This manual is the latest at the time of printing, and does not
include the modification which ma
the constant improvement of product.
be made after the printing, b
CAUTION:
Use of controls, adjustments or procedures other than those specified herein may result in
hazardous radiation exposure.
CAUTION: T O REDUCE THE RISK OF
CAUTION
RISK RISK OF OF ELECTRIELECTRICC
SHOCK SHOCK DO DO NOT NOT OPEN.OPEN.
The lighting flash with arrowhead symbol, with an equilateral triangle is intended to
alert the user to the presence of uninsulated voltage within the products
enclosure that may be of sufficient magnitude to constitute a risk of electric shock to
the person.
The exclamation point within an equilateral triangle is intended to alert the user to the
presence of important operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
ELECTRICAL SHOCK, DO NOT REMOVE
COVER (OR BACK). NO USER SERVICEABLE
PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
dangerous
WARNING: TO REDUCE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
2
IMPORTANT SAFETY INSTRUCTIONS
CAUTION:
Read all of these instructions. Save these instructions for later use . Follow all Warnings and
Instructions marked on the audio equipment.
1. Read Instructions- All the safety and operating instructions should be read before the product is operated.
2. Retain Instructions- The safety and operating instructions should be retained for future reference.
3. Heed Warnings- All warnings on the product and in the operating instructions should be adhered to.
4. Follow Instructions- All operating and use instructions should be followed.
FOR YOUR PERSONAL SAFETY
1.When the power cord or plug is damaged or frayed, unplug this television set from the wall outlet and refer servicing to
qualified service personnel.
2.Do not overload wall outlets and extension cords as this can result in fire or electric shock.
3.Do not allow anything to rest on or roll over the power cord, and do not place the TV where power cord is subject to
traffic or abuse. This may result in a shock or fire hazard.
4.Do not attempt to service this television set yourself as opening or removing covers may expose you to dangerous
voltage or other hazards. Refer all servicing to qualified service personnel.
5.Never push objects of any kind into this television set through cabinet slots as they may touch dangerous voltage
points or shor t out parts that could result in a fire or electric shock. Never spill liquid of any kind on the television set.
6.If the television set has been dropped or the cabinet has been damaged, unplug this television set from the wall outlet
and refer servicing to qualified service personnel.
7.If liquid has been spilled into the television set, unplug this television set from the wall outlet and refer servicing to
qualified service personnel.
8.Do not subject your television set to impact of any kind. Be particularly careful not to damage the picture tube surface.
9.Unplug this television set from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a
damp cloth for cleaning.
10.1. Do not place this television set on an unstable cart, stand, or table. The television set may fall, causing serious injury
to a child or an adult, and serious damage to the appliance. Use only with a cart or stand recommended by the
manufacturer, or sold with the television set. Wall or shelf mounting should follow the manufacturer s instructions, and
should use a mounting kit approved by the manufacturer.
10.2. An appliance and car t combination should be moved with care. Quick stops, excessive force, and uneven surfaces
may cause the appliance and cart combination to overturn.
3
PROTECTION AND LOCATION OF YOUR SET
11.Do not use this television set near water ... for example, near a bathtub, washbowl, kitchen sink, or laundry tub, in a
wet basement, or near a swimming pool, etc.
Never expose the set to rain or water. If the set has been exposed to rain or water, unplug the set from the wall
outlet and refer servicing to qualified service personnel.
12. Choose a place where light (artificial or sunlight) does not shine directly on the screen.
13. Avoid dusty places, since piling up of dust inside TV chassis may cause failure of the set when high humidity persists.
14. The set has slots, or openings in the cabinet for ventilation purposes, to provide reliable operation of the receiver, to
protect it from overheating. These openings must not be blocked or covered.
Never cover the slots or openings with cloth or other material.
Never block the bottom ventilation slots of the set by placing it on a bed, sofa, rug, etc.
Never place the set near or over a radiator or heat register.
Never place the set in enclosure, unless proper ventilation is provided.
a built-in
PROTECTION AND LOCATION OF YOUR SET
15.1. If an outside antenna is connected to the television set, be sure the antenna system is grounded so as to provide some
protection against voltage surges and built up static charges, Section 810 of the National Electrical Code, NFPA No.
70-1975, provides information with respect to proper grounding of the mast and supporting structure, grounding of the
lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna discharge unit, connection
to grounding electrode, and requirements for the grounding electrode.
EXAMPLE OF ANTENNA GROUNDING AS PER NATIONAL ELECTRICAL CODE INSTRUCTIONS
EXAMPLE OF ANTENNA GROUNDING AS PER
NATIONALELECTRICAL CODE
ANTENNA
LEAD- INWIRE
GROUND CLAMP
ELECTRIC SERVICE
EQUIPMENT
NEC-NATIONALELECTRICAL CODE
ANTENNA DISCHARGE
UNIT (NEC SECTION
810-20)
GROUNDING
CONDUCTORS
(NECSECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250. PARTH)
15.2. Note to CATV system installer : (Only for the television set with CATV reception)
This reminder is provided to call the CATV system attention to Article 820-40 of the NEC that provides
installer s
guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding
system of the building, as close to the point of cable entry as practical.
16. An outside antenna system should not be located in the vicinity of overhead power lines or other electric lights or power
circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care
should be taken to keep from touching such power lines or circuits as contact with them might be fatal.
17. For added protection for this television set during a lightning storm, or when it is left unattended and unused for long
periods of time, unplug it from the wall outlet and disconnect the antenna. This will prevent damage due to lightning
and power-line surges.
4
OPERATION OF YOUR SET
18.
This television set should be operated only from the type of power source indicated on the marking label. If you are not
sure of the type of power supply at your home, consult your television dealer or local power company. For television
sets designed to operate from batter y power, refer to the operating instructions.
19. If the television set does not operate normally by following the operating instructions, unplug this television set from the
wall outlet and refer servicing to qualified service personnel. Adjust only those controls that are covered in the operating
instructions as improper adjustment of other controls may result in damage and will often require extensive work by a
qualified technician to restore the television set to normal operation.
20. When going on a holiday : If your television set is to remain unused for a period of time, for instance, when you go on
a holiday, turn the television set and unplug the television set from the wall outlet.
off
IF THE SET DOES NOT OPERATE PROPERLY
21. If you are unable to restore normal operation by following the detailed procedure in your operating instructions,
do not attempt any further adjustment. Unplug the set and call your dealer or service technician.
22. Whenever the television set is damaged or fails, or a distinct change in performance indicates a need for
service, unplug the set and have it checked by a professional service technician.
23. It is normal for some TV sets to make occasional snapping or popping sounds, particularly when being
turned on or off. If the snapping or popping is continuous or frequent, unplug the set and consult your
dealer or service technician.
FOR SERVICE AND MODIFICATION
24. Do not use attachments not recommended by the television set manufacturer as they may cause hazards.
25. When replacement parts are required, be sure the service technician has used replacement parts specified
by the manufacturer that have the same characteristics as the original part. Unauthorized substitutions
may result in fire, electric shock, or other hazards.
26. Upon completion of any service or repairs to the television set, ask the ser vice technician to perform
routine safety checks to determine that the television is in safe operating condition.
5
PRODUCT SPECIFICATION
MODEL:::: 2560
AMBIENT CONDITIONS::::
AMBIENT TEMPERATURE::::
OPERATING ::::-10°°°°C ~ +40°°°°C
STORAGE ::::-15°°°°C ~ +45°°°°C
HUMIDITY
OPERATING:<
STORAGE: <<<<90%
AIR PRESSURE: 86kpa ~ 106kpa
PREPARED BY : DATE:
:<80%
:<:<
APPROVED BY: DATE:
6
A: GENERAL SPECIFICATION :
1: CRT
14” 20”
21” XX
25”
29” 34” OTHER
2: CHASSIS:
DIGITAL NICAM STEREO XX
ANALOG
SURROUND SOUND TELETEXT GERMAN STEREO
XX
S.VHS OTHER
3: CPU:
TSB M5C01 TSB M5C03 TSB M5ENG TSB M6/M6A TSB
M7/M7A
TSB M8A TSB M8B TSB CTS-654A TSB M2A SS M4F
PHIL.CTV 222S MIT.(2911) SIE SDA 5352 XX
OTHERS M13
4: TV BROADCASTING SYSTEM AND COUNTRY
PAL-I XX
PAL-DK.BGSECAM-BG SECAM-L SECAM-DK.BG
PAL-N NTSC-M
PAL-BG PAL-DK PAL-DK.1
NTSC3.579/4.43 AV MODE 21 MULTI SYSTEM
X
X
UK HK GERMAN RUSSIA
CHINA USA E.EUROPE VIETNAM
CANADA DUBAI INDONESIA S.AFRICA
MALAYSIA MID. AMERICA SINGAPORE ISRAEL
XX
AUSTRALIA & NEW ZEALAND TAIWAN MOROCCO
PHILIPPINES OTHER
5: RECEIVING CHANNELS
CH21--CH69 CH2--CH12(CCIR)
CHFA-CHS20(FRANCE BAND) CH2--CHS41(HYPER BAND)
CH21--CH69 CH21--CH69
7
CH2--CHS20(CABLE BAND) CH2--CH13(USA BAND)
CH21--CH69 CH14--CH83
CHR1--CHR12(OIRT) CH1--CH12/CH13-CH57(CHINA BAND)
XX
OTHER CATV 470MHz
6: SCANNING LINES AND FREQUENCIES
625 LINES 15.625kHz 50Hz
525 LINES 15.75kHz 60Hz
525/625 LINES 15.625kHz /15.75kHz 50/60Hz
X
X
7: COLOUR SUB-CARRIER
4.433MHz
X
X
3.579MHz
X
X
3.58MHz
8: INTERMEDIATE FREQUENCIES
PICTURE 39.5MHz SOUND 6.0MHz
XX
PICTURE 38.9MHz XX
SOUND5.5MHz
PICTURE 38.0MHz SOUND 6.5MHz
PICTURE 45.75MHz SOUND 4.5MHz
OTHER AM SOUND 6.5MHz
9: POWER CONSUMPTION :
65W 70W 75W 80W XX
110W 120W
130W 140W 180W 190W OTHER
10: POWER SOURCE :
AC 120V 60Hz±10%
AC 200V 50Hz±10%
AC 220V 50Hz±10%
AC 220V 50Hz+10%~25%
AC 240V 50Hz±10%
X
X
AC 110V-240V 50/60Hz±10%
OTHER
8
11: AUDIO OUTPUT POWER (7%THD)
13”& 14”---1W
20”& 21”---2W
20”& 21”---2W + 2W (R + L)
25”---4W + 4W (R + L)
29” >=6W + 6W (R + L)
34”---8W + 8W(R + L)
XX
OTHER 25” >=6W + 6W (R + L)
12: AERIAL INPUT IMPEDANCE
XX
75 Ω UNBALANCED DIN JACK ANT.INPUT75
75Ω UNBALANCED F TYPE ANT.INPUT FOR NTSC
300 Ω BALANCED(TWO TERMINALS ANT.INPUT)
OTHER
13: PRODUCT SAFETY REQUIREMENT
BS APPROVAL
VDE APPROVAL
UL APPROVAL
CHINA APPROVAL
CB APPORVAL
OTHER
14: PRODUCT EMC/EMI REQUIREMENT
FTZ APPOVAL
FCC APPROVAL
CHINA APPOVAL
OTHER
B: BASIC FEATURES OF CONTROLLER
1: CHANNEL TUNING METHOD
9
XX
VOLTAGE SYNTHESIZER (V.S.)
PLL FREQUENCY SYNTHESIZER (F.S.)
2: PRESETTABLE PROGRAM
50 PROGRAMS 0-99 PROGRAMS
XX
100 PROGRAMS 181 PROGRAMS
OTHER
3: TUNING FOR VHF AND UHF BANDS
X
AUTO SEARCH)
X
XX
FINE TUNING
X
MANUAL TUNING)
X
4: PICTURE AND SOUND ADJUSTMENT
XX
BRIGHT,CONTRAST,COLOUR AND VOLUME CONTROL
XX
TINT CONTROL(NTSC)
XX
TREBLE,BASS,BALANCE CONTROL
XX
SHARPNESS CONTROL OTHER
5: TELETEXT
SIMPLE TEXT TOP(TABLE OF PAGES)
FLOF (FASTEXT) LIST
6: ON SCREEN DISPLAY
X
GENERAL FEATURES∗ STEREO DUAL LAN.
X
FOUR S.EFFECT INDICATOR GERMAN STEREO INDICATOR
注:∗REMARK:OSD-GENERAL FEATURES OF CPU:
VOLUME,BRIGHTNESS,CONTRAST,COLOUR,PROGRAM,BAND,
AUTO SEARCH,MANUAL,TUNE,MUTING,AV AND SLEEP TIMER.
7: SLEEP TIMER
XX
10-120 MINUTES WITH 10M.INCREMENT
8:AUTO OFF WHEN NO BROADCASTING SIGNAL
10 min XX
10
15 min 20 min
9: FULL FUNCTION INFRARED REMOTE CONTROL
P/N OF REMOTE CONTROL INLAY) :
10: REMOTE EFFECTIVE DISTANCE 8 m
C: CONSTRUCTION OF FRONT PANEL
XX
MAIN POWER SWITCH FUNCTION SELECT
XX
REMOTE SENSOR XX
MENU SELECT
SYSTEM FUNCTION S.VHS INPUT
MICROPHONE INPUT XX
XX
STANDBY INDICATOR XX
BAND SELECT XX
TV/AV SELECT
PROGRAM VOLUME UP/DOMN
RCA SOCKET (SIDE)
EARPHONE INPUT OTHER
AUTO SEARCH AND MANUAL TUNING SELECT
D: CONSTRUCTION OF REAR PANEL
XX
75Ω AERIAL TERMINAL
300Ω AERIAL TERMINAL
RCA SOCKET(AV INPUT ONLY
RCA SOCKET--AV IN/OUT
RCA SOCKET --A-R+L IN/OUT,V- IN/OUT
X
X
RCA SOCKET --A-R+L /V INPUT X 2,
SCART SOCKET
XX
S.VHS INPUT
EXT/INT SPEAKER SELECT
EXT.SPEAKERS(R+L)TERMINALS
EXT.SPEAKERS(R+L)RCA SOCKET
SUPER WOOFER TERMINAL
OTHER
E: AUDIO AND VIDEO INPUT/OUTPUT
11
XX
RCA SOCKET
SCART SOCKET(AV)
S SCART SOCKET(FULL)
SPECIFICATION SCART RCA
VIDEO INPUT 75Ω S
1V
1V
P-P
P-P
AUDIO INPUT 10kΩ (R+L)
VIDEO OUTPUT 75Ω
AUDIO OUTPUT 1kΩ (R+L)
RGB INTPUT 75Ω
AUDIO LINE OUTPUT 1kΩ
0.5V
1V
0.5V
0.7V
1V
0.5V
rmS
1V
P-P
0.5V
rmS
P-P
P-P
F: OTHERS INFORMATION
1. FLYBACK :
2. TUNER :
3. SAW FILTER :
4. POWER CORD :
P-P
rmS
rmS
5. FUSE :
6. COLOUR TEMP :
7. MAGNETIC FIELD :
8. IC EEPROM :
9. IR RECEIVER :
10. CIRCUIT DIAGRAM :
11. MAIN BOARD :
12
TB1240 + TCLM13 chassis alignment instruction
f
Enter factory mode in production line
Simply press the D-mode key on the factory remote handset.
Enter service mode
Press and hold the VOLUME DOWN key tightly on the unit until minimum level and don’t release the
VOLUMN DOWN key, then press the DISPLAY key on the remote handset three times.
“D” letter on the screen indicated that the factory mode was entered. Now you can use the shortcut key
to access the factory menu. All change in factory data will save in EEPROM automatically
Note:
1. You can disable th e D-Mode key (on factory remote handset) b y change “BIT- 0” of “MODE2” to
“0”. If the D-Mode key was disabled, you can’t enter D-Mode by the D-mode key on the factory
remote (but you can still enter service mode). It is suggested to disable the D-Mod e key b efore the
set leave the factory.
2. On the factory remote handset, you can find the “BUS OFF” key. It can cut off the I2C control from
the CPU to other IC. This is only useful when automatic adjustment of white balance.
3. All system data in menu of “key 7” must keep unchanged when servicing. Otherwise, the set may not
work properly.
Setting method:
No Adjustment
Items
1Screen
voltage
2 Focus voltage------------Cross hatch
3VCO------------Apply an IF
Data Name (default
value inside blanket)
------------“IRGB cut off”
Conditions and
input signal
must set to 80 (all
signal (see tuner
frequency) to the
pattern)
pattern.
spec. For
IF input.
Setting method (need enter D-mode)
Press “MUTE” key on the remote handset
and the screen will become a horizontal
line. Then adjust the “screen” VR on the
flyback until the horizontal line can just be
seen (minimum visible intensity).
Adjust the “focus” VR on the flyback until
the screen becomes clear.
Monitor the DC voltage at pin 48 o
IC201, then adjust T271 until the voltage at
pin 48 become 4.62 +/- 0.02 V.
Press the AFT button on the factory remote
and AFT adjustment will be done
automatically.
4Vertical
f
f
geometry for
PAL system
(Key 2)
VPOS50 (04)
HIGH50 (25)
VLIN50 (04)
VSC50 (05)
OSD50 (20)
Input a PAL cross
hatch pattern.
Adjust VPOS50 for vertical position.
Adjust HIGH50 for vertical amplitude.
Adjust VLIN50 for vertical linearity.
Adjust VSC50 for vertical S-correction
Adjust OSD50 for OSD position (normally
use default value).
5Vertical
geometry for
NTSC system
(Key 3)
6Horizontal
geometry for
PAL system
(Key 4)
7Horizontal
geometry for
NTSC system
(Key 5)
VPOS60 (00)
HIGH60 (2E)
VLIN60 (05)
VSC60 (0A)
OSD60 (89)
HPOS50 (0D)
HSIZE50 (2A)
PARA50 (14)
TRAP50 (0E)
CORN50 (0A)
VEHT50 (03)
HEHT50 (02)
HPOS60 (11)
HSIZE60 (2A)
PARA60 (18)
TRAP60 (0D)
CORN60 (0D)
VEHT60 (03)
HEHT60 (02)
Input a NTSC
cross hatch
pattern.
Input a PAL cross
hatch pattern with
black and white
background.
Input a NTSC
cross hatch
pattern with black
and white
background.
Adjust VPOS60 for vertical position.
Adjust HIGH60 for vertical amplitude.
Adjust VLIN60 for vertical linearity.
Adjust VSC60 for vertical S-correction
Adjust OSD60 for OSD position (normally
use default value).
Adjust HPOS50 for horizontal position.
Adjust HSIZE50 for horizontal width.
Adjust PARA50, TRAP50 and CORN50
until the vertical line at left and right side
of the picture become straight.
VEHT and HENT is for the picture size
stability when changing the brightness o
the screen. Receive pattern of cross hatch
with black background and then change to
white background, then compare the
vertical and horizontal size between black
and white background. Adjust VEHT and
HEHT until you get the minimum
difference of screen size. After you adjust
VEHT and HEHT, you must re-adjust
vertical and horizontal amplitude.
Adjust HPOS60 for horizontal position.
Adjust HSIZE60 for horizontal width.
Adjust PARA60, TRAP60 and CORN60
until the vertical line at left and right side
of the picture become straight.
Adjust VEHT and HEHT using same
method of PAL system. Also need readjustment of vertical and horizontal
amplitude.
1
2
adjustment)
Key 6
(Status
RFAGC (25)
PIFAFT (44)
HAFC (00)
S-B-Y (08)
S-R-Y (08)
VOL 05 (48)
VOL 25 (65)
VOL OUT(73)
Receive a 60dB
grey scale + color
bar signal
RFAGC – monitor the voltage at AGC pin
of the tuner. Then increase the setting o
RFAGC until the tuner AGC voltage reach
maximum (about 5V). Then decrease the
RFAGC setting until the AGC voltage just
drop.
Adjust S-B-Y and S-R-Y to get the optimal
color for SECAM system.
Please keep the PIFAFT value after auto
AFT adjustment.
HAFC item must use the default value.
(curve of
volume
control)
--------- VOL05 is the volume output level at 5%
VOL25 is the volume output level at 25%
Remark: The value of VOL05 and VOL25 was
not suggested to vary in every set. It is
suggested to use the default value.
13 White balance
adjustment
(key 1)
R CUT (6B)
G CUT (9E)
B CUT (7C)
G DRV (39)
B DRV (35)
Black and white
pattern (PAL)
1. Measure the dark side of the picture with a
color analyzer and set RCUT to 80. Then
adjust BCUT and GCUT until the data on
the analyzer become x = 284, y = 299.
2. Measure the bright side of the picture,
Then adjust BDRV and GDRV until the
data on the analyzer become x = 284, y =
299.
3. Repeat step 1 and 2 until you get right
color on both dark and bright side of the
screen.
Other adjustment (default value was suggested, except BRTC)
8Key 0OSD (0A)
TXCX (30)
RGCN (20)
TNTX (25)
TNTN (32)
FMMODE (13)
DKFMMD (20)
9Key 8SCNT (0F)
CNTX (3F)
CNTN (00)
BRTX (20)
BRTN (25)
COLX (35)
COLN (00)
10Key 9CNTC (22)
BRTC (37)
COLC (50)
TNTC (35)
COLP (00)
COLS (54)
BRTS (00)
----------OSD – OSD position
TXCX – OSD intensity when maximum
contrast
RGCN – OSD intensity when minimum
contrast
TNTX – maximum tint level
TNTN – minimum tint level
FMMODE – frequency shift for FM (mono)
mode, only useful for NICAM
model
DKFMMD - frequency shift for DK NICAM
mode
----------SCNT – sub contrast for luminance signal
CNTX – maximum contrast
CNTN – minimum contrast
BRTX – maximum brightness
BRTN – minimum brightness
COLX – maximum color
COLN – minimum color
----------CNTC – 50% contrast
BRTC – 50% brightness
COLC – 50% color
TNTC – 50% tint
COLP – color level for PAL
COLS – color level for SECAM
BRTS – sub brightness for SECAM
For the adjustment of BRTC, receive an 8
step grey scale pattern and adjust all
picture settings to 50%. Then adjust B RTC
until the first and second step on the screen
can just be distinguished.
11 Two digit key
-/--
(sharpness
adjustment)
13 KEY CALLDBE STR 50
SHPTV3 (1A)
SHPAV3 (1A)
SHPTV4 (18)
SHPAV4 (18)
SHPX (1A)
SHPN (1F)
DBE HMC 0D
DBE HP 07
DBE LP 00
DBE LIM FO
SUB FRE 15
SUB HP 02
VOLMAI 03
System data:
ItemAdjust itemDefault value
----------SHPTV3 – 50% sharpness in 3.58 system
(TV)
SHP AV3 – 50% sharpness in 3.58 system (AV)
SHPTV4 – 50% sharpness in 4.43 system
(TV)
SHP AV4 – 50% sharpness in 4.43 system (AV)
SHPX – maximum sharpness
SHPN – minimum sharpness
Richly Music
Signal
Effect Strength
Harmonic Content
High Pass Corner Frequency
Low Pass Corner Frequency
Amplitude Limit
Subwoofer Corner Frequency
Subwoofer Complementary High Pass Filter
Volume Loudspeaker
12Key 7VCDM0
VCDM1
VCDM2
MODE0
MODE1
MODE2
OPTION
It is subject to the current ODF.
Please check the sample to get the value.
System setting of M13
VCDM0 (default value: 28)
BIT Item
0System switch: 0 : normal identify mode 1 : weak signal identify mode
1White peak suppress: 0: on 1: off
3High Sensibility: 0: off 1: on
4, 5STANDBY status after switch on : 00 or 10: force STANDBY
01: force on. 11: status before switch off
6,7Mode0.6, Mode0.7: 0X: English 10: English + Russia 11: English + Vietnamese
MODE1
BIT Item
0BG : 0 : off 1 : on
1I : 0 : off 1 : on
2DK : 0 : off 1 : on
3M : 0 : off 1 : on
4, 5 SSIF1, SSIFO Default sound system after auto search:
00 : BG 01 : I 10 : DK 11 : M
6AV/TV: 0: TV/AV 1: TV AV1/AV2
7Number of channels: 0: 50 1: 100
MODE2
BIT Item
0D-MODE : 0: off 1: on
1Teletext 0: off 1: on
2COMB Filter 0: off 1: on
3BBE 0: off 1: on
4NICAM & IGR 0: off 1: on
5WOOFER 0: off 1: on
6DBE 0: off 1: on
7VM 0: off 1: on
OPTION (default value: 10)
BIT Item
0When blue background off (mute pin of CPU):
0: audio mute on 1: audio mute off
1When blue background off (external mute pin of CPU):
0: audio mute on 1: audio mute off
2When change channel:
0: picture mute on 1: picture mute off
3Audio demodulation gain setting:
0: 50KHz 1: 25KHz
4When no signal:
0: search channel by changing VT 1: use memorized VT
5Logo: 0: off 1: on
6OSD black background: 0: off 1: on
7Display on Sound Mode Changing:
0: on 1: off
Part number Description QtyLocation -----------------
Part number Description QtyLocation -----------------
41WJ0050B00WIRE BARE JUMPER 5MM1J420
41WJ0050B00WIRE BARE JUMPER 5MM1J435
41WJ0050B00WIRE BARE JUMPER 5MM1J436
41WJ0050B00WIRE BARE JUMPER 5MM1J437
41WJ0050B00WIRE BARE JUMPER 5MM1J636
41WJ0050B00WIRE BARE JUMPER 5MM1J637
41WJ0050B00WIRE BARE JUMPER 5MM1J525
41WJ0050B00WIRE BARE JUMPER 5MM1J638
41WJ0060B00WIRE BARE JUMPER 6mm1J044
41WJ0060B00WIRE BARE JUMPER 6mm1J123
41WJ0060B00WIRE BARE JUMPER 6mm1J132
41WJ0060B00WIRE BARE JUMPER 6mm1J141
41WJ0060B00WIRE BARE JUMPER 6mm1J229
41WJ0060B00WIRE BARE JUMPER 6mm1J230
41WJ0060B00WIRE BARE JUMPER 6mm1J232
41WJ0060B00WIRE BARE JUMPER 6mm1J242
41WJ0060B00WIRE BARE JUMPER 6mm1J261
41WJ0060B00WIRE BARE JUMPER 6mm1J301
41WJ0060B00WIRE BARE JUMPER 6mm1J338
41WJ0060B00WIRE BARE JUMPER 6mm1J401
41WJ0060B00WIRE BARE JUMPER 6mm1J421
41WJ0060B00WIRE BARE JUMPER 6mm1J512
41WJ0060B00WIRE BARE JUMPER 6mm1J543
41WJ0060B00WIRE BARE JUMPER 6mm1J601
41WJ0060B00WIRE BARE JUMPER 6mm1J633
41WJ0060B00WIRE BARE JUMPER 6mm1J732
41WJ0060B00WIRE BARE JUMPER 6mm1J733
41WJ0060B00WIRE BARE JUMPER 6mm1J825
41WJ0060B00WIRE BARE JUMPER 6mm1J826
41WJ0060B00WIRE BARE JUMPER 6mm1J832
41WJ0060B00WIRE BARE JUMPER 6mm1J834
41WJ0060B00WIRE BARE JUMPER 6mm1J836
41WJ0060B00WIRE BARE JUMPER 6mm1J837
41WJ0060B00WIRE BARE JUMPER 6mm1J838
41WJ0060B00WIRE BARE JUMPER 6mm1J911
41WJ0060B00WIRE BARE JUMPER 6mm1J921
41WJ0060B00WIRE BARE JUMPER 6mm1R126
41WJ0060B00WIRE BARE JUMPER 6mm1R224
41WJ0140B00WIRE BARE JUMPER 14MM1J321
41WJ0060B00WIRE BARE JUMPER 6mm1R028A
41WJ0060B00WIRE BARE JUMPER 6mm1R028B
41WJ0060B00WIRE BARE JUMPER 6mm1R028C
41WJ0060B00WIRE BARE JUMPER 6mm1J720
41WJ0060B00WIRE BARE JUMPER 6mm1J523
41WJ0060B00WIRE BARE JUMPER 6mm1J327
41WJ0060B00WIRE BARE JUMPER 6mm1J328
41WJ0060B00WIRE BARE JUMPER 6mm1R027
41WJ0060B00WIRE BARE JUMPER 6mm1R023
41WJ0060B00WIRE BARE JUMPER 6mm1R024
41WJ0060B00WIRE BARE JUMPER 6mm1R025
41WJ0060B00WIRE BARE JUMPER 6mm1R026
41WJ0065B00WIRE BARE JUMPER 6.5MM1J615
Page 13 of 22CTM5954
Part number Description QtyLocation -----------------
41WJ0065B00WIRE BARE JUMPER 6.5MM1J514
41WJ0065B00WIRE BARE JUMPER 6.5MM1J511
41WJ0065B00WIRE BARE JUMPER 6.5MM1J433
41WJ0065B00WIRE BARE JUMPER 6.5MM1J632
41WJ0065B00WIRE BARE JUMPER 6.5MM1J725
41WJ0065B00WIRE BARE JUMPER 6.5MM1J729
41WJ0065B00WIRE BARE JUMPER 6.5MM1J410
41WJ0065B00WIRE BARE JUMPER 6.5MM1R238
41WJ0070B00WIRE BARE JUMPER 7MM1J513
41WJ0070B00WIRE BARE JUMPER 7MM1J426
41WJ0070B00WIRE BARE JUMPER 7MM1J023
41WJ0070B00WIRE BARE JUMPER 7MM1J726
41WJ0070B00WIRE BARE JUMPER 7MM1J741
41WJ0070B00WIRE BARE JUMPER 7MM1J671
41WJ0070B00WIRE BARE JUMPER 7MM1J672
41WJ0070B00WIRE BARE JUMPER 7MM1J724
41WJ0075B00WIRE BARE JUMPER 7.5MM1D141
41WJ0075B00WIRE BARE JUMPER 7.5MM1J041
41WJ0075B00WIRE BARE JUMPER 7.5MM1J043
41WJ0075B00WIRE BARE JUMPER 7.5MM1J124
41WJ0075B00WIRE BARE JUMPER 7.5MM1J151
41WJ0075B00WIRE BARE JUMPER 7.5MM1J152
41WJ0075B00WIRE BARE JUMPER 7.5MM1J154
41WJ0075B00WIRE BARE JUMPER 7.5MM1J207
41WJ0075B00WIRE BARE JUMPER 7.5MM1J208
41WJ0075B00WIRE BARE JUMPER 7.5MM1J217
41WJ0075B00WIRE BARE JUMPER 7.5MM1J241
41WJ0075B00WIRE BARE JUMPER 7.5MM1J331
41WJ0075B00WIRE BARE JUMPER 7.5MM1J351
41WJ0075B00WIRE BARE JUMPER 7.5MM1J412
41WJ0075B00WIRE BARE JUMPER 7.5MM1J541
41WJ0075B00WIRE BARE JUMPER 7.5MM1J551
41WJ0075B00WIRE BARE JUMPER 7.5MM1J642
41WJ0075B00WIRE BARE JUMPER 7.5MM1J651
41WJ0075B00WIRE BARE JUMPER 7.5MM1J656
41WJ0075B00WIRE BARE JUMPER 7.5MM1J693
41WJ0075B00WIRE BARE JUMPER 7.5MM1J712
41WJ0075B00WIRE BARE JUMPER 7.5MM1J734
41WJ0075B00WIRE BARE JUMPER 7.5MM1J812
41WJ0075B00WIRE BARE JUMPER 7.5MM1J821
41WJ0075B00WIRE BARE JUMPER 7.5MM1J833
41WJ0075B00WIRE BARE JUMPER 7.5MM1J851
41WJ0075B00WIRE BARE JUMPER 7.5MM1J915
41WJ0075B00WIRE BARE JUMPER 7.5MM1J405
41WJ0075B00WIRE BARE JUMPER 7.5MM1J406
41WJ0075B00WIRE BARE JUMPER 7.5MM1J407
41WJ0075B00WIRE BARE JUMPER 7.5MM1J408
41WJ0075B00WIRE BARE JUMPER 7.5MM1J521
41WJ0075B00WIRE BARE JUMPER 7.5MM1J941
41WJ0080B00WIRE BARE JUMPER 8 MM1J201
41WJ0080B00WIRE BARE JUMPER 8 MM1J425
41WJ0080B00WIRE BARE JUMPER 8 MM1J443
Page 14 of 22CTM5954
Part number Description QtyLocation -----------------
41WJ0080B00WIRE BARE JUMPER 8 MM1J453
41WJ0085B00WIRE BARE JUMPER 8.5MM1J122
41WJ0085B00WIRE BARE JUMPER 8.5MM1J204
41WJ0085B00WIRE BARE JUMPER 8.5MM1J205
41WJ0085B00WIRE BARE JUMPER 8.5MM1J424
41WJ0085B00WIRE BARE JUMPER 8.5MM1J441
41WJ0085B00WIRE BARE JUMPER 8.5MM1J502
41WJ0085B00WIRE BARE JUMPER 8.5MM1J503
41WJ0085B00WIRE BARE JUMPER 8.5MM1J553
41WJ0085B00WIRE BARE JUMPER 8.5MM1J554
41WJ0085B00WIRE BARE JUMPER 8.5MM1J621
41WJ0085B00WIRE BARE JUMPER 8.5MM1J723
41WJ0085B00WIRE BARE JUMPER 8.5MM1J822
41WJ0085B00WIRE BARE JUMPER 8.5MM1J409
41WJ0090B00WIRE BARE JUMPER 9MM1J031
41WJ0090B00WIRE BARE JUMPER 9MM1J634
41WJ0095B00WIRE BARE JUMPER 9.5MM1J226
41WJ0095B00WIRE BARE JUMPER 9.5MM1J343
41WJ0095B00WIRE BARE JUMPER 9.5MM1J344
41WJ0095B00WIRE BARE JUMPER 9.5MM1J713
41WJ0100B00WIRE BARE JUMPER 10MM1J423
41WJ0100B00WIRE BARE JUMPER 10MM1J001
41WJ0100B00WIRE BARE JUMPER 10MM1J002
41WJ0100B00WIRE BARE JUMPER 10MM1J061
41WJ0100B00WIRE BARE JUMPER 10MM1J203
41WJ0100B00WIRE BARE JUMPER 10MM1J402
41WJ0100B00WIRE BARE JUMPER 10MM1J432
41WJ0100B00WIRE BARE JUMPER 10MM1J611
41WJ0100B00WIRE BARE JUMPER 10MM1J631
41WJ0100B00WIRE BARE JUMPER 10MM1J652
41WJ0100B00WIRE BARE JUMPER 10MM1J653
41WJ0100B00WIRE BARE JUMPER 10MM1J692
41WJ0100B00WIRE BARE JUMPER 10MM1J728
41WJ0100B00WIRE BARE JUMPER 10MM1J735
41WJ0100B00WIRE BARE JUMPER 10MM1J501
41WJ0100B00WIRE BARE JUMPER 10MM1J134
41WJ0100B00WIRE BARE JUMPER 10MM1J916
41WJ0105B00WIRE BARE JUMPER 10.5MM1J442
41WJ0105B00WIRE BARE JUMPER 10.5MM1J622
41WJ0110B00WIRE BARE JUMPER 11MM1J244
41WJ0110B00WIRE BARE JUMPER 11MM1J227
41WJ0110B00WIRE BARE JUMPER 11MM1J228
41WJ0110B00WIRE BARE JUMPER 11MM1J302
41WJ0110B00WIRE BARE JUMPER 11MM1J313
41WJ0110B00WIRE BARE JUMPER 11MM1J322
41WJ0110B00WIRE BARE JUMPER 11MM1J625
41WJ0110B00WIRE BARE JUMPER 11MM1JP213
41WJ0110B00WIRE BARE JUMPER 11MM1J612
41WJ0110B00WIRE BARE JUMPER 11MM1J614
41WJ0115B00WIRE BARE JUMPER 11.5MM1J342
41WJ0115B00WIRE BARE JUMPER 11.5MM1J052
41WJ0115B00WIRE BARE JUMPER 11.5MM1J627
Page 15 of 22CTM5954
Part number Description QtyLocation -----------------
41WJ0115B00WIRE BARE JUMPER 11.5MM1J628
41WJ0115B00WIRE BARE JUMPER 11.5MM1J246
41WJ0115B00WIRE BARE JUMPER 11.5MM1J522
41WJ0120B00WIRE BARE JUMPER 12MM1J051
41WJ0120B00WIRE BARE JUMPER 12MM1J434
41WJ0120B00WIRE BARE JUMPER 12MM1J711
41WJ0120B00WIRE BARE JUMPER 12MM1J250
41WJ0120B00WIRE BARE JUMPER 12MM1J253
41WJ0120B00WIRE BARE JUMPER 12MM1J254
41WJ0125B00WIRE BARE JUMPER 12.5MM1J131
41WJ0125B00WIRE BARE JUMPER 12.5MM1J206
41WJ0125B00WIRE BARE JUMPER 12.5MM1J218
41WJ0125B00WIRE BARE JUMPER 12.5MM1J263
41WJ0125B00WIRE BARE JUMPER 12.5MM1J352
41WJ0125B00WIRE BARE JUMPER 12.5MM1J643
41WJ0125B00WIRE BARE JUMPER 12.5MM1J813
41WJ0125B00WIRE BARE JUMPER 12.5MM1J222
41WJ0125B00WIRE BARE JUMPER 12.5MM1J951
41WJ0125B00WIRE BARE JUMPER 12.5MM1J981
41WJ0125B00WIRE BARE JUMPER 12.5MM1J225
41WJ0125B00WIRE BARE JUMPER 12.5MM1J772
41WJ0130B00WIRE BARE JUMPER 13MM1J239
41WJ0130B00WIRE BARE JUMPER 13MM1J413
41WJ0130B00WIRE BARE JUMPER 13MM1J346
41WJ0135B00WIRE BARE JUMPER 13.5MM1J248A
41WJ0135B00WIRE BARE JUMPER 13.5MM1J224
41WJ0135B00WIRE BARE JUMPER 13.5MM1J236
41WJ0135B00WIRE BARE JUMPER 13.5MM1J411
41WJ0135B00WIRE BARE JUMPER 13.5MM1J247
41WJ0135B00WIRE BARE JUMPER 13.5MM1R228A
41WJ0135B00WIRE BARE JUMPER 13.5MM1J345
41WJ0140B00WIRE BARE JUMPER 14MM1J335
41WJ0140B00WIRE BARE JUMPER 14MM1J336
41WJ0140B00WIRE BARE JUMPER 14MM1J337
41WJ0140B00WIRE BARE JUMPER 14MM1J742
41WJ0150B00WIRE BARE JUMPER 15MM1J032
41WJ0150B00WIRE BARE JUMPER 15MM1J133
41WJ0150B00WIRE BARE JUMPER 15MM1J153
41WJ0150B00WIRE BARE JUMPER 15MM1J235
41WJ0150B00WIRE BARE JUMPER 15MM1J237
41WJ0150B00WIRE BARE JUMPER 15MM1J243
41WJ0150B00WIRE BARE JUMPER 15MM1J245
41WJ0150B00WIRE BARE JUMPER 15MM1J255
41WJ0150B00WIRE BARE JUMPER 15MM1J262
41WJ0105B00WIRE BARE JUMPER 10.5MM1J311
41WJ0150B00WIRE BARE JUMPER 15MM1J461
41WJ0150B00WIRE BARE JUMPER 15MM1J542
41WJ0150B00WIRE BARE JUMPER 15MM1J714
41WJ0150B00WIRE BARE JUMPER 15MM1J761
41WJ0150B00WIRE BARE JUMPER 15MM1J931
41WJ0150B00WIRE BARE JUMPER 15MM1J721A
41WJ0150B00WIRE BARE JUMPER 15MM1J722A
Page 16 of 22CTM5954
Part number Description QtyLocation -----------------
41WJ0150B00WIRE BARE JUMPER 15MM1J211
41WJ0150B00WIRE BARE JUMPER 15MM1J347
41WJ0160B00WIRE BARE JUMPER 16MM1J238
41WJ0160B00WIRE BARE JUMPER 16MM1J325
41WJ0160B00WIRE BARE JUMPER 16MM1J334
41WJ0160B00WIRE BARE JUMPER 16MM1J431
41WJ0160B00WIRE BARE JUMPER 16MM1J444
41WJ0160B00WIRE BARE JUMPER 16MM1J445
41WJ0165B00WIRE BARE JUMPER 16.5MM1J221
41WJ0165B00WIRE BARE JUMPER 16.5MM1J314
41WJ0165B00WIRE BARE JUMPER 16.5MM1J234
41WJ0170B00WIRE BARE JUMPER 17MM1J231
41WJ0170B00WIRE BARE JUMPER 17MM1J240
41WJ0170B00WIRE BARE JUMPER 17MM1J835
41WJ0175B00WIRE BARE JUMPER 17.5MM1J249A
41WJ0175B00WIRE BARE JUMPER 17.5MM1J251
41WJ0175B00WIRE BARE JUMPER 17.5MM1J661
41WJ0175B00WIRE BARE JUMPER 17.5MM1J771
41WJ0175B00WIRE BARE JUMPER 17.5MM1J811
41WJ0175B00WIRE BARE JUMPER 17.5MM1J223
41WJ0175B00WIRE BARE JUMPER 17.5MM1J913
41WJ0175B00WIRE BARE JUMPER 17.5MM1J912
41WJ0180B00WIRE BARE JUMPER 18MM1J214
41WJ0180B00WIRE BARE JUMPER 18MM1J623
41WJ0190B00WIRE BARE JUMPER 19MM1J823
41WJ0195B00WIRE BARE JUMPER 19.5MM1J323
41WJ0195B00WIRE BARE JUMPER 19.5MM1J355
41WJ0195B00WIRE BARE JUMPER 19.5MM1J641
41WJ0200B00WIRE BARE JUMPER 20MM1J824
41WJ0200B00WIRE BARE JUMPER 20MM1J831
41WJ0200B00WIRE BARE JUMPER 20MM1J312
41WJ0200B00WIRE BARE JUMPER 20MM1J427
41WJ0200B00WIRE BARE JUMPER 20MM1J624
41WJ0200B00WIRE BARE JUMPER 20MM1J626
41WJ0200B00WIRE BARE JUMPER 20MM1J727
45FIL5M50Y1 CER FILTER 5.5MHz1Z261
45OSC4M43Y0 CRYSTAL 4.43MHz (CL=16pF)1X201
45OSC8M00Y0 CRYSTAL 8.0MHZ1X051
45SAWK3350K SAW FILTER K3350K (38.9MHZ)1Z141
45TRA5M50Y0CER TRAP TPS 5.5MHZ1Z254
4620598W04XPIN BASE *4 TJC1-4A1
4633079W04XPIN BASE *4 TJC3-4A1
4633079W05XPIN BASE *5 TJC3-5A1
4633079W06XPIN BASE *6 TJC3-6A1
4633079W06XPIN BASE *6 TJC3-6A1P003
4612866W02X PIN BASE *2 S11-02Y1
4633079W02XPIN BASE *2 TJC3-2A1
4633079W05XPIN BASE *5 TJC3-5A1
47RCA023XX1RCA JACK 3PV YEL WHI RED/SW1P911
47RCA023XX1RCA JACK 3PV YEL WHI RED/SW1P931
47SVI002XX0 Y/C SOCKET VERTICAL TYPE1P981
541287000X0FIBRE WASHER 3.3 X 10 X 0.82
Page 17 of 22CTM5954
Part number Description QtyLocation -----------------
