Technics DP-1810P User Manual

Digital Imaging Systems

Operating Instructions

(For Copier)

Model No. DP-1810P

Getting T o Know Y our

Before StartingMaking CopiesOptionsOthers

Machine

Before operating this equipment, please read these instructions completely and keep these oper ating
instructions for future reference.

English

J
?

I

IMPORTANT INFORMATION

When requesting information, supplies or service always refer to the model and serial number of your
machine. The model and serial number plate (Main Name Plate) is located on the rear side of machine.
For your con venience, space is provided below to record information you may need in the future.

Model No.

Serial No.

Date of Purchase

Dealer

Address

Telephone Number
()

Supplies T elephone Number
()

Service T elephone Number
()

(Digital copier with ADF option)

Model and Serial Number

2

Copyright  2002 by Matsushita Graphic Communication Systems , Inc.

All rights reserved. Unauthorized cop ying and distrib ution is a violation of la w. Printed in Japan.

The contents of these Operating Instructions are subject to change without notice.

Operation Chart

Common Features and Usage

■■

■ Basic Operation

■■

Getting T o Know Y our

Machine

Original

INV

INVOICE R

1

Place the
Original

LTR

LGL

LEGAL

LETTER R

Load Paper

Turn Power
Switch On

■■

■ Position of the Original

■■

Original Guide

INV

INV

INV
LTR
LGL

LTR
LDR

INVOICE

LDR

Original Size

(Reduction/
Enlargement
Only)

LEDGER



2

C Place originals face down on the platen or face up on

the ADF.

C If the original is not positioned properly, a portion of the

original may not be copied.

C For originals smaller than in v oice size , position the

original within the area of INVOICE and select inv oice.

3

Copy Size

(Reduction/
Enlargement
Only)

4

Number
of Copies

5

Press

START

■■

■ Commonly Used Functions and Operating Procedures

■■

Full Size

Makes a copy that is the same
size as the original

Reduction or Enlargement

Copies the original at a fixed
reduction or enlargement ratio

■■

■ Memory Capacity

■■

When the memory becomes full during original scanning, the message “Function not av ailab le
for lack of memory” will be displayed in the message displa y. In this case , f o llow the oper ating
instruction in the message display.
When additional memory is required, consult with an authorized servicing dealer .

145
13425

(See page 12)

(See page 13)

3

Energy Star

As an ENERGY STAR® Partner, Panasonic has determined that this product meets the

ENERGY STAR

This voluntary program specifies certain energy consumption and usage standards. This product
will automatically “power do wn” after a specified period of non-use. The use of this ENERGY

®

STAR

environment.
The default functions can be adjusted depending on your office requirements .

Please see your authorized P anasonic dealer f or more details.

compliant product will reduce energy consumption and ultimately benefit the

®

guidelines for energy efficiency.

4

Table of Contents

Getting T o Know Y our Machine

Operation Chart .............................................................................................................................. 3

■ Common Features and Usage..............................................................3

Energy Star ..................................................................................................................................... 4

Before Starting

Precautions..................................................................................................................................... 7

■ For Y our Safety .....................................................................................8

■ Handling ...............................................................................................8

■ Toner and Paper ...................................................................................8

■ Ventilation.............................................................................................8

■ Installation ............................................................................................9

Control Panel ................................................................................................................................10

Making Copies

Basic Copy.................................................................................................................................... 12

■ Full Size Copying................................................................................12

■ Reduction or Enlargement Copying ....................................................13

■ Zoom Copying ....................................................................................14

■ Using the Sheet Bypass .....................................................................15

Creative Features ......................................................................................................................... 16

■ 2 in 1 Copy .........................................................................................16

■ 2 Page Copy.......................................................................................17

■ Book/Edge/Margin ..............................................................................18

■ Job Memory .......................................................................................19

■ Sort Copy ...........................................................................................20

Other Features.............................................................................................................................. 21

■ Energy Saver/Interrupt Mode..............................................................21

■ Skyshot Mode.....................................................................................22

Combined Function T able ............................................................................................................ 24

Function ........................................................................................................................................ 25

■ Checking the Copier’s Total Counter ...................................................25

■ General Functions ..............................................................................26

■ Copier Settings ...................................................................................27

■ General Functions for Key Operator ...................................................28

■ Copier Settings for Ke y Operator........................................................29

■ Function Setting..................................................................................30

■ Function Setting for Key Oper ator.......................................................31

Table of Contents

5

Table of Contents

Options

Accessories .................................................................................................................................. 35

■ Components .......................................................................................35

■ Automatic Document Feeder ..............................................................36

Problem Solving

Problem Solving ........................................................................................................................... 38

■ Adding Paper (J) ...............................................................................38

■ Adding the Toner and Replacing Toner Waste Container (?) ..............39

■ Removing a Misfed Paper...................................................................41

Troubleshooting............................................................................................................................ 46

■ Before Calling Service ........................................................................46

■ User Error Codes (U Code) ................................................................48

Others

Specifications ............................................................................................................................... 49

Options and Supplies................................................................................................................... 51

6

Precautions

For Y our Safety

■■

■ Laser Safety

■■

LASER SAFETY

This unit employs a laser. Only qualified service personnel should
attempt to service this device due to possible ey e injury.

CAUTION:

USE OF CONTROLS, ADJUSTMENTS OR PERFORMANCE
PROCEDURES O THER THAN THOSE SPECIFIED HEREIN MAY
RESULT IN HAZARDOUS RADIATION EXPOSURE.

■■

■ Caution Labels

■■

Before Starting

(Digital copier with ADF option)

(Digital copier with ADF option)

Manufacturer’ s name and address Factory ID

7

Precautions

Handling

■ Do not look directly at the exposure lamp when

copying.

■ Do not turn the power switch Off or open the front

panel during copying.

C Do not drop paper clips or other metal objects into

the copier.

Toner and Paper

Ventilation

■ Store toner, drum and paper in cool areas with low

humidity.

C High quality paper of 16 - 24 lb (60 – 90 g/m2) [15 –

34 lb (56 – 128 g/m2) using the sheet bypass] may
be used.

C For optimum perf ormance, it is recommended that

only Panasonic Brand supplies are used in the
copier.

■ The copier should be installed in a well-ventilated

area to minimize the ozone density in the air .

8

Installation

Precautions

■ The copier should not be installed in areas with the

following conditions:

C Extremely high or low temperature and humidity.

Ambient conditions

Temperature: 50°F – 95°F (10°C – 35°C)
Relative humidity: 45% – 85%

C Where temperature and humidity can change

rapidly, causing condensation.

C Direct exposure to sunlight.
C Directly in the air conditioning flow.
C In areas of high dust concentration.
C In areas of poor ventilation.
C In areas with chemical fume concentration.
C In areas with extreme vibration.
C With unstable or unev en conditions (floors , etc.).

Before Starting

■ The maximum power consumption is 1.5 kW .

A properly wired (grounded), dedicated, 15A, 120 VAC outlet is required. Do not use an extension
cord.
The power cord on this equipment must be used to disconnect the main power. Please ensure
that the socket outlet is installed near the equipment and is easily accessib le .

FCC WARNING For U.S.A.

FCC W ARNING:

This equipment has been tested and found to comply with the limits f or a Class A digital de vice ,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications . Operation of this equipment in a residential area is likely
to cause harmful interference in which case the user will be required to correct the interference
at his/her own expense.

The user could lose the authority to operate this equipment if any unauthorized changes or
modifications are made to this equipment.

CAUTION

CTHIS PRODUCT CONTAINS A LITHIUM BATTERY. DANGER OF EXPLOSION IF

BATTERY IS INCORRECTLY REPLACED .
REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE. DISPOSE OF USED
BA TTERIES ACCORDING T O THE INSTRUCTIONS OF Y OUR LOCAL SOLID WASTE
OFFICIALS.

9

Control Panel

No Contents Refer to

#

$

%

&

(

)

* Original Mode Select Key (Photo;Text/Photo;Te xt) Page 12

2 in 1 Key

C From two 1-sided originals, side by side, to 1-sided copies.

2 Page Copy Key

C Copying two facing pages on a ledger size original on two separate

letter size sheets.

Sort Key

C When using Electric Sorting Mode. Optional memory is required.

Margin Key

C Shifts the image to the right or left.

Edge Key

CCreates a blank edge.

Book Key

C Eliminates dark inner binding shadows.

Page 16

Page 17

Page 20

Page 18

Page 18

Page 18

10

+ Exposure Keys (Darker, Lighter) Page 12

-

.

/

0

1

NOTE

SET Key

C Set the present selection.

Function Key

C Use when changing the paper size, initial values for functions (def ault

values) and ke y oper ator settings.

Clear Key

C Clears the copy count in the display.

Energy Saver Ke y

C Can save power while the copier is not in use.

Reset Key

C Resets all features to the initial power-on state.

C The Control Panel displayed above shows only copier functions. Please refer to the

operating instructions in the Panasonic Document Management System CD-R OM f or
the Printer control panel functions.

——

Pages 25– 34

——

Page 21

——

LCD Display



Warning Indications

Control Panel

Before Starting

J Add Paper
? Add T oner
I Misfeed

2 Call Service

No Contents Refer to

2

3

4 Interrupt Key , Memory In Key , M1/M2 Keys Pages 19 – 21

5

6

7

8

9

Stop Key

C Stops the copy run.

Start Key

C Used to start an operation.

Cursor Keys

C Select copy ratio and function modes using (G or F).

Paper T ray Key

C Used to select the paper tray manually.

Copy Size Key

C Used to select Reduction/Enlargement only. For additional details ,

see page 13.

Original Size Key

C Used to select the original size manually. F or additional details,

see page 13.

Print Key

C When selecting the Printer ON/OFF Line.

NOTE

C The Control Panel displayed above shows only copier functions. Please refer

to the operating instructions in the Panasonic Document Management
System CD-ROM for the Printer control panel functions.

——

——

——

——

——

——

——

11

Basic Copy

Full Size Copying

■■

■ Copying the Same Size Originals (1:1)

■■

Copy size is automatically selected.



Original Size Key

Clear Key

1

Place the Original

LCD Display (Sample)

READY TO COPY
COPIES:001

Select the Original Size on units
without the ADF Option.

■■

■ Manually Selecting Exposure Control or Original Type

■■

# Select the original type

Photo : Originals are mainly composed of photo .
Text/Photo: Combined originals with text and photo.
Text : Originals are mainly composed of te xt.

$ Select exposure control

Press the Darker/Lighter keys to adjust the e xposure .

Number of Copies*
Up to 999

2

3

Press START**

12

NOTE

Use Clear key when canceling the copy count.

∗

While the copier is warming up, you ma y position y our original on the copier, enter

∗∗

your cop y job selections and press the Start ke y.The COPY JOB RESERVED
indicator displays until the warm up cycle is completed and the copy job will
automatically start.

Reduction or Enlargement Copying

■■

■ Copying with Preset Ratios

■■

Basic Copy

Reset



1

Place the
Original

2

Select the

Original Size

3

Select the Copy

Size

Example: Reduction
Original size Copy size

4

Number of
Copies

LEDGER LETTER

LDR ->LTRB [LTRB ]
ZOOM: 65% COPIES:001

The correct ratio is automatically selected.
Reduction and enlargement ratios (%)

Original

size

Ledger

Legal
Letter

Invoice

Ledger Legal Letter Invoice

100 77 65 50
121 100 79 61
129 100 100 65
200 155 129 100

Copy size

5

Press START

Making Copies

NOTE

C When changing the paper tray, touch the

Paper T ray key.

C If the desired copy size is different from the paper size loaded in the paper

tray, use the sheet bypass. (See page 15)

C Press the RESET key to cancel all job settings .

13

Basic Copy

Zoom Copying

■■

■ Zoom

■■

Copies with variable zoom ratios from 50% to 200% in 1% increments .



Reset

1

Place the
Original

2

Select Original Size
(without using ADF)

LTR ->LTRB [LTRB ]
ZOOM:125% COPIES:001

3

Press Cursor (G or F)
keys to select Zoom Ratio

B

(Example: 125% Zoom)

4

Number
of Copies

5

Press

START

14

ATTENTION

NOTE

C When changing the paper size after setting the zoom ratio, please use the paper tray

key .

C Press the RESET key to cancel all job settings .

Using the Sheet Bypass

■■

■ Copying on Special Paper, etc.

■■

Basic Copy

Place the original.

1
2

3

Open the sheet bypass.

Sheet Bypass

Pull out the sheet bypass tray
until it stops.
(For Ledger size only)

Making Copies

# Place the sheets of paper into

the tray. (approximately up to
50 Letter size sheets/20 lb)

ATTENTION

NOTE

Do not fill above.

Side Guides

C Do not feed curled paper through the sheet bypass to a v oid misfeed.

C Adjust the side guides properly to avoid ske wing, wrinkling or misf eeding.

Insert the paper until it stops.

$ Adjust the side guides.

Incorrect adjustment may cause the
paper to wrinkle, misfeed or skew .

Press ST AR T.

15

Creative Features

2 in 1 Copy

■ 2 in 1 Copy

From tw o 1-sided originals, side by
side, to 1-sided pages.

Landscape (Orientation)*

■■

■ Procedure

■■

Face-Up

1

Place the
Originals

ADF

1 \ 2 (Lay out)*

2 \ 1 (Lay out)*

2

Press 2
in 1 key

Portrait (Orientation)*



(3)

Copy Size

(Reduction/
Enlargement
Only)

Number of
Copies

1 \ 2 (Layout) *

2 \ 1 (Layout) *

4

5

Press

START

16

NOTE

C The ADF is required for 2 in 1 copy.
CPress the RESET key to cancel all job settings.

The Orientation and Layout can be set in the function mode. (See page 27)

∗

2 Page Copy

■ 2 Page Copy

Copying two f acing pages on a ledger size
original on two separate letter size sheets.

■■

■ Procedure

■■

Creative Features



1

Place the
Originals

Platen Ledger siz e original

Letter

2

Press the 2

Page Copy

key

Book Mark

3

Original Size

(Letter or Ledger
size Only)

Center book
by length
and width
according
to center
marks.

4

Number of
Copies

Making Copies

5

Press

START

NOTE

C To reset all job settings, press the RESET key.

17

Creative Features

Book/Edge/Margin

■ Book Key

Eliminates dark inner binding shadows when copying from a book.

■ Edge Key

Creates a blank edge.

■ Margin Key

Shifts the image to the right or left.

■■

■ Procedure

■■



3

Press Cursor (G or F) keys to adjust
the void width while the button is
blinking. (approx. 5 sec.)

1

Place the
Original

2

Press Book, Edge or
Margin key

CV oid/Margin width: 5-99 mm

4

Number
of Copies

5

Press

START

NOTE

Book

BOOK MARGIN
CENTER VOID = 20mm ∨∧

Edge

EQUAL RATE
VOID MARGIN = 5mm ∧

Margin**

LEFT MARGIN
10mm ∨∧

Initial setting (F actory setting) can be changed in the User Mode function.

∗

(See page 27)
If a part of the copied image is missing when using the Margin mode, change the

∗∗

Fr ame Reduction setting to ON.
(See page 27)

CPress the RESET key to cancel all job settings.

Initial setting (Factory setting): 20 mm

∗

Initial setting (Factory setting): 5 mm and Equal Rate

∗

Initial setting (Factory setting): 10 mm and Left Margin

∗

18

Creative Features

Job Memory

■■

■ Two Copy Jobs Can Be Programmed in Memory (M1, M2) for recall at a

■■

later time.



To store a job in memory

# Set up the copy job to be stored in memory,

by first selecting each function you wish the
copier to perform.

JOB MEMORY
PRESS M1,M2 TO STORE.

RECALL JOB MEMORY
LOADING...

$ Press the Memory In (F2) key.
% Press the M1 (F3) or M2 (F4) key.

Making Copies

To recall a job stored in memory

& Place the Original
( Press the M1 (F3) or M2 (F4) key.

The stored contents will be displayed.

) Press START

NOTE

C Stored job(s) will not be deleted even if the power switch is turned Off.
C When storing a new job into programmed memory, the previously stored job

will be overwritten.

19

Creative Features

1

1

1

Sort Copy

■ Sort Copy

The sort copy has 2 availab le electronic sorting functions as follows:
Note: Before using the sort copy, select the desired sorting mode by setting its function first
(See page 26).

Sort Sort-Rotate

1

1

1

Platen Glass ADF

1

ADF : Place the

Originals

Platen: Place the

First Original

Multiple copies
sorted
automatically.

2

Select the
Sort Mode

(3)

Copy Size
(Reduction/
Enlargement
Only)

Multiple copies sorted
automatically and
Stacked in alternate
direction.

(Up to Letter size)



4

Number of
Copies

5

Press

START

20

From Platen Glass only:

ANOTHER ORIGINAL?
1:YES 2:NO

6

Press “1” key.

Repeat steps 6 and 7

9

NOTE

until all originals are
scanned and stored
into the copier’s memory.

CWhen the memory becomes full during original scanning, the message “OUT OF

MEMORY...... ” will be displa y ed in the message displa y. If this occurs, f ollow the

instructions in the message display.
For additional memory consult your authorized servicing dealer .

CTo reset all job settings, press the RESET key.

10

Place next Original

7

ANOTHER ORIGINAL?
1:YES 2:NO

Press “2” key.

Press START

8

Other Features

Energy Saver/Interrupt Mode

Interrupt (F1) Key Energy Saver K e y



ENERGY SAVER

INTERRUPT

■ These modes can save power while the copier is

not in use.

Energy Saver Mode

# To enter this mode

Press the Energy Saver key or the copier will
automatically enter the Energy Saver Mode after 15
minutes* from the last copy. The indicator will flash.

$ To cancel this mode and make copies

Press the Energy Saver ke y again.

Sleep Mode

# Automatically enters the Sleep Mode after 30

minutes from the last copy. The copier power will
drop and the indicator will light.

$ To make copies, press the Energy Sa ver key.

Interrupt Mode

C This mode can interrupt other copy jobs while

making copies.

# Press the Interrupt (F1) key, the indicator will

light.

$ Make another cop y job using the platen glass.
% Press the Interrupt (F1) key again to continu e

the original job.

Making Copies

NOTE

Note: The ADF can not be used with interrupt.

(Use only the Platen)

Energy saver time (15 minutes) and Sleep time (30 min utes) can be changed

∗

by the ke y operator. (See page 28)

Modes Po wer Consumption Warm Up Time

Normal Operation

Energy Sav er Mode

Sleep Mode

Approximately 92 Wh
Approximately 40 Wh
Approximately 1.5 Wh

N/A
30 sec. recovery
30 sec. recovery

21

Other Features

Skyshot Mode

■■

■ Skyshot allows copying a manuscript without generating dark borders

■■

even if the platen cover or ADF is opened.

Skyshot mode eliminate dark borders around the originals, and is especially convenient for
copying small-sized originals like bank chec ks or documents with un usual shapes (round, oval,
etc.). These documents can be reproduced without generating any unnecessary black areas
simply by making a copy with the cover open.

Two types of Skyshot modes can be selected;
Digital Skyshot Mode : The scanning area (size) is not pre-determined.
Manual Skyshot Mode: The scanning area (siz e) is pre-registered into memory (M1 and M2) in

advance. (See page 29)

■■

■ Digital Skyshot Mode

■■



1

Place the Original on
the platen (Opening the
Platen Cover/ADF)

2

Number of
Copies

3

Press
Start Key

Note:The default setting of Digital Skyshot Mode is “NORMAL”. In this setting, the unit scans once.

If there are black areas around the borders in the copies, set the Digital Skyshot Mode to
“QUALITY” to soften the dark borders. In this setting, the unit scans twice .

FUNCTION MODE (1-2)
ENTER NO. OR ∨ ∧

2:COPIER SETTINGS
PRESS SET TO SELECT

COPIER PARAM. (00-14)
ENTER NO. OR ∨ ∧

06 DIGITAL SKYSHOT
2:NORMAL

# Press the 2 key to select COPIER SETTINGS.

$ Press the SET key.

% Press 6 and SET ke y to select DIGITAL

SKYSHOT.

&

Press 1-3 key to select the Digital Skyshot Mode.
1: OFF NONE
2: NORMAL Default setting (usually select this

mode).

3: QUALITY For better definition, select the

Quality mode.

( Press the SET key.
) Press the Reset key.

22

NOTE

C An incorrect exposure ma y occur when there is a black line at the edge of

the original or an image which the copier interprets as a black pattern in the
Skyshot mode.

C An incorrect position detection of the original may occur when a strong light

shines onto the glass during Skyshot mode.

Other Features

■■

■ Manual Skyshot Mode

■■

When using this function, the custom size should be registered into memory (M1, M2) in
advance. (See page 29)

Platen

Upper­left
corner

2

Place the
Original

FUNCTION MODE (1-2)
ENTER NO. OR ∨ ∧

2:COPIER SETTINGS
PRESS SET TO SELECT

COPIER PARAM. (00-14)
ENTER NO. OR ∨ ∧

07 MANUAL SKYSHOT
2:M1 ON

1



23

Select the Custom
Size (M1/F3 or M2/F4)

# Press the 2 key to select COPIER SETTINGS.

$ Press the SET key .

% Press 7 and SET ke y to select MANU AL SKYSHO T.

&

Press 2 or 3 key to select the Custom Size.
1: OFF NONE
2: M1 ON M1 size is ON*
3: M2 ON M2 size is ON*
4: M1, M2 ON Both sizes are ON

Number of
Copies

4

Press

START

Making Copies

NOTE

( Press the SET key .
) Press the Reset key.

The default size f or M1 is: 70(X) × 160(Y) mm, and M2 is: 95(X) × 220(Y) mm

∗

C When changing the M1 or M2 size, consult with the key operator.
C When using the manual skyshot mode, M1 and M2 are turned ON and other

job memory cannot be used.

C Press the RESET key to cancel all job settings .

23

Combined Function Table

First
Selections

Zoom Copy

2 in 1 Copy

2 Page Cop y

2-ORIGINAL H

COPY

Book
Edge

Margin

Margin
Non-Sort

Next
Selections

2-ORIGINAL
H COPY

Zoom Copy

A O O OOOOOO AAO

O AAOOOOOO AAO

O AAOOOOOO AAO

OO OA OOOOO AAO
OO OOA OOOO AAO
OO OOOA OOO AAO
O O O OOOAAA A AO

2 in 1 Copy

2 Page Cop y

Margin SORT

Book

Edge

Margin

Non-Sort

Sort

Other
Functions

Sort-Rotate

Manual Skyshot

Job Memory Retrieval

Remarks

Job Memory Storing

Sort

SORT

Sort-Rotate

Manual Skyshot

Other

Functions

Interrupt

O: Possib le Combined Functions.
✕ : Unavailable Combined Functions.
A : Next Selection is Carried Out.
– : Indicates that SORT mode cannot be used. Non-sort operation is carried out.

O O O OOOAAA A AO
OO OOOOAAA A AO

O ✕✕OOO––– AA✕

O ✕ O OOO––– ✕✕✕

24

Function

■■

■ Using Function Modes to Change the Initial Copy Modes

■■

Options

General

Functions

General

Functions for

Ke y Operator

■■

■ Procedure

■■

Copier

Settings

Copier

Settings for

Ke y Operator

Copy Size
Key

LAN Settings

Input Identification Code

LAN Settings

for K e y

Operator

Function Ke y



Paper Tray
Key

Printer

Settings

Printer

Settings for

Ke y Operator

Reset Ke y

Making Copies

FUNCTION MODE (1-2)
ENTER NO. OR ∨ ∧

■ Checking the Copier’s Total Counter

To display the copier’s Total Counter, press the Copy Size and Paper T ray keys
simultaneously.

NOTE

C Please refer to each options operating instructions for function settings.

# Press the Function Key
$ Press 1 (GENERAL FUNCTIONS) or 2

(COPIER SETTINGS) key. You may also use
the (G or F) keys.

% Press the SET key.
& Press the Keypad to select function modes

or use the (G or F) ke y s .

( Follow the on screen instructions.
) After setting, press the SET key to set up the

function.

25

Function

General Functions

No. Modes

00 SORT MODE DEFAULT Selects the sort mode.

C NON-SORT, SORT

05 Displays the amount of sort memory used on

SORT MEMOR Y USAGE

the panel.
C INV ALID , VALID

DEPT. COUNTER Consult

06

08

SORT-ROTA TE DEFAULT ON

09

KEY OPERATOR MODE

Copy usage and copy limit of the selected
department and total copy usage will appear
on the screen.

Select Sort-Rotate mode.
COFF, ON

Input the key operator ID code .

Function

Initial

Setting

NON-SORT

INVALID

your
service
technician.

26

Copier Settings

Function

No. Modes

00 MARGIN DEFAULT Selects the margin position and shift value.

C POSITION (Left, Right, Top, Bottom)
C VALUE (5 - 99 mm)

EDGE DEF AUL T

01

BOOK MARGIN DEF.

02

FRAME MARGIN03

2-SIDED MODE DEF.04

05 Selects whether or not to disable edge deletion.

2 in 1 WITH FRAME

DIGITAL SKYSHOT

06

MANUAL SKYSHO T

07

AUT O EXPOSURE

08

1 \ 2 BINDING DEF.

09

10

2 \ 1 BINDING DEF.

BOOK \ 2 DEFAULT

11

2 in 1 DEF AULT12

2 PAGE MODE DEF.

13

14

Selects the edge mode (Equal Rate = set the
same value for X & Y or Individual = set the
value for X & Y individually) and width.

C EQU AL RATE (X & Y ), INDIVIDUAL
C 5 - 99 mm

Selects the book Center Void margin width.
C 5- 99 mm

Select the reduction ratio in margin mode.
C INVALID , V ALID

Function sets the duplex priority mode.

COFF, 1 \ 2, 2 \ 2, Book \ 2

C INV ALID , VALID

Enables or disables the use of skyshot mode.
C OFF, NORMAL, QUALITY

Enables or disables the use of Manual
Skyshot.
C OFF; M1 ON; M2 ON; M1, M2 ON

Automatically adjusts the cop y density for text
and photographic originals.
C INVALID , V ALID

Selects the binding location for 1 \ 2 Copy.
C LONG EDGE, SHORT EDGE

Selects the binding location for 2 \ 1 Copy.
C LONG EDGE, SHORT EDGE

Selects the page order and book format for
Book \ 2 Copy.

1. BOOK FORMAT (1: FACING, 2: FLIPPING)

2. PAGE ORDER (1: L \ R, 2: R \ L)
Selects the orientation and layout f or 2 in 1 Cop y.

C ORIENT ATION (Portrait, L-Scape)
C LAYOUT (L \ R, R \ L)

C L \ R, R \ L

Input key operator ID code.KEY OPERATOR MODE

Function

Initial

Setting

LEFT
10 mm

EQUAL RATE
5 mm

20 mm

INVALID

OFF

INVALID

NORMAL

OFF

Making Copies

INVALID

LONG EDGE

LONG EDGE

FACING
L \ R

PORTRAIT
L \ R

L \ RSelects the 2 page mode.

NOTE

C Certain Functions or Parameters are av ailab le f or selection only when their

respective option is installed.

27

Function

General Functions for Key Operator

No. Modes

AU TO RESET TIME

01

ENERGY SA VER MODE

02

04

LANGUA GE DEFAULT

05

SPECIAL TRA Y 1

06

SPECIAL TRA Y 2 NONE

KEY/TOUCH BEEP

09

BYPASS SET BEEP INV ALID10

11

ORIG.SET BEEP ADF V ALID

14

DEPT. COUNTER MODE

TCP/IP ADDRESS

22

TCP/IP SUBNET MSK

23

24

TCP/IP G/W ADDR.

25

COPY SETTING LIST

Function

Selects the Control Panel reset time.
C OFF, 30 sec, 1 min., 2 min., 3 min.,

4 min.

Sets the Energy Saver mode and time .
C INV ALID, ENERGY-SAVER, SLEEP

Energy save mode timer : 1-120 minutes
Sleep mode timer : 1-120 minutes

Selects the message language of the display.
C A-ENGLISH, C-FRENCH, SPANISH

Sets the paper tray f or special paper (e x: colored).
C NONE, TRAY 1, TRAY 2, BYPASS

Sets the paper tray f or special paper.
C NONE, TRA Y 1, TRA Y 2, BYP ASS

Sets the panel touch sound.
C OFF, SOFT, LOUD

Sets the sound when put paper(s) on bypass
tray.
C 1: INVALID 2: V ALID

Sets the sound when put paper(s) on ADF.
C 1: INVALID 2: V ALID

Monitors copy usage of each department.
(1)TOTAL COUNTER
(2)DEPT. COUNTER
(3)DEPT. COUNTER LIST

Sets the IP Address assigned to your machine.

∗

C 3 digit × 4 (Use the MEMOR Y IN key to

enter the "." between each set of 3-digit
numbers)

Sets the Subnet Mask.

∗

C 3 digit × 4 (Use the MEMOR Y IN key to

enter the "." between each set of 3-digit
numbers)

Sets the Subnet Mask.

∗

C 3 digit × 4 (Use the MEMOR Y IN key to

enter the "." between each set of 3-digit
numbers)

Prints list containg Current Setting and
Standard Setting.

Initial

Setting

1 min.

SLEEP

A-ENGLISH

NONE

SOFT

Consult
your
service
technician.

Contact
your
Network
Adminstrator .

Contact
your
Network
Adminstrator .

Contact
your
Network
Adminstrator .

28

NOTE

C It is necessary to input the Key Operator ID code before changing items on

this page.

C The Special Tray 1 and 2 are not auto-selectable in the s witching mode.

Not availab le f or plain copier, but will be available when installing options

∗

for adv anced functions. (See page 50)

Copier Settings for Key Operator

Function

No. Modes

PAPER SIZE PRIOR. Specifies the paper size in manual paper siz e

00

setting mode.

ORIGINAL (HOME)

01

TEXT CONTRAST

02

T/P CONTRAST 3

03

PHOT O CONTRAST Selects contrast for Photo mode

04

10

MAX. COPY SETTING Determines whether to limit number of copies

12

M1, SIZE

M2, SIZE

13

16 MEM. FULL A CTION Selects the memory full action

Selects original setting

C TEXT, T/P (T ext/Photo), PHOT O

C 1 ~ 5

Selects contrast for T e xt/Photo mode

C 1 ~ 5

C 1 ~ 5

C 1 ~ 999

Input a size in memory 1 for frequent usage
size.
C X: 5~432/Y : 5~297 mm

(See page 22)

Input a size in memory 2 for frequent usage
size.
C X: 5~432/Y : 5~297 mm

(See page 22)

C PRINT , CANCEL

Function

Initial

Setting

LETTER

T/P
(

Text/Photo

3Selects contrast for Text mode

3

999

70 × 160 mm
(X) (Y)

95 × 220 mm
(X) (Y)

Print

h

)

Making Copies

NOTE

C It is necessary to input the Key Oper ator ID code before changing items on

this page.

29

Function

Function Setting

■■

■ Changing the Auto Exposure Setting

■■

You can select whether the copying density is adjusted automatically for text and photographic
originals.

Press the Function Key

1
2

Proceed as Follows:

FUNCTION MODE (1-2)
ENTER NO. OR ∨ ∧

2:COPIER SETTINGS
PRESS SET TO SELECT

COPIER PARAM. (00-14)
ENTER NO. OR ∨ ∧

08 AUTO EXPOSURE
2:VALID



# Press the 2 ke y to select COPIER SETTINGS .

$ Press the SET key.

% Press 8 and SET key to select AUTO

EXPOSURE MODE.

& Press 1 or 2 key whether Auto Exposure is to be

carried out or not.

( Press the SET ke y to set up the AUTO

EXPOSURE MODE.

) Press the RESET key to exit the Function mode.

30

Function Setting for Key Operator

■■

■ Changing the Paper Size

■■

The paper trays are designed to accommodate inv oice , letter, letter R, legal and ledger size
paper. To change the paper size, perform the steps shown below.

Press the Function Key

Function

1
2



Proceed as Follows:

FUNCTION MODE (1-2)
ENTER NO. OR ∨ ∧

# Press the 1 key to select GENERAL

FUNCTIONS.

1:GENERAL FUNCTIONS
PRESS SET TO SELECT

$ Press the SET key.

GENERAL PARAM. (0-9)
ENTER NO. OR ∨ ∧

( Press 00 and 1 or 2 ke y to select

the PAPER SIZE.

00 PAPER SIZE

B

1:TRAY-1[LTR

) Press SET to select the paper tray and

press (G or F) keys to set the paper
size.
Paper siz e changes are as f ollo ws .

]

Making Copies

% Press 9 key.

09 KEY OPERATOR MODE
ENTER PASSWORD=- ■ ■

& Input the Key Operator ID code (3 digit)

and the SET key.

KEY OPR. MODE (00-25)
ENTER NO. OR ∨ ∧

Letter R In voice R

Letter
Legal

Ledger

* Press the SET ke y to set up the PAPER

SIZE.

+ Press the RESET key, then exit the

Function mode.

FLS2 FLS1 A5R B5R

A3 B4 A4

A4R

B5

31

Function

Function Setting for Key Operator

Changing the Paper Guide and Paper Size Indicator in the Paper Tray

3

Paper

aa

Guide

a

Paper
Guide

aa

bb

b

bb

Stopper

# Pull out paper tray and remove paper.

$ Move the paper guide a to the paper

length required.

% Move the paper guide b to the paper

width required.
Pinch the stopper to move the paper
guide b.

NOTE

& Change the paper size indicator.

Size Indicator

( Close the paper tray.

C It is recommended that the paper guide b be fixed in place with scre ws.

Consult an authorized servicing dealer for details on how to f asten using
screws.

32

Function

■■

■ Departmental Counter

■■

The Ke y operator can manage, limit copies , counters and code numbers f or each department.
(Maximum department number: 50)

Press the Function Key

1
2



Proceed as Follows:

FUNCTION MODE (1-2)
ENTER NO. OR ∨ ∧

# Press the 1 key to select GENERAL

FUNCTIONS.

1:GENERAL FUNCTIONS
PRESS SET TO SELECT

$ Press the SET key.

GENERAL PARAM. (0-9)
ENTER NO. OR ∨ ∧

& Press the Key Operator ID code (3 digit)

and SET key.

KEY OPR. MODE (00-25)
ENTER NO. OR ∨ ∧

( Press 14 and the SET key to select

DEPT. COUNTER MODE.

Making Copies

% Press 9 key.

NOTE

09 KEY OPERATOR MODE
ENTER PASSWORD=- ■ ■

C To reset the function mode, press the RESET key.

C

Contact your authorized servicing dealer to enable the Departmental Counter
feature.

33

Function

Function Setting for Key Operator

Select the Department Counter Mode.

3

14 DEPT.COUNTER MODE
1:TOTAL COUNTER

4

DEPT. CODE (01-50)
ENTER NO. OR ∨ ∧

Change the Department ID Code, limit the maximum number of copies
and department Counter number.

I.D CODE
01:1234

MAX COPIES
01:123456

DEPT.COUNTER
01:123456

Press 2 and the SET key.

# Press the Keypad and the SET key to input the

Department ID Code.
01: 1234 Department ID Code
Department No.

$ Press the Keypad and the SET key to input the

maximun number of copies.
01: 123456
Department No.

% Press the Keypad and the SET key (G or F keys) to

select the Department No.

Maximun number of copies (6 digits)

34

NOTE

01: 123456 Counter (6 digits)
Department No.

& Press 0 and the SET key (Input “0”) to clear the counter.

C T o reset the function mode , press the RESET key.

Accessories

Components

ADF (Automatic Document Feeder)

(DA-AS180)

C Feeds originals automatically.
C For 2 in 1 cop ying.

Image Memory

(DA-SM16B/SM28B)

C 16/128 MB
C To increase the memory capacity for

electronic sorting.

PCL6 Emulation Kit

(DA-PC210)
C Printer Controller for PCL6*

10/100 Ethernet Interface/
Internet Fax Kit

(DA-NE200)
C Network Interface Board

PCL6 is a Page Description Language of the Hewlett-Packard Company.

NOTE

∗

C The table below shows the options which are required for various functions.

C

Contact your authorized servicing dealer for details on combinations of options.

Function

2nd Paper Feed Module

(DA-DS182)
C T o increase the paper f eed

sources and capacity.
Paper F eed Module × 1
(550 sheets)

2-ORIGINAL H

COPY

Margin SORT

Options

Other

Functions

Options
ADF

2nd P aper Feed Module

Zoom Copy

2 in 1 Copy

:Required

2 Page Cop y

Book

Edge

Margin

Non-Sort

Sort

Sort-Rotate

Manual Skyshot

35

Accessories

Automatic Document Feeder

■■

■

ADF (DA-AS180)

■■

1. Features

# Automatic Original Feeding

C The ADF tray can hold up to 50 Letter size originals of 20 lb (80 g/m2) paper (up to 30 Legal or

Ledger size originals).
It can accommodate originals from invoice to ledger size.

C Automatic original size detection.

$ 2 in 1 Copy

C T o mak e a 1-Sided copy (full size or reduction), from two 1-Sided originals side-by-side.

2. Components

Original Guides

Adjust to the original’s width

C Set the originals up to the upper limit arrow .

ADF T ray

36

3. Operation

■ Operation Procedure

Accessories

ADF

Face-Up

1

Place the
Original

Inappropriate originals

C P aper with a smooth surface such as glossy

and coated papers

CTransparencies
C Originals with a lead edge that is “creased”,

“folded”, “punched” or “glued”



2

Number of
Copies

C Paste-ups
C Pressure sensitive or carbon backed papers
C Paper with excessive curl
C Stapled originals
C Freshly printed copies from a laser printer

3

Press

START

NOTE

Options

C To copy these kinds of originals, use the Platen Glass instead.

37

Problem Solving

Adding Paper (

■■

■ 550-Sheet Paper Tray

■■

JJ

J)

JJ

1
2

Pull the paper tray out.

Place the paper with the copying
surface facing upward.

Special papers, like glossy paper , mailing
labels and transparencies cannot be used
in the paper tray. Use the sheet b ypass
for special paper .

3
4

ATTENTION

Make sure paper is not loaded
above the overfill indicator located
in the paper tray.

Firmly push the paper tray back
into the copier.

C Do not use paper with folds or wrinkles.

Refer to page 30 f or details on changing the paper siz e for the paper tray.

C Unused paper should alwa ys be placed into a bag and the opening should be sealed

for storage.
If the paper is left exposed, problems such as paper curl, paper jams, wrinkles or
loss of copied image quality may occur.

38

Problem Solving/U13

Adding the Toner and Replacing Toner Waste Container (

Open the front cover.

1

Remove the toner waste container by
slowly pulling it towards the left as

2

illustrated.

Seal the container with the enclosed
cap and dispose of it properly.

3

??

?)

??

4

ATTENTION

Cap

1

2

C For optimum copy quality use the recommended Panasonic toner. Store toner in a cool

dark place. Do not unseal toner before use. Use it as fast as possib le after unsealing.

C When U13 is display ed the Add Toner Warning Indicator will begin to flash. This message

is to prompt you that the toner bottle is nearly empty (approx. 300-sheets can be printed).
This message will continue to be display ed until the bottle is replaced. When the count­down counter reaches 0, the copier will stop operating. To clear the message and enable
the copier to operate, replace the empty toner bottle with a new one .

# Tu rn the empty Toner Bottle

counter-clockwise until it stops. The
Arrow mark (Unlocked symbol )
visible on the end of the Toner
Bottle is aligned with the Arrow
mark on the machine.

Note: To prevent toner spill, ensure that

the key is facing upwards

before removing the toner bottle.
$ Pull out the empty Toner Bottle.
Note: If the bottle will not pull out from

the machine, turn the bottle

slightly in either direction to

release the key and try it again.

J

?

39

Problem Solving

Adding the Toner and Replacing Toner Waste Container (

# Shake the new toner bottle four

or five times to loosen the
contents.

$ Remove the cap from the toner

bottle.

# Align the Key of the bottle, also

represented by the Arrow mark
(Unlocked symbol ) visible on
the end of the Toner Bottle with
the Arrow mark on the machine.

Note: To prevent toner spill,

ensure that the key is facing
upwards before installing the
bottle.

$ Insert the bottle as far as it will

go, then turn it clockwise (160°,
approx. 1/2 turn) until it locks
(Locked symbol ).

Note: If the bottle is not inserted

all the way into the machine
as illustrated, turn the bottle
slightly in either direction to
engage the key and try it
again.

5
6

1

2

2-2

Incorrect

2-1

2

1

2-3

Correct

??

?)

??

40

7
8

ATTENTION

Install a new toner waste
container.

Close the front cover.

C Do not reuse the toner from the Toner Waste Container.

Problem Solving

Removing a Misfed Paper

■■

■ Paper Misfeed Indicators and Locations

■■

When a paper misfeed occurs, the misfeed indicator and the misfeed
location(s) will be displayed on the panel displa y.



I

Paper Misfeed Locations

A: ADF (see page 45)

(J70, J71)

B: Copier (Paper Exit, Paper Entry/T r ansport)

area (see page 42)
(J51 - J59, J80)

C: Paper Feed Module (see page 44)

(J00 - J50)

Misfeed Indicator

NOTE

I

C Make sure that the misfeed indicator goes off after removing the misfed

paper.

C The misfeed indicator will not go off if the paper is still jammed in the copier.

Check again and remove all misf ed paper.

41

Problem Solving

Removing a Misfed Paper

1

■ Paper Exit Area

C Make sure that the misf eed indicator

goes off after removing all misfe d
paper.

Remove the misfed paper.

42

ATTENTION

C Make sure that the misfeed indicator goes off after remo ving all misf ed paper.

1

Problem Solving

■ Paper Entry/Transport Area

C Make sure that the misf eed indicator

goes off after removing all misfe d
paper.

Open the right cover.

Remove the misfed paper.

2
3

4

Caution
heated
surface

If copy paper is f ed f ar into the copier;

# T urn the right paper clearing knob.
$ Remove the misfed paper .

# Open the heat roller cover.
$ Remove the misfed paper.
% Close the right cover.

Caution: This fuser area may be

hot.

I

ATTENTION

C Make sure that the misfeed indicator goes off after remo ving all misf ed paper.

43

Problem Solving

Removing a Misfed Paper

1

■ Paper Feed Module

C Make sure that the misf eed indicator

goes off after removing all misfe d
paper.

# Pull out the paper tray.
$ Remove the misfed paper.
% Return the paper tray to the original

position.

2

# Open the feed co v er.
$ Remove the misfed paper.
% Close the feed co v er.

44

ATTENTION

C Make sure that the misfeed indicator goes off after remo ving all misf ed paper.

1

Problem Solving

■ ADF

C Make sure that the misf eed indicator

goes off after removing all misfe d
paper.

# Open the entry cover.
$ Remove the misfed paper .
% Close the entry cover.

2

ATTENTION

# Open the ADF cover.
Note: To prev ent damaging the originals,

open the ADF cover bef ore
removing the misfed original(s).

$ Remove the misfed paper .
% Close the ADF Cover.
& Close the ADF.

I

C Push the tab on the center of the ADF cover to close it.
C Make sure that the misfeed indicator goes off after removing all misfed

paper.

C T o prevent original(s) damage, please make sure ADF cover open bef ore

removing misfed original(s).

45

Troubleshooting

Before Calling Service

Check Action

Unit Does Not Operate

Does the display light?

(No) (Yes)

Does the Energy Saver k e y flash (or light)
and displays are turned OFF? (See page

20)

Does any of the U## codes and messages
appear on the display?
(U01, U07, U13, U14, U16, U20 and U21)
(See page 48)

Does the add paper indicator and message
appear on the display? (J)

Does the paper misfeed indicator and
message appear on the display? (I)

Does E#-## indicator and message appear
on the display?

(No)

(No)

∗

(No)

(No)

Check if the P o w er Switch is turned On and
if the power cord is connected to the outlet.

Press Energy Saver k e y on the control
panel.

(Yes)

Perform actions in accordance with each
message.

(Yes)

Add paper. (See page 38)

(Yes)

Remove the misf ed paper. (See page 41)

(Yes)

Turn the copier Off, then On. If the error
code does not clear, call f or service.

(Yes)

46

When the Add Toner Warning Indicator begins to flash∗ or is lit, replace the toner bottle with a new
one. After this w arning is activated, machine operation will begin with the Toner Charging Mode
(approximately 3 minutes to complete) each time the pow er s witch is turned Off then On or if the
Front/Right Cov er is opened and then closed.

Note: ∗When the warning indicator starts flashing, a 300-sheet count-down counter is activated,

and upon reaching 0 the machine will stop operating. The 300-sheet counter is based on
6% fill, depending on the density some pages may print Blank.

Machine operation and displays are as f ollows:

1. When turning the power switch to On or opening and then closing the Front/Right Cover, the
machine starts to warm-up and the LCD displays:

PLEASE WAIT...

Troubleshooting

2. The Toner Charging Mode starts and the LCD displays:

CHARGING TONER

Add Toner Warning Indicator:

C Flashing = Toner Bottle is nearly empty
C Lit = Toner Bottle is empty

3. This message is displayed for appro ximately 200 seconds.

CHARGING TONER

.....

Each “.” is approximately 10 sec.

∗C

4. This massage will continue to be displayed until the warm-up cycle is completed, and if the toner
bottle was replaced, upon completion, the Add Toner Warning Indicator automatically turns Off.

Check Action

Light Copies

Does the exposure indicator sa y “Lighter”?

(No)

Does the add toner indicator and message
appear on the display? (?)

Marked Copies

Is the copier platen glass or platen cover
dirty?

Press the Darker key until the indicator
LED is set to Darker . (See page 12)

(Yes)

Add the Toner. (See page 38)

(Yes)

Clean the glass or platen cover.
(See below)

(Yes)

47

Others

Troubleshooting

User Error Codes (U Code)

The self-diagnostic functions detect troubles in the important components of the copier.
When any trouble occurs, the copier stops .

Code Display Message Check Points

U01 CLOSE FRONT/R T COVER Front Co v er is open.
U07 CLOSE FEED CO VER Feed Cover is open.

U13

U14 W ASTE TONER BOX IS FULL

U16 NO WASTE T ONER BOX No T oner W aste Container.
U20 CLOSE ADF CO VER ADF Cover is open.

U21 CLOSE PLATEN COVER

ADD TONER
NO W ASTE TONER BO X

■ If the measures outlined above do not solve the problem, call y our Service provider.

1. Toner Cartridge is incorrectly installed.

2. Lo w T oner.

1. Toner Waste Container is incorrectly
installed.

2. Toner Waste Container is full of toner.

While the copier is initializing, the ADF
Cover was opened. (Optional ADF installed)

Copier Care

■ As a rule, clean weekly.

Platen
Cover

Platen
(glass)

Platen/Platen Cover
# Wipe marks off with a cloth and a neutral

detergent.

$ Wipe again with a dry cloth.

48

Specifications

■■

■ DP-1810P (Copier)

■■

Type: Desktop

Platen T ype: Fixed
Acceptable Originals: Sheets, Books (max. Ledger)
Copying Method: Laser Electrophotography
Fixing Method: Heat Roller Fixing
Imaging Method: Dry-Type Single component imaging
Resolution:
Maximum Copy Size: Ledger - Invoice via paper tray
V oid Area: Max. 0.2 in (5 mm)
Warm Up Time: Approx. 30 seconds (68°F/20°C)
First Copy Time: Approx. 6.5 seconds (Letter , from 1st tray)
Multi-Copy Speed: 18 Letter size copies per minute
Enlargement Ratios:

Reduction Ratios: Preset: 79%, 77%, 65%, 61%, 50%

Paper F eed:

Paper W eight:

Quantity Selector:
Electrical Requirements:
Energy Consumption: Max. 1.2 kW, 1.5 Wh in Sleep Mode

Max. 600 dpi

Preset: 121%, 129%, 155%, 200%
Variable: from 101% to 200% in 1% increments

Variable: from 99% to 50% in 1% increments
Paper tr ay (550 sheets × 1) + Sheet bypass (50 sheets)

2nd Paper f eed module (550 sheets - option)
Paper Tray: 16 - 24 lb (60 - 90 g/m2)

[Sheet Bypass: 15 - 34 lb (56 - 128 g/m2)]
Max. 999 sheets (output tr ay capacity is 250 sheets)
AC 120V, 50/60Hz, 9A

Dimensions (W × D × H):

Weight: 90 lb (41 kg)
Operating Environment:

C Specifications are subject to change without notice.

23.1 × 23.8 × 18.0 in
(588 × 605 × 458 mm)

Temperature: 50°F (10°C ) - 95°F (35°C) Relative Humidity: 45% - 85%
(Howe ver, the humidity should be 70% or less at a temperature of 95°F (35°C),
and the temperature should be 86°F (30°C) or less at a humidity le vel of 85%.)

49

Others

Specifications

■■

■ ADF (DA-AS180)

■■

DA-AS180

Tray Capacity:

Paper Size: Invoice/Letter/Legal/Ledger
Paper W eight: 14 – 28 lb (50 – 110 g/m2)
Electrical Requirements: Supplied from the copier
Dimensions (W × D × H):

Weight:

■■

■ 2nd Paper Feed Module (DA-DS182)

■■

Paper Size: Invoice/Letter/Legal/Ledger
Paper W eight: 16 – 24 lb (60 – 90 g/m2)
Electrical Requirements: Supplied from the copier
Dimensions (W × D × H):

Weight:

Letter, In voice: 50 sheets (20 lb)
Ledger, Legal: 30 sheets (20 lb)

21.7 × 20.5 × 5.3 in
(552 × 520 × 135 mm)

18.3 lb (8.3 kg)

DA-DS182

21.7 × 6.1 × 23.0 in
(550 × 155 × 585 mm)

20.9 lb (9.5 kg)

C Specifications are subject to change without notice.

50

Options and Supplies

■

The DP-1810P is a digital photocopier which can produce images with great clarity . Furthermore, its
copying functionality can also be greatly enhanced b y the addition of the following options and supplies .
We hope you find that the wide r anging capabilities will make y our office-place more productive and efficient.

■■

■ Options

■■

RemarksPart Name P art No.

DA-AS180Automatic Document F eeder
DA-DS1822nd Paper Feed Module

I

mage Memory (16 MB)

■■

■ For Printer

■■

Part Name P art No. Remarks

PCL6 Emulation Kit DA-PC210
10/100 Ethernet Interface/

Internet Fax Kit

■■

■ Supplies

■■

Part Name P art No. Remarks

Toner Bottle DQ-TU10C

DA-SM16B
DA-SM28BImage Memory (128 MB)

DA-NE200

Also referred as ADF

For Electronic Sorting
For Electronic Sorting

Printer Controller for PCL6
Network Interface Board

∗

NOTE

PCL6 is a Page Description Language of the Hewlett-Packard Company.

∗

51

Others

52

53

U.S.A. Only

WARRANTY

PANASONIC DOCUMENT IMAGING COMPANY MAKES NO WARRANTIES, GUARANTEES OR
REPRESENTATIONS, EXPRESSED OR IMPLIED , TO CUSTOMER WITH RESPECT TO THIS
PANASONIC MACHINE, INCLUDING BUT NOT LIMITED TO, ANY IMPLIED WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.

PANASONIC DOCUMENT IMAGING COMPANY ASSUMES NO RISK AND SHALL NOT BE SUBJECT
TO LIABILITY FOR ANY DAMAGE, INCLUDING, BUT NOT LIMITED TO DIRECT, INDIRECT , SPECIAL,
INCIDENTAL OR CONSEQUENTIAL DAMA GES OR LOSS OF PR OFITS SUSTAINED BY THE
CUSTOMER IN CONNECTION WITH THE USE OR APPLICATION OF THIS PANASONIC MACHINE.
SEE YOUR DEALER FOR DETAILS OF DEALER’S WARRANTY.

For Service, Call:

Panasonic Document Imaging Company
A Business Unit of Matsushita Electric Corporation of America
Two Panasonic Way
Secaucus, New Jersey 07094

Panasonic Canada Inc.
5770 Ambler Drive,
Mississauga, Ontario L4W 2T3

S0102-0
DZSD001627-0
January 2002
Printed in Japan
