Tektronix WFM6100, WFM7000, WFM7100 Technical Reference

Download

Technical Reference

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP Specifications and Performance Verification

071-2291-00

This document applies to firmware version 3.0.X.

www.tektronix.com

Copyright © Tektronix. All rights reserved. Licensed software products are owned by Tektronix or its subsidiaries or suppliers, and are protected by national copyright laws and international treaty provisions.

Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication supercedes that in all previously published material. Spec ifications and price change privileges reserved.

TEKTRONIX and TEK are registered trademarks of Tektronix, Inc.

Contacting Tektronix

Tektronix, Inc. 14200 SW Karl Braun Drive P.O. Box 500 Beaverton, OR 97077 USA

For product information, sales, service, and technical support:

H In North America, call 1-800-833-9200. H Worldwide, visit www.tektronix.com to find contacts in your a rea.

Warranty 2

Tektronix warrants that this product will be free from defects in materials and workmanship for a period of one (1) year from the date of shipment. If any such product proves defective during this warranty period, Tektronix, at its option, either will repair the defective product without charge for parts and labor, or will provide a replacement in exchange for the defective product. Parts, modules and replacement products used by Tektronix for warranty work may be new or reconditioned to like new performance. All replaced parts, modules and products become the property of Tektronix.

In order to obtain service under this warranty, Customer must notify Tektronix of the defect before the expiration of the warranty period and make suitable arrangements for the performance of service. Customer shall be responsible for packaging and shipping the defective product to the service center designated by Tektronix, with shipping charges prepaid. Tektronix shall pay for the return of the product to Customer if the shipment is to a location within the country in which the Tektronix service center is located. Customer shall be responsible for paying all shipping charges, duties, taxes, and any other charges for products ret urned to any other locations.

This warranty shall not apply to any defect, failure or damage caused by improper use or improper or inadequate maintenance and care. Tektronix shall not be obligated to furnish service under this warranty a) to repair damage resulting from attempts by personnel other than Tektronix representatives to install, repair or service the product; b) to repair damage resulting from improper use or connection to incompa tible equipment; c) to repair any damage or malfunction caused by the use of non-Tektronix supplie s; or d) to service a product that has been modified or integrated with other products when the effect of such modification or integration increases the time or difficulty of servicing the product.

THIS WARRANTY IS GIVEN BY TEKTRONIX WITH RESPECT TO THE PRODUCT IN LIEU OF ANY OTHER WARRANTIES, EXPRESS OR IMPLIED. TEKTRONIX AND ITS VENDORS DISCLAIM ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. TEKTRONIX’ RESPONSIBILITY TO REPAIR OR REPLACE DEFECTIVE PRODUCTS IS THE SOLE AND EXCLUSIVE REMEDY PROVIDED TO THE CUSTOMER FOR BREACH OF THIS WARRANTY. TEKTRONIX AND ITS VENDORS WILL NOT BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES IRRESPECTIVE OF WHETHER TEKTRONIX OR THE VENDOR HAS ADVANCE NOTICE OF THE POSSIBILITY OF SUCH DAMAGES.

General Safety Summary v...................................

Service Safety Summary vii....................................

Environmental Considerations ix...............................

Preface xi...................................................

Related User Documents xi..........................................

Related Reference Documents xii......................................

Specifications 1--1.............................................

Electrical Specifications 1--1...........................................

Physical Specifications 1--39............................................

Certifications and Compliances 1--40.....................................

Supported Input Formats and Allowed References 1--42......................

Alarms 1--45.........................................................

Performance V erification 2--1...................................

Test Records 2--3....................................................

Test Record -- Function Tests 2--3.......................................

Test Record -- All Instruments 2--5......................................

Test Record -- Tests for SD-Equipped Instruments Only 2--7..................

T e s t R e c o r d -- O p t i o n C P S o n l y 2 -- 9.....................................

Test Record -- Options AD and DDE only 2--10.............................

Test Record -- Option DS only 2--15......................................

Incoming Inspection 2--19.......................................

Required Equipment 2--19..............................................

Incoming Inspection Tests 2--21.........................................

Video and General Performance Verification Procedures 2--41.........

Required Equipment 2--41..............................................

Instrument Tests 2--43.................................................

Tests for SD-Equipped Instruments Only 2--60..............................

Tests for Option-CPS-Equipped Instruments Only 2--74......................

Signal Source Characterization for E ye Signal Bandwidth 2--84................

Audio Performance Verification Procedures 2--87....................

Required Equipment 2--87..............................................

Tests for Waveform Monitors Equipped with Audio Options 2--88.............

Additional Tests for Instruments equipped with Options AD and DDE 2--97......

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

Table of Contents

List of Figures

Figure 1--1: VM5000 HD Frequency Response display 2--47...........

Figure 1 --2: Wiring diagram for LTC input/Ground Closure cable 2--55.

Figure 1--3: VM5000 SD Frequency Response display 2--63...........

Figure 1--4: Trigger polarity positive 2--67..........................

Figure 1--5: Trigger polarity negative 2--68.........................

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

List of Tables

Table of Contents

Table 1--1: SDI Input Waveform Vertical Characteristics 1--1........

Table 1--2: Composite Analog Input Waveform Vertical

Characteristics 1--3........................................

Table 1--3: Composite Analog Inputs A and B Physical Layer 1--3....

Table 1--4: Waveform Sweep (Horizontal) Deflection 1--5............

Table1--5:EyePatternDisplay 1--6..............................

Table 1--6: Jitter Display 1--8...................................

T able 1--7: Component V ector Mode 1--10..........................

Table 1--8: Waveform Mode Filter Characteristics 1--10..............

Table 1--9: SDI Lightning and Diamond Modes 1--11................

Table 1--10: Data Mode 1--12....................................

Table 1--11: Composite Vector Mode 1 --12..........................

Table 1--12: Arrowhead mode

(NTSC/PAL composite limit display) 1--13......................

Table 1--13: Bowtie mode 1-- 13...................................

Table 1--14: Timing Display 1--14.................................

Table 1--15: Picture Mode 1--15..................................

Table 1--16: Signal Level / Cable Length Detector 1--15..............

T able 1--17: Data error detection

(EDH / Status, Under STATUS Button) 1--16....................

Table 1--18: ANC Data and ARIB 1--17............................

Table 1--19: Audio Bar Displays 1--18.............................

Table 1--20: Audio Bar and Lissajous/Surround Display 1--21........

Table 1--21: AV Delay display (Option AVD) 1--22...................

Table 1--22: AES Audio Inputs 1 1--22............................

Table 1--23: AES Audio Outputs

(alternate function on second set of inputs) 1 1--23...............

Table 1--24: Embedded Audio Extraction 1--25.....................

Table 1--25: Analog Audio Inputs 1 --25............................

Table 1--26: Analog Audio Outputs 1--27...........................

Table 1--27: Dolby Digital (AC--3) Compressed Audio Monitoring

(Opt. DDE) 1--28...........................................

Table 1--28: Dolby E and E xtended Dolby Digital (AC--3)

ompressed Audio Monitoring (Opt. DDE) 1--29..................

Table 1--29: Picture Monitor Outputs (VGA Pix Mon) 1--29...........

Table 1--30: LCD display 1--31...................................

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

iii

Table of Contents

Table 1--31: External XGA Output (EXT DISPLAY) 1--31............

Table 1--32: LTC Time Code Input / Ground Closures 1--31..........

Table 1--33: VITC Decoding 1--32................................

Table 1--34: Serial Digital Video Interface (Input A, Input B) 1--32.....

Table 1--35: Serial Video Output (Serial Out/SDI PixMon) 1--34.......

Table 1--36: External Reference 1--35..............................

T able 1--37: Ethernet 1--36......................................

Table 1--38: USB 1--36..........................................

T able 1--39: Remote Port 1--37...................................

Table 1--40: Power Source 1--38..................................

Table 1--41: Miscellaneous 1--38..................................

Table 1--42: Physical Characteristics 1--39.........................

Table 1--43: Environmental Performance 1--39......................

Table 1--44: Certifications and compliances 1--40....................

Table 1--45: 25 Hz and 50 Hz Frame and Field rates 1--42............

Table 1--46: 59.94 Hz, 23.98 Hz, and 29.97 Hz

Frame and Field rates 1--42..................................

Table 1--47: 24 Hz, 30 Hz, and 60 Hz Frame and Field rates 1--43......

Table 1--48: Supported Standards 1--44............................

Table 1--49: Common Alarms 1--45...............................

T able 1--50: HD Specific Alarms

(WFM7100, WFM7000 Opt. HD) 1--46.........................

Table 1--51: SD Specific Alarms 1--47.............................

Table 1--52: Composite Specific Alarms (Opt. CPS) 1--47.............

Table 1--53: Audio Alarms (Opts. DS and AD Only) 1--47............

Table 1--54: Additional Audio Alarms (Opt. DDE Only) 1--48.........

Table 1--55: Additional Audio Alarms (Opt. DDE Only) 1--48.........

Table 2--1: Required Test Equipment 2--19.........................

T able 2--2: LCD Visual Defects 2--23..............................

Table 2--3: Diagnostics Limits 2--24...............................

Table 2--4: Required Test Equipment

(Video and General Performance) 2--41........................

Table 2--5: Oscilloscope Settings for Serial Output Amplitude 2--66....

T able 2--6: Generator Characterization 2--84.......................

Table 2--7: Required Test Equipment (Audio) 2--87..................

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

General Safety Summary

Review the following safety precautions to avoid injury and prevent damage to this product or any products connected to it. To avoid potential hazards, use this product only as specified.

Only qualified personnel should perform service procedures.

ToAvoidFireor

Personal Injury

Use Proper Power Cord. Use only the power cord specified for this product and certified for the country of use.

Ground the Product. This product is grounded through the grounding conductor of the power cord. To avoid electric shock, the grounding conductor must be connected to earth ground. Before making connections to the input or output terminals of the product, ensure that the product is properly grounded.

Observe All Terminal Ratings. To avoid fire or shock hazard, observe all ratings and markings on the product. Consult the product manual for further ratings information before making connections to the product.

Do not apply a potential to any terminal, including the common terminal, that exceeds the maximum rating of that terminal.

Replace Batteries Properly. Replace batteries only with the proper type and rating specified.

Do Not Operate Without Covers. Do not operate this product with covers or panels removed.

Use Proper Fuse. Use only the fuse type and rating specified for this product.

Avoid Exposed Circuitry. Do not touch exposed connections and components

when power is present.

Do Not Operate With Suspected Failures. If you suspect there is damage to this product, have it inspected by qualified service personnel.

Do Not Operate in Wet/Damp Conditions.

Do Not Operate in an Explosive Atmosphere.

Keep Product Surfaces Clean and Dry.

Provide Proper Ventilation. Refer to the manual’s installation instructions for

details on installing the product so it has proper ventilation.

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

General Safety Summary

Symbols and Terms

Terms in this Manual. These terms may appear in this manual:

WARNING. Warning statements identify conditions or practices that could result in injury or loss of life.

CAUTION. Caution statements identify conditions or practices that could result in damage to this product or other property.

Terms on the Product. These terms may appear on the product:

DANGER indicates an injury hazard immediately accessible as you read the marking.

WARNING indicates an injury hazard not immediately accessible as you read the marking.

CAUTION indicates a hazard to property including the product.

Symbols on the Product. The following symbols may appear on the product:

CAUTION

Refer to Manual

Protective Ground

(Earth) Terminal

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

Service Safety Summary

Only qualified personnel should perform service procedures. Read this Service Safety Summary and the General Safety Summary before performing any service

procedures.

Do Not Service Alone. Do not perform internal service or adjustments of this product unless another person capable of rendering first aid and resuscitation is present.

Disconnect Power. To avoid electric shock, switch off the instrument power, then disconnect the power cord from the mains power.

Use Care When Servicing With Power On. Dangerous voltages or currents may exist in this product. Disconnect power, remove battery (if applicable), and disconnect test leads before removing protective panels, soldering, or replacing components.

To avoid electric shock, do not touch exposed connections.

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

vii

Service Safety Summary

viii

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

Environmental Considerations

This section provides information about the environmental impact of the product.

Product End-of-Life

Handling

Observe the following guidelines when recycling an instrument or component:

Equipment Recycling. Production of this equipment required the extraction and use of natural resources. The equipment may contain substances that could be harmful to the environment or human health if improperly handled at the product’s end of life. In order to avoid release of such substances into the environment and to reduce the use of natural resources, we encourage you to recycle this product in an appropriate system that will ensure that most of the materials are reused or recycled appropriately.

The symbol shown to the left indicates that this product complies with the European Union’s requirements according to Directive 2002/96/EC on waste electrical and electronic equipment (WEEE). For information about recycling options, check the Support/Service section of the Tektronix Web site (www.tektronix.com).

Mercury Notification. This product uses an LCD backlight lamp that contains mercury. Disposal may be regulated due to environmental considerations. Please contact your local authorities or, within the United States, the Electronics Industries Alliance (www.eiae.org) for disposal or recycling information.

Restriction of Hazardous

Substances

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

This product has been classified as Monitoring and Control equipment, and is outside the scope of the 2002/95/EC RoHS Directive. This product is known to contain lead, cadmium, mercury, and hexavalent chromium.

Environmental Considerations

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

Preface

This reference document provides technical information about using the WFM6100, WFM7000, and WFM7100 Series multi-format waveform monitors with Option FP installed.

Specifications

The following tables list the specifications for the Tektronix WFM6100, WFM7000, and WFM7100 Waveform Monitors with Option FP installed. Items listed in the Performance Requirement column are generally quantitative, and can be tested by the Performance Verification procedure in Section 2 of this manual. Items listed in the Reference Information column are useful operating parameters that have typical values; information in this column is not guaranteed.

The specifications listed in the Electrical Specifications portion of these tables apply over an ambient temperature range of +0 _Cto+40_C. The rated accuracies are valid when the instrument is calibrated in an ambient temperature range of +20 _Cto+30_C.

Electrical Specifications

Table 1- 1: SDI Input Waveform Vertical Characteristics

Characteristic Performance requirement Reference information

Vertical Measurement Accuracy Using graticule or cursor. Measure in

Gain X1, X2, X5, and X10

Variable Gain Range, Typical 0.25X to 1.8X, typical (variable gain

Frequency Response -- HD

Luminance Channel (Y)

Chrominance Channels (Pb, Pr)

Frequency Response -- SD

Luminance Channel (Y)

Chrominance Channels (Pb, Pr)

YPbPr to RGB Conversion Accuracy 0.1%, nominal

0.5% of 700 mV full scale mode

0.2% of 700 mV full scale mode

50 kHz to 30 MHz, 0.5%

50 kHz to 15 MHz, 0.5%

50 kHz to 5.75 MHz, 0.5%

50 kHz to 2.75 MHz, 0.5%

YPbPr mode.

multiplied by fixed gain to get total gain).

50 kHz to 60 MHz for 1080P 60/59/50 dual link formats.

50 kHz to 30 MHz for 1080P 60/59/50 dual link formats.

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

1- 1

Specifications

Table 1- 1: SDI Input Waveform Vertical Characteristics (Cont.)

Characteristic Reference informationPerformance requirement

Step Response, Typical Sine-squared bars

Preshoot

Overshoot

Ringing

≤ 0.3% peak (2T5 bar)

≤ 0.5% peak (2T30 bar)

≤ 0.3% peak (2T5 bar)

≤ 0.5% peak (2T30 bar)

≤ 0.8% peak-peak (2T5 bar)

≤ 0.8% peak-peak (2T30 bar)

Most of the error seen on the display comes from the inherent ringing in the digital data. The response of the monitor is close to the theoretical limit of a perfect sinx/x reconstruction filter.

Pulse Response, Typical Blackman pulse

Baseline Ringing

Tilt, Typical

Field Rate 0.1%

Line Rate 0.1%

Off Screen Recovery, Typical 0.1% variation in baseline of a 5 MHz

≤0.6% peak-peak (2T5)

≤0.7% peak-peak (2T30)

Pulse-to-bar ratio 0.995:1 to 1.005:1 on appropriate Sine Squared or Blackman 2T pulse.

A sine-squared pulse near Nyquist is not band-limited and so inherently has ringing much larger than the waveform monitor filter. A three term Blackman pulse with the same HAD has much less inherent ringing, so it is a better choice for most testing. See Digital

to Analog Conversion, Data and Filter Requirements, SMPTE Journal Mar 1995,

Vol. 104, Fibush, Baker, Penny.

modulated pulse when positioned anywhere on screen at any gain setting.

1- 2

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

Specifications

Table 1- 2: Composite Analog Input Waveform Vertical Characteristics

Characteristic Performance requirement Reference information

Vertical Measurement Accuracy Measured using cursors or graticules

Gain X1, X2, X5, and X10

Variable Gain Range, Nominal 0.25X to 1.8X

Frequency Response

Delay Variation over Frequency

Transient Response on Sine Squared 2T4 Pulse

Preshoot

Overshoot

Ringing

Field Rate Tilt <0.5% With DC Restore Fast or Off

Line Rate Tilt <0.5% With DC Restore Fast or Off

Off Screen Recovery

SNR 60 dB

1%

Flat to 5.75 MHz, 1%

10 ns to 5.75 MHz Typically 2.5 ns

Pulsetobarratio0.99:1to1.01:1

≤1%

≤0.5% variation in baseline of a Chroma

modulated pulse when positioned anywhere on screen. Signal must meet specification for Video Maximum Operating Amplitude. Any gain setting.

minimum, relative to 700 mv for

RMS

PAL or 714 mv for NTSC.

Table 1- 3: Composite Analog Inputs A and B Physical Layer

Characteristic Performance requirement Reference information

Formats Supported NTSC, NTSC no setup, and PAL, I, B, D,

G, H. Complies with RS170A & I TU-R BT.471

Manual or auto detect of input standard

Internal Reference Proper horizontal and vertical synchroniza-

tion with a composite signal of appropriate line and field rate

Input Dynamic Range, Typical

6 dB range

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

1- 3

Specifications

Table 1- 3: Composite Analog Inputs A and B Physical Layer (Cont.)

Characteristic Reference informationPerformance requirement

Video Maximum Operating Amplitudewith Clamp Off (DC Coupled), Typical

Maximum Absolute Video Input Voltage --6.0 V to +6.0 V (DC + peak AC)

Input Type Passive loop-through 75 Ω compensated

DC Input Impedance 20 kΩ

Return Loss

Video Input Crosstalk Between Channels

Loop through Isolation

DC Offset with Restore Off, Typical

DC Restore Modes Fast, Slow and Off modes

DC Restore Offset Error

DC Offset Between Inputs With Restore Off

DC Restore 50 Hz and 60 Hz Attenuation

Fast Mode >95% attenuation

Slow Mode <10% attenuation, <10% peaking

Blanking Shift with 10% to 90% APL Change

Blanking Shift with Presence and Absence of Burst

Lock Range

≥40 dB to 6 MHz with power on

--1.8 V to +2.2 V (all inputs) DC + peak AC

Typically >46 dB to 6 MHz, >40 dB to 10 MHz. Typically 35 dB with power off for standard amplitude video

≥60 dB to 6 MHz

≥70 dB to 6 MHz

≤20 mV

Measured in full screen mode at X5 Gain

Slow has a typical bandwidth of 10 Hz Fast has a typical bandwidth of 500 Hz

≤2mV

Registration between back porch and 0 V graticule

≤7mV

≤1IRE(7mVPAL)

≤1 IRE (7 mV PAL), Typically 0 mV

50 ppm, remains locked

Vector typically OK to 80 ppm. waveform display typically locked to 200 ppm

Lock in Presence of Hum 700 mV

bar signal, remains locked

Lock in Presence of White Noise Signal/Noise ratio of 32 dB, 5 MHz

bandwidth on black burst, remains locked

Color Framing Correct color framing detected for signals

having <45 SCH phase error with burst present

1- 4

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

, on full amplitued 100% color

p-p

Specifications

Table 1- 4: Waveform Sweep (Horizontal) Deflection

Characteristic Performance requirement Reference information

Sweep

Accuracy

Linearity 0.2% of time displayed on screen Fully digital system

Timing Cursor Delta Readout Accuracy, Typical

Rates 1, 2, 3, or 4 line, or field depending on

Line Select In 2-line sweep, the selected line is the first

 0.5%, all rates

Line sweeps for 1080P 60/59/50 dual link formats are shown with image scanning time scale. In these formats, each link operates at link time scale is twice the indicated time per division.

 0.5% of sweep time displayed on screen

mode

displayed line.

/2the image scanning rate, so

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

1- 5

Specifications

Table 1- 5: Eye Pattern Display

Characteristic Performance requirement Reference information

Type Equivalent Time Sampler

Formats SD and HD, as shown in Table 1--47

Signal Bandwidth 100 MHz to 2.5 GHz at --3 dB point

Time Base Jitter, Typical

SD 60 ps

HD 20 ps

Eye Clock Bandwidth Settings Clock bandwidth can be set to 10 Hz,

100 Hz, 1000 Hz, 10 kHz, or 100 kHz high pass filter

Eye Clock Bandwidth Accuracy Actual --3 dB frequency within 10% of

nominal

Jitter Attenuation Error

10 Hz High Pass Filter Within 0.3 UI + 10% for jitter frequencies

above five times bandwidth selection

100 Hz to 100 kHz High Pass Filter

Within 0.05 UI + 10% for jitter frequencies above five times bandwidth selection

SD All High Pass Filter settings Within 0. 05 UI + 10% for jitter frequencies

above five times bandwidth selection

in 1 kHz high-pass filter mode

p-p

in 1 kHz high-pass filter mode

p-p

1- 6

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

Table 1- 5: Eye Pattern Display (Cont.)

Characteristic Reference informationPerformance requirement

Display Modes

Overlay Overlays all bits to form each eye opening.

10 Eye Displays eye relative to the parallel clock.

Overlay Overlays all bits to form each eye opening.

20 Eye Displays eye relative to the parallel clock.

Specifications

Useful for observing peak jitter

Useful for observing jitter correlated to word clock

Useful for observing peak jitter

Useful for observing jitter correlated to word clock

Vertical Scale Accuracy 800 mV ±5% with an 800 mV

signal

Horizontal Scale Accuracy Indicated time per division ±1%, fully

Eye Derived Measurements

Rise Time / Fall Time, Typical

Amplitude, Typical

Equalized Eye Display Shows eye from input after it has gone

p--p

input

digital system

20ps

Measurements only valid on a clean signal. Excess jitter, overshoot, or other aberrations will reduce the accuracy. Limited by inherent rise time of eye display

10 mV

Measurements only valid on a clean signal. Excess jitter, overshoot, or other aberrations will reduce the accuracy. Limited by inherent rise time of eye display

through equalizer

Allows limited use of eye at long cable length. Equalizer adds some jitter. Can bypass equalizer at short cable lengths to overcome this effect

Equalized Eye Amplitude, Typical 600 mv ±80mv

Amplitude of equalized eye is not related to input amplitude. This waveform is from the digital output of the equalizer. It is intentionally displayed at a smaller size to reduce the chance of it being confused with the input eye

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

1- 7

Specifications

Table 1- 6: Jitter Display

Characteristic Performance requirement Reference information

Type Displays numerical and graphical readouts

of peak--to--peak jitter. Jitter derived from demodulated recovered clock as described in SMPTE RP192 2003. If Opt. PHY is installed, then Jitter Waveform can also be displayed

High-Pass Filter Settings Can be set to 10 Hz, 1 kHz, 10 kHz, or

100 kHz

High pass filter has type--3 response for low frequency rejection of 60 dB/decade below the filter setting. High pass filter also applies to digital readout, jitter waveform and Eye diagram display, but not the reference clock output. There are two independent Jitter demodulators which may be configured with different loop bandwidths. One is applied to the upper two tiles of the display, and the other applies to the lower two tiles

High-Pass Filter Attenuation Accuracy Frequency at which response is --3dB is

within 10% of nominal

High--Pass Frequency Response also applies to readout and jitter waveform

High-End Frequency Response, Typical --3dBat >5MHz

Applies to digital readout, jitter waveform, and reference clock output

1- 8

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

Specifications

and

Ref

loc

Maximumjitterislimitedbymeasurement

Table 1- 6: Jitter Display (Cont .)

Characteristic Reference informationPerformance requirement

Maximum Jitter Applies to digital readout, jitter waveform,

erence

output

Maximum is a function of jitter frequency and standard:

range at low frequencies, and by jitter tolerance of serial receiver at high frequencies

10 Hz to 30 kHz, HD 20 UI

10 Hz to 40 kHz, SD 10 UI

p-p

30 kHz to 1 MHz, HD Declines to 0.35 UI at 1 MHz

50 kHz to 1 MHz, SD Declines to 0.35 UI at 1 MHz

>1 MHz, HD 0.35 UI

1MHzto4MHz,SD 0.35 UI

>4 MHz, SD 0.25 UI

Minimum (noise floor) is a function of

Applies to jitter waveform

bandwidth selection:

10 Hz, HD 200 ps typical

100 Hz, 1 kHz, 10 kHz, 100 kHz,

40 ps typical

All HPF settings, SD 250 ps typical

Digital Readout Type Displays peak to peak value of jitter

detected over the measurement period, as defined by selected high--pass filter setting. Indicates timing jitter or alignment jitter if appropriate

Digital Readout

Accuracy, Typical For jitter frequencies from 5 times band-

width selection to 4 MHz

10 Hz, HD <0.3 UI + 10% of reading

100 Hz, 1 kHz, 10 kHz, 100 kHz,

<0.05 UI + 10% of reading

All HPF settings, SD <0.05 UI + 10% of reading

Resolution 0.01 UI

Jitter Waveform

Gain Error, Typical For jitter frequencies from 5 times band-

width selection to 4 MHz

Error for jitter frequencies between HPF setting and 5x HPF setting due to loop peaking: max of 1.5 dB

10 Hz, HD <0.4 UI + 10% of reading

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

1- 9

Specifications

Table 1- 6: Jitter Display (Cont .)

Characteristic Reference informationPerformance requirement

100 Hz, 1 kHz, 10 kHz, 100 kHz, HD

All HPF settings, SD <0.1 UI + 10% of reading

Scale

Horizontal Modes 1 Line, 2 Line, 1 Field, 2 Field

Vertical Modes 1UI/div,0.2UI/div,0.1UI/div

Reference Clock Output, Typical 1Vp-pinto75Ω load

Jitter Measurement Time 0.5 Sec

<0.1 UI + 10% of reading

SD frequency = 27 MHz HD frequency = 74.25 or 74.17852 MHz

Approximately 5,000,000 independent samples

Table 1- 7: Component Vector Mode

Characteristic Performance requirement Reference information

Vertical Bandwidth, Typical

SD 800 kHz

HD 3.4 MHz (6.8 MHz for 1080P 60/59/50 dual

link formats)

Vertical Gain Accuracy

Horizontal Gain Accuracy

Display to Graticule Registration 0.5% Fully digital system limited by sample

Vector Display PBis displayed on horizontal axis and PRis

 0.5%

Fully digital system

resolution

displayed on vertical axis

Table 1- 8: Waveform Mode Filter Character istics

Characteristic Performance requirement Reference information

Low Pass Filter Gain

1- 10

SD, component only

HD, component only

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

1  0.1% relative to flat gain

Table 1- 8: Waveform Mode Filter Character istics (Cont.)

Characteristic Reference informationPerformance requirement

Low Pass Filter Frequency Response

SD, component only

HD, component only

Luma Filter Gain, composite only

Luma Filter Frequency Response, composite only

Chroma Filter Gain, composite only

Chroma Filter Response, composite only

Chroma Filter Attenuation at 2x FSC, composite only

≤ 3 dB attenuation at 800 kHz

≥ 32 dB attenuation at 3 MHz

Filter meets IEEE STD-205

≤ 3 dB attenuation at 4.5 MHz

≥25 dB attenuation above 15 MHz, Noise

bandwidth is approximately 8 MHz Stopband null at 18 MHz

1  0.1% relative to flat gain at 50 kHz

≤ 3 dB attenuation at 800 kHz

32 dB attenuation at F

Same as SD serial component low pass filter

1  0.1% relative to flat gain

3 dB bandwidth 1 MHz  0.2 MHz

FSCautoselected based on input standard, implemented digitally, centered on F

≥ 25 dB

Implemented digitally. Typically 28 dB for NTSC, 53 dB for PAL

Specifications

For 1080P 60/59/50 dual link formats:

≤3 dB attenuation at 9 MHz ≥25 dB attenuation above 30 MHz

Table 1- 9: SDI Lightning and Diamond Modes

Characteristic Performance requirement Reference information

Vertical Gain Accuracy

0.5%

Fully digital system

Electronic Graticule Display

Diamond RGB deflection axis indicated. Upper and

lower halves are separated, to see negative signals

Lightning Displays signal components as follows:

Y vertically Pb horizontally on top half of display P

horizontally on bottom half of display

Detection Level

High Limit +630 mV to +756 mV in 1 mV steps

Low Limit --50mVto+35mVin1mVsteps

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

1- 11

Specifications

Table 1- 9: SDI Lightning and Diamond Modes (Cont.)

Characteristic Reference informationPerformance requirement

Detection Level Accuracy

Diamond Area Threshold Range 0% to 10%

 3.5 mV

Table 1- 10: Data Mode

Characteristic Performance requirement Reference information

Digital Waveform Non-interpolated waveform display. Cursor

identifies selected sample value (hex, decimal, binary). Cursor inserted on picture monitor output shows selected line

Digital List Sequential list of sample values in table

format. Cursor identifies selected sample

Display Format HEX, DEC, BIN

Table 1- 11: Composite Vector Mode

Characteristic Performance requirement Reference information

Displayed Horizontal and Vertical Gain Accuracy

X1 Gain

X5 Gain

Display to Graticule Registration Centered in target, +0.5 box diameter

1%

With the color bar black/white display dot centered in target. Boxes are 2% targets

Vector Display B--Y is displayed on horizontal axis and

R--Y is displayed on vertical axis

Bandwidth, Typical 360 kHz

Horizontal to Vertical Bandwidth Matching <0.5° at 500 kHz and 2 MHz

Composite Vector Dot Reference Shows “true” zero subcarrier reference

R--Y B--Y Axis Orthogonalit y. Typical

1- 12

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

0.1°, implemented digitally

Table 1- 12: Arrowhead mode (NTSC/PAL composite limit display)

Characteristic Performance requirement Reference information

Specifications

Signal to Graticule Accuracy

Composite Limit Cursor Accuracy

Detection Level, nominal Adjustable thresholds, 1% steps

Composite Limit Detection Level Accuracy

Composite Limit Area Threshold Range 0% to 10%

Luma Limit Detection Range

High 90 to 108%, 0.5% steps

Low +5 to --6%, 0.5% steps

Luma Limit Detection Level Accuracy

Luma Limit Area Threshold Range 0% to 10%

1%, 100 IRE (700 mV), and 131 IRE (900 mV)

1.0% at 100 IRE, 110 IRE, 120 IRE, and 131 IRE (700 and 950 mV)

1.0% at --24 IRE, --33 IRE, and --40 IRE (--230 and 300 mV)

Detection Level =  7 mV of cursor level

(PAL values in parenthesis)

Upper detection level can be set to 100, 110, 120 or 131 IRE (700 mV or 950 mV PAL)

Lower detection level can be set to --24,

--33, and --40 IRE (--230 mV or --300 mV PAL)

Detection level = 7 mV of cursor level, nominal

Table 1- 13: Bowtie mode

Characteristic Performance requirement Reference information

Common Mode Rejection Ratio

Interchannel Timing Match

Functional Description Displays Y minus Pr and Y minus Pb

≥34 dB at 2.5 MHz

≥34 dB at 5 MHz

0.5 ns

signals. Requires bowtie signal to be useful. Null in center indicates the channels are time aligned

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

1- 13

Specifications

Table 1- 14: Timing Display

Characteristic Performance requirement Reference information

Input Timing Relative to External Reference Display of Vertical and Horizontal timing

offset graphically and numerically. One clock cycle resolution

Patented proprietary display. Display Timing difference between input and Ref at rear panel or relative to an offset saved by the user

Timing Display Zero Definition For vertical timi ng, conf orm s to SMPTE

168--2002

For horizontal timing, zero delay analog signals have coincident syncs. For digital signals, timing is such that if converted to analog by a WFM601A, then the resultant analog signal is conincident with the reference

Timing zero is equivalent to nominal zero delay on TG700. Also agrees with signal that shows minimal shift on the waveform display when going from internal to external

Vertical timing, according to SMPTE 168, specifies that the lines with the start of the broad pulses are aligned

Operation with input and reference being different formats

Link B to Link A Display of dual link timing skew. Uncertain-

Input Timing Reference to Other Input For Simultaneous inputs, allows selecti on

Compatible with any combination listed in Tables 1--45, 1--46, and 1--47. In cases where there are multiple ways to interpret the phase relationship, multiple indicators of the phase will be shown. The numeric display will follow the smallest phase offset

ty of ± 1.5 clocks or 20 ns.

of other channel as reference.

1- 14

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

Specifications

Table 1- 15: Picture Mode

Characteristic Performance requirement Reference information

Format (XGA) Allows viewing picture in all formats

In SD formats, full screen picture occupies the central portion of the XGA raster area. For tile mode, the image is downsampled to fit the 512 x 350 size

In HD formats, picture is downsampled to fit in 1024 x 768 size (512 x 350 in 4--tile mode). In 1080P 60/59/50 dual link formats, picture is formed by averaging two lines, one from each link, then downsampling as required for display

In Low Frame Rate formats, frames are repeated as needed to achieve XGA frame rate; similar to 3:2 pulldown on some frame rates

Pix Border On/Off Allows user to mask or show the inactive

portions of the raster such as ANC area for digital and sync for analog.

When the border is on, the image is scaled to correct the aspect ratio. When the border is off, the image is either mapped pixel to pixel (full screen SD), or minimally decimated to reduce the atrifacts

Synchronization Picture mode always uses internal timing; it

is not affected by external sync

Aspect Ratio Allows choice of 16:9 or 4:3 for SD, to

support widescreen

Table 1- 16: Signal Level / Cable Length Detector

Characteristic Performance requirement Reference information

Cable Length Measurement Error

Cable Length Measurement Resolution 2 meters, nominal

15 m 10% for cable types listed at end of table

Requires clean SD signal with rise time <1 ns for full accuracy. Excessive ringing or slower rise time may appear as increased cable length

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

1- 15

Specifications

Table 1- 16: Signal Level / Cable Length Detector (Cont.)

Characteristic Reference informationPerformance requirement

Cable Length Measurement Range, Typical Cable loss range of 0 to 30 dB at1/2serial

bit rate

Typically runs to 40 dB, but with reduced accuracy

Equivalent to 0 to 300 m Belden 8281 for SD, 0 to 120 m Belden 8281 for HD

Launch Amplitude Measurement Accuracy, Typical

Launch Amplitude Measurement Resolution, Typical

Launch Amplitude Measurement Dynamic Range, Typical

Cable Types Belden 1694A/1505A/8281/1855A

40 mV at 800 mV level, 0 to 100 m Belden 8281 cable

10 mV

50% from 800 mV

Canare L--5CFB Image 1000

Cable loss measurement Displays loss around 160 MHz minus loss

around 18 MHz

Table 1- 17: Data error detection (EDH / Status, Under STATUS Button)

Characteristic Performance requirement Reference information

Data Integrity

SD Active picture and full field. Field rate

resolution Complies with SMPTE RP165

HD Field rate Resolution, separate reporting for

errors in Y or Color Difference data streams

Uses CRC check-word system. System is known as EDH (Error Detection and Handling) in industry literature

Error icon asserted for 1 second after any error

1- 16

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

Specifications

Table 1- 18: ANC Data and ARIB

Characteristic Performance requirement Reference information

Displays Detects ANC data in SDI streams, displays

data from user specified DID and SDID. Displays Audio Control Packet. Decodes data for ARIB types B39, B37, B35, TR--B22, and TR--B23.

Alarms Allows Alarms to be set for :

ANC Parity ANC Checksum B39 Absence B37 Absence B35 Absence TR--B22 Absence TR--B23 Absence

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

1- 17

Specifications

Table 1- 19: Audio Bar Displays

Characteristic Performance requirement Reference information

Modes The user may configure the response

dynamics (ballistics), reference levels, peak hold, offset, and scale of the meters to suit the monitoring needs of the particular installation or situation

Channel Mode Any 10 channels configured into 5 pairs

with phase correlation meters between pairs; analog audio inputs havea6channel maximum

Surround Mode Left, Right, Center Lfe, Left surround, Right

surround meters, and an extra channel pair. Phase correlation meters between L--R, L--C, C--R, Ls--Rs, L--Ls, R--Rs and the extra pair

In Dolby mode, the bar configuration is automatically set by metadata

Dual Audio Display Mode For Simultaneous inputs, Dual Audio

Displays are available. A total of 8 bars may be allocated between the two displays. Dolby decoding may be enabled for either display, but not for both

Audio Sources Monitoring the signal levels and stereo

phase of AES/EBU digital audio, digital audio embedded in serial digital video, and Analog Audio inputs

Digital Audio (direct and embedded) may be PCM, Dolby digital, or Dolby E

Level Meter Resolution 0.056 dB steps at 30 dB scale, from full

scale to --20 dB FS

XGA Full Screen mode = 510 steps XGA 4-tile mode = 255 steps VGA Full or 4-tile mode = 260 steps

1- 18

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

Specifications

Table 1- 19: Audio Bar Displays (Cont .)

Characteristic Reference informationPerformance requirement

Correlation Meter Speed User selectable 1 to 20. Factory default is

set to 8.

Speed 1 averages over 0.04 sec. Speed 2 averages over 0.04 sec. Speed 3 averages over 0.08 sec. Speed 4 averages over 0.12 sec. Speed 5 averages over 0.28 sec. Speed 6 averages over 0.52 sec. Speed 7 averages over 1.0 sec. Speed 8 averages over 1.5 sec. Speed 9 averages over 2.0 sec. Speed 10 averages over 2.5 sec. Speed 11 averages over 3.0 sec. Speed 12 averages over 3.5 sec. Speed 13 averages over 4.0 sec. Speed 14 averages over 4.5 sec. Speed 15 averages over 5.0 sec. Speed 16 averages over 5.5 sec. Speed 17 averages over 6.0 sec. Speed 18 averages over 6.5 sec. Speed 19 averages over 7.0 sec. Speed 20 averages over 7.5 sec.

The Phase Correlation Meter Speed setting determines how quickly the meter reacts to changes in phase relationship. The meter reading is actually an average of correlation over time, and this setting determines how many samples are used to calculate the average. The instrument uses the fewest samples when this setting is 1, and the meter reacts almost instantaneously. The instrument uses the most samples when the setting is 20, and the meter reacts much more slowly. Experiment to find the setting that best fits your application

Metering Ballistic Types Selectable from true peak, PPM Type 1,

PPM Type 2, and Extended VU

Peak Program Meter (PPM) Ballistic Response

PPM Type I (IEC Type I, essentially the same as DIN 45406 and Nordic N-9)

PPM Type II (IEC Type II, the same as IEEE std. 152--1991)

PPM Type I has a slightly faster attack time and a faster return time, 1.7 seconds to fall 20 dB as opposed to 2.8 seconds for Type II

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

1- 19

Specifications

Table 1- 19: Audio Bar Displays (Cont .)

Characteristic Reference informationPerformance requirement

True Peak Ballistic Response PPM Type II decay characteristics, no

attack delay, factory default ballistic

Extended VU Ballistic Response VU meter as defined in IEEE 152--1991,

but with an extended dB-linear scale. The meter bars also contain true peak indicators when VU is selected

Peak Hold True peak indicator remains at the most

recent peak for a user selectable time of 1 to 10 seconds

Clip Indication Delay Count Consecutive FS samples for Clip Indica-

tion, user selectable Off or 1 to 100. Factory default is set to 1. A setting of 0 is equivalent to “Off”

Mute Indication Delay Count Consecutive “0” samples for Mute Indica-

tion, user selectable Off or 1 to 100. Factory default is set to 10. A setting of 0 is equivalent to “Off”

Clip/Mute Error Readout Hold Time 1 to 30 seconds, user selectable. Fact ory

Default set to 2

Silence Indication Threshold Audio level below which the signal will be

considered “silent”

Used to trigger on-screen indication and alarms

Silence Indication Delay Off or 1 to 60 seconds, user selectable

Indication and alarm will not be asserted until signal stays below the silence threshold for this number of consecutive seconds. Factory default is set to 10. A setting of 0 is equivalent to “Off”

Over Indication Threshold Audio level above which the signal will be

considered “over”

Used to trigger on-screen indication and alarms

Over Indication Delay Off or 1 to 30 seconds, user selectable

Indication and alarm will not be asserted until signal stays above the Over Indication Threshold for this number of consecutive seconds. Factory default is set to 2. A setting of 0 is equivalent to “Off”

1- 20

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

Specifications

Table 1- 19: Audio Bar Displays (Cont .)

Characteristic Reference informationPerformance requirement

Adjustable Peak Program Level Peak Program level is the level, relative to

digital full scale, that the user chooses as the maximum desired level for monitored programs. The meter bars change to red above Peak Program level

Digital Range0to--30dBFS

Analog Range 24 to --6 dBu

Adjustable Test Level Test level is the level, relative to digital full

scale, that the user chooses as the test or “line up” level for monitored programs. The meter bars change to yellow between the Test and Peak Program levels

Digital Range0to--30dBFS

Analog Range 24 to --6 dBu

Set 0 dB Mark Selections are 0 dBFS or 0 dBu, Peak

Program Level (dB), or Test Level (dB)

Analog Audio Scale Types Selection of DIN, Nordic, or PPM preset the

Use this item to number the meter scale relative to Digital Full scale with digital sources, or relative to 0 dBu with analog sources, or to one of the two user-adjustable levels. When the zero mark is set to either Peak Program or Test level, the scale units are dBr, relative to the 0 dB level; units above the selected 0 dB mark are positive, while units below it are negative

scale, test, and reference levels to match these defined meter types

Table 1- 20: Audio Bar and Lissajous/Surround Display

Characteristic Performance requirement Reference information

Description In combination with Bar mode (see

Table 1--19) can have Lissajous or Surround Display in one tile

Automatic Gain Control (AGC) Lissajous gain control may be on or off AGC time constant: 0.5 second to expand

display after a 0 to --40 dB level transition,

0.05 second to reduce gain after a --40 to 0 dB level transition

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

1- 21

Specifications

Table 1- 20: Audio Bar and Lissajous/Surround Display (Cont.)

Characteristic Reference informationPerformance requirement

Manual Scaling When AGC is off, level at perimeter of

display follows Peak Program Level on Bar display

Surround Display Frequency Weighting Filter

Frequency weighting can be A-weighting or Linear (Flat Response) as described in IEC 651

Dominant sound indicator can be turned on and off

Table 1- 21: AV Delay display (Option AVD)

Characteristic Performance requirement Reference information

Audio Video Delay measurement Displays the delay of embedded

audio relative to SDI video. Shows delay in milliseconds and in fields. Requires SDI signal from TG700 in AV Timing mode.

Measurement Range At least --2 to +2 seconds: a negative

reading indicates audio is advanced with respect to video; a positive reading indicates it is delayed. Range depends on the repetition rate of the test signal. Specification applies for TG700 AV Timing mode, which has a nominal 5 second repetition rate.

Measurement Accuracy +/--1/2video field.

Table 1- 22: AES Audio Inputs

Characteristic Performance requirement Reference information

Inputs 2 sets with 8 channels each, 32--192 kHz,

Input Connector BNC, terminated, unbalanced

Input Impedance 75 Ω

1- 22

24 bit, meets requirements of AES-3ID and SMPTE 276M-1995

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

Specifications

Table 1- 22: AES Audio Inputs

(Cont.)

Characteristic Reference informationPerformance requirement

Input Return Loss >25dBrelativeto75Ω, from 0.1 to 6 MHz Typically better than 30 dB to 24 MHz

Input A has passive terminations, so they are the same with power on or off. Input B has active terminations that go to a higher impedance with the power off

Input Amplitude Range 0.1 V to 2 V peak-to-peak

Input Sample Rate 32k to 192k samples/sec

Input Lock Frequency Range

>5%. If input sample rate changes more than 5%, then the instrument may search again for a new lock point. Typically stays locked to 12.5%

Level Meter Accuracy Over Frequency ±0.1dBfrom20Hzto20kHzwith0to

--40 dBFS sine wave input, Peak Ballistic mode. Within 5 Hz of some submultiples of

May not display full amplitude on fast transients due to sampled nature of digital

signal the sampling frequency it may be attenuated additionally, as shown below. Sampling frequency refers to the 192 kHz upsampled data used for the bar ballistics For example:

1/12

of rate --0.30 dB (16 kHz 5 Hz)

of rate --0.17 dB (12 kHz 5 Hz)

1/16

of rate --0.11 dB (9.6 kHz 5 Hz)

1/20

Audio Levels Bars display signals up to 0 dBFS

Must not exceed maximum power specifi-

cation on analog outputs. Configure output

attenuation if necessary

The AES B connectors can be configured for input or output functionality.

Table 1- 23: AES Audio Outputs (alternate function on second set of inputs)

Characteristic Performance requirement Reference information

Source AES Line B outputs can be sourced from

embedded, AES line A inputs (active

loopthrough) or analog inputs

If either Dolby option is installed, then the

source may also be a repeat of the

encoded Dolby stream, or decoded AES

from a Dolby input. See the Dolby spec

section for limitations

Number of Outputs Up to 8 channels

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

1- 23

Specifications

Table 1- 23: AES Audio Outputs (alternate function on second set of inputs)

Characteristic Reference informationPerformance requirement

Output Format AES 3--ID Output, 48 kHz, 20 bit for

Output Connector BNC, terminated, unbalanced

Output Impedance 75 Ω

Output Return Loss >25dBrelativeto75Ω from0.1to6MHz Typically better than 30 dB to 24 Mhz

Output Amplitude Range 0.9 V to 1.1 V peak-to-peak into 75 Ω

Output Sample Rate Locked to embedded sample rate (nominal-

(Cont.)

embedded; 48 kHz, 24 bit for analog to AES. For AES to AES loogthrough, output format equals input format. Meets requirements of SMPTE 276M--1995 (AES 3--ID)

For decoded Dolby Digital, output is 24 bits at a rate of 32, 44.1, or 48KHz. For decoded Dolby E the output is 24 bits at 48KHz, or 47.952KHz

Tested in input mode

ly 48 kHz) for embedded source, to AES incoming rate for AES source, and to 48 kHz for analog source

Output Jitter, Typical 3.5 ns peak with 700 Hz high pass filter per

AES specification

AES3 rev. 1997 specification is 4.1 ns peak for 48 kHz audio

Rise and Fall Time, Typical 37 ns from 10% to 90% as per AES3 for

48 kHz sampling <12 ns for 96 kHz and 192 kHz sampling

Analog input to AES output levels, Typical Analog input of +24 dBu translates to

0 dBFS digital signal

Accuracy governed by analog input accuracy spec

The AES B connectors can be configured for input or output functionality.

1- 24

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

Specifications

Table 1- 24: Embedded Audio Extraction

Characteristic Performance requirement Reference information

Embedded Audio Formatting 24-bit Embedded audio i s not supported

(no AUX bits are extracted), only 20 most

significant bits will be extracted. Supports

SMPTE 272M Operation Level B only

(48 kHz audio sampling rate synchronized

with video)

SD Extract 20-bit audio formatted according to

SMPTE 272M

HD Extract 20 or 24 bit audio formatting

according to SMPTE299M

Channel Numbering Channel numbers per SMPTE 272M (1

through 16) will be correctly shown on all

displays

Audio Rates No support for SMPTE 272M levels C

through J

Number of Channels Monitored for Presence

16 channels are monitored for presence.

With Simultaneous inputs or dual link

formats, 16 channels of of each selected

SDI input are monitored for presence.

Maximum Number of Channels Monitored for Activity

Audio levels Bars display signals up to 0 dBFS

Monitoring done by audio board only. Can

only monitor channels set up for display

Must not exceed maximum power specifi-

cation on analog outputs. Configure output

attenuation if necessary

Table 1- 25: Analog Audio Inputs

Characteristic Performance requirement Reference information

Number of Channels Provides up to two sets of six channels of

professional balanced differential inputs for

each video input, 12 channels total

Input Connector Balanced, unterminated via rear panel

connector

Use 62 pin, 3 row, DSUB connector, only 2

rows of 42 pins are connected

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

1- 25

Specifications

Table 1- 25: Analog Audio Inputs

(Cont.)

Characteristic Reference informationPerformance requirement

Level Meter Accuracy over Frequency ±0.3 dB from 20 Hz to 20 kHz, 24 dBu to

--16 dBu sine wave input, Peak Ballistic mode. Within 5 Hz of some submultiples of the sampling frequency it may be attenuated additionally, as shown below. Sampling frequency refers to the 192 kHz upsampled data used for the bar ballistics. For example:

1/12

of rate --0.30 dB (16 kHz ±5 Hz)

1/16

of rate --0.17 dB (12 kHz ±5 Hz)

1/20

of rate --0.11 dB (9.6 kHz ±5 Hz)

Cross Talk, Typical

≤--90 dB from 20 Hz to 20 kHz, inputs driven from <600 Ω source impedance

Defined as the displayed bar level in any channel that results from a full scale signal on a different input pair than that input

Maximum Input Levels

+24 dBu ±0.3 dBu (see Level Meter Accuracy over Frequency above)

Must not exceed maximum power specification on analog outputs. Configure output attenuation if necessary

Resolution Sampling 24 bits at 48 kHz

Input Impedance 24 kΩ

Off Isolation

≤--90 dB, from 20 Hz to 20 kHz. Unused input driven from <600 Ω source impedance

Analog Input to Digital Output Distortion (THD+N), Typical

1- 26

Defined as the displayed bar level that results from a full scale signal on any pair of the unused input

<0.03% from full scale to --30 dBFS , 20 Hz to 20 kHz

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

Specifications

Table 1- 26: Analog Audio Outputs

Characteristic Performance requirement Reference information

Audio Modes Balanced: provides a full-scale output of

24 dBu and is designed for professional

balanced applications

Unbalanced: Designed to drive the

unbalanced inputs of consumer amplifiers,

in which case the negative output pin must

be grounded

Audio Sources The channels routed to the line outputs

may include: Embedded audio source, AES

audio source, Analog audio source, and

Decoded Dolby

Number of Channels Provides up to eight channels

Output Connections Balanced, unterminated via rear panel

connector

62 pin, 3 row, DSUB connector, but only 2

rows of 42 pins are connected

Ground negative output to support unbal-

anced mode

Maximum Output Levels

Input to Output Gain 0 dB to --120 dB in 0.5 dB steps

Digital Input to Analog Output Gain Accuracy over Frequency

Analog Input to Analog Output Gain Accuracy over Frequency

Output Impedance 50 Ω

Digital Input to Analog Output Distortion (THD + N)

Analog Input to Analog Output Distortion (THD + N)

+24 dBu ±0.5 dBu

0.5 dB, 20 Hz to 20 kHz, 0 to --40 dBFS,

20 or 24 bit input

0.8 dB, 20 Hz to 20 kHz, 24 dBu to

--16 dBu

When one output is grounded to achieve

unbalanced mode, the outher output will be

driven to a larger amplitude. You can

reduce the level by adding attenuation in

the Audio Settings menu. Do not exceed

the maximum rated output power in either

mode

Intended to drive ≥600 Ω load. Drivers are

capable of driving a minimum load

impedance of 300 Ω but may overheat. DO

NOT exceed maximum rated output power

≤--0.01% from full scale to --20 dBFS,

20 Hz to 20 kHz

≤--0.02% from full scale to --20 dBFS,

20 Hz to 20 kHz

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

1- 27

Specifications

Table 1- 26: Analog Audio Outputs (Cont.)

Characteristic Reference informationPerformance requirement

Digital Input to Analog Output Crosstalk, Typical

Output Power Capability, Typical Capable of continously driving a --10 dBFS

Meter Level to Headphone Output Gain 0dBto--63dBin0.5dBstepsrelativeto

Digital Input to Headphone Output Gain Accuracy over Frequency

Digital Input to Headphone Output Distortion (THD + N), Typical

0.1 dB, 20 Hz to 20 kHz, 0 to --40 dBFS

<--90 dB, 20 Hz to 20 kHz, 24 dBu or 0 dBFS input

<--100 dB, 20 Hz to 2 kHz, 24 dBu or 0 dBFS input

Defined as cross talk within a pair

sinewave into 600 Ω or --13 dB into 300 Ω

This is 25 mW RMS in the load per output pair. Live audio may reach full voltage level as long as the duty cycle is such that the RMS power is less than 25 mW averaged over any 10 second period. If an overtemp condition is detected, the output attenuation may be increased automatically to prevent damage

maximum output level

±0.05% from full scale to --10 dBFS, 20 Hz to 20 kHz, into 32 Ω

<0.2%atfullscaleinto32Ω

<2%atfullscaleinto16Ω

Headphone Output Power Capability Capable of continuously driving a 6.25 dBu

sinewave into 32 Ω or 16 Ω

Table 1- 27: Dolby Digital (AC - 3) Compressed Audio Monitoring (Opt. DDE)

Characteristic Performance requirement Reference information

Compressed Audio Input Format Decodes audio and metadata from Dolby

data stream transported through AES or 48 kHz embedded audio source. Supports 32--bit professional and consumer modes on stream zero only

Decoded Audio Outputs A single, selectable, Dolby Digital decoded

channel pair may be output on AES B 1--2 and Analog Outputs 1 & 2

Limited to a single channel pair and line compression mode only, by license requirements

1- 28

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

Specifications

Table 1- 27: Dolby Digital (AC - 3) Compressed Audio Monitoring (Opt. DDE) (Cont.)

Characteristic Reference informationPerformance requirement

Dolby Audio Status Display Displays basic Dolby D status and bit

stream meta--data

Alarms See Tables 1--49 through 1--55 for added

error indicators

Table 1- 28: Dolby E and Extended Dolby Digital ( AC- 3) Compressed Audio Monitoring (Opt. DDE)

Characteristic Performance requirement Reference information

Compressed Audio Input Format Decodes audio and metadata from Dolby

data stream transported through AES or

48 kHz embedded audio source, streams 0

through 7. Supports 16--bit professional

mode on Channel 1 or 2

Decoded Audio Outputs Up to eight decoded channels including all

surround sound channels plus down mix

may be output on AES B or Analog Outputs

Dolby Audio Status Display Displays extensive Dolby D and Dolby E

status and bit stream meta--data

Alarms See Tables 1--49 through 1--55 for added

error indicators

Table 1- 29: Picture Monitor Output s (VGA Pix Mon)

Characteristic Performance requirement Reference information

Signal Format VGA DSUB Outputs Y, Pb, Pr with sync on Y, RGB with sync on

all, HD and SD. HD sync is tri-level, also

have TTL H and V drive. Component mode

only available for SDI input mode. With

1080P 60/59/50 dual link formats, com-

bined links are down--converted to the

related 1080i format. 4:4:4 dual link formats

are down-converted to 4:2:2

Does not support 720p 30, 720p 29.97,

720p 25, 720p 24 or 720p 23.98 formats

No H and V sync outputs when sourcing

1080p sf 23.98 or 24, just tri--level sync on

Green/Y

DAC Resolution 10 bit

Impedance, Typical 75 Ω unbalanced

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

1- 29

Specifications

Table 1- 29: Picture Monitor Output s (VGA Pix Mon) (Cont.)

Characteristic Reference informationPerformance requirement

Active Video Accuracy 700 mV ±5% peak-peak (Y-Pb-Pr mode)

Black (blanking) Output Level 0mV±50 mV for HD and SD

Frequency Response, Typical Measure with a VM5000 and use “normal”

VGA to BNC cable (such as Allied 796--9640)

SD ±5% to 5.5 MHz, Y, G, B, and R

HD ±8% to 30 MHz, Y, G, B, and R

Non-Linearity, Typical ≤1.5%

Rise and Fall Time, Typical

SD 250nsforY,R,G,B

500 ns for Pb, Pr

HD 35nsforY,R,G,B

70 ns for Pb, Pr

Overshoot and Undershoot, Typical 1%

K Factor, Typical 1%

Interchannel Timing Match, Typical

SD Y-t o -Pb a nd Y-t o -Pr ±5.0 ns

HD Y-to-P b and Y-to-P r ±4.0 ns

Sync Amplitude Accuracy, Typical

SD --300 mV

HD 300 mV on positive and negative excur-

sions

Signal to Noise Ratio, Typical

SD 70 dB to 5.5 MHz

58 dB to 100 MHz

RMS noise on quiet line, relative to 700 mV

HD 58 dB to 30 MHz

55 dB to 250 MHz

RMS noise relative to 700 mV

Return Loss on BNCs >20dbto30MHz

Transcoder Accuracy 9bit

Composite Mode When using composite input only. Sourced

on Green channel of connector

Composite Amplitude, Typical 1V±5% including sync and 100% white

video

Composite Offset, Typical ±100 mV

Composite mode SNR,Typical 60 dB RMS to 700 mV with 20 MHz BW

1- 30

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

Specifications

Table 1- 30: LCD display

Characteristic Performance requirement Reference information

Display Area

Horizontal 13 cm

Vertical 10 cm

Resolution 1024 (H) x 768 (V) pixels

Color Palette 6 bits per component. LSB is dithered to

improve picture

Pixel Defects

≤6 bad pixels

Table 1- 31: External XGA Output (EXT DISPLAY)

Characteristic Performance requirement Reference information

Content Identical to front-panel LCD display

Output Levels 0.7 V or 1 V for RGB signals, selectable.

Fixed 5 V for H and V sync signals

Resolution 1024 (H) x 768 (V) pixels

Color Palette 6 bits per component

Connector Pin Assignments Pin 1: R Pin 6: GND Pin 11: NC

Pin 2: G Pin 7: GND Pin 12: NC

Pin 3: B Pin 8: GND Pin 13: HSync

Pin 4: NC Pin 9: NC Pin 14: VSync

Pin 5: GND Pin 10: NC Pin 15: NC

Table 1- 32: LTC Time Code Input / Ground Closures

Characteristic Performance requirement Reference information

LTC Input Connector Balanced, unterminated via rear-panel GC

remote connector. See Table 1--39 for

connector pinout

LTC Input Impedance Greater than 10 kΩ

LTC Signal Characteristics Longtitudinal Time Code per IEC Publica-

tion 461

LTC Signal Amplitude Range, Typical 0.2 V

single-ended

p-p

to 5.0 V

, balanced differential or

p-p

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

1- 31

Specifications

Table 1- 32: LTC Time Code Input / Ground Closures (Cont.)

Characteristic Reference informationPerformance requirement

Ground Closure Input Signaling (Preset Selection)

Ground Closure Output Characteristics One open collector output

TTL thresholds, 5 V maximum input, --0.5 V minimum input. Pull low to assert

Has internal 10 kΩ pull-up to 5 V on each input

Direct or encoded inputs must be asserted and stable for at least 150 ms to be recognized reliably. Inputs that are stable for 75 ms or less will never be recognized

Inputs are sampled every 16.6 ms. Five consecutive samples must all have the same code for the code to be accepted. It is possible to pulse the codes synchronously with the sampling process and trick the system. Users are encouraged to work within the intent of the specification to insure reliable operation

Pulledupby10kΩ resistor in series with a diode to +5 V. Pull down current is limited by 10 Ω resistor. Maximum current allowed is 100 mA

Table 1- 33: VITC Decoding

Characteristic Performance requirement Reference information

Sources Composite input A or B, SDI input A or B

No embedded time-code extraction

Table 1- 34: Serial Digital Video Interface (Input A, Input B)

Characteristic Performance requirement Reference information

Video Inputs Two inputs; only one input active at a time

Format Each input compatible with

SMPTE 292M/BTA--S004A and 270 Mb/s SMPTE 259M

Input Type 75 Ω BNC, internally terminated

1- 32

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

Specifications

Table 1- 34: Serial Digital Video Interface (Input A, Input B) (Cont.)

Characteristic Reference informationPerformance requirement

Cable Loss Accommodation With 1/SQRT(f) characteristic at ½ of serial

rate.

SD 0 to 30 dB attenuation Equivalent to approximately 300 m of

Belden 8281 at 270 Mb/s

HD 0 to 20 dB attenuation Equivalent to approximately 80 m of Belden

8281 at 1.485 Gb/s. Typical performance to

110 m

Launch Amplitude Accommodation, Typical

For Full Specification

Up to 20 dB Cable Loss

Jitter Tolerance, Typical 0.35 UI

Return Loss >15 dB to 1.5 GHz

Isolation Between Inputs >45 dB to 1 GHz

Time Base Range

800 mV  10%

800 mV  30%

above 2 MHz. Increases

p-p

proportional to 1/f below 2 MHz

≥50 ppm

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

1- 33

Specifications

Table 1- 35: Serial Video Output ( Serial Out/SDI PixMon)

Characteristic Performance requirement Reference information

Format 1.485 Gb/s, 1.4835 Gb/s, or 270 Mb/s

same as selected input. With Simultaneous inputs, configurable to be Channel 1 or Channel 2

With 1080P 60/59/50 dual link formats, combined links are down--converted to the related 1080i 4:2:2 single link format

With other dual link formats, combined links are down--converted to the related 4:2:2 10-bit single link format

Content -- Follows Active Input With Brightups

Selectable as loop output of active input, or Digital version of RGB/YPbPr analog pix monitor output. Gamut and/or line select brightups optionally displayable. For dual link formats, Pix Mon may be configured to display picture from link A alone, link B alone, or links A and B combined

Gamut error brightups appear one line below error

Output Level

Rise and Fall Time, Typical

SD 400 ps minimum,

HD 220 ps maximum, 20% to 80%

Return Loss 15 dB to 1.5 GHz

800 mV,  10% into 75 Ω load

800 ps maximum, 20% to 80%

1- 34

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

Specifications

Table 1- 36: External Reference

Characteristic Performance requirement Reference information

Input Type Passive loop-through, 75 Ω compensated

Operational Locks to analog bi-level and tri-level signals

of formats listed in Tables 1--45 through

1--47. Reference must have a frame rate

compatible with input. WFM mode and Line

Select derive timing from the external sync

information

Picture mode and Data mode do not use

timing from the external reference

With Simultaneous inputs, External

Reference settings apply to both channels

Analog Sync Format PAL

1080i 60 Hz 720p 59.94 Hz

NTSC 1080i 59.94 Hz 1080p 23.98 Hz 1080p 24 Hz

720p 50 720p 60 1080i 50 1080sf 23.98 1080sf 24

Input Signal Level, Typical --6dBto+6dB

DC Input Impedance 20 kΩ

Maximum Operating Input Voltage, Typical

Absolute Maximum Input Voltage, Typical

Inband Input Impedance, Typical

Return Loss. Typical >40 dB to 6 MHz

Hum Tolerance, Typical Operates with 500 mV

Signal/Noise Tolerance, Typical Operates to 25 dB

5VDC

≥ 15 kΩ

>29 dB to 30 MHz

at 50 or 60 Hz

p--p

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

1- 35

Specifications

Table 1- 37: Ethernet

Characteristic Performance requirement Reference information

IP Address Mode Supports manual and DHCP

SNMP For instrument control and feedback of

status. Complies with SNMP version 2

Connector Type RJ-45 LAN connector supporting 10/100

Base-T

Table 1- 38: USB

Characteristic Performance requirement Reference information

Type Host

Speed Complies with USB 1.1 and USB 2.0 full

speed specification

Full speed operation in accordance with USB 2.0 spec is 12 Mb/s.

1- 36

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

Table 1- 39: Remote Port

Performance

Characteristic

Alarm Output

Type Open collector. Has weak pull-up with a diode to +5 V

Connector Pin Assignments

requirement

Reference information

Pin # Signal 1Out;GND 2 In; Time Code Positive (LTC input) 3 In; Time Code Negative (LTC input) 4Out;GND 5 Out; Ground Closure Output 6 In; Preset Recall A1 7 In; Preset Recall A2 8 In; Preset Recall A3 9 In; Preset Recall A4

Specifications

Hex Binary

Pins 9,8,7,6

F 1111 none none

E 1110 Preset 1 CPS B

D 1101 Preset 2 CPS A

C 1100 SDI B

B 1011 Preset 3 SDI A

A 1010 Channel B

9 1001 Channel A

8 1000 Preset 8

7 0111 Preset 4 Preset 7

6 0110 Preset 6

5 0101 Preset 5

4 0100 Preset 4

3 0011 Preset 3

2 0010 Preset 2

1 0001 Preset 1

0 0000 unused

Direct mode selection

Encoded mode selection

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

1- 37

Specifications

Table 1- 40: Power Source

Characteristic Performance requirement Reference information

Electrical Rating 100 -- 240 VAC ±10%, 50/60 Hz

115 Watts max.

Supply Connection Detachable cord set

Power Consumption, Typical 50 to 110 VA at 110 or 240 VAC

Surge, Typical 7.5Ampsat90V

10 Amps at 240 V

Fuse Rating T3.5, 250 V

Not operator replaceable. Refer servicing to qualified service personnel

Table 1- 41: Miscellaneous

Characteristic Performance requirement Reference information

Real-time Clock Battery Life >10 year

1- 38

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

Physical Specifications

Table 1- 42: Physical Characteristics

Characteristic Standard

Dimensions

Height 5 1/4 inches (133.4 millimeters)

Width 8 1/2 inches (215.9 millimeters)

Depth 18 1/8 inches (460.4 millimeters)

Weight

Net 12 pounds (5.5 kilograms)

Shipping 21 pounds (9.6 kilograms), approximate

Specifications

Table 1- 43: Environmental Performance

Category Standards or description

Temperature

Operating 0 °Cto+40°C

Non Operating -- 2 0 °Cto+60°C

Humidity

Operating 20% to 80% relative humidity (% RH) at up to +40 °C, non-condensing

Non Operating 5% to 90% RH (relative humidity) at up to +60 °C, non-condensing

Altitude

Operating Up to 9,842 feet (3,000 meters)

Non Operating Up to 40,000 feet (12,192 meters)

Cooling Variable Fan. Forced air circulation with no air filter.

Required Clearances Do not bl ock the bezel or rear panel vent holes, or more t han half the vent holes on the sides

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

1- 39

Specifications

Declarati

Conf

Certifications and Compliances

Table 1- 44: Certifications and com pliances

Category Standards or description

EC Declaration of Conformity -EMC

Australia / New Zealand

on o

EMC

ormity--

Meets the intent of Directive 89/336/EEC for Electromagnetic Compatibility. Compliance was demonstrated to the following specifications as listed in the Official Journal of the European Communities:

EN 55103 Product family standard for audio, video, audio-visual and

entertainment lighting control apparatus for professional use.

Environment E2 -- commercial and light industrial

Part 1 Emission

EN 55022 Class B radiated and conducted emissions EN 55103--1, Annex A Radiated magnetic field emissions EN 55103--1, Annex B Inrush current; I peak = 3.1 amps

Part 2 Immunity

IEC 61000--4--2 Electrostatic discharge immunity IEC 61000--4--3 RF electromagnetic field immunity IEC 61000--4--4 Electrical fast transient / burst immunity IEC 61000--4--5 Power line surge immunity IEC 61000--4--6 Conducted RF Immunity IEC 61000--4--11 Voltage dips and interruptions immunity EN 55103--2, Annex A Radiated magnetic field immunity

EN 61000--3--2 AC power line harmonic emissions

Complies with EMC provision of Radiocommunications Act per the following standard(s):

AS/NZS 2064.1/2 Industrial, Scientific, and Medical Equipment: 1992

FCC Compliance Exempt from FCC Code of Federal Regulations 47, Part 15, Subpart B, Class A Limits.

EC Declaration of Conformity -Low Voltage

U.S. Nationally Recognized UL61010--1:2004 Standard for electrical measuring and test equipment. Testing Laboratory Listing

Canadian Certification CAN/CSA C22.2 No. 61010--1:2004 Safety requirements for electrical equipment for

Must use high-quality shielded cables to ensure compliance.

1- 40

Compliance was demonstrated to the following specification as listed in the Official Journal of the European Communities:

Low Voltage Directive

EN61010--1:2001 Safety requirements for electrical equipment for measurement

control and laboratory use.

measurement, control, and laboratory use.

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

Specifications

gyp

Table 1- 44: Certifications and com pliances (cont.)

Category Standards or description

Additional Compliance IEC61010-1:2001 Safety requirements for electrical equipment for measurement,

control, and laboratory use.

ISA S82.02.01:1999 Safety standard for electrical and electronic test, measuring,

controlling, and related equipment.

Installation (Overvoltage) Category Descriptions

Overvoltage Category CAT II

Pollution Degree Descriptions A measure of the contaminates that could occur in the environment around and within a product.

Terminals on this product may have different installation (overvoltage) category designations. The installation categories are:

CAT III Distribution-level mains (usually permanently connected). Equipment at this level is

typically in a fixed industrial location.

CAT II Local-level mains (wall sockets). Equipment at this level includes appliances, portable

tools, and similar products. Equi pment is usually cord-connected.

CAT I Secondary (signal level) or battery operated circuits of electronic equipment.

Typically the internal environment inside a product is considered to be the same as the external. Products should be used only in the environment for which they are rated.

Pollution Degree 1 No pollution or only dry, nonconductive pollution occurs. Products in

Pollution Degree 2 Normally only dry, nonconductive pollution occurs. Occasionally a

Pollution Degree 3 Conductive pollution, or dry, nonconductive pollution that becomes

Pollution Degree 4 Pollution that generates persistent conductivity through conductive

Pollution Degree Pollution Degree 2

Equipment type Test and Measurement

Safety Class Class I

this category are generally encapsulated, hermetically sealed, or located in clean rooms.

temporary conductivity that is caused by condensation must be expected. This location is a typical office/home environment. Temporary condensation occurs only when the product is out of service.

conductive due to condensation. These are sheltered locations where neither temperature nor humidity is controlled. The area is protected from direct sunshine, rain, or direct wind.

dust, rain, or snow. Typical outdoor locations.

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

1- 41

Specifications

Supported Input Formats and Allowed References

An X in Tables 1--45 through 1-- 47 indicates that that combination is supported and verified. Other combinations within each of these tables may work, but are unverified and only supported on a best effort basis.

Operation with an input from one of these three tables and a reference from another table is not supported (for example, a 1080i 50 input will not work with a 1080i 60 reference). Such mismatches may be reported on the display, and/or the display will “roll” due to the inherent incompatibility between the standards.

Table 1- 45: 25 Hz and 50 Hz Frame and Field rates

Reference Format

Input Format

720p 25 Hz

720p 50 Hz

1080p 25 Hz

1080sf 25 Hz

1080i 50 Hz

PAL

3,4

X X X

720p 25 720p 50 1080p 25 1080sf 25 1080i 50

576i 50 Hz (625) X X X

PAL50Hz

Table 1- 46: 59.94 Hz, 23.98 Hz, and 29.97 Hz Frame and Field rates

Reference Format

Input Format

720p 23.98 Hz

720p 29.97 Hz

720p 59.94 Hz

1080p 23.98 Hz

1080sf 23.98 Hz

1080p 29.97 Hz

1080sf 29.97 Hz

720p

NTSC

3,4

X X X X X

X X X

X X X X X

X X X

23.98

720p

29.97

720p

59.94

1080p

23.98

1080sf

23.98

1080p

29.97

1080sf

29.97

1080i

59.94

1- 42

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

Table 1- 46: 59.94 Hz, 23.98 Hz, and 29.97 Hz Frame and Field rates (Cont.)

Specifications

1080i

59.94

Input Format

1035i 59.94 Hz

1080i 59.94 Hz

3,4

1080sf

29.97

NTSC

720p

23.98

720p

29.97

720p

59.94

1080p

23.98

1080sf

23.98

1080p

29.97

X X X

483i 59.94 Hz (525) X X X

NTSC 59.94 Hz

WFM7000 and WFM7100 Opt. HD only.

Includes support dual- link standards with option DL.

Opt. CPS only.

Table 1- 47: 24 Hz, 30 Hz, and 60 Hz Frame and Field rates

Reference Format

Input Format

720p 24

720p 30

720p 60

1080p 24

1080sf 24

1080p 30

1080sf 30

1035i 60 Hz

1080i 60 Hz

3,4

WFM7000 and WFM7100 Opt. HD only.

Includes support dual- link standards with option DL.

720p 24

720p 30 720p 60 1080p 24 1080sf 24 1080p 30 1080sf 30 1080i 60

X X X X

X X

X X X X

X X

X X X X

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

1- 43

Specifications

080/,

1080/

080/,pp

Table 1- 48: Supported Standards

Image Standard

274M

295M (1250/50)

System Nomeclature

Interface Standard

Signal Type Image system number for indicated field/frame rate

1920 x 1080/P 4:2:2

Y’C’

10-bit 4:4:4(:4) R’G’B’ (A)

12-bit 4:4:4 R’G’B’

1920 x 1080/P, PsF

372M (dual link)

10-bit 4:4:4(:4) Y’C’

12-bit 4:4:4 Y’C’

12-bit 4:2:2(:4) Y’C’

292M 4:2:2

Y’C’

10-bit 4:4:4(:4) R’G’B’ (A)

1920 x

372M (dual link)

12-bit 4:4:4 R’G’B’

10-bit 4:4:4(:4) Y’C’

12-bit 4:4:4 Y’C’

12-bit 4:2:2(:4) Y’C’

292M 4:2:2

Y’C’

10-bit 4:4:4(:4) R’G’B’ (A)

12-bit 4:4:4 R’G’B’

2048 x 1080/P, PsF

372Mpropsed

10-bit 4:4:4(:4) Y’C’

12-bit 4:4:4 Y’C’

12-bit 4:2:2(:4) Y’C’

1920 x 1080/I, P

BC’R

60 59.94 50 30 29.97 25 24 23.98

1 2 3

7 8 9 10 11

(A)

7 8 9 10 11

(A)

7 8 9 10 11

4 5 6

(A)

4 5 6

(A)

4 5 6

X X X X X

(A)

X X X X X

(A)

Not supported

1- 44

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

Table 1- 48: Supported Standards (Cont.)

Specifications

Image Standard

240M 260M

296M 292M 4:2:2 Y’C’BC’

ITU--R BT.601

293M 720 x

System Nomeclature

1920 x 1035/I

720 x 576/I (625)

720 x 483/I (525)

480/P

Interface Standard

292M 4:2:2 Y’C’BC’

4:2:2 Y’C’BC’

292M

4:2:2 Y’C’BC’

Alarms

The following tables list the alarms that may be set for the waveform monitors.

Table 1- 49: Common Alarms

Image system number for indicated field/frame rateSignal Type

X X

1 2 3 4 5 6 7 8

Not supported

Alarm Description

HW Fault Indicates a system fault occurred. May require service

SDI Input Missing Indicates that no signal is detected on the selected SDI input

SDI Input Signal Lock Indicates unable to lock to selected SDI input signal

Reference Missing Indicates that no signal is detected on the Ref input when REF EXT is selected

Ref Lock Indicates unable to lock to the Ref input signal when REF EXT is selected

Ref Fmt Mismatch Indicates that the signal format detected on Ref input differs from the configured External Ref

format

RGB Gamut Error Indicates that the selected video input signal contains colors that violate the configured

Diamond gamut thresholds

Composite Gamut Error Indicates that the selected video input signal contains colors that violate the configured

Arrowhead gamut thresholds

Luma Gamut Error Indicates that the selected video input signal contains luminance levels that violate the

configured Luma gamut thresholds

Video Fmt Change Indicates that a change occurred in the format of the selected video input signal

Video Fmt Mismatch Indicates that the signal format detected on the selected video input differs from the configured

Input Format or that the format detected differs from that indicated by the signal’s SMPTE 352 payload identifier

Vid/Ref Mismatch Indicates that the Ref signal format is not compatible with the Input signal format. See Tables

1--45, 1--46, and 1--47, Supported Input Formats and Allowed References

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

1- 45

Specifications

Table 1- 49: Common Alarms (Cont.)

Alarm Description

Line Length Error Indicates that the length of a video line differs from that expected for the detected video format

Field Length Error Indicates that the length of a video field differs from that expected for the detected video format

EAV Place Error Indicates that the location of the EAV timing reference signal differs from that expected for the

detected video format.

SAV Place Error Indicates that the location of the SAV timing reference signal differs from that expected for the

detected video format

Timecode Vitc Missing Indicates that a break or discontinuity in the VITC has occurred

Timecode Vitc Invalid Indicates that the VITC was lost for one frame but has reappeared

Timecode Ltc Missing Indicates that a break or discontinuity in the LTC has occurred

Timecode Ltc Invalid Indicates that the LTC was lost for one frame but has reappeared

Timecode Anc Missing Indicates that a break or discontinuity in the ANC timecode has occurred

Timecode Anc Invalid Indicates that the ANC timecode was lost for one frame but has reappeared

Closed Caption Missing Indicates that the configured Closed Caption Transport stream or streams are not present in the

selected video input signal

CC Service(s) Missing Indicates that one or more configured EIA 608 Required Services is not present in the closed

caption data stream

EIA608 Caption Error Indicates a data error in an EIA608 data stream, excluding Extended Data Services and EIA708

Caption Data Packet errors

V--Chip Presence Error Indicates that no content advisory packet has been detected in the selected video input signal

for at least 4 seconds

V--Chip Format Error Indicates that a content advisory packet contained illegal data or was formatted incorrectly

Extended Data Services Error Indicates a data error in Extended Data Services of an EIA608 data stream

Caption Data Packet Error Indicates a Caption Data Payload error in the EIA708 stream carrying EIA608 data

Line 21 presence Error Indicates no VBI caption signal was found on the configured Line and Timing of the selected

video input signal

ANC CC Presence Error Indicates no caption ancillary data (SMPTE334M) was found in the s elected video input signal

TSID Missing Indicates no Transmission Signal Identifier was found in the selected video input signal

TSID Format Error Indicates detected Transmission Signal Identifier is not an allowed value

Table 1- 50: HD Specific Alarms (WFM7100, WFM7000 Opt. HD)

Alarm Description

Video Not HD Indicates that the selected SDI video input signal is not an HD format

Line Number Error Indicates that the encoded line number differs from the counted line number

Y Chan CRC Error Indicates that the encoded CRC for a line’s Y (luminance) samples differs from the calculated

CRC

1- 46

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

Specifications

Table 1- 50: HD Specific Alarms (WFM7100, WFM7000 Opt. HD) (Cont.)

Alarm Description

C Chan CRC Error Indicates that the encoded CRC for a line’s C (chrominance) samples differs from the calculated

CRC

Y Anc Checksum Error Indicates that the encoded checksum in a Y (luminance) ancillary data packet differs from the

calculated checksum

C Anc Checksum Error Indicates that the encoded checksum in a C (chrominance) ancillary data packet differs from the

calculated checksum

Table 1- 51: SD Specific Alarms

Alarm Description

AP CRC Error Indicates that encoded AP (active picture) CRC differs from the calculated CRC

FF CRC Error Indicates that encoded FF (full field) CRC differs from the calculated CRC

EDH Error Indicates that EDH (error detection and handling) has detected an error

Table 1- 52: Composite Specific Alarms (Opt. CPS)

Alarm Description

Cmpst Input Missing Indicates that no signal is detected on the selected composite video input

Cmpst Lock Indicates unable to lock to the selected composite video input

Table 1- 53: Audio Alarms (Opts. DS and AD Only)

Alarm Description

Over Indicates that the signal has exceeded the level specified by the Over Level setting for the

period of time specified by the Duration for Over set ting.

Silence Indicates that the signal has fallen below the level specified by the Silence Level setting for the

period of time specified by the Duration for Silence setting.

Clip Indicates that the number of consecutive, full--scale digital audio samples monitored has

exceeded the value specified by the Number of Samples for Clip setting.

Mute Indicates that the number of consecutive, “0” digital audio samples monitored has exceeded the

Number of Samples for Mute setting.

AES Unlocked Indicates unlocked condition of an AES input

CRC Error Indicates that the AES channel status CRC as calculated by the instrument does not agree with

the CRC embedded in the channel status bytes

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

1- 47

Specifications

Table 1- 53: Audio Alarms (Opts. DS and AD Only) (Cont.)

Alarm Description

VBit Indicates that the Validity bit is set high for one or more AES audio samples. I n the AES/EBU

standard, a set validity bit indicates that the sample is not suitable for conversion to audio

AES Parity Indicates incorrect parity in one or more AES audio samples

AES Sync Error Indicates a timing error of greater than 25% of an audio frame between the monitored AES input

and the selected AES reference input

Emb. Audio Presence Indicates that no embedded audio stream is detected in the selected SDI input

(Embedded) Checksum Indicates that the checksum present in the embedded audio stream does not match the

calculated checksum

(Embedded) Parity Indicates incorrect parity in one or more embedded audio samples

Emb. Group Sample Phase Indicates embedded audio streams are not time--aligned due to asynchronous audio or data

error

Table 1- 54: Additional Audio Alarm s (Opt. DDE Only)

Alarm Description

Dolby Format Indicates Dolby audio Format is not as expected

Table 1- 55: Additional Audio Alarm s (Opt. DDE Only)

Alarm Description

Dolby E /Video Frame Rate Error Indicates that the Dolby E stream frame rate is not the same as the video frame rate

1- 48

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

Performance Verification

This section contains a collection of manual procedures for verifying that the following waveform monitor products perform as warranted:

H WFM7100 models (with Option FP) and their options

H WFM7000 models (with Option FP) and their options

H WFM6100 models (with Option FP) and their options

This chapter is divided into two sections: Incoming Inspection Procedures and Performance Verification Procedures. The test procedures in this chapter provide

for an extensive confirmation of performance and functionality.

NOTE. Before performing any of the procedures and tests in this manual, the waveform monitor must have been operating for a warm--up period of at least 20 minutes and must be operating at an ambient temperature as listed in Table 1--43.

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

2- 1

Performance Verification

2- 2

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

Test Records

Use the tables on the following pages to record the measured performance or Pass/Fail status for each step of the specified test procedure. In cases where a measurement is made in different units than specified in the manual, the actual measured values that correspond to the specification limits are shown in parentheses.

Test Record - Function Tests

WFM6100, WFM7000, and WFM7100 with Option FP Waveform Monitor Functional Test Record

Instrument Serial Number: Certificate Number: Temperature: RH %: Date of Calibration: Technician:

Functional Test (Incoming Inspection) Incoming Outgoing Comments

Basic Turn On and Self Test

Front Panel LEDs

POST

Front Panel Test

LCD Pixel and Defects

LCD Color Palette and Advanced Diagnostics Test

LCD Color Palette Test

Advanced Diagnostics

Fan Test

SDI Bit Integrity

External Reference

NTSC Lock

Ref Missing

EYE (Options EYE and PHY only)

Eye Waveform

Jitter Waveform

Composite Input (Option CPS only)

CMPST A, WFM with NTSC

CMPST A, Vector with NTSC

CMPST A, Picture with NTSC

CMPST B, WFM with NTSC

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

2- 3

Test Records

WFM6100, WFM7000, and WFM7100 with Option FP Waveform Monitor Functional Test Record (cont.)

Instrument Serial Number: Certificate Number: Temperature: RH %: Date of Calibration: Technician:

Functional Test (Incoming Inspection) CommentsOutgoingIncoming

CMPST B, Vector with NTSC

CMPST B, Picture with NTSC

Analog Audio Input (Options AD, DD, & DDE only)

Analog Audio input A ports 1–6 display bar

Analog Audio input B ports 1--6 display bar

Analog Audio Output (Options AD, DD, & DDE only)

Digital Audio Input (Options AD, DS, DD, & DDE only)

AES Audio input A to Display Bar

AES Audio input B to Display Bar

Embedded Audio to Display Bar

Embedded Audio to Lissajous Display

Digital Audio Output (Options AD, DS, DD, & DDE only)

AES B 1--2 Audio Output

AES B 3--4 Audio Output

AES B 5--6 Audio Output

AES B 7--8 Audio Output

Dolby Decode (Options DD, & DDE only)

LTC Waveform and Decode

LTC Waveform

LTC Decode

Ground Closure Remote

Remote Input – Activate Preset

Remote Output – Ground Closure

Ethernet Functionality

Simultaneous Input Operation (Option SIM only)

Dual Link Format (Option DL only)

A/V Delay (Option AVD only)

2- 4

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

Test Record - All Instruments

If you are testing a WFM6100 or a WFM7000 without Opt HD, skip the HD-only entries in the record. Complete the other entries, which are common to all models.

WFM6100, WFM7000, and WFM7100 with Option FP Waveform Monitor Video Per formance Test Record

Instrument Serial Number: Certificate Number: Temperature: RH %: Date of Calibration: Technician:

Performance Test Minimum Incoming Outgoing Maximum

HD SDI Input Level Low and High (HD only)

Input A, Low Level 90% (720 mV)

Input A, High Level 110% (880 mV)

Input B, Low Level 90% (720 mV)

Input B, High Level 110% (880 mV)

EDH and HD SDI Input Equalization Range (HD only)

EDH Pass

Input A 20 dB

Input B 20 dB

HD SDI Loop Through Isolation (HD only) Pass

HD PixMon Frequency Response --0.92 dB

(--10%)

HD SDI Return Loss, A and B Inputs (HD only)

Input A --15 dB

Input B --15 dB

HD Cable Meter (HD only)

SDI A Input (Short Cable) 0m 17 m

SDI A Input (Long Cable) 76 m 127 m

SDI B Input (Short Cable) 0m 17 m

SDI B Input (Long Cable) 76 m 127 m

HD Jitter Noise Floor and Bounce (HD only)

Jitter Noise Floor Pass

10 second 10 Hz Jitter Bounce Pass

+0.82 dB (+10%)

Test Records

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

2- 5

Test Records

WFM6100, WFM7000, and WFM7100 with Option FP Waveform Monitor Video Per formance Test Record (cont.)

Instrument Serial Number: Certificate Number: Temperature: RH %: Date of Calibration: Technician:

Performance Test MaximumOutgoingIncomingMinimum

HD Jitter Readout Accuracy (HD only)

Jitter Trace Pass

Jitter Readout Pass

External Reference Return Loss

To6MHz --40 dB

To 30 M H z --29 dB

External Reference Formats supported: Bi-Level Pass

External Reference Lock Range --50 ppm 50 ppm

External Reference Formats supported: Tri-Level Pass

External Reference Lock in Presence of Hum: Bi-Level

LTC Decoding Functionality Pass

External Reference Lock in Presence of Hum: Tri-Level

Recovered Sine Wave Pass

Eye Gain

SDI A Input 760 mV 840 mV

SDI B Input 760 mV 840 mV

Reference Clock Amplitude and Frequency

Clock Amplitude Pass

Clock Frequency Pass

Eye Signal Bandwidth

SDI A 2.5 GHz Response

SDI A Minimum Response

SDI B 2.5 GHz Response

SDI B Minimum Response

Pass

2- 6

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

Test Record - Tests for SD-Equipped Instruments Only

SD-equipped instruments include all WFM6100 and WFM7100 instruments and all Option SD-equipped WFM7000 instruments.

WFM7100 with Option FP Waveform Monitor Video Performance Test Record (Option SD only)

Instrument Serial Number: Certificate Number: Temperature: RH %: Date of Calibration: Technician:

Performance Test Minimum Incoming Outgoing Maximum

SD SDI Input Level Low and High

Input A, Low Level 720 mV

Input A, High Level 880 mV

Input B, Low Level 720 mV

Input B, High Level 880 mV

SD SDI Input Equalization Range and EDH

EDH Pass

Input A 30 dB

Input B 30 dB

SD PixMon Multiburst Frequency Response --0.92 dB ( --10%) +0.82 dB (+10%)

Analog Pixmon Gain and Offset

YPbPr Pass

RGB Pass

Composite Pass

SD SDI Serial Output Amplitude 760 mV 840 mV

SD SDI Return Loss

Input A --25 dB

Input B --25 dB

SD VITC Decoding Functionality Pass

SD Cable Meter

SDI A Input (Short Cable) 0m 17 m

SDI A Input (Long Cable) 76 m 127 m

SDI B Input (Short Cable) 0m 17 m

SDI B Input (Long Cable) 76 m 127 m

SD Equalized Eye Gain Pass

SD Jitter Noise Floor and Bounce

Jitter Noise Floor Pass

Test Records

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

2- 7

Test Records

WFM7100 with Option FP Waveform Monitor Video Performance Test Record (Option SD only) (cont.)

Instrument Serial Number: Certificate Number: Temperature: RH %: Date of Calibration: Technician:

Performance Test MaximumOutgoingIncomingMinimum

SD Jitter Readout Accuracy

Jitter Trace Pass

Jitter Readout Pass

Jitter Vibration Pass

2- 8

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

Test Record - Option CPS only

WFM7100 with Option FP Waveform Monitor Video Performance Test Record (Options CPS only)

Instrument Serial Number: Certificate Number: Temperature: RH %: Date of Calibration: Technician:

Performance Test Minimum Incoming Outgoing Maximum

Test Records

Composite Analog Frequency Response 99%

(7 mV)

Composite Analog Delay Variation Over Frequency (Group Delay)

Composite Analog Pulse to Bar Ratio 99%

Composite Analog Field Rate Tilt --0.5%

Composite Analog Line Rate Tilt --0.5%

Composite Analog Input Return Loss, A and B Inputs

Input A --40 dB

Input B --40 dB

Composite Analog Input DC Offset with Restore Off -- 1 0 m V 10 mV

Composite Analog Input Clamp Off Check Pass/Fail

Composite Analog Input DC Restore Hum Attenuation

DC Restore Off Pass

Fast Mode

--10ns

(--7.1 mV)

(--7 mV)

(--3.5 mV)

101%

(--7 mV)

+10ns

(7.1 mV)

101%

(7 mV)

+0.5%

(+3.5 mV)

+0.5%

(+3.5 mV)

(0mV)

Slow Mode 90%

(643 mV)

Composite Analog Vertical Measurement Accuracy 707.71 mV 722.01 mV

External Reference Lock Range --50 ppm 50 ppm

VITC Decoding Functionality Pass

(35 mV)

110%

(785 mV)

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

2- 9

Test Records

Test Record - Options AD and DDE only

WFM7100 with Option FP Waveform Monitor Audio Options AD and DDE only Test Record

Instrument Serial Number: Certificate Number: Temperature: RH %: Date of Calibration: Technician:

Performance Test Minimum Incoming Outgoing Maximum

AES Audio Return Loss

AESA1--2In --25 dB

AESA3--4In --25 dB

AESA5--6In --25 dB

AESA7--8In --25 dB

AESB1--2I/O --25 dB

AESB3--4I/O --25 dB

AESB5--6I/O --25 dB

AESB7--8I/O --25 dB

AES Audio Input Sample Rate

AES A 1--2 In (96 kHz) pass

AES A 3--4 In (96 kHz) pass

AES A 5--6 In (96 kHz) pass

AES A 7--8 In (96 kHz) pass

AES A 1--2 In (35 kHz) pass

AES A 3--4 In (35 kHz) pass

AES A 5--6 In (35 kHz) pass

AES A 7--8 In (35 kHz) pass

AES Audio Output Amplitude

AESB1--2I/O 0.9 v 1.1 v

AESB3--4I/O 0.9 v 1.1 v

AESB5--6I/O 0.9 v 1.1 v

AESB7--8I/O 0.9 v 1.1 v

AES Audio Output Jitter

AESB1--2I/O Pass

AESB3--4I/O Pass

AESB5--6I/O Pass

AESB7--8I/O Pass

AES Audio Level Meter Accuracy Over Frequency

AESA1In(100Hz) Pass

2- 10

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

WFM7100 with Option FP Waveform Monitor Audio Options AD and DDE only Test Record (cont.)

Instrument Serial Number: Certificate Number: Temperature: RH %: Date of Calibration: Technician:

Performance Test MaximumOutgoingIncomingMinimum

AESA2In(100Hz) Pass

AESA3In(100Hz) Pass

AESA4In(100Hz) Pass

AESA5In(100Hz) Pass

AESA6In(100Hz) Pass

AESA7In(100Hz) Pass

AESA8In(100Hz) Pass

AES A 1 In (1 kHz) Pass

AES A 2 In (1 kHz) Pass

AES A 3 In (1 kHz) Pass

AES A 4 In (1 kHz) Pass

AES A 5 In (1 kHz) Pass

AES A 6 In (1 kHz) Pass

AES A 7 In (1 kHz) Pass

AES A 8 In (1 kHz) Pass

AES A 1 In (19 kHz) Pass

AES A 2 In (19 kHz) Pass

AES A 3 In (19 kHz) Pass

AES A 4 In (19 kHz) Pass

AES A 5 In (19 kHz) Pass

AES A 6 In (19 kHz) Pass

AES A 7 In (19 kHz) Pass

AES A 8 In (19 kHz) Pass

Test Records

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

2- 11

Test Records

WFM7100 with Option FP Waveform Monitor Audio Options AD and DDE only Test Record (cont.)

Instrument Serial Number: Certificate Number: Temperature: RH %: Date of Calibration: Technician:

Performance Test MaximumOutgoingIncomingMinimum

Headphone level accuracy over frequency

Left (100 Hz) --0.75 dBu 1.25 dBu

Right (100 Hz) --0.75 dBu 1.25 dBu

Left (1 kHz) --0.75 dBu 1.25 dBu

Right (1 kHz) --0.75 dBu 1.25 dBu

Left (19 kHz) --0.75 dBu 1.25 dBu

Right (19 kHz) --0.75 dBu 1.25 dBu

Analog Audio Level Meter Accuracy Over Frequency

Analog Input A1 (100 Hz) 17.5 dBu 18.5 dBu

Analog Input A2 (100 Hz) 17.5 dBu 18.5 dBu

Analog Input A3 (100 Hz) 17.5 dBu 18.5 dBu

Analog Input A4 (100 Hz) 17.5 dBu 18.5 dBu

Analog Input A5 (100 Hz) 17.5 dBu 18.5 dBu

Analog Input A6 (100 Hz) 17.5 dBu 18.5 dBu

Analog Input A1 (1 kHz) 17.5 dBu 18.5 dBu

Analog Input A2 (1 kHz) 17.5 dBu 18.5 dBu

Analog Input A3 (1 kHz) 17.5 dBu 18.5 dBu

Analog Input A4 (1 kHz) 17.5 dBu 18.5 dBu

Analog Input A5 (1 kHz) 17.5 dBu 18.5 dBu

Analog Input A6 (1 kHz) 17.5 dBu 18.5 dBu

Analog Input A1 (19 kHz) 17.5 dBu 18.5 dBu

Analog Input A2 (19 kHz) 17.5 dBu 18.5 dBu

Analog Input A3 (19 kHz) 17.5 dBu 18.5 dBu

Analog Input A4 (19 kHz) 17.5 dBu 18.5 dBu

Analog Input A5 (19 kHz) 17.5 dBu 18.5 dBu

Analog Input A6 (19 kHz) 17.5 dBu 18.5 dBu

Analog Input B1 (100 Hz) 17.5 dBu 18.5 dBu

Analog Input B2 (100 Hz) 17.5 dBu 18.5 dBu

Analog Input B3 (100 Hz) 17.5 dBu 18.5 dBu

Analog Input B4 (100 Hz) 17.5 dBu 18.5 dBu

Analog Input B5 (100 Hz) 17.5 dBu 18.5 dBu

Analog Input B6 (100 Hz) 17.5 dBu 18.5 dBu

2- 12

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

WFM7100 with Option FP Waveform Monitor Audio Options AD and DDE only Test Record (cont.)

Instrument Serial Number: Certificate Number: Temperature: RH %: Date of Calibration: Technician:

Performance Test MaximumOutgoingIncomingMinimum

Analog Audio Level Meter Accuracy Over Frequency

Analog Input B1 (1 kHz) 17.5 dBu 18.5 dBu

Analog Input B2 (1 kHz) 17.5 dBu 18.5 dBu

Analog Input B3 (1 kHz) 17.5 dBu 18.5 dBu

Analog Input B4 (1 kHz) 17.5 dBu 18.5 dBu

Analog Input B5 (1 kHz) 17.5 dBu 18.5 dBu

Analog Input B6 (1 kHz) 17.5 dBu 18.5 dBu

Analog Input B1 (19 kHz) 17.5 dBu 18.5 dBu

Analog Input B2 (19 kHz) 17.5 dBu 18.5 dBu

Analog Input B3 (19 kHz) 17.5 dBu 18.5 dBu

Analog Input B4 (19 kHz) 17.5 dBu 18.5 dBu

Analog Input B5 (19 kHz) 17.5 dBu 18.5 dBu

Analog Input B6 (19 kHz) 17.5 dBu 18.5 dBu

Digital Input to Analog Output Gain Accuracy Over Frequency

Analog Output 1 (100 Hz) 17.5 dBu 18.5 dBu

Analog Output 2 (100 Hz) 17.5 dBu 18.5 dBu

Analog Output 3 (100 Hz) 17.5 dBu 18.5 dBu

Analog Output 4 (100 Hz) 17.5 dBu 18.5 dBu

Analog Output 5 (100 Hz) 17.5 dBu 18.5 dBu

Analog Output 6 (100 Hz) 17.5 dBu 18.5 dBu

Analog Output 7 (100 Hz) 17.5 dBu 18.5 dBu

Analog Output 8 (100 Hz) 17.5 dBu 18.5 dBu

Analog Output 1 (1 kHz) 17.5 dBu 18.5 dBu

Analog Output 2 (1 kHz) 17.5 dBu 18.5 dBu

Analog Output 3 (1 kHz) 17.5 dBu 18.5 dBu

Analog Output 4 (1 kHz) 17.5 dBu 18.5 dBu

Analog Output 5 (1 kHz) 17.5 dBu 18.5 dBu

Analog Output 6 (1 kHz) 17.5 dBu 18.5 dBu

Analog Output 7 (1 kHz) 17.5 dBu 18.5 dBu

Analog Output 8 (1 kHz) 17.5 dBu 18.5 dBu

Analog Output 1 (19 kHz) 17.5 dBu 18.5 dBu

Analog Output 2 (19 kHz) 17.5 dBu 18.5 dBu

Test Records

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

2- 13

Test Records

WFM7100 with Option FP Waveform Monitor Audio Options AD and DDE only Test Record (cont.)

Instrument Serial Number: Certificate Number: Temperature: RH %: Date of Calibration: Technician:

Performance Test MaximumOutgoingIncomingMinimum

Analog Output 3 (19 kHz) 17.5 dBu 18.5 dBu

Analog Output 4 (19 kHz) 17.5 dBu 18.5 dBu

Analog Output 5 (19 kHz) 17.5 dBu 18.5 dBu

Analog Output 6 (19 kHz) 17.5 dBu 18.5 dBu

Analog Output 7 (19 kHz) 17.5 dBu 18.5 dBu

Analog Output 8 (19 kHz) 17.5 dBu 18.5 dBu

Analog Input to Analog Output Gain Accuracy Over Frequency

Analog Output 1 (100 Hz) Pass

Analog Output 2 (100 Hz) Pass

Analog Output 3 (100 Hz) Pass

Analog Output 4 (100 Hz) Pass

Analog Output 5 (100 Hz) Pass

Analog Output 6 (100 Hz) Pass

Analog Output 7 (100 Hz) Pass

Analog Output 8 (100 Hz) Pass

Analog Output 1 (1 kHz) Pass

Analog Output 2 (1 kHz) Pass

Analog Output 3 (1 kHz) Pass

Analog Output 4 (1 kHz) Pass

Analog Output 5 (1 kHz) Pass

Analog Output 6 (1 kHz) Pass

Analog Output 7 (1 kHz) Pass

Analog Output 8 (1 kHz) Pass

Analog Output 1 (19 kHz) Pass

Analog Output 2 (19 kHz) Pass

Analog Output 3 (19 kHz) Pass

Analog Output 4 (19 kHz) Pass

Analog Output 5 (19 kHz) Pass

Analog Output 6 (19 kHz) Pass

Analog Output 7 (19 kHz) Pass

Analog Output 8 (19 kHz) Pass

2- 14

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

Test Records

Test Record - Option DS only

WFM7100 with Option FP Waveform Monitor Audio Option DS only Test Record

Instrument Serial Number: Certificate Number: Temperature: RH %: Date of Calibration: Technician:

Performance Test Minimum Incoming Outgoing Maximum

AES Audio Return Loss

AESA1--2In --25 dB

AESA3--4In --25 dB

AESA5--6In --25 dB

AESA7--8In --25 dB

AESB1--2I/O --25 dB

AESB3--4I/O --25 dB

AESB5--6I/O --25 dB

AESB7--8I/O --25 dB

AES Audio Input Sample Rate

AES A 1--2 In (96 kHz) Pass

AES A 3--4 In (96 kHz) Pass

AES A 5--6 In (96 kHz) Pass

AES A 7--8 In (96 kHz) Pass

AES B 1--2 I/O (96 kHz) Pass

AES B 3--4 I/O (96 kHz) Pass

AES B 5--6 I/O (96 kHz) Pass

AES B 7--8 I/O (96 kHz) Pass

AES A 1--2 In (35 kHz) Pass

AES A 3--4 In (35 kHz) Pass

AES A 5--6 In (35 kHz) Pass

AES A 7--8 In (35 kHz) Pass

AES B 1--2 I/O (35 kHz) Pass

AES B 3--4 I/O (35 kHz) Pass

AES B 5--6 I/O (35 kHz) Pass

AES B 7--8 I/O (35 kHz) Pass

AES Audio Output Amplitude

AESB1--2I/O 0.9 v 1.1 v

AESB3--4I/O 0.9 v 1.1 v

AESB5--6I/O 0.9 v 1.1 v

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

2- 15

Test Records

WFM7100 with Option FP Waveform Monitor Audio Option DS only Test Record (cont.)

Instrument Serial Number: Certificate Number: Temperature: RH %: Date of Calibration: Technician:

Performance Test MaximumOutgoingIncomingMinimum

AESB7--8I/O 0.9 v 1.1 v

AES Audio Output Jitter

AESB1--2I/O Pass

AESB3--4I/O Pass

AESB5--6I/O Pass

AESB7--8I/O Pass

AES Audio Level Meter Accuracy Over Frequency

AESA1In(100Hz) Pass

AESA2In(100Hz) Pass

AESA3In(100Hz) Pass

AESA4In(100Hz) Pass

AESA5In(100Hz) Pass

AESA6In(100Hz) Pass

AESA7In(100Hz) Pass

AESA8In(100Hz) Pass

AES A 1 In (1 kHz) Pass

AES A 2 In (1 kHz) Pass

AES A 3 In (1 kHz) Pass

AES A 4 In (1 kHz) Pass

AES A 5 In (1 kHz) Pass

AES A 6 In (1 kHz) Pass

AES A 7 In (1 kHz) Pass

AES A 8 In (1 kHz) Pass

AES A 1 In (19 kHz) Pass

AES A 2 In (19 kHz) Pass

AES A 3 In (19 kHz) Pass

AES A 4 In (19 kHz) Pass

AES A 5 In (19 kHz) Pass

AES A 6 In (19 kHz) Pass

AES A 7 In (19 kHz) Pass

AES A 8 In (19 kHz) Pass

2- 16

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

WFM7100 with Option FP Waveform Monitor Audio Option DS only Test Record (cont.)

Instrument Serial Number: Certificate Number: Temperature: RH %: Date of Calibration: Technician:

Performance Test MaximumOutgoingIncomingMinimum

Headphone level accuracy over frequency

Left (100 Hz) --0.75 dBu 1.25 dBu

Right (100 Hz) --0.75 dBu 1.25 dBu

Left (1 kHz) --0.75 dBu 1.25 dBu

Right (1 kHz) --0.75 dBu 1.25 dBu

Left (19 kHz) --0.75 dBu 1.25 dBu

Right (19 kHz) --0.75 dBu 1.25 dBu

Test Records

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

2- 17

Test Records

2- 18

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

Incoming Inspection

This section contains functional/operational checks appropriate to an incoming inspection.

The waveform monitor must have been operating for a warm-up period of at least 20 minutes, and must be operating at an ambient temperature as listed in Table 1--43 on page 1--39.

Use the following procedures to check the basic functionality of WFM6100, WFM7000, and WFM7100 Waveform Monitorswith Option FP installed. The checks are arranged by model and option so that you can choose the sections that are appropriate for your instrument. The last two sections are for less critical waveform monitor features: the ground closure and Ethernet ports. You need only test these if you intend to use them. In general, you should test in the order presented, since later tests might depend on items checked in the earlier tests.

Required Equipment

The following equipment is required to perform the incoming inspection procedure.

Table 2- 1: Required Test Equipment

Test Equipment

XGA Monitor Computer monitor capable of 1024 x 768 x

75 Ω coaxial cables

(3 required)

75 Ω Terminator for Analog Video Male connector, Precision Tektronix part number

Analog audio breakout cable (required for Audio Options AD and DDE only)

Dolby bit-stream generator Generate Dolby Digital, Dolby E and PCM

Requirements Example

60 Hz scan rate

General purpose digital video

Male-to-male BNC connectors 1 or 2 meters long

DB62 to XLR I/O Tektronix part number

bit streams at 48 kHz.

AES3ID--1995/SMPTE 276M output (75 Ω BNC)

Belden 8281.

Tektronix part numbers 012--0159--00 or

012--0159--01

011--0102--03

012-1688-00

Dolby Laboratories DM100 Bitstream

Analyzer. (Option DDE only.)

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

2- 19

Incoming Inspection

Table 2- 1: Required Test Equipment (Cont.)

Test Equipment

SDI serial digital video test generator, with embedded audio and composite signal source

NTSC Black Tektronix TG2000 with BG1 and additional

1080i 59.94 HD signals required for WFM7100 or WFM7000 with Option HD:

100% color bars

10-bit shallow ramp

SDI Matrix Split Field Pathologi cal Si gnal

100% sweep 525/270 SD signals required:

100% color bars

10-bit shallow ramp

SDI Matrix Split Field Pathologi cal Si gnal

ExampleRequirements

modules indicated in the next three rows HDVG1 module for TG2000 (Embedded

audio needed for audio options AD, DS, DDE)

DVG1 module for TG2000 (Embedded audio needed for audio options AD, DS, DDE)

100% sweep Composite signals required for Option

CPS:

NTSC SMPTE bars

Dual link signals required for Options DL and SIM

AES Audio Signal Generator 48 kHz, 24 bit word length signals Rohde & Schwarz UPL06, Tektronix AM700

AES Audio Signal Analyzer Rohde & Schwarz UPL06, Tektronix

Analog Audio Signal Generator Rohde & Schwarz UPL06, Tektronix AM700

Waveform Monitor Used to test SDI Pixmon output Tektronix WFM7100 or WFM700

Video Test Signals SDI 525 10-bit shallow ramp

SDI 525 100% sweep

NTSC black

NTSC SMPTE bars

LTC generator Horita TRG--50 or Adrienne AEC--Box--28

Voltmeter Fluke 87 or equivalent

15-pin Dsub male connector and cable Used to mate with the ground closure port See Figure 1--2 on page 2--55 for wiring

Computer and ethernet cable Used to test Ethernet connection Generic equipment

Dual Link Generator Tektronix TG700

AVG1 module for TG2000

TG700 with HDVG7 and DVG7 modules; or TG2000 with HDVG1 and DVG1 modules

and AM70.

AM700.

and AM70.

Provided by Tektronix TG2000 as specified above

diagram of cable

2- 20

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

Incoming Inspection Tests

Incoming Inspection

Basic Turn On and

Self Test

1. Connect an XGA monitor to the EXT DISPLAY connector on the rear of

the waveform monitor.

2. Connect the AC line cord to the rear of the instrument and to a 100 to

240 VAC source. There is no power switch on the waveform monitor, so the instrument will turn on as soon as you apply power.

3. Look at the front panel immediately after you apply power. The MAG, LINE SEL,andCURSOR buttons should be lit. The other front-panel

buttons will light one at a time, in sequence. Verify that all buttons do light. The sequence will repeat until the Boot Loader process completes (approximately 30 seconds).

4. Record pass or fail in the test record for Front Panel LEDs.

5. After about 50 seconds, the power-on diagnostic page should appear on the

monitor.

6. Verify that all self tests pass. Any failures will be shown in red. The results of the power-on diagnostics are erased from the screen, but you can view the results by selecting CONFIG > Utilities > View Diagnostics Log > SEL.

7. After the diagnostics are finished, the instrument state is restored. When the progress indicator in the status bar is finished, the instrument has finished initializing.

Restore the Factory

Presets

Front Panel Test

8. Record Pass or Fail for the POST in the test record.

9. If it is still open, exit the Diagnostics Log.

1. Follow these steps to reset the waveform monitor to the Factory Presets:

a. Press and hold the PRESET button.

b. Select Recall Preset > Recall Factory Preset.

c. Press the SEL button.

1. Set the waveform monitor to the Factory Presets (see above). Wait for the

process to complete as indicated by the progress indicator. Record Pass or Fail in the test record.

2. Connect a 525/270 color bar signal from DVG1 to the SDI A input

3. Press FULL to set the active tile to full screen.

4. Turn the HORIZONTAL and VERTICAL knobs and verify the waveform

moves appropriately.

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

2- 21

Incoming Inspection

5. Press HELP to display the online help.

6. Press each of the front panel buttons.

Each button should flash as you press it. Most buttons will bring up help text related to that button in the right pane of the help screen. Some buttons, such as the presets, all bring up the same information, so you may need to alternate between preset buttons and another button to see the text change. The navigation keys (the four arrow keys and the SEL key) do not bring up help text. They are used to navigate the help panes and content.

7. Press the right arrow key until the Help Contents pane in the upper-left

corner is highlighted.

8. Turn the GENERAL knob and verify the selector box moves up and down

the list of topics.

9. Press HELP to exit help.

10. Record Pass or Fail for Buttons and Knobs in the test record.

LCD Pixel Defects

1. Set the waveform monitor to display a white screen:

a. Press the CONFIG button.

b. Select Utilities > Screen Solid Color > Select Color > White

c. Press the SEL button.

2. Count any pixels stuck low (not white).

3. While the screen is all white, inspect for visible defects that exceed the limits

in Table 2--2 (page 2--23).

NOTE. Inspection should be done from 18” away from the display, under normal room lighting. Loose dust on the front of the screen does not constitute a defect

4. Press the SEL button to cancel the white screen.

5. Set the waveform monitor for an all black screen:

a. Select Utilities > Screen Solid Color > Select Color > Black

b. Press the SEL button.

6. Count any pixels stuck high (not black).

2- 22

7. Press the SEL button to cancel the black screen.

8. Check that the total number of pixels counted in steps 2 and 6 is less

than six.

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

Table 2- 2: LCD Visual Defects

Incoming Inspection

Defect Type

Circular Defect

Black Defect (opaque) >0.005I None

Linear Defect (Scratches)

Stains, discolorations, streaks, scuffs

Defects should be visible from 18I under normal lighting. If you have to hol d it closer or use special lighting to see the defect, it is not a rejectable defect.

For irregular defects, use (LengthxWidth)/2.

Allowable Defect

>0.020I None

0.015I to 0.020I Maximum of two allowed within a 2I circle

>0.004I width None

0.003I to 0.004Iwide

0.0021I to

0.0030Iwide

0.0010I to

0.0020Iwide

Allowed if they fade when backlit

Max length 0.500I Mi n separation

0.250I

Max length 1.000I Mi n separation

0.150I

Max length 1.500I Mi n separation

0.050I

9. Record pass or fail for Pixel Defect in the test record.

LCD Color Palette and

Advanced Diagnostics

Test

10. Press the CONFIG button to close the configuration menu.

1. Run the Advanced Diagnostics:

a. Press the CONFIG button.

b. Select Utilities > Run Advanced Diags

c. Press the SEL button.

d. Select Continue in the Advanced Diagnostics message window.

e. Press the SEL button.

LCD Color Palette.

2. Verify the LCD Color Palette by observing the white and red ramps at the top of the screen, and the green and blue ramps at the bottom of the screen:

H The topmost ramp is white. It should vary smoothly from black on the

left side of the screen to white on the right side of the screen.

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

2- 23

Incoming Inspection

H The ramp just below the white ramp is red. It should vary smoothly from

black on the left side of the screen to bright red on the right side of the screen.

H The bottom ramp is blue. It should vary smoothly from black on the left

side of the screen to bright blue on the right side of the screen.

H The ramp just above the blue ramp is green. It should vary smoothly

from black on the left side of the screen to bright green on the right side of the screen.

For each of these ramps it is normal to have some discrete steps in the brightness. The width of these steps should not exceed 0.1 inches. Some very fine lines may be visible in the ramps. This is normal.

3. Record Pass or Fail in the test record for the LCD Color Palette test.

Advanced Diagnostics.

4. Verify the following frequencies and pulse widths, shown in the diagnostics

display, are within the limits listed in Table 2--3.

Table 2- 3: Diagnostics Limits

Readout Nominal Min Max

VGA Clock Frequency 64.4475 MHz 64.4375 MHz 64.4575 M Hz

QDR Clock Frequency 25.1750 MHz 25.1650 MHz 25.1850 MHz

SD Eye Frequency

HD Eye Frequency

Audio PLL 1 Frequency 12.2880 MHz 12.2780 MHz 12.2980 MHz

Audio PLL 2 Frequency 12.2880 MHz 12.2780 MHz 12.2980 MHz

Hsync PW 20.6 s 20.4 s 20.8 s

Vsync PW 19074.9 s 18974.9 s 19174.9 s

Lissajous Frequency

Options EYE and PHY only.

For WFM6100 this will display 0.000 MHz.

Options AD and DDE only.

1,2

36.0204 MHz 35.9844 MHz 36.0564 MHz

59.3700 MHz 59.3106 MHz 59.4924 MHz

61.4400 MHz 61.3900 MHz 61.4900 MHz

5. Verify that all the tests in the middle section of the screen have a green Pass

status.

2- 24

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

Incoming Inspection

6. Press the SEL button to reboot the unit in normal operation. It may take some time before the button press has any effect. You can cycle the power instead.

7. Record Pass or Fail for Advanced Diagnostics in the test record.

Fan Test

SDI Input – Check Output

Validity and Bit Integrity

You should be able to hear the fans and feel air coming out the back of the instrument. At low temperatures the fans will turn slowly and be very quiet. Record Pass or Fail for Fan Test in the test record.

1. Connect an SDI 10-bit shallow-ramp signal to the SDI A input. Use a signal type appropriate to the options installed on the unit under test:

H Option HD: 1080 59.94i 10-bit shallow ramp matrix from HDVG1

H Option SD: 525/270 10-bit shallow ramp matrix from DVG1

2. Set the waveform monitor to the Factory Presets (see Page 2--21).

3. Set the display style to Parade:

a. Press and hold the WFM button to display the waveform menu.

b. Select Display Style.

c. Use the SEL button to select Parade.

d. Press the WFM button.

4. Turn off the Pb waveform:

a. Press and hold the WFM button to display the waveform menu.

b. Select Pb.

c. Use the SEL button to select Off.

d. Press the WFM button.

5. Set the display vertical gain:

a. Press and hold the GAIN button to display the gain menu.

b. Select Gain Settings.

c. Use the arrow keys to select x10.

d. Press the GAIN button once to close the Gain menu. The GAIN button

should remain lit.

6. Press the FULL button to expand the waveform tile to full screen:

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

2- 25

Incoming Inspection

7. Connect the waveform monitor SDI OUT to a second, known good,

waveform monitor SDI A input.

8. Repeat steps 2 through 5 for the second waveform monitor.

9. Perform steps 10 through 14, on both the DUT (to check the Serial Input),

and the second waveform monitor (to check the DUT Serial Output)

10. Position the waveform so that you can check the ramps.

11. Check a major division of both ramps in the signals. Check for 11 to 13 even

vertical steps over a major division (10 mV). The steps should always step upward in a monotonic ramp. On the second waveform monitor, check that there are no EDH errors (SD). If relevant, check that there are no CRC errors (HD) by pressing and holding the STATUS button and selecting Video

Session.

12. Press the GAIN button on both waveform monitors so that the button is no

longer lit, to return the instruments to x1 gain.

13. Change the input signal to a 100% sweep.

External Reference

14. Verify the sine waves are uniform and do not have steps. Also verify the

amplitude is 700 mV. Check that there are no EDH errors (SD) or CRC errors (HD) on the second waveform monitor.

15. If you want, move the signal input to input B by pressing the CONFIG button and then selecting Outputs > SDI Output > Loopout B. Repeat steps 5 through 14.

16. Record Pass or Fail for SDI Bit Integrity in the test record.

17. Disconnect the second waveform monitor.

1. Restore the Factory Preset (See Page 2--21).

2. Connect a signal to an input. Use a signal type appropriate to the options

installed on the unit under test, such as:

H Option HD: SDI input; 1080 59.94i 10-bit shallow ramp from HDVG1

H Option SD: SDI input; 525/270 10-bit shallow ramp from DVG1

H Option CPS: CMPST input; NTSC or PAL color bars from AVC1

3. Apply an NTSC signal to the External Reference input from the Analog Signal Generator. Install a termination on the loopthrough.

2- 26

4. Press EXT REF on the instrument front panel.

5. The status bar in the lower left-hand corner of the display should display

Ref: NTSC.

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

Incoming Inspection

6. Press the Display Select 4 button, then the WFM button, and then the SWEEP button.

7. Verify that both WFM tiles are stable.

8. Record Pass or Fail for NTSC Lock in the test record.

9. Remove the NTSC signal from the reference input.

10. Both WFM tiles should “unlock” and scroll.

11. The status bar in the lower left-hand corner of the display should display

Ref: Ext. Missing.

12. Record Pass or Fail for Ref Missing in the test record.

Eye

(Options EYE and PHY

Only)

1. Restore the Factory Preset (See Page 2--21).

2. Connect a signal to the SDI A input. Use a signal type appropriate to the

options installed on the unit under test, such as:

H Option HD: 1080 59.04i color bars from HDVG1

H Option SD: 525/270 color bars from DVG1

3. Press the EYE button.

4. Check for the presence of a stable eye diagram in tile 1. (The actual wave

shape depends on the generator signal.)

5. Record Pass or Fail for Eye Waveform in the test record.

6. Proceed to the next step if option PHY is present. Otherwise, this test is

complete.

7. Set the Eye waveform display to jitter display:

a. Press and hold the EYE button to display the Eye waveform menu.

b. Select Display Type > Jitter Display > Jitter Display.

8. Check for a flat line wave shape. (The residual jitter level depends on the

quality of the generator signal.)

9. Record Pass or Fail for Jitter Waveform in the test record.

Composite Input

(Option CPS Only)

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

1. Restore the Factory Preset (See Page 2--21).

2. Apply an NTSC SMPTE color bar signal from the TG2000 AVC1 module to

the Composite A input (CMPST A). Install a termination on the loop through.

2- 27

Incoming Inspection

3. Press Input C to select the CMPST A input.

4. Observe the WFM display in tile 1, the signal should be aligned with the

zero graticule.

NOTE. Recalling the factory presets does not set the vertical position to zero. You may need to adjust the Vertical control to set the vertical position to zero.

5. Record Pass or Fail for WFM with NTSC in the test record.

6. Observe the Vector in tile 2, the burst should be aligned with the burst

marker that extends to the left of the vector center.

7. Record Pass or Fail for Vector with NTSC in the test record.

8. Observe the picture in tile 3. It should be stable and show the color bar

signal.

9. Record Pass or Fail for Picture with NTSC in the test record.

Analog Audio Input

(Options AD and DDE

Only)

10. If desired, move the input to input B and repeat steps 3 – 8.

1. Restore the Factory Preset (See Page 2--21).

2. Set the analog audio generator to output a 1 kHz, 18 dBu sine wave.

3. Press and hold the Display Select button 4 button to display the Audio

pop-up menu.

4. In the Audio Input submenu, select Analog Input > Analog A.

5. Press the AUDIO button briefly to dismiss the menu.

6. Using the audio breakout cable or equivalent, connect the analog audio

generator to the first Line A input pair and verify that the output level of the generator signal is 18 dBu, as indicated on the audio bars.

7. Repeat step 6 for the second and third line A input pair.

8. Record Pass or Fail in the test record.

9. Press and hold the Display Select button 4 button to display the AUDIO

pop-up menu.

2- 28

10. In the Audio Input submenu, select Analog Input > Analog B.

11. Press the AUDIO button briefly to dismiss the menu

12. Repeat step 6 for all three Line B input pairs.

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

13. Record Pass or Fail in the test record.

Incoming Inspection

Analog Audio Output

(Options AD and DDE

Only)

1. Restore the Factory Preset (See Page 2--21).

2. Press and hold the Display Select button 4 button to display the AUDIO

pop-up menu.

3. In the Audio Input submenu, select Analog Input > Analog A.

4. Press the AUDIO button briefly to dismiss the menu

5. Using the audio breakout cable or equivalent, connect the first Line A input

pair to the analog audio generator and verify that the output level of the generator is 18 dBu, as indicated on the audio bars.

6. Press CONFIG to display the CONFIG menu.

7. Select Audio Inputs/Outputs > Atten Analog Out

8. Press SEL and use the GENERAL knob to adjust the value to 0db, then

press SEL again to set the value.

9. While still in the Audio Inputs/Outputs submenu, select Analog A > Analog Output Map.

10. Press SEL to display the Analog Output to Analog “A” Bar Map.

11. Put an X in the first bar pair row for Analog Outputs 1&2, 3&4, 5&6, and

7&8.

12. Press CONFIG to exit the CONF IG menu.

13. Connect the first analog output pair on the breakout cable to the second line

A input pair.

14. Verify on the level meter bars that the second set of bars is within 1 dB of the first set of bars.

15. Connect the second analog output pair on the breakout cable to the second line A input pair.

16. Verify on the level meter bars, that the second set of bars is within 1 dB of the first set of bars.

17. Connect the third analog output pair on the breakout cable to the second line A input pair.

18. Verify on the level meter bars, that the second set of bars is within 1 dB of the first set of bars.

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

2- 29

Incoming Inspection

19. For Option AD, skip to step 22.

20. Connect the fourth analog output pair on the breakout cable to the second

line A input pair.

21. Verify, on the level meter bars, that the second set of bars is within 1 dB of

the first set of bars.

22. Record Pass or Fail in the test record.

Digital Audio Input

(Options AD, DS, and DDE

Only)

1. Restore the Factory Preset (See Page 2--21).

2. Set the digital audio generator to output a 1 kHz, -6 dBF S sine wave.

3. Press and hold the Display Select button 4 to display the AUDIO pop-up

menu.

4. Select Audio Input > AES A.

5. Connect the unbalanced output of the digital audio generator to the AES A

1-2 input.

6. Press the AUDIO button to dismiss the menu.

7. Verify that the first set of level meter bars indicates –6 dBFS.

8. Repeat steps 5 and 7 for AES A 3-4, AES A 5-6, and AES A 7-8.

9. Record Pass or Fail for AES A in the test record.

10. Press and hold the Display Select 4 button to display the AUDIO pop-up

menu.

11. Select Audio Input > AES B.

12. Press the AUDIO button to dismiss the menu.

2- 30

13. Connect the output of the digital audio generator to the AES B 1-2 input.

14. Verify that the first set of level meter bars indicates --6 dBFS.

15. Repeat steps 13 and 14 for AES B 3-4, AES B 5-6, and AES B 7-8.

16. Record Pass or Fail for AES B in the test record.

17. Set the SDI generator for a signal type appropriate to the unit under test:

a. Option HD: 1080 59.94i color bars from HDVG1

b. Option SD: 525/270 color bars from DVG1

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

Incoming Inspection

18. Set the SDI generator for embedded audio in 2 groups starting with group 1, and then access and set its audio channels:

a. Press Modules, and then select the appropriate module icon, HDVG1 or

DVG1.

b. Press Test Signals, and select Module Parameters.

c. Select Audio, and set the audio channels as follows:

H Channel 1: 50 Hz, --35 dB

H Channel 2: 100 Hz, --30 dB

H Channel 3: 150 Hz, --25 dB

H Channel 4: 200 Hz, --20 dB

H Channel 5: 250 Hz, --15 dB

H Channel 6: 300 Hz, --10 dB

H Channel 7: 400 Hz, --5 dB

H Channel 8: 500 Hz, 0 dB

19. Connect the output of the SDI signal generator with embedded audio to the A SDI input.

20. Press and hold the Display Select button 4 to display the AUDIO pop-up menu.

21. Select Audio Input > Embedded.

22. Press the AUDIO button.

23. Verify that the level meter bars have a stair step pattern from –35 dB on

channel 1 to 0 dB on channel 8.

NOTE. If level-meter bars indicate that audio is not present, set the TG2000 module number of groups to 2 even if it appears to be set already.

24. Record Pass or Fail for Embedded Display in the test record.

25. Press and hold the Display Select button 4 to display the AUDIO pop-up

menu.

26. Select Phase Pair > 1 & 2.

27. Go through the other phase pairs (3 & 4, 5 & 6, 7 & 8) and verify that the

phase display changes in each one.

WFM6100, WFM7000, and WFM7100 Waveform Monitors With Option FP

2- 31

Incoming Inspection

28. Record Pass or Fail for Embedded to Lissajous in the test record.

Digital Audio Output

(Options DS, AD, and DDE

Only)

1. Restore the Factory Preset (See Page 2--21).

2. If you have just finished testing the Digital Audio Inputs, proceed to step 3,

otherwise do steps 18-23 of the Digital Audio Input test.

3. Press CONFIG to display the configuration menu.

4. Select Audio Inputs/Outputs > AES B Config Port As > Output.

5. Briefly press the CONFIG button to close the menu.

6. Connect the AES B 1-2 output to the Audio Signal Analyzer input.

7. Verify on the analyzer that the signal levels are at –35 dBFS for the left

channel and –30 dBFS for the right.

8. Connect the AES B 3-4 output to the Audio Signal Analyzer input.

9. Verify on the analyzer that the signal levels are at –25 dBFS for the left

channel and –20 dBFS for the right.

10. Connect the AES B 5-6 output to the Audio Signal Analyzer input.

11. Verify on the analyzer that the signal levels are at –15 dBFS for the left

channel and –10 dBFS for the right.

Dolby Decode

(Option DDE Only)

12. Connect the AES B 7-8 output to the Audio Signal Analyzer input.

13. Verify on the analyzer that the signal levels are at –5 dBFS for the left

channel and 0 dBFS for the right.

14. Record Pass or Fail for each output in the test record.
