Page 1
H 385 x W 458 x D 810 mm
Marrakech 4pc Lounge Set-Table
catalogue ref: 303-8999
Assembly instructions
Produced in China for TESCO Stores Ltd.
©Tesco
2014.
1
Page 2
This product should only be used on firm, level ground.
Keep small parts out of reach of children.
Unwrap all packaging materials and place the components
on top of the carton box or on a clean floor to prevent it from
scratching.
Check the pack and make sure you have all the parts listed.
Make sure the legs remain in contact with the ground.
We recommend the use of furniture covers to protect your
product when not in use.
During bad weather and winter months the product should be
stored in a cool dry place. Before storage ensure that it is
clean and dry.
Do not use power tools to construct this product..
Do not tighten screws until fully assembled.
Do not over tighten screws or bolts.
Do not use this product if parts are missing, damaged or worn.
Do not sit or stand on the product.
Never use a pressure hose or washer to clean the product.
Never use scourers, abrasives or chemical cleaners.
“Hi, look out for me throughout this manual. Wherever you
see my picture I will have a handy tip to help you with the
assembly of your product.”
My first tip is:” Before you start get a cup of tea, sit down and
read though these instructions carefully.”
And for good measure my second tip is that you will need the
following tools to assemble this product, so gather them to
hand before you start.
2
Check all screws or bolts are tightened and inspect regularly.
To clean wipe with a sponge and warm soapy water then
wipe with a dry, clean cloth.
Ensure that this product is fully assembled as illustrated
before use.
If a glass component is chipped or broken, stop using the
Produced in China for TESCO Stores Ltd.
©Tesco 2014.
Marrakech 4pc Lounge Set-Table
Assembly instructions
product and consult the manufacturer or supplier
Do not place very hot or very cold items on the glass surface(s)
unless adequately thick table mats are used to prevent such
items coming into contact with the glass.
Do not sit or stand upon the glass surface.
Do not use the glass as a chopping surface. Do not strike the
glass with hard or pointed items.
The glass of this product complies with BS EN 12150-1:2000
When you are ready to start, make sure that you have the
right tools, plenty of sapce and a clean, dry area for assembly.
Important:
RETAIN FOR FUTURE REFERENCE: READ CAREFULLY
Two people to assemble and lift the table into position.
15 minutes
clause 8
The frames are manufactured using the powder coated steel
tubing. When steel is exposed to air and moisture it will rust.
Any scratches on the paintwork should be touched up
immediately with metal paint, otherwise corrosion may occur.
This product is intended for a maximum weight of 75 kg.
Do not exceed this weight
Page 3
We are happy to refund or replace any Tesco product
which falls below the high standard you expect. Just ask
any member of staff. This will not effect your statutory
rights.
Missing parts
If you are missing any fixtures and fittings for your product
please contact our customer service team on
and they will be happy to arrange for a replacement to
be sent to you free of charge.
Assembly Service
If you decide that you do not wish to assemble this
product yourself, please contact our trained assembly
team on who will be able to provide a
quote for assembling this item for you.
Tesco Self Assembly Furniture
Telephone Service
Tesco has enlisted the help of FIRA Service Technicians,
the UK’s experts on furniture, to provide a helpline for
those hitting snags when putting their flat pack item
together.
The knowledgeable and patient staff at FIRA can help you
and are available to take your call 08.00hrs to 20.00hrs
Monday to Friday on: 0845 520 5516*.
* Calls are charged at local rates.
Home service technicians
If you have a fault with your product please contact our
customer service team on 08450 264 549. If you have had the
product for 28 days or less you may be offered a replacement,
refund or for a fully trained home service technician to visit your
home to assess the fault and repair the product where
possible.
If you have had the product for more than 28 days we will send
an independent home service technician to review and repair
the product where possible and recommend further action.
The Furniture Ombudsman
“Inspiring Consumer Confidence”
As part of our commitment to maintaining high standards and
responsible furniture retailing, Tesco is a Full Member of The
Furniture Ombudsman. This means that if you’re not entirely
satisfied with your purchase – and we haven’t managed to
resolve the problem – you can contact them to look into it for
you. By signing up to The Furniture Ombudsman Code of
Practice we promise to follow their decisions – ensuring that
you get a fair deal. This means that you can buy in complete
confidence when selecting your furniture from Tesco.
You should first discuss your complaint with our Customer
Service team on 08450 264 549 so that we can try to solve any
issues. After that, if you’re still not happy you can contact The
Furniture Ombudsman at www.thefurnitureombudsman.org.
You can write to us at
Tesco Stores Ltd,
New Tesco House,
Delamare Road,
Cheshunt,
Herts, EN8 9SL, UK
FREEPHONE 0800 50 55 55
3
08450 264
549
08450 264 549
Produced in China for TESCO Stores Ltd.
©Tesco 2014.
Marrakech 4pc Lounge Set-Table
Assembly instructions
Page 4
4
1
1
4
2
3
Produced in China for TESCO Stores Ltd.
©Tesco 2014.
Getting to know your product
Marrakech 4pc Lounge Set-Table
Assembly instructions
Page 5
5
8
2
1
8
L455*W55*H380
L685*W445*H18
L630*W20*H75
L680*W415*H5
Produced in China for TESCO Stores Ltd.
©Tesco 2014.
Marrakech 4pc Lounge Set-Table
Assembly instructions
1
Fixturesandfittings s
upplied(actualsize
)
M6 x 1
8
A
∅
16
x
6.5x2
B
C
omponents s
upplied(notactualsize
)
1
1
C
2
3
Fixturesandfittings s
upplied(notactualsize
)
4
1
1
∅
Page 6
12
34
6
1
2
3
A x4
M6 x 18
supplied
∅
16x 6.5x2
Bx4
33
M6 x 18
supplied
3
A
B
A
B
2
1
1
1
4
2
4
Produced in China for TESCO Stores Ltd.
©Tesco 2014.
A x4
Bx4
Marrakech 4pc Lounge Set-Table
Assembly instructions
∅
∅
16x 6.5x2
∅
