1 Introduction
The LM34919EVAL evaluation board provides the design engineer with a fully functional buck regulator,
employing the constant on-time (COT) operating principle. This evaluation board provides a 5V output
over an input range of 8V to 40V. The circuit delivers load currents to 600 mA, with current limit set at a
nominal 700 mA. The board is populated with all components except R5, C9 and C10. These components
provide options for managing the output ripple as described later in this document.
The board’s specification are:
• Input Voltage: 8V to 40V
• Output Voltage: 5V
• Maximum load current: 600 mA
• Minimum load current: 0A
• Current Limit: 640 mA to 730 mA
• Measured Efficiency: 92.7% (VIN= 8V, I
• Nominal Switching Frequency: 800 kHz
• Size: 2.6 in. x 1.6 in. x 0.5 in
User's Guide
SNVA250A–June 2007–Revised April 2013
AN-1650 LM34919 Evaluation Board
= 300 mA)
OUT
All trademarks are the property of their respective owners.
SNVA250A–June 2007–Revised April 2013 AN-1650 LM34919 Evaluation Board
Submit Documentation Feedback
Figure 1. Evaluation Board - Top Side
1
Copyright © 2007–2013, Texas Instruments Incorporated
tON =
VIN - 1.5V
1.13 x 10
-10
x
(R1 + 1.4 k:)
+ 100 ns
Theory of Operation
2 Theory of Operation
Refer to the evaluation board schematic in Figure 5, which contains a simplified block diagram of the
LM34919. When the circuit is in regulation, the buck switch is on each cycle for a time determined by R1
and VIN according to the equation:
The on-time of this evaluation board ranges from ≊875 ns at VIN = 8V, to ≊231 ns at VIN = 40V. The ontime varies inversely with VIN to maintain a nearly constant switching frequency. At the end of each ontime the Minimum Off-Timer ensures the buck switch is off for at least 155 ns. In normal operation, the offtime is much longer. During the off-time, the load current is supplied by the output capacitor (C7, C8).
When the output voltage falls sufficiently that the voltage at FB is below 2.5V, the regulation comparator
initiates a new on-time period. For stable, fixed frequency operation, a minimum of 25 mV of ripple is
required at FB to switch the regulation comparator. The current limit threshold, is ≊640 mA at Vin = 8V,
and ≊730 mA at Vin = 40V. The variation is due to the change in ripple current amplitude as Vin varies.
Refer to the LM34919 data sheet for a more detailed block diagram, and a complete description of the
various functional blocks.
3 Board Layout and Probing
The pictorial in Figure 1 shows the placement of the circuit components. The following should be kept in
mind when the board is powered:
1) When operating at high input voltage and high load current, forced air flow may be necessary.
2) The LM34919, and diode D1 may be hot to the touch when operating at high input voltage and high
load current.
3) Use CAUTION when probing the circuit at high input voltages to prevent injury, as well as possible
damage to the circuit.
4) At maximum load current (0.6A), the wire size and length used to connect the load becomes important.
Ensure there is not a significant drop in the wires between this evaluation board and the load.
www.ti.com
(1)
4 Board Connection/Start-up
The input connections are made to the J1 connector. The load is connected to the J2 (OUT) and J3
(GND) terminals. Ensure the wires are adequately sized for the intended load current. Before start-up a
voltmeter should be connected to the input terminals, and to the output terminals. The load current should
be monitored with an ammeter or a current probe. It is recommended that the input voltage be increased
gradually to 8V, at which time the output voltage should be 5V. If the output voltage is correct with 8V at
VIN, then increase the input voltage as desired and proceed with evaluating the circuit. DO NOT EXCEED
40V AT VIN.
5 Output Ripple Control
The LM34919 requires a minimum of 25 mVp-p ripple at the FB pin, in phase with the switching waveform
at the SW pin, for proper operation. The required ripple can be supplied from ripple at V
feedback resistors as described in Options A and B below, or the ripple can be generated separately
(using R5, C9, and C10) in order to keep the ripple at V
Option A) Lowest Cost Configuration: This evaluation board is supplied with R4 installed in series with
the output capacitance (C7, C8). Since ≥25 mVp-p are required at the FB pin, R4 is chosen to generate
≥50 mVp-p at V
Using 0.39Ω for R4, the ripple at V
range. If the application can accept this ripple level, this is the most economical solution. The circuit is
shown in Figure 2 and Figure 8.
, knowing that the minimum ripple current in this circuit is ≊155 mAp-p at minimum VIN.
OUT
, through the
OUT
at a minimum (Option C).
OUT
ranges from ≊60 mVp-p to ≊140 mVp-p over the input voltage
OUT
2
AN-1650 LM34919 Evaluation Board SNVA250A–June 2007–Revised April 2013
Copyright © 2007–2013, Texas Instruments Incorporated
Submit Documentation Feedback
Cff t
t
ON (max)
(R2//R3)
FB
SW
BST
VCC
ISEN
SGND
VIN
R1
43.2k
SS
RTN
Gnd
D1
A1
A2
On
Timer
Minimum
Off
Timer
Logic
Regulation
Comparator
B3
A3
Current Limit
Detect
D3
C3
0.18:
C1
IN
Gnd
C2
1PF
8
V to
40V
RON/SD
C6
0.022
PF
0.1
PF
C3
1PF
0.
1
PF
C4
B1
V
IN
V
OUT
C5
D1
D2
C1
2.49k
R3
2.49k
R2
1000 pF
PF10
PF10
5V
LM34919
15 PH
L1
R
6 0:
C8C7
2.5V
0.022
PF
Cff
R
4
FB
SW
BST
VCC
ISEN
SGND
VIN
R1
43.2k
SS
RTN
Gnd
D1
A1
A2
On
Timer
Minimum
Off
Timer
Logic
Regulation
Comparator
B3
A3
Current Limit
Detect
D3
C3
0.39:
C1
IN
Gnd
C2
1PF
8
V to
40V
RON/SD
C6
0.022
PF
0.1
PF
C3
1PF
0.
1
PF
C4
B1
V
IN
V
OUT
C5
D1
D2
C1
2.49k
R3
2.49k
R2
PF10
PF10
5V
LM34919
15 PH
L1
R
6 0:
C8C7
2.5V
0.022
PF
R
4
www.ti.com
Output Ripple Control
Figure 2. Lowest Cost Configuration
Option B) Intermediate Ripple Configuration: This configuration generates less ripple at V
OUT
than
option A above by the addition of one capacitor (Cff) across R2, as shown in Figure 3.
Figure 3. Intermediate Ripple Configuration
Since the output ripple is passed by Cff to the FB pin with little or no attenuation, R4 can be reduced so
the minimum ripple at V
is ≊25 mVp-p. The minimum value for Cff is calculated from:
OUT
where t
feedback resistors. See Figure 8.
Option C) Minimum Ripple Configuration: To obtain minimum ripple at V
C9, and C10 are added to generate the required ripple for the FB pin. In this configuration, the output
ripple is determined primarily by the ESR of the output capacitance and the inductor’s ripple current.
The ripple voltage required by the FB pin is generated by R5, C10, and C9 since the SW pin switches
from -1V to VIN, and the right end of C10 is a virtual ground. The values for R5 and C10 are chosen to
generate a 50-100 mVp-p triangle waveform at their junction. That triangle wave is then coupled to the FB
pin through C9. The following procedure is used to calculate values for R5, C10 and C9:
SNVA250A–June 2007–Revised April 2013 AN-1650 LM34919 Evaluation Board
is the maximum on-time (at minimum VIN), and R2//R3 is the parallel equivalent of the
ON(max)
Submit Documentation Feedback
Copyright © 2007–2013, Texas Instruments Incorporated
, R4 is set to 0Ω, and R5,
OUT
(2)
3
FB
SW
R4
BST
VCC
ISEN
SGND
VIN
R1
43.2k
SS
RTN
Gnd
D1
A1
A2
On
Timer
Minimum
Off
Timer
Logic
Regulation
Comparator
B3
A3
Current Limit
Detect
D3
C3
0:
C1
IN
Gnd
C2
R5
1PF
8
V to
40V
RON/SD
C6
0.022
PF
0.1
PF
C3
1PF
0.
1
PF
C4
B1
V
IN
V
OUT
3300
pF
C10
C5
D1
D2
C1
2.49k
R3
2.49k
R2
C9
0.1
P
F
PF10
PF10
5V
LM34919
15 PH
L1
R
6 0:
C8C7
2.5V
0.022
PF
8.87
k:
R5 x C10 =
(8V - 4.63V) x 875 ns
0.1V
= 29.5 x 10
-6
R5 x C10 =
(VIN ± VA) x t
ON
'V
Monitor The Inductor Current
1) Calculate the voltage VA:
VA= V
– (VSWx (1 – (V
OUT
where VSWis the absolute value of the voltage at the SW pin during the off-time (typically 1V), and VINis
the minimum input voltage. For this circuit, VAcalculates to 4.63V. This is the approximate DC voltage at
the R5/C10 junction, and is used in the next equation.
2) Calculate the R5 x C10 product:
where tONis the maximum on-time (≊875 ns), VINis the minimum input voltage, and ΔV is the desired
ripple amplitude at the R5/C10 junction, 100 mVp-p for this example.
R5 and C10 are then chosen from standard value components to satisfy the above product. Typically C10
is 3000 to 5000 pF, and R5 is 10kΩ to 300 kΩ. C9 is chosen large compared to C10, typically 0.1 µF. See
Figure 4 and Figure 8.
))) (3)
OUT/VIN
www.ti.com
(4)
(5)
Figure 4. Minimum Output Ripple Configuration
6 Monitor The Inductor Current
The inductor’s current can be monitored or viewed on a scope with a current probe. Remove R6, and
install an appropriate current loop across the two large pads where R6 was located. In this way the
inductor’s ripple current and peak current can be accurately determined.
7 Scope Probe Adapters
Scope probe adapters are provided on this evaluation board for monitoring the waveform at the SW pin,
and at the circuit’s output (V
switching waveforms. The probe adapters are suitable for Tektronix P6137 or similar probes, with a 0.135”
diameter.
8 Minimum Load Current
The LM34919 requires a minimum load current of ≊1 mA to ensure the boost capacitor (C5) is recharged
sufficiently during each off-time. In this evaluation board, the minimum load current is provided by the
feedback resistors allowing the board’s minimum load current at V
4
AN-1650 LM34919 Evaluation Board SNVA250A–June 2007–Revised April 2013
), without using the probe’s ground lead which can pick up noise from the
OUT
Copyright © 2007–2013, Texas Instruments Incorporated
to be specified at zero.
OUT
Submit Documentation Feedback
FB
SW
R4
BST
VCC
ISEN
SGND
VIN
R1
43.2k
SS
RTN
Gnd
D1
A1
A2
On
Timer
Minimum
Off
Timer
Logic
Regulation
Comparator
B3
A3
Current Limit
Detect
D3
C3
0.39:
C1
IN
Gnd
C2
R5
1PF
8
V to
40V
RON/SD
C6
0.022
PF
0.1
PF
C3
1PF
0.
1
PF
C4
B1
V
IN
V
OUT
C10
C5
D1
D2
C1
2.49k
R3
2.49k
R2
C9
PF10
PF10
5V
LM34919
15 PH
L1
R
6 0:
C8C7
2.5V
0.022
PF
OUTPUT
SW
www.ti.com
Minimum Load Current
Figure 5. Complete Evaluation Board Schematic
Table 1. Bill of Materials
Item Description Mfg., Part Number Package Value
C1, C2 Ceramic Capacitor TDK C3216X7R1H105M 1210 1.0 µF, 50V
C3 Ceramic Capacitor TDK C1608X7R1H104K 0603 0.1 µF, 50V
C4 Ceramic Capacitor TDK C1608X7R1H104K 0603 0.1 µF, 50V
C5, C6 Ceramic Capacitor TDK C1608X7R1H223K 0603 0.022 µF, 50V
C7, C8 Ceramic Capacitor TDK C3216X7R1C106K 1206 10 µF, 16V
C9 Ceramic Capacitor Unpopulated 0603
C10 Ceramic Capacitor Unpopulated 0603
D1 Schottky Diode Zetex ZLLS2000 SOT23-6 40V, 2.2A
L1 Power Inductor Bussman DR73-150 7.6 mm x 7.6 mm 15 µH, 1.8A
R1 Resistor Vishay CRCW06034322F 0603 43.2 kΩ
R2, R3 Resistor Vishay CRCW06032491F 0603 2.49 kΩ
R4 Resistor Panasonic ERJ3RQFR39 0603 0.39Ω
R5 Resistor Unpopulated 0603
R6 Resistor Vishay CRCW08050000Z 0805 0Ω Jumper
U1 Switching Regulator LM34919 10 Bump DSBGA
SNVA250A–June 2007–Revised April 2013 AN-1650 LM34919 Evaluation Board
Submit Documentation Feedback
Copyright © 2007–2013, Texas Instruments Incorporated
5
Circuit Performance
9 Circuit Performance
www.ti.com
Figure 6. Efficiency vs Load Current
6
AN-1650 LM34919 Evaluation Board SNVA250A–June 2007–Revised April 2013
Figure 7. Efficiency vs Input Voltage
Figure 8. Output Voltage Ripple
Copyright © 2007–2013, Texas Instruments Incorporated
Submit Documentation Feedback
www.ti.com
Circuit Performance
Figure 9. Switching Frequency vs. Input Voltage
Figure 10. Load Current Limit vs Input Voltage
SNVA250A–June 2007–Revised April 2013 AN-1650 LM34919 Evaluation Board
Submit Documentation Feedback
7
Copyright © 2007–2013, Texas Instruments Incorporated
Typical Waveforms
10 Typical Waveforms
www.ti.com
Trace 4 = V
Trace 3 = inductor Current
Trace 2 = SW Pin
Vin = 24V, Iout = 400 mA
Trace 4 = V
Trace 3 = inductor Current
Trace 2 = SW Pin
Vin = 24V, Iout = 20 mA
OUT
OUT
Figure 11. Continuous Conduction Mode
Figure 12. Discontinuous Conduction Mode
8
AN-1650 LM34919 Evaluation Board SNVA250A–June 2007–Revised April 2013
Copyright © 2007–2013, Texas Instruments Incorporated
Submit Documentation Feedback
www.ti.com
11 PC Board Layout
PC Board Layout
Figure 13. Board Silkscreen
SNVA250A–June 2007–Revised April 2013 AN-1650 LM34919 Evaluation Board
Submit Documentation Feedback
Figure 14. Board Top Layer
9
Copyright © 2007–2013, Texas Instruments Incorporated
PC Board Layout
www.ti.com
Figure 15. Board Second Layer (Viewed from Top)
10
AN-1650 LM34919 Evaluation Board SNVA250A–June 2007–Revised April 2013
Copyright © 2007–2013, Texas Instruments Incorporated
Submit Documentation Feedback
IMPORTANT NOTICE
Texas Instruments Incorporated and its subsidiaries (TI) reserve the right to make corrections, enhancements, improvements and other
changes to its semiconductor products and services per JESD46, latest issue, and to discontinue any product or service per JESD48, latest
issue. Buyers should obtain the latest relevant information before placing orders and should verify that such information is current and
complete. All semiconductor products (also referred to herein as “components”) are sold subject to TI’s terms and conditions of sale
supplied at the time of order acknowledgment.
TI warrants performance of its components to the specifications applicable at the time of sale, in accordance with the warranty in TI’s terms
and conditions of sale of semiconductor products. Testing and other quality control techniques are used to the extent TI deems necessary
to support this warranty. Except where mandated by applicable law, testing of all parameters of each component is not necessarily
performed.
TI assumes no liability for applications assistance or the design of Buyers’ products. Buyers are responsible for their products and
applications using TI components. To minimize the risks associated with Buyers’ products and applications, Buyers should provide
adequate design and operating safeguards.
TI does not warrant or represent that any license, either express or implied, is granted under any patent right, copyright, mask work right, or
other intellectual property right relating to any combination, machine, or process in which TI components or services are used. Information
published by TI regarding third-party products or services does not constitute a license to use such products or services or a warranty or
endorsement thereof. Use of such information may require a license from a third party under the patents or other intellectual property of the
third party, or a license from TI under the patents or other intellectual property of TI.
Reproduction of significant portions of TI information in TI data books or data sheets is permissible only if reproduction is without alteration
and is accompanied by all associated warranties, conditions, limitations, and notices. TI is not responsible or liable for such altered
documentation. Information of third parties may be subject to additional restrictions.
Resale of TI components or services with statements different from or beyond the parameters stated by TI for that component or service
voids all express and any implied warranties for the associated TI component or service and is an unfair and deceptive business practice.
TI is not responsible or liable for any such statements.
Buyer acknowledges and agrees that it is solely responsible for compliance with all legal, regulatory and safety-related requirements
concerning its products, and any use of TI components in its applications, notwithstanding any applications-related information or support
that may be provided by TI. Buyer represents and agrees that it has all the necessary expertise to create and implement safeguards which
anticipate dangerous consequences of failures, monitor failures and their consequences, lessen the likelihood of failures that might cause
harm and take appropriate remedial actions. Buyer will fully indemnify TI and its representatives against any damages arising out of the use
of any TI components in safety-critical applications.
In some cases, TI components may be promoted specifically to facilitate safety-related applications. With such components, TI’s goal is to
help enable customers to design and create their own end-product solutions that meet applicable functional safety standards and
requirements. Nonetheless, such components are subject to these terms.
No TI components are authorized for use in FDA Class III (or similar life-critical medical equipment) unless authorized officers of the parties
have executed a special agreement specifically governing such use.
Only those TI components which TI has specifically designated as military grade or “enhanced plastic” are designed and intended for use in
military/aerospace applications or environments. Buyer acknowledges and agrees that any military or aerospace use of TI components
which have not been so designated is solely at the Buyer's risk, and that Buyer is solely responsible for compliance with all legal and
regulatory requirements in connection with such use.
TI has specifically designated certain components as meeting ISO/TS16949 requirements, mainly for automotive use. In any case of use of
non-designated products, TI will not be responsible for any failure to meet ISO/TS16949.
Products Applications
Audio www.ti.com/audio Automotive and Transportation www.ti.com/automotive
Amplifiers amplifier.ti.com Communications and Telecom www.ti.com/communications
Data Converters dataconverter.ti.com Computers and Peripherals www.ti.com/computers
DLP® Products www.dlp.com Consumer Electronics www.ti.com/consumer-apps
DSP dsp.ti.com Energy and Lighting www.ti.com/energy
Clocks and Timers www.ti.com/clocks Industrial www.ti.com/industrial
Interface interface.ti.com Medical www.ti.com/medical
Logic logic.ti.com Security www.ti.com/security
Power Mgmt power.ti.com Space, Avionics and Defense www.ti.com/space-avionics-defense
Microcontrollers microcontroller.ti.com Video and Imaging www.ti.com/video
RFID www.ti-rfid.com
OMAP Applications Processors www.ti.com/omap TI E2E Community e2e.ti.com
Wireless Connectivity www.ti.com/wirelessconnectivity
Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265
Copyright © 2013, Texas Instruments Incorporated
Loading...
