TerraTec Cinergy 400 TV mobile, Cinergy 400 TV mobile MK II User Manual

Installing hardware and drivers

Version:20.08.04

CE Declaration

We:

TerraTec Electronic GmbH, Herrenpfad 38, D-41334 Nettetal, Germany

hereby declare that the product:

ReceiverSystem TerraTec Cinergy 400 TV mobile

to which this declaration refers is in compliance with the following standards or standardizing
documents:

EN55o13

EN55020: 2000 + A1 :2003

The following are the stipulated operating and environmental conditions for said compliance:

residential, business and commercial environments and small-company environments.

The Cinergy 400 TV mobile is solely intended to be connected to devices

that comply with the EN60950 safety standard.

This declaration is based on:

Test report(s) of the EMC testing laboratory

The information in this document is subject to change without notice and shall not be deemed as a warranty by the
seller. No warranties, express or implied, are made with regard to the quality, suitability or accuracy of this docu­ment. The manufacturer reserves the right to change the contents of this document and/or the associated products
at any time without the provision of prior notice to specific persons or organizations. The manufacturer shall not be
held liable for damages of any kind arising from the use, or the inability to use this product or its documentation,
even if the possibility of such damage is known. The information in this document is subject to copyright. All rights
are reserved. No part of this manual may be reproduced or transmitted in any form or for any purpose without the
express written permission of the copyright holders. Product and brand names contained in this document are used
for identification purposes only. All registered trademarks, product designations or brand names used in this
document are the registered property of their respective owners.

©TerraTec

®

Electronic GmbH, 1994-2004. All rights are reserved (20.08.04).

2 Cinergy 400 TV mobile Hardware (English)

Contents

Welcome! ............................................................................................................................. 4

Key features. ........................................................................................................................5

System requirements. .......................................................................................................... 5

Scope of delivery.................................................................................................................. 5

The connections at a glance.................................................................................................. 6

Installing hardware and drivers..............................................................................................7

Driver installation under Windows 2000...............................................................................7

Driver installation under Windows XP .................................................................................12

Connecting external devices to the TV card......................................................................... 13

Connecting an external device equipped with antenna-out. ............................................ 13

Connecting an external device with video output (composite)......................................... 14

Connecting an external device with S-video output. ........................................................ 14

Connecting an external device equipped with Scart-out. ................................................. 15

Service at TerraTec. ............................................................................................................16

Hotline & Internet............................................................................................................ 16

Broken?!.......................................................................................................................... 17

Cinergy 400 TV mobile Hardware (English) 3

Welcome!

We're pleased that you have chosen a TerraTec ReceiverSystem and would like to congratu­late you on this decision. With the PCMCIA TV card of the TerraTec Cinergy series you've pur­chased a sophisticated product representing the state of the art of PC/TV technology. We're
convinced that our product will prove extremely useful to you and provide you with a great
deal of entertainment.

Before we go into detail, here's a foretaste of what you can expect:

Superior picture clarity. TerraTec's TV cards of the Cinergy series offer your eyes a needle­sharp TV picture that is always comfortably calm. This quality is created by a powerful receiver
component, not to mention a function that automatically reduces the so-called “picket-fence
effect” using a combination of modern chip technology and software-controlled deinterlacing.

Comprehensive software equipment. From current video drivers for Microsoft's WDM technol­ogy and a powerful operating software with numerous settings and recording functions, to
useful bundled software programs, the Cinergy software package is both highly functional
and comprehensively designed. The flexible software concept of the Cinergy TV cards sup­ports the installation of additional video compressors codecs—by third-party vendors that are
often available free of charge and which provide a range of fascinating options.

Multiple connections. Your Cinergy is equipped with a coaxial antenna jack for TV reception,
as well as a composite input and an S-video input for connecting other video units and high­quality SVHS components. To complete the connection options, the unit is also equipped with
audio input jacks.

We hope you enjoy your Cinergy TV card and would like to suggest that you browse this hope­fully entertaining manual when you get the chance. In addition to the important information
about its technology, we have outlined a number of typical applications wherever appropri­ate. We're convinced that even experienced users will profit from this guide.

Thanks for your attention—enjoy!

...your TerraTec Team

4 Cinergy 400 TV mobile Hardware (English)

Key features.

· Phillips SAA 713x chipset

· Software-controlled deinterlacing

· Integration of external codecs

· High-speed teletext—teletext without delays

· Recording of single frames and video sequences

· TV screen scalable up to full screen size

· Multi-channel preview

· S-video and video inputs for external video sources

· TerraTec Scheduler software

· 2 years warranty

System requirements.

· CPU 1GHz (Pentium IV / AMD Athlon XP / Intel Centrino recommended)

· 256 MB RAM

· Windows 2000 or XP

· PCMCIA slot

· Sound card

· CD-ROM drive (to install drivers/software)

If your notebook and/or equipment do not meet these requirements, the TV card will not
operate correctly.

Scope of delivery.

· TerraTec Cinergy 400 TV mobile

· Multi-connector cable

· TerraTec Cinergy 400 TV mobile CD ROM

· Service request form

· Registration documents

Cinergy 400 TV mobile Hardware (English) 5

The connections at a glance.

1 - TV Antenna In

2 - Composite In

3 - Stereo audio inputs

4 - S-video In

5 - Multi-connector cable jack

TV Antenna In (1)

Use this terminal to connect your home antenna or to establish a connection to a cable net­work.

Analog video inputs (2 and 4)

These inputs are used to connect external devices like video recorders and satellite receivers.
If your video recorder has an S-video output, we recommend you use it.

Stereo audio inputs (3)

If you are connecting external devices using the Composite or S-video input terminal, you also
have to establish an audio connection. Use this jack to do so.

Multi-connector cable jack (5)

Use the multi-connector cable provided to connect analog units (such as a VCR or Camcorder)
to the Cinergy 400 TV mobile.
