Performance Data Sheet
AE4440U-AA1A
General Information
Model AE4440U-AA1A Refrigerant R-290
Test Condition ASHRAE Performance Test Voltage 115V ~ 60HZ
Return Gas 4.4°C (40°F) RETURN GAS Motor Type CSIR
Performance Information
Evap Temp (°F)
5
10
15
20
25
30
35
40
Condensing Temperature (°F)
80 90 100 110 120 130 140
Btu/h 2170 2110 2000 1860 1690 1510 1320
Watts 297 309 324 339 353 364 371
Amps 3.81 4.06 4.22 4.33 4.40 4.45 4.52
Lb/h 16.2 16.2 16.1 15.8 15.4 14.7 13.9
Btu/h 2470 2380 2260 2100 1920 1720 1520
Watts 308 321 338 355 371 385 394
Amps 3.88 4.13 4.31 4.43 4.52 4.60 4.69
Lb/h 18.4 18.4 18.2 17.9 17.5 16.9 16.1
Btu/h 2810 2700 2550 2370 2170 1960 1740
Watts 319 334 352 371 390 406 418
Amps 3.97 4.23 4.42 4.55 4.66 4.76 4.87
Lb/h 21.0 20.9 20.7 20.4 19.9 19.3 18.5
Btu/h 3190 3050 2870 2670 2440 2210 1970
Watts 329 346 365 387 408 426 441
Amps 4.06 4.33 4.52 4.67 4.79 4.91 5.05
Lb/h 23.9 23.7 23.5 23.1 22.5 21.9 21.1
Btu/h 3600 3430 3220 2980 2730 2470 2210
Watts 337 355 377 400 423 445 463
Amps 4.12 4.40 4.60 4.76 4.90 5.04 5.20
Lb/h 27.1 26.8 26.4 25.9 25.3 24.6 23.8
Btu/h 4030 3820 3580 3310 3020 2730 2450
Watts 341 361 384 410 436 461 482
Amps 4.14 4.42 4.64 4.81 4.96 5.12 5.30
Lb/h 30.5 30.1 29.6 28.9 28.2 27.4 26.5
Btu/h 4490 4240 3950 3640 3320 2990 2670
Watts 339 361 387 415 444 472 496
Amps 4.09 4.37 4.60 4.78 4.95 5.12 5.33
Lb/h 34.1 33.5 32.8 32.0 31.1 30.2 29.2
Btu/h 4960 4660 4330 3980 3610 3250 2890
Watts 332 356 384 415 447 477 505
Amps 3.94 4.23 4.46 4.66 4.84 5.03 5.26
Lb/h 37.7 36.9 36.0 35.0 34.0 32.9 31.8
Btu/h 5440 5090 4700 4300 3890 3480 3080
45
50
55
60
COEFFICIENTS CAPACITY POWER CURRENT MASS FLOW
C1 -4.909401E+02 5.008784E+02 -3.982433E+00 7.655797E+00
C2 7.766167E+01 1.919578E+00 8.116139E-03 4.153623E-01
C3 7.291241E+01 -8.180246E+00 1.899949E-01 1.489170E-01
C4 1.916149E+00 3.162360E-02 1.447521E-03 1.532178E-02
C5 -5.926632E-01 -2.377369E-02 -3.754382E-04 -2.840976E-03
C6 -6.601933E-01 9.302664E-02 -1.470955E-03 -7.525448E-04
C7 -8.835698E-03 -1.699193E-03 -3.032628E-05 -8.948205E-05
C8 -9.124385E-03 2.571883E-04 -1.405459E-06 -5.673424E-05
C9 1.907002E-03 2.703025E-04 3.288786E-06 1.653926E-05
C10 1.592705E-03 -3.020100E-04 3.866393E-06 -6.340528E-07
Watts 317 343 373 407 442 476 507
Amps 3.68 3.98 4.21 4.42 4.61 4.82 5.07
Lb/h 41.3 40.2 39.1 38.0 36.7 35.5 34.2
Btu/h 5920 5510 5070 4610 4150 3690 3240
Watts 293 321 354 391 429 466 501
Amps 3.29 3.58 3.82 4.04 4.24 4.47 4.73
Lb/h 44.9 43.5 42.2 40.8 39.3 37.9 36.4
Btu/h 6390 5910 5420 4910 4390 3870 3370
Watts 259 289 325 365 406 447 486
Amps 2.73 3.02 3.27 3.49 3.71 3.95 4.23
Lb/h 48.3 46.7 45.0 43.3 41.7 40.0 38.2
Btu/h 6840 6300 5740 5170 4590 4020 3460
Watts 213 246 285 328 372 417 460
Amps 1.99 2.28 2.54 2.77 3.00 3.25 3.55
Lb/h 51.6 49.6 47.6 45.6 43.7 41.7 39.8
Value = C1 + C2 * Te + C4 * Te^2 + C7 * Te^3 + (C3 + C5 * Te + C8 * Te^2) * Tc + (C6 + C9 * Te) * Tc^2 + C10 * Tc^3
Te = Evaporator Temperature
Tc = Condensing Temperature
Performance Data Sheet
AE4440U-AA1A
General Information
Model AE4440U-AA1A Refrigerant R-290
Test Condition ASHRAE Performance Test Voltage 115V ~ 60HZ
Return Gas 18.3°C (65°F) RETURN GAS Motor Type CSIR
Performance Information
Evap Temp (°F)
5
10
15
20
25
30
35
40
Condensing Temperature (°F)
80 90 100 110 120 130 140
Btu/h 2570 2440 2290 2110 1930 1760 1600
Watts 295 309 322 336 350 363 376
Amps 4.18 4.18 4.23 4.30 4.39 4.47 4.52
Lb/h 16.4 16.2 15.9 15.3 14.8 14.2 13.8
Btu/h 2900 2760 2590 2410 2210 2020 1840
Watts 307 322 338 354 369 384 399
Amps 4.26 4.27 4.32 4.41 4.51 4.60 4.67
Lb/h 18.4 18.4 18.0 17.5 16.9 16.4 15.9
Btu/h 3250 3100 2920 2720 2510 2300 2100
Watts 316 333 351 369 387 404 421
Amps 4.33 4.35 4.41 4.51 4.62 4.73 4.82
Lb/h 20.7 20.7 20.4 19.9 19.3 18.6 18.1
Btu/h 3620 3470 3270 3050 2820 2590 2360
Watts 322 343 363 383 404 423 443
Amps 4.39 4.41 4.49 4.60 4.73 4.86 4.97
Lb/h 23.1 23.1 22.9 22.4 21.7 21.1 20.4
Btu/h 4030 3860 3650 3410 3150 2890 2640
Watts 327 350 373 396 419 441 463
Amps 4.43 4.47 4.56 4.69 4.84 4.99 5.12
Lb/h 25.7 25.8 25.6 25.1 24.4 23.7 23.0
Btu/h 4460 4270 4040 3780 3510 3220 2940
Watts 329 355 381 407 432 457 482
Amps 4.45 4.50 4.61 4.76 4.93 5.11 5.27
Lb/h 28.5 28.7 28.5 28.0 27.3 26.5 25.7
Btu/h 4930 4720 4470 4180 3880 3570 3250
Watts 329 357 387 415 444 472 500
Amps 4.46 4.52 4.65 4.83 5.02 5.23 5.41
Lb/h 31.6 31.8 31.6 31.1 30.3 29.5 28.6
Btu/h 5420 5190 4920 4610 4280 3930 3590
Watts 326 358 390 422 454 486 517
Amps 4.44 4.53 4.68 4.88 5.11 5.34 5.56
Lb/h 34.9 35.1 34.9 34.4 33.7 32.7 31.8
Btu/h 5950 5700 5400 5060 4700 4320 3940
45
50
55
60
COEFFICIENTS CAPACITY POWER CURRENT MASS FLOW
C1 9.676530E+02 2.247924E+02 7.968064E+00 -2.312381E+00
C2 4.814793E+01 -4.929341E-02 3.683430E-02 6.996986E-02
C3 5.491935E+01 7.610499E-02 -1.144258E-01 5.195166E-01
C4 7.768064E-01 -7.464387E-02 -6.905995E-04 3.430915E-03
C5 3.290922E-01 3.807037E-02 -3.757422E-04 5.783008E-03
C6 -6.330398E-01 1.076778E-02 1.073217E-03 -5.056860E-03
C7 1.926119E-03 -9.785623E-05 -1.145368E-06 2.387774E-05
C8 -4.259595E-03 4.262847E-04 5.370039E-06 -1.055941E-05
C9 -2.510310E-03 -2.035584E-05 2.279308E-06 -2.537188E-05
C10 1.867943E-03 -3.455064E-05 -3.137335E-06 1.476199E-05
Watts 320 356 392 427 463 498 532
Amps 4.40 4.52 4.70 4.92 5.18 5.44 5.69
Lb/h 38.5 38.8 38.6 38.0 37.2 36.2 35.1
Btu/h 6520 6240 5910 5550 5150 4740 4320
Watts 312 351 391 430 470 508 546
Amps 4.35 4.49 4.70 4.95 5.24 5.54 5.83
Lb/h 42.4 42.7 42.5 41.9 41.0 40.0 38.8
Btu/h 7120 6810 6460 6060 5630 5180 4720
Watts 301 344 388 431 474 517 559
Amps 4.27 4.44 4.68 4.97 5.29 5.63 5.96
Lb/h 46.6 46.9 46.7 46.1 45.2 44.0 42.7
Btu/h 7760 7420 7030 6600 6130 5640 5140
Watts 287 335 382 430 477 524 570
Amps 4.17 4.37 4.64 4.97 5.33 5.71 6.08
Lb/h 51.1 51.4 51.2 50.6 49.6 48.3 46.9
Value = C1 + C2 * Te + C4 * Te^2 + C7 * Te^3 + (C3 + C5 * Te + C8 * Te^2) * Tc + (C6 + C9 * Te) * Tc^2 + C10 * Tc^3
Te = Evaporator Temperature
Tc = Condensing Temperature
Performance Data Sheet
AE4440U-AA1A
General Information
Model AE4440U-AA1A Refrigerant R-290
Test Condition ASHRAE Performance Test Voltage 115V ~ 60HZ
Return Gas 35°C (95°F) RETURN GAS Motor Type CSIR
Performance Information
Evap Temp (°F)
5
10
15
20
25
30
35
40
Condensing Temperature (°F)
80 90 100 110 120 130 140
Btu/h 2850 2570 2370 2220 2080 1910 1690
Watts 281 298 314 331 346 359 371
Amps 4.12 4.13 4.19 4.28 4.39 4.48 4.54
Lb/h 17.4 15.9 15.1 14.8 14.5 14.1 13.1
Btu/h 3160 2850 2630 2460 2310 2140 1910
Watts 292 309 327 345 362 377 391
Amps 4.17 4.19 4.26 4.37 4.49 4.60 4.67
Lb/h 19.2 17.6 16.8 16.4 16.2 15.8 14.8
Btu/h 3540 3200 2950 2760 2590 2400 2160
Watts 301 320 340 359 378 396 412
Amps 4.23 4.25 4.34 4.46 4.59 4.72 4.82
Lb/h 21.5 19.8 18.9 18.4 18.2 17.8 16.9
Btu/h 3970 3590 3320 3100 2910 2700 2450
Watts 310 330 351 373 394 414 433
Amps 4.27 4.31 4.41 4.55 4.70 4.85 4.97
Lb/h 24.1 22.3 21.3 20.8 20.5 20.0 19.1
Btu/h 4460 4040 3720 3480 3260 3030 2760
Watts 317 339 362 385 409 432 454
Amps 4.31 4.36 4.48 4.63 4.81 4.98 5.12
Lb/h 27.1 25.1 24.0 23.4 23.0 22.5 21.6
Btu/h 4990 4530 4170 3890 3640 3380 3090
Watts 322 346 371 397 423 449 475
Amps 4.34 4.41 4.54 4.72 4.91 5.10 5.27
Lb/h 30.4 28.2 26.9 26.2 25.8 25.2 24.3
Btu/h 5560 5050 4650 4330 4040 3760 3440
Watts 324 350 378 407 436 465 494
Amps 4.35 4.44 4.59 4.79 5.01 5.23 5.42
Lb/h 34.0 31.6 30.2 29.3 28.7 28.1 27.1
Btu/h 6170 5610 5160 4790 4460 4140 3790
Watts 324 353 383 415 447 480 513
Amps 4.35 4.46 4.63 4.85 5.10 5.34 5.56
Lb/h 37.8 35.2 33.6 32.5 31.8 31.1 30.0
Btu/h 6810 6190 5680 5260 4890 4530 4150
45
50
55
60
COEFFICIENTS CAPACITY POWER CURRENT MASS FLOW
C1 1.193892E+04 1.869937E+02 8.665839E+00 9.206655E+01
C2 1.066623E+02 3.419579E+00 1.126774E-02 5.321694E-01
C3 -2.410925E+02 -7.516161E-02 -1.348432E-01 -2.055416E+00
C4 2.213002E+00 -4.476966E-02 -1.794100E-04 1.310543E-02
C5 -1.184432E+00 -3.624682E-02 -1.584297E-04 -6.022077E-03
C6 2.043071E+00 2.043983E-02 1.262894E-03 1.809691E-02
C7 -7.172310E-03 -4.689661E-04 -4.091966E-06 -4.498189E-05
C8 -9.184870E-03 5.061915E-04 3.435406E-06 -4.375337E-05
C9 4.622168E-03 2.755815E-04 1.736431E-06 2.868699E-05
C10 -6.093996E-03 -8.222349E-05 -3.689493E-06 -5.369703E-05
Watts 321 352 386 420 457 493 530
Amps 4.33 4.46 4.66 4.90 5.17 5.44 5.69
Lb/h 41.8 39.0 37.1 35.9 35.0 34.2 33.0
Btu/h 7480 6790 6230 5750 5330 4930 4500
Watts 315 349 385 424 463 504 545
Amps 4.28 4.44 4.66 4.93 5.23 5.53 5.81
Lb/h 46.1 42.9 40.8 39.4 38.4 37.4 36.1
Btu/h 8170 7410 6780 6250 5770 5320 4850
Watts 304 342 382 424 468 513 558
Amps 4.21 4.39 4.64 4.94 5.27 5.60 5.92
Lb/h 50.4 47.0 44.6 43.0 41.7 40.6 39.1
Btu/h 8870 8040 7340 6750 6210 5700 5180
Watts 290 331 374 421 469 518 569
Amps 4.11 4.32 4.60 4.93 5.28 5.65 6.01
Lb/h 54.9 51.2 48.5 46.6 45.1 43.8 42.2
Value = C1 + C2 * Te + C4 * Te^2 + C7 * Te^3 + (C3 + C5 * Te + C8 * Te^2) * Tc + (C6 + C9 * Te) * Tc^2 + C10 * Tc^3
Te = Evaporator Temperature
Tc = Condensing Temperature
