TEXAS INSTRUMENTS LM3S2651 Technical data
PRELIMINARY
LM3S2651 Microcontroller
DATA SHEET
Copyright © 2007 Luminary Micro, Inc.DS-LM3S2651-1972
Legal Disclaimers and Trademark Information
INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH LUMINARY MICRO PRODUCTS. NO LICENSE, EXPRESS OR
IMPLIED, BY ESTOPPEL OR OTHERWISE, TO ANY INTELLECTUAL PROPERTY RIGHTS IS GRANTED BY THIS DOCUMENT. EXCEPT
AS PROVIDED IN LUMINARY MICRO'S TERMS AND CONDITIONS OF SALE FOR SUCH PRODUCTS, LUMINARY MICRO ASSUMES NO
LIABILITY WHATSOEVER,AND LUMINARYMICRO DISCLAIMS ANY EXPRESS OR IMPLIED WARRANTY,RELATING TO SALE AND/OR
USE OF LUMINARY MICRO'S PRODUCTS INCLUDING LIABILITY OR WARRANTIES RELATING TO FITNESS FOR A PARTICULAR
PURPOSE, MERCHANTABILITY, OR INFRINGEMENT OF ANY PATENT, COPYRIGHT OR OTHER INTELLECTUAL PROPERTY RIGHT.
LUMINARY MICRO'S PRODUCTS ARE NOT INTENDED FOR USE IN MEDICAL, LIFE SAVING, OR LIFE-SUSTAINING APPLICATIONS.
Luminary Micro may make changes to specications and product descriptions at any time, without notice. Contact your local Luminary Micro sales ofce
or your distributor to obtain the latest specications before placing your product order.
Designers must not rely on the absence or characteristics of any features or instructions marked "reserved" or "undened." Luminary Micro reserves these
for future denition and shall have no responsibility whatsoever for conicts or incompatibilities arising from future changes to them.
Copyright © 2007 Luminary Micro, Inc. All rights reserved. Stellaris, Luminary Micro, and the Luminary Micro logo are registered trademarks of
Luminary Micro, Inc. or its subsidiaries in the United States and other countries. ARM and Thumb are registered trademarks and Cortex is a trademark
of ARM Limited. Other names and brands may be claimed as the property of others.
Luminary Micro, Inc.
108 Wild Basin, Suite 350
Austin, TX 78746
Main: +1-512-279-8800
Fax: +1-512-279-8879
http://www.luminarymicro.com
Preliminary
November 29, 20072
LM3S2651 Microcontroller
Table of Contents
About This Document .................................................................................................................... 20
Audience .............................................................................................................................................. 20
About This Manual ................................................................................................................................ 20
Related Documents ............................................................................................................................... 20
Documentation Conventions .................................................................................................................. 20
1 Architectural Overview ...................................................................................................... 22
1.1 Product Features ...................................................................................................................... 22
1.2 Target Applications .................................................................................................................... 28
1.3 High-Level Block Diagram ......................................................................................................... 28
1.4 Functional Overview .................................................................................................................. 29
1.4.1 ARM Cortex™-M3 ..................................................................................................................... 30
1.4.2 Motor Control Peripherals .......................................................................................................... 30
1.4.3 Analog Peripherals .................................................................................................................... 31
1.4.4 Serial Communications Peripherals ............................................................................................ 32
1.4.5 System Peripherals ................................................................................................................... 33
1.4.6 Memory Peripherals .................................................................................................................. 34
1.4.7 Additional Features ................................................................................................................... 34
1.4.8 Hardware Details ...................................................................................................................... 35
2 ARM Cortex-M3 Processor Core ...................................................................................... 36
2.1 Block Diagram .......................................................................................................................... 37
2.2 Functional Description ............................................................................................................... 37
2.2.1 Serial Wire and JTAG Debug ..................................................................................................... 37
2.2.2 Embedded Trace Macrocell (ETM) ............................................................................................. 38
2.2.3 Trace Port Interface Unit (TPIU) ................................................................................................. 38
2.2.4 ROM Table ............................................................................................................................... 38
2.2.5 Memory Protection Unit (MPU) ................................................................................................... 38
2.2.6 Nested Vectored Interrupt Controller (NVIC) ................................................................................ 38
3 Memory Map ....................................................................................................................... 42
4 Interrupts ............................................................................................................................ 44
5 JTAG Interface .................................................................................................................... 47
5.1 Block Diagram .......................................................................................................................... 48
5.2 Functional Description ............................................................................................................... 48
5.2.1 JTAG Interface Pins .................................................................................................................. 49
5.2.2 JTAG TAP Controller ................................................................................................................. 50
5.2.3 Shift Registers .......................................................................................................................... 51
5.2.4 Operational Considerations ........................................................................................................ 51
5.3 Initialization and Configuration ................................................................................................... 54
5.4 Register Descriptions ................................................................................................................ 54
5.4.1 Instruction Register (IR) ............................................................................................................. 54
5.4.2 Data Registers .......................................................................................................................... 56
6 System Control ................................................................................................................... 58
6.1 Functional Description ............................................................................................................... 58
6.1.1 Device Identification .................................................................................................................. 58
6.1.2 Reset Control ............................................................................................................................ 58
Preliminary
3November 29, 2007
Table of Contents
6.1.3 Power Control ........................................................................................................................... 61
6.1.4 Clock Control ............................................................................................................................ 61
6.1.5 System Control ......................................................................................................................... 63
6.2 Initialization and Configuration ................................................................................................... 64
6.3 Register Map ............................................................................................................................ 64
6.4 Register Descriptions ................................................................................................................ 65
7 Hibernation Module .......................................................................................................... 117
7.1 Block Diagram ........................................................................................................................ 118
7.2 Functional Description ............................................................................................................. 118
7.2.1 Register Access Timing ........................................................................................................... 118
7.2.2 Clock Source .......................................................................................................................... 119
7.2.3 Battery Management ............................................................................................................... 119
7.2.4 Real-Time Clock ...................................................................................................................... 119
7.2.5 Non-Volatile Memory ............................................................................................................... 120
7.2.6 Power Control ......................................................................................................................... 120
7.2.7 Interrupts and Status ............................................................................................................... 120
7.3 Initialization and Configuration ................................................................................................. 121
7.3.1 Initialization ............................................................................................................................. 121
7.3.2 RTC Match Functionality (No Hibernation) ................................................................................ 121
7.3.3 RTC Match/Wake-Up from Hibernation ..................................................................................... 121
7.3.4 External Wake-Up from Hibernation .......................................................................................... 122
7.3.5 RTC/External Wake-Up from Hibernation .................................................................................. 122
7.4 Register Map .......................................................................................................................... 122
7.5 Register Descriptions .............................................................................................................. 123
8 Internal Memory ............................................................................................................... 136
8.1 Block Diagram ........................................................................................................................ 136
8.2 Functional Description ............................................................................................................. 136
8.2.1 SRAM Memory ........................................................................................................................ 136
8.2.2 Flash Memory ......................................................................................................................... 137
8.3 Flash Memory Initialization and Configuration ........................................................................... 138
8.3.1 Flash Programming ................................................................................................................. 138
8.3.2 Nonvolatile Register Programming ........................................................................................... 139
8.4 Register Map .......................................................................................................................... 139
8.5 Flash Register Descriptions (Flash Control Offset) ..................................................................... 140
8.6 Flash Register Descriptions (System Control Offset) .................................................................. 147
9 General-Purpose Input/Outputs (GPIOs) ....................................................................... 160
9.1 Functional Description ............................................................................................................. 160
9.1.1 Data Control ........................................................................................................................... 161
9.1.2 Interrupt Control ...................................................................................................................... 162
9.1.3 Mode Control .......................................................................................................................... 163
9.1.4 Commit Control ....................................................................................................................... 163
9.1.5 Pad Control ............................................................................................................................. 163
9.1.6 Identification ........................................................................................................................... 163
9.2 Initialization and Configuration ................................................................................................. 163
9.3 Register Map .......................................................................................................................... 165
9.4 Register Descriptions .............................................................................................................. 166
Preliminary
November 29, 20074
LM3S2651 Microcontroller
10 General-Purpose Timers ................................................................................................. 201
10.1 Block Diagram ........................................................................................................................ 201
10.2 Functional Description ............................................................................................................. 202
10.2.1 GPTM Reset Conditions .......................................................................................................... 203
10.2.2 32-Bit Timer Operating Modes .................................................................................................. 203
10.2.3 16-Bit Timer Operating Modes .................................................................................................. 204
10.3 Initialization and Configuration ................................................................................................. 208
10.3.1 32-Bit One-Shot/Periodic Timer Mode ....................................................................................... 208
10.3.2 32-Bit Real-Time Clock (RTC) Mode ......................................................................................... 209
10.3.3 16-Bit One-Shot/Periodic Timer Mode ....................................................................................... 209
10.3.4 16-Bit Input Edge Count Mode ................................................................................................. 210
10.3.5 16-Bit Input Edge Timing Mode ................................................................................................ 210
10.3.6 16-Bit PWM Mode ................................................................................................................... 211
10.4 Register Map .......................................................................................................................... 211
10.5 Register Descriptions .............................................................................................................. 212
11 Watchdog Timer ............................................................................................................... 237
11.1 Block Diagram ........................................................................................................................ 237
11.2 Functional Description ............................................................................................................. 237
11.3 Initialization and Configuration ................................................................................................. 238
11.4 Register Map .......................................................................................................................... 238
11.5 Register Descriptions .............................................................................................................. 239
12 Analog-to-Digital Converter (ADC) ................................................................................. 260
12.1 Block Diagram ........................................................................................................................ 261
12.2 Functional Description ............................................................................................................. 261
12.2.1 Sample Sequencers ................................................................................................................ 261
12.2.2 Module Control ........................................................................................................................ 262
12.2.3 Hardware Sample Averaging Circuit ......................................................................................... 263
12.2.4 Analog-to-Digital Converter ...................................................................................................... 263
12.2.5 Test Modes ............................................................................................................................. 263
12.2.6 Internal Temperature Sensor .................................................................................................... 263
12.3 Initialization and Configuration ................................................................................................. 264
12.3.1 Module Initialization ................................................................................................................. 264
12.3.2 Sample Sequencer Configuration ............................................................................................. 264
12.4 Register Map .......................................................................................................................... 265
12.5 Register Descriptions .............................................................................................................. 266
13 Universal Asynchronous Receivers/Transmitters (UARTs) ......................................... 293
13.1 Block Diagram ........................................................................................................................ 294
13.2 Functional Description ............................................................................................................. 294
13.2.1 Transmit/Receive Logic ........................................................................................................... 294
13.2.2 Baud-Rate Generation ............................................................................................................. 295
13.2.3 Data Transmission .................................................................................................................. 296
13.2.4 Serial IR (SIR) ......................................................................................................................... 296
13.2.5 FIFO Operation ....................................................................................................................... 297
13.2.6 Interrupts ................................................................................................................................ 297
13.2.7 Loopback Operation ................................................................................................................ 298
13.2.8 IrDA SIR block ........................................................................................................................ 298
13.3 Initialization and Configuration ................................................................................................. 298
13.4 Register Map .......................................................................................................................... 299
Preliminary
5November 29, 2007
Table of Contents
13.5 Register Descriptions .............................................................................................................. 300
14 Synchronous Serial Interface (SSI) ................................................................................ 334
14.1 Block Diagram ........................................................................................................................ 334
14.2 Functional Description ............................................................................................................. 334
14.2.1 Bit Rate Generation ................................................................................................................. 335
14.2.2 FIFO Operation ....................................................................................................................... 335
14.2.3 Interrupts ................................................................................................................................ 335
14.2.4 Frame Formats ....................................................................................................................... 336
14.3 Initialization and Configuration ................................................................................................. 343
14.4 Register Map .......................................................................................................................... 344
14.5 Register Descriptions .............................................................................................................. 345
15 Inter-Integrated Circuit (I2C) Interface ............................................................................ 371
15.1 Block Diagram ........................................................................................................................ 371
15.2 Functional Description ............................................................................................................. 371
15.2.1 I2C Bus Functional Overview .................................................................................................... 372
15.2.2 Available Speed Modes ........................................................................................................... 374
15.2.3 Interrupts ................................................................................................................................ 375
15.2.4 Loopback Operation ................................................................................................................ 375
15.2.5 Command Sequence Flow Charts ............................................................................................ 376
15.3 Initialization and Configuration ................................................................................................. 382
15.4 I2C Register Map ..................................................................................................................... 383
15.5 Register Descriptions (I2C Master) ........................................................................................... 384
15.6 Register Descriptions (I2C Slave) ............................................................................................. 397
16 Controller Area Network (CAN) Module ......................................................................... 406
16.1 Controller Area Network Overview ............................................................................................ 406
16.2 Controller Area Network Features ............................................................................................ 406
16.3 Controller Area Network Block Diagram .................................................................................... 407
16.4 Controller Area Network Functional Description ......................................................................... 408
16.4.1 Initialization ............................................................................................................................. 408
16.4.2 Operation ............................................................................................................................... 409
16.4.3 Transmitting Message Objects ................................................................................................. 409
16.4.4 Configuring a Transmit Message Object .................................................................................... 409
16.4.5 Updating a Transmit Message Object ....................................................................................... 410
16.4.6 Accepting Received Message Objects ...................................................................................... 410
16.4.7 Receiving a Data Frame .......................................................................................................... 411
16.4.8 Receiving a Remote Frame ...................................................................................................... 411
16.4.9 Receive/Transmit Priority ......................................................................................................... 411
16.4.10 Configuring a Receive Message Object .................................................................................... 411
16.4.11 Handling of Received Message Objects .................................................................................... 412
16.4.12 Handling of Interrupts .............................................................................................................. 412
16.4.13 Bit Timing Configuration Error Considerations ........................................................................... 413
16.4.14 Bit Time and Bit Rate ............................................................................................................... 413
16.4.15 Calculating the Bit Timing Parameters ...................................................................................... 415
16.5 Controller Area Network Register Map ...................................................................................... 417
16.6 Register Descriptions .............................................................................................................. 419
17 Analog Comparator ......................................................................................................... 447
17.1 Block Diagram ........................................................................................................................ 447
Preliminary
November 29, 20076
LM3S2651 Microcontroller
17.2 Functional Description ............................................................................................................. 447
17.2.1 Internal Reference Programming .............................................................................................. 448
17.3 Initialization and Configuration ................................................................................................. 449
17.4 Register Map .......................................................................................................................... 450
17.5 Register Descriptions .............................................................................................................. 450
18 Pulse Width Modulator (PWM) ........................................................................................ 458
18.1 Block Diagram ........................................................................................................................ 458
18.2 Functional Description ............................................................................................................. 458
18.2.1 PWM Timer ............................................................................................................................. 458
18.2.2 PWM Comparators .................................................................................................................. 459
18.2.3 PWM Signal Generator ............................................................................................................ 460
18.2.4 Dead-Band Generator ............................................................................................................. 461
18.2.5 Interrupt/ADC-Trigger Selector ................................................................................................. 461
18.2.6 Synchronization Methods ......................................................................................................... 461
18.2.7 Fault Conditions ...................................................................................................................... 462
18.2.8 Output Control Block ............................................................................................................... 462
18.3 Initialization and Configuration ................................................................................................. 462
18.4 Register Map .......................................................................................................................... 463
18.5 Register Descriptions .............................................................................................................. 464
19 Pin Diagram ...................................................................................................................... 493
20 Signal Tables .................................................................................................................... 494
21 Operating Characteristics ............................................................................................... 508
22 Electrical Characteristics ................................................................................................ 509
22.1 DC Characteristics .................................................................................................................. 509
22.1.1 Maximum Ratings ................................................................................................................... 509
22.1.2 Recommended DC Operating Conditions .................................................................................. 509
22.1.3 On-Chip Low Drop-Out (LDO) Regulator Characteristics ............................................................ 510
22.1.4 Power Specifications ............................................................................................................... 510
22.1.5 Flash Memory Characteristics .................................................................................................. 512
22.2 AC Characteristics ................................................................................................................... 512
22.2.1 Load Conditions ...................................................................................................................... 512
22.2.2 Clocks .................................................................................................................................... 512
22.2.3 Analog-to-Digital Converter ...................................................................................................... 513
22.2.4 Analog Comparator ................................................................................................................. 514
22.2.5 I2C ......................................................................................................................................... 514
22.2.6 Hibernation Module ................................................................................................................. 515
22.2.7 Synchronous Serial Interface (SSI) ........................................................................................... 515
22.2.8 JTAG and Boundary Scan ........................................................................................................ 517
22.2.9 General-Purpose I/O ............................................................................................................... 518
22.2.10 Reset ..................................................................................................................................... 519
23 Package Information ........................................................................................................ 521
A Serial Flash Loader .......................................................................................................... 523
A.1 Serial Flash Loader ................................................................................................................. 523
A.2 Interfaces ............................................................................................................................... 523
A.2.1 UART ..................................................................................................................................... 523
A.2.2 SSI ......................................................................................................................................... 523
Preliminary
7November 29, 2007
Table of Contents
A.3 Packet Handling ...................................................................................................................... 524
A.3.1 Packet Format ........................................................................................................................ 524
A.3.2 Sending Packets ..................................................................................................................... 524
A.3.3 Receiving Packets ................................................................................................................... 524
A.4 Commands ............................................................................................................................. 525
A.4.1 COMMAND_PING (0X20) ........................................................................................................ 525
A.4.2 COMMAND_GET_STATUS (0x23) ........................................................................................... 525
A.4.3 COMMAND_DOWNLOAD (0x21) ............................................................................................. 525
A.4.4 COMMAND_SEND_DATA (0x24) ............................................................................................. 526
A.4.5 COMMAND_RUN (0x22) ......................................................................................................... 526
A.4.6 COMMAND_RESET (0x25) ..................................................................................................... 526
B Register Quick Reference ............................................................................................... 528
C Ordering and Contact Information ................................................................................. 547
C.1 Ordering Information ................................................................................................................ 547
C.2 Kits ......................................................................................................................................... 547
C.3 Company Information .............................................................................................................. 547
C.4 Support Information ................................................................................................................. 548
Preliminary
November 29, 20078
LM3S2651 Microcontroller
List of Figures
Figure 1-1. Stellaris®2000 Series High-Level Block Diagram ............................................................... 29
Figure 2-1. CPU Block Diagram ......................................................................................................... 37
Figure 2-2. TPIU Block Diagram ........................................................................................................ 38
Figure 5-1. JTAG Module Block Diagram ............................................................................................ 48
Figure 5-2. Test Access Port State Machine ....................................................................................... 51
Figure 5-3. IDCODE Register Format ................................................................................................. 56
Figure 5-4. BYPASS Register Format ................................................................................................ 57
Figure 5-5. Boundary Scan Register Format ....................................................................................... 57
Figure 6-1. External Circuitry to Extend Reset .................................................................................... 59
Figure 7-1. Hibernation Module Block Diagram ................................................................................. 118
Figure 8-1. Flash Block Diagram ...................................................................................................... 136
Figure 9-1. GPIO Port Block Diagram ............................................................................................... 161
Figure 9-2. GPIODATA Write Example ............................................................................................. 162
Figure 9-3. GPIODATA Read Example ............................................................................................. 162
Figure 10-1. GPTM Module Block Diagram ........................................................................................ 202
Figure 10-2. 16-Bit Input Edge Count Mode Example .......................................................................... 206
Figure 10-3. 16-Bit Input Edge Time Mode Example ........................................................................... 207
Figure 10-4. 16-Bit PWM Mode Example ............................................................................................ 208
Figure 11-1. WDT Module Block Diagram .......................................................................................... 237
Figure 12-1. ADC Module Block Diagram ........................................................................................... 261
Figure 12-2. Internal Temperature Sensor Characteristic ..................................................................... 264
Figure 13-1. UART Module Block Diagram ......................................................................................... 294
Figure 13-2. UART Character Frame ................................................................................................. 295
Figure 13-3. IrDA Data Modulation ..................................................................................................... 297
Figure 14-1. SSI Module Block Diagram ............................................................................................. 334
Figure 14-2. TI Synchronous Serial Frame Format (Single Transfer) .................................................... 336
Figure 14-3. TI Synchronous Serial Frame Format (Continuous Transfer) ............................................ 337
Figure 14-4. Freescale SPI Format (Single Transfer) with SPO=0 and SPH=0 ...................................... 338
Figure 14-5. Freescale SPI Format (Continuous Transfer) with SPO=0 and SPH=0 .............................. 338
Figure 14-6. Freescale SPI Frame Format with SPO=0 and SPH=1 ..................................................... 339
Figure 14-7. Freescale SPI Frame Format (Single Transfer) with SPO=1 and SPH=0 ........................... 340
Figure 14-8. Freescale SPI Frame Format (Continuous Transfer) with SPO=1 and SPH=0 .................... 340
Figure 14-9. Freescale SPI Frame Format with SPO=1 and SPH=1 ..................................................... 341
Figure 14-10. MICROWIRE Frame Format (Single Frame) .................................................................... 342
Figure 14-11. MICROWIRE Frame Format (Continuous Transfer) ......................................................... 343
Figure 14-12. MICROWIRE Frame Format, SSIFss Input Setup and Hold Requirements ........................ 343
Figure 15-1. I2C Block Diagram ......................................................................................................... 371
Figure 15-2. I2C Bus Configuration .................................................................................................... 372
Figure 15-3. START and STOP Conditions ......................................................................................... 372
Figure 15-4. Complete Data Transfer with a 7-Bit Address ................................................................... 373
Figure 15-5. R/S Bit in First Byte ........................................................................................................ 373
Figure 15-6. Data Validity During Bit Transfer on the I2C Bus ............................................................... 373
Figure 15-7. Master Single SEND ...................................................................................................... 376
Figure 15-8. Master Single RECEIVE ................................................................................................. 377
Figure 15-9. Master Burst SEND ....................................................................................................... 378
Preliminary
9November 29, 2007
Table of Contents
Figure 15-10. Master Burst RECEIVE .................................................................................................. 379
Figure 15-11. Master Burst RECEIVE after Burst SEND ........................................................................ 380
Figure 15-12. Master Burst SEND after Burst RECEIVE ........................................................................ 381
Figure 15-13. Slave Command Sequence ............................................................................................ 382
Figure 16-1. CAN Module Block Diagram ........................................................................................... 407
Figure 16-2. CAN Bit Time ................................................................................................................ 414
Figure 17-1. Analog Comparator Module Block Diagram ..................................................................... 447
Figure 17-2. Structure of Comparator Unit .......................................................................................... 448
Figure 17-3. Comparator Internal Reference Structure ........................................................................ 449
Figure 18-1. PWM Module Block Diagram .......................................................................................... 458
Figure 18-2. PWM Count-Down Mode ................................................................................................ 459
Figure 18-3. PWM Count-Up/Down Mode .......................................................................................... 460
Figure 18-4. PWM Generation Example In Count-Up/Down Mode ....................................................... 460
Figure 18-5. PWM Dead-Band Generator ........................................................................................... 461
Figure 19-1. Pin Connection Diagram ................................................................................................ 493
Figure 22-1. Load Conditions ............................................................................................................ 512
Figure 22-2. I2C Timing ..................................................................................................................... 515
Figure 22-3. Hibernation Module Timing ............................................................................................. 515
Figure 22-4. SSI Timing for TI Frame Format (FRF=01), Single Transfer Timing Measurement .............. 516
Figure 22-5. SSI Timing for MICROWIRE Frame Format (FRF=10), Single Transfer ............................. 516
Figure 22-6. SSI Timing for SPI Frame Format (FRF=00), with SPH=1 ................................................. 517
Figure 22-7. JTAG Test Clock Input Timing ......................................................................................... 518
Figure 22-8. JTAG Test Access Port (TAP) Timing .............................................................................. 518
Figure 22-9. JTAG TRST Timing ........................................................................................................ 518
Figure 22-10. External Reset Timing (RST) .......................................................................................... 519
Figure 22-11. Power-On Reset Timing ................................................................................................. 520
Figure 22-12. Brown-Out Reset Timing ................................................................................................ 520
Figure 22-13. Software Reset Timing ................................................................................................... 520
Figure 22-14. Watchdog Reset Timing ................................................................................................. 520
Figure 23-1. 100-Pin LQFP Package .................................................................................................. 521
Preliminary
November 29, 200710
LM3S2651 Microcontroller
List of Tables
Table 1. Documentation Conventions ............................................................................................ 20
Table 3-1. Memory Map ................................................................................................................... 42
Table 4-1. Exception Types .............................................................................................................. 44
Table 4-2. Interrupts ........................................................................................................................ 45
Table 5-1. JTAG Port Pins Reset State ............................................................................................. 49
Table 5-2. JTAG Instruction Register Commands ............................................................................... 54
Table 6-1. System Control Register Map ........................................................................................... 64
Table 7-1. Hibernation Module Register Map ................................................................................... 122
Table 8-1. Flash Protection Policy Combinations ............................................................................. 138
Table 8-2. Flash Resident Registers ............................................................................................... 139
Table 8-3. Flash Register Map ........................................................................................................ 139
Table 9-1. GPIO Pad Configuration Examples ................................................................................. 164
Table 9-2. GPIO Interrupt Configuration Example ............................................................................ 164
Table 9-3. GPIO Register Map ....................................................................................................... 165
Table 10-1. Available CCP Pins ........................................................................................................ 202
Table 10-2. 16-Bit Timer With Prescaler Configurations ..................................................................... 205
Table 10-3. Timers Register Map ...................................................................................................... 211
Table 11-1. Watchdog Timer Register Map ........................................................................................ 238
Table 12-1. Samples and FIFO Depth of Sequencers ........................................................................ 261
Table 12-2. ADC Register Map ......................................................................................................... 265
Table 13-1. UART Register Map ....................................................................................................... 299
Table 14-1. SSI Register Map .......................................................................................................... 345
Table 15-1. Examples of I2C Master Timer Period versus Speed Mode ............................................... 374
Table 15-2. Inter-Integrated Circuit (I2C) Interface Register Map ......................................................... 383
Table 15-3. Write Field Decoding for I2CMCS[3:0] Field (Sheet 1 of 3) ................................................ 388
Table 16-1. Transmit Message Object Bit Settings ............................................................................. 410
Table 16-2. Receive Message Object Bit Settings .............................................................................. 412
Table 16-3. CAN Protocol Ranges .................................................................................................... 414
Table 16-4. CAN Register Map ......................................................................................................... 417
Table 17-1. Comparator 0 Operating Modes ...................................................................................... 448
Table 17-2. Internal Reference Voltage and ACREFCTL Field Values ................................................. 449
Table 17-3. Analog Comparators Register Map ................................................................................. 450
Table 18-1. PWM Register Map ........................................................................................................ 463
Table 20-1. Signals by Pin Number ................................................................................................... 494
Table 20-2. Signals by Signal Name ................................................................................................. 498
Table 20-3. Signals by Function, Except for GPIO ............................................................................. 502
Table 20-4. GPIO Pins and Alternate Functions ................................................................................. 506
Table 21-1. Temperature Characteristics ........................................................................................... 508
Table 21-2. Thermal Characteristics ................................................................................................. 508
Table 22-1. Maximum Ratings .......................................................................................................... 509
Table 22-2. Recommended DC Operating Conditions ........................................................................ 509
Table 22-3. LDO Regulator Characteristics ....................................................................................... 510
Table 22-4. Detailed Power Specifications ........................................................................................ 511
Table 22-5. Flash Memory Characteristics ........................................................................................ 512
Table 22-6. Phase Locked Loop (PLL) Characteristics ....................................................................... 512
Table 22-7. Clock Characteristics ..................................................................................................... 512
Preliminary
11November 29, 2007
Table of Contents
Table 22-8. Crystal Characteristics ................................................................................................... 513
Table 22-9. ADC Characteristics ....................................................................................................... 513
Table 22-10. Analog Comparator Characteristics ................................................................................. 514
Table 22-11. Analog Comparator Voltage Reference Characteristics .................................................... 514
Table 22-12. I2C Characteristics ......................................................................................................... 514
Table 22-13. Hibernation Module Characteristics ................................................................................. 515
Table 22-14. SSI Characteristics ........................................................................................................ 515
Table 22-15. JTAG Characteristics ..................................................................................................... 517
Table 22-16. GPIO Characteristics ..................................................................................................... 519
Table 22-17. Reset Characteristics ..................................................................................................... 519
Table C-1. Part Ordering Information ............................................................................................... 547
Preliminary
November 29, 200712
LM3S2651 Microcontroller
List of Registers
System Control .............................................................................................................................. 58
Register 1: Device Identification 0 (DID0), offset 0x000 ....................................................................... 66
Register 2: Brown-Out Reset Control (PBORCTL), offset 0x030 .......................................................... 68
Register 3: LDO Power Control (LDOPCTL), offset 0x034 ................................................................... 69
Register 4: Raw Interrupt Status (RIS), offset 0x050 ........................................................................... 70
Register 5: Interrupt Mask Control (IMC), offset 0x054 ........................................................................ 71
Register 6: Masked Interrupt Status and Clear (MISC), offset 0x058 .................................................... 72
Register 7: Reset Cause (RESC), offset 0x05C .................................................................................. 73
Register 8: Run-Mode Clock Configuration (RCC), offset 0x060 .......................................................... 74
Register 9: XTAL to PLL Translation (PLLCFG), offset 0x064 .............................................................. 78
Register 10: Run-Mode Clock Configuration 2 (RCC2), offset 0x070 ...................................................... 79
Register 11: Deep Sleep Clock Configuration (DSLPCLKCFG), offset 0x144 .......................................... 81
Register 12: Device Identification 1 (DID1), offset 0x004 ....................................................................... 82
Register 13: Device Capabilities 0 (DC0), offset 0x008 ......................................................................... 84
Register 14: Device Capabilities 1 (DC1), offset 0x010 ......................................................................... 85
Register 15: Device Capabilities 2 (DC2), offset 0x014 ......................................................................... 87
Register 16: Device Capabilities 3 (DC3), offset 0x018 ......................................................................... 89
Register 17: Device Capabilities 4 (DC4), offset 0x01C ......................................................................... 91
Register 18: Run Mode Clock Gating Control Register 0 (RCGC0), offset 0x100 .................................... 92
Register 19: Sleep Mode Clock Gating Control Register 0 (SCGC0), offset 0x110 .................................. 94
Register 20: Deep Sleep Mode Clock Gating Control Register 0 (DCGC0), offset 0x120 ......................... 96
Register 21: Run Mode Clock Gating Control Register 1 (RCGC1), offset 0x104 .................................... 98
Register 22: Sleep Mode Clock Gating Control Register 1 (SCGC1), offset 0x114 ................................. 101
Register 23: Deep Sleep Mode Clock Gating Control Register 1 (DCGC1), offset 0x124 ....................... 104
Register 24: Run Mode Clock Gating Control Register 2 (RCGC2), offset 0x108 ................................... 107
Register 25: Sleep Mode Clock Gating Control Register 2 (SCGC2), offset 0x118 ................................. 109
Register 26: Deep Sleep Mode Clock Gating Control Register 2 (DCGC2), offset 0x128 ....................... 111
Register 27: Software Reset Control 0 (SRCR0), offset 0x040 ............................................................. 113
Register 28: Software Reset Control 1 (SRCR1), offset 0x044 ............................................................. 114
Register 29: Software Reset Control 2 (SRCR2), offset 0x048 ............................................................. 116
Hibernation Module ..................................................................................................................... 117
Register 1: Hibernation RTC Counter (HIBRTCC), offset 0x000 ......................................................... 124
Register 2: Hibernation RTC Match 0 (HIBRTCM0), offset 0x004 ....................................................... 125
Register 3: Hibernation RTC Match 1 (HIBRTCM1), offset 0x008 ....................................................... 126
Register 4: Hibernation RTC Load (HIBRTCLD), offset 0x00C ........................................................... 127
Register 5: Hibernation Control (HIBCTL), offset 0x010 ..................................................................... 128
Register 6: Hibernation Interrupt Mask (HIBIM), offset 0x014 ............................................................. 130
Register 7: Hibernation Raw Interrupt Status (HIBRIS), offset 0x018 .................................................. 131
Register 8: Hibernation Masked Interrupt Status (HIBMIS), offset 0x01C ............................................ 132
Register 9: Hibernation Interrupt Clear (HIBIC), offset 0x020 ............................................................. 133
Register 10: Hibernation RTC Trim (HIBRTCT), offset 0x024 ............................................................... 134
Register 11: Hibernation Data (HIBDATA), offset 0x030-0x12C ............................................................ 135
Internal Memory ........................................................................................................................... 136
Register 1: Flash Memory Address (FMA), offset 0x000 .................................................................... 141
Register 2: Flash Memory Data (FMD), offset 0x004 ......................................................................... 142
Preliminary
13November 29, 2007
Table of Contents
Register 3: Flash Memory Control (FMC), offset 0x008 ..................................................................... 143
Register 4: Flash Controller Raw Interrupt Status (FCRIS), offset 0x00C ............................................ 145
Register 5: Flash Controller Interrupt Mask (FCIM), offset 0x010 ........................................................ 146
Register 6: Flash Controller Masked Interrupt Status and Clear (FCMISC), offset 0x014 ..................... 147
Register 7: USec Reload (USECRL), offset 0x140 ............................................................................ 148
Register 8: Flash Memory Protection Read Enable 0 (FMPRE0), offset 0x130 and 0x200 ................... 149
Register 9: Flash Memory Protection Program Enable 0 (FMPPE0), offset 0x134 and 0x400 ............... 150
Register 10: User Debug (USER_DBG), offset 0x1D0 ......................................................................... 151
Register 11: User Register 0 (USER_REG0), offset 0x1E0 .................................................................. 152
Register 12: User Register 1 (USER_REG1), offset 0x1E4 .................................................................. 153
Register 13: Flash Memory Protection Read Enable 1 (FMPRE1), offset 0x204 .................................... 154
Register 14: Flash Memory Protection Read Enable 2 (FMPRE2), offset 0x208 .................................... 155
Register 15: Flash Memory Protection Read Enable 3 (FMPRE3), offset 0x20C ................................... 156
Register 16: Flash Memory Protection Program Enable 1 (FMPPE1), offset 0x404 ............................... 157
Register 17: Flash Memory Protection Program Enable 2 (FMPPE2), offset 0x408 ............................... 158
Register 18: Flash Memory Protection Program Enable 3 (FMPPE3), offset 0x40C ............................... 159
General-Purpose Input/Outputs (GPIOs) ................................................................................... 160
Register 1: GPIO Data (GPIODATA), offset 0x000 ............................................................................ 167
Register 2: GPIO Direction (GPIODIR), offset 0x400 ......................................................................... 168
Register 3: GPIO Interrupt Sense (GPIOIS), offset 0x404 .................................................................. 169
Register 4: GPIO Interrupt Both Edges (GPIOIBE), offset 0x408 ........................................................ 170
Register 5: GPIO Interrupt Event (GPIOIEV), offset 0x40C ................................................................ 171
Register 6: GPIO Interrupt Mask (GPIOIM), offset 0x410 ................................................................... 172
Register 7: GPIO Raw Interrupt Status (GPIORIS), offset 0x414 ........................................................ 173
Register 8: GPIO Masked Interrupt Status (GPIOMIS), offset 0x418 ................................................... 174
Register 9: GPIO Interrupt Clear (GPIOICR), offset 0x41C ................................................................ 175
Register 10: GPIO Alternate Function Select (GPIOAFSEL), offset 0x420 ............................................ 176
Register 11: GPIO 2-mA Drive Select (GPIODR2R), offset 0x500 ........................................................ 178
Register 12: GPIO 4-mA Drive Select (GPIODR4R), offset 0x504 ........................................................ 179
Register 13: GPIO 8-mA Drive Select (GPIODR8R), offset 0x508 ........................................................ 180
Register 14: GPIO Open Drain Select (GPIOODR), offset 0x50C ......................................................... 181
Register 15: GPIO Pull-Up Select (GPIOPUR), offset 0x510 ................................................................ 182
Register 16: GPIO Pull-Down Select (GPIOPDR), offset 0x514 ........................................................... 183
Register 17: GPIO Slew Rate Control Select (GPIOSLR), offset 0x518 ................................................ 184
Register 18: GPIO Digital Enable (GPIODEN), offset 0x51C ................................................................ 185
Register 19: GPIO Lock (GPIOLOCK), offset 0x520 ............................................................................ 186
Register 20: GPIO Commit (GPIOCR), offset 0x524 ............................................................................ 187
Register 21: GPIO Peripheral Identification 4 (GPIOPeriphID4), offset 0xFD0 ....................................... 189
Register 22: GPIO Peripheral Identification 5 (GPIOPeriphID5), offset 0xFD4 ....................................... 190
Register 23: GPIO Peripheral Identification 6 (GPIOPeriphID6), offset 0xFD8 ....................................... 191
Register 24: GPIO Peripheral Identification 7 (GPIOPeriphID7), offset 0xFDC ...................................... 192
Register 25: GPIO Peripheral Identification 0 (GPIOPeriphID0), offset 0xFE0 ....................................... 193
Register 26: GPIO Peripheral Identification 1 (GPIOPeriphID1), offset 0xFE4 ....................................... 194
Register 27: GPIO Peripheral Identification 2 (GPIOPeriphID2), offset 0xFE8 ....................................... 195
Register 28: GPIO Peripheral Identification 3 (GPIOPeriphID3), offset 0xFEC ...................................... 196
Register 29: GPIO PrimeCell Identification 0 (GPIOPCellID0), offset 0xFF0 .......................................... 197
Register 30: GPIO PrimeCell Identification 1 (GPIOPCellID1), offset 0xFF4 .......................................... 198
Register 31: GPIO PrimeCell Identification 2 (GPIOPCellID2), offset 0xFF8 .......................................... 199
Preliminary
November 29, 200714
LM3S2651 Microcontroller
Register 32: GPIO PrimeCell Identification 3 (GPIOPCellID3), offset 0xFFC ......................................... 200
General-Purpose Timers ............................................................................................................. 201
Register 1: GPTM Configuration (GPTMCFG), offset 0x000 .............................................................. 213
Register 2: GPTM TimerA Mode (GPTMTAMR), offset 0x004 ............................................................ 214
Register 3: GPTM TimerB Mode (GPTMTBMR), offset 0x008 ............................................................ 216
Register 4: GPTM Control (GPTMCTL), offset 0x00C ........................................................................ 218
Register 5: GPTM Interrupt Mask (GPTMIMR), offset 0x018 .............................................................. 221
Register 6: GPTM Raw Interrupt Status (GPTMRIS), offset 0x01C ..................................................... 223
Register 7: GPTM Masked Interrupt Status (GPTMMIS), offset 0x020 ................................................ 224
Register 8: GPTM Interrupt Clear (GPTMICR), offset 0x024 .............................................................. 225
Register 9: GPTM TimerA Interval Load (GPTMTAILR), offset 0x028 ................................................. 227
Register 10: GPTM TimerB Interval Load (GPTMTBILR), offset 0x02C ................................................ 228
Register 11: GPTM TimerA Match (GPTMTAMATCHR), offset 0x030 ................................................... 229
Register 12: GPTM TimerB Match (GPTMTBMATCHR), offset 0x034 .................................................. 230
Register 13: GPTM TimerA Prescale (GPTMTAPR), offset 0x038 ........................................................ 231
Register 14: GPTM TimerB Prescale (GPTMTBPR), offset 0x03C ....................................................... 232
Register 15: GPTM TimerA Prescale Match (GPTMTAPMR), offset 0x040 ........................................... 233
Register 16: GPTM TimerB Prescale Match (GPTMTBPMR), offset 0x044 ........................................... 234
Register 17: GPTM TimerA (GPTMTAR), offset 0x048 ........................................................................ 235
Register 18: GPTM TimerB (GPTMTBR), offset 0x04C ....................................................................... 236
Watchdog Timer ........................................................................................................................... 237
Register 1: Watchdog Load (WDTLOAD), offset 0x000 ...................................................................... 240
Register 2: Watchdog Value (WDTVALUE), offset 0x004 ................................................................... 241
Register 3: Watchdog Control (WDTCTL), offset 0x008 ..................................................................... 242
Register 4: Watchdog Interrupt Clear (WDTICR), offset 0x00C .......................................................... 243
Register 5: Watchdog Raw Interrupt Status (WDTRIS), offset 0x010 .................................................. 244
Register 6: Watchdog Masked Interrupt Status (WDTMIS), offset 0x014 ............................................. 245
Register 7: Watchdog Test (WDTTEST), offset 0x418 ....................................................................... 246
Register 8: Watchdog Lock (WDTLOCK), offset 0xC00 ..................................................................... 247
Register 9: Watchdog Peripheral Identification 4 (WDTPeriphID4), offset 0xFD0 ................................. 248
Register 10: Watchdog Peripheral Identification 5 (WDTPeriphID5), offset 0xFD4 ................................. 249
Register 11: Watchdog Peripheral Identification 6 (WDTPeriphID6), offset 0xFD8 ................................. 250
Register 12: Watchdog Peripheral Identification 7 (WDTPeriphID7), offset 0xFDC ................................ 251
Register 13: Watchdog Peripheral Identification 0 (WDTPeriphID0), offset 0xFE0 ................................. 252
Register 14: Watchdog Peripheral Identification 1 (WDTPeriphID1), offset 0xFE4 ................................. 253
Register 15: Watchdog Peripheral Identification 2 (WDTPeriphID2), offset 0xFE8 ................................. 254
Register 16: Watchdog Peripheral Identification 3 (WDTPeriphID3), offset 0xFEC ................................. 255
Register 17: Watchdog PrimeCell Identification 0 (WDTPCellID0), offset 0xFF0 .................................... 256
Register 18: Watchdog PrimeCell Identification 1 (WDTPCellID1), offset 0xFF4 .................................... 257
Register 19: Watchdog PrimeCell Identification 2 (WDTPCellID2), offset 0xFF8 .................................... 258
Register 20: Watchdog PrimeCell Identification 3 (WDTPCellID3 ), offset 0xFFC .................................. 259
Analog-to-Digital Converter (ADC) ............................................................................................. 260
Register 1: ADC Active Sample Sequencer (ADCACTSS), offset 0x000 ............................................. 267
Register 2: ADC Raw Interrupt Status (ADCRIS), offset 0x004 ........................................................... 268
Register 3: ADC Interrupt Mask (ADCIM), offset 0x008 ..................................................................... 269
Register 4: ADC Interrupt Status and Clear (ADCISC), offset 0x00C .................................................. 270
Register 5: ADC Overflow Status (ADCOSTAT), offset 0x010 ............................................................ 271
Register 6: ADC Event Multiplexer Select (ADCEMUX), offset 0x014 ................................................. 272
Preliminary
15November 29, 2007
Table of Contents
Register 7: ADC Underflow Status (ADCUSTAT), offset 0x018 ........................................................... 275
Register 8: ADC Sample Sequencer Priority (ADCSSPRI), offset 0x020 ............................................. 276
Register 9: ADC Processor Sample Sequence Initiate (ADCPSSI), offset 0x028 ................................. 277
Register 10: ADC Sample Averaging Control (ADCSAC), offset 0x030 ................................................. 278
Register 11: ADC Sample Sequence Input Multiplexer Select 0 (ADCSSMUX0), offset 0x040 ............... 279
Register 12: ADC Sample Sequence Control 0 (ADCSSCTL0), offset 0x044 ........................................ 281
Register 13: ADC Sample Sequence Result FIFO 0 (ADCSSFIFO0), offset 0x048 ................................ 284
Register 14: ADC Sample Sequence Result FIFO 1 (ADCSSFIFO1), offset 0x068 ................................ 284
Register 15: ADC Sample Sequence Result FIFO 2 (ADCSSFIFO2), offset 0x088 ................................ 284
Register 16: ADC Sample Sequence Result FIFO 3 (ADCSSFIFO3), offset 0x0A8 ............................... 284
Register 17: ADC Sample Sequence FIFO 0 Status (ADCSSFSTAT0), offset 0x04C ............................. 285
Register 18: ADC Sample Sequence FIFO 1 Status (ADCSSFSTAT1), offset 0x06C ............................. 285
Register 19: ADC Sample Sequence FIFO 2 Status (ADCSSFSTAT2), offset 0x08C ............................ 285
Register 20: ADC Sample Sequence FIFO 3 Status (ADCSSFSTAT3), offset 0x0AC ............................ 285
Register 21: ADC Sample Sequence Input Multiplexer Select 1 (ADCSSMUX1), offset 0x060 ............... 286
Register 22: ADC Sample Sequence Input Multiplexer Select 2 (ADCSSMUX2), offset 0x080 ............... 286
Register 23: ADC Sample Sequence Control 1 (ADCSSCTL1), offset 0x064 ........................................ 287
Register 24: ADC Sample Sequence Control 2 (ADCSSCTL2), offset 0x084 ........................................ 287
Register 25: ADC Sample Sequence Input Multiplexer Select 3 (ADCSSMUX3), offset 0x0A0 ............... 289
Register 26: ADC Sample Sequence Control 3 (ADCSSCTL3), offset 0x0A4 ........................................ 290
Register 27: ADC Test Mode Loopback (ADCTMLB), offset 0x100 ....................................................... 291
Universal Asynchronous Receivers/Transmitters (UARTs) ..................................................... 293
Register 1: UART Data (UARTDR), offset 0x000 ............................................................................... 301
Register 2: UART Receive Status/Error Clear (UARTRSR/UARTECR), offset 0x004 ........................... 303
Register 3: UART Flag (UARTFR), offset 0x018 ................................................................................ 305
Register 4: UART IrDA Low-Power Register (UARTILPR), offset 0x020 ............................................. 307
Register 5: UART Integer Baud-Rate Divisor (UARTIBRD), offset 0x024 ............................................ 308
Register 6: UART Fractional Baud-Rate Divisor (UARTFBRD), offset 0x028 ....................................... 309
Register 7: UART Line Control (UARTLCRH), offset 0x02C ............................................................... 310
Register 8: UART Control (UARTCTL), offset 0x030 ......................................................................... 312
Register 9: UART Interrupt FIFO Level Select (UARTIFLS), offset 0x034 ........................................... 314
Register 10: UART Interrupt Mask (UARTIM), offset 0x038 ................................................................. 316
Register 11: UART Raw Interrupt Status (UARTRIS), offset 0x03C ...................................................... 318
Register 12: UART Masked Interrupt Status (UARTMIS), offset 0x040 ................................................. 319
Register 13: UART Interrupt Clear (UARTICR), offset 0x044 ............................................................... 320
Register 14: UART Peripheral Identification 4 (UARTPeriphID4), offset 0xFD0 ..................................... 322
Register 15: UART Peripheral Identification 5 (UARTPeriphID5), offset 0xFD4 ..................................... 323
Register 16: UART Peripheral Identification 6 (UARTPeriphID6), offset 0xFD8 ..................................... 324
Register 17: UART Peripheral Identification 7 (UARTPeriphID7), offset 0xFDC ..................................... 325
Register 18: UART Peripheral Identification 0 (UARTPeriphID0), offset 0xFE0 ...................................... 326
Register 19: UART Peripheral Identification 1 (UARTPeriphID1), offset 0xFE4 ...................................... 327
Register 20: UART Peripheral Identification 2 (UARTPeriphID2), offset 0xFE8 ...................................... 328
Register 21: UART Peripheral Identification 3 (UARTPeriphID3), offset 0xFEC ..................................... 329
Register 22: UART PrimeCell Identification 0 (UARTPCellID0), offset 0xFF0 ........................................ 330
Register 23: UART PrimeCell Identification 1 (UARTPCellID1), offset 0xFF4 ........................................ 331
Register 24: UART PrimeCell Identification 2 (UARTPCellID2), offset 0xFF8 ........................................ 332
Register 25: UART PrimeCell Identification 3 (UARTPCellID3), offset 0xFFC ........................................ 333
Preliminary
November 29, 200716
LM3S2651 Microcontroller
Synchronous Serial Interface (SSI) ............................................................................................ 334
Register 1: SSI Control 0 (SSICR0), offset 0x000 .............................................................................. 346
Register 2: SSI Control 1 (SSICR1), offset 0x004 .............................................................................. 348
Register 3: SSI Data (SSIDR), offset 0x008 ...................................................................................... 350
Register 4: SSI Status (SSISR), offset 0x00C ................................................................................... 351
Register 5: SSI Clock Prescale (SSICPSR), offset 0x010 .................................................................. 353
Register 6: SSI Interrupt Mask (SSIIM), offset 0x014 ......................................................................... 354
Register 7: SSI Raw Interrupt Status (SSIRIS), offset 0x018 .............................................................. 356
Register 8: SSI Masked Interrupt Status (SSIMIS), offset 0x01C ........................................................ 357
Register 9: SSI Interrupt Clear (SSIICR), offset 0x020 ....................................................................... 358
Register 10: SSI Peripheral Identification 4 (SSIPeriphID4), offset 0xFD0 ............................................. 359
Register 11: SSI Peripheral Identification 5 (SSIPeriphID5), offset 0xFD4 ............................................. 360
Register 12: SSI Peripheral Identification 6 (SSIPeriphID6), offset 0xFD8 ............................................. 361
Register 13: SSI Peripheral Identification 7 (SSIPeriphID7), offset 0xFDC ............................................ 362
Register 14: SSI Peripheral Identification 0 (SSIPeriphID0), offset 0xFE0 ............................................. 363
Register 15: SSI Peripheral Identification 1 (SSIPeriphID1), offset 0xFE4 ............................................. 364
Register 16: SSI Peripheral Identification 2 (SSIPeriphID2), offset 0xFE8 ............................................. 365
Register 17: SSI Peripheral Identification 3 (SSIPeriphID3), offset 0xFEC ............................................ 366
Register 18: SSI PrimeCell Identification 0 (SSIPCellID0), offset 0xFF0 ............................................... 367
Register 19: SSI PrimeCell Identification 1 (SSIPCellID1), offset 0xFF4 ............................................... 368
Register 20: SSI PrimeCell Identification 2 (SSIPCellID2), offset 0xFF8 ............................................... 369
Register 21: SSI PrimeCell Identification 3 (SSIPCellID3), offset 0xFFC ............................................... 370
Inter-Integrated Circuit (I2C) Interface ........................................................................................ 371
Register 1: I2C Master Slave Address (I2CMSA), offset 0x000 ........................................................... 385
Register 2: I2C Master Control/Status (I2CMCS), offset 0x004 ........................................................... 386
Register 3: I2C Master Data (I2CMDR), offset 0x008 ......................................................................... 390
Register 4: I2C Master Timer Period (I2CMTPR), offset 0x00C ........................................................... 391
Register 5: I2C Master Interrupt Mask (I2CMIMR), offset 0x010 ......................................................... 392
Register 6: I2C Master Raw Interrupt Status (I2CMRIS), offset 0x014 ................................................. 393
Register 7: I2C Master Masked Interrupt Status (I2CMMIS), offset 0x018 ........................................... 394
Register 8: I2C Master Interrupt Clear (I2CMICR), offset 0x01C ......................................................... 395
Register 9: I2C Master Configuration (I2CMCR), offset 0x020 ............................................................ 396
Register 10: I2C Slave Own Address (I2CSOAR), offset 0x000 ............................................................ 398
Register 11: I2C Slave Control/Status (I2CSCSR), offset 0x004 ........................................................... 399
Register 12: I2C Slave Data (I2CSDR), offset 0x008 ........................................................................... 401
Register 13: I2C Slave Interrupt Mask (I2CSIMR), offset 0x00C ........................................................... 402
Register 14: I2C Slave Raw Interrupt Status (I2CSRIS), offset 0x010 ................................................... 403
Register 15: I2C Slave Masked Interrupt Status (I2CSMIS), offset 0x014 .............................................. 404
Register 16: I2C Slave Interrupt Clear (I2CSICR), offset 0x018 ............................................................ 405
Controller Area Network (CAN) Module ..................................................................................... 406
Register 1: CAN Control (CANCTL), offset 0x000 ............................................................................. 420
Register 2: CAN Status (CANSTS), offset 0x004 ............................................................................... 422
Register 3: CAN Error Counter (CANERR), offset 0x008 ................................................................... 425
Register 4: CAN Bit Timing (CANBIT), offset 0x00C .......................................................................... 426
Register 5: CAN Interrupt (CANINT), offset 0x010 ............................................................................. 428
Register 6: CAN Test (CANTST), offset 0x014 .................................................................................. 429
Register 7: CAN Baud Rate Prescalar Extension (CANBRPE), offset 0x018 ....................................... 431
17November 29, 2007
Preliminary
Table of Contents
Register 8: CAN IF1 Command Request (CANIF1CRQ), offset 0x020 ................................................ 432
Register 9: CAN IF2 Command Request (CANIF2CRQ), offset 0x080 ................................................ 432
Register 10: CAN IF1 Command Mask (CANIF1CMSK), offset 0x024 .................................................. 433
Register 11: CAN IF2 Command Mask (CANIF2CMSK), offset 0x084 .................................................. 433
Register 12: CAN IF1 Mask 1 (CANIF1MSK1), offset 0x028 ................................................................ 436
Register 13: CAN IF2 Mask 1 (CANIF2MSK1), offset 0x088 ................................................................ 436
Register 14: CAN IF1 Mask 2 (CANIF1MSK2), offset 0x02C ................................................................ 437
Register 15: CAN IF2 Mask 2 (CANIF2MSK2), offset 0x08C ................................................................ 437
Register 16: CAN IF1 Arbitration 1 (CANIF1ARB1), offset 0x030 ......................................................... 438
Register 17: CAN IF2 Arbitration 1 (CANIF2ARB1), offset 0x090 ......................................................... 438
Register 18: CAN IF1 Arbitration 2 (CANIF1ARB2), offset 0x034 ......................................................... 439
Register 19: CAN IF2 Arbitration 2 (CANIF2ARB2), offset 0x094 ......................................................... 439
Register 20: CAN IF1 Message Control (CANIF1MCTL), offset 0x038 .................................................. 440
Register 21: CAN IF2 Message Control (CANIF2MCTL), offset 0x098 .................................................. 440
Register 22: CAN IF1 Data A1 (CANIF1DA1), offset 0x03C ................................................................. 442
Register 23: CAN IF1 Data A2 (CANIF1DA2), offset 0x040 ................................................................. 442
Register 24: CAN IF1 Data B1 (CANIF1DB1), offset 0x044 ................................................................. 442
Register 25: CAN IF1 Data B2 (CANIF1DB2), offset 0x048 ................................................................. 442
Register 26: CAN IF2 Data A1 (CANIF2DA1), offset 0x09C ................................................................. 442
Register 27: CAN IF2 Data A2 (CANIF2DA2), offset 0x0A0 ................................................................. 442
Register 28: CAN IF2 Data B1 (CANIF2DB1), offset 0x0A4 ................................................................. 442
Register 29: CAN IF2 Data B2 (CANIF2DB2), offset 0x0A8 ................................................................. 442
Register 30: CAN Transmission Request 1 (CANTXRQ1), offset 0x100 ................................................ 443
Register 31: CAN Transmission Request 2 (CANTXRQ2), offset 0x104 ................................................ 443
Register 32: CAN New Data 1 (CANNWDA1), offset 0x120 ................................................................. 444
Register 33: CAN New Data 2 (CANNWDA2), offset 0x124 ................................................................. 444
Register 34: CAN Message 1 Interrupt Pending (CANMSG1INT), offset 0x140 ..................................... 445
Register 35: CAN Message 2 Interrupt Pending (CANMSG2INT), offset 0x144 ..................................... 445
Register 36: CAN Message 1 Valid (CANMSG1VAL), offset 0x160 ....................................................... 446
Register 37: CAN Message 2 Valid (CANMSG2VAL), offset 0x164 ....................................................... 446
Analog Comparator ..................................................................................................................... 447
Register 1: Analog Comparator Masked Interrupt Status (ACMIS), offset 0x00 .................................... 451
Register 2: Analog Comparator Raw Interrupt Status (ACRIS), offset 0x04 ......................................... 452
Register 3: Analog Comparator Interrupt Enable (ACINTEN), offset 0x08 ........................................... 453
Register 4: Analog Comparator Reference Voltage Control (ACREFCTL), offset 0x10 ......................... 454
Register 5: Analog Comparator Status 0 (ACSTAT0), offset 0x20 ....................................................... 455
Register 6: Analog Comparator Control 0 (ACCTL0), offset 0x24 ....................................................... 456
Pulse Width Modulator (PWM) .................................................................................................... 458
Register 1: PWM Master Control (PWMCTL), offset 0x000 ................................................................ 465
Register 2: PWM Time Base Sync (PWMSYNC), offset 0x004 ........................................................... 466
Register 3: PWM Output Enable (PWMENABLE), offset 0x008 .......................................................... 467
Register 4: PWM Output Inversion (PWMINVERT), offset 0x00C ....................................................... 468
Register 5: PWM Output Fault (PWMFAULT), offset 0x010 ................................................................ 469
Register 6: PWM Interrupt Enable (PWMINTEN), offset 0x014 ........................................................... 470
Register 7: PWM Raw Interrupt Status (PWMRIS), offset 0x018 ........................................................ 471
Register 8: PWM Interrupt Status and Clear (PWMISC), offset 0x01C ................................................ 472
Register 9: PWM Status (PWMSTATUS), offset 0x020 ...................................................................... 473
Register 10: PWM0 Control (PWM0CTL), offset 0x040 ....................................................................... 474
Preliminary
November 29, 200718
LM3S2651 Microcontroller
Register 11: PWM1 Control (PWM1CTL), offset 0x080 ....................................................................... 474
Register 12: PWM0 Interrupt and Trigger Enable (PWM0INTEN), offset 0x044 .................................... 476
Register 13: PWM1 Interrupt and Trigger Enable (PWM1INTEN), offset 0x084 .................................... 476
Register 14: PWM0 Raw Interrupt Status (PWM0RIS), offset 0x048 .................................................... 478
Register 15: PWM1 Raw Interrupt Status (PWM1RIS), offset 0x088 .................................................... 478
Register 16: PWM0 Interrupt Status and Clear (PWM0ISC), offset 0x04C ........................................... 479
Register 17: PWM1 Interrupt Status and Clear (PWM1ISC), offset 0x08C ........................................... 479
Register 18: PWM0 Load (PWM0LOAD), offset 0x050 ....................................................................... 480
Register 19: PWM1 Load (PWM1LOAD), offset 0x090 ....................................................................... 480
Register 20: PWM0 Counter (PWM0COUNT), offset 0x054 ................................................................ 481
Register 21: PWM1 Counter (PWM1COUNT), offset 0x094 ................................................................ 481
Register 22: PWM0 Compare A (PWM0CMPA), offset 0x058 ............................................................. 482
Register 23: PWM1 Compare A (PWM1CMPA), offset 0x098 ............................................................. 482
Register 24: PWM0 Compare B (PWM0CMPB), offset 0x05C ............................................................. 483
Register 25: PWM1 Compare B (PWM1CMPB), offset 0x09C ............................................................. 483
Register 26: PWM0 Generator A Control (PWM0GENA), offset 0x060 ................................................ 484
Register 27: PWM1 Generator A Control (PWM1GENA), offset 0x0A0 ................................................ 484
Register 28: PWM0 Generator B Control (PWM0GENB), offset 0x064 ................................................ 487
Register 29: PWM1 Generator B Control (PWM1GENB), offset 0x0A4 ................................................ 487
Register 30: PWM0 Dead-Band Control (PWM0DBCTL), offset 0x068 ................................................ 490
Register 31: PWM1 Dead-Band Control (PWM1DBCTL), offset 0x0A8 ................................................. 490
Register 32: PWM0 Dead-Band Rising-Edge Delay (PWM0DBRISE), offset 0x06C ............................. 491
Register 33: PWM1 Dead-Band Rising-Edge Delay (PWM1DBRISE), offset 0x0AC ............................. 491
Register 34: PWM0 Dead-Band Falling-Edge-Delay (PWM0DBFALL), offset 0x070 ............................. 492
Register 35: PWM1 Dead-Band Falling-Edge-Delay (PWM1DBFALL), offset 0x0B0 ............................. 492
Preliminary
19November 29, 2007
About This Document
About This Document
This data sheet provides reference information for the LM3S2651 microcontroller, describing the
functional blocks of the system-on-chip (SoC) device designed around the ARM® Cortex™-M3
core.
Audience
This manual is intended for system software developers, hardware designers, and application
developers.
About This Manual
This document is organized into sections that correspond to each major feature.
Related Documents
The following documents are referenced by the data sheet, and available on the documentation CD
or from the Luminary Micro web site at www.luminarymicro.com:
■
ARM® Cortex™-M3 Technical Reference Manual
■
ARM® CoreSight Technical Reference Manual
■
ARM® v7-M Architecture Application Level Reference Manual
The following related documents are also referenced:
■
IEEE Standard 1149.1-Test Access Port and Boundary-Scan Architecture
This documentation list was current as of publication date. Please check the Luminary Micro web
site for additional documentation, including application notes and white papers.
Documentation Conventions
This document uses the conventions shown in Table 1 on page 20.
Table 1. Documentation Conventions
MeaningNotation
General Register Notation
REGISTER
offset 0xnnn
Register N
APB registers are indicated in uppercase bold. For example, PBORCTL is the Power-On and
Brown-Out Reset Control register. If a register name contains a lowercase n, it represents more
than one register. For example, SRCRn represents any (or all) of the three Software Reset Control
registers: SRCR0, SRCR1 , and SRCR2.
A single bit in a register.bit
Two or more consecutive and related bits.bit field
A hexadecimal increment to a register's address, relative to that module's base address as specified
in “Memory Map” on page 42.
Registers are numbered consecutively throughout the document to aid in referencing them. The
register number has no meaning to software.
Preliminary
November 29, 200720
reserved
yy:xx
Register Bit/Field
Types
R/W1C
W1C
Reset Value
Pin/Signal Notation
assert a signal
SIGNAL
SIGNAL
Numbers
X
0x
LM3S2651 Microcontroller
MeaningNotation
Register bits marked reserved are reserved for future use. In most cases, reserved bits are set to
0; however, user software should not rely on the value of a reserved bit. To provide software
compatibility with future products, the value of a reserved bit should be preserved across a
read-modify-write operation.
The range of register bits inclusive from xx to yy. For example, 31:15 means bits 15 through 31 in
that register.
This value in the register bit diagram indicates whether software running on the controller can
change the value of the bit field.
Software can read this field. The bit or field is cleared by hardware after reading the bit/field.RC
Software can read this field. Always write the chip reset value.RO
Software can read or write this field.R/W
Software can read or write this field. A write of a 0 to a W1C bit does not affect the bit value in the
register. A write of a 1 clears the value of the bit in the register; the remaining bits remain unchanged.
This register type is primarily used for clearing interrupt status bits where the read operation
provides the interrupt status and the write of the read value clears only the interrupts being reported
at the time the register was read.
Software can write this field. A write of a 0 to a W1C bit does not affect the bit value in the register.
A write of a 1 clears the value of the bit in the register; the remaining bits remain unchanged. A
read of the register returns no meaningful data.
This register is typically used to clear the corresponding bit in an interrupt register.
Only a write by software is valid; a read of the register returns no meaningful data.WO
This value in the register bit diagram shows the bit/field value after any reset, unless noted.Register Bit/Field
Bit cleared to 0 on chip reset.0
Bit set to 1 on chip reset.1
Nondeterministic.-
Pin alternate function; a pin defaults to the signal without the brackets.[ ]
Refers to the physical connection on the package.pin
Refers to the electrical signal encoding of a pin.signal
Change the value of the signal from the logically False state to the logically True state. For active
High signals, the asserted signal value is 1 (High); for active Low signals, the asserted signal value
is 0 (Low). The active polarity (High or Low) is defined by the signal name (see SIGNAL and SIGNAL
below).
Change the value of the signal from the logically True state to the logically False state.deassert a signal
Signal names are in uppercase and in the Courier font. An overbar on a signal name indicates that
it is active Low. To assert SIGNAL is to drive it Low; to deassert SIGNAL is to drive it High.
Signal names are in uppercase and in the Courier font. An active High signal has no overbar. To
assert SIGNAL is to drive it High; to deassert SIGNAL is to drive it Low.
An uppercase X indicates any of several values is allowed, where X can be any legal pattern. For
example, a binary value of 0X00 can be either 0100 or 0000, a hex value of 0xX is 0x0 or 0x1, and
so on.
Hexadecimal numbers have a prefix of 0x. For example, 0x00FF is the hexadecimal number FF.
All other numbers within register tables are assumed to be binary. Within conceptual information,
binary numbers are indicated with a b suffix, for example, 1011b, and decimal numbers are written
without a prefix or suffix.
Preliminary
21November 29, 2007
Architectural Overview
1 Architectural Overview
The Luminary Micro Stellaris®family of microcontrollers—the first ARM® Cortex™-M3 based
controllers—brings high-performance 32-bit computing to cost-sensitive embedded microcontroller
applications. These pioneering parts deliver customers 32-bit performance at a cost equivalent to
legacy 8- and 16-bit devices, all in a package with a small footprint.
The Stellaris®family offers efficient performance and extensive integration, favorably positioning
the device into cost-conscious applications requiring significant control-processing and connectivity
capabilities. The Stellaris®LM3S1000 series extends the Stellaris®family with larger on-chip
memories, enhanced power management, and expanded I/O and control capabilities. The Stellaris
LM3S2000 series, designed for Controller Area Network (CAN) applications, extends the Stellaris
family with Bosch CAN networking technology, the golden standard in short-haul industrial networks.
The Stellaris®LM3S2000 series also marks the first integration of CAN capabilities with the
revolutionary Cortex-M3 core. The Stellaris®LM3S6000 series combines both a 10/100 Ethernet
Media Access Control (MAC) and Physical (PHY) layer, marking the first time that integrated
connectivity is available with an ARM Cortex-M3 MCU and the only integrated 10/100 Ethernet MAC
and PHY available in an ARM architecture MCU. The Stellaris®LM3S8000 series combines Bosch
Controller Area Network technology with both a 10/100 Ethernet Media Access Control (MAC) and
Physical (PHY) layer.
®
The LM3S2651 microcontroller is targeted for industrial applications, including remote monitoring,
electronic point-of-sale machines, test and measurement equipment, network appliances and
switches, factory automation, HVAC and building control, gaming equipment, motion control, medical
instrumentation, and fire and security.
For applications requiring extreme conservation of power, the LM3S2651 microcontroller features
a Battery-backed Hibernation module to efficiently power down the LM3S2651 to a low-power state
during extended periods of inactivity. With a power-up/power-down sequencer, a continuous time
counter (RTC), a pair of match registers, an APB interface to the system bus, and dedicated
non-volatile memory, the Hibernation module positions the LM3S2651 microcontroller perfectly for
battery applications.
In addition, the LM3S2651 microcontroller offers the advantages of ARM's widely available
development tools, System-on-Chip (SoC) infrastructure IP applications, and a large user community.
Additionally, the microcontroller uses ARM's Thumb®-compatible Thumb-2 instruction set to reduce
memory requirements and, thereby, cost. Finally, the LM3S2651 microcontroller is code-compatible
to all members of the extensive Stellaris®family; providing flexibility to fit our customers' precise
needs.
Luminary Micro offers a complete solution to get to market quickly, with evaluation and development
boards, white papers and application notes, an easy-to-use peripheral driver library, and a strong
support, sales, and distributor network.
1.1 Product Features
The LM3S2651 microcontroller includes the following product features:
■ 32-Bit RISC Performance
– 32-bit ARM® Cortex™-M3 v7M architecture optimized for small-footprint embedded
applications
November 29, 200722
Preliminary
LM3S2651 Microcontroller
– System timer (SysTick), providing a simple, 24-bit clear-on-write, decrementing, wrap-on-zero
counter with a flexible control mechanism
– Thumb®-compatible Thumb-2-only instruction set processor core for high code density
– 50-MHz operation
– Hardware-division and single-cycle-multiplication
– Integrated Nested Vectored Interrupt Controller (NVIC) providing deterministic interrupt
handling
– 35 interrupts with eight priority levels
– Memory protection unit (MPU), providing a privileged mode for protected operating system
functionality
– Unaligned data access, enabling data to be efficiently packed into memory
– Atomic bit manipulation (bit-banding), delivering maximum memory utilization and streamlined
peripheral control
■ Internal Memory
– 128 KB single-cycle flash
• User-managed flash block protection on a 2-KB block basis
• User-managed flash data programming
• User-defined and managed flash-protection block
– 32 KB single-cycle SRAM
■ General-Purpose Timers
– Four General-Purpose Timer Modules (GPTM), each of which provides two 16-bit timers.
Each GPTM can be configured to operate independently:
• As a single 32-bit timer
• As one 32-bit Real-Time Clock (RTC) to event capture
• For Pulse Width Modulation (PWM)
• To trigger analog-to-digital conversions
– 32-bit Timer modes
• Programmable one-shot timer
• Programmable periodic timer
• Real-Time Clock when using an external 32.768-KHz clock as the input
Preliminary
23November 29, 2007
Architectural Overview
• User-enabled stalling in periodic and one-shot mode when the controller asserts the CPU
• ADC event trigger
– 16-bit Timer modes
• General-purpose timer function with an 8-bit prescaler
• Programmable one-shot timer
• Programmable periodic timer
• User-enabled stalling when the controller asserts CPU Halt flag during debug
• ADC event trigger
– 16-bit Input Capture modes
• Input edge count capture
• Input edge time capture
Halt flag during debug
– 16-bit PWM mode
• Simple PWM mode with software-programmable output inversion of the PWM signal
■ ARM FiRM-compliant Watchdog Timer
– 32-bit down counter with a programmable load register
– Separate watchdog clock with an enable
– Programmable interrupt generation logic with interrupt masking
– Lock register protection from runaway software
– Reset generation logic with an enable/disable
– User-enabled stalling when the controller asserts the CPU Halt flag during debug
■ Controller Area Network (CAN)
– Supports CAN protocol version 2.0 part A/B
– Bit rates up to 1Mb/s
– 32 message objects, each with its own identifier mask
– Maskable interrupt
– Disable automatic retransmission mode for TTCAN
– Programmable loop-back mode for self-test operation
■ Synchronous Serial Interface (SSI)
Preliminary
November 29, 200724
LM3S2651 Microcontroller
– Two SSI modules, each with the following features:
– Master or slave operation
– Programmable clock bit rate and prescale
– Separate transmit and receive FIFOs, 16 bits wide, 8 locations deep
– Programmable interface operation for Freescale SPI, MICROWIRE, or Texas Instruments
synchronous serial interfaces
– Programmable data frame size from 4 to 16 bits
– Internal loopback test mode for diagnostic/debug testing
■ UART
– Three fully programmable 16C550-type UARTs with IrDA support
– Separate 16x8 transmit (TX) and 16x12 receive (RX) FIFOs to reduce CPU interrupt service
loading
– Programmable baud-rate generator with fractional divider
– Programmable FIFO length, including 1-byte deep operation providing conventional
double-buffered interface
– FIFO trigger levels of 1/8, 1/4, 1/2, 3/4, and 7/8
– Standard asynchronous communication bits for start, stop, and parity
– False-start-bit detection
– Line-break generation and detection
■ ADC
– Single- and differential-input configurations
– Four 10-bit channels (inputs) when used as single-ended inputs
– Sample rate of 500 thousand samples/second
– Flexible, configurable analog-to-digital conversion
– Four programmable sample conversion sequences from one to eight entries long, with
corresponding conversion result FIFOs
– Each sequence triggered by software or internal event (timers, analog comparators, PWM
or GPIO)
– On-chip temperature sensor
■ Analog Comparators
– One integrated analog comparator
25November 29, 2007
Preliminary
Architectural Overview
– Configurable for output to: drive an output pin, generate an interrupt, or initiate an ADC sample
sequence
– Compare external pin input to external pin input or to internal programmable voltage reference
■ I2C
– Master and slave receive and transmit operation with transmission speed up to 100 Kbps in
Standard mode and 400 Kbps in Fast mode
– Interrupt generation
– Master with arbitration and clock synchronization, multimaster support, and 7-bit addressing
mode
■ PWM
– Two PWM generator blocks, each with one 16-bit counter, two comparators, a PWM generator,
and a dead-band generator
– One 16-bit counter
• Runs in Down or Up/Down mode
• Output frequency controlled by a 16-bit load value
• Load value updates can be synchronized
• Produces output signals at zero and load value
– Two PWM comparators
• Comparator value updates can be synchronized
• Produces output signals on match
– PWM generator
• Output PWM signal is constructed based on actions taken as a result of the counter and
PWM comparator output signals
• Produces two independent PWM signals
– Dead-band generator
• Produces two PWM signals with programmable dead-band delays suitable for driving a
half-H bridge
• Can be bypassed, leaving input PWM signals unmodified
– Flexible output control block with PWM output enable of each PWM signal
• PWM output enable of each PWM signal
• Optional output inversion of each PWM signal (polarity control)
Preliminary
November 29, 200726
LM3S2651 Microcontroller
• Optional fault handling for each PWM signal
• Synchronization of timers in the PWM generator blocks
• Synchronization of timer/comparator updates across the PWM generator blocks
• Interrupt status summary of the PWM generator blocks
– Can initiate an ADC sample sequence
■ GPIOs
– 16-53 GPIOs, depending on configuration
– 5-V-tolerant input/outputs
– Programmable interrupt generation as either edge-triggered or level-sensitive
– Bit masking in both read and write operations through address lines
– Can initiate an ADC sample sequence
– Programmable control for GPIO pad configuration:
• Weak pull-up or pull-down resistors
• 2-mA, 4-mA, and 8-mA pad drive
• Slew rate control for the 8-mA drive
• Open drain enables
• Digital input enables
■ Power
– On-chip Low Drop-Out (LDO) voltage regulator, with programmable output user-adjustable
from 2.25 V to 2.75 V
– Hibernation module handles the power-up/down 3.3 V sequencing and control for the core
digital logic and analog circuits
– Low-power options on controller: Sleep and Deep-sleep modes
– Low-power options for peripherals: software controls shutdown of individual peripherals
– User-enabled LDO unregulated voltage detection and automatic reset
– 3.3-V supply brown-out detection and reporting via interrupt or reset
■ Flexible Reset Sources
– Power-on reset (POR)
– Reset pin assertion
– Brown-out (BOR) detector alerts to system power drops
Preliminary
27November 29, 2007
Architectural Overview
– Software reset
– Watchdog timer reset
– Internal low drop-out (LDO) regulator output goes unregulated
■ Additional Features
– Six reset sources
– Programmable clock source control
– Clock gating to individual peripherals for power savings
– IEEE 1149.1-1990 compliant Test Access Port (TAP) controller
– Debug access via JTAG and Serial Wire interfaces
– Full JTAG boundary scan
■ Industrial-range 100-pin RoHS-compliant LQFP package
1.2 Target Applications
■ Remote monitoring
■ Electronic point-of-sale (POS) machines
■ Test and measurement equipment
■ Network appliances and switches
■ Factory automation
■ HVAC and building control
■ Gaming equipment
■ Motion control
■ Medical instrumentation
■ Fire and security
■ Power and energy
■ Transportation
1.3 High-Level Block Diagram
Figure 1-1 on page 29 represents the full set of features in the Stellaris®2000 series of devices;
not all features may be available on the LM3S2651 microcontroller.
Preliminary
November 29, 200728
Figure 1-1. Stellaris®2000 Series High-Level Block Diagram
LM3S2651 Microcontroller
1.4 Functional Overview
The following sections provide an overview of the features of the LM3S2651 microcontroller. The
page number in parenthesis indicates where that feature is discussed in detail. Ordering and support
information can be found in “Ordering and Contact Information” on page 547.
29November 29, 2007
Preliminary
Architectural Overview
1.4.1 ARM Cortex™-M3
1.4.1.1 Processor Core (see page 36)
All members of the Stellaris®product family, including the LM3S2651 microcontroller, are designed
around an ARM Cortex™-M3 processor core. The ARM Cortex-M3 processor provides the core for
a high-performance, low-cost platform that meets the needs of minimal memory implementation,
reduced pin count, and low-power consumption, while delivering outstanding computational
performance and exceptional system response to interrupts.
“ARM Cortex-M3 Processor Core” on page 36 provides an overview of the ARM core; the core is
detailed in the ARM® Cortex™-M3 Technical Reference Manual.
1.4.1.2 System Timer (SysTick)
Cortex-M3 includes an integrated system timer, SysTick. SysTick provides a simple, 24-bit
clear-on-write, decrementing, wrap-on-zero counter with a flexible control mechanism. The counter
can be used in several different ways, for example:
■ An RTOS tick timer which fires at a programmable rate (for example, 100 Hz) and invokes a
SysTick routine.
■ A high-speed alarm timer using the system clock.
■ A variable rate alarm or signal timer—the duration is range-dependent on the reference clock
used and the dynamic range of the counter.
■ A simple counter. Software can use this to measure time to completion and time used.
■ An internal clock source control based on missing/meeting durations. The COUNTFLAG bit-field
in the control and status register can be used to determine if an action completed within a set
duration, as part of a dynamic clock management control loop.
1.4.1.3 Nested Vectored Interrupt Controller (NVIC)
The LM3S2651 controller includes the ARM Nested Vectored Interrupt Controller (NVIC) on the
ARM Cortex-M3 core. The NVIC and Cortex-M3 prioritize and handle all exceptions. All exceptions
are handled in Handler Mode. The processor state is automatically stored to the stack on an
exception, and automatically restored from the stack at the end of the Interrupt Service Routine
(ISR). The vector is fetched in parallel to the state saving, which enables efficient interrupt entry.
The processor supports tail-chaining, which enables back-to-back interrupts to be performed without
the overhead of state saving and restoration. Software can set eight priority levels on 7 exceptions
(system handlers) and 35 interrupts.
“Interrupts” on page 44 provides an overview of the NVIC controller and the interrupt map. Exceptions
and interrupts are detailed in the ARM® Cortex™-M3 Technical Reference Manual.
1.4.2 Motor Control Peripherals
To enhance motor control, the LM3S2651 controller features Pulse Width Modulation (PWM) outputs.
1.4.2.1 PWM
Pulse width modulation (PWM) is a powerful technique for digitally encoding analog signal levels.
High-resolution counters are used to generate a square wave, and the duty cycle of the square
wave is modulated to encode an analog signal. Typical applications include switching power supplies
and motor control.
November 29, 200730
Preliminary
Loading...
