Performance Data Sheet
AEA9415EXA
General Information
Model AEA9415EXA Refrigerant R-22
Test Condition ASHRAE Performance Test Voltage 115V ~ 60HZ
Return Gas 4.4°C (40°F) RETURN GAS Motor Type CSIR
Performance Information
Evap Temp (°F)
0
5
10
15
20
25
30
Condensing Temperature (°F)
80 90 100 110 120 130 140
Btu/h 1740 1390 1160 982 823 633 366
Watts 228 253 264 271 283 309 359
Amps 3.42 3.65 3.76 3.83 3.92 4.10 4.42
Lb/h 21.7 17.7 15.2 13.5 11.9 9.75 6.44
Btu/h 1950 1610 1380 1220 1080 911 670
Watts 228 262 278 286 295 316 356
Amps 3.47 3.71 3.84 3.90 3.97 4.10 4.37
Lb/h 24.3 20.5 18.2 16.7 15.5 13.8 10.9
Btu/h 2150 1810 1580 1420 1290 1130 909
Watts 226 270 292 303 311 326 359
Amps 3.49 3.77 3.91 3.98 4.03 4.13 4.35
Lb/h 26.8 23.1 20.9 19.6 18.6 17.1 14.6
Btu/h 2380 2020 1780 1620 1480 1330 1110
Watts 220 275 305 319 328 340 365
Amps 3.50 3.83 4.00 4.07 4.12 4.20 4.38
Lb/h 29.7 25.8 23.6 22.4 21.4 20.2 17.9
Btu/h 2650 2270 2010 1840 1690 1530 1310
Watts 209 276 315 335 345 355 374
Amps 3.49 3.87 4.08 4.18 4.23 4.30 4.45
Lb/h 33.3 29.2 26.8 25.5 24.5 23.3 21.1
Btu/h 3010 2600 2310 2110 1940 1760 1530
Watts 191 273 322 348 361 370 385
Amps 3.47 3.92 4.17 4.30 4.37 4.44 4.57
Lb/h 38.0 33.6 30.9 29.4 28.3 26.9 24.7
Btu/h 3490 3030 2700 2460 2260 2060 1800
Watts 166 263 323 357 375 385 396
Amps 3.43 3.95 4.27 4.44 4.53 4.61 4.73
Lb/h 44.2 39.3 36.3 34.4 33.0 31.5 29.1
COEFFICIENTS CAPACITY POWER CURRENT MASS FLOW
C1 1.407174E+04 -1.599006E+03 -9.950732E+00 1.856007E+02
C2 5.716513E+01 -3.875926E+01 -1.415688E-01 6.343973E-01
C3 -3.163676E+02 5.222324E+01 3.730435E-01 -4.310854E+00
C4 8.350065E-01 -2.433333E-01 -1.983278E-03 1.015480E-02
C5 -4.883371E-01 7.816667E-01 3.233244E-03 -5.807057E-03
C6 2.651465E+00 -4.929722E-01 -3.429627E-03 3.710797E-02
C7 3.955586E-02 -1.629630E-03 1.481440E-06 5.313080E-04
C8 -1.955571E-02 2.666667E-03 1.999945E-05 -2.466169E-04
C9 4.111143E-03 -3.666667E-03 -1.666621E-05 6.059084E-05
C10 -7.792653E-03 1.570370E-03 1.070341E-05 -1.104060E-04
Value = C1 + C2 * Te + C4 * Te^2 + C7 * Te^3 + (C3 + C5 * Te + C8 * Te^2) * Tc + (C6 + C9 * Te) * Tc^2 + C10 * Tc^3
Te = Evaporator Temperature
Tc = Condensing Temperature
Performance Data Sheet
AEA9415EXA
General Information
Model AEA9415EXA Refrigerant R-22
Test Condition ASHRAE Performance Test Voltage 115V ~ 60HZ
Return Gas 18.3°C (65°F) RETURN GAS Motor Type CSIR
Performance Information
Evap Temp (°F)
20
25
30
35
40
45
50
Condensing Temperature (°F)
80 90 100 110 120 130 140
Btu/h 2230 2140 2000 1840 1670 1530 1440
Watts 243 289 317 334 345 355 370
Amps 3.70 3.95 4.09 4.17 4.23 4.30 4.42
Lb/h 27.2 27.4 26.7 25.5 24.3 23.3 23.0
Btu/h 2580 2470 2300 2110 1920 1760 1660
Watts 257 302 332 351 365 378 398
Amps 3.73 4.00 4.17 4.27 4.36 4.46 4.61
Lb/h 31.4 31.4 30.5 29.1 27.7 26.7 26.3
Btu/h 2950 2810 2620 2400 2190 2020 1900
Watts 268 314 345 366 382 400 424
Amps 3.76 4.05 4.24 4.37 4.48 4.61 4.79
Lb/h 35.7 35.4 34.4 32.9 31.4 30.2 29.8
Btu/h 3330 3160 2950 2710 2480 2290 2160
Watts 278 324 356 379 399 420 448
Amps 3.79 4.10 4.31 4.47 4.60 4.75 4.96
Lb/h 40.2 39.7 38.5 36.9 35.3 34.1 33.7
Btu/h 3740 3540 3300 3050 2800 2590 2450
Watts 286 333 367 392 414 439 472
Amps 3.82 4.15 4.38 4.56 4.72 4.89 5.12
Lb/h 44.8 44.2 42.9 41.2 39.6 38.3 37.9
Btu/h 4180 3950 3690 3410 3150 2930 2770
Watts 294 342 376 404 429 458 495
Amps 3.85 4.20 4.46 4.65 4.83 5.03 5.29
Lb/h 49.8 49.1 47.6 45.9 44.2 43.0 42.7
Btu/h 4650 4400 4120 3820 3540 3300 3130
Watts 302 350 386 415 444 476 518
Amps 3.89 4.26 4.53 4.75 4.95 5.17 5.45
Lb/h 55.2 54.3 52.8 51.0 49.3 48.2 47.9
COEFFICIENTS CAPACITY POWER CURRENT MASS FLOW
C1 -5.108797E+03 -1.562660E+03 -5.968908E+00 -8.475860E+01
C2 1.471342E+02 1.130475E+01 -2.278603E-02 1.804608E+00
C3 1.685409E+02 4.315413E+01 2.571121E-01 2.562697E+00
C4 -4.776866E-01 -9.068595E-02 -8.556385E-05 -1.033421E-02
C5 -1.130543E+00 -1.376754E-01 3.616266E-04 -1.339414E-02
C6 -1.539978E+00 -3.415262E-01 -2.240744E-03 -2.244921E-02
C7 7.566630E-03 6.156602E-04 2.637523E-06 9.797993E-05
C8 1.876056E-03 4.799889E-05 -1.978168E-06 5.629325E-05
C9 2.705684E-03 8.364935E-04 1.091626E-06 3.518547E-05
C10 4.492171E-03 8.909398E-04 6.361133E-06 6.443880E-05
Value = C1 + C2 * Te + C4 * Te^2 + C7 * Te^3 + (C3 + C5 * Te + C8 * Te^2) * Tc + (C6 + C9 * Te) * Tc^2 + C10 * Tc^3
Te = Evaporator Temperature
Tc = Condensing Temperature
