PRISM MPI2-10 and MPX2-10 Field Upgrade Kit Instructionsi
Important safety information
Important saf
ety information
This manual c
for safe operation and to keep the product in a safe condition.
To safely perform service on this product, additional information is provided at
the end of this section. (See page iv, Servicesafetysummary.)
General safety summary
Use the product only as specified. Review the following safety precautions to
avoid injury and prevent damage to this product or any products connected to it.
Carefully read all instructions. Retain these instructions for future reference.
This product shall be used in accordance with loca l and national codes.
For correct and safe operation of the product, it is essential that you follow
generally accepted safety procedures in addition to the safety precautions specified
in this manual.
The product is designed to be used by trained personnel only.
Only qualified personnel who are aware of the hazards involved should remove
the cover for repair, maintenance, or adjustment.
ontains information and warnings that must be followed by the user
To avoid fire or personal
injury
Before use, always check the product with a known source to be sure it is
operating correctly.
This product is not intended for detection of hazardous voltages.
While using this product, you may need to access other parts of a larger system.
Read the safety sections of the oth
cautions related to operating the system.
When incorporating this equipment into a system, the safety of that system is the
responsibility of the assembler of the system.
Use proper power cord. Use only the power cord specified for this product and
certified for the country of use.
Do not use the provided power cord for other products.
Power disconnect. The power cord disconnects the product from the power
source. See instructions for the location. Do not p osition the equipment so that
it is difficult to operate the power cord; it must remain accessible to the u ser at
all times to allow for quick disconnection if needed.
Observe all terminal ratings. To avoid fire or shock hazard, observe all ratings
and markings on the product. Consult the product manual for further ratings
information before making connections to the product.
er component manuals for warnings and
iiPRISM MPI2-10 and MPX2-10 Field Upgrade Kit Instructions
Important safety information
Do not apply a po
tential to any terminal, including the common terminal, that
exceeds the maximum rating of that terminal.
Do not operate without covers. Do not operate this product with covers or panels
removed, or with the case open. Hazardous voltage exposure is possible.
Avoid expos
ed circuitry. Do not touch exposed connections and components
when power is present.
Do not operate with suspected failures. If you suspect that there is damage to this
product, have it inspected by qualified service personnel.
Disable the product if it is damaged. Do not use the product if it is damaged
or operates incorrectly. If in doubt about safety of the product, turn it off and
disconnect the power cord. Clearly mark the product to prevent its further
operati
on.
Before use, inspect test leads and accessories for mechanical damage and replace
when da
maged. Do not use test leads if they are damaged, if there is exposed
metal, or if a wear indicator shows.
ne the exterior of the product before you use it. Look for cracks or missing
Exami
pieces.
nly specified replacement parts.
Use o
Do not operate in wet/damp conditions. Be aware that condensation may occur if
a unit is moved from a cold to a warm environment.
Do not operate in an explosive atmosphere.
Keep product surfaces clean and dry. Remove the input signals before you clean
the product.
rovide proper ventilation. Refer to the installation instructions in the manual for
P
details on installing the product so it has proper ventilation.
Slots and openings are provided for ventilation and should never be covered or
otherwise obstructed. Do not push objects into any of the openings.
Provide a safe working environment. Always place the product in a location
convenient for viewing the display and indicators.
Avoid improper or prolonged use of keyboards, pointers, and button pads.
Improper or prolonged keyboard or pointer use may result in serious injury.
Be sure your work area meets applicable ergonomic standards. Consult with an
ergonomics professional to avoid stress injuries.
Use only the Tektronix rackmount hardware specified for this product.
PRISM MPI2-10 and MPX2-10 Field Upgrade Kit Instructionsiii
Important safety information
Service safet
ysummary
The Service safety summary section contains additional information required to
safely perform service on the product. Only qualified personnel should perform
service proc
summary before performing any service procedures.
To avoid electric shock. Do not touch exposed connections.
Do not service alone. Do not perform internal service or adjustments of this
product un
present.
Disconnect power. To avoid electric shock, switch off the product power and
disconnect the power cord from the mains power before removing any covers or
panels, or opening the case for servicing.
Use care when servicing with power on. Dangerous voltages or currents may exist
in this product. Disconnect power, remove battery (if applicable), and disconnect
test leads before removing protective panels, soldering, or replacing components.
Verify safety after repair. Always recheck ground continuity and mains dielectric
stre
edures. Read this Service safety summary and the General safety
less another person capable of rendering first aid and resuscitation is
ngth after performing a repair.
Termsinthismanual
se terms may appear in this manual:
The
WARNING. Warning statements identify conditions or practices that could result
in injury or loss of life.
CAUTION. Caution statements identify conditions or practices that could result in
damage to this product or other property.
ivPRISM MPI2-10 and MPX2-10 Field Upgrade K it Instructions
Important safety information
Symbols and te
rms on the product
These terms may appear on the product:
DANGER indicates an injury hazard immediately accessible as you read
the marking.
WARNING indicates an injury hazard not immediately accessible as you
read the marking.
CAUTION indicates a hazard to property including the product.
When this symbol is marked on the product, be sure to consult the manual
to find out the nature of the potential hazards and any actions which have to
be taken to avoid them. (This symbol may also be used to refer the user to
ratings in the manual.)
The follo
wing symbol(s) may appear on the product:
PRISM MPI2-10 and MPX2-10 Field Upgrade Kit Instructionsv
Important safety information
viPRISM MPI2-10 and MPX2-10 Field Upgrade Kit Instructions
Kit description
Supported upgrades
This document provides instructions for installing the Eye mezzanine board,
upgrading the firmware, and updating software licenses. The k it applies to the
following Tektronix instruments:
PRISM MPI2-10 Media Analysis Platform
PRISM MPX2-10 Media Analysis Platform
The following hardware upgrades are supported by this document:
MPI2-10-UP PHY. Add SDI Physical Layer Measurement Package to the
MPI2-10 product; includes automated measurement of 12G/3G/HD/SD-SDI
Eye pattern parameters, jitter p arameters and jitter waveform display.
(Option MP2-FMT-4K required for 12G support)
MPX2-10-UP PHY. Add SDI Physical Layer Measurement Package t o the
MPX2-10 product; includes automated measurement of 12G/3G/HD/SD-SDI
Eye pattern parameters and jitter parameters and jitter waveform display.
Kit parts list
(Option MP2-FMT-4K required for 12G support)
The following table lists the parts that are supplied with the upgrade kit.
QuantityPart NumberDescription
1878-1285-XX
2211-1117-XX
1129-1889-XX
1075-1095-XX
1
The spacer post provided in the kit will not be needed for the MPI2-10 12G Eye board upgrade. The
MPI2-10 Mixed Media board comes with a second spacer post installed.
1
EMBLY, CIRCUIT BOARD,12G EYE MEZZ, 3895134XX
ASS
SCREW, MACHINE; 4-40 X 0.187, PAN HE AD, STEEL, ZINC
NISH, T-10, TORX DR
FI
SPACER POST .188 HEX X .325L BNC, MEZZ BOARD
OUNTING
M
PRISM FIELD UPGRADE INSTRUCTIONS
PRISM MPI2-10 and MPX2-10 Field Upgrade Kit Instructions1
Kit description
2PRISM MPI2-10 and MPX2-10 Field Upgrade Kit Instructions
MPI2-10 hardware upgrades
These instructions are for the qualified, trained personnel or personnel familiar
with servicing the product. Contact your nearest Tektronix, Inc., Service Center or
Tektronix Factory Service for installation assistance.
WAR NI NG . Dangerous voltages may be present. To prevent electrical shock,
disconnect
Failure to do so could cause serious injury or death.
the power cord from the unit before starting the upgrade procedure.
Recommended tool list
CAUTION. M
any components within the instrument are susceptible to static
discharge damage. To prevent static discharge damage, service the product
only in a static-free environment. Observe standard handling precautions for
static-sensitive devices while installing this kit. Always wear a grounded wrist
strap, grounded foot strap, and static resistant apparel while installing this kit.
Table 1
NameDescri
9/16 i
Scre
T-10
T-15 TORX tipUsed for removing instrument screws.
Torque driver
: Recommended tool list
nch socket nut driver
wdriver handle
TORX tip
ption
o removed BNC nuts.
Used t
Accepts Torx-driver bits
for removing instrument screws.
Used
TORX-driver bit for T-10 size screw heads.
TORX-driver bit for T-15 size screw heads.
Used to apply precisely a specific torque to
astener.
af
PRISM MPI2-10 and MPX2-10 Field Upgrade Kit Instructions3
MPI2-10 hardware upgrades
Upgrade the PR
ISM MPI2-10 Eye mezzanine board
Complete the following steps to remove the currently installed mezzanine board
from the instrument and install the Eye mezzanine board:
1. Set the instrument so the bottom is down on a static-free work surface.
2. Remove the top cover as follows:
a. Use a TORX-driver with a T-10 TORX tip to remove the thirteen screws
securing the cover to the instrument.
b. Slide the cover back and then lift it from the back to remove it from the
instrument; set the cover aside.
4PRISM MPI2-10 and MPX2-10 Field Upgrade Kit Instructions
re 1: Remove the cover
Figu
MPI2-10 hardware upgrades
3. Use the 9/16 inc
h socket nut driver to remove the two BNC nuts and lock
washers (SDI IN 1 and 2).
Figure 2: Remove the BNC hardware
4. Using a TORX-driver with a T-10 TORX tip to remove the screw securing
the BNC m
ezzanine board.
Figure 3: Remove the screw from the mezzanine board
PRISM MPI2-10 and MPX2-10 Field Upgrade Kit Instructions5
MPI2-10 hardware upgrades
5. Gently lift the
back of the BNC mezzanine board from its connector and
remove it from the Mixed Media board.
Figure 4: Remove mezzanine board from Mixed Media board
6. Locate the new Eye mezzanine board from the kit (Tektronix part number
878-12
85-XX).
Figure 5: Eye mezzanine board
6PRISM MPI2-10 and MPX2-10 Field Upgrade Kit Instructions
MPI2-10 hardware upgrades
7. Guide the BNC co
nnectors through the bracket and line up the two board
connectors with the connectors on the Mixed Media board.
CAUTION. Bending the Eye mezzanine board can damage the board or instrument.
Avoid fully inserting the back connector until the front connector is properly
aligned; this prevents the bending of the board.
8. Begin by engaging the connector near the BNCs. Do not fully insert.
9. Line up the connectors furthest away from the BNCs. Finish inserting the
first connector.
10. Gently press the last connector into the Mixed Media board.
NOTE. The MPI2-10 Mixed Media board comes with a second spacer post
installed. The spacer post in the kit will not be needed during the upgrade process.
Fig
PRISM MPI2-10 and MPX2-10 Field Upgrade Kit Instructions7
ure 6: Connect the Eye mezzanine board
MPI2-10 hardware upgrades
11. Use a TORX-driv
er with a T-10 TORX tip to install the two screws in the Eye
mezzanine board. Tighten these screws to 0.6 N·m (5.31 in-lb).
Figure 7: Secure the Eye mezzanine board
12. Replace the two BNC nuts and lock washers. Tighten the BNC nuts to
1.0N·m(8.85in-lb).
13. Place the top cover over the instrument and use the TORX-driver with a T-10
TORX tip to reinstall the screws. Tighten these screws to 0.9 N·m (7.97 in-lb).
8PRISM MPI2-10 and MPX2-10 Field Upgrade Kit Instructions
MPI2-10 hardware upgrades
14. Apply the MPI2-
10-UP serial number label to the side panel (right side as
viewed from the front of the instrument). Place the new serial number label
below the labels that contain the regulatory marks.
NOTE. The MPI2-10-UP serial number label is included in the upgrade kit. The
label lets Tektronix Service know that the instrument contains the upgrade kit.
Figure 8: Installing the MPI2-10-UP serial number label
15. Upgrade the instrument firmware. (See page 21, Upgrade the instrument
firmware.)
16. Upgrade the software license. (See page 24, Upgrade the software license.)
17. Verify the upgrade. (See page 30, Verify the hardware upgrade.)
PRISM MPI2-10 and MPX2-10 Field Upgrade Kit Instructions9
MPI2-10 hardware upgrades
10PRISM MPI2-10 and MPX2-10 Field Upgrade Kit Instructions
MPX2-10 hardware upgrades
These instructions are for personnel who are familiar with servicing the product.
Contact your nearest Tektronix, Inc., Service Center or Tektronix Factory Service
for installation assistance.
WAR NI NG . Dangerous voltages may be present. To prevent electrical shock,
disconnect
Failure to do so could cause serious injury or death. This product does not
provide the AC Mains power switch.
the power cord from the unit before starting the upgrade procedure.
Recommended tool list
CAUTION.
Many components within the instrument are susceptible to static
discharge damage. To prevent static discharge damage, service the product
only in a static-free environment. Observe standard handling precautions for
static-sensitive devices while installing this kit. Always wear a grounded wrist
strap, grounded foot strap, and static resistant apparel while installing this kit.
2: Recommended tool list
Table
NameDescr
nch socket nut driver
3/16 i
2 inch socket nut driver
11/ 3
ut driver
BNC n
ewdriver handle
Scr
T-10 Torx tip
rque driver
To
iption
Used to remove jack screws.
Used to remove lock nuts.
to remove BNC nuts.
Used
Accepts Torx-driver bits
ed for removing instrument screws.
Us
Torx-driver bit for T-10 size screw heads.
Used to apply precisely a specific torque to
a fastener.
PRISM MPI2-10 and MPX2-10 Field Upgrade Kit Instructions11
MPX2-10 hardware upgrades
Upgrade the PR
ISM MPX Eye mezzanine board
Complete the following steps to remove the currently installed mezzanine board
from the instrument and install the Eye mezzanine board:
1. Set the instrument so that the bottom is down on a static-free surface.
2. Remove the top cover as follows:
a. Use a TORX-driver with a T-10 TORX tip to remove the eighteen screws
securing the cover to the instrument.
b. Lift the cover up to remove it from the instrument and set it aside.
Figure 9: R emove the top cover
12PRISM MPI2-10 and MPX2-10 Field Upgrade Kit Instructions
MPX2-10 hardware upgrades
3. Use the BNC nut d
river to remove all five BNC nuts and lock washers.
Figure 10: Remove the rear panel plate hardware
4. Use a TORX-driver with a T-10 TORX tip to remove the four screws securing
the rear panel plate to the instrument.
e 11: Remove the four rear panel plate screws
Figur
PRISM MPI2-10 and MPX2-10 Field Upgrade Kit Instructions13
MPX2-10 hardware upgrades
5. Pull the rear pa
nel plate straight off the back panel.
NOTE. TheGPIOboardwillkeeptherearplate connected to the instrument.
Figure 12: Remove the rear panel plate
6. Use a TORX-driver with a T-10 TORX tip to remove the two screws on either
end of t
he back panel.
7. Pull the right side of the back panel away from the instrument.
Figure 13: Remove the back panel
14PRISM MPI2-10 and MPX2-10 Field Upgrade Kit Instructions
MPX2-10 hardware upgrades
8. Use the 11/32 in
ch socket nut driver to loosen the two lock nuts on the side
of the Mixed Media board module.
Figure 14: Loosen the lock nuts securing the Mixed Media board module to the
instrument
9. Slide the Mixed Media board and carrier frame away from the PCIe and
power connector on the Slot Host board.
10. Use a TORX-driver with a T-10 TORX tip to remove the four screws on the
corners of the Mixed Media board.
Figure 15: Remove the Mixed Media board screws
PRISM MPI2-10 and MPX2-10 Field Upgrade Kit Instructions15
MPX2-10 hardware upgrades
11. Slide the Mixed
Media board out from between the grinches as shown in
the following figure.
Figure 16: Remove the Mixed Media board from the grinches
12. Turn the board over and disconnect the GPIO ribbon cable.
CAUTION. Make sure the back panel is pulled out enough to clear the BNC
connectors on the Mixed Media module. Excessive pressure on the BNCs will
cause damage to the connectors on the Mixed Media and mezzanine boards.
Figure 17: Remove Mixed Media board
16PRISM MPI2-10 and MPX2-10 Field Upgrade Kit Instructions
MPX2-10 hardware upgrades
13. Use a TORX-driv
er with a T-10 TORX tip to remove the screw from the
mezzanine board shown below.
14. Remove the mez
zanine board from t he connector and set it aside.
Figure 18: Remove the mezzanine board
15. Refer to the following figure and install the screw from the kit (Tektronix
part number 211-1117-XX) and the spacer post (Tektronix part number
129-1889-XX) into the hole closest to second connector using the following
method:
a. Insert the screw from the bottom of the board and use a finger to hold
it in place.
b. Install the spacer post over the screen on the board, while keeping a finger
on head of the screw; tighten the spacer post until tight.
Figure 19: Install the spacer on the board
PRISM MPI2-10 and MPX2-10 Field Upgrade Kit Instructions17
MPX2-10 hardware upgrades
16. Locate the new E
ye mezzanine board from the kit (Tektronix part number
878-1285-XX).
17. Line up the Eye
mezzanine board with both of the connectors and press down
until it is fully engaged as show in the following figure.
CAUTION. Bending the Eye mezzanine board can damage the board or instrument.
Avoid fully inserting the connectors until they are properly aligned; this prevents
the bending of the board.
Figure 20: Install the Eye mezzanine board on the main board
18PRISM MPI2-10 and MPX2-10 Field Upgrade Kit Instructions
MPX2-10 hardware upgrades
18. Use the TORX-dr
iver with a T-10 TORX tip to secure the Eye mezzanine
board to the main board using the two screws provided in the kit. Tighten
these screws to 0.6 N·m (5.31 in-lb).
Figure 21: Attach the Eye mezzanine board
19. Perform steps 8 to 12 in reverse order to reinstall the Mixed Media board
back into instrument. Tighten the four Mixed Media board bracket screws to
0.6 N·m
(5.31 in-lb).
20. Secure the back panel to the instrument. Tighten two side screws to 0.9 N·m
in-lb).
(7.97
21. Tighten the two lock nuts on the opposite side of the Mixed Media board to
·m ( 7.97 in- lb).
0.9 N
22. Secure the rear panel plate. Tighten the four rear panel plate screws to 0.9
(7.97 in-lb).
N·m
23. Reinstall the rear panel hardware. Tighten t he five BNC nuts to 0.9 N·m
.97 in-lb).
(7
24. Place the cover over the instrument and replace the top cover screws. Tighten
e cover screws to 0.9 N·m (7.97 in-lb).
th
PRISM MPI2-10 and MPX2-10 Field Upgrade Kit Instructions19
MPX2-10 hardware upgrades
25. Apply the MPX2-
10-UP serial number label below the existing MPX serial
number label on the bottom of the instrument.
NOTE. The MPX2-10-UP serial number label is included in the upgrade kit. The
label lets Tektronix Service know that the instrument c ontains the upgrade kit.
Figure 22: Installing the MPX2-10-UP serial number label
CAUTION. The MPX2-10-UP label is not inset and is at risk of damage. To avoid
ging the label, use caution when inserting or removing the instrument.
dama
26. Upgrade the instrument firmware. (See page 21, Upgrade the instrument
ware.)
firm
27. Upgradethesoftwarelicense.(Seepage24,Upgrade the software license.)
28. Verify the upgrade. (See page 30, Verify the hardware upgrade.)
20PRISM MPI2-10 and MPX2-10 Field Upgrade Kit Instructions
Upgrade the instrument firmware
Before you begin
Tektronix releases updates to product firmware to add new feat
reported problems. You should c heck the Tektronix Web site regularly for new
firmware releases.
Perform the following steps to determine the current firmware version on your
instrument:
1. Power on the instrument.
2. Verify the current software version installed on the instrument:
a. Touch t he Settings icon to open the Settings menu.
b. Touch Utilities to open the Utilities submenu.
c. To uch Versio n to open the Version display.
d. In the Software section, note the version number install
instrument.
Instrument Firmware version number
3. Verify the latest version of firmware on the Tektronix Web site:
a. Go to the following Tektronix Web site:
http://www.tek.com/product-support
ures or to fix
ed on the
b. Under the Tektronix Product Support page, enter a product name, such as
MPX or MPI. On the landing page for your product, click the Software
tab, and sear
c. Note the latest version number of the software-upgrade package(s).
Web site Firmware version number
4. If the latest firmware version at the Web site is newer than the version on your
instrument, you should upgrade the firmware.
5. Select the newer firmware release and click the Download File button.
NOTE. If you are not logged into tek.com, click the Login to a ccess this conte nt
button. If it is the first time you are downloading firmware, you are asked to
enter your company name and address. This information is required before
downloading the firmware.
6. The upgrade fi les will have a .bin file extension and there may also be a
readme.txt file.
ch for the firmware version for your instrument.
PRISM MPI2-10 and MPX2-10 Field Upgrade Kit Instructions21
Upgrade the instrument firmware
Firmware
upgrade
procedure
The time requir
ed to complete the upgrade is about 1 5 minutes.
CAUTION. Removing the power from the instrument during the upgrade process
will corrupt the flash memory. If the flash memory is corrupted, the instrument will
have to be sent to a Tektronix factory service center to have the s ystem firmware
restored. DO NOT remove power from the instrument during the upgrade process.
NOTE. If power to the instrument is lost before it begins erasing the internal flash
memory, restart the firmware upgrade after the instrument reboots.
Perform the following steps to upgrade the instrument firmware:
1. Copy the upgrade file with a .bin file extension from the upgrade package
to a USB memory device. You will need approximately 1 GB of available
space on the USB device.
NOTE. If the upgrade package included a readme.txt file, read the file before
rming the upgrade. The file will contain important information about the
perfo
firmware release.
2. Inse
rt the USB memory device into a USB port on the PRISM monitor.
3. On the PRISM monitor, touch the Settings icon to open the Settings menu.
4. Touch Utilities to open the Utilities submenu.
5. Touch Firmware Upgrade. The display will list all of the files on the USB
device with a .bin file extension.
6. Touch the desired file in the list to select it, and then touch Install to start
the upgrade.
Figure 23: Selecting the firmware upgrade fi le
22PRISM MPI2-10 and MPX2-10 Field Upgrade Kit Instructions
Upgrade the instrument firmware
7. While the upgra
de is in process, the message box shown below appears
stating that the firmware installation is in progress.
CAUTION. Removing the USB device or powering off the instrument before the
upgrade is complete can cause upgrade failure. To prevent upgrade failure, wait
until the Installation Complete message box is displayed before performing these
actions. The upgrade may take up to five minutes.
Figure 24: Upgrade Installation In Progress message box
8. Remove the USB device from the PRISM monitor.
Verify the firmware
upgrade
Perform the following procedure to verify the firmware upgrade:
1. Touch
the Settings icon to open the Settings menu.
2. Touch Utilities to open the Utilities submenu.
3. Touch Version to open the Version display.
4. Verify the displayed firmware version matches the firmware version that you
installed.
PRISM MPI2-10 and MPX2-10 Field Upgrade Kit Instructions23
Upgrade the software license
Upgrade the so
Obtain the software license
upgrade
ftware license
Asoftwareli
1. Place your order with a Tektronix sales representative for the upgrade license.
Provide the email address of the person who will be responsible for generating
the license
2. The license key manager will get a n email with instructions on how to access
the licens
NOTE. TekAMS is a free, web based tool for generating license keys.
3. The lice
4. When all authorizations are in place, the license key manager will have access
to the p
cense upgrade is required after the installation of a hardware upgrade.
key. This person will be a license key manager.
e through TekAMS.
nse key manager will be required to create an account on tek.com.
urchased upgrade license that is ready for checkout.
24PRISM MPI2-10 and MPX2-10 Field Upgrade Kit Instructions
Upgrade the software license
Checkout the software
license
To install a sof
tware upgrade license on your PRISM it must be checked out
through TekAMS. Use the following procedure to checkout a license:
1. Go to www.tek.
com/ams through a Web browser.
2. Locate the software upgrade license under the Node Locked License
Inventory t
ab for the PRISM.
3. Click the Checkout to instrument icon next to the license.
4. Find the Model, Serial Number, and Host ID on your instrument and enter
these device identifiers into the required fields.
Model. Located on the instrument label or in the Settings > Utilities >
Options menu (labeled as Nomenclature)
Serial Number. Located on the instrument label or in the Settings >
Utilities > Version menu
Host ID. LocatedintheSettings > Utilities > Options menu
5. Click the Lookup Unit button.
NOTE. If your instrument is not found in the asset library, you will be asked for
the location of the instrument and an (optional) Asset Number. Select a Site from
op down list, or click the + icon to add a new site. Click Add Asset when
the dr
finished. If the instrument you entered shares a Host ID with an incompatible
instrument, you may receive an error. Follow the instructions in the License
Checkout Error section to correct the asset details and begin the checkout process
again.
6. Provide any end-user information and select Generate License (optional).
NOTE. If the person checking out the license is not the end user of the license, the
end user information c an be provided here.
7. Download the license file to your PC.
8. Use the license file to install the software upgrade license on your PRISM.
PRISM MPI2-10 and MPX2-10 Field Upgrade Kit Instructions25
Upgrade the software license
License checkout error
Entering incor
rect device identifiers when checking out software licenses on
TekAMS will result in the following error message:
Requested opt
ion is not compatible with the indicated product/software
platform
This error w
ill prevent you from obtaining software licenses for your instrument
until the identifiers are fixed.
Prevention. To prevent entering incorrect identifiers, use the Settings > Utilities
> Options menu on your PRISM to verify the Model and Host ID. The model
number is called Nomenclature on your PRISM.
Figure 25: Example Host ID and Nomenclature (Model) on a PRISM MPI2-10
Troubleshooting.
To fix the device identifiers use the following steps:
1. Select the Asset tab from the top navigation bar.
2. Find the instrument with the error in the Asset Data table.
3. Cli
ck the Edit Asset icon.
4. Fix the Model under the Asset Details tab and click the Save button when
ished.
fin
5. Return to the Software Licenses tab in the top navigation bar.
6. Select the Node Locked License Inventory tab and confirm that the error
message has been removed.
26PRISM MPI2-10 and MPX2-10 Field Upgrade Kit Instructions
Upgrade the software license
Install the software license
upgrade
Perform the fol
lowing procedure to install the software license upgrade:
1. On the PRISM monitor, open the Settings > Network menu page to view the
Control IP Por
t address of the instrument which you are going to upgrade.
2. Copy the software license upgrade file you downloaded to a location on the
computer.
3. On your computer, enter the following in the URL box of your Web browser,
where xxx.x
xx.xxx.xxx is the IP address of the Control IP Port of the
instrument you are upgrading. The IP address is case sensitive.
http://xx
x.xxx.xxx.xxx:9000/licensePortal.html
4. This opens the Tektronix PRISM License Installation Web page as shown
below. Th
e Web page shows the Host ID (a string that uniquely identifies the
instrument) and the instrument serial number.
Fi
PRISM MPI2-10 and MPX2-10 Field Upgrade Kit Instructions27
gure 26: PRISM License Installation Web page – initial view
Upgrade the software license
5. Click the Brows
e... button, and then navigate to the location of the software
license file.
6. Select the sof
tware license file and click Open.
7. The license installation Web page displays the new license information
in the Revie
w license information box. The example below shows an
instrument that is being upgraded with two software options: MP-IP-STD
and MP-IP-MEAS.
Figure 27: PRISM License Installation Web page – license upgrade information
review
8. If the license information is correct, click Install to start the license
installation.
28PRISM MPI2-10 and MPX2-10 Field Upgrade Kit Instructions
Upgrade the software license
9. When the licens
e(s) is installed, the bottom of the license installation Web
page displays a message that the license was installed successfully.
10. After the upgrade is installed, close the PRISM License Installation Web page.
Perform the following procedure to verify the software license upgrade:
1. Touc
htheSettings icon to open the Settings menu.
2. Touch Utilities to open the Utilities submenu.
3. Touch Options to open the Options display.
4. Verify that the displayed option(s) match the option(s) you installed.
PRISM MPI2-10 and MPX2-10 Field Upgrade Kit Instructions29
Verify the hardware upgrade
Verify the har
dware upgrade
Table 3: Requ
Test equipme
Video test signal generatorHD 1080 59.94i
75 Ω coaxial
Computer m
(for use with MPX)
Mouse w ith USB interface
(for use with MPX)
1. Apply power to the instrument.
2. MPX only: Connect the external display.
3. Connect the TG8000 SDI7 module output to the SDI 1 IN input on the
PRISM monitor.
ired equipment
nt
cables
onitor and cable
Requirement
■ 100% color b
RG-6 type co
male 75 Ω BNC connectors,
1 to 2 m long, suitable for
use to 6000
Any standard 1080-capable
monitor wi
connector and cable.
Any standard USB computer
mouse
s
ars
axial cable with
MHz.
th Display Port
Example
Tektronix TG
SDI7 module
1694A. Tektronix part
number 012-
8000 with
0159-01.
4. Set the SDI7 module to HD 1080 59.94i format using the following steps:
a. On the TG8000, push the front-panel MODULE button until the
SDI7 module main menu appears.
b. Push the down (▼) arrow button to access the output mode menu.
c. Use the left (◄)orright(►) arrow button to scroll through the available
output modes.
d. Select the HD output and push the ENTER button.
NOTE. The dot will appear in front of the output mode on the display, to
indicate that it is now the selected output mode.
e. To select the signal format, push the FORMAT button.
f.Use the left (◄)orright(►) arrow button, or push the FORMAT button
repeatedly, to select the 1080 59.94i signal format.
30PRISM MPI2-10 and MPX2-10 Field Upgrade Kit Instructions
Verify the hardware upgrade
g. Push the ENTER b
uttontoconfirm the selection.
NOTE. The dot will appear at the left of the second line to indicate that the
format was selected.
h. Push the BACK button to exit FORMAT mode.
5. Select the 1
00% Color Bars signal using the following steps:
a. On the TG8000, push the front-panel BARS test signal button.
b. Use the left (◄)orright(►) arrow button, or push the BARS test signal
button repeatedly to select 100% Color Bars.
NOTE. 100
% Color Bars is the factory default signal.
6. Configure the SDI input using the following steps:
a. Touch t he Settings icon (
) to open the Settings menu.
b. Select Inputs to open the Inputs submenu.
PRISM MPI2-10 and MPX2-10 Field Upgrade Kit Instructions31
Figure 29: Settings menu
Verify the hardware upgrade
c. Select an SDI in
put.
NOTE. In the following figure there are six virtual inputs to choose from.
Inputs can be given any meaningful name.
Figure 30
d. Select o
: Settings inputs submenu
ne of the four physical SDI inputs to monitor. The TG8000
SDI7 module output is connected to the SDI 1 input.
7. Double-tap any tile to display it full screen.
8. Press and hold a nywhere on screen to display the application banner. Select
32PRISM MPI2-10 and MPX2-10 Field Upgrade Kit Instructions
ure 31: SDI signal configuration
Fig
lect Save and close the menu.
e. Se
Eye Pattern Display from the drop-down list.
Verify the hardware upgrade
9. Press and hold a
nywhere on screen to display the application banner. Touch
the Tool icon and select Align from the Jitter HP Filter drop-down list.
10. Check for a sta
ble eye diagram. Eye Amplitude and the actual wave shape
depend on the generator signal. Eye Amplitude is typically 720 mV to
880 mV. Eye Risetime and Eye Falltime are typically 500 ps to 1500 ps.
Figure 32: Eye diagram example
PRISM MPI2-10 and MPX2-10 Field Upgrade Kit Instructions33
Loading...
+ hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
