Telefunken DPF 9332 User Guide
DIGITAL PHOTO FRAME OPERATING INSTRUCTIONS
TELEFUNKEN DPF 9332 DIAMOND
I. Learn about and install your frame .................................................................. 2
1. Box contents ...........................................................................................................2
2. Frame diagrams.......................................................................................................3
3. Remote control........................................................................................................3
4. Installation ...............................................................................................................4
II. 1BUse your frame............................................................................................... 4
ENGLISH
1. Selecting a language ...............................................................................................4
2. “ECO LOGIC” mode ................................................................................................4
3. Reading a memory card or a USB key.....................................................................5
III. 2BSelecting the type of files to play ..................................................................... 5
1. Internal memory/Removable media..........................................................................5
2. Photos.....................................................................................................................6
3. Movies.....................................................................................................................6
4. Music ......................................................................................................................6
5. Calendar..................................................................................................................7
6. Copying photos, movies or music to the internal memory or Memory Card..............7
7. Deleting photos .......................................................................................................8
8. Sorting photos.........................................................................................................8
IV. 3BWI-FIP®............................................................................................................ 9
1. Wi-Fi Setup..............................................................................................................9
2. Accounts Configuration .........................................................................................11
3. Applications over Wi-Fi ..........................................................................................13
V. 4BSettings ....................................................................................................... 16
VI. 5BConnecting to a computer ............................................................................ 20
VII. 6BSafety instructions ........................................................................................ 21
VIII. 7BWarranty ...................................................................................................... 22
IX. 8BSpecifications............................................................................................... 24
Non contractual document subject to change in case of typographical errors (Mktg0810) COPYRIGHT SOPEG 2010
The manufacturer reserves the right to modify the product specifications without notice.
1
ENGLISH
PRELIMINARY NOTICE
During the first use, the animated demo is played. To exit and go to
the frame functions, simply press SETUP
on the remote control, or
press and hold the ◄ (left) key on the digital frame for 3.5 second to
exit the demo mode.
I. Learn about and install your frame
Thank you for your recent purchase of a TELEFUNKEN “DIAMOND Series” digital photo frame. Before using
your device, please consult these operating instructions and keep them so you may refer to them later.
1. Box contents
- 1 digital photo frame
- 1 AC adaptor
- 1 remote control
- 1 dust cloth
- 1 quick start guide
2
Non contractual document subject to change in case of typographical errors (Mktg0810) COPYRIGHT SOPEG 2010
The manufacturer reserves the right to modify the product specifications without notice.
2. Frame diagrams
ENGLISH
3. Remote control
All functions can be accessed with the remote control. Press the following keys to access the functions:
Key Function
▲
◄
▼
►
ENTER Confirm your selection or switch modes
EXIT Exit current menu and return to previous menu
STOP Stop file playback (photo, music or movie) and return to main menu
Navigation up in the menus
Navigation left in the menus and skip to the previous file (photo, music or movie)
Navigation down in the menus
Navigation right in the menus and skip to the next file (photo, music or movie)
Switch the digital photo frame on or to standby mode
Mute/unmute sound, in mute mode the mute icon is displayed
Increase volume, the volume level is displayed
(COPY/DEL) Access copy, delete and sort functions (only in main menu)
(ROTATE) Rotate photo clockwise 90°
Enlarge image, press repeatedly to cycle through zoom modes x2, x4, x8 and x16; press again
to return to normal size
Decrease volume, the volume level is displayed
SETUP Access setup menu (Settings) directly
Non contractual document subject to change in case of typographical errors (Mktg0810) COPYRIGHT SOPEG 2010
The manufacturer reserves the right to modify the product specifications without notice.
3
ENGLISH
4. Installation
- Take your frame and its accessories out of their packaging.
- Remove the plastic film protecting the front of the frame.
- Pull the plastic tab protecting the contacts in the remote control.
- Stand the frame in the desired location, pulling the adjustable stand towards you
- Connect the electrical cord to the frame in the space provided.
- Plug your frame into an outlet. Your frame will start up automatically.
(see diagram above).
II. 1BUse your frame
1. Selecting a language
During the first use, the animated demo is played. To exit and go to
the frame functions, simply press the SETUP key on the remote.
The language selection screen then appears.
- Select your language using the arrow keys on the
remote control, then press ENTER.
Once you have selected your language, the frame is ready for use.
Simply insert a memory card or flash drive to begin playback of your
pictures.
Caution: The animated demo is located in the folder named “DEMO”. You must delete it for the frame to
keep benefit of the 2 GB internal memory.
2. “ECO LOGIC” mode
ECO LOGIC mode combines 3 essential elements to reduce energy consumption by over 40% compared
to a standard frame:
- A LED screen, which uses less energy while improving picture quality;
- A low-energy and ‘Energy Star’-certified power adapter;
- A light sensor.
This sensor, on by default, will automatically turn off your picture frame at night and turn it on during the day.
You can deactivate the light sensor in your frame’s system settings menu.
4
Non contractual document subject to change in case of typographical errors (Mktg0810) COPYRIGHT SOPEG 2010
The manufacturer reserves the right to modify the product specifications without notice.
Caution: Depending on where you place the frame (for example, in furniture or under a shelf), there may not
be enough light to turn on the frame or it may unexpectedly turn off. To reactivate it, simply bring into bright
light for 2-3 seconds.
3. Reading a memory card or a USB key
If your frame is off:
- Insert your card or USB key in the space provided.
- Switch on your frame: The slideshow will automatically play the contents of your memory card
or USB key.
If your frame is on and playing the slideshow from the internal memory:
ENGLISH
- Your memory card is not automatically detected.
1. Press EXIT to exit the slideshow, the thumbnails will appear.
2. Press EXIT again to exit the internal memory and return to
the Photo menu.
3. Press ▼ to highlight USB or inserted memory card and
press ENTER to display the thumbnails on the media.
4. Press ENTER to display the selected photo in full screen
mode.
5. Repeatedly press ENTER to choose between Single, Slide with music and Slide photo only modes.
6. Press EXIT to exit the slideshow, the thumbnails will appear.
III. 2BSelecting the type of files to play
1. Internal memory/Removable media
If no media has been inserted, the slideshow from the internal memory will launch automatically whenever
the frame is turned on.
If there is a memory card or a flash drive inserted when the frame is turned on, the card’s content will be
played. In this case, you can switch between the card and the internal memory as follows:
- Keep pressing EXIT on your remote to go to the select media screen.
- Press ▲/▼ on the remote to select the media you want to play.
- Press ENTER to confirm.
Non contractual document subject to change in case of typographical errors (Mktg0810) COPYRIGHT SOPEG 2010
The manufacturer reserves the right to modify the product specifications without notice.
5
ENGLISH
2. Photos
- Press EXIT on your remote as many times as
necessary for the media selection screen to come up.
- Press ▲/▼ on the remote to select the media you
want to play.
- Press ◄/► to select Photo.
- Press ENTER to access the photos in thumbnail mode.
- Press ENTER again to start playback.
- Repeatedly press ENTER to choose between Single, Slide with music and Slide photo only
modes.
3. Movies
- Press EXIT on your remote as many times as necessary for the media selection screen to
come up.
- Press ▲/▼ on the remote to select the media you want to play.
- Press ◄/► to select Movie.
- Press ENTER to show the movie list.
- Press ENTER again to start playback of the first movie file or select with ▲/▼ to start playback
of the desired movie.
- During playback, press ▲/▼ to select previous or next movie, press ◄/► for fast rewind or
fast forward modes. Press
- Press ENTER key to pause, press again to resume.
- Press EXIT to exit the mode.
4. Music
/ to adjust the volume, or press MUTE to mute/unmute.
6
- Press EXIT on your remote as many times as necessary for the media selection screen to
come up.
- Press ▲/▼ on the remote to select the media you want to play.
- Press ◄/► to select Music.
- Press ENTER to show the music list.
- Press ENTER again to start playback of the first music file or select with ▲/▼ to start playback
of the desired title.
Non contractual document subject to change in case of typographical errors (Mktg0810) COPYRIGHT SOPEG 2010
The manufacturer reserves the right to modify the product specifications without notice.
- During playback, press ▲/▼ to select previous or next music. Press / to adjust the
volume, or press MUTE to mute/unmute.
- Press ENTER key to pause, press again to resume.
- Press EXIT to exit the mode.
5. Calendar
- Press EXIT on your remote as many times as necessary for the media selection screen to
come up.
- Press ◄/► to select Calendar.
- Press ENTER to enter the calendar preview screen, the slideshow automatically starts.
ENGLISH
- Press ENTER again to enter full screen mode, repeatedly press ENTER to toggle between
Single and Slide photo only modes. Press the ► or ◄ to skip to the next or previous photo.
- Press EXIT to exit the full screen mode.
Note:
If you have set the alarm, an alarm icon will show on the Calendar screen.
6. Copying photos, movies or music to the internal memory or Memory Card
Copy your photos, movies or music in the thumbnail mode
Using this method, you can copy all or a selection of photos, music
or movies and possibly resize photos to the frame’s resolution in
order to optimize internal memory capacity.
The procedure is similar for all file types sowe will describe it for
photos only.
- Copying photos
1. Press EXIT on your remote as many times as necessary for
the media selection screen to come up.
Non contractual document subject to change in case of typographical errors (Mktg0810) COPYRIGHT SOPEG 2010
The manufacturer reserves the right to modify the product specifications without notice.
7
