LM193, LM293, LM293A, LM393
LM393A, LM393Y, LM2903, LM2903Q
DUAL DIFFERENTIAL COMPARATORS
SLCS005E – JUNE 1976 – REVISED NOVEMBER 1999
1
POST OFFICE BOX 655303 • DALLAS, TEXAS 75265
D
Single Supply or Dual Supplies
D
Wide Range of Supply Voltage
...2 V to 36 V
D
Low Supply-Current Drain Independent of
Supply Voltage . . . 0.4 mA Typ Per
Comparator
D
Low Input Bias Current . . . 25 nA Typ
D
Low Input Offset Current ...3 nA Typ
(LM193)
D
Low Input Offset Voltage ...2 mV Typ
D
Common-Mode Input Voltage Range
Includes Ground
D
Differential Input Voltage Range Equal to
Maximum-Rated Supply V oltage . . . ±36 V
D
Low Output Saturation Voltage
D
Output Compatible With TTL, MOS, and
CMOS
description
These devices consist of two independent voltage
comparators that are designed to operate from a
single power supply over a wide range of voltages.
Operation from dual supplies also is possible as
long as the difference between the two supplies is 2 V to 36 V , and V
CC
is at least 1.5 V more positive than the
input common-mode voltage. Current drain is independent of the supply voltage. The outputs can be connected
to other open-collector outputs to achieve wired-AND relationships.
The LM193 is characterized for operation from –55°C to 125°C. The LM293 and LM293A are characterized for
operation from –25°C to 85°C. The LM393 and LM393A are characterized for operation from 0°C to 70°C. The
LM2903 and LM2903Q are characterized for operation from –40°C to 125°C and are manufactured to
demanding automotive requirements.
logic diagram (each comparator)
IN+
IN–
OUT
Copyright 1999, Texas Instruments Incorporated
PRODUCTION DATA information is current as of publication date.
Products conform to specifications per the terms of Texas Instruments
standard warranty. Production processing does not necessarily include
testing of all parameters.
Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of
Texas Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.
1
2
3
4
8
7
6
5
1OUT
1IN–
1IN+
GND
V
CC
2OUT
2IN–
2IN+
D, JG, P, OR PW PACKAGE
(TOP VIEW)
3212019
910111213
4
5
6
7
8
18
17
16
15
14
NC
2OUT
NC
2IN–
NC
NC
1IN–
NC
1IN+
NC
FK PACKAGE
(TOP VIEW)
NC
1OUT
NC
2IN+
NC
V
NC
NC
GND
NC
CC
NC – No internal connection
LM193, LM293, LM293A, LM393
LM393A, LM393Y, LM2903, LM2903Q
DUAL DIFFERENTIAL COMPARATORS
SLCS005E – JUNE 1976 – REVISED NOVEMBER 1999
2
POST OFFICE BOX 655303 • DALLAS, TEXAS 75265
AVAILABLE OPTIONS
PACKAGED DEVICES
T
A
V
IO(max
)
AT 25°C
SMALL
OUTLINE
(D)
†
CHIP
CARRIER
(FK)
CERAMIC
DIP
(JG)
PLASTIC
DIP
(P)
TSSOP
(PW)
‡
CHIP
FORM
(Y)
§
°
°
5 mV LM393D — — LM393P LM393PW LM393Y
0°C to 70°C
2 mV LM393AD — — LM393AP — —
°
°
5 mV LM293D — — LM293P — —
–
25°C to 85°C
2 mV LM293AD — — LM293AP — —
°
°
LM2903D — — LM2903P LM2903PW —
–
40°C to 125°C
7 mV
LM2903QD — — LM2903QP — —
–55°C to 125°C 5 mV LM193D LM193FK LM193JG LM193P — —
†
The D package is available taped and reeled. Add the suffix R (e.g., LM393DR).
‡
The PW package is only available left-end taped and reeled (e.g., LM393PWR).
§
Chips are tested at 25°C (see LM393Y for electrical characteristics).
schematic (each comparator)
80-µA
Current Regulator
80 µA
60 µA
10 µA
V
CC
10 µA
OUT
GND
IN+
IN–
Epi-FET
Diodes
Resistors
Transistors
Current values shown are nominal.
COMPONENT COUNT
1
2
2
30
LM193, LM293, LM293A, LM393
LM393A, LM393Y, LM2903, LM2903Q
DUAL DIFFERENTIAL COMPARATORS
SLCS005E – JUNE 1976 – REVISED NOVEMBER 1999
3
POST OFFICE BOX 655303 • DALLAS, TEXAS 75265
absolute maximum ratings over operating free-air temperature range (unless otherwise noted)
†
Supply voltage, VCC (see Note 1) 36 V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Differential input voltage, VID (see Note 2) ±36 V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Input voltage range, VI (either input) –0.3 V to 36 V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Output voltage, V
O
36 V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Output current, IO 20 mA. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Duration of output short-circuit to ground (see Note 3) Unlimited. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Continuous total power dissipation See Dissipation Rating Table. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Package thermal impedance, θJA (see Note 4): D package 97°C/W. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
P package 85°C/W. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PW package 149°C/W. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Case temperature for 60 seconds: FK package 260°C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Lead temperature 1,6 mm (1/16 inch) from case for 10 seconds: D, P, or PW package 260°C. . . . . . . . . . . .
Lead temperature 1,6 mm (1/16 inch) from case for 60 seconds: JG package 300°C. . . . . . . . . . . . . . . . . . . .
Storage temperature range, T
stg
–65°C to 150°C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
†
Stresses beyond those listed under “absolute maximum ratings” may cause permanent damage to the device. These are stress ratings only, and
functional operation of the device at these or any other conditions beyond those indicated under “recommended operating conditions” is not
implied. Exposure to absolute-maximum-rated conditions for extended periods may affect device reliability.
NOTES: 1. All voltage values, except differential voltages, are with respect to the network ground.
2. Differential voltages are at IN+ with respect to IN–.
3. Short circuits from outputs to VCC can cause excessive heating and eventual destruction.
4. The package thermal impedance is calculated in accordance with JESD 51.
DISSIPATION RATING TABLE
PACKAGE
TA ≤ 25°C
POWER RATING
DERATING
FACTOR
DERATE
ABOVE T
A
TA = 70°C
POWER RATING
TA = 85°C
POWER RATING
TA = 125°C
POWER RATING
FK 900 mW 11.0 mW/°C 68°C 880 mW 715 mW 275 mW
JG 900 mW 8.4 mW/°C 43°C 672 mW 546 mW 210 mW
LM193, LM293, LM293A, LM393
LM393A, LM393Y, LM2903, LM2903Q
DUAL DIFFERENTIAL COMPARATORS
SLCS005E – JUNE 1976 – REVISED NOVEMBER 1999
4
POST OFFICE BOX 655303 • DALLAS, TEXAS 75265
electrical characteristics at specified free-air temperature, VCC = 5 V (unless otherwise noted)
PARAMETER TEST CONDITIONS
T
†
LM193
LM293
LM393
UNIT
A
MIN TYP MAX MIN TYP MAX
p
VCC = 5 V to 30 V,
25°C 2 5 2 5
VIOInput offset voltage
V
O
= 1.4 V,
VIC = V
IC(min)
Full range 9 9
mV
p
25°C 3 25 5 50
IIOInput offset current
V
O
= 1.4
V
Full range 100 250
nA
p
25°C –25 –100 –25 –250
IIBInput bias current
V
O
= 1.4
V
Full range –300 –400
nA
Common-mode
25°C
0 to
VCC–1.5
0 to
VCC–1.5
V
ICR
input voltage range
‡
Full range
0 to
VCC–2
0 to
VCC–2
V
A
VD
Large-signal
differential voltage
amplification
VCC = 15 V,
VO = 1.4 V to 11.4 V,
RL ≥ 15 kΩ to V
CC
25°C 50 200 50 200 V/mV
High-level
VOH = 5 V, VID = 1 V 25°C 0.1 0.1 50 nA
I
OH
g
output current
VOH = 30 V,
VID = 1 V Full range 1 1 µA
Low-level
25°C 150 400 150 400
V
OL
output voltage
I
OL
=
4 mA
,
V
ID
= –
1 V
Full range 700 700
mV
I
OL
Low-level
output current
VOL = 1.5 V, VID = 1 V 25°C 6 6 mA
pp
VCC = 5 V 25°C 0.8 1 0.8 1
ICCSupply current
R
L
= ∞
VCC = 30 V Full range 2.5 2.5
mA
†
Full range (MIN or MAX) for LM193 is –55°C to 125°C, for LM293 is 25°C to 85°C, and for LM393 is 0°C to 70°C. All characteristics are measured
with zero common-mode input voltage, unless otherwise specified.
‡
The voltage at either input or common-mode should not be allowed to go negative by more than 0.3 V . The upper end of the common-mode voltage
range is V
CC+
–1.5 V , but either or both inputs can go to 30 V without damage.
LM193, LM293, LM293A, LM393
LM393A, LM393Y, LM2903, LM2903Q
DUAL DIFFERENTIAL COMPARATORS
SLCS005E – JUNE 1976 – REVISED NOVEMBER 1999
5
POST OFFICE BOX 655303 • DALLAS, TEXAS 75265
electrical characteristics at specified free-air temperature, VCC = 5 V (unless otherwise noted)
PARAMETER TEST CONDITIONS
T
†
LM293A
LM393A
LM2903
LM2903Q
UNIT
A
MIN TYP MAX MIN TYP MAX
p
VCC = 5 V to 30 V,
25°C 1 3 2 7
VIOInput offset voltage
V
O
= 1.4 V,
VIC = V
IC(min)
Full range 4 15
mV
p
25°C 5 50 5 50
IIOInput offset current
V
O
= 1.4
V
Full range 150 200
nA
p
25°C –25 –250 –25 –250
IIBInput bias current
V
O
= 1.4
V
Full range –400 –500
nA
Common-mode
25°C
0 to
VCC–1.5
0 to
VCC–1.5
V
ICR
input voltage range
‡
Full range
0 to
VCC–2
0 to
VCC–2
V
A
VD
Large-signal
differential voltage
amplification
VCC = 15 V,
VO = 1.4 V to 11.4 V,
RL ≥ 15 kΩ to V
CC
25°C 50 200 25 100 V/mV
High-level
VOH = 5 V, VID = 1 V 25°C 0.1 50 0.1 50 nA
I
OH
g
output current
VOH = 30 V,
VID = 1 V Full range 1 1 µA
Low-level
25°C 150 400 150 400
V
OL
output voltage
I
OL
=
4 mA
,
V
ID
= –
1 V
Full range 700 700
mV
I
OL
Low-level
output current
VOL = 1.5 V, VID = 1 V 25°C 6 6 mA
pp
VCC = 5 V 25°C 0.8 1 0.8 1
ICCSupply current
R
L
= ∞
VCC = 30 V Full range 2.5 2.5
mA
†
Full range (MIN or MAX) for LM293A is 25°C to 85°C, for LM393A is 0°C to 70°C, and for LM2903 and LM2903Q is –40°C to 125°C. All
characteristics are measured with zero common-mode input voltage, unless otherwise specified.
‡
The voltage at either input or common-mode should not be allowed to go negative by more than 0.3 V . The upper end of the common-mode voltage
range is V
CC+
–1.5 V , but either or both inputs can go to 30 V without damage.
electrical characteristics at VCC = 5 V, TA = 25°C (unless otherwise noted)
LM393Y
PARAMETER
TEST CONDITIONS
MIN TYP§MAX
UNIT
V
IO
Input offset voltage
2 5 mV
I
IO
Input offset current
VCC = 5 V to 30 V,
VIC = V
ICR(min)
,
5 50 nA
I
IB
Input bias current
V
O
= 1.4
V
–25 –250 nA
V
ICR
Common-mode input voltage range VCC = 5 V to 30 V
0 to
VCC–1.5
V
A
VD
Large-signal differential voltage amplification
VCC = 15 V,
RL ≥ 15 kΩ to V
CC
VO = 1.4 V to 11.4 V,
25 200 V/mV
I
OH
High-level output current VOH = 5 V, VID = 1 V 0.1 50 nA
V
OL
Low-level output voltage IOL = 4 mA, VID = –1 V 150 400 mV
I
OL
Low-level output current VOL = 1.5 V, VID = –1 V 6 mA
I
CC
Supply current RL = ∞, VCC = 5 V 0.8 1 mA
§
All characteristics are measured under open-loop conditions with zero common-mode input voltage, unless otherwise specified.
LM193, LM293, LM293A, LM393
LM393A, LM393Y, LM2903, LM2903Q
DUAL DIFFERENTIAL COMPARATORS
SLCS005E – JUNE 1976 – REVISED NOVEMBER 1999
6
POST OFFICE BOX 655303 • DALLAS, TEXAS 75265
switching characteristics, VCC = 5 V, TA = 25°C
PARAMETER TEST CONDITIONS
LM193
LM293, LM293A
LM393, LM393A
LM2903, LM2903Q
UNIT
MIN TYP MAX
p
RL connected to 5 V through 5.1 kΩ,
100-mV input step with 5-mV overdrive 1.3
Response time
L
g
CL = 15 pF†, See Note 5
TTL-level input step 0.3
µ
s
†
CL includes probe and jig capacitance.
NOTE 5: The response time specified is the interval between the input step function and the instant when the output crosses 1.4 V.
IMPORTANT NOTICE
T exas Instruments and its subsidiaries (TI) reserve the right to make changes to their products or to discontinue
any product or service without notice, and advise customers to obtain the latest version of relevant information
to verify, before placing orders, that information being relied on is current and complete. All products are sold
subject to the terms and conditions of sale supplied at the time of order acknowledgement, including those
pertaining to warranty, patent infringement, and limitation of liability.
TI warrants performance of its semiconductor products to the specifications applicable at the time of sale in
accordance with TI’s standard warranty. Testing and other quality control techniques are utilized to the extent
TI deems necessary to support this warranty. Specific testing of all parameters of each device is not necessarily
performed, except those mandated by government requirements.
CERT AIN APPLICATIONS USING SEMICONDUCTOR PRODUCTS MAY INVOLVE POTENTIAL RISKS OF
DEATH, PERSONAL INJURY, OR SEVERE PROPERTY OR ENVIRONMENTAL DAMAGE (“CRITICAL
APPLICATIONS”). TI SEMICONDUCTOR PRODUCTS ARE NOT DESIGNED, AUTHORIZED, OR
WARRANTED TO BE SUITABLE FOR USE IN LIFE-SUPPORT DEVICES OR SYSTEMS OR OTHER
CRITICAL APPLICATIONS. INCLUSION OF TI PRODUCTS IN SUCH APPLICA TIONS IS UNDERSTOOD T O
BE FULLY AT THE CUSTOMER’S RISK.
In order to minimize risks associated with the customer’s applications, adequate design and operating
safeguards must be provided by the customer to minimize inherent or procedural hazards.
TI assumes no liability for applications assistance or customer product design. TI does not warrant or represent
that any license, either express or implied, is granted under any patent right, copyright, mask work right, or other
intellectual property right of TI covering or relating to any combination, machine, or process in which such
semiconductor products or services might be or are used. TI’s publication of information regarding any third
party’s products or services does not constitute TI’s approval, warranty or endorsement thereof.
Copyright 1999, Texas Instruments Incorporated
Loading...
