Telenav Boost Mobile Supported Devices User Manual v3.7

TeleNav v3.7.86

Auto GPS Navigation for Boost Mobile i285, i415, i455, 730, i830, and i860 Java/GPS Phones

User’s Guide

©2003-5 Televigation, Inc. All rights reserved. TeleNa v is a re giste red tr ademar k of Te leviga tion, Inc. B oost Mobi le is a registered trademark of Nextel Communications, Inc. Nextel is a registered trad emark of Nextel Communications, Inc. All other trademarks or registered trademarks are acknowledged as the exclusive property of their respe ctive owners.

All rights reserved. No part of this manual may be reproduced, transmitted, copied, or stored in any storage medium, for any purpose, without prior written consent from Televigation, Inc. Televigation, Inc. hereby grants the right to download one copy of this manual onto a hard drive for personal use. This manual is copyrighted and contains proprietary information that is subject to change without notice. For more information visit www.telenav.com.

Table of Contents

1. Welcome................................................................................................................................5

2. Safety and Legal Notices......................................................................................................5

3. The Handset Control Keys....................................................................................................6

4. Installing TeleNav on Your Phone ........................................................................................6

5. Access Permissions..............................................................................................................7

GPS Privacy............................................................................................................................. 7

Auto Invocation Permissions ...................................................................................................8

6. Using TeleNav.......................................................................................................................8

Launching the Application........................................................................................................8

Logging In................................................................................................................................. 9

Initial Content Loading...................................................................................................... 9

TeleNav Main Menu...............................................................................................................10

GPS Tools ..............................................................................................................................10

Compass .........................................................................................................................10

Mark waypoint.................................................................................................................11

View waypoint .................................................................................................................11

Maps .......................................................................................................................................12

Friend Finder ..........................................................................................................................13

Find Friend(s)..................................................................................................................13

Where Am I......................................................................................................................14

Send GPS->Friend .........................................................................................................15

Send GPS->Website ......................................................................................................16

Block Requests...............................................................................................................16

Refresh Requests ...........................................................................................................16

Edit Friend List.................................................................................................................16

Locator Help....................................................................................................................17

GPS Navigation......................................................................................................................17

Driving Directions from a Different Origin...................................................................... 18

GPS Origin Refinement..................................................................................................18

GPS Guidance................................................................................................................18

Audible Messages...........................................................................................................18

Miss a turn?..................................................................................................................... 18

Biz Finder................................................................................................................................19

Search Point....................................................................................................................19

Category Search .............................................................................................................20

Business Name Search..................................................................................................21

Picking a Business..........................................................................................................21

Preferences............................................................................................................................21

Address Entry.........................................................................................................................22

Voice Address Input........................................................................................................22

Web address entry..........................................................................................................23

Address entry from the phone........................................................................................24

Voice Call.........................................................................................................................24

New City/State.................................................................................................................24

Street Name Input...........................................................................................................25

Address validation...........................................................................................................25

Using an Airport as an address......................................................................................25

Zip Code..........................................................................................................................26

Using Biz finder to find an address.................................................................................26

Using a Waypoint as an address ...................................................................................26

Guidance Instructions ............................................................................................................26

Navigation guidance.......................................................................................................27

Non-GPS mode or Driving Directio ns............................................................................28

Activity Messages...................................................................................................................28

Taking an Incoming Call........................................................................................................28

7. Personalizing.......................................................................................................................28

8. Error Conditions...................................................................................................................29

Unable to reach server...........................................................................................................29

TeleNav not available.............................................................................................................29

GPS Access Restricted .........................................................................................................29

GPS Signal Weak ..................................................................................................................29

Low battery.............................................................................................................................29

9. Exiting TeleNav ...................................................................................................................29

10. The TeleNav Web Site........................................................................................................30

Account Management............................................................................................................30

Personalization.......................................................................................................................30

Preplanning.............................................................................................................................30

Customer Service...................................................................................................................30

11. FAQ’s...................................................................................................................................30

12. Customer Support ...............................................................................................................32

13. TeleNav Services Warranty................................................................................................32

1. Welcome

TeleNav™ 3.7 utilizes the integration of GPS position determination technology, the Java™ programming environment, and access to Boost Mobile’s packet data netwo rk that are all built-in to the Motorola i 710, i730, i733, i736, and i830 mobile phones. TeleNav 3 .7 offers basi c free services, and o ne level of enhanced p aid subscription services.

The free services (GPS Tools) include:

1. A compass-like indicator presenting your direction of travel, location, and speed.

2. The ability to mark your current location as a waypoint that you ca n label.

3. A viewer that allows you to see your current location relative to a select ed waypoint, a nd to navigate relative to that selected waypoint.

None of these basic GPS services require you to have Boo st Mobile packet data service. They a ll operate sol ely within the mobile phone itself.

The paid TeleNav GPS services include all basic service s and the additiona l services noted be low:

1. GPS navigation than punctually guides you turn-by-turn to any destination address in the Continental

US. If you miss a turn or get off-track, TeleNav will calculate a new route for you. You can enter one or more destination addresses by calling an automatic voice recognition system, entering them on the TeleNav website, or keying them directly into the phone. Optionally, the user can in put a remote origin and receive Driving Directions from that origin address t o a selected de stination address.

2. A Biz Finder look up feature that allows you to find businesses or points of interest near your current

location, around a waypoint, around an entered add ress, or around a n airport. You can call the business first to check availability of an item, or get a re servation, and then navigate to it; or you can save the address for use later in the day.

3. Maps of the area around your current location; a marked waypoint; or an address you enter manually,

or have previously entered. You can pan (adjust left/right or up/down) the map, or zoom in or out. You can also mark a point under the cursor as a waypoi nt.

4. A suite of Locator functions that allow you to: a) see your current location as an approximate stre et

address rather than latitude and longitude; b) send your locatio n to a friend; c) reque st and receive t he locations of one or more friends and d) send your location to the TeleNav website so someone with the access control PIN you provide can find you.

TeleNav’s servers support each of these services via the Boost Mobile packet data network.

2. Safety and Legal Notices

Please read this section carefully before using TeleNav

Televigation will not accept any responsibility whatsoever for accidents resulting from failure to observe common sense precautions. Your personal judgme nt, traffic regulations, and common sense mu st always take pre cedence over any driving direction produced by TeleNav.

WARNING: Keep your eyes on the road.

It is your responsibility as the vehicle operator to keep your eyes on the road and be an alert driver at all times, ESPECIALLY when the vehicle is moving. The vehicle operator should not be distracted by the application displays, audible cues, or manually interacting with the controls. When you ne ed to enter dat a on your phone u sing the keypad or study the display, please do so while the vehicle is parked, not while in motion. Should your ability to drive responsibly be decreased, please turn off th e device.

WARNING: Install the equipment safely .

If you are using a phone mounting kit, make sure that it does not obscu re your vision. You m ay wish to charge the phone while using TeleNav. If so, make sure the charging cabl e does not interf ere with any of the vehicl e controls.

WARNING: Drive safely and use common sens e.

The vehicle operator’s personal judgment, traffic regulation s, and common se nse must alway s take precedence over the instructions provided by TeleNav.

It is your responsibility as the vehicle operator to drive safely, observe all traffic rule s and above all use your own personal judgment while driving. If you feel that a ro ute suggested by the n avigation softwa re instructs you to perform an unsafe or illegal maneuver, places you in an unsafe situation, or routes you into an area which you consider unsafe, do not follow the instructions.

3. The Handset Control Keys

Placement of the control keys varies slightly depen ding upon the sp ecific handset model.

Left Option Ke

Menu Key

OK Key

Send Key

Right Option Ke

4-way Navigation Key

End/Home Key

NOTE: In this guide, boldfaced upper-case words like SELECT refer to labels that appear in the lower left or lower right corner of the phone’s display directly above an Option Key. If this guide asks you to press SELECT, it means you should find the Option Key below the SELECT label on the display, and press it.

TeleNav 3.7 is operated using the Option Keys. If you are to press the OK key shown above, it will be expressly called the OK key.

4. Installing TeleNav on Your Phone

NOTE: There are four variants of TeleNav 3.7. One ve rsion is targete d to hand sets like t he i73 0 and i830 h ave medium sized primary screens, and a secondary screen on the outside of the cover. Another version is targeted to handsets with a single medium size screen. A third version is targeted to handsets with a large primary screen, like the i850 and i860, and also have an external screen. A fourth version is designed specifically for the i285. The i285 version does NOT have the map feat ures describe d herein.

Follow these steps to download the TeleNav pro gram to your phone: a) Launch the WAP browser on your phone. To do this, press the MENU key and then highlight the WEB

entry, and press the OK button. b) Select 'Downloads & Services' c) Select 'Application - download' d) Select 'Browse' or 'Search' to find TeleNav e) Go to the app detail screen and follow through with a pu rchase f) Exit the WAP browser by holding down the MENU key, and selecting EXIT BROWSER g) From the main screen, press the MENU key h) Select 'Java Apps' from the menu i) Select 'Download' or 'Download Apps' j) Select 'New Purchases' k) Find TeleNav 3.7 and then click on 'Get it' l) Wait while TeleNav downloads to your phone. This may take 1 to 2 minutes. m) Once TeleNav is downloaded, you will see a screen with further instructions. Please read the instructions

carefully, and then press EXIT. Follow these steps to install the TeleNav Java progra m: a) From the main screen, press the MENU key, scroll down until Java Apps is highlighted and press the OK

key, or the Option key labeled “Select”. This opens the Java Apps folder. b) Highlight TeleNav 3.7 and press the OK key or the Option key labeled “Install” to start software

installation. c) As the TeleNav software installs, a ch eck mark appears to the left of each row on the display. When

installation is complete, press DONE and you will be taken back to the main Menu. If during the installation process the phone repo rts that it does not h ave enough space to in stall TeleNav, you

may have to remove one of the other Java programs to create space for Te leNav. You can rem ove any program except Java System.

NOTE: If you accidentally remove Java System, you must take yo ur phone to a Boo st Mobile service center to have the software reinstalled!

To remove a program, highlight the program you want to unin stall, press the Menu key, highlight Deinstall (or Remove) and press the OK key or the Option key labeled “Select” to remove the program. You will be asked to confirm the removal. Follow the steps on the screen u ntil the program has b een removed then perform t he above steps.

5. Access Permissions

GPS Privacy

Your phone restricts access to its GPS location data. Th e phone’s GP S receiver can be in one of three mod es: 1) Restricted, 2) Unrestricte d or 3) By Permission. To allow TeleNav to acce ss the GPS data may requ ire changing the Privacy Settings.

First, press the Menu key, highlight GPS (or the satellite icon) and press the OK key. (If you do not find it in the first page of Menu items, select MORE to expose more menu entries). From the GPS menu, se lect Privacy, and pres s the OK key, or the Option key labeled “Select”. In the Priv acy menu, scroll down until Unrestricted or By

Permission is highlighted, and press the OK key , or the Option key labele d “Selec t”. Then, press BACK twice to return to the main screen. “Unrestricted” means that a ny application can access GPS data, and “By Permission ” means that only those applications you allow to do so can acce ss GPS data. We recomm end setting the cont rol to By Permission.

Second, if you set the Privacy control to By Permission, you have to gra nt the TeleNav applicatio n access to the GPS data. This activity only occurs the first time you use TeleNav after changing the privacy setting to By Permission.

1. To do this press the Menu key and then select Java Apps, and press the OK key or the Option key that

reads “Select”..

2. Once in the Java Apps menu highlight TeleNav 3.7 and press the OK key, or the Option key that reads

“Run”.

3. Because the phone has not tested the Privacy Settings for TeleNav before, it will challenge this action, and

ask if you want to grant permission. You should press GRANT. Then, it will ask you to chose from three

options, highlight ALWAYS, and press the OK key.

4. TeleNav will then auto-resume so that the handset system can present its request for Auto Invocation

permissions.

Future invocations of the TeleNav application only requi re you to press the Menu key, select Java Apps, highl ight TeleNav, and press the OK key. You may wi sh to use the Personali ze feature of your phone to promote TeleNav to one of the option keys as described in Section 9.

Auto Invocation Permissions

As explained above, TeleNav resumes after you de al with the GPS pri vacy issues, and will then ask you about Auto Invocation permission. This feature allows TeleNav’s servers to awak en TeleNav even though it is turned off so that it can report your location to a requestor t o whom you have granted location a ccess. If you want thi s capability to work, you should GRANT this permission ALWAYS.

6. Using TeleNa v

Launching the Application

To launch TeleNav on your phone: press the Menu key, scroll until Java Apps (or the Java Apps icon) is highlighted, and press the OK key or the Option key that reads “Select”. In the Java Apps menu, highlight TeleNav (or the TeleNav icon), and pre ss the OK key or the Option key that reads “Run”. From this point on in this guide, key presses refer to the Option Keys below the scre en labels bea ring the key functional names.

After starting TeleNav, the banner screen will appear for a few seconds. The first time TeleNav is used, the next screens will explain what it is, and how to get signed u p for TeleNav service.

Logging In

During first use, you must agree to the TeleNav software license and terms of use by pressing YES.

NOTE: If after you press OK, the TeleNav application indicates that it

cannot reach the TeleNav servers, the most likely reason is that your Boost Mobile Data Access/Total Connect packet data service plan is not yet active. If the application reaches the TeleNav servers, the server will cause your phone t o store the account inf ormation so that you will not need to enter it again.

NOTE: If your TeleNav account is expired, you will be notified at this point, and will be directed to go to www.telenav.net to extend your service agreement. You wil l not be able to progress b eyond this point until y our account is returned to current status. You may al so see an impo rtant message from Tele Nav regarding up grades, scheduled downtime, pending account expiration, et c.

Initial Content Loading

During your first time use of TeleNav subscription servic es, it will be necessary for the handset to obtain the audible and graphical conte nt needed to build the displays and produce the audible messages you wil l hear. The follo wing Alert screen will advise you this is about to take place.

Press Done to start the content download and installation process. From time to time, TeleNav may update this content, and will advise you

accordingly.

The Boost Mobile icon and “where you at” logo shown here is a service mark of Boost Mobile.

TeleNav Main Menu

After the application launches, you will be taken to the TeleNav Home menu. This menu packages the free basic se rvices unde r GPS Tools. Except for Preferences, the rest of the services require a TeleNav subscription, and Boost Mobile Data Access/Total Connect packet data service. Highlight your ch oice, and press OK.

You EXIT TeleNav from this menu screen. If you are elsewhere in the TeleNav application, press BACK until you see this screen, or p ress MENU, and select TeleNav Home to return to this screen. To avoid inadvertently leaving TeleNav, you must confirm your desire to exit by pressing YES on the exit confirmation screen.

GPS Tools

None of the GPS Tools require Boost Mobile packet data service or a TeleNav subscription. If you select GPS Tools from the main menu, you will be taken to the GPS Tools submenu. You can make a choice by highlighting th e item, and pressing OK. Otherwise, press BACK to return to the main menu.

Compass

If you choose Compass, you will see a display similar to a nautical compass, but more correctly it actually displays course over gr ound, the direction you a re traveling if you are moving. The screen also provides current latitude, longit ude, and speed. Using the main menu Preferences, you can select the f ormat of the speed as mi les per hour or kilometers per hour. Press BACK to return to the GPS basic submenu.

If no GPS data is available, “No GPS” appears inste ad of latitude and long itude. Otherwise, a GPS satellite count indicator occupies the area below t he speed value. Add three (3) to the number of bars shown to determine the number of satellites being tracked by the GPS receiver. When the indicator shows that 7 satellites are being tracked (which is good), the receiver may actually be tracki ng even more (which is even better).

Marking a Waypoint. The left MARK Option Key allows you to mark a waypoi nt (as described bel ow) dire ctly from the Compass view.

Color variations in the screen shots are due to the different emulators used.
