Tektronix TDS6604B Data Sheet

Digital Storage Oscilloscope

TDS6000B Series

Uncompromised Performance
Oscilloscope Solution — Probing,
Acquisition, Analysis, Compliance
and Debug

TDS6000B Series digital storage

oscilloscopes provide unprecedented

performance along with a complete

feature set designed to address design

validation, debug and compliance

challenges of next generation computer,

datacom and communications equipment.

High bandwidth, high sample rate and

deep memory also provide the ideal

solution for data acquisition applications.

Uncompromised Acquisition

Never again will you need to trade-off

bandwidth, record length and sample

rate. The TDS6000B Series DSO

provides a new acquisition architecture

that has maximum sample rate (20 GS/s)

and record length (32 Megasamples) on

each of the four channels simultaneously.

The TDS6804B provides matched 8 GHz

performance across all four channels

using advanced DSP enhancement,

important for high speed channel-to-

channel measurements. The DSP filter

on each channel provides magnitude

and phase compensation of the analog

bandwidth to provide more accurate

signal fidelity for high-speed measurements.

Ideal for analyzing and debugging

multi-lane serial device designs and

interconnect. Four lanes of serial data

traffic can be analyzed simultaneously.

The DSP filter on each channel can also

be disabled to take advantage of the

true 7 GHz analog bandwidth.

Features & Benefits

8 GHz (TDS6804B) and
6 GHz (TDS6604B) Models

35 ps (20 to 80%) Typical Rise
Time, with Channel Matched,
User Selectable DSP

20 GS/s Real-time Sample Rate
(500 fs Interpolated Resolution)
on Each Channel

Up to 32 Megasamples Record
Length on Each Channel with
MultiView Zoom™for quick
navigation

Pinpoint™Triggering Provides
Highest Performance and Over
1400 Triggering Combinations

Serial Data Compliance and
Analysis up to 5 Gb/s

Dual Processor System (2.8 GHz
Pentium 4 and 583 MHz PowerPC)
Provide Fast Waveform Processing

OpenChoice®Software with
Windows XP OS Delivers Built-in
Networking and Analysis

Technology-specific Software
Solutions Provide Built-in
Domain Expertise for Serial
Data, Jitter, Ethernet, DVI,
USB2.0, Communications and
Power Measurements

System Includes:
High-resolution XGA Display,
Front Panel CD-R/W, Front Panel
USB2.0 Port and 1000Base-T
Network Connection

*1

TDS6804B Only. Analog BW is 7 GHz guaranteed,
with 43 ps (20 to 80%) typical rise time. Rise time
specified with 10 ps (20 to 80%) source.

*1

Applications

Signal Integrity, Jitter and
Timing Analysis

Validation, Debug, Characterization
and Compliance of Next
Generation Digital Designs

Computer, Datacom, Storage
Area Network Equipment Designs
and High-speed Backplanes

High Energy Physical
Measurements and Data
Acquisition

Digital Storage Oscilloscopes

TDS6000B Series

Pinpoint™Triggering

The ability to trigger an oscilloscope on

events of interest is paramount in high

speed debug and validation. Whether you

are trying to isolate a system error or

need to isolate a section of interest of a

complex signal for further analysis,

Tektronix’ new Pinpoint trigger system

provides the solution. The Pinpoint trigger

system uses Silicon Germanium (SiGe)

technology to provide trigger sensitivity of

7 GHz (at 2.5 divisions) for all trigger types

on both A and B trigger circuits. Capture

glitches down to 100 ps wide, trigger jitter

less than to 1.5 ps

advanced trigger types were offered on a

single event (A Event). If a delayed trigger

(B Event) were used, it would be limited to

edge triggering and not provide any way

to reset the trigger after the B-event

occurred (or didn’t occur). With Pinpoint

triggering, the system provides the full

suite of advance trigger types on both A

and B triggers. Reset triggering provides

the ability to reset the trigger circuit after a

specified time, state or transition so that

even events in the most complex signals

can be captured. Other oscilloscopes

offer less than 20 trigger combinations;

Pinpoint triggering offers over 1400

combinations, all at full bandwidth.

. In the past,

RMS

Trigger on glitches down to 100 ps wide.

Pinpoint Trigger System provides the most
advanced, highest performance triggering
available.

Unparalleled Analysis

Waveform data analysis can take many

forms. Whether it’s a simple math expres-

sion, waveform mask testing, a pass/fail

compliance test or a custom application

that you develop. The TDS6000B Series

offers the industry’s most comprehensive

set of analysis and compliance tools.

Measurement System. Enables over
50 parametric measurements in the
amplitude, time and statistical domain.

HW Golden PLL Clock Recovery and Mask
Testing up to 3.125 Gb/s (with Opt.SM).
Supports widest range of industry standards.

Waveform Math Equation Editor. Enables
boundless analysis on waveform data.

Embedded Analysis Tools

Embedded in the oscilloscope user

interface is a wide range of analysis

tools including Cursors, Measurements,

Math Equation Editor, Serial Data

Communications Mask Testing (with

Opt. SM) and Spectrum Analysis.

Product Type • www.tektronix.com/xxx

2

Digital Storage Oscilloscopes

TDS6000B Series

TDSRT-Eye™. Compliance and analysis for
testing high-speed serial standards.
Eye diagrams to 5 Gb/s. Software clock
recovery to 10 Gb/s.

TDSJIT3. Jitter analysis for validation and
debug high-speed digital systems.

Technology-specific
Software Solutions

Validation, debug and compliance testing

often require automated test tools that

quickly analyze waveform data and

provide the answers you need. The

TDS6000B Series provides complete

“turn-key” solutions for the most

TDSET3 10/100/1000BaseT Compliance.

TDSDVI Digital Visual Interface Compliance.

demanding technologies. The unique

dual-processor system off-loads data

intensive operations to the 2.8 GHz

Pentium 4 processor to provide jitter

*2

measurement efficiency

of greater than

100,000 TIE measurements per second

using TDSJIT3 Jitter and Timing Analysis

Software. Software options are also

available for performing validation and

compliance measurements on emerging

industry standards.

*2

Jitter measurement efficiency is a performance benchmark
that combines acquisition and analysis performance.
It is defined by the number of TIE (Time Interval Error)
measurements per second made by an oscilloscope’s jitter
measurement software. The signal under test is a 4 Gb/s
serial data bit stream with repeating CJTPAT (Compliance
Jitter Test Pattern) from an AWG710 arbitrary waveform
generator. The acquisition system is set to 20 GS/s and
8 Mb record length.

OpenChoice®Analysis

Designing your own custom solution?

The analysis and networking features of

OpenChoice software adds more flexibility

to Tektronix open Windows XP oscilloscopes:

Fast, PCI bus speed communication between

the data acquisition processor and the
Microsoft Windows desktop

ActiveX controls to connect the oscilloscope

to popular Windows applications – WITHOUT
leaving the application

PnP drivers to control the scope from

LabVIEW and Lab Windows/CVI running
directly on the oscilloscope or running
on external PCs

Support for application development

environments includes Visual BASIC,

.NET, C, C++, MATLAB, LabVIEW and

LabWindows/CVI.

Oscilloscopes • www.tektronix.com/oscilloscopes

3

Digital Storage Oscilloscopes

TDS6000B Series

8 GHz Differential Probing

Most high-speed signals today are differ-

ential. The P7380SMA 8 GHz Differential

Probing System provides true differential

SMA connection (for SMA connected test

fixtures) to the device under test. The

optional P7380SMA Differential Probing

System provides a 50 Ω per side termination

network with a termination voltage. The

termination voltage can be applied externally

®

or through the TekConnect

from the TDS6000B probe menu or not

used at all. A gain switch provides two

different sensitivity settings of the probe

and an Aux Out provides an inverted

version of the signal for driving other

equipment. The P7380SMA probing

system used with the TDS6000B

oscilloscopes provide an ideal solution

for validation and compliance testing

of high speed serial data links.

interface

P7380SMA Differential Probing System.

The P7380SMA uses second generation

SiGe (Silicon Germanium) technology and

is the first of a new family of differential

probing solutions.

Termination Voltage Menu.

4

Oscilloscopes • www.tektronix.com/oscilloscopes

Digital Storage Oscilloscopes

Characteristics

Vertical System

TDS6604B TDS6804B

Input Channels 4 4

Bandwidth, Rise Time (DSP) N/A 8 GHz

50 ps (10 to 90%) (typical)
35 ps (20 to 80%) (typical)

True Analog Bandwidth (–3 dB), Rise Time 6 GHz 7 GHz

70 ps (10 to 90%) (typical) 62 ps (10 to 90%) (typical)
53 ps (20 to 80%) (typical) 43 ps (20 to 80%) (typical)

Hardware Bandwidth Limits Full, 250 MHz or 20 MHz
(Requires TCA-1 MEG Adapter)

Input Coupling DC, GND

Input Impedance 50 Ω ±2.5%

Input Sensitivity, 50 Ω 10 mV/div to 1 V/div

Vertical Resolution 8-Bit (>11-Bit with averaging)

Max Input Voltage, 50 Ω <1 V

<7 V

Also determined by TekConnect®accessory

DC Gain Accuracy ±(2.5% + (2% x offset))

Position Range ±5 divisions

Offset Range

*1

10 mV to 50 mV/div: ±0.5 V

50.5 mV to 99.5 mV: ±0.25 V

Offset Accuracy ±(0.5% of channel offset + 15 mV + 0.1 div x V/div setting)

Channel-to-channel Isolation for Any ≥80:1 at 1.5 GHz and ≥15:1 at rated bandwidth
Two Channels at Equal Vertical Scale

*1

Offset range in addition to ±5 division position range.

for <100 mV/div,

RMS

for ≥100 mV/div settings

RMS

100 mV to 500 mV: ±5 V

505 mV to 1 V/div: ±2.5 V

for ranges >100 mV/div

TDS6000B Series

Oscilloscopes • www.tektronix.com/oscilloscopes

5

Digital Storage Oscilloscopes

TDS6000B Series

Timebase System

All Models

Timebase Range 25 ps to 40 s/div; Interpolation down to 500 fs/pt

Timebase Delay Time Range 5 ns to 250 s

Channel-to-channel Deskew Range ±75 ns

Trigger Jitter (RMS) <1.5 ps

Long-term Sample Rate and Delay Time Accuracy 2.5 ppm over any ≥100 ms interval

Clock Stability <1 ppm (typical)

<2.5 ppm (warranted)

Acquisition System

Max Sample Rate 20 GS/s on all 4 Channels

Equivalent Time Sample Rate (max) 2 TS/s

Maximum Record Length per Channel

Standard 2 Mb on all 4 Channels

with Memory Opt. 2M 8 Mb on all 4 Channels

with Memory Opt. 3M 16 Mb on all 4 Channels

with Memory Opt. 4M 32 Mb on all 4 Channels

(typical)

RMS

All Models

Maximum Time Duration Captured at Highest Real-time Resolution (All Channels)

All Models

Max Duration with Standard Memory 100 µs

Max Duration with Opt. 2M 400 µs

Max Duration with Opt. 3M 800 µs

Max Duration with Opt. 4M 1.6 ms

6

Oscilloscopes • www.tektronix.com/oscilloscopes

Digital Storage Oscilloscopes

TDS6000B Series

Acquisition Modes

All Models

Waveform Database Accumulate Waveform Database providing three-dimensional array of amplitude, time and counts

Sample Acquire sampled values

Peak Detect Captures narrow glitches at all real-time sampling rates

Minimum Peak Detect Pulse Width 50 ps

Averaging From 2 to 10,000 waveforms included in average

Envelope From 2 to 2x109waveforms included in min-max envelope

Hi-Res Real-time boxcar averaging reduces random noise and increases resolution

FastFrame™Acquisition Acquisition memory divided into segments; maximum trigger rate >310,000 waveforms per second

Time of arrival recorded with each event

Roll Mode 200 kSamples/sec at 8 Mg Record Length and 500 kSamples/sec at

4 Mg Record Length on all channels

Pinpoint™Trigger System

All Models

Sensitivity

Internal DC Coupled 0.5 div DC to 50 MHz increasing to 2.5 div at 7 GHz (typical)

External (auxiliary input) 200 mV from DC to 50 MHz increasing to 500 mV at 2 GHz

Trigger Characteristics

Main Trigger Modes Auto, Normal and Single

A Event and Delayed B Event Trigger Types Edge, Glitch, Runt, Width, Transition Time, Timeout, Pattern, State, Setup/Hold, Window –

all except Edge, Pattern and State can be Logic State qualified by up to two channels

Trigger Sequences Main, Delayed by Time, Delayed by Events, Reset by Time, Reset by State,

Reset by Transition. All sequences can include separate horizontal delay

after the trigger event to position the acquisition window in time

Communications-related Triggers Support for AMI, HDB3, BnZS, CMI, MLT3 and NRZ encoded communications signals
(requires Opt. SM) up to 3.125 Gb/s. Select among isolated positive or negative one, zero pulse form

or eye patterns as applicable to standard

Serial Pattern Trigger (requires Opt. ST) 64-Bit serial word recognizer, bits specified in binary (high, low, don’t care) or hex format

Trigger on NRZ-encoded data up to 1.25 G Baud

Trigger Level Range

Internal ±12 divisions from center of screen

External (auxiliary in) ±5 V

Line Fixed at 0 V

Trigger Coupling DC, AC (attenuate <60 Hz), HF reject (attenuate >30 kHz)

LF reject (attenuates <80 kHz) Noise reject (reduce sensitivity)

Trigger Holdoff Range 250 ns minimum to 12 s maximum

Oscilloscopes • www.tektronix.com/oscilloscopes

7

Digital Storage Oscilloscopes

TDS6000B Series

Trigger Types

Edge – Positive and/or negative slope on any
channel or front panel auxiliary input. Coupling
includes DC, AC, noise reject, HF reject and
LF reject.

Glitch – Trigger on or reject glitches of positive,
negative or either polarity. Minimum glitch width is
down to 100 ps with rearm time of 250 ps.

Width – Trigger on width of positive or negative
pulse (down to 100 ps) either within or out of
selectable time limits.

Runt – Trigger on a pulse that crosses one
threshold but fails to cross a second threshold
before crossing the first again. Optional time
qualification.

Timeout – Trigger on an event which remains high,
low or either for a specified time period, selectable
from 360 ps to 1 s.

Transition – Trigger on pulse edge rates that are
faster or slower than specified. Slope may be
positive, negative or either.

Setup/Hold – Trigger on violations of both setup
time and hold time between clock and data present
on any two input channels.

Pattern – Trigger when pattern goes false or stays
true for specified period of time. Pattern (AND, OR,
NAND, NOR) specified for four input channels
defined as HIGH, LOW or Don’t Care.

State – Any logical pattern of channels (1, 2, 3)
clocked by edge on channel 4. Trigger on rising or
falling clock edge.

Window – Trigger on an event that enters or exits
a window defined by two user-adjustable thresholds.
Event can be time or logic qualified.

Trigger Delay by Time – 5 ns to 250 seconds.

Trigger Delay by Events – 1 to 10,000,000 Events.

Waveform Measurements

Amplitude – Amplitude, High, Low, Maximum,
Minimum, Peak to Peak, Mean, Cycle Mean, RMS,
Cycle RMS, Positive Overshoot, Negative Overshoot.

Time – Rise Time, Fall Time, Positive Width,
Negative Width, Positive Duty Cycle, Negative Duty
Cycle, Period, Frequency, Delay.

Combination – Area, Cycle Area, Phase, Burst Width.

Histogram-related – Waveform count, Hits in box,

Peak hits, Median, Maximum, Minimum, Peak-to­peak, Mean (µ), Standard Deviation (σ),µ+ 1σ,
µ+ 2σ,µ+ 3σ.

Eye Pattern-related – Extinction Ratio (absolute,
% and dB), Eye Height, Eye Top, Eye Base, Eye
Width, Crossing %, Jitter (peak-peak, RMS and
6sigma), Noise (Peak-to-peak and RMS), S/N ratio,
Cycle Distortion, Q-factor.

Waveform Processing/Math

Algebraic Expressions – Define extensive algebraic
expressions including waveforms, scalars and
results of parametric measurements e.g.,
(Integral (CH.1-Mean(CH.1))x1.414).

Arithmetic – Add, subtract, multiply, divide
waveforms and scalars.

Relational –

Boolean result of comparison >, <, ≥, ≤,=,≠.

Calculus – Integrate, differentiate.

Frequency Domain Functions – Spectral

magnitude and phase, real and imaginary spectra.

Vertical Units – Magnitude: Linear, dB, dBm;
Phase: Degrees, radians.

Window Functions – Rectangular, Hamming,
Hanning, Kaiser-Bessel, Blackman-Harris,
Gaussian, Flattop2, Tek Exponential.

Waveform Definition –

As arbitrary math expressions.

Display Characteristics

Display Type –

Liquid crystal active-matrix color display.

Display Size – Diagonal: 264 mm (10.4 in.).

Display Resolution –

1024 horizontal x 768 vertical pixels.

Waveform Styles – Vectors, Dots, Variable
Persistence, Infinite Persistence.

Computer System and
Peripherals

CPU – Intel Pentium 4 processor, 2.8 GHz.

PC System RAM – 1 GB (266 MHz DDR).

Hard Disk Drive – 40 GB removable hard disk

drive: rear-panel standard or front-panel
(option FHD).

USB Ports – One front panel, four on rear panel,
USB2.0 compliant.

CD-R/W Drive – Front-panel CD-R/W standard or
rear-panel (option FHD).

Mouse – Thumb wheel model included,
USB interface.

Keyboard – Small keyboard included (fits in
pouch). Order 119-6297-xx for full-size keyboard;
USB interface and hub.

Input/Output Ports

Front Panel

Probe Compensator Output – Front panel SMA
connector, requires Probe Cal-Deskew Fixture
(included) for probe attachment. Amplitude 350 mV
±20% into a ≥50 Ω load, frequency 1 kHz ±5%,
200 ps typical rise time.

Recovered Clock – SMA connector, ≤1.25 Gb/s,
Output swing ≥130 mV

into 50 Ω. Requires

p-p

Opt. SM or Opt. ST to enable.

Recovered Data – SMA connector, ≤1.25 Gb/s,
Output swing of 1010 repeating pattern 200 mV
into 50 Ω. Requires Opt. SM or Opt. ST to enable.

Probe Calibration Output –

BNC connector, ±10 V DC for DC probe calibration.

AUX Trigger Output – BNC connector, provides a
TTL-compatible, polarity switchable pulse when the
oscilloscope triggers.

USB2.0 Port – One in front. Allows connection or
disconnection of USB keyboard, mouse or storage
device while oscilloscope is on.

Oscilloscopes • www.tektronix.com/oscilloscopes8Oscilloscopes • www.tektronix.com/oscilloscopes

Digital Storage Oscilloscopes

TDS6000B Series

Rear Panel

External Time Base Reference In –

BNC connector, time base system can
phase-lock to external 10 MHz reference.

Time Base Reference Out – BNC connector,
accepts TTL-compatible output of internal
10 MHz reference oscillator.

Aux Trigger Input –

BNC, see Ext Trigger specification.

Parallel Port – IEEE 1284, DB-25 connector.

Audio Ports – Miniature phone jacks for stereo

microphone input and stereo line output.

USB2.0 Ports – Four in back. Allows connection or
disconnection of USB keyboard, mouse or storage
device while oscilloscope power is on.

Keyboard Port – PS-2 compatible.

Mouse Port – PS-2 compatible.

LAN Port – RJ-45 connector, supports 10Base-T,

100Base-T, and 1000Base-T.

Serial Port – DB-9 COM1 port.

Windows Video Port – 15 pin D-Sub connector on

the rear panel; connect a second monitor to use
dual-monitor display mode allowing analysis results
and plots to be viewed along with the oscilloscope
display. Video is DDC2B compliant.

GPIB Port – IEEE 488.2 standard.

Scope XGA Video Port – 15 pin D-Sub connector

on the rear panel, video is IBM XGA compatible.
Connect to show the oscilloscope display, including
live waveforms on an external monitor or projector.
The primary Windows desktop can also be
displayed on an external monitor using this port.

Power Source

Power – 100 to 240 V

±10%, 400 Hz; CAT II,

115 V

RMS

, ±10%, 50/60 Hz;

RMS

<500 W typical (650 VA).

Option SM

156 Standards Masks Supported –

ITU-T (1.544 Mb/s to 155 Mb/s)

ANSI T1.102 (1.544 Mb/s to 155 Mb/s)

Ethernet IEEE Std 802.3, ANSI X3.263

(1.544 Mb/s to 3.125 Gb/s XAUI)

Sonet/SDH (51.84 Mb/s to 2.4883 Gb/s)

*2

Fibre Channel (133 Mb/s to 4.25 Gb/s

)

InfiniBand (2.5 Gb/s)

USB (12 Mb/s to 480 Mb/s)

Serial ATA (1.5 Gb/s, 3.0 Gb/s)

Serial Attached SCSI (1.5 Gb/s, 3.0 Gb/s)

IEEE 1394b (491.5 Mb/s to 1.966 Gb/s)

Rapid I/O (1.25 Gb/s to 3.125 Gb/s)

OIF Standards (2.488 Gb/s to 3.11 Gb/s)

PCI Express (2.5 Gb/s)

*2

4.25Gb/s mask supported using Glitch Trigger.

Physical Characteristics

BENCHTOP CONFIGURATION
Dimensions mm in.

Height 282 11.1
Width 457 18.0
Depth 540 23.25

Weight kg lb.

Net 21 47
Shipping 32.3 71.2

RACKMOUNT CONFIGURATION
Dimensions mm in.

Height 267 10.5
Width 491 19.3
Depth 638 25.1

Weight kg lb.

Net 22 49
Kit 5.6 12.25

Environmental

Temperature

Operating – +5 ºC to +50 ºC, excluding CD-R/W
drive; +10 ºC to +45 ºC, including CD-R/W drive.

Nonoperating – –22 ºC to +60 ºC.

Humidity

Operating – 20% to 80% relative humidity with a
maximum wet bulb temperature of +29 ºC at or
below +50 ºC, noncondensing. Upper limit derated
to 25% relative humidity at +50 ºC.

Nonoperating – 5% to 90% relative humidity with
a maximum wet bulb temperature of +29 ºC at or
below +60 ºC, noncondensing. Upper limit derated
to 20% relative humidity at +60 ºC.

Altitude

Operating – 10,000 ft. (3,048 m).

Nonoperating – 40,000 ft. (12,190 m).

Random Vibration

Operating – 0.000125 g2/Hz from 5 to 350 Hz,
–3 dB/octave from 350 to 500 Hz,

0.0000876 g

Nonoperating – 0.0175 g2/Hz from 5 to 100 Hz,
–3 dB/octave from 100 to 200 Hz, 0.00875 g
from 200 to 350 Hz, –3 dB/octave from 350 to
500 Hz, 0.006132 g
of 2.28 g

Certifications

2

/Hz at 500 Hz. Overall level of 0.24 g

2

/Hz at 500 Hz. Overall level

.

RMS

RMS

2

/Hz

Electromagnetic Compatibility – 89/336/EEC.
Safety –

UL 3111-1, CSA1010.1, EN61010-1, IEC 61010-1.

.

MECHANICAL
Cooling – mm in.
Required Clearance

Top 0 or >76 0 or >3
Bottom 25 1
Left side 76 3
Right side 76 3
Front 0 0
Rear 0 0

9

Digital Storage Oscilloscopes

TDS6000B Series

Ordering Information

TDS6604B

6 GHz Digital Storage Oscilloscope.

TDS6804B

8 GHz Digital Storage Oscilloscope.

TDS6604B and TDS6804B Includes:

Accessory pouch, front cover, USB mouse,
PS2 mini-keyboard, user manual (071-1503-xx),
quick reference kit (020-2552-xx), TDS6000B
Series Documentation CD-ROM (063-3760-xx),
TDS6000B Series product software CD-ROM
(063-3761-xx), TDS6000B Series operating
system restoration CD-ROM (063-3762-xx),
TDS6000B Series optional applications software
CD-ROM (063-3478-xx), performance verification
procedure PDF file, GPIB programmer’s reference
(on product software CD-ROM), calibration
certificate documenting NIST traceability, 2 540-1
compliance and ISO9000, power cord, one year
warranty. (4) TekConnect
(TCA-SMA), Deskew Fixture (067-0484-xx).
Please specify power plug when ordering.

Instrument Options

Power Plug Options

Opt. A0 – North America power.

Opt. A1 – Universal EURO power.

Opt. A2 – United Kingdom power.

Opt. A3 – Australia power.

Opt. A5 – Switzerland power.

Opt. A6 – Japan power.

Opt. A10 – China power.

Opt. A99 – No power cord or AC adapter.

Disk Drive Options

Opt. FHD – Front-panel 40 GB removable hard
disk drive, replaces front panel CD-R/W which is
moved to the back.

®

to SMA adapters

Cables

GPIB Cable (1 m) – Order 012-0991-01.

GPIB Cable (2 m) – Order 012-0991-00.

RS-232 Cable – Order 012-1298-00.

Centronics Cable – Order 012-1214-00.

Mounting Options

1K – K4000 Oscilloscope Cart.

1R – Rackmount Kit.

Service Options

Opt. C3 – Calibration Service 3 Years.

Opt. C5 – Calibration Service 5 Years.

Opt. D1 – Calibration Data Report.

Opt. D3 – Calibration Data Report 3 Years

(requires Option C3).

Opt. D5 – Calibration Data Report 5 Years
(requires Option C5).

Opt. R3 – Repair Service 3 Years.

Opt. R5 – Repair Service 5 Years.

Acquisition Memory Options

2M – 8 Mb samples on all channels.

3M – 16 Mb samples on all channels.

4M – 32 Mb samples on all channels.

Software Options

*1

CP2

– TDSCPM2 ANSI/ITU Telecom pulse

compliance testing software (requires option SM).

DVD – TDSDVD Optical storage analysis.

DVI – TDSDVI DVI compliance test solution.

ET3 – TDSET3 Ethernet compliance test software.

JT3 – TDSJIT3 Advanced jitter analysis software.

J3E – TDSJIT3 Essentials.

J2 – TDSDDM2 Disk drive analysis software.

2

– TDSPWR3 Power measurement and

PW3

analysis software.

RTE – TDSRT-Eye

™

Serial Data Compliance and

Analysis Software.

RTJ – Software Bundle of TDSJIT3 (Opt. JT3) and
TDSRT-Eye (Opt. RTE).

RJS – Software Bundle of TDSJIT3 (Opt. JT3),
RT-Eye (Opt. RTE), and Serial Mask testing (Opt. SM).

*3

PCE

– PCI Express Compliance Module for Opt. RTE.

*3

– InfiniBand Compliance Module for Opt. RTE.

IBA

SM – Serial communications mask testing (enables

hardware clock recovery).

ST – Serial pattern trigger (enables hardware
clock recovery).

*4

– TDSUSBS USB2.0 Compliance test S/W only.

USB

Recommended Accessories

P7380SMA – 8 GHz Differential Probing System.

P7380 – 8 GHz Differential Probe.

AFTDS – Telecom differential electrical interface

adapter (for line rates <8 MB/sec; requires
TCA-BNC adapter).

Keyboard (USB interface) full-size keyboard with
4-port USB hub – Order 119-6297-00.

Transit Case – Order 016-1942-00.

®

TekConnect

TCA-1MEG: TekConnect

Adapters –

®

high-impedance buffer

amplifier. Includes P6139A passive probe.

TCA-SMA: TekConnect-to-SMA Adapter.

TCA-N: TekConnect-to-N Adapter.

TCA-BNC: TekConnect-to-BNC Adapter.

TCA75: 4 GHz precision TekConnect 75 Ω to 50 Ω
adapter with 75 Ω BNC input connector.

Oscilloscope Cart – Order K4000.

™

Software – WSTRO: WaveStar

waveform capture

and documentation software.

Test Fixtures – TDSUSBF: TDSUSB test fixture for
use with Opt. USB.

*1

Requires Opt. SM.

*2

Opt. 3M and a TCA-1MEG TekConnect 1 MΩ buffer
amplifier are recommended for use with this software.

*3

Requires Opt. RTE (Serial Data Compliance and Analysis).

*4

Requires Opt. TDSUSBF (USB Test Fixture).

10

Oscilloscopes • www.tektronix.com/oscilloscopes

Digital Storage Oscilloscopes

TDS6000B Series

After Purchase Upgrades of TDS6000B Series Oscilloscopes

To upgrade your oscilloscope, order option as noted.

Acquisition Record Length:

Current Record Length Desired Order

Standard 8 Msamples TDS6BUP Opt. M02

16 Msamples TDS6BUP Opt. M03

32 Msamples TDS6BUP Opt. M04

8 Msamples 16 Msamples TDS6BUP Opt. M23

32 Msamples TDS6BUP Opt. M24

16 Msamples 32 Msamples TDS6BUP Opt. M34

Desired Option Order

Serial Comm Mask Testing TDS6BUP Opt. SM

Serial Pattern Trigger TDS6BUP Opt. ST

Hardware Clock Recovery for Serial Data Stream Included in Opt. SM and ST

Analysis and Compliance Software

ANSI/ITU Telecom Pulse Compliance TDS6BUP Opt. CP2 (Requires Opt. SM)

DVD Optical Storage Analysis TDS6BUP Opt. DVD

DVI Compliance Test TDS6BUP Opt. DVI

Ethernet Compliance TDS6BUP Opt. ET3

JIT3 Advanced Jitter Analysis Software TDS6BUP Opt. JT3

JIT3 Essentials TDS6BUP Opt. J3E

DDM2 Disk Drive Analysis Software TDS6BUP Opt. J2

Power Measurement/Analysis TDS6BUP Opt. PW3

RT-Eye Serial Data Compliance and Analysis Software TDS6BUP Opt. RTE

PCI Express Compliance Module for option RTE TDS6BUP Opt PCE (Requires Opt. RTE)

InfiniBand Compliance Module for Option RTE TDS6BUP Opt IBA (Requires Opt. RTE)

USB2.0 Compliance, Software Only TDS6BUP Opt. USB (Requires TDSUSBF test fixture)

RT-Eye Serial Data Analysis Software and TDS6BUP Opt. RTJ
TDSJIT3 Advanced Jitter Analysis Software Bundle

RT-Eye Serial Data Analysis, TDSJIT3 Advanced TDS6BUP Opt. RJS
Jitter Analysis, Opt. SM Serial Mask Software Bundle

Oscilloscopes • www.tektronix.com/oscilloscopes

11

Digital Storage Oscilloscopes

TDS6000B Series

DPO – Digital Phosphor Technology

You have to see it to believe it.

A Digital Phosphor Oscilloscope (DPO) is ideal for those who need the best design and

troubleshooting tool for a wide range of applications, for communication mask testing,

digital debug of intermittent signals, repetitive digital design and timing applications.

Covering a spectrum of bandwidth from 100 MHz to 7 GHz, Tektronix offers a wide

selection of DPOs for you to see a world others don’t.

OpenChoice

Provides more choices for your networking
and analysis solutions.

TekConnect

Superior signal fidelity and unparalleled versatility
at your fingertips.

®

OpenChoice is a collection of software libraries, utilities, samples, industry-standard

protocols and interfaces offered with many Tektronix oscilloscopes and logic

analyzers. From 60 MHz to 6 GHz, OpenChoice allows you to communicate with your

oscilloscope or logic analyzer over a network, using numerous connectivity protocols

and physical interfaces, such as GPIB, Ethernet, RS-232 and shared memory.

®

TekConnect interface takes probe intelligence to the next level whether you are measuring

high voltage, current, power, or even micro-volt level signals. The TekConnect interface

ensures superior signal fidelity with useful bandpass up to 18 GHz at the oscilloscope

input, while offering unparalleled versatility.With the TekConnect interface, you can be

assured that maximum signal integrity is maintained to meet your present and future

bandwidth needs.

Contact Tektronix:

ASEAN / Australasia / Pakistan (65) 6356 3900

Austria [phone]

Belgium [phone]

Brazil & South America 55 (11) 3741-8360

Canada 1 [phone]

Central Europe & Greece [phone]

Denmark [phone]

Finland [phone]

France & North Africa [phone]

Germany [phone]

Hong Kong (852) 2585-6688

India (91) 80-22275577

Italy [phone]

Japan 81 (3) 6714-3010

Mexico, Central America & Caribbean 52 (55) 56666-333

The Netherlands [phone]

Norway [phone]

People’s Republic of China 86 (10) 6235 1230

Poland [phone]

Republic of Korea 82 (2) 528-5299

Russia, CIS & The Baltics [phone]

South Africa [phone]

Spain [phone]

Sweden [phone]/4

Taiwan 886 (2) 2722-9622

United Kingdom & Eire [phone]

USA 1 [phone]

USA (Export Sales) 1 [phone]

For other areas contact Tektronix, Inc. at: 1 [phone]

Last Update March 01, 2004

Oscilloscope Software

Turn your general purpose oscilloscope
into a highly specialized analysis tool.

Tektronix offers exceptional application solutions that instill your oscilloscope with

specific technology or procedure expertise, vastly simplifying the development and

testing of specialized designs. From serial data standards to power measurements,

Tektronix has the broadest selection of oscilloscope software to convert your

oscilloscope into a highly specialized and power analysis tool.

Our most up-to-date product information is available at:

www.tektronix.com

Product(s) are manufactured

in ISO registered facilities.

Copyright © 2004, Tektronix, Inc.All rights reserved. Tektronix products are
covered by U.S. and foreign patents, issued and pending. Information in this publi­cation supersedes that in all previously published material. Specification and price
change privileges reserved. TEKTRONIX and TEK are registered trademarks of
Tektronix, Inc. All other trade names referenced are the service marks, trade­marks or registered trademarks of their respective companies.

07/04 HB/WWW 55W-14873-5
