Tesoro Durandal Ultimate Quick Start Guide
Quick Start Guide
MIC
PHONEUSB
G
C
D
A
Key Features
TESORO Logo Lighting
B
A
4 levels Illumination Control,
B
Fn+Num 8+/2Multimedia Keys, Fn+F1~F6
C
Profile Keys, Fn+F7~F11
D
Game / PC mode, Fn+F12
Detachable Wrist Pad
USB Hub, Phone, MIC Jack
G
Welcome to TESORO World
Congratulations on purchasing your very own TESORO DURANDALTM ULTIMATE Backlit Mechanical Gaming Keyboard - a gaming keyboard engineered to suit the
needs of every gamer. Featuring Cherry mechanical switches and changeable illumination, it is the keyboard of choice for optimizing the gaming experience.
TESORO DURANDAL
Backlit Mechanical Gaming Keyboard Quick Start Guide
Package Contents
• Mechanical Keyboard x 1 • Wrist pad x 1 • Quick start guide x 1 • TESORO brochure x 1
NOTICE: The quick start guide with registration code and worldwide warranty card on the bottom page, please keep it for after service.
System Requirements
• PC system with built-in at least (1)*USB, phone-out and MIC-in ports
®
• Windows
• 50MB of free hard disk space
Hardware Installation
1. Plug TESORO DURANDALTM ULTIMATE into the USB,
MIC (pink), PHONE (green) port of your computer.
XP / Vista / 7 / 8 / 8.1
TM
ULTIMATE
1
1
MIC (pink)Phone (green)
2. USB Hub, MIC and PHONE jack connection on keyboard, please refer as follow.
NOTICE : USB Hub on keyboard is available for portable USB
devices: earphone/headphone, speaker, pen drive or MP3
player.
3. Specific Functions :
The multimedia and programmable profile functions are available
to press with “Fn” key
a. Multimedia keys :
b. Macros profile keys:
c. To switch Game and PC mode:
4. Illumination Control :
illuminate up:
illuminate down:
4 levels for LED illumination.
Level 0: Non-Light
Level 1: Low-Light
Level 2: Mid-Light
Level 3: High-Light
Level 4: Dimming Mode
5. Wrist Pad Installation:
Attachment:
Insert the wrist pad into the slots underneath
Detachment:
Bend the wrist pad down to detach it from keyboard
