Tektronix Spectra Datasheet

Network Diagnostics
Spectra
Spectra set the industry standard as an easy-to-use tool for performing sophisti­cated SS7-based signaling testing. Enhancement requests from our customers drive Spectra’s design and feature evolu­tion. This has helped make us the market leader in SS7 test solutions. Spectra provides integrated Monitoring, Testing and Generation features for PSTN technologies. Users can perform deep protocol analysis, standards-based conformance testing, network element emulation and load generation from one integrated tool. Monitor – Capture and analyze link data, perform real-time and post-capture call trace. View data based on specific criteria such as phone numbers, error messages and link status. Collect data from special­ized tests that you create. Capture and decode SS7 PDUs from MTP2 to the ISUP and TCAP layers with full parameter display. Test – Create any desired test scenario using Spectra’s menu-driven test-building capability. Choose from more than 2,400 pre-scripted conformance test cases or use Spectra’s “Ping-Pong” editor to create your own test cases. Run and observe tests in real time. Spectra also lets you get a detailed look at parameter values. View post-capture test results. Save and recall test files, batch test files together and perform call tracing.
Generate – Stress test network elements with Spectra’s load generation capabilities for TCAP, ISUP, TUP, GSM, ISDN and MTP3. Flexible traffic modeling lets users create multiple call scenarios such as steady ramping traffic and mass call spikes. Create and modify number databases for use by Spectra system generators. Spectra supports more than 150 PSTN protocols, including country-specific variants and equipment manufacturer implementations. Spectra’s modular architecture lets you easily add software and hardware options. Spectra’s integrated hardware and software solution addresses: Conformance Testing – With over 2,400 defined conformance test cases, Spectra is the industry-leading product for SS7­based conformance testing. Protocol Support – For more than 150 PSTN-based protocols. Spectra’s modular design lets you add multiple protocol support as needed. High-Speed Links – Test SS7/ATM, SS7/Unchannelized HDLC, M3UA, M2PA and SUAfrom a single test tool. Sigtran – Assess the performance of Signaling Gateways (SGs) and next­generation STPs. Wireless Testing – Test the core network WIN and IN features of CDMA, GSM, GPRS and UMTS networks. Easily monitor MAP and A-interface transactions.
Features & Benefits
Monitor and Test SS7 and ISDN Signaling Networks
Conformance Testing For: Sigtran, HSL, ISUP, GSM, TCAP, Conformance, Validation and Regression Testing (CVR)
Network Element Emulation SSP, STP, HLR, VLR, SG, ASP
Complete Support for Standard Protocols and Signaling Interfaces
One Box for All of Your Testing Needs
PCI Processing Cards for Increased Link and Traffic Capacity
Scalable Architecture for Multi-protocol Analysis
Over 2,400 PSTN Protocol Conformance Test Cases
Reduce Lab Equipment Cost with Network Element Simulation (STPs, SCPs, HLRs)
Applications
Industry Leadership in SS7 Conformance Testing
More Than 150 SS7 and ISDN­based Protocols for Monitoring, Testing and Generation
Market Leader in High-speed Link Testing
Spectra’s Core Monitor, Test and Generation Features Deliver a Complete Sigtran Testing Solution
Features to Test the Core Network WIN and IN Features of GSM, GPRS, UMTS, IS-41 and cdma2000 Networks
Network Diagnostics
Spectra
Characteristics
General Characteristics
Portable Chassis Rackmount Chassis
Slots 6 PCI 16 PCI Operating System Windows XP Monitor Flat Panel 35.8 cm (14.1 in.) XGA TFT Optional Power 110 to 220 VAC 110 to 220 VAC
48 VDC Available
Physical Characteristics
Portable Chassis Rackmount Chassis
Dimensions cm in. cm in.
Height 27 10.6 26.5 10.5 Width 41 16.1 43.26 17 Depth 25 9.8 46 18
Weight kg lb. kg lb.
Net 9.5 21 22.7 50.5
Network Diagnostics • www.tektronix.com/network
2
Network Diagnostics
Spectra
Spectra Packages
SS7 Monitor SS7 Monitor/Tester ISDN Monitor ISDN Monitor/Tester SS7 and ISDN Monitor
Spectra Applications
SCTP Tester
M2PA and M2UA
SUA Tester High-speed Link (HSL) SAAL/ATM Tester ISDN Generator GSM Generator TCAP Generator Trunk Tester
SS7 Conformance Testing
Conformance,Validation and Regression Testing (CVR)
Level 2, ITU-T Q.781 Level 3, ITU-T Q.782 TUP,ITU-T Q.783 ISUP,ITU-T Q.784 TCAP,ITU-T Q.787
Network Element Emulation SSP, STP, SCP,SG,AS/ASP
Protocol Support
SS7 SS7 over ATM Unchannelized SS7 (HDLC) ISDN GSM GSM/CAMEL/BSSA TCAP ANSI ITU-T
China Ericcson INAP/INCS1+ ETSI INAP
Media and Signaling Interfaces
DS1/E1 V5 Bantam DS1/E1 V6 BNC HSL DS1/E1 BRI S/T V2 J1 DSO V.35 RS449 RS232
Ordering Information
Have a Diagnostics Representative Contact Me.
Network Diagnostics • www.tektronix.com/network
3
Network Diagnostics
Spectra
ASEAN / Australasia / Pakistan (65) 6356 3900
Contact Tektronix:
Austria +41 52 675 3777
Balkan, Israel, South Africa and other ISE Countries +41 52 675 3777
Belgium 07 81 60166
Brazil & South America 55 (11) 3741-8360
Canada 1 (800) 661-5625
Central East Europe, Ukraine and the Baltics +41 52 675 3777
Central Europe & Greece +41 52 675 3777
Denmark +45 80 88 1401
Finland +41 52 675 3777
France & North Africa +33 (0) 1 69 86 81 81
Germany +49 (221) 94 77 400
Hong Kong (852) 2585-6688
India (91) 80-22275577
Italy +39 (02) 25086 1
Japan 81 (3) 6714-3010
Luxembourg +44 (0) 1344 392400
Mexico, Central America & Caribbean 52 (55) 56666-333
Middle East, Asia and North Africa +41 52 675 3777
The Netherlands 090 02 021797
Norway 800 16098
People’s Republic of China 86 (10) 6235 1230
Poland +41 52 675 3777
Portugal 80 08 12370
Republic of Korea 82 (2) 528-5299
Russia & CIS 7 095 775 1064
South Africa +27 11 254 8360
Spain (+34) 901 988 054
Sweden 020 08 80371
Switzerland +41 52 675 3777
T aiwan 886 (2) 2722-9622
United Kingdom & Eire +44 (0) 1344 392400
USA 1 (800) 426-2200
For other areas contact Tektronix, Inc. at: 1 (503) 627-7111
Updated 15 June 2005
Our most up-to-date product information is available at:
www.tektronix.com
Product(s) are manufactured
in ISO registered facilities.
Copyright © 2005,Tektronix, Inc.All rights reser ved. Tektronix products are covered by U.S. and foreign patents,issued and pending. Information in this publi­cation supersedes that in all previously published material. Specification and price change privileges reserved. TEKTRONIX and TEK are registered trademarks of Tektronix,Inc.All other trade names referenced are the service marks, trade­marks or registered trademarks of their respective companies.
10/05 HB/WOW 5TW-18207-1
