Testo 480 Data sheet

Committing to the future

testo 480 IAQ Pro

testo 480 IAQ Pro

The Ultimate in Accurate Indoor Climate Measurement

°F • FPM • RH • CO2 • CFM

Intelligent probes for every measuring task

NEW!

The NEW
testo 480 IAQ Pro

The Ultimate in
Accurate Indoor
Climate Measurement

A comfortable climate is a key factor to productivity
at the office, health at home, and safe storage at an
industrial location. When adjustments are required,
HVAC and Test and Balance professionals work
to identify issues quickly, so the indoor climate is
adjusted and comfortable once again.

The testo 480 IAQ Pro is the latest in cutting-edge

measurement technology from testo providing the
most accurate indoor climate measurements, like

temperature, humidity, and airflow.

The testo 480 can aid HVAC professionals to
optimally configure systems in offices, residential
locations, and industrial buildings, and record all
relevant climate parameters of indoor air quality
such as CO2, °F, and even light.

Use the new testo 480 and its intelligent probes to keep indoor climates

comfortable and HVAC equipment working optimally!

Advantages
of the testo 480
IAQ Pro

• Reliable Measurements

The perfect combination of a highly accurate,
rugged hand-held instrument and a wide
variety of probes to meet the needs of
HVAC and T&B professionals.

• Save Calibration Time

Intelligent probes retain calibration information
and increase productivity in the field.

• Manage Data

Use the easyCLIMATE software to simplify data
handling of large jobs and maintain stored profiles.

• Save Time

Perform multiple measurements simultaneously.

• Probe Variety

Choose from a wide selection of probes
to match any measurement need.

The testo 480 can meet any indoor climate measurement need

The testo 480 can meet any indoor climate measurement need

When taking duct measurements, the testo
480 can measure the flow within the duct and
complete HVAC grid measurements so the
system can be adjusted optimally.

When measuring at air outlets, the 480
can check whether a system is optimally
configured and balanced, allowing the
HVAC professional to take any necessary
corrective measures and improve the indoor
air conditioning quickly and easily.

A full line of probes are available for measuring
comfort level and indoor air quality for a wide
variety of different circumstances. A tripod
is also available for use with the 480 for
workplace evaluation.

Intelligent probes for every measuring task

Intelligent probes for every measuring task

Thermal probe

Can bend to a 90º angle and includes telescope with
easy-to-read scaling and integrated measurement button

Part #: 0635 1543

Committing to the future

Comfort level probe

Standards-compliant
measurement according
to ASHRAE 55-2004

Part #: 0628 0143

RTD Pt100

High-precision
immersion and
penetration probe

Part #:
available in
January 2012

0.62" vane probe

Includes telescope with easy­to-read scaling and integrated
measurement button

Part #: 0635 9542

IAQ probe

Measures CO
humidity and absolute
pressure. Includes tripod

Part #: 0632 1543

, temperature,

2

Light probe

Assesses lighting
conditions in workplaces

Part #: 0635 0543

Humidity probe

High-precision 1%
humidity probe

Part #: 0636 9743

4" vane probe

Can be used with funnel set
as well as in combination with
extension (available separately)

Part #: 0635 9343

Globe probe

Measures radiated heat
with thermocouple probe
type K, class 1

Part #: 0602 0743

easyCLIMATE Software simplifies measuring tasks
and processes data into clear and concise reports

easyCLIMATE Software simplifies the measuring
tasks and processes the data into clear and

concise reports for faster and more thorough
diagnosis and evaluation of HVAC systems and

IAQ parameters.

• Simple menu guided operation

• Measuring tasks based on today’s compliance standards

• Prints data on-site or transfers data via USB or SD card to PC

• Seamless interface with PC

• Customize reports for measuring locations

[phone] • testo.com

ORDERING INFORMATION TECHNICAL DATA

IAQ Measurement Kit Part #

testo 480 including easyCLIMATE PC software, power supply and USB cable 0563 4800
Tripod for comfort level measurement 0554 0743
Comfort level probe (requires part no. 0430 0100) 0628 0143
Globe probe, 6" 0602 0743
Humidity and temperature probe, 0.4" diam. (requires part no. 0430 0100) 0636 9743
IAQ probe including desktop stand (requires part no. 0430 0100) 0632 1543
Light probe 0635 0543
System case for comfort level measurements 0516 4801

HVAC System Performance Kit Part #

testo 480 including easyCLIMATE PC software, power supply and USB cable 0563 4800
Vane probe, 0.62" diam. with telescope (requires part no. 0430 0100) 0635 9542
Thermal flow probe with telescope (requires part no. 0430 0100) 0635 1543
Vane probe, 4" diam. (requires part no. 0430 0100) 0635 9343
Humidity and temperature probe, 0.47" diam. (requires part no. 0430 0100) 0636 9743

IAQ probe including tripod (requires part no. 0430 0100) 0632 1543
Prandtl pitot tube “L” type pitot tube 13" SS 0635 2145
System case for HVAC measurements 0516 4800

Other Accessories Part #

Funnel set (13” x 13”), including carry bag for round vents 8” diam. 0563 4170
Connection hose for differential pressure measurement 0554 0440
Testo IR printer, 1 roll of thermal paper and 4 AA batteries 0554 0549
Plug-in head cable 0430 0100
TC probe Type K see testo.com
Testovent 410 Flow Funnel: for low flow (<50 CFM) including carrying bag 0554 0410
Testo saline pots: Humidity adjustment 11.3% RH and 75.3% RH,

including adapter for humidity probe
Spare thermal paper for printer (6 rolls) 0554 0568

0554 0660

Sensor
connections

Other
connections

Operating temp. 32° to 105 °F
Power supply Battery or

Battery life Up to 8 hours
Display Color graphics/

Memory Up to 10,000 rdgs.
Differential

pressure
measuring range

Differential
pressure
resolution

2 x TC Type K,
1 x differential
pressure, 3 x digital

USB, SD-card,
power supply

connected power
supply for longterm
measuring and
battery charging

display

±10 "H2O

0.001 "H2O

ORDERING INFORMATION: PROBES

Probe Measurement

Flow Probes

Vane measurement probe,
ø 0.6"

Thermal flow probe 0 to 4000 fpm

Vane measurement probe,
ø 4"

Comfort Level Probes

Humidity and temperature
probe, ø 0.4"

IAQ probe -4 to 158 °F

Degree of turbulence probe 32 to 122 °F

Globe probe, ø 6" 32 to 248 °F Type K thermocouple, class 1 0602 0743

Lux probe 0 to 1000,000

Additional Probes

High-precision Pt100 immersion/
penetration probe

TC probe Type K and Pitot tubes see www.testo.com

Range

78 to 9,800 fpm

14 to 158 °F

-4 to 158 °F
0 to 100 %RH

20 to 3,000 fpm
32 to 140 °F

0 to 100 %RH

-4 to 158 °F

0 to +100 RH
0 to 10,000 ppm
CO

2

281 to 442 "H2O

0 - 1,000 fpm

Lux

Accuracy (±1 digit) Part #

±(39 fpm + 1% of reading) 78 - 8,000 fpm
±(39 fpm + 2% of reading) 8,000 - 10,000 fpm
±3°F

±(6 fpm + 4% of reading)
±0.9 °F

2.5%
±(20 fpm + 1.5% of reading)

±0.9 °F

±(1.0 %) 0 to 90 %RH
±(1.4 %) 90 to 100 %RH
±0.9 °F

±0.9 °F

2.5 %
±(50 ppm CO2 + 2% of reading)
0 to +5,000 ppm CO
±(100 ppm CO2 +3% of reading)

5.001 to +10,000 ppm CO
±1.2 "H2O
26s

±0.9 °F
±(59 fpm +4 of reading)

Class C according to DIN 5032-7
f1 = 6% V-Lamda
f2 = 5% cos

available in January 2012

2

2

0635 9542

0635 1543

0635 9343

0636 9743

0632 1543

0623 0143

0635 0543

Committing to the future

[phone]

testo.com

11TES830 (1) 9/11 2.5K
