INA117

High Common-Mode Voltage

DIFFERENCE AMPLIFIER

INA117

FEATURES

● COMMON-MODE INPUT RANGE:

±200V (V

= ±15V)

S

● PROTECTED INPUTS:

±500V Common-Mode
±500V Differential

● UNITY GAIN: 0.02% Gain Error max

● NONLINEARITY: 0.001% max

● CMRR: 86dB min

DESCRIPTION

The INA117 is a precision unity-gain difference
amplifier with very high common-mode input voltage
range. It is a single monolithic IC consisting of a
precision op amp and integrated thin-film resistor
network. It can accurately measure small differential
voltages in the presence of common-mode signals up
to ±200V. The INA117 inputs are protected from
momentary common-mode or differential overloads
up to ±500V.

In many applications, where galvanic isolation is not
essential, the INA117 can replace isolation amplifiers.
This can eliminate costly isolated input-side power
supplies and their associated ripple, noise and quies­cent current. The INA117’s 0.001% nonlinearity and
200kHz bandwidth are superior to those of conven­tional isolation amplifiers.

The INA117 is available in 8-pin plastic mini-DIP and
SO-8 surface-mount packages, specified for the –40°C
to +85°C temperature range. The metal TO-99 models
are available specified for the –40°C to +85°C and
–55°C to +125°C temperature range.

APPLICATIONS

● CURRENT MONITOR

● BATTERY CELL-VOLTAGE MONITOR

● GROUND BREAKER

● INPUT PROTECTION

● SIGNAL ACQUISITION IN NOISY

ENVIRONMENTS

● FACTORY AUTOMATION

Ref

–In

+In

V–

21.11kΩ

1

B

380kΩ

2

380kΩ

3

4

380kΩ

20kΩ

Comp

8

V+

7

V

6

O

Ref

5

A

Copyright © 2000, Texas Instruments Incorporated SBOS154A Printed in U.S.A. December, 2000

SPECIFICATIONS

At TA = +25°C, VS = ±15V, unless otherwise noted.

INA117AM, SM INA117BM INA117P, KU
PARAMETER CONDITIONS MIN TYP MAX MIN TYP MAX MIN TYP MAX UNITS
GAIN

(1)

Initial
Error 0.01 0.05 ✻ 0.02 ✻✻ %

vs Temperature 2 10 ✻✻ppm/°C

Nonlinearity

(2)

OUTPUT

Rated Voltage I
Rated Current V
Impedance 0.01 ✻✻Ω

= +20mA, –5mA 10 12 ✻✻ ✻✻ V

O

= 10V +20, –5 ✻✻mA

O

Current Limit To Common +49, –13 ✻✻mA
Capacitive Load Stable Operation 1000 ✻✻pF

INPUT

Impedance Differential 800 ✻✻kΩ

Common-Mode 400 ✻✻kΩ

Voltage Range Differential ±10 ✻✻V

Common-Mode, Continuous

Common-Mode Rejection

(3)

±200 ✻✻ V

DC 70 80 86 94 ✻✻ dB
AC, 60Hz V

vs Temperature, DC T

AM, BM, P, KU 66 75 80 90 ✻ dB

= 400Vp-p 66 80 66 94 ✻✻ dB

CM

= T

to T

A

MIN

MAX

SM 60 75 dB

OFFSET VOLTAGE RTO

(4)

Initial 120 1000 ✻ 1000 ✻✻µV

KU Grade (SO-8 Package) 600 2000 µV
vs Temperature T
vs Supply V
vs Time 200 ✻✻µV/mo

OUTPUT NOISE VOLTAGE RTO

= T

to T

A

MIN

= ±5V to ±18V 74 90 80 ✻✻✻✻ dB

S

MAX

(5)

fB = 0.01Hz to 10Hz 25 ✻✻µVp-p
f

= 10kHz 550 ✻✻nV/√Hz

B

DYNAMIC RESPONSE

Gain Bandwidth, –3dB 200 ✻✻kHz
Full Power Bandwidth V
Slew Rate 2 2.6 ✻✻ ✻✻ V/µs
Settling Time: 0.1% V

0.01% V

0.01% V

= 20Vp-p 30 ✻✻kHz

O

= 10V Step 6.5 ✻✻µs

O

= 10V Step 10 ✻✻µs

O

= 10V Step, V

CM

= 0V 4.5 ✻✻µs

DIFF

POWER SUPPLY

Rated ±15 ✻✻V
Voltage Range Derated Performance ±5 ±18 ✻✻✻✻V
Quiescent Current V

= 0V 1.5 2 ✻✻ ✻✻mA

O

TEMPERATURE RANGE

Specification: AM, BM, P, KU –25 +85 ✻✻–40 +85 °C

SM –55 +125 °C
Operation –55 +125 ✻✻–40 +85 °C
Storage –65 +150 ✻✻–55 +125 °C

✻Specification same as for INA117AM.
NOTES: (1) Connected as difference amplifier (see Figure 1). (2) Nonlinearity is the maximum peak deviation from the best-fit straight line as a percent of full-scale
peak-to-peak output. (3) With zero source impedance (see discussion of common-mode rejection in Application Information section). (4) Includes effects of amplifier’s
input bias and offset currents. (5) Includes effects of amplifier’s input current noise and thermal noise contribution of resistor network.

1 ✻✻V/V

0.0002 0.001 ✻✻ ✻✻ %

8.5 40 ✻ 40 ✻ µV/°C

2

INA117

SBOS154A

PIN CONFIGURATION

Top View TO-99

Tab

Comp

8

Ref B

1

INA117AM, BM, SM

V+

7

Top View DIP/SO

1

Ref

B

8

INA117P, KU

Comp

–In

3

+In

4

V–

Case internally connected to V–. Make no connection.

62

Output

5

Ref A

ABSOLUTE MAXIMUM RATINGS

Supply Voltage .................................................................................. ±22V

Input Voltage Range, Continuous ................................................... ±200V

Common-Mode and Differential, 10s ........................................... ±500V

Operating Temperature

M Metal TO-99 ................................................................ –55 to +125°C

P Plastic DIP and U SO-8 ................................................ –40 to +85°C

Storage Temperature

M Package .......................................................................–65 to +150°C

P Plastic DIP and U SO-8 .............................................. –55 to +125°C

Lead Temperature (soldering, 10s) ............................................... +300°C

Output Short Circuit to Common ............................................. Continuous

–In

+In

V–

2

3

4

7

V+

6

Output

5

Ref

A

ELECTROSTATIC
DISCHARGE SENSITIVITY

This integrated circuit can be damaged by ESD. Texas Instru­ments recommends that all integrated circuits be handled with
appropriate precautions. Failure to observe proper handling
and installation procedures can cause damage.

ESD damage can range from subtle performance degrada­tion to complete device failure. Precision integrated circuits
may be more susceptible to damage because very small
parametric changes could cause the device not to meet its
published specifications.

PACKAGE/ORDERING INFORMATION

PACKAGE SPECIFIED

PRODUCT PACKAGE NUMBER RANGE MARKING NUMBER

DRAWING TEMPERATURE PACKAGE ORDERING TRANSPORT

INA117P DIP-8 006 –40°C to +85°C INA117P INA117P Rails
INA117KU SO-8 Surface-Mount 182 " INA117KU INA117KU Rails

" " " " " INA117KU/2K5 Tape and Reel
INA117AM TO-99 Metal 001 –25°C to +85°C INA117AM INA117AM Rails
INA117BM " " " INA117BM INA117BM Rails
INA117SM " " –55°C to +125°C INA117SM INA117SM Rails

NOTE: (1) Models with a slash (/ ) are available only in Tape and Reel in the quantities indicated (e.g., /2K5 indicates 2500 devices per reel). Ordering 2500
pieces of “INA117KU/2K5” will get a single 2500-piece Tape and Reel.

(1)

MEDIA

INA117

SBOS154A

3

TYPICAL PERFORMANCE CURVES

At TA = +25°C, VS = ±15V, unless otherwise noted.

100

Common-Mode Rejection (dB)

400

350

300

250

200

COMMON-MODE REJECTION vs FREQUENCY

INA117BM

90

80

INA117AM, SM, P, KU

70

60

50

40

20 100 1k 10k 100k 2M

Frequency (Hz)

POSITIVE COMMON-MODE VOLTAGE RANGE

vs POSITIVE POWER-SUPPLY VOLTAGE

TA = –55°C

TA = +25°C

Max Rating = 200V

TA = +125°C

100

Power-Supply Rejection (dB)

–400

–350

–300

–250

–200

POWER-SUPPLY REJECTION vs FREQUENCY

90

80

70

60

50

40

1 10 100 1k 10k

V+

NEGATIVE COMMON-MODE VOLTAGE RANGE

vs NEGATIVE POWER-SUPPLY VOLTAGE

Max Rating = –200V

V–

Frequency (Hz)

TA = +25°C

TA = –55°C to +125°C

150

100

Positive Common-Mode Range (V)

50

5101520

Positive Power-Supply Voltage (V)

–VS = –5V to –20V

–150

–100

Negative Common-Mode Range (V)

–50

–5 –10 –15 –20

Negative Power-Supply Voltage (V)

+VS = +5V to +20V

4

INA117

SBOS154A

TYPICAL PERFORMANCE CURVES (Cont.)

At TA = +25°C, VS = ±15V, unless otherwise noted.

SMALL SIGNAL STEP RESPONSE

C

= 0

L

SMALL SIGNAL STEP RESPONSE

CL = 1000pF

LARGE SIGNAL STEP RESPONSE

INA117

SBOS154A

5

APPLICATION INFORMATION

Figure 1 shows the basic connections required for operation.
Applications with noisy or high-impedance power-supply lines

may require decoupling capacitors close to the device pins.
The output voltage is equal to the differential input volt-

age between pins 2 and 3. The common mode input
voltage is rejected.

Internal circuitry connected to the compensation pin 8 can­cels the parasitic distributed capacitance between the feed­back resistor, R2, and the IC substrate. For specified dy­namic performance, pin 8 should be grounded or connected
through a 0.1µF capacitor to an AC ground such as V+.

–15V +15V

1µF

Tantalum

–In = V

+In = V

+

47

R

1

380kΩ 380kΩ

2

2

R

3

380kΩ

3

3

R

5

21.1kΩ

815

R

20kΩ

R

2

4

+

Tantalum

6

VO = V3 – V

1µF

2

FIGURE 1. Basic Power and Signal Connections.

V– V+

380kΩ 380kΩ

2

V

2

380kΩ

3

V

3

21.1kΩ 20kΩ

(a)

V– V+

47

380kΩ 380kΩ

2

V

2

380kΩ

3

V

3

21.1kΩ 20kΩ

815

47

6

815

100kΩ

10Ω

6

V = V – V

O 3 2

V+

VO = V3 – V

+15V

–15V

1/2 REF200

2

50kΩ
±1.5mV
Range

100µA

COMMON-MODE REJECTION

Common-mode rejection (CMR) of the INA117 is depend­ent on the input resistor network, which is laser-trimmed for
accurate ratio matching. To maintain high CMR, it is impor­tant to have low source impedances driving the two inputs.
A 75Ω resistance in series with pin 2 or 3 will decrease CMR
from 86dB to 72dB.

Resistance in series with the reference pins will also degrade
CMR. A 4Ω resistance in series with pin 1 or 5 will decrease
CMRR from 86dB to 72dB.

Most applications do not require trimming. Figures 2 and 3
show optional circuits that may be used for trimming offset
voltage and common-mode rejection.

TRANSFER FUNCTION

Most applications use the INA117 as a simple unity-gain
difference amplifier. The transfer function is:

VO = V3 – V

2

V3 and V2 are the voltages at pins 3 and 2.

100Ω

100Ω

100µA

1/2 REF200

V–

(b)

Offset adjustment is regulated—

insensitive to power supply variations.

OPA27

±10mV

10kΩ

FIGURE 2. Offset Voltage Trim Circuits.

Some applications, however, apply voltages to the reference
terminals (pins 1 and 5). A more complete transfer function
is:

VO = V3 – V2 + 19 • V5 – 18 • V

1

V5 and V1 are the voltages at pins 5 and 1.

6

INA117

SBOS154A

MEASURING CURRENT

The INA117 can be used to measure a current by sensing the
voltage drop across a series resistor, R

. Figure 4 shows the

S

INA117 used to measure the supply currents of a device
under test. The circuit in Figure 5 measures the output
current of a power supply. If the power supply has a sense
connection, it can be connected to the output side of RS to
eliminate the voltage-drop error. Another common applica­tion is current-to-voltage conversion, as shown in Figure 6.

V– V+

47

380kΩ

2

V

2

380kΩ

(+200V max)

+V

S

R

S

I

DUT+

Device

Under

Test

V– V+

47

20kΩ

380kΩ

V+

6

VO = RS I

DUT+

380kΩ

2

C

RC*

380kΩ

3

21.1kΩ

815

V–

380kΩ

3

V

3

21.1kΩ 20kΩ

815

200Ω

10Ω

If offset adjust is also required,
connect to offset circuit, Figure 2.

FIGURE 3. CMR Trim Circuit.

Power Supply

Sense Connection

CMR

Adjust

10Ω

Out

Sense

Optional Load

(see text)

6

VO = V3 – V

±200V max

R

S

Load

47

I

2

DUT–

R

S

–V

S

(–200V max)

2

RC*

380kΩ

3

21.1kΩ

815

*Not needed if R is less than 20 —see text.Ω

S

20kΩ

380kΩ380kΩ

6

VO = RS I

DUT–

FIGURE 4. Measuring Supply Currents of Device Under

Test.

V– V+

47

380kΩ 380kΩ

2

RC*

I

L

380kΩ

3

815

20kΩ21.1kΩ

6

VO = IL R

S

*R

= RS not needed if RS is less than 20Ω—see text.

C

FIGURE 5. Measuring Power Supply Output Current.

INA117

SBOS154A

7

V

S

(±200V max)

R

250Ω

4 to 20mA

(a)

4 to 20mA

R

250Ω

2

S

380kΩ

3

380kΩ380kΩ

6

V

= 1V to 5V

O

250Ω

R

*

C

21.1kΩ 20kΩ

815

V

S

(±200V max)

*Not needed if R

is less than 20Ω—see text.

S

R

250Ω

4 to 20mA

380kΩ 380kΩ

2

250Ω

RC*

S

380kΩ

3

6

V

= –1V to –5V

O

21.1kΩ 20kΩ

815

(b)

380kΩ

2

380kΩ

*Not needed if R

is less than 20Ω—see text.

S

250Ω

S

RC*

380kΩ

3

6

V

= 1V to 5V

O

21.1kΩ

V

S

815

(±200V max)

(c)

*Not needed if RS is less than 20Ω—see text.

FIGURE 6. Current to Voltage Converter.

8

20kΩ

4 to 20mA

R

250Ω

(±200V max)

S

V

S

380kΩ

2

380kΩ

3

250Ω

RC*

21.1kΩ 20kΩ

*Not needed if R

815

is less than 20Ω—see text.

S

380kΩ

6

= –1V to –5V

V

O

(d)

INA117

SBOS154A

In all cases, the sense resistor imbalances the input resistor

380kΩ 380kΩ

380kΩ

21.1kΩ 20kΩ

47

2

3

815

V

O

= I • RS • (1 + )

6

I

–15V +15V

R

2

R

1

R2*

1/2

OPA1013

V

1

R *

1

R

S

–V

X

380kΩ 380kΩ

380kΩ

21.1kΩ 20kΩ

47

2

3

815

V

O

= I • R

S

6

I

V– V+

1/2

OPA1013

R

S

0.1µF

IN4702

MPS-A42

180k

Ω

0.01µF

V

Z

or

–V

X

–V

X

Op amp power can be derived with voltage­dropping zener diode if –V

X

power is relatively
constant.
|V

X

| = (5V to 36V) + V

Z

e.g., If VZ is 50V then VX = –55V to –86V.

Regulated power for op amp allows –V

X

power to vary over wide range.

V

X

= –30V to –200V

*Or connect as buffer (R2 = 0, omit R1).

matching of the INA117, degrading its CMR. Also, the input
impedance of the INA117 loads RS, causing gain error in the
voltage-to-current conversion. Both of these errors can be
easily corrected.

The CMR error can be corrected with the addition of a
compensation resistor, RC, equal in value to RS as shown in
Figures 4, 5, and 6. If RS is less than 20Ω, the degradation
in CMR is negligible and RC can be omitted. If RS is larger
than approximately 2kΩ, trimming RC may be required to
achieve greater than 86dB CMR. This is because the actual
INA117 input impedances have 1% typical mismatch.

If RS is more than approximately 100Ω, the gain error will
be greater than the 0.02% specification of the INA117. This
gain error can be corrected by slightly increasing the value
of RS. The corrected value, RS', can be calculated by:

Rk

•Ω

380

R

S

'–=

S

kR

Ω

380

S

Example: For a 1V/mA transfer function, the nominal,
uncorrected value for RS would be 1kΩ. A slightly larger
value, RS' = 1002.6Ω, compensates for the gain error due to
loading.

The 380kΩ term in the equation for RS' has a tolerance of
±25%, so sense resistors above approximately 400Ω may
require trimming to achieve gain accuracy better than 0.02%.

Of course, if a buffer amplifier is added as shown in Figure
7, both inputs see a low source impedance, and the sense
resistor is not loaded. As a result, there is no gain error or
CMR degradation. The buffer amplifier can operate as a
unity gain buffer or as an amplifier with non-inverting gain.
Gain added ahead of the INA117 improves both CMR and
signal-to-noise. Added gain also allows a lower voltage drop
across the sense resistor. The OPA1013 is a good choice for
the buffer amplifier since both its input and output can swing
close to its negative power supply.

V

X

–21V to +10V +15V

–5V to –36V Ground

–20V to –51V –15V

V

1

FIGURE 7. Current Sensing with Input Buffer.

INA117

SBOS154A

9

Figure 8 shows very high input impedance buffer used to
measure low leakage currents. Here, the buffer op amp is
powered with an isolated, split-voltage power supply. Using
an isolated power supply allows full ±200V common-mode
input range.

NOISE PERFORMANCE

The noise performance of the INA117 is dominated by the
internal resistor network. The thermal or Johnson noise of

±200V max

these resistors produces approximately 550nV/√Hz noise.
The internal op amp contributes virtually no excess noise at
frequencies above 100Hz.

Many applications may be satisfied with less than the full
200kHz bandwidth of the INA117. In these cases, the noise
can be reduced with a low-pass filter on the output. The two­pole filter shown in Figure 9 limits bandwidth to 1kHz and
reduces noise by more than 15:1. Since the INA117 has a
1/f noise corner frequency of approximately 100Hz, a cutoff
frequency below 100Hz will not further reduce noise.

100MΩ

1kΩ

D

*

1,2

I

100kΩ

L

Device

Under

Test

*D

and D2 are each a 2N3904 transistor

1

base-collector junction (emitter open).

9kΩ

OPA111

FIGURE 8. Leakage Current Measurement Circuit.

V–

V+

Isolated DC/DC Converter

+15V

PWS725

Com

–15V

380kΩ 380kΩ

2

380kΩ

3

21.1kΩ

815

20kΩ

+15V

INA117

6

e

= IL x 10

O

(1V/nA)

9

47

380kΩ 380kΩ

2

V

2

380kΩ

3

V

3

20kΩ21.1kΩ

815

See Application Bulletin AB-017 for other filters.

FIGURE 9. Output Filter for Noise Reduction.

10

C

2

0.02µF

R

1

11.0kΩ

6

BUTTERWORTH
LOW-PASS OUTPUT NOISE
f

–3dB

200kHz 1.8 No Filter
100kHz 1.1 11kΩ 11.3kΩ 100pF 200pF
10kHz 0.35 11kΩ 11.3kΩ 1nF 2nF
1kHz 0.11 11kΩ 11.3kΩ 10nF 20nF
≤100Hz

NOTE: (1) Since the INA117 has a 1/f noise corner frequency of approximately 100Hz,
bandwidth reduction below this frequency will not significantly reduce noise.

R

11.3kΩ

0.01µF

(1)

2

C

1

OPA27

2-Pole Butterworth

(mVp-p) R

0.05 11kΩ 11.3kΩ 0.1µF 0.2µF

V

= V2 – V

O

Low-Pass Filter

1

3

R

2

C

1

C

2

INA117

SBOS154A

380kΩ

2

V

2

380kΩ

V– V+

47

VO =

1 +

V3 – V

19 R

2

7

R

6

V

2

V

3

380kΩ 380kΩ

2

380kΩ

3

6

VO = V3 – V2 + V

X

380kΩ

3

V

3

21.1kΩ

20kΩ

6

INA117

815

R

7

R

6

Refer to Application

OPA27

GAIN R
(V/V) (kΩ)(kΩ)

7

Bulletin AB-001 for
details.

1/2 1.05 20
1/4 3.16 20
1/5 4.22 20

FIGURE 10. Reducing Differential Gain.

Refer to Application Bulletin AB-010 for details.

R

1

380kΩ

2

V

2

R

3

380kΩ

3

V

3

R

5

21.1kΩ

815

(b)

R

20kΩ

OPA27

4

380kΩ

R

5kΩ

A

1

R

2

INA117

100pF

R

6

10kΩ

7

21.1kΩ 20kΩ

INA117

815

R

6

OPA27

V

X

FIGURE 11. Summing VX in Output.

6

V

OUT

(a)

= V3 – V

–V3/20

2

6

R

9

400kΩ

R

8

10kΩ

R

10kΩ

A

2

OPA27

10

V

OUT

100pF

2

V

2

3

V

3

= V3 – V

VCM /20

R

1

380kΩ

R

3

380kΩ

R

5

21.1kΩ

R

20kΩ

815

2

OPA27

4

A

R

2

380kΩ

R

6

5kΩ

1

INA117

100pF

R

7

10kΩ

FIGURE 12. Common-Mode Voltage Monitoring.

INA117

SBOS154A

11

7

+9V

Range =

V

CM

+50V to +200V

(V

±9V)

S

(a)

Range =

V

CM

–12V to +200V

(V

= ±9V)

S

(b)

2

V

2

380kΩ

3

V

3

21.1kΩ 20kΩ

815

380kΩ380kΩ

7

6

INA117

4

25kΩ 25kΩ

2

25kΩ

3

25kΩ

INA105

5

6

–3V > V

1

= V3 – V

V

O

2 and 3 for +4V > V

2

> –6V swap A2 pins

O

> 3V.

O

4

–9V

5

6

0V > V

1

+9V

V = V – V

O 3 2

> –6V swap A2 pins

O

2 and 3 for +4V > V

> 0V.

O

7

380kΩ 380kΩ

2

V

2

25kΩ 25kΩ

2

25kΩ

3

25kΩ

INA117

6

10kΩ

380kΩ

3

V

3

21.1kΩ

815

20kΩ

4

7

INA105

Range = ±200V

V

CM

(V

= ±9V)

S

(c)

(V–) +3.3V

1N4684

3.3V

4

–9V

380kΩ 380kΩ

V

2

V

3

2

380kΩ

3

21.1kΩ

20kΩ

6

25kΩ 25kΩ

2

5

6

V

= V3 – V

O

2

INA117

815

R

7

1MΩ

R

1MΩ

8

OPA602

13.7kΩ

(V = ±9V)

S

25kΩ

3

Refer to Application Bulletin AB-015 for details.

25kΩ

INA105

1

FIGURE 13. Offsetting or Boosting Common-Mode Voltage Range for Reduced Power-Supply Voltage Operation.

12

INA117

SBOS154A

+200V max

+

V– V+

47

380kΩ

2

380kΩ

Repeat

for each

cell

–

+

–

+

380kΩ

3

21.1kΩ 20kΩ

815

V– V+

47

380kΩ

2

380kΩ

3

21.1kΩ 20kΩ

815

V– V+

47

380kΩ 380kΩ

2

INA117

380kΩ

INA117

6

6

eO = Cell Voltage

MUX

–

+

–

–200V max

380kΩ

3

21.1kΩ 20kΩ

815

V– V+

47

380kΩ 380kΩ

2

380kΩ

3

21.1kΩ 20kΩ

815

FIGURE 14. Battery Cell Voltage Monitor.

6

INA117

Cell Select

6

INA117

INA117

SBOS154A

13

(200V max)

V

S

–15V

+15V

74

R

0.1Ω

380kΩ

2

1

380kΩ

3

I

1

21.1kΩ

20kΩ

380kΩ

6

–0.1 (I1)

INA117

815

A

I

R

0.1Ω

1

I

= I1 – I

LOAD

2

2

380kΩ

2

380kΩ

3

V

IN

Load

2

–15V+15V

74

380kΩ

6

–0.1 (I

2

3

)

2

–15V+15V

74

10kΩ

10kΩ

100kΩ

5

6

VO = I1 – I

V

O

2

= I

LOAD

100kΩ

21.1kΩ 20kΩ

INA117

INA106

1

815

VS (–200V max)

FIGURE 15. Measuring Amplifier Load Current.

R

380kΩ

2

V

2

R

380kΩ

3

V

3

R

21.1kΩ

815

1

3

5

380kΩ

R

4

20kΩ

C

0.47µF

OPA602

R

2

6

V

= V3 – V

OUT

2

INA117

R

1

1

1MΩ

Refer to Application
Bulletin AB-008 for
details.

FIGURE 16. AC-Coupled INA117.

14

INA117

SBOS154A

PACKAGE OPTION ADDENDUM

www.ti.com 16-Apr-2009

PACKAGING INFORMATION

Orderable Device Status

(1)

Package

Type

Package
Drawing

Pins Package

Qty

Eco Plan

INA117AM NRND TO-99 LMC 8 20 Green (RoHS &

(2)

Lead/Ball Finish MSL Peak Temp

AU N / A for Pkg Type

(3)

no Sb/Br)

INA117AM4 OBSOLETE TO-100 LME 10 TBD Call TI CallTI

INA117BM NRND TO-99 LMC 8 20 Green (RoHS &

AU N / A for Pkg Type

no Sb/Br)

INA117BM-22 OBSOLETE TO-100 LME 10 TBD Call TI CallTI

INA117BM-3 OBSOLETE ZZ (BB) ZZ001 8 TBD Call TI Call TI

INA117BM-33 OBSOLETE TO-100 LME 10 TBD Call TI Call TI

INA117BM1 OBSOLETE TO-100 LME 10 TBD Call TI Call TI

INA117KU ACTIVE SOIC D 8 75 Green (RoHS &

CU NIPDAU Level-3-260C-168 HR

no Sb/Br)

INA117KU/2K5 ACTIVE SOIC D 8 2500 Green (RoHS &

CU NIPDAU Level-3-260C-168 HR

no Sb/Br)

INA117KU/2K5G4 ACTIVE SOIC D 8 2500 Green (RoHS &

CU NIPDAU Level-3-260C-168 HR

no Sb/Br)

INA117KUG4 ACTIVE SOIC D 8 75 Green (RoHS &

CU NIPDAU Level-3-260C-168 HR

no Sb/Br)

INA117P ACTIVE PDIP P 8 50 Green (RoHS &

CU NIPDAU N / A for Pkg Type

no Sb/Br)
INA117P-BI OBSOLETE PDIP P 8 TBD Call TI Call TI
INA117PG4 ACTIVE PDIP P 8 50 Green (RoHS &

CU NIPDAU N / A for Pkg Type

no Sb/Br)

INA117SM NRND TO-99 LMC 8 20 Green (RoHS &

AU N / A for Pkg Type

no Sb/Br)

INA117SMQ NRND TO-99 LMC 8 20 Green(RoHS &

AU N / A for Pkg Type

no Sb/Br)

(1)

The marketing status values are defined as follows:

ACTIVE: Product device recommended for new designs.
LIFEBUY: TI has announced that the device will be discontinued, and a lifetime-buy period is in effect.
NRND: Not recommended for new designs. Device is in production to support existing customers, but TI does not recommend using this part in

a new design.

PREVIEW: Device has been announced but is not in production. Samples may or may not be available.
OBSOLETE: TI has discontinued the production of the device.

(2)

Eco Plan - The planned eco-friendly classification: Pb-Free (RoHS), Pb-Free (RoHS Exempt), or Green (RoHS & no Sb/Br) - please check

http://www.ti.com/productcontent for the latest availability information and additional product content details.

TBD: The Pb-Free/Green conversion plan has not been defined.
Pb-Free (RoHS): TI's terms "Lead-Free" or "Pb-Free" mean semiconductor products that are compatible with the current RoHS requirements

for all 6 substances, including the requirement that lead not exceed 0.1% by weight in homogeneous materials. Where designed to be soldered
at high temperatures, TI Pb-Free products are suitable for use in specified lead-free processes.
Pb-Free (RoHS Exempt): This component has a RoHS exemption for either 1) lead-based flip-chip solder bumps used between the die and
package, or 2) lead-based die adhesive used between the die and leadframe. The component is otherwise considered Pb-Free (RoHS
compatible) as defined above.
Green (RoHS & no Sb/Br): TI defines "Green" to mean Pb-Free (RoHS compatible), and free of Bromine (Br) and Antimony (Sb) based flame
retardants (Br or Sb do not exceed 0.1% by weight in homogeneous material)

(3)

MSL, Peak Temp. -- The Moisture Sensitivity Level rating according to the JEDEC industry standard classifications, and peak solder

temperature.

Important Information and Disclaimer:The information provided on this page represents TI's knowledge and belief as of the date that it is
provided. TI bases its knowledge and belief on information provided by third parties, and makes no representation or warranty as to the

Addendum-Page 1

PACKAGE OPTION ADDENDUM

www.ti.com 16-Apr-2009

accuracy of such information. Efforts are underway to better integrate information from third parties. TI has taken and continues to take
reasonable steps to provide representative and accurate information but may not have conducted destructive testing or chemical analysis on
incoming materials and chemicals. TI and TI suppliers consider certain information to be proprietary, and thus CAS numbers and other limited
information may not be available for release.

In no event shall TI's liability arising out of such information exceed the total purchase price of the TI part(s) at issue in this document sold by TI
to Customer on an annual basis.

Addendum-Page 2

PACKAGE MATERIALS INFORMATION

www.ti.com

TAPE AND REEL INFORMATION

24-Jan-2009

*All dimensions are nominal

Device Package

Type

INA117KU/2K5 SOIC D 8 2500 330.0 12.4 6.4 5.2 2.1 8.0 12.0 Q1

Package
Drawing

Pins SPQ Reel

Diameter

(mm)

Reel

Width

W1 (mm)

A0 (mm) B0 (mm) K0 (mm) P1

(mm)W(mm)

Pin1

Quadrant

Pack Materials-Page 1

PACKAGE MATERIALS INFORMATION

www.ti.com

24-Jan-2009

*All dimensions are nominal

Device Package Type Package Drawing Pins SPQ Length (mm) Width (mm) Height (mm)

INA117KU/2K5 SOIC D 8 2500 346.0 346.0 29.0

Pack Materials-Page 2

IMPORTANT NOTICE

Texas Instruments Incorporated and its subsidiaries (TI) reserve the right to make corrections, modifications, enhancements, improvements,
and other changes to its products and services at any time and to discontinue any product or service without notice. Customers should
obtain the latest relevant information before placing orders and should verify that such information is current and complete. All products are
sold subject to TI’s terms and conditions of sale supplied at the time of order acknowledgment.

TI warrants performance of its hardware products to the specifications applicable at the time of sale in accordance with TI’s standard
warranty. Testing and other quality control techniques are used to the extent TI deems necessary to support this warranty. Except where
mandated by government requirements, testing of all parameters of each product is not necessarily performed.

TI assumes no liability for applications assistance or customer product design. Customers are responsible for their products and
applications using TI components. To minimize the risks associated with customer products and applications, customers should provide
adequate design and operating safeguards.

TI does not warrant or represent that any license, either express or implied, is granted under any TI patent right, copyright, mask work right,
or other TI intellectual property right relating to any combination, machine, or process in which TI products or services are used. Information
published by TI regarding third-party products or services does not constitute a license from TI to use such products or services or a
warranty or endorsement thereof. Use of such information may require a license from a third party under the patents or other intellectual
property of the third party, or a license from TI under the patents or other intellectual property of TI.

Reproduction of TI information in TI data books or data sheets is permissible only if reproduction is without alteration and is accompanied
by all associated warranties, conditions, limitations, and notices. Reproduction of this information with alteration is an unfair and deceptive
business practice. TI is not responsible or liable for such altered documentation. Information of third parties may be subject to additional
restrictions.

Resale of TI products or services with statements different from or beyond the parameters stated by TI for that product or service voids all
express and any implied warranties for the associated TI product or service and is an unfair and deceptive business practice. TI is not
responsible or liable for any such statements.

TI products are not authorized for use in safety-critical applications (such as life support) where a failure of the TI product would reasonably
be expected to cause severe personal injury or death, unless officers of the parties have executed an agreement specifically governing
such use. Buyers represent that they have all necessary expertise in the safety and regulatory ramifications of their applications, and
acknowledge and agree that they are solely responsible for all legal, regulatory and safety-related requirements concerning their products
and any use of TI products in such safety-critical applications, notwithstanding any applications-related information or support that may be
provided by TI. Further, Buyers must fully indemnify TI and its representatives against any damages arising out of the use of TI products in
such safety-critical applications.

TI products are neither designed nor intended for use in military/aerospace applications or environments unless the TI products are
specifically designated by TI as military-grade or "enhanced plastic." Only products designated by TI as military-grade meet military
specifications. Buyers acknowledge and agree that any such use of TI products which TI has not designated as military-grade is solely at
the Buyer's risk, and that they are solely responsible for compliance with all legal and regulatory requirements in connection with such use.

TI products are neither designed nor intended for use in automotive applications or environments unless the specific TI products are
designated by TI as compliant with ISO/TS 16949 requirements. Buyers acknowledge and agree that, if they use any non-designated
products in automotive applications, TI will not be responsible for any failure to meet such requirements.

Following are URLs where you can obtain information on other Texas Instruments products and application solutions:

Products Applications

Amplifiers amplifier.ti.com Audio www.ti.com/audio
Data Converters dataconverter.ti.com Automotive www.ti.com/automotive
DLP® Products www.dlp.com Broadband www.ti.com/broadband
DSP dsp.ti.com Digital Control www.ti.com/digitalcontrol
Clocks and Timers www.ti.com/clocks Medical www.ti.com/medical
Interface interface.ti.com Military www.ti.com/military
Logic logic.ti.com Optical Networking www.ti.com/opticalnetwork
Power Mgmt power.ti.com Security www.ti.com/security
Microcontrollers microcontroller.ti.com Telephony www.ti.com/telephony
RFID www.ti-rfid.com Video & Imaging www.ti.com/video
RF/IF and ZigBee® Solutions www.ti.com/lprf Wireless www.ti.com/wireless

Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265

Copyright © 2009, Texas Instruments Incorporated
