F l e x i b l e D u r a b l e M o b i l e P r i n t i n g S o l u t i o n s

MD-480i

A ONE- STOP SOLUTION

(including media, service & support)

Toshiba can offer a total solution
including a full range of approved
media, labels, consumables and
cleaning products.

A European support network
in the majority of European
countries provides essential peace of mind that - once
installed - the printers will be serviced and maintained by
experienced engineers and service staff.

GREEN CREDENTIALS

Toshiba is committed to the design

and production of products that

reduce environmental impact, creating
environmental quality standards for each

product and prescribing them with the

highest levels required by the industry.

All Toshiba products are RoHS compliant.

http://www.toshibatec.co.jp/csr/report

CHARACTERISTICS

Printhead Type

Dimensions (not including
levers & mount plate)

Weight

Operating &
Storage Conditions

Power Rating

RoHS

Noise Level

Interface

PRINT

Max. Print Speed

Font

Barcode

Emulation

MEDIA

Print Width

Paper Size (continuous form)

Paper Size (single form)

OPTIONS

MD-480i

24 wire dot head

120(H) x 360(W) x 260(D) mm

5.7kg (except for optional parts)

Operating temperature:-20°C to 60°C

Storage temperature: -30°C to 65°C

Operating humidity: 30% to 80%

Storage humidity: 10% to 90%

Applicable power voltage: 100 to 120V AC ±10, 200 to 230V AC

Draft, LQ (Courier, Sans Serif, Sans Serif H, Roman, RomanT, Script,

UPC/A, UPC/E, EAN8, EAN13, Code39, Code128, CODABAR,

Nominal: 15V DC (10.5 to 28V DC)

RoHS compliant

63dB (A)

®

v1.2 (MS12 variant only)

Bluetooth

Prestige, Gothic, Bold PS, Orator, Orator S, OCR A/B)

Interleaved 2 of 5, Industrial 2 of 5

IBM 2390+ (including Pro printer XL24E), ESC/P2

102 to 267(W) x 102(L) mm or greater

102 to 267(W) x 76 to 364(L) mm

Vehicle power cable & AC/DC power supply

RS-232

USB 2.0 full speed

480 characters/second (12cpi)

203.2 mm

MD-480i

High Speed, Multi-form Mobile Printing for Logistics

TOSHIBA TEC EUROPE RETAIL INFORMATION SYSTEMS

www.toshibatec-eu.com

HQ Tel. [phone]

[e-mail]
www.toshibatec-eu.com

AT Tel. [phone]

[e-mail]
www.toshibatec-eu.de

BE Tel. [phone]

[e-mail]
www.toshibatec-eu.be

DE Tel. [phone]

[e-mail]
www.toshibatec-eu.de

ES Tel. [phone]

[e-mail]
www.toshibatec-eu.es

FR Tel. [phone]

[e-mail]
www.toshibatec-eu.fr

IE Tel. [phone]

[e-mail]
www.toshibatec-eu.co.uk

IT Tel. [phone]

[e-mail]
www.toshibatec-eu.it

NL Tel. [phone]

[e-mail]
www.toshibatec-eu.nl

PL Tel. [phone]

[e-mail]
www.toshibatec-eu.pl

PT Tel. [phone]

[e-mail]
www.toshibatec-eu.pt

UK Tel. [phone]

[e-mail]
www.toshibatec-eu.co.uk

Your TOSHIBA Dealer:

All company and/or product names are trademarks and/or registered trademarks of their respective owners.
All features and specifications described in this brochure are subject to change without notice.

Fast and reliable receipt printing for

delivery applications, warehouse

operations and ticketing on the move.

Ideal for in-vehicle and logistics

applications, the Toshiba MD-480i

rapidly produces delivery notes,

invoices, tickets and transaction

documents at speeds of up to

480cps (12cpi).

DESIGNHUT.CO.UK - JN916UK

RUGGED ENDURANCE

MD-480i

APPLICATIONS

Retail

Goods delivery, receipts, invoicing

Warehousing & Logistics

Invoices, receipts and delivery notes

Public Services

Traffic wardens, police, facilities

operatives & public transport (tickets,
fines, utility billing, meter reading, etc.)

- can be complemented by EP portable range

with 2 & 4 inch printing solutions

ON THE MOVE

High speed and durable with superior functionality. Perfect for the widest
range of in-vehicle delivery and receipt applications, the MD-480i is ideal for
environments requiring multiple copies.

The 180o degree cover opening facility allows easy
operation and replacement of the ribbon cassette.

With an impressive paper width range of 102 to
267mm (4” to 10.5”), producing small or large
format documents is easy, either loose leaf or
fanfold (with an optional paper storage stand).
Multi-part forms? No problem, including the
original, up to 7 copies (with special paper) can
be produced at one time.

The small footprint of the MD-480i guarantees total
flexibility for in-cab printing.

Field Support

PAT testing, receipts for field sales

& support charges

ECONOMICAL

& RELIABLE

The long-life 24-wire printhead has an
expected life of 300 million impacts and
each ribbon lasts up to 4 million characters,
keeping intervention and downtime to a
minimum. Robust engineering and long-life
product design also contribute to a low total
cost of ownership.

EXTREME

PERFORMANCE IN
ANY ENVIRONMENT

From refrigerated storage units to sweltering
lorry cabs, this printer is specifically designed to
perform reliably in extreme temperatures, from
a chilly -20oC to a stifling 60oC (-4oF to 140oF).
The operating buttons are back-lit so it
remains simple to operate even in darkness
and the ergonomic cover protects the unit from
liquid and dust.

FLEXIBLE

CONNECTIVITY &
INTEGRATION

Communicate with the Toshiba MD-480i
using the in-built Bluetooth®, serial or
high speed USB 2.0 interfaces. With IBM
Proprinter XL24e and Epson ESC/P2
emulation, integrating this device into existing
systems is straightforward.

LOW COST OF

OWNERSHIP

The printer can be powered from the
in-vehicle power supply, reducing the need
for batteries and lowering the ongoing
operation costs. Sleep mode functionality
dramatically reduces the power consumption
of the unit, typically to an output of 2 watts,
compared to 7 watts for normal stand-by
mode. The long-life printhead further reduces
the total cost of ownership.

The addition of a customisable vehicle mount plate for the
dashboard ensures the printer installation can be tailored to
meet the needs of any customer’s vehicle (exact specification
may vary according to country).

TRUST TOSHIBA

With over 20 years of experience in the
Auto-ID market, Toshiba is one of the only
manufacturers that still manufactures its
own products, guaranteeing consistency
and long-term reliability. All Toshiba
products have been designed to operate
in the most extreme environments.
Toshiba’s user-protected design improves
safety, restricting access to the printers
moving parts.
