Fryer • Friteuse• Fritözünüz
Instructions for use • Mode d’emploi
Kullanim kilavuzu
4
5
7
8
9
10
11
12
6
20
19
18
17
14
16
15
13
1
2
3
2
ENG
Protection of the environment
• Your equipment has been designed to work for many years. However, when finally you decide to
replace your deep fryer, do not forget to think of what you can do to help to protect the environment.
• Before throwing away your deep fryer, the timer battery must be removed by an approved Service
Centre.
• Approved Service Centres will take back your used equipment in order to destroy it while respecting
the environment.
Description
1. Filter compartment cover
2. Filter saturation indicator
3. Anti-odour filter cartridge
4. Basket
5. Basket locking button
6. Basket raising
and lowering handle
7. Min. and Max.
bowl-filling markers
8. Removable bowl
with non-stick coating
9. Lid opening button
10. Special Booster button
for frozen foods
(depending on model)
11. Timer (depending on model)
12. Temperature indicator light
13. Carrying handle
14. Thermostat/On-off Switch
15. Power lead storage
16. Bowl positioning guide
17. Seal
18. Steam guard
19. Window
20. Lid
After Sales Services (for UK only)
In the unlikely event your appliance should fail
within the first 28 days from date of purchase, your
retailer is authorised to exchange it. After 29 days
from date of purchase, for repairs and spares,
telephone your nearest Tefal Service Centre on
0845 725 8588 (calls charged at local rate).
Alternatively you may post your faulty product for
repair at the following address:
• TEFAL Service Operations
PF Box 155, Birmingham B13 DP
Tel. 0121 200 2740.
• TEFAL Ireland Gavin Electronics Ltd, 83 Lower
Camden Street, Dublin 2. Eire. Southern Ireland
Tel. 14 75 71 09.
Before posting:
1. Enclose your name and address and details of the
fault.
2. If you are returning under the guarantee, it must
be accompanied by a till receipt (keep a photocopy
for your records) as proof of date of purchase.
3. If it is outside the guarantee period, please advise
our Service Centre of the maximum amount of
money to make it operation again.
4. Please empty the oil from the fryer and clean the
inside before returning your fryer.
The above details are in addition to a consumer’s
statutory rights and does not affect those rights in
any way.
Replacement accessories and spare parts for your
TEFAL appliance such as anti-scaling cassettes for
irons, filters for deep oil fryers or gaskets for
pressure cookers are available from TEFAL stockists
or your local Service Centre.
Alternatively you can obtain them by Mail Order
from TEFAL DIRECT on 01702 290 089. When
ordering spares you will need to know the model
number of your appliance.
Product information:
For other product information, telephone 0800
616 413.
3
ENG
• This equipment complies with current safety regulations
and requirements as well as directives:
- 89/336/CEE modified by 93/68/CEE
- 73/23/CEE modified by 93/68/CEE
• This electrical equipment operates at high temperatures
which may cause burns. Although this deep fryer offers a
high level of thermal protection, do not touch metal parts
that are visible after opening the lid.
• Do not leave the equipment switched on while
unattended.
• Never insert any object between the removable bowl and
the bottom of the equipment.
• Always plug in the equipment at an earthed power
socket.
• Do not use an extension lead. If you accept liability for
doing so, only use an extension lead which is in good
condition, has an earthed plug, and is suited to the power
of the equipment.
• Check that the mains voltage corresponds with that
shown on the equipment (alternating current only).
• If the equipment is used in a country other than that of
purchase, have it checked by an approved Service
Centre.
• Never use or plug in your equipment if:
- its power lead is faulty or damaged,
- the equipment has been dropped,
- it has visible damage or operating faults.
• In such cases, to avoid any danger contact your nearest
approved Service Centre to have the equipment repaired,
as special tools are needed. Never disassemble the
equipment yourself.
• If the power lead is damaged, it must be replaced by the
manufacturer, its after-sales service or someone similarly
qualified, in order to avoid any danger.
• In the event of fire, never try to extinguish the flames with
water. Close the lid. Smother the flames with a damp
cloth.
• Do not switch on the equipment near to inflammable
materials (blinds, curtains, etc.) or close to an external
heat source (gas stove, hotplate, etc.)
• This equipment has been designed for domestic use only.
Any professional use which is inappropriate or does not
comply with the instructions for use disengages the
manufacturer from his liability or guarantee.
Safety instructions
For UK users only - Wiring instructions
Warning:
this appliance
must be earthed.
Important:
the wire in this lead are coloured in accordance with
the following codes :
Green and Yellow . . . . . . . . Earth
Blue . . . . . . . . . . . . . . . . . . Neutral
Brown . . . . . . . . . . . . . . . . . . . Live
• Connect the Green/Yellow wire to the terminal in the
plug marked “E” (or by the earth symbol) or
coloured Green or coloured Green and Yellow.
Connect the Brown wire to the terminal in the plug
marked “L” or coloured Red. Connect the Blue wire
to the terminal in the plug marked “N” or coloured
Black. A 13 amp fuse should be fitted when the
appliance is connected to a BS 1362 plug. Seek
professional advice if you are unsure of the correct
procedure of the above.
Voltage
• This appliance is designed to run on 230 volts only.
Check that the mains supply corresponds to that
shown on the rating plate of the appliance. If the
appliance is to be used in any country other than that
of purchase, it should be checked by an approved
Service Dealer. Standards can vary from country to
country.
About your factory fitted plug.
FOR UK ONLY
(supplied with certain models only)
• The lead is already fitted with a plug incorporating a
13 amp fuse. If the plug does not fit your socket
outlet, see next paragraph.
• Should you need to replace the fuse in the plug
supplied, a 13 amp approved BS 1362 fuse must be
used.
• The fuse cover is an important part of the plug.
Please ensure that it is always refited. If you lose
this cover please do not use the plug. You may
contact TEFAL for a replacement.
• If the plug supplied does not fit your socket outlet, it
should be removed from the mains lead and
disposed of safety. The flexible cord insulation
should be stripped back as appropiate and a
suitable alternative plug fitted. The replacement
plug must be equipped with a 13 amp fuse.
Important:
if the electrical cord of this appliance is damaged, it
must only be replaced by an authorised Service
Dealer. The safety of this appliance complies with the
technical regulations and standards in force.
4
ENG
Preparation
Fill up the bowl
•
It must always be filled to between the
Min. and Max. markers.
Preheat
•
Plug in the fryer, and close the lid.
•
Melt solid fat at 150° directly in the bowl.
•
Adjust the thermostat (see tables, p.8).
For frozen foods, press the Booster button
(depending on model).
Prepare the foods
Recommended Visialis 1250 Visialis 1000
maximum capacity 2.6 litres 2.2 litres
Fresh potato chips 670 g 550 g
Frozen potato chips 500 g 400 g
•
After the temperature indicator light goes
out, lower the basket gently into the oil with
the lid closed.
Cooking
Keep an eye on the cooking
•
It is normal for the temperature indicator
light to light up and go out.
End of cooking
•
Raise the basket.
•
Open the lid.
•
Drain, and serve.
Maintenance
•
Change the oil and filter cartridge regularly.
Do not mix different types
of fats.
Place the deep fryer:
- out of the reach of children,
- on a steady surface,
- away from water splashes
or heat sources.
Do not overfill the basket.
Dry the foods thoroughly.
To avoid burns:
Do not place your hand above
the filter.
Do not touch the window.
Do not touch the uncovered
metal parts.
Never move your deep fryer
with hot fat inside.
1
2
3
To sum up, 3 steps are vital for making
perfect light, crisp fried foods
Read and follow carefully the instructions for use.
!
!
!
!
!
5
ENG
Fat
quantity
Visialis 1000
Mini 2 l 1750 g
Maxi 2,2 l 2000 g
Visialis 1250
Mini 2,4 l 2125 g
Maxi 2,6 l 2250 g
1 l
500 g
A safety system
prevents the deep
fryer from working
if you have not put
the bowl correctly
in place.
Never plug in the
deep fryer when it
is empty.
Do not mix different
types of fats.
The fat level must
always be between
the Min. and Max.
markers. Check this
each time before
cooking, and add
some of the same
type of fat if
necessary.
Place the deep
fryer:
- on a steady
surface,
- out of the reach of
children,
- away from water
splashes or heat
sources.
Do not leave the
deep fryer
unattended. Do not
let the power lead
hang down.
Preparation for use
Before using your deep fryer
for the first time
•
Clean the lid, steam guard, bowl and
basket with a sponge and washing-up
liquid. Dry.
•
Remove the cartridge from its plastic
bag (if necessary).
•
Open the cover and insert the antiodour cartridge.
•
Replace the cover.
Replace the removable bowl
•
Insert the bowl, with the Min./Max.
markers (bowl symbol) towards the
back of the equipment.
•
The bowl rim must fit perfectly onto the
equipment.
Fill up the bowl
•
Use a food fat recommended for frying:
sunflower, groundnut, vegetable, etc.
If using sunflower oil ensure the oil is
changed after every 5 uses.
•
If you use solid fat:
- Cut it into pieces and place it at the
bottom of the bowl (never in the
basket).
- Never exceed 150° to melt it, then
follow the manufacturer’s cooking
recommendations.
Preheat
•
Close the lid.
•
Plug in the deep fryer.
•
Adjust the thermostat (see tables, p. 8).
The deep fryer is working.
!
!
!
!
!
click!
6
ENG
This quickly raises
the bath
temperature, which
is lowered by the
frozen foods. Your
fried food will be
crisper.
Never exceed the
quantity safety
limit.
- Cut the foods into
like-sized pieces so
that they cook
evenly,
- Avoid using pieces
that are too thick.
- Shake frozen
foods to detach
pieces of ice away
from the deep fryer.
- Not all frozen
foods are ready to
use. Check the
manufacturer’s
instructions.
The timer signals
that the cooking
time is complete,
but does not stop
the deep fryer.
Preparation for use
Special Booster
for frozen foods
(depending on model)
•
Set the thermostat to I.
•
Press the Booster button.
Prepare the basket
•
Raise the basket handle until you hear a
“click” as it locks.
•
Dry the foods.
•
Fill the basket.
•
Reduce the quantities for frozen foods.
Lower the basket
•
Place the basket in position on the edge
of the bowl.
•
Close the lid.
•
After the temperature indicator light goes
out, press the basket locking button.
•
Close softly and completely the basket
handle in its compartement.
Set the timer (depending on model)
•
Press the button to set the time, minute
by minute.
•
Release the button. The time displayed is
selected and the countdown begins.
•
If you make a mistake, or want to cancel
the time selected, press the button for
2 seconds.
•
To stop the timer alarm, press the button.
Oil quantity Fresh potato chips Frozen potato chips
Visialis 1000 (2,2 l) Quantity safety limit 1000 g 750 g
Maximum recommended quantity 550 g 400 g
Visialis 1250 (2,6 l) Quantity safety limit 1250 g 900 g
Maximum recommended quantity 670 g 500 g
click!
7
ENG
Warning: do not
place your hand
above the filter or on
the window. The
steam and glass are
very hot. Never
remove the bowl
while the deep fryer
is working.
If you used the
Booster, press the
Booster button to
switch it off.
Never move your
deep fryer with hot
fat inside.
Add salt and pepper
away from the deep
fryer to conserve the
fat.
To prepare to use a
second time:
- wait for the
temperature
indicator to go out
before lowering the
foods into the oil.
- adjust the oil level
according to the
quantity of food to be
fried.
Keep an eye
on the cooking
•
During cooking, it is normal for the
temperature indicator light to light up
and go out.
Remove the foods
•
Lift the handle horizontally to raise the
basket until you hear a “click” as it
locks.
•
Open the lid.
•
Drain the foods.
•
Remove the basket, making sure that
the rod comes completely out of the
bowl.
•
Serve.
Switch off the deep fryer
•
When you have finished frying foods,
turn the thermostat/on-off switch
to the 0 position.
•
Unplug the deep fryer.
•
Leave the deep fryer to cool
(1 to 2 hours).
•
Put the power lead back into its
compartment.
•
Only use the carrying handles to move
the deep fryer.
For very crisp fried
foods, open the lid
immediately.
Cooking
!
!
8
ENG
Cooking tables
The cooking times are given as an indication only. They may
vary depending on quantities and personal tastes.
Cooking
Temperature Cooking time
Potato chips (1.25 kg) (Visialis 1250) 190° 16-17 min.
Potato chips (1 kg) 190° 12-15 min.
Potato chips (670 g) 190° 9-10 min.
Potato crisps (550 g) 190° 7-9 min.
Dauphine potatoes (300 g) 190° 7-9 min.
Soufflé potatoes (250 g) 190° 6-8 min.
Poultry croquettes (8-10 p) 190° 8-9 min.
Potato croquettes (8-10 p) 190° 8-9 min.
Stuffed veal escalopes (8 p) 180° 10-12 min.
Quarter of fried chicken (8 p) 180° 12-15 min.
Thin pork slices (400 g) 180° 5-6 min.
Apple fritters (7-8 p) 170° 4-6 min.
Vegetable fritters (aubergines) (10-12 p) 170° 10-11 min.
Fritters (12-15 p) 170° 7-9 min.
Aubergine napolitaine (6 p) 170° 6-7 min.
Sea bream, hake, sole, skate (2 p) 160° 6-8 min.
Mushrooms (200 g) 150° 4-6 min.
Without Booster With Booster
Turn the thermostat Press the Booster
to the 190° setting button
Cooking time Cooking time
Potato chips (pre-cooked) (900 g) (Visialis 1250) 12-14 min. 11-13 min.
Potato chips (pre-cooked) (750 g) 11-13 min. 9-11 min.
Potato chips (pre-cooked) (500 g) 10-12 min. 8-10 min.
Potato chips (pre-cooked) (400 g) 5-7 min. 4-6 min.
Noisette potatoes (50 p) 5-6 min. 4-5 min.
Potato croquettes (8-10 p) 5-6 min. 4-5 min.
Breaded cod (10 p) 5-6 min. 4-5 min.
Frittered fish fillets (8 p) 5-6 min. 4-5 min.
Breaded plaice fillets (3 p) 5-6 min. 4-5 min.
Fishcakes in breadcrumbs (8 p) 5-6 min. 4-5 min.
Prawn fritters (12 p) 4-5 min. 3-4 min.
Squid fritters (12-15 p) 4-5 min. 3-4 min.
Apple fritters (7-8 p) 5-6 min. 4-5 min.
Breaded veal rissolettes (12-15 p) 7-9 min. 6-8 min.
Breaded pork rissolettes (12-15 p) 7-9 min. 6-8 min.
Beef meatballs (15-18 p) 7-9 min. 6-8 min.
(depending on model)(depending on model)
Fresh foods
Frozen foods
9
ENG
The fat must be
filtered regularly.
Scraps that break
away from foods
tend to burn and
cause the fat to
change more rapidly,
as well as risking
igniting over time.
Store the fat
•
Turn off the fryer and wait until the oil
has completely cooled.
•
With a sieve, collect the small pieces of
food left in the fat.
•
Store the fat in the deep fryer, or keep it
in the fridge in a separate container
(recommended if you do not use the
deep fryer often).
Filter the fat
With a filter paper (available from
approved Service Centres).
•
Wait for the fat to become lukewarm.
•
Empty the fat gently into a pan.
•
Place a filter paper in the bottom of the
basket.
•
Clean inside the bowl.
•
Place the basket and filter paper into the
deep fryer (handle in the upper
position).
•
Pour the fat carefully back into the bowl.
•
Throw the filter paper away and clean
the basket.
With a filtering container
maximum capacity: 2.4 l (available
from approved Service Centres).
Maintenance
Change the fat after
being used for a
maximum of 8 to 12
times each time.
“Clean” fat keeps the
flavour and lightness
of foods.
Renew the fat
•
Do not pour used fat into the sink.
Leave it to cool and throw it away with
the household waste.
Change the cartridge
each time the deep
fryer has been used a
maximum of 40 to 50
times.
Replace
the Anti-odour cartridge
(available from approved Service Centres)
•
When the cartridge’s saturation
indicator is dark red, change the
cartridge.
•
Slide out the filter compartment cover.
•
Replace the cartridge, with the
saturation indicator upwards.
•
Put back the cover so that you hear a
“click”.
ENG
Cleaning
Remove and wipe
the cartridge before
washing it.
Clean the window
each time the deep
fryer has been used
8 to 12 times.
Clean the lid
•
To lift off the lid, push the flap
backwards.
•
You can clean your lid in a dishwasher.
•
Dry the lid, before replacing it and the
cartridge in the fryer.
•
To ensure good visibility, clean the
viewing window by wiping it with a
sponge and lemon juice.
•
Allow the window to dry at room
temperature or dry with a clean cotton
cloth.
To preserve its nonstick properties
longer, do not use
any metal tools.
However, if your
bowl does become
misshapen, have it
replaced by your
nearest approved
Service Centre.
Never place the
equipment in water.
Do not use
aggressive or
abrasive products.
Clean the removable bowl
•
Browning and scratches that may
appear after prolonged use do not
cause any problems.
•
We guarantee that the non-stick coating
COMPLIES WITH REGULATIONS
regarding materials coming into contact
with foodstuffs.
•
You can clean your bowl in a
dishwasher. Take care not to damage its
coating with the dishwasher shelves.
•
Try not to damage the shape of your
bowl through bumps or being dropped.
•
Clean the outside of the deep fryer with
a damp cloth. Dry it carefully.
If your basket is
misshapen, have it
replaced by your
nearest approved
Service Centre.
Clean the basket
•
Separate the basket and handle.
•
Wash the basket with large quantities of
water and washing up liquid.
•
Dry it.
!
!
10
11
ENG
If your deep fryer does not work properly
Problem and possible causes
The deep fryer does not work.
• The equipment is not plugged in.
• The thermostat is not lit.
• The bowl is the wrong way round.
The Booster does not work.
• The deep fryer is not switched on.
Unpleasant odours.
• The Anti-odour cartridge is saturated.
• The fat has deteriorated.
• Unsuitable fat has been used.
Steam escapes from around the lid.
• The lid is not closed properly.
• The seal is defective.
The frying bath overflows.
• The Anti-odour cartridge is saturated.
• The Max. marker for filling the bowl has
been exceeded.
• The basket is misshapen.
• Mixture of different oils and fats.
• Oil emulsifies violently.
The foods do not become golden,
and remain soft.
• They are too thick and contain a lot of
water.
• Too much food is being cooked at the
same time and the cooking bath is no
longer at the right temperature.
• The frying bath temperature may not be
high enough; the thermostat is set
incorrectly.
The timer no longer works.
• The battery is worn.
Solutions
• Plug in the equipment.
• Set the thermostat to the required temperature
and check that the temperature indicator lights up.
• Replace the bowl the right way round (with the
Min./Max. markers towards the back of the
equipment).
• Set the thermostat to
I
and press the Booster
button. The Booster indicator lights up.
• Replace the cartridge (see page 9).
• Renew the frying oil (maximum 8 to 12 uses).
• Use a vegetable fat for top-quality frying of food.
• Check that the lid is properly locked closed.
• Contact your nearest approved Service Centre.
• Change the cartridge (see page 9).
• Check the bath level (Max.), and remove the
excess.
• Check that the basket is not overfilled.
• Change your basket.
• Empty and clean the bowl. Refill the bowl with
only one type of fat.
• Lower the basket very slowly.
OR
Remove the ice and dry the foods thoroughly.
• As a test, try a longer cooking time.
• Fry the foods in small quantities (particularly
frozen foods).
• Set the thermostat to the recommended
temperature.
• Have it replaced at an approved Service Centre.
If the problem remains, please call 0800 616 413.
Any repairs must only be carried out by an approved Service Centre with the
manufacturer’s own replacement parts.
For spares or repairs telephone your nearest TEFAL Service Centre
(calls charged at local rate): 0845 725 8588.
!
Loading...
