Tektronix TDS7054, TDS7254, TDS7404, TDS7104, TDS6604 Primary User

...

Download

Printed Help Document

TDSET3 Ethernet Compliance Test Software

Adapted from the TDSET3 Ethernet Compliance Test Software Online Help 077000501, Version 1.3.0, 2005

This document supports software version 1.3.0 and above.

Warning

The servicing instructions are for use by qualified personnel only. To avoid personal injury, do not perform any servicing unless you are qualified to do so. Refer to all safety summaries prior to performing service.

Copyright © Tektronix, 2005, Inc. All rights reserved. Licensed software products are owned by Tektronix or its suppliers and are protected by United States copyright laws and international treaty provisions.

Use, duplication, or disclosure by the Government is subject to restrictions as set forth in subparagraph (c)(1)(ii) of the Rights in T echnical Data and Computer Software clause at DFARS 252.227-7013, or subparagraphs (c)(1) and (2) of the Commercial Computer Software – Restricted Rights clause at FAR 52.227-19, as applicable.

Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this documentation supercedes that in all previously published material. Specifications and price change privileges reserved.

Tektronix, Inc., P.O. Box 500, Beaverton, OR 97077 TEKTRONIX, TEK and TEKPROBE are registered trademarks of Tektronix, Inc.

TDSET3 077000501, Version 1.3.0, 2005.

Table of Contents

About TDSET3 ...................................................................................................................... 1-1

Using Online Help ....................................................................................................................................1-2

Printing from the Online Help ................................................................................................................. 1-3

Conventions .............................................................................................................................................1-3

Contacting Tektronix ...............................................................................................................................1-4

Feedback...................................................................................................................................................1-5

Information through the Web site ..........................................................................................................1-5

Getting Started...................................................................................................................... 2-1

Compatibility ............................................................................................................................................2-1

Recommended Accessories ................................................................................................................... 2-2

Requirements and Restrictions.............................................................................................................. 2-3

About the Test Fixture.............................................................................................................................2-4

Starting the Application ..........................................................................................................................2-5

Minimizing and Maximizing the Application .........................................................................................2-6

Returning to the Application...................................................................................................................2-6

Exiting the Application ............................................................................................................................ 2-7

Application Directories and File Names ................................................................................................ 2-7

Application Software Default Layouts and Templates.........................................................................2-8

Application Software Default Settings.................................................................................................2-10

Operating Basics .................................................................................................................. 3-1

TDSET3 Application Window..................................................................................................................3-1

TDSET3 Application Interface Controls.................................................................................................3-1

Menu bar ...................................................................................................................................................3-2

File Menu...................................................................................................................................................3-2

TDSET3 Printed Help Document

Table of Contents

Tests Menu................................................................................................................................................3-3

Results Menu ............................................................................................................................................3-4

Utilities Menu ............................................................................................................................................3-4

Help Menu .................................................................................................................................................3-5

Selection pane..........................................................................................................................................3-5

Speed pane ...............................................................................................................................................3-6

Client pane ................................................................................................................................................3-6

1000BASE-T Client pane ....................................................................................................................3-7

100BASE-TX Client pane ...................................................................................................................3-7

10BASE-T Client pane ........................................................................................................................3-7

Execution pane.........................................................................................................................................3-8

Status bar..................................................................................................................................................3-8

Result pane...............................................................................................................................................3-9

Result Summary pane ........................................................................................................................3-10

Report Configuration pane.................................................................................................................3-11

Dialog Boxes...........................................................................................................................................3-11

Preferences dialog box.......................................................................................................................3-11

Advanced Report Configuration dialog box.......................................................................................3-15

Result Details dialog box...................................................................................................................3-16

Locate Hits dialog box.......................................................................................................................3-17

Flash Hits dialog box .........................................................................................................................3-17

Show Segments dialog box................................................................................................................3-18

Manual Fit dialog box........................................................................................................................3-18

Jig match dialog box ..........................................................................................................................3-19

Virtual Keyboard dialog box ..............................................................................................................3-24

Virtual Keypad dialog box..................................................................................................................3-24

Mask Setup dialog box ......................................................................................................................3-25

TDSET3 Printed Help Document

Table of Contents

Smooth dialog box............................................................................................................................. 3-26

Exit dialog box...................................................................................................................................3-27

How To Select Test Parameters .......................................................................................... 4-1

Selecting 1000BASE-T Test Parameters ...............................................................................................4-1

Selecting 100BASE-TX Test Parameters ............................................................................................... 4-1

Selecting 10BASE-T Test Parameters ...................................................................................................4-2

How To Configure Parameters ............................................................................................ 5-1

Configuring 1000BASE-T ........................................................................................................................5-1

Configuring 100BASE-TX........................................................................................................................5-5

Configuring 10BASE-T ............................................................................................................................ 5-7

Making Connections ............................................................................................................ 6-1

1000BASE-T Connections.......................................................................................................................6-1

Template, Peak Volt, Droop, and Distortion ........................................................................................6-1

Jitter Master Filtered.............................................................................................................................6-5

Jitter Master Unfiltered......................................................................................................................... 6-8

Jitter Slave Filtered.............................................................................................................................6-11

Jitter Slave Unfiltered.........................................................................................................................6-15

Return Loss......................................................................................................................................... 6-17

Return Loss Calibration.....................................................................................................................6-19

CM Voltage ........................................................................................................................................6-20

100BASE-TX Connections ....................................................................................................................6-22

All Tests except Return Loss..............................................................................................................6-22

Return Loss......................................................................................................................................... 6-23

Return Loss Calibration.....................................................................................................................6-24

10BASE-T Connections.........................................................................................................................6-25

Link Pulse...........................................................................................................................................6-25

MAU...................................................................................................................................................6-28

TDSET3 Printed Help Document

iii

Table of Contents

TP_IDL ...............................................................................................................................................6-29

Jitter with cable...................................................................................................................................6-31

Jitter without cable..............................................................................................................................6-33

Differential Voltage ............................................................................................................................6-35

Harmonic ............................................................................................................................................6-36

Return Loss.........................................................................................................................................6-37

Return Loss Calibration .....................................................................................................................6-38

CM Voltage ........................................................................................................................................6-40

Set up the Signal................................................................................................................... 7-1

1000BASE-T ..............................................................................................................................................7-1

100BASE-TX..............................................................................................................................................7-1

10BASE-T ..................................................................................................................................................7-2

How To Test 1000BASE-T .................................................................................................... 8-1

Template....................................................................................................................................................8-1

Peak Volt ...................................................................................................................................................8-3

Droop.........................................................................................................................................................8-5

Jitter Master Filtered................................................................................................................................8-7

Jitter Master Unfiltered ..........................................................................................................................8-11

Jitter Slave Filtered ................................................................................................................................8-16

Jitter Slave Unfiltered ............................................................................................................................8-20

Distortion ................................................................................................................................................8-26

Return Loss ............................................................................................................................................8-29

CM Voltage..............................................................................................................................................8-31

How To Test 100BASE-TX.................................................................................................... 9-1

Template....................................................................................................................................................9-1

Differential Output Voltage......................................................................................................................9-3

Signal Amplitude Symmetry ...................................................................................................................9-5

TDSET3 Printed Help Document

Table of Contents

Rise Time ..................................................................................................................................................9-6

Fall Time....................................................................................................................................................9-8

Rise/Fall Time Symmetry ......................................................................................................................9-11

Waveform Overshoot.............................................................................................................................9-12

Jitter ........................................................................................................................................................9-14

Duty Cycle Distortion ............................................................................................................................9-16

Return Loss ............................................................................................................................................9-17

How To Test 10BASE-T...................................................................................................... 10-1

MAU ......................................................................................................................................................... 10-1

Link Pulse ...............................................................................................................................................10-4

TP_IDL.....................................................................................................................................................10-7

Differential Voltage .............................................................................................................................. 10-10

Harmonic...............................................................................................................................................10-12

Jitter with cable .................................................................................................................................... 10-13

Jitter without cable ..............................................................................................................................10-16

Return Loss ..........................................................................................................................................10-19

CM Voltage............................................................................................................................................10-21

View Waveform for 1000BASE-T....................................................................................... 11-1

Template, Peak Volt, Droop ..................................................................................................................11-1

Jitter Master............................................................................................................................................ 11-2

Jitter Slave ..............................................................................................................................................11-3

Distortion ................................................................................................................................................11-5

Return Loss ............................................................................................................................................11-6

CM Voltage..............................................................................................................................................11-6

View Waveform for 100BASE-TX....................................................................................... 12-1

All 100BASE-TX Tests except Return Loss.........................................................................................12-1

Return Loss ............................................................................................................................................12-1

TDSET3 Printed Help Document

Table of Contents

View Waveform for 10BASE-T ........................................................................................... 13-1

Link Pulse ...............................................................................................................................................13-1

MAU .........................................................................................................................................................13-1

TP_IDL .....................................................................................................................................................13-2

Jitter with or without cable....................................................................................................................13-2

Differential Voltage ................................................................................................................................13-3

Harmonic.................................................................................................................................................13-4

Return Loss ............................................................................................................................................13-4

CM Voltage..............................................................................................................................................13-5

Generate Reports................................................................................................................14-1

About Report Generator ........................................................................................................................14-2

Automating AWG ................................................................................................................ 15-1

Automate AWG.......................................................................................................................................15-1

Connect the Equipment and Verify the Connections .........................................................................15-2

Reference to Standards ..................................................................................................... 16-1

1000BASE-T ............................................................................................................................................16-1

Template .............................................................................................................................................16-1

Peak Voltage.......................................................................................................................................16-2

Droop ..................................................................................................................................................16-2

Jitter (with TX_TCLK ACCESS).......................................................................................................16-3

Jitter (without TX_TCLK ACCESS)..................................................................................................16-4

Distortion ............................................................................................................................................16-5

CM Voltage ........................................................................................................................................16-5

Return Loss.........................................................................................................................................16-6

100BASE-TX............................................................................................................................................16-6

Template .............................................................................................................................................16-6

Differential Output Voltage ................................................................................................................16-6

TDSET3 Printed Help Document

Table of Contents

Signal Amplitude Symmetry ..............................................................................................................16-7

Rise and Fall Time..............................................................................................................................16-7

Waveform Overshoot .........................................................................................................................16-8

Jitter ....................................................................................................................................................16-8

Duty Cycle Distortion.........................................................................................................................16-8

Return Loss......................................................................................................................................... 16-9

10BASE-T................................................................................................................................................16-9

MAU Ext ............................................................................................................................................16-9

MAU Int ...........................................................................................................................................16-10

TP_IDL.............................................................................................................................................16-10

Link Pulse.........................................................................................................................................16-10

Differential Voltage..........................................................................................................................16-11

Harmonic ..........................................................................................................................................16-11

Jitter ..................................................................................................................................................16-12

CM Voltage ......................................................................................................................................16-12

Return Loss....................................................................................................................................... 16-13

Remote GPIB ...................................................................................................................... 17-1

About Remote GPIB...............................................................................................................................17-1

Starting and Setting Up the Application Using GPIB.........................................................................17-1

GPIB Command Syntax.........................................................................................................................17-2

TDSET3 Application Command Arguments and Queries..................................................................17-2

GPIB Commands for 1000BASE-T .......................................................................................................17-6

GPIB Commands for 100BASE-TX.......................................................................................................17-8

GPIB Commands for 10BASE-T ...........................................................................................................17-9

GPIB Commands for AWG Automation.............................................................................................17-11

Program Example ................................................................................................................................17-11

Guidelines to GPIB Programming......................................................................................................17-23

TDSET3 Printed Help Document

vii

Table of Contents

Calibration for Return Loss ............................................................................................... 18-1

1000BASE-T Return Loss......................................................................................................................18-1

100BASE-TX Return Loss Transmitter ................................................................................................18-4

100BASE-TX Return Loss Receiver .....................................................................................................18-7

10BASE-T Return Loss Transmitter...................................................................................................18-10

10BASE-T Return Loss Receiver........................................................................................................18-13

Appendix A: Specification Range .......................................................................................A-1

1000BASE-T ............................................................................................................................................. A-1

100BASE-TX............................................................................................................................................. A-2

10BASE-T ................................................................................................................................................. A-3

Appendix B: Error Messages...............................................................................................B-1

TDSET3 Error Messages ........................................................................................................................B-1

Remote GPIB Error Messages ............................................................................................................... B-3

viii

TDSET3 Printed Help Document

List of Figures

Figure 1-1: TDSET3 Splash Screen......................................................................................................................................... 1-1

Figure 2-1: Run Application .................................................................................................................................................... 2-5

Figure 2-2: Application Interface............................................................................................................................................. 2-6

Figure 3-1: Application Window ............................................................................................................................................. 3-1

Figure 3-2: File Menu .............................................................................................................................................................. 3-2

Figure 3-3: Tests menu ............................................................................................................................................................ 3-3

Figure 3-4: Results menu......................................................................................................................................................... 3-4

Figure 3-5: Utilities menu........................................................................................................................................................ 3-4

Figure 3-6: Help menu............................................................................................................................................................. 3-5

Figure 3-7: Selection pane ....................................................................................................................................................... 3-5

Figure 3-8: Speed pane ............................................................................................................................................................ 3-6

Figure 3-9: 1000BASE-T Client pane ..................................................................................................................................... 3-7

Figure 3-10: 100BASE-TX Client pane................................................................................................................................... 3-7

Figure 3-11: 10BASE-T Client pane ....................................................................................................................................... 3-7

Figure 3-12: Execution pane.................................................................................................................................................... 3-8

Figure 3-13: Status bar............................................................................................................................................................. 3-8

Figure 3-14: Result pane for all tests ....................................................................................................................................... 3-9

Figure 3-15: Result pane for Return Loss tests........................................................................................................................ 3-9

Figure 3-16: Result Summary pane ....................................................................................................................................... 3-10

Figure 3-17: Report Configuration pane................................................................................................................................ 3-11

Figure 3-18: Preferences dialog box ...................................................................................................................................... 3-12

Figure 3-19: Advanced Report Configuration dialog box...................................................................................................... 3-15

Figure 3-20: Result Details dialog box .................................................................................................................................. 3-16

Figure 3-21: Mask Segments dialog box ............................................................................................................................... 3-17

TDSET3 Printed Help Document

List of Figures

Figure 3-22: Flash Hits message box......................................................................................................................................3-17

Figure 3-23: Show Segments dialog box................................................................................................................................3-18

Figure 3-24: 1000BASE-T Manual Fit dialog box .................................................................................................................3-18

Figure 3-25: 100BASE-TX/10BASE-T Manual Fit dialog box .............................................................................................3-19

Figure 3-26: Jig Match dialog box..........................................................................................................................................3-20

Figure 3-27: Connections for Disturber Compensation..........................................................................................................3-21

Figure 3-28: Step 1 Connections of Test Fixture Compensation............................................................................................3-22

Figure 3-29: Step 2 Connections of Test Fixture Compensation............................................................................................3-23

Figure 3-30: Virtual Keyboard ...............................................................................................................................................3-24

Figure 3-31: Virtual Keypad...................................................................................................................................................3-24

Figure 3-32: 100BASE-TX Mask Setup dialog box...............................................................................................................3-25

Figure 3-33: 10BASE-T Mask Setup dialog box....................................................................................................................3-26

Figure 3-34: Smooth dialog box.............................................................................................................................................3-26

Figure 3-35: Exit dialog box...................................................................................................................................................3-27

Figure 5-1: 1000BASE-T Configure pane................................................................................................................................5-1

Figure 5-2: 100BASE-TX Configure pane...............................................................................................................................5-5

Figure 5-3: 10BASE-T Configure pane....................................................................................................................................5-7

Figure 6-1: 1000BASE-T Connections with disturbing signal for Template, Peak Volt, Droop, and Distortion.....................6-1

Figure 6-2: 1000BASE-T Connections without disturbing signal for Template, Peak Volt, Droop, and Distortion................6-3

Figure 6-3: 1000BASE-T Step 1 Connections for Jitter Master Filtered..................................................................................6-5

Figure 6-4: 1000BASE-T Step 2 Connections for Jitter Master Filtered..................................................................................6-6

Figure 6-5: 1000BASE-T Connections for Jitter Master Filtered.............................................................................................6-7

Figure 6-6: 1000BASE-T Connections for Jitter Master Unfiltered.........................................................................................6-8

Figure 6-7: 1000BASE-T Connections for Jitter Master Unfiltered.........................................................................................6-9

Figure 6-8: 1000BASE-T Step 1 Connections for Jitter Slave Filtered..................................................................................6-11

Figure 6-9: 1000BASE-T Step 2 Connections for Jitter Slave Filtered..................................................................................6-12

Figure 6-10: 1000BASE-T Connections for Jitter Slave Filtered...........................................................................................6-13

TDSET3 Printed Help Document

List of Figures

Figure 6-11: 1000BASE-T Connections for Jitter Slave Unfiltered ...................................................................................... 6-15

Figure 6-12: 1000BASE-T Connections for Jitter Slave Unfiltered ...................................................................................... 6-16

Figure 6-13: 1000BASE-T Connections for Return Loss...................................................................................................... 6-17

Figure 6-14: 1000BASE-T Connections for Return Loss Calibration................................................................................... 6-19

Figure 6-15: 1000BASE-T Connections for CM Voltage ..................................................................................................... 6-20

Figure 6-16: All 100BASE-TX Connections except Return Loss ......................................................................................... 6-22

Figure 6-17: 100BASE-TX Connections for Return Loss..................................................................................................... 6-23

Figure 6-18: 100BASE-TX Connections for Return Loss Calibration .................................................................................. 6-24

Figure 6-19: 10BASE-T Connections for Link Pulse without Twisted-pair model............................................................... 6-26

Figure 6-20: 10BASE-T Connections for Link Pulse with Twisted-pair model.................................................................... 6-27

Figure 6-21: 10BASE-T Connections for MAU.................................................................................................................... 6-28

Figure 6-22: 10BASE-T Connections for TP_IDL without Twisted-pair model................................................................... 6-29

Figure 6-23: 10BASE-T Connections for TP_IDL with Twisted-pair model........................................................................ 6-30

Figure 6-24: 10BASE-T Connections for Jitter with cable.................................................................................................... 6-31

Figure 6-25: 10BASE-T Connections for Jitter without cable............................................................................................... 6-33

Figure 6-26: 10BASE-T Connections for Differential Voltage............................................................................................. 6-35

Figure 6-27: 10BASE-T Connections for Harmonic ............................................................................................................. 6-36

Figure 6-28: 10BASE-T Connections for Return Loss.......................................................................................................... 6-37

Figure 6-29: 10BASE-T Connections for Return Loss Calibration....................................................................................... 6-38

Figure 6-30: 10BASE-T Connections for CM Voltage ......................................................................................................... 6-40

Figure 8-1: Waveform for 1000BASE-T Template Points A, B, C, and D.............................................................................. 8-2

Figure 8-2: Waveform for 1000BASE-T Template Points F and H ........................................................................................ 8-3

Figure 8-3: Waveform for 1000BASE-T Peak Volt Points A, B, C, and D............................................................................. 8-5

Figure 8-4: Waveform for 1000BASE-T Droop Points F and G ............................................................................................. 8-7

Figure 8-5: 1000BASE-T Jitter Master Filtered Step 1 ........................................................................................................... 8-8

Figure 8-6: 1000BASE-T Jitter Master Filtered Step 2 ........................................................................................................... 8-9

Figure 8-7: Waveform for 1000BASE-T Jitter Master Filtered............................................................................................... 8-9

TDSET3 Printed Help Document

List of Figures

Figure 8-8: 1000BASE-T Jitter Master Filtered (without TX_TCLK)...................................................................................8-10

Figure 8-9: TIE Waveform for 1000BASE-T Jitter Master Unfiltered ..................................................................................8-13

Figure 8-10: Histogram Waveform for 1000BASE-T Jitter Master Unfiltered......................................................................8-13

Figure 8-11: TIE Waveform for 1000BASE-T Jitter Master Unfiltered ................................................................................8-15

Figure 8-12: Histogram Waveform for 1000BASE-T Jitter Master Unfiltered......................................................................8-15

Figure 8-13: 1000BASE-T Jitter Slave Filtered Step 1 ..........................................................................................................8-17

Figure 8-14: 1000BASE-T Jitter Slave Filtered Step 2 ..........................................................................................................8-18

Figure 8-15: Waveform for 1000BASE-T Jitter Slave Filtered..............................................................................................8-18

Figure 8-16: Waveform for 1000BASE-T Jitter Slave Filtered..............................................................................................8-20

Figure 8-17: TIE Waveform for 1000BASE-T Jitter Slave Unfiltered...................................................................................8-22

Figure 8-18: Histogram Waveform for 1000BASE-T Jitter Slave Unfiltered ........................................................................8-23

Figure 8-19: TIE Waveform for 1000BASE-T Jitter Slave Unfiltered...................................................................................8-25

Figure 8-20: Histogram Waveform for 1000BASE-T Jitter Slave Unfiltered ........................................................................8-25

Figure 8-21: 1000BASE-T Distortion user control ................................................................................................................8-27

Figure 8-22: Waveform for 1000BASE-T Distortion.............................................................................................................8-28

Figure 8-23: Waveform for 1000BASE-T Return Loss..........................................................................................................8-30

Figure 8-24: Waveform for 1000BASE-T Common mode Voltage.......................................................................................8-32

Figure 9-1: Waveform for 100BASE-TX Template for Positive polarity ................................................................................9-2

Figure 9-2: Waveform for 100BASE-TX Template for Negative polarity...............................................................................9-2

Figure 9-3: Waveform for 100BASE-TX Differential Output Voltage for Positive polarity ...................................................9-4

Figure 9-4: Waveform for 100BASE-TX Differential Output Voltage for Negative polarity..................................................9-4

Figure 9-5: Waveform for 100BASE-TX Amplitude Symmetry for Positive polarity.............................................................9-6

Figure 9-6: Waveform for 100BASE-TX Amplitude Symmetry for Negative polarity...........................................................9-6

Figure 9-7: Waveform for 100BASE-TX Rise Time for Positive polarity...............................................................................9-8

Figure 9-8: Waveform for 100BASE-TX Rise Time for Negative polarity .............................................................................9-8

Figure 9-9: Waveform for 100BASE-TX Fall Time for Positive polarity..............................................................................9-10

Figure 9-10: Waveform for 100BASE-TX Fall Time for Negative polarity ..........................................................................9-10

xii

TDSET3 Printed Help Document

List of Figures

Figure 9-11: Waveform for 100BASE-TX Rise/Fall Time Symmetry for Positive polarity ................................................. 9-12

Figure 9-12: Waveform for 100BASE-TX Rise/Fall Time Symmetry for Negative polarity................................................ 9-12

Figure 9-13: Waveform for 100BASE-TX Waveform Overshoot for Positive polarity........................................................ 9-14

Figure 9-14: Waveform for 100BASE-TX Waveform Overshoot for Negative polarity ...................................................... 9-14

Figure 9-15: Waveform for 100BASE-TX Jitter for Positive polarity................................................................................... 9-15

Figure 9-16: Waveform for 100BASE-TX Jitter for Negative polarity................................................................................. 9-16

Figure 9-17: Waveform for 100BASE-TX Distortion ........................................................................................................... 9-17

Figure 9-18: Waveform for 100BASE-TX Return Loss Transmitter .................................................................................... 9-19

Figure 9-19: Waveform for 100BASE-TX Return Loss Receiver......................................................................................... 9-19

Figure 10-1: 10BASE-T Template user control dialog box................................................................................................... 10-2

Figure 10-2: Waveform for 10BASE-T MAU Ext ................................................................................................................ 10-2

Figure 10-3: Waveform for 10BASE-T MAU Ext Inv.......................................................................................................... 10-3

Figure 10-4: Waveform for 10BASE-T MAU Int ................................................................................................................. 10-3

Figure 10-5: Waveform for 10BASE-T MAU Int Inv ........................................................................................................... 10-3

Figure 10-6: 10BASE-T Template user control dialog box................................................................................................... 10-5

Figure 10-7: Waveform for 10BASE-T Link Pulse Timing .................................................................................................. 10-6

Figure 10-8: Waveform for 10BASE-T Link Pulse Head...................................................................................................... 10-6

Figure 10-9: Waveform for 10BASE-T Link Pulse Tail........................................................................................................ 10-7

Figure 10-10: 10BASE-T Template user control dialog box................................................................................................. 10-9

Figure 10-11: Waveform for 10BASE-T TP_IDL Head...................................................................................................... 10-10

Figure 10-12: Waveform for 10BASE-T TP_IDL Tail ....................................................................................................... 10-10

Figure 10-13: Waveform for 10BASE-T Differential Voltage............................................................................................ 10-11

Figure 10-14: Waveform for 10BASE-T Harmonic ............................................................................................................ 10-13

Figure 10-15: 10BASE-T Jitter with cable user control ...................................................................................................... 10-14

Figure 10-16: Waveform for 10BASE-T Jitter with Cable for Normal output timing jitter ................................................ 10-15

Figure 10-17: Waveform for 10BASE-T Jitter with Cable for 8 BT output timing jitter ................................................... 10-15

Figure 10-18: Waveform for 10BASE-T Jitter with Cable for 8.5 BT output timing jitter ................................................. 10-16

TDSET3 Printed Help Document

xiii

List of Figures

Figure 10-19: 10BASE-T Jitter without cable user control..................................................................................................10-17

Figure 10-20: Waveform for 10BASE-T Jitter without Cable for Normal output timing jitter............................................10-18

Figure 10-21: Waveform for 10BASE-T Jitter without Cable for 8 BT output timing jitter................................................10-18

Figure 10-22: Waveform for 10BASE-T Jitter without Cable for 8.5 BT output timing jitter.............................................10-19

Figure 10-23: Waveform for 10BASE-T Return Loss Transmitter ......................................................................................10-21

Figure 10-24: Waveform for 10BASE-T Return Loss Receiver ..........................................................................................10-21

Figure 10-25: Waveform for 10BASE-T Common mode Voltage.......................................................................................10-22

Figure 11-1: 1000BASE-T View Waveform for Template, Peak Volt, and Droop with disturbing signal............................11-1

Figure 11-2: 1000BASE-T View Waveform for Template, Peak Volt, and Droop without disturbing signal.......................11-1

Figure 11-3: 1000BASE-T View Waveform for Jitter Master Filtered (with TX_TCLK access)..........................................11-2

Figure 11-4: 1000BASE-T View Waveform for Jitter Master Filtered (without TX_TCLK access) ....................................11-2

Figure 11-5: 1000BASE-T View Waveform for Jitter Master Unfiltered (with TX_TCLK access)......................................11-2

Figure 11-6: 1000BASE-T View Waveform for Jitter Master Filtered (without TX_TCLK access) ....................................11-3

Figure 11-7: 1000BASE-T View Waveform for Jitter Slave Filtered (with TX_TCLK access)............................................11-3

Figure 11-8: 1000BASE-T View Waveform for Jitter Master Filtered (without TX_TCLK access) ....................................11-4

Figure 11-9: 1000BASE-T View Waveform for Jitter Slave Unfiltered (with TX_TCLK access)........................................11-4

Figure 11-10: 1000BASE-T View Waveform for Jitter Master Filtered (without TX_TCLK access) ..................................11-4

Figure 11-7: 1000BASE-T View Waveform for Distortion ...................................................................................................11-5

Figure 11-8: 1000BASE-T View Waveform for Return Loss................................................................................................11-6

Figure 11-9: 1000BASE-T View Waveform for CM Voltage................................................................................................11-6

Figure 12-1: 100BASE-TX View Waveform for all tests except Return Loss.......................................................................12-1

Figure 12-2: 100BASE-TX View Waveform for Return Loss Transmitter............................................................................12-1

Figure 12-3: 100BASE-TX View Waveform for Return Loss Receiver................................................................................12-2

Figure 13-1: 10BASE-T View Waveform for Link Pulse ......................................................................................................13-1

Figure 13-2: 10BASE-T View Waveform for MAU..............................................................................................................13-1

Figure 13-3: 10BASE-T View Waveform for TP_IDL..........................................................................................................13-2

Figure 13-4: 10BASE-T View Waveform for Jitter with cable..............................................................................................13-2

xiv

TDSET3 Printed Help Document

List of Figures

Figure 13-5: 10BASE-T View Waveform for Jitter with cable............................................................................................. 13-3

Figure 13-6: 10BASE-T View Waveform for Differential Voltage ...................................................................................... 13-3

Figure 13-7: 10BASE-T View Waveform for Harmonic....................................................................................................... 13-4

Figure 13-8: 10BASE-T View Waveform for Return Loss ................................................................................................... 13-4

Figure 13-9: 10BASE-T View Waveform for CM Voltage................................................................................................... 13-5

Figure 15-1: AWG Automation Setup................................................................................................................................... 15-1

Figure 15-2: Connecting the AWG and the Oscilloscope...................................................................................................... 15-3

Figure 15-3: Verifying the instrument connections ............................................................................................................... 15-4

Figure 15-4: TekVISA Resource Manager Configuration..................................................................................................... 15-5

Figure 18-1: Calibration for 1000BASE-T Return Loss........................................................................................................ 18-1

Figure 18-2: Connect pane of 1000BASE-T Return Loss ..................................................................................................... 18-2

Figure 18-3: Waveform of 1000BASE-T Return Loss Open Calibration.............................................................................. 18-2

Figure 18-4: Waveform of 1000BASE-T Return Loss Short Calibration.............................................................................. 18-3

Figure 18-5: Waveform of 1000BASE-T Return Loss Load Calibration .............................................................................. 18-3

Figure 18-6: Calibration for 100BASE-TX Return Loss....................................................................................................... 18-4

Figure 18-7: Waveform of 100BASE-TX Return Loss Open Calibration............................................................................. 18-5

Figure 18-8: Waveform of 100BASE-TX Return Loss Short Calibration............................................................................. 18-5

Figure 18-9: Waveform of 100BASE-TX Return Loss Load Calibration ............................................................................. 18-6

Figure 18-10: Calibration for 100BASE-TX Return Loss..................................................................................................... 18-7

Figure 18-11: Waveform of 100BASE-TX Return Loss Open Calibration........................................................................... 18-8

Figure 18-12: Waveform of 100BASE-TX Return Loss Short Calibration........................................................................... 18-8

Figure 18-13: Waveform of 100BASE-TX Return Loss Load Calibration ........................................................................... 18-9

Figure 18-14: Calibration for 10BASE-T Return Loss........................................................................................................ 18-10

Figure 18-15: Waveform of 10BASE-T Return Loss Open Calibration.............................................................................. 18-11

Figure 18-16: Waveform of 10BASE-T Return Loss Short Calibration.............................................................................. 18-11

Figure 18-17: Waveform of 10BASE-T Return Loss Load Calibration.............................................................................. 18-12

Figure 18-18: Calibration for 10BASE-T Return Loss........................................................................................................ 18-13

TDSET3 Printed Help Document

List of Figures

Figure 18-19: Waveform of 10BASE-T Return Loss Open Calibration ..............................................................................18-14

Figure 18-20: Waveform of 10BASE-T Return Loss Short Calibration ..............................................................................18-14

Figure 18-21: Waveform of 10BASE-T Return Loss Load Calibration...............................................................................18-15

xvi

TDSET3 Printed Help Document

List of Tables

Table 2-1: Application Default Directories.............................................................................................................................. 2-7

Table 2-2: 1000BASE-T Default Layouts and Templates....................................................................................................... 2-8

Table 2-3: 100BASE-TX Default Layouts and Templates ...................................................................................................... 2-9

Table 2-4: 10BASE-T Default Layouts and Templates........................................................................................................... 2-9

Table 2-5: Default Settings .................................................................................................................................................... 2-10

Table 3-1: Application Interface Controls ............................................................................................................................... 3-1

Table 3-2: File menu................................................................................................................................................................ 3-3

Table 3-3: Tests menu.............................................................................................................................................................. 3-3

Table 3-4: Results menu .......................................................................................................................................................... 3-4

Table 3-5: Utilities menu ......................................................................................................................................................... 3-4

Table 3-6: Help menu .............................................................................................................................................................. 3-5

Table 3-7: Selection pane buttons............................................................................................................................................ 3-5

Table 3-8: Execution pane ....................................................................................................................................................... 3-8

Table 3-9: Result Summary pane buttons.............................................................................................................................. 3-10

Table 3-10: Report Configuration fields................................................................................................................................ 3-11

Table 3-11: Preferences ......................................................................................................................................................... 3-12

Table 3-12: Advanced Report Configuration......................................................................................................................... 3-15

Table 3-13: Result Details Categorization ............................................................................................................................. 3-16

Table 4-1: Select 1000BASE-T Test Parameters..................................................................................................................... 4-1

Table 4-2: Select 100BASE-TX Test Parameters.................................................................................................................... 4-1

Table 4-3: Select 10BASE-T Test Parameters......................................................................................................................... 4-2

Table 5-1: 1000BASE-T Configure parameters....................................................................................................................... 5-1

Table 5-2: 1000BASE-T Configure parameter description ..................................................................................................... 5-2

Table 5-3: 1000BASE-T Configuration Default Settings........................................................................................................ 5-4

TDSET3 Printed Help Document

xvii

List of Tables

Table 5-4: 100BASE-TX Configure parameters..............................................................................................5-5

Table 5-5: 100BASE-TX Configure parameter description .....................................................................................................5-6

Table 5-6: 100BASE-TX Configuration Default Settings........................................................................................................5-7

Table 5-7: 10BASE-T Configure parameters...................................................................................................5-8

Table 5-8: 10BASE-T Configure parameter description ..........................................................................................................5-8

Table 5-9: 10BASE-T Configuration Default Settings...........................................................................................................5-10

Table 7-1: Test and Pattern description....................................................................................................................................7-1

Table 7-2: Test and Pattern description....................................................................................................................................7-1

Table 7-3: Test and Pattern description....................................................................................................................................7-2

Table 8-1: 1000BASE-T Template Configuration Options......................................................................................................8-1

Table 8-2: 1000BASE-T Peak Volt Configuration Options .....................................................................................................8-4

Table 8-3: 1000BASE-T Droop Configuration Options...........................................................................................................8-6

Table 8-4: 1000BASE-T Jitter Master Filtered Configuration Options....................................................................................8-7

Table 8-5: 1000BASE-T Jitter Master Unfiltered Configuration Options..............................................................................8-11

Table 8-6: 1000BASE-T Jitter Slave Filtered Configuration Options....................................................................................8-16

Table 8-7: 1000BASE-T Jitter Master Unfiltered Configuration Options..............................................................................8-21

Table 8-8: 1000BASE-T Distortion Configuration Options...................................................................................................8-26

Table 8-9: 1000BASE-T Return Loss Configuration Options................................................................................................8-29

Table 8-10: 1000BASE-T CM Voltage Configuration Options .............................................................................................8-31

Table 9-1: 100BASE-TX Template Configuration Options.....................................................................................................9-1

Table 9-2: 100BASE-TX Differential Output Voltage Configuration Options........................................................................9-3

Table 9-3: 100BASE-TX Amplitude Symmetry Configuration Options..................................................................................9-5

Table 9-4: 100BASE-TX Rise Time Configuration Options....................................................................................................9-7

Table 9-5: 100BASE-TX Fall Time Configuration Options ....................................................................................................9-9

Table 9-6: 100BASE-TX Rise/Fall Time Symmetry Configuration Options.........................................................................9-11

Table 9-7: 100BASE-TX Waveform Overshoot Configuration Options................................................................................9-13

Table 9-8: 100BASE-TX Jitter Configuration Options ..........................................................................................................9-15

xviii

TDSET3 Printed Help Document

List of Tables

Table 9-9: 100BASE-TX Distortion Configuration Options ................................................................................................. 9-16

Table 9-10: 100BASE-TX Return Loss Configuration Options............................................................................................ 9-18

Table 10-1: 10BASE-T MAU Configuration Options........................................................................................................... 10-1

Table 10-2: 10BASE-T Link Pulse Configuration Options ................................................................................................... 10-4

Table 10-3: 10BASE-T TP_IDL Configuration Options....................................................................................................... 10-8

Table 10-4: 10BASE-T Differential Voltage Configuration Options .................................................................................. 10-11

Table 10-5: 10BASE-T Harmonic Configuration Options .................................................................................................. 10-12

Table 10-6: 10BASE-T Jitter with cable Configuration Options......................................................................................... 10-13

Table 10-7: 10BASE-T Jitter without cable Configuration Options.................................................................................... 10-16

Table 10-8: 10BASE-T Return Loss Configuration Options............................................................................................... 10-19

Table 10-9: 10BASE-T CM Voltage Configuration Options .............................................................................................. 10-22

Table 15-1: AWG Configuration Parameters and Descriptions............................................................................................. 15-1

Table 15-2: AWG Configuration Parameters and Defaults ................................................................................................... 15-2

Table 17-1: Command Arguments and Queries..................................................................................................................... 17-2

Table 17-2: 1000BASE-T GPIB Commands......................................................................................................................... 17-6

Table 17-3: 100BASE-TX GPIB Commands........................................................................................................................ 17-8

Table 17-4: 10BASE-T GPIB Commands............................................................................................................................. 17-9

Table 17-5: AWG Automation GPIB Commands ............................................................................................................... 17-11

Table A-0-1: 1000BASE-T Specification Range.................................................................................................................... A-1

Table A-0-2: 100BASE-TX Specification Range................................................................................................................... A-2

Table A-0-3: 10BASE-T Specification Range........................................................................................................................ A-3

Table B-0-1: TDSET3 Error Messages....................................................................................................................................B-1

Table B-0-2: Remote GPIB Error Messages............................................................................................................................B-3

TDSET3 Printed Help Document

xix

List of Tables

TDSET3 Printed Help Document

About TDSET3

Figure 1-1: TDSET3 Splash Screen

The TDSET3 Ethernet Compliance Test Software tests the Ethernet 's physical layer for — 1000BASE-T, 100BASE-TX, and 10BASE-T in compliance with IEEE 802.3-2000 and ANSI X3.263-1995 standards. This version allows you to test each speed for various fields such as:

1000BASE-T

Template Peak Voltage Droop Jitter Master Filtered Jitter Master Unfiltered Jitter Slave Filtered Jitter Slave Unfiltered Distortion Return Loss Common mode Voltage

100BASE-TX

Template Differential Output Voltage Signal Amplitude Symmetry Rise Time Fall Time Rise / Fall Time Symmetry Waveform Overshoot Jitter Duty Cycle Distortion Return Loss

TDSET3 Printed Help Document

1-1

About TDSET3

10BASE-T

Template MAU Ext Template MAU Ext Inv Template MAU Int Template MAU Int Inv Template Link Pulse Template TP_IDL Differential Voltage Harmonic Jitter with cable Jitter without cable Return Loss Common mode Voltage

TDSET3 has a Report Generator tool that helps you create and print custom reports.

Using Online Help

TDSET3 also supports Remote GPIB commands.

Note: Use the Select All button to test all the parameters of the selected speed.

The TDSET3 online help serves as a reference for using the TDSET3 Ethernet Compliance Test Software.

Contents: The Contents tab displays books and pages that represent the categories of information in the online Help system.

Index: The Index tab displays a multi-level list of keywords and keyword phrases. These terms are associated with topics in the Help system and direct you to specific topics.

Search: The Search tab enables you to search for keywords in the Help system and to locate topics containing those words. When the search is completed, a list of topics is displayed so you can select a specific topic to view.

Back and Forward: The Back and Forward buttons allow you to browse through topics.

1-2

To print a topic: Select the Print button from the Help Topics menu bar.

TDSET3 Printed Help Document

Printing from the Online Help

While using the online help, you can print topics and information from the HTML Help viewer.

To print a single topic:

1. Find the topic in the Contents pane. Click Print.

2. Click Print the selected topic and click OK.

To print all topics in a selected TOC book:

1. Find the TOC book in the Contents pane. Click Print.

2. Click Print the selected heading and all subtopics and click OK.

About TDSET3

Conventions

Note: If topics include expanding or drop-down hotspots, click the hotspots to display the information before you.

Hotspot is a clickable text that displays additional information below the link. Click on the hotspot text to show or hide the hotspot content

Some online help topics have color in the examples of the displayed application. If you want to print this type of topic on a monochrome printer, some information may not print because of certain colors. Instead, you should print the topic from the PDF (portable document format) file that corresponds to the online help. You can find the file in the Documents directory on the Optional Applications Software on Windows-Based Oscilloscopes CD-ROM. The application menus in the PDF file are gray scale and all the information can be printed.

Online help uses the following conventions:

 When steps require a sequence of selections using the application interface,

the ">" delimiter marks each transition between a menu and an option. For example, File > Minimize.

TDSET3 Printed Help Document

 DUT refers to the transmitter transmitting the required signal to be tested.

 Two or more adjacent hyperlinks are separated with "|".

 Hotspot is a clickable text that displays additional information below the

link. Click on the hotspot link to show or hide the hotspot content.

1-3

About TDSET3

The application uses this convention:

 Three dots "..." next to any menu item means that the dialog box that pops

up requires user input.

Contacting Tektronix

Phone 1–800–833–9200*

Address

Web site www.tektronix.com

Sales support 1–800–833–9200, select option 1*

Service support 1–800–833–9200, select option 2*

Technical support Email: techsupport@tektronix.com

* This phone number is toll free in North America. After office hours, please leave a voice mail message. Outside North America, contact a Tektronix sales office or distributor; see the Tektronix Web site for a list of offices.

Tektronix, Inc. 14200 SW Karl Braun Drive P.O. Box 500 Beaverton, OR 97077 USA

1–800–833–9200, select option 3*

6:00 a.m. - 5:00 p.m. Pacific time

1-4

TDSET3 Printed Help Document

Feedback

About TDSET3

Tektronix values your feedback on our products. To help us serve you better, please send us your suggestions, ideas, or comments on the application.

Direct your feedback via email to techsupport@tektronix.com or FAX at (503) 627-5695 and include the following information. Please be as specific as possible.

General information:

 Instrument model number and hardware options, if any

 Probes used

 Your name, company, mailing address, phone number, FAX number,

email id

 Please indicate if you would like to be contacted by Tektronix about your

suggestion or comments

Application specific information:

 Software version number

 Description of the problem such that technical support can duplicate the

problem

 The instrument setup file of the oscilloscope and the application is also

required to identify the problem

 If possible, save the waveform on which you are performing the

measurement as a .wfm file

Note: To know the Software version number, click Help > About in the application.

Information through the Web site

You can find information about this and other applications at the Tektronix Inc. Web site, www.tektronix.com information about our application. You can download a free trial version of the TDSET3 application that allows you a five-time trial.

TDSET3 Printed Help Document

. Check this site for firmware updates and other

1-5

About TDSET3

1-6

TDSET3 Printed Help Document

Getting Started

Compatibility

The application is compatible with the following TDS5000, TDS6000, TDS7000 or CSA7000 series oscilloscopes:

TDS5000 series oscilloscopes:

 TDS5032B

 TDS5034B

 TDS5052B

 TDS5054B

 TDS5104B

Note: The two-channel oscilloscopes are TDS5052B and TDS5032B.

TDS6000 series oscilloscopes:

 TDS6404

 TDS6604

 TDS6604B

 TDS6804B

 TDS6124C

 TDS6154C

TDSET3 Printed Help Document

TDS7000 series oscilloscopes:

 TDS7054

 TDS7104

 TDS7154

 TDS7254

 TDS7404

2-1

Getting Started

 TDS7704B

 TDS7404B

 TDS7254B

 TDS7154B

CSA7000 series oscilloscopes:

 CSA7154

 CSA7404

 CSA7404B

Other oscilloscope:

 VMS5000HD

Recommended Accessories

Differential Probes

 P6247 — 1.0 GHz Differential Probe

 P6248 — 1.5 GHz Differential Probe

 P6330 — 3.5 GHz Differential Probe

 P7330 — 3.5 GHz Differential Probe

 P7350 — 5.0 GHz Differential Probe

Active Probes

 P6243, and P6245 1 GHz or above depending on the Oscilloscope (for

1000BASE-T Jitter tests)

Arbitrary Waveform Generator

2-2

 AWG410 — 200 MS/s, 16-Bit Arbitrary Waveform Generator

 AWG420 — 200 MS/s, 16-Bit Arbitrary Waveform Generator

 AWG430 — 200 MS/s, 16-Bit Arbitrary Waveform Generator

 AWG510 — 1 GS/s, 10-Bit Arbitrary Waveform Generator

 AWG520 — 1 GS/s, 10-Bit Arbitrary Waveform Generator

TDSET3 Printed Help Document

Getting Started

 AWG610 — 2.6 GS/s, 8-Bit Arbitrary Waveform Generator

 AWG710 — 4.0 GS/s, 8-Bit Arbitrary Waveform Generator

 AWG2021 — 250 MS/s, 12-Bit Arbitrary Waveform Generator (for

Disturbing Signal Generator)

Note: In the case of AWG 400 series, the 1000Base-T return loss test values after

98.5 MHz are extrapolated.

Probe Positioner

 PPM100 Flexible Arm Probe Positioner

Differential Input Voltage of Differential Probes

 P6247 — ± 8.5 V

 P6248 — ± 8.5 V

 P6330 — ± 2 V

 P7330 — ± 2 V

 P7350 — ± 2.5 V

Requirements and Restrictions

Do not change the oscilloscope settings when the test is running. If you change the settings when the test is running, the application may give abnormal test results.

Prerequisites

 TekVisa must be installed in the oscilloscope

 A TDS7000/CSA7000/TDS6000 series oscilloscope with Firmware version

2.2.0 or later

TDSET3 Printed Help Document

 A TDS7000B/CSA7000B oscilloscope with Firmware version 3.0.0 or later.

 A TDS5000B series oscilloscope with Firmware version 2.0.0 or later.

 A TDS6000B series ocilloscope with Firmware version 4.0.1 or later.

 A TDS6000C series oscilloscope with Firmware version 5.0.0 or later.

2-3

Getting Started

For better and reliable results

 Prior to running any test, calibrate the probes, and oscilloscope for Signal

Path Compensation

 Cable length between the DUT and the test fixture should not be more than

two inches

 Use 500 waveforms for averaging 1000BASE-T

 Use 64 waveforms for averaging, and 200000 samples for mask testing

10BASE-T or 100BASE-TX wherever applicable

 Use 48 waveforms for averaging 10BASE-T harmonics

 If the signal is not connected and the noise level is below 50 mV, the

application detects and gives a message as invalid signal

To calibrate an oscilloscope, select Utilities > Instrument Calibration in the

oscilloscope menu bar and select the Calibrate button.

Note: If you do not install the latest version (Version 2.2.0 or above) of TDS7000 or CSA7000 Firmware, the application will not test the mask related parameters.

Remember

About the Test Fixture

 TDS5032B and TDS5052B are two-channel oscilloscopes. The drop-down

list for any Data, Ref, or Math sources displays only two channels.

 For 1000BASE-T Template test, the TDS5000B series oscilloscope displays

the horizontal scale in 4 ns.

 The two-channel oscilloscopes do not support the 1000BASE-T Jitter Slave

Filtered test.

 The TDS6000B and TDS7000B series oscilloscope do not support Flash

Hits.

The TF-GBE test fixture, designed by Tektronix and manufactured and distributed by Crescent Heart Software, facilitates 1000BASE-T, 100BASE-TX and 10BASE-T Ethernet compliance testing when used with an appropriate TDS5000, TDS6000, TDS7000 or CSA7000 Series oscilloscope and Tektronix TDSET3 Ethernet Compliance Test Software.

For more information, visit Crescent Heart Software Web site www.c-h-s.com

2-4

TDSET3 Printed Help Document

Starting the Application

Getting Started

1. From the oscilloscope menu, select File > Run Application > Ethernet

Compliance Test Software.

TDSET3 Printed Help Document

Figure 2-1: Run Application

2. The splash screen appears. The oscilloscope display resizes to fit the upper

half of the screen and the lower half of the oscilloscope screen displays the TDSET3 application.

2-5

Getting Started

Figure 2-2: Application Interface

3. The application is automatically set to its default settings.

4. If you access oscilloscope functions, the oscilloscope display appears in full

screen and the TDSET3 application recedes to the background.

5. To return to the TDSET3 application, select the APP button in the

oscilloscope display.

Minimizing and Maximizing the Application

The application appears even when you minimize the oscilloscope.

 To minimize the application, select File > Minimize. The TDSET3 window

minimizes to the Windows taskbar and upper half screen has the oscilloscope display and lower half of the screen has the desktop

 To maximize the application, select Ethernet Compliance Test Software in

the Windows taskbar.

 To hide the application, select the Hide button or select File > Hide.

The Report Generator module windows are independent of the TDSET3 application. Select the Minimize button on the right hand corner of the relevant report generator window to minimize it.

Note: If you select Hide button, the TDSET3 window goes to the background and the Oscilloscope display resizes to the whole screen.

Returning to the Application

When you access oscilloscope functions, the oscilloscope fills the display. You can access oscilloscope functions in the following ways:

2-6

TDSET3 Printed Help Document

Exiting the Application

Getting Started

 Choose the Menu bar or the Toolbar mode on the oscilloscope and access

the menus.

 Press front-panel buttons.

 To return to the application, select the APP button on the top right of the

oscilloscope display.

To exit the application, do the following:

 Select File > Exit or select the Exit button .

 On exiting the application a message box "Do you want to restore the

oscilloscope settings to their state prior to starting this application?" appears.

 Select Yes, No, or Cancel. Yes is selected by default.

Note: Using other methods to exit the application results in abnormal termination of the application.

Application Directories and File Names

The TDSET3 application uses directories to save and recall setup files and uses file name extensions to identify the file type. The next table lists the default directory names.

Table 2-1: Application Default Directories

Directory Action

C:\TekApplications\TDSET3\Setup Stores the application settings to

C:\TekApplications\TDSET3\ReportGenerator\Templates Stores the default templates of

C:\TekApplications\TDSET3\ReportGenerator\Reports Stores the Reports for 10BASE-T,

C:\TekApplications\TDSET3\ReportGenerator\Layouts Stores the Report Layouts for

C:\TekApplications\TDSET3\AWGWaveforms Stores the AWG waveforms. C:\TekApplications\TDSET3\Images Stores all the images.

setup files

report generator

100BASE-TX, and 1000BASE-T

10BASE-T, 100BASE-TX, and 1000BASE-T

TDSET3 Printed Help Document

2-7

Getting Started

Application Software Default Layouts and Templates

Table 2-2: 1000BASE-T Default Layouts and Templates

Test Default template

1000BASE-T (Default layout — 1000T.rpl)

Coversheet Coversheet for 1000BaseT.rgt

Coversheet for 1000BaseT_2.rgt

Template 1000T-TemplateA.rgt

1000T-TemplateB.rgt 1000T-TemplateC.rgt 1000T-TemplateD.rgt 1000T-TemplateF.rgt 1000T-TemplateH.rgt

Peak Volt 1000T-PeakVoltA.rgt

1000T-PeakVoltB.rgt 1000T-PeakVoltC.rgt 1000T-PeakVoltD.rgt

Droop 1000T-DroopG.rgt

1000T-DroopJ.rgt

Jitter 1000 Jitter Master filtered.rgt

1000 Jitter Master Unfiltered[TIE].rgt 1000 Jitter Master Unfiltered[HIS].rgt 1000 Jitter Slave filtered.rgt 1000 Jitter Slave Unfiltered[TIE].rgt 1000 Jitter Slave Unfiltered[HIS].rgt 1000T- Jitter master filtered_NOCLK.rgt 1000T- Jitter master unfiltered[HIS]_NOCLK.rgt 1000T- Jitter master unfiltered[TIE]_NOCLK.rgt 1000T- Jitter slave filtered_NOCLK.rgt 1000T- Jitter slave unfiltered[HIS]_NOCLK.rgt

1000T- Jitter slave unfiltered[TIE]_NOCLK.rgt Distortion 1000T-Distortion.rgt Common mode Voltage 1000T-Common mode Voltage.rgt Return Loss 1000T-Return Loss.rgt

2-8

TDSET3 Printed Help Document

Getting Started

Table 2-3: 100BASE-TX Default Layouts and Templates

Test Default template

100BASE-TX (Default layout — 100TX.rpl)

Coversheet Coversheet for 100BaseTX.rgt Template 100-AOI Template.rgt Differential Output Voltage 100-Differential Output Voltage.rgt Signal Amplitude Symmetry 100-Signal Amplitude Symmetry.rgt Rise Time 100-Rise Time.rgt Fall Time 100-Fall Time.rgt Rise/Fall Time Symmetry 100-Rise Fall Time Symmetry.rgt Waveform Overshoot 100-Waveform Overshoot.rgt Jitter 100-Transmit Jitter.rgt Duty Cycle Distortion 100-Duty Cycle Distortion.rgt Return Loss 100-Tx Return Loss.rgt

100-Rx Return Loss.rgt

Table 2-4: 10BASE-T Default Layouts and Templates

Test Default template

10BASE-T (Default layout — 10T.rpl)

Coversheet Coversheet for 10BaseT.rgt MAU Ext Template 10 MAU ext template.rgt MAU Ext Inv Template 10 mau ext inv template.rgt MAU Int Template 10 mau int template.rgt MAU Int Inv Template 10 mau int inv template.rgt Link Pulse Template Load with TPM 10 Link Pulse Load1 with TPM template.rgt

10 Link Pulse Load2 with TPM template.rgt 10 Link Pulse 100 with TPM template.rgt

Link Pulse Template Load without TPM 10 Link Pulse Load1 without TPM template.rgt

10 Link Pulse Load2 without TPM template.rgt

10 Link Pulse 100 without TPM template.rgt Link Pulse Timing 10 Link Pulse Timing.rgt TP_IDL Template Load with TPM 10 TP_IDL Load1 with TPM template.rgt

10 TP_IDL Load2 with TPM template.rgt

10 TP_IDL 100 with TPM template.rgt TP_IDL Template Load without TPM 10 TP_IDL Load1 without TPM template.rgt

10 TP_IDL Load2 without TPM template.rgt

10 TP_IDL 100 without TPM template.rgt Differential Output Voltage 10 differential output voltage.rpt

TDSET3 Printed Help Document

2-9

Getting Started

Table 2-4: 10BASE-T Default Layouts and Templates

Harmonic 10 harmonic of all ones.rgt Jitter with cable Normal output timing 10 output timing jitter with cable.rgt Jitter with cable 8.0 output timing 10 8.0 output timing jitter with cable.rgt Jitter with cable 8.5 output timing 10 8.5 output timing jitter with cable.rgt Jitter without cable Normal output timing 10 output timing jitter without cable.rgt Jitter without cable 8.0 output timing 10 8.0 output timing jitter without cable.rgt Jitter without cable 8.5 output timing 10 8.5 output timing jitter without cable.rgt Return Loss 10 Tx Return Loss.rgt

Common mode Voltage 10 Common mode Voltage.rgt

Application Software Default Settings

10 Rx Return Loss.rgt

The TDSET3 application is automatically set to the default settings. The next table lists the default settings with which the TDSET3 application starts.

Table 2-5: Default Settings

Parameter Selection Default Setting

Speed 1000-T Select > 1000-T Template/Volt tab Template/Volt tab A Droop tab G Jit/Distortion tab Master Unfiltered Return Loss tab Return Loss CM Voltage tab CM Voltage Select > 100-TX Parametric tab Parametric tab Template (Both Polarity) Return Loss tab Transmitter Configure > 1000-T Data CH1 Master CLK CH2 Slave CLK CH3 Data (TM2) CH1 Data (TM3) CH2 TX_TCLK CH1 # Averages 64 Clock Edge Rising Hi Resolution 64 Output Ref1 Disturbing Signal No Filter Int TX_TCLK No

2-10

TDSET3 Printed Help Document

Getting Started

Table 2-5: Default Settings

LP Filter Yes Meas Type TIE Probe:P1 CH1 Probe:P2 CH2 Pair ID A Load 85, 100, 115 ohm Smooth 7 Record Length Varies depending on the Memory option

available on the Oscilloscope. Hysteresis 5.00 % Configure > 100-TX Data CH1 Mask Setup

Samples

Fail Threshold Mask Scale Normal Acquisition Sample/Average (depends on the

Pulse Width 16 ns Probe:P1 / Probe:P3 CH1 Probe:P2 / Probe:P4 CH2 Load 85, 100, 115 ohm Smooth 7 # Averages 100 for Return Loss and 48 for other

Configure > 10-T Data CH1 Acquisition Sample/Average (depends on the

Section Both MAU Type Internal MAU Scale Normal Mask Setup

Samples

Fail Threshold

Harmonic Ones

Output

# Averages

Time/Scale

Sequence Normal (NLP) Probe: P1 / Probe: P3 CH1 Probe: P2 / Probe: P4 CH2

50K 1

parameter selected) Average is the default mode # Waveforms = 16

tests

parameter selected) Average is the default mode # Waveforms = 16

50K 1

Math1 48 10 microseconds

TDSET3 Printed Help Document

2-11

Getting Started

Table 2-5: Default Settings

Load 85, 100, 111 ohm Smooth 7 Report > Report Generator Generate Report tab

2-12

TDSET3 Printed Help Document

Operating Basics

TDSET3 Application Window

The TDSET3 application is a Windows-based application. The application window comprises Menu bar, Selection pane, Speed pane, Client pane, Execution pane, and Status bar. The Client pane changes between Configuration pane, Parameter Selection pane, Connection pane, and View Waveform pane depending on what you have selected in the Selection pane. The Client pane changes to Result pane automatically after you run the test.

Figure 3-1: Application Window

TDSET3 Application Interface Controls

The TDSET3 application interface uses the following controls:

Table 3-1: Application Interface Controls

Controls Description

Menu bar Located at the top of the application and has the TDSET3 menus. Tab Labeled group of options with similar items. Pane Enclosed visual frame with a set of related options. Option button Defines a particular command or task. Drop-down list box Lists the items from which you can select one item. Field Box that you can use to type in text or to enter a value with the keypad or a

multipurpose knob.

TDSET3 Printed Help Document

3-1

Operating Basics

Table 3-1: Application Interface Controls

Check Boxes Square box that you can use to select or clear preferences. Scroll bar Vertical or horizontal bar at the side or bottom of a display area used to

move around that area. Browse Displays a window where you can look through a list of directories and files. Command button Initiates an immediate action. Keypad Appears when you select the box and enter a value. MP/GP knob Displays a line between the knob and the box. You can turn the knob on the

oscilloscope to select a value.

Menu bar

The menu bar of TDSET3 has the following menus.

File Menu

 File menu

 Tests menu

 Results menu

 Utilities menu

 Help menu

The File menu appears as shown by the next figure:

3-2

Figure 3-2: File Menu

TDSET3 Printed Help Document

Operating Basics

The next table lists the menu selection and description for the File menu.

Table 3-2: File menu

Menu selection Description

Recall Default Setup

Recall Setup Recalls the application settings from a setup file. Save Setup Saves the application settings to a setup file. Preferences Shows/Hides the message boxes displayed while running the test. Minimize Minimizes the Application window. Hide Hides the Application window. Exit Displays the Restore Settings dialog box and closes the Application.

Recalls the default settings for the application.

Tests Menu

The Tests menu appears as shown by the next figure:

Figure 3-3: Tests menu

The next table lists the menu selection and description for the Tests menu.

Table 3-3: Tests menu

Menu selection Description

Select

1000BASE-T Displays the point and test parameter selections for 1000BASE-T in the

Client pane. 100BASE-TX Displays the parameters for 100BASE-TX in the Client pane. 10BASE-T Displays the parameters for 10BASE-T in the Client pane.

Configure Displays the configuration details for the selected speed and test. Connect Displays the connection instructions for the selected speed. View Waveform Displays the waveform based on the settings.

TDSET3 Printed Help Document

3-3

Operating Basics

Results Menu

The Results menu appears as shown by the next figure:

Figure 3-4: Results menu

The next table lists the menu selection and description for the Results menu.

Table 3-4: Results menu

Utilities Menu

Menu selection Description

Summary Displays the results summary of last test conducted. Details Displays the detailed results of last test conducted.

The Utilities menu appears as shown by the next figure:

Figure 3-5: Utilities menu

The next table lists the menu selection and description for the Utilities menu.

Table 3-5: Utilities menu

Menu selection Description

Report Generator Displays the Report Generator window. Enable Remote GPIB Enables you to use remote GPIB commands to control the application. Automate AWG Enables you to automate file transfer and waveform setup on an

Arbitrary Waveform Generator.

3-4

TDSET3 Printed Help Document

Help Menu

Operating Basics

The Help menu appears as shown by the next figure:

Figure 3-6: Help menu

The next table lists the menu selection and description for the Help menu.

Table 3-6: Help menu

Selection pane

Menu selection Description

Help Topics Displays the help file for the TDSET3 application. About Ethernet Compliance

Test Software

Displays a dialog box with information about the current TDSET3 application.

The Selection pane located to the left of the Application window allows you to navigate through the application.

Figure 3-7: Selection pane

TDSET3 Printed Help Document

The next table lists the button and the task description.

Table 3-7: Selection pane buttons

Button Description

Select Displays the test selection parameters in the Client pane for the selected

speed.

3-5

Operating Basics

Table 3-7: Selection pane buttons

Configure Displays the configuration parameters in the Client pane for the selected test

parameter.

Connect Displays the connection details in the Client pane for the selected test

parameter.

View Wfm Displays the waveform in the Client pane for the selected test parameter.

Speed pane

The Speed pane located to the left of the Application window displays the speed to be selected.

Client pane

Figure 3-8: Speed pane

Select 1000-T to test 1000BASE-T, 100-TX to test 100BASE-TX and 10-T to test 10BASE-T.

The Client pane displays the parameters of the selected speed.

The Client pane located adjacent to the Speed pane displays the test parameters, configuration parameters, connections, view waveforms or results. Clicking on each tab changes the Client pane to display the relevant test parameters.

3-6

TDSET3 Printed Help Document

Operating Basics

1000BASE-T

Client pane

100BASE-TX

Client pane

The following figure shows the Client pane of 1000BASE-T Template.

Figure 3-9: 1000BASE-T Client pane

The following figure shows the Client pane of 100BASE-TX Template.

10BASE-T

Client pane

TDSET3 Printed Help Document

Figure 3-10: 100BASE-TX Client pane

The following figure shows the Client pane of 10BASE-T Template.

Figure 3-11: 10BASE-T Client pane

3-7

Operating Basics

Execution pane

The Execution pane located to the right of the Application window displays the buttons Run Test and Result.

Figure 3-12: Execution pane

Clicking on each button performs a particular task. The following table lists the button and the task description.

Table 3-8: Execution pane

Button Button Name Description

Run Test Runs the selected test or tests.

Result Displays the Result pane that shows the test results.

Report Summary

Report Detail

Displays the location to which the report summary is saved. Click OK to store the result details in a .csv file.

Displays the location to which the detailed report is saved. Click OK to store the result details in a .rpt file depending on the layout selected in Report Configuration pane.

Note: The report details are real time and no history is maintained. Ensure that you save the report details before you run another test.

Status bar

3-8

At the bottom of the application window is the status bar that displays the selected test and the important configuration parameters.

Figure 3-13: Status bar

TDSET3 Printed Help Document

Result pane

Operating Basics

After you run a test, the Result pane automatically appears as shown by the following figure.

Figure 3-14: Result pane for all tests

After you run a Return Loss test, the Result pane automatically appears as shown by the following figure.

Figure 3-15: Result pane for Return Loss tests

The Result pane comprises Result Summary pane and Report Configuration pane.

TDSET3 Printed Help Document

3-9

Operating Basics

Result

Summary pane

The Result Summary pane displays the test results as Pass/Fail/Inconclusive.

Figure 3-16: Result Summary pane

Indicates that the test has passed.

Indicates that the test has failed.

Indicates that the test is inconclusive.

The next table lists the button and the task description.

Table 3-9: Result Summary pane buttons

Button Description

Export Exports the return loss values in a .csv file. Clear Results Clears the results in the Result Summary pane. Result Details Displays the Result Details dialog box that shows the details of test results

categorized as Description, Specification range, Measured Value, Pass/Fail/Inconclusive, and Remarks.

Manual Fit Displays the Manual Fit dialog box that allows you to adjust the waveform to fit

into the Mask. This button is enabled only when you test 1000BASE-T Template, 100BASE-TX Template or 10BASE-T Template.

Smooth Displays the Smooth dialog box that allows you to smoothen the return loss

waveform. This button is enabled only when you test Return Loss.

3-10

TDSET3 Printed Help Document

Operating Basics

Report

Configuration pane

You can set the report details to identify and automatically generate the report. You can set a default report file.

Figure 3-17: Report Configuration pane

The next table lists the report configuration fields and description.

Table 3-10: Report Configuration fields

Field Description

Device ID To identify on which DUT the test was conducted by printing the Device ID

on the generated report.

Device description To identify on which DUT the test was conducted by printing the Device

Description on the generated report.

Pair ID To identify the unique pairs by printing the Device Description on the

generated report. This field is enabled only for 1000BASE-T.

Report File To specify the path and the file in which the generated report will be saved.

A default file name and path displayed for the selected speed.

Enable Preview To automatically preview the report after generation. Advanced button Displays the Advanced Report Configuration dialog box.

Dialog Boxes

Preferences

dialog box

TDSET3 Printed Help Document

Use this dialog box to set the user preferences such as, show or hide the Overwrite Reference message box, Overwrite Math message box, 10Base-T user intervention for Template, 10Base-T user intervention for Jitter tests and 1000Base-T user intervention for Distortion test.

Click File > Preferences to display the Preferences dialog box.

3-11

Operating Basics

Figure 3-18: Preferences dialog box

The next table lists the preferences and task description.

Table 3-11: Preferences

Preference Task Description

Show or Hide the Overwrite Reference message box

Show or Hide the Overwrite Math message box

In Preference dialog box, select or clear the Show Ref overwrite check box.

If you select Show Ref overwrite check box, the application displays the following warning every time you run 1000BASE-T Template, Peak Volt, Distortion, and Jitter tests. This dialog box also appears for Return Loss tests. This dialog box appears for 1000BASE-T Droop test only if Disturbing Signal is selected as Yes.

In Preference dialog box, select or clear the Show Math overwrite check box.

If you select Show Math overwrite check box, the application displays the following warning box every time you run 10BASE-T Harmonic Test.

3-12

TDSET3 Printed Help Document

Table 3-11: Preferences

Show or hide 1000Base-T user intervention for Distortion test

In Preference dialog box, select or clear the Show 1000Base-T Distortion

user control check box.

If you select the check box, the application displays the following warning

box every time you run 1000BASE-T Distortion Test.

Operating Basics

Show or hide 10Base-T user intervention for Template tests

In Preference dialog box, select or clear the Show 10Base-T Template

user control check box.

If you select the check box, the application displays the following warning

box every time you run 10BASE-T Template Test.

Toggle Lock Mask to Wfm between ON and OFF to lock or unlock the

mask to waveform when you zoom in or zoom out.

Toggle Mask Autofit between ON and OFF to allow the oscilloscope to

automatically fit the waveform to mask.

TDSET3 Printed Help Document

3-13

Operating Basics

Table 3-11: Preferences

Show or hide 10Base-T user intervention for Jitter tests

In Preference dialog box, select or clear the Show 10Base-T Jitter user control check box.

If you select the check box, the application displays the following warning box every time you run 10BASE-T Jitter with cable Test.

If you select the check box, the application displays the following warning box every time you run 10BASE-T Jitter without cable Test.

Click OK to set the preferences.

Click Cancel to exit the Preference dialog box.

3-14

TDSET3 Printed Help Document

Advanced Report

Configuration

dialog box

Operating Basics

Select Results in the Execution pane, and Advanced in the Report Configuration pane of the Result pane. The Advanced Report Configuration dialog box appears as shown in the next figure.

Figure 3-19: Advanced Report Configuration dialog box

The table lists the options that you can configure in the advanced report configuration dialog box.

Table 3-12: Advanced Report Configuration

Field Description

Device ID Prints the Device Id on the generated report to help you identify

on which DUT the test was conducted.

Process Prints the Process on the generated report to help you identify

the process used for DUT.

Voltage Prints the Voltage on the generated report to help you identify

the voltage values used while testing the DUT.

Temperature Prints the Temperature on the generated report to help you

identify the temperature values used while making the DUT.

Last Cal date Prints the Last Cal date on the generated report to help you

identify the date on which the Oscilloscope was last calibrated.

Use oscilloscope settings for image report

Select this check box to use the oscilloscope settings for exporting images.

TDSET3 Printed Help Document

Click OK to configure the report.

Click Cancel to exit the report setup.

3-15

Operating Basics

Result Details

dialog box

Select Result Details button in Result pane to display the Result Details dialog box.

After you have completed the test and you want to see the result details, click on the Result Details button in Result pane. The Result Details dialog box appears as shown by the following figure. The title bar displays the selected speed.

Figure 3-20: Result Details dialog box

The results are categorized as listed in the next table.

Table 3-13: Result Details Categorization

Category Description

Description Displays the selected test. Spec Range Displays the specification range. Measured Value Measured value of the selected test. Pass/Fail

Remarks Additional information about the test.

Test passed or failed or inconclusive as

, ,

Note: Locate Hits, and Flash Hits are enabled only if a template test fails. The TDS5000B series oscilloscopes do not support Flash Hits.

Select Locate Hits to view and change the mask color and hit color

Select Flash Hits to flash the hits on the oscilloscope display

3-16

Select Show Seg to display the mask segments.

Select Close to close the dialog box.

Note: If you run all the tests together using Select All, the Locate Hits, Flash Hits, and Show Seg is disabled.

TDSET3 Printed Help Document

Locate Hits

dialog box

Operating Basics

Select Result Details button in Result pane to display the Result Details dialog box. In the Result Details dialog box, select Locate Hits to display the Mask Hit Locator dialog box as shown below.

Flash Hits

dialog box

Figure 3-21: Mask Segments dialog box

1. Selecting Locate Hits changes the mask color and hit color. Closing the

Locate Hits dialog box will set the Mask color to default.

2. In the Circle Color drop-down list, select the color in which you want to see

the mask hits circled.

3. Select Save to save the mask-hit image as a jpg or a bmp file. The default

directory is C:\TekApplications\TDSET3\Images.

4. Select Close to close the dialog box.

Select Result Details button in Result pane to display the Result Details dialog box. In the Result Details dialog box, select Flash Hits to flash the hits on the oscilloscope display. The Flash Hits message box appears as shown below.

TDSET3 Printed Help Document

Figure 3-22: Flash Hits message box

Select Stop in the Flash Hits message box to stop flashing the mask hits.

3-17

Operating Basics

Show Segments

dialog box

Select Result Details button in Result pane to display the Result Details dialog box. In the Result Details dialog box, select Show Seg to display the mask segments. The Show Segments dialog box appears as shown below.

Manual Fit dialog box

Figure 3-23: Show Segments dialog box

The Show Seg is enabled only if you run the template test.

Select Close to close the dialog box.

Select Result Details button in Result pane to display the Result Details dialog box. In the Result Details dialog box, select Manual Fit to display the manual fit dialog box.

Note: If you select the Select All button, the Manual Fit is not enabled.

If you are running 1000BASE-T Template test, the Manual Fit dialog box appears as shown by the next figure.

3-18

Figure 3-24: 1000BASE-T Manual Fit dialog box

TDSET3 Printed Help Document

Operating Basics

When you test Template in 1000BASE-T, you can manually fit the waveform into the mask.

If the processed waveform does not lie within the mask, use Manual Fit to manually fit the waveform into the mask as described below:

Click the arrow buttons to adjust the waveform to fit into the Mask.

Click OK to perform the mask pass/fail test again.

Click Cancel to exit the Manual Fit dialog box without performing the mask pass/fail test.

If you are running 100BASE-TX or 10BASE-T Template tests, the Manual Fit dialog box appears as shown by the next figure.

Jig match

dialog box

Figure 3-25: 100BASE-TX/10BASE-T Manual Fit dialog box

When you test Template in 100BASE-TX, and 10BASE-T, you can manually fit the waveform into the mask.

If the processed waveform does not lie within the mask, use Manual Fit to manually fit the waveform into the mask as described below:

To adjust the waveform to fit into the Mask, change the horizontal position and vertical position using the general purpose knobs or Virtual Keyboard.

Click OK to perform the mask pass/fail test again.

If you are running 1000BASE-T Template test, the Jig Match button appears in the Connect pane. Click Jig Match to display the Jig Match dialog box.

Note: Jig Match is enabled only if you select Disturbing Signal as Yes.

Use Jig Match to effectively remove the disturbing signal and compensate for non-linearities in the disturber and the test fixture. You can measure the

TDSET3 Printed Help Document

3-19

Operating Basics

disturbing signal's Amplitude, and Frequency. You can also set the default values. The application measures and displays the values in Measured Value fields. You can validate the disturbing signal by comparing the Measured Value with the Expected Value.

Figure 3-26: Jig Match dialog box

To compensate for the Disturbing Signal, do the following:

1. Use TC5 of the test fixture for Disturber Compensation.

3-20

TDSET3 Printed Help Document

2. Make the connections as shown by the following figure.

Operating Basics

Figure 3-27: Connections for Disturber Compensation

3. Do not connect the Ethernet cable to J700 and the test port of the DUT.

4. Connect a BNC Cable to AWG+ and Channel 1 of Arbitrary Waveform

Generator.

5. Connect a BNC Cable to AWG– and Channel 2 (

) of Arbitrary

Waveform Generator.

6. Short the jumpers J621, J630, J620, J623, J721, J723, J680, and J781.

7. Connect the Differential Probe to P19 and configured channel of the

oscilloscope.

8. In the Jig Match dialog box, select Measure button in the Disturber

Compensation pane.

9. Compare the Measured Value with the Expected Value.

10. If the Measured Value is not approximately equal to the Expected Value,

modify the amplitude and clock frequency settings of the Arbitrary

TDSET3 Printed Help Document

3-21

Operating Basics

Waveform Generator. Then click Measure and compare the values to be approximately equal. To compensate for the Test Fixture, do the following:

1. Use TC2 and TC5 of the test fixture for Test Fixture Compensation.

2. Make the connections as shown by the following figure.

3-22

Figure 3-28: Step 1 Connections of Test Fixture Compensation

3. For Template, Droop, and Peak Voltage tests, set the DUT to generate Test

Mode 1 signal. For Distortion test, set the DUT to generate Test Mode 4 signal.

4. Connect the Ethernet cable to J490 and the test port of the DUT.

5. Connect the Differential Probe to P9 and configured channel of the

oscilloscope.

6. In the Jig Match dialog box, select Measure button in Step 1 in the Test

Fixture Compensation pane.

7. Make the connections as shown by the following figure.

TDSET3 Printed Help Document

Operating Basics

Figure 3-29: Step 2 Connections of Test Fixture Compensation

8. For Template, Droop, and Peak Voltage tests, set the DUT to generate Test

Mode 1 signal. For Distortion test, set the DUT to generate Test Mode 4 signal.

9. Connect the Ethernet cable to J700 and test port of the DUT.

10. Connect a BNC Cable to AWG+ and Channel 1 of Arbitrary Waveform

Generator.

11. Connect a BNC Cable to AWG- and Channel 2 (

) of Arbitrary

Waveform Generator.

12. Switch OFF the Arbitrary Waveform Generator.

13. Short the jumpers J621, J630, J623, J721, J723, J680, and J781.

14. Connect the Differential Probe to P18 and configured channel of the

oscilloscope.

15. In the Jig Match dialog box, select Measure button in Step 2 in the Test

Fixture Compensation pane.

TDSET3 Printed Help Document

3-23

Operating Basics

Virtual Keyboard

dialog box

Selecting

Figure 3-30: Virtual Keyboard

The field on the top displays what you have selected. After you have selected the required number, select Enter.

adjacent to any number field displays the Virtual Keyboard.

 Selecting Space inserts a space.

 Selecting Enter enters the value for the selected field.

 Selecting Backspace deletes the value entered.

Virtual Keypad

dialog box

 Selecting Esc exits the Virtual Keyboard.

Select the knob or the keypad icon adjacent to any text field to display the Virtual Keypad dialog box.

Figure 3-31: Virtual Keypad

Use this dialog box to enter custom values.

3-24

TDSET3 Printed Help Document

Mask Setup

dialog box

Operating Basics

 Selecting Set to min to automatically display the minimum value of the

selected field.

 Selecting Set to max to automatically display the maximum value of the

selected field.

 Selecting CLR to clear the value for the field selected and returns to zero

value.

 Selecting Enter to enters the value for the selected field.

The Mask Setup button is available in the Configure pane and is enabled only when you run template tests.

If you are configuring 100BASE-TX Template test, click on Mask Setup button in the Configure pane to display the Mask Setup dialog box.

TDSET3 Printed Help Document

Figure 3-32: 100BASE-TX Mask Setup dialog box

In the Samples text box, enter the number of samples to use in the test. Entering the number of samples stops the test when that number has been reached. The accepted range of samples is between 5000 and 2,147,400,000. The default number of samples is 16,000.

In the Fail Thresh text box, enter the minimum number of samples that must fail for the test to fail. The accepted range of samples is between 1 and 2,147,483,647. The default fail threshold is 1.

Note: You can use the Virtual Keyboard or the General Purpose knobs to enter the values in the Samples and Fail Thresh fields.

If you are configuring 10BASE-T Template test, click on Mask Setup button in the Configure pane to display the Mask Setup dialog box.

3-25

Operating Basics

Figure 3-33: 10BASE-T Mask Setup dialog box

In the # of Wfms text box, enter the number of waveforms to use in the test. Entering the number of waveforms stops the test when that number has been reached. The accepted range of samples is between 1 and 2,147,483,647. The default number of samples is 16.

Smooth

dialog box

In the Fail Thresh text box, enter the minimum number of samples that must fail for the test to fail. The accepted range of samples is between 1 and 2,147,483,647. The default fail threshold is 1.

Select Result Details button in Result pane to display the Result Details dialog box. In the Result Details dialog box, select Smooth to smoothen the return loss waveform. This button is enabled only when you test Return Loss for all speeds.

Figure 3-34: Smooth dialog box

After you test Return Loss, you can change the smoothness of the waveform. The accepted range is within 0 to 10. The default is 7.

3-26

TDSET3 Printed Help Document

Operating Basics

Click the arrow buttons to increase or decrease the value and view the smoothness of the waveform. The waveform is automatically updated as you change the value.

Click Close to perform the pass/fail test again.

Exit

dialog box

Select File > Exit to display the following message box:

Figure 3-35: Exit dialog box

You can exit the application by restoring the oscilloscope settings to the previous state prior to starting the application or retaining the present oscilloscope settings.

 Select File> Exit.

 Select Yes to restore the oscilloscope settings to their original state prior to

starting the application and exit the application. or Select No to retain the present oscilloscope settings and exit the application. or Select Cancel to cancel the operation and return to the application.

TDSET3 Printed Help Document

Note: Clicking

displays the Exit dialog box.

3-27

Operating Basics

3-28

TDSET3 Printed Help Document

How To Select Test Parameters

Selecting 1000BASE-T Test Parameters

The following table lists how to select the 1000BASE-T test parameters.

Table 4-1: Select 1000BASE-T Test Parameters

Test Parameter Selection

1000BASE-T Click Tests > Select > 1000BASE-T or select 1000-T in the

Speed pane. Template In the Template/Volt tab, select a point in the Template group. Peak Voltage In the Template/Volt tab, select a point in the Peak Volt group. Droop In the Droop tab, select a point. Jitter Master Filtered In the Jit/Distortion tab, select Master Filtered. Jitter Master Unfiltered In the Jit/Distortion tab, select Master Unfiltered. Jitter Slave Filtered In the Jit/Distortion tab, select Slave Filtered. Jitter Slave Unfiltered In the Jit/Distortion tab, select Slave Unfiltered. Distortion In the Jit/Distortion tab, select Distortion. Return Loss In the Return Loss tab, select Return Loss. CM Voltage In the CM Voltage tab, select CM Voltage.

Note: The TDS5000B series oscilloscopes do not support Jitter Slave Filtered test.

Selecting 100BASE-TX Test Parameters

The following table lists how to select the 100BASE-TX test parameters.

Table 4-2: Select 100BASE-TX Test Parameters

Test Parameter Selection

100BASE-TX Click Tests > Select > 100BASE-TX or select 100-TX in the Speed

Template In the Parametric tab, select Template. In the Polarity drop-down list,

Differential Output Voltage

pane.

select Pos for positive, Neg for negative, or Both. For Positive polarity, the application tests segments 1, 2, 3, 6, and 7. For Negative polarity, the application tests segments 4, 5, 8, 9, and 10. For Both, the application tests all the segments.

In the Parametric tab, select Output Volt. In the Polarity drop-down list, select Pos for positive, Neg for negative, or Both.

TDSET3 Printed Help Document

4-1

How To Select Parameters

Signal Amplitude Symmetry

Rise Time In the Parametric tab, select Rise Time. In the Polarity drop-down list,

Fall Time In the Parametric tab, select Fall Time. In the Polarity drop-down list,

Rise/Fall Time Symmetry

Waveform Overshoot In the Parametric tab, select Overshoot. In the Polarity drop-down list,

Jitter In the Parametric tab, select Jitter. In the Polarity drop-down list, select

Duty Cycle Distortion In the Parametric tab, select Distortion.

Return Loss In the Return Loss tab, select either Transmitter or Receiver.

Selecting 10BASE-T Test Parameters

The following table lists how to select the 10BASE-T test parameters.

Table 4-3: Select 10BASE-T Test Parameters

Test Parameter Selection

10BASE-T Click Tests > Select > 10BASE-T or select 100-T in the Speed pane. Template MAU In the Template tab, select MAU and select Normal, Inverted or Both in

Template Link Pulse In the Template tab, select Link Pulse. In the adjacent drop-down list,

Template TP_IDL In the Template tab, select TP_IDL. In the adjacent drop-down list, select

Differential Voltage In the Parametric tab, select Diff Volt.

Harmonic In the Parametric tab, select Harmonic. Jitter with cable In the Parametric tab, select With Cable in the Jitter group.

Jitter without cable In the Parametric tab, select w/o Cable in Jitter group.

Return Loss In the Return Loss tab, select either Transmitter or Receiver. CM Voltage In the CM Voltage tab, select CM Voltage.

In the Parametric tab, select Amp Sym. In the Polarity drop-down list, select Pos for positive, Neg for negative, or Both.

select Pos for positive, Neg for negative, or Both.

select Pos for positive, Neg for negative, or Both. In the Parametric tab, select R/F Sym. In the Polarity drop-down list,

select Pos for positive, Neg for negative, or Both.

Pos for positive, Neg for negative, or Both.

Select Random or 010101 in the Pattern drop-down list.

the adjacent drop-down list. Select Configure in the Selection pane and select the MAU Type as

External or Internal.

select the load with or without TPM — Load1 w/o TPM, Load2 w/o TPM, 100 ohm w/o TPM, Load1 with TPM, Load2 with TPM, or 100 ohm with TPM.

the load with or without TPM — Load1 w/o TPM, Load2 w/o TPM, 100 ohm w/o TPM, Load1 with TPM, Load2 with TPM, or 100 ohm with TPM.

From the Peak drop-down list, select the peak value as Max or MinMax.

Select Normal, 8BT, 8.5BT, or All in the adjacent drop-down list.

4-2

TDSET3 Printed Help Document

How To Configure Parameters

Configuring 1000BASE-T

Use this dialog box to configure 1000BASE-T for Source, # Averages, Output, Disturbing Signal, and Filter.

Figure 5-1: 1000BASE-T Configure pane

The following table shows the 1000BASE-T tests parameters you can configure.

Table 5-1: 1000BASE-T Configure parameters

TDSET3 Printed Help Document

5-1

How To Configure Parameters

The following table describes the 1000BASE-T configuration parameters.

Table 5-2: 1000BASE-T Configure parameter description

Configure parameters Description

Source

# of Averages

The Data source and CLK source should be mutually exclusive. The Data source, Master CLK source and Slave clock source should be mutually exclusive.

Data — Select the channel to which the DUT signal is connected. Master CLK — Select the channel to which the master clock is connected. Slave CLK — Select the channel to which the slave clock is connected. TX_TCLK — Select the channel to which the TX_TCLK is connected. Data (TM2) — Select the channel to which data in Test Mode 2 is connected. Data (TM3) — Select the channel to which data in Test Mode 3 is connected. Note: TX_TCLK drop-down list appears only for Distortion test and if you have selected

TX_TCLK as Yes. Data (TM2) and Data (TM3) drop-down list appears only for Jitter tests if you have selected

the TX_TCLK as No. Master CLK and Slave CLK drop-down list appears only for Jitter tests if you have selected

the TX_TCLK as Yes. Enter the number of averages between 64 and 10000 depending on the noise present in

the acquired waveform.

Clock Edge

Disturbing Signal

Filter

TX_TCLK

Output

Select the clock edge on which the oscilloscope finds the trigger point.

Select Yes or No depending on whether the disturbing signal is added to the test mode signal.

Select Int or Ext depending on whether the filter is applied internally or externally.

Select Yes or No to perform the Distortion test with TX_TCLK.

Select the reference waveform on which the processed waveform will be stored.

5-2

TDSET3 Printed Help Document

Table 5-2: 1000BASE-T Configure parameter description

Configure parameters Description

Meas Type

Hi Resolution

Return Loss

Select the measurement type as either Time Interval Error (TIE) or Histogram.

Enter the number of averages to be done in the vertical domain.

Probe:P1 and Probe:P2 — Select the channels to which the probes are connected. Note: Depending on the Pair ID selected, the sources will change from P1/P3/P5/P7 and

P2/P4/P6/P8. Load — Select the load as 85, 100, 111 ohm or 100 ohm. Pair ID — Select the Pair ID as A, B, C, or D. Depending on the Pair ID selected the

sources will change from P1/P3/P5/P7 and P2/P4/P6/P8. Return Loss — Select the reference waveform on which the output waveform will be

stored. 0dB Marker — Select the reference waveform on which you want the OdB Marker to be

indicated. Note: Return Loss and 0dB Marker fields appear only if you set Load as 100 ohm. # Averages — Enter the number of waveforms you want to average. Smooth — Enter the smoothening factor.

How To Configure Parameters

Record Length

Low Pass Filter

Hysteresis

TDSET3 Printed Help Document

Varies depending on the Memory option available on the Oscilloscope.

Select Yes or No. The Low Pass Filter has a cutoff frequency of 150 MHz and when applied, eliminates high frequency noise.

Enter the hysteresis percent value.

5-3

How To Configure Parameters

The following table lists the configuration parameters and default settings.

Table 5-3: 1000BASE-T Configuration Default Settings

Parameter Options Default

Data CH1, CH2, CH3, CH4 CH1 Master CLK CH1, CH2, CH3, CH4 CH2 Slave CLK CH1, CH2, CH3, CH4 CH3 Data (TM2) CH1, CH2, CH3, CH4 CH1 Data (TM3) CH1, CH2, CH3, CH4 CH2 # Averages 64 to 10000 64 Clock Edge Rising, Falling Rising Disturbing Signal Yes, No No Filter Int, Ext Int TX_TCLK No, Yes No TX_TCLK CH1, CH2, CH3, CH4 CH2 Output Ref1, Ref2, Ref3, Ref4 Ref1 Meas Type Histogram, TIE TIE Hi Resolution 02 to 75 64 Probe:P1/P3/P5/P7 CH1, CH2, CH3, CH4 CH1 Probe:P2/P4/P6/P8 CH1, CH2, CH3, CH4 CH2 Pair ID A, B, C, D A Load 85, 100, 115 or 100 ohm 85, 100, 115 ohm

Note: The TDS5052B oscilloscope displays the graticule only for 100 ohm Load.

Smooth 0 - 10 7 Record Length Varies depending on the Memory option

available on the Oscilloscope. Low Pass Filter Yes, No Yes Hysteresis 5.00% to 30.00% 5.00%

5-4

TDSET3 Printed Help Document

Configuring 100BASE-TX

Use this dialog box to configure 100BASE-TX for Data source, Acquisition, Rise/Fall Time Test, and Mask Setup.

How To Configure Parameters

Figure 5-2: 100BASE-TX Configure pane

The following table shows parameters of 100BASE-TX that you can configure.

Table 5-4: 100BASE-TX Configure parameters

TDSET3 Printed Help Document

5-5

How To Configure Parameters

The following table describes the 100BASE-TX configuration parameters.

Table 5-5: 100BASE-TX Configure parameter description

Configure parameters Description

Source

Select the channel to which the Device Under Test (DUT) is connected.

Acquisition

Rise/Fall Time Test

Mask Scale

Mask Setup

Return Loss

Select Sample or Average depending on the acquisition mode. The Acquisition is only enabled for some tests.

If you select Average, enter the number of waveforms in # of Wfms field. If you select Sample, the application assumes the number of waveforms as 1. You can use the virtual keyboard or the general-purpose knobs to enter the values in

the samples and fail thresh text boxes.

Select Pulse Width as 16ns or 80ns. You can onl

Time tests.

Select Mask Scale as Normal, 0.95, or 1.05 depending on the Mask scale factor. You can configure Mask Scale only for Template test.

You can configure the Samples and Fail Thresh. You can only configure these parameters for the template tests.

Probe:P1 and Probe:P2 — Select the channels to which the probes are connected on the fixture.

Note: Depending on whether the Transmitter or Receiver is selected, the sources will change from P1/P3 and P2/P4.

Return Loss — Select the reference waveform on which the output waveform will be stored.

0dB Marker — Select the reference waveform on which you want the OdB Marker to be indicated.

Note: Return Loss and 0dB Marker fields appear only if you set Load as 100 ohm. AWG Series — Select the AWG Series to use. If you select the default value–Select–

then the application considers all AWGs other than the AWG 4xx series. Load — Select the load as 85, 100, 111 ohm or 100 ohm. # Averages — Enter the number of waveforms you want to average. Smooth — Enter the smoothening factor.

configure this parameter for Rise/Fall Time Symmetry, Rise Time, and Fall

5-6

TDSET3 Printed Help Document

How To Configure Parameters

The following table lists the configuration parameters and default settings.

Table 5-6: 100BASE-TX Configuration Default Settings

Parameter Options Default

Data CH1, CH2, CH3, CH4 CH1 Acquisition Sample, Average If you select Sample, the default value is 1.

If you select Average, the default # of Wfms

is 16. Mask Scale Normal, 0.95, 1.05 Normal Mask Setup See Mask Setup for information on default

Sample and Fail Thresh. Pulse Width 16 ns, 80 ns 80 ns Probe:P1/P3 CH1, CH2, CH3, CH4 CH1 Probe:P2/P4 CH1, CH2, CH3, CH4 CH2 AWG Series Select, AWG 4xx, AWG

2021, AWG 5xx, AWG 6xx, AWG 7xx

Load 85, 100, 115 ohm or 100

ohm

Select

85, 100, 115 ohm

Configuring 10BASE-T

Note: The two-channel oscilloscopes display the graticule only for 100 ohm

Load.

Smooth 0 - 10 7

Use this dialog box to configure 10BASE-T for Data source, Acquisition, Harmonic Ones, and Mask Setup.

Figure 5-3: 10BASE-T Configure pane

TDSET3 Printed Help Document

5-7

How To Configure Parameters

The following table shows parameters of 10BASE-T that you can configure.

Table 5-7: 10BASE-T Configure parameters

The following table describes the 10BASE-T configuration parameters.

Table 5-8: 10BASE-T Configure parameter description

Configure parameters Description

Source

Acquisition

Select the channel to which the Device Under Test (DUT) is connected.

Select Sample or Average depending on the acquisition mode. The Acquisition is only enabled for some tests.

If you select Average, enter the number of waveforms in # of Wfms field. If you select Sample, the application assumes the number of samples as 1. You can use the virtual keyboard or the general-purpose knobs to enter the values in

the samples and fail thresh text boxes.

5-8

TDSET3 Printed Help Document

Table 5-8: 10BASE-T Configure parameter description

Configure parameters Description

Mask Selection

Select MAU Type as Internal or External. Select MAU Scale as Normal, 0.9, or 1.1 depending on the MAU scale factor. Select Section as Both, Head or Tail depending on the section of mask to test. You can configure MAU Type and MAU Scale only for Template MAU tests. You can configure Section only for Template TP_IDL and Link Pulse tests.

How To Configure Parameters

Mask Setup

Harmonic all of ones

Sequence

Test Options

Return Loss

You can configure the Samples and Fail Thresh. You can only configure these parameters for the template tests.

Select the math waveform on which the processed waveform will be displayed. Enter the number of math waveforms to be averaged. Enter the time or scale depending on the packet length being transmitted.

You can set the sequence to Normal (NLP) or Fast (FLP). You can only configure this parameter for the Template Link Pulse test.

Select Both to perform Template and Timing tests, Template Only to perform Template tests, and Timin pulse.

Probe:P1 and Probe:P2 — Select the channels to which the probes are connected on the fixture.

Note: Depending on whether the Transmitter or Receiver is selected, the sources will change from P1/P3 and P2/P4.

Return Loss — Select the reference waveform on which the output waveform will be stored.

0dB Marker — Select the reference waveform on which you want the OdB Marker to be indicated.

Note: Return Loss and 0dB Marker fields appear only if you set Load as 100 ohm. AWG Series — Select the AWG Series to use. If you select the default value–Select–

then the application considers all AWGs other than the AWG 4xx series. Load — Select the load as 85, 100, 111 ohm or 100 ohm.

Only to perform Timing tests. Timing tests are available for normal link

TDSET3 Printed Help Document

5-9

How To Configure Parameters

Table 5-8: 10BASE-T Configure parameter description

Configure parameters Description

# Averages — Enter the number of waveforms you want to average. Smooth — Enter the smoothening factor.

The following table lists the configuration parameters and default settings.

Table 5-9: 10BASE-T Configuration Default Settings

Parameter Options Default

Data CH1, CH2, CH3, CH4 CH1 Acquisition Sample, Average If you select Sample, the default value is 1.

If you select Average, the default # of Wfms

is 16. Section Both, Head, Tail Both MAU Type Internal, External Internal MAU Scale Normal, 0.9, 1.1 Normal Mask Setup See Mask Setup for information on default

Sample and Fail Thresh. Sequence Normal (NLP), Fast (FLP) Normal (NLP) Test Options Both, Template Only,

Timing Only

Output Math1, Math2, Math3,

Math4

Time/Scale 10 micro seconds, 1micro

seconds # Averages 48 for other tests and 100 for Return Loss Probe:P1/P3 CH1, CH2, CH3, CH4 CH1 Probe:P2/P4 CH1, CH2, CH3, CH4 CH2 AWG Series Select, AWG 4xx, AWG

2021, AWG 5xx, AWG 6xx,

AWG 7xx

Load 85, 100, 111 ohm or 100

ohm

Both

Math1

10 micro seconds

Select

85, 100, 111 ohm

5-10

Note: The TDS5052B oscilloscope displays the graticule only for 100 ohm Load.

Smooth 0 - 10 7

TDSET3 Printed Help Document

Making Connections

1000BASE-T Connections

Template, Peak Volt,

Droop, and Distortion

With Disturbing Signal

Use TC5 of the test fixture for these tests with disturbing signal and TC2 of the test fixture for these tests without disturbing signal.

Make the connections as shown by the following figure.

TDSET3 Printed Help Document

Figure 6-1: 1000BASE-T Connections with disturbing signal for Template, Peak Volt, Droop, and Distortion

For Template, Peak Volt, and Droop tests, set the DUT to generate Test Mode 1 signal. For Distortion test, set the DUT to generate Test Mode 4 signal.

1. Connect the Ethernet cable to J700 and test port of the DUT.

6-1

Making Connections

2. Connect a BNC Cable to AWG+ and Channel 1 of Arbitrary Waveform

Generator.

3. Connect a BNC Cable to AWG− and Channel 2 (

Waveform Generator.

Note: The AWG waveforms are available in C:\TekApplications\TDSET3\AWGWaveforms. You can use relevant waveform files to generate the disturbing signal. Some of the AWG models do not support the .set file for automatic settings. Referto the ReadMe.txt file for instructions to make those settings manually. In particular, ensure that the AWG clock frequency is set to 250 MHz. This file is available in the corresponding AWG waveform file folder. You can automate the AWG to transfer files and settings as described in Automate AWG.

4. To test Pair A, do the following:

) of Arbitrary

 Short the jumpers J621, J630, J623, J721, J723, J680, and J781.

 Ensure that the other jumpers are open.

 Connect the Differential Probe to P18 and configured channel of the

oscilloscope.

5. To test Pair B, do the following:

 Short the jumpers J620, J622, J631, J721, J723, J680, and J781.

 Ensure that the other jumpers are open.

 Connect the Differential Probe to P18 and configured channel of the

oscilloscope.

6. To test Pair C, do the following:

 Short the jumpers J620, J623, J720, J730, J723, J680, and J781.

 Ensure that the other jumpers are open.

 Connect the Differential Probe to P18 and configured channel of the

oscilloscope.

7. To test Pair D, do the following:

 Short the jumpers J620, J623, J721, J722, J731, J680, and J781.

 Ensure that the other jumpers are open.

6-2

TDSET3 Printed Help Document

Without Disturbing Signal

Make the connections as shown by the following figure.

Making Connections

 Connect the Differential Probe to P18 and configured channel of the

oscilloscope.

TDSET3 Printed Help Document

Figure 6-2: 1000BASE-T Connections without disturbing signal for Template, Peak Volt, Droop, and Distortion

1. For Template, Peak Volt, and Droop tests, set the DUT to generate Test

Mode 1 signal. For Distortion test, set the DUT to generate Test Mode 4 signal.

2. Connect the Ethernet cable to J490 and test port of the DUT.

3. To test Pair A, connect the Differential Probe to P9 and configured channel

of the oscilloscope.

6-3

Making Connections

4. To test Pair B, connect the Differential Probe to P10 and configured channel

of the oscilloscope.

5. To test Pair C, connect the Differential Probe to P11 and configured channel

of the oscilloscope.

6. To test Pair D, connect the Differential Probe to P12 and configured channel

of the oscilloscope.

Note: Align the positive (+) probe-tip of the differential probe with the notch marked on the test fixture.

6-4

TDSET3 Printed Help Document

Jitter Master Filtered

Making Connections

If you have access to TX_TCLK

Step 1

Use TC3 of the test fixture to calculate master clock jitter. Make the connections as shown by the following figure.

TDSET3 Printed Help Document

Figure 6-3: 1000BASE-T Step 1 Connections for Jitter Master Filtered

1. Set the DUT in Normal mode as master.

2. Connect the Ethernet cable to J501 and test port of the DUT.

3. Connect the Test Channel spool to J580 and Link partner.

4. Connect the active probe from TX_TCLK of the DUT to the configured

channel of the oscilloscope.

6-5

Making Connections

Step 2

Use TC2 of the test fixture to calculate data jitter with respect to master clock. Make the connections as shown by the following figure.

6-6

Figure 6-4: 1000BASE-T Step 2 Connections for Jitter Master Filtered

1. Set the DUT to generate Test Mode 2 signal.

2. Connect the Ethernet cable to J490 and test port of the DUT.

3. Connect the active probe from TX_TCLK of the DUT to the configured

channel of the oscilloscope.

4. To test Pair A, connect the Differential Probe to P9 and configured channel

of the oscilloscope.

TDSET3 Printed Help Document

Making Connections

5. To test Pair B, connect the Differential Probe to P10 and configured channel

of the oscilloscope.

6. To test Pair C, connect the Differential Probe to P11 and configured channel

of the oscilloscope.

7. To test Pair D, connect the Differential Probe to P12 and configured channel

of the oscilloscope.

If you do not have access to TX_TCLK

TDSET3 Printed Help Document

Figure 6-5: 1000BASE-T Connections for Jitter Master Filtered

• Set the DUT to generate Test Mode 2 signal.

• Connect the Ethernet cable to J490 and test port of the DUT.

6-7

Making Connections

• To test Pair A, connect the Differential Probe to P9 and configured channel

of the oscilloscope.

• To test Pair B, connect the Differential Probe to P10 and configured channel

of the oscilloscope.

• To test Pair C, connect the Differential Probe to P11 and configured channel

of the oscilloscope.

• To test Pair D, connect the Differential Probe to P12 and configured channel

of the oscilloscope.

Jitter Master Unfiltered

If you have access to TX_TCLK

Use TC3 of the test fixture to calculate master clock jitter. Make the connections as shown by the following figure.

6-8

Figure 6-6: 1000BASE-T Connections for Jitter Master Unfiltered

1. Set the DUT to generate Test Mode 2 signal.

TDSET3 Printed Help Document

Making Connections

2. Connect the Ethernet cable to J501 and test port of the DUT.

3. Connect the Test Channel spool to J580 and Link partner.

4. Connect the active probe from TX_TCLK of the DUT to the configured

channel of the oscilloscope.

If you do not have access to TX_TCLK

TDSET3 Printed Help Document

Figure 6-7: 1000BASE-T Connections for Jitter Master Unfiltered

• Set the DUT to generate Test Mode 2 signal.

• Connect the Ethernet cable to J490 and test port of the DUT.

6-9

Making Connections

• To test Pair A, connect the Differential Probe to P9 and configured channel of the oscilloscope.

• To test Pair B, connect the Differential Probe to P10 and configured channel of the oscilloscope.

• To test Pair C, connect the Differential Probe to P11 and configured channel of the oscilloscope.

• To test Pair D, connect the Differential Probe to P12 and configured channel of the oscilloscope.

6-10

TDSET3 Printed Help Document

Jitter Slave Filtered

Making Connections

If you have access to TX_TCLK

Step 1

Use TC3 of the test fixture to calculate master and slave clock jitter. Make the connections as shown by the following figure.

TDSET3 Printed Help Document

Figure 6-8: 1000BASE-T Step 1 Connections for Jitter Slave Filtered

1. Set the DUT in Normal mode as Slave.

2. Connect the Ethernet cable to J501 and test port of the DUT.

3. Connect the Test Channel spool to J580 and Link partner.

4. Connect the active probe from TX_TCLK of the DUT to the configured

channel of the oscilloscope.

6-11

Making Connections

5. Connect the active probe from TX_TCLK of the Link Partner to the configured channel of the oscilloscope.

Step 2

Use TC2 of the test fixture to calculate data jitter with respect to slave clock. Make the connections as shown by the following figure.

6-12

Figure 6-9: 1000BASE-T Step 2 Connections for Jitter Slave Filtered

1. Set the DUT to generate Test Mode 3 signal.

2. Connect the Ethernet cable to J490 and test port of the DUT.

3. Connect the active probe from TX_TCLK of the DUT to the configured

channel of the oscilloscope.

TDSET3 Printed Help Document

Making Connections

4. To test Pair A, connect the Differential Probe to P9 and configured channel

of the oscilloscope.

5. To test Pair B, connect the Differential Probe to P10 and configured channel

of the oscilloscope.

6. To test Pair C, connect the Differential Probe to P11 and configured channel

of the oscilloscope.

7. To test Pair D, connect the Differential Probe to P12 and configured channel

of the oscilloscope.

If you do not have access to TX_TCLK

TDSET3 Printed Help Document

Figure 6-10: 1000BASE-T Connections for Jitter Slave Filtered

• Set the DUT in Normal mode as Master.

6-13

Making Connections

• Connect the Ethernet cable to J501 and test port of the DUT.

• Connect the Test Channel spool to J580 and Link partner.

• Set the Link partner to generate Test Mode 3 signal.

• Connect the active probe from Data (TM3) of the Link partner to the

configured channel of the oscilloscope.

• To test Pair A, connect the Differential Probe to P13 and configured channel of the oscilloscope.

• To test Pair B, connect the Differential Probe to P14 and configured channel of the oscilloscope.

• To test Pair C, connect the Differential Probe to P15 and configured channel of the oscilloscope.

• To test Pair D, connect the Differential Probe to P16 and configured channel of the oscilloscope.

6-14

TDSET3 Printed Help Document

Jitter Slave Unfiltered

Making Connections

If you have access to TX_TCLK

Use TC3 of the test fixture to calculate slave clock jitter. Make the connections as shown by the following figure.

TDSET3 Printed Help Document

Figure 6-11: 1000BASE-T Connections for Jitter Slave Unfiltered

1. Set the DUT in Normal mode as Slave.

2. Connect the Ethernet cable to J501 and test port of the DUT.

3. Connect the Test Channel spool to J580 and Link partner.

4. Connect the active probe from TX_TCLK of the DUT to the configured

channel of the oscilloscope.

6-15

Making Connections

5. Connect the active probe from TX_TCLK of the Link Partner to the configured channel of the oscilloscope.

If you do not have access to TX_TCLK

6-16

Figure 6-12: 1000BASE-T Connections for Jitter Slave Unfiltered

• Set the DUT in Normal mode as Master.

• Connect the Ethernet cable to J501 and test port of the DUT.

• Connect the Test Channel spool to J580 and Link partner.

• Set the Link partner to generate Test Mode 3 signal.

• Connect the active probe from Data (TM3) of the Link partner to the

configured channel of the oscilloscope.

TDSET3 Printed Help Document

Return Loss

Making Connections

• To test Pair A, connect the Differential Probe to P13 and configured channel of the oscilloscope.

• To test Pair B, connect the Differential Probe to P14 and configured channel of the oscilloscope.

• To test Pair C, connect the Differential Probe to P15 and configured channel of the oscilloscope.

• To test Pair D, connect the Differential Probe to P16 and configured channel of the oscilloscope.

Use TC1 of the test fixture for calibration.

Make the connections as shown by the following figure.

TDSET3 Printed Help Document

Figure 6-13: 1000BASE-T Connections for Return Loss

1. Set the DUT to generate Test Mode 4 signal.

2. Connect the Ethernet cable to J200 and test port of the DUT.

6-17

Making Connections

3. Connect a BNC Cable to AWG+ and Channel 1 of Arbitrary Waveform

Generator.

4. Connect a BNC Cable to AWG- and Channel 2 (

) of Arbitrary

Waveform Generator.

Note: The AWG waveforms are available in C:\TekApplications\TDSET3\AWGWaveforms. Some of the AWG models do not support the .set file for automatic settings. Refer to the ReadMe.txt file for instructions to make those settings manually. In particular, ensure that the AWG clock frequency is set to 250 MHz. This file is available in the corresponding AWG waveform file folder. You can automate the AWG to transfer files and settings as described in Automate AWG.

5. To test Pair A, connect the Differential Probes to P1(J240) and P2(J230), and

configured channels of the oscilloscope.

6. To test Pair B, connect the Differential Probe to P3(J241) and P4(J231), and

configured channels of the oscilloscope.

7. To test Pair C, connect the Differential Probe to P5(J242) and P6(J232), and

configured channels of the oscilloscope.

8. To test Pair D, connect the Differential Probe to P7(J243) and P8(J233), and

configured channels of the oscilloscope.

6-18

TDSET3 Printed Help Document

Return Loss

Calibration

Making Connections

Use TC1 of the test fixture for calibration. Make the connections as shown by the following figure.

Figure 6-14: 1000BASE-T Connections for Return Loss Calibration

1. Connect the Ethernet cable to J200 and test port of the DUT.

2. Connect a BNC Cable to AWG+ and Channel 1 of Arbitrary Waveform

Generator.

3. Connect a BNC Cable to AWG- and Channel 2 (

) of Arbitrary

Waveform Generator.

Note: The AWG waveforms are available in C:\TekApplications\TDSET3\AWGWaveforms.

4. To test Pair A, connect the Differential Probes to P1(J240) and P2(J230), and configured channels of the oscilloscope.

5. To test Pair B, connect the Differential Probe to P3(J241) and P4(J231), and configured channels of the oscilloscope.

TDSET3 Printed Help Document

6-19

Making Connections

6. To test Pair C, connect the Differential Probe to P5(J242) and P6(J232), and

configured channels of the oscilloscope.

7. To test Pair D, connect the Differential Probe to P7(J243) and P8(J233), and

configured channels of the oscilloscope.

8. Connect CAT5 cable to J200 of TC1 and J702 for OPEN calibration.

9. Connect CAT5 cable to J200 of TC1 and J703 for SHORT calibration.

10. Connect CAT5 cable to J200 of TC1 and J704 for LOAD calibration.

CM Voltage

Use TC4 of the test fixture for this test. Make the connections as shown by the following figure.

6-20

Figure 6-15: 1000BASE-T Connections for CM Voltage

1. Set the DUT to generate Test Mode 4 signal.

TDSET3 Printed Help Document

Tektronix TDS7054, TDS7254, TDS7404, TDS7104, TDS6604 Primary User

Specifications and Main Features

Frequently Asked Questions

User Manual

About TDSET3

Getting Started

Operating Basics

How To Select Test Parameters

How To Configure Parameters

Making Connections
