Telex LCU-3 User Manual

Telex
User Manual
Lufthansa
LCU-3
Communication Unit
9350-7773-000 Rev b 12/2005
Headset
1 2
Power
LCU-3
2
11
1
LCU-3
Power
2
HEADSET
H e a
d s e
t L C U
­3
1
2
Powe
r
LCU-3
6
Modes of Operation
Figure 4. The LCU-3 Communication unit in battery powered mode of
operation.
Figure 5. The LCU-3 Communication unit also can use the AUX
connection to power the unit. The AUX connection can be used for a headset as well as to power the unit.
Proprietary Notice
The Audiocom product information and design disclosed herein were originated by and are the property of Telex Communications, Inc. Telex reserves all patent, proprietary design, manufacturing, reproduction, use and sales rights thereto, and to any article disclosed therein, except to the extent rights are expressly granted to others.
Copyright Notice
Copyright 2003 by Telex Communications, Inc. All rights reserved. Reproduction in whole or in part without prior written permission from Telex is prohibited.
Unpacking and Inspection
Immediately upon receipt of the equipment, inspect the shipping container and the contents carefully for any discrepancies or damage. Should there be any, notify the freight company and the dealer at once.
Warranty Information
See enclosed warranty card
Customer Support
Technical questions shouls be directed to:
Customer Service Department RTS/Telex 12000 Portland Ave South Burnsville, MN 55337 U.S.A. Telephone: (877) 392-3497 Fax: (800) 323-0498
DO NOT RETURN ANY EQUIPMENT DIRECTLY TO THE FACTORY WITHOUT OBTAINING A RETURN AUTHORIZATION. Be prepared to provide the company name, address, phone number, a person to contact regarding the repair, the type and quantity of equipment, a description of the problem and the serial number(s).
Shipping to Manufacturer for Repair or Adjustment
All shipments of Audiocom products should be made via United Parcel Service or the best available shipper, prepaid. The equipment should be shipped in the original packing carton; if that is not available, use any suitable container that is rigid and of adequate size. If a substitute container is used, the equipment should be wrapped in paper and surrounded with at least four inches of excelsior or similar shock absorbing material. All shipments must be sent to the following address and must include the Return Authorization:
Factory Service Department Telex Communications, Inc. 8601 East Cornhusker Hwy Lincoln, NE 68507 Tel: 1-800-553-5992 Direct: 1-402-4675321
Upon completion of any repair the equipment will be returned via United Parcel Service or specified shipper collect.
Headset
1 2
LCU-3
Power
LCU-3
1
LCU-3
Power
2
HEADSET
4-pin XLR Connector
9VOLT BATTERY CHARGE
+
-
AUX
3
10
Bottom Panel: AUX, XLR, 4-pin male
Pin 1 Talk (electret pwr) Pin 2 Listen Pin 3 GND Pin 4 External Power
Charger connector, 3.5 mm T = Power S = Chassis GND R = Signal GND
Mechanical Specifications
Color Clear Anodized Aluminum
Weight 13.4 oz. / 381 g
Dimensions
Length 5.0 inches / 127 mm Width 3.5 inches / 88.9 mm Depth 1.8 inches / 45.7 mm
4 9
Specifications
Power Requirements
Battery 9VDC 250 mAh recharge
able
External Power 12-28 VDC
Electrical Specifications
Gain (Input to Output) +42 dBu ±2 dB Frequency Response 400 -10 kHz + 1/-3
reference to 1kHz Noise < -40 dBu THD% 1% Max. Output Power 20 mW into 150 ohms
Environmental Specifications
Temperature
Operating: -20 to 50° C Storage -20 to 80° C Humidity 0-90% non-condensing
Connectors, Controls and Indicators
Top Panel: Headset connectors, 6.35
mm
T = Listen
R = Talk
S = GND
Contents
General Description .....................................................5
Features ........................................................................ 5
Operations .................................................................... 6
Controls and Connections ............................................6
Specifications............................................................... 9
Modes of Operation .....................................................10
8
General Description
The LCU-3 communication unit, is a simple accessory allowing three people to communicate in full-duplex mode (i.e., talking and listening at the same time). With two headsets, it covers all situations where up to three people are working closely together as a team to complete some critical task
The LCU-3 communication unit is used with the Groundcom Headset 2002 which offers optimum hearing protection with the critical clarity needed to communicate in the airline maintenance environment.
5
4. AUX Connector
5. Battery Charger 3.5mm Connector
6. 9 Volt, 250 mAh battery
76
OPERATION
All workers who are connected to the LCU-3 communica­tion unit and use the GroundCom headset 2002 must use the PTT (push-to-talk) feature to enable their mic.
System Power
The LCU-3 communication unit is powered by a 9 Volt rechargable battery (see figure 1). It can also be powered externally through the AUX connector
LCU-3
Headset
LCU-3
1
2
Power
9 Volt battery
Figure 1. LCU-3 9 Volt battery placement.
Figure 2. AUX Connector.
Controls and Connections
1&2. Headset connectors: The headset connector
takes a 6.35mm stereo plug. When the headset is plugged into the unit, the unit automatically turns on. Conversely, when the headset is unplugged, it turns off.
3. Power ON LED: The power ON LED lights green when power is active in the product.
Figure 3. Connectinos and Controls of the LCU-3.
9 VOLT BATTERY CHARGE
+
-
AUX
1
LCU-3
Power
2
HEADSET
1
To p
2
3
Bottom
4
Headset
LCU-3
1
2
Power
LCU-3
6
9 VOLT BATTERY CHARGE
9 VOLT BATTERY CHARGE
+
-
AUX
5
