Technicolor COM2002 Guidelines
COM1000/2000 Video Channel Assignment
Local
HD
1
NBC
Medium
HD
2
ABC
Medium
HD
3
CBS
Medium
HD
4
FOX
Medium
HD
5
CW
Medium
Movie
HD
6
HBO
Medium
News
HD
7
Fox News
Medium
HD
8
MSNBC
Medium
HD
9
CNN
Medium
Three HD channels per QAM Guidelines
The following table represents the 40 most popular HD channels which are commonly delivered
via a COM1000/2000 system. The channels are categorized into three buckets: Low bandwidth,
Medium bandwidth, and High bandwidth. As a general rule, sports channels should be
considered High Bandwidth. News and Entertainment channels are typically Medium
Bandwidth. Dedicated Movie channels with content captured in 24 frames per second (fps) is
generally considered Low Bandwidth.
The channel bandwidth definition includes both the statically average bandwidth as well as the
likelihood of a channel to exceed 13 Mbps for a statistically significant period of time. The
recommendation when assigning 3 HD channels per QAM is to observe the following rules:
Assign only 1 High Bandwidth channel per QAM.
Medium and Low Channel Bandwidth can be group together in any combination
Avoid grouping two or more sports channels on the same QAM.
If the table below does not include a desired channel, the recommendation is to categorize the
channel to a similar channel within the same category that is captured in the table below. (e.g.
news, sports, movie, local or entertainment). For example: The Science Channel 284 is similar to
the Discovery channel and should be assigned a Medium Bandwidth designation.
HD
10
CNBC
Medium
HD
11
CNN Headline
News
Medium
HD
12
Bloomberg
Medium
HD
13
Weather
Channel
Medium
Sports
HD
14
ESPN
High
HD
15
ESPN2
High
HD
16
ESPN News
Medium
HD
17
ESPNU
High
Entertainment
HD
18
TBS
Low
HD
19
TNT
High
HD
20
USA
Medium
HD
21
Comedy Central
Medium
HD
22
Discovery
High
HD
23
FX
Medium
HD
24
Food Network
Medium
HD
25
HGTV
High
HD
26
A&E
Medium
HD
27
Disney Channel
Low
HD
28
Cartoon
Network
Low
HD
29
AMC
Low
HD
30
History
Medium
HD
31
National
Geographic
Medium
HD
32
Bravo
Low
HD
33
MTV
High
HD
34
Travel
Medium
