TeleEpoch M560 User Manual
1
Mobile Phone
User Guide
2
Table of Contents
1．Safety and Precautions ........................................................................ 3
2．Photo ID .............................................................................................. 4
3．Specifications ...................................................................................... 4
4．Essential Topics .................................................................................... 5
5．Getting Started .................................................................................... 6
6．Basic Operations .................................................................................. 7
7．Using the Menu ................................................................................... 8
7.1 Menu option list .................................................................................. 9
7.2 Messages ............................................................................................10
7.3 Phonebook .........................................................................................12
7.4 Games ................................................................................................12
7.5 Call History .........................................................................................13
7.6 Profile.................................................................................................14
8. Settings ................................................................................................14
8.1 Additional Functions ..........................................................................15
9．Operation of Input Method ................................................................16
Appendix I Common fault diagnoses ........................................................16
Appendix II Abbreviations and explanations ............................................ 17
3
1．Safety and Cautions
Switch off the mobile phone in the vicinity of chemical plants, gas stations and other locations
containing explosive objects.
Keep the mobile phone away from small children.
Switch off the mobile phone as instructed where signs are present.
Switch off the mobile phone before boarding planes and during flight.
Obey the local laws while driving. When hands free function is available, use the hands free
calling device to ensure safety. Park the car at the side of the road to make a call in emergency
situations only.
Take special care when using the mobile phone in the vicinity of such devices as pacemakers,
hearing aids and electro-medical equipment, which may be affected by the mobile phone.
When using other medical equipment, verify with suppliers and medical staff that the
equipment will not be affected,
There is no warranty or guarantee for accessories not produced by the original mobile phone
manufacturer.
Never attempt to disassemble the mobile phone. Opening the unit may void any warranty.
Recharging the mobile phone without the battery installed can damage the phone and create
a fire hazard.
Charge the mobile phone in a well-ventilated environment, and keep it away from flammable
or explosive objects.
To avoid demagnetization, keep the handset away from magnetic substances such as magnetic
discs or credit cards.
Keep the handset away from liquids. Remove the battery if the handset gets wet. Do not
attempt to use the mobile phone under these circumstances.
Avoid using the mobile phone in extreme temperature environments. Never leave the mobile
phone exposed directly to sunlight or in a extremely humid or dust filled environment.
Do not clean the handset with liquids or detergents.
Do not drop the handset or subject it to strong pressure or any other forms of abuse.
The original mobile phone manufacturer will not honor any warranties or guarantees if the
above instructions are not followed by the mobile phone user.
Please recycle the lithium-ion batteries or dispose of them properly. Do not dispose of the
batteries by throwing them into household waste.
4
2．Look and Feel
Model
Specification
V-Q3C
Dimension
110×63×13.9mm
Weight
110g
LCD resolution
1600*1200
Frequency
800MHz/1900MHZ
Contact capacity
500
SMS capacity
200 messages
Call history
20 each for missed, answered and dialed calls
Vibrate
Supported
Preset ring tone type
10 ring tones
Preset SMS ring tone
10 ring tones
Call time
Supported
Single key dial
Supported
Blacklist
Supported
Date and time display
Supported
Note：Picture is for reference purposes only.
3．Specification
5
Alarm／Calculator
Supported
Smart Input method
Supported
Receive/Send SMS
Supported
English input method
Supported
Incoming call display*
Supported
Call forward*
Supported
Call blocking*
Supported
Call waiting*
Supported
Voice message*
Supported
Note: Functions or services marked with ‘*’ are supported by this unit but require network services to fully
function.
4．Essential Topics
Communication control keys
The green ‘Answer Call’ key is used for answering a call, making a call (after a number has been
entered); or for dialing from the call history.
The red ‘On/Off’ key is used for ending a call (during dialing and communication state), or for exiting
menu under menu state to return to standby menu. Pressing and holding this key will switch the
phone on or off.
Functional keys and soft keys
Direction keys of up, down, left and right direction are used for browsing menus, lists, options or
content compiled.
Under standby mode, the up/down direction key is used to change the volume of the ring from
maximum to Zero. Right and left direction keys scroll thru Messages to Contacts, to Call History to
Profiles. Under standby state, the left soft key is a shortcut key for accessing main graphical menu.
The functions of the two soft keys depend on the mode and the functions that are being accessed.
The keypad
Keys from ‘0’ to ‘9’, and key ‘*’ and ‘#’ are used for dialing. (# and * automatically switch from text to
digit depending on the mode the phone is currently in.)
Inputting password, English letters, symbols etc. is accomplished by the QWERTY keyboard. See the
section on input method for further details.
Backlight
After the mobile phone is in standby for period of time (time length is set by the user), the phone will
turn off the screen backlight to save power. If the screen backlight goes out, you can press any key on
the phone’s keypad to turn on the backlight again.
Display icons
In standby, common icons on the top of the screen are as follows :
6
Signal strength received by the antenna
Alarm clock
There are unread messages
Battery level indicator (This icon indicates full battery).
Vibrate icon
Ring icon
Vibrate first then ring
Keypad locked
Missed call
Alert modes
There are multiple user-selectable tones available for text message and call notifications. Please
follow the paths below for selecting the modes and the specific tones for each type.
Text message alerts: For text message alerts, follow the path [Profiles], then choose one alert
mode from the list (General, Meeting, Outdoors, Indoors) -[Tone Set up]-[SMS Tone].
Call alerts and ringtones: Follow the [Profiles], then choose one alert mode from the list
(General, Meeting, Outdoors, Indoors) -[Caller Ring Tone]-and tone and OK.
Find contacts
This handset provides a way to search for phone number by first letter of a name. Highlight and select
‘Contacts’ under main, input the first letter of the contact’s name and the screen will display all
applicable records.
5．Getting Started
Charging your battery
A new battery must be fully charged before it is used for the first time.
To keep the battery functioning optimally, it is recommended that you occasionally discharge
the battery fully by consuming the power until the phone is switched off automatically.
During the course of charging, it is normal for the phone and the battery to heat up slightly.
The phone will automatically protect itself when battery temperature rises to control
temperature variation by extending the charging time.
The handset will give off an alert as the battery is running out. When the power has run out
the handset will be switched off automatically.
7
Note: Actual time of usage of the battery varies according to different operation modes and settings
of network base station. If you use the phone when battery is rather low, the phone may switch off
automatically.
Procedure for battery charging
Insert the charging plug into the Micro USB jack of the phone, then connect the charger to a
wall socket.
While the battery is charging, the battery symbol will gradually scan from right to left.
You may choose to charge the battery under power-off or standby state. If the phone is
charged under power-off state, it will start and display the graphic denoting that the unit is
‘Charging’.
When the battery is fully charged, charging operation stops automatically. The battery symbol
on the screen will maintain a graphic showing that the battery is full. At this time, please
unplug the charging plug.
Calls can be made while charging.
USB Charging
The phone may also be charged by plugging a cable with the micro-USB end to the phone and the
other end to a supported USB source for power such as a computer.
6．Basic Operations
Switching on
Pressing and holding the ‘on/off’ key in the standby state will switch on the phone. It will automatically
search the network as long as the phone has no password protection. After the phone has registered
on the network, the signal strength will be displayed at the top left corner of the screen. The phone is
now in the standby state and you can make or answer a call.
Your phone remains in a searching state if it fails to find the available network system.
If a password for the phone is required after it is switched on, please input the password, , then press
the right soft key for confirmation. After unlocking, the phone will display the signal strength.
Switching off
To switch off the phone, please press and hold the ‘on/off’ key for 2 seconds or more if the phone is in
the standby state. When the phone displays ‘power off’, the phone will switch off.
Warning: If you switch off the phone by removing the battery, you may lose stored information.
Making a call
Under standby state, input number directly via the keypad. In case of international number, please see
your local requirements to access international service or press alt ‘O’ until ‘+’ displays and then input
the number completely. Then press the ‘Call /Send’ key to make the call.
If you want to make a call to another city within the country, you’ll need to use a long-distance area
code.
To end a call, press the ‘on/off’ key. When a call is ended, the call timer stops and the text ‘Call ends’ is
displayed on the screen.
8
Saving a number by dialing
You may save the other party’s number in the contacts list (phonebook), or by dialing under standby
state. The number saving procedure of the former method is described in details in communication
phonebook menu. Specific steps for saving a number by dialing under standby state are as follows:
Input the other party’s phone number under standby state.
Press the left soft key for Options. You may highlight ‘save” then OK to save this number ”to
Phone” (the number is saved in the phone), to ‘Update records’ (add this number to an
existing contact), save this number in the phone.
Adjusting the volume during a call
During a conversation, you may press the up and down-direction key (on the side of the phone) to
adjust the volume of earpiece.
Answering a call
To answer a call, press the green ‘Answer Call’ key to answer the call directly. To reject a call,
press the red ‘On/Off’ key . The call will go directly to Voice Mail, if that service is active.
If you have subscribed to the caller ID service, then during the conversation the caller ID will
be displayed on the screen. If this number is already saved in the phonebook, then caller’s
name will also be displayed on the screen.
To end a conversation, press the ‘on/off’ key.
Note: If you have subscribed to the call forwarding services, incoming calls may be forwarded to the
specified number automatically.
Call Silencing
When ringing tone is enabled, you may press and hold the # key to select vibration mode, and back
again by pressing and holding the same key.
Recent call numbers
This handset will store the 60 most recent numbers in the call history. On standby screen, press the
‘Call control’ key to display the call history. You can press the up and down keys to view the called
numbers and press the ‘Call’ key to directly dial the selected number. You may also access the call
record menu to view the most recent call history.
Missed call
If there are missed calls, ‘Missed N Call(s)’ will be displayed on the main screen. You can access the call
history menu to view the record of the calls missed.
7．Using the Menu
The main menu has four options, Messages, Contacts, Call History and Profiles. By pressing the left
soft key, all 12 menu items can be viewed. Each set of menus is further divided into multi-item
sub-menus. Menu functions may let you set, check or change the phone’s various functional settings
to meet your personal requirements. Please refer to the following ‘Menu option list’ for selection of
the functions you require.
Press the direction keys to select from the menu. Press OK key or left soft key to enter the
9
sub-menu list of the selected menu. Then press up and down-direction key to select and the
Option
Brief Description
Messaging
Write SMS
Create message, preset message, continue edit
Inbox
200 total pieces for inbox, outbox and sentbox
Outbox
Sentbox
Draftbox
50 pieces in Draftbox
Templates
Commonly used phrases
Deferred
Drafts of messages
Settings
Delivery report, storage, validity period, auto
delete
Delete all
All, Inbox, Outbox, Sentbox, Draftbox
Voice mail
Edit number, connect to voice mail
Contacts
All contacts
Display all contacts.
Search Entry
Search contacts by name
Add new Entry
Add new contacts to the phone.
Delete
Delete call contacts in phone.
Memory Status
Check memory status of phone.
Game
Snake
Russia Block
Call History
Missed calls
Maximally display 20 pieces missed call
Received calls
Maximally display 20 pieces received call
Dialed call
Maximally display 20 pieces dialed call
Delete log
Delete Missed Calls, Delete Received Calls,
Delete Dialed Calls, Delete All
Call time
Last Call Time, Total Dialed, Total Received,
Reset All Time
Profile
General, Meeting,
Outdoors, Indoors
Settings
Call Setup
Time Reminder, Call Connect Notification, Blacklist,
Emergency Call
left soft key to confirm or enter into the lower-level menu.
Press the right soft key to return to higher-level menu. Press the ‘on/off’ key to exit the menu
directly and return to the standby screen.
In editing state (during texting or adding names, etc), the right soft key has deleting function.
Press it once to delete one character and hold it to delete all the input characters.
In options, ‘On’ or ‘Activate’ enables corresponding function and ‘Off’ or ‘Cancel’ disables
corresponding function.
7.1 Menu option list
10
Security
Setup
Phone lock, Keypad lock, History Lock, PhoneBook Lock,
Message Lock, Change Password,
Call History Lock
Enable/Disable
Security
Phonebook Lock
Off, 5 sec, 30 sec, 60 sec, 5 min
Setup
Message Lock
Enable/Disable
Change Password
Enable/Disable
Restore Factory
Setting
Enable/Disable
Phone Lock
Keypad Lock
Phone
Greeting
Disable/Enable
Setup
Speed Dial
Status, Single Key Dial
Clock Format
Digital 12, Digital 24
Language
Spanish/English
Phone info
Software Version, Hardware Version, Phone Number, MEID, ESN, PRL
Version, SID
Alarm（3 alarms in maximum ）
Calculator
Stopwatch
Calendar
World Time
Note: This menu structure only lists the main menu of this phone; for details please see the phone’s
software.
7.2 Messages
Text messaging is a network service. You may be required to subscribe to the service from your
network operator prior to sending and receiving text messages. Under standby status, you can use the
up-direction key to access the text message menu.
A message is sent to the messages center of the network, then to the targeted user by the network. If
the targeted user’s phone is off or out of network area, the network will store the message
temporarily.
When the phone receives a new text message, you will be prompted according to setting and the icon
will appear at the top of the main screen to indicate unread text message.
New SMS
You can create a text message in this menu. Every text message has a capacity of 160 characters.
Once the text has been entered, the following options are available, by pressing the left soft key.
Save and send: Send text message and save it to outbox.
Send: Send text message.
Save: Save text message to draft.
Send to many: Send text message to others (up to 10 numbers).
11
Insert template: Insert common phrase in the text message. It provides you with 10 common
phrases.
Insert Number
Deferred Send.
Exit
Voice Mail
Edit Number: Display the voicemail number you have set. You may also modify this number.
Connect to voicemail: Call the voicemail number that has been set.
Inbox
The Inbox is used for reading text messages received. In the inbox, the phone can store up to 50 text
messages. You may press up and down-direction key to browse the message list. Press the up and
down direction key to scroll the list. In the message reading mode, the following options are available.
Delete: Delete the text message you are currently reading.
Reply: Reply to the text message you are currently reading.
Forward: Forward the text message you are currently reading to others.
Use number
Outbox
The outbox is used for storing the text messages you have saved or are awaiting upload. It can store up
to 50 text messages.
Sentbox
The sentbox is used for storing the text messages you have sent.
Draftbox
After editing a new text message, choose “Save”. The message will be saved into the draft box. If the
message displays “No number”, it means there is no target party selected. If the message isn’t sent
successful, it will be saved to the “Drafts”.
Template
There are 12 common short phrases stored in the phone. You can add, then edit or delete your own
common phrases.
Deferred
Lists messages that have been deferred sending.
Settings
Delivery report: This is a message sending receipt. It’s used for indicating whether the message
is sent successfully or not.
Validity Period: 12 hours, 1 day, 1 week, 1 month, Maximum (sets the time that texts are
stored)
Auto Delete On/Off
Delete All
ALL: Delete all text messages stored in the outbox, inbox, sentbox, outbox
Loading...
