequency − kHz

−250

−200

−150

−100

−50

1 10 100 1000 10000

TYPICAL PHASE vs FREQUENCY

Phase − degrees

Slow Mode

Fast Mode

Medium Mode

MSP430xG461x MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 2011

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

electrical characteristics over recommended operating free-air temperature (unless otherwise noted)

operational amplifier OA feedback network, noninverting amplifier mode (OAFCx = 4)

PARAMETER TEST CONDITIONS V

MIN TYP MAX UNIT

OAFBRx = 0 0.996 1.00 1.002 OAFBRx = 1 1.329 1.334 1.340 OAFBRx = 2 1.987 2.001 2.016 OAFBRx = 3

2.64 2.667 2.70

G Gain

OAFBRx = 4

2.2 V/ 3 V

3.93 4.00 4.06 OAFBRx = 5 5.22 5.33 5.43 OAFBRx = 6 7.76 7.97 8.18 OAFBRx = 7 15.0 15.8 16.6

Total harmonic distortion/

2.2 V −60

THD

Total harmonic distortion/

nonlinearity

All gains

3 V −70

Settle

Settling time (see Note 1) All power modes 2.2 V/3 V 7 12 μs

NOTES: 1. The settling time specifies the time until an ADC result is stable. This includes the minimum required sampling time of the ADC. The

settling time of the amplifier itself might be faster.

operational amplifier OA feedback network, inverting amplifier mode (OAFCx = 6) (see Note 1)

PARAMETER TEST CONDITIONS V

MIN TYP MAX UNIT

OAFBRx = 1 −0.371 −0.335 −0.298 OAFBRx = 2 −1.031 −1.002 −0.972 OAFBRx = 3 −1.727 −1.668 −1.609 OAFBRx = 4

−3.142 −3.00 −2.856

Gai

OAFBRx = 5

2.2 V/ 3 V

−4.581 −4.33 −4.073

OAFBRx = 6 −7.529 −6.97 −6.379 OAFBRx = 7

−17.04 0

−14.8

−12.27 9

Total harmonic distortion/

2.2 V −60

THD

Total harmonic distortion/

nonlinearity

All gains

3 V −70

Settle

Settling time (see Note 2) All power modes 2.2 V/3 V 7 12 μs

NOTES: 1. This includes the 2 OA configuration “inverting amplifier with input buffer”. Both OA needs to be set to the same power mode OAPMx.

2. The settling time specifies the time until an ADC result is stable. This includes the minimum required sampling time of the ADC. The settling time of the amplifier itself might be faster.

MSP430xG461x

MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 201 1

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

electrical characteristics over recommended operating free-air temperature (unless otherwise noted)

flash memory (MSP430FG461x devices only)

PARAMETER

TEST

CONDITIONS

MIN TYP MAX UNIT

CC(PGM/

ERASE)

Program and Erase supply voltage 2.7 3.6 V

FTG

Flash Timing Generator frequency 257 476 kHz

PGM

Supply current from DVCC during program 2.7 V/ 3.6 V 3 5 mA

ERASE

Supply current from DVCC during erase See Note 3 2.7 V/ 3.6 V 3 7 mA

GMERASE

Supply current from DVCC during global mass erase

See Note 4 2.7 V/ 3.6 V 6 14 mA

CPT

Cumulative program time See Note 1 2.7 V/ 3.6 V 10 ms

CMErase

Cumulative mass erase time 2.7 V/ 3.6 V 20 ms Program/Erase endurance 10

cycles

Retention

Data retention duration TJ = 25°C 100 years

Word

Word or byte program time 30

Block, 0

Block program time for 1st byte or word 25

Block, 1-63

Block program time for each additional byte or word

Block, End

Block program end-sequence wait time

See Note 2

FTG

Mass Erase

Mass erase time 10593

Global Mass Erase

Global mass erase time 10593

Seg Erase

Segment erase time 4819

NOTES: 1. The cumulative program time must not be exceeded during a block-write operation. This parameter is only relevant if the block write

feature is used.

2. These values are hardwired into the Flash Controller’s state machine (t

FTG

= 1/f

FTG

3. Lower 64-KB or upper 64-KB Flash memory erased.

4. All Flash memory erased.

JTAG interface

PARAMETER

TEST

CONDITIONS

MIN TYP MAX UNIT

2.2 V 0 5 MHz

TCK

TCK input frequency See Note 1

3 V 0 10 MHz

Internal

Internal pull-up resistance on TMS, TCK, TDI/TCLK See Note 2 2.2 V/ 3 V 25 60 90 kΩ

NOTES: 1. f

TCK

may be restricted to meet the timing requirements of the module selected.

2. TMS, TDI/TCLK, and TCK pull-up resistors are implemented in all versions.

JTAG fuse (see Note 1)

PARAMETER

TEST

CONDITIONS

MIN TYP MAX UNIT

CC(FB)

Supply voltage during fuse-blow condition TA = 25°C 2.5 V

Voltage level on TDI/TCLK for fuse-blow: F versions 6 7 V

Supply current into TDI/TCLK during fuse blow 100 mA

Time to blow fuse 1 ms

NOTE 1: Once the fuse is blown, no further access to the MSP430 JTAG/Test and emulation features is possible. The JTAG block is switched

to bypass mode.

MSP430xG461x MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 2011

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

APPLICATION INFORMATION

input/output schematics

Port P1, P1.0 to P1.5, input/output with Schmitt trigger

Bus

Keeper

Direction 0: Input 1: Output

P1SEL.x

P1DIR.x

P1IN.x

Pad Logic

P1IRQ.x

Module X IN

Module X OUT

P1OUT.x

Note: x= 0,1,2,3,4,5

P1.0/TA0 P1.1/TA0/MCLK P1.2/TA1 P1.3/TBOUTH/SVSOUT P1.4/TBCLK/SMCLK P1.5/TACLK/ACLK

Interrupt

Edge

Select

Set

P1SEL.x

P1IES.x

P1IFG.x

P1IE.x

MSP430xG461x

MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 201 1

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

Port P1 (P1.0 to P1.5) pin functions

CONTROL BITS / SIGNALS

PIN NAME (P1.X)

X FUNCTION

P1DIR.x P1SEL.x

P1.0/TA0 0

P1.0 (I/O) I: 0; O: 1 0 Timer_A3.CCI0A 0 1 Timer_A3.TA0 1 1

P1.1/TA0/MCLK 1

P1.1 (I/O) I: 0; O: 1 0 Timer_A3.CCI0B 0 1 MCLK 1 1

P1.2/TA1 2

P1.2 (I/O) I: 0; O: 1 0 Timer_A3.CCI1A 0 1 Timer_A3.TA1 1 1

P1.3/TBOUTH/SVSOUT 3

P1.3 (I/O) I: 0; O: 1 0 Timer_B7.TBOUTH 0 1 SVSOUT 1 1

P1.4/TBCLK/SMCLK 4

P1.4 (I/O) I: 0; O: 1 0 Timer_B7.TBCLK 0 1 SMCLK 1 1

P1.5/TACLK/ACLK 5

P1.5 (I/O) I: 0; O: 1 0 Timer_A3.TACLK 0 1 ACLK 1 1

MSP430xG461x MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 2011

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

Port P1, P1.6, P1.7, input/output with Schmitt trigger

−

Comp_A

Bus

Keeper

Direction 0: Input 1: Output

P1SEL.x

P1DIR.x

P1IN.x

Pad Logic

CAPD.x

P1IRQ.x

Module X IN

Module X OUT

P1OUT.x

Note:x = 6,7

P1.6/CA0 P1.7/CA1

Interrupt

Edge

Select

Set

P1SEL.x

P1IES.x

P1IFG.x

P1IE.x

P2CA0

CA0

CA1

P2CA1

Port P1 (P1.6 and P1.7) pin functions

CONTROL BITS / SIGNALS

PIN NAME (P1.X)

X FUNCTION

CAPD.x P1DIR.x P1SEL.x

P1.6/CA0 6

P1.6 (I/O) 0 I: 0; O: 1 0 CA0 1 X X

P1.7/CA1 7

P1.7 (I/O) 0 I: 0; O: 1 0 CA1 1 X X

NOTE 1: X: Don’t care

MSP430xG461x

MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 201 1

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

port P2, P2.0 to P2.3, P2.6 to P2.7, input/output with Schmitt trigger

Bus

Keeper

Direction 0: Input 1: Output

P2SEL.x

P2DIR.x

P2IN.x

Pad Logic

TBOUTH

P2IRQ.x

Module X IN

Module X OUT

P2OUT.x

Note:x = 0,1,2,3,6,7

P2.0/TA2 P2.1/TB0 P2.2/TB1 P2.3/TB2 P2.6/CAOUT P2.7/ADC12CLK/DMAE0

Interrupt

Edge

Select

Set

P2SEL.x

P2IES.x

P2IFG.x

P2IE.x

MSP430xG461x MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 2011

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

Port P2 (P2.0, P2.1, P2.2, P2.3, P2.6 and P2.7) pin functions

CONTROL BITS / SIGNALS

PIN NAME (P2.X)

X FUNCTION

P2DIR.x P2SEL.x

P2.0/TA2 0

P2.0 (I/O) I: 0; O: 1 0 Timer_A3.CCI2A 0 1 Timer_A3.TA2 1 1

P2.1/TB0 1

P2.1 (I/O) I: 0; O: 1 0 Timer_B7.CCI0A and Timer_B7.CCI0B 0 1 Timer_B7.TB0 (see Note 1) 1 1

P2.2/TB1 2

P2.2 (I/O) I: 0; O: 1 0 Timer_B7.CCI1A and Timer_B7.CCI1B 0 1 Timer_B7.TB1 (see Note 1) 1 1

P2.3/TB3 3

P2.3 (I/O) I: 0; O: 1 0 Timer_B7.CCI2A and Timer_B7.CCI2B 0 1 Timer_B7.TB3 (see Note 1) 1 1

P2.6/CAOUT 6

P2.6 (I/O) I: 0; O: 1 0 CAOUT 1 1

P2.7/ADC12CLK/DMAE0 7

P2.7 (I/O) I: 0; O: 1 0 ADC12CLK 1 1 DMAE0 0 1

NOTE 1: Setting TBOUTH causes all Timer_B outputs to be set to high impedance.

MSP430xG461x

MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 201 1

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

port P2, P2.4 to P2.5, input/output with Schmitt trigger

Bus

Keeper

Direction 0: Input 1: Output

P2SEL.x

P2DIR.x

P2IN.x

Pad Logic

P2IRQ.x

Module X IN

Module X OUT

P2OUT.x

Note: x =4,5

P2.4/UCA0TXD P2.5/UCA0RXD

Interrupt

Edge

Select

Set

P2SEL.x

P2IES.x

P2IFG.x

P2IE.x

Direction control

from Module X

Port P2 (P2.4 and P2.5) pin functions

CONTROL BITS / SIGNALS

PIN NAME (P2.X)

X FUNCTION

P2DIR.x P2SEL.x

P2.4/UCA0TXD 4

P2.4 (I/O) I: 0; O: 1 0 USCI_A0.UCA0TXD (see Note 1, 2) X 1

P2.5/UCA0RXD 5

P2.5 (I/O) I: 0; O: 1 0 USCI_A0.UCA0RXD (see Note 1, 2) X 1

NOTES: 1. X: Don’t care

2. When in USCI mode, P2.4 is set to output, P2.5 is set to input.

MSP430xG461x MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 2011

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

port P3, P3.0 to P3.3, input/output with Schmitt trigger

Bus

Keeper

Direction 0: Input 1: Output

P3SEL.x

P3DIR.x

P3IN.x

Pad Logic

Module X IN

Module X OUT

P3OUT.x

Note: x = 0,1,2,3

P3.0/UCB0STE P3.1/UCB0SIMO/UCB0SDA P3.2/UCB0SOMI/UCB0SCL P3.3/UCB0CLK

Port P3 (P3.0 to P3.3) pin functions

CONTROL BITS / SIGNALS

PIN NAME (P3.X)

X FUNCTION

P3DIR.x P3SEL.x

P3.0/UCB0STE 0

P3.0 (I/O) I: 0; O: 1 0 UCB0STE (see Notes 1, 2) X 1

P3.1/UCB0SIMO/ 1

P3.1 (I/O) I: 0; O: 1 0

UCB0SDA

UCB0SIMO/UCB0SDA (see Notes 1, 2, 3) X 1

P3.2/UCB0SOMI/ 2

P3.2 (I/O) I: 0; O: 1 0

UCB0SCL

UCB0SOMI/UCB0SCL (see Notes 1, 2, 3) X 1

P3.3/UCB0CLK 3

P3.3 (I/O) I: 0; O: 1 0 UCB0CLK (see Notes 1, 2) X 1

NOTES: 1. X: Don’t care

2. The pin direction is controlled by the USCI module.

3. In case the I2C functionality is selected the output drives only the logical 0 to V

level.

MSP430xG461x

MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 201 1

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

port P3, P3.4 to P3.7, input/output with Schmitt trigger

Bus

Keeper

Direction 0: Input 1: Output

P3SEL.x

P3DIR.x

P3IN.x

Pad Logic

TBOUTH

Module X IN

Module X OUT

P3OUT.x

Note: x = 4,5,6,7

P3.4/TB3 P3.5/TB4 P3.6/TB5 P3.7/TB6

Port P3 (P3.4 to P3.7) pin functions

CONTROL BITS / SIGNALS

PIN NAME (P3.X)

X FUNCTION

P3DIR.x P3SEL.x

P3.4/TB3 4

P3.4 (I/O) I: 0; O: 1 0 Timer_B7.CCI3A and Timer_B7.CCI3B 0 1 Timer_B7.TB3 (see Note 1) 1 1

P3.5/TB4 5

P3.5 (I/O) I: 0; O: 1 0 Timer_B7.CCI4A and Timer_B7.CCI4B 0 1 Timer_B7.TB4 (see Note 1) 1 1

P3.6/TB5 6

P3.6 (I/O) I: 0; O: 1 0 Timer_B7.CCI5A and Timer_B7.CCI5B 0 1 Timer_B7.TB5 (see Note 1) 1 1

P3.7/TB6 7

P3.7 (I/O) I: 0; O: 1 0 Timer_B7.CCI6A and Timer_B7.CCI6B 0 1 Timer_B7.TB6 (see Note 1) 1 1

NOTE 1: Setting TBOUTH causes all Timer_B outputs to be set to high impedance.

MSP430xG461x MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 2011

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

port P4, P4.0 to P4.1, input/output with Schmitt trigger

Bus

Keeper

Direction 0: Input 1: Output

P4SEL.x

P4DIR.x

P4IN.x

Pad Logic

Module X IN

Module X OUT

P4OUT.x

Note: x = 0,1

P4.1/URXD1 P4.0/UTXD1

Direction control

from Module X

Port P4 (P4.0 to P4.1) pin functions

CONTROL BITS / SIGNALS

PIN NAME (P4.X)

X FUNCTION

P4DIR.x P4SEL.x

P4.0/UTXD1 0

P4.0 (I/O) I: 0; O: 1 0 USART1.UTXD1 (see Notes 1, 2) X 1

P4.1/URXD1 1

P4.1 (I/O) I: 0; O: 1 0 USART1.URXD1 (see Notes 1, 2) X 1

NOTES: 1. X: Don’t care

2. When in USART1 mode, P4.0 is set to output, P4.1 is set to input.

MSP430xG461x

MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 201 1

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

port P4, P4.2 to P4.7, input/output with Schmitt trigger

Bus

Keeper

Direction 0: Input 1: Output

P4SEL.x

P4DIR.x

P4IN.x

LCDS32/36

Segment Sy

Pad Logic

Module X IN

Module X OUT

P4OUT.x

Note:x =2,3,4,5,6,7 y

= 34,35,36,37,38,39

P4.7/UCA0RXD/S34 P4.6/UCA0TXD/S35 P4.5/UCLK1/S36 P4.4/SOMI1/S37 P4.3/SIMO1/S38 P4.2/STE1/S39

Direction control

from Module X

MSP430xG461x MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 2011

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

Port P4 (P4.2 to P4.5) pin functions

CONTROL BITS / SIGNALS

PIN NAME (P4.X)

X FUNCTION

P4DIR.x P4SEL.x LCDS36

P4.2/STE1/S39 2

P4.2 (I/O) I: 0; O: 1 0 0 USART1.STE1 X 1 0 S39 (see Note 1) X X 1

P4.3/SIMO/S38 3

P4.3 (I/O) I: 0; O: 1 0 0 USART1.SIMO1 (see Notes 1, 2) X 1 0 S38 (see Note 1) X X 1

P4.4/SOMI/S37 4

P4.4 (I/O) I: 0; O: 1 0 0 USART1.SOMI1 (see Notes 1, 2) X 1 0 S37 (see Note 1) X X 1

P4.5/SOMI/S36 5

P4.5 (I/O) I: 0; O: 1 0 0 USART1.UCLK1 (see Notes 1, 2) X 1 0 S36 (see Note 1) X X 1

P4.6/UCA0TXD/S35 6

P4.6 (I/O) I: 0; O: 1 0 0 USCI_A0.UCA0TXD (see Notes 1, 3) X 1 0 S35 (see Note 1) X X 1

P4.7/UCA0RXD/S34 7

P4.7 (I/O) I: 0; O: 1 0 0 USCI_A0.UCA0RXD (see Notes 1, 3) X 1 0 S34 (see Note 1) X X 1

NOTES: 1. X: Don’t care

2. The pin direction is controlled by the USART1 module.

3. When in USCI mode, P4.6 is set to output, P4.7 is set to input.

MSP430xG461x

MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 201 1

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

port P5, P5.0, input/output with Schmitt trigger

Bus

Keeper

Direction 0: Input 1: Output

P5SEL.x

P5DIR.x

P5IN .x

LCDS0

Segment Sy

P5OUT.x

P5.0/S1/A13/OA1I1

INCH=13

A13

Pad Logic

−

OA1

Note:x = 0

y = 1

MSP430xG461x MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 2011

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

Port P5 (P5.0) pin functions

CONTROL BITS / SIGNALS

PIN NAME (P5.X)

X FUNCTION

P5DIR.x P5SEL.x INCHx

OAPx(OA1) OANx(OA1)

LCDS0

P5.0/S1/A13/OA1I1 0

P5.0 (I/O) (see Note 1) I: 0; O: 1 0 X X 0 OAI11 (see Note 1) 0 X X 1 0 A13 (see Notes 1, 3) X 1 13 X X S1 enabled (see Note 1) X 0 X X 1 S1 disabled (see Note 1) X 1 X X 1

NOTES: 1. X: Don’t care

2. N/A: Not available or not applicable.

3. Setting the P5SEL.x bit disables the output driver as well as the input Schmitt trigger to prevent parasitic cross currents when applying analog signals.

MSP430xG461x

MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 201 1

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

port P5, P5.1, input/output with Schmitt trigger

Bus

Keeper

Direction 0: Input 1: Output

P5SEL.x

P5DIR.x

P5IN.x

LCDS0

Segment Sy

P5OUT.x

P5.1/S0/A12/DAC1

INCH=12

A12

Pad Logic

DAC12.1OPS

DAC1

0 if DAC12.1AMPx = 0 and DAC12.1OPS=1 1 if DAC12.1AMPx = 1 and DAC12.1OPS=1 2 if DAC12.1AMPx > 1 and DAC12.1OPS=1

Note:x = 1

y = 0

MSP430xG461x MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 2011

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

Port P5 (P5.1) pin functions

CONTROL BITS / SIGNALS

PIN NAME (P5.X)

X FUNCTION

P5DIR.x P5SEL.x INCHx DAC12.1OPS DAC12.1AMPx LCDS0

P5.1/S0/A12/DAC1 1

P5.1 (I/O) (see Note 1) I: 0; O: 1 0 X 0 X 0 DAC1 high impedance

(see Note 1)

X X X 1 0 X

DVSS (see Note 1) X X X 1 1 X DAC1 output

(see Note 1)

X X X 1 > 1 X

A12 (see Notes 1, 2) X 1 12 0 X 0 S0 enabled (see Note 1) X 0 X 0 X 1 S0 disabled

(see Note 1)

X 1 X 0 X 1

NOTES: 1. X: Don’t care

2. Setting the P5SEL.x bit disables the output driver as well as the input Schmitt trigger to prevent parasitic cross currents when applying analog signals.

MSP430xG461x

MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 201 1

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

port P5, P5.2 to P5.4, input/output with Schmitt trigger

Bus

Keeper

Direction 0: Input 1: Output

P5SEL.x

P5DIR.x

P5IN.x

LCD Signal

Pad Logic

P5OUT.x

Note:x = 2,3,4

P5.2/COM1 P5.3/COM2 P5.4/COM3

Port P5 (P5.2 to P5.4) pin functions

CONTROL BITS / SIGNALS

PIN NAME (P5.X)

X FUNCTION

P5DIR.x P5SEL.x

P5.2/COM1 2

P5.2 (I/O) I: 0; O: 1 0 COM1 (see Note 1) X 1

P5.3/COM2 3

P5.3 (I/O) I: 0; O: 1 0 COM2 (see Note 1) X 1

P5.4/COM3 4

P5.4 (I/O) I: 0; O: 1 0 COM3 (see Note 1) X 1

NOTE 1: X: Don’t care

MSP430xG461x MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 2011

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

port P5, P5.5 to P5.7, input/output with Schmitt trigger

Bus

Keeper

Direction 0: Input 1: Output

P5SEL.x

P5DIR.x

P5IN.x

LCD Signal

Pad Logic

P5OUT.x

Note:x = 5,6,7

P5.5/R03 P5.6/LCDREF/R13 P5.7/R03

Port P5 (P5.5 to P5.7) pin functions

CONTROL BITS / SIGNALS

PIN NAME (P5.X)

X FUNCTION

P5DIR.x P5SEL.x

P5.5/R03 5

P5.5 (I/O) I: 0; O: 1 0 R03 (see Note 1) X 1

P5.6/LCDREF/R13 6

P5.6 (I/O) I: 0; O: 1 0 R13 or LCDREF (see Notes 1, 2) X 1

P5.7/R03 7

P5.7 (I/O) I: 0; O: 1 0 R03 (see Note 1) X 1

NOTES: 1. X: Don’t care

2. External reference for the LCD_A charge pump is applied when VLCDREFx = 01. Otherwise R13 is selected.

MSP430xG461x

MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 201 1

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

port P6, P6.0, P6.2, and P6.4, input/output with Schmitt trigger

Bus

Keeper

Direction 0: Input 1: Output

P6SEL.x

P6DIR.x

P6IN.x

INCH=0/2/4

Pad Logic

P6OUT.x

P6.0/A0/OA0I0 P6.2/A2/OA0I1 P6.4/A4/OA1I0

−

OA0/1

Note:x = 0, 2, 4

y = 0, 1 # = Signal from or to ADC12

Port P6 (P6.0, P6.2, and P6.4) pin functions

CONTROL BITS / SIGNALS

PIN NAME (P6.X)

X FUNCTION

P6DIR.x P6SEL.x

OAPx (OA0) OANx (OA0)

OAPx (OA1)

OANx(OA1)

INCHx

P6.0/A0/OA0I0 0

P6.0 (I/O) (see Note 1) I: 0; O: 1 0 X X X OA0I0 (see Note 1) 0 X 0 X X A0 (see Notes 1, 3) X 1 X X 0

P6.2/A2/OA0I1 2

P6.2 (I/O) (see Note 1) I: 0; O: 1 0 X X X OA0I1 (see Note 1) 0 X 1 X X A2 (see Notes 1, 3) X 1 X X 2

P6.4/A4/OA1I0 4

P6.4 (I/O) (see Note 1) I: 0; O: 1 0 X X X OA1I0 (see Note 1) 0 X X 0 X A4 (see Notes 1, 3) X 1 X X 4

NOTES: 1. X: Don’t care

2. N/A: Not available or not applicable.

3. Setting the P6SEL.x bit disables the output driver as well as the input Schmitt trigger to prevent parasitic cross currents when applying analog signals.

MSP430xG461x MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 2011

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

port P6, P6.1, P6.3, and P6.5 input/output with Schmitt trigger

Bus

Keeper

Direction 0:Input 1:Output

P6SEL.x

P6DIR.x

P6IN.x

INCH=1/3/5

Pad Logic

P6OUT.x

P6.1/A1/OA0O P6.3/A3/OA1O P6.5/A5/OA2O

−

OAy

OAPMx> 0

OAADC1

Note:x = 1, 3, 5

y = 0, 1, 2 # = Signal from or to ADC12

MSP430xG461x

MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 201 1

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

Port P6 (P6.1, P6.3, and P6.5) pin functions

CONTROL BITS / SIGNALS

PIN NAME (P6.X)

X FUNCTION

P6DIR.x P6SEL.x OAADC1 OAPMx INCHx

P6.1/A1/OA0O 1

P6.1 (I/O) (see Note 1) I: 0; O: 1 0 X 0 X OA0O (see Notes 1, 4) X X 1 > 0 X A1 (see Notes 1, 3) X 1 X 0 1

P6.3/A3/OA1O 3

P6.3 (I/O) (see Note 1) I: 0; O: 1 0 X 0 X OA1O (see Notes 1, 4) X X 1 > 0 X A3 (see Notes 1, 3) X 1 X 0 3

P6.5/A5/OA2O 5

P6.5 (I/O) (see Note 1) I: 0; O: 1 0 X 0 X OA2O (see Notes 1, 4) X X 1 > 0 X A5 (see Notes 1, 3) X 1 X 0 5

NOTES: 1. X: Don’t care

2. N/A: Not available or not applicable.

3. Setting the P6SEL.x bit disables the output driver as well as the input Schmitt trigger to prevent parasitic cross currents when applying analog signals.

4. Setting the OAADC1 bit or setting OAFCx = 00 will cause the operational amplifier to be present at the pin as well as internally connected to the corresponding ADC12 input.

MSP430xG461x MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 2011

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

port P6, P6.6, input/output with Schmitt trigger

Bus

Keeper

Direction 0: Input 1: Output

P6SEL.x

P6DIR.x

P6IN.x

INCH=6

Pad Logic

P6OUT.x

P6.6/A6/DAC0/OA2I0

−

OA2

DAC0

DAC12.0OPS

DAC12.0AMP> 0

0 2

0 if DAC12.0AMPx=0 and DAC12.0OPS= 0 1 if DAC12.0AMPx=1 and DAC12.0OPS= 0 2 if DAC12.0AMPx>1 and DAC12.0OPS= 0

DVSS

Note:x = 6

# = Signal from or to ADC12

MSP430xG461x

MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 201 1

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

Port P6 (P6.6) pin functions

CONTROL BITS / SIGNALS

PIN NAME (P6.X)

X FUNCTION

P6DIR.x P6SEL.x INCHx DAC12.0OPS DAC12.0AMPx

OAPx (OA2) OANx (OA2)

P6.6/A6/DAC0/OA2I0 6

P6.6 (I/O) (see Note 1) I: 0; O: 1 0 X 1 X X DAC0 high impedance

(see Note 1)

X X X 0 0 X

DVSS (see Note 1) X X X 0 1 X DAC0 output

(see Note 1)

X X X 0 >1 X

A6 (see Notes 1, 2) X 1 6 X X X OA2I0 (see Note 1) 0 X 0 X X 0

NOTES: 1. X: Don’t care

2. Setting the P6SEL.x bit disables the output driver as well as the input Schmitt trigger to prevent parasitic cross currents when applying analog signals.

MSP430xG461x MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 2011

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

port P6, P6.7, input/output with Schmitt trigger

Bus

Keeper

Direction 0: Input 1: Output

P6SEL.x

P6DIR.x

P6IN.x

INCH=7

Pad Logic

P6OUT.x

P6.7/A7/DAC1/SVSIN

DAC1

DAC12.1OPS

DAC12.1AMP> 0

0 if DAC12.1AMPx = 0 and DAC12.1OPS= 0 1 if DAC12.1AMPx = 1 and DAC12.1OPS= 0 2 if DAC12.1AMPx > 1 and DAC12.1OPS= 0

To SVS Mux

VLD=15

DVSS

Note:x = 7

# = Signal from or to ADC12

MSP430xG461x

MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 201 1

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

Port P6 (P6.7) pin functions

CONTROL BITS / SIGNALS

PIN NAME (P6.X)

X FUNCTION

P6DIR.x P6SEL.x INCHx DAC12.1OPS DAC12.1AMPx

P6.7/A7/DAC1/SVSIN 7

P6.7 (I/O) (see Note 1) I: 0; O: 1 0 X 1 X DAC1 high impedance

(see Note 1)

X X X 0 0

DVSS (see Note 1) X X X 0 1 DAC1 output

(see Note 1)

X X X 0 > 1

A7 (see Notes 1, 2) X 1 7 X X SVSIN (see Notes 1,3) 0 1 0 1 X

NOTES: 1. X: Don’t care

2. Setting the P6SEL.x bit disables the output driver as well as the input Schmitt trigger to prevent parasitic cross currents when applying analog signals.

3. Setting VLDx = 15 will also cause the external SVSIN to be used. In this case, the P6SEL.x bit is a do not care.

MSP430xG461x MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 2011

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

port P7, P7.0 to P7.3, input/output with Schmitt trigger

Bus

Keeper

Direction 0: Input 1: Output

P7SEL.x

P7DIR.x

P7IN.x

LCDS28/32

Segment Sy

Pad Logic

Module X IN

Module X OUT

P7OUT.x

P7.3/UCA0CLK/S30 P7.2/UCA0SOMI/S31 P7.1/UCA0SIMO/S32 P7.0/UCA0STE/S33

Direction control

from Module X

Note:x = 0, 1, 2, 3

y = 30, 31, 32, 33

MSP430xG461x

MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 201 1

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

Port P7 (P7.0 to P7.1) pin functions

CONTROL BITS / SIGNALS

PIN NAME (P7.X)

X FUNCTION

P7DIR.x P7SEL.x LCDS32

P7.0/UCA0STE/S33 0

P7.0 (I/O) I: 0; O: 1 0 0 USCI_A0.UCA0STE (see Notes 1, 2) X 1 0 S33 (see Note 1) X X 1

P7.1/UCA0SIMO/S32 1

P7.1 (I/O) I: 0; O: 1 0 0 USCI_A0.UCA0SIMO (see Notes 1, 2) X 1 0 S32 (see Note 1) X X 1

P7.2/UCA0SOMI/S31 2

P7.2 (I/O) I: 0; O: 1 0 0 USCI_A0.UCA0SOMI (see Notes 1, 3) X 1 0 S31 (see Note 1) X X 1

P7.3/UCA0CLK/S30 3

P7.3 (I/O) I: 0; O: 1 0 0 USCI_A0.UCA0CLK (see Notes 1, 3) X 1 0 S30 (see Note 1) X X 1

NOTES: 1. X: Don’t care

2. The pin direction is controlled by the USCI module.

3. The pin direction is controlled by the USCI module.

MSP430xG461x MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 2011

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

port P7, P7.4 to P7.7, input/output with Schmitt trigger

Bus

Keeper

Direction 0: Input 1: Output

P7SEL.x

P7DIR.x

P7IN .x

LCDS24/28

Segment Sy

Pad Logic

P7OUT.x

P7.7/S26 P7.6/S27 P7.5/S28 P7.4/S29

Note:x = 4, 5, 6, 7

y = 26, 27, 28, 29

Port P7 (P7.4 to P7.5) pin functions

CONTROL BITS / SIGNALS

PIN NAME (P7.X)

X FUNCTION

P7DIR.x P7SEL.x LCDS28

P7.4/S29 4

P7.4 (I/O) I: 0; O: 1 0 0 S29 (see Note 1) X X 1

P7.5/S28 5

P7.5 (I/O) I: 0; O: 1 0 0 S28 (see Note 1) X X 1

P7.6/S27 6

P7.6 (I/O) I: 0; O: 1 0 0 S27 (see Note 1) X X 1

P7.7/S26 7

P7.7 (I/O) I: 0; O: 1 0 0 S26 (see Note 1) X X 1

NOTE 1: X: Don’t care

MSP430xG461x

MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 201 1

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

port P8, P8.0 to P8.7, input/output with Schmitt trigger

Bus

Keeper

Direction 0: Input 1: Output

P8SEL.x

P8DIR.x

P8IN.x

LCDS16/20/24

Segment Sy

Pad Logic

P8OUT.x

Note:x = 0,1,2,3,4,5,6,7 y= 25,24,23,22,21,20,19,18

P8.7/S18 P8.6/S19 P8.5/S20 P8.4/S21 P8.3/S22 P8.2/S23 P8.1/S24 P8.0/S25

MSP430xG461x MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 2011

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

Port P8 (P8.0 to P8.1) pin functions

CONTROL BITS / SIGNALS

PIN NAME (P8.X)

X FUNCTION

P8DIR.x P8SEL.x LCDS16

P8.0/S18 0

P8.0 (I/O) I: 0; O: 1 0 0 S18 (see Note 1) X X 1

P8.1/S19 0

P8.0 (I/O) I: 0; O: 1 0 0 S19 (see Note 1) X X 1

P8.2/S20 2

P8.2 (I/O) I: 0; O: 1 0 0 S20 (see Note 1) X X 1

P8.3/S21 3

P8.3 (I/O) I: 0; O: 1 0 0 S21 (see Note 1) X X 1

P8.4/S22 4

P8.4 (I/O) I: 0; O: 1 0 0 S22 (see Note 1) X X 1

P8.5/S23 5

P8.5 (I/O) I: 0; O: 1 0 0 S23 (see Note 1) X X 1

NOTE 1: X: Don’t care

Port P8 (P8.6 to P8.7) pin functions

CONTROL BITS / SIGNALS

PIN NAME (P8.X)

X FUNCTION

P8DIR.x P8SEL.x LCDS24

P8.6/S24 6

P8.6 (I/O) I: 0; O: 1 0 0 S24 (see Note 1) X X 1

P8.7/S25 7

P8.7 (I/O) I: 0; O: 1 0 0 S25 (see Note 1) X X 1

NOTE 1: X: Don’t care

MSP430xG461x

MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 201 1

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

port P9, P9.0 to P9.7, input/output with Schmitt trigger

Bus

Keeper

Direction 0:Input 1:Output

P9SEL.x

P9DIR.x

P9IN.x

LCDS8/12/16

Segment Sy

Pad Logic

P9OUT.x

Note:x = 0,1,2,3,4,5,6,7 y= 17,16,15,14,13,12,11,10

P9.7/S10 P9.6/S11 P9.5/S12 P9.4/S13 P9.3/S14 P9.2/S15 P9.1/S16 P9.0/S17

MSP430xG461x MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 2011

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

Port P9 (P9.0 to P9.1) pin functions

CONTROL BITS / SIGNALS

PIN NAME (P9.X)

X FUNCTION

P9DIR.x P9SEL.x LCDS16

P9.0/S17 0

P9.0 (I/O) I: 0; O: 1 0 0 S17 (see Note 1) X X 1

P9.1/S16 1

P9.1 (I/O) I: 0; O: 1 0 0 S16 (see Note 1) X X 1

P9.2/S20 2

P9.2 (I/O) I: 0; O: 1 0 0 S15 (see Note 1) X X 1

P9.3/S21 3

P9.3 (I/O) I: 0; O: 1 0 0 S14 (see Note 1) X X 1

P9.4/S22 4

P9.4 (I/O) I: 0; O: 1 0 0 S13 (see Note 1) X X 1

P9.5/S23 5

P9.5 (I/O) I: 0; O: 1 0 0 S12 (see Note 1) X X 1

P9.6/S24 6

P9.6 (I/O) I: 0; O: 1 0 0 S11 (see Note 1) X X 1

P9.7/S25 7

P9.7 (I/O) I: 0; O: 1 0 0 S10 (see Note 1) X X 1

NOTE 1: X: Don’t care

MSP430xG461x

MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 201 1

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

port P10, P10.0 to P10.5, input/output with Schmitt trigger

Bus

Keeper

Direction 0: Input 1: Output

P10SEL.x

P10DIR.x

P10IN .x

LCDS4/8

Segment Sy

Pad Logic

P10OUT.x

Note:x = 0,1,2,3,4,5 y= 9,8,7,6,5,4

P10.5/S4 P10.4/S5 P10.3/S6 P10.2/S7 P10.1/S8 P10.0/S9

Port P10 (P10.0 to P10.1) pin functions

CONTROL BITS / SIGNALS

PIN NAME (P10.X)

X FUNCTION

P10DIR.x P10SEL.x LCDS8

P10.0/S8 0

P10.0 (I/O) I: 0; O: 1 0 0 S8 (see Note 1) X X 1

P10.1/S7 1

P10.1 (I/O) I: 0; O: 1 0 0 S7 (see Note 1) X X 1

P10.2/S7 2

P10.2 (I/O) I: 0; O: 1 0 0 S7 (see Note 1) X X 1

P10.3/S6 3

P10.3 (I/O) I: 0; O: 1 0 0 S6 (see Note 1) X X 1

P10.4/S5 4

P10.4 (I/O) I: 0; O: 1 0 0 S5 (see Note 1) X X 1

P10.5/S4 5

P10.5 (I/O) I: 0; O: 1 0 0 S4 (see Note 1) X X 1

NOTE 1: X: Don’t care

MSP430xG461x MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 2011

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

port P10, P10.6, input/output with Schmitt trigger

Bus

Keeper

Direction 0: Input 1: Output

P10SEL.x

P10DIR.x

P10IN .x

LCDS0

Segment Sy

P10OUT.x

Note: x= 6

P10.6/S3/A15

INCH=15

A15

Pad Logic

Port P10 (P10.6) pin functions

CONTROL BITS / SIGNALS

PIN NAME (P10.X)

X FUNCTION

P10DIR.x P10SEL.x INCHx LCDS0

P10.6/S3/A15 6

P5.0 (I/O) (see Note 1) I: 0; O: 1 0 X 0 A15 (see Notes 1, 3) X 1 15 0 S3 enabled (see Note 1) X 0 X 1 S3 disabled (see Note 1) X 1 X 1

NOTES: 1. X: Don’t care

2. N/A: Not available or not applicable.

3. Setting the P10SEL.x bit disables the output driver as well as the input Schmitt trigger to prevent parasitic cross currents when applying analog signals.

MSP430xG461x

MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 201 1

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

port P10, P10.7, input/output with Schmitt trigger

Bus

Keeper

Direction 0: Input 1: Output

P10SEL.x

P10DIR.x

P10IN .x

LCDS0

Segment Sy

P10OUT.x

Note:x = 7 y= 2

P10.7/S2/A14/OA2 I1

INCH=14

A14

Pad Logic

−

OA2

MSP430xG461x MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 2011

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

Port P10 (P10.7) pin functions

CONTROL BITS / SIGNALS

PIN NAME (P10.X)

X FUNCTION

P10DIR.x P10SEL.x INCHx

OAPx (OA1) OANx (OA1)

LCDS0

P10.7/S2/A14/OA2I1 7

P10.7 (I/O) (see Note 1) I: 0; O: 1 0 X X 0 A14 (see Notes 1, 3) X 1 14 X 0 OA2I1 (see Notes 1, 3) 0 X X 1 0 S2 enabled (see Note 1) X 0 X X 1 S2 disabled (see Note 1) X 1 X X 1

NOTES: 1. X: Don’t care

2. N/A: Not available or not applicable.

3. Setting the P10SEL.x bit disables the output driver as well as the input Schmitt trigger to prevent parasitic cross currents when applying analog signals.

MSP430xG461x

MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 201 1

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

REF+

/DAC0

REF+

/DAC0

Reference Voltage to ADC12

’0’, if DAC12CALON = 0

DAC12AMPx>1 AND DAC12OPS=1

’1’, if DAC12AMPx=1

’1’, if DAC12AMPx>1

−

DAC12OPS

Reference Voltage to DAC1

Reference Voltage to DAC0

If the reference of DAC0 is taken from pin Ve

REF+

/DAC0, unpredictable voltage levels will be on pin.

In this situation, the DAC0 output is fed back to its own reference input.

DAC0_2_OA

DAC12.0OPS

P6.6/A6/DAC0/OA2I0

MSP430xG461x MIXED SIGNAL MICROCONTROLLER

SLAS508I − APRIL 2006 − REVISED MARCH 2011

100

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

JTAG pins TMS, TCK, TDI/TCLK, TDO/TDI, input/output with Schmitt trigger or output

TDI

TDO

TMS

TDI/TCLK

TDO/TDI

Controlled

by JTAG

TCK

TMS

TCK

Controlled by JTAG

Test

JTAG

and

Emulation

Module

Burn and Test

Fuse

RST/NMI

D S

TCK

Tau ~ 50 ns

Brownout

Controlled by JTAG

Texas Instruments MSP430FG4616IPZ, MSP430FG4616IZQW, MSP430FG4617IPZ, MSP430FG4617IZQW, MSP430FG4618IPZ User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
