Tektronix Phaser 220e, Phaser 220i User Manual

User Manual
Phaser™ 220i and Phaser™ 220e Color Printers
First printing December 1993 070-8869-00
Copyright
©
1993 by Tektronix, Inc., Wilsonville, Oregon. Printed in the United States of America. All rights reserved. Contents of this publication may not be reproduced in any form without permission of Tektronix, Inc.
This instrument, in whole or in part, may be protected by one or more U.S. or foreign patents or patent applications. Information provided upon request from Tektronix, Inc., P.O. Box 1000, Wilsonville, Oregon 97070-1000.
If acquired subject to FAR or DFARS, the following shall apply:
Unpublished — rights reserved under the copyright laws of the United States.
Restricted Rights Legend — Use, duplication, or disclosures by the U.S. government is subject to restrictions as set forth in subparagraph (c)(1)(ii) of the Rights in T echnical Data and Computer Softwar e clause at DFARS
252.227-7013, or in subparagraph (c) (2) of the Commercial Computer Software – Restricted Rights clause at FAR 52.227-19, as applicable. Tektronix, Inc., P.O. Box 1000, Wilsonville, Oregon 97070-1000.
Tektronix
®
is a registered trademark of Tektronix, Inc. TekColor™, ColorCoat™, ColorStix™ and Finepoint™ are trademarks of Tektronix, Inc. Phaser™ is a trademark of Tektronix, Inc. for color printers and related products.
Adobe™ and PostScript™, and IntelliSellect™ are trademarks of Adobe Systems, Incorporated which may be registered in certain jurisdictions.
Times™, Helvetica™ and Palatino™ are trademarks of Linotype-Hell AG and/or its subsidiaries.
Other marks are trademarks or registered trademarks of the companies with which they are associated.
PANTONE
®
*
Colors generated by the Phaser 220i and 220e Color Printers are four-color process simulations and may not match PANTONE-identified solid color standards. Use current PANTONE Color Reference Manuals for accurate colors.
PANTONE Color simulations are only obtainable on these products when driven by qualified Pantone-licensed software packages. Contact Pantone, Inc. for a current list of qualified licensees.
*
Pantone, Inc.’s check-standard trademark for color reproduction and color reproduction materials.
© Pantone, Inc., 1988.
Users safety summary
Terms in manual:
CAUTION Conditions that can result in damage to the product. WARNING Conditions that can result in personal injury or loss of life.
Power source:
Do not apply more than 250 volts RMS between the supply conductors or between either supply conductor and ground. Use only the specified power cord and connector. Refer to a qualified service technician for changes to the cord or connector.
Operation of product:
Avoid electric shock by contacting a qualified service technician to replace fuses inside the product. Do not operate without the covers and panels properly installed. Do not operate in an atmosphere of explosive gases.
Safety instructions:
Read all installation instructions carefully before you plug the product into a power source.
Terms on product:
CAUTION A personal injury hazard exists that may not be apparent. For example, a
panel may cover the hazardous area. Also applies to a hazard to property including the product itself.
DANGER A personal injury hazard exists in the area where you see the sign.
Care of product:
Disconnect the power plug by pulling the plug, not the cord. Disconnect the power plug if the power cord or plug is frayed or otherwise damaged, if you spill anything into the case, if product is exposed to any excess moisture, if product is dropped or damaged, if you suspect that the pr oduct needs servicing or repair, and whenever you clean the product.
Ground the product:
Plug the three-wire power cord (with grounding prong) into grounded AC outlets only. If
necessary, contact a licensed electrician to install a properly grounded outlet.
Symbols as marked on product:
DANGER high voltage:
Protective ground (earth) terminal:
Use caution. Refer to the manual(s) for information:
WARNING:
If the product loses the ground connection, usage of knobs and controls (and other conductive parts)
can cause an electrical shock. Electrical product may be hazardous if misused.
!
User Manual
v
Contents
1 Introduction
2 Getting Set Up
At a glance 2-1 Setting up the printer 2-2
What you get with your printer 2-2 Installing the optional lower tray assembly 2-4 Removing the packing material from inside the printer 2-6 Install the transfer roll 2-7 Adding paper or transparencies 2-8
Connecting the printer 2-12
Printer ports 2-12 LocalTalk connection 2-13
Connecting the printer to a single computer using LocalTalk 2-14 Parallel connection 2-15 Serial connection 2-16 Ethernet connection (Phaser 220i only) 2-18 Connecting the power and turning on the printer 2-19
Front panel at power-up 2-20
Rear panel at power-up 2-21
Sample prints 2-21
Startup page 2-22
When the printer is ready for operation 2-22
Installing a driver on your computer 2-23
Phaser 220 drivers and utilities diskettes 2-23 PC users 2-23
Microsoft Windows 2-23
DOS 2-25 Macintosh users 2-26
Other software requirements 2-26 Workstation users 2-27
Turning off the sample prints 2-27 Turning off the startup page 2-27
vi
Phaser 220i and Phaser 220e Color Printers
Setting up PC ports (DOS) 2-28
Parallel port setup 2-28 Serial port setup 2-29
What next? 2-30
3 Printing
Printing from a Macintosh 3-1 Printing from a PC (Windows) 3-3 Printing from a PC (DOS) 3-4 Printing from a workstation 3-5 Margins and print area 3-6
Perforated paper and transparencies 3-6
Non-perforated plain paper 3-7 Using two paper trays 3-8 Selecting driver features 3-9 Getting information on printing from specific applications 3-9 Print modes 3-10 Color correction 3-11 Fonts 3-12
Resident typefaces (PostScript) 3-12
Resident typefaces (PCL5) 3-13
Downloading fonts 3-13
Font upgrade (Phaser 220e) 3-13
Installing Macintosh screen fonts 3-13 Printer languages: PostScript, HP-GL, PCL5 3-14
Enabling and disabling automatic language switching 3-14
Printing with HP-GL 3-15
Changing the HP-GL default settings 3-15
Printing hints 3-16
Getting the largest printed picture 3-16
Why should I use perforated paper? 3-16
How long does it take to make a print? 3-16
Which port is faster, parallel or serial? 3-16
User Manual
vii
4 Caring for Your Printer
Overview 4-1
Importance of cleaning 4-1 When to clean 4-2 Cleaning kit 4-3
Cleaning the printer (with every transfer roll change) 4-4
Cleaning the thermal head and transfer roll guide 4-4 Cleaning the paper-feed rollers 4-5 Cleaning the paper-pick rollers 4-6
Cleaning the printer (every 5000 prints) 4-10
Cleaning the transfer roll sensor pad 4-10 Cleaning the drum 4-12 Cleaning the exit rollers 4-13
5 Supplies
Always use Tektronix supplies 5-1 Ordering information 5-1 Supplies kits 5-1 Using plain paper 5-2
ColorCoat™ transfer roll 5-2 Use the correct paper tray for plain-paper printing 5-3 Plain-paper startup kit 5-3 Recommended paper types 5-4 Handling supplies 5-6
Removing a used transfer roll 5-7
6 Troubleshooting
Clearing transfer roll jams 6-1 Clearing paper jams 6-2
To remove paper from the drum: 6-3
Problems and solutions 6-5
If you can't make a print 6-5
Printer not operating 6-5
viii
Phaser 220i and Phaser 220e Color Printers
Printer doesn't appear in the Chooser 6-7 READY light blinks, but the file does not print 6-7 MEDIA light blinks, and no print is produced 6-7 Print job does not finish (the printer times out) 6-7
Media problems 6-8
Frequent paper-picking errors 6-8 Frequent paper jams 6-8 You feel resistance when installing the paper tray 6-8
Problems with image size and position 6-9
Off-set images 6-9 Cut-off images 6-9 Image prints over perforations 6-9 Margins are too big with perforated paper or transparencies 6-9 Image shifts or margins are incorrect (Macintosh) 6-9
Print quality problems 6-10
Plain paper prints have dull, faded colors and significant dropout 6-10 Prints on thermal-transfer paper or transparencies have dull colors 6-10 Streaks or spots 6-10 Black-and-white instead of color 6-11
Startup page prints even though it is disabled 6-12 Generating the configuration page 6-13 Whom to call for help 6-14
HAL — Highly Automated Library 6-14
7 Front and Rear Panels
Rear panel (Phaser 220e) 7-1
Rear panel DIP switches (Phaser 220e) 7-2 Rear panel (Phaser 220i) 7-3
Rear panel DIP switches (Phaser 220i) 7-4 Front panel (Phaser 220i and Phaser 220e) 7-6
User Manual
ix
A Technical Notes
Printer ports A-1
Parallel port A-1 Serial port A-3
Serial port signals A-4
Specifications A-5
B Expanding Your Printing System
Upgrade kits B-1 Advantages of adding memory B-2 Adding a hard disk for font storage (Phaser 220i only) B-3
Compatible hard disks B-3 Requirements for adding a hard disk B-3 Connecting one disk B-5 Connecting multiple disks B-6
C Moving Your Printer
Changing the line voltage C-1 Repacking your printer C-2
D Regulatory Information
Canadian EMC (Electromagnetic Compatibility) regulatory standards D-1 Declaration of conformity D-2 FCC Class B device (for 115 VAC equipment) D-3 Material Safety Data Sheet D-4
Index
x
Phaser 220i and Phaser 220e Color Printers
User Manual
1-1
Chapter
1
Introduction
The Tektronix Phaser 220i and Phaser 220e are thermal-wax color printers that provide superior quality A/Letter-size and A4-size color prints. Both printers provide color printing at speeds up to two pages per minute. Both printers are PANTONE Color approved and include TekColor imaging enhancements.
Both printers deliver 300 x 300 dots-per inch (dpi) color resolution in their default printing modes. A driver-selectable high-resolution printing mode gives you 600 x 300 dpi resolution for the sharpest, clearest thermal-wax prints imaginable.
An optional lower tray assembly is available for both printers; the optional lower tray assembly provides dual-tray printing capability. Printing from two trays allows you to have paper and transparencies ready for printing at all times without switching trays. You can also load the same media in both trays.
Phaser 220 printers can provide vivid color on common laser paper, coated thermal-transfer paper, and transparencies. A specially formulated transfer roll gives prints on standard laser paper the brilliant color quality pr eviously available only with coated thermal-transfer papers.
By using Tektronix
perforated paper and transparencies, you can print full
A/Letter-size or A4-size images with ISO (International Standards Organization) margins (5 mm; 0.2 in.).
1
Introduction
1-2
Phaser 200i and Phaser 200e Color Printers
Phaser 220 printers work with Macintosh computers, IBM Personal Computers and compatibles, and various workstations. You can print from several computers at the same time because the Phaser 220 printers support simultaneous input through serial, parallel, and LocalTalk ports. With the Phaser 220i, an optional Ethernet interface provides Ethernet connectivity with EtherTalk and Novell NetWare protocols. The TCP/IP protocol is also available by purchasing an additional option.
The Phaser 220i also provides a SCSI (Small Computer System Interface) port, which allows you to attach an external hard disk for additional font storage.
Phaser 220 printers let you make color prints from a variety of software applications since they incorporate Adobe's PostScript Level 2 software (based on Adobe PostScript code revision 2013) and accept HP-GL (Hewlett-Packard Graphics Language) files. Also, the printer can accept monochrome PCL5 (Printer Command Language) files. The Phaser 220 printer interfaces can automatically switch between all of the three supported languages: PostScript, HP-GL, and PCL5.
The Phaser 220i has 39 resident PostScript fonts; the Phaser 220e has 17 resident PostScript fonts, upgradable to 39. Both printers have PCL5 fonts resident. The printers accept the following types of fonts:
Adobe Type 1
Adobe Type 3
TrueType
A variety of user-defined fonts
To order supplies such as paper, transparencies, or color transfer rolls, refer to the supplies information sheet that is shipped with the printer and contact your local dealer or, in the U.S.A., call Tektronix at
1-800-835-6100 .
User Manual
2-1
Chapter
2
Getting Set Up
At a glance
To install your printer, perform the steps listed here. The following pages provide detailed installation instructions. If you used the pictorial installation instructions, you have already performed Steps 1 and 2. Begin with Step 3; turn to “Installing a driver on your computer” on page 2-23.
1.
Setting up the printer
Putting all the pieces together: unpacking the printer and accessories, checking the inventory, removing the packing material, installing the optional lower tray assembly, loading the transfer roll, loading the paper tray(s), and setting the media switch for paper or transparencies.
2.
Connecting the printer
Connecting all necessary cables and turning on the printer.
3.
Installing a driver on your computer
Using the Phaser 220 driver diskettes to install a driver on your computer (Macintosh or Windows).
4.
Turning off the sample prints and the start page
5.
Setting up serial or parallel computer ports (DOS)
Note
For instructions for adding a hard disk to your printer, see “Adding a hard disk for font storage (Phaser 220i only)” on page B-3.
2
Getting Set Up
2-2
Phaser 220i and Phaser 220e Color Printers
Setting up the printer
What you get with your printer
1.
Lower tray assembly (optional)
2.
Paper tray(s)
3.
Sample transfer roll
4.
Power cord
5.
Getting Started envelope
6.
Cleaning kit
7.
User manual
8.
Supplies information sheet
9.
Transparencies
10.
Thermal-transfer paper
11.
Phaser 220 Drivers and Utilities Printing Reference manual
12.
Tektronix Phaser 220 drivers and utilities diskettes
13.
Network Utilities for Phaser Color Printers (manual; optional with
the Phaser 220i)
14.
Tektronix network utilities diskettes (optional with the Phaser 220i)
Getting Set Up
2
User Manual
2-3
4
8
6
7
5
9
10
8869-2
11
12
3
Transfer
Roll
Cleaning
Kit
Supplies
Reference
Manual
User
Manual
13
Network
Manual
14
2
Transparency
Sample
1
Paper
Sample
Getting Started
2
Getting Set Up
2-4
Phaser 220i and Phaser 220e Color Printers
Installing the optional lower tray assembly
An optional lower tray assembly is available with both Phaser 220 printers; with the optional lower tray assembly, you can print from two trays.
Note
The printer weighs about 18 kg. (40 lbs.). Observe standard precautions for lifting heavy objects.
Warning
The printer is not permanently attached to the lower tray assembly. Take care to move the printer and lower tray assembly together by using the slots on the sides of the lower tray assembly. Moving the printer incorrectly may damage it and may cause personal injury.
Getting Set Up
2
User Manual
2-5
If you have a lower tray assembly, install it by performing these steps:
1.
Place the printer on top of the lower tray assembly.
2.
Make sure that the left and right alignment pins fit in the holes in the base of the printer.
3.
Plug the lower tray assembly cable into the printer.
4.
To move the printer, use the slots on either side of the lower tray assembly. Observe standard precautions for lifting heavy objects. To move the printer more than a few feet, it is easier to disconnect the lower tray assembly and move it separately from the printer.
Note
When using a Phaser 220 with the optional lower tray assembly installed, make sure that the door covering the upper slot is closed. You cannot print from the lower tray with the door open.
8869-18
1
2
3
1
...
..
...
.
SECOND
FEEDER
TEST
SWITCH
4
2
Getting Set Up
2-6
Phaser 220i and Phaser 220e Color Printers
Removing the packing material from inside the printer
1.
Remove the packing tape from the top and front covers.
2.
Press the button; open the top cover.
3.
Remove the shipping material from the sides of the drum. (Keep all shipping material for storing or shipping the printer).
8869-3
2
3
Getting Set Up
2
User Manual
2-7
Install the transfer roll
Note
ColorCoat transfer rolls are used with common laser paper; black and 3-color transfer rolls are used with Tektronix transparencies, thermal-transfer paper, and perforated premium laser paper.
With the top cover still open, install the transfer roll:
1.
Remove the transfer roll from the box. Remove the shipping foam from the transfer roll. Remove the foam clip from the full end of the roll.
2.
Hold the transfer roll so that the black band on the roll is on your left.
3.
With the black band on the r oll to your left, place the empty end of the roll in the slots at the front of the printer.
4.
Place the full end of the roll in the slots at the back of the printer.
5.
Turn the full end of the roll to remove slack.
6.
Close the cover.
8869-19
3
2
4
5
2
Getting Set Up
2-8
Phaser 220i and Phaser 220e Color Printers
Adding paper or transparencies
Unpack the paper tray. Be sure to remove all adhesive tape.
Note
The printer uses a different paper tray for each paper size (Letter, Letter-perforated, A4, A4-perforated). The trays are not adjustable.
1.
If you are using a tray for perforated paper or transparencies, set the selection switch on the tray (
1) for paper or transparencies.
Trays for non-perforated plain paper do not have this switch.
2.
Make sure that the metal plate is all the way down. If necessary, push the metal plate down until it clicks into place. Do not attempt to change the position of the vertical tab (3) at the back of the paper tray.
TRANSPARENCY
PAPER
1
8869-20
8869-12
23
Getting Set Up
2
User Manual
2-9
3.
Fan the paper or transparencies.
4.
Load perforated paper or transparencies with the perforations toward the front of the tray.
5.
Place paper or transparencies in the tray under the hooks. Load transparencies with the film side up. Load thermal-transfer paper with the shiny side up (not applicable for plain paper).
8869-21
8869-22
5
4
2
Getting Set Up
2-10
Phaser 220i and Phaser 220e Color Printers
6.
If your printer has a single paper tray, push the paper tray into the slot.
6
8869-23
Getting Set Up
2
User Manual
2-11
7.
If your printer has a lower tray assembly:
a.
Install a tray in the lower slot.
b.
Open the door to install a tray in the upper slot.
8869-4
7a
8869-5
7b
2
Getting Set Up
2-12
Phaser 220i and Phaser 220e Color Printers
Connecting the printer
Printer ports
Both the Phaser 220i and Phaser 220e printers accept data through these ports:
LocalTalk
Parallel
Serial (RS-232)
The Phaser 220i has a SCSI port, which is used only for connecting an external hard disk. Refer to “Adding a hard disk for font storage (Phaser 220i only)” on page B-3 for more information on the SCSI port.
The Phaser 220i also has an Ethernet connector. An optional Ethernet interface is required to activate the connector. The optional Ethernet interface provides Ethernet connectivity with EtherTalk and Novell NetW are protocols. The TCP/IP protocol is also available by purchasing an additional option.
Getting Set Up
2
User Manual
2-13
LocalTalk connection
You can make LocalTalk connections between the printer and a single computer or on a LocalTalk network using a daisy-chain setup. If your LocalTalk installation is complex, or if you need assistance, contact your network system administrator.
LocalTalk connectors and cables are available through your dealer. This illustration shows two commonly used types of LocalTalk connectors:
1.
Self-terminating connector
2.
Connector that requires an external terminator, depending on your network configuration
Note
Depending on the type of LocalTalk cables you use and your network configuration, you might need to use terminators at certain points in the installation. Refer to the documentation for your LocalTalk connectors and cables for details.
Note
LocalTalk is sometimes referred to as AppleTalk. LocalTalk refers to the physical connection; AppleTalk is the protocol.
8869-18
2
3
1
...
..
...
.
SECOND FEEDER
TEST
SWITCH
4
2
Getting Set Up
2-14
Phaser 220i and Phaser 220e Color Printers
Connecting the printer to a single computer using LocalTalk
You can use LocalTalk connectors and cables to connect the printer directly to your computer, without connecting it to any other network. Make sure that the printer is turned off before making any LocalTalk connections.
1.
Connect the short cable of a LocalTalk connector to the printer's LocalTalk port.
2.
Connect the short cable of another LocalTalk connector to your computer's LocalTalk port.
3.
Connect a LocalTalk cable from the LocalTalk connector that you have just attached to your computer to the printer's LocalTalk connector.
For details on how to select the printer in the Chooser, change the printer’s name, or set the printer’s zone, refer to the manual Phaser 220 Drivers and Utilities Printing Reference. If you have no other connections to make, turn immediately to “Connecting the power and turning on the printer” on page 2-19.
8869-24
3
2
1
LocalTalk®
Getting Set Up
2
User Manual
2-15
Parallel connection
1.
Connect a parallel interface cable to your computer and to the printer's parallel port.
2.
If you have no other connections to make, turn immediately to “Connecting the power and turning on the printer” on page 2-19. After you turn on the printer and install a driver on your computer, you may disable timeouts on your computer's parallel port (see “Setting up PC ports (DOS)” on page 2-28).
8869-6
Phaser 220i
1
Phaser 220e
1
2
Getting Set Up
2-16
Phaser 220i and Phaser 220e Color Printers
Serial connection
1.
Connect a serial interface cable to your computer and to the printer's serial port. Use a null-modem cable (if you need to order a cable, see the supplies information sheet that is shipped with the printer).
2.
Set the rear panel DIP switch(es) for the baud rate you want. The following table lists the switch settings.
Baud rate settings for Phaser 220i and Phaser 220e
Printer Baud rate Switch setting
Phaser 220i Variable,
9600 default
Switch 7
down
Fixed, 1200 Switch 7
up
Phaser 220e Variable,
9600 default
Setting Switches 2, 3, and 4
down
enables the variable baud rate and sets other printer functions to default values. Refer to Chapter 7 for details on all printer functions affected by the rear panel DIP switches.
Fixed, 1200 Switch 2
up
, and switches 3 and 4
down
. This setting also turns off color adjustment and sample prints. Refer to Chapter 7 for details on all printer functions affected by the rear panel DIP switches.
8869-13
Phaser 220i
1
Phaser 220e
1
2 2
Getting Set Up
2
User Manual
2-17
Note
With the serial port set for variable baud rate, the default baud rate is 9600, however, you can change the baud rate to a setting other than 9600. For details, refer to the manual Phaser 220 Drivers and Utilities Printing Reference.
If you have no other connections to make, turn to the topic “Connecting the power and turning on the printer” on page 2-19. After you turn on the printer and install a driver on your computer, you must set up your computer's serial port to match the settings you have selected for the printer's serial port (see “Setting up PC ports (DOS)” on page 2-28).
2
Getting Set Up
2-18
Phaser 220i and Phaser 220e Color Printers
Ethernet connection (Phaser 220i only)
Ethernet is a communication standard that supports very high speed data transmission. For complete information on installing the Phaser 220i on Ethernet networks, refer to the manual Network Utilities for Phaser Color Printers.
The Phaser 220e can be attached to Ethernet networks by using the Tektronix 4511A Network Interface. The 4511A Network Interface supports the TCP/IP protocol. See your authorized Tektronix representative for 4511A ordering information.
Note
For information on connecting your Phaser 220 in VMS environments, contact Tektronix Customer Support.
Getting Set Up
2
User Manual
2-19
Connecting the power and turning on the printer
1.
Plug the power cord into the printer and into a grounded outlet.
2.
Turn on the printer.
When you turn on the printer, it executes a series of self-tests to determine if there are any problems. After running self-tests, the printer prints sample prints, if sample prints are enabled. (The factory default is to have sample prints enabled.) After running self-tests and printing the sample pages, the printer is ready for operation. The entire power-up sequence can last from 6 to 7 minutes, depending on the type of transfer roll installed and whether the sample pages are enabled. The next few topics describe the printer's power-up sequence in detail.
8869-25
1
1
POWER
OFF ON
2
2
Getting Set Up
2-20
Phaser 220i and Phaser 220e Color Printers
Front panel at power-up
All indicators light briefly and immediately go out, except POWER and READY, which remain on for about 10 seconds. Then the READY indicator
blinks while the POWER indicator remains on and the self-tests are run. When both POWER and READY are on steady (not blinking), the self-tests are complete.
When a standard transfer roll is more than 75 percent used up, the front-panel RIBBON indicator lights, reminding you that it is time to order a new transfer roll.
When you install the sample transfer roll supplied with the printer, the RIBBON indicator may light as soon as you install it, or after you make a few prints. This is because the sample transfer roll contains a limited number of prints.
For complete information on the front-panel indicator lights, refer to “Front panel (Phaser 220i and Phaser 220e)” on page 7-6.
ERROR JAM RIBBON COVER
READY
POWER
8869-26
MEDIA
Getting Set Up
2
User Manual
2-21
Rear panel at power-up
During the first 40 - 60 seconds of the power-up sequence, the rear-panel status indicator (
1) goes on and off periodically. After about 40 - 60 seconds,
the status indicator blinks continuously, indicating that the printer is ready for normal operation.
Sample prints
After the self-tests run successfully, the printer prints three sample prints, if the sample prints are enabled. These sample prints verify that the printer is ready for normal operation and show you the brilliant color you can get with the Phaser 220. The samples take about four minutes to print. The READY indicator blinks while the sample pages are printing.
When sample prints are enabled, the samples are printed whenever you turn on the printer. For details on how to disable the sample prints, see “Turning off the sample prints” on page 2-27.
Note
If the startup page is disabled, the sample prints do not print.
8869-8
Phaser 220i
Phaser 220e
1
1
2
Getting Set Up
2-22
Phaser 220i and Phaser 220e Color Printers
Startup page
When sample prints are disabled, the printer produces a startup page after the self-tests run successfully, if the startup page is enabled. The printer takes from 15 to 45 seconds to print the startup page, depending on the type of transfer roll installed. The READY indicator blinks while the startup page is printing.
The startup page contains information on printer configuration and error messages. When enabled, the startup page prints whenever you turn on the printer. For details on how to disable the startup page, refer to the manual Phaser 220 Drivers and Utilities Printing Reference.
Note
After the startup page prints, a registration page prints if the printer has made between 6 and 8 prints since it was built. If you have not already registered your printer, please do so by filling out this page and sending it in.
When the printer is ready for operation
When the power-up sequence is complete, both the POWER and READY indicators remain on, indicating that the printer is ready for operation.
Getting Set Up
2
User Manual
2-23
Installing a driver on your computer
Phaser 220 drivers and utilities diskettes
Packaged with your printer are the Phaser 220 drivers and utilities diskettes for PC and Macintosh.
For complete details on the contents of the Phaser 220 drivers and utilities diskettes and how to use them, refer to the manual Phaser 220 Drivers and Utilities Printing Reference, which is shipped with the diskettes.
PC users
Microsoft Windows
The Phaser 220 diskettes include a Microsoft Windows 3.1 driver for this printer . If you want to use Microsoft Windows applications with this printer, install the driver onto your PC.
To install the Tektronix Windows 3.1 driver:
1.
Start Windows on your PC.
2.
Insert the Tektronix Windows 3.1 Printer Driver diskette into your computer’s disk drive.
3.
Open the Control Panel. Double-click the Printers icon; the Printers dialog box appears.
4.
Choose the Add button.
5.
In the List of Printers, select Install Unlisted or Updated Printer.
6.
Choose the Install button.
7.
Type in the drive that the PC diskette is in (for example, drive B) and click on the
OK button.
2
Getting Set Up
2-24
Phaser 220i and Phaser 220e Color Printers
8.
Select your printer and click on OK.
9.
The driver software you need is automatically installed.
10.
Assign the printer to a port:
a.
Select the printer from the list of installed printers.
b.
Choose the Connect button to display the Connect dialog box.
c.
Set the Transmission Retry value to 995. Refer to your Windows documentation for details.
d.
Select a port:
Interface
Select
Parallel LPT1 or LPT2 Serial COM1 or COM2 Network Network button
If you selected a parallel port, go on to step e. If you selected a serial port, click on the Settings button to
open the Settings dialog box. Fill in each item according to your configuration, then click on
OK. Refer to your Windows
documentation for details or ask your network administrator for help.
If you clicked on the Network button, the Printers – Network Connections dialog box appears. Fill in each item according to your configuration. Refer to your Windows documentation for details or ask your network administrator for help.
Note
The printer’s configuration page contains the information you need to set up the printer port. For information on generating a configuration page, see “Generating the configuration page” on page 6-13.
e.
Click on OK in the Connect dialog box and close the Printers dialog box.
Getting Set Up
2
User Manual
2-25
Note
If you are using Windows 3.1, you can use the Phaser 220 with the standard Microsoft Windows PostScript driver (with a WPD file). With the standard driver, you get the printer page size information, but you do not get color corrections and other PostScript Level 2 features; those features are only available through the Tektronix driver for Windows 3.1. For details on WPD files, refer to the manual Phaser 220 Drivers and Utilities Printing Reference.
The manual Phaser 220 Drivers and Utilities Printing Reference provides a detailed driver installation procedure and complete information on using the Tektronix driver or the standard Windows PostScript driver with the printer.
DOS
Check the list of supported printers in your DOS application for support of the Phaser 220i or Phaser 220e. If the list does not include the Phaser 220i or Phaser 220e, use a generic color PostScript driver.
2
Getting Set Up
2-26
Phaser 220i and Phaser 220e Color Printers
Macintosh users
Install the Phaser 220i or Phaser 220e driver onto your Macintosh to make the best use of the printer. Phaser 220i and Phaser 220e drivers allow you to select Tektronix Phaser page sizes, upper and lower paper trays, and color adjustments. The driver works under Macintosh system software versions
6.0.7, 7.0.x, and above.
To install the driver:
1.
Before installing the driver, disable all virus protection software you may have running. Virus protection software interferes with the driver installation. Refer to the program’s documentation for instructions.
2.
Insert the Macintosh Printer Driver diskette into the disk drive.
3.
Double-click on the Installer icon.
4.
Follow the directions on the screen to complete the driver installation.
The manual Phaser 220 Drivers and Utilities Printing Reference provides a detailed driver installation procedure and complete information on using the Tektronix driver with the printer.
Other software requirements
In addition to installing the driver, you may also need to install application-specific files (such as PPDs or PDFs) for such applications as PageMaker and QuarkXpress. For complete software requirements, refer to the manual Phaser 220 Drivers and Utilities Printing Reference.
Getting Set Up
2
User Manual
2-27
Workstation users
The files on the Phaser 220 utilities diskettes are in PC format and can be used by Unix workstations to control Tektronix printer features. They are also available through electronic mail (see the manual Phaser 220 Drivers and Utilities Printing Reference for details).
You can copy these files to your workstation as you would other PC-format files (log on as root, mount the drive, and use the cp command). For detailed information on using these utility files, refer to the Phaser 220 Drivers and Utilities Printing Reference.
Turning off the sample prints
To disable the sample prints, use the DIP switches on the printer’s rear panel. Set Switches 2, 3, and 4 down.
When the sample prints are disabled, a startup page will print at power-up if the startup page is enabled.
Turning off the startup page
You can disable the startup page by sending a PostScript language file from the printer’s utilities diskette to the printer. For details on how to disable the startup page, refer to the manual Phaser 220 Drivers and Utilities Printing Reference.
Even when the startup page is enabled, you can still keep it from printing by removing the paper tray(s) at power-up. Put the paper tray(s) back in after the READY light stops blinking.
2
Getting Set Up
2-28
Phaser 220i and Phaser 220e Color Printers
Setting up PC ports (DOS)
Parallel port setup
If you are using the printer's parallel port, you should disable timeouts on your computer's parallel port. Disabling timeouts ensures that large files will print, even if data transmission is slow.
The DOS MODE command is used to disable timeouts on your computer's parallel port. Type this command at the DOS prompt (if LPT1 is not available, use LPT2):
MODE LPT1:,,P > NUL
See your DOS documentation for details on the MODE command.
You may want to add the MODE command to your AUTOEXEC.BAT file, so that it takes effect every time you turn on your computer.
Getting Set Up
2
User Manual
2-29
Serial port setup
If you are using the serial port, you must set up your computer's serial port parameters to match the way you set the printer's serial port parameters.
Under DOS, use the MODE command to set up your computer's serial port:
If you set up the printer's serial port for variable baud rate and
you are using the default serial parameters for this position, type this command at the DOS prompt (if COM1 is not available, use COM2):
MODE COM1:9600,N,8,1,P
If you changed the printer's serial port parameters from the default values, you must enter different values for the MODE command (see your DOS documentation for details on the MODE command).
If you set up the printer's serial port for a fixed baud rate of 1200,
type this command at the DOS prompt (if COM1 is not available, use COM2):
MODE COM1:1200,N,8,1,P
For a complete listing of the printer's default serial port parameters, see “Serial port” on page A-3.
You may want to add the MODE command to your AUTOEXEC.BAT file, so that it takes effect every time you turn on your computer.
2
Getting Set Up
2-30
Phaser 220i and Phaser 220e Color Printers
What next?
Once you have set up all the hardware and connectors, installed
the software on your computer, and turned on the power, you are ready to print. Chapter 3, “Printing,” contains useful information on printing features such as color adjustment, fonts, and printing hints. For detailed information on printing options, refer to
Phaser 220 Drivers and Utilities Printing Reference.
To install a hard disk for font storage, turn to “Adding a hard disk
for font storage (Phaser 220i only)” on page B-3.
User Manual
3-1
Chapter
3
Printing
Printing from a Macintosh
1.
Make sure that the Tektronix printer driver for the Macintosh has been installed.
2.
Select the driver:
a.
Select Chooser from the Apple menu.
b.
Select the Tektronix driver by clicking on the Phaser 220 printer icon. (If it did not appear in the list of drivers, restart your Macintosh and repeat the driver installation procedure.)
A list of printers available in the current zone appears.
c.
Select the zone where your Phaser 220 is connected.
d.
Select the printer by name (default is Phaser 220i or Phaser 220e).
You can change the default with the LaserWriter Utility, which is on the drivers and utilities diskettes. See the Phaser 220 Drivers and Utilities Printing Reference for instructions.
3
Printing
3-2
Phaser 220i and Phaser 220e Color Printers
3.
To print a file, use the Page Setup and Print commands from the File menu within your application:
a.
In the Page Setup dialog box, select the desired Tektronix paper size so that the application uses the correct margins for the printer. To see the Tektronix paper sizes in the Page Setup dialog box, use the pop-up menu to the right of the standard LaserWriter page sizes.
b.
Click the TekColor button in the Print dialog box to open the TekColor Options dialog box, in which you can select T ekColor color corrections, print quality ( Standard, Enhanced, High-resolution), and paper trays (Upper, Lower, AutoSelect). For more details on the driver, refer to Phaser 220
Drivers and Utilities Printing Reference.
Printing
3
User Manual
3-3
Printing from a PC (Windows)
1.
Make sure that the Windows printer driver has been installed.
2.
Click on the Printer Setup command from the File menu (or the similar command in your application). Select Tek Phaser 220 (TekColor) from the list. If you have previously set the printer as the default printer, it will already be selected on the list.
3.
Use the Setup dialog box to select the paper size, paper source (Upper tray, Lower tray, or Auto Select), and other printing options.
4.
Click on the Options button to display the Options dialog box. Then, click on the Printer Features button to display the Tektronix Printer Features dialog box. Use the Tektronix Printer Features dialog box to select TekColor color corrections and print quality (Standard, Enhanced, High-resolution). If the Printer Features button does not appear in the Options dialog box, the Tektronix Windows driver pr obably is not installed or the Phaser 220 has not been selected.
For details on the Tektronix driver, refer to Phaser 220 Drivers and Utilities
Printing Reference.
3
Printing
3-4
Phaser 220i and Phaser 220e Color Printers
Printing from a PC (DOS)
1.
Set up the printing options in your application software for a color printer driver and a communications port. Refer to your application software user manual for details on how to make these selections.
2.
Select the printer driver for the Phaser 220i or Phaser 220e, or a general color PostScript driver.
a.
Select an LPT port if you have the printer connected to the parallel port, or select a COM port if you have the printer connected to the serial port.
b.
Set the page margins in your application software as needed. For details on the printer's paper and margin sizes, refer to “Margins and print area” on page 3-6.
3.
Execute the application software's print command. Refer to the software's user manual for details.
Printing
3
User Manual
3-5
Printing from a workstation
You send files to this printer as you would any PostScript printer such as the Apple LaserW riter II NTX. Workstation users can print from any application that generates PostScript (Level 1 or 2), HP-GL, or PCL5.
Sun and SGI users can use Tektronix' Unix Phaser Print software with Tektronix color printers. Phaser Print provides fast raster screen copy printing to Tektronix color printers. Phaser Print also provides a graphical user interface for push-button control of certain Tektronix printer features.
Unix Phaser Print for Sun works with lpr to print PostScript files and raster files in these formats: Sun Raster Format (SRF), xwd, and SGI/RGB.
Unix Phaser Print for SGI works with lp to print ASCII text files, PostScript files, and raster files in these formats: SGI/RGB and xwd. Unix Phaser Print for SGI requires the Impresario printing software from SGI.
For more information on setting up spooling systems and printing from workstations, contact HAL, the Tektronix automated FAX system. Refer to “Whom to call for help” on page 6-14 for details on using the HAL system.
3
Printing
3-6
Phaser 220i and Phaser 220e Color Printers
Margins and print area
When the printer places an image on paper, the image is a bit smaller than the paper size. You may need to adjust the page margins in your application software to match the print area.
Perforated paper and transparencies
Use Tektronix perforated paper or transparencies and the Tektronix Phaser 220i or Phaser 220e driver to get the largest image areas. With Tektronix perforated paper or transparencies, you can print the largest area and tear off the excess at the perforation. This gives full A or A-4 Letter-size images within ISO margins.
This illustration shows the largest image areas for perforated paper and transparencies. All margins are 5 mm (0.2 in.). The bottom margin is 5 mm (0.2 in) after the perforated area is removed.
1.
American A-size (LETTER PERF)
2.
Metric A4-size (A4 PERF)
1
8869-27
2
210 x 313 mm
8.5 x 12.3 in.
200 mm
287 mm
8.1 in.
10.6 in.
Printing
3
User Manual
3-7
Non-perforated plain paper
This illustration shows the largest image areas for non-perforated plain paper. All margins are 5 mm (0.2 in.), except the bottom margin (21 mm for A4-size, 0.83 in. for A-size).
Note
The standard trays supplied with the printer are for Tektronix perforated paper and transparencies; they are not adjustable for plain paper. Trays for plain paper must be ordered separately.
1.
American A-size (LETTER)
2.
Metric A4-size (A4)
210 x 297 mm
8.5 x 11 in.
1
8869-28
200 mm
271 mm
10 in.
8.1 in.
2
3
Printing
3-8
Phaser 220i and Phaser 220e Color Printers
Using two paper trays
Note
When using a printer with a lower tray assembly, make sure that the door covering the upper slot is closed before you try to make a print from the lower tray. You cannot print from the lower tray with the door open.
You can select the Upper or Lower tray by using a Tektronix Phaser 220 driver or a PostScript language file provided on the printer’s utility diskettes. If you select the upper or lower tray by one of these methods, the printer will pick paper from the selected tray until the tray is empty. When the tray is empty, printing stops until the selected tray is filled, or until you select the other tray.
You can also select AutoSelect by using a Tektronix Phaser 220 driver or a PostScript language file provided on the printer’s utility diskettes. If you select AutoSelect by one of these methods, the printer will pick paper from the tray that contains the selected paper size. When that tray is empty, the printer will automatically pick from the other tray if it also contains the selected media size.
Note
Paper tray selections made in the driver take priority over selections made by sending PostScript files to the printer.
In all cases, you can change the printer's tray-switching behavior by sending the appropriate PostScript language file to the printer. For more information, see the manual Phaser 220 Drivers and Utilities Printing Reference.
Recommended paper tray selections
Use If Upper or
Lower tray
You use different media in each tray or different sizes in each tray. Some examples:
Paper in one tray and transparency in the other.
Standard paper in one tray and special letterhead in the other.
Perforated paper in one tray and non-perforated in the other.
AutoSelect You use the same media in both trays.
Printing
3
User Manual
3-9
Selecting driver features
You can use the Phaser 220i or Phaser 220e drivers to select Phaser 220 features:
Page sizes
Paper tray
Color adjustments
Print modes
For complete instructions on installing and using the Phaser 220 drivers, see the manual Phaser 220 Drivers and Utilities Printing Reference.
Getting information on printing from specific applications
You can get information on printing from specific applications by contacting HAL, the Tektronix automated information system. HAL faxes you information immediately on applications and other topics. For complete information on HAL, see “Whom to call for help” on page 6-14.
3
Printing
3-10
Phaser 220i and Phaser 220e Color Printers
Print modes
The printer has three driver-selectable print modes:
Standard mode is the default. It provides high-quality
300 x 300 dpi prints with the fastest print time.
Enhanced mode provides improved 300 x 300 dpi prints; print
time is increased by 10 seconds over Standard mode.
High-resolution mode provides exceptionally high-quality
600 x 300 dpi prints. In High-resolution mode, image processing time is about 30% longer than with Standard mode. Also, the printer’s paper-marking speed can be up to twice as long as Standard mode. (The paper-marking speed is the time it takes the printer to put the colored wax on the paper after it has processed the image).
Printing
3
User Manual
3-11
Color correction
There are several ways to correct colors on your prints:
Using a printer driver or a utility file.
For details on making color corrections through a printer driver or a utility file, refer to Phaser 220 Drivers and Utilities Printing Reference.
Using the color correction switches on the printer’s rear panel.
The Phaser 220 allows you to make color corrections using the printer’s rear-panel DIP switches. For specific information on DIP switch settings, see Chapter 7.
Using the rear panel switches for color correction is only necessary if you are not set up to use the Phaser 220 drivers. If you are using TekColor Dynamic Correction in the Phaser 220 drivers, the settings you choose in the drivers override the rear panel switches.
For complete information on color correction, refer to Phaser 220 Drivers and Utilities Printing Reference.
3
Printing
3-12
Phaser 220i and Phaser 220e Color Printers
Fonts
Resident typefaces (PostScript)
The standard Phaser 220i supports all typefaces shown. The Phaser 220e ships with 17 fonts; additional fonts can be added by adding Option 1F or the equivalent upgrade kit, 4680F1F.
1.
Resident typefaces for Phaser 220e without Option 1F.
2.
Additional resident typefaces provided with Phaser 220e Option 1F.
8869-29
Courier
Courier Bold
Courier Oblique
Courier Bold Oblique
Helvetica
Helvetica Bold
Helvetica Oblique
Helvetica Bold Oblique
Helvetica Narrow
Helvetica Narrow Bold
Helvetica Narrow Oblique
Helvetica Narrow Bold Oblique
Times Roman
Times Bold
Times Italic
Times Bold Italic
Symbol ( Σψµβολ)
New Century Schoolbook
New Century Schoolbook Bold
New Century Schoolbook Italic
New Century Schoolbook Bold Italic
ITC Bookman Light
ITC Bookman Light Italic
ITC Bookman Demi
ITC Bookman Demi Italic
Palatino
Palatino Italic
Palatino Bold
Palatino Bold Italic
ITC Avant Garde Gothic Book
ITC Avant Garde Gothic Book Oblique
ITC Avant Garde Gothic Demi
ITC Avant Garde Gothic Demi Oblique
Helvetica Condensed
Helvetica Condensed Bold
Helvetica Condensed Oblique
Helvetica Condensed Bold Oblique
ITC Zapf Chancery
ITC Zapf Dingbats (✩ ✴ ✣ ✺ ❁ ❐ ❆)
1 2
Printing
3
User Manual
3-13
Resident typefaces (PCL5)
In PCL5 mode (HP LaserJet III emulation), the printer supports Courier, Times, and Universe typefaces in the following styles and stroke weights: medium, bold, italic medium, and bold italic.
Downloading fonts
The printer accepts Type 1, Type 3, and TrueType downloadable fonts including those from Adobe, AGFA, Bitstream, and many others. TrueType fonts are scalable to any point size and look the same on the screen as they do when printed.
If you have an external hard disk connected to the Phaser 220i, you can store the downloadable fonts on it. You can use utilities on the Phaser 220 printer utilities diskettes to download fonts to the printer. For details, see the manual Phaser 220 Drivers and Utilities Printing Reference.
Font upgrade (Phaser 220e)
You can upgrade the Phaser 220e to 39 resident fonts (the same as the Phaser 220i). The font SIMM for this upgrade is available as Option 1F or upgrade kit 4680F1F.
Installing Macintosh screen fonts
Phaser 220 Macintosh diskettes include screen fonts for these typeface families: Times, Helvetica, Courier, Symbol, Helvetica Condensed, Helvetica Narrow, Palatino, ITC Avant Garde Gothic, ITC Bookman, ITC Zapf Chancery, ITC Zapf Dingbats, and New Century Schoolbook.
If they are not already installed, you must install these screen fonts if you want to see the printer’s resident typefaces on the Macintosh screen. For information on how to install fonts, see the Phaser 220 Drivers and Utilities Printing Reference or your Macintosh documentation.
3
Printing
3-14
Phaser 220i and Phaser 220e Color Printers
Printer languages: PostScript, HP-GL, PCL5
With Adobe IntelliSellect™ technology, Phaser 220 printers can automatically sense the language of the print job and process it accordingly. This is called automatic language selection. You can also set up any printer port to receive one language only. If you set up a port to receive a particular language only, the port will only accept jobs of that type. The printer reports an error if another language is sent to that port.
The following table shows the default language setting for each port.
Enabling and disabling automatic language switching
To enable or disable automatic language selection on a port, send the appropriate PostScript language file to the printer. For more information, see the manual Phaser 220 Drivers and Utilities Printing Reference.
Default printer port settings
Port Language
Serial PostScript Parallel PostScript LocalTalk PostScript EtherTalk PostScript LPR PostScript AppSocket Automatic language switching NetWare Automatic language switching
Printing
3
User Manual
3-15
Printing with HP-GL
1.
Use automatic language selection or change the printer port’s language from PostScript to HP-GL.
2.
Set up the printing options in your application by selecting a printer driver that supports the 7475A plotter.
3.
Print from your application as usual.
Changing the HP-GL default settings
The printer has default values for the HP-GL parameters, such as pen color and pen width. When you turn the printer off and on (or reset it), the HP-GL values return to their default settings.
To change the values, send a PostScript language file to the printer. For details, refer to the manual Phaser 220 Drivers and Utilities Printing Reference.
HP-GL default settings
Parameter Default setting
Image scaling To paper size Timeout interval 15 seconds Pen width 0.35 mm Pen colors:
Pen 1 Pen 2 Pen 3 Pen 4 Pen 5 Pen 6 Pen 7
Black Red Green Blue Cyan Magenta Yellow
Background color White (pen number 0)
3
Printing
3-16
Phaser 220i and Phaser 220e Color Printers
Printing hints
Getting the largest printed picture
Use the Tektronix Phaser 220i or Phaser 220e driver and perforated paper or transparencies to get the largest print areas. You may also have to adjust the margins in your application software.
Why should I use perforated paper?
By using Tektronix perforated paper (and transparencies), you can print full A-size or A4-size images with standard ISO margins (5 mm; 0.2 in.).
How long does it take to make a print?
The total print time depends on the image complexity, the type of port used, and the printer's paper-marking speed. The paper-marking speed is the time it takes the printer to put the colored wax on the paper, once it has received the processed image.
Of these three elements, only the printer's paper-marking speed is predictable; the others can vary greatly depending on your system configuration and the type of image you are printing. However, the Phaser 220 PostScript interpreter combines very fast image processing and communication with sophisticated memory management to keep the total print time to a minimum. For details on the printer's paper-marking speed, see “Specifications” on page A-5.
Which port is faster, parallel or serial?
The parallel port is generally faster than the serial port.
User Manual
4-1
Chapter
4
Caring for Your Printer
Overview
To ensure the best print quality and the most reliable printer operation, follow these two simple guidelines:
Use only Tektronix transparencies and transfer rolls. When
printing with a 3-color or black transfer roll, use only Tektronix thermal-transfer paper. When printing with a ColorCoat transfer roll on common laser paper, use paper that conforms to the guidelines given in “Recommended paper types” on page 5-4.
Perform the regular cleaning described in this chapter.
Importance of cleaning
By performing regular cleaning, you can ensure that your printer produces the highest quality prints. Regular cleaning also helps prevent paper jams, smudged prints, skewed images, and misregistration. If you clean the printer at intervals listed under the next topic, “When to clean,” you will experience fewer paper problems, improved print quality, and less downtime.
Cleaning the printer is easy. Follow the cleaning procedures given in the next few pages, or use the
Cleaning Instructions that come with each
cleaning kit.
4
Caring for Your Printer
4-2
Phaser 220i and Phaser 220e Color Printers
When to clean
Every time you replace the transfer roll, clean these printer parts:
Thermal head and transfer roll guide
Paper-feed rollers
Paper-pick rollers
Clean these printer parts every 5,000 prints, or as needed to prevent smudging on prints:
Transfer roll sensor pad
Drum
Exit rollers
A preventive check by a Tektronix field service representative is recommended every 10,000 prints or every year. The startup page and the configuration page report the number of prints made since the printer was shipped from Tektronix.
Caring for Your Printer
4
User Manual
4-3
Cleaning kit
A cleaning kit comes with the printer. The cleaning kit contains these items:
Lint-free cleaning wipes
A plastic bottle for isopropyl alcohol
A cleaning tray for cleaning paper-pick rollers
Cleaning instructions (you may use those instructions, or follow
the instructions in the next few pages)
For the cleaning kit that is shipped with the printer, you must supply isopropyl alcohol (available at pharmacies); shipping regulations prohibit supplying alcohol or presoaked cleaning materials with the printer.
In general, you should use the purest isopropyl alcohol available to you. 99% pure is best, and 90% also works well.
Caution
Do not use rubbing alcohol because it can contain oils that leave undesirable residue on the printer parts.
Note
To order a new cleaning kit, call your dealer or Tektronix (order number 016-1233-00). You can also order a cleaning kit containing presoaked alcohol cleaning wipes (order number 016-1276-00).
4
Caring for Your Printer
4-4
Phaser 220i and Phaser 220e Color Printers
Cleaning the printer (with every transfer roll change)
Perform the next three cleaning procedures every time you replace the transfer roll.
Note
Turn off the printer before cleaning the thermal head and the paper-feed rollers. The printer must be turned on to clean the paper-pick rollers.
Cleaning the thermal head and transfer roll guide
1.
Press the button to open the top cover. Dampen a lint-free cleaning wipe with isopropyl alcohol.
2.
Wipe the full width of the thermal head several times. Remove any dust, dirt, and wax.
3.
Wipe the full width of the transfer roll guide several times. Close the top cover when you are finished .
8869-30
2
1
2
3
Caring for Your Printer
4
User Manual
4-5
Cleaning the paper-feed rollers
Caution
Be careful not to scratch the curved plastic parts inside the front cover. Scratches in this area could cause paper jams.
1.
Slide out the front cover and remove it. Dampen a lint-free cleaning wipe with isopropyl alcohol.
2.
Wipe the paper-feed rollers. Be sure to clean all three rollers. It is not necessary to move the rollers as you clean them; clean only the exposed surface of the rollers.
3.
Slide the front cover back into place.
8869-31
2
1
4
Caring for Your Printer
4-6
Phaser 220i and Phaser 220e Color Printers
Cleaning the paper-pick rollers
Make sure that the transfer roll is installed before you begin this cleaning procedure.
To clean the paper-pick rollers, you must use the cleaning tray from the cleaning kit.
1.
Turn the printer off, then on again.
2.
Remove the paper tray(s), and remove the paper or transparencies from one of the trays.
When removing paper or transparencies, do not push the paper tray's metal plate down. (If the metal plate is down, put the paper tray into the slot and pull it out; this returns the metal plate to the up position.)
3.
If you are using an A4-size (metric) paper tray, break off the tabs on the sides of the cleaning tray. The allows the cleaning tray to fit into the metric paper tray. Do not break off the tabs if you are
using an A-size (U.S.) paper tray.
8869-32
3
Caring for Your Printer
4
User Manual
4-7
4.
Open the cleaning tray.
5.
Dampen the pad on the cleaning tray with isopropyl alcohol. Dampen the entire surface of the pad.
6.
Slide the cleaning tray into the paper tray. As you slide the cleaning tray into position, press down the paper tray's metal plate slightly. When the cleaning tray is properly installed, the paper tray's metal plate presses up against the cleaning tray, holding it in place.
7.
Make sure that the flanges on the front of the cleaning tray overlap the front of the metal plate.
8869-15
4
7
5
6
4
Caring for Your Printer
4-8
Phaser 220i and Phaser 220e Color Printers
8.
Slide the paper tray (containing the cleaning tray) into the slot. If your printer has a lower tray assembly, slide the tray into the lower slot.
9.
Press the TEST button on the back of the printer for 3 seconds. The printer attempts to load paper , bringing the paper-pick rollers in contact with the alcohol-dampened pad in the cleaning tray.
10.
The JAM indicator blinks, indicating that the rollers have been cleaned.
a.
If your printer has a single paper tray, the procedure is complete. Slide out the paper tray, remove the cleaning tray, and replace the paper or transparencies. Slide the paper tray back into the slot. If paper-picking problems occur, repeat this cleaning procedure.
b.
If your printer has a lower tray assembly, pull out the paper tray a few inches and then push it back in to clear the JAM indicator. Then perform the steps on the next page to complete the procedure.
ERROR JAM MEDIA
8869-33
8
9
10
...
..
...
.
SECOND FEEDER
TEST
SWITCH
Caring for Your Printer
4
User Manual
4-9
To complete the paper-pick roller cleaning for printers with a lower tray assembly:
1.
Remove the paper tray (containing the cleaning tray) from the lower slot. Dampen the pad on the cleaning tray again.
2.
Insert the paper tray (containing the cleaning tray) into the upper slot. (Leave the lower slot empty for now.)
3.
Press the TEST button on the back of the printer for 3 seconds. Again, the printer attempts to load paper , bringing the paper -pick rollers in contact with the alcohol-dampened pad in the cleaning tray.
4.
The JAM indicator blinks, indicating that the rollers have been cleaned.
5.
Pull out the paper tray. Remove the cleaning tray from the paper tray, and replace the paper or transparencies. Put both paper trays back into their slots.
ERROR JAM MEDIA
8869-43
2
3
4
...
..
...
.
SECOND FEEDER
TEST
SWITCH
4
Caring for Your Printer
4-10
Phaser 220i and Phaser 220e Color Printers
Cleaning the printer (every 5000 prints)
Perform the next three procedures every 5000 prints.
Note
Turn off the printer before performing these three cleaning procedures.
Cleaning the transfer roll sensor pad
1.
Press the button to open the top cover.
2.
Remove the transfer roll.
2
1
8869-17
Caring for Your Printer
4
User Manual
4-11
3.
Dampen a lint-free cleaning wipe with isopropyl alcohol. Wipe the transfer roll sensor.
4.
Leave the transfer roll out and the top cover open. Go on to the next procedure.
8869-34
3
3
4
Caring for Your Printer
4-12
Phaser 220i and Phaser 220e Color Printers
Cleaning the drum
1.
To clean the drum, you must have the top cover open and the transfer roll removed.
2.
Dampen a lint-free cleaning wipe with isopropyl alcohol. Wipe the drum. Move the drum toward the front of the printer to access the entire surface of the drum as you clean.
3.
When the alcohol on the drum is dry, put the transfer roll back into the printer and close the top cover.
8869-35
2
Caring for Your Printer
4
User Manual
4-13
Cleaning the exit rollers
1.
Slide out the front cover and remove it.
2.
Dampen a lint-free cleaning wipe with isopropyl alcohol. Wipe the exit-feed rollers. Be sure to clean all three rollers. It is not necessary to move the rollers as you clean; clean only the exposed surface of the rollers.
3.
Replace the front cover.
2
8869-16
1
4
Caring for Your Printer
4-14
Phaser 220i and Phaser 220e Color Printers
User Manual
5-1
Chapter
5
Supplies
Always use Tektronix supplies
Tektronix supplies for the Phaser 220 printer are developed and tested as a total system: printer, transfer rolls, and media. These components work together to produce consistent, high-quality color images.
Use only Tektronix transparencies and transfer rolls. When printing with a 3-color or black transfer roll, use only Tektronix thermal-transfer paper. When printing with a ColorCoat transfer roll on common laser paper, use paper that conforms to the guidelines given in Refer to the topic “Recommended paper types” on page 5-4.
Ordering information
To order supplies or upgrade kits, refer to the supplies information sheet that came with the printer and contact your local dealer or, in the U.S.A., call Tektronix at 1-800-835-6100.
Supplies kits
4681FSS Plain-paper startup kit including ColorCoat™ transfer
roll, paper tray for non-perforated plain paper, and
perforated premium laser paper. Order Option 01 to get a
metric paper tray and metric paper.
4681FTA Lower tray assembly (including paper tray for perforated
paper). Order Option 01 to get a metric paper tray.
5
Supplies
5-2
Phaser 220i and Phaser 220e Color Printers
Using plain paper
Note
When printing on plain paper, the sound of the printer is louder than for thermal-transfer paper. This is normal.
The Phaser 220 printers give prints on standard laser paper the brilliant color quality previously available only with coated thermal-transfer papers. The excellent plain-paper printing capability of the Phaser 220 printers is possible through Tektronix' proprietary ColorCoat™ technology. This topic provides details on the Phaser 220 plain-paper printing capabilities.
ColorCoat™ transfer roll
Plain-paper printing requires a special ColorCoat™ transfer roll. The ColorCoat™ transfer roll uses a fourth panel to put a specially formulated precoat on the paper, allowing it to accept the thermal-wax inks and retain their vivid colors. The printer's image processing software determines where the precoat is needed and avoids placing the pr ecoat where ther e is no color (for example, white areas).
The ColorCoat™ transfer roll also prints well on coated thermal-transfer paper and on transparencies. (When the selection switch on the paper tray is set to TRANSPARENCY, the precoat is not applied.) The standard thermal-wax transfer roll does not print well on plain paper.
Supplies
5
User Manual
5-3
Use the correct paper tray for plain-paper printing
If you use common laser paper for plain-paper printing, you must use a LETTER or A4 size paper tray. The standard trays supplied with the printer are for Tektronix perforated paper and transparencies (they are labeled LETTER PERF and A4 PERF). LETTER and A4 trays for plain paper must be ordered separately. If you use Letter or A4 size plain paper in a LETTER PERF or A4 PERF paper tray, the printer reports an error condition.
Plain-paper startup kit
For first-time startup using plain-paper printing capability, order the plain-paper startup kit (4681FSS), which contains everything you need for plain-paper printing.
Paper trays and media types
Tray Media
LETTER A4
Common laser paper
LETTER PERF A-4 PERF
Tektronix premium laser paper (perforated) Tektronix thermal-transfer paper (perforated) Tektronix transparencies (perforated)
5
Supplies
5-4
Phaser 220i and Phaser 220e Color Printers
Recommended paper types
Observe the following guidelines when selecting plain paper for use with the printer:
Many types of Bond, Text, and Book paper work well with the
printer . For Bond paper, use a basis weight of 75 - 90 g/m
2
(20 - 24
lb.); 75 g/m
2
(20 lb.) is best. For Book paper, 75 g/m2 (50 lb.) is
best. In general, avoid paper with a high rag content.
In general, smoother papers work better. Avoid using “fuzzy”
papers with loose fibers. This type of paper does not produce the best image quality and leaves more paper residue inside the printer, requiring you to clean the printer more frequently.
Don't use watermarked paper. The watermark may show through
as dropout on the print.
You can recycle plain-paper prints with other mixed paper.
Tektronix offers a premium laser paper that gives excellent print quality for plain-paper printing. Like Tektronix thermal-transfer paper, this premium laser paper is larger than standard Letter or A4 size paper and perforated, which allows you to print the largest possible image area (for details, see “Margins and print area” on page 3-6). For information on ordering Tektronix premium laser paper and other printer supplies, refer to the supplies information sheet that is shipped with the printer.
Supplies
5
User Manual
5-5
The following table lists a selection of papers that provide good results. Some office papers, especially in Europe, may be too rough to provide good print quality. For best results on plain paper, use Tektronix perforated premium laser paper.
Recommended paper types
Paper Basis weight
Aussedat Rey Rdeerey (France) 100g/m
2
Boise Cascade Laser 20 lb. Boise Cascade Laser 24 lb. Boise Cascade Xerographic 20 lb. Champion Bond 20 lb. Cross Point Laser/Recycled 24 lb. Hammermill Laser Print 24 lb. Nashua Dual Purpose 20 lb. Nekoosa Laser 1000 24 lb. Neusiedler Color Copy (Austria) 100g/m
2
Nymoella MultiCopy Art (Sweden) 100 g/m
2
Western Red Label (HM) 20 lb. Xerox 4024 Smooth 20 lb. Zellerbach Matrix Plus 20 lb.
5
Supplies
5-6
Phaser 220i and Phaser 220e Color Printers
Handling supplies
Make sure that the paper trays are free of dust. Dust and dirt in a
paper tray can be transferred to the paper, resulting in poor print quality.
Handle paper and transparencies at the edges to avoid
fingerprints.
Store paper and transparencies in the original, dust-free package.
Handle transparencies with both hands to avoid creases, which
can result in poor print quality.
To avoid having transparencies or perforated paper stick together,
fan them before loading into the paper tray.
If you switch transfer rolls temporarily, be sure to store the
partially used transfer roll so that it will not be exposed to dust or dirt. The best way to store a partially used transfer roll is to put it back into its original packing material and plastic bag.
Supplies
5
User Manual
5-7
Removing a used transfer roll
Note
Negative images of all prints remain on the used transfer roll. If this is a security risk, dispose of the used transfer roll properly.
Every time you replace a transfer roll, you must clean three printer components. This cleaning is user care that helps ensure reliable operation and uniformly high print quality. Cleaning instructions are provided with each transfer roll. You may also refer to Chapter 4, or refer to the Phaser 220 Color Printers Cleaning Instructions that come with each cleaning kit.
1.
Push the button and open the printer's top cover.
2.
Lift out the back spool of the used transfer roll.
3.
Lift out the front spool of the used transfer roll.
4.
To install the new transfer roll, follow the instructions on the sheet that comes with each transfer roll, or refer to “Install the transfer roll” on page 2-7.
2
1
8869-17
5
Supplies
5-8
Phaser 220i and Phaser 220e Color Printers
User Manual
6-1
Chapter
6
Troubleshooting
Clearing transfer roll jams
1.
Push the button and open the printer's top cover.
2.
Lift out the transfer roll. Check the roll for tears and wrinkles. (If the roll is damaged, replace it with a new one.) Straighten the r oll and put it back in. Make sure the transfer roll is pr operly installed: the black band is on the left, with the unused end in the back of the printer.
2
1
8869-17
6
Troubleshooting
6-2
Phaser 220i and Phaser 220e Color Printers
Clearing paper jams
If a paper jam occurs, the JAM indicator comes on. Follow these steps to remove the jam:
1.
Remove the paper tray(s).
2.
Carefully remove any jammed paper from the paper tray slot(s) and replace the tray(s).
Caution
Be careful not to scratch the curved plastic parts inside the front cover. Scratches in this area could cause paper jams.
3.
Slide out the front cover and remove it.
4.
Remove any jammed paper from inside the printer and replace the front cover. If you did not find paper jammed in the paper tray slot(s) or inside the printer, it is wrapped around the drum, and you must go to the next procedure .
1
4
2
3
8869-36
Troubleshooting
6
User Manual
6-3
To remove paper from the drum:
1.
Push the button and open the printer's top cover.
2.
Remove the transfer roll.
Caution
Be careful not to scratch the drum. Scratches can affect print quality.
Note
If you getting frequent jams when using thermal-transfer paper or transparencies, make sure you are using Tektronix media (order from the supplies information sheet that is shipped with your printer).
8869-37
2
1
6
Troubleshooting
6-4
Phaser 220i and Phaser 220e Color Printers
3.
Turn drum toward the front of the printer until the edge of the paper is visible.
Note
If you have not yet found any paper jammed in the printer, the printer has failed to pick up the paper (reported as a paper jam). cleaning the paper-pick rollers should fix the problem. See “Cleaning the paper-pick rollers” on page 4-6.
4.
The paper is clamped to the drum. If you pull the paper out without releasing the clamp, you may tear the paper and leave some pieces inside the printer.
To open the clamp, move the drum toward the back of the printer until it stops. Then gently continue the motion until you hear a click; now the clamp is open and you can remove the paper without tearing it.
5.
Replace the transfer roll and close the top cover.
8869-38
3
4
4
Troubleshooting
6
User Manual
6-5
Problems and solutions
If you can't make a print
Note
When using a printer with a lower tray assembly, make sure that the door covering the upper slot is closed before you try to make a print from the lower tray. You cannot print from the lower tray with the door open.
Printer not operating
Make sure you plugged in the printer and turned it on. Make sure you connected the interface cable properly and set the rear panel switches correctly. For details on the switch settings, refer to Chapter 7. Make sure the line voltage selector switch is set properly.
Press the TEST button on the back of the printer for 3 seconds. If the printer produces a test print, the printer is functional, and the next step is to verify that your computer can communicate with the printer. If the printer fails to produce a test print, make sure that paper is loaded and a transfer roll is installed. If you have paper and transfer roll installed and the printer does not produce a test print, the printer requires service.
Note
When you have checked all possible causes and your printer is still not operating, you can call for service at 1-800-547-8949 in the U.S.A. and Canada, or call your Tektronix dealer.
6
Troubleshooting
6-6
Phaser 220i and Phaser 220e Color Printers
To verify that your computer can communicate with the printer, use one of these methods:
If you have a Macintosh, make sure you have the correct driver
installed and that you have selected the printer in the Chooser. If the printer's name does not appear in the Chooser, your LocalTalk or EtherTalk connection may be faulty. (See also “Printer doesn't appear in the Chooser” on page 6-7.
You can use the Print Directory command to send a file to the printer without using an application. If the communication link between your computer and the printer is working, the printer produces a directory listing of the active window on the desktop.
If you have a PC, use this DOS ECHO command:
ECHO %! > port
ECHO SHOWPAGE[CTRL-D] > port
Where [CTRL-D] indicates pressing the D key while holding down the CTRL key. Substitute the name of the printer port (for example COM1:, COM2:, LPT1:, LPT2:) for the variable port in this command. For example, if you are testing a parallel connection on LPT1, type:
ECHO %! > LPT1:
ECHO SHOWPAGE[CTRL-D] > LPT1:
If the communication link between your computer and the printer is working, the printer ejects a blank page. If this works, but you cannot print from your application or through Windows, make sure that the appropriate driver is installed and that you have selected the printer correctly.
Troubleshooting
6
User Manual
6-7
Printer doesn't appear in the Chooser
Make sure the printer is turned on and the cables are correctly attached. Check the termination (refer to the documentation for your Ethernet adapter or LocalTalk connector for information on termination).
Make sure you have the correct zone selected in the Chooser before looking for the printer's name in the list of printers. If you have changed the printer's name, make sure you have given it a unique name (not the same as any other printer in the zone).
READY light blinks, but the file does not print
This is probably the result of a PostScript error. Download the PostScript error handler file from the Phaser 220 utility diskettes. For mor e information on using the PostScript error handler, see the manual Phaser 220 Drivers and Utilities Printing Reference.
MEDIA light blinks, and no print is produced
You have the wrong size paper in the paper tray (non-perforated paper in a tray for perforated paper).
Print job does not finish (the printer times out)
If you are using the serial or parallel port from a PC, make sure that you used the MODE command to set the PC's communication parameters. For example:
MODE LPT1:,,P > NUL
MODE COM1:9600,N,8,1,P
The P parameter in these commands sets the port timeout to Infinite Retry and must be part of the command.
If you are using Windows 3.1, make sure the Transmission Retry value for the printer's assigned port is set to 995. For more information, see “PC users” on page 2-23.
6
Troubleshooting
6-8
Phaser 220i and Phaser 220e Color Printers
Media problems
Frequent paper-picking errors
Be sure to fan the paper or transparencies befor e installing them in the paper tray. This is especially important for transparencies and perforated paper . If you still experience paper-picking errors, clean the paper-pick rollers. For details, see “Cleaning the paper-pick rollers” on page 4-6.
Frequent paper jams
If you are using thermal-transfer paper or transparencies, make sure that you use the Tektronix paper and transparency film listed in the supplies information sheet. Also, do not overfill the paper tray, as indicated by the red line on the right side of the tray. If you still experience paper jams, clean the printer. For information on cleaning the printer, see Chapter 4.
You feel resistance when installing the paper tray
If you try to install a paper tray and you find it won't go in, look in the slot. If you see the paper-pick rollers in the way, rotate the rollers towar d the front of the printer until the slot is clear.
Troubleshooting
6
User Manual
6-9
Problems with image size and position
Off-set images
Check your application for correct image sizing.
Cut-off images
Check your application for image sizing.
If you are using non-perforated plain paper, make sure you are using a Phaser 220 driver and have selected Letter or A4 as the paper size. If you select Letter Perf or A4 Perf and print on non-perforated paper, the image may be cut off.
Image prints over perforations
Reverse the direction of the paper or transparencies in the tray. The perforated portion of the paper or transparencies must be in the front of the tray. (The front of the tray is the part that has the paper-size label: LETTER, LETTER PERF, A4, A4-PERF.)
Margins are too big with perforated paper or transparencies
Make sure you are using a Phaser 220 driver and have selected Letter Perforated or A4 Perforated as the paper size.
Image shifts or margins are incorrect (Macintosh)
For details on how to print from a Macintosh, refer to “Printing from a Macintosh” on page 3-1. You should install the Phaser 220i or Phaser 220e printer driver onto your Macintosh so you can select the correct page sizes from the driver. For details on the Phaser 220i and Phaser 220e drivers, refer to the manual Phaser 220 Drivers and Utilities Printing Reference.
6
Troubleshooting
6-10
Phaser 220i and Phaser 220e Color Printers
Print quality problems
Plain paper prints have dull, faded colors and significant dropout
If plain paper prints have dull, faded colors and significant dropout (areas where the wax does not adhere to the paper), make sur e that you ar e using a ColorCoat™ transfer roll; the thermal-wax transfer roll does not print well on plain paper. If a transfer roll has a clear panel after every three colored panels, it is a ColorCoat™ transfer roll.
If you are using Tektronix perforated premium laser paper, make sure you have the selection switch on the paper tray set to PAPER and not TRANSPARENCY.
If you have the correct transfer roll and switch selection and the prints still have dull, faded colors and dropout, you may be using a paper that is too rough. Try another type of plain paper. Refer to “Recommended paper types” on page 5-4. You can achieve excellent results with Tektronix perforated premium laser paper.
Prints on thermal-transfer paper or transparencies have dull colors
Make sure the switch on the paper tray is set to PAPER, not TRANSPARENCY. If you are using thermal-transfer paper, make sure that you load the paper in the tray with the whiter, shinier side up.
Streaks or spots
Most spots and streaks are caused by dust introduced into the printer during transfer roll installation or paper loading. To prevent dust from getting inside of the printer, make sure the surface where you unpack transfer rolls, paper, and transparencies is free of dust. Keep supplies in a covered area or a closed box.
To get rid of spots or streaks, clean the thermal head (see “Cleaning the thermal head and transfer roll guide” on page 4-4).
Troubleshooting
6
User Manual
6-11
Black-and-white instead of color
Make sure that a color transfer roll is installed in the printer.
If you have a Macintosh, make sure you are using the Phaser 220i
or Phaser 220e driver or the latest Apple LaserWriter printer driver (version 6.0.7 or higher), which supports color PostScript. Make sure Color/Grayscale is selected in the Print dialog box. Some applications require special files to print in color. Make sure that these files are properly installed. For information, refer to the manual Phaser 220 Drivers and Utilities Printing Reference.
If you have a PC, be sure to use a driver that supports color
PostScript. If you are using Windows 3.1, use the Phaser 220i or Phaser 220e driver. If you are using Windows, make sure that the Color box in the Options dialog box is checked. For information on the drivers, refer to the manual Phaser 220 Drivers and Utilities Printing Reference.
6
Troubleshooting
6-12
Phaser 220i and Phaser 220e Color Printers
Startup page prints even though it is disabled
The printer's power-up self-test can detect problems that do not necessarily make the printer completely inoperable. Examples of these non-fatal errors include faulty printer ports and some memory failures.
If the printer detects a non-fatal error at power-up, the startup page prints, even if you have disabled it. In this case, the page contains one or more of the error messages listed in the following table. Depending on your needs, you may not need to call for service immediately.
Error messages on the startup page
Message Description
Serial Port failed Parallel Port failed LocalTalk Port failed Ethernet Port failed (Phaser 220i only) SCSI Port failed (Phaser 220i only)
The named port is not working. The other ports can still be used.
Font SIMM failed (Phaser 220e only) The optional FONT SIMM is not
working. The printer can still be used, but only the standard 17 fonts are available.
DRAM SIMM failed (Phaser 220e only) The memory SIMM is not working.
Since the printer's base memory is still working, the printer can still be used, but large image files may not print, and throughput may suffer.
DRAM SIMM
x
failed (Phaser 220i only) One of the memory SIMMs is not
working. In this message,
x
indicates the number of the SIMM that failed. Since the printer's base memory is still working, the printer can still be used, but large image files may not print, and throughput may suffer.
Troubleshooting
6
User Manual
6-13
Generating the configuration page
The Phaser 220 can generate a configuration page that contains useful information for installation and troubleshooting.
There are two ways to generate the configuration page:
Use the printer’s rear panel DIP switches.
1.
Set Switches 2, 3, and 4 down.
2.
After about five seconds, set Switch 4 up (leave Switches 2 and 3 down). The printer generates the configuration page as soon as the switches are set (you do not have to reset the printer).
Send a PostScript language file to the printer. For information on
how to generate the configuration page by sending a PostScript language file to the printer, see the manual Phaser 220 Drivers and Utilities Printing Reference.
6
Troubleshooting
6-14
Phaser 220i and Phaser 220e Color Printers
Whom to call for help
Call your dealer or a Tektronix sales representative for assistance, or in the U.S.A. and Canada, call the Customer Support Hot Line at Tektronix at 1-800-835-6100. The Customer Support Hot Line is staffed from 6:00 am to 5:00 pm Pacific Time. To avoid peak hours, call before 11:00 am or after 2:00 pm Pacific Time.
For technical support outside the United States and Canada, contact your local Tektronix dealer or Tektronix sales representative.
If your printer needs repair, call 1-800-547-8949 (in the U.S.A., from 5:00 am to 5:00 pm PST).
HAL — Highly Automated Library
As an alternative to the Customer Support Hotline, and to provide up-to-date information quickly, Tektronix has set up HAL, an interactive, automated fax system. Topics include:
The latest technical hints and tips
Solutions to most common technical problems
Application notes (for example, QuarkXPress and CorelDRAW!)
Data sheets
Sales literature
Troubleshooting
6
User Manual
6-15
To order a technical support catalog listing all available HAL articles, call (503) 682-7450 directly from any phone (24 hours/day, from anywhere in the world). In the United States and Canada, call toll-free 1-800-835-6100 (6:00 am — 5:00 pm, PST) and ask to be transferred to HAL. To order a HAL catalog or document, do the following:
1.
Before you call, write down the area code and phone number for your fax machine. HAL will ask you to key this number through the keypad on your voice phone. If you are calling from outside the United States or Canada, you’ll need to know the international access code to reach your country from the United States. Without a complete fax number, HAL cannot call your fax machine. Call only from a touch-tone voice phone.
Note
Before ordering documents from HAL, order a HAL catalog listing the numbers of the available documents.
2.
Follow the instructions in the voice-prompted menu.
3.
Order individual documents by entering the desired document’s number as listed in the HAL catalog. Enter the number by using the telephone’s keypad.
4.
You can order up to 3 documents per call.
5.
The HAL catalog or documents you request are faxed to you in a matter of minutes.
6
Troubleshooting
6-16
Phaser 220i and Phaser 220e Color Printers
User Manual
7-1
Chapter
7
Front and Rear Panels
Rear panel (Phaser 220e)
1.
Status indicator
2.
DIP switches
3.
LocalTalk connector
4.
Serial connector
5.
Parallel connector
8869-10
Phaser 220e
1
23
4 5
7
Front and Rear Panels
7-2
Phaser 220i and Phaser 220e Color Printers
Rear panel DIP switches (Phaser 220e)
In this table, D indicates that the switch is down; U indicates that the switch is up.
Phaser 220e rear panel DIP switches
Switch Function Settings
1 Reset/run
Up
: The printer resets and does not accept data
while the switch is in this position.
Down
. The printer runs a self-test, then proceeds
to run normally. Leave the switch
down
for normal
operation.
2, 3, and 4 Serial port
Color correction Configuration page
See the next table, “Phaser 220e DIP Switches 2, 3, and 4.”
Phaser 220e DIP Switches 2, 3, and 4
Switches Operation Features
2 3 4 Serial port Color correction
DDD
Normal Variable None
UDD
Fixed serial parameters Fixed None
DUD
Color correction Variable Vivid blue
UUD
For service personnel only Variable None
DDU
Print configuration page* Variable None
UDU
Enable sample prints Variable None
DUU
For service personnel only Variable None
UUU
For service personnel only Variable None
*To print the configuration page, first set Switches 2, 3, and 4
down.
After about
5 seconds, set Switch 4
up
.
Front and Rear Panels
7
User Manual
7-3
Note
If your printer is on a network and you have changed rear panel Switches 2, 3, and 4 for color correction, make sure you tell other users on the network, since the color correction affects all prints made with non-Tektronix drivers or the Use Printer Setting option in the Tektronix drivers. Color correction selections made in the Phaser 220 driver take priority over selections made by setting the printer’s rear-panel DIP switches.
Rear panel (Phaser 220i)
1.
Status indicator
2.
DIP switches
3.
LocalTalk connector
4.
Ethernet connector
5.
SCSI connector (for adding a hard disk for font storage)
6.
Parallel connector
7.
Serial connector
Phaser 220i
1
8869-9
2 3
4
5
6
7
7
Front and Rear Panels
7-4
Phaser 220i and Phaser 220e Color Printers
Rear panel DIP switches (Phaser 220i)
Phaser 220i rear panel DIP switches
Switch Function Settings
1 Reset/run
Up
: The printer resets and does not accept data
while the switch is in this position.
Down
. The printer runs a self-test, then proceeds
to run normally. Leave the switch
down
for normal
operation.
2, 3, and 4 Configuration page
Sample prints
See the table, “Phaser 220i DIP Switches 2, 3, and 4” on page 7-5.
5 Start Job
Up
: The Sys/Start job on the hard disk does
not run.
Down: The Sys/Start job runs. 6 Unused 7 Baud Rate
Up
: Fixed. Sets the serial communication parameters to 1200 baud, software flagging, and ignore parity.
Down
: Variable. Lets you change the serial communication parameters. The factory setting is 9600 baud, software flagging, and ignore parity.
8 and 9 Color correction See the table, “Phaser 220i DIP Switches 8 and 9”
on page 7-5.
Loading...
