Tektronix TDS7104 Data Sheet

Digital Phosphor Oscilloscopes

TDS7000B Series

Up to 7.25 GHz True
Analog Bandwidth and
Down to 43 ps Rise Time
(20% to 80%)

>400,000 wfms/s Waveform
Capture Rate, Powered by
Exclusive DPX®Acquisition
Technology

20 GS/s Maximum Real-time
Sample Rate

Exceptional Delta-time
Accuracy for High-confidence
in Critical Timing Measurements

Powerful Triggering Features
for Fast Detection of
Relevant Faults

Communications Mask
Testing Up to 4.25 Gb/s Rates

Clock Recovery from Serial
Data Streams up to 3.125 Gb/s

Up to 64 MB Record Length
with MultiView Zoom
Quick Navigation of Long

Superior Measurement Fidelity, Unrivaled Analysis,
Uncompromised Usability

The TDS7000B Series’ unique combination

of superior measurement fidelity, unrivaled

analysis, and uncompromised usability

makes it the ultimate test machine to sim-

plify and speed the design of high-speed,

complex systems.

s best solution to the challeng

y’

industr

This family offers the

ing

signal integrity issues faced by designers

verifying, characterizing and debugging

sophisticated electronic designs.

They deliver up to 7.25 GHz (typical) true

analog bandwidth, down to 43 ps rise time

(20% to 80%) and 20 GS/s maximum real-

time sample rate to capture critical events

with fine detail. Exclusive DPX

technology enables waveform capture rates

up to 400,000 wfms/s to quickly find rare

glitches in seconds or minutes, instead of

hours or days. Innovative software solutions

deliver domain expertise f

ysis and compliance testing,

anal

®

OpenChoice

architecture enables users to

integrate their expertise through the ability

to easily write custom programs or utilize

popular commercial software. The intuitive

graphical user interface delivers sophisti-

bility to advanced users without

pa

ted ca

ca

intimidating occasional users.

®

acquisition

or advanced

while the

Records

TekConnect®Interface for
High Fidelity Connection

Classic Direct Controls,
Touch-sensitive Display, or
Mouse Navigation

OpenChoice®with Windows
2000 Delivers Built-in
Networking and Analysis

XGA 1024x768 display

Signal Integrity, Jitter and
T

Verification, Debug and
Characterization of
Sophisticated Designs

Design Development and
Compliance T
Data Streams Up to

4.25 Gb/s Rates

Debug of Telecom, Datacom
and Storage Area Network
Equipment Designs and
High-speed Backplanes

Spectral Analysis

Investigation of Transient
Phenomena

Features & Benefits

TM

for

Applications

iming Analysis

esting of Serial

1

Oscilloscopes

•

.tektronix.com/tds7000B

www

Digital Phosphor Oscilloscopes

TDS7000B Series

Characteristics

Vertical System

TDS7054 TDS7104 TDS7154B TDS7254B TDS7404B TDS7704B

Input Channels 4 4 4 4 4 4

Hardware

Analog Bandwidth (–3 dB) 500 MHz 1 GHz 1.5 GHz

*1

Rise Time 10% to 90% (typical) 800 ps 400 ps 200 ps 130 ps 100 ps 62 ps

Time 20% to 80% (typical) 135 ps 83 ps 72 ps 43 ps

Rise

DC Gain Accuracy 1% ±(2% + ±(2.5% +

(2% x offset)) (2% x offset))

Hardware Bandwidth Limits

250 MHz or 20 MHz Requires TCA-1 MEG

Input Coupling AC, DC, GND DC, GND

Input Impedance 1 MΩ ±0.5% or 50 Ω ±1% 50 Ω ±2.5%

Input Sensitivity, 1 MΩ 1 mV/div to 10 V/div —

Input Sensitivity, 50 Ω 1 mV/div to 1 V/div 2 mV/div to 1 V/div

Vertical Resolution 8-Bit (>11-Bit with averaging) 8-Bit (>11-Bit with averaging)

Max Input Voltage, 1 MΩ ±150 V CAT I Derate at —

20 dB/decade to

9V

above 200 kHz

RMS

Max Input Voltage, 50 Ω 5V

with peaks less than <1 V

RMS

±30 Volts <5 V

Also determined by TekConnect®accessory

Offset Range 1 mV/div to 100 mV/div: ±1 V 2 mV to 50 mV/div: ±0.5 V

101 mV/div to 1 V/div: ±10 V 50.5 mV to 99.5 mV: ±0.25 V

1.01 V/div to 10 V/div: ±100 V 100 mV to 500 mV: ±5 V

Channel-to-Channel Isola

tion ≥100:1 at 100 MHz and ≥80:1 at 1.5 GHz and

Any Two Channels at Equal ≥30:1 at the rated bandwidth ≥15:1 at rated bandwidth

ertical Scale Settings

V

*1

At ≥10 mV/div.

Note: Typical system bandwidth of TDS7404B with P7240: 4 GHz.

Note: Typical system bandwidth of TDS7404B with P7330: 3.5 GHz.

Note: Typical system bandwidth of TDS7704B with P7260: 6 GHz

ypical system bandwidth of

Note: T

ypical system bandwidth of

Note: T

TDS7704B with P7350: 5 GHz.

TDS7704B with P7380: 7 GHz

*1

GHz

2.5

for <100 mV/div,

RMS

for ≥100 mV/div settings

RMS

GHz

4

505 mV to 1 V/div: ±2.5 V

*1

GHz

7.25

(typical), 7 GHz

guaranteed

*1

*1

2

Oscilloscopes

•

www.tektronix.com/tds7000B

Digital Phosphor Oscilloscopes

Time Base System

TDS7054/TDS7104 TDS7154B/TDS7254B/TDS7404B/TDS7704B

Time Base Range 200 ps/div to 40 s/div 50 ps to 10 s/div

Time Base Delay Time Range 16 ns to 250 s 5 ns to 250 s

Channel-to-channel Deskew Range ±25 ns ±75 ns

Delta Time Measurement Accuracy ±((0.06/sample rate) + ±((0.06/sample rate) +

(15 ppm x reading)) RMS (2.5 ppm x reading)) RMS

Trigger Jitter (RMS) 8 ps

Long Term Sample Rate and Delay ±15 ppm over ≥1 ms interval 2.5 ppm over any ≥100 ms interval
Time Accuracy

Acquisition System

TDS7054 TDS7104 TDS7154B/ TDS7254B/ TDS7404B/ TDS7704B

(typical) 2 ps

RMS

(typical) (7254B/7154B)

RMS

1.5 ps

1.2 ps

(typical) (7404B)

RMS

(typical) (7704B)

RMS

TDS7000B Series

Real-time Sample Rates

1 channel (max) 5 GS/s 10 GS/s 20 GS/s

2 channels (max) 5 GS/s 5 GS/s 10 GS/s

3-4 channels (max) 2.5 GS/s 2.5 GS/s 5 GS/s

Equivalent Time Sample Rate (max) 250 GS/s 250 GS/s 1 TS/s

Maximum Record Length per Channel 2 Mb (1-CH.), 1 Mb (2-CH.), 4 Mb (1-CH.), 2 Mb (2-CH.), 1 Mb (4-CH.)
with Standard Memory 500 Kb (4-CH.)

With Memor

y Opt. 2M 8 Mb (1-CH.), 4 Mb (2-CH.), 2 Mb (4-CH.)

With Memory Opt. 3M 16 Mb (1-CH.), 8 Mb (2-CH.), 4 Mb (4-CH.)

With Memory Opt. 4M 32 Mb (1-CH.), 16 Mb (2-CH.), 8 Mb (4-CH.)

With Memory Opt. 5M 64 Mb (1-CH.), 32 Mb (2-CH.), 16 Mb (4-CH.)

Oscilloscopes

•

www.tektronix.com/tds7000B

3

Digital Phosphor Oscilloscopes

TDS7000B Series

Maximum Duration at Highest Real-time Resolution (1-CH)

TDS7054 TDS7104 TDS7154B/TDS7254B/TDS7404B/TDS7704B

Time Resolution (Single-shot) 200 ps (5 GS/s) 100 ps (10 GS/s) 50 ps (20 GS/s)

Max Duration with Standard Memory 400 µs 200 µs 200 µs

Max Duration with Opt. 2M 1.6 ms 800 µs 400 µs

Max Duration with Opt. 3M 3.2 ms 1.6 ms 800 µs

Max Dura

Max Dura

FastAcq Acquisition Powered by exclusive DPX®acquisition technology, FastAcq optimizes the instrument

Maximum FastAcq Waveform >200,000 wfms/sec >400,000 wfms/sec
Capture Rate

Waveform Database Accumulate Waveform Database providing three-dimensional array of amplitude, time and counts

Sample Acquire sampled values

Peak Detect Captures narrow glitches at all real-time sampling rates

Minimum Peak Detect Pulse Width ≤1 ns 400 ps

Averaging From 2 to 10,000 waveforms included in average

Envelope From 2 to 2x109waveforms included in min-max envelope

Hi-res Real-time boxcar averaging reduces random noise and increases resolution

FastFrame

tion with Opt. 4M 1.6 ms

tion with Opt. 5M 3.2 ms

Acquisition Modes

TDS7054/TDS7104 TDS7154B/TDS7254B/TDS7404B/TDS7704B

for analysis of dynamic signals and capture of infrequent events

™

Acquisition Acquisition memory divided into segments; maximum trigger rate >265,000 waveforms per second.

Time of arrival recorded with each event

4

Oscilloscopes

•

www.tektronix.com/tds7000B

Digital Phosphor Oscilloscopes

TDS7000B Series

Trigger System

TDS7054 TDS7104 TDS7154B/TDS7254B/TDS7404B/TDS7704B

Sensitivity

Internal DC Coupled 0.35 div DC 0.35 div DC 0.5 div DC to 50 MHz increasing to 1.5 div at 3 GHz

External (Auxiliary Input) 400 mV from DC 250 mV from DC 150 mV from DC to 50 MHz increasing

Main Trigger Modes Auto, Normal and Single

Trigger Sequences Main, Delayed by Time, Delayed by Events. All sequences can include separate horizontal delay

Trigger Characteristics

Standard Trigger Types Edge, Glitch, Runt, Width, Transition Edge, Glitch, Runt, Width, Transition Time, Timeout, Pattern,

Communications-related Triggers Support for AMI, HDB3, BnZS, CMI, MLT3 and NRZ encoded communications signals.
(requires Option SM) Select among isolated positive or negative one, zero pulse form or eye patterns as applicable to standard

Serial Pattern Trigger 64-Bit serial word recognizer, bits specified in binary
(requires Option ST) (high, low, don’t care) or hex format.

to 50 MHz to 50 MHz TDS7404B/TDS7704B: 2.7 div at 4 GHz (typical)

increasing to increasing to

1

div at 1 div at

500 MHz 1 GHz

to 50 MHz to 50 MHz to 500 mV at 2.5 GHz

increasing to increasing to

750 mV at 500 mV at

100

MHz 100 MHz

after the trigger event to position the acquisition windo

w in time

Time, Timeout, Pattern, State, State, Setup/Hold, Window – all except Edge,

Setup/Hold Pattern and State can be logic qualified

Trigger on NRZ-encoded data up to 1.25 GBaud

Trigger Level Range

Internal ± 12 divisions from center of screen

External (Auxiliary In) ±8 V ±5 V

Line fixed at 0 V

Trigger Coupling DC, AC (attenuates <60 Hz), HF Rej (attenuates >30 kHz), LF Rej (attenuates <80 kHz),

Noise Reject (reduces sensitivity)

Trigger Holdoff Range 250 ns minimum to 12 s maximum

Oscilloscopes

•

www.tektronix.com/tds7000B

5

Digital Phosphor Oscilloscopes

TDS7000B Series

Clock Recovery System (Option SM, ST)

TDS7154B/TDS7254B/TDS7404B/TDS7704B

Clock Recovery Phase Locked Loop Bandwidth Fbaud/1600 typical

Tracking/Acquisition Range ±2% of requested baud

Clock Recovery Jitter (typical) 0.25% period +5 ps

Input Sensitivity for Clock Recovery 1 division peak-to-peak displayed signal

Input Data Rates 1.5 Mbaud to 3.125 Gbaud

for PRBS data pattern or 4 ps

RMS

for repeating “011” data patterns

RMS

Trigger Modes

Edge–Positive and/or nega

tive slope on any
channel or front panel auxiliary input. Coupling
includes DC, AC, noise reject, HF reject and
LF reject.

Glitch – Trigger on or reject glitches of positive,
negative or either polarity. Minimum glitch width is

1.0 ns with 200 ps resolution (TDS7104/TDS7054).
Minimum glitch width is 170 ps (TDS7704B) or
225 ps (all other B models) with rearm time of

ps (B models).

250

Width – Trigger on width of positive or negative
pulse (down to 170 ps on B models) either within
or out of selecta

ble time limits – 1 ns (TDS7104/

TDS7054) or 340 ps (B models) to 1 s.

Runt – Trigger on a pulse that crosses one threshold
but fails to cross a second threshold before crossing
the first again. Optional time qualification.

imeout –Trigger on an event which remains high,

T

low or either, for a specified time period, selectable
from 1 ns (TDS7104/TDS7054) or 340 ps (B models)

s with 200 ps (TDS7104/TDS7054) or 100 ps

to 1
(B models).

Transition – Trigger on pulse edge rates that are
faster or slower than specified. Slope may be
positive, negative or either.

Setup/Hold – Trigger on violations of both setup
time and hold time between clock and da

ta present

on any two input channels.

Pattern – Trigger when pattern goes false or stays
true for specified period of time. Pattern (AND, OR,

NOR) specified for four input channels

NAND,
defined as HIGH, LOW or Don’t Care.

State – Any logical pattern of channels (1, 2, 3)
clocked by edge on channel 4. Trigger on rising or
falling clock edge.

Window–T

rigger on an event that enters or exits
a window defined by two user-adjustable thresholds.
Event can be time or logic qualified (B models only).

ic Qualified Trigger applicable to Glitch, Width,

Log
Runt, Timeout, Transition, Setup/Hold,Window
triggers – Trigger on the specified event only if the
logic state defined with the remaining unused chan­nels occurs (B models onl

y).

Trigger Delay by Time – 16 ns (5 ns for B models)
to 250 seconds.

Trigger Delay by Events – 1 to 10,000,000 Events.

6

Oscilloscopes

•

www.tektronix.com/tds7000B

Digital Phosphor Oscilloscopes

TDS7000B Series

Waveform Measurements

Amplitude–Amplitude,

High, Low, Maximum,
Minimum, Peak-to-Peak, Mean, Cycle Mean, RMS,
Cycle RMS, Positive Overshoot, Negative Overshoot.

Time – Rise Time, Fall Time, Positive Width,
Negative Width, Positive Duty Cycle, Negative Duty
Cycle, Period, Frequency, Delay.

Combination – Area, Cycle Area, Phase, Burst Width.

Histogram-related – Waveform Count, Hits in Box,

Peak Hits, Median, Maximum, Minimum, Peak-to­Peak, Mean (µ), Standard Deviation (

σ),µ+ 1σ,

µ+ 2σ,µ+ 3σ.

Ey

e Pattern-related (B models only) –

Extinction
Ratio (absolute, %, and dB), Eye Height, Eye Top,
Eye Base, Eye Width, Crossing %, Jitter (Peak-to­Peak, RMS and 6

S/N ratio, Cycle Distortion, Q-factor.

RMS),

σ), Noise (Peak-to-Peak and

Waveform Processing/Math

Algebr

aic Expressions –

Define extensive algebraic
expressions including waveforms, scalars and
results of parametric measurements e.g. (Integral
(CH.1-Mean(CH.1)) x 1.414).

Arithmetic – Add, subtract, multiply, divide
waveforms and scalars.

Relational – Boolean result of comparison >, <,
>=, <=, ==, !=.

Calculus – Integrate, differentiate.

equency Domain Functions –

Fr

Spectral ma

gnitude

and phase, real and imaginary spectra.

Vertical Units – Magnitude: Linear, dB, dBm;
Phase: Degrees, radians.

Window Functions – Rectangular, Hamming,
Hanning, Kaiser-Bessel, Blackman-Harris,
Gaussian, Flattop2, Tek Exponential.

W

aveform Definition –

As arbitrar

y math expression.

Display Characteristics

Display

Type –

Liquid cr

ystal active-matrix

color display.

Display Size – Diagonal: 264 mm (10.4 in.).

Display Resolution –

TDS7104/TDS7054: 640 horizontal x 480
vertical pixels.
TDS7154B/TDS7254B/TDS7404B/TDS7704B:
1024 horizontal x 768 vertical pixels.

Waveform Styles – Vectors, Dots, Variable
Persistence, Infinite Persistence.

Oscilloscopes

•

www.tektronix.com/tds7000B

7

Digital Phosphor Oscilloscopes

TDS7000B Series

Computer System and
Peripherals

CPU –

TDS7104/TDS7054:

Intel Celeron processor,
850 MHz.
TDS7154B/TDS7254B/TDS7404B/TDS7704B:
Intel Pentium 4 processor

, 2.8 GHz*.

PC System Memory – 1 GB*.

d Disk Drive

Har

– 40

GB remova

ble hard disk
drive: rear-panel or (B models only) front-panel,
(option FHD).

Floppy Disk Drive – 1.44 MB 3.5 in floppy disk
drive: front-panel, or (B models only) rear-panel
(option FHD).

CD-R/W Drive – Rear-panel CD-R/W drive with CD
creation software application.

Mouse – Thumb wheel model included, USB
interface.

Keyboard – Mini keyboard included (fits in pouch);
PS-2 interface.

Order 119-6633-00 for full-size

keyboard; USB interface and hub.

Available September 2004

*

Input/Output Ports

Probe Compensator Output– Front panel BNC

connector, requires Probe Cal-Deskew Fixture
(included) for probe attachment. Amplitude 200 mV
(TDS7104/TDS7054) or 500mV (B models) ±20%
into a 50 Ω load, frequency 1 kHz ±5%.

Analog Signal Output Amplitude – Front-panel
BNC connector, provides a buffered version of the
signal that is attached to the Ch 3 input when Ch 3
is selected as trigger source. 20 mV/div ±20% into
a 1.8

MΩ load, 10 mV/div ±20% into a 50 Ω load.

Analog Signal Output Bandwidth, Typical –

TDS7054, TDS7104: 100 MHz into a 50 Ω load.
TDS7154B/TDS7254B/TDS7404B/TDS7704B:
1 GHz into a 50 Ω load.

External Time Base Reference In – Rear-panel
BNC connector,time base system can phase-lock
to external 10 MHz reference.

Time Base Reference Out – Rear-panel BNC con­nector, accepts TTL-compatible output of internal
10 MHz reference oscillator.

Auxiliary Output Levels – Front-panel BNC

, provides a TTL-compatible, polarity

connector
switchable pulse when the oscilloscope triggers.

Parallel Port – IEEE 1284, DB-25 connector.

Audio Ports– Minia

ture phone jacks for stereo

microphone input and stereo line output.

USB Port – Allows connection or disconnection of
USB ke

yboard and/or mouse while oscilloscope

power is on. B models have 2 USB ports.

Keyboard Port – PS-2 compatible.

Mouse Port – PS-2 compatible.

LAN Port – RJ-45 connector, supports 10Base-T

and 100Base-T

.

Serial Port – DB-9 COM1 port.

Windows Video Port – 15 pin D-Sub connector

on the rear panel; connect a second monitor to
use dual-monitor display mode. Video is DDC2B
compliant.

GPIB Port – IEEE 488.2 standard.

Oscilloscope

on the rear panel,

Video Port –

15 pin D-Sub connector

video is IBM XGA compatible on
B models. Connect to show the oscilloscope
display, including live waveforms on an external
monitor or projector.The primary Windows desktop
can also be displayed on an external monitor using
this port.

Power Source

Power – 100 to 240 V

V

115

10%, 400 Hz; CAT II, <300 W (450 VA).

±

RMS

±10%, 50/60 Hz;

RMS

8

Oscilloscopes

•

www.tektronix.com/tds7000B

Digital Phosphor Oscilloscopes

TDS7000B Series

Physical Characteristics

BENCHTOP CONFIGURATION
Dimensions mm in.

Height 277 10.9
Width 455 17.9
Depth 425 16.75

Weight kg lbs.

Net 19.1 42.0
Shipping 37 85

RACKMOUNT CONFIGURATION
Dimensions mm in.

Height 277 10.5
Width 502 19.75
Depth 486 19.125

Weight kg lbs.

Net 18.6 41
Kit 5.6 12.25

MECHANICAL
Cooling – Required mm in.

ance

Clear

Top 0 or >76 0 or >3
Bottom 0 0
Left side 76 3
Right side 76 3
Front 0 0
Rear 0 0

Environmental

T

emperature –

Operating: 0 ºC (TDS7104/TDS7054) or +5 ºC
(B models) to +50 ºC, excluding floppy disk and
CD-R/W drives; +10 ºC to +45 ºC, including floppy
disk and CD-ROM drives.
Nonoperating: -22 ºC to +60 ºC.

Humidity –

Operating: 20% to 90% relative humidity with a
maximum wet bulb temperature of +29 ºC at or
below +50

ºC, noncondensing. Upper limit derated
to 25% relative humidity at +50 ºC.
Nonoperating: With no diskette in floppy disk drive.
20% to 90% rela

tive humidity with a maximum wet
bulb temperature of +29 ºC at or below +60 ºC,
noncondensing. Upper limit derated to 20% relative
humidity at +60 ºC.

Altitude

–

Operating: 10,000 ft. (3,048 m).
Nonoperating: 40,000 ft. (12,190 m).

Random

Vibration –

Operating: 0.000125 G2/Hz from 5 to 350 Hz,
–3 dB/octave from 350 to 500 Hz,

0.0000876 G

0.24 G
Nonoperating: 0.0175 G
–3 dB/octave from 100 to 200 Hz, 0.00875 G
from 200 to 350 Hz, –3 dB/octave from 350 to
500
of 2.28 G

2

/Hz at 500 Hz. Overall level of

.

RMS

Hz, 0.006132 G

RMS

2

.

2

/Hz from 5 to 100 Hz,

/Hz a

t 500 Hz. Overall level

2

/Hz

Electromagnetic Compatibility – 89/336/EEC.

Safety – UL 3111-1, CSA 1010.1, EN61010-1.2,

IEC 61010-1.

Oscilloscopes

•

www.tektronix.com/tds7000B

9

Digital Phosphor Oscilloscopes

TDS7000B Series

Options (available on models indicated by “x”)

TDS7054

Acquisition Memory Options

TDS7104 TDS7154B TDS7254B TDS7404B TDS7704B

2M 8 Msamples max, x x x x x x

2 Msamples/ch

3M 16 Msamples max, x x x x x x

4 Msamples/ch

4M

32 Msamples max, x x x x

8

Msamples/ch

5M 64 Msamples max, x x x x

16 Msamples/ch

Software Options

DVI TDSDVI DVI compliance x x x

test solution

DVD TDSDVD Optical x x x x x x

storage analysis

ET3 TDSET3 Ethernet compliance x x x x x x

test software

JT3 TDSJIT3 Advanced jitter x x x x x x

analysis software

J3E TDSJIT3 Essentials x x x x x x

J2 TDSDDM2 Disk drive x x x x x x

analysis software

*1

CP2

TDSCPM2 ANSI/ITU x x x x x x

Telecom pulse compliance

testing software

*2

USB

TDSUSBS USB2.0 x x x x x x

Compliance test S/W only

SM Serial communications x x x x x x

mask testing

ST Serial pattern trigger x x x x

PW3 TDSPWR3 Power measurement x x x x x x

and analysis software

RTE Serial Data Compliance x x x x

Analysis Software

and

*3

PCE

PCI Express™Compliance xx

Module for option RTE

*3

IBA

InfiniBand®Compliance xx

Module for option RTE

*1

Requires Option SM.

*2

Requires Option

*3

Requires Option R

TDSUSBF (USB

TE.

est Fixture).

T

To view instrument upgrades for the TDS7000 and TDS7000B Series, please go to www.tektronix.com/tds7000b_upgrades.

10

Oscilloscopes

•

www.tektronix.com/tds7000B

Digital Phosphor Oscilloscopes

TDS7000B Series

Ordering Information

TDS7054

500 MHz Digital Phosphor Oscilloscope.

TDS7104

1 GHz Digital Phosphor Oscilloscope.

TDS7104 and TDS7054 include: (4) P6139A
500 MHz, 10x Passive Probes, accessory pouch,
front cover, mouse, probe calibration and deskew
fixture (067-0405-xx), quick reference kit
(020-2404-xx), user manual (071-1035-xx),
TDS7000 Series product software CD-ROM,
TDS7000 Series operating system restoration
CD-ROM, TDS7000 Series optional applications
software CD-ROM, performance verification procedure
PDF file, GPIB programmer’s reference (on product
software CD-ROM), calibration certificate docu­menting NIST traceability, 2 540-1 compliance and
ISO9000, power cord, one year warranty.

TDS7154B

1.5 GHz Digital Phosphor Oscilloscope.

TDS7254B

2.5 GHz Digital Phosphor Oscilloscope.

TDS7404B

4 GHz Digital Phosphor Oscilloscope.

TDS7704B

7 GHz Digital Phosphor Oscilloscope.

TDS7154B, TDS7254B, TDS7404B, and
TDS7704B Include:

mouse, user manual (071-1226-xx), quick
reference kit (020-2519-xx), TDS7000B Series
product software CD-ROM 063-3632-00
(TDS7154/7254/7404B) 063-3633-00
(TDS7704B), TDS7000B Series operating system
restoration CD-ROM, TDS7000B Series optional
applications software CD-ROM, performance
verification procedure PDF file, GPIB programmer’s
reference (on product software CD-ROM),
calibration certificate documenting NIST traceability,
2 540-1 compliance and ISO9000, power cord,
one year warranty.

For TDS7154B and TDS7254B Only, Also Includes:

(4) TekConnect®to BNC adapters (TCA-BNC),
(2) TekConnect high-impedance buffer amplifiers
(TCA-1MEG), and deskew fixture (067-0405-xx).

For TDS7404B and TDS7704B Only, Also Includes:

(4) TekConnect to SMA adapters (TCA-SMA).

For TDS7404B Only, Also Includes:

Deskew fixture (067-0405-xx).

TDS7704B Only, Also Includes:

Deskew fixture (067-0484-xx).

Please specify disk drive and power cord option
when ordering.

Accessory pouch, front cover,

Instrument Options

Power Plug Options

Opt. A0 – North America power.

Opt. A1 – Universal EURO power.

Opt. A2 – United Kingdom power.

Opt. A3 – Australia power.

Opt. A5 – Switzerland power.

A6 –Japan power.

Opt.

A99 –

Opt.

Opt.

Mounting Options

No power cord or

China power

A10 –

AC adapter.

.

1K – K4000 Oscilloscope Cart.

1R – Rackmount Kit.

Disk Drive Options
(for TDS7154B,
TDS7254B, TDS7404B,
and TDS7704B only)

Opt. FHD– Front-panel 40

GB removable hard
disk drive, replaces floppy disk drive that goes
on the rear panel.

Service Options

Opt. C3 – Calibra

tion Service 3 Years.

Opt. C5 – Calibration Service 5 Years.

Opt. D1 – Calibration Data Report.

Opt. D3 – Calibration Data Report 3 Years

(with Option C3).

Opt. D5 – Calibration Data Report 5 Years
(with Option C5).

Opt. R3 – Repair Service 3 Years.

Opt. R5 – Repair Service 5 Years.

Recommended
Accessories

Probes

P7380 – >8 GHz Z-ActiveTMDifferential Probe

P7380SMA – >8 GHz Differential Signal Acquisition

System

P7350 – 5 GHz Differential Probe recommended
for TDS7404B/TDS7704B.

P7350SMA – 5 GHz SMA input Differential Probe

P7260 – 6 GHz Active Probe recommended

for TDS7404B/TDS7704B.

P6158 – 3 GHz, 20x Low C Probe.

P6247 – 1.0 GHz Differential Probe.

P6139A – 500 MHz, 10x Passive Probe.

P6245 – 1.5 GHz Active Probe.

P6248 – 1.7 GHz Differential Probe.

P7240 – 4 GHz Active Probe.

P7330 – 3.5 GHz Differential Probe.

Adapters

TCA-1MEG – TekConnect®High-impedance
Buffer Amplifier.

TCA-SMA – TekConnect-to-SMA Adapter.

TCA-N – TekConnect-to-N Adapter.

TCA-BNC – TekConnect-to-BNC Adapter.

TCA75 – 4 GHz Precision TekConnect 75 Ω to

50 Ω Adapter with 75 Ω BNC Input Connector.

AFTDS – Telecom Differential Electrical Interface
Adapter (for line rates <8 MB/s; requires
TCA-BNC adapter for TDS7404B).

Cables

GPIB Cable (1 m) – Order 012-0991-01.

GPIB Cable (2 m) – Order 012-0991-00.

RS-232 Cable – Order 012-1298-00.

Centronics Cable – Order 012-1214-00.

T

est Fixtures

TDSUSBF – TDSUSB test fixture for use
with Opt. USB.

Software

WSTRO – WaveStarTMwaveform capture
and documentation software.

Miscellaneous

Keyboard (USB interface) – Order 119-6633-00.
Service Manual – TDS7054/TDS7104:

Order 071-0711-xx.
TDS7154B/TDS7254B/TDS7404B/TDS7704B:

Order 071-0898-xx.

Transit Case – Order 016-1522-00.

Oscilloscopes

•

www.tektronix.com/tds7000B

11

Digital Phosphor Oscilloscopes

TDS7000B Series

Contact T

ektronix:

ASEAN / Australasia / Pakistan (65) 6356 3900

Austria [phone]

Belgium [phone]

Brazil & South America 55 (11) 3741-8360

Canada 1 [phone]

Central Europe & Greece [phone]

Denmark [phone]

Finland [phone]

France & North Africa [phone]

Germany [phone]

Hong Kong (852) 2585-6688

India (91) 80-22275577

Italy [phone]

Japan 81 (3) 6714-3010

Mexico, Central America & Caribbean 52 (55) 56666-333

The Netherlands [phone]

Norway [phone]

People’s Republic of China 86 (10) 6235 1230

Poland [phone]

Republic of Korea 82 (2) 528-5299

CIS & The Baltics

Russia,

[phone]

South Africa [phone]

Spain [phone]

Sweden [phone]/4

aiwan

T

886 (2) 2722-9622

United Kingdom & Eire [phone]

USA 1 [phone]

USA (Export Sales) 1 [phone]

For other areas contact

Tektronix, Inc. at: 1 [phone]
