Telenav Nextel Supported Devices User Manual v2.2

TeleNav v2.2 for GPS-enabled Java phones

Auto GPS Navigation for Nextel Java Phones

Motorola i730 Java phone with integral GPS receiver

User’s Guide

All rights reserved. No part of this manual may be reproduced, transmitted, copied, or stored in any storage medium, for any purpose, without prior written consent from TeleNav, Inc. TeleNav, Inc. hereby grants the right to download one copy of this manual onto a hard drive for personal use. This manual is copyrighted and contains proprietary information that is subject to change without notice. For more information visit www.telenav.com

Table of Contents

1. Welcome ................................................................................................................................5

2. Safety and Legal Notices ......................................................................................................6

3. Getting Started with TeleNav ................................................................................................6

4. Installing TeleNav on Your Phone ........................................................................................7

5. GPS Privacy...........................................................................................................................9

6. Using TeleNav .....................................................................................................................10

Launching the Application...................................................................................................... 10

Logging In ...............................................................................................................................10

Main TeleNav Menu...............................................................................................................13

GPS Basic (free services)...................................................................................................... 13

Compass .........................................................................................................................13

View waypoint ................................................................................................................. 15

View track ........................................................................................................................ 16

Record Track/End Track................................................................................................. 16

GPS Plus ................................................................................................................................ 17

Maps ................................................................................................................................ 17

Locator............................................................................................................................. 18

Driving Directions ............................................................................................................ 21

TeleNav................................................................................................................................... 22

GPS Navigation............................................................................................................... 22

Yellow Pages................................................................................................................... 23

Preferences ............................................................................................................................27

Address Entry ......................................................................................................................... 27

Keypad address entry..................................................................................................... 28

Using an Airport as an address ...................................................................................... 31

Using Yellow Pages to find an address .........................................................................31

Using a Waypoint as an address ...................................................................................32

Activity Messages................................................................................................................... 32

Error Messages ...................................................................................................................... 32

Error message: GPS Access Restricted........................................................................ 32

Error message: GPS Signal Weak................................................................................. 32

Error message: Low battery (i88s and i58sr only)......................................................... 33

GPS Working Correctly................................................................................................... 33

Guidance Instructions ............................................................................................................35

Navigation guidance ....................................................................................................... 35

Non-GPS mode or Driving Directions ................................................................................... 36

Miss a turn? ............................................................................................................................ 36

7. Error Conditions...................................................................................................................36

Unable to reach server........................................................................................................... 36

TeleNav not available............................................................................................................. 36

8. Exiting TeleNav....................................................................................................................37

9. The TeleNav Web Site ........................................................................................................37

Personal Information .............................................................................................................. 37

Preplanning............................................................................................................................. 37

Customer Service................................................................................................................... 37

10. FAQ’s ...................................................................................................................................37

11. Customer Support ...............................................................................................................40

12. TeleNav Services Warranty ................................................................................................41

1. Welcome

TeleNav 2.2 exploits the integration of GPS position determination technology, the Java programming environment, and access to Nextel’s packet data network that are all built-in to the Motorola i730 mobile phone. TeleNav 2.2 offers basic free services, and two levels of enhanced paid subscription services.

The basic GPS services include:

1. A compass-like indicator presenting your direction of travel, location, and speed.

2. A display of the number of satellites in view that the GPS receiver is tracking.

3. The ability to mark your current location as a waypoint that you can label.

4. The ability to start and stop recording a track list of your location as you move around.

5. A viewer that allows you to see your current location relative to a selected waypoint, or a track you have created.

None of these basic GPS services require you to have Nextel packet data service. They all operate solely within the mobile phone itself.

The lower tier of paid GPS services include:

1. Maps of the area around your current location; a marked waypoint; or an address you

enter manually, or have previously entered. You can pan (adjust left/right or up/down) the map, or zoom in or out.

2. A suite of Locator functions that allow you to see your current location as an approximate

street address rather than latitude and longitude; allow you to send your location to someone else, or receive their location; and allow you to send your location to a the TeleNav website so someone with the access control PIN you provide can find you.

3. Driving directions from an origin address to a destination address that you specify.

TeleNav’s servers support each of these services via the Nextel packet data network.

The upper tier of paid GPS services include:

1. GPS navigation than punctually guides you turn-by-turn to any address in the Continental US. If you miss a turn or get off-track, it will calculate a new route for you. You can enter one or more destination addresses by calling an automatic voice recognition system, entering them on the TeleNav website, or keying them directly into the phone.

2. A Yellow Pages look up feature that allows you to find businesses or points of interest near your current location, around a waypoint, around an entered address, or around an airport.

TeleNav’s servers support each of these services via the Nextel packet data network.

2. Safety and Legal Notices

Please read this section carefully before using TeleNav

TeleNav will not accept any responsibility whatsoever for accidents resulting from failure to observe common sense precautions. Your personal judgment, traffic regulations, and common sense must always take precedence over any driving direction produced by TeleNav.

WARNING: Keep your eyes on the road.

It is your responsibility as the vehicle operator to keep your eyes on the road and be an alert driver at all times, ESPECIALLY when the vehicle is moving. The vehicle operator should not be distracted by the application displays, audible cues, or manually interacting with the controls. When you need to enter data on your phone using the keypad or study the display, please do so while the vehicle is parked, not while in motion. Should your ability to drive responsibly be decreased, please turn off the device.

WARNING: Install the equipment safely.

If you are using a phone mounting kit, make sure that it does not obscure your vision. You may wish to charge the phone while using TeleNav. If so, make sure the charging cable does not interfere with any of the vehicle controls.

WARNING: Drive safely and use common sense.

The vehicle operator’s personal judgment, traffic regulations, and common sense must always take precedence over the instructions provided by TeleNav.

It is your responsibility as the vehicle operator to drive safely, observe all traffic rules and above all use your own personal judgment while driving. If you feel that a route suggested by the navigation software instructs you to perform an unsafe or illegal maneuver, places you in an unsafe situation, or routes you into an area which you consider unsafe, do not follow the instructions.

3. Getting Started with TeleNav

There are 4 steps you will need to follow before your TeleNav service can become active:

STEP 1: Set-up your TeleNav account at http://www.telenav.com

Before you can begin using your TeleNav system, you will first need to establish your TeleNav account by going to www.telenav.com and clicking on the “SIGNUP” button. Proceed through the sign-up instructions as displayed on the website.

STEP 2: Contact Nextel to activate a packet data service plan.

The TeleNav application that resides within your phone communicates with the TeleNav servers using Nextel’s Total Connect packet data service. Contact Nextel’s Customer Service Dept. on a phone other than your Nextel phone at 1-800-639-6111, select option 1 followed by option 3, enter your Nextel

phone number, and then select option 1 followed by option 3 again (or dial 611 on your Nextel Phone and select the menu option for Nextel On-Line). Ask the service representative to add the Total Connect plan with a private IP address (not public) of your choice.

TELENAV USAGE RECOMMENDED PLAN

Less than 10 trips per month As-You-Go $2.99 1 60 to 100 trips per month 1 megabyte $9.99 300 to 500 trips per month 5 megabytes $19.99

STEP 3: Configure the GPS privacy settings in your phone so that the TeleNav Java application can obtain position fixes from the internal receiver.

STEP 4: Place the phone so it can receive the GPS satellite signals from space. These signals are very faint, and come from virtually every direction in the sky as the satellites move through their orbits. We recommend placing the phone in a mount above the dashboard of your vehicle for best results.

4. Installing TeleNav on Your Phone

NOTE: TeleNav comes preloaded on the Motorola i730. These instructions are provided in case TeleNav is removed from your phone and you would like to reload it.

STYLE: In this guide, boldfaced upper-case words like SELECT refer to labels that appear on the

display directly above an Option Key. If this guide asks you to press SELECT, it means you should find the Option Key below the SELECT label on the display, and press it.

NOTE: You need at least XXXX kilobytes (KB) of program memory and XXXX kilobytes (KB) of data space to install and use TeleNav on your phone. Follow these steps to install the program to your phone:

a.) Press the Menu key on your phone, and scroll down until Settings is highlighted. Then press

the SELECT key on the right. Then scroll down until Initial Setup is highlighted, and press the SELECT key again. If the year is not the current year, scroll down until Year is highlighted, then press CHANGE. Key in the correct value, and press OK. Then, press YES to confirm the change. Press BACK to return to the top level MENU.

b.) Press the Menu key on your phone and using the Navigation Key, highlight Java Apps, and

press SELECT. Then highlight Download Apps and press RUN. If you see INSTALL instead of RUN, press it to complete loader installation, and follow the guidance given on the screen. Then press RUN

c.) The downloader will then contact Nextel’s server to obtain the top-level catalog for your phone.

In this top-level catalog, highlight Free Applications or Free/Demo, and press SELECT. Again, the downloader will contact Nextel’s server to get the next catalog level. At the next level, highlight the Business and Productivity category, and press SELECT.

The As-You-Go plan is $2.99, and data usage is billed additionally at $0.05 per kilobyte. If you make more than 10 trips, the total

cost of this plan will likely exceed the cost of the Total Connect 1 megabyte plan.

Download Apps

APPLICATIONS

- Free/Demo

- New Purchases

- Re-Downloads

- Subscriptions OTHER

EXIT SELECT

•

Apps Categories

Business and Productivity

Games

Color

EXIT SELECT

d.) After the Business/Productivity catalog has loaded, highlight Auto GPS Nav Service -

TeleNav 2.2 in the list of applications, and press SELECT. (If a newer version is available, select it, and consult the TeleNav website for an up-to-date user guide.) Next, the TeleNav application details are presented. After reading the product description, press GET IT.

Free/Demo Apps

A Auto GPS Nav Service - TeleNav

TeleNavTrack

EXIT SELECT

Note: Data and program sizes shown above are not the actual values – please consult the phone display.

e.) Wait while TeleNav downloads to your phone. This may take 1 to 2 minutes. Once

downloaded, you will see a screen with further instructions. Please read the instructions carefully. When you’re done, press EXIT.

f.) Highlight TeleNav and press INSTALL. As the TeleNav software installs, a check mark

appears to the left of each row on the display. When installation is complete, press DONE and you will be taken back to the main MENU.

If during the installation process the phone reports that it does not have enough space to install TeleNav, you may have to remove one of the other Java programs to create space for TeleNav. You can remove any program except Java System and Download Apps. If you accidentally remove either of these, you must take your phone to a Nextel service center to have the software reinstalled!

To remove a program first highlight the program you want to delete. Then press the Menu key, and select Deinstall to remove the program. Follow the steps on the screen until the program has been removed then repeat steps d-f above.

5. GPS Privacy

Your phone restricts access to its GPS location data. The phone’s GPS receiver can be in one of three modes: 1) Restricted, 2) Unrestricted or 3) By Permission. To allow TeleNav to access the GPS data requires changing the Privacy Settings in two places.

First, press the Menu key, select GPS and then from the GPS menu, select Privacy. In the Privacy menu, scroll down until By Permission is highlighted, and press SELECT. A check mark should appear as shown below on the right. Then, press EXIT to return to the main menu.

Second, you have to change the TeleNav application privacy setting so that it is one of the applications that has Permission as described above.

1. To do this press the Menu key and then select Java Apps.

2. Once in the Java Apps menu highlight TeleNav and press the RUN soft key.

3. Because the phone has not tested the Privacy Settings for TeleNav before, it will challenge this action, and ask if you want to grant permission. You should press GRANT. Then, it will ask you if you want to grant access always, so press YES.

Because the TeleNav application was “suspended” by this security challenge, after you press YES in response to the “Always Grant” question, the following screen will appear.

At this point, you should press RESUME. Future invocations of the TeleNav application only require you to press the Menu key, select Java Apps, highlight TeleNav, and press RUN.

If later on you want to block TeleNav’s access to GPS location fixes, you will have to change the Privacy Setting to “Restricted”.

6. Using TeleNav

Launching the Application

To launch TeleNav on your phone, press the Menu key, scroll down using the Navigation Key until Java Apps is highlighted and press SELECT. In the Java Apps menu, scroll down until TeleNav is

highlighted, and press RUN.

After selecting TeleNav, the banner screen will appear for a few seconds.

Logging In

If you choose to use any of the lower or upper tier paid services, you will be asked if you have a TeleNav account and PIN. If you have already created a TeleNav account click YES, but if not, click NO; and go to www.telenav.com using a PC-based Web browser to create an account.

If you already have Total Connect, click YES, but if you do not, order Total Connect -- see the GETTING STARTED section above for ordering details.

Next you must agree to the TeleNav terms of use and software license by pressing YES.

The next screen will collect the same account number and PIN you provided when registering for TeleNav services at www.telenav.com

. Your account number MUST be the same as your Nextel phone number with area code so that when you call the Voice Address Input System you will not need to type in the account number. After you have entered the account number, use the Navigation Key to move the cursor down to the PIN entry field. When you have finished entering your PIN, press the OK soft key to proceed.

NOTE: If after you press OK, the TeleNav application indicates that it cannot

reach the TeleNav servers, the most likely reason is that your Nextel packet data service plan is not yet active. If the application reaches the TeleNav servers, the server will cause your phone to remember the account information so that you will not need to enter it again.

NOTE: If your TeleNav account is expired, you will be notified at this point, and will be directed to go to www.telenav.com

to extend your service agreement. You will not be able to progress beyond this point until your account is returned to current status. You may also see an important message from us regarding upgrades, scheduled downtime, pending account expiration, etc.

Main TeleNav Menu

After the application launches, you will be taken to the TeleNav™ Menu. This menu packages the free basic services, the lower tier paid services, and the upper tier paid services. It also provides access to user Preferences where you can set the system of units and tracking record interval. Highlight your choice, and press OK.

TeleNav (TM) Menu

GPS basic

GPS plus

TeleNav

Preferences

EXIT OK

GPS Basic (free services)

If you select GPS basic from the main menu, you will be taken to the next lower level menu. You can make a choice by highlighting the item, and press OK. Otherwise, press BACK to return to the main menu. The submenu item shown as Record Track starts recording a track, and then the menu item changes to End Track.

GPS Basic

Compass

View waypoint

View track

Record track

BACK OK

Compass

If you select Compass from the submenu, you will see a lower level menu with the options of View Compass, and Sats in View.

Compass

View compass

Sats in view

BACK OK

+ 28 hidden pages
