Tektronix PRISM User Manual

Download

PRISM

ZZZ

MediaAnalysisPlatform

User Manual

*P077129003*

077-1290-03

PRISM

ZZZ

Media Analysis Platform

User Manual

Revision A

This document supports software version 1.5 and above.

www.tek.com

077-1290-03

Copyright © Tektronix. All rights reserved. Licensed software products are owned by Tektronix or its subsidiaries or suppliers, and are protected by national copyright laws and international treaty provisions.

Tektronix products are c overed by U.S. and foreign patents, issued and pending. Information in this publication supersedes that in all previously published material. Speciﬁcations and price change privileges reserved.

TEKTRONIX and TEK are registered trademarks of Tektronix, Inc.

FlexVu is a registered trademark of Tektronix, Inc.

Contacting Tektronix

Tektronix, Inc. 14150 SW Karl Braun Drive P.O. Box 50 0 Beaverton, OR 97077 USA

For product information, sales, service, and technical support:

In North America, call 1-800-833-9200. Worldwide, visit www.tek.com to ﬁnd contacts in your area.

Warranty

Tektronix warrants that this product will be free from defects in materials and workmanship for a period of one (1) year from the date of shipment. If any such product proves defective during this warranty period, Tektronix, at its option, either will repair the defective product without charge for parts and labor, or will provide a replacement in exchange for the defective product. Parts, modules and replacement products used by Tektronix for warranty work may be n the property of Tektronix.

ew or reconditioned to like new performance. All replaced parts, modules and products become

In order to o the warranty period and make suitable arrangements for the performance of service. Customer shall be responsible for packaging and shipping the defective product to the service center designated by Tektronix, with shipping charges prepaid. Tektronix shall pay for the return o f the product to Customer if the shipment is to a location within the country in which the Tektronix service center is located. Customer shall be responsible for paying all shipping charges, duties, taxes, and any other charges for products returned to any other locations.

This warranty shall not apply to any defect, failure or damage caused by improper use or improper or inadequate maintenance and care. Tektronix shall not be obligated to furnish service under this warranty a) to repair damage result b) to repair damage resulting from improper use or connection to incompatible equipment; c) to repair any damage or malfunction caused by the use of non-Tektronix supplies; or d) to service a product that has been modiﬁed or integrated with other products when the effect of such modiﬁcation or integration increases the time or difﬁculty of servicing the product.

THIS WARRANTY IS GIVEN BY TEKTRONIX WITH RESPECT TO THE PRODUCT IN LIEU OF ANY OTHER WARRANTIES, EXPRESS OR IMPLIED. TEKTRONIX AND ITS VENDORS DISCLAIM ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.

TRONIX' RESPONSIBILITY TO REPAIR OR REPLACE DEFECTIVE PRODUCTS IS THE SOLE

TEK AND EXCLUSIVE REMEDY PROVIDED TO THE CUSTOMER FOR BREACH OF THIS WARRANTY. TEKTRONIX AND ITS VENDORS WILL NOT BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES IRRESPECTIVE OF WHETHER TEKTRONIX OR THE VENDOR HAS ADVANCE NOTICE OF THE POSSIBILITY OF SUCH DAMAGES.

[W2 – 15AUG04]

btain service under this warranty, Customer must notify Tektronix of the defect before the expiration of

ing from attempts by personnel other than Tektronix representatives to install, repair or service the product;

TEKTRONIX SOFTWARE LICENSE AGREEMENT

THE PROGRAM, OR PROGRAMS, ENCODED OR INCORPORATED WITHIN EQUIPMENT OR ACCOMPANYING THIS AGREEMENT, IS FURNISHED SUBJECT TO THE TERMS AND CONDITIONS OF THIS AGREEMENT. RETENTION OF THE PROGRAM FOR MORE THAN THIRTY DAYS OR USE OF THE PROGRAM IN ANY MANNER WILL BE CONSIDERED ACCEPTANCE OF THE AGREEMENT TERMS. IF THESE TER DOCUMENTATION SHOULD BE RETURNED PROMPTLY TO TEKTRONIX FOR A FULL REFUND OF THE LICENSE FEE PAID. (FOR INFORMATION REGARDING THE RETURN OF PROGRAMS ENCODED OR INCORPORATED WITHIN EQUIPMENT, CONTACT THE NEAREST TEKTRONIX SALES OFFICE.)

DEFINITIONS.

"Tektronix" means Tektronix, Inc., an Oregon corporation, or local Tektronix’ legal entity that is supplying the equipment.

"Program" means the Tektronix software product (executable program and/or data) enclosed with this Agreement or included within the equipment with which this Agreement is packed.

"Customer" means the person or organizationinwhosenametheProgramwasordered.

MS ARE NOT ACCEPTABLE, THE UNUSED PROGRAM AND ANY ACCOMPANYING

LICENS

Customer may:

1. Use the Program on a single machine at any one time; and

2. Copy the Program for archival or backup purposes, provided that no more than one (1) such copy is permitted

Each copy of the Program made by Customer must include a reproduction of any copyright notice or restrictive rights legend appearing in or on the copy of the Program as received from Tektronix.

Customer may not:

1. Use the Program on more than one machine at any one time;

2. Transfer the Program to any person or organization outside of Customer or the corporation of which Customer

3. Export or re-export, directly or indirectly, the program, any associated documentation, or the direct product

4. Modify the Program, create derivative works, or merge the Program with another program;

to exist at any one time.

is a part without the prior written consent of Tektronix, except in connection with the transfer of the equipment within which the programs are encoded or incorporated;

thereof, to any country to which such export or re-export is restricted by law or regulation of the United States or any foreign government having jurisdiction without the prior authorization, if required, of the Ofﬁce of Export Administration, Department of Commerce, Washington, D.C. and the corresponding agency of such foreign government;

5. Reverse compile or disassemble the Program for any purpose, beyond the extent that such activity is expressly permitted by applicable open source licenses or applicable law notwithstanding this limitation; or

6. Copy the documentation accompanying the Program.

For Programs designed to reside on a single-machine and support one or more additional machines, either locally or remotely, without permitting the Program to be transferred to an additional machine for local execution, the additional ma Program to be transferred t o an additional machine for local execution, a separ ate license shall be required for each such machine with which the Program may be used.

Title to the Program and all copies thereof, but not the media on which the Program or copies may reside, shall be and remain with Tektronix or others for whom Tektronix has obtained a respective licensing right.

Customer shall pay when due all property taxes that may now or hereafter be imposed, levied or assessed with respect to the possession or use of the Program or this license and shall ﬁle all reports required in connection with such taxes.

If the Program or any related documentation is acquired by or for an agency of the U.S. Government, the Program and documentation shall be considered “commercial computer s oftware” or “commercial computer software documentation” respectively, as those terms are used in 48 CFR §12.212, 48 CFR §227.7202, or 48 CFR §252.227-7014, and are licensed with only those rights as are granted to all other licensees as set forth in this Agreement.

THE PROGRAM MAY NOT BE USED, COPIED, MODIFIED, MERGED, OR TRANSFERRED TO ANOTHER EXCEPT AS EXPRESSLY PERMITTED BY THESE TERMS AND CONDITIONS. UPON TRANSFER OF ANY COPY, MODIFICATION, OR MERGED PORTION OF THE PROGRAM, THE LICENSE GRANTED HEREIN IS AUTOMATICALLY TERMINATED WITH RESPECT TO THE PARTY THAT TRANSFERS THE PROGRAM.

TERM.

chines shall be considered within the deﬁnition of "single machine." For programs permitting the

The license granted herein is effective upon acceptance by Customer, and shall remain in effect until terminated as provided herein. The license may be terminated by Customer at any time upon written notice to Tektronix. The license may be terminated by Tektronix or any third party from whom Tektronix may have obtained a respective licensing right if Customer fails to comply with any term or condition and such failure is not remedied within thirty (30) days after notic return to Tektronix or destroy, the Program and all associated documentation, together with all copies in any form.

LIMITED WARRANTY.

The Program is provided "as is" without warranty of any kind, either express or implied. Tektronix does not warrant that the functions contained in the Program will meet Customer's requirements or that the operation of the Program will be uninterrupted or error-free.

TEKTRONIX AND ITS VENDORS DISC L AIM ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.

LIMITATION OF LIABILITY, IN NO EVENT SHALL TEKTRONIX OR OTHERS FROM WHOM TEKTRONIX HAS OBTAINED A LICENSING RIGHT BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES ARISING OUT OF OR CONNECTED WITH CUSTOMER'S POSSESSION OR USE OF THE PROGRAM, EVEN IF TEKTRONIX OR SUCH OTHERS HAS ADVANCE NOTICE OF THE POSSIBILITY OF SUCH DAMAGES.

THIRD-PARTY DISCLAIMER.

Except as expressly agreed otherwise, third parties from whom Tektronix may have obtained a licensing right do not warrant the program, do not assume any liability with respect to its use, and do not undertake to furnish any support or information relating thereto.

e hereof from Tektronix or such third party. Upon termination by either party, Customer shall

GENERAL.

This Agreement contains the entire agreement between the parties with respect to the use, reproduction, and transfer of the Program. Neither this Agreement nor the license granted herein is assignable or transferable by Customer without the prior written consent of Tektronix.

This Agreement and the license granted herein shall be governed by the laws of the state of Oregon.

All questions regarding this Agreement or the license granted herein should be directed to the nearest Tektronix Sales Ofﬁce.

Table of Contents

Important safety information ............. ................................ .................................. ..... viii

General safety summary .................................................................................... viii

Service safety summary ........................ .................................. ............................. x

Terms in this manual ..................... ................................ ................................ .... xi

Symbols and terms on the product.......................................................................... xi

Preface ............................................................................................................. xiii

Where to ﬁnd more information......................... ................................ ................... xiii

Conventions used in this manual...................................... ................................ ..... xiv

Getting started..... . ..... . ..... . ..... . ..... . ..... . ... . . . .... . . .... . ..... . ..... . ..... . ..... . ..... . ..... . ..... . ..... . .. 1

Product description ..................... ................................ .................................. ..... 1

Rackmount installation................................... ................................ ..................... 5

MPI power-on and power-off procedures............ ................................ ...................... 12

MPX power-on and power-off procedures................................................................. 16

SFP+ module installation .................................................................................... 18

Network installation.......................................................................................... 20

MPI rear panel connectors......... .................................. ................................ ........ 22

MPX rear panel connectors.................... ................................ .............................. 25

Display elements.............................................................................................. 27

Diagnostics report ............................................................................................ 28

Message Center ............... ................................ .................................. .............. 29

Methods of operation.............................................................................................. 31

MPI touchscreen operation .................................................................................. 31

MPX front panel controls ................................................................................... 33

Keyboard and mouse operation ....................... ................................ ...................... 35

External touchscreen display operation .................................................................... 36

Remote control via VNC operation................................. ................................ ........ 36

Remote control via API commands..................... .................................. .................. 39

How to conﬁgure the instrument........................................... ................................ ...... 40

How to conﬁgure and select signal inputs ................................................................. 40

How to conﬁgure the instrument for HDR / WCG monitoring.................. ........................ 53

How to conﬁgure PTP reference settings .... . ..... . ... . . ..... . ..... . .... . . .... . ..... . ..... . .... . ..... . .... 56

How to set and recall instrument presets ............... ................................ .................... 58

How to manage tile display . ..... . ..... . ..... . ..... ..... . ..... . ..... . ..... . ..... . .... . . .... . ..... . ..... . ..... 66

How to set the time and date .......... .................................. ................................ .... 69

How to upgrade the instrument ﬁrmware ............ .................................. .................... 71

How to upgrade the software license....................................................................... 74

How to verify the installed software and hardware versions............................................. 80

Functions ........................................................................................................... 81

Headphone/speaker volume and source adjustment .................... ................................ .. 81

PRISM Media Analysis Platform User Manual i

Table of Contents

Capture..................................... ................................ ................................ .... 82

Application information .......................................................................................... 85

Waveform display application .............................................................................. 88

Stop Display application .................................................................................... 91

Vector application ............................................................................................ 94

Diamond display application ......................................... ................................ ...... 96

Eye Display

Jitter Display application ..... . .... . . ..... . .... . . ..... . .... . . ..... . .... . . ..... . .... . . ..... . .... . . ..... . .... 103

Picture application ............... ................................ .................................. ........ 106

Audio application ................. ................................ ................................ .......... 107

Video Session application ............... ................................ .................................. 110

Event Log application ........... .................................. ................................ ........ 116

Timing a

IP Status application ............. ................................ ................................ .......... 122

IP Session application ........... ................................ ................................ .......... 126

IP Graphs application ...................................................................................... 138

PIT Histogram application..... ................................ ................................ ............ 144

PTP graphs application............... .................................. ................................ .... 146

perational overview ...................................................................................... 150

PTP o

PTP introduction............................................................................................ 150

The ﬁve basic PTP timing messages...................................................................... 151

Proﬁles and domains ....................................................................................... 153

One-step and two-step operation.......................................................................... 153

Multicast, Unicast, and Mixed Communication modes . . ..... ..... . . .... . . .... . . ..... . ..... . ..... . .... 154

CA operation............................................................................................ 156

Compensating for causes of asymmetric delay ........................ ................................ .. 156

Index

application ......... .................................. ................................ ........ 100

pplication.......................................................................................... 119

ii PRISM Media Analysis Platform User Manual

List of Figures

Figure 1: Installing one MPI monitor and one WFM52x0 waveform monitor in the MPI-RACK-MW dual

rack cabinet..................................................................................................... 8

Figure 2: Installing one MPI monitor and one WFM7200 or WFM8x00 waveform monitor in the

MPI-RACK-MW dual rack cabinet............................. ................................ ............. 9

Figure 3: Installing two MPI monitors in the MPI-RACK-MM dual rack cabinet..... . ..... . .... . ..... . .. 10

Figure 4: Connecting the rack cabinet USB and audio cables to the MPI monitor ........................ 11

Figure 5: Connecting power to the MPI monitor .............................................................. 13

Figure 6: Disconnecting the power cord from the MPI monitor ........... ................................ .. 14

Figure 7: MPI Power/Standby button ......................... ................................ .................. 15

Figure 8: Connecting power to the MPX monitor ................... ................................ .......... 16

Figure 9: MPX Power/Standby button.......................................................................... 17

Figure 10: Installing and removing an optical SFP+ module on an MPI monitor. . ..... . ..... . ..... . ..... . 18

Figure 11: Installing and removing an optical SFP+ module on an MPX monitor. . ..... . ... . . ..... . ..... . 19

Figure 12: Connecting the instrument to a PC (MPI monitor shown)................. ...................... 20

Figure 13: Setting network parameters . .... . . .... . ..... . ..... . ..... . ..... . ..... ..... . ..... . ..... . ..... . ..... . .. 21

Figure 14: PRISM MPI rear panel....................... .................................. ...................... 22

Figure 15: PRISM MPX rear panel ... .................................. ................................ ........ 25

Figure 16: Elements of the display (MPI monitor shown).................................................... 27

Figure 17: Messages icon with one message ......... ................................ .......................... 29

Figure 18: Message Center popup window..................................................................... 29

Figure 19: Four-tile display with menu selection . . ..... . ..... . ..... . ..... . ... . . . .... . ..... . ..... . ..... . ..... . . 31

Figure 20: Selecting an application to display ................................................................. 32

Figure 21: MPX front panel controls............................................................................ 33

Figure 22: API documentation web page ....................................................................... 39

Figure 23: Settings menu . . ..... . ..... . ..... . .... . ..... . ..... . ... . . . .... . ..... . ..... . ... . . ..... . ..... . ... . . . .... . . 41

Figure 24: Settings inputs submenu ... . . ..... . ..... . ... . . . .... . ..... . ..... . ... . . ..... . ..... . ... . . . .... . ..... . ... 41

Figure 25: Single SDI signal conﬁguration............. .................................. ...................... 42

Figure 26: Quad Link SDI signal conﬁguration................................................................ 43

Figure 27: SDI signal settings... . ..... . ..... . ..... . .... . . .... . ..... . ..... . ..... . ..... . ..... . .... . ..... . ..... . .... 46

Figure 28: Renaming a signal input ............................................................................. 47

Figure 29: IP input protocols and ST2022-7 seamless switching ........ .................................. .. 48

Figure 30: Editing parameter ﬁelds.............................. .................................. .............. 49

Figure 31: Conﬁgure ASPEN stream ... . . ..... . ..... . ..... . ..... . ..... . ..... . ..... . ..... . ..... . ..... . ..... . .... 50

Figure 32: IP signal settings.. . ..... . ..... ..... . ..... . ..... . ..... . ..... . ... . . . .... . ..... . ..... . ..... . ..... . ..... .. 52

Figure 33: List of the conﬁgured inputs... ................................ ................................ ...... 52

Figure 34: Waveform display with nits scale................................................................... 53

Figure 35: Stop Display with Stop scale .......................... ................................ .............. 54

Figure 36: Vector display with (right) and without (left) 3D LUT enabled, 100% color bar in

PQ/BT.2020 ................................................................................................... 55

PRISM Media Analysis Platform User Manual iii

Table of Contents

Figure 37: Edit

Figure 38: Editing the PTP domain setting . . ..... . ..... . ... . . ..... . ..... . ..... . ..... . ... . . . .... . ..... . ..... . ... 57

Figure 39: Preset selection controls (Group B shown) .......... .................................. ............ 59

Figure 40: Assigning a preset.. .................................. ................................ ................ 60

Figure 41: Presets Rename submenu............................................................................ 61

Figure 42: Editing a Preset name . ..... . ... . . ..... . ..... . ..... . ... . . . .... . ..... . ..... . ..... . ..... ..... . ..... . .... 62

Figure 43: Preset selection controls (Group B shown) .......... .................................. ............ 63

Figure 44: Presets Rename submenu............................................................................ 64

Figure 45: Four quarter screen tiles . . ..... . ..... . ..... . ..... . ..... . ..... . ..... . ... . . ..... . ..... . ..... . ..... . .... 66

Figure 46: One half screen tile and two quarter screen tiles .... . ..... . ..... ..... . ..... . ..... . .... . ..... . ..... 67

Figure 47: Two half screen tiles showing vector and waveform displays. .... . ..... . ..... . ..... . ... . . ..... . 67

Figure 48: Full screen tile . ..... . ..... . ... . . ..... . ..... . ..... . ..... . .... . . .... . ..... . ..... . ..... . ..... . ..... . .... . 68

Figure 49: Time Zone submenu.................................................................................. 69

Figure 50: Time and Date submenu ............................................................................. 70

Figure 51: Time and date change reboot message ....................... ................................ ...... 70

Figure 52: Selecting the ﬁrmware upgrade ﬁle................................................................. 72

Figure 53: Upgrade Installation In Process message box..................................................... 73

Figure 54: Upgrade Installation Complete message box.......... ................................ ............ 73

Figure 55: PRISM License Installation Web page – initial view.. . . . .... . . .... . . .... . . .... . ..... . ..... . ..... 76

Figure 56: PRISM License Installation Web page – license upgrade information review ................ 77

Figure 57: PRISM License Installation Web page – license install message ................. .............. 78

Figure 58: Verifying the software license upgrade ............................................................ 79

Figure 59: Utilities Version submenu . ..... . ..... . ... . . . .... . ..... . ..... . ..... . ..... ..... . ..... . ..... . ..... . ... . 80

Figure 60: Volume control........................................................................................ 81

Figure 61: Selecting Screenshot ......... .................................. ................................ ...... 82

Figure 62: Application bar Capture ........... ................................ ................................ .. 83

Figure 63: Selecting Screenshot and Stream ................................................................... 83

Figure 64: Stream Size settings . . .... . . .... . ..... . ..... . ..... . ..... . ..... . ..... . ..... . ..... . ..... . ..... . ..... . ... 84

Figure 65: Stream capture icon with percentage shown..................................... .................. 84

Figure 66: Waveform display application ...................................................................... 88

Figure 67: Waveform application banner............. ................................ .......................... 88

Figure 68: Waveform application settings menu... . ..... . ... . . ..... . ..... . ..... . ..... . ..... . ..... . ..... . ..... . 89

Figure 69: Stop Display application..................... ................................ ........................ 91

Figure 70: Stop Display application banner.................................................................... 91

Figure 71: Stop Display application settings menu .... . . .... . . .... . ..... . ..... . ..... . ..... . ..... . ..... . ..... . . 92

Figure 72: Vector application display ........................................................................... 94

Figure 73: Vector application banner............................................................................ 94

Figure 74: Vector application settings menu ................................................................... 95

Figure 75: Diamond display application ........................................................................ 96

Figure 76: Diamond application banner ........................................................................ 96

Figure 77: Diamond application settings menu . ..... . ..... . ..... . ..... ..... . ..... . ..... . ..... . ..... . ... . . . .... 97

ing PTP reference settings............ ................................ .......................... 56

iv PRISM Media Analysis Platform User Manual

Table of Contents

Figure 78: Diam

Figure 79: Out-of-gamut examples.................................... ................................ .......... 99

Figure 80: Eye Display application display .................... ................................ .............. 100

Figure 81: Eye Display application banner............................. ................................ ...... 100

Figure 82: Eye Display application settings menu. . ..... . ..... . ..... ..... . ..... . ..... . ..... . .... . . .... . ..... 101

Figure 83: Jitter Display application display .... . ..... . .... . . .... . ..... . ... . . ..... . ..... . .... . ..... . ..... . ... 103

Figure 84: Jitter Display application banner... . . . .... . ..... . ..... . .... . ..... . ..... . ... . . ..... . ..... . ..... .... 103

Figure 85: Jitter Display application settings menu . . ..... . ..... . .... . ..... . ..... . ..... . .... . . .... . ..... . ... 104

www.bigbuckbunny.org) ................................................................................... 106

Figure 87: Picture application banner........... .................................. ............................ 106

Figure 88: Audio application display ......................................................................... 107

Figure 89: Audio application banner.......................................................................... 107

Figure 90: Video Session application – SDI FORMAT tab display ....................... ................ 110

Figure 91: Video Session application banner....................................... .......................... 110

Figure 92: Video Session application – VPID 352 tab display for 3G-SDI Level B signal . .... . ..... . . 112

Figure 93: Video Session application – BIT LEVEL tab display ...... ................................ .... 113

Figure 94: Video Session application – CRC STATUS tab display.............. .......................... 114

Figure 95: Event Log application display ...... ................................ .............................. 116

Figure 96: Event Log application banner............... ................................ ...................... 116

Figure 97: Event application Go to Bottom icon ............................................................ 117

Figure 98: Event application slider control ............................. .................................. .... 117

Figure 99: Timing application display ........ ................................ ................................ 119

Figure 100: Timing application banner ......... ................................ .............................. 119

Figure

Figure 102: IP Status application banner ... ................................ .................................. 122

Figure 103: IP Status port settings. . ... . . ..... . ..... . .... . . .... . ..... . ..... . ..... ..... . ..... . ..... . .... . . .... . . 123

Figure 104: IP Status application with yellow and green gradients.................. ...................... 124

Figure 105: IP Session application display................................................................... 126

Figure 106: IP Session application banner ......... .................................. ........................ 126

Figure 107: IP Session application – Layer 1/2 tab display ........ ................................ ........ 128

Figure 108: IP Session application – VIDEO tab display................................... ................ 130

Figure 109: IP Session application – PTP tab display....................................................... 134

Figure 110: IP Graphs application banner .................................................................... 138

Figure 111: IP Graphs application settings menu................ ................................ ............ 139

Figure 112: IP Graphs application display............................ ................................ ........ 140

Figure 113: IP Graphs application – PIT and RTP Sequence Error graphs ............................... 141

Figure 114: IP Graphs application – Video CRC Error and TS-DF graphs ............................... 142

Figure 115: IP Graphs application – Path1–Path2 Differential graph ..................................... 143

Figure 116: Seamless protection switc

Figure 117: PIT Histogram application display .................. .................................. .......... 144

101: IP Status application display..................................................................... 122

ond display plot ........ ................................ .................................. ...... 98

hing of SMPTE ST-2022-7 IP stream ........ .................... 143

PRISM Media Analysis Platform User Manual v

Table of Contents

Figure 118: PIT

Figure 119: PTP Graphs application banner.................................................................. 146

Figure 120: PTP Graphs application settings menu ......................................................... 147

Figure 121: PTP Master-Slave Delay and Variation graphs .................... ............................ 147

Histogram application banner .............................................................. 144

vi PRISM Media Analysis Platform User Manual

List of Tables

Table i: Product documentation................................................................................. xiii

Table 1 : Cle

Table 2: Supplied hardware ....................................................................................... 6

Table 3: Keyboard controls for selecting SDI inputs and instrument presets............................... 35

Table 4: Instrument settings that are reset by recalling the Factory preset . ..... ..... . ..... . ..... . ..... . .... 64

arance requirements for the dual rack cabinet ............. ................................ ....... 5

Table of Contents

PRISM Media Analysis Platform User Manual vii

Important safety information

Important saf

ety information

This manual c for safe operation and to keep the product in a safe condition.

To safely pe the end of this section. (See page x, Service safety summary.)

General safety summary

Use the product only as speciﬁed. Review the following safety precautions to avoid injury and prevent damage to this product or any products connected to it. Carefully read all instructions. Retain these instructions for future reference.

Comply with local and national safety codes.

For correct and safe operation of the product, it is essential that you follow generally accepted safety procedures in addition to the safety precautions speciﬁed in this manual.

The product is designed to be used by trained personnel only.

Only qualiﬁed personnel who are aware of the hazards involved should remove the cover for repair, maintenance, or adjustment.

ontains information and warnings that must be followed by the user

rform service on this product, additional information i s provided at

Before use, always check the product with a known source to be sure it is operating correctly.

This product is not intended for detection of hazardous voltages.

le using this product, you may need to access other parts of a larger system.

Whi Read the safety sections of the other component manuals for warnings and cautions related to operating the system.

When incorporating this equipment into a system, the safety of that system is the responsibility of the assembler of the system.

viii PRISM Media Analysis Platform User Manual

Important safety information

To avoid ﬁre or

personal

injury

Use proper powe

certiﬁed for the country of use.

Do not use the provided power cord for other products.

Power disconnect. The power cord disconnects the product from the power source. See instructions for the location. Do not position the equipment so that it is difﬁcult to operate the power cord; it must remain accessible to the user at all times to allow for quick disconnection if needed.

Use proper AC adapter. Use only the AC adapter speciﬁed for this product.

Observe all terminal ratings. To avoid ﬁre or shock hazard, observe all ratings

and markings on the product. Consult the product manual for further ratings information before making connections to the product.

Do not apply a potential to any terminal, including the common terminal, that exceeds the maximum rating of that terminal.

The measuring terminals on this product are not rated for connection to mains or Category II, III, or IV circuits.

Do not operate without covers. Do not operate this product with covers or panels removed, or with the case open. Hazardous voltage exposure is possible.

r cord. Use only the power cord speciﬁed for this product and

Avoid exposed circuitry. Do not touch exposed connections and components

when power is present.

Do not operate with suspected failures. If you suspect that there is damage to this product, have it inspected by qualiﬁed service personnel.

Disable the product if it is damaged. Do not use the product if it is d amaged or operates incorrectly. If in doubt about safety of the product, turn it off and disconnect the power cord. Clearly mark the product to prevent its further operation.

Before use, inspect voltage probes, test leads, and accessories for mechanical damage and replace when damaged. Do not use probes or test leads if they are damaged, if there is exposed metal, or if a wear indicator shows.

Examine the exterior of the product before you use it. Look for cracks or missing pieces.

Use only speciﬁed replacement parts.

Do not operate in wet/damp conditions. Be aware that condensation may occur if a unit is moved from a cold to a warm environment.

Do not operate in an explosive atmosphere.

Keep product surfaces clean and dry. Remove the input signals before you clean

the p roduct.

PRISM Media Analysis Platform User Manual ix

Important safety information

Provide proper

details on installing the product so it has proper ventilation.

Slots and open otherwise obstructed. Do not push objects into any of the openings.

Provide a safe working environment. Always place the product in a location convenient for viewing the display and indicators.

Avoid improper or prolonged use of keyboards, pointers, and button pads.

Be sure your work area meets applicable ergonomic standards. Consult with an ergonomics professional to avoid stress injuries.

Use only the Tektronix rackmount hardware speciﬁed for this product.

Servicesafetysummary

The Service safety summary section contains additional information required to safely perform service on the product. Only qualiﬁed personnel should perform service procedures. Read this Service safety summary and the General safety summary before performing any service procedures.

ventilation. Refer to the installation instructions in the manual for

ings are provided for ventilation and should never be covered or

To avoid electric shock. Do not touch exposed connections.

Do not service alone. Do not perform internal service or adjustments of this

product unless another person capable of rendering ﬁrst aid and resuscitation is present.

Disconnect power. To avoid electric shock, switch off the product power and disconnect the power cord from the mains power before removing any covers or panels, or opening the case for servicing.

Use care when servicing with power on. Dangerous voltages or currents may exist

n this product. Disconnect power, remove battery (if applicable), and disconnect

i test leads before removing protective panels, soldering, or replacing components.

Verify safety after repair. Always recheck ground continuity and mains dielectric strength after performing a repair.

x PRISM Media Analysis Platform User Manual

Terms in this manual

These terms may appear in this manual:

WAR NI NG . Warning statements identify conditions or practices that could result

in injury or loss of life.

CAUTION. Caution statements identify conditions or practices that could result in

damage to this product or other property.

Symbols and terms on the product

Important safety information

These ter

The following symbol(s) may appear on the product:

ms may appear on the product:

DANGER indicates an injury hazard immediately accessible as you read the mark

WARNING indicates an injury hazard not immediately accessible as you read th

CAUTION indicates a hazard to property including the product.

ing.

emarking.

When this symbol is marked on the product, be sure to consult the manual to ﬁnd out the nature of the potential hazards and any actions which have to be taken to avoid them. (This symbol may also be used to refer the user to ratings in the manual.)

PRISM Media Analysis Platform User Manual xi

Important safety information

xii PRISM Media Analysis Platform User Manual

Preface

This manual c Analysis Platform. This information includes the following:

How to opera mouse/keyboard/display, or remote connection.

How to use t

How to capture display data.

How to set up error logging and alarms.

How to navigate instrument menus.

Where to ﬁnd more information

The following table shows you where you can ﬁnd information about your product. You can always ﬁnd the most updated documentation and software for your product on the Tektronix Web site at www.tek.com/downloads.

i: Product documentation

Table

Tektronix part

Document

Installation and Safety

ructions

Inst

User Manual 077-1290-XX

ciﬁcations and

Spe Performance Veriﬁcation

lease Notes

Dual Rack Cabinet

nstallation Instructions

Field Upgrade Kit

nstructions

number Description Print Web

071-3500-XX Describes how to install the instrument and provides

077-1291-XX

7-1293-XX

071-3501-XX Describes how to install the instrument in a 19”

075-1095-XX

ontains information to help you use the Tektronix PRISM Media

te the instrument using the front panel, external

he various displays for monitoring SDI or IP video signals.

ability

Avail

basic safety and operating information

vides detailed operating information

Pro

ts the product speciﬁcations and provides

Lis procedures for verifying product performance

Describes the new features, improvements, and limitations of the instrument ﬁrmware

equipment rack using the optional MPI-RACK-MM

r MPI-RACK-MW dual rack cabinet

escribes how to install post-purchase ﬁeld

D upgrades in the instrument

√√

√ √

√

√√

PRISM Media Analysis Platform User Manual xiii

Preface

Conventions u

sedinthismanual

The PRISM Media Analysis Platform is also referred to as the “PRISM monitor” throughout this manual.

The terms "press and hold" are used throughout this document and applies to the touchscreen on the MPI or MPX instrument. If you are using a mouse and keyboard wi

th the instrument you must click and hold the mouse buttons.

xiv PRISM Media Analysis Platform User Manual

Getting started

Product description

This section will help you set up and begin to use the PRISM Media Analysis Platform. It is divided into the following subsections:

Product description describes your instrument and provides a list of key features.

Controls and connectors shows you how to verify that you have received all of the parts of your instrument and provides a list of standard and optional accessori

Network installation shows you how to set up your instrument on an Ethernet

es and a list of options that are available for your instrument.

network.

The PRIS ﬁeld-installable upgrades to monitor a diverse variety of IP statistics as well as video and audio content. The comprehensive feature set, with an intuitive and simpliﬁed graphical presentation of IP statistics, including video quality and diagnostic information, enables engineers to ensure the delivery of superior Quality of Service (QoS) levels in an increasingly complex broadcast environment invo paths.

PRIS including master control rooms, production studios, OB vans, and signal contribution/distribution centers.

M Media Analysis Platform provides ﬂexible options and

lving compressed / uncompressed video transmission through SDI/IP signal

M is an ideal solution for monitoring SDI/IP hybrid environments

PRISM Media Analysis Platform User Manual 1

Getting s tarted

PRISM model form factors

The PRISM Media

MPI. The PRISM MPI is 3RU half rack with integrated 9 inch HD display and touch pane

Analysis Platform is available in two form factors:

MPX. The PRISM MPX is 1RU full rack width. The MPX requires an

al monitor.

extern

2 PRISM Media Analysis Platform User Manual

Getting started

Features and beneﬁts for

analysis of hybrid IP/SDI

infrastructures

A comprehensiv systems that provides system evaluation for long term system quality monitoring and reporting

Real time IP/SDI analysis and monitoring to quickly identify the issue to determine the root cause

Graphical displays that show the trafﬁc present in the 10G Ethernet link, allowing engineers to understand what is on their network and to easily select the stream

Select a stream to v iew and monitor the content using the Picture, Waveform, and Audio a monitoring

Detect IP stamped delay factor (TS-DF) to allow engineers to observe issues that may cause intermittent loss of Video, Audio or Data

Analysis tools coupled with historical data give engineers the ability to understand and resolve complex and intermittent problems quickly

Monitor PTP trend graphs to ensure proper IP system setup for robust sync system

Tektronix patented Timing display showing the relative timing of the input signal and PTP reference that makes facility timing easy

e analysis and monitoring tool for a hybrid IP/SDI broadcast

of interest

pplications, and listen to audio with headphones for conformance

packet errors, monitor the packet inter arrival time (PIT) and time

1 PPS output when the instrument is locked to a PTP reference

ultaneous two paths monitoring to ensure proper SMPTE 2022-7

Sim redundant system operation

I to control PRISM from system management software

Multipoint or remote site monitoring allowing one engineer to quickly

espond to issues from multiple points in the system

Build an extensive monitoring solution with the SDI signal decoded from

MPTE 2022-6 streams reconstructe d from streams compliant to SMPTE

S 2022-7

10GE line rate packet capture for ofﬂine analysis

The Picture application provides a full H D 9-inch screen that can be used for conﬁdence monitoring

All-in-one instrument using a 3RU half-rack platform (MPI) or a 1RU full-rack platform (MPX) that can be used for either portable or rackmount applications

PRISM Media Analysis Platform User Manual 3

Getting s tarted

Features and beneﬁts

for production tools supporting 4K/UHD, WCG and HDR content creation

A comprehensiv creation

SDI / IP hybrid format support with 12G-SDI / Q uad 3G-SDI interface, and up to 1080p60 format with SMPTE 2022-6/7

Integrated 9-inch 1920×1080 display

Stop displa in a consistent manner

Vect or d i s match skin tones of video signals to standard BT.709 vector locations and verify wide color gamut compatibility to BT.709 color gamut

Flexible display conﬁguration with Full / Quad / Vertical extended tile modes

12G-SDI integrity

e production tool set supporting 4K / WCG / HDR content

interface supporting up to 4K resolution, up to 2160p60

y for monitoring video signals with a variety of transfer functions

play equipped with a 3D LUT conversion, allowing operators to

physical layer measurements to check SDI signal quality and

4 PRISM Media Analysis Platform User Manual

Rackmount installation

Getting started

MPI monitor

MPX monit

How to

install the

MPI monitor in a

dual rack cabinet

For the PRISM MPI monitor, there are two optional dual rack cabinets (19”, 3RU).

MPI-RACK-MM. Allows you to install one MPI monitor or two MPI monitors side-by-side. Each side of the cabinet front panel has two USB ports and a headphone jack for each MPI monitor.

MPI-RACK-MW. Allows you to install one MPI monitor or one MPI monitor in a side-by-side installation with a Tektronix WFM52x0, WFM7200, WFM8x00 waveform monitor. The left side of the cabinet front panel has two USB ports and a headphone jack for one MPI monitor.

For the PRISM MPX monitor, there is an optional 1RU full-rack kit that can be

used for either portable or rackmount applications.

MPX RACK. Allows you to install one PRISM 1RU full width MPX RACK. The MPX RACK rackmount kit includes the Rackmount Slides and Rails Kit Installation Instructions document (Tektronix part number 071-2746-xx).

The information on the following pages describes how to install the MPI monitor in one of the optional dual rack cabinets.

rack cabinet cooling and clearance requirements. The MPI monitor

Dual

has speciﬁc cooling and clearance requirements. Ensure that the cle arance requirements for proper airﬂow are met for both the dual rack cabinet and the instrument. See the PRISM MPI Installation and Safety Instructions for information about the environmental operating requirements for the instrument.

UTION. To prevent risk of ﬁre, adequate airﬂow to instrum ent(s) and rack

adapter must be maintained. Failure to provide adequate airﬂow to instrument(s) could cause an instrument to shut down.

Inadequate airﬂow includes placing instrument(s) and rack adapter in any small, enclosed room that lacks a ventilation system, such as a closet. If the airﬂow is restricted or blocked and the instrument(s) do not shut down, the risk of ﬁre is increased and the instrument(s) could be permanently damaged.

Table 1: Clearance requirements for the dual rack cabinet

Instrument side Clearance requirement

Top and bottom None

Left and right sides 2 in (51 mm)

Front None

Rear

PRISM Media Analysis Platform User Manual 5

3 in (76 mm)

Getting s tarted

Supplied hardw

are. The following table lists the hardware supplied with the dual

rack cabinet kit. The installation instructions includes references to these parts by the item numbers to aid in selecting the correct parts.

Table 2: Supplied hardware

Item number

1 210-1061-00

2 210-1298-01

3 211-0511-00

4 211-0718-00

6 212-0591-00

8 407-3752-00

9 407-6011-00

Tektronix part number Description Quantity

WASHER, FLAT; 0.203 ID X 0.625 OD X

0.062, ZINC PLATED STEEL

WASHER; SHOULDER & RETAINER,

0.195 ID X 0.195 THK, PLASTIC, TV GRAY,

6.575 OD

SCREW, MACHINE; 6-32 X 0.5, PNH, STEEL, ZINC PLATED, T15 TORX

SCREW, MACHINE; 6-32 X 0.312, FLH100, STEEL, ZINC FINISH, T-10 TORX DR

212-0577-00

381-0251-01 NUT BAR; 10-32 X 3.0 X 0.375 X 0.120 4

SCREW, MACHINE; 10-32 X 0.625, TRH, ZINC PLATED STEEL, PHIL

SCREW, MACHINE; 10-32X.750 O VAL HEAD, POZI

BRACKET, EXT; 2.5 X 8.06 X 0.06, STEEL; SAFETY C ONTROLLED

RACK MOUNT, INSTRUMENT MTG BRACKET, 5000 SERIES

6 PRISM Media Analysis Platform User Manual

Getting started

Install the MPI

instrument into the rack adapter, install the adapter into the rack as follows:

1. Position the d cabinet is on the bottom. (See Figure 1.)

NOTE. The MPI-RACK-MM cabinet has headphone jacks on both sides of the

cabinet; the MPI-RACK-MW cabinet has one headphone jack on the left side of the cabinet.

2. MPI-RACK-MW only: Perform the following steps if you are installing a WFM52x0 waveform monitor in a MPI-RACK-MW cabinet:

a. Install the WFM52x0 bracket (item 9 in Table 2) in the right side of the

b. Secure the WFM52x0 bracket to the cabinet using four screws (item 4 in

3. If desired, you can adjust the position of the handle brackets to mount the

adapter ﬂush with other equipment in the rack. To do this, loosen the nuts that attach the handle brackets to the rack adapter, adjust the position of the handle brack

dual rack cabinet in the equipment rack. Before you install an

ual rack cabinet so that the headphone jack(s) on the front of the

cabinet as shown. (See Figure 1.)

Table 2).

ets as desired, and then tighten the nuts securely. (See Figure 2.)

4. Secure the rack adapter assembly to the front frame of the rack using four

ws (item 6 in Table 2) and four shoulder washers (item 2 in Table 2).

scre

5. Install one guide bracket (item 8 in Table 2) to one side of the rear frame

he rack using two screws (item 5 in Table 2) and one nut bar (item 7 in

of t Table 2) as shown. (See Figure 1.)

cure the guide bracket to the cabinet using two screws (item 5 in Table 2),

6. Se two washers (item 1 in Table 2) and one nut bar (item 7 in Table 2). Use the holes in the bracket that will accommodate the depth of the instrument rack frame being used. Leave the screws loose.

7. Repeat steps 5 and 6 to install the second guide bracket to the other side of the cabinet.

8. Tighten all of the attaching screws that were left loose in the previous steps.

PRISM Media Analysis Platform User Manual 7

Getting s tarted

Figure 1: Installing one MPI monitor and one WFM52x0 waveform monitor in the MPI-RACK-MW dual rack cabinet

8 PRISM Media Analysis Platform User Manual

Getting started

Figure 2: Installing one MPI monitor and one WFM7200 or WFM8x00 waveform monitor in the MPI-RACK-MW dual rack cabinet

PRISM Media Analysis Platform User Manual 9

Getting s tarted

Figure 3: Installing two MPI m onitors in the MPI-RACK-MM dual rack cabinet

10 PRISM Media Analysis Platform User Manual

Getting started

Install instru

cabinet in the equipment rack, perform the following steps to install instrument(s) in the cabinet:

1. Install an MPI monitor in the dual rack cabinet: (See Figure 1.) (See Figure 2.) (See Figure 3.)

a. Slide an MPI monitor into the left slot in the dual rack cabinet.

NOTE. For the MPI-RACK-MW cabinet, the MPI monitor must be installed in

the left slot of the cabinet. For the MPI-RACK-MM cabinet, you can install the MPI monitor in the left or right slot of the cabinet.

b. Use two screws (item 3 in Table 2) to secure the instrument in the dual

c. Connect the cables from the USB ports and headphone jack on the dual

d. Connect power, signal, and Ethernet cables to the instrument as needed.

ment(s) in the MPI dual rack cabinet. After you install the dual rack

rack cabinet. The screws attach to the top right and bottom left holes in the instrument chassis as viewed from the rear.

rack cabinet to the rear of the instrument. (See Figure 4.) You can connect the USB

See th about making signal connections to the instrument.

cables to either set of USB ports on the rear panel.

e PRISM Installation and Safety Instructions manual for information

Figure 4: Connecting the rack cabinet USB and audio cables to the MPI monitor

PRISM Media Analysis Platform User Manual 11

Getting s tarted

2. For the MPI-RAC monitor in the right slot of the dual rack cabinet.

3. For the MPI-RA

a. Install a Tektronix WFM52x0, WFM7200, or WFM8x00 waveform

monitor in t Figure 2.)

b. Use two scre

the dual rack cabinet. The screws attach to the right and left holes in the middle of the instrument chassis as viewed from the rear.

c. Connect power and signal cables to the waveform monitor as needed.

NOTE. See t he installation manual for your waveform monitor for information

about making power and signal connections to the instrument.

K-MM cabinet only, repeat step 1 to install a second MPI

CK-MW cabinet only:

he right slot of the dual rack cabinet. (See Figure 1.) (See

ws (item 3 in Table 2) to secure the waveform monitor in

MPI power-on and power-off procedures

This section describes how to apply power to the MPI monitor and how to

-on and power-off the instrument.

power

MPI power cord installation

The MPI monitor is p owered by the DC output of an AC power adapter. Connect the AC adapter to the power connector on the rear panel of the instrument as

n below. The power connector is keyed to be directional, with the ﬂat portion

show of the power cord housing facing the left of the instrument (as viewed from the rear). When fully inserted, the power cord housing latches on the instrument power connector.

CAUTION. Tominimizetheriskofdamagetotheinstrument,itisstrongly

recommended that the AC adapter be connected to the MPI monitor before the

dapter is connected to the AC power source.

12 PRISM Media Analysis Platform User Manual

Getting started

Figure 5: Connecting power to the MPI monitor

PRISM Media Analysis Platform User Manual 13

Getting s tarted

MPI power cord removal

The power cord h inserted. To remove the power cord, grasp the connector housing as shown below and ﬁrmly pull the cord away from the instrument.

CAUTION. To prevent damage to the power cord or to the instrument power

connector, do not attempt to disconnect the power cord by pulling on the cable. You must pull on the connector housing to disengage the locking mechanism.

To minimize the risk of damage to the instrument, it is strongly recommended that the AC adapter be d isconnected from the AC power source before the adapter is disconn

ected from the instrument.

ousing latches on the instrument power connector when fully

MPI power-on procedure

e 6: Disconnecting the power cord from the MPI monitor

Figur

1. Apply power to the instrument. (See page 12, MPI power cord installation.)

E. If the MPI monitor was previously powered off by a power interruption

NOT

or by removing the power cord from the rear of the instrument, the instrument will power on when power is reapplied.

2. Press the Power/Standby button on the instrument front panel to turn the instrument on.

NOTE. The Power/Standby button illuminates during the power-on sequence and

hen turns off during normal instrument operation.

14 PRISM Media Analysis Platform User Manual

Getting started

MPI power-off procedure

Figure 7

1. Press the Power/Standby button on the instrument front panel to turn the

CAUTION. To prevent data loss, it is strongly recommended that you ﬁrst shut

down the instrument using the power button or the Settings > Utilities > Power submenu before disconnecting the power cord.

To minimize the risk of damage to the instrument, it is strongly recommended that the AC adapter be disconnected from the AC power source before the adapter is disconnected from the instrument.

2. To completely remove power from the MPI monitor, disconnect the power

: MPI Power/Standby button

ment off.

instru

cord from the instrument. (See page 14, MPI power cord removal.)

PRISM Media Analysis Platform User Manual 15

Getting s tarted

MPX power-on a

MPX power cor

installation

nd power-off procedures

This section describes how to apply power to the MPX monitor and how to power-on and power-off the instrument.

The MPX monitor is powered by an AC power source. Connect the power cord

to the power connector on the rear panel of the instrument as shown below. The power connector is keyed to be directional, with the ﬂat portion of the power cord housing fa inserted, the power cord housing latches on the instrument power connector.

cing the left of the instrument (as viewed from the rear). When fully

Figure 8: Connecting power to the MPX monitor

16 PRISM Media Analysis Platform User Manual

Getting started

MPX power-on procedure

1. Apply power to t

NOTE. If the MPX monitor was previously powered off by a power interruption

or by removing the power cord from the rear of the instrument, the instrument will power on when power is reapplied.

2. Press the Power/Standby button on the instrument front panel to turn the instrument on.

NOTE. The P

then turns o ff during normal instrument operation.

ower/Standby button illuminates during the power-on sequence and

he instrument. (See page 16, MPX power cord installation .)

Figure 9: MPX Power/Standby button

MPX power-off procedure

1. Press the Power/Standby button on the instrument front panel to turn the

CAUTION. To prevent data loss, it is strongly recommended that you ﬁrst shut

down the instrument using the power button or the Settings > Utilities > Power submenu before disconnecting the power cord.

2. To completely remove power from the instrument, disconnect the power cord

instrument off.

from the instrument. The power cord has a locking mechanism to keep it

ttached to the instrument. Push the button on the cord housing to release the

a locking mechanism.

PRISM Media Analysis Platform User Manual 17

Getting s tarted

SFP+ module in

MPI SFP+ module

install

stallation

There are several types of optional SFP+ modules available:

NOTE. ST2

need to be installed in 10 GbE SFP+ ports 1 and 2.

To install the SFP+ module on an MPI monitor, insert the m odule into the SFP+

ation

connec into place when fully inserted.

To rem out of the SFP+ connector as shown a bove (optical SFP+ module shown).

SD/HD/3G-SDI optical transmitter

SD/HD/3G-SDI DIN transmitter

SD/HD/3G-SDI HD-BNC transmitter

10G Ethern

10G Ethernet long range transceiver (1310 nm)

tor as shown below (optical SFP+ module shown). The module will latch

ove the optical SFP+ module, lift up on the latch and then pull the module

et short range transceiver (850 nm)

022-7 requires two 10 GbE SFP modules to be installed. The modules

NOTE. An optical SFP+ module is shown below. Other types of SFP+ modules

may have different latching mechanisms.

Figure 10: Installing and removing an optical SFP+ module on an MPI monitor

18 PRISM Media Analysis Platform User Manual

Getting started

MPX SFP+ module

installation

To install an SF SFP+ connector. The module will latch into place when fully inserted.

To remov e the S of the SFP+ connector. (optical SFP+ module shown).

NOTE. To ensure you are using the correct SFP+ connectors, the 10 GbE and SDI

SFP+ connectors are marked on the back of the MPI (See page 22, MPI rear panel connectors.) and M PX. (See page 25, MPX rear panel connectors.)

An optical SFP+ module is shown above. Other types of SFP+ modules may have different latching mechanisms.

P+ module on an MPX monitor, insert the SFP+ module into the

FP+ module, pull down on the latch and then pull the module out

Figure 11: Installing and removing an optical SFP+ module on an MPX monitor

SFP+ module

transportation

CAUTION. To prevent static damage to the SFP+ module, if you remove the SFP+

module from the instrument, always transport the SFP+ module in a anti-static bag or container.

To prevent possible damage to the PRISM monitor and SFP+ modules, remove the SFP+ modules before transporting the PRISM monitor.

PRISM Media Analysis Platform User Manual 19

Getting s tarted

Network installation

See the PRISM Installation and Safety Instructions manual that shipped with your instrument for basic installation instructions.

After your instrument is physically installed, you might want to connect it directly to a PC or to a network. The following information can help you do that.

Connecting directly to a

The following procedure will help you connect your instrument directly to a PC:

1. Connect th use an Ethernet Switch. (See Figure 12.)

2. Set up the Manual IP mode to set the IP address manually. Be sure to set an address that is compatible with the setting of your PC. The default IP address of the PRISM monitor is 192.168.1.2.

e instrument directly to a PC with an Ethernet cable. You can also

instrument as described in the following procedures, choosing

Figure 12: Connecting the instrument to a PC (MPI monitor shown)

20 PRISM Media Analysis Platform User Manual

Getting started

Connecting to a network

To allow networ addresses can be assigned either automatically (DHCP) or manually. If your network does not use DHCP, you will have to manually enter the address for the instrument. To get a ﬁxed address, talk to your LAN administrator. The default IP address of the PRISM monitor is 192.168.1.2.

To connect your instrument to a network and access it with a remote PC, do the following:

1. On the PRISM monitor, touch the Settings icon to display the Settings menu.

2. Touch Network to open the Network submenu.

3. Touch CONTROL IP PORT to open the Control IP Port submenu.

4. Dependin

select the method for selecting an IP addres s.

k access to the instrument, you must set the IP address. Network

g on your local network requirements, touch DHCP or Manual to

Figure 13: Setting network parameters

5. If you cannot use DHCP and you selected Manual, use the Manual submenu to set the IP address, subnet mask, gateway address and DNS address n etwork parameters you obtained from your LAN administrator. (Be sure to use compatible addresses between the PC and the instrument.) Touch an address

ox to open the address editing tool. Use the editing box as described for

b editing an IP input address. (See Figure 30 on page 49.)

6. Touch the Settings icon or touch the

PRISM Media Analysis Platform User Manual 21

icon to close the Settings menu.

Getting s tarted

MPI rear panel connectors

The following ﬁgure shows the external connections to the instrument. A description of each connector is provided in the following table.

Figure 14: PRISM MPI rear panel

Item number (See Figure 14.) Description

SDI IN 1-2. Two BNC inputs that can operate in the following modes:

Single SD/HD/3G/12G-SDI link (Option MP-FMT-4K is required for 12G support). When used as a single link, only one of the SDI 1-4 inputs is active at a time.

Quad 4K links when used in conjunction with the SDI 3-4 inputs (Option MP-FMT-4K only). When used as Quad 4K links, all four SDI inputs are active.

Single 12G Eye link on SDI 1 input only for physical layer measurements, including automated measurement of 12G-SDI Eye pattern parameters (requires Options MP-FMT-4K and PHY-12G).

SDI IN 3-4. Two BNC inputs that can operate in the following modes:

Single SD/HD/3G-S DI link. When used as a single link, only one of the SDI 1-4 inputs is active at a time.

Quad 4K links when used in conjunction with the SDI 1-2 inputs (Option MP-FMT-4K only). When used as Quad 4K links, all four SDI inputs are active.

SDI SFP+ 1-2. Two optional SFP+ outputs for SD/HD/3G-SDI signals (HD-BNC transmitter SFP+ modules shown).

SDI SFP+ 3-4. Two optional SFP+ outputs for SD/HD/3G-SDI signals (HD-BNC transmitter SFP+ modules shown).

10 GbE SFP+ 1-2. Two optional SFP+ ports for 10 GbE Ethernet applications.

22 PRISM Media Analysis Platform User Manual

Item number (See Figure 14.) Description

SDI OUT. BNC output of the selected SDI or 10 GbE input.

LTC/GPIO. 15-pin, D-type connector is for future functionality.

Getting started

IN – REF – OUT. The REF IN connector is for future use. The REF OUT connector outputs a 1 PPS (Pulse Per Second) signal when the instrument is locked to a PTP reference.

DC power input. Power connector for 48 VDC input.

Display port (DP). Two display port outputs for external monitors. The output video format is 1920 x

1080.

PC MONITOR. 15-pin, D-type connector for 1920×1080 analog video output of the instrument display.

Pin 1: R ed video

Pin 2: Green video

Pin 3: B lue video

Pin 4: Not connected

Pin 5: GND

Pin 6: Red GND

Pin 7: Green GND

Pin8: BlueGND

Pin 9: Not connected

Pin 10: Not connected

Pin 11: Not connected

Pin 12: VGA_b_DDAT

Pin 13: Horizontal sync

Pin 14: Vertical sync

Pin 15: VGA_b_DCLK

Ethernet port 1. Standard RJ-45 connector for 10/100/1000Base-T Ethernet cable.

USB ports. USB 3.0 ports for connecting a mouse and keyboard, importing or exporting instrument

presets, upgrading the instrument ﬁrmware, or saving screen and stream captures.

USB ports. USB 3.0 ports for connecting a mouse and keyboard, importing or exporting instrument presets, or for upgrading the instrument ﬁrmware.

Audio input. This connector i s for future use.

PRISM Media Analysis Platform User Manual 23

Getting s tarted

Item number (See Figure 14.) Description

Audio output. 3.5 mm line out port for using headphones with the selected audio channel pair.

Mic input. This connector is for future use.

24 PRISM Media Analysis Platform User Manual

MPX rear panel connectors

The following ﬁgure shows the external connections to the rear panel of the instrument. A description of each connector is provided in the following table. See Front panel controls and connectors for information about the front panel connectors. (See page 33.)

Figure 15: PRISM MPX rear panel

Item number (See Figure 15.) Description

AC power input. Connector for AC power source.

DisplayPort (DP). Two DisplayPort outputs for external monitors. The output video format is 1920 x

1080.

PC MONITOR. 15-pin, D-type connector for 1920×1080 analog video output of the instrument display.

Getting started

Pin 1: R ed video

Pin 2: Green video

Pin 3: B lue video

Pin 4: Not connected

Pin 5: GND

Pin 6: Red GND

Pin 7: Green GND

Pin8: BlueGND

Pin 9: Not connected

Pin 10: Not connected

Pin 11: Not connected

Pin 12: VGA_b_DDAT

Pin 13: Horizontal sync

Pin 14: Vertical sync

Pin 15: VGA_b_DCLK

PRISM Media Analysis Platform User Manual 25

Getting s tarted

Item number (See Figure 15.) Description

Ethernet port. Standard RJ-45 connector for 10/100/1000Base-T Ethernet cable.

SDI OUT. BNC output of the selected SDI or 10 GbE input.

10 GbE SFP+ 1-2. Two optional SFP+ ports for 10 GbE Ethernet applications.

SDI SFP+ 3-4. Two optional SFP+ outputs for SD/HD/3G-SDI signals.

SDI SFP+ 1-2. Two optional SFP+ outputs for SD/HD/3G-SDI signals.

SDI IN 3-4. Two BNC inputs that can operate in the following modes:

Single SD/HD/3G-S DI link. When used as a single link, only one of the SDI 1-4 inputs is active at a time.

Quad 4K links when used in conjunction with the SDI 1-2 inputs (Option MP-FMT-4K only). When used as Qu

SDI IN 1-

2. Two BNC inputs that can operate in the following modes:

ad 4K links, all four SDI inputs are active.

Single S a single link, only one of the SDI 1-4 inputs is active at a time.

Quad 4K links when used in conjunction with the SDI 3-4 inputs (Option MP-FMT-4K only). When used as Quad 4K links, all four SDI inputs are active.

Single 12G Eye link on SDI 1 input only for physical layer measurements, including automated measu

LTC/G

IN – REF – OUT. The REF IN connector is for future use. The REF OUT connector outputs a 1 PPS

(Pulse Per Second) signal when the instrument is locked to a PTP reference.

Audio input. This connector is for future use.

Audio output. 3.5 mm line out port for using headphones with the selected audio channel pair.

Mic input. This connector is for future use.

USB ports. Four USB 3.0 ports for connecting a mouse and ke yboard, importing or exporting instrument

presets, upgrading the instrument ﬁrmware, or saving screen and stream captures.

DVI port. DVI port output for an external monitor. The output video format is 1920 x 1080.

D/HD/3G/12G-SDI link (Option MP-FMT-4K is required for 12G support). When used as

rement of 12G-SDI Eye pattern parameters (requires Options MP-FMT-4K and PHY-12G).

PIO. 15-pin, D-type connector is for future functionality.

26 PRISM Media Analysis Platform User Manual

Display elements

Getting started

Figure 16: Elements of the display (MPI monitor shown)

Item number

Description

2 Application tile 1.

3 Application tile 3.

Application name. Lists the name of the displayed application.

Status bar. The right side of the Status bar lists instrument status such as the selected input, type of input signal, selected signal reference (internal or external), audio channel status, the real time clock setting, and the Message Center.

The left side of the Status bar has icons with links to various instrument setting menus, presets, audio volume control, and status readouts. Use the Home icon to exit any displayed menus.

Power / Standby button. Press the button to turn the instrument on or off. To completely remove power from the instrument, remove the power cord.

CAUTION. To prevent data loss, it is strongly recommended that you ﬁrst shut down the instrument

using the power button or the Settings > Utilities menu before disconnecting the power cord.

8 Applicat

The application panels can be shown in four-tile mode, side-by-side two-tile mode, or in full screen mode.

Application tabs. Some applications have selectable tabs (highlighted readouts) you can use to display additional information.

Application tile 4.

ion tile 2.

PRISM Media Analysis Platform User Manual 27

Getting s tarted

Diagnostics report

You can download a .zip ﬁle containing a service report of instrument diagnostics using the Settings menu. Should your instrument need service, you may be asked to provide the Diagnostics ﬁle to Tektronix to aid in troubleshooting problems with the instrument.

1. Touch the Settings icon (

2. Select Utilities to open the Utilities submenu.

3. Select Diagnostics to open the Diagnostics submenu.

4. Insert a USB device into one of the USB ports on the PRISM monitor.

5. Select Save Diagnostics to save the diagnostics report to the USB device.

) to open the Settings menu.

28 PRISM Media Analysis Platform User Manual

Getting started

Message Cente

The Mess age Center enables you to view messages. For example, you can view messages that allow you to eject devices mounted to the instrument. The following st Message Center:

1. A number abo

Figure 17

2. Select t instrument.

NOTE. After using a USB stick, it must be unmounted using the Message Center

before removing it from the instrument.

eps show you how to eject a USB stick from the instrument using the

ve the icon indicates the number of messages on the instrument.

: Messages icon with one message

he Messages icon to view the messages or devices mounted to the

Figure 18: Message Center popup window

3. Select the Eject icon ( ) to unmount the USB stick from the instrument.

4. Select the Messages icon again to hide the Message Center popup window.

PRISM Media Analysis Platform User Manual 29

Getting s tarted

30 PRISM Media Analysis Platform User Manual

Methods of operation

This section describes the primary methods of operating the instrument:

MPI front panel touchscreen

MPX front panel controls

External touchscreen display

MPI touch

screen operation

The following ﬁgure shows the instrument display with an open menu for one of the applications.

Keyboard a

Remote control via VNC

Remote control via API commands

nd mouse

Figure 19: Four-tile display with menu selection

PRISM Media Analysis Platform User Manual 31

Methods of operation

Supported touchscreen

gestures

How to select and control

an application to display

You c an u s e the f

Touch or tap the screen to select display elements.

Press and hold on an application panel to open the application menu.

Double tap an application panel to toggle the display between four-tile and a full-screen display of the tapped application panel.

Swipe up/down or left/right as necessary to navigate menus and preset listings and to view additional application information.

1. Pressandholdonanopenapplicationtoopentheapplicationmenu.

2. If necessary, touch the menu down arrow to open the list of available

applications.

NOTE. You may need to scroll down through the list to access all of the

applications.

ollowing touchscreen gestures to control the instrument:

Figure 20: Selecting an application to display

3. Swipe the application list up or down to locate the desired application.

4. Touch the name of the desired application to display that application.

32 PRISM Media Analysis Platform User Manual

Methods of operation

5. If available, touch or tap the icon in the menu bar to open the settings menu for the ap

plication.

6. Touch o r tap the

7. If available

MPX front panel controls

Figure 2

Item number (See Figure 21.) Description

1: MPX front panel controls

Power / Standby button. Press the button to turn the instrument on or off. To completely remove

power from the instrument, remove the power cord.

display to full screen.

, touch or tap the

icon in the menu bar to change the selected application

icon to clear or reset the selected display.

CAUTION. To prevent data loss, it is strongly recommended that you ﬁrst shut down the instrument

using the power button or the Settings > Utilities menu before disconnecting the power cord.

PRESET butto

Group A using the SELECTIONS buttons (1-6). Press the button repeatedly to select preset Group B-F.

SELECTIONS b utto ns. After pressing the PRESET or INPUT button, press one of the SELECTIONS buttons (1-6) to recall an instrument preset or to select an input to monitor.

VOLUME control. Turn the VOLUME control to adjust the volume on the front and rear-panel headphone o

Headphone

USB ports.

presets, or upgrading the instrument ﬁrmware.

n. Press the button once to prepare the instrument for a preset selection from preset

utputs. Push the VOLUME control to mute or unmute the audio.

jack. 1/4 inch headphone jack for listening to the selected audio channel pair.

Two USB 2.0 ports for connecting a mouse and keyboard, importing or exporting instrument

NOTE. It is strongly recommended you do NOT use the front USB 2.0 ports for stream captures. Using

aUSB2.0p

3.0 ports for stream captures.

When you use the PRESET and INPUT buttons, the associated menus appear on the display. The menus close after a short time-out period. Similarly, when you use the VOLUME control, the volume slider and mute controls appear on the display and close after a short time-out period.

INPUT button. Press the button to prepare the instrument for an input selection using the SELECTIONS buttons (1-6).

ort for stream captures will take an excessive amount of time. Use the rear panel USB

PRISM Media Analysis Platform User Manual 33

Methods of operation

MPX front panel operation

You can use the i

Recall instrume nt presets

Select an input to m onitor

Control or mute the volume on the headphone outputs

Connect a mouse and keyboard

Connect a US instrument ﬁrmware, or save screen and stream captures

NOTE. It is strongly recommended you do NOT use the front USB 2.0 ports for

stream captures. Using a USB 2.0 port for stream captures will take an excessive amount of time. Use the rear panel USB 3.0 ports for stream captures.

How to recall instrument presets (MPX). Perform the following steps to recall instrument presets using the front panel:

1. Press the PRESET button once to prepare the instrument for a preset selection from preset Group A using the SELECTIONS buttons (1-6).

2. Press the PRESET button r epeatedly to select preset Group B-F. The selected preset group will be displayed.

nstrument front panel to perform the following functions:

B drive to import or export instrument presets, upgrade the

3. After you select the desired preset group, press the SELECTIONS numbered button corresponding to the preset in that group you want to recall (1-6).

NOTE. When you use the PRESET and INPUT buttons, the associated menus

ear on the display. The menus close after a short time-out period. Similarly,

app when you use the VOLUME control, the volume slider and mute controls appear on the display and close after a short time-out period.

How to select an input to monitor (MPX). Perform the following steps to recall instrument presets using the front panel:

1. Press the INPUT button to prepare the instrument for an input selection.

2. Press the SELECTIONS numbered button corresponding to the input you

want to monitor.

34 PRISM Media Analysis Platform User Manual

Keyboard and mouse operation

You can use a USB keyboard and mouse to operate the instrument. The mouse must have a scrolling wheel to access all of the menu selections. Click or click and hold on applications to perform actions like you would on the touch panel.

Connect the keyboard and mouse as follows:

Use the USB ports on the rear panel of the instrument (MPI) or front panel (MPX)

Use the USB port on the front of the optional dual rack cabinet (MPI-RACK-MM or MPI-RACK-MW)

Connect the external monitor to any of the available display outputs, including VGA, Display Port, or DVI (MPX)

Methods of operation

Keyboard controls

Home icon. TheESCkeyonthekeyboardismappedtofunctionastheHome

icon, which closes any displayed menus.

Volume control. If your keyboard has volume control keys, you can use them to control the volume of the audio output on the instrument.

Input and preset selection. The following table lists the keyboard controls that allow you to quickly select between the SDI inputs and to select from instrument

ets 1 through 6.

pres

Table 3: Keyboard controls for selecting SDI inputs and instrument presets

Action Keyboard control Result

Input ALT+i

Preset ALT+p

Select 1

Select 2

Select 3

Select 4

Select 5

Select 6

Prepares the instrument for an input selection.

Prepares the instrument for a preset selection from preset Group A. Repeat 2-5 times to select preset Group B-F.

Selects Input 1 or selects Preset 1 from the selected preset group.

Selects Input 2 or selects Preset 2 from the selected preset group.

Selects Input 3 or selects Preset 3 from the selected preset group.

Selects Input 4 or selects Preset 4 from the selected preset group.

Selects Input 5 or selects Preset 5 from the selected preset group.

Selects Input 6 or selects Preset 6 from the selected preset group.

PRISM Media Analysis Platform User Manual 35

Methods of operation

To select an SDI

1. On the keyboard, do one of the following:

While pressing the ALT key, press i to enable an input selection change.

While pressing the ALT key, press p once to recall a preset from Preset

Group A. Repeat 2-5 times to select a preset from another Preset Group (B-F). For example, press ALT+p three times to make a selection from Preset Group C.

2. Pressanumberfrom1 to 6 to select the desired input or to select a preset from the selected Preset Group (A-F).

input or instrument preset.

External touchscreen d isplay operation

You can use an external touchscreen display to control the instrument. Two connect

ions are required:

Connect the Display Port, or DVI Port (MPX only), output from the PRISM monito

Connect the output of the external device/touchscreen to one of the USB ports

r to the input on the external device/touchscreen.

on the PRISM monitor.

Remote control via VNC operation

the PRISM monitor is c onnected to an Ethernet network, you can use a

When computer connected to the same network to remotely control the instrument in a web browser or in a VNC client such as VNC Viewer. Use the followi ng steps to connect to the PRISM monitor via VNC:

NOTE. When using VNC for extended periods of time, it is recommended to use a

VNC client such as VNC Viewer.

1. On the PRISM monitor, open the Settings > Network page to view the Control IP Port address of the instrument to which you are going to connect.

2. On your computer, enter the following in the URL box of your web browser,

where x xx.xxx.xxx.xxx is the IP address of the Control IP Port of the instrument.

http://xxx.xxx.xxx.xxx:6080/vnc.html

36 PRISM Media Analysis Platform User Manual

Methods of operation

3. This opens a log

4. In the Control bar, click the Settings icon to open the Settings dialog.

in Web page as shown below.

5. In the Settings dialog, use the Scaling Mode drop-down list to select Local Scaling, and then click Apply.

PRISM Media Analysis Platform User Manual 37

Methods of operation

6. In the Control b

7. In the Settings dialog, enter the default password PRISM (case sensitive), and then click Con

NOTE. You can use the WEB REMOTE tab of the PRISM Settings > Network

menu to change the default password for the remote Web connection.

8. The web browser connects to the instrument with the browser display appearing exactly like the instrument display, but with a slower u pdate rate.

ar, click the Connect icon to open the Connect dialog.

nect.

38 PRISM Media Analysis Platform User Manual

Remote control via API commands

The PRISM monitor has a limited command set for controlling the instrument using REST-style API commands. You can use GET and POST commands to conﬁgure the signal inputs and to select the active input.

Use the following steps to access the API documentation:

1. On the PRISM monitor, open the Settings > Network page to view the Control IP Port address o f the instrument to which you are going to connect.

2. On your computer, enter the following in the URL box of your web browser,

where xxx.xxx.xxx.xxx is the IP address of the Control IP Port of the instrument.

http://xxx.xxx.xxx.xxx:9000/api/help

3. This opens a PRISM API Documentation Web page as shown below.

Methods of operation

Figure 22: API documentation web page

PRISM Media Analysis Platform User Manual 39

How to conﬁgure the instrument

How to conﬁgur

etheinstrument

Most of the in access the Settings menu by touching the Settings icon. This section describes how to conﬁgure the following instrument settings:

Signal inputs (See page 40, How to conﬁgure and select signal inputs.)

HDR monito / WCG monitoring.)

PTP refere

Presets (See page 58, How to set and recall instrument presets.)

Internal time and date (See page 66, How to manage tile display.)

Firmware upgrade (See page 71, How to upgrade the instrument ﬁrmware.)

Installed software and hardware versions (See page 80, How to verify the installed software and hardware versions.)

NOTE. Some of the conﬁguration settings require you to enter values. A USB

keyboard can be used to enter these values instead of using the touchscreen

dontheinstrument.

keypa

strument settings are controlled using the Settings menu. You can

ring (See page 53, How to conﬁgure the instrument for HDR

nce settings (See page 56, How to conﬁgure PTP reference settings.)

How to conﬁgure and select signal inputs

The PRISM monitor allows you to conﬁgure multiple signal inputs. Use the Settings > Inputs menu to:

Conﬁgure SDI inputs

Conﬁgure IP stream inputs, including ST2022-6, ST2110-20/30, and ASPEN IP streams

Modify input names

nable ST2022-7 Seamless Switching

NOTE. IGMP communications can fail when the video IP inputs are conﬁgured for

the same IP Address. The video inputs should always have different IP addresses.

40 PRISM Media Analysis Platform User Manual

How to conﬁgure the instrument

Conﬁguring SDI inputs

TheSingleandQ MP-FMT-4K is present. If this option is not present, only a single input can be conﬁgured.

Single input conﬁguration. Perform the following procedures to conﬁgure a Single signal input:

1. Touch the Settings icon (

2. Select Inputs to open the Inputs submenu.

Figure 23: Settings menu

uad link buttons are only available when software option

) to open the Settings menu.

NOTE. In the following ﬁgure are six virtual inputs to choose from. Inputs can be

given any meaningful name, (See page 47, To rename a signal input.)

gure 24: Settings inputs submenu

elect an SDI input.

3.S

PRISM Media Analysis Platform User Manual 41

How to conﬁgure the instrument

4. Select Single f SDI inputs to monitor. The example shows the SDI 1 input being selected.

Figure 25: Single SDI signal conﬁguration

5. Select Save and close the menu.

or the Input Conﬁguration and select one of the four physical

42 PRISM Media Analysis Platform User Manual

How to conﬁgure the instrument

Quad Link input

conﬁguration procedure and then perform the following steps to conﬁgure a Quad Link input:

NOTE. All four SDI inputs must be connected to a cable on the back of the

instrument to use the Quad Link Input Conﬁguration.

1. Conﬁrm that Quad Link cables are connected to the back of the instrument.

Quad Link A is connected to SDI-IN 1

Quad Link B is connected to SDI-IN 2

Quad Link

Quad Link D is connected to SDI-IN 4

2. Select Quad Link for the Input Conﬁguration. SDI 1-4 (Link A-D) is selected by default.

conﬁguration. Follow the steps 1 through 3 in Single input

C is connected to SDI-IN 3

Figure 26: Quad Link SDI signal conﬁguration

NOTE. The Quad Link and UHD/4K Mode buttons are only available when

software option MP-FMT-4K is present.

PRISM Media Analysis Platform User Manual 43

How to conﬁgure the instrument

3. Use the UHD/4K M Division) or 2SI(Two Sample Interleave).

NOTE. In AUTO mode, the instrument defaults to Two Sample Interleave mode

if the Video Payload Identiﬁer (VPID) complies with SMPTE 425.3 or SMPTE

425.5. The instrument defaults to Square Division mode if the VPID complies with

SMPTE 292.1, SMPTE 372, SMPTE 425.1, or a quad-HD signal is present and VPID is miss

4. Select Save and close the menu.

ing. VPID in the signal is required for this option to operate properly.

ode drop-down menu to select Auto, Sq Div (Square

44 PRISM Media Analysis Platform User Manual

How to conﬁgure the instrument

SDI input setti

Link input conﬁgurations. The Gamma and Color Gamut settings deﬁne the characteristics of the video signal.

1. Choose the appropriate Gamma selection from the drop-down menu. The selection characterizes the video signal on each virtual input.

ngs. The following settings are the same for Single and Quad

SDR Narrow. The reference OETF (Optical to Electrical Transfer

Function) is deﬁned in ITU-R BT.709 with gamma of 0.45 and the reference EOTF (Electrical to Optical Transfer Function) is deﬁned in ITU-R BT.1886 with gamma of 2.4.

The scaling places the extrema of the nonlinear color value from zero to unity at code words 40h(64) and 3ACh(940) in a 10-bit representation.

PQ Narrow. The reference OETF with a high luminance range capability

of 0 to 10,000 cd/m2 standardized in SMPTE2084. The EOTF is the inverse of OETF.

The scaling places the extrema of the nonlinear color value from zero to unity at code words 40h(64) and 3ACh(940) in a 10-bit representation.

HLG. The reference OETF is standardized in ARIB B67 and the reference

EOTF is standardized in ITU BT.2100 at the nominal display peak

ance of 1000 nits.

lumin

S-Log2. The reference OETF is deﬁned as Sony S-Log2. The EOTF is

nverse of OETF.

the i

S-Log3. The reference OETF is deﬁned as Sony S-Log3. The EOTF is

inverse of OETF.

the

2. Select the color space of the video signal using the Color G amut drop-down

nu.

Rec. 709.StandardforHD.

Rec. 2020. Standard for 4K.

NOTE. Rec. 601 gamut is automatically selected when the SD format is detected /

selected in the video signal.

PRISM Media Analysis Platform User Manual 45

How to conﬁgure the instrument

Figure 27: SDI signal settings

3. Select Save and close the menu.

46 PRISM Media Analysis Platform User Manual

How to conﬁgure the instrument

Torenameasign

1. To rename the input to a meaningful name, touch the Name box to open the text editing d isplay shown below.

al input.

Figure 28: Renaming a signal input

2. Use the editing controls to enter a new name for the input. Here are some notes on using the text editor.

Enter a name with a maximum of 16 characters.

Use th

Use the shift key to access capital letters.

Use the backspace key to delete characters by backspacing over them.

Use the 123 and abc keys to toggle between accessing letters and

numbers/symbols.

3. When you are done editing the input name, touch the Enter key.

4. When you are done editing the input, touch Save to save your changes.

icon next to the input box to clear the existing name.

PRISM Media Analysis Platform User Manual 47

How to conﬁgure the instrument

Conﬁgure IP stream inputs

To con ﬁgure an I

1. Touch the Settings icon (

2. Select Inputs to open the Inputs submenu.

3. Select the desired input from the list.

4. Select IP.

NOTE. ST2110 will also appear as a protocol option in addition to ST2022-6 and

ASPEN. This is a preview of the ST2110-20 video decode feature.

P stream, perform these steps:

) to open the Settings menu.

Figure 29: IP input protocols and ST2022-7 seamless switching

le ST2022-7 seamless switching.

Enab

NOTE. Only available for ST2022-6 streams.

lect ST2022-6.

1. Se

2. Slide the ST2022-7 Seamless Switching control to Enabled.

OTE. There is a difference between “Port” and “Path”. The Port is the physical

SPF port that is used to input the 10GbE signal. Path 1 and Path 2 are the signal paths to be used for seamless switching. This differentiation is being made since it is possible for both Path 1 and Path 2 to use a single Port.

48 PRISM Media Analysis Platform User Manual

How to conﬁgure the instrument

3. Enter the Sourc applicable.

NOTE. You may have to scroll down to see Path 2.

4. To have the instrument ignore a parameter, touch the Unmasked control next to the parameter to toggle the state to Masked.

5. To edit one of the parameter values, touch inside the parameter box to ope n the editing display shown below.

e and Destination information for Path 1 and Path 2, if

Figure 30: Editing parameter ﬁelds

6. When you are done editing touch the Enter key.

7. Scroll down to enter the Source and Destination information for Path 2.

NOTE. If ST2022-7 Seamless Switching is set to Disabled only Path 1 is available,

Path 2 will be grayed out.

8. Select Save and close the menu.

PRISM Media Analysis Platform User Manual 49

How to conﬁgure the instrument

Conﬁgure ASPEN

Encapsulation) streams, follow the instructions (See page 52, Input selection.) and then:

Figure 31: Conﬁgure ASPEN stream

. If you will be monitoring ASPEN (Adaptive Sample Picture

1. Select ASPEN.

2. Enter the Source and Destination information.

3. Enter the Video PID, the default is 361.

4. Sele

ct Save and close the menu.

50 PRISM Media Analysis Platform User Manual

How to conﬁgure the instrument

IP input settin

and ST2110 (Preview). The Gamma and Color Gamut settings deﬁne the characteristics of the video signal.

1. Choose the appropriate Gamma selection from the drop-down menu. The selection characterizes the video signal on each virtual input.

gs. The following settings are the same for ST2022-6, ASPEN,
