Page 1
www.groupeseb.com
Page 2
1
3
5
2
18
19
20
21
4
6
8
7
9
11
10
12
16
17
13
14
15
O
I
L
B
O
X
OIL BOX
Page 3
3
Description
Filtration, drainage and automatic storage of oil/fat
Your fryer is fitted with an exclusive and patented system for filtration and automatic
drainage, suitable for most types of oils and fats used for cooking.
• The drainage of oil is completely automatic and safe.
• The automatic patented filtration system ensures your oil/fat stays clean and lasts
longer for healthier frying. No crumbs guarantees less odours.
• The OIL BOX container enables you to store your oil or fat and keep it until you next
want to use it and avoid any transfer of flavours.
Ultra easy cleaning
Your fryer is easy to handle and to dismantle.
• All the pieces (except the electrical base and the cord) are dishwasher safe
• Thanks to the patented automatic filtration and oil storage system, your fryer can go into
the dishwasher after each use.
Clean as new after each use.
Variable oil level
Your fryer is ideal for various dishes. Adjust the right oil quantity for each type of food.
•You can use it as a frying pan with an oil level between 0.5 l and 1.2 l and as a fryer with
an oil level between 1.2 l and 2.2 l.
1. Filter cover
2. Washable anti-odour filter
3. Lid
4. Viewing window
5. Basket
6. Handle unlocking button
7. Basket “rise and fall” handle
8. Fryer with non-stick bowl
9. Bowl fill level marks :
2.2 l / 1.2 l / 0.5 l
10. Carrying handles
11. Fixed oil filter grid
12. Lid opening button
13. Temperature light
14. Electrical control base
15. Thermostat control / ON/OFF
position
16. Timer (depending on model)
17. Cord
OIL BOX
18. Lid
19. Container
20. Draining pin
21. Carrying handles
Page 4
4
Read and follow carefully the instructions for use.
Protection of the environment
•Your appliance has been designed to work for many years. However, when finally you
decide to replace your deep fryer, do not forget to think of what you can do to help to
protect the environment by disposing of it at your local waste disposal centre.
•This appliance complies with current safety
regulations and requirements as well as
directives:
- 89/336/CEE
modified by
92/31/CEE and
93/68/CEE.
- 73/23/ CEE
modified by
93/68/CEE.
•Check that the mains voltage corresponds
with that shown on the appliance
(alternating current only).
•If the appliance is used in a country other
than that of purchase, have it checked by an
Approved Service Centre.
•This electrical appliance operates at high
temperatures which may cause burns.
Despite the high heat protection of the deep
fryer, do not touch the apparent metal parts.
•Do not leave the appliance switched on
while unattended.
•The basket handle may become hot after
prolonged use.
•Use and store it out of children’s reach.
•Never insert any object between the
removable body and the bottom of the
equipment.
•Always plug in the appliance at an earthed
power socket.
•Do not use an extension lead. If you accept
liability for doing so, only use an extension
lead which is in good condition, has an
earthed plug, and is suited to the power of
the equipment.
•Do not leave the cord hanging.
•Do not unplug the appliance by pulling on
the cord.
•Always unplug the appliance: immediately
after use, when moving it, prior to any
cleaning or maintenance.
•Never use or plug in your appliance if:
- its power cord is faulty or damaged,
- the appliance has been dropped,
- it has visible damage or operating faults.
In such cases, to avoid any danger contact
our Approved Service Centre to have the
appliance repaired, as special tools are
needed. Never dismantle the appliance
yourself. This will negate the guarantee.
•If the power cord is damaged, it must be
replaced by an authorised service centre, in
order to avoid any danger.
•Do not switch on the appliance near to
inflammable materials (blinds, curtains, etc.)
or close to an external heat source (gas
stove, hotplate, etc.)
•In the event of fire, never try to extinguish
the flames with water. Close the lid. Smother
the flames with a damp cloth.
•Use a flat, stable, heat-resistant surface,
away from any water splashes.
•Never immerse the electrical base and cord
in water.
•Do not move the appliance when it is full of
liquids or hot food.
•If you have a removable bowl, never take it
out when the fryer is switched on.
•This product has been designed for
domestic use only. Any commercial use,
inappropriate use or failure to comply with
the instructions, the manufacturer accepts
no responsibility and the guarantee will not
apply.
Important: if the electrical cord of this
appliance is damaged, it must only be
replaced by an authorised Service Dealer. The
safety of this appliance complies with the
technical regulations and standards in force.
•If you have any product problems or
queries, please contact our Customer
Relations Team first for expert help and
advice.
H
ELPLINE:
0845 602 1454 - UK
(01) 4751947 - Ireland
or consult our website - www.tefal.co.uk
Safety instructions
Page 5
5
O
I
L
B
O
X
Before first use
Dismantling
•Press on the lid opening button and
remove the lid.
•Lift the basket handle and remove the
basket. Remove the bowl from the
electrical base.
Cleaning
•Clean all parts (except the electrical
base and the cord). The OIL BOX, the
fryer body, the lid, the basket and its
handle are dishwasher safe or can be
cleaned with a sponge and washing-up
liquid.
•Dry them thoroughly using a soft cloth,
ensuring that the connection ends at the
back of the fryer are dry.
• Replace the lid.
• Remove the filter cover.
•Put the filter into place.
• Place the fryer on the electrical base.
1
2
After cleaning,
press on the red
button under the
fryer to release any
water in the bowl.
Never immerse the
electrical base and
cord in water.
Unpacking
• Unpack the appliance and remove all the stickers.
OK
Check that the antiodour filter is
completely dry
before putting it
back into place.
Page 6
6
Preparation for use
2,2 L
0,5 L
Oil to use
•Fill the bowl with oil.
• Use an oil recommended for deep
frying.
For best results we recommend blended
vegetable oil. For sunflower oil,
groundnut, oil, or soya oil, ensure the
oil is changed after every 5 uses.
• If you use solid vegetable fat :
- cut it into pieces and melt it in the
bowl at 150°C,
- never melt solid fat in the basket.
•Follow the manufacturer’s cooking
recommendations.
•You have the possibility of frying your
food with 0.5 litres of fat/oil to 2.2 litre
of fat/oil depending on type of food (see
cooking tables p. 9).
•Lard or dripping should not be used
under any circumstances and may
cause overflowing, smoking or risk of
fire. For traditional UK style deep fried
foods, especially chips, we do not
recommend using olive oil.
Do not mix different
types of fat/oil.
Adjust the oil level
depending on type
of food. Do not
exceed the quantity
corresponding to
the marks 2.2 l .
Never use less than
0.5 l.
Do not use the
basket if you use
less than 1.2 l.
Preheating
• Close the lid.
•Plug in the fryer.
• Set the thermostat according to the food
you are frying (see cooking tables p. 9)
• The fryer heats up and the temperature
light comes on.
Never plug in the
deep fryer without
oil/fat inside.
Oil Soid vegetable fat
2.2 l 1925 g
1.2 l 890 g
0.5 l 445 g
Do not leave the
deep fryer
unattended. Do
not let the power
cord hang down.
Place the fryer:
- on a flat, stable,
heat-resistant
surface,
- where the lid can
open fully and
away from
overhead
cupboards,
- away from water
splashes or heat
sources,
- out of the reach
of children.
Page 7
7
Preparation for use
Preparing food for frying
•Lift the handle on the basket until you
hear a click as it locks into place.
• Remove excess moisture (water and
ice) from the food.
• No matter what the recipe, food must
be perfectly dry : this will prevent
overflowing and extend the life of the
oil. When dishes include raw potatoes
(chips, crisps and potato straws), wash
them in cold water to remove the
starch. This will stop them from sticking
together. Dry them carefully and
thoroughly with paper kitchen towel.
Before frying, remove any ice crystals
on the food by shaking the basket of
food to be fried over the sink.
•Fill the basket.
•Reduce food quantity for frozen food.
Lowering the basket
•Put the basket in place on the edge of
the bowl and leave the handle in the
horizontal position.
•When the oil has reached the right
temperature, the light goes out.
•Close the lid and press the handle
unlocking button.
•Fold the handle very slowly into its
housing to lower the basket into the oil.
The timer does not
switch off the
fryer.
Set the cooking time
(depending on model)
•Press on the timer button to set the time
minute by minute.
• Release. The selected time (in minutes)
is displayed and the countdown starts.
•In case of a mistake or to delete the
selected time, hold the button down for
2 seconds.
•To stop the timer ringing signal, press
on the button.
Remove excess ice
from frozen food
before frying by
shaking the basket
of food to be fried
over the sink.
Cut food to the same
size so that it cooks
evenly. Avoid using
pieces that are too
thick.
Fresh chips Frozen chips
Maximum quantity 1000 g 900 g
Recommended max quantity 625 g 450 g
Keep out of reach
of children.
Page 8
8
For a second frying
• Correct the level of oil if necessary, with
the same type of oil.
•Wait until the temperature light goes out
before lowering the second batch of
food.
Taking food out
•Lift the basket handle until you hear the
click as it locks.
• Open the lid
• Remove the basket, making sure that
the rod comes completely out of the
bowl.
• Serve.
Cooking
Warning : do not
place your hand
above the filter.
The steam is very
hot.
Do not remove the
lid during cooking.
Do not mix different
types of oil.
Stopping the appliance
• Once frying is completed, place the
thermostat/control button on to the
position O/I.
• Unplug the appliance.
• Move the fryer using the carrying
handles.
•For filtering and draining the fat, see the
chapter on Maintenance.
Never move the
fryer with hot oil
or fat inside.
While cooking
•During cooking, it is normal for the
temperature light to go on and off.
Season food with salt
and pepper once out
of the fryer to avoid
getting it into the
oil/fat.
click!
Page 9
9
Quantity
Fresh foods Frozen foods
Chips -
Maximum quantity
2.2 l 1000 g 190°C 13 - 18 min
- -
Chips -
Recommended max. quantity
2.2 l 625 g 170°C 12 - 14 min
- -
Chips -
Maximum quantity
2.2 l 900 g
- -
190°C 11 - 16 min
Chips -
Recommended max. quantity
2.2 l 450 g
- -
170°C 7 - 9 min
Cooking
Cooking times
The cooking times and the quantities of oil are only a guide,
they may vary depending on quantities, size of pieces and
personal taste.
We recommend that you:
- limit the quantity and the temperature at 170°C especially for potatoes,
- use the basket for french fries,
- control the cooking : only eat golden brown fried food not burnt food,
- filter the oil after every use to avoid burnt crumbs and change it regularly,
- have a balanced and varied diet which includes 5 portions of fruit and vegetables daily,
- store your fresh potatoes in a room above 8°C.
For good quality and fast cooking, we recommend that you limit the quantity of chips to 1/2 a basket per fry.
For a larger quantity of food or potatoes, the temperature drops very fast just after lowering the basket. While
cooking, this temperature does not rise above 175°C even if the thermostat is at the 190°C (= Stabilized
Temperature before lowering).
Chips 2.2 l 150 g 170°C 7 - 10 min 170°C 7 - 10 min
Fried chicken drumstick 2.2 l 400 g 180°C 12 - 16 min 190°C 15 - 17 min
Chicken nuggets 1.2 l 14 p 170°C 6 - 8 min 190°C 6 - 8 min
Breaded fish nuggets 1.2 l 14 p 170°C 6 - 8 min 190°C 6 - 8 min
Breaded camembert wedges 1.2 l 300 g 190°C 1 min
- -
Fried whole mushrooms 2.2 l 240 g 150°C 4 - 5 min 190°C 4 - 5 min
Breaded plaice fillet 2.2 l 170 g 160°C 4 - 6 min 190°C 5 - 7 min
Vegetables fritters
(zucchini…)
1.2 l 240 g 170°C 8 - 9 min 190°C 8 - 9 min
Tempura 1.2 l 420 g 190°C 2 - 3 min 190°C 4 - 5 min
Apple fritters 1.2 l 240 g 170°C 5 - 6 min 190°C 5 - 6 min
Breaded or battered onion rings 0.5 l 200 g 170°C 3 - 4 min 190°C 3 - 4 min
Battered calamari 0.5 l 10 - 12 p 170°C 5 - 6 min 190°C 4 - 6 min
Battered large prawns 0.5 l 10 - 12 p 170°C 4 - 5 min 170°C 4 - 5 min
Samosas 0.5 l 8 p 170°C 4 - 5 min 190°C 5 - 6 min
Mozzarella sticks 0.5 l 10 - 12 p 190°C 40 - 50 sec
- -
Cooks tips: When cooking battered food and doughnuts, remove the wire basket to prevent food
sticking to it. Take great care when handling the food and use tongs. Gradually place the food
into the hot oil, submerging it an inch at a time to prevent it from sinking straight away.
Page 10
10
Draining the oil
For your safety, the appliance
automatically drains all kinds of fat (oil or
solid fat).
• Once frying is finished, leave the oil to
cool for approximately 2 hours.
• Remove the OIL BOX lid.
•Take the fryer off its electrical base.
•Place the fryer on the OIL BOX ensuring
it is positioned on the draining pin. The
filtration may take one hour to
complete.
Maintenance
clean oil
max
O
I
L
B
O
X
Make sure that the
oil container is
empty before
draining the fryer.
If you use solid fat,
do not wait for it
to go solid before
putting the fryer
on the OIL BOX.
Never put your
hand under the
fryer or on the
base, they are both
still very hot.
It is important to
drain/filter the oil
after each use.
Crumbs that break
away from food
tend to burn and
alter the quality of
the oil more
rapidly. Over time
this increases the
risk of catching
fire.
Storing the container of oil
•Take the fryer off the OIL BOX after
making sure the fryer is empty.
Oil is filtered and ready to reuse.
• Replace the lid on the OIL BOX.
• Carry the container with both hands.
•Store it in a cool dry place away from
the light.
clean oil
max
Page 11
11
Cleaning the fryer
Clean as new after each use.
The fryer is very easy to clean.
•You can put all the parts in the
dishwasher except the electrical base
and power cord.
You can also clean them using a
sponge and washing-up liquid.
•For a more efficient odour filtration, we
recommed that you remove the antiodour filter from the lid and wash it.
•After cleaning, press on the red button
under the fryer to release any water in
the bowl.
•Clean the electrical base regularly with
a damp cloth. You may find some oil
drops in the centre of the electrical
base. This is normal.
• The fryer is fitted with a non-stick
coated bowl :
The browning and scratches which
may appear after long use are normal.
We guarantee that the non-stick
coating complies with regulations
concerning materials in contact with
foodstuffs.
•Take care not to bang or drop the bowl
which can distort it.
• Do not distort the connection ends
under the bowl.
• Do not try to dismantle the fixed oil
filter grid.
Maintenance
Do not use
agressive or
abrasive products.
Do not put the
electrical base and
its cord in the
dishwasher or
immerse them in
the water.
To retain the nonstick qualities for
as long as
possible, do not
use metal utensils.
Before filling the
fryer bowl, always
check to ensure
the red button
under the fryer is
in the right
position.
OK
Page 12
12
Re-Using the fat/oil
Hold the container carefully
For oil:
• Remove the lid from the OIL BOX then
empty the oil in the bowl.
For solid fat:
• Remove the lid from the OIL BOX.
•Loosen the fat using a round-ended
knife.
• Cut it into pieces and melt it in the fryer
at 150°C (never melt it in the basket).
Maintenance
2
1
Changing the oil/fat
•Do not pour used oil into the sink.
Leave it to cool and throw it away with
the household waste.
Change the oil
after a maximum
of 10 to 12 uses.
“Clean” oil keeps
the flavour and
lightness of foods
and prevents
overflowing.
1
2
Replace the anti-odour filter
(ref XA 500000)
• Remove the filter lid.
•Take the filter out.
• Change the filter.
•Replace the filter lid.
The filter is
washable, however
for improved
efficiency, change
the filter each time
the fryer has been
used a maximum
of 80 times.
Never put the OIL
BOX in the
microwave oven.
Page 13
13
• The max (2.2 l) fill mark for the bowl has been
exceeded.
• Respect the oil level (2.2 l). Clean the fryer before any use.
•The bowl is leaking. • If it is only some drops on the electrical base, go to the page
11. For a larger leak, contact an Approved Service Centre.
•Some oil was left in the OIL BOX. •Empty the OIL BOX before draining the oil. Clean the fryer
before any use.
Practical advice in case of difficulties
• The appliance is not plugged in or the thermostat
button is in the off position O/I.
•Plug-in the appliance, place the thermostat button onto the
temperature you require.
• The safety cut-out is activated. •Place the thermostat control button in the off position then
place it onto the temperature you require.
• The fryer is not positioned properly on the
electrical base.
• Make sure there are no foreign objects between the base and
the fryer.
• The anti- odour filter is saturated. • Change the filter (after 80 uses).
• The fat/oil has deteriorated.
•Renew the frying oil (after 10 to 12 uses max), more frequently
depending on the oil.
• The fat/oil is unsuitable
• Use a good quality blended vegetable oil (See Page 6).
• The lid is not properly closed • Make sure that the lid is properly locked/closed.
• The max (2.2 l) fill mark for the bowl has been
exceeded.
• Check the oil level (2.2 l) and take out any surplus.
• The basket is too full or misshappen. • Check that the basket is not too full. Change your basket.
•Mixture of different oils and /or fats,or oil needs
changing.
• Empty and clean the bowl. Refill the bowl with only one type
of oil.
•Food too wet before frying. • Shake off loose ice and dry food well. Lower the basket very
gently.
• They are too thick and contain too much water. • Experiment by lengthening the cooking time or cut food into
thinner pieces.
•Too much food being cooked at the same time
and the cooking oil is not at the right temperature.
•Fry food in small quantities (especially when frozen).
• The temperature of the frying oil may not be high
enough: the thermostat is set incorrectly.
• Set the thermostat to the recommended temperature.
• The oil is still too hot. •Wait for the temperature to go down (approximately 2 hours).
• The fryer is not properly positioned on the
container.
•Position the fryer correctly.
• The filter grid is blocked or clogged.
• Empty the fryer into a container using the pouring spout and
clean the filter grid with warm water, washing-up liquid and a
non-metallic brush. Press on the red button under the fryer to
let out water and debris.
• The timer does not work (depending on model):
the battery is spent.
•Contact an Approved Service Centre.
• The temperature light does not come on. •Contact an Approved Service Centre.
Any repairs must be carried out only by an Approved Service Centre using original spare parts.
Emits unpleasant smells
A large quantity of steam is coming out around the lid
Foods are not browning and stay soft
The bowl does not drain
Others problems
Oil leaks
The fryer touches the oil on the OIL BOX (too much oil in the OIL BOX)
The frying oil is overflowing
The fryer is not heating
If you have any product problems or queries, please contact our Customer Relations Team
first for expert help and advice.
HELPLINE: 0845 602 1454 - UK
(01) 4751947 - Ireland
or consult our website - www.tefal.co.uk.
Problems and possible causes Solutions
Page 14
14
GB-IE Environment protection!
Your appliance contains valuable materials which can be
recovered or recycled.
Take it to your local waste collection centre.
Page 15
S.A.S. SEB SELONGEY CEDEX • RC. DIJON B 302 412 226 • REF. 5068425
Loading...
