Tecumseh AE4430E-DS1A Performance Data Sheet

Performance Data Sheet

AE4430E-DS1A

General Information

Model AE4430E-DS1A Refrigerant R-22
Test Condition EN12900 ASERCOM Performance Test Voltage 127V ~ 60HZ
Return Gas 20°C (68°F) RETURN GAS Motor Type CSIR

Performance Information

Evap Temp (°F)

5

10

15

20

25

30

35

40

Condensing Temperature (°F)

80 90 100 110 120 130 140

Btu/h 1480 1390 1300 1200 1100 998 900
Watts 284 285 288 291 293 293 291
Amps 4.73 4.76 4.79 4.80 4.80 4.79 4.78

Lb/h 18.1 17.7 17.2 16.6 15.9 15.1 14.4

Btu/h 1700 1610 1500 1390 1270 1160 1040
Watts 289 293 298 304 309 313 315
Amps 4.75 4.79 4.81 4.83 4.84 4.84 4.84

Lb/h 20.8 20.5 19.9 19.2 18.4 17.5 16.7

Btu/h 1950 1840 1730 1600 1470 1330 1200
Watts 294 299 307 315 324 331 337
Amps 4.77 4.81 4.84 4.86 4.88 4.89 4.89

Lb/h 23.9 23.5 22.9 22.1 21.2 20.3 19.3

Btu/h 2230 2110 1970 1830 1680 1530 1380
Watts 298 305 314 325 336 347 356
Amps 4.78 4.82 4.86 4.89 4.92 4.94 4.95

Lb/h 27.3 26.9 26.3 25.4 24.5 23.4 22.2

Btu/h 2540 2400 2250 2090 1920 1750 1580
Watts 301 309 320 333 347 361 374
Amps 4.79 4.84 4.88 4.92 4.96 4.99 5.02

Lb/h 31.1 30.7 30.0 29.1 28.0 26.9 25.6

Btu/h 2870 2710 2550 2370 2180 1990 1800
Watts 303 313 326 341 357 373 389
Amps 4.80 4.85 4.90 4.95 4.99 5.04 5.08

Lb/h 35.3 34.9 34.1 33.2 32.0 30.7 29.3

Btu/h 3230 3060 2870 2670 2470 2260 2040
Watts 306 316 330 347 365 384 403
Amps 4.80 4.86 4.92 4.98 5.03 5.09 5.14

Lb/h 39.9 39.4 38.6 37.6 36.4 35.0 33.5

Btu/h 3620 3430 3220 3000 2780 2540 2300
Watts 308 320 335 353 373 394 415
Amps 4.79 4.86 4.93 5.00 5.07 5.14 5.21

Lb/h 44.9 44.4 43.6 42.5 41.2 39.7 38.1

Btu/h 4040 3830 3600 3360 3110 2850 2590

45

50

55

60

COEFFICIENTS CAPACITY POWER CURRENT MASS FLOW

C1 1.234293E+03 4.121444E+02 3.983702E+00 7.550783E+00
C2 4.662722E+01 2.534386E-01 1.035941E-02 3.442441E-01
C3 1.105708E+01 -4.148641E+00 1.556725E-02 2.736936E-01
C4 6.895558E-01 8.444697E-03 -1.529520E-04 5.452691E-03
C5 -4.254583E-02 -1.517992E-02 -1.784625E-04 3.227940E-03
C6 -1.702811E-01 4.235164E-02 -9.036947E-05 -2.765278E-03
C7 6.918762E-04 3.205419E-04 -1.071392E-06 2.588500E-05
C8 -2.344901E-03 -4.970973E-04 1.822699E-06 3.663842E-06
C9 -9.217796E-04 3.872605E-04 1.228964E-06 -2.220198E-05

C10 4.857642E-04 -1.448660E-04 1.240381E-07 7.567789E-06

Watts 311 323 339 358 380 403 427
Amps 4.78 4.86 4.94 5.02 5.10 5.18 5.27

Lb/h 50.3 49.8 49.0 47.9 46.5 44.9 43.1

Btu/h 4490 4250 4000 3740 3470 3190 2900
Watts 315 327 343 363 386 411 437
Amps 4.76 4.85 4.94 5.03 5.13 5.23 5.33

Lb/h 56.2 55.7 54.9 53.7 52.2 50.5 48.6

Btu/h 4960 4710 4440 4150 3850 3540 3230
Watts 319 331 348 369 393 419 447
Amps 4.73 4.83 4.94 5.04 5.15 5.26 5.38

Lb/h 62.6 62.1 61.2 60.0 58.4 56.6 54.6

Btu/h 5470 5200 4900 4590 4260 3930 3580
Watts 325 336 353 374 399 427 456
Amps 4.69 4.81 4.92 5.04 5.17 5.30 5.44

Lb/h 69.5 69.0 68.1 66.8 65.2 63.3 61.2

Value = C1 + C2 * Te + C4 * Te^2 + C7 * Te^3 + (C3 + C5 * Te + C8 * Te^2) * Tc + (C6 + C9 * Te) * Tc^2 + C10 * Tc^3

Te = Evaporator Temperature

Tc = Condensing Temperature
