PQA600
ZZZ
Picture Quality Analyzer
Video Sequences Recovery Media
*P071278300*
0
71-2783-00
Page 2
Copyright © Tektronix. All rights reserved. Licensed software products are
owned by Tektronix or its subsidiaries or suppliers, and are protected by national
copyright laws and international treaty provisions.
Tektronix products are covered by U.S. and foreign patents, issued and pending.
Information in this publication supersedes that in all previously published
material. Specifications and price change privileges reserved.
TEKTRONIX and TEK are registered trademarks of Tektronix, Inc.
Contacting Tektronix
Tektronix, Inc.
14150 SW Karl Braun Drive
P.O. Box 500
Beaverton, OR 97077
USA
For product information, sales, service, and technical support:
In North America, call 1-800-833-9200.
Worldwide, visit www.tektronix.com to find contacts in your area.
Page 3
Video Sequences Recovery Media
The PQA600 Picture Quality Analyzer comes from the factory with video
sequences preinstalled on the hard drive of the instrument. Use this recovery
media to reinstall those sequences if the software on your instrument becomes
corrupted or if you have performed an operating system recovery.
The PQA600 Video Sequences Recovery Media consists of a multi-DVD set.
The table below lists the formats of the video sequences that are installed on
each DVD.
Sequence
type
PQA300 with Trigger
525
625
PQA300 without Trigger
525
625
Width/
Height
720 / 486 29.97 / No interlace CbYCrY
720 / 576 25 / No interlace CbYCrY
720 / 486 29.97 / No interlace
720 / 576 25 / No interlace CbYCrY
Frame rate/
structure Sample format DVD
1
1
1
1
1
(601-422)
(601-422)
CbYCrY
(601-422)
(601-422)
1
Page 4
Video Sequences Recovery Media
Sequence
type
23
Vclips
320x180
Width/
Height
Frame rate/
structure Sample format DVD
320 / 180 30 / No interlace YCbCr 4:2:0
1
(Planar only)
864x486
864 / 486 30 / No interlace YCbCr 4:2:0
1
(Planar only)
1280x720
1280x720
1920x1088
1920x1080
1
The Cheer_2Mbps_25fps.yuv sequence has a frame rate of 24.975 fps even though it is
1280 /
720
1280 /
720
1920 /
1088
1920 /
1080
30 / No interlace YCbCr 4:2:0
(Planar only)
60 / No interlace CbYCrY
(601–422)
30 / No interlace YCbCr 4:2:0
(Planar only)
60 / No interlace CbYCrY
(601–422)
2, 3
6
4, 5
6
located in the PQA600 without Trigger/525 directory. Use this sequence in conjunction with
the Cheer.610–525.yuv sequence for measuring between different frame-rate sequences.
2
The 1280x720 and 1920x1088 format Vclips sequences are a subset of the Tektronix Vclips
VC031A series of video clips. The 320x180 and 864x486 format Vclips sequences are
modified versions of Vclips VC031A 1280x720 sequences.
2
Page 5
Video Sequences Recovery Media
3
You can use the contents on Disk 6 for HD signal generation. You can change the Frame
rate from the above list. For SD signal generation, you can use the contents under PQA300
with Trigger and PQA300 without trigger folders.
Reinstalling the Software
To reinstall the PQA600 video sequences, perform the following steps:
1. Insert the PQ A600 Video Sequences Recovery disc that contains the sequence
you want to reinstall in the front-panel DVD drive of the instrument and close
the drive tray.
NOTE. You do not need to reinstall all of the video sequences. You can reinstall only the
sequences required for your application.
2. Use Windows Explorer to copy the video sequence(s) from the recovery media
to the hard drive of the instrument. The sequences were originally installed
in the following directories:
F:\PreInstalled_Sequences\PQA300 with Trigger\525
F:\PreInstalled_Sequences\PQA300 with Trigger\625
F:\PreInstalled_Sequences\PQA300 without Trigger\525
F:\PreInstalled_Sequences\PQA300 without Trigger\625
F:\PreInstalled_Sequences\Vclips\320x180
F:\PreInstalled_Sequences\Vclips\864x486
F:\PreInstalled_Sequences\Vclips\1280x720
3
Page 6
Video Sequences Recovery Media
F:\PreInstalled_Sequences\Vclips\1920x1088
F:\PreInstalled_Sequences\Vclips\1920x1080
3. Remove the recovery media from the DVD drive of the instrument and
reinstall the front panel. The reinstalled video sequences are now ready to use.
