Tektronix TDS7404 Data Sheet

Features & Benefits
4 GHz, 1 GHz and 500 MHz bandwidth models
Up to 20 GS/s real-time capture rate
Up to 32 Megasamples memory depth
>400,000 wfms/second maximum waveform capture rate
Jitter measurements to 1 ps
RMS
Graphical user interface Control via classic direct
controls, touch-sensitive color display or mouse
Open Windows
®
environment
Built in networking
Applications
Verification, debug and characterization of sophisticated designs
Jitter and timing analysis Spectral analysis Disk drive analysis Investigation of transient
phenomena
Digital Phosphor Oscilloscopes
TDS7000 Series
Performance, Simplicity, and Connectivity
TDS7000 Series oscilloscopes are high perform­ance solutions for verification, debug,and charac­terization of sophisticated electronic designs.The family features exceptional signal acquisition per­formance, operational simplicity and open connec­tivity to the design environment. Classic analog­style controls, a large touch-sensitive display and graphical menus provide intuitive control. Open access to the Windows operating system enables unprecedented customization and extensibility.
Superior Performance
TDS7000 models range from 500 MHz to 4 GHz bandwidth with single-shot sample rates to 20 GS/s, meeting demands of the latest high speed logic families and multi-Gigabit communication standards. Acquisition memory options from 2 to 32 Megasamples maximize the value of high sample rate and ensure that critical events are captured with fine detail. High performance jitter analysis to 1 ps
RMS
is achieved through exceptional trigger and acquisition performance, deep memory and applied software.
TDS7000 Series high bandwidth signal access solutions include the P7240 4 GHz (120 ps rise time) active probe and the P7330 3 GHz (130 ps rise time) differential probe. Small form-factors and a wide array of tip accessories ensure effective­ness. In addition,the TDS7404 includes the TekConnect™ signal interconnect system.This interface replaces traditional BNC input connectors with a convenient positive-locking interface suitable for higher system bandwidths. P7000 Series probes are directly compatible with TekConnect signal interconnect system along with adapters that provide SMA, BNC and N connections.
Digital Phospor Oscilloscopes•TDS7000 Series
http://dpo.tektronix.com
1
Digital Phosphor Oscilloscopes
TDS7000 Series
Digital Phosphor Oscilloscopes
Signal observation time is critical for successful dis­covery of intermittent faults and characterization of complex dynamic signals.TDS7000 Series Digital Phosphor Oscilloscopes incorporate 3rd generation DPX technology to enable maximum waveform cap­ture rates of more than 400,000 waveforms per second.This unprecedented performance allows users to fully visualize signal activity.In trou­bleshooting applications, Digital Phosphor can save minutes, hours,or even days by quickly revealing the nature of faults so sophisticated trigger modes can be applied to isolate them.
Operational Simplicity
The TDS7000 Series graphical user interface deliv­ers sophisticated capability to advanced users with­out intimidating occasional users.The front panel includes a complete set of classic analog-style con­trols for most commonly used features. For advanced use, the combination of large 10.4 inch (264 mm) touch sensitive display and graphical interface creates a highly visual environment with explicit illustration of instrument features.The wave
form display area remains visible even when dis­playing control windows so changes in the wave­form aren’t missed when making selections or adjustments. Context-sensitive help supplements graphic control windows and encourages users to apply advanced capabilities to solve their problem.
The adaptable TDS7000 Series human interface readily supports any operating style and environ­ment. Users can select traditional instrument-style buttons for navigation or switch to a Windows menu bar.Classic analog-style controls provide instant access to the most frequently used functions while the large touch sensitive display provides intuitive menu operation.Waveform positions, cursor loca­tions and trigger level can be directly dragged using the touch screen or a mouse.A graphical drag-box can be used to select a waveform area for zooming, histogram analysis or measurement gating.The USB interface allows a mouse, keyboard and other peripherals to be added without powering off the instrument.With this flexibility, TDS7000 Series instruments readily adapt to a cart, cluttered bench top, shelf,floor and other locations that otherwise make operation awkward.
Application-specific Extensions
The TDS7000 family contains many extended fea­tures to quantify and document signal characteris­tics.These features remain close at hand without cluttering the human interface. Applied measure­ment extensions can be installed to enhance TDS7000 capabilities. Optional applications include jitter analysis and disk drive measurements.These applications build on the precision signal acquisition performance of TDS7000 Series to address the need for application specific measurements to quickly quantify device performance.
Intuitive Zooming
TDS7000 acquired waveforms are always horizon­tally fit into the display.This “big picture” is retained for context while zoom is used to select areas of specific interest.Waveform zoom can be directly controlled with knobs or the graphical user interface for intuitive interaction.
Digital Phospor Oscilloscopes•TDS7000 Series
http://dpo.tektronix.com
2
Figure 1. Digital Phosphor technology provides unprecedented waveform capture rate, maxi mizing the probability of discovering hidden faults and revealing dynamic signal behavior.
Figure 2. Extensive use of illustrations helps users locate advanced features quickly and apply them with confidence.
Figure 3. Sophisticated analysis capabilities allow users to fully characterize and document design performance.
Digital Phosphor Oscilloscopes
TDS7000 Series
Parametric Measurements
The TDS7000 includes a complete parametric meas­urement system for signal characterization. Direct selection from a graphical palette makes locating choices simple. Users can quickly reassign measure­ments to a different waveform, simplifying verifica­tion tasks. Split cursors make it easy to measure trace-to-trace timing characteristics. Measurement statistics can be gathered for deeper insight. Measurement results are easily extracted for inclu­sion in a document or analysis in a spreadsheet using the Windows clipboard or an Export function.
Powerful Math
The TDS7000 Series allows user defined math expressions to be performed on waveform data giv­ing them the opportunity to get on-screen results in terms that they can define. Common waveform math functions are provided at the touch of a button. For advanced applications, algebraic expressions con­sisting of waveform sources, math functions,meas­urement values and scalars can be created easily using a calculator-style editor.This allows users to quickly transform raw waveform data into powerful information that is readily interpreted.
Enhanced Spectral Analysis
The TDS7000 Series includes a unique spectrum­analyzer style interface for performing frequency domain analysis. Controls such as center frequency, frequency span, resolution bandwidth and reference level provide access to wide- or narrow-band fre­quency,phase, and group delay information. A gat­ing function allows selection of only a portion of the time-domain signal for analysis.These controls allow users to focus on extracting spectral informa­tion instead of confronting the idiosyncrasies of FFTs found in typical DSOs.
Complete Connectivity
The TDS7000 Series includes open access to the Windows operating environment.While the instrument remains a dedicated oscilloscope, the ability to access the Windows desktop creates a powerful new tool. Built-in applications such as WordPad, Paint and a web browser allow users to concurrently maintain lab notes while working with the instrument.This saves time and eliminates error-prone steps associated with transporting images for later report development. Other applica­tions such as Microsoft Excel, MATLAB
®
and
MathCAD
®
can be installed in the instrument to accomplish local signal analysis.The installation of networking enables Web-based information brows­ing, e-mail exchange,printing and file sharing.
View the Windows®Desktop on Separate Monitor
TDS7000 can also be expanded with the addition of an external monitor.With dual-monitor mode enabled the instrument retains live scope displays while other applications such as publishing, analysis or browsing tools reside on the external monitor. Users can easily transfer images and waveform data from TDS7000 to the locally running applica­tion or view Web-based reference information while using the scope for design work.
Standard Interfaces
The TDS7000 includes standard interfaces for con­trol and peripheral expansion.The GPIB command set shares a high degree of commonality with previ­ous TDS 500/700-class instruments while increas­ing hardware and software performance. Both USB and PS-2 interfaces are included for mouse, key­board and other peripheral expansion. USB offers the advantage of hot-insertion and removal so devices can be added or removed without cycling power.The TDS7000 also includes a LAN interface for network connection.
Digital Phospor Oscilloscopes •TDS7000 Series
http://dpo.tektronix.com
3
Figure 4. Open access to the Windows desktop allows users to leverage standard tools for documentation, analysis,information browsing and communications.
Digital Phosphor Oscilloscopes
TDS7000 Series
Digital Phospor Oscilloscopes•TDS7000 Series
http://dpo.tektronix.com
4
Characteristics
Vertical System
TDS7054 TDS7104 TDS7404
Input Channels 4 4 4 Analog Bandwidth (–3 dB) 500 MHz 1 GHz 4 GHz Calculated Rise Time 10mV/div – 1 V/div 800 ps 400 ps 100 ps Hardware Bandwidth Limits 250 MHz or 20 MHz Input Coupling AC, DC,Gnd DC, Gnd Input Impedance 1 M±0.5% or 50 Ω ±1% 50Ω ±2.5% Input Sensitivity,1 M 1 mV/div to 10V/div Input Sensitivity,50 1 mV/div to 1V/div 2 mV/div to 1 V/div Vertical Resolution 8-bits (>11-bits w/averaging) 8-bits (>11-bits w/averaging) Max Input Voltage,1 M ±150 V CAT I Derate at 20dB/decade to
9V
RMS
above 200 kHz
Max Input Voltage,50 5V
RMS
, with peaks less than ±30 Volts Determined by TekConnect accessory DC Gain Accuracy 1.00% 1.00% Offset Range 1 mV/div – 100 mV/div ±1 V 2 mV – 50 mV/div ±0.5 V
101 mV/div – 1V/div ±10 V 50.5 mV – 99.5 mV ±0.25 V
1.01 V/div – 10V/div ±100V 100 mV – 500 mV ±5 V 505 mV – 1V/div ±2.5 V
Channel to Channel Isolation 100:1 at 100 MHz and 30:1 at the rated bandwidth 100:1 at 4 GHz Any two channels at equal vertical scale settings
DC Measurement Accuracy ±((0.3% * |Reading – Net Offset|) + Offset Accuracy + ±((1.0% * |Reading – Net Offset|) + Offset Accuracy + Stated for average >16 waveforms (0.06 div * V/div)) (0.06 div * V/div))
Net Offset = Offset – (Position * Volts/div) Net Offset = Offset – (Position * Volts/div)
Delta-DC Measurement Accuracy ±((1.0% * |Reading|) + (0.1 div * V/div)+ 0.3 mV) ±((1.0% * |Reading|) + (0.1 div * V/div)+ 0.3 mV) Stated for average >16 waveforms
Timebase System
TDS7054 TDS7104 TDS7404
Timebase Range 200 ps/div – 40 s/div 50 ps – 10s/div Timebase Delay Time Range 16 ns to 250 s 16ns to 250 s Channel to Channel Deskew Range ±25 ns ±25 ns Time Interval Accuracy ±(0.30 sample interval) + ±(0.15/sample rate) +
(15 ppm * reading) (10 ppm * reading)
Trigger Jitter (RMS) 8 ps
RMS
(typical) 7 ps
RMS
Long Term Sample Rate and ±15 ppm over 1 ms interval ±10 ppm over 1 ms interval Delay Time Accuracy
Digital Phosphor Oscilloscopes
TDS7000 Series
Digital Phospor Oscilloscopes •TDS7000 Series
http://dpo.tektronix.com
5
Acquisition System
TDS7054 TDS7104 TDS7404
Real-time Sample Rates
1 channel (max) 5 GS/s 10 GS/s 20 GS/s 2 channels (max) 5 GS/s 5 GS/s 10 GS/s 3-4 channels (max) 2.5 GS/s 2.5 GS/s 5 GS/s Equivalent time sample rate (max) 250 GS/s 250 GS/s 250 GS/s Maximum record length per channel 400 k (1 ch),200 k (2 ch), 100k (4 ch) 400k (1 ch), 200 k (2 ch),100 k (4 ch)
with standard memory with Memory Opt. 1M 2 M (1 ch), 1M (2 ch), 500 k (4 ch) 2 M (1 ch),1 M (2 ch), 500k (4 ch) with Memory Opt. 2M 8 M (1 ch),4 M (2 ch), 2M (4 ch) 8 M (1 ch),4 M (2 ch), 2M (4 ch) with Memory Opt. 3M 16 M (1ch), 8 M (2 ch),4 M (4 ch) 16 M (1 ch),8 M (2 ch), 4M (4 ch) with Memory Opt. 4M 32 M (1 ch),16 M (2 ch), 8M (4 ch)
Maximum Duration at Highest Real-time Resolution (1 ch)
TDS7054 TDS7104 TDS7404
Time Resolution (single-shot) 200 ps (5 GS/s) 100 ps (10 GS/s) 50 ps (20 GS/s) Max Duration with Standard Memory 80 µs 40 µs 20 µs Max Duration with Opt. 1M 400 µs 200 µs 100 µs Max Duration with Opt. 2M 1.6 ms 800 µs 400 µs Max Duration with Opt. 3M 3.2 ms 1.6 ms 800 µs Max Duration with Opt. 4M 1.6 ms
Digital Phosphor Oscilloscopes
TDS7000 Series
Digital Phospor Oscilloscopes•TDS7000 Series
http://dpo.tektronix.com
6
Trigger System
TDS7054 TDS7104 TDS7404
Sensitivity
Internal DC Coupled 0.35 div DC to 50 MHz 0.35div DC to 50 MHz 0.35 div DC to 50 MHz
increasing to 1 div at 500 MHz increasing to 1 div at 1 GHz increasing to 1 div at 3 GHz
External (Auxiliary Input) 400 mV from DC to 50 MHz 250 mV from DC to 50 MHz 250 mV from DC to 50 MHz
increasing to 750 mV at 100 MHz increasing to 500 mV at 100 MHz increasing to 350 mV at 500 MHz Main Trigger Modes Auto, Normal and Single Auto, Normal and Single Auto, Normal and Single Trigger Sequences Main, Delayed by Time, Delayed by Events. All sequences can include separate
horizontal delay after the trigger event to position the acquisition window in time
Trigger Level Range
Internal ± 12 divisions from ±12 divisions from ±12 divisions from
center of screen center of screen center of screen External (Auxiliary Input) ±8 V ± 8 V ±8 V Line fixed at 0 V fixed at 0 V fixed at 0V Trigger Coupling DC,AC (attenuate < 60 Hz), HF Rej (attenuate >30 kHz), LF Rej (attenuates <80 kHz), Noise Reject (reduce sensitivity) Trigger Holdoff Range 250 ns minimum to 12 250ns minimum to 12 250 ns minimum to 12
seconds maximum seconds maximum seconds maximum
Acquisition Modes
TDS7054 TDS7104 TDS7404
FastAcq Acquisition FastAcq optimizes the instrument for analysis of dynamic signals and capture of infrequent events Maximum FastAcq Waveform Capture Rate >200,000 wfms/sec >200,000 wfms/sec >400,000 wfms/sec Sample Acquire sampled values Acquire sampled values Acquire sampled values Peak Detect Captures narrow glitches at all real-time sampling rates Minimum Peak Detect Pulse Width ≤1ns 1 ns 400 ps Averaging From 2 to 10,000 waveforms included in average Envelope From 2 to 2x109waveforms included in min-max envelope Hi-res Real-time boxcar averaging reduces random noise and increases resolution FastFrame Acquisition Acquisition memory divided into segments; maximum trigger rate 150,000 waveforms per second.
Time of arrival recorded with each event
Digital Phosphor Oscilloscopes
TDS7000 Series
Trigger Modes
Edge – Positive or negative slope on any channel or front panel auxiliary input. Coupling includes DC,AC, noise reject, HF reject and LF reject.
Glitch – Trigger on or reject glitches of positive,negative, or either polarity. Minimum glitch width is 1.0 ns with 200 ps resolution.
Width – Trigger on width of positive or negative pulse either within or out of selectable time limits (1 ns to 1 s).
Runt – Trigger on a pulse that crosses one threshold but fails to cross a second threshold before crossing the first again. Optional time qualification.
Timeout – Trigger on an event which remains high, low, or either,for a specified time period, selectable from 1 ns to 1 s with 200 ps resolution.
Transition – Trigger on pulse edge rates that are faster or slower than specified. Slope may be positive,negative or either.
Setup/Hold – Trigger on violations of both setup time and hold time between clock and data present on any two input channels.
Pattern – Trigger when pattern goes false or stays true for specified period of time. Pattern – (AND,OR, NAND, NOR) specified for four input channels defined as HIGH, LOW or Don’t Care.
State – Any logical pattern of channels (1, 2,3) clocked by edge on channel 4. Trigger on rising or falling clock edge.
Trigger Delay by Time – 16 ns to 250 seconds. Trigger Delay by Events – 1 to 10,000,000 Events.
Waveform Measurements
Amplitude – Amplitude, High, Low,Maximum, Minimum, Peak to Peak, Mean, Cycle Mean, RMS,Cycle RMS, Positive Overshoot, Negative Overshoot.
Time – Rise time,Fall time, Positive Width,Negative Width, Positive Duty Cycle,Negative Duty Cycle, Period, Frequency,Delay.
Combination – Area, Cycle Area,Phase, Burst Width. Histogram-related – Waveform count,Hits in box, Peak
hits, Median,Maximum, Minimum,Peak to Peak, Mean (µ), Standard Deviation (σ),µ+1 σ,µ+2 σ, µ+3 σ.
Waveform Processing/Math
Algebraic Expressions – Define extensive algebraic expressions including waveforms, scalars and results of parametric measurements e.g. (Integral (Ch1­Mean(Ch1))*1.414.
Arithmetic – Add, subtract, multiply,divide waveforms and scalars.
Calculus – Integrate, differentiate. Frequency Domain Functions – Spectral magnitude and
phase, real and imaginary spectra. Vertical Units – Magnitude:Linear,dB, dBm; Phase:
degrees, radians. Window Functions – Rectangular,Hamming, Hanning,
Kaiser-Bessel,Blackman-Harris, Gaussian,Flattop2, Tek Exponential.
Digital Phospor Oscilloscopes •TDS7000 Series
http://dpo.tektronix.com
7
Digital Phosphor Oscilloscopes
TDS7000 Series
Display Characteristics
Display Type – Liquid crystal active-matrix color display. Display Size – 211.2 mm (W) x 158.4 mm (H),264 mm
(10.4 in) diagonal. Display Resolution – 640 horizontal x 480 vertical
pixels. Waveform Styles – Vectors,Dots, Intensified Samples,
Variable Persistence,Infinite Persistence.
Computer System and Peripherals
CPU – Intel®Celeron™Processor,500 MHz. PC System Memory – 128 MB. Hard Disk Drive – Rear-panel,removable hard disk drive,
>4.3 GB capacity. Floppy Disk Drive – Front panel 3.5 in floppy disk drive,
1.44 MB capacity.
CD-ROM Drive – Rear panel CD-ROM drive. Mouse – Logitech thumb wheel model included, USB
interface. Keyboard – Order 119-6297-00 (USB interface).
Input/Output Ports
Probe Compensator Output – Front panel BNC connec­tor,requires Probe Cal-Deskew Fixture (included) for probe attachment.Amplitude 1 V±1.0% into a ≥50 Ω load,fre- quency 1 kHz ±5%.
Analog Signal Output Amplitude – Front-panel BNC connector,provides a buffered version of the signal that is attached to the Channel 3 input when Ch 3 is selected as trigger source. 20mV/div ±20% into a 1 MΩload, 10 mV/div ±20% into a 50 load.
Analog Signal Output Bandwidth,Typical –
TDS7054/TDS7104: 100MHz into a 50 Ω load TDS7404: 1GHz into a 50 load.
Auxiliary Output Levels – Front-panel BNC connector, provides a TTL-compatible,polarity switchable pulse when the oscilloscope trigger.
Parallel Port – IEEE 1284, DB-25 connector. Audio Ports – Miniature phone jacks for stereo
microphone input and stereo line output. USB Port – Allows connection or disconnection of USB
keyboard and/or mouse while oscilloscope power is on.
Keyboard Port – PS-2 compatible. Mouse Port – PS-2 compatible. LAN Port – RJ-45 connector,supports 10Base-T and
100Base-T.
Serial Port – DB-9 COM1 port. SVGA Video Port – DB-15 female connector; connect a
second monitor to use dual-monitor display mode. Supports Basic requirements of PC99 specifications.
GPIB Port – IEEE 488.2 standard. Scope VGA Video Port – DB-15 female connector,
31.6 kHz sync,EIA RS-343A compliant, connect to show the oscilloscope display,including live waveforms on an external monitor or projector.
Power Source
Power – 100 - 240V
RMS
±10%, 50/60 Hz; 115 V
RMS
±10%, 400 Hz; CAT II,<300 W (450 VA).
Digital Phospor Oscilloscopes•TDS 7000 Series
http://dpo.tektronix.com
8
Digital Phospor Oscilloscopes •TDS 7000 Series
http://dpo.tektronix.com
9
Digital Phosphor Oscilloscopes
TDS7000 Series
Physical Characteristics
Benchtop Configuration
Dimensions mm in.
Height 277 10.9 Width 455 17.9 Depth 425 16.75
Weight kg lbs.
Net 18 39 Shipping 37 80
Rackmount Configuration
Dimensions mm in.
Height 277 10.5 Width 502 19.75 Depth 486 19.125
Weight kg lbs.
Net 19 41 Kit 5.6 12.25
Mechanical
Cooling – Required clearances:
in. mm.
Top 0 or >3 76 Bottom 0 0 Left side 3 76 Right side 3 76 Front 0 0 Rear 0 0
Environmental
Temperature –
Operating: 0°C to +50°C, excluding floppy disk and CD­ROM drives; +10°C to +45°C, including floppy disk and CD-ROM drives.
Nonoperating: –22°C to +60°C.
Humidity –
Operating: 20% to 80% relative humidity with a maximum wet bulb temperature of +29°C at or below +50°C, noncondensing. Upper limit derated to 25% relative humidity at +50°C.
Nonoperating:With no diskette in floppy disk drive. 5% to 90% relative humidity with a maximum wet bulb tem­perature of +29°C at or below +60°C, noncondensing. Upper limit derated to 20% relative humidity at +60°C.
Altitude –
Operating: 10,000ft. (3,048 m). Nonoperating: 40,000ft. (12,190 m).
Random Vibration –
Operating: 0.00015 g
2
/Hz from 5 to 350 Hz, –3 dB/octave from 350 to 500 Hz,0.000105 g2/Hz at 500 Hz.Overall level of 0.27 GRMS.
Nonoperating: 0.0175 g2/Hz from 5 to 100 Hz, –3 dB/octave from 100 to 200 Hz,0.00875 g2/Hz from 200 to 350 Hz,–3 dB/octave from 350 to 500 Hz,
0.006132 g2/Hz at 500 Hz. Overall level of 2.28GRMS. Safety – UL 3111-1, CSA-22.2 No.1010.1,
EN61010-1.
Digital Phosphor Oscilloscopes
TDS7000 Series
Ordering Information
TDS7054
500 MHz Digital Phosphor Oscilloscope.
TDS7104
1 GHz Digital Phosphor Oscilloscope.
TDS7404
4 GHz Digital Phosphor Oscilloscope. All models include:Accessor y pouch, Front cover,
Mouse, Probe Calibration and Deskew Fixture (067-0405-00), Quick Reference (020-2335-00),User Reference (071-0700-00), GPIB Programmer’s Reference,TDS 7000 Series Product Software CD-ROM, TDS 7000 Series operating system restoration CD-ROM, Performance verification procedure PDF file, NIST, MIL-STD-45662A and ISO9000 Calibration Certificate, Power Cord.
TDS7054 also includes: (4) P6139A 500 MHz, 10x Passive Probes.
TDS7404 also includes: (4) TekConnect to SMA adapters (TCA-SMA).
Power Cord Options for all Models
Opt. A1 – Universal European power cord (220 V,50 Hz). Opt. A2 – UK power cord (240 V, 50Hz). Opt. A3 – Australia power cord (240 V,50 Hz). Opt. A5 – Switzerland power cord (220 V,50 Hz). Opt. A99 – No power cord. Opt. AC – China power cord.
Recommended Accessories
Keyboard (USB interface) – Order 119-6297-00. Service Manual – Order 071-0711-00. Transit Case– Order 016-1522-00. TekConnect Adapters– TCA-SMA TekConnect-to-SMA Adapter. TCA-N TekConnect-to-N Adapter. TCA-BNC TekConnect-to-BNC Adapter.
Software
TDSJIT2 Jitter Analysis Software. TDSDDM2 Disk Drive Analysis Software. WSTRO Wavestar™waveform capture and
documentation software.
Cables
GPIB Cable (1 m) – Order 012-0991-01. GPIB Cable (2 m) – Order 012-0991-00. RS-232 Cable – Order 012-1298-00. Centronics Cable – Order 012-1250-00.
Digital Phospor Oscilloscopes•TDS 7000 Series
http://dpo.tektronix.com
10
Instrument Acquisitions Memory Upgrades
Acquisition memory upgrades equivalent to Options 1M – 4M can be ordered to extend instrument performance after initial purchase. Users can install upgrades without opening the instru­ment case or requiring on-site service. Order the appropriate TDS7Mxx kit from the following table according to current and intended configuration.
To Opt. 1M To Opt. 2M To Opt. 3M To Opt. 4M (TDS7404 only)
From Standard Memory TDS7M01 TDS7M02 TDS7M03 TDS7M04 From Opt. 1M TDS7M12 TDS7M13 TDS7M14 From Opt. 2M TDS7M23 TDS7M24 From Opt. 3M TDS7M34
Digital Phospor Oscilloscopes •TDS 7000 Series
http://dpo.tektronix.com
1111
Digital Phosphor Oscilloscopes
TDS7000 Series
Instrument Options (Available where indicated by "x")
TDS7054 TDS7104 TDS7404
Acquisition Memory Options
1M 2 Msamples max, 500ksamples/ch x x x 2M 8 Msamples max,2 Msamples/ch x x x 3M 16 Msamples max,4 Msamples/ch x x x 4M 32 Msamples max,8 Msamples/ch x
Mounting Options
1K K4000 Scope cart x x x 1R Rackmount kit x x x
Software Options
J1 TDSJIT2 Jitter Analysis Software x x x J2 TDSDDM2 Disk Drive Analysis Software x x x
Probe Options
30 No Probes x x x 33 Add (1) P6158 3 GHz,20x Low C Probe x 34 Add (1) P6247 1.0 GHz Differential Probe x 35 Add (1) P6243 1.0 GHz Active Probe x 36 Add (1) P6139A 500 MHz, 10x Passive Probe x x 37 Add (1) P6245 1.5 GHz Active Probe x 39 Add (1) P6248 1.7 GHz Differential Probe x 51 Add (1)P7240 4 GHz Active Probe x 52 Add (1) P7330 3 GHz Differential Probe x
Service Options
D1 Calibration data report x x x C3 Additional 2 years of calibration x x x D3 Calibration data report for Option C3 x x x R3 Additional 2 years of repair x x x
Digital Phosphor Oscilloscopes
TDS7000 Series
For other areas,contact: Tektronix, Inc.
Export Sales, P.O.Box 500, M/S 50-255,
Beaverton, Oregon 97077-0001, USA 1 (503) 627-6877
For the most up-to-date product information
visit our web site at
www.tektronix.com
Copyright © 2000, Tektronix, Inc. All rights reser ved. Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publi­cation supersedes that in all previously published material. Specification and price change privileges reserved. TEKTRONIX and TEK are registered trademarks of Tektronix,Inc. All other trade names referenced are the service marks, trademarks or registered trademarks of their respective companies.
4/00 HB/PG 55W-13766-0
Contact Tektronix:
ASEAN Countries
(65) 356-3900
Australia & New Zealand
61 (2) 9888-0100
Austria, Central Eastern Europe,
Greece,Turkey, Malta & Cyprus
+43 2236 8092 0
Belgium
+32 (2) 715 89 70
Brazil and South America
55 (11) 3741-8360
Canada
1 (800) 661-5625
Denmark
+45 (44) 850 700
Finland
+358 (9) 4783 400
France & North Africa
+33 1 69 86 81 81
Germany
+49 (221) 94 77 400
Hong Kong
(852) 2585-6688
India
(91) 80-2275577
Italy
+39 (2) 25086 501
Japan (Sony/Tektronix Corporation)
81 (3) 3448-3111
Mexico, Central America, & Caribbean
52 (5) 666-6333
The Netherlands
+31 23 56 95555
Norway
+47 22 07 07 00
People’s Republic of China
86 (10) 6235 1230
Republic of Korea
82 (2) 528-5299
South Africa
(27 11) 651-5222
Spain & Portugal
+34 91 372 6000
Sweden
+46 8 477 65 00
Switzerland
+41 (41) 729 36 40
Taiwan
886 (2) 2722-9622
United Kingdom & Eire
+44 (0)1344 392000
USA
1 (800) 426-2200
Digital Phospor Oscilloscopes
TDS 7000 Series
http://dpo.tektronix.com
12
For Further Information
Tektronix maintains a comprehensive, constantly expanding collection of application notes, technical briefs and other resources to help engineers working on the cutting edge of technology.
Please visit “Resources For You” on our Web site at
www.tektronix.com
Loading...
