Thank you for choosing an appliance from the Tefal range, which is intended exclusively for the
preparation of food and is only for indoor, domestic use.
• Read the instructions for use carefully before using your appliance for the first time: the manufacturer
shall accept no liability in the event of any use that does not comply with the instructions.
• This appliance is not designed to be used by persons (including children) with reduced physical,
sensorial or mental capacities, or by people with no prior knowledge or experience, except where they
have benefited from supervision or previous instructions relating to the use of the appliance, from a
person responsible for their safety. Children must be supervised to ensure that they do not play with
the appliance.
• Check that the power rating of your appliance corresponds to your electrical supply. Any connection
fault invalidates the warranty.
• Your appliance is intended only for domestic culinary use, in an indoor setting and under supervision.
• Always unplug the appliance as soon as you have finished using it and when you are cleaning it.
• Do not use the appliance if it is not working properly or if it has been damaged. Contact an authorised
service centre (See details at the end of this is leaflet).
• Any maintenance other than routine cleaning and upkeep by customers must be carried out by an
approved service centre (See details at the end of this is leaflet).
• Do not place the appliance, the supply cable or the plug in water or any other liquid.
• The power cord must be kept out of the reach of children and must not be placed near or come into
contact with the hot parts of the appliance, sources of heat or sharp corners.
• If the power cable or the plug are damaged, do not use the appliance. To maintain safety, these parts
must be replaced by an approved service centre (See details at the end of this is leaflet).
• Do not place the accessories in a microwave oven.
• For your own safety, use only accessories and spare parts designed for your appliance and sold in an
approved service centre.
DESCRIPTION
a - Motor unit
a1 Electronic speed selector
a2 Multi-function head (a3) release button
a3 Multi-function head
a4 High speed outlet (blender jug / juice
extractor / grinder)
a5 Safety cover
a6 Mixer accessories outlet (kneader, balloon
whisk, mixer)
a7 Power cord storage
b - Bowl assembly
b1 Stainless steel bowl
b2 Lid
c - Mixer accessories
c1 Kneader
c2 Mixer
c3 Balloon whisk
d - Blender jug (depending on model)
d1 Jug
d2 Lid
d3 Measuring cap
e - Attachment holder (depending on model)
f - Mincer head (depending on model)
f1 Metal body
f2 Feed screw
f3 Blade
f4 Large-hole screen
f5 Small-hole screen
f6 Nut
f7 Pusher
f8 Tray
g - Vegetable slicer (depending on model)
g1 Drum body
g2 Pusher
g3 Slicer drum A
g4 Coarse grater drum C
g5 Fine grater drum D
g6 Reibekuchen (potato rosti) grater drum E
h - Juice extractor (depending on model)
h1 Pusher
h2 Lid
h3 Rotary filter
h4 Juice collector
h5 Pouring spout
h6 Locking lever
i - Grinder (depending on model)
SAFETY INSTRUCTIONS
9
EN
TE_KITCHEN-MACHINE_0828680-02_0828680-02 09/01/12 13:36 Page9
• Always remove the blender (d) or the juice extractor (h) before pressing the multi-function head (a3)
release button (a2).
• Always use the pusher (f7) with the mincer head accessory (f), to guide food in the feed tube. Never
use your fingers, a fork, a spoon, a knife or any other object.
• Never touch any moving parts. Wait for the appliance to come to a complete stop before removing
accessories.
• Handle the sharp blades (d, f, g) carefully when emptying the bowls and when cleaning: they are
extremely sharp.
• Do not touch the whisks or the kneader when the appliance is running.
• Do not allow long hair, scarves, ties etc. to dangle over the appliance during operation.
• Never insert utensils (spoon, spatula, etc.) through the feed tube in the lids (b2), (d2) or (h2) in the
drum body (g1).
• Do not run the blender jug (d1) without its lid (d2).
• Use only one accessory at a time.
• Do not use the bowls (b1, d1) as containers for freezing, cooking or sterilisation.
• Do not use the juice extractor if the rotary filter (h3) is damaged.
• Switch off the appliance and unplug from the mains supply before changing accessories or handling
any parts that move during use.
• Before using for the first time, wash all accessory parts in warm water and washing up liquid (except
for the attachment (e): see cleaning paragraph) Rinse and dry.
• Place the appliance on a flat, clean and dry surface. Make sure that the selector button (a1) is in "0"
position and plug in your appliance.
• You have several options for starting your appliance:
- Intermittent operation (pulse): Turn the selector button (a1) to the "pulse" position. Using a
succession of pulses can give you better control when preparing certain foods.
- Continuous operation: Turn the selector button (a1) to the desired position from "1" to "max"
depending on the food you are preparing.
You can change it as required during preparation.
• To stop the appliance, turn the button (a1) to "0".
Important
: The appliance will start only if the cover (a5) and the head (a3) are locked. The
appliance will stop immediately if you unlock the cover (a5) and/or the head (a3) during
operation. Lock the cover and/or the head, turn the control button (a1) to the "0" position, and
then start the appliance normally by selecting the desired speed.
Your appliance comes with a microprocessor that controls and analyses the operating power. If the load
becomes too high, your appliance will stop automatically. To restart your appliance, turn the rotary
button (a1) to the "0" position and remove some of your ingredients. Allow your appliance to cool down
for a few minutes. You can then select the desired speed to complete your preparation.
1 - MIXING / KNEADING / BEATING / EMULSIFYING / WHISKING
You can prepare up to 1,8 kg of ingredients using the stainless steel bowl (b1) and its lid (b2) depending
on the food.
ACCESSORIES USED:
- Stainless steel bowl (b1).
- Lid (b2)
- Kneader (c1) or mixer (c2) or balloon whisk (c3)
BEFORE FIRST USE
The paragraph numbering corresponds to the numbers in the diagrams.
10
EN
TE_KITCHEN-MACHINE_0828680-02_0828680-02 09/01/12 13:36 Page10
1.1 - ASSEMBLING THE ACCESSORIES
• Press the button (a2) to release the multi-function head (a3) and raise it until it locks in place (Fig
1.1.a).
• Lock the stainless steel bowl (b1) (clockwise) on the appliance and put in the ingredients (Fig.1.b).
• Insert the desired accessory (c1, c2 or c3) on the outlet (a6), push and rotate it anti-clockwise a
quarter turn to lock the accessory in its housing (Fig 1.1c).
• Place the multi-function head (a3) to the horizontal position: press the button (a2) and manually lower
the multi-function head (a3) until it locks (the button (a2) returns to its initial position).
• Slide the lid (b2) over the stainless steel bowl (b1) (Fig 1.1d).
Note: It is not essential to use the lid but it prevents splashing.
• Make sure that the cover (a5) is locked correctly (clockwise) on the high-speed outlet (a4).
1.2 - USAGE
Start by turning the selector button (a1) to the desired position according to the recipe.
• The appliance starts running immediately.
You can add food through the hole in the lid (b2) during preparation.
• To stop the appliance, turn the button (a1) to "0".
Tips:
- Kneading
- Use the kneader accessory (c1) at speed "1".
You can knead up to 500 g of flour (e.g. for white bread, short crust pastry, pizza dough etc..) NB. for
wholemeal and rye flour up to 450g of flour.
- Mixing
- Use the mixer (c2) at speed "1" to "max".
You can mix up to 1,8 kg of light dough (light cake mixture, sponge cake, biscuit or cookie dough).
- Never use the mixer (c2) to knead heavy dough.
- Beating / emulsifying / whisking
- Use the balloon whisk (c3) at speed "1" to "max".
- You can prepare: mayonnaise, aioli, sauces, whisked egg whites (up to 8 egg whites), whipped cream
(up to 500 ml), meringues etc.
- Never use the balloon whisk (c3) to knead heavy dough or mix light dough.
1.3 - DISMANTLING THE ACCESSORIES
• Wait for the appliance to come to a complete stop.
• Remove the lid (b2).
• Using the button (a2), release the multi-function head (a3) and raise it to the upper position.
• Release the accessory (c1), (c2) or (c3) from the multi-function head by pushing the accessory into
the head and rotating it clockwise a quarter turn.
• Remove the stainless steel bowl.
2 - BLENDING/MIXING (DEPENDING ON MODEL)
Depending on the nature of the food, you can use the blender (d) to prepare up to 1.5 L of thick mixtures
and 1.25 L of liquid mixtures.
ACCESSORIES USED :
- Blender jug (d)
2.1 - ASSEMBLING THE ACCESSORIES
• Place the multi-function head (a3) in the horizontal position: press the button (a2) and manually
lower the multi-function head (a3) until it locks (the button (a2) returns to its initial position) (Fig
2.1a).
• Unlock the safety cover (a5) from the high-speed outlet (a4) by rotating it anti-clockwise and then
remove it (Fig 2.1.b).
11
EN
TE_KITCHEN-MACHINE_0828680-02_0828680-02 09/01/12 13:36 Page11
• Make sure that the appliance is switched off before fitting the blender (d).
• Lock the blender jug (d) on the outlet (a4) by rotating it clockwise.
• Place the food in the blender jug, and lock the lid (d2) fitted with the measuring cap (d3), by rotating
it anti-clockwise (Fig 2.1c).
2.2 - USAGE
• Start by turning the selector button (a1) to the desired position according to the recipe.
Use the "Pulse" position for better mixing control and for a better blending of your preparation.
You can add food through the hole in the measuring cap (d3) during preparation.
• To stop the appliance, turn the button (a1) to "0".
Tips :
You can prepare:
- finely blended soups, cream soups, stewed fruit, milkshakes and cocktails.
- liquid batter (pancake, fritters, Yorkshire pudding, waffles, clafoutis and custard flans).
If ingredients stick to the sides of the jug when mixing, stop the appliance. Remove the blender, and
push the food down onto the blades and put your blender back to continue your preparation.
• Never fill the blender jug with boiling liquid. Only use liquids or foods at simmering temperatures or
below.
• Never run the blender jug empty.
• Always use the blender jug with its lid.
• Never remove the lid before the blades have stopped completely.
• Always pour liquid ingredients into the blender jug first before adding solid ingredients.
2.3 - DISMANTLING THE ACCESSORY
• Wait for the appliance to come to a complete stop before removing the blender by unlocking it in the
anti-clockwise direction and put back the cover (a5) by locking it on the outlet (a4) (clockwise).
3 - MINCING (DEPENDING ON MODEL)
ACCESSORIES USED :
- Attachment holder (e)
- Assembled mincer head (f)
3.1 - FITTING THE MINCER ATTACHMENT
• Press the button (a2) to release the multi-function head (a3) and raise it until it locks in place (Fig
3.1a).
• Place the attachment (e) and lock it in the anti-clockwise direction such that the outlet is in alignment
with the appliance (Fig 3.1b).
• Place the multi-function head (a3) in the horizontal position by pressing the button (a2) once again.
3.2 - ASSEMBLING THE MINCER HEAD
• Hold the body (f1) by the feed tube, with the wider opening uppermost.
• Insert the feed screw (f2) (long shaft first) into the body (f1) (Fig 3.2a).
• Fit the blade (f3) onto the short shaft protruding from the feed screw (f2) with the cutting edges facing
outwards.
• Fit the chosen screen (f4 or f5) on the blade (f3), aligning the two lugs with the two notches in the
body (f1).
• Screw the nut (f6) home on the body (f1) in the clockwise direction, without locking it.
• Check the assembly. The shaft should have no play, neither should it be able to turn on its own.
Otherwise, repeat the assembly procedure (Fig 3.2b).
3.3 - FITTING THE MINCER HEAD ON THE APPLIANCE
• Facing the attachment outlet (e), insert the assembled mincer head (f) inclined to the right, aligning
the two bayonets in the mincer head with the two notches in the attachment. Push the mincer head
home into the attachment and turn the mincer head anti-clockwise until it latches with the feed tube
in the vertical position (Fig 3.3a).
• Place the removable tray (f8) on the feed tube (Fig 3.3b).
• Turn the safety cover (a5) clockwise on the high speed outlet (a4).
12
EN
TE_KITCHEN-MACHINE_0828680-02_0828680-02 09/01/12 13:36 Page12
3.4 - USAGE, TIPS AND DISMANTLING
• Make sure that the safety cover (a5) is locked correctly (clockwise) on the high-speed outlet (a4).
• Place a container to collect the preparation in front of the appliance.
• Run the appliance by turning the selector (a1) to speed "3" or "4".
• Push the meat, piece by piece, down the feed tube, using the pusher (f7). Never push the ingredients
down the feed tube with your fingers or any other utensil.
• To stop the appliance, turn the selector to "0" speed and wait for the appliance to come to a complete
stop.
• Unlock the mincer head in the reverse order of the assembly.
Tips :
- Prepare all of the foodstuffs to be minced (for meat, remove the bones, gristle and tendons and cut
it into pieces of approximately 2 x 2 cm).
- Make sure that frozen meat is thoroughly thawed.
- At the end of the operation, you can feed a few small pieces of bread into the feed tube to clear any
meat remaining in the machine.
4 - GRATING / SLICING (DEPENDING ON MODEL)
ACCESSORIES USED :
- Attachment holder (e)
- Assembled vegetable slicer (g)
- Drums (depending on model)
4.1 - ASSEMBLING THE ACCESSORIES
• Press the button (a2) to release the multi-function head (a3) and raise it until it locks in place.
• Insert the attachment (e) and lock it in an anti-clockwise direction so that the outlet is aligned to
the left of the appliance.
• Place the multi-function head (a3) in the horizontal position by pressing the button (a2) once again
(Fig 4.1b).
• Make sure that the safety cover (a5) is locked correctly (clockwise) on the high-speed outlet (a4) (Fig
4.1c).
• Position the attachment (e) facing you, insert the drum body (g1) inclined to the right, aligning the
two bayonets in the drum body with the two notches in the attachment. Push the drum body home
and turn the drum body anti-clockwise until it latches with the feed tube in the vertical position.
• Insert the chosen drum into the body, and make sure that it is fully engaged in the body.
4.2 - USAGE AND TIPS
• Place a container to collect the food in front of the appliance.
• Run the appliance by turning the selector (a1) to speed "3" to slice and to speed "4" to grate.
• Place the food in the feed tube and press down with the pusher (g2). Never push the ingredients
with your fingers or any other utensil.
• To stop the appliance, turn the selector to "0" speed and wait for the appliance to come to a complete
stop.
• Unlock the drum body in the reverse order of the assembly.
• Use the drums to :
- Grate coarsely C (g4) / grate finely D (g5): carrots, celery, potatoes, hard cheese (firm texture),
etc.
- Slice thickly A (g3): potatoes, carrots, cucumbers, apples, beetroot, etc.
- Reibekuchen (potato rosti) E (g6): potatoes, parmesan, etc.
5 - EXTRACTING JUICE FROM FRUITS AND VEGETABLES (DEPENDING ON MODEL)
ACCESSORIES USED :
- Assembled juice extractor (h).
13
EN
TE_KITCHEN-MACHINE_0828680-02_0828680-02 09/01/12 13:36 Page13
5.1 - ASSEMBLING THE JUICE EXTRACTOR
• Place the filter (h3) in the middle of the juice collector (h4) (Fig 5.1a).
• Lock the lid: turn it anti-clockwise and lock the lid (h2) on the juice collector (h4) (closed padlock
position) (Fig 5.1b).
• General locking: push the locking lever (h6) to closed padlock position (Fig 5.1c).
5.2 - FITTING THE JUICE EXTRACTOR ON THE APPLIANCE
• Place the multi-function head (a3) in the horizontal position: press the button (a2) and manually
lower the multi-function head (a3) until it locks (the button (a2) returns to its initial position) (Fig
5.2a).
• Unlock and remove the cover (a5) from the outlet (a4) by turning it anti-clockwise (Fig 5.2b).
• Make sure that the appliance is switched off before locking the juice extractor (h).
• Lock the assembled juice extractor on the outlet (a4) by turning it clockwise, so as to have the outlet
for the pouring spout aligned with the appliance (Fig 5.2c).
• Fit the pouring spout (h5) on the collector (h4).
5.3 - USAGE AND TIPS
• Place a large glass under the pouring spout (h5).
• Run the appliance by turning the selector (a1) to speed "3".
• Cut the fruits and/or vegetables into pieces.
• Insert them down the feed tube in the lid (h2) push them slowly using the pusher (h1). Never push
the ingredients with your fingers or any other utensil.
• Do not process 500 g of food more than 5 times continuously, without allowing your appliance to cool
down completely.
• For best results, clean the filter after every 300 g of ingredients.
• Important: When the pulp collector is full, stop the appliance and empty the collector.
• To stop the appliance, turn the selector to "0" speed and wait for the appliance to come to a complete
stop.
• Wait until the rotary filter comes to a complete stop before removing the assembly from the
appliance.
• To remove the juice extractor, unlock it by turning it anti-clockwise.
• Place the locking lever (h6) in the open padlock position. Open the lid (open padlock position). You
can then remove the filter (h3) to clean it and empty the collector (h4).
Tips :
• You can make juice from: carrots, tomatoes, apples, grapes, raspberries, etc.
• Peel fruits with thick skins; remove stones and the core of pineapples.
• It is not possible to extract juice from certain fruits and vegetables: bananas, avocado pears,
blackberries, etc.
• You can prepare juices with different fruits and vegetables without having to clean the juice extractor
every time, the flavours will not be mixed. Just run the extractor with a little water to rinse it between
two different juices.
• Drink the juices immediately after preparation, and add lemon juice to keep them in the fridge for a
few hours.
6 - ADJUSTING THE CORD LENGTH
For more comfortable use or for storage, you can reduce the cord length by pushing it inside the motor
unit (a) via the opening on the rear (a7) (Fig 6).
14
EN
TE_KITCHEN-MACHINE_0828680-02_0828680-02 09/01/12 13:36 Page14
7 - FINELY CHOPPING SMALL QUANTITIES (DEPENDING ON MODEL)
ACCESSORY USED :
- Assembled grinder (i), (refer to the grinder instruction booklet for details on assembly).
You can use the grinder to :
- Chop in a few seconds by pulsing: dried figs, dried apricots, etc.
Quantity / max time: 100g / 5 secs
This grinder is not designed for hard products like coffee beans or hard spices.
• Unplug the appliance.
• Do not immerse the motor unit (a) or the attachment (e) in water or under running water. Wipe them
with a dry or slightly damp cloth.
• For easier cleaning, rinse the accessories quickly after use. Dismantle the mincer head assembly fully.
Handle the blades with care to prevent injury.
• Wash, rinse and dry the accessories: they are dishwasher-safe, except for all the metal components in
the mincer head: body (f1), feed screw (f2), blade (f3), screens (f4 and f5), nut (f6).
• The screens (f4) and (f5) as well as the blade (f3) must remain greased. Coat them with cooking oil.
Tips :
• In the event any of your accessories are coloured by food (carrots, oranges, etc.), rub with a cloth
soaked in cooking oil and then clean them as usual.
• Blender jug (d): pour some hot water containing a few drops of washing up liquid into the blender.
Close the lid. Place it on the appliance and pulse a few times. After removing it, rinse the jug in
running water and allow to dry (jug upside down).
Do not store your appliance in a humid environment.
If your appliance does not work, check:
- that it is plugged in correctly.
- that the accessories are correctly locked.
- that the safety cover (a5) is present and locked when the high-speed outlet (a4) is not used.
- that the multi-function head (a3) is locked horizontally.
Your appliance comes with a microprocessor that controls and analyses the operating power. If the load
becomes too high, your appliance will stop automatically. To restart your appliance, turn the speed
control (a1) to the "0" position and remove some of your ingredients. Allow your appliance to cool
down for a few minutes. You can then select the desired speed to complete your preparation.
HELPLINE:
If you have any product problems or queries, please contact our Customer Relations Team first for expert
help and advice:
0845 602 1454 – UK
(01) 677 4003 – Ireland
02 97487944 – Australia
CLEANING
STORAGE
WHAT TO DO IF YOUR APPLIANCE DOES NOT WORK
15
EN
TE_KITCHEN-MACHINE_0828680-02_0828680-02 09/01/12 13:36 Page15
TE_KITCHEN-MACHINE_0828680-02_0828680-02 09/01/12 13:36 Page22
Loading...
