DIGITAL ENSEMBLE
SX-PR54/M
Operating Instructions
Before connecting, operating or adjusting this product, please read these
instructions completely. Please keep this manual for future reference.
This manual was printed
with soy based ink.
QQTG0701 ENGLISH
Caution for AC Mains Lead
(For United Kingdom)
(For the type as shown in figures A
and B)
For your safety, please read the following text
carefully.
This appliance is supplied with a moulded three
pin mains plug for your safety and convenience.
A 5-ampere fuse is fitted in this plug. Should the
fuse need to be replaced please ensure that the
replacement fuse has a rating of 5-ampere and
that it is approved by ASTA or BSI to BS1362.
Check for the ASTA mark or the BSI mark
on the body of the fuse.
If the plug contains a removable fuse cover you
must ensure that it is refitted when the fuse is
replaced. If you lose the fuse cover the plug must
not be used until a replacement cover is obtained.
A replacement fuse cover can be purchased from
your local dealer.
WARNING: DO NOT CONNECT EITHER WIRE
TO THE EARTH TERMINAL WHICH IS MARKED
WITH THE LETTER E, BY THE EARTH
SYMBOL OR COLOURED GREEN OR
GREEN/ YELLOW.
THIS PLUG IS NOT WATERPROOF
—KEEP DRY.
Before use
Remove the connector cover.
How to replace the fuse
The location of the fuse differ according to the type
of AC mains plug (figures A and B). Confirm the
AC mains plug fitted and follow the instructions
below. Illustrations may differ from actual AC
mains plug.
Open the fuse cover with a screwdriver.
1.
Figure A Figure B
Fuse cover
CAUTION!
IF THE FITTED MOULDED PLUG IS
UNSUITABLE FOR THE SOCKET OUTLET IN
YOUR HOME THEN THE FUSE SHOULD BE
REMOVED AND THE PLUG CUT OFF AND
DISPOSED OF SAFELY. THERE IS A
DANGER OF SEVERE ELECTRICAL SHOCK
IF THE CUT OFF PLUG IS INSERTED INTO
ANY 13-AMPERE SOCKET.
If a new plug is to be fitted please observe the
wiring code as stated below. If in any doubt please
consult a qualified electrician.
IMPORTANT
The wires in this mains lead are coloured in accordance with the following code:
Blue: Neutral, Brown: Live.
As these colours may not correspond with the coloured markings identifying the terminals in your
plug, proceed as follows:
The wire which is coloured Blue must be connected to the terminal which is marked with the
letter N or coloured Black or Blue.
The wire which is coloured Brown must be connected to the terminal which is marked with the
letter L or coloured Brown or Red.
Replace the fuse and close or attach the fuse
2.
cover.
Figure A Figure B
Fuse
(5 ampere)
Fuse
(5 ampere)
For United Kingdom and Republic of Ireland
www.panasonic.co.uk (for UK customers only)
•
Order accessory and consumable items for your
product with ease and confidence by telephoning
our Customer Care Centre Mon–Friday
9:00am–5:30pm. (Excluding public holidays.)
• Or go on line through our Internet Accessory
ordering application.
• Most major credit and debit cards accepted.
• All enquiries transactions and distribution facilities
are provided directly by Panasonic UK Ltd.
• It couldn’t be simpler!
Customer Care Centre
For UK customers: 08705 357357 For Republic of
Ireland customers: 01 289 8333
Technical Support
For UK customers: 0870 1 505610
This Technical Support Hot Line number is for
Panasonic PC software related products only.
For Republic of Ireland, please use the Customer
Care Centre number listed above for all enquiries.
For all other product related enquiries, please
use the Customer Care Centre numbers listed
above.
2
QQTG0701
THE FOLLOWING APPLIES ONLY
IN THE U.S.A. AND CANADA
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT
REMOVE SCREWS.
NO USER-SERVICEABLE PARTS
INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
The lightning flash with arrowhead
symbol, within an equilateral triangle, is intended to alert the user
to the presence of uninsulated
“dangerous voltage” within the product’s enclosure that may be of
sufficient magnitude to constitute a
risk of electric shock to persons.
The exclamation point within an
equilateral triangle is intended to
alert the user to the presence of
important operating and maintenance (servicing) instructions in
the literature accompanying the
appliance.
(for U.S.A. and Canada)
CAUTION:
TO PREVENT ELECTRIC SHOCK MATCH WIDE
BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
WARNING:
TO REDUCE THE RISK OF FIRE, ELECTRIC
SHOCK OR PRODUCT DAMAGE, DO NOT EXPOSE
THIS APPARATUS TO RAIN, MOISTURE, DRIPPING OR SPLASHING AND THAT NO OBJECTS
FILLED WITH LIQUIDS, SUCH AS VASES, SHALL
BE PLACED ON THE APPARATUS.
THE FOLLOWING APPLIES
ONLY IN THE U.S.A.
CAUTION:
This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio
or television reception, which can be determined by
turning the equipment off and on, the user is
encouraged to try to correct the interference by one
or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment
and receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV
technician for help.
FCC Warning:
To assure continued FCC emission limit compliance, use only the provided power supply cord and
the shielded interface cable when connecting this
device to the computer.
Also, any unauthorized changes or modifications to
this equipment would void the user’s authority to
operate this device.
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that
may cause undesired operation.
Responsible Party:
Matshshita Electric Corporation of America
One Panasonic Way
Secaucus, NJ, 07094 USA
Telephone No.: 1-800-211-7262
THE FOLLOWING APPLIES ONLY IN THE U.S.A.
Notice:
This product has a fluorescent lamp that contains a
small amount of mercury.
It also contains lead in some components. Disposal of
these materials may be regulated in your community
due to environmental considerations.
For disposal or recycling information please contact
your local authorities, or the Electronics Industries
Alliance: <http://www.eiae.org>
The model number and serial number are found
underneath the keyboard.
Please note the model and serial numbers in the
space provided below and retain this sheet as a
permanent record of your purchase to aid identification
in the event of theft.
MODEL NUMBER
SERIAL NUMBER
THIS UNIT IS INTENDED FOR USE IN TROPICAL CLIMATES.
DENNA ENHET ÄR AVSEDD FÖR ANVÄNDNING PÅ PLATSER MED TROPISKT KLIMAT.
TÄMÄ LAITE ON TARKOITETTU KÄYTETTÄVÄKSI TROOPPISESSA ILMASTOSSA.
DETTE APPARATET ER BEREGNET TIL BRUK UNDER TROPISKE KLIMAFORHOLD.
3
QQTG0701
4
QQTG0701
QQTG0701
5
THE FOLLOWING APPLIES ONLY IN THE U.S.A.
Safety
Installation
Placement
Environment
Maintenance
Service
IMPORTANT SAFETY INSTRUCTIONS
Read these operating instructions carefully before using the unit. Follow the safety instructions on the unit and the
safety precautions listed below. Keep these operating instructions handy for future reference.
6.
Carts and stands—Use the unit only
1.
Power Source—Connect the unit to a power
source of the type described in these instructions or
as marked on the unit.
2.
Polarization—The unit is equipped with a polarized
power plug where one blade is wider than the other.
This safety feature ensures that the plug fits into
your household AC outlet only one way. If the plug
doesn’t fit one way, try reversing it. If the plug still
doesn’t fit, contact an electrician to replace the
obsolete outlet. Do not attempt to defeat the safety
purpose of the plug.
3.
Power Cord protection—Route the AC power sup-
ply cord so that it will not be walked on or pinched
by items placed on or against it. Never take hold of
the plug or cord with wet hands. Always grasp the
plug body firmly when connecting and disconnecting it.
4.
Overloading—When connecting the AC power
supply cord, be careful not to overload the household AC outlet, extension cord, or outlet from any
other device as this can result in fire or electric
shock.
5.
Nonuse periods—Turn the unit off when it is not in
use. Unplug the unit from the household AC outlet if
it is not to be used for a long time. Unplug the unit
during lightning storms.
6.
Attachments and accessories—Use only the
attachments and accessories recommended in
these operating instructions.
1.
Ventilation—Situate the unit so that it receives
proper ventilation. Do not install in a confined space
such as a bookcase or cabinet. Allow at least 10 cm
(4 inches) clearance from the rear of the unit. To
prevent the risk of electric shock or fire due to overheating ensure curtains and other materials do not
obstruct the unit’s ventilation.
2.
Foreign material—Ensure objects and liquids do
not get into the unit. Avoid exposing the unit to
excessive smoke, dust, mechanical vibration, and
shock.
3.
Magnetism—Situate the unit away from equipment
and devices that generate strong magnetic fields.
4.
Stacking—Do not place heavy objects on top of
this unit.
5.
Surface—Place the unit on a flat, level surface.
with carts and stands recommended by
the manufacturer. Move carts with care.
Sudden stops, excessive force, and
uneven surfaces can cause carts to
overturn.
7.
Wall and ceiling mounting—Do not mount the unit
on walls or ceilings unless specified in the instructions.
1.
Water and moisture—Do not use the unit near
water, such as near a bathtub or swimming pool.
Avoid damp basements.
2.
Heat—Situate the unit away from heat sources,
such as radiators.
Do not situate where temperatures fall below 5°C
(41°F) or rise above 35°C (95°F).
(See page 7 for details.)
Unplug the unit from the household AC outlet before
cleaning.
Clean with a damp cloth.
Do not use abrasive pads, scouring powders, or solvents.
1.
Damage Requiring Service—The unit should be
serviced by qualified service personnel if:
(a) The AC power supply cord or the plug has been
damaged; or
(b) Objects or liquids have gotten into the unit; or
(c) The unit has been exposed to rain; or
(d) The unit does not operate normally or exhibits a
marked change in performance; or
(e) The unit has been dropped or the cabinet dam-
aged.
2.
Servicing—Do not attempt to service the unit
beyond that described in these operating instructions. Refer all other servicing to authorized servicing personnel.
3.
Replacement parts—When parts need replacing
ensure the servicer uses parts specified by the
manufacturer or parts that have the same characteristics as the original parts. Unauthorized substitutes may result in fire, electric shock, or other
hazards.
4.
Safety check—After repairs or service, ask the ser-
vicer to perform safety checks to confirm that the
unit is in proper working condition.
6
QQTG0701
Cautions for safest use of this unit
Installation location
A well-ventilated place.
1.
Take care not to use this unit in a place where it
will not receive sufficient ventilation, and not to
permit the ventilation holes to be covered by curtains, or any similar materials.
Place away from direct sunlight and excessive
2.
heat from heating equipment.
A place where humidity, vibration and dust are
3.
minimized.
Power source
Be sure the line voltage selector is in accordance
1.
with local voltage in your area before connecting
the plug to the socket.
DC power cannot be used.
2.
Handling the power cord
Never touch the power cord, or its plug, with wet
1.
hands.
Don’t pull the power cord.
2.
Metal items inside the unit may
result in electric shock or damage.
Do not permit metal articles to get inside the unit.
If operation seems abnormal
Immediately turn off the power, disconnect the power
cord plug from the electrical outlet, and contact the
store where it was purchased.
Discontinue using the unit at once. Failure to do so
may result in additional damage or some other unexpected damage or accident.
• Because the power source is located inside the
unit, it is normal for the cabinet to become warm.
A word about the power cord
If the power cord is scarred, is partially cut or
bronken, or has a bad contact, it may cause a fire or
serious electrical shock if used. NEVER use a damaged power cord for any appliance. Moreover, the
power cord should never be forcibly bent.
Don’t touch the inside parts of this
unit.
Some places inside this unit have high voltage potential. Never try to remove the top or back panels of this
unit, or to touch inside parts by hand or with tools.
Contact someone who is qualified in order to inspect
the inside, or to replace a fuse, if such becomes necessary. Never attempt to do these things yourself.
Be especially careful with regard to this point if
children are near this unit. They should be warned
never to try to put anything inside.
If, nevertheless, some such article does get inside,
disconnect the power cord plug from the electrical
outlet, and contact the store where the unit was
purchased.
If water gets into the unit
Disconnect the power cord plug from the electrical
outlet, and contact the store where it was purchased.
As a precaution, it is suggested that flower vases and
other containers which hold liquids not be placed on
the top of this unit.
• This product may receive radio interference
caused by mobile telephones during use. If such
interference is apparent, please increase separation between the product and the mobile telephone.
Maintenance
The following suggestions will assist you in keeping
the unit in top condition.
• Be sure to switch the instrument off after use, and
do not switch the unit on and off in quick
succession, as this places an undue load on the
electronic components.
• To keep the luster of the surface and buttons, simply use a clean, damp cloth; polish with a soft, dry
cloth. Polish may be used but do not use thinners
or petro-chemical-based polishes.
• A wax-based polish may be used on the cabinet,
although you will find that rubbing with a soft cloth
will suffice.
SVENSK: Det kan inträffa att den här produkten
under användningen tar emot radiostörningar,
orsakade av mobiltelefoner. Öka avståndet mellan
produkten och mobiltelefonen om störningarna är
uppenbara.
SERVICE MUST BE CARRIED OUT BY DEALER
OR OTHER QUALIFIED PERSON
7
QQTG0701
Contents
Cautions for safest use of this unit ............................................................................................................. 7
Controls and functions ............................................................................................................................... 10
BASIC FUNCTIONS
Getting started ................................................................................................................................ 12
Playing the piano ............................................................................................................................ 13
Progressive Pianist......................................................................................................................... 14
See and listen to the demonstration ............................................................................................... 15
Select a sound ................................................................................................................................ 16
Select the registration for a music style (PIANO STYLIST)............................................................ 17
Automatic panel settings (ONE TOUCH PLAY) .............................................................................. 18
Record your performance (SEQUENCER)..................................................................................... 20
Store your panel settings (PANEL MEMORY) ................................................................................ 22
Save data on a floppy disk.............................................................................................................. 23
Load rhythm data from a Technics pattern disk (COMPOSER LOAD)........................................... 25
Play back commercial song disks (DIRECT PLAY) ........................................................................ 26
PRACTICAL APPLICATIONS
About the display ............................................................................................................................ 27
Favorites ......................................................................................................................................... 30
Part I Sounds and effects ......................................................................................................................... 31
Overview of sounds ........................................................................................................................ 31
Selecting sounds ............................................................................................................................ 31
Assigning parts to the keyboard ..................................................................................................... 34
Pedals............................................................................................................................................. 35
Touch Sensitivity............................................................................................................................. 36
Effects............................................................................................................................................. 37
Transpose ....................................................................................................................................... 39
Techni-chord ................................................................................................................................... 40
Part II Playing the rhythm......................................................................................................................... 41
Overview of rhythm performance.................................................................................................... 41
Selecting rhythms ........................................................................................................................... 41
Playing the rhythm.......................................................................................................................... 43
Auto Play Chord.............................................................................................................................. 44
Fade In/Fade Out............................................................................................................................ 48
Sound Arranger .............................................................................................................................. 49
One Touch Play .............................................................................................................................. 49
Piano Stylist.................................................................................................................................... 50
Music Style Arranger ...................................................................................................................... 51
Panel Memory................................................................................................................................. 52
Part III Sequencer ...................................................................................................................................... 54
Outline of the Sequencer................................................................................................................ 54
Sequencer parts ............................................................................................................................. 57
Easy Record ................................................................................................................................... 58
Realtime Record............................................................................................................................. 59
Sequencer Play .............................................................................................................................. 61
Naming ........................................................................................................................................... 63
Panel Write ..................................................................................................................................... 63
Song Select .................................................................................................................................... 64
Punch Record................................................................................................................................. 64
Step Record.................................................................................................................................... 65
Track Assign ................................................................................................................................... 70
Quantize ......................................................................................................................................... 71
Song Clear...................................................................................................................................... 72
Track Clear...................................................................................................................................... 72
Note Edit......................................................................................................................................... 73
Drum Edit........................................................................................................................................ 74
Copy and paste the recorded data ................................................................................................. 75
Changing the note position etc. of the recorded data ..................................................................... 78
Part IV Composer...................................................................................................................................... 80
Outline of the Composer................................................................................................................. 80
Simple recording method................................................................................................................ 81
Create a completely new rhythm .................................................................................................... 82
Chord Modify Change..................................................................................................................... 84
Part Setting..................................................................................................................................... 84
Playback ......................................................................................................................................... 85
Step Record.................................................................................................................................... 86
Measure Edit................................................................................................................................... 87
Pattern Copy................................................................................................................................... 88
8
QQTG0701
Part V Disk Drive ....................................................................................................................................... 90
Outline of the Disk Drive function ................................................................................................... 90
Outline of the procedure................................................................................................................. 92
Loading data................................................................................................................................... 93
Direct Play ...................................................................................................................................... 95
Song Medley................................................................................................................................... 96
Saving data..................................................................................................................................... 97
Disk management........................................................................................................................... 99
Set the automatic display when a disk is inserted ........................................................................ 100
Part VI Sound........................................................................................................................................... 101
Outline of the Sound ..................................................................................................................... 101
Part Setting................................................................................................................................... 102
Mixer............................................................................................................................................. 104
Master Tuning ............................................................................................................................... 106
Key Scaling................................................................................................................................... 106
Sound Load Option....................................................................................................................... 107
APC Reverb Setting...................................................................................................................... 107
Part VII Reverb & Effect .......................................................................................................................... 108
Outline of the Reverb & Effect ...................................................................................................... 108
Tone Control ................................................................................................................................. 108
Part VIII Sound Edit ................................................................................................................................. 109
Outline of the Sound Edit.............................................................................................................. 109
Easy Edit....................................................................................................................................... 110
Tone Edit....................................................................................................................................... 110
Pitch Edit....................................................................................................................................... 113
Filter Edit....................................................................................................................................... 114
Amplitude Edit............................................................................................................................... 116
LFO Edit........................................................................................................................................ 117
Effect Edit ..................................................................................................................................... 118
Controller Edit............................................................................................................................... 118
Store the new sound..................................................................................................................... 119
Part IX Control ......................................................................................................................................... 120
Outline of Control functions .......................................................................................................... 120
Pedal Setting ................................................................................................................................ 120
Part X Customize..................................................................................................................................... 122
Outline of Customize functions..................................................................................................... 122
Display Time Out .......................................................................................................................... 123
Data Protection............................................................................................................................. 124
MIDI Setting Load Option ............................................................................................................. 124
Part XI MIDI .............................................................................................................................................. 125
What is MIDI? ............................................................................................................................... 125
Outline of MIDI functions .............................................................................................................. 126
Part Setting................................................................................................................................... 127
Control Messages......................................................................................................................... 128
Realtime Messages ...................................................................................................................... 128
Common Setting........................................................................................................................... 129
Mode Setting................................................................................................................................. 130
Input/output Setting....................................................................................................................... 130
MIDI Presets................................................................................................................................. 131
Computer Connection................................................................................................................... 132
Initialize...................................................................................................................................................... 133
Connections .............................................................................................................................................. 134
Assembly ................................................................................................................................................... 135
Symptoms which appear to be signs of trouble .................................................................................... 136
Error messages ......................................................................................................................................... 138
Index........................................................................................................................................................... 140
Specifications............................................................................................................................................ 141
Supplied accessories
䡲
Please check the supplied accessories.
Music stand □ CD-ROM
□
AC cord
□
QQTG0701
9
Controls and functions
MAIN
VOLUME
MAX
MIN
MAX
OFF
AUTO PLAY CHORD
RHYTHM GROUP
TEMPO / PROGRAM
PROGRESSIVE
PIANIST PIANO STYLIST
SPLIT
POINT
METRONOME
POP ROCK
FUNK &
SOUL DISCO
POP BALLAD
BALLAD
BALLROOM
& SHOW
MEMORY
CONTRAST
LATIN &
WORLD
JAZZ &
SWING
WALTZ
& TRADUSA16 BEAT8 BEAT
IN OUT
SOUND
ARRANGER
SET
MODE
CHORD FINDER
OFF/ON
ONE TOUCH
PLAY
APC/SEQUENCER
VOLUME
DEMO
MUSIC STYLE ARRANGER
VARIATION
1 2 1 2 1 1 2 3 4 BEAT
LOAD
SEQUENCER
RESET
COUNT
INTRO
234
FADE
FILL IN INTRO & ENDING
SYNCHRO & BREAK
START / STOP TAP TEMPO
HELP
OTHER PARTS/TR
-
TRANSPOSE
+
M
AUTO PLAY CHORD
Add an automatic
accompaniment to your
selected rhythm.
(Refer to page 44.)
PIANO STYLIST
You can choose to have
all the settings of this
instrument automatically
set. (Refer to page 50.)
RHYTHM GROUP
Various rhythm patterns are
available for each rhythm
group.
(Refer to page 41.)
PROGRESSIVE PIANIST
Your piano offers a fun method
of learning to play piano.
(Refer to page 14.)
FADE IN/OUT
Begin your song with a slowly
increasing volume, or end it by
having the sound slowly fade away.
(Refer to page 48.)
Tuning
Unlike an acoustic piano, your PR Series Digital Ensemble never needs tuning.
The pitch of this instrument can be adjusted for when playing along with other instruments.
(Refer to page 106.)
TRANSPOSE
Raise or lower the key
of the entire keyboard.
(Refer to page 39.)
10
QQTG0701
PAG E
DISPLAY HOLD
EXIT GRAND
UPRIGHT ELECTRIC
MODERN SIMPLE PIANO TECHNI-CHORD BANK
AB
C
P.MEM 5-8
SET 1 / 5 2 / 6 3 / 7 4 / 8
SOUND GROUP
SEQUENCER
PIANO
STRINGS
BASS
MALLET &
ORCH PERC
WORLD
PIANO
MIXTURES
ORCH
MIXTURES
DIGITAL
DRAWBARS
DRUM KITS
MEMORY
LEFT RIGHT 2 RIGHT 1
DIGITAL
EFFECT
MULTI
EFFECT
CHORUS REVERB
CHORD STEP REC
VOCAL
GUITAR &
HARPSI BRASS PLAY
EASY
REC
FAVORITES
PROGRAM
MENUS
DISK
IN USE
DISK
LOAD
SAX &
WOODWIND
ORGAN &
ACCORDION
SYNTH
SOUND
EXPLORER
CONDUCTOR
PANEL MEMORY
EFFECT
Add various effects
to the sounds.
(Refer to page 37.)
SOUND GROUP
Various sounds are
available for each
sound group.
(Refer to page 31.)
SEQUENCER
Record and play
back your
performance.
(Refer to page 54.)
CONDUCTOR
Assign a different sound to
each part, then assign the
desired parts to sections of
the keyboard.
(Refer to page 34.)
TECHNI-CHORD
Block chords are
automatically added to the
melody.
(Refer to page 40.)
PANEL MEMORY
Store the panel settings,
then recall them
instantaneously just by
pressing a button or two.
(Refer to page 52.)
FAVORITES
Fashion a customized display
in which all your favorite
sounds, rhythms and styles etc. are
assembled. (Refer to page 30.)
DISPLAY
Displays performance information,
function settings and other messages.
(Refer to page 27.)
Use the CONTRAST buttons to
adjust the display so that it is easy to
read.
QQTG0701
11
Getting started
Basic functions
MAIN
VOLUME
DEMO
MAX
MIN
AUTO PLAY CHORD
SPLIT
POINT
PROGRESSIVE
PIANIST PIANO STYLIST
MUSIC STYLE ARRANGER
VOLUME
ONE TOUCH
MODE
OFF/ON
PLAY
CHORD FINDER
1 2 1 2 1 1 2 3 4 BEAT
VARIATION
MAX
OFF
IN OUT
ARRANGER
FILL IN INTRO & ENDING
SEQUENCER
COUNT
RESET
INTRO
RHYTHM GROUP
SOUND
SET
METRONOME
234
POP ROCK
SYNCHRO & BREAK
FUNK &
SOUL DISCO
POP BALLAD
WALTZ
& TRADUSA16 BEAT8 BEAT
START / STOP TAP TEMPO
JAZZ &
SWING
TEMPO / PROGRAM
BALLROOM
BALLAD
& SHOW
LATIN &
MEMORY
WORLD
CONTRAST
LOAD
-
TRANSPOSE
HELP
OTHER PARTS/TR
+
MUTE
PAGE
DISPLAY HOLD
EXIT GRAND
FADE
APC/SEQUENCER
SOUND GROUP
GUITAR &
SAX &
ORGAN &
STRINGS
VOCAL
HARPSI BRASS PLAY
MALLET &
ORCH PERC
WORLD
BASS
UPRIGHT ELECTRIC
SOUND
WOODWIND
ACCORDION
SYNTH
EXPLORER
PIANO
ORCH
DIGITAL
MIXTURES
MIXTURES
DRAWBARS
DRUM KITS
MEMORY
MODERN SIMPLE PIANO TECHNI-CHORD BANK
PIANO
SEQUENCER
CHORD STEP REC
CONDUCTOR
LEFT RIGHT 2 RIGHT 1
C
AB
SET 1 / 5 2 / 6 3 / 7 4 / 8
EASY
REC
FAVORITES
PANEL MEMORY
PROGRAM
DISK
MENUS
IN USE
DISK
LOAD
DIGITAL
MULTI
EFFECT
EFFECT
CHORUS REVERB
P.MEM 5-8
4
1
Plug the power cord into an outlet.
4
Press the POWER button to turn it on.
Set the MAIN VOLUME to an
appropriate level with the sliding control.
MAIN
VOLUME
MAX
2
POWER
OFF ON
MIN
(Right end of the keyboard)
• The power indicator in the left front of the body is
lit.
Touch any note on the keyboard.
3
• Your piano features Touch Response. You
control the volume by playing the keys harder or
softer.
Keyboard cover
Open and close the cover slowly.
Music Stand
Insert the music stand in the two holes as
shown in the diagram.
12
QQTG0701
Playing the piano
Your piano is equipped with various fine functions which make it an extremely versatile instrument. But it
should be remembered that it is first of all a fine piano. Select one of the piano sounds and enjoy its
excellent quality.
When you activate the SIMPLE PIANO feature, the entire keyboard is instantly transformed into a piano,
regardless of the current instrument settings.
Basic functions
1
2
AUTO PLAY CHORD
SPLIT
MAIN
POINT
VOLUME
MAX
PROGRESSIVE
PIANIST PIANO STYLIST
MIN
MUSIC STYLE ARRANGER
DEMO
VOLUME
ONE TOUCH
MODE
OFF/ON
PLAY
CHORD FINDER
1 2 1 2 1 1 2 3 4 BEAT
VARIATION
MAX
OFF
IN OUT
ARRANGER
FILL IN INTRO & ENDING
SEQUENCER
COUNT
RESET
INTRO
RHYTHM GROUP
SOUND
SET
METRONOME
234
POP ROCK
SYNCHRO & BREAK
FUNK &
SOUL DISCO
POP BALLAD
WALTZ
& TRADUSA16 BEAT8 BEAT
START / STOP TAP TEMPO
BALLROOM
BALLAD
& SHOW
LATIN &
JAZZ &
MEMORY
WORLD
SWING
CONTRAST
LOAD
-
TRANSPOSE
FADE
APC/SEQUENCER
Press the SIMPLE PIANO button to turn
it on.
SIMPLE PIANO
• The indicator lights.
• The display changes to the SIMPLE PIANO
display.
Select the desired type of piano sound.
TEMPO / PROGRAM
+
SOUND GROUP
GUITAR &
SAX &
ORGAN &
STRINGS
VOCAL
HARPSI BRASS PLAY
MALLET &
WORLD
ORCH PERC
BASS
HELP
OTHER PARTS/TR
MUTE
PAGE
DISPLAY HOLD
EXIT GRAND
UPRIGHT ELECTRIC
SOUND
WOODWIND
ACCORDION
SYNTH
EXPLORER
PIANO
ORCH
DIGITAL
DRUM KITS
MEMORY
MIXTURES
MIXTURES
DRAWBARS
MODERN SIMPLE PIANO TECHNI-CHORD BANK
PIANO
SEQUENCER
CHORD STEP REC
CONDUCTOR
LEFT RIGHT 2 RIGHT 1
C
AB
SET 1 / 5 2 / 6 3 / 7 4 / 8
EASY
REC
FAVORITES
PANEL MEMORY
PROGRAM
DISK
MENUS
IN USE
DISK
LOAD
DIGITAL
MULTI
CHORUS REVERB
EFFECT
EFFECT
P.MEM 5-8
21
• The sounds and effects are automatically set.
•“COMPLETED!” is shown on the display, and
then the normal display reappears.
Play anywhere on the keyboard.
3
• This procedure will cancel the current settings for sounds
and effects, etc. Therefore, if you wish to later recall the
current settings, be sure to store them in the PANEL
MEMORY (page 52) or save them to a disk (page 97)
before beginning this procedure.
13
QQTG0701
Progressive Pianist
MAIN
VOLUME
MAX
MIN
MAX
OFF
AUTO PLAY CHORD
RHYTHM GROUP
TEMPO / PROGRAM
PROGRESSIVE
PIANIST PIANO STYLIST
SPLIT
POINT
METRONOME
POP ROCK
FUNK &
SOUL DISCO
POP BALLAD
BALLAD
BALLROOM
& SHOW
MEMORY
CONTRAST
LATIN &
WORLD
JAZZ &
SWING
WALTZ
& TRADUSA16 BEAT8 BEAT
IN OUT
SOUND
ARRANGER
SET
MODE
CHORD FINDER
OFF/ON
ONE TOUCH
PLAY
APC/SEQUENCER
VOLUME
DEMO
MUSIC STYLE ARRANGER
VARIATION
1 2 1 2 1 1 2 3 4 BEAT
LOAD
SEQUENCER
RESET
COUNT
INTRO
234
FADE
FILL IN INTRO & ENDING
SYNCHRO & BREAK
START / STOP TAP TEMPO
HELP
OTHER PARTS/TR
-
TRANSPOSE
+
MUTE
PAGE
DISPLAY HOLD
EXIT GRAND
UPRIGHT ELECTRIC
MODERN SIMPLE PIANO TECHNI-CHORD BANK
AB
C
P.MEM 5-8
SET 1 / 5 2 / 6 3 / 7 4 / 8
SOUND GROUP
SEQUENCER
PIANO
STRINGS
BASS
MALLET &
ORCH PERC
WORLD
PIANO
MIXTURES
ORCH
MIXTURES
DIGITAL
DRAWBARS
DRUM KITS
MEMORY
LEFT RIGHT 2 RIGHT 1
DIGITAL
EFFECT
MULTI
EFFECT
CHORUS REVERB
CHORD STEP REC
VOCAL
GUITAR &
HARPSI BRASS PLAY
EASY
REC
FAVORITES
PROGRAM
MENUS
DISK
IN USE
DISK
LOAD
SAX &
WOODWIND
ORGAN &
ACCORDION
SYNTH
SOUND
EXPLORER
CONDUCTOR
PANEL MEMORY
2-81·9
Your piano offers a fun method of learning to play piano. Start one of the 100 etudes incorporated in this
piano, read the music in the display, listen to the gentle accompaniment for your own and, have a good
Basic functions
practice!
1
2
3
4
Press the PROGRESSIVE PIANIST
button.
PROGRESSIVE
PIANIST
Select the goal of the practice.
Use the SONG ∧ and ∨ buttons to select
a preferred song.
Press the LISTEN button.
6
7
8
When you have finished listening, press
the appropriate button to access the next
step.
• In the Practice Makes Perfect/Musical Discovery
mode, press the PLAY (STEP2) button, and for
the Grand Performer/Pianist Mode Session
mode, follow the step number to continue your
practice.
Press the RESET button.
• The MEASURE returns to the beginning of the
song.
Press the START/STOP button to start
the exercise. Play the keyboard and
follow the music exactly.
• To redo your exercise from the beginning, press
the START/STOP button to stop the music and
press the SEQUENCER RESET (FILL IN 1)
button. You can also use the MEAS button to
start from a desired position.
• If the tempo of the accompaniment is too fast,
press the SLOW 1 button in the ONE TOUCH
TEMPO section. If it is still too fast, press the
SLOW 2 button. (You can also use the
TEMPO/PROGRAM dial to adjust the tempo.)
• The music pages shown on the display turn
automatically. If you wish to turn them manually,
set TURN PAGE to MANUAL and you can press
the PAGE button to change the display (upper;
previous page, lower; next page). In this case,
you can also turn the page by depressing the left
pedal.
• To play a different song while the performance is
stopped, press the EXIT button, and then repeat
the above procedure from step 2.
To exit this feature, press the
PROGRESSIVE PIANIST button again.
5
Press the START/STOP button on the
control panel and listen to the model
9
interpretation while watching the music
on the display.
• Press the START/STOP button to stop the
14
model performance. Press it again to continue
the interpretation from the point at which it was
interrupted.
QQTG0701
See and listen to the demonstration
Basic functions
1
2
APC/SEQUENCER
VOLUME
MAX
OFF
FADE
SOUND
IN OUT
ARRANGER
FILL IN INTRO & ENDING
SEQUENCER
COUNT
RESET
INTRO
RHYTHM GROUP
FUNK &
SOUL DISCO
POP BALLAD
JAZZ &
WALTZ
SWING
& TRADUSA16 BEAT8 BEAT
START / STOP TAP TEMPO
BALLROOM
BALLAD
& SHOW
LATIN &
MEMORY
WORLD
CONTRAST
LOAD
-
TRANSPOSE
METRONOME
POP ROCK
SET
234
SYNCHRO & BREAK
AUTO PLAY CHORD
SPLIT
MAIN
VOLUME
MAX
MIN
DEMO
ONE TOUCH
MODE
OFF/ON
PLAY
POINT
CHORD FINDER
PROGRESSIVE
PIANIST PIANO STYLIST
1 2 1 2 1 1 2 3 4 BEAT
MUSIC STYLE ARRANGER
VARIATION
Press the DEMO button.
DEMO
Use the buttons to the left and right the
display to select the demonstration tune
you wish to see and listen to.
TEMPO / PROGRAM
+
SOUND GROUP
GUITAR &
SAX &
ORGAN &
STRINGS
VOCAL
HARPSI BRASS PLAY
MALLET &
WORLD
ORCH PERC
BASS
HELP
OTHER PARTS/TR
MUTE
PAGE
DISPLAY HOLD
EXIT GRAND
UPRIGHT ELECTRIC
SOUND
WOODWIND
ACCORDION
SYNTH
EXPLORER
PIANO
ORCH
DIGITAL
DRUM KITS
MEMORY
MIXTURES
MIXTURES
DRAWBARS
MODERN SIMPLE PIANO TECHNI-CHORD BANK
PIANO
SEQUENCER
CHORD STEP REC
CONDUCTOR
LEFT RIGHT 2 RIGHT 1
C
AB
SET 1 / 5 2 / 6 3 / 7 4 / 8
EASY
REC
FAVORITES
PANEL MEMORY
PROGRAM
DISK
MENUS
IN USE
DISK
LOAD
DIGITAL
MULTI
CHORUS REVERB
EFFECT
EFFECT
P.MEM 5-8
21·3
• The demonstration performance and display
corresponding to your selection will begin.
• To end the demonstration before it has finished,
press the START/STOP button.
When you are finished listening to the
3
demonstration tunes, press the DEMO
button again.
• If you press and hold the DEMO button for a few seconds,
or if you press first the DEMO button and then the
START/STOP button, all the internal demo tunes are
demonstrated in order in a medley performance. The
medley performance continues until the START/STOP
button or the DEMO button is pressed again.
• Some of the buttons do not function during the DEMO
mode.
15
QQTG0701
Select a sound
GRAND
UPRIGHT ELECTRIC
MODERN
PIANO
SOUND GROUP
STRINGS
BASS
MALLET &
ORCH PERC
WORLD
PIANO
MIXTURES
ORCH
MIXTURES
DIGITAL
DRAWBARS
DRUM KITS
MEMORY
VOCAL
GUITAR &
HARPSI BRASS
SAX &
WOODWIND
ORGAN &
ACCORDION
SYNTH
SOUND
EXPLORER
Basic functions
MAIN
VOLUME
DEMO
MAX
MIN
AUTO PLAY CHORD
SPLIT
POINT
PROGRESSIVE
PIANIST PIANO STYLIST
MUSIC STYLE ARRANGER
VOLUME
ONE TOUCH
MODE
OFF/ON
PLAY
CHORD FINDER
1 2 1 2 1 1 2 3 4 BEAT
VARIATION
MAX
OFF
IN OUT
ARRANGER
FILL IN INTRO & ENDING
SEQUENCER
COUNT
RESET
INTRO
RHYTHM GROUP
SOUND
SET
METRONOME
234
POP ROCK
SYNCHRO & BREAK
FUNK &
SOUL DISCO
POP BALLAD
WALTZ
& TRADUSA16 BEAT8 BEAT
START / STOP TAP TEMPO
JAZZ &
SWING
TEMPO / PROGRAM
BALLROOM
BALLAD
& SHOW
LATIN &
MEMORY
WORLD
CONTRAST
LOAD
-
TRANSPOSE
HELP
OTHER PARTS/TR
+
MUTE
PAGE
DISPLAY HOLD
EXIT GRAND
FADE
APC/SEQUENCER
SOUND GROUP
GUITAR &
SAX &
ORGAN &
WOODWIND
ACCORDION
SYNTH
PIANO
ORCH
DIGITAL
MIXTURES
MIXTURES
DRAWBARS
DRUM KITS
MODERN SIMPLE PIANO TECHNI-CHORD BANK
PIANO
SOUND
EXPLORER
MEMORY
STRINGS
VOCAL
HARPSI BRASS PLAY
MALLET &
ORCH PERC
WORLD
BASS
UPRIGHT ELECTRIC
SEQUENCER
CHORD STEP REC
CONDUCTOR
LEFT RIGHT 2 RIGHT 1
C
AB
SET 1 / 5 2 / 6 3 / 7 4 / 8
EASY
REC
FAVORITES
PANEL MEMORY
PROGRAM
DISK
MENUS
IN USE
DISK
LOAD
DIGITAL
MULTI
EFFECT
EFFECT
CHORUS REVERB
P.MEM 5-8
321A
1
2
In the CONDUCTOR section on the
panel, press the RIGHT 1 button to turn
it on.
LEFT RIGHT 2 RIGHT 1
CONDUCTOR
In the SOUND GROUP or PIANO
section, press one of the sound buttons.
Add reverberation.
Press the REVERB button to turn it on.
A
REVERB
3
4
16
QQTG0701
Select a sound from the list of sounds
shown on the display.
• For most of the buttons, the list of sounds is
contained on two or more screen “pages.” To
see a different part of the list, press either PAGE
button.
Play the keyboard.
Select the registration for a
music style
APC/SEQUENCER
VOLUME
MAX
OFF
IN OUT
FILL IN INTRO & ENDING
SEQUENCER
RESET
FADE
SOUND
ARRANGER
METRONOME
POP ROCK
SET
234
SYNCHRO & BREAK
COUNT
INTRO
PIANO STYLIST
RHYTHM GROUP
FUNK &
SOUL DISCO
WALTZ
& TRADUSA16 BEAT8 BEAT
START / STOP TAP TEMPO
POP BALLAD
JAZZ &
SWING
1
AUTO PLAY CHORD
SPLIT
MAIN
VOLUME
MAX
MIN
DEMO
ONE TOUCH
MODE
OFF/ON
PLAY
POINT
CHORD FINDER
PROGRESSIVE
PIANIST PIANO STYLIST
1 2 1 2 1 1 2 3 4 BEAT
MUSIC STYLE ARRANGER
VARIATION
Press the PIANO STYLIST button to
turn it on.
Press the PIANO STYLES button.
2
(PIANO STYLIST)
TEMPO / PROGRAM
BALLROOM
BALLAD
& SHOW
LATIN &
MEMORY
WORLD
CONTRAST
LOAD
-
TRANSPOSE
HELP
OTHER PARTS/TR
+
MUTE
PAGE
2-61·7
Use the GENRE/ERA/ALPHABET
5
button to select a group. Use the STYLE
button to select a style.
• In the above example, GENRE was selected.
• If the list covers more than one screen “page,”
the MORE button is shown on the display. Use
the MORE button to switch between screen
pages.
• The AUTO PLAY CHORD and SYNCHRO &
BREAK turn on, and the sounds, effects,
rhythm, tempo, volume balance, etc. which are
best suited for the selected music style are
automatically selected.
DISPLAY HOLD
EXIT GRAND
SOUND GROUP
GUITAR &
SAX &
STRINGS
BASS
ORGAN &
VOCAL
HARPSI BRASS PLAY
WOODWIND
ACCORDION
MALLET &
PIANO
ORCH
DIGITAL
ORCH PERC
WORLD
MIXTURES
MIXTURES
DRAWBARS
UPRIGHT ELECTRIC
MODERN SIMPLE PIANO TECHNI-CHORD BANK
PIANO
SYNTH
DRUM KITS
SOUND
EXPLORER
MEMORY
SEQUENCER
CHORD STEP REC
CONDUCTOR
LEFT RIGHT 2 RIGHT 1
C
AB
SET 1 / 5 2 / 6 3 / 7 4 / 8
EASY
REC
FAVORITES
PANEL MEMORY
Basic functions
PROGRAM
DISK
MENUS
IN USE
DISK
LOAD
DIGITAL
MULTI
EFFECT
EFFECT
CHORUS REVERB
P.MEM 5-8
3
4
Use the ARRANGE MODE button to
select the desired type of arrangement.
• Select the type you wish to play (PIANO
SOLO/PIANO & COMBO/PIANO &
ENSEMBLE).
Use the SELECT MODE button to
specify how you wish to select a style.
GENRE: Select a style by musical genre.
ERA: Select a style by era.
ALPHABET: Select a style from an alphabetical
list.
6
7
Play the keyboard.
• When you specify a chord on the left area of the
keyboard, the automatic accompaniment
immediately begins to play.
• You can use the TEMPO/PROGRAM dial to
adjust the tempo.
When you are finished selecting the
style, turn the PIANO STYLIST button
off.
17
QQTG0701
Automatic panel settings
INTRO & ENDING
(ONE TOUCH PLAY)
Basic functions
APC/SEQUENCER
VOLUME
MAX
OFF
FADE
IN OUT
ARRANGER
FILL IN INTRO & ENDING
SEQUENCER
COUNT
RESET
INTRO
RHYTHM GROUP
SOUND
SET
METRONOME
234
POP ROCK
SYNCHRO & BREAK
FUNK &
SOUL DISCO
POP BALLAD
WALTZ
& TRADUSA16 BEAT8 BEAT
START / STOP TAP TEMPO
JAZZ &
SWING
TEMPO / PROGRAM
BALLROOM
BALLAD
& SHOW
LATIN &
MEMORY
WORLD
CONTRAST
LOAD
-
TRANSPOSE
HELP
OTHER PARTS/TR
+
MUTE
PAGE
DISPLAY HOLD
EXIT GRAND
AUTO PLAY CHORD
SPLIT
MAIN
VOLUME
MAX
MIN
DEMO
ONE TOUCH
MODE
OFF/ON
PLAY
POINT
CHORD FINDER
PROGRESSIVE
PIANIST PIANO STYLIST
1 2 1 2 1 1 2 3 4 BEAT
MUSIC STYLE ARRANGER
VARIATION
SOUND GROUP
GUITAR &
SAX &
ORGAN &
WOODWIND
ACCORDION
SYNTH
PIANO
ORCH
DIGITAL
MIXTURES
MIXTURES
DRAWBARS
DRUM KITS
MODERN SIMPLE PIANO TECHNI-CHORD BANK
PIANO
SOUND
EXPLORER
MEMORY
STRINGS
VOCAL
HARPSI BRASS PLAY
MALLET &
ORCH PERC
WORLD
BASS
UPRIGHT ELECTRIC
SEQUENCER
CHORD STEP REC
CONDUCTOR
LEFT RIGHT 2 RIGHT 1
C
AB
SET 1 / 5 2 / 6 3 / 7 4 / 8
EASY
REC
FAVORITES
PANEL MEMORY
PROGRAM
DISK
MENUS
IN USE
DISK
LOAD
DIGITAL
MULTI
EFFECT
EFFECT
CHORUS REVERB
P.MEM 5-8
2153
1
In the RHYTHM GROUP section, press
the button for a desired rhythm.
RHYTHM GROUP
METRONOME
POP ROCK
FUNK &
SOUL DISCO
WALTZ
& TRADUSA16 BEAT8 BEAT
POP BALLAD
JAZZ &
SWING
BALLAD
LATIN &
WORLD
BALLROOM
& SHOW
MEMORY
4
5
Use your left hand to play the chords
and your right hand to play the melody.
• Pressing a key on the left area of the keyboard
will cause the automatic rhythm pattern to start
playing (synchro start).
At the end of your performance, press
the INTRO & ENDING 1 or 2 button.
2
3
LOAD
• Do not select the METRONOME or the
MEMORY button.
Select a rhythm from the list of rhythms
on the display.
Press and hold the ONE TOUCH PLAY
button for a few seconds.
ONE TOUCH
PLAY
• An ending pattern is played, after which the
automatic accompaniment stops.
• If the START/STOP button is pressed, the
accompaniment stops immediately.
• The sound, effects and tempo suitable for the
selected rhythm are automatically selected.
The tempo can be adjusted with the
TEMPO/PROGRAM dial.
18
QQTG0701
Basic functions
C F G
7
C
C F G
7
C
CG7 F
• In this example you played chords by pressing the keys for
the “root notes” (ONE FINGER chords). But you can also
specify the chord by playing all the notes in the chord.
(Refer to page 45.)
• You can insert a fill-in pattern while the preset rhythm
pattern is playing by pressing either the FILL IN 1 or FILL
IN 2 button.
19
QQTG0701
Record your performance
Sonatina
Right hand
Left hand
(SEQUENCER)
Basic functions
APC/SEQUENCER
VOLUME
MAX
OFF
FADE
IN OUT
ARRANGER
FILL IN INTRO & ENDING
SEQUENCER
COUNT
RESET
INTRO
RHYTHM GROUP
SOUND
SET
METRONOME
234
POP ROCK
SYNCHRO & BREAK
FUNK &
SOUL DISCO
POP BALLAD
WALTZ
& TRADUSA16 BEAT8 BEAT
START / STOP TAP TEMPO
JAZZ &
SWING
TEMPO / PROGRAM
BALLROOM
BALLAD
& SHOW
LATIN &
MEMORY
WORLD
CONTRAST
LOAD
-
TRANSPOSE
HELP
OTHER PARTS/TR
+
MUTE
PAGE
DISPLAY HOLD
EXIT GRAND
AUTO PLAY CHORD
SPLIT
MAIN
VOLUME
MAX
MIN
DEMO
ONE TOUCH
MODE
OFF/ON
PLAY
POINT
CHORD FINDER
PROGRESSIVE
PIANIST PIANO STYLIST
1 2 1 2 1 1 2 3 4 BEAT
MUSIC STYLE ARRANGER
VARIATION
SOUND GROUP
GUITAR &
SAX &
ORGAN &
WOODWIND
ACCORDION
SYNTH
PIANO
ORCH
DIGITAL
MIXTURES
MIXTURES
DRAWBARS
DRUM KITS
MODERN SIMPLE PIANO TECHNI-CHORD BANK
PIANO
SOUND
EXPLORER
MEMORY
STRINGS
VOCAL
HARPSI BRASS PLAY
MALLET &
ORCH PERC
WORLD
BASS
UPRIGHT ELECTRIC
SEQUENCER
CHORD STEP REC
CONDUCTOR
LEFT RIGHT 2 RIGHT 1
C
AB
SET 1 / 5 2 / 6 3 / 7 4 / 8
EASY
REC
FAVORITES
PANEL MEMORY
PROGRAM
DISK
MENUS
IN USE
DISK
LOAD
DIGITAL
MULTI
EFFECT
EFFECT
CHORUS REVERB
P.MEM 5-8
21
1
20
QQTG0701
In the SEQUENCER section, press the
EASY REC button to turn it on.
SEQUENCER
EASY
PLAY
REC
Press the OK button.
2
• The display changes to the REALTIME
RECORD display.
Basic functions
SEQUENCER
PLAY
EASY
REC
12
SEQUENCER
RESET
COUNT
INTRO
FILL IN
3
4
APC/SEQUENCER
VOLUME
MAX
OFF
FADE
IN OUT
ARRANGER
FILL IN INTRO & ENDING
SEQUENCER
COUNT
RESET
INTRO
RHYTHM GROUP
SOUND
SET
METRONOME
234
POP ROCK
SYNCHRO & BREAK
FUNK &
SOUL DISCO
POP BALLAD
WALTZ
& TRADUSA16 BEAT8 BEAT
START / STOP TAP TEMPO
BALLROOM
BALLAD
& SHOW
LATIN &
JAZZ &
MEMORY
WORLD
SWING
CONTRAST
LOAD
-
TRANSPOSE
AUTO PLAY CHORD
SPLIT
MAIN
VOLUME
MAX
MIN
DEMO
ONE TOUCH
MODE
OFF/ON
PLAY
POINT
CHORD FINDER
PROGRESSIVE
PIANIST PIANO STYLIST
1 2 1 2 1 1 2 3 4 BEAT
MUSIC STYLE ARRANGER
VARIATION
Play the song on the keyboard.
When you have finished playing, press
the EASY REC button again to turn it off.
TEMPO / PROGRAM
+
SOUND GROUP
GUITAR &
SAX &
ORGAN &
WOODWIND
ACCORDION
SYNTH
PIANO
ORCH
DIGITAL
MIXTURES
MIXTURES
DRAWBARS
DRUM KITS
MODERN SIMPLE PIANO TECHNI-CHORD BANK
PIANO
SOUND
EXPLORER
MEMORY
STRINGS
VOCAL
HARPSI BRASS PLAY
MALLET &
ORCH PERC
WORLD
BASS
HELP
OTHER PARTS/TR
MUTE
PAGE
DISPLAY HOLD
EXIT GRAND
UPRIGHT ELECTRIC
SEQUENCER
CHORD STEP REC
CONDUCTOR
LEFT RIGHT 2 RIGHT 1
C
AB
SET 1 / 5 2 / 6 3 / 7 4 / 8
EASY
REC
FAVORITES
PANEL MEMORY
PROGRAM
DISK
MENUS
IN USE
DISK
LOAD
DIGITAL
MULTI
EFFECT
EFFECT
CHORUS REVERB
P.MEM 5-8
4BA
Playing back your recorded
performance
Press the SEQUENCER RESET (FILL
A
IN 1) button.
• The PLAY button in the SEQUENCER section
turns on.
Press the START/STOP button.
B
1 2 3 4 BEAT
START / STOP
• Your performance is played back just as you
recorded it.
• When you are finished playing back your
performance, press the PLAY button in the
SEQUENCER section to turn it off.
21
QQTG0701
Store your panel settings
AB
C
BANK
(PANEL MEMORY)
Basic functions
1
2
APC/SEQUENCER
VOLUME
MAX
OFF
FADE
IN OUT
ARRANGER
FILL IN INTRO & ENDING
SEQUENCER
COUNT
RESET
INTRO
RHYTHM GROUP
SOUND
SET
METRONOME
234
POP ROCK
SYNCHRO & BREAK
FUNK &
SOUL DISCO
POP BALLAD
WALTZ
& TRADUSA16 BEAT8 BEAT
START / STOP TAP TEMPO
BALLROOM
BALLAD
& SHOW
LATIN &
JAZZ &
MEMORY
WORLD
SWING
CONTRAST
LOAD
-
TRANSPOSE
AUTO PLAY CHORD
SPLIT
MAIN
VOLUME
MAX
MIN
DEMO
ONE TOUCH
MODE
OFF/ON
PLAY
POINT
CHORD FINDER
PROGRESSIVE
PIANIST PIANO STYLIST
1 2 1 2 1 1 2 3 4 BEAT
MUSIC STYLE ARRANGER
VARIATION
Set up the desired panel settings
(sounds, volumes, etc.)
Use the BANK button to select a bank
(A, B, C).
• Lighting up both the A and B indicators enables
C to be selected.
• The bank names are shown on the display.
BANK
TEMPO / PROGRAM
+
SOUND GROUP
GUITAR &
SAX &
ORGAN &
WOODWIND
ACCORDION
SYNTH
PIANO
ORCH
DIGITAL
MIXTURES
MIXTURES
DRAWBARS
DRUM KITS
MODERN SIMPLE PIANO TECHNI-CHORD BANK
PIANO
SOUND
EXPLORER
MEMORY
STRINGS
VOCAL
HARPSI BRASS PLAY
MALLET &
ORCH PERC
WORLD
BASS
HELP
OTHER PARTS/TR
MUTE
PAGE
DISPLAY HOLD
EXIT GRAND
UPRIGHT ELECTRIC
SEQUENCER
CHORD STEP REC
CONDUCTOR
LEFT RIGHT 2 RIGHT 1
C
AB
SET 1 / 5 2 / 6 3 / 7 4 / 8
EASY
REC
FAVORITES
PANEL MEMORY
PROGRAM
DISK
MENUS
IN USE
DISK
LOAD
DIGITAL
MULTI
EFFECT
EFFECT
CHORUS REVERB
P.MEM 5-8
23
With the SET button held down, press
3
one of the numbered buttons of the
PANEL MEMORY (1 to 8).
P.MEM 5-8
SET 1 / 5 2 / 6 3 / 7 4 / 8
PANEL MEMORY
• Turning the P.MEM 5-8 button ON enables the
selection of panel settings for numbers 5 to 8.
• The current panel settings are now stored in the
specified bank and number. When you select
the same bank and number again, the stored
panel settings are recalled.
22
QQTG0701
Save data on a floppy disk
MUTE
1
AUTO PLAY CHORD
SPLIT
MAIN
POINT
VOLUME
MAX
PROGRESSIVE
PIANIST PIANO STYLIST
MIN
MUSIC STYLE ARRANGER
DEMO
VOLUME
ONE TOUCH
MODE
OFF/ON
PLAY
CHORD FINDER
1 2 1 2 1 1 2 3 4 BEAT
VARIATION
MAX
OFF
IN OUT
ARRANGER
FILL IN INTRO & ENDING
SEQUENCER
COUNT
RESET
INTRO
RHYTHM GROUP
SOUND
SET
METRONOME
234
POP ROCK
SYNCHRO & BREAK
FUNK &
SOUL DISCO
POP BALLAD
WALTZ
& TRADUSA16 BEAT8 BEAT
START / STOP TAP TEMPO
BALLROOM
BALLAD
& SHOW
LATIN &
JAZZ &
MEMORY
WORLD
SWING
CONTRAST
LOAD
-
TRANSPOSE
FADE
APC/SEQUENCER
Insert a disk you wish to save to into the
Disk Drive slot. Push it all the way in until
you hear a click.
TEMPO / PROGRAM
+
SOUND GROUP
GUITAR &
SAX &
ORGAN &
WOODWIND
ACCORDION
SYNTH
PIANO
ORCH
DIGITAL
DRUM KITS
MIXTURES
MIXTURES
DRAWBARS
MODERN SIMPLE PIANO TECHNI-CHORD BANK
PIANO
SOUND
EXPLORER
MEMORY
STRINGS
VOCAL
HARPSI BRASS PLAY
MALLET &
WORLD
ORCH PERC
BASS
HELP
OTHER PARTS/TR
MUTE
PAGE
DISPLAY HOLD
EXIT GRAND
UPRIGHT ELECTRIC
SEQUENCER
CHORD STEP REC
CONDUCTOR
LEFT RIGHT 2 RIGHT 1
C
AB
SET 1 / 5 2 / 6 3 / 7 4 / 8
EASY
REC
FAVORITES
PANEL MEMORY
PROGRAM
DISK
MENUS
IN USE
DISK
LOAD
DIGITAL
MULTI
CHORUS REVERB
EFFECT
EFFECT
P.MEM 5-8
Basic functions
2-5
Specify a file number to save to.
4
2
3
On the DISK MENU display, select
SAVE.
• If you attempt to use the SAVE procedure when
an unformatted disk is inserted into the Disk
Drive slot, the FORMAT display appears. Follow
the instructions on the display to format the disk.
(Formatting the disk will clear any data which is
currently stored on the disk.)
Select TECHNICS FORMAT.
Press the SAVE button.
5
• The performance data of the song recorded in
the SEQUENCER is saved on the floppy disk.
23
QQTG0701
Basic functions
MUTE
MAIN
VOLUME
DEMO
MAX
MIN
AUTO PLAY CHORD
SPLIT
POINT
PROGRESSIVE
PIANIST PIANO STYLIST
MUSIC STYLE ARRANGER
VOLUME
ONE TOUCH
MODE
OFF/ON
PLAY
CHORD FINDER
1 2 1 2 1 1 2 3 4 BEAT
VARIATION
MAX
OFF
IN OUT
ARRANGER
FILL IN INTRO & ENDING
SEQUENCER
COUNT
RESET
INTRO
RHYTHM GROUP
SOUND
SET
METRONOME
234
POP ROCK
SYNCHRO & BREAK
FUNK &
SOUL DISCO
POP BALLAD
WALTZ
& TRADUSA16 BEAT8 BEAT
START / STOP TAP TEMPO
JAZZ &
SWING
TEMPO / PROGRAM
BALLROOM
BALLAD
& SHOW
LATIN &
MEMORY
WORLD
CONTRAST
LOAD
-
TRANSPOSE
HELP
OTHER PARTS/TR
+
MUTE
PAGE
DISPLAY HOLD
EXIT GRAND
FADE
APC/SEQUENCER
SOUND GROUP
GUITAR &
SAX &
ORGAN &
WOODWIND
ACCORDION
SYNTH
PIANO
ORCH
DIGITAL
DRUM KITS
MIXTURES
MIXTURES
DRAWBARS
MODERN SIMPLE PIANO TECHNI-CHORD BANK
PIANO
SOUND
EXPLORER
MEMORY
STRINGS
VOCAL
HARPSI BRASS PLAY
MALLET &
WORLD
ORCH PERC
BASS
UPRIGHT ELECTRIC
SEQUENCER
CHORD STEP REC
CONDUCTOR
LEFT RIGHT 2 RIGHT 1
C
AB
SET 1 / 5 2 / 6 3 / 7 4 / 8
EASY
REC
FAVORITES
PANEL MEMORY
PROGRAM
DISK
MENUS
IN USE
DISK
LOAD
DIGITAL
MULTI
CHORUS REVERB
EFFECT
EFFECT
P.MEM 5-8
2·3541
Recall data from a floppy disk
Press and hold the DISK button for a few
1
seconds.
DISK
LOAD
DISK
IN USE
Select the file you wish to load.
2
3
4
5
Press the LOAD button.
• The data is copied to the internal memory of this
instrument.
Press the PLAY button in the
SEQUENCER section to turn it on.
SEQUENCER
EASY
PLAY
REC
CHORD STEP REC
Press the START/STOP button.
1 2 3 4 BEAT
START / STOP
• The recalled song is played back.
■■■■ The following data can be saved/loaded:
CURRENT PANEL (The current panel settings)
PANEL MEMORY
PERFORMANCE
SEQUENCER
COMPOSER (MEMORY contents)
SOUND MEMORY
EFFECT MEMORY
BACKUP MIDI (USER memory of the MIDI PRESETS) & FAVORITES
• For detailed infomation, refer to page 90.
24
QQTG0701
Load rhythm data from a Technics
RHYTHM GROUP
METRONOME
POP ROCK
FUNK &
SOUL DISCO
POP BALLAD
BALLAD
BALLROOM
& SHOW
MEMORY
LATIN &
WORLD
JAZZ &
SWING
WALTZ
& TRADUSA16 BEAT8 BEAT
LOAD
pattern disk
APC/SEQUENCER
VOLUME
MAX
OFF
FADE
IN OUT
ARRANGER
FILL IN INTRO & ENDING
SEQUENCER
COUNT
RESET
INTRO
RHYTHM GROUP
SOUND
SET
METRONOME
234
POP ROCK
SYNCHRO & BREAK
FUNK &
SOUL DISCO
POP BALLAD
WALTZ
& TRADUSA16 BEAT8 BEAT
START / STOP TAP TEMPO
BALLROOM
BALLAD
& SHOW
LATIN &
JAZZ &
MEMORY
WORLD
SWING
LOAD
1
2
AUTO PLAY CHORD
SPLIT
MAIN
VOLUME
MAX
MIN
DEMO
ONE TOUCH
MODE
OFF/ON
PLAY
POINT
CHORD FINDER
PROGRESSIVE
PIANIST PIANO STYLIST
1 2 1 2 1 1 2 3 4 BEAT
MUSIC STYLE ARRANGER
VARIATION
Insert a commercially sold Technics
pattern disk into the Disk Drive slot.
In the RHYTHM GROUP section, press
and hold the LOAD (MEMORY) button
for a few seconds.
(COMPOSER LOAD)
TEMPO / PROGRAM
CONTRAST
HELP
-
TRANSPOSE
OTHER PARTS/TR
+
MUTE
PAGE
DISPLAY HOLD
EXIT GRAND
3·42
Press the LOAD button.
4
SOUND GROUP
GUITAR &
SAX &
ORGAN &
WOODWIND
ACCORDION
SYNTH
PIANO
ORCH
DIGITAL
MIXTURES
MIXTURES
DRAWBARS
DRUM KITS
MODERN SIMPLE PIANO TECHNI-CHORD BANK
PIANO
SOUND
EXPLORER
MEMORY
STRINGS
VOCAL
HARPSI BRASS PLAY
MALLET &
ORCH PERC
WORLD
BASS
UPRIGHT ELECTRIC
SEQUENCER
CHORD STEP REC
CONDUCTOR
LEFT RIGHT 2 RIGHT 1
C
AB
SET 1 / 5 2 / 6 3 / 7 4 / 8
EASY
REC
FAVORITES
PANEL MEMORY
Basic functions
PROGRAM
DISK
MENUS
IN USE
DISK
LOAD
DIGITAL
MULTI
EFFECT
EFFECT
CHORUS REVERB
P.MEM 5-8
3
• Rhythm data is loaded to the COMPOSER
memory (MEMORY). You can use the rhythms
during your performance, just like the preset
rhythms.
Select the name of the pattern to load.
MUTE
25
QQTG0701
Play back commercial song disks
MUTE
(DIRECT PLAY)
Basic functions
1
2
APC/SEQUENCER
VOLUME
MAX
OFF
FADE
IN OUT
ARRANGER
FILL IN INTRO & ENDING
SEQUENCER
COUNT
RESET
INTRO
RHYTHM GROUP
SOUND
SET
METRONOME
234
POP ROCK
SYNCHRO & BREAK
FUNK &
SOUL DISCO
POP BALLAD
WALTZ
& TRADUSA16 BEAT8 BEAT
START / STOP TAP TEMPO
BALLROOM
BALLAD
& SHOW
LATIN &
JAZZ &
MEMORY
WORLD
SWING
LOAD
-
AUTO PLAY CHORD
SPLIT
MAIN
VOLUME
MAX
MIN
DEMO
ONE TOUCH
MODE
POINT
OFF/ON
PLAY
CHORD FINDER
PROGRESSIVE
PIANIST PIANO STYLIST
1 2 1 2 1 1 2 3 4 BEAT
MUSIC STYLE ARRANGER
VARIATION
Insert the song disk into the Disk Drive
slot.
On the DISK MENU display, select
DIRECT PLAY.
CONTRAST
TRANSPOSE
TEMPO / PROGRAM
+
SOUND GROUP
GUITAR &
SAX &
ORGAN &
WOODWIND
ACCORDION
SYNTH
PIANO
ORCH
DIGITAL
DRUM KITS
MIXTURES
MIXTURES
DRAWBARS
MODERN SIMPLE PIANO TECHNI-CHORD BANK
PIANO
SOUND
EXPLORER
MEMORY
STRINGS
VOCAL
HARPSI BRASS PLAY
MALLET &
WORLD
ORCH PERC
BASS
HELP
OTHER PARTS/TR
MUTE
PAGE
DISPLAY HOLD
EXIT GRAND
UPRIGHT ELECTRIC
SEQUENCER
CHORD STEP REC
CONDUCTOR
LEFT RIGHT 2 RIGHT 1
C
AB
SET 1 / 5 2 / 6 3 / 7 4 / 8
EASY
REC
FAVORITES
PANEL MEMORY
PROGRAM
DISK
MENUS
IN USE
DISK
LOAD
DIGITAL
MULTI
CHORUS REVERB
EFFECT
EFFECT
P.MEM 5-8
2-4
Use a the buttons below the display to
3
select a song.
• DIRECT PLAY is possible from the following
disks:
Standard MIDI File
Standard MIDI File with Lyrics
DISK ORCHESTRA COLLECTION™ (DOC)
PianoDisc™
* All product and company names are trademarks or
registered trademarks of their respective owners.
* DISK ORCHESTRA COLLECTION is a trademark of
the YAMAHA Corporation.
4
• For SMF songs, use the PLAY AS button to
specify a sound arrangement mode.
Press the START button.
• The selected song is played back.
26
QQTG0701
About the display
A large-size display, easy to operate with excellent readability, is used for displaying various information
such as the names of the selected sounds and rhythms etc. and when setting the functions. Let’s take a
look.
• The display illustrations shown in this User’s Manual are examples for the sake of clarification; the actual displays on your in strument may differ from the illustrations.
Normal display (HOME PAGE)
This is the kind of information you see on the display during a normal performance.
Selected rhythm
Tempo
Volume of each part
Volume balance
At the bottom half of the normal display, the volume balance of each part is represented in a
fader illustration and by a number (0 to 127). You
can use the balance buttons below the display to
adjust the volumes.
RIGHT 1 part sound
About the display
RIGHT 2 part sound
LEFT part sound
OTHER PARTS/TR
MUTE
APC: AUTO PLAY CHORD RT: RIGHT
METR: METRONOME
When setting the volume balance, press the
upper button to increase the volume and the
lower button to decrease it.
• Hold a button down to scroll the volume quickly.
<Auto accompaniment part>
Pressing the OTHER PARTS/TR button will display the auto accompaniment part setting
screen.
• DRM: DRUMS ACP: ACCOMP
MUTE
䡲䡲䡲䡲
To mute a part, press both the corresponding
upper and lower buttons at the same time.
• The volume display for a muted part is shown as “MUTE.”
• Pressing either balance button for a muted part will cancel the mute function.
OTHER PARTS/TR
䡲䡲䡲䡲
By the pressing the OTHER PARTS/TR button,
the screen sequentially switches to the respective volume balance screens of the play part,
auto accompaniment part, playback part (1 to 8),
and playback part (9 to 16). The playback part
(PT) is used to playback recording and song
data.
27
QQTG0701
PAGE
PROGRAM
MENUS
When there are additional parts to the current
display, a page number indication, for example
PAGE1/2, appears in the upper right corner of
the screen. For example, 1/2 indicates that there
are two pages of the display, and the current
Setting display
When you select an item from the menu display,
the setting display for the item is shown.
The buttons to the right, left and/or directly below
the display are used to select and adjust the set-
tings.
page is page 1. In this case, you can use the
upper and lower PAGE buttons, to the right of
the balance buttons, to view different “pages” of
Example of setting display: MASTER
䡲䡲䡲䡲
TUNING
the display.
PAG E
About the display
• Press the upper button to view the next page of the display, and the lower button to view the previous page of
the display.
• On the last page of the display, pressing the upper button
returns to the first page. And conversely, on the first page
of the display, pressing the lower button will skip to the
last page.
Press the button corresponding to the
MUTE
or ∨ but-
∧
ton on the display to change the value.
• In this manual, this procedure is written as follows: “Use
∧
the
Menu display
and ∨ buttons to adjust the pitch.”
The PROGRAM MENUS button controls multiple
functions. Press the button to access its menu
display.
TEMPO/PROGRAM
If the TEMPO/PROGRAM indicator is lit while
you are using the display to adjust the setting, it
indicates that this dial can be used to quickly
change the displayed value or setting.
Example of menu display: PROGRAM
䡲䡲䡲䡲
MENUS
Select a function from the menu display by
pressing the corresponding button to the left or
right of the display indicated by the
䊴
and
䊳
arrows.
• In this manual, the steps describing how to select a function from a menu display are generally abbreviated as follows, for example: “On the PROGRAM MENUS display,
select SOUND.”
TEMPO / PROGRAM
• The setting which can be adjusted is highlighted on the
display.
EXIT
While the setting display is shown, press this button to go back to the previous display.
DISPLAY HOLD
EXIT
28
QQTG0701
DISPLAY HOLD
Press this button to turn it on when you wish to
maintain the current display. You can keep a display which is normally automatically canceled,
for example, or even during a performance, you
can monitor information which is not shown on
the normal display.
DISPLAY HOLD
• The indicator for this button may flash if the current display is one which is normally automatically canceled.
• If the PROGRAM MENUS button, for example, is
pressed, the DISPLAY HOLD mode is canceled.
EXIT
CONTRAST
Press the CONTRAST button and adjust the display's viewability using the
the screen.
and ∨ buttons on
∧
• The following display appears.
Use the buttons below the display to select a
2.
language.
Press the OK button.
3.
Press a button on the panel whose explana-
4.
tion you wish to read.
• An explanation of the button’s function is shown on the
display.
Press the HELP button again to exit the help
5.
mode.
• Attention display messages and error messages are also
shown in the selected language.
About the display
CONTRAST
• When adjusting the CONTRAST, the set value is shown
shortly on the display.
HELP
You can find an explanation of each button’s
function on the display.
Press the HELP button.
1.
HELP
OTHER PARTS/TR
• The appearance of the display on your instrument may
be different from the illustrated display in this manual
depending on the region in which your instrument was
purchased and the selected display language.
29
QQTG0701
Favorites
AUTO PLAY CHORD
SPLIT
ONE TOUCH
MAIN
POINT
OFF/ON
PLAY
MODE
VOLUME
MAX
CHORD FINDER
PROGRESSIVE
PIANIST PIANO STYLIST
MIN
1 2 1 2 1 1 2 3 4 BEAT
MUSIC STYLE ARRANGER
VARIATION
DEMO
FADE
APC/SEQUENCER
VOLUME
SOUND
METRONOME
IN OUT
ARRANGER
MAX
SET
OFF
234
FILL IN INTRO & ENDING
SEQUENCER
COUNT
RESET
INTRO
TEMPO / PROGRAM
RHYTHM GROUP
FUNK &
BALLROOM
POP ROCK
SOUL DISCO
POP BALLAD
BALLAD
& SHOW
LATIN &
JAZZ &
WALTZ
MEMORY
WORLD
SWING
& TRADUSA16 BEAT8 BEAT
CONTRAST
LOAD
SYNCHRO & BREAK
START / STOP TAP TEMPO
HELP
OTHER PARTS/TR
-
TRANSPOSE
+
MUTE
DISPLAY HOLD
PAGE
SOUND GROUP
GUITAR &
STRINGS
VOCAL
HARPSI BRASS PLAY
MALLET &
BASS
ORCH PERC
WORLD
EXIT GRAND
UPRIGHT ELECTRIC
SAX &
ORGAN &
WOODWIND
ACCORDION
PIANO
ORCH
DIGITAL
MIXTURES
MIXTURES
DRAWBARS
DRUM KITS
MODERN SIMPLE PIANO TECHNI-CHORD BANK
PIANO
SEQUENCER
PROGRAM
DISK
EASY
SOUND
MENUS
IN USE
REC
FAVORITES
CONDUCTOR
LEFT RIGHT 2 RIGHT 1
AB
CHORD STEP REC
DIGITAL
EFFECT
C
SET 1 / 5 2 / 6 3 / 7 4 / 8
PANEL MEMORY
DISK
LOAD
MULTI
EFFECT
CHORUS REVERB
P.MEM 5-8
SYNTH
EXPLORER
MEMORY
With up to 9 types of sounds, rhythms, functions, etc., you can arrange them to make up your own unique
screen pattern.
Press the FAVORITES button to turn it on.
1.
While pressing the SET button, specify where
4.
you wish to paste (put) the item.
FAVORITES
• While the SET button is depressed, the display appears
as shown below. Use the buttons to the left and right of
the display to specify where you wish to paste the item.
About the display
• The display looks similar to the following.
Repeat steps 3 and 4 to create the display you
5.
want.
• There are nine settable items on the display.
Press the FAVORITES SETTING button.
2.
On the FAVORITES SETTINGS display,
• The display looks similar to the following.
6.
press the OK button.
• Your customized display is stored.
Select the desired item.
3.
∨
• Use the CATEGORY ∧ and
gory, and then the ITEM
buttons to specify a cate-
∧
and ∨ buttons to select an
item.
• The MUTE KEYS function silences the sound of the keyboard keys. This is convenient when you wish to pretend
to play the keyboard while playing back a recorded performance.
• The PANIC function interrupts the sound, for example,
when it fails to cease during a MIDI performance.
Recall a FAVORITES display
䡲䡲䡲䡲
Press the FAVORITES button to turn it on.
1.
Use the buttons to the left and right of the dis-
2.
play to specify the ITEM you wish to recall.
• The FAVORITES settings can be saved to a disk.
30
QQTG0701
Part I Sounds and effects
Overview of sounds
The following is an overview of the sound parts of this instrument.
NX SOUND
NX SOUND is the Technics original sound generator format which evokes realtime performance quality and expressive power, and
dramatically expands the number of sounds
and effects generated. This format includes
GM2 (General MIDI Level 2), and make various
controls possible when data is created and
reproduced by computer.
• For information about GM2, refer to page 91.
• Equipment with the logo shown below is compatible
with NX SOUND song data.
Part
This instrument is organized into the following
parts.
RIGHT 1, RIGHT 2, LEFT:
These are the parts the performer plays on
the keyboard.
• These are independent from the playback parts. For
example one can to perform on the keyboard while
playing back a song disk with 16-part standard MIDI
files (SMF).
PART1 to 16:
SMF song disk playback parts, or parts for
MIDI receive.
Sounds and effects
ACCOMP1 to 5, BASS, DRUMS 1, 2:
Parts for the automatic accompaniment.
METRONOME:
METRONOME part.
Selecting sounds
SPLIT
MAIN
POINT
VOLUME
MAX
MIN
MUSIC STYLE ARRANGER
DEMO
FADE
AUTO PLAY CHORD
APC/SEQUENCER
VOLUME
ONE TOUCH
SOUND
OFF/ON
MODE
CHORD FINDER
PROGRESSIVE
PIANIST PIANO STYLIST
1 2 1 2 1 1 2 3 4 BEAT
VARIATION
METRONOME
PLAY
IN OUT
ARRANGER
MAX
SET
OFF
FILL IN INTRO & ENDING
SEQUENCER
COUNT
RESET
INTRO
SAX &
ORGAN &
WOODWIND
ACCORDION
SYNTH
PIANO
ORCH
DIGITAL
MIXTURES
MIXTURES
DRAWBARS
DRUM KITS
MODERN SIMPLE PIANO TECHNI-CHORD BANK
PIANO
SEQUENCER
EASY
PROGRAM
CONDUCTOR
LEFT RIGHT 2 RIGHT 1
AB
REC
FAVORITES
CHORD STEP REC
DIGITAL
EFFECT
C
SET 1 / 5 2 / 6 3 / 7 4 / 8
PANEL MEMORY
DISK
MENUS
IN USE
DISK
LOAD
MULTI
EFFECT
CHORUS REVERB
P.MEM 5-8
SOUND
EXPLORER
MEMORY
DISPLAY HOLD
PAGE
GUITAR &
STRINGS
VOCAL
HARPSI B RASS PLAY
MALLET &
BASS
ORCH PERC
WORLD
EXIT GRAND
SOUND GROUP
UPRIGHT ELECTRIC
TEMPO / PROGRAM
RHYTHM GROUP
FUNK &
BALLROOM
POP ROCK
SOUL DISCO
POP BALLAD
BALLAD
& SHOW
LATIN &
JAZZ &
WALTZ
MEMORY
WORLD
SWING
& TRADUSA16 BEAT8 BEAT
CONTRAST
LOAD
234
SYNCHRO & BREAK
START / STOP TAP TEMPO
HELP
OTHER PARTS/TR
-
TRANSPOSE
+
MUTE
Select the sounds for the three parts you can play on the keyboard—RIGHT 1, RIGHT 2 and LEFT. After
first selecting a part and a SOUND GROUP, choose the desired sound from the display.
Select a sound
In the CONDUCTOR section, choose RIGHT
1.
1, RIGHT 2 or LEFT.
LEFT RIGHT 2 RIGHT 1
•The CONDUCTOR buttons are used to specify which
part is heard. (Refer to page 34.)
CONDUCTOR
In the SOUND GROUP section, select a
2.
sound group.
SOUND GROUP
SAX &
STRINGS
BASS
GUITAR &
VOCAL
HARPSI BRASS
MALLET &
ORCH PERC
WORLD
GRAND
PIANO
MIXTURES
UPRIGHT ELECTRIC
PIANO
WOODWIND
ACCORDION
ORCH
MIXTURES
DRAWBARS
ORGAN &
DIGITAL
SYNTH
DRUM KITS
SOUND
EXPLORER
MEMORY
MODERN
(Continued on the next page)
31
QQTG0701
Part I Sounds and effects
• The sounds in DRUM KITS are percussion sounds that
you play by striking the keyboard keys.
• MEMORY is reserved for storing sounds you modify.
(Refer to page 119.)
Select the desired sound from the list on the
3.
ALPHABET
䡲䡲䡲䡲
Press the CTG button to show the sound names
in alphabetical order.
• Press the ALP button to return to the CATEGORY display.
display.
Digital Drawbar
You can play organ sounds while controlling the
drawbars on the display.
In the CONDUCTOR section, select a part.
1.
Press the DIGITAL DRAWBAR button to turn
2.
it on.
• When you select a sound, the optimum effects for the
sound are automatically applied.
You can also choose to cancel this automatic feature.
(Refer to page 107.)
• If there is more than one page to the display, use the
PAGE buttons to move from one screen page to another.
• Use the OCTAVE
• To exit the sound select display, press the EXIT button.
• The sound you select is memorized for the part you
selected in step 1.
• The sounds that can be selected for the RIGHT 1, RIGHT
Sounds and effects
2 and LEFT parts and for PART 1-16 vary.
• The illustrated display shows one example, and the
actual display may be different.
∧
and ∨ buttons to select the octave.
• The display looks similar to the following.
DIGITAL
DRAWBARS
Play the keyboard.
4.
SOUND EXPLORER
This is a convenient feature for finding the sound
you want from the many available sounds.
In the CONDUCTOR section, choose RIGHT
1.
1, RIGHT 2 or LEFT.
Press the SOUND EXPLORER button to turn
2.
it on..
SOUND
EXPLORER
Use the balance buttons below the display to
3.
adjust the volume of each drawbar.
• The volume of each drawbar is illustrated on the display
and changes when you press the corresponding balance
buttons to adjust the volume.
• The DIGITAL DRAWBAR can not be selected for the
ACCOMP and BASS parts of the COMPOSER or
SOUND ARRANGER.
<DRAWBAR SETTING>
Press the DRAWBAR SETTING button.
Change the sound type
䡲䡲䡲䡲
Use the <Jazz Drawbars> / <Rock Drawbars>
button to select the type of sound.
Use the GRP ∧ and ∨ buttons to select a
3.
GROUP of sound.
Use the buttons on both side of the display to
4.
select the sound.
• The numerical value that is displayed for each sound is
the MIDI [BANK MSB, LSB]-PROGRAM CHANGE number.
• GM2 sounds are selected on this display.
32
QQTG0701
PERCUSSIVE TONE
䡲䡲䡲䡲
PERCUSSIVE TONE adds a tone with a fast initial attack to the drawbar sounds. You can select
two pitch levels of attack tones.
Use the PERCUSSIVE TONE 2 2/3’ and 4’ buttons to turn the respective tone on or off.
Part I Sounds and effects
TREMOLO
䡲䡲䡲䡲
Tremolo is a rapid oscillation in volume, like the
effect of a rotating speaker. The tremolo speed
can be changed while you are playing.
Use the TREMOLO button to switch between the
SLOW and FAST rotating speeds.
• The tremolo setting is effective for each part in common.
• The TREMOLO is disabled if the MULTI EFFECT button
is turned ON.
Other settings
䡲䡲䡲䡲
Use the buttons on either side of the display to
select a setting item, and use one of the
and
∧
buttons, whichever is relevant for the selection,
and set.
ATTACK TIME:
Use the
and ∨ buttons to adjust the time it
∧
takes for the drawbar sound to sound after
a key is played.
RELEASE TIME:
Use the
and ∨ buttons to adjust the time it
∧
takes for the drawbar sound to die out after
the keys are released.
DECAY:
Use the
and ∨ buttons to adjust the time it
∧
takes for the percussive tone to die out.
LEVEL:
Use the ∧ and ∨ buttons to adjust the volume of the percussive tone.
∨
• The above settings are effective for the RIGHT 1, RIGHT
2 and LEFT parts in common.
About foot marks
The foot indication (for example 8’) refers to the pitch of a rank of pipes in a pipe organ. If 8’ is used as
the standard (the pitch as played on the keyboard), a 16’ rank pitch will be one octave below the 8’ rank
pitch, and a 4’ rank pitch one octave above.
When the C key is pressed, the sounds of the different pitch ranks are as follows.
1
3
2
3
2 / '
1
3
5
2'4'5 / '16' 8' 1'
1 / '
3
1 / '
Sounds and effects
33
QQTG0701
Part I Sounds and effects
RIGHT 1
RIGHT 2
LEFT RIGHT 2 RIGHT 1
CONDUCTOR
RIGHT 1 + RIGHT 2
LEFT RIGHT 1 + RIGHT 2
LEFT RIGHT 1
LEFT RIGHT 2
Assigning parts to
the keyboard
AUTO PLAY CHORD
SPLIT
ONE TOUCH
MAIN
POINT
OFF/ON
PLAY
MODE
VOLUME
MAX
CHORD FINDER
PROGRESSIVE
PIANIST PIANO STYLIST
MIN
1 2 1 2 1 1 2 3 4 BEAT
MUSIC STYLE ARRANGER
VARIATION
DEMO
FADE
APC/SEQUENCER
VOLUME
SOUND
METRONOME
IN OUT
ARRANGER
MAX
SET
OFF
234
FILL IN INTRO & ENDING
SEQUENCER
COUNT
RESET
INTRO
TEMPO / PROGRAM
RHYTHM GROUP
FUNK &
BALLROOM
POP ROCK
SOUL DISCO
POP BALLAD
BALLAD
& SHOW
LATIN &
JAZZ &
WALTZ
MEMORY
WORLD
SWING
& TRADUSA16 BEAT8 BEAT
CONTRAST
LOAD
SYNCHRO & BREAK
START / STOP TAP TEMPO
HELP
OTHER PARTS/TR
-
TRANSPOSE
+
MUTE
DISPLAY HOLD
PAGE
SOUND GROUP
GUITAR &
STRINGS
VOCAL
HARPSI BRASS PLAY
MALLET &
BASS
WORLD
ORCH PERC
EXIT GRAND
UPRIGHT ELECTRIC
SAX &
ORGAN &
WOODWIND
ACCORDION
PIANO
ORCH
DIGITAL
DRUM KITS
MIXTURES
MIXTURES
DRAWBARS
MODERN SIMPLE PIANO TECHNI-CHORD BANK
PIANO
SEQUENCER
PROGRAM
DISK
EASY
SOUND
MENUS
IN USE
REC
FAVORITES
CONDUCTOR
LEFT RIGHT 2 RIGHT 1
AB
CHORD STEP REC
DIGITAL
EFFECT
C
SET 1 / 5 2 / 6 3 / 7 4 / 8
PANEL MEMORY
DISK
LOAD
MULTI
CHORUS REVERB
EFFECT
P.MEM 5-8
SYNTH
EXPLORER
MEMORY
The CONDUCTOR buttons are used to assign the parts (RIGHT 1, RIGHT 2, LEFT) to the keyboard in
many different ways. For example, you can split the keyboard into right and left sections (SPLIT), and
assign a different sound to each section.
CONDUCTOR
CONDUCTOR settings How sounds are assigned to the keyboard
All keys produce the RIGHT 1 sound.
LEFT RIGHT 2 RIGHT 1
LEFT RIGHT 2 RIGHT 1
Sounds and effects
CONDUCTOR
All keys produce the RIGHT 2 sound.
CONDUCTOR
LEFT RIGHT 2 RIGHT 1
LEFT RIGHT 2 RIGHT 1
LEFT RIGHT 2 RIGHT 1
CONDUCTOR
CONDUCTOR
CONDUCTOR
All keys produce both the RIGHT 1 sound and the RIGHT 2 sound.
The left keys produce the LEFT sound and the right keys produce the
RIGHT 1 sound and the RIGHT 2 sound.
The left keys produce the LEFT sound and the right keys produce the
RIGHT 1 sound.
The left keys produce the LEFT sound and the right keys produce the
RIGHT 2 sound.
• The volume for each part can be adjusted independently. (Refer to page 27.)
• The following conditions are in effect when the AUTO PLAY CHORD is used.
—BASIC, ADVANCED mode: You cannot assign sounds to all the keys.
—PIANIST mode: The keyboard cannot be split.
34
QQTG0701
Part I Sounds and effects
SPLIT POINT
You can split the keyboard into right and left sections (SPLIT), and assign a different sound to
each section.
Customized split point
䡲䡲䡲䡲
Use the following procedure if you wish to store a
split point at a location other than G2/C3/C4.
Press the LEFT button in the CONDUCTOR
1.
to turn it on.
• If the LEFT part does not turn on, then turn off the AUTO
PLAY CHORD, or select any mode except PIANIST.
Use the SPLIT POINT button to define the
2.
point that divides the left and right keyboard
sections.
SPLIT
POINT
• Each time the SPLIT POINT button is pressed, the indi-
cation moves to the next split point in the following order.
G2 → C3 → C4 → customized split point (all indicators
off) (see below).
G2
C3
C4
Press and hold the SPLIT POINT button for a
1.
few seconds.
SPLIT
POINT
• The following display appears.
Press a key on the keyboard to specify the
2.
desired split point.
• A split point is set at the location of the pressed key, and
is indicated on the keyboard illustration on the display.
• The key at the split point is the lowest note of the right
keyboard section.
• After a few seconds, the display exits the setting mode.
• Whenever the keyboard is split, you can select your cus-
tomized split point by pressing the SPLIT POINT button
until none of the split point indicators is lit. In this case,
the customized split point is indicated on the display.
Sounds and effects
Pedals
Sustain pedal
䡲䡲䡲䡲
When a key is released while this pedal is
depressed, the sound is sustained so that it lingers and slowly fades out.
• This effect does not work for the sounds in the DRUM
KITS group.
• This effect does not work for some sounds.
• The length of the sustain can be set for each part. (Refer
to page 102.)
Soft pedal
䡲䡲䡲䡲
When this pedal is depressed, the sound is
softer and the volume is slightly lower.
• You can select a different function to control with this
pedal. (Refer to page 120.)
String resonance
String resonance is the sound heard in an acoustic piano when the struck strings produce a sympathetic resonance of the other unstruck strings.
For the GRAND PIANO and UPRIGHT PIANO
sounds, string resonance is produced as long as
the sustain pedal is depressed. The amount of
string resonance can be adjusted.
Sustain pedal
Soft pedal
Press and hold the GRAND button for a few
1.
seconds.
GRAND
• STRING RESONANCE DEPTH is shown on the display.
(Continued on the next page)
35
QQTG0701
Part I Sounds and effects
Use the ∧ and ∨ buttons to adjust the amount
2.
of resonance (0 to 99).
• The higher the number, the greater the amount of resonance.
• When set to 0, there is no string resonance.
Touch Sensitivity
FADE
AUTO PLAY CHORD
SPLIT
ONE TOUCH
MAIN
OFF/ON
PLAY
POINT
MODE
VOLUME
MAX
CHORD FINDER
PROGRESSIVE
PIANIST PIANO STYLIST
MIN
1 2 1 2 1 1 2 3 4 BEAT
MUSIC STYLE ARRANGER
VARIATION
DEMO
APC/SEQUENCER
VOLUME
SOUND
METRONOME
IN OUT
ARRANGER
MAX
SET
OFF
234
FILL IN INTRO & ENDING
SEQUENCER
COUNT
RESET
INTRO
TEMPO / PROGRAM
RHYTHM GROUP
BALLROOM
FUNK &
POP ROCK
SOUL DISCO
POP BALLAD
BALLAD
& SHOW
LATIN &
JAZZ &
WALTZ
MEMORY
WORLD
SWING
& TRADUSA16 BEAT8 BEAT
CONTRAST
LOAD
SYNCHRO & BREAK
START / STOP TAP TEMPO
HELP
OTHER PARTS/TR
-
TRANSPOSE
+
MUTE
DISPLAY HOLD
PAGE
GUITAR &
STRINGS
VOCAL
HARPSI BRASS PLAY
MALLET &
BASS
ORCH PERC
WORLD
EXIT GRAND
UPRIGHT ELECTRIC
Adjust keyboard touch response.
Press the PROGRAM MENUS button to turn it
1.
on.
PROGRAM
MENUS
Sounds and effects
MINIMUM RANGE: Specify whether or not the keyboard
keys function when the keys are pressed very softly
(ON/OFF).
• When set to ON, the keys do not function when they are
pressed very softy, as in an acoustic piano. When set to
OFF, the keys function even when they are pressed very
softly.
SOUND GROUP
SAX &
ORGAN &
WOODWIND
ACCORDION
PIANO
ORCH
DIGITAL
MIXTURES
MIXTURES
DRAWBARS
MODERN SIMPLE PIANO TECHNI-CHORD BANK
PIANO
SEQUENCER
EASY
PROGRAM
CONDUCTOR
LEFT RIGHT 2 RIGHT 1
AB
REC
FAVORITES
CHORD STEP REC
C
SET 1 / 5 2 / 6 3 / 7 4 / 8
PANEL MEMORY
DISK
MENUS
IN USE
DISK
LOAD
DIGITAL
MULTI
EFFECT
EFFECT
CHORUS REVERB
P.MEM 5-8
SOUND
SYNTH
EXPLORER
DRUM KITS
MEMORY
• The display looks similar to the following.
Select TOUCH SENSITIVITY.
2.
• The display looks similar to the following.
Use the buttons to the left of the display to
3.
select the function you wish to set. Use the ▲
and ▼ buttons to adjust the setting.
TOUCH SENSITIVITY: This is the keyboard touch response
setting.
• Select from HEAVY 3, HEAVY 2, HEAVY 1, NORMAL
and LIGHT.
When you have finished adjusting the settings,
4.
press the PROGRAM MENUS button again.
36
QQTG0701
Part I Sounds and effects
Effects
DIGITAL EFFECT
DIGITAL EFFECT gives the sound richness and
enhances your performance.
AUTO PLAY CHORD
APC/SEQUENCER
VOLUME
SPLIT
ONE TOUCH
MAIN
POINT
OFF/ON
PLAY
MODE
VOLUME
MAX
CHORD FINDER
PROGRESSIVE
PIANIST PIANO STYLIST
MIN
12 1 2 1 1234BEAT
MUSIC STYLE ARRANGER
VARIATION
DEMO
3.
FADE
SOUND
METRONOME
IN OUT
ARRANGER
MAX
SET
OFF
234
FILL IN INTRO & ENDING
SEQUENCER
COUNT
RESET
INTRO
TEMPO / PROGRAM
RHYTHM GROUP
FUNK &
BALLROOM
POP ROCK
SOUL DISCO
POP BALLAD
BALLAD
& SHOW
LATIN &
JAZZ &
WALTZ
MEMORY
WORLD
SWING
& TRADUSA16 BEAT8 BEAT
CONTRAST
LOAD
SYNCHRO & BREAK
START / STOP TAP TEMPO
HELP
OTHER PARTS/TR
-
TRANSPOSE
+
MUTE
Use the buttons to the right of the display to
DISPLAY HOLD
PAGE
GUITAR &
STRINGS
VOCAL
HARPSI BRASS PLAY
MALLET &
BASS
ORCH PERC
WORLD
EXIT GRAND
UPRIGHT ELECTRIC
SOUND GROUP
select the type.
• If the types comprise more than one display “page,” use
the PAGE buttons to switch pages.
SAX &
ORGAN &
WOODWIND
ACCORDION
PIANO
ORCH
DIGITAL
MIXTURES
MIXTURES
DRAWBARS
MODERN SIMPLE PIANO TECHNI-CHORD BANK
PIANO
SEQUENCER
PROGRAM
EASY
REC
CHORD STEP REC
CONDUCTOR
C
AB
SET 1 / 5 2 / 6 3 / 7 4 / 8
DISK
MENUS
IN USE
FAVORITES
DISK
LOAD
DIGITAL
MULTI
EFFECT
EFFECT
CHORUS REVERB
P.MEM 5-8
PANEL MEMORY
SOUND
SYNTH
EXPLORER
DRUM KITS
MEMORY
LEFT RIGHT 2 RIGHT 1
In the CONDUCTOR or PART SELECT sec-
1.
tion, turn on the part to which this effect will be
applied.
Press the DIGITAL EFFECT button to turn it
2.
on.
DIGITAL
EFFECT
• The on or off status of the DIGITAL EFFECT is preset for
each sound.
• This effect does not work for the sounds in the DRUM
KITS sound groups.
• This effect may not work for some sounds.
MULTI EFFECT
The MULTI EFFECT works like a studio effects
processor, providing effects such as CHORUS,
PHASER, DELAY and DISTORTION.
In the CONDUCTOR or PART SELECT sec-
1.
tion, turn on the part to which this effect will be
applied.
Press the MULTI EFFECT button to turn it on.
2.
MULTI
EFFECT
• Press the VARI button to enable the variation effect.
• This display can also be accessed from the REVERB &
EFFECT MENU display. (Refer to page 108.)
EFFECT EDIT
䡲䡲䡲䡲
The effects can be edited and then stored in a
memory.
Select an effect type to use as a base.
1.
Press the EFFECT EDIT button.
2.
• The display changes to the following.
Use the PARAMETER ▲ and ▼ buttons to
3.
select the parameter.
Use the VALUE ∧ and ∨ buttons to adjust the
4.
setting.
• The parameters vary depending on the effect type
selected as the base.
• (V) is the abbreviation of VARIATION.
Press the WRITE button.
5.
Sounds and effects
Type and parameter settings
䡲䡲䡲䡲
Press and hold the MULTI EFFECT button for
1.
a few seconds.
• The display changes to the following.
Use the ▲ and ▼ buttons to select an effect
2.
group.
• The EFFECT MEMORY is for edited effects (see below).
Press the EFFECT NAMING button and
6.
assign a name to the effect, if necessary.
• Refer to page 52 for details about the NAMING procedure.
Use the EFFECT MEMORY ▲ and ▼ buttons
7.
to specify the location in which to store the
edited effect.
Press the OK button.
8.
QQTG0701
37
Part I Sounds and effects
PROGRAM
MENUS
REVERB
• The display looks similar to the following.
REVERB applies a reverberation effect to the
sound.
Press the REVERB button to turn it on.
REVERB
Use the ▲ and ▼ buttons to select the name
2.
of the effect group.
Type and parameter settings
䡲䡲䡲䡲
Press and hold the REVERB button for a few
1.
seconds.
• The display changes to the following.
• EFFECT MEMORY is an edited effect group.
Use the buttons to the right of the display to
3.
select a type.
EFFECT EDIT
䡲䡲䡲䡲
Your edited effect can be stored in a memory for
later recall.
• The procedure is the same as for MULTI EFFECT. (Refer
to page 37.)
Use the ▲ and ▼ buttons to select an effect
Sounds and effects
2.
group.
• The EFFECT MEMORY is an edited effect group.
BRILLIANCE
The brightness of the sound can be set for each
performance part.
Use the buttons to the right of the display to
3.
select a type.
• If the types comprise more than one display “page,” use
the PAGE buttons to switch pages.
Use the TOTAL DEPTH ∧ and ∨ buttons to
4.
set the depth of the effect.
• This display can also be accessed from the REVERB &
EFFECT MENU display. (Refer to page 108.)
EFFECT EDIT
䡲䡲䡲䡲
Your edited effect can be stored in a memory for
later recall.
• The procedure is the same as for MULTI EFFECT. (Refer
to page 37.)
CHORUS
Add breadth to the sound.
Press the CHORUS button to turn it on.
CHORUS
Press the PROGRAM MENUS button to turn it
1.
on.
• The display will appear as follows:
Select BRILLIANCE.
2.
Type and parameter settings
䡲䡲䡲䡲
Press and hold the CHORUS button for a few
1.
seconds.
38
QQTG0701
Use the PART ∧ and ∨ buttons to select a
3.
part.
Use the buttons to the left of the display to
4.
select the level of brightness.
• For some sounds, the brightness does not change.
Part I Sounds and effects
MAIN
VOLUME
MAX
MIN
MAX
OFF
AUTO PLAY CHORD
RHYTHM GROUP
TEMPO / PROGRAM
PROGRESSIVE
PIANIST PIANO STYLIST
SPLIT
POINT
METRONOME
POP ROCK
FUNK &
SOUL DISCO
POP BALLAD
BALLAD
BALLROOM
& SHOW
MEMORY
CONTRAST
LATIN &
WORLD
JAZZ &
SWING
WALTZ
& TRADUSA16 BEAT8 BEAT
IN OUT
SOUND
ARRANGER
SET
MODE
CHORD FINDER
OFF/ON
ONE TOUCH
PLAY
APC/SEQUENCER
VOLUME
DEMO
MUSIC STYLE ARRANGER
VARIATION
1 2 1 2 1 1 2 3 4 BEAT
LOAD
SEQUENCER
RESET
COUNT
INTRO
234
FADE
FILL IN INTRO & ENDING
SYNCHRO & BREAK
START / STOP TAP TEMPO
HELP
OTHER PARTS/TR
-
TRANSPOSE
+
MUTE
PAGE
DISPLAY HOLD
EXIT GRAND
UPRIGHT ELECTRIC
MODERN SIMPLE PIANO TECHNI-CHORD BANK
AB
C
P.MEM 5-8
SET 1 / 5 2 / 6 3 / 7 4 / 8
SOUND GROUP
SEQUENCER
PIANO
STRINGS
BASS
MALLET &
ORCH PERC
WORLD
PIANO
MIXTURES
ORCH
MIXTURES
DIGITAL
DRAWBARS
DRUM KITS
MEMORY
LEFT RIGHT 2 RIGHT 1
DIGITAL
EFFECT
MULTI
EFFECT
CHORUS REVERB
CHORD STEP REC
VOCAL
GUITAR &
HARPSI BRASS PLAY
EASY
REC
FAVORITES
PROGRAM
MENUS
DISK
IN USE
DISK
LOAD
SAX &
WOODWIND
ORGAN &
ACCORDION
SYNTH
SOUND
EXPLORER
CONDUCTOR
PANEL MEMORY
Select MIC REVERB & EFFECT.
MIC REVERB & EFFECT
You can add reverb and other effects to sound
from a connected microphone.
• Connect a microphone to this instrument. (Refer to page
134.)
Press the PROGRAM MENUS button to turn it
1.
on.
PROGRAM
MENUS
• The display will appear as follows:
Select REVERB & EFFECT.
2.
3.
• The display looks similar to the following.
Set using the button on the left of the display.
4.
Select the effect name (MIC REVERB/MIC
EFFECT).
Set the MIC REVERB.
5.
• Use the PARAMETER ▲ and ▼ buttons to select an
∨
attribute, and use the VALUE ∧ and
the corresponding setting.
• You can specify whether or not to apply the reverb with
the MIC REV ON/OFF button.
Set the MIC EFFECT.
6.
• Use the PARAMETER ▲ and ▼ buttons to select an
attribute, and use the VALUE
∧
the corresponding setting.
• You can specify whether or not to apply the effect with
the MIC EFF ON/OFF button.
buttons to adjust
∨
buttons to adjust
and
Sounds and effects
Transpose
The TRANSPOSE buttons are used to change the key of the entire instrument in semi-tone steps across
an entire octave.
Suppose you learn to play a song—in the key of C, for example—and decide you want to sing it, only to
find that it’s either too high or too low for your voice. Your choice is to either learn the song all over again
in a different key, or to use the TRANSPOSE feature.
<Example: transposed to D>
-
TRANSPOSE
Adjust the key with the + and – buttons.
• The key is changed in half-tone increments up to plus or
minus one octave.
• If the two buttons are pressed at the same time, the key
returns to C.
• When the TRANSPOSE function is active, the trans-
posed key is shown on the HOME PAGE display.
+
Played keys
C major
Notes that sound
D major
39
QQTG0701
Part I Sounds and effects
Techni-chord
AUTO PLAY CHORD
SPLIT
ONE TOUCH
MAIN
POINT
OFF/ON
PLAY
MODE
VOLUME
MAX
CHORD FINDER
PROGRESSIVE
PIANIST PIANO STYLIST
MIN
1 2 1 2 1 1 2 3 4 BEAT
MUSIC STYLE ARRANGER
VARIATION
DEMO
FADE
APC/SEQUENCER
VOLUME
SOUND
METRONOME
IN OUT
ARRANGER
MAX
SET
OFF
234
FILL IN INTRO & ENDING
SEQUENCER
COUNT
RESET
INTRO
TEMPO / PROGRAM
RHYTHM GROUP
FUNK &
BALLROOM
POP ROCK
SOUL DISCO
POP BALLAD
BALLAD
& SHOW
LATIN &
JAZZ &
WALTZ
MEMORY
WORLD
SWING
& TRADUSA16 BEAT8 BEAT
CONTRAST
LOAD
SYNCHRO & BREAK
START / STOP TAP TEMPO
HELP
OTHER PARTS/TR
-
TRANSPOSE
+
MUTE
DISPLAY HOLD
PAGE
SOUND GROUP
GUITAR &
STRINGS
VOCAL
HARPSI BRASS PLAY
MALLET &
BASS
ORCH PERC
WORLD
EXIT GRAND
UPRIGHT ELECTRIC
TECHNI-CHORD turns your single note melodies into full chords and offers you a choice of different types
from a simple duet which adds one harmony note to your melody note, to big band reeds which adds four
harmony notes to your melody note. If TECHNI-CHORD is part of a ONE TOUCH PLAY or PIANO
STYLIST registration, a suitable TECHNI-CHORD type will be selected automatically.
Example:
Left hand (chord)
CD G7 C
Right hand (melody)
Split the keyboard into left and right sections.
1.
Press the TECHNI-CHORD button to turn it
2.
on.
Sounds and effects
TECHNI-CHORD
Type setting
Press and hold the TECHNI-CHORD button
1.
for a few seconds.
• The display looks similar to the following.
SAX &
ORGAN &
WOODWIND
ACCORDION
PIANO
ORCH
DIGITAL
MIXTURES
MIXTURES
DRAWBARS
DRUM KITS
MODERN SIMPLE PIANO TECHNI-CHORD BANK
PIANO
SEQUENCER
PROGRAM
CONDUCTOR
LEFT RIGHT 2 RIGHT 1
AB
EASY
REC
FAVORITES
CHORD STEP REC
DIGITAL
EFFECT
C
SET 1 / 5 2 / 6 3 / 7 4 / 8
PANEL MEMORY
DISK
MENUS
IN USE
DISK
LOAD
MULTI
EFFECT
CHORUS REVERB
P.MEM 5-8
SOUND
SYNTH
EXPLORER
MEMORY
Play the keyboard.
3.
• The melody you play with your right hand is automatically
played in chords which are based on the chords you play
with your left hand.
• This feature is very effective when used with the AUTO
PLAY CHORD.
䊳
Use the 䊴, ▲, ▼,
2.
buttons to select the har-
mony style.
• When the OCTAVE, HARD ROCK or FANFARE style is
selected, the TECHNI-CHORD functions even when the
keyboard is not split.
䡲䡲䡲䡲
ORCHESTRATOR
You can specify which part is used for the harmony tones. Your TECHNI-CHORD performance is enhanced by selecting harmony
sounds different from the sounds you play and
the sounds produced by the automatic accompaniment.
Use the ORCHESTRATOR ∧ and ∨ buttons
1.
to select the part for the harmony notes.
• If CONDUCTOR is selected, the harmony notes are produced in the sounds of the part which is currently
selected in the CONDUCTOR (RIGHT 1, RIGHT 2). In
other words, the harmony notes are produced in the
same sound as the melody notes. If both RIGHT 1 and
RIGHT 2 are on, the harmony notes are produced in the
sound of the RIGHT 1 part.
40
QQTG0701
• In the case of EASY RECORD (see page 58), when set
to a PART other than PART 4, the TECHNI-CHORD
sound is not recorded; so when you use EASY
RECORD, please set to CONDUCTOR or PART 4.
Part II Playing the rhythm
MAIN
VOLUME
MAX
MIN
MAX
OFF
AUTO PLAY CHORD
RHYTHM GROUP
TEMPO / PROGRAM
PROGRESSIVE
PIANIST PIANO STYLIST
SPLIT
POINT
METRONOME
POP ROCK
FUNK &
SOUL DISCO
POP BALLAD
BALLAD
BALLROOM
& SHOW
MEMORY
CONTRAST
LATIN &
WORLD
JAZZ &
SWING
WALTZ
& TRADUSA16 BEAT8 BEAT
IN OUT
SOUND
ARRANGER
SET
MODE
CHORD FINDER
OFF/ON
ONE TOUCH
PLAY
APC/SEQUENCER
VOLUME
DEMO
MUSIC STYLE ARRANGER
VARIATION
1 2 1 2 1 1 2 3 4 BEAT
LOAD
SEQUENCER
RESET
COUNT
INTRO
234
FADE
FILL IN INTRO & ENDING
SYNCHRO & BREAK
START / STOP TAP TEMPO
HELP
OTHER PARTS/TR
-
TRANSPOSE
+
MUTE
PAGE
DISPLAY HOLD
EXIT GRAND
UPRIGHT ELECTRIC
MODERN SIMPLE PIANO TECHNI-CHORD BANK
AB
C
P.MEM 5-8
SET 1 / 5 2 / 6 3 / 7 4 / 8
SOUND GROUP
SEQUENCER
PIANO
STRINGS
BASS
MALLET &
ORCH PERC
WORLD
PIANO
MIXTURES
ORCH
MIXTURES
DIGITAL
DRAWBARS
DRUM KITS
MEMORY
LEFT RIGHT 2 RIGHT 1
DIGITAL
EFFECT
MULTI
EFFECT
CHORUS REVERB
CHORD STEP REC
VOCAL
GUITAR &
HARPSI BRASS PLAY
EASY
REC
FAVORITES
PROGRAM
MENUS
DISK
IN USE
DISK
LOAD
SAX &
WOODWIND
ORGAN &
ACCORDION
SYNTH
SOUND
EXPLORER
CONDUCTOR
PANEL MEMORY
Overview of rhythm performance
An explanation follows of the terms related to this instrument’s rhythm performance.
Rhythm and accompaniment
pattern
Each rhythm is comprised of not only a DRUMS
pattern, but also of accompaniment patterns
called BASS and ACCOMP. The combination
of all of these is the rhythm.
• The accompaniment pattern sounds when you perform
using the AUTO PLAY CHORD (APC). (Refer to page
44.).
Selecting rhythms
Rhythm and Style
One rhythm of this instrument is comprised of
four VARIATION patterns, and for each one the
optimum sounds and effects are set.
All of these together comprise one STYLE.
STYLE
RHYTHM
VARIATION 1
VARIATION 2
VARIATION 3
VARIATION 4
•In the PIANO STYLIST (page 50) and MUSIC STYLE
ARRANGER (page 51) etc. this STYLE is summoned.
PANEL setting
PANEL setting
PANEL setting
PANEL setting
Playing the rhythm
Many exciting rhythms are stored in the memory of this instrument. First select one of the rhythm groups
and then choose the desired rhythm.
Select a rhythm
In the RHYTHM GROUP section, select a
1.
rhythm group.
RHYTHM GROUP
METRONOME
POP ROCK
FUNK &
SOUL DISCO
WALTZ
& TRADUSA16 BEAT8 BEAT
POP BALLAD
JAZZ &
SWING
• MEMORY is the group in which you store the rhythms
you create with the COMPOSER. (Refer to page 85.)
BALLAD
LATIN &
WORLD
BALLROOM
& SHOW
MEMORY
LOAD
Select the desired rhythm from the list on the
2.
display.
• If there is more than one page to the display, use the
PAGE buttons to move from one screen page to another.
41
QQTG0701
Part II Playing the rhythm
TEMPO / PROGRAM
VARIATION
䡲䡲䡲䡲
There are four variations available for each
rhythm. Use the VARIATION buttons to select
the desired variation.
1234
MUSIC STYLE ARRANGER
• Confirm that the MUSIC STYLE ARRANGER button is
off. (If it is on, press it once to turn it off.)
• The nuance of the pattern differs with each variation
number.
• You can change to a different variation while the rhythm
is playing.
VARIATION
METRONOME
In the RHYTHM GROUP section, select MET-
1.
RONOME.
• The following display appears.
Synchronized start
䡲䡲䡲䡲
With the synchronized start feature, the rhythm
pattern starts when you play a key on the keyboard.
Select a rhythm.
1.
Press the SYNCHRO & BREAK button to turn
2.
it on.
SYNCHRO & BREAK
Play a key to the left of the keyboard split
3.
point.
• The rhythm pattern begins to play.
• You can use the synchronized start feature even when
the keyboard is not divided into left and right sections. To
start the rhythm, press a key to the left of the specified
split point.
Adjust the tempo
䡲䡲䡲䡲
The tempo of the rhythm pattern is adjusted with
the TEMPO/PROGRAM dial.
Playing the rhythm
Select the time signature for the metronome.
2.
• Select “Metronome Off” if you do not wish the first beat of
the measure to be accented.
• Press the START/STOP button to start the metronome.
Start the rhythm
There are two ways to start the rhythm.
Normal start
䡲䡲䡲䡲
Select a rhythm.
1.
Press the START/STOP button to turn it on.
2.
1 2 3 4 BEAT
START / STOP
• The selected rhythm pattern immediately begins to play.
• You can stop the rhythm by pressing the START/STOP
button again to turn it off.
• The BEAT indicators above the START/STOP button
light to indicate the beat.
• The tempo is shown on the display as a numerical value
q
(
= 40 to 300).
• When the TEMPO/PROGRAM indicator is lit, the
TEMPO/PROGRAM cannot be used to adjust the tempo.
• To adjust the tempo during playback, refer to page 61.
TAP TEMPO
䡲䡲䡲䡲
You can set the tempo of the rhythm by tapping
this button few times with your finger at the
tempo you wish to play.
TAP TEMPO
• The tempo at which the button is tapped is detected, and
the tempo automatically changes correspondingly.
42
QQTG0701
Part II Playing the rhythm
1 2 3 4 BEAT
START / STOP
Playing the rhythm
MAIN
VOLUME
MAX
MIN
MUSIC STYLE ARRANGER
DEMO
FADE
AUTO PLAY CHORD
APC/SEQUENCER
VOLUME
SPLIT
ONE TOUCH
POINT
CHORD FINDER
PROGRESSIVE
PIANIST PIANO STYLIST
MODE
SOUND
OFF/ON
PLAY
IN OUT
ARRANGER
MAX
SET
OFF
1 2 1 2 1 1 2 3 4 BEAT
VARIATION
FILL IN INTRO & ENDING
SEQUENCER
COUNT
RESET
INTRO
SAX &
ORGAN &
WOODWIND
ACCORDION
SYNTH
PIANO
ORCH
DIGITAL
MIXTURES
DRAWBARS
DRUM KITS
MODERN SIMPLE PIANO TECHNI-CHORD BANK
PIANO
SEQUENCER
PROGRAM
CONDUCTOR
LEFT RIGHT 2 RIGHT 1
AB
EASY
REC
FAVORITES
CHORD STEP REC
DIGITAL
EFFECT
C
SET 1 / 5 2 / 6 3 / 7 4 / 8
PANEL MEMORY
DISK
MENUS
IN USE
DISK
LOAD
MULTI
EFFECT
CHORUS REVERB
P.MEM 5-8
SOUND
EXPLORER
MEMORY
DISPLAY HOLD
PAGE
SOUND GROUP
GUITAR &
STRINGS
VOCAL
HARPSI BRASS PLAY
MALLET &
BASS
ORCH PERC
MIXTURES
WORLD
EXIT GRAND
UPRIGHT ELECTRIC
TEMPO / PROGRAM
RHYTHM GROUP
FUNK &
BALLROOM
METRONOME
POP ROCK
SOUL DISCO
POP BALLAD
BALLAD
& SHOW
LATIN &
JAZZ &
WALTZ
MEMORY
WORLD
SWING
& TRADUSA16 BEAT8 BEAT
CONTRAST
LOAD
234
SYNCHRO & BREAK
START / STOP TAP TEMPO
HELP
OTHER PARTS/TR
-
TRANSPOSE
+
MUTE
Intro, fill-in and ending patterns fitting each different rhythm pattern are permanently recorded in your PR,
thus allowing a versatile rhythm performance.
Mode setting
INTRO
䡲䡲䡲䡲
You can select the mode for the count sound.
Begin the rhythm performance with an intro pattern.
Press the MODE button in the AUTO PLAY
1.
CHORD section to turn it on.
Press the INTRO & ENDING 1 or INTRO &
1.
ENDING 2 button to turn it on.
AUTO PLAY CHORD
MODE
OFF/ON
12
INTRO & ENDING
CHORD FINDER
• The display looks similar to the following.
Press the START/STOP button to start the
2.
rhythm.
• An intro pattern is played, after which the normal rhythm
pattern begins.
COUNT INTRO
You can begin the rhythm performance with a
spoken one-measure count.
Press the COUNT INTRO (FILL IN 2) button
1.
to turn it on.
2
FILL IN
COUNT
INTRO
Press the START/STOP button to start the
2.
rhythm.
• A spoken one-measure count is played, after which the
normal rhythm pattern begins.
Use the COUNT INTRO button to select a
2.
mode.
VOICE: A spoken count (initialized setting).
CLICK: A clicking sound for the count.
FILL IN
You can insert a fill-in pattern any time during the
rhythm performance. Choose from two different
fill-in patterns.
Select a rhythm and press the START/STOP
1.
button.
Press the FILL IN 1 or FILL IN 2 button.
2.
12
FILL IN
SEQUENCER
COUNT
RESET
INTRO
• A fill-in pattern is heard immediately for the remainder of
the measure.
• When a FILL IN button is pressed on the last beat of the
measure, the fill-in pattern continues to the end of the following measure.
Playing the rhythm
43
QQTG0701
Part II Playing the rhythm
Chord
Melody
Press the INTRO & ENDING 1 or INTRO &
ENDING
2.
ENDING 2 button to turn it on.
Finish the rhythm performance with an ending
pattern.
Select a rhythm and press the START/STOP
1.
12
INTRO & ENDING
button.
• An ending pattern is produced, and then the rhythm performance stops.
• If you accidentally press the INTRO & ENDING button in
the middle of the tune, you can press the FILL IN 1 or
FILL IN 2 button. The ending pattern stops, and a fill-in
pattern is produced, after which the normal rhythm performance continues.
Auto Play Chord
AUTO PLAY CHORD
SPLIT
ONE TOUCH
MAIN
OFF/ON
PLAY
POINT
MODE
VOLUME
MAX
CHORD FINDER
PROGRESSIVE
PIANIST PIANO STYLIST
MIN
1 2 1 2 1 1 2 3 4 BEAT
MUSIC STYLE ARRANGER
VARIATION
DEMO
FADE
APC/SEQUENCER
VOLUME
SOUND
METRONOME
IN OUT
ARRANGER
MAX
SET
OFF
234
FILL IN INTRO & ENDING
SEQUENCER
COUNT
RESET
INTRO
TEMPO / PROGRAM
RHYTHM GROUP
BALLROOM
FUNK &
POP ROCK
SOUL DISCO
POP BALLAD
BALLAD
& SHOW
LATIN &
JAZZ &
WALTZ
MEMORY
WORLD
SWING
& TRADUSA16 BEAT8 BEAT
CONTRAST
LOAD
SYNCHRO & BREAK
START / STOP TAP TEMPO
HELP
OTHER PARTS/TR
-
TRANSPOSE
+
MUTE
DISPLAY HOLD
PAGE
SOUND GROUP
GUITAR &
STRINGS
VOCAL
HARPSI BRASS PLAY
MALLET &
BASS
ORCH PERC
WORLD
EXIT GRAND
UPRIGHT ELECTRIC
SAX &
ORGAN &
WOODWIND
ACCORDION
PIANO
ORCH
DIGITAL
MIXTURES
MIXTURES
DRAWBARS
DRUM KITS
MODERN SIMPLE PIANO TECHNI-CHORD BANK
PIANO
SEQUENCER
EASY
PROGRAM
CONDUCTOR
LEFT RIGHT 2 RIGHT 1
AB
REC
FAVORITES
CHORD STEP REC
DIGITAL
EFFECT
C
SET 1 / 5 2 / 6 3 / 7 4 / 8
PANEL MEMORY
DISK
MENUS
IN USE
DISK
LOAD
MULTI
EFFECT
CHORUS REVERB
P.MEM 5-8
SOUND
SYNTH
EXPLORER
MEMORY
Playing the rhythm
Simply by playing a chord on the keyboard, the AUTO PLAY CHORD function automatically plays an
accompaniment pattern which matches perfectly the selected rhythm. With a real accompaniment as a
background, you can concentrate on playing the melody.
How the AUTO PLAY CHORD works
Playing chords
Choose from the 4 ways of playing chords.
BASIC mode
䡲䡲䡲䡲
This mode lets beginners specify chords with just
one finger. With this mode, chords can be specified either with one finger <one finger> or by
pressing all of the chord's sound components
<fingered>.
When an AUTO PLAY CHORD mode is
selected, an automatic accompaniment which
matches the rhythm you have chosen is played
<one finger>
In the <one-finger>, a major chord can be played
just by pressing the key for its root note.
in the chord which you specify with your left
hand. The melody is played with your right hand.
• The accompaniment pattern of the AUTO PLAY CHORD
is composed of 8 parts: DRUMS 1, 2, BASS, ACCOMP
1–5.
• The volume of each part can be adjusted with the buttons
below the display. (Refer to page 27.)
Example: C chord
44
QQTG0701
Part II Playing the rhythm
Minor, seventh and minor seventh chords are also easily produced.
minor chord seventh chord minor seventh chord
Play the root note plus a
black key to the left of it.
Play the root note plus a
white key to the left of it.
Play the root note plus a
black key and a white key to
the left of it.
Example: Cm Example: C7 Example: Cm7
• When three or more keys of a chord are pressed, it is recognized as a <fingered> chord.
<fingered>
In the <fingered>, you specify the chord by playing all the notes in the chord.
• Play at least three notes to specify the chord.
• If the CHORD FINDER procedure is used, you can see the
types of chords that can be specified and the keys you
press to play them. (Refer to page 47.)
ADVANCED 1 mode
䡲䡲䡲䡲
This mode accepts chords specified with <fingered> and disregards all unrecognizable chord
specifications.
• It recognizes many more chords than the BASIC mode’s
<fingered> chords.
ADVANCED 2 mode
䡲䡲䡲䡲
This mode accepts chords specified with <fingered> and, for unrecognizable chords, it plays
the auto accompaniment according to the keys
pressed.
• It recognizes many more chords than the BASIC mode’s
<fingered> chords.
PIANIST mode
䡲䡲䡲䡲
In the PIANIST mode, the entire keyboard can
be used to specify chords <fingered>
(ADVANCE) for the automatic accompaniment; a
RIGHT part is assigned to all the keys, and the
keyboard does not split.
• When specifying chords, if you press a key a perfect 5th or
more below the lowest note of the chord, the BASS part
becomes a pattern based on that note.
<APC HOLD>
If this function is assigned to the left pedal, for
example, pressing the left pedal will play the currently specified chord in that timing, allowing you
to focus your performance on a solo melody.
• The accompaniment continues in the same chord as long
as the PEDAL is depressed, and it does not change even if
other chords are played.
• To change the PEDAL assignment, refer to page 120.
How to use the AUTO PLAY CHORD
Select the desired rhythm and sound(s), and
1.
set the tempo.
Press the AUTO PLAY CHORD’s OFF/ON
2.
button to turn it on.
AUTO PLAY CHORD
MODE
OFF/ON
CHORD FINDER
Press the AUTO PLAY CHORD’s MODE but-
3.
ton to turn it on.
• The display looks similar to the following.
Select an AUTO PLAY CHORD mode .
4.
• After a few seconds, the display returns to the previous
display.
• If the BASIC or ADVANCED mode was selected, the keyboard automatically splits into right and left sections.
Press the START/STOP button to begin the
5.
rhythm.
• You can start the rhythm by playing a key on the keyboard. (Refer to page 42.)
(Continued on the next page)
Playing the rhythm
45
QQTG0701
Part II Playing the rhythm
Specify a chord.
6.
• If the BASIC or ADVANCED mode was selected, specify
the chord on the keyboard section to the left of the split
point.
• An accompaniment pattern in the specified chord is automatically played. Play the melody with your right hand.
• When you use FILL IN, INTRO and ENDING, the auto-
matic accompaniment is also used in these patterns.
• You can set the mode which determines how the LEFT
part sounds during an AUTO PLAY CHORD perfor-
mance. (See below.)
• In the initialized condition, when the rhythm is off, if an
AUTO PLAY CHORD mode is on and a chord is specified, the specified root note (R. BASS part) and chord
notes (CHORD part) are produced. The volumes of these
notes can be adjusted. (Refer to page 27.)
To stop the automatic accompaniment, press
7.
the START/STOP button.
• If you wish the automatic accompaniment to begin and
end the performance, set the OFF/ON button to off.
MEMORY
䡲䡲䡲䡲
Press the MEMORY button and select either one
of the following:
ON: Even when removing your finger from
OFF: When removing your finger, the chord
AUTO: The chord is retained when auto
ON BASS
䡲䡲䡲䡲
If the ON BASS button is ON, the BASS part is
produced in the key of the lowest note of the
played chord, thus making it possible to play
chords such as C on G.
• For example, with the ON BASS button on, if you play a
C chord by pressing the keys G, C and E, the BASS part
is produced in the key of G.
Example of how to play a BASIC <One-Finger> accompaniment
Play the melody with
C F G C
your right hand.
the keys, the present chord is retained
until the next chord is specified.
is deleted.
accompaniment is playing but is not
retained when stopped.
Playing the rhythm
Left hand
Left Hold
This setting determines how the LEFT part
sounds when the LEFT button in the CONDUC-
TOR is on during a performance with the BASIC
or ADVANCED mode.
Press the MODE button to turn it on.
1.
• The display changes to the following.
Use the LEFT HOLD: ON/OFF button to set
2.
the mode to on or off.
ON:
Specifying <one-finger> chords in the BASIC
mode produces the full chords; otherwise the
LEFT part notes are those of the pressed
chord keys.
• When BASIC is selected the LEFT part turns off, but it
will sound if you turn it on.
• Touch response does not function for the LEFT part.
• When the mode is set to ON, during a rhythm perfor-
mance, the LEFT part continues to play even when the
keys are released.
APC VOLUME
To adjust the volume balance between the automatic accompaniment and the parts you play
manually on the keyboard, the volume of all the
automatic accompaniment parts can be lowered
as one.
OFF:
The LEFT part sounds from the pressed chord
keys.
• When BASIC is selected, the LEFT part turns off. The
LEFT part sounds if you turn it on, but <one-finger>
chords cannot be specified.
46
QQTG0701
⇒ Use the APC/SEQUENCER VOLUME slide
control to adjust the volume.
APC/SEQUENCER
VOLUME
MAX
OFF
Part II Playing the rhythm
AUTO PLAY CHORD
MODE
CHORD FINDER
OFF/ON
SYNCHRO & BREAK
• Use this control to lower the automatic accompaniment
volume when it is too loud relative to your manual performance.
• At the MAX position, the volumes of the automatic
accompaniment parts correspond to their current settings; at the OFF position, the volume is 0. The volume
should normally be set to MAX.
• The set values are shown in the APC column of the volume balance display. (Refer to page 27.)
• The volume can be adjusted for each part. (Refer to page
27.)
• When the position of the slide control coincides with the
actual volume, the indicator is lit. When the volume is
changed by of the PANEL MEMORY or SEQUENCER
playback, the actual volume differs from that indicated by
the position of the slide control. In this case, the indicator
is not lit.
• During SEQUENCER playback or disk DIRECT PLAY,
operation of this slide control affects the total volume of
all the playback parts.
CHORD FINDER
The CHORD FINDER can help, for example,
when you do not know which keys to press to
specify a given chord. When you input the chord
name, the CHORD FINDER shows you which
keys to press and even lets you hear the notes
that make up.
Use the ROOT buttons to select the root note
4.
of the chord. Use the TYPE buttons to select
the type of chord.
• A typical way to finger the specified chord (TYPICAL) is
illustrated on a keyboard diagram.
• Each time the INVERSION button is pressed, different
INVERSION fingerings are illustrated in order. (If there is
no INVERSION fingering for the specified chord, this button is not shown on the display.)
• When the button with a picture of an ear is pressed, the
notes of the chord sound. (The octave of the illustrated
keys and that of the played tones may differ.)
To exit the CHORD FINDER procedure, press
5.
the EXIT button.
BREAK function
With the break function, the rhythm starts when
the left keyboard is played and stops when the
fingers are removed from the keys.
Select an AUTO PLAY CHORD mode.
1.
• At this time, the MEMORY (APC SELECT) button should
be OFF.
Press the SYNCHRO & BREAK button to turn
2.
it on.
Press the AUTO PLAY CHORD’s MODE but-
1.
ton to turn it on.
• The display changes to the following.
Select CHORD FINDER.
2.
• The display changes to the following.
Specify a chord.
3.
• The automatic accompaniment begins to play (synchronized start).
• For the PIANIST mode, play the keys to the left of the
currently set split point.
Release the chord keys.
4.
• The automatic accompaniment stops. When the keys are
pressed again, the rhythm starts from the first beat.
Playing the rhythm
Use the APC MODE button to select the auto-
3.
matic accompaniment mode you will use to
specify chords (BASIC, ADVANCED 1).
• In the list column are shown the chords which can be
specified in each mode.
47
QQTG0701
Part II Playing the rhythm
Fade In/Fade Out
AUTO PLAY CHORD
SPLIT
ONE TOUCH
MAIN
OFF/ON
PLAY
POINT
MODE
VOLUME
MAX
CHORD FINDER
PROGRESSIVE
PIANIST PIANO STYLIST
MIN
1 2 1 2 1 1 2 3 4 BEAT
MUSIC STYLE ARRANGER
VARIATION
DEMO
FADE
APC/SEQUENCER
VOLUME
SOUND
METRONOME
IN OUT
ARRANGER
MAX
SET
OFF
234
FILL IN INTRO & ENDING
SEQUENCER
COUNT
RESET
INTRO
TEMPO / PROGRAM
RHYTHM GROUP
FUNK &
BALLROOM
POP ROCK
SOUL DISCO
POP BALLAD
BALLAD
& SHOW
LATIN &
JAZZ &
WALTZ
WORLD
SWING
& TRADUSA16 BEAT8 BEAT
MEMORY
CONTRAST
LOAD
SYNCHRO & BREAK
START / STOP TAP TEMPO
HELP
OTHER PARTS/TR
-
TRANSPOSE
+
MUTE
DISPLAY HOLD
PAGE
SOUND GROUP
GUITAR &
STRINGS
VOCAL
HARPSI BRASS PLAY
MALLET &
BASS
ORCH PERC
WORLD
EXIT GRAND
UPRIGHT ELECTRIC
Add interest to your performance by starting a part with a fade-in or ending it with a fade-out.
SAX &
ORGAN &
WOODWIND
ACCORDION
PIANO
ORCH
DIGITAL
MIXTURES
MIXTURES
DRAWBARS
DRUM KITS
MODERN SIMPLE PIANO TECHNI-CHORD BANK
PIANO
SEQUENCER
PROGRAM
DISK
EASY
SOUND
MENUS
IN USE
REC
FAVORITES
CONDUCTOR
LEFT RIGHT 2 RIGHT 1
AB
CHORD STEP REC
DIGITAL
EFFECT
C
SET 1 / 5 2 / 6 3 / 7 4 / 8
PANEL MEMORY
DISK
LOAD
MULTI
EFFECT
CHORUS REVERB
P.MEM 5-8
SYNTH
EXPLORER
MEMORY
Playing the rhythm
FADE IN
At the beginning of the song, the volume of each
part rises slowly.
Set up the panel settings for your perform-
1.
ance.
Turn on the FADE IN button.
2.
FADE
IN OUT
• The indicator flashes. In this condition, the volumes for all
parts change to 0 and no sound is produced from this
instrument until the FADE IN is turned off or until step 3 is
executed.
Play the keyboard or press the START/STOP
3.
button.
• The volume slowly builds to its preset level.
• For the fade-in effect for a rhythm part or when playing
back a SEQUENCER performance, turn on the FADE IN
button before pressing the START/STOP button.
• At the end of the fade-in, the FADE IN indicator goes out.
• During the fade-in, FADE IN is shown in the upper right
part of the normal display.
FADE OUT
At the end of the song, the volume of each part
gradually fades to nothing.
Start the performance.
1.
Turn on the FADE OUT button at the point you
2.
want the fade-out to start.
FADE
IN OUT
• The volumes of all the parts slowly fade to 0.
• The indicator flashes to show that fade-out is completed,
and then goes out. The volumes for all parts return to
their specified settings.
• If you wish to interrupt the fade-out, press the FADE OUT
button to turn it off.
FADE SET
Adjust the settings for the FADE IN and FADE
OUT.
Press and hold the FADE IN or FADE OUT
1.
button for a few seconds.
FADE
IN OUT
• The display looks similar to the following.
Use the ▲ and ▼ buttons to select the item.
2.
Use the
ting.
FADE IN
Time:
Specify the time elapsed between 0 volume
to the set volume (1 measure to 16 measure).
FADE OUT
Time:
Specify the time elapsed between the set
volume and 0 volume (1 measure to 16
measure).
Auto Reset:
Specify whether the volume of each part
automatically returns to its specified setting
(ON, OFF).
Rhythm Auto stop:
Specify whether the rhythm turns off after
fade-out is completed (ON, OFF).
SEQ Auto stop:
Specify whether the SEQUENCER playback automatically stops after fade-out is
completed (ON, OFF).
• The display returns to the previous display a few seconds
after you have changed the settings.
• You can also access this display from the CONTROL
MENU display. (Refer to page 120.)
and ∨ buttons to change the set-
∧
48
QQTG0701
Part II Playing the rhythm
Sound Arranger
FADE
AUTO PLAY CHORD
SPLIT
ONE TOUCH
MAIN
OFF/ON
PLAY
POINT
MODE
VOLUME
MAX
CHORD FINDER
PROGRESSIVE
PIANIST PIANO STYLIST
MIN
1 2 1 2 1 1 2 3 4 BEAT
MUSIC STYLE ARRANGER
VARIATION
DEMO
APC/SEQUENCER
VOLUME
SOUND
METRONOME
IN OUT
ARRANGER
MAX
SET
OFF
234
FILL IN INTRO & ENDING
SEQUENCER
COUNT
RESET
INTRO
TEMPO / PROGRAM
RHYTHM GROUP
FUNK &
BALLROOM
POP ROCK
SOUL DISCO
POP BALLAD
BALLAD
& SHOW
LATIN &
JAZZ &
WALTZ
WORLD
SWING
& TRADUSA16 BEAT8 BEAT
MEMORY
CONTRAST
LOAD
SYNCHRO & BREAK
START / STOP TAP TEMPO
HELP
OTHER PARTS/TR
-
TRANSPOSE
+
MUTE
DISPLAY HOLD
PAGE
GUITAR &
STRINGS
VOCAL
HARPSI BRASS PLAY
MALLET &
BASS
ORCH PERC
WORLD
EXIT GRAND
UPRIGHT ELECTRIC
The SOUND ARRANGER feature lets you select other sounds for the AUTO PLAY CHORD parts of
each rhythm.
SOUND GROUP
SAX &
ORGAN &
WOODWIND
ACCORDION
PIANO
ORCH
DIGITAL
MIXTURES
MIXTURES
DRAWBARS
MODERN SIMPLE PIANO TECHNI-CHORD BANK
PIANO
SEQUENCER
PROGRAM
DISK
EASY
SOUND
MENUS
IN USE
REC
FAVORITES
CONDUCTOR
LEFT RIGHT 2 RIGHT 1
AB
CHORD STEP REC
C
SET 1 / 5 2 / 6 3 / 7 4 / 8
PANEL MEMORY
DISK
LOAD
DIGITAL
MULTI
EFFECT
EFFECT
CHORUS REVERB
P.MEM 5-8
SYNTH
EXPLORER
DRUM KITS
MEMORY
Select the rhythm whose sound you wish to
1.
change.
• Do not select the METRONOME or the MEMORY button.
Press and hold the SOUND ARRANGER but-
2.
ton for a few seconds.
SOUND
ARRANGER
SET
• The display looks similar to the following.
Use the ▲ and ▼ buttons to select the part
3.
whose sound you wish to change.
Select the desired sound.
4.
•The DIGITAL EFFECT on/off status can also be speci-
fied (except for DRUMS part).
DIGITAL
EFFECT
• For the DRUMS part, select sounds from the DRUM
KITS group.
• The sound and on/off status of the DIGITAL EFFECT are
shown on the display.
• The sounds marked with # cannot be changed.
Repeat steps 3 and 4 for the other parts as
5.
desired.
• Pressing the ORIGINAL button will reset the sounds to
their original settings.
When you have finished selecting the sounds,
6.
press the EXIT button.
• This display can also be accessed from the SOUND
MENU display. (Refer to page 101.)
Playing back the sounds
Press the SOUND ARRANGER button to turn
1.
it on.
Start the rhythm (automatic accompaniment).
2.
• When the SOUND ARRANGER button is off, the factory-
preset sounds are produced.
• This setting can be set separately for each rhythm.
Playing the rhythm
One Touch Play
AUTO PLAY CHORD
SPLIT
ONE TOUCH
MAIN
POINT
OFF/ON
PLAY
MODE
VOLUME
MAX
CHORD FINDER
PROGRESSIVE
PIANIST PIANO STYLIST
MIN
1 2 1 2 1 1 2 3 4 BEAT
MUSIC STYLE ARRANGER
VARIATION
DEMO
FADE
APC/SEQUENCER
VOLUME
SOUND
METRONOME
IN OUT
ARRANGER
MAX
SET
OFF
234
FILL IN INTRO & ENDING
SEQUENCER
COUNT
RESET
INTRO
TEMPO / PROGRAM
RHYTHM GROUP
FUNK &
BALLROOM
POP ROCK
SOUL DISCO
POP BALLAD
BALLAD
& SHOW
LATIN &
JAZZ &
WALTZ
MEMORY
WORLD
SWING
& TRADUSA16 BEAT8 BEAT
CONTRAST
LOAD
SYNCHRO & BREAK
START / STOP TAP TEMPO
HELP
OTHER PARTS/TR
-
TRANSPOSE
+
MUTE
DISPLAY HOLD
PAGE
GUITAR &
STRINGS
VOCAL
HARPSI BRASS PLAY
MALLET &
BASS
ORCH PERC
WORLD
EXIT GRAND
UPRIGHT ELECTRIC
SOUND GROUP
MIXTURES
PIANO
ONE TOUCH PLAY automatically sets a suggested combination of sounds and an appropriate tempo for
your chosen rhythm style.
Select a rhythm pattern.
1.
• Do not select the METRONOME or the MEMORY button.
Press and hold the ONE TOUCH PLAY button
2.
for a few seconds.
ONE TOUCH
PLAY
• During setting, the style name is shown on the display.
•The AUTO PLAY CHORD and the SYNCHRO & BREAK
are automatically turned on, and the sounds and effects,
volume balances, tempo etc. that are ideal for your
selected rhythm are automatically set.
Play the keyboard.
3.
• When you specify a chord, the automatic
rhythm begins to play immediately.
SAX &
ORGAN &
WOODWIND
ACCORDION
SYNTH
PIANO
ORCH
DIGITAL
MIXTURES
DRAWBARS
DRUM KITS
MODERN SIMPLE PIANO TECHNI-CHORD BANK
SEQUENCER
EASY
PROGRAM
CONDUCTOR
LEFT RIGHT 2 RIGHT 1
AB
REC
FAVORITES
CHORD STEP REC
C
SET 1 / 5 2 / 6 3 / 7 4 / 8
PANEL MEMORY
DISK
MENUS
IN USE
DISK
LOAD
DIGITAL
MULTI
EFFECT
EFFECT
CHORUS REVERB
P.MEM 5-8
SOUND
EXPLORER
MEMORY
49
QQTG0701
Part II Playing the rhythm
Piano Stylist
SPLIT
MAIN
POINT
VOLUME
MAX
PROGRESSIVE
MIN
MUSIC STYLE ARRANGER
DEMO
FADE
AUTO PLAY CHORD
APC/SEQUENCER
VOLUME
ONE TOUCH
SOUND
METRONOME
OFF/ON
PLAY
MODE
CHORD FINDER
PIANIST PIANO STYLIST
12 1 2 1 1234BEAT
VARIATION
POP ROCK
IN OUT
ARRANGER
MAX
SET
OFF
234
FILL IN INTRO & ENDING
SYNCHRO & BREAK
SEQUENCER
COUNT
RESET
INTRO
RHYTHM GROUP
FUNK &
SOUL DISCO
WALTZ
& TRADUSA16 BEAT8 BEAT
START / STOP TAP TEMPO
SAX &
ORGAN &
WOODWIND
ACCORDION
PIANO
ORCH
DIGITAL
MIXTURES
MIXTURES
DRAWBARS
MODERN SIMPLE PIANO TECHNI-CHORD BANK
PIANO
SEQUENCER
EASY
PROGRAM
CONDUCTOR
LEFT RIGHT 2 RIGHT 1
AB
REC
FAVORITES
CHORD STEP REC
C
SET 1 / 5 2 / 6 3 / 7 4 / 8
PANEL MEMORY
DISK
MENUS
IN USE
DISK
LOAD
DIGITAL
MULTI
EFFECT
EFFECT
CHORUS REVERB
P.MEM 5-8
SOUND
SYNTH
EXPLORER
DRUM KITS
MEMORY
DISPLAY HOLD
PAGE
GUITAR &
STRINGS
VOCAL
HARPSI BRASS PLAY
MALLET &
BASS
ORCH PERC
WORLD
EXIT GRAND
UPRIGHT ELECTRIC
SOUND GROUP
TEMPO / PROGRAM
BALLROOM
POP BALLAD
BALLAD
& SHOW
LATIN &
JAZZ &
MEMORY
WORLD
SWING
CONTRAST
LOAD
HELP
OTHER PARTS/TR
-
TRANSPOSE
+
MUTE
This feature automatically launches the appropriate instrument settings when you select the style of the
arrangement you wish to play in. By using this feature, you can easily achieve a performance like that of a
first-rate pianist.
PIANO STYLES
Select a suitable style for your performance
based principally on the piano sound.
Press the PIANO STYLIST button to turn it on.
1.
PIANO STYLIST
• The display looks similar to the following.
Play the keyboard.
6.
• When you specify a chord on the left area of the keyboard, the automatic accompaniment begins to play.
• You can use the TEMPO/PROGRAM dial to adjust the
tempo.
When you are finished selecting the style, turn
7.
the PIANO STYLIST button off.
ENSEMBLE STYLES
Select a style suitable for an ensemble performance that uses the many sounds and rhythms
incorporated in this instrument.
Playing the rhythm
Press the PIANO STYLES button.
2.
• The display looks similar to the following.
Use the ARRANGE MODE button to select
3.
the desired type of arrangement.
• Select the type you wish to play (PIANO SOLO/PIANO &
COMBO/PIANO & ENSEMBLE).
Use the SELECT MODE button to specify how
4.
you wish to select a style.
GENRE: Select a style by musical genre.
ERA: Select a style by era.
ALPHABET: Select a style from an alphabetical list.
Use the GENRE/ERA/ALPHABET button
5.
below the display to select a group. Use the
STYLE button to select a style.
• In the above example, GENRE was selected.
• If the list covers more than one screen “page,” the MORE
button is shown on the display. Use the MORE button to
switch between screen pages.
On the PIANO STYLIST display, press the
1.
ENSEMBLE STYLES button.
• The display looks similar to the following.
Use the GROUP button the select a style
2.
group.
• These are the same as the groups for the RHYTHM
GROUP button.
Use the RHYTHM button to select a rhythm,
3.
and the STYLE button to select a style.
•The AUTO PLAY CHORD and SYNCHRO & BREAK
turn on, and the sounds, effects, rhythm, tempo, volume
balance etc. which are best suited for the selected music
style are automatically selected.
Play the keyboard.
4.
• When you specify a chord on the left area of the keyboard, the automatic accompaniment immediately begins
to play.
• You can use the TEMPO/PROGRAM dial to adjust the
tempo.
When you are finished selecting the style, turn
5.
the PIANO STYLIST button off.
•The AUTO PLAY CHORD and SYNCHRO & BREAK
turn on, and the sounds, effects, rhythm, tempo, volume
balance, etc. which are best suited for the selected music
style are automatically selected.
50
QQTG0701
Part II Playing the rhythm
MUSIC STYLE ARRANGER
VARIATION
1234
Music Style Arranger
AUTO PLAY CHORD
SPLIT
ONE TOUCH
MAIN
POINT
OFF/ON
PLAY
MODE
VOLUME
MAX
CHORD FINDER
PROGRESSIVE
PIANIST PIANO STYLIST
MIN
1 2 1 2 1 1 2 3 4 BEAT
MUSIC STYLE ARRANGER
VARIATION
DEMO
FADE
APC/SEQUENCER
VOLUME
SOUND
METRONOME
POP ROCK
IN OUT
ARRANGER
MAX
SET
OFF
234
FILL IN INTRO & ENDING
SEQUENCER
COUNT
RESET
INTRO
TEMPO / PROGRAM
RHYTHM GROUP
FUNK &
BALLROOM
SOUL DISCO
POP BALLAD
BALLAD
& SHOW
LATIN &
JAZZ &
WALTZ
MEMORY
WORLD
SWING
& TRADUSA16 BEAT8 BEAT
CONTRAST
LOAD
SYNCHRO & BREAK
START / STOP TAP TEMPO
HELP
OTHER PARTS/TR
-
TRANSPOSE
+
MUTE
DISPLAY HOLD
PAGE
GUITAR &
STRINGS
VOCAL
HARPSI BRASS PLAY
MALLET &
BASS
ORCH PERC
WORLD
EXIT GRAND
UPRIGHT ELECTRIC
SOUND GROUP
SAX &
ORGAN &
WOODWIND
ACCORDION
PIANO
ORCH
DIGITAL
MIXTURES
MIXTURES
DRAWBARS
MODERN SIMPLE PIANO TECHNI-CHORD BANK
PIANO
SEQUENCER
PROGRAM
DISK
EASY
SOUND
MENUS
IN USE
REC
FAVORITES
CONDUCTOR
LEFT RIGHT 2 RIGHT 1
AB
CHORD STEP REC
DIGITAL
EFFECT
C
SET 1 / 5 2 / 6 3 / 7 4 / 8
PANEL MEMORY
DISK
LOAD
MULTI
EFFECT
CHORUS REVERB
P.MEM 5-8
SYNTH
EXPLORER
DRUM KITS
MEMORY
The MUSIC STYLE ARRANGER helps you to make professional registration changes during your performance. Select between four contrasting registrations at the push of a button, or let your instrument
change the registration automatically for you when you use FILL IN 1 or 2. The MUSIC STYLE
ARRANGER will also alter the accompaniment in character with the registration change creating a polished sounding arrangement.
How to use the MUSIC STYLE
ARRANGER
Select a rhythm pattern.
1.
• Do not select the METRONOME or the MEMORY button.
Press the MUSIC STYLE ARRANGER button
2.
to turn it on.
• Each time the FILL IN 1 button is pressed, the FILL IN 1
pattern plays, and then the music style changes in the 4
➝ 3 ➝ 2 ➝ 1 order. And each time the FILL IN 2 button is
pressed, the FILL IN 2 pattern plays, and then the style
changes in the 1 ➝ 2 ➝ 3 ➝ 4 order.
MUSIC STYLE ARRANGER mode
䡲䡲䡲䡲
You can define which panel settings change by
pressing a FILL IN button when the MUSIC
STYLE ARRANGER is used.
MUSIC STYLE ARRANGER
Press and hold the MUSIC STYLE AR-
1.
RANGER button for a few seconds.
• The display changes to the following.
Use the VARIATION buttons to select a style
3.
(1 to 4).
• The nuance of the pattern differs with each number.
• The panel settings (including the tempo) change accord-
ing to the selected rhythm and music style. The AUTO
PLAY CHORD, the MEMORY and the SYNCHRO &
BREAK button are automatically turned on. When a key
on the left section of the keyboard is pressed, the automatic rhythm begins to play immediately.
• During your performance, the style can be changed, but
the tempo does not change.
How to change the music style
during your performance
While you are playing the keyboard with the
MUSIC STYLE ARRANGER on, press the FILL
IN 1 or FILL IN 2 button.
12
FILL IN
SEQUENCER
COUNT
RESET
INTRO
Select the mode.
2.
RHYTHM:
Only the rhythm changes.
SOUND & RHYTHM:
The sound, effects, rhythms, etc. change.
PANEL MEMORY:
The PANEL MEMORY number (BANK A: 1 to
4) changes. You can store your desired panel
settings in the PANEL MEMORY beforehand
and switch from one to another quickly.
• After a few seconds, the display exits the setting mode.
• You can also access this setting display from the CON-
TROL MENU display. (Refer to page 120.)
Playing the rhythm
51
QQTG0701
Part II Playing the rhythm
Panel Memory
AUTO PLAY CHORD
SPLIT
ONE TOUCH
MAIN
POINT
OFF/ON
PLAY
MODE
VOLUME
MAX
CHORD FINDER
PROGRESSIVE
PIANIST PIANO STYLIST
MIN
1 2 1 2 1 1 2 3 4 BEAT
MUSIC STYLE ARRANGER
VARIATION
DEMO
FADE
APC/SEQUENCER
VOLUME
SOUND
METRONOME
POP ROCK
IN OUT
ARRANGER
MAX
SET
OFF
234
FILL IN INTRO & ENDING
SEQUENCER
COUNT
RESET
INTRO
TEMPO / PROGRAM
RHYTHM GROUP
FUNK &
BALLROOM
SOUL DISCO
POP BALLAD
BALLAD
& SHOW
LATIN &
JAZZ &
WALTZ
MEMORY
WORLD
SWING
& TRADUSA16 BEAT8 BEAT
CONTRAST
LOAD
SYNCHRO & BREAK
START / STOP TAP TEMPO
HELP
OTHER PARTS/TR
-
TRANSPOSE
+
MUTE
DISPLAY HOLD
PAGE
GUITAR &
STRINGS
VOCAL
HARPSI BRASS PLAY
MALLET &
BASS
ORCH PERC
WORLD
EXIT GRAND
UPRIGHT ELECTRIC
SOUND GROUP
SAX &
ORGAN &
WOODWIND
ACCORDION
PIANO
ORCH
DIGITAL
MIXTURES
MIXTURES
DRAWBARS
MODERN SIMPLE PIANO TECHNI-CHORD BANK
PIANO
SEQUENCER
PROGRAM
DISK
EASY
SOUND
MENUS
IN USE
REC
FAVORITES
CONDUCTOR
LEFT RIGHT 2 RIGHT 1
AB
CHORD STEP REC
C
SET 1 / 5 2 / 6 3 / 7 4 / 8
PANEL MEMORY
DISK
LOAD
DIGITAL
MULTI
EFFECT
EFFECT
CHORUS REVERB
P.MEM 5-8
SYNTH
EXPLORER
DRUM KITS
MEMORY
PANEL MEMORY stores all the current panel settings so you can recall them at the push of a button.
How to store the panel settings
• You can use the bank names on PAGE 1/2 to select the
bank.
By storing all the panel settings you use for a
song in the same bank, for example, you can
switch from one panel setup to the next in a
Assign a name to the bank/memory
flash.
You can assign names to the banks and memo-
Set up the desired panel settings (sounds, vol-
1.
ries.
umes, etc.)
Select one of the numbered buttons marked
1.
Use the BANK button to select a bank (A, B,
2.
C).
C
AB
BANK SET
PANEL MEMORY and hold it down for several seconds.
Playing the rhythm
• Lighting up both the A and B indicators enables C to be
selected.
With the SET button held down, press one of
3.
the numbered buttons of the PANEL
MEMORY (1 to 8).
C
AB
BANK SET 1 / 5 2 / 6 3 / 7 4 / 8
PANEL MEMORY
• Turning the P.MEM 5-8 button ON enables the selection
of panel settings for numbers 5 to 8.
• The panel settings are now stored in the specified bank
and number.
BANK VIEW
䡲䡲䡲䡲
P.MEM 5-8
Select one of the numbered buttons marked
PANEL MEMORY and hold it down for several
seconds to check the 8 memory names of the
selected bank.
Press the BANK NAMING button to assign a
2.
name to the bank, or the MEMORY NAMING
button for the memory.
• The display looks similar to the following.
Use the buttons below the display to assign a
3.
name.
• Set the character input position with the POSITION buttons, select the characters with the alphanumeric buttons
and repeat name assignment.
• Switch from upper to lower case letters with the ABC, abc
button.
• Use the !#$ button to switch to the symbols character set.
• Press the INS button to enter a space at the cursor posi-
tion.
• Press the DEL button to erase the character at the cursor
position.
• Press the CLR button to erase the entire name.
• Press the →← button to center the name.
• You can use the BANK ∧ and ∨ buttons to view other
banks.
52
QQTG0701
When you have finished assigning the name,
4.
press the OK button.
Part II Playing the rhythm
Use the ∧ and ∨ buttons to select the item.
Recall the panel setup
Use the BANK button to select a bank (A, B,
1.
C).
Press the desired PANEL MEMORY number
2.
button (1 to 8).
• Turning the P.MEM 5-8 button ON enables the selection
of panel settings for numbers 5 to 8.
• The panel setup changes to the one stored in the specified memory.
• You can then change the sound settings, etc. manually;
however, the contents of the memory remain unchanged
until you store them again.
• The currently selected bank, memory number and memory name are shown in the top line on the normal display.
2.
Use the ON and OFF buttons to store the on
3.
or off status for the selected item.
PANEL MEMORY mode
You can define which panel settings are recalled
when the PANEL MEMORY is used.
Press and hold the SET button for a few sec-
1.
onds.
• The display changes to the following.
Select the mode.
2.
NORMAL:
The sounds and volume balance, and CON-
DUCTOR status are stored.
EXPAND:
All the instrument’s settings are stored, including the rhythm (except for SOUND ARRANGER
on/off status), TRANSPOSE, tempo, etc.
• After a few seconds, the display exits the setting mode.
EXPAND MODE FILTER
䡲䡲䡲䡲
You can specify which data is stored in the
EXPAND mode.
Use the PAGE buttons to access the PAGE
1.
2/3–3/3 EXPAND MODE FILTER display.
• The display looks similar to the following.
Playing the rhythm
53
QQTG0701
Part III Sequencer
Outline of the Sequencer
AUTO PLAY CHORD
SPLIT
ONE TOUCH
MAIN
POINT
OFF/ON
PLAY
MODE
VOLUME
MAX
CHORD FINDER
PROGRESSIVE
PIANIST PIANO STYLIST
MIN
1 2 1 2 1 1 2 3 4 BEAT
MUSIC STYLE ARRANGER
VARIATION
DEMO
FADE
APC/SEQUENCER
VOLUME
SOUND
METRONOME
POP ROCK
IN OUT
ARRANGER
MAX
SET
OFF
234
FILL IN INTRO & ENDING
SEQUENCER
COUNT
RESET
INTRO
TEMPO / PROGRAM
RHYTHM GROUP
FUNK &
BALLROOM
SOUL DISCO
POP BALLAD
BALLAD
& SHOW
LATIN &
JAZZ &
WALTZ
WORLD
SWING
& TRADUSA16 BEAT8 BEAT
MEMORY
CONTRAST
LOAD
SYNCHRO & BREAK
START / STOP TAP TEMPO
HELP
OTHER PARTS/TR
-
TRANSPOSE
+
MUTE
DISPLAY HOLD
PAGE
SOUND GROUP
GUITAR &
STRINGS
VOCAL
HARPSI BRASS PLAY
MALLET &
BASS
ORCH PERC
WORLD
EXIT GRAND
UPRIGHT ELECTRIC
PIANO
MIXTURES
PIANO
SAX &
ORGAN &
SOUND
WOODWIND
ACCORDION
SYNTH
EXPLORER
ORCH
DIGITAL
MIXTURES
DRAWBARS
DRUM KITS
MEMORY
MODERN SIMPLE PIANO TECHNI-CHORD BANK
CONDUCTOR
LEFT RIGHT 2 RIGHT 1
AB
SEQUENCER
EASY
REC
FAVORITES
CHORD STEP REC
DIGITAL
EFFECT
C
SET 1 / 5 2 / 6 3 / 7 4 / 8
PANEL MEMORY
PROGRAM
DISK
MENUS
IN USE
DISK
LOAD
MULTI
EFFECT
CHORUS REVERB
P.MEM 5-8
A sequencer records your performance in a similar way to a tape recorder. This instrument’s
SEQUENCER allows you to record up to 10 performances in a variety of ways. You may want to record
your entire performance in one go (especially if you are using AUTO PLAY CHORD to provide the
accompaniment), or to build up a complex arrangement with several different parts playing together, like
an orchestral score. This instrument’s SEQUENCER has 16 tracks. This means that you can record 16
different parts. However, you don’t have to use all 16 tracks. For some uses you may only need to use
one or two tracks. This instrument’s SEQUENCER enables you to edit your recorded performance. Unlike
a tape recorder you can change the sound or the tempo during playback, or correct wrong notes or timing
errors.
SEQUENCER features
You can change the tempo without
changing the pitch
When you record your performance at a slow
tempo and play it back at a faster tempo, the
pitch stays the same.
Consistent sound
Popular features
Simplified recording method
EASY RECORD is a feature that allows you to
bypass the more complex recording procedures
so you can record and play back your performance quickly and easily.
• You can also record an accompaniment from the AUTO
PLAY CHORD.
Your performance is reproduced by a sound
Create a one-man ensemble
module as it reads digital data. So, unlike a
recorded tape, the sound never deteriorates no
matter how many times you play back your performance.
Use the REALTIME RECORD function to record
your performance in up to 16 tracks and create
your own orchestra or band.
Sequencer
Edit your recorded performance
Comprehensive editing functions allow you to
modify your recorded performance. Data can
easily be erased, corrected or copied, providing
an especially convenient tool for creating your
original tunes.
Instant search
A recorded tape has to be rewound, but digital
action means you can return to the beginning of
your performance, or find any measure, instantly.
Store individual data to create your song
For repeating patterns or those especially complicated phrases, the STEP RECORD feature is
convenient for recording the notes one-by-one.
Memory capacity
Up to 10 songs can be stored in the
SEQUENCER. Expressed in terms of notes, the
total number of notes which can be stored in all
the SEQUENCER songs and tracks is about
40,000. The remaining memory available for
recording is shown on the display as a percentage (MEMORY= %).
• When “Memory full!” appears on the display, no more
data can be stored in the SEQUENCER.
54
QQTG0701
Part III Sequencer
SEQUENCER menu
The configuration of the SEQUENCER setting
display is as follows.
Press the PROGRAM MENUS button to turn it
1.
on.
PROGRAM
MENUS
• The display looks similar to the following.
Select SEQUENCER.
2.
• The display looks similar to the following.
<RECORD & EDIT>
<COPY & PASTE>
<RANGE EDIT>
∧
•The SONG
• You can press the NAMING button and assign a name to
the song. (Refer to page 63.)
• You can press the PANEL WRITE button to store the current settings of the instrument at the beginning of the
song. (Refer to page 63.)
Select RECORD & EDIT, COPY & PASTE or
3.
and ∨ buttons are used to select a song.
RANGE EDIT, and follow the corresponding
procedure.
Sequencer
55
QQTG0701
Part III Sequencer
Summary of the SEQUENCER menu items
About the measure count
Sequencer
RECORD & EDIT
These functions are recording and editing
operations used for creating a new performance.
REALTIME RECORD (page 59)
Record each part of your performance just
as you play it on the keyboard.
PUNCH RECORD (page 64)
Correct a selected portion of your recorded
performance.
STEP RECORD (page 65)
Store the sounds note-by-note on the display.
• You can also store the chord, control or rhythm pro-
gression for the AUTO PLAY CHORD.
TRACK ASSIGN (page 70)
Assign parts to tracks.
QUANTIZE (page 71)
Correct the timing of your performance.
SONG SELECT (page 64)
Select a song.
SONG CLEAR (page 72)
Erase all the recorded data of a song.
TRACK CLEAR (page 72)
Erase the contents of a specific track.
NOTE EDIT (page 73)
Store and correct performance (NOTE)
data on a piano roll display.
DRUM EDIT (page 74)
Store and correct DRUMS part data on a
special display.
COPY & PASTE
Copy recording data and paste it to the
desired location.
TRACK COPY (page 75)
Copy data of specific tracks.
SONG COPY (page 75)
Copy data of specific songs.
TRACK MERGE (page 76)
Merge the recorded contents of two tracks
and store in a third track.
TRACK CLEAR (page 72)
Erase the contents of a specific track.
SONG CLEAR (page 72)
Erase all the recorded data of a song.
MEASURE COPY (page 76)
Copy the contents of specific measures.
MEASURE ERASE (page 76)
Erase the contents of specific measures.
MEASURE DELETE (page 77)
Delete specific measures from the performance.
MEASURE INSERT (page 77)
Insert additional measures in the performance.
APC TO SMF CONVERT (page 78)
Save automatic accompaniment patterns
data in a Standard MIDI File (SMF).
RANGE EDIT
Change the note position etc. in the recorded
data.
QUANTIZE (page 71)
Correct the timing of your performance.
NOTE CHANGE (page 78)
Change the pitch of specific notes.
VELOCITY CHANGE (page 79)
Modify the recorded velocity (how hard the
keyboard was played) of performance data.
TRANSPOSE (page 79)
Change the key of the performance data.
ADVANCE/DELAY (page 79)
Speed up or delay the sound production of
performance data.
The measure count on the display corresponds to the time signature of the selected rhythm. However,
if rhythm data is stored in the RHYTHM part and that part is played back, the measure count on the display corresponds to the stored rhythm data. (Refer to page 69.)
• If you wish to use a time signature not available in the preset rhythms, use the COMPOSER to create a new time signature.
(Refer to page 82.)
56
QQTG0701
Part III Sequencer
Sequencer parts
The following summary explains what is stored in each SEQUENCER part.
Part name
[name on display]
RIGHT1 [RT1]
RIGHT2 [RT2]
LEFT [LFT]
PART1 [P 1]
–PART9 [P 9]
PART11 [P 11]
–PART16 [P16]
Recording the performance of each part
(REALTIME/STEP)
Used for Recorded contents
• Sound and volume settings
• PART EXPRESSION
• Contents of sound and effect settings that can be set
on the MIXER display (Refer to page 104.)
• PITCH BEND, MODULATION data
• Pedal operation
DRUMS [DRM]
(PART 10)
CONTROL [CTL] Recording changes in
AUTO PLAY CHORD
[APC]
CHORD [CHD] Recording chord
Recording the drums
performance with the
DRUM KITS group
sounds (REALTIME/STEP)
the panel button status
(REALTIME/STEP)
Recording chords for the
AUTO PLAY CHORD
(REALTIME)
progression for the
AUTO PLAY CHORD
(STEP)
• Sound and volume settings
• PART EXPRESSION
• Contents of sound and effect settings that can be set
on the MIXER display (Refer to page 104.)
• Rhythm setting and selection changes
• RHYTHM VARIATION 1–4 setting
• REVERB on/off
• AUTO PLAY CHORD status, volume balance
• MUSIC STYLE ARRANGER status
• FILL IN 1, 2, INTRO & ENDING 1, 2 on
• PANEL MEMORY selection changes
• TRANSPOSE status
• TECHNI-CHORD status
• START/STOP on/off
• TEMPO setting
• CONDUCTOR status
• FADE IN/OUT operation
• TOTAL EXPRESSION
• Chord progression
• AUTO PLAY CHORD status, volume balance
• START/STOP on/off
• FILL IN 1, 2, INTRO & ENDING 1, 2 on
• Chord progression
• FILL IN 1, 2, INTRO & ENDING 1, 2 on
RHYTHM [RHY] Settings related to
rhythm (STEP)
• You can use the TRACK ASSIGN function to assign parts to tracks as you wish. (Refer to page 70.)
• Those items above which are not operations available with this instrument can be recorded only from MIDI input.
• Rhythm settings and selection changes
• RHYTHM VARIATION 1–4 setting
• FILL IN 1, 2, INTRO & ENDING 1, 2 on
• START/STOP on/off
• TEMPO setting
Sequencer
57
QQTG0701
Part III Sequencer
Easy Record
Suppose you are playing your instrument and you wish to record and play back your performance to hear
how it sounds. You can bypass the set-up procedures of the full-scale sequencer and begin recording
quickly and easily.
• Note that by executing EASY REC, the original data in the selected song number is erased.
Recording procedure
Press the EASY REC button to turn it on.
1.
SEQUENCER
EASY
PLAY
REC
CHORD STEP REC
• The display changes to the following.
Use the SONG ∧ and ∨ buttons to select the
2.
song number in which to record (1 to 10).
• If you press the NAMING button, you can assign a name
to your song. (Refer to page 63.)
Set the desired sounds, effects, rhythms, etc.
3.
Press the OK button.
4.
• The display changes to the REALTIME RECORD display.
Play the keyboard.
5.
• Recording begins as soon as you start the rhythm or play
the keyboard.
When you have finished recording, press the
6.
EASY REC button to turn it off.
•The PLAY button turns on.
Sequencer
Playback
Press the SEQUENCER RESET (FILL IN 1)
1.
button.
1
FILL IN
SEQUENCER
RESET
Press the START/STOP button.
2.
• Your recorded performance is played back automatically.
• When you are finished playing back your performance,
press the SEQUENCER PLAY button to turn it off.
58
QQTG0701
Part III Sequencer
Realtime Record
With REALTIME RECORD, your performance is recorded with the timing exactly as you played it on the
keyboard. Use this mode to record your performance in up to 16 tracks and create your own orchestra or
band.
Recording procedure
Press the PROGRAM MENUS button to turn it
1.
on.
• The display changes to the following.
Select SEQUENCER.
2.
• The display looks similar to the following.
• When you press the PANEL WRITE button, the PANEL
WRITE display appears. To store the currently active settings, such as the sounds, at the beginning of the song,
press the OK button.
• The display looks similar to the following.
Use the buttons below the display to turn on
6.
the “REC” indication above the track numbers
you are going to record.
• While you are recording, you can play back tracks which
are already recorded. Press the corresponding balance
buttons to display “PLAY” above the track number you
wish to have played back.
•For the RIGHT 1, RIGHT 2 and LEFT parts, you can
select two or more tracks to record at one time; however,
to record a performance part, the corresponding button in
the CONDUCTOR must also be on. For parts that are not
in the CONDUCTOR, multiple parts cannot be recorded
at one time.
• To record AUTO PLAY CHORD (APC) parts, turn on the
AUTO PLAY CHORD’s OFF/ON button. In this case,
press the START/STOP button when beginning recording.
• The track for the RHYTHM (RHY) part can be selected
for recording only when STEP RECORD is active.
Use the SONG ∧ and ∨ buttons to select a
3.
song number in which to record. (The song
number is shown on the display.)
Select RECORD & EDIT.
4.
• The display looks similar to the following.
Select REALTIME RECORD.
5.
Set the sounds, effects, volumes, etc. for the
7.
parts you are going to record.
• If you press the MIXER button, you can use the MIXER
display to visually adjust the settings for each track.
• The LOCAL ON/OFF setting on the MIXER display is
used to specify whether the part assigned to that track
sounds when it is played on the keyboard during recording. For the LOCAL ON/OFF during playback, use the
TRACK ASSIGN display to adjust the settings. (Refer to
page 70.)
• If you are recording GM2 song data, select from the GM2
group in the SOUND EXPLORER.
• The panel settings which are active at the beginning of
recording are stored.
Use the TEMPO/PROGRAM to adjust the
8.
recording tempo.
• The tempo is shown on the display as q =.
• If you wish to record the tempo setting and tempo
changes, store them in the control (CTL) part, or use the
step record to store them in the rhythm (RHY) part.
Turn the metronome on or off as desired with
9.
the ON/OFF button at the upper right of the
display.
• The metronome selection alternates between ON and
OFF each time the button is pressed.
• When set to ON, the metronome volume setting display is
momentarily shown.
• The metronome sound is not recorded.
(Continued on the next page)
Sequencer
59
QQTG0701
Part III Sequencer
START
CYCLE END MEASURE: 4
1234
END
Play the keyboard.
10.
• Recording begins.
• You can also press the START/STOP button to start the
rhythm and begin recording.
• If the metronome is on, when you press the
START/STOP button, a two-measure count plays, after
which recording automatically begins. In this case, the
rhythm does not start. Recording does not start until the
two-measure count is completed.
• The recording status is continuously updated on the display:
MEASURE= indicates the current measure.
TIME SIG.= indicates the current time signature.
MEMORY= indicates the remaining memory (%) avail-
able for recording.
• If you wish to redo the recording, press the REC STOP
button and then record again. To change the sounds and
effects, etc. please set them again.
• If you make a mistake in recording, you can correct a
specific portion of your performance without having to
redo the whole part. (Refer to page 64.)
When you have finished recording, press the
11.
REC STOP button on the display, or turn off
the PROGRAM MENUS button.
• When the PROGRAM MENUS button is turned off, the
ending command (END) is recorded. Note that, as long
as the ending command is not recorded, blank recording
continues even if you stop playing.
• The SEQUENCER PLAY button turns on.
CYCLE RECORD
This mode allows you to have specified recording measures continuously repeated. Thus you
can record measures by adding notes during any
cycle.
On the REALTIME RECORD display, specify
1.
“REC” for a track number you are going to
record, and “PLAY” for track numbers you
wish to have played back.
Press the CYCLE: OFF button.
2.
• The display looks similar to the following.
Use the START MEASURE ∧ and ∨ buttons
3.
to specify the beginning measure number.
Use the END MEASURE ∧ and ∨ buttons to
4.
specify the ending measure number.
• The measure in which the END command has been
stored can also be specified.
Sequencer
Multi-track recording
Use the following procedure to record one track
while listening to the track or tracks already
recorded.
Follow the procedure to record the first track,
1.
and press the REC STOP button at the end of
the recording.
• The indication for the track just recorded changes from
“REC” to “PLAY”.
Turn on the “REC” indication for the track you
2.
wish to record next, and select the sounds and
effects, etc.
Press the START/STOP button and begin
3.
recording.
• Tracks for which “PLAY” is shown are played back, and
you can record in time with this.
• If you turn on the “REC” for the CONTROL track and
begin recording, the rhythm start will not be recorded.
Press the REC STOP button at the end of the
4.
recording.
Repeat steps 2 to 4 for other tracks, as
5.
desired.
Press the START/STOP button.
5.
• If the metronome is on, cycle recording of the specified
measures begins after a two-measure count.
Play the keyboard.
6.
• The specified measures are repeated, during which time
you can record by adding notes little by little at the correct
timing (over-dubbing).
• If you wish to erase all the performance data from the
specified measures, press the CLEAR button.
• If the CYCLE: ON button is pressed, it changes to OFF.
This button does not function during recording.
• To return to the REALTIME RECORD display, press the
EXIT button.
• Cycle record can also be started from the REALTIME
RECORD display whenever the CYCLE: ON indication is
shown.
When you have finished recording, press the
7.
REC STOP button on the display, or turn off
the PROGRAM MENUS button.
When multi-track recording is finished, turn off
6.
the PROGRAM MENUS button.
• If you wish to store part settings that you modified after
recording as beginning song data, press the MIXER button and follow the PANEL WRITE procedure. (Refer to
page 63.)
60
QQTG0701
Part III Sequencer
Sequencer Play
Play back your recorded performance.
Press the SEQUENCER PLAY button to turn
1.
it on.
SEQUENCER
EASY
PLAY
REC
CHORD STEP REC
• The display looks similar to the following.
After pressing the SONG button, use the
2.
SONG
and ∨ buttons to select a song num-
∧
ber for playback.
Use the balance buttons below the display to
3.
show “PLAY” above the track numbers you
wish to have played back.
• Highlighted track numbers indicate tracks that are
already recorded. Only highlighted track numbers can be
selected for playback.
• You can select two or more tracks to play back at one
time.
If you want to playback a song starting from a
5.
point other than the first measure, use the
MEAS
and ∨ buttons to specify the measure
∧
number.
•“MEASURE=” indicates the current measure number.
Press the START/STOP button.
6.
• The recorded performance is played back from the specified measure.
• When playback is begun from a measure in which an
INTRO, COUNT INTRO, FILL IN or ENDING is recorded,
the corresponding function does not work.
• You can press the MIXER button and modify the settings
for each part.
• For information about LYRICS, refer to page 91.
To stop playback, press the START/STOP
7.
button.
• If the START/STOP button is pressed again, playback
will continue from the point it was interrupted.
When you are finished playing back your per-
8.
formance, press the SEQUENCER PLAY button to turn it off.
If a rhythm progression has been recorded in
the RHYTHM (RHY) part, the MEASURE display used in the STEP RECORD and EDIT
displays conforms to the time signature data
stored in the RHYTHM part.
Press the SEQUENCER RESET (FILL IN 1)
4.
button.
• The SEQUENCER returns to the beginning of the song
and the beginning panel settings are recalled.
Adjusting the playback tempo
Even with a song having recorded tempo data, you can use TEMPO/PROGRAM or TAP TEMPO to
adjust the tempo to your liking.
• When the tempo is changed, all the tempo data of that song is automatically changed by the same ratio. Accordingly, even in
song data in which tempo change data is stored, a single adjustment of the tempo produces a natural-sounding playback.
• To return to the original tempo, while the song is stopped press the SEQUENCER RESET button. Note that the tempo
change is also canceled when you switch to another song or load a new song.
• The adjusted tempo is canceled when you begin the recording procedure and the original tempo data will be recorded.
Sequencer
61
QQTG0701
Part III Sequencer
START
CYCLE END MEASURE: 4
1234
END
CYCLE PLAY
You can have specified measures played back
repeatedly.
On the SEQUENCER PLAY display, specify
1.
“PLAY” for track numbers you wish to have
played back.
Press the CYCLE button.
2.
• The display looks similar to the following.
Use the START MEASURE ∧ and ∨ buttons
3.
to specify the beginning measure number.
Use the END MEASURE ∧ and ∨ buttons to
4.
specify the ending measure number.
• The measure in which the END command has been
stored can also be specified.
• The display looks similar to the following.
Specify the order of songs in the medley.
2.
• If ALL is pressed, all the files are selected, and the songs
are played back in order in a medley. If ALL is pressed
again, the files are deselected.
• You can use the buttons below the display to select a
song to add to the song list, then press the ADD button to
add it to the list. Repeat these steps to create your own
list of songs to have played back. M01, M02 etc. next to
the file name indicates its order in the list.
• You can delete a marked file from the medley song list by
selecting it and pressing the ADD button.
• Use the LOOP button to specify ON or OFF for repeat
playback of the medley.
Press the START button.
3.
• During medley playback, you can use the SKIP button to
skip to the next song.
Sequencer
Press the START/STOP button.
5.
• Cycle playback of the specified measures begins.
• Normally the rhythm pattern is not played back.
To stop cycle playback, press the START/
6.
STOP button again.
• During playback stop, if the SEQUENCER RESET (FILL
IN 1) button is pressed, the SEQUENCER returns to the
measure number specified in step 3. If the SEQUENCER
RESET button is pressed again, the SEQUENCER
returns to measure 1.
• If you press the CYCLE: ON button to turn it OFF, cycle
playback is not possible.
• To return to the SEQUENCER PLAY display, press the
EXIT button.
• Cycle playback can also be specified on the
SEQUENCER PLAY display whenever the CYCLE: ON
indication is shown.
MEDLEY
Recorded songs can be played back in a medley.
On the SEQUENCER PLAY display, press the
1.
MEDLEY button.
SEQUENCER VOLUME
When playing the keyboard along with a
recorded performance, you can adjust the total
volume of all the playback parts as one.
⇒ Use the APC/SEQUENCER VOLUME slide
control to adjust the volume.
APC/SEQUENCER
VOLUME
MAX
OFF
• Use this control to lower the volume of the recorded playback parts when it is too loud relative to the volume of
your manual performance.
• The volume of all sounds other than your manual performance—MIDI input, etc.—is lowered.
• At the MAX position, the volume of the playback parts
correspond to their current settings; at the OFF position,
the volume is 0.
• The volume can be adjusted for each part. (Refer to page
27.)
• Except during SEQUENCER playback or DIRECT PLAY
of a disk, this slide control adjusts the total volume of all
the automatic accompaniment parts.
• During SEQUENCER recording, the volume is automati-
cally at its maximum regardless of the position of the
slide control. During playback, however, lowering the
slide control from the MAX position will lower the volume
from its recorded level. For this reason, the slide control
should normally be left in the MAX position.
62
QQTG0701
Part III Sequencer
Naming
Here is the way to assign a name to your recorded song.
On the SEQ MENU display use the SONG
1.
SELECT
Press the NAMING button.
2.
• The display looks similar to the following.
and ∨ buttons to select a song.
∧
Use the buttons below the display to assign a
3.
name.
• Set the character input position with the POSITION buttons, select the characters with the alphanumeric buttons
and repeat name assignment.
• Switch from upper to lower case letters with the ABC, abc
button.
• Use the !#$ button to switch to the symbols character set.
• Press the INS button to enter a space at the cursor posi-
tion.
• Press the DEL button to erase the character at the cursor
position.
• Press the CLR button to erase the entire name.
• Press the →← button to center the name.
Press the OK button.
4.
Panel Write
You can change the panel status which is in effect at the beginning of the song. These are the settings
which are recalled when the SEQUENCER RESET button is pressed.
On the SEQ MENU display, use the SONG
1.
and ∨ buttons to select the song number.
∧
Press the OK button.
4.
•“COMPLETED!” is shown on the display.
Use the panel buttons to change to the
2.
desired panel settings.
On the SEQ MENU display, select PANEL
3.
WRITE.
• The display looks similar to the following.
• PANEL WRITE is automatically activated at the when
you start to record.
• For rhythm data, the data in the RHYTHM part has priority.
Sequencer
63
QQTG0701
Part III Sequencer
Song Select
You can select a desired song from the list of recorded songs.
On the SEQ MENU display, select RECORD
1.
& EDIT.
On the RECORD & EDIT display, select
2.
SONG SELECT.
• The display looks similar to the following.
Use the SONG SELECT ▲ and ▼ buttons to
3.
select a song.
• The total amount of memory used for the current song is
shown as a percentage (%) to the right of the song name.
• If the NAMING button is pressed, the NAMING display
appears.
• To optimize memory, songs you do not wish to preserve
should be deleted. (Refer to page 72.)
Punch Record
If you make a playing error during REALTIME RECORD or would like to change the recording for some
other reason, you can use the punch recording feature to correct a selected portion of the performance
without having to redo the whole part.
Sequencer
Recording the performance
Playback
On the SEQ MENU display, use the SONG
1.
SELECT
number. Then select RECORD & EDIT.
On the RECORD & EDIT display, select
2.
PUNCH RECORD.
• The display looks similar to the following.
Select the track which contains the portion you
3.
want to correct.
• You cannot select a track in which no data is stored.
and ∨ buttons to select the song
∧
Playing error
Punch in Punch out
Replay this portion
Recording mode
• On the display “REC” indicates tracks which are being
recorded, and “PLAY” indicates tracks which are being
played back.
Use the MEAS ∧ and ∨ buttons to specify the
4.
beginning measure of playback.
• “MEASURE=” indicates the current measure number.
Press the START/STOP button to begin play-
5.
back of the specified track.
During playback, press the PUNCH IN button
6.
at the point you want to begin recording.
• Recording begins as soon as the PUNCH IN button is
pressed. Begin playing at this point.
• The REC indication changes to the PUNCH indication.
• The PUNCH IN button switches to the REC STOP button.
64
QQTG0701
Part III Sequencer
Press the REC STOP button at the point you
7.
want to stop recording.
• Punch recording stops immediately.
• You can also begin punch-in recording by playing the
keyboard.
• You can specify the punch-in/punch-out points with the
Pedal. (Refer to page 120.)
AUTO PUNCH RECORD
You can also set the punch-in and punch-out
points beforehand, so that recording automatically begins and ends at the specified points.
On the PUNCH RECORD display, press the
1.
AUTO: OFF button.
• The display looks similar to the following.
Use the FIRST MEASURE ∧ and ∨ buttons to
2.
specify the number of the punch-in measure.
Use the COUNT IN MEASURE ∧ and ∨ but-
4.
tons to specify the number of lead-in measures you wish to have played back before the
punch-in measure.
• Set the metronome to on or off with the ON or OFF button.
Press the EXIT button.
5.
• The display changes to the PUNCH RECORD display.
Press the START/STOP button.
6.
• Playback begins from the measure indicated by MEASURE on the display.
• Pertinent information, such as the FIRST MEASURE, is
shown in the upper section of the display.
Correct the performance.
7.
• The mode changes automatically to the recording mode
at the specified FIRST measure. Begin playing at this
point. The mode automatically changes back to the playback mode at the specified LAST measure.
• To discontinue punch recording in the middle, press the
CANCEL button. In this case, the recorded contents up to
that point are erased.
Use the LAST MEASURE ∧ and ∨ buttons to
3.
specify the number of the punch-out measure.
• The number of the LAST measure must be higher than
the number of the FIRST measure.
• The specified measure is recorded.
Step Record
STEP RECORD is simply a method of making a tune by storing the sounds note-by-note on the display.
Instead of playing the keyboard directly as in the REALTIME RECORD mode, you can take your time to
input each single note. This is an especially effective method for storing complicated passages that are
difficult to play or when the exact timing of a part is critical.
Recording procedure
Record the keyboard performance and panel
changes.
On the SEQ MENU display, use the SONG
1.
SELECT
and ∨ buttons to select the song
∧
number. Then select RECORD & EDIT.
• The display changes to the PART SELECT display.
Sequencer
On the RECORD & EDIT display, select STEP
2.
RECORD.
Use the balance buttons below the display to
3.
specify the track for the part you are going to
record (only one track can be selected at a
time).
(Continued on the next page)
QQTG0701
65
Part III Sequencer
Sequencer
• The display changes to the STEP RECORD input display
similar to the following.
• If you selected the track to which the CHORD part has
been assigned, the display changes to the STEP
RECORD: CHORD display. (Refer to page 67.)
• If you selected the track to which the RHYTHM part has
been assigned, the display changes to the STEP
RECORD: RHYTHM display. (Refer to page 69.)
• If you selected the track to which the CONTROL part has
been assigned, the display changes to the STEP
RECORD: CONTROL display.
Use the MEAS ∧ and ∨ buttons to select the
4.
measure.
• This step is not necessary if you are recording from measure 1 of a blank track.
Use the CURSOR
5.
and buttons to move
the cursor to the note position (dot) you are
going to store.
• Each dot represents one-eighth of a quarter-note (a
thirty-second note).
• When storing triplets, it may not be possible to match the
timing exactly with the 1/32-note steps. However, if you
select triplet-type notes for the note length (LENGTH) in
step 6 below, the timing is automatically corrected.
Use the left REC NOTE LENGTH ∧ and
6.
buttons to specify the note value. Select from
3,
r
r, x
3,
x, e
3,
e, q
3,
q, h, w, w
× 2 to 4. (A 3
denotes a triplet-type note.)
• For note values other than these, use the center REC
NOTE LENGTH buttons to specify the note value to be
added to that which you specified with the left buttons.
Example: To record a dotted quarter-note
(
)
q
.
+
q
e
Use the right REC NOTE LENGTH ∧ and
7.
buttons to specify the actual length of the
produced sound for the desired legato or
staccato effect.
• Any panel setting changes—for example changes in the
sound selection, button operation, wheel operation,
etc.—are recorded at the cursor position.
• When a dial is operated, the input value is indicated on
the display. Confirm that this is the correct value and
press the YES button to record the value or the NO button to cancel it.
REST:
To store a rest, after specifying the note
LENGTH, press the REST button.
• Positions at which nothing is stored are read as rests.
ERS:
If you make a mistake, move the cursor to
the error, and after displaying the data you
wish to erase, press the ERS button.
BAL:
To specify the volume at the cursor position,
after pressing the BAL button, use the
VALUE buttons to set the volume (0 to 127).
Repeat steps 4 through 8 to continue storing
9.
notes.
• To input data on another track, press the button for the
desired track and repeat the procedure from step 2.
When you have finished recording, press the
10.
PROGRAM MENUS button to turn it off.
Storing control data
Various control data can be stored at the cursor
∨
position.
On the STEP RECORD: MELODY display,
1.
press the CTL button.
Use the CTL ∧ and ∨ buttons to select the
2.
control data you wish to insert.
• Select from PAN, KEY SHIFT (COARSE TUNE), TUNING (FINE TUNE), BEND SENS.
Use the VALUE ∧ and ∨ buttons to adjust the
3.
numerical value of the setting.
∨
Press YES button.
4.
TENU (tenuto): Sound is produced for 95%
of the note length.
NORM (normal): 80%
STAC (staccato): 50%
CUTT (cutting): 25%
Specify the pitch and velocity of the note by
8.
playing the keyboard.
• The dot on the display where the note is stored changes
to a
mark.
∗
• When recording chords, you can store multiple notes at
one position.
66
QQTG0701
Part III Sequencer
&
Correcting the data
In the STEP RECORD mode, specify the track
1.
you wish to correct.
Use the MEAS buttons to go to the measure
2.
you wish to modify. Use the CURSOR buttons
to move the cursor to the point (
) you wish
∗
to edit.
• The data stored at that point is shown on the display.
• When multiple data is stored at one point, different data is
displayed in order each time a CURSOR button is
pressed. When a chord is recorded, a different note in the
chord is displayed each time a CURSOR button is
pressed.
Correct the data.
3.
There are three types of data:
Performance data
NOTE data (note pitch) and VEL data (how hard
the key was played) and LEN data (1 = 1/96 of a
]) are displayed. Use the relevant
quarter note [
q
buttons to correct the data as desired.
Sound data
The name of the sound is displayed. Change the
sound as desired (the sound setting display is
interposed on the current display).
Control data
The name of the function is displayed. Change
the data as desired.
• Press the ERS button to erase the data which is displayed.
• You can also correct data which was stored in the REALTIME RECORD mode.
• Performance (NOTE) data can be recorded or edited on
a piano roll display, and there is also a specialized display for recording and editing the DRUMS part data.
(Refer to page 73 or 74.)
Store a chord progression
Store the chord progression for the AUTO PLAY CHORD in the track for the CHORD part. Then, when
the AUTO PLAY CHORD is used during playback, even if you do not specify the chords with your left
hand, the chords change automatically.
• The chord length is specified with the CHORD STEP RECORD keys on the keyboard.
Correction keys
Move back one step.
Move forward one step.
DELETE
&
Note value keys
Whole note
w
. Dotted half-note
h
Half-note
h
. Dotted quarter-note
q
Quarter-note
q
Eighth-note
e
Reset key
Press to begin storing from the beginning.
eq
q.
wh.h
Repeat key
Press to end the chord-storing procedure and to specify automatic repeat
playback of the stored progression.
End key
Press after the whole chord progression has been stored.
DELETE key
DELETE
• To erase all the data from the current track, while
Press to erase data.
pressing the DELETE key, press the End key
( ).
Sequencer
67
QQTG0701
Part III Sequencer
&
Example of storing a chord progression
Measure 1 2 3 4
C
w
On the SEQ MENU display, use the SONG
1.
SELECT
C
w
and ∨ buttons to select the song
∧
Am
h
F
D7
G7
h
h
number. Then select RECORD & EDIT.
On the RECORD & EDIT display, select STEP
2.
RECORD.
• The display changes to the PART SELECT display.
Using the balance buttons below the display,
3.
select the track to which the CHORD (CHD/
APC) part has been assigned.
• The display changes to the STEP RECORD: CHORD
input display similar to the following.
(2) While playing an F chord, press the
key one
h
time.
h
h
<Measure 4>
(1) While playing a D7 chord, press the
key one
h
time.
key one
(2) While playing a G7 chord, press the
h
time.
• You can press the INTRO & ENDING button or a FILL IN
button on the panel to store the desired pattern at the cursor position. (An INTRO or COUNT INTRO can be stored
only at the beginning.)
• Store a rest by pressing a note value key without specifying a chord.
At the end of the chord progression, press the
5.
End key ( ).
• The Keyboard exits the recording mode.
• During playback, playback of the recorded chord progres-
sion stops at this point. For automatic repeat playback of
the chord progression, press the Repeat key ( )
instead of the End key
().
Sequencer
• STEP REC: CHORD can also be enabled by pressing on
the EASY RECORD button continuously a few seconds.
This will display the CHORD screen.
Store the chords.
4.
<Measure 1, measure 2>
While playing a C chord with your left hand,
press the
w
key two time with your right hand.
w
• A “beep” tone indicates that the chord has been successfully stored.
• The dot on the display where the chord is stored changes
to a
mark and the cursor automatically moves forward, in
∗
accordance with the specified note value, to the next unrecorded position. The chord name is shown on the display.
<Measure 3>
(1) While playing an Am chord, press the
one time.
key
h
h
• When you play back the track for the CHORD part, the
chords of the automatic accompaniment change in accordance with the stored chord progression.
• To specify chords by the <one finger> mode, select the
BASIC mode before entering the STEP RECORD mode.
• If the ON BASS button is on, chords such as “C on G”
can also be specified (except in the <one finger> mode).
• The CHORD FINDER feature, which shows you how to
finger a specified chord, is available. (Refer to page 47.)
Correct the recorded chord progression
Follow the procedure to select the STEP
1.
RECORD: CHORD display.
Use the MEAS buttons to go to the measure
2.
you wish to modify. Use the
and Correction keys to move the cursor to the point (
you wish to edit.
• The lengths of rests are indicated by the respective rest
value × its multiplier.
Example:
Œ
.................1-beat rest (quarter rest)
‰
................1/2-beat rest (eighth rest)
Œ
× 1 +
‰
....1-1/2-beat rest
(dotted quarter rest)
Œ
× 10........10-beat rest
• To go to the end of the chord progression, while pressing
the Reset key ( ), press the
key.
)
∗
Correct the chord data.
3.
68
QQTG0701
Part III Sequencer
Chord data
When the chord name is displayed at the cursor
position, you can press the DELETE key to
erase the data and then store a new chord.
• If you do not erase the displayed data before entering new
chord data, the new data is inserted at this point, and the
displayed data is merely shifted by the note value of the
new chord.
• Rests can also be erased. Each time the DELETE key is
pressed, the rest is erased in units of
erased last.
• If you wish to cancel the REPEAT, enter an END command.
Œ
× 1. The
‰
rest is
Control data
The name of the stored function (INTRO, FILL,
etc.) is displayed. You can press the DELETE
key to erase the data which is displayed.
TRACK CLEAR
To erase all data from the current track, press
the CLR button, and then press the YES button
on the confirmation display.
• If you wish to cancel the clear procedure, press the NO
button.
Store a rhythm progression
Changes in the rhythm selection and tempo, as well as the intro, fill-ins and the ending, can be stored by
measures with the step recording method.
On the SEQ MENU display, use the SONG
1.
and ∨ buttons to select the song number.
Then select RECORD & EDIT.
On the RECORD & EDIT display, select STEP
2.
RECORD.
• The display changes to the PART SELECT display.
Using the balance buttons below the display,
3.
select the track to which the RHYTHM (RHY)
part has been assigned.
• The display changes to the STEP RECORD: RHYTHM
input display similar to the following.
∧
Repeat steps 4 and 5 to continue storing the
6.
rhythm progression.
At the end of the rhythm progression, press
7.
the END button.
• If the REP button is pressed instead of the END button,
during playback the recorded rhythm progression is
repeated.
• The Keyboard exits the recording mode.
Correct the recorded rhythm progression
Follow the procedure to select the STEP
1.
RECORD: RHYTHM display.
Use the MEAS buttons to go to the measure
2.
you wish to modify. (The
is highlighted.)
∗
Use the MEAS ▲ and ▼ buttons to go to the
4.
measure you wish to record.
Store the rhythm data.
5.
• Data which can be stored:
START/STOP
Changes in the rhythm selection
RHYTHM VARIATION 1–4,
COUNT INTRO, INTRO, FILL IN,
ENDING
Tempo changes
• Be sure to store the START/STOP data in the measure in
which the rhythm starts or stops.
• If you are storing a COUNT INTRO or INTRO, store this
data before the START/STOP data.
• If the tempo is changed, the display changes to the confirmation display. After specifying the desired tempo,
Press the YES button to store the specified tempo, or
press the NO button to cancel the new tempo value.
Correct the rhythm data.
3.
• Press the ERS button to erase data at the cursor position.
• If you wish to cancel the REPEAT, enter an END command.
• If you select a rhythm with a different time signature, the
time signature of all subsequent measures will also
change.
• If data has already been recorded in other tracks, you
cannot select a rhythm with a different time signature.
TRACK CLEAR
To erase all data from the current track, press
the CLR button, and then press the YES button
on the confirmation display.
• If you wish to cancel the clear procedure, press the NO
button.
Sequencer
69
QQTG0701
Part III Sequencer
Track Assign
Each SEQUENCER part is already assigned to a track number. However, you can use the TRACK
ASSIGN function to assign parts to tracks as you wish.
Sequencer
On the SEQ MENU display, use the SONG
1.
SELECT
and ∨ buttons to select the song
∧
number. Then select RECORD & EDIT.
On the RECORD & EDIT display, select
2.
TRACK ASSIGN.
• The display looks similar to the following.
Use the TR ▲ and ▼ buttons to select the
3.
track.
Use the TRACK ASSIGN ∧ and ∨ buttons to
4.
select the part for the specified track.
• When a part other than the CONTROL, APC, CHORD or
RHYTHM part is assigned, the track assign procedure is
completed at this point.
• Either the CHORD part or APC part can be assigned to a
track, but not both.
• The CONTROL, APC, CHORD and RHYTHM parts cannot be assigned to more than one track.
• You can use the ON and OFF buttons for LOCAL CONT.
to specify whether or not the sound of the part assigned
to this track is generated. Because no sound is generated
for this instrument’s parts assigned to tracks set to OFF
through this procedure, use this setting to generate
sound from an external sound source through the MIDI
connectors.
• You can use the MIDI OUT ON and OFF buttons to specify whether or not the data of the part assigned to this
track is sent as MIDI data. When set to OFF, the data is
not sent, even if MIDI equipment is connected.
TRACK ASSIGN PRESETS
A preset track assignment can be selected.
On the TRACK ASSIGN display, press the
1.
PRESET button.
• The display looks similar to the following.
Use the SONG ∧ and ∨ buttons to select the
2.
song number for which the preset track
assignment will be effective.
• If ALL is selected, the track assignment is effective for all
the songs.
Select the track assign mode.
3.
INITIAL:
Factory-preset settings.
TECHNICS MULTI RECORDING:
The optimum track assignment for multiplex
recording.
GM MULTI RECORDING:
The optimum track assignment for creating
GENERAL MIDI data.
Press the OK button.
4.
•“COMPLETED!” is shown on the display and the selected
track assign mode is enabled.
• You can confirm the track assignment settings on the
TRACK ASSIGN display.
When assigning the CONTROL, APC,
5.
CHORD or RHYTHM part, press the OK button.
70
QQTG0701
Part III Sequencer
Rhythm as written
in the score
Timing of actual
performance
Quantized
performance
e
100%
50%just
50%
100%
+100%
+50%
+30%
–50%
–30%
–100%
Quantize
The QUANTIZE function can correct the timing of your performance after it has been recorded. If the
rhythm is slightly out of sync or inexact, it will automatically be corrected to the specified quantize level.
On the SEQ MENU display, select RECORD
1.
& EDIT.
On the RECORD & EDIT display, select
2.
QUANTIZE.
• The display looks similar to the following.
Use the STRENGTH ∧ and ∨ buttons to select
7.
the amount of quantize (%).
• 100% is a convenient setting. When set to 100%, the performance data is quantized exactly to the level specified
for the VALUE (“just”). For example, at 50%, the data is
quantized to a point that is half that of the just level. By
this setting, you can attain an effect that is very slightly
off-beat from the rhythm.
Use the WINDOW ∧ and ∨ buttons to specify
8.
the range (%) affected by the quantize setting.
• With the increment set to 100 for the VALUE, at a + setting, data close to the just point is corrected, and at a –
setting, data far from the just point is corrected. For
example, if set to –30% the quantize function affects data
far from the just point, and if set to +30% the quantize
function affects data close to the just point. +100% is usually a convenient setting.
• The +100% setting and the –100% setting are the same.
Example: When VALUE is set to
q
Use the TRACK ∧ and ∨ buttons to specify
3.
the track number.
• You cannot select the track for the CONTROL, RHYTHM
or CHORD part.
• If ALL is selected, all the tracks are quantized.
Use the FIRST MEAS ∧ and ∨ buttons to
4.
specify the start point (measure number).
Use the LAST MEAS ∧ and ∨ buttons to spec-
5.
ify the end point (measure number).
Use the VALUE ∧ and ∨ buttons to specify the
6.
quantize level.
3
3
• Select from q, e,
type note.)
e
x
, x,
3
r
, r,
. (A 3 denotes a triplet-
Press the OK button.
9.
• The confirmation display appears. Press the YES button
to execute the function, or press the NO button to cancel
the function.
Sequencer
71
QQTG0701
Part III Sequencer
Song Clear
Erase the recorded contents of all tracks.
On tne SEQ MENU display, select RECORD
1.
& EDIT.
On the RECORD & EDIT display, selct SONG
2.
CLEAR.
• The display looks similar to the following.
Use the SONG No./ALL ∧ and ∨ buttons to
3.
specify the number of the song to erase.
• The data size (KB) and the total amount of SEQUENCER
memory or current song memory used is shown as a percentage (%) to the right of the song name.
• If ALL is selected, all the songs recorded in the
SEQUENCER will be erased.
Track Clear
Press the OK button.
4.
• The confirmation display appears. Press the YES button
to execute the function, or press the NO button to cancel
the function.
• If the YES button is pressed, “COMPLETED!” appears on
the display, the specified songs are erased.
Sequencer
Erase the contents of a specific track.
On the SEQ MENU display, select RECORD
1.
& EDIT.
On the RECORD & EDIT display, select
2.
TRACK CLEAR.
• The display looks similar to the following.
Use the balance buttons to select the track or
3.
tracks you wish to clear.
• A “CLR” mark is shown for the selected tracks.
Press the OK button.
4.
• The confirmation display appears. Press the YES button
to execute the function, or press the NO button to cancel
the function.
• If the YES button is pressed, the specified tracks are
erased.
72
QQTG0701
Part III Sequencer
Note Edit
You can edit performance (NOTE) data on a piano roll display. This differs from the normal STEP
RECORD edit procedure, and is a convenient way to check the data for each note.
• Data other than NOTE data cannot be corrected or recorded. To correct or record other types of data, use the STEP RECORD
display. (Refer to page 65.)
On the SEQ MENU display, select RECORD
1.
& EDIT.
On the RECORD & EDIT display, select
2.
NOTE EDIT.
On the PART SELECT display, select a track.
3.
• The CHORD, RHYTHM and CONTROL tracks cannot be
selected.
• The display looks similar to the following.
Use the MEAS ▲ and ▼ buttons to select the
4.
measure you wish to edit.
Use the CURSOR and buttons to move
5.
the cursor ( ▼ ) to the point you wish to edit.
• Recorded performance (NOTE) data is shown as horizontal bars. Data selected for editing is highlighted.
• You can use the INC ∧ and ∨ buttons to change the
increment of cursor movement. The resolution can be set
q
at
/96. However, if NOTE data is present between incre-
ments, the cursor will stop.
• Use the POS ▲ and ▼ buttons to change the timing.
• Example: 10.2.48 indicates a point in measure 10, beat 2,
point 48 (one point is 1/96 of a quarter note [
• is shown at the point where the END command is
stored.
q
]).
Select the data to edit (it changes to a high-
6.
lighted horizontal bar). Edit the data.
• Use the POS ▲ and ▼ buttons to move the timing, the
• Use the GRAPH ▲ and ▼ buttons to view a higher or
• If the ERS button is pressed, the selected NOTE data is
7.
∧
NOTE
VEL
the keys are played), and the LEN ∧ and ∨ buttons to
change the note length (1 = 1/96 of a quarter note [
lower section of the keyboard (in one-octave steps).
erased.
and ∨ buttons to change the note number, the
∧
and ∨ buttons to change the velocity (how hard
Repeat steps 4 to 6 to continue editing.
Inserting note data
You can also store note data on this display.
Specify the point where the new note data will
1.
be stored.
Use the LEN ∧ and ∨ buttons to specify the
2.
note length.
• Examples of note lengths ( q = 96)
91: tenuto (95%)
76: normal (80%)
48: staccato (50%)
24: cutting (25%)
Play a key on the keyboard to specify the note
3.
pitch (NOTE NUMBER) and velocity (how
hard the key is played).
Repeat steps 1 to 3 to input more note data.
4.
q
]).
Sequencer
73
QQTG0701
Part III Sequencer
CYCLE PLAY
You can aurally check the data you are editing by
accessing the CYCLE PLAY display from the
NOTE EDIT display.
• If you wish other tracks to be played back, they should be
selected beforehand on the SEQUENCER PLAY display.
(Refer to page 61.)
On the NOTE EDIT display, press the PLAY
1.
button.
• The display looks similar to the following.
Use the START MEASURE ∧ and ∨ buttons
2.
to select the beginning playback measure.
Use the END MEASURE ∧ and ∨ buttons to
3.
select the last playback measure.
Press the START/STOP button.
4.
• Cycle playback of the specified measures begins.
• If the SOLO button is turned on, playback changes to that
of the recording track only. If it is turned off, all the tracks
specified on the SEQUENCER PLAY display are played
back.
To stop cycle playback, press the START/
5.
STOP button again.
• During playback stop, if the SEQUENCER RESET (FILL
IN 1) button is pressed, the SEQUENCER returns to the
measure number specified in step 2. If the SEQUENCER
RESET button is pressed again, the SEQUENCER
returns to measure 1.
Sequencer
Drum Edit
The DRUMS part can be edited on a specialized display. This differs from the normal STEP RECORD edit
procedure, and is a convenient way to check the data for each note.
On the SEQ MENU display, select RECORD
1.
& EDIT.
On the RECORD & EDIT display, select
2.
DRUM EDIT.
On the PART SELECT display, select the
3.
track for the DRUMS part.
• The CHORD, RHYTHM and CONTROL tracks cannot be
selected.
• The display looks similar to the following.
Use the SOUND ∧ and ∨ buttons to select the
4.
percussion instrument you wish to edit.
• The number to the left of the instrument name is its MIDI
NOTE NUMBER in the Technics arrangement.
• If sounds other than percussion instrument sounds are
assigned, they are not displayed.
• You can use the INC ∧ and ∨ buttons to change the
increment of cursor movement. The resolution can be set
q
at
/96. However, if NOTE data is present between incre-
ments, the cursor will stop.
• Use the POS ▲ and ▼ buttons to change the timing.
Example: 10.2.48 indicates a point in measure
10, beat 2, point 48 (one point is 1/96 of a
quarter note [
• is shown at the point where the END command is
stored.
Select the data to edit (it changes to a long
7.
q
]).
bar). Edit the data.
• Use the POS ▲ and ▼ buttons to move the timing, the
∧
SND
and ∨ buttons to change the percussion instrument sound, and the VEL ∧ and ∨ buttons to change the
velocity (how hard the keys are played).
• If the ERS button is pressed, the selected NOTE data is
erased.
Repeat steps 4 to 7 to continue editing.
8.
Use the MEAS ▲ and ▼ buttons to select the
5.
measure you wish to edit.
Use the CURSOR and buttons to move
6.
the cursor (▼) to the point you wish to edit.
• Recorded performance data is shown as vertical bars.
Data selected for editing is highlighted.
74
QQTG0701
Part III Sequencer
Inserting DRUMS data
You can also store DRUMS data on this display.
Specify the point where the new note data will
1.
be stored.
Use the VEL ∧ and ∨ buttons to specify the
2.
velocity (how hard the key is played).
Press the ENTER button to store the data.
3.
• Instead of the ENTER button, you can store data (including velocity data) by playing the keyboard. In this case,
the instrument is that specified on the display, regardless
of which key is played.
Repeat steps 1 to 3 to input more DRUMS
4.
data.
CYCLE PLAY
You can aurally check the data you are editing by
accessing the CYCLE PLAY display from the
DRUM EDIT display.
• The procedure is the same as for NOTE EDIT.
• If you wish other tracks to be played back, they should be
selected beforehand on the SEQUENCER PLAY display.
(Refer to page 61.)
Copy and paste the recorded data
You can copy and paste specific portions of the recorded data.
Select the function
On the SEQ MENU display, use the SONG
1.
SELECT
of the song. Then select COPY & PASTE.
• The display looks similar to the following.
On the COPY & PASTE display, select a func-
2.
tion.
Perform the editing procedures. (See below.)
3.
• During the editing procedure, if the indicator for the
TEMPO/PROGRAM is lit, you can use the TEMPO/PROGRAM dial for the editing function.
and ∨ buttons to select the number
∧
SONG COPY
Copy all the recording data of a song to a specific song memory.
On the FROM side, use the SONG ∧ and
1.
buttons to select the song number you wish to
copy from.
On the TO side, use the SONG ∧ and ∨ but-
2.
tons to select the song number to copy to.
Press the OK button.
3.
• The confirmation display appears. Press the YES button
to execute the function, or press the NO button to cancel
the function.
TRACK COPY
Copy the recorded data from specific tracks of a
song.
Specify the track you wish to copy from.
1.
• On the FROM side, use the SONG ∧ and ∨ buttons and
TRACK ∧ and ∨ buttons to specify a track.
• If ALL is selected, all the tracks of the specified song
number will be copied.
∨
Sequencer
Specify the track you wish to copy to (TO
2.
side).
Press the OK button.
3.
• The confirmation display appears. Press the YES button
to execute the function, or press the NO button to cancel
the function.
QQTG0701
75
Part III Sequencer
• The track assignment settings are also copied. Note that
in some cases, the CONTROL, RHYTHM and CHORD
part data in the destination tracks may be lost.
TRACK MERGE
Merge the recorded contents of two tracks
(source tracks) and store the merged contents in
a third track (destination track).
• When the TRACK MERGE function is executed, the data
is erased from the two source tracks.
Select the two source tracks (FROM).
1.
• On the FROM side, use the TRACK ∧ and ∨ buttons to
select the two source tracks.
• You cannot select the track to which the CONTROL,
RHYTHM or CHORD part has been assigned.
• If the part assigned to the left source track (“left” meaning
its position on the TRACK MERGE display) is different
from the part assigned to the right source track, when the
parts are merged in the destination track, the new track is
assigned the same part as the left track.
Select the destination track (TO).
2.
• Use the TRACK ∧ and ∨ buttons to the right of the dis-
play to specify the track number.
• If ALL is selected, the specified measures are copied
to all tracks at the same time.
FIRST MEAS:
Specify the first measure to copy.
LAST MEAS:
Specify the last measure to copy.
Specify where you wish to copy the selected
2.
measures to.
• On the TO side, specify the settings with the corresponding buttons.
TRACK:
Specify the track number you wish to copy
to.
• Measures in a track for the CONTROL, RHYTHM or
CHORD part can be copied only to the same track.
START MEAS:
Specify the start point to copy the selected
measures to.
REPEAT:
Specify the number of times the selected
measures are to be repeated.
Press the OK button.
3.
• The confirmation display appears. Press the YES button
to execute the function, or press the NO button to cancel
the function.
• Note that if the END command is included in the source
data, it is also copied. Any data following the END command is not copied.
Sequencer
Press the OK button.
3.
• The confirmation display appears. Press the YES button
to execute the function, or press the NO button to cancel
the function.
MEASURE COPY
Copy recorded data of specified measures to a
specified point.
• On the destination track, the new data replaces the current measure contents.
Specify the measures you wish to copy from
1.
the source track (FROM).
• On the FROM side, specify the settings with the corresponding buttons.
TRACK:
Specify the track number you wish to copy
the measures from.
• You cannot select the track for the RHYTHM part or
CHORD part in which a repeat command has been
stored.
MEASURE ERASE
Erase the recorded contents of specific measures. You can also specify which type of data is
to be erased.
• Note that only the contents of the measures are erased,
not the measures themselves; the length of the performance remains the same.
Use the TRACK ∧ and ∨ buttons to specify
1.
the track number.
• This function does not work for the RHYTHM part or
CHORD part in which a repeat command has been
stored.
• If ALL is selected, data is erased from the specified measures of all the tracks at one time.
Use the FIRST MEAS ∧ and ∨ buttons to
2.
specify the start point (measure number).
Use the LAST MEAS ∧ and ∨ buttons to spec-
3.
ify the end point (measure number).
76
QQTG0701
Part III Sequencer
Use the ERASE DATA ∧ and ∨ buttons to
4.
specify the type of data to be erased.
ALL:
All data is erased.
NOTE:
Only note data is erased.
CONTROL:
Only control data (volume, effect and other
panel settings as well as selection changes)
is erased.
Press the OK button.
5.
• The confirmation display appears. Press the YES button
to execute the function, or press the NO button to cancel
the function.
MEASURE DELETE
Delete specified measures from a track.
• The length of the performance accordingly decreases by
the number of deleted measures.
MEASURE INSERT
Insert specified measures at a specified point.
• The length of the performance accordingly increases by
the number of inserted measures.
Specify the measures you wish to copy from
1.
the source track.
• On the FROM side, specify the settings with the corresponding buttons.
TRACK:
Specify the track number you wish to copy
the measures from.
• This function does not work for the CHORD or
RHYTHM track in which the repeat function has been
stored.
• If ALL is selected, the measures are inserted in all
tracks at the same time.
Use the TRACK ∧ and ∨ buttons to select the
1.
track from which measures are to be deleted.
• This function does not work for the CHORD or RHYTHM
track in which the repeat function has been stored.
• If ALL is selected, the specified measures are deleted
from all the tracks at one time.
Use the FIRST MEAS ∧ and ∨ buttons, to
2.
specify the first measure to delete.
Use the LAST MEAS ∧ and ∨ buttons to
3.
specify the last measure to delete.
Press the OK button.
4.
• The confirmation display appears. Press the YES button
to execute the function, or press the NO button to cancel
the function.
FIRST MEASURE:
Specify the first measure to copy.
LAST MEASURE:
Specify the last measure to copy.
Specify where you wish to insert the selected
2.
measures.
• On the TO side, specify the settings with the corresponding buttons.
TRACK:
Specify the track number.
• Measures from the CHORD, RHYTHM or CONTROL
track can only be inserted in the same track.
START MEASURE:
Specify the start point to insert the selected
measures.
REPEAT:
Specify the number of times the selected
measures are to be repeated.
Press the OK button.
3.
• The confirmation display appears. Press the YES button
to execute the function, or press the NO button to cancel
the function.
• Note that if the END command is included in the source
data, it is also inserted. Any data following the END command is not inserted.
Sequencer
77
QQTG0701
Part III Sequencer
Use the APC ∧ and ∨ buttons to select the
APC TO SMF CONVERT
This function converts data to Standard MIDI File
(SMF) format, allowing you to play back song
data created using this instrument’s automatic
accompaniment on an external sequencer or
sound generator.
Use the TR ▲ and ▼ buttons to select the
1.
track you wish to convert.
• In the PART column, the part name currently assigned is
shown.
• In the DATA column, a check mark (√) indicates a track in
which data is stored.
• Tracks in which RHYTHM, CONTROL, APC and CHORD
parts are stored cannot be selected (− − − is shown).
2.
parts you wish to convert.
• Parts that are set to OFF will not be converted.
Press the CONVERT button.
3.
• Note that after the conversion, the APC/CHORD part
data is cleared; if necessary, save this data beforehand.
• A confirmation display appears. Press EXECUTE to continue with the conversion, or press the CANCEL button is
you wish to discontinue.
• After the EXECUTE button is pressed, the conversion
begins. Conversion takes the same length of time as
playback.
• If you wish to discontinue the conversion process midway, press the ABORT button.
Sequencer
Changing the note position etc. of the
recorded data
You can change the note pitch and position etc. of recorded data.
Select the function
On the SEQ MENU display, use the SONG
1.
and ∨ buttons to select the number of the
song. Then select RANGE EDIT.
• The display looks similar to the following.
On the RANGE EDIT display, select a func-
2.
tion.
Perform the editing procedures. (See below.)
3.
• During the editing procedure, if the indicator for the
TEMPO/PROGRAM is lit, you can use the TEMPO/PROGRAM for the editing function.
∧
NOTE CHANGE
Change of pitch of specified notes.
Use the TRACK ∧ and ∨ buttons to select the
1.
track you wish to edit.
• You cannot select the track for the CONTROL, RHYTHM
or CHORD part.
• If ALL is selected, all tracks will be edited.
Use the FIRST MEAS ∧ and ∨ buttons to
2.
specify the start point (measure number) of
the note change.
Use the LAST MEAS ∧ and ∨ buttons to spec-
3.
ify the end point (measure number) of the note
change.
78
QQTG0701
Use the TARGET NOTE ∧ and ∨ buttons to
4.
specify the pitch of the note you wish to
change.
• The number next to the note name is its note number.
Part III Sequencer
Use the CHANGE TO ∧ and ∨ buttons to
5.
specify the pitch you wish to change to.
Press the OK button.
6.
• The confirmation display appears. Press the YES button
to execute the function, or press the NO button to cancel
the function.
VELOCITY CHANGE
Modify the recorded velocity in specific measures of specific tracks.
Use the TRACK ∧ and ∨ buttons to select the
1.
track you wish to edit.
• You cannot select the track for the CONTROL, RHYTHM
or CHORD part.
• If ALL is selected, all tracks will be edited.
Use the FIRST MEAS ∧ and ∨ buttons to
2.
specify the start point (measure number) of
the transpose.
Use the LAST MEAS ∧ and ∨ buttons to spec-
3.
ify the end point (measure number) of the
transpose.
Use the TRANSPOSE ∧ and ∨ buttons to
4.
specify the change in pitch.
• Increments are in semitones. A value of 12 is one octave.
A – value lowers the pitch, and a + value raises it.
Press the OK button.
5.
• The confirmation display appears. Press the YES button
to execute the function, or press the NO button to cancel
the function.
ADVANCE/DELAY
Speed up or delay the sound production of specified performance data.
Use the FIRST MEAS ∧ and ∨ buttons to
2.
specify the start point (measure number) of
the velocity change.
Use the LAST MEAS ∧ and ∨ buttons to spec-
3.
ify the end point (measure number) of the
velocity change.
Use the VELOCITY ∧ and ∨ buttons to specify
4.
the change in velocity.
• The value you select will be added to or decrease from
the current velocity.
Press the OK button.
5.
• The confirmation display appears. Press the YES button
to execute the function, or press the NO button to cancel
the function.
TRANSPOSE
Change of key of specific measures of specific
tracks.
Use the TRACK ∧ and ∨ buttons to select the
1.
track you wish to edit.
• You cannot select the track for the CONTROL, RHYTHM
or CHORD part.
• If ALL is selected, all tracks will be edited.
Use the FIRST MEAS ∧ and ∨ buttons to
2.
specify the start point (measure number) of
the change.
Use the LAST MEAS ∧ and ∨ buttons to spec-
3.
ify the end point (measure number) of the
change.
Use the ADVANCE/DELAY ∧ and ∨ buttons
4.
to accelerate or delay the timing of the sound
production (–96 to +96).
• A + value causes the notes to sound later, and a – value
causes the notes to sound earlier.
Press the OK button.
5.
• The confirmation display appears. Press the YES button
to execute the function, or press the NO button to cancel
the function.
Sequencer
Use the TRACK ∧ and ∨ buttons to select the
1.
track you wish to edit.
• You cannot select the track for the CONTROL, RHYTHM
or CHORD part.
• If ALL is selected, all tracks will be edited.
79
QQTG0701
Part IV Composer
Outline of the Composer
AUTO PLAY CHORD
SPLIT
ONE TOUCH
MAIN
POINT
OFF/ON
PLAY
MODE
VOLUME
MAX
CHORD FINDER
PROGRESSIVE
PIANIST PIANO STYLIST
MIN
1 2 1 2 1 1 2 3 4 BEAT
MUSIC STYLE ARRANGER
VARIATION
DEMO
FADE
APC/SEQUENCER
VOLUME
SOUND
METRONOME
POP ROCK
IN OUT
ARRANGER
MAX
SET
OFF
234
FILL IN INTRO & ENDING
SEQUENCER
COUNT
RESET
INTRO
TEMPO / PROGRAM
RHYTHM GROUP
BALLROOM
FUNK &
SOUL DISCO
POP BALLAD
BALLAD
& SHOW
LATIN &
JAZZ &
WALTZ
MEMORY
WORLD
SWING
& TRADUSA16 BEAT8 BEAT
CONTRAST
LOAD
SYNCHRO & BREAK
START / STOP TAP TEMPO
HELP
OTHER PARTS/TR
-
TRANSPOSE
+
MUTE
DISPLAY HOLD
PAGE
GUITAR &
STRINGS
VOCAL
HARPSI BRASS PLAY
MALLET &
BASS
ORCH PERC
WORLD
EXIT GRAND
UPRIGHT ELECTRIC
SOUND GROUP
MIXTURES
PIANO
SAX &
ORGAN &
WOODWIND
ACCORDION
SYNTH
PIANO
ORCH
DIGITAL
MIXTURES
DRAWBARS
DRUM KITS
MODERN SIMPLE PIANO TECHNI-CHORD BANK
SEQUENCER
PROGRAM
DISK
EASY
SOUND
MENUS
IN USE
REC
FAVORITES
CONDUCTOR
LEFT RIGHT 2 RIGHT 1
AB
CHORD STEP REC
C
SET 1 / 5 2 / 6 3 / 7 4 / 8
PANEL MEMORY
DISK
LOAD
DIGITAL
MULTI
EFFECT
EFFECT
CHORUS REVERB
P.MEM 5-8
EXPLORER
MEMORY
The COMPOSER enables you to create your own accompaniment patterns. A pattern is comprised of 8
parts: DRUMS 1, 2, BASS and ACCOMP1–5 parts. These parts would form the backing of a song.
Rhythm components which can be stored
Different INTRO 1, 2, VARIATION 1 to 4, FILL IN
1, 2 patterns can be created for each MEMORY
(A, B, C).
• Each VARIATION is made of a PATTERN, FILL 1 and
FILL 2.
• A Maj (major) and Min (minor) pattern is available for
each of the INTRO and ENDING 1 and 2.
INTRO VARI 1 VARI 2 VARI 3 VARI 4 ENDING
1 Maj
1 Min
2 Maj
2 Min
PATTERN
FILL IN 1
FILL IN 2
PATTERN
FILL IN 1
FILL IN 2
PATTERN
FILL IN 1
FILL IN 2
PATTERN
FILL IN 1
FILL IN 2
1 Maj
1 Min
2 Maj
2 Min
Composer
Memory capacity
Expressed in terms of notes, the total number of
notes which can be stored in all the COMPOSER
memories is about 13,000. The remaining memory available for recording is shown on the
recording display as a percentage (%).
• When “Memory full!” appears on the display no more data
can be stored in the COMPOSER.
MEMORY
䡲䡲䡲䡲
Because the contents of the MEMORY are
erased after the power is turned off, you should
save the data on disks if you wish to keep it.
(Refer to page 97.)
COMPOSER menu
Press the PROGRAM MENUS button to turn it
1.
on.
• The display looks similar to the following.
Select COMPOSER.
2.
• The display looks similar to the following.
80
QQTG0701
Part IV Composer
Summary of the COMPOSER menu items
RECORDING MEMORY-A
Create a memory in the MEMORY A bank.
RECORDING MEMORY-B
Create a memory in the MEMORY B bank.
RECORDING MEMORY-C
Create a memory in the MEMORY C bank.
EASY COMPOSER
Create a rhythm pattern with a simplified
procedure.
Three ways to record in the COMPOSER
There are three ways to create and record a
rhythm.
Simple recording method
䡲䡲䡲䡲
Use EASY COMPOSER to quickly create a
unique rhythm just by selecting a pattern for
each part.
Create a completely new rhythm (page 82)
䡲
Compose all the parts of a completely new
rhythm from scratch.
• You can use either realtime recording or step record for
any part of the recording.
PATTERN COPY (page 88)
Copy a rhythm pattern into a memory.
SEQ TO COMPOSER COPY (page 89)
Copy recorded data in the SEQUENCER to
the COMPOSER.
LOAD SINGLE COMPOSER
Recall the desired COMPOSER data from
data saved on a disk. This procedure is the
same as when COMPOSER is selected for
SINGLE LOAD. (Refer to page 93.)
Pattern Copy (page 88)
䡲
Copy a preset rhythm or SEQUENCER data to a
COMPOSER memory, edit it as you like, and
then store it as a new rhythm.
Simple recording method
With EASY COMPOSER you can easily create a unique rhythm pattern by selecting a different style for
each part of the rhythm.
On the COMPOSER MENU display, select
1.
EASY COMPOSER.
• The display looks similar to the following.
Use the MEM ∧ and ∨ buttons to select the
2.
memory in which to record your rhythm.
• Select from A-vari 1 to 4, B-vari 1 to 4 and C-vari 1 to 4.
Use the PART ▲ and ▼ buttons to select the
3.
part.
• In the EASY COMPOSER, the new rhythm pattern is
divided into 9 parts, to each of which a style and variation
is assigned.
Use the STYLE ∧ and ∨ buttons to select a
4.
style.
Use the VARI ∧ and ∨ buttons to select the
5.
variation number.
• The number of variations differs depending on the
selected style.
• A part which is set to OFF does not sound. Note that the
“BsDrum&Snare” part cannot be set to OFF.
Repeat steps 3 to 5 to select styles for the
6.
other parts.
Press the SET button.
7.
• The rhythm pattern is played back.
• If you are not satisfied with the rhythm pattern, repeat
steps 3 to 7.
• If you wish to correct the sounds or phrases in your
rhythm pattern, press the EDIT button. The display
changes to the recording display. (Refer to page 83.)
• For playback, refer to page 85.
Composer
81
QQTG0701
Part IV Composer
Create a completely new rhythm
Clear the memories and compose a completely new rhythm from scratch.
• You can also use this method when copying a pattern from a preset rhythm or the SEQUENCER.
Prepare to record
On the COMPOSER MENU display, select a
1.
memory in which to record (RECORDING
MEMORY A, B, or C).
• The display looks similar to the following.
Use the buttons below the display to select the
2.
pattern you want to create.
• If the MEM CLR button is pressed, all the current contents of the MEMORY (A/B/C) are erased (a confirmation
display appears).
• You can press the NAMING button and assign a name to
the MEMORY.
Press the YES button.
5.
• All the data for the selected pattern is erased.
Press the MEASURE SETTING button.
6.
Use the MEASURE ∧ and ∨ buttons to spec-
7.
ify the number of measures in your new
rhythm pattern (1 to 16).
Use the TIME SIGNATURE ∧ and ∨ buttons
8.
to specify the meter of the pattern (1/4 to
8/4).
• When the settings for the MEASURE and TIME SIGNATURE of the INTRO or ENDING patterns are changed,
the Maj and Min settings change at the same time.
Composer
• To assign a name to each VARIATION, press the VARI
button and select a number.
On the RECORD MEMORY display, press the
3.
OK button.
• The display looks similar to the following.
Press the CLEAR THE ENTIRE PATTERN
4.
button.
• The display looks similar to the following.
Press the OK button.
9.
Press the EXIT button.
10.
82
QQTG0701
Part IV Composer
KEY SETTING
Set the key and chord in which you wish the
recorded pattern to be played. If the recorded
performance is played in a key or chord different
from this setting, the automatic accompaniment
will not be able to distinguish the correct chord.
On the RECORDING display press the KEY
1.
SETTING button.
• The display looks similar to the following.
Use the KEY ∧ and ∨ buttons to set the key.
2.
Use the CHORD
and ∨ buttons to set the
∧
chord type (Maj/Min).
When you have finished making the settings,
3.
press the EXIT button.
Recording procedure
• For the ACCOMP and BASS parts, select sounds from
groups other than the DIGITAL DRAWBAR sound
groups.
• The sounds marked with # represent special guitar performances and changing them to other sounds may
result in an unnatural, awkward sound expression.
Record the part.
4.
• The specified number of measures are repeatedly played
back, during which time any newly played notes are
added to those already recorded. The current measure
number is shown on the display as “MEASURE=”.
• Record the performance in C major for correct chord progressions during playback. Follow the KEY SETTING
procedure if you wish to record the performance in a different scale.
• The sustain pedal operation or PITCH BEND and MODULATION effects when MIDI data is received are also
recorded (except for the DRUMS part).
Button functions
䡲䡲䡲䡲
PART BALANCE:
Adjust the volume of each part on the PART
BALANCE display. (These settings are not
recorded.)
In the START RECORDING area on the dis-
1.
play, select the rhythm part you want to record
first.
BAS: BASS
AC1–5: ACCOMP 1–5
DR1, 2: DRUMS 1, 2
• The metronome sound starts and the display looks similar to the following.
Adjust the tempo.
2.
• The tempo is shown on the display as q =.
• The tempo can be freely adjusted when you play back
the rhythm pattern, so record at the tempo which is easiest for you to play.
PART SETTING:
You can make detailed settings for each part.
(Refer to page 84.)
STEP RECORD:
Change to the STEP RECORD mode. (Refer
to page 86.)
SOLO:
Mute all parts except the part which is currently being recorded.
• A MUTE mark is shown for the other parts on the display.
• To turn off the SOLO function, press this button again.
PART CLR:
Erase all recorded contents of the currently
selected part.
NOTE CLR:
Data is erased one note or one percussion
instrument (DRUMS part) sound at a time.
• Hold and press this button, and press the keyboard key
that corresponds to the note or percussion instrument
(DRUMS part) sound you wish to erase.
ALL ERAS:
The performance recorded in the selected part
is erased for as long as this button is pressed.
Composer
Select the sound.
3.
•For the DRUMS part, only sounds from the DRUM KITS
sound group can be selected.
(Continued on the next page)
83
QQTG0701
Part IV Composer
QUANTIZE:
Smooth out any unevenness in the timing of
your performance.
• Before recording, select the note value for the desired
quantize level. (The quantize level is shown on the display as QUANTIZE=.)
KEY IN CHORD MODIFY <PAGE 2/2> (except
for INTRO, ENDING, DRUMS):
Use the GROUP and TYPE
to select the type of pattern progression.
• This setting is for the sound that is going to be recorded
from this time.
Use the buttons below the display to switch to
5.
a different recording part, and proceed to
record each part in turn.
and ∨ buttons
∧
When you have finished recording the rhythm,
6.
turn off the PROGRAM MENUS button.
Chord Modify Change
For data that has already been recorded, you can select the type of pattern progression for the bass and
accomp parts.
• This function cannot be used for the INTRO and ENDING patterns.
On the RECORDING display, press the
1.
CHORD MODIFY CHANGE button.
• The display looks similar to the following.
Use the PART ▲ and ▼ buttons to select the
2.
part you wish to set.
Use the GROUP and MODIFY TYPE ∧ and
3.
buttons to select the corresponding progression type.
Part Setting
You can make detailed settings for each part.
• If a progression type for which the note name is displayed
(in C key) was selected for the chord group, played notes
which are not displayed are changed to notes which are
displayed.
Use the FUNCTION ∧ and ∨ buttons to
4.
enable or disable the function.
KEEP: No change.
CHANGE: The change is enabled.
When you have finished making the settings
5.
for each part, press the OK button.
Press the EXIT button.
6.
∨
Composer
On the REALTIME RECORDING display,
1.
press the PART SETTING button.
• The settings comprise 3 pages of the display. Use the
PAGE buttons to switch pages.
Use the PART ▲ and ▼ buttons to select a
2.
part.
Use the ∧ and ∨ buttons to set the corre-
3.
sponding item.
84
QQTG0701
<PAGE 1>
Part IV Composer
PITCH POINT:
The pitch at which the pattern progression
sound is lowered by one octave.
• When the root note of the specified chord is higher than
the set pitch point, the pitch of that part is automatically
lowered by one octave, thus avoiding an unnaturally high
accompaniment pitch.
• This is effective only for the part for which the Melody
group was selected in CHORD MODIFY CHANGE.
SOUND:
Use the panel buttons to select the sound.
DIGI EFF:
Set the DIGITAL EFFECT to on or off.
• (SOUND) is the initialized setting of the sound.
<PAGE 2>
BALANCE:
Adjust the volume balance.
PAN:
Adjust the stereo balance of each part (LEFT
64 – CENTER – RIGHT 63).
• At “LEFT 64”, the sound is all the way to the left, at
“RIGHT 63” all the way to the right. The center point is
CENTER.
REV:
Depth of the REVERB (0 to 127).
CHO:
Depth of the CHORUS (0 to 127).
BEND RANGE:
Adjust the range of pitch change when the
PITCH BEND data is received (0 to 12).
<PAGE 3>
EQ-Hi:
Sound correction in the high range.
• Use the FC ∧ and ∨ buttons to adjust the standard fre-
quency. Use the GAIN
change.
∧
and ∨ buttons to set the ratio of
EQ-Low:
Sound correction in the low range.
• Use the FC ∧ and ∨ buttons to adjust the standard fre-
quency. Use the GAIN
change.
∧
and ∨ buttons to set the ratio of
Playback
In the RHYTHM GROUP section, press the
1.
MEMORY button.
RHYTHM GROUP
METRONOME
POP ROCK
FUNK &
SOUL DISCO
WALTZ
& TRADUSA16 BEAT8 BEAT
POP BALLAD
JAZZ &
SWING
BALLAD
LATIN &
WORLD
BALLROOM
& SHOW
MEMORY
LOAD
• The display looks similar to the following.
Select the desired memory (A/B/C).
2.
Use the VARIATION buttons to select a varia-
3.
tion.
Press the START/STOP button.
4.
• The DRUMS part begins to play back.
• The BASS and ACCOMP parts are played back when
you use the AUTO PLAY CHORD.
Composer
85
QQTG0701
Part IV Composer
Step Record
Use STEP RECORD to store the notes one-by-one on the display. This is a convenient way to store complicated patterns that are difficult to play.
Recording procedure
While you are recording, press the STEP
1.
RECORD button.
• The display changes to the STEP RECORD display similar to the following.
Use the CURSOR buttons to move the cursor
2.
to the note position you are going to store.
• Each dot represents one-eighth of a quarter-note (a
thirty-second note).
• When storing triplets, it may not be possible to match the
timing exactly with the 1/32-note steps. However, if you
select triplet-type notes for the note length (LENGTH) in
step 4 below, the timing is automatically corrected.
Use the PAGE button to access the PAGE 2/2
3.
display.
Specify the pitch and velocity of the note by
6.
playing the keyboard.
• The dot on the display where the note is stored changes
∗
to a
mark.
• When recording chords, you can store multiple notes at
one position.
REST:To store a rest, after specifying the note
LENGTH, press the REST button.
• Positions at which nothing is stored are read as rests.
ERS:If you make a mistake, move the cursor to
the error, and after displaying the data
you wish to erase, press the ERS button.
Repeat steps 2 through 6 to continue storing
7.
notes.
• To record a different part, use the PART ∧ and ∨ buttons
to select another part.
• The NOTE, VELOCITY, LENGTH, CHORD MODIFY and
CONTROL can be revised later. Press the OK button
after the revision.
• You can easily switch between the REALTIME mode and
the STEP mode any time during recording. To return to
the realtime recording display during the STEP RECORD
mode, press the EXIT button.
Composer
Use the left LENGTH buttons to specify the
4.
3
3
note value. Select from
h, w, w
× 2 to 4. (A 3 denotes a triplet-type
, r,
r
x
, x,
3
, e,
e
note.)
• For note values other than these, use the right LENGTH
buttons to specify the note value to be added to that
which you specified with the left buttons.
Example: To record a dotted quarter-note (q.)
+
q
e
Use the PHRS ∧ and ∨ buttons to specify the
5.
actual length of the produced sound for the
desired legato or staccato effect.
TENU (tenuto): Sound is produced for 95%
of the note length.
NORM (normal): 80%
STAC (staccato): 50%
CUTT (cutting): 25%
3
, q,
q
86
QQTG0701
Part IV Composer
Measure Edit
You can edit the recorded data one measure at a time.
Select the function you wish to edit.
During recording, press the MEASURE EDIT
1.
button.
• The display looks similar to the following.
Select the function.
2.
Follow the procedure to edit the function (see
3.
below).
• Only the contents of the same pattern can be edited.
MEASURE COPY
Copy recorded data of specified measures to a
specified point.
• On the destination track, the new data replaces the cur-
rent measure contents.
START MEASURE:
Specify the start point to copy the selected
measures to.
Press the OK button.
3.
• The confirmation display appears. Press the YES button
to execute the function, or press the NO button to cancel
the function.
• If the FROM and TO parts are the same and the FROM
and TO measures overlap, copy is not possible.
MEASURE ERASE
Erase the recorded contents of specific measures.
• Note that only the contents of the measures are erased,
not the measures themselves; the length of the performance remains the same.
Use the PART ∧ and ∨ buttons to specify the
1.
part.
• If ALL is selected, data is erased from the specified measures of all the parts at one time.
Specify the measures you wish to copy from
1.
the source track (FROM).
• On the FROM side, specify the settings with the corresponding buttons.
PART:
Select the part to copy from. (If ALL is
selected, all parts are copied.)
FIRST MEASURE:
Specify the first measure to copy.
LAST MEASURE:
Specify the last measure to copy.
Specify where you wish to copy the selected
2.
measures to.
• On the TO side, specify the settings with the corresponding buttons.
PART:
Select the part to copy to.
Use the FIRST MEASURE ∧ and ∨ buttons to
2.
specify the start point (measure number).
Use the LAST MEASURE ∧ and ∨ buttons to
3.
specify the end point (measure number).
Press the OK button.
4.
• The confirmation display appears. Press the YES button
to execute the function, or press the NO button to cancel
the function.
Composer
87
QQTG0701
Part IV Composer
MEASURE DELETE
Delete specified measures from all parts at once.
• The length of the performance accordingly decreases by
the number of deleted measures.
Use the FIRST MEASURE ∧ and ∨ buttons, to
1.
specify the first measure to delete.
Use the LAST MEASURE ∧ and ∨ buttons to
2.
specify the last measure to delete.
• One measure is the smallest unit that can be deleted.
Press the OK button.
3.
• The confirmation display appears. Press the YES button
to execute the function, or press the NO button to cancel
the function.
• When the INTRO or ENDING measures are deleted, the
Maj and Min data are erased at the same time.
MEASURE INSERT
Insert blank measures at a specified point.
• The length of the performance accordingly increases by
the number of inserted measures.
Use the FIRST MEASURE button to select the
1.
point (measure) where the measures are to be
inserted.
Use the NUMBER OF MEASURE button to
2.
select the number of blank measures to insert.
• No more than 16 measures total can be inserted.
Press the OK button.
3.
• The confirmation display appears. Press the YES button
to execute the function, or press the NO button to cancel
the function.
• The Maj or Min data is inserted in the INTRO and ENDING at the same time.
Composer
Pattern Copy
Use this function to copy a pattern from a rhythm or from SEQUENCER data.
PATTERN COPY
Copy a rhythm to the COMPOSER.
• You can also copy a pattern from the MEMORY.
On the COMPOSER MENU display, select
1.
PATTERN COPY.
• The display looks similar to the following.
Select the pattern you wish to copy.
2.
• In the FROM box, specify the settings with the corresponding buttons.
GROUP: Group name
RHYTHM: Rhythm name
PATTERN: Pattern name
•If ALL is selected, all the patterns are copied.
Select the memory you wish to copy to.
3.
• In the TO box, specify the settings with the corresponding
buttons.
MEMORY: Memory name (A, B or C)
PATTERN: Pattern name
•If ALL is selected, all the patterns are copied.
Press the OK button.
4.
• When copying has been successfully completed, “COMPLETED!” appears on the display.
• If you wish to use the COMPOSER functions to edit the
copied data, press the EDIT button, and follow the procedure to record a pattern.
88
QQTG0701
Part IV Composer
Copying individual parts
䡲䡲䡲䡲
Use the PAGE ∧ and ∨ buttons to select
1.
PAGE 2/2.
• The display looks similar to the following.
On the FROM side, use the buttons to specify
2.
the part to copy from.
• For the DRUM part you can specify the DRUMS 1 or 2
part; for other parts you can specify a part other than a
DRUMS part.
Specify the destination on the TO side to
3.
which the part will be copied.
Press the OK button.
4.
SEQ TO COMPOSER COPY
Data from the SEQUENCER can be copied to a
COMPOSER memory. For example, you can
use a rhythm pattern on a song disk as the automatic accompaniment for your own performance.
Use the TRANSPOSE ∧ and ∨ buttons to
6.
change the key of the copied measures (−24
to +24).
• Units are in semitones.
Use the MEMORY ∧ and ∨ buttons to specify
7.
the COMPOSER memory to copy to.
Use the PATTERN ∧ and ∨ buttons to specify
8.
the pattern to copy to.
For each COMPOSER part, specify the
9.
SEQUENCER track from which to copy data.
• Use the PART ▲ and ▼ buttons to specify the part name,
and the TRACK ∧ and ∨ buttons to specify the track
number.
• Parts which are set to OFF are blank.
Press the OK button.
10.
• “COMPLETED!” is shown on the display.
• If you wish to use the COMPOSER function to edit the
copied data, press the EDIT button, and follow the procedure to record a pattern.
• In the case of INTRO or ENDING, if a measure contains
a Maj or Min command, it is reproduced in the other pattern as well.
Play back the song you wish to copy from
1.
SEQUENCER to confirm the tracks, the measures and the time signature you wish to copy.
Follow the procedure in “Prepare to record” to
2.
prepare the COMPOSER memory you will be
copying to. (Refer to page 82.)
• Be sure that time signature setting in the SEQUENCER
data you are copying from and the time signature in the
COMPOSER memory you are copying to are the same,
or the data will not be copied successfully.
On the COMPOSER MENU display, select
3.
SEQ TO COMPOSER COPY.
• The display looks similar to the following.
Use the FIRST MEAS ∧ and ∨ buttons to
4.
specify the number of the first measure to
copy.
Composer
Use the LAST MEAS ∧ and ∨ buttons to spec-
5.
ify the number of the last measure to copy.
89
QQTG0701
Part V Disk Drive
Floppy Disk Drive
Floppy disk
SAVE LOAD
Outline of the Disk Drive function
The Disk Drive enables you to store recorded and stored data from this instrument’s memories on disks,
as well as play commercial recorded disks on this instrument.
Internal memory and Disk Drive
The storable internal memory of this instrument
as well as the backup time are limited. However,
the Disk Drive maximizes your control of data
management by allowing you to store (SAVE)
this instrument’s data on disks, and then to recall
(LOAD) it at any time.
• The BACK UP data will not be erased even with the passage of time.
The following data can be saved/loaded:
䡲
PERFORMANCE
CURRENT PANEL (The current panel settings)
PANEL MEMORY
SEQUENCER
COMPOSER (MEMORY contents)
SOUND MEMORY
EFFECT MEMORY
BACKUP
MIDI & FAVORITES
• When creating or saving song data, it is recommended
that you use the performance data in the PERFORMANCE group.
Main parts of the Disk Drive
• Instead of using MIDI & FAVORITES as frequently
loaded and saved data, it is recommended that you save
it with other data as backup data.
•The SEQUENCER contents can be saved in one-song
increments (SEQUENCER SONG SAVE).
• Please use 2HD disks to load/save BACKUP data.
Eject button
Press to remove the disk from the Disk Drive.
Disk slot
• You can use 3.5 inch 2DD (720 KB) or 2HD (1.44 MB)
disks; however, 2HD disks formatted as 2DD cannot be
used.
Eject button
This indicator is lit continuously
as long as the power is on.
Disk Drive
90
QQTG0701
Part V Disk Drive
Using commercial song disks
Not only disks recorded on this instrument, but
also data from commercial song disks can be
read on this instrument.
• This instrument accepts the following file formats:
TECHNICS File format
Standard MIDI File format
Loading Technics File format disks
䡲䡲䡲䡲
Using Technics file format disks allows you load
SOUND EDIT, rhythm & accompaniments,
PANEL MEMORY and Song data into your
instrument to expand its potential even further.
About Standard MIDI Files
䡲䡲䡲䡲
“Standard MIDI File” (SMF) is a standardized
data format which makes it possible for music
data to be exchanged among different sequencers. Data stored in this format on sequencers of
different models can be played back on this
instrument, and vice versa. Note, however, that
Standard MIDI Files ensure the compatibility of
data such as NOTE data (keyboard performance
data), VELOCITY (how hard the keyboard is
played), PROGRAM NUMBER data (voice number data), etc. Because it does not guarantee
100% faithful reproduction of recorded music
which is replete with such data, it may be necessary for you to adjust the settings to your satisfaction.
• Only files with the “.MID” extension can be loaded.
• Standard MIDI File FORMAT 1 can be loaded, but not
saved.
• This instrument’s SEQUENCER data can be saved to a
disk in Standard MIDI File (FORMAT 0) and can be used
by other equipment.
Playback of commercial song disks
DIRECT PLAY lets you enjoy playing commercially sold song disks directly from a disk. It’s fast
because you don’t have to load the disk data into
your instrument’s memory.
• DIRECT PLAY is possible from the following disks:
Standard MIDI File
Standard MIDI File with Lyrics
DISK ORCHESTRA
COLLECTION™ (DOC)
PianoDisc™
*All product and company names are trademarks or
registered trademarks of their respective owners.
*DISK ORCHESTRA COLLECTION is a trademark of
the YAMAHA Corporation.
SMF with LYRICS
䡲䡲䡲䡲
SMF with LYRICS is a format in which character
information that is included with the MIDI data,
such as karaoke lyrics, can be displayed. This
instrument supports this format, making it possible to view the lyrics on the display while a performance is played back.
GENERAL MIDI LEVEL 2 (GM2)
䡲䡲䡲䡲
This instrument complies with GENERAL MIDI
(GM) LEVEL 2 standards. GM LEVEL 2 is a uniform world standard for MIDI sound generators
that improves on existing GM standards, in order
to realize an enhanced performance expression.
Sound generators of this class can reproduce virtually the identical conditions that were in effect
at the time of recording.
Equipment which conforms to GENERAL MIDI
LEVEL 2 standards is indicated by the following
logo.
• This instrument also conforms to GENERAL MIDI playback.
91
QQTG0701
Disk Drive
Part V Disk Drive
LOAD
DISK
IN USE
DISK
Outline of the procedure
Insert the disk into the Disk Drive slot. Push it
1.
all the way in until you hear a click.
• On this instrument, if the normal display is active, it automatically changes to the DISK MENU display when a disk
is inserted into the Disk Drive (initialized settings). The
PREFERENCES menu is used to specify which display is
shown when a disk is inserted.
Select a menu on the DISK MENU display.
2.
• If the DISK MENU display does not appear, turn on the
DISK button.
Follow the procedure for the function (see
3.
below).
• When function is being set, if the TEMPO/PROGRAM
indicator is lit, the TEMPO/PROGRAM is available for
setting the current function.
When you have finished setting the functions,
4.
turn off the DISK button.
FADE
AUTO PLAY CHORD
SPLIT
ONE TOUCH
MAIN
OFF/ON
PLAY
POINT
MODE
VOLUME
MAX
CHORD FINDER
PROGRESSIVE
PIANIST PIANO STYLIST
MIN
1 2 1 2 1 1 2 3 4 BEAT
MUSIC STYLE ARRANGER
VARIATION
DEMO
APC/SEQUENCER
VOLUME
MAX
OFF
IN OUT
FILL IN INTRO & ENDING
SEQUENCER
RESET
RHYTHM GROUP
FUNK &
BALLROOM
SOUND
METRONOME
POP ROCK
SOUL DISCO
POP BALLAD
BALLAD
& SHOW
ARRANGER
SET
LATIN &
JAZZ &
WALTZ
MEMORY
WORLD
SWING
& TRADUSA16 BEAT8 BEAT
CONTRAST
LOAD
234
SYNCHRO & BREAK
START / STOP TAP TEMPO
-
COUNT
INTRO
TRANSPOSE
■■■■ About the menu
LOAD (page 93)
Load data from a disk into this instrument’s
memory.
SAVE (page 97)
Save data from this instrument’s memory to a
disk.
DIRECT PLAY (page 95)
Direct playback of SMF etc. commercial song
disks and medley playback.
TEMPO / PROGRAM
+
SAX &
ORGAN &
WOODWIND
ACCORDION
SYNTH
PIANO
ORCH
DIGITAL
MIXTURES
DRAWBARS
DRUM KITS
MODERN SIMPLE PIANO TECHNI-CHORD BANK
SEQUENCER
EASY
PROGRAM
CONDUCTOR
LEFT RIGHT 2 RIGHT 1
AB
REC
FAVORITES
CHORD STEP REC
C
SET 1 / 5 2 / 6 3 / 7 4 / 8
PANEL MEMORY
DISK
MENUS
IN USE
DISK
LOAD
DIGITAL
MULTI
EFFECT
EFFECT
CHORUS REVERB
P.MEM 5-8
SOUND
EXPLORER
MEMORY
SOUND GROUP
GUITAR &
STRINGS
VOCAL
HARPSI BRASS PLAY
MALLET &
BASS
ORCH PERC
MIXTURES
HELP
OTHER PARTS/TR
MUTE
WORLD
DISPLAY HOLD
EXIT GRAND
UPRIGHT ELECTRIC
PAGE
PIANO
DISK IN USE
䡲䡲䡲䡲
DISK
DISK
IN USE
LOAD
This indicator lights when data is being loaded or
saved.
• To prevent data loss, do not eject the disk or turn off the
power while this indicator is lit.
DISK IN USE
DISK
IN USE
DISK
LOAD
SONG MEDLEY (page 96)
Medley playback of songs in the disk (Technics format).
DISK TOOLS (page 99)
Disk management procedures, such as disk
format.
PREFERENCES (page 100)
Used to specify which screen is to be jumped
to as well as the preferred file when a disk is
inserted.
Disk Drive
92
QQTG0701
Part V Disk Drive
Loading data
Recall (load) the data from the disk to this instrument’s memories.
• Note that the load procedure causes any data which is currently stored in the relevant memories to be erased.
LOAD
Load data that saved to a disk into this instrument’s memory.
Insert the disk with the stored data into the
1.
Disk Drive. Push it all the way in until you hear
a click.
On the DISK MENU display, select LOAD.
2.
• The display looks similar to the following.
• The display looks similar to the following.
Use the buttons below the display to specify
2.
the types of data you wish to load (YES/NO).
• - - - - - indicates that this type of data has not been saved.
• This setting is canceled when you quit the LOAD display
or when another file is selected.
Press the LOAD button.
3.
• The LOAD operation begins.
SINGLE LOAD
䡲䡲䡲䡲
You can specify which data to load from a disk
into a specific PANEL MEMORY, COMPOSER
(MEMORY), SOUND MEMORY, EFFECT
MEMORY or SEQUENCER (when SONG SAVE
was executed) memory.
• If there are only SMF files on the disk, the display automatically changes to the SMF LOAD display.
Use the buttons below the display to select the
3.
song (Technics file) you wish to load.
• If there are SMF files on the disk and you wish to load an
SMF file, press the SMF button. (Refer to next page.)
Press the LOAD button.
4.
• The LOAD operation begins.
• When the operation has been successfully completed,
“COMPLETED!” is shown on the display.
• If song data was loaded, you can press the
START/STOP button to begin playback when the
SEQUENCER PLAY display is active.
• You can load the type of data for which only one song
can be recorded in the SEQUENCER. (This type is available for disks used with older Technics models.) Note,
however, that in this case, the song is loaded into SONG
1, but the data in SONG memories 2 to 10 are erased.
• You can also access the LOAD display by pressing the
DISK button for a few seconds.
LOAD OPTION
䡲䡲䡲䡲
Specify the kind of data you wish to load from the
disk to your instrument.
Use the PAGE buttons to access the PAGE
1.
2/3 LOAD OPTION display.
Use the PAGE buttons to access the PAGE
1.
3/3 SINGLE LOAD display.
• The display looks similar to the following.
Use the MODE button to select the data you
2.
wish to load.
Use the BANK/SINGLE button to select the
3.
load increment. (except for SEQUENCER)
BANK:
Load one bank at a time.
SINGLE:
Load the smallest data increment.
Follow the appropriate procedure to load the
4.
specified data.
• Specify the data source for SONG (left side), and the
data destination (this instrument’s memory location) for
TO.
Disk Drive
93
QQTG0701
Part V Disk Drive
SMF LOAD
䡲䡲䡲䡲
Load data which was saved in the “Standard
MIDI File” (SMF) format.
On the LOAD (PAGE 1/3) display, press the
1.
SMF button.
• The display looks similar to the following.
• For disks which contain SMF files only, this display
appears automatically when LOAD is selected on the
DISK MENU display.
Use the buttons below the display to select the
2.
filename you wish to load.
• If the number of files is 10 or more, you can use the
PREV and NEXT buttons to go back or advance 10 files
at a time.
• If you press the TECH button, the display changes to the
LOAD display for Technics format.
• You can use the INFORMATION button to switch the displayed data.
DISK: Disk name
SONG: Song name
Press the LOAD button.
5.
• The LOAD operation begins.
• When the operation has been successfully completed,
“COMPLETED!” is shown on the display.
• If you press the START/STOP button, playback of the
loaded data begins.
• During the LOAD operation, data that cannot be processed by this instrument is ignored.
COMPOSER LOAD
䡲䡲䡲䡲
Load COMPOSER data only from a disk.
In the RHYTHM GROUP section, press and
1.
hold the LOAD (MEMORY) button for a few
seconds.
RHYTHM GROUP
METRONOME
POP ROCK
• The display looks similar to the following.
FUNK &
SOUL DISCO
WALTZ
& TRADUSA16 BEAT8 BEAT
POP BALLAD
JAZZ &
SWING
BALLAD
LATIN &
WORLD
BALLROOM
& SHOW
MEMORY
LOAD
Use the TO SONG button to select the num-
3.
ber to load to (this instrument’s SEQUENCER
song number).
• Songs to load are specified one at a time.
• The song name to load to is shown below the TO SONG
button.
Use the LOAD AS button to specify the load
4.
method.
Select from the following.
GM/GM2 → GM2:
Activate the GM2 initialized settings, and
load GM/GM2 data.
NX → NX:
Active the NX SOUND settings, and load
NX data.
GM/GM2 → NX:
Activate the NX SOUND initialized settings,
and load GM/GM2 data.
PREV. TEC → NX:
Activate the NX SOUND initialized settings,
and load SMF data that was saved in the
TECHNICS mode on a previous model.
(The volume balance and octave settings
may differ from the saved settings.)
Select the name of the file you wish to load.
2.
Press the LOAD button.
3.
• Data is loaded to this instrument’s COMPOSER memory
(MEMORY).
• If you select the setting which is different from that in
which the song was stored, the sounds, octaves, and
arrangement of percussion instrument sounds, etc. will
Disk Drive
be different.
94
QQTG0701
Part V Disk Drive
Direct Play
You can enjoy immediate playback of “Standard MIDI File” (SMF), “Disk Orchestra Collection” (DOC) and
“PianoDisc” disks—all without loading the song data.
Insert the disk with the stored data into the
1.
Disk Drive.
On the DISK MENU display, select DIRECT
2.
PLAY.
• The display looks similar to the following.
<Example: SMF>
Use the buttons below the display to select the
3.
song you wish to have played.
• If the number of files is 10 or more, you can use the
PREV and NEXT buttons to go back or advance 10 files
at a time.
• For SMF files, use the PLAY AS button to specify a
sound arrangement mode.
GM2: GENERAL MIDI LEVEL 2
NX: NX SOUND
PREV. TEC: Data from Technics instruments
not having NX SOUND capability.
• For SMF files, you can use the INFO button to switch the
displayed data.
DISK: Disk name
SONG: Song name
• For SMF files, use the MIDI OUT button to specify
whether or not MIDI data is output during playback
(ON/OFF). (This cannot be changed during playback.)
Press the START button.
4.
• The selected song is played back.
The display during playback
䡲䡲䡲䡲
<Example: SMF>
Next song
Fast forward
Play/pause
Stop
Previous song
• During playback, the buttons below the display are used
for player functions such as fast forward, pause, etc.
• During playback, if you press the MIXER button you can
change the settings for each part.
• If you press the MIC button during playback, the display
changes to the MIC REVERB & EFFECT setting display.
• For SMF disks:
For “SMF with LYRICS” disks, by pressing the LYRICS
button, the lyrics are shown on the display.
For a “minus one” performance, use the TRACK MUTE
∧, ∨∨∨∨
buttons to select the channel you wish to mute. Use
the ON/OFF buttons and set the track you want to MUTE
to ON. Following this, you can play a keyboard performance on the channel which was last set to MUTE.
• For DOC disks:
You can use the CH 1, CH 2 and ORC (other accompaniment parts) buttons to set the respective parts to ON or
OFF.
• For PIANO DISC playback:
You can use the CH 1 and ORCH (other accompaniment
parts) buttons to set the respective parts to ON or OFF.
Adjusting the playback tempo
䡲䡲䡲䡲
Even with a song having recorded tempo data,
you can use TEMPO/PROGRAM or TAP
TEMPO to adjust the tempo to your liking.
• When the tempo is changed, all the tempo data of that
song is automatically changed by the same ratio. Accordingly, even in song data in which tempo change data is
stored, a single adjustment of the tempo produces a natural-sounding playback.
Disk Drive
95
QQTG0701
Part V Disk Drive
MEDLEY PLAY
䡲䡲䡲䡲
With DIRECT PLAY, songs saved on a disk can
be played back continuously in a medley.
On the DIRECT PLAY display, set the MED-
1.
LEY settings.
• If ALL is pressed, all the files are selected, and the songs
are played back in order in a medley. If ALL is pressed
again, the files are deselected.
• You can use the buttons below the display to select a
song to add to the song list, then press the ADD button to
add it to the list. Repeat these steps to create your own
list of songs to have played back. M01, M02 etc. next to
the file name indicates its order in the list.
• If the number of files is 10 or more, you can use the
PREV and NEXT buttons to go back or advance 10 files
at a time.
• You can delete a marked file from the medley song list by
selecting it and pressing the ADD button.
• Use the LOOP button to specify ON or OFF for repeat
playback of the medley.
Song Medley
Press the START button.
2.
• Medley playback begins.
• During medley playback, you can use the SKIP button to
skip to the next song.
Songs saved from the SEQUENCER to a disk (disk data) in the TECHNICS FORMAT can be played back
in a medley.
On the DISK MENU display, select SONG
1.
MEDLEY from the display.
• The display looks similar to the following.
Select the order of files in the medley.
2.
• If ALL is pressed, all the files are selected, and the songs
are played back in numerical in a medley.
• You can select a file and song, then press the ADD button to add it to the song list. Repeat these steps to create
your own list of songs to have played back. M01, M02
etc. next to the file name indicates its order in the list.
• You can delete a marked file from the medley song list by
selecting it and pressing the ADD button.
• Use the LOOP button to specify ON or OFF for repeat
playback of the medley.
• You can use the MODE button to select the medley
mode.
• During a medley performance, if you press the MIXER
button you can change the settings for each part.
• During a medley performance, you can use the SKIP button to skip to the next song.
• If the disk contains SMF or other files, but no TECHNICS
FORMAT file, the display changes to the DIRECT PLAY
display.
10 SNGS:
Songs 1 to 10 from each SONG are
played in a medley.
1 SONG:
Only song 1 from each SONG is played
back in a medley.
Press the START button.
3.
• Medley playback begins.
Disk Drive
• During the performance, the display changes to the playback display.
96
QQTG0701
Part V Disk Drive
Storage is not
possible
Storage is
possible
Open Closed
Saving data
The recorded data and panel settings of this instrument can be saved on a disk.
TECHNICS FORMAT
Disks
You can use 3.5 inch 2DD (720KB) or 2HD
(1.44MB) disks.
• How to distinguish the two disk types:
䡲䡲䡲䡲
2DD
No hole
• Although 2HD disks can hold more data and are convenient for quick loading and saving, some models may be
able to read only 2DD disks. Therefore, you may not be
able to use your 2HD disk data with other musical instrument models.
• When saving data to the disk, the write-protect tab must
be closed.
Hole
2HD
SAVE
Insert a formatted disk into the Disk Drive slot.
1.
Push it all the way in until you hear a click.
• A disk which is used with this instrument for the first time
must first be formatted.
On the DISK MENU display, select SAVE.
2.
• The display looks similar to the following.
Use the buttons below the display to specify
1.
the file number you wish to save to.
• The types of data that can be saved are shown in a frame
on the right side of the display. If you press the SAVE
button, all the indicated data is saved. Ordinarily PERFORMANCE data is selected, but you can use the SAVE
OPTION to select specific data to save.
If you wish to assign a name to the file, press
2.
the NAME button.
• The display looks similar to the following.
Use the buttons below the display to assign a
3.
name.
• Set the character input position with the POSITION buttons, select the characters with the alphanumeric buttons
and repeat name assignment.
• Press the INS button to enter a space at the cursor position.
• Press the DEL button to erase the character at the cursor
position.
• Press the CLR button to erase the entire name.
• Press the →← button to center the name.
Select the type of data save you want.
3.
TECHNICS FORMAT:
Save this instrument’s data in the Technics
File format.
SMF FORMAT 0:
Save the SEQUENCER data in the “Stan-
dard MIDI File” format (FORMAT 0).
Press the OK button.
4.
• The display returns to the SAVE display.
Press the SAVE button.
5.
• The SAVE operation begins.
• If you attempt to save data to a file number in which data
is currently saved, the display changes to the confirmation display. Press the YES button to continue the SAVE
procedure, or press the NO button if you wish to cancel it.
QQTG0701
Disk Drive
97
Part V Disk Drive
<SAVE OPTION>
Specify the kind of data you wish to save to the
disk. To maximize effective use of disk memory
or to minimize the save time, select only the type
of data you wish to save.
Use the PAGE buttons to access the 2/3
1.
SAVE OPTION display.
• The display looks similar to the following.
Use the buttons below the display to specify
2.
the types of data you wish to save (YES/NO).
• For PANEL MEMORY, select from NO/1 BANK/ALL.
Selecting 1 BANK will save only bank A.
• Press the PERFORM button to select all the performance
data, or press the BACKUP button to select all the back
up data at once.
• If the ALL OFF button is pressed, all the settings change
to NO.
Press the SAVE button.
3.
• The SAVE operation begins.
SMF FORMAT 0
䡲䡲䡲䡲
This instrument’s SEQUENCER data can be
saved in the “Standard MIDI File” format (FORMAT 0) for use on other instruments.
• What you can save in the SMF format (FORMAT 0) is
ordinary performance data, such as note data. Data such
as chord and rhythm data, COMPOSER data, etc. is not
saved. If you wish to also save this special Technics
data, save the data in the Technics File format.
• If you use the APC TO SMF CONVERT function of the
SEQUENCER, you can convert the patterns of the automatic accompaniment, etc. to SMF data. (Refer to page
78.)
To overwrite a file, use the ▲ and ▼ buttons
1.
and then select a song name.
• If the number of files is 10 or more, you can use the
PREV and NEXT buttons to go back or advance 10 files
at a time.
If you wish to assign a name to the file, press
2.
the NAME button.
<SEQUENCER SONG SAVE>
You can specify a single song in the
SEQUENCER to save to the disk.
Use the PAGE buttons to access the 3/3
1.
SEQUENCER SONG SAVE display.
• The display looks similar to the following.
Use the buttons below the display to select the
2.
song number you wish to save.
Press the SAVE button.
3.
• The SAVE operation begins.
Use the buttons below the display to assign a
3.
name.
Press the OK button.
4.
• The display returns to the SAVE display.
Use the FROM SONG buttons to select the
5.
SEQUENCER song number you wish to save.
• The song name to save from is shown below the FROM
SONG button.
Use the PANEL HEADER buttons to specify
6.
ON or OFF.
ON:
The sound and volume settings for each
part are saved as data at the beginning of
the file.
OFF:
This data is not saved.
Use the 1 MEASURE SPACE buttons to
7.
select ON or OFF.
ON:
A one-measure space is added to the
beginning of the file.
OFF:
No space is added.
Disk Drive
• When there is various data other than performance data
stored at the beginning of a file, the start of playback may
be delayed. This can be avoided by set the 1 MEASURE
SPACE to ON to inserting a before the beginning of the
performance.
98
QQTG0701
Part V Disk Drive
• When set to ON, a space is added each time a file is
saved. Therefore, if you have already saved a file once
with the 1 MEASURE SPACE set to ON, please set it to
OFF each time the file is subsequently saved.
Use the SAVE AS button to select the sound
8.
generator mode (GM/GM2/NX).
Press the SAVE button.
9.
• The SAVE operation begins.
• When the operation has been successfully completed,
“COMPLETED!” is shown on the display.
• If you attempt to save data to a file name in which data is
currently saved, the display changes to the confirmation
display. Press the YES button to continue the SAVE procedure, or press the NO button if you wish to cancel it.
Disk management
Various disk management procedures, such as file delete, file copy, and disk format, are available from
the DISK TOOLS menu.
DISK TOOLS
Insert the disk into the Disk Drive slot.
1.
On the DISK MENU display, select DISK
2.
TOOLS from the display.
• The display looks similar to the following.
FORMAT display appears. Follow the instructions shown to format the disk.
• Note that this procedure clears any data which is currently stored on the disk.
Select the type of format (2DD or 2HD).
1.
• Be sure to select the type which is the same as your disk
type.
• If the type is automatically detected, the display changes
directly to the following display, without showing the type
select display.
• The display looks similar to the following.
Select a function and follow the procedure to
3.
execute it.
• Use the buttons below the display to select a file.
• You can press the SMF/TECH button to change to the
display for procedures related to SMF/TECH files.
• Use the buttons to the left and right of the display to
access the corresponding setting display.
RENAME:
䡲䡲䡲䡲
Assign a name to a file.
DEL:
䡲䡲䡲䡲
Delete a file.
COPY (TECH):
䡲䡲䡲䡲
Copy a file.
MOVE (TECH):
䡲䡲䡲䡲
Replace a file.
INFO (DISK/SONG) (SMF files only):
䡲䡲䡲䡲
Select whether to display the disk data or the
song names.
FORMAT
䡲䡲䡲䡲
Disks which are used for the first time with this
instrument have to be formatted through the following procedure. When an unformatted disk is
inserted into the Disk Drive slot and you attempt
to execute the save or load procedure, the DISK
• If you wish to select the type again, use the PAGE button
to access the PAGE 2/2 display.
Press the YES button to format the disk, or
2.
press the NO button to cancel the format.
• When the YES button is pressed, disk format begins.
After about 1–2 minutes, formatting is completed and
DISK NAMING display is shown.
Use the buttons below the display to assign a
3.
name.
• Set the character input position with the POSITION buttons, select the characters with the alphanumeric buttons
and repeat name assignment.
• Press the INS button to enter a space at the cursor position.
• Press the DEL button to erase the character at the cursor
position.
• Press the CLR button to erase the entire name.
• Press the →← button to center the name.
Press the OK button.
4.
Disk Drive
99
QQTG0701
Part V Disk Drive
Set the automatic display when a disk is
inserted
When a disk is inserted in the Disk Drive, the display automatically changes to a disk-procedure display.
Follow this procedure to customize the automatic display.
PREFERENCES
On the DISK MENU display, select PREFER-
1.
ENCES.
• The display looks similar to the following.
Use the buttons to the left of the display to
2.
select the item, and the
change the setting.
and ∨ buttons to
∧
DISK INSERT OPTION:
The display automatically changes to a diskprocedure display when a disk is inserted in
the Disk Drive (OFF, DISK MENU, LOAD,
DIRECT PLAY, SONG MEDLEY).
• During playback, recording or changing the settings, the
displays unrelated to the settings made here do not
change.
FILE TYPE PRIORITY:
Specify the desired priority ranking of displayed files when several types of files are
recorded on one disk (TECHNICS/SMF).
Press the OK button.
3.
Disk Drive
100
QQTG0701
Loading...
