TCL 42E5300, 42E5300 MS82S-AP Schematic

TCL

SERVICE MANUAL

42E5300 MS82S-AP

1. Caution…………………………………………………………………………2

2. specification……………………………………………………………………6

3. Alignment Procedure…………………………………………………………7
4．Block diagram…………………………………………………………………２６
5．Scheme Diagram ……………………………………………………………２７

5. Troubleshooting………………………………………………………………３４

6([SORGHGUDZLQJ7

This m anual i s t he l atest at t he t ime of pr inting, and doe s not
include the modification which may be made after the printing, by
the constant improvement of product

RISK OF

ELECTRIC

SHOCK DO

NOT

OPEN.

SCHNEIDER ELECTRONICS GMBH-GERMANY

1. CAUTION

CAUTION:

Use of controls, adjustments or procedures other than those specified herein may result in
hazardous radiation exposure.

CA UT ION : TO RE DU CE THE RIS K OF

CA U T IO N

RISK

SHOCK

The lighting flash with arrowhead symbol, with an equilateral triangle is intended to
alert the user to the presence of uninsulated voltage within the products
enclosure that may be of sufficient magnitude to constitute a risk of electric shock to
the person.

The exclamation point within an equilateral triangle is intended to alert the user to the
presence of important operating and maintenance (servicing) instructions in the
literature accompanying the appliance.

ELECTRI

NOT

OPEN.

ELECTR ICAL SH OCK, DO NOT REMOVE
COVER (OR BACK). NO USER SERVIC EA BLE
PAR TS INS IDE . REFE R SER VIC ING TO
QUALIFIE D SERVICE PERS ONNEL.

dangerous

WARNING: TO REDUCE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

2

2

SCHNEIDER ELECTRONICS GMBH-GERMANY

IMPORTANT SAFETY INSTRUCTIONS

CAUTION:

Read all of these instructions. Sa ve these instructions f or later use . Follo w all Warnings and
Instructions marked on the audio equipment.

1. Read Instructions-All the safety and operatinginstructionsshouldbe read before the productis operated.

2. Retain Instructions- The safety and operating instructions should be retained for future reference.

3. Heed Warnings- All warnings on the product and in the operating instructions should be adhered to.

4. Follow Instructions- All operating and use instructions should be followed.

FOR YOUR PERSONAL SAFETY

1. When the power cord or plug is damaged or frayed, unplug this television set from the wall outlet and refer servicing to
qualified service personnel.

2. Do not overload wall outlets and extension cords as this can result in fire or electric shock.

3. Do not allow anything to rest on or roll over the power cord, and do not place the TV where power cord is subject to
traffic or abuse. This may result in a shock or fire hazard.

4. Do not attempt to service this television set yourself as opening or removing covers may expose you to dangerous
voltage or other hazards. Refer all servicing to qualified service personnel.

5. Never push objects of any kind into this television set through cabinet slots as they may touch dangerous voltage
points or short out parts that could result in a fire or electric shock. Never spill liquid of any kind on the television set.

6. If the television set has been dropped or the cabinet has been damaged, unplug this television set from the wall outlet
and refer servicing to qualified service personnel.

7. If liquid has been spilled into the television set, unplug this television set from the wall outlet and refer servicing to
qualified service personnel.

8. Do not subject your television set to impact of any kind. Be particularly careful not to damage the picture tube surface.

9. Unplug this television set from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a
damp cloth for cleaning.

10.1. Do not place this television set on an unstable cart, stand, or table. The television set may fall, causing serious injury
to a child or an adult, and serious damage to the appliance. Use only with a cart or stand recommended by the
manufacturer, or sold with the television set. Wall or shelf mounting should follow the manufacturer s instructions, and
should use a mounting kit approved by the manufacturer.

10.2. An appliance and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces
may cause the appliance and cart combination to overturn.

3

3

SCHNEIDER ELECTRONICS GMBH-GERMANY

PROTECTION AND LOCATION OF YOUR SET

11. Do not use this television set near water ... for example, near a bathtub, washbowl, kitchen sink, or laundry tub, in a
wet basement, or near a swimming pool, etc.
Never expose the set to rain or water. If the set has been exposed to rain or water, unplug the set from the wall
outlet and refer servicing to qualified service personnel.

12. Choose a place where light (artificial or sunlight) does not shine directly on the screen.

13. Avoid dusty places, since piling up of dust inside TV chassis may cause failure of the set when high humidity persists.

14. The set has slots, or openings in the cabinet for ventilation purposes, to provide reliable operation of the receiver, to

protect it from overheating. These openings must not be blocked or covered.

Never cover the slots or openings with cloth or other material.
Never block the bottom ventilation slots of the set by placing it on a bed, sofa, rug, etc.
Never place the set near or over a radiator or heat register.
Never place the set in enclosure, unless proper ventilation is provided.

a built-in

PROTECTION AND LOCATION OF YOUR SET

15.1. If an outside antenna is connected to the television set, be sure the antenna system is grounded so as to provide some

protection against voltage surges and built up static charges, Section 810 of the National Electrical Code, NFPA No.
70-1975, provides information with respect to proper grounding of the mast and supporting structure, grounding of the
lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna discharge unit, connection
to grounding electrode, and requirements for the grounding electrode.

EXAMPLE OF ANTENNA GROUNDING AS PER NATIONAL ELECTRICAL CODE INSTR UCTIONS

EXAMPLE OF ANTENNA GROUNDING AS PER

NATIONAL ELECTRICAL CODE

ANTENNA
LEAD- IN WIRE

GROUND CLAMP

ELECTRIC SERVICE

EQUIPMENT

NEC-NATIONAL ELECTRICAL CODE

ANTENNA DISCHARGE
UNIT (NEC SECTION
810-20)

GROUNDING
CONDUCTORS
(NECSECTION 810-21)

GROUND CLAMPS

POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250. PART H)

15.2. Note to CATV system installer : (Only for the television set with CATV reception)

This reminder is provided to call the CATV system attention to Ar ticle 820-40 of the NEC that provides

installer s
guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding
system of the building, as close to the point of cable entry as practical.

16. An outside antenna system shouldnot be located in the vicinity of overhead power lines or other electric lights or power
circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care
should be taken to keep from touching such power lines or circuits as contact with them might be fatal.

17. For added protection for this television set during a lightning storm, or when it is left unattended and unused for long
periods of time, unplug it from the wall outlet and disconnect the antenna. This will prevent damage due to lightning
and power-line surges.

4

4

SCHNEIDER ELECTRONICS GMBH-GERMANY

OPERATION OF YOUR SET

18.

This television set should be operated only from the type of power source indicated on the marking label.If you are not
sure of the type of power supply at your home, consult your television dealer or local power company. For television
sets designed to operate from battery power, refer to the operating instructions.

19. If the television set does not operate normally by following the operating instructions, unplug this television set from the
wall outlet and refer servicing to qualified service personnel. Adjust only those controls that are covered in the operating
instructions as improper adjustment of other controls may result in damage and will often require extensive work by a
qualified technician to restore the television set to normal operation.

20. When going on a holiday : If your television set is to remain unused for a period of time, for instance, when you go on
a holiday, turn the television set and unplug the television set from the wall outlet.

off

IF THE SET DOES NOT OPERATE PROPERLY

21. If youare unable to restorenormal operation by following the detailedprocedurein your operatinginstructions,
do not attempt any further adjustment. Unplug the set and call your dealer or service technician.

22. Whenever the television set is damaged or fails, or a distinct change in performance indicates a need for
service, unplug the set and have it checked by a professional service technician.

23. It is normal for some TV sets to make occasional snapping or popping sounds, particularly when being
turned on or off. If the snapping or popping is continuous or frequent, unplug the set and consult your
dealer or service technician.

FOR SERVICE AND MODIFICATION

24. Do not use attachments not recommendedby the television set manufacturer as they may cause hazards.

25. When replacementparts are required, be sure the service technician has used replacementparts specified
by the manufacturer that have the same characteristics as the original part. Unauthorized substitutions
may result in fire, electric shock, or other hazards.

26. Upon completion of any service or repairs to the television set, ask the service technician to perform
routine safety checks to determine that the television is in safe operating condition.

5

5

EM BUSINESS CENTER
FTV PRODUCT MANAGEMENT DEPT.

SPECIFICATION RELEASE

Version: V2.0 Issued Date: 2012.8.8

Model: L42E5300F/MS82S-AP/AUTM E20 V1


Category

Naturalight Technology Yes (Natural Light Engine ‖)

Dynamic Contrast Yes

Color Temperature Warm / Normal / Cold

Backlight Adjustable Yes Component Video Format Y,PB/CB,PR/CR:up to 1080P

Scale Mode

Picture Effect Standard, Bright, Soft, Personal HDMI Video Format up to 1080P

Film Mode (3:2 pull down) AUTO PC Compatibility Up to SXGA

VGA Dot to Dot Display Yes (Natural)

Light Sensor

Picture Enhancement YPBPR Input 1---Downward

Comb Filter 3D Audio Input for YP

Adaptive Deinterlacing 3D YC

Blue Stretch Yes Audio Input for YC

Black Stretch Yes VGA(PC) Input 1 (D-Sub,15 Pins)---Downward

Motion Compensation Yes Audio Input for VGA(PC) Share with Audio for "YP

DLTI Yes HDMI 3 (HDMI1,HDMI2,HDMI3) ---in side

DCTI Yes

Dynamic Skin Correction Yes

PANEL SPECIFICATION

Back light Unit

Panel supplier TCL USB 1（Standard）---in side

Aspect Ratio 16:9

Panel Size (inch) 42" TV System PAL/SECAM B/G,D/K,I ;NTSC-M

Display Resolution 1920*1080 AV System

Brightness (cd/m2)

Contrast Ratio

Response Time Tr/Tf 6.5ms Certification

Viewing Angle (H/V) 178°/178° Power Supply

Life Time 30,000hrs Power Consumption-TV on

Color 16.7M Power Consumption-Standby

310 Channels

SOUND

Speakers Integrated speakers (Bottom side) Keyboard Position

Audio Power Output 2×8W Base Stand Detachable
Woofer Power Output --

Smart Volume Yes Unpackaged Dimension for Main Body (L*H*D) (mm)

Sound Effect Stereo, Music, Movie, News,Personal With Base Stand (mm)

Sound Control

Sound Features

FUNCTION

OSD Language English/French/Thai/Vietnamese/Russian Base Stand

OSD Features Motion Bmp Style Gross Weight (Kg)

Source in OSD Source Bmp Icon Selecting,Source Jack Layout Display

Teletext Yes 20 feet

Clock/Sleep Timers Yes 40 feet

Wake up/Turn off time Yes 40 feet high

Wake up Source/Chanel Yes

Watch Time Limit Yes Operation Manual English(Default)

Startup Setting Yes(User can set a picture for turning on Logo display) Remote Control For TV control (with two batteries)

Smart Switch Yes(Signal Auto Detecting and Changing Source) Base Stand

Picture Freeze Yes Speaker Box

DNR（Dynamic Noise Reduction） Off、Low、Middle、High Wall Mount

Hotel Menu In factory mode Others AC Power cord, AV Adapter cable

USB Connection

Design and specifications are subject to change without notice!

LCDTV

SIGNAL FORMAT CAPABILITY

Standard,Full, Subtitle, Wide Screen,
Zoom,Expand,Original,Natural DVI Video Format Up to XGA for HDMI-PC

TERMINALS

--

LED RF Input(Antenna) 1 (IEC Type)---Downward

AV1 Input (Composite)
AV2 Input (Composite)

BPR 1---Downward

BCR Input Share with "YPBPR"

BCR Share with Audio for "YPBPR"

CVBS Output (Composite)

SPDIF Output

Headphone Output 1 (Φ3.5mm )---Downward

Audio/CVBS---R/L+ Video in side

and Audio share with Y

1 (Φ3.5mm,need a adapter cable) ---Downward

1 (coaxial digital audio output)---Downward

Video Share with Y

BASIC INFO.

PAL,NTSC,SECAM

199(1~199)

3200:1 Chassis

Default Color of Front Cabinet

MS82S-AP

CB

AC 100V-240V 50/60Hz

90W

≤1W

Black

Side

Yes

PACKAGE INFO.

966.7L x 631.2Hx226D

Balance, Sound EQ Adjust; Without Base Stand (mm)

MTS（NICAM）

Scene Selecting（DeskTop mode and HangUp mode） Main Body (mm)

Portuguese/Arabic//Farsi/Hebrew/Mongolian Net Weight (Kg)

Packaged Dimension (L*H*D)

Speaker Box

966.7Lx571Hx57D

1105(L)x158(W)x705(H)

--

Packaged with Main Body

13.3Kg（with stand)

15.7Kg

Container Loading

（

2*37）*3+16=238

（1

4*8+2*19）*3+32=482

（14*8+2*19）*3+100(卧放）=550

ACCESSORIES

Integrated Packaging

Integrated

WMB331（Optional）

Movie：Support H.264、RM/RMVB、XVID、FLV

DivX、MPEG2、MPEG2、MPEG4、VC1

Photo: Support JPEG、BMP、PNG；

Music: support MP3、WMA 、M4A；

HW Drafted by: 钟永胜　　　　２０１２－８－８

MD Drafted by:

Approved by:

PBPR Audio

BPR"

TCL Multimedia Technology Holdings Ltd.
R&D Center

Alignment Procedure

MS82S-AP/LA Chassis

Version: 1.0
Release Date: 2011-9-6

PREPARED BY: Wise Zhang

APPROVED BY:

DATE: 2011-9-6

DATE:

MS82S-AP/LA Chassis Software Upgrade Guidance

Content

1. General Description 3

2. Factory Menu 3

2.1 Way of accessing 3

2.2 Factory Menu 4

2.3 ADC calibration menu 5

2.4 White Balance adjustment 6

3. Design Menu 7

3.1 way of accessing 7

3.2 SHOP Menu 8

3.3 Other Menu 9

3.4 Service Menu 10

3.5 PARAM SETTING MENU 11

3.6 Hotel Menu 12

4. Steps of debugging 13

4.1 Device 13

4.2 steps of debugging 13

4.3 ADC calibration 13

4.4 White Balance adjustment 14

4.5 White Balance adjustment (automatically) 16

5. Chip list of software programming before SMT 16

6. Appendix 17

6.1 Software upgrading through USB 17

6.2 Check software version, release date and Project ID 18

6.3 FAQ 20

History Description of major changes Release

Date

V1.0 2011-9-7

Chassis Model

FHD MS82S-AP/LA L40D3260F etc
HD MS82S-APLA L32D3260, L32D3270 etc

PRELIMINARY INFORMATION ----- SUBJECT TO CHANGE

2

MS82S-AP/LA Chassis Software Upgrade Guidance

1. General Description

MS82S-AP/LA is our latest design especially for LCDTV products selling in Asia

Pacific (AP) and Latin America (LA) market. It features by its high integration,
easy debugging as well as convenience in terms of maintenance. Fast software
upgrade through USB disk facilitates both manufacture and after-sale service.
Meantime, a variety of functions involved in Factory Main Menu can not only
bring benefits for production, but also satisfy various demands of customer.

Note: Factory Main Menu (FMM) is divided into Factory Menu, Design Menu, Service
Menu and Hotel Menu. Factory Menu covers all indispensable functions during
manufacture such as White Balance Adjustment, ADC Calibration, USB Upgrading e.g.,
while the items under Design Menu is exclusively used by R&D engineer, anyone else
shouldn’t change the settings in the menu. When you wish to learn the product
information like project ID, model name, chassis name, software version, release date,
you can access to Service Menu. In addition, in Hotel Menu, we also provide a great
deal of useful functions for specific applications in hotel.

2. Factory Menu

2.1 Accessing way:

a. In the first place, press Menu button of
remote

control, then select Contrast item of Picture
submenu. Finally, press 9, 7, 3, 5 consecutively.
b. When the FAC HOTKEY item o f Factory Menu
is enabled (ON), press Return button of remote
control.

PRELIMINARY INFORMATION ----- SUBJECT TO CHANGE

3

MS82S-AP/LA Chassis Software Upgrade Guidance

2.2 Factory Menu

Factory Menu

Name Default Description Status

FAC
HOTKEY

OFF Factory Menu shortcut button switch

The item must be disabled (OFF) after production

OK

WARM-
UP

ADC >> ADC calibration ( see details below) OK

WHITE
BALANCE

SHOP

NVM RESET DO Restore default value except WB and ADC data. OK

SET FAC CH DO Preset the channel table of factory. Option: HZ, WX, EGYPT-EL,

Power On
Mode

OFF OFF: Normal mode. Display blue screen when no signal. Turn to

automatically standby mode if keep the signal unavailable over
15 minutes.

ON: Aging mode. Display snow dot when no signal. The set will not
turn to standby even if the unavailability of signal

>> White Balance Adjustment ( see details below) OK

DO It is crucial that the function is executed after production aim to clear

information of production process, ensure user cannot access to
Factory Menu after executing the item.

ALGERIA e.g. To p reset th e ch an nel table of certain factory, firstly,
choose the corresponding factory name, then press OK button of
remote control and wait until the disappearance of Factory Menu,

LAST/STB ON: the set will power on after switching on power.

STB: the set will remain standby status after switching on power.
Last: the set will turn to the status in which it lies when last switching

off.

If without requirement from certain customer,

OK

OK

OK

OK

by default, the Setting should be Last for MS82S-AP and STB for
MS82S-LA

USB
UPDATE

SW NO. OFF Version information of Main Software OK

Project
Name

SIACP
Version

Date Release date and time of main software OK

Upgrade software. Please see details below. OK

Product model OK

Serial port remote control protocol OK

PRELIMINARY INFORMATION ----- SUBJECT TO CHANGE

4

MS82S-AP/LA Chassis Software Upgrade Guidance

2.3 ADC calibration menu

ADC Menu

Press the button in remote control to select certain
item and

ADC calibration.
Notes:

1. Only YPBPR and RGB source should be calibrated.

to change the value of ADC data or start

ADC Calibration menu

Name Default Description Status

SOURCE Select the source you intend to ADC Calibrate.

R GAIN 4096 Gain of R channel ( cannot be changed after auto calibration) OK

G GAIN 4096 Gain of G channel ( cannot be changed after auto calibration) OK

B GAIN 4096 Gain of B channel ( cannot be changed after auto calibration) OK
R OFFSET 0 Offset of R channel ( cannot be changed after auto calibration) OK

Only YPBPR and RGB are available.

OK

B OFFSET 0 Offset of B channel ( cannot be changed after auto calibration) OK

G OFFSET 0 Offset of G channel ( cannot be changed after auto calibration) OK

AUTO ADC DO Select and execute the item, ADC Calibration starts. It indicates

ADC
STATUS

Show the ADC status of YPbPr/RGB Channel. SUCCESS will be

a successful calibration if prompt “OK” is displayed.
Otherwise, It is a failing calibration (“FAIL” is displayed).

display if YPbPr/RGB Channel has been correctly calibrated.
Otherwise FAIL will be displayed

OK

OK

PRELIMINARY INFORMATION ----- SUBJECT TO CHANGE

5

MS82S-AP/LA Chassis Software Upgrade Guidance

2.4 White Balance Adjustment menu

White Balance menu

Press the button in remote control to select
certain item and

to adjust White Balance

White Balance Adjustment menu

Name Default Description Status

Source PC Select the source you intend to apply WB adjustment.

COLOR
TEMPERATURE

R GAIN

G GAIN

B GAIN

R OFFSET

Cool Select color temperature you intend to adjust Three groups of

-2

0

+9

+6

Only HDMI1, AV1, YPBPR, PC and should be adjusted.

color temperature: Normal, Warm, Cool are available for each
source.

Gain of R channel ( cannot be changed after auto calibration) OK

Gain of G channel ( cannot be changed after auto calibration) OK

Gain of B channel ( cannot be changed after auto calibration) OK

Offset of R channel ( cannot be changed after auto calibration) OK

OK

OK

G OFFSET

0

Offset of G channel ( cannot be changed after auto calibration) OK

B OFFSET

-2

Offset of B channel ( cannot be changed after auto calibration) OK

WB INIT

PRELIMINARY INFORMATION ----- SUBJECT TO CHANGE

White Balance Initalization. Before WB adjustment, this item should
be executed.

OK

6

MS82S-AP/LA Chassis Software Upgrade Guidance

3 Factory Main Menu

3.1 Accessing way:

1. In the first place, press Menu button of
remote control, then select Contrast item
of Picture submenu. Finally, press 1, 9, 5, 0
consecutively.

2. When the DESIGN HOTKEY item of Design
Menu is enabled (ON), press Return button of
remote control.

Press the button in remote control to select
certain item and to toggle among or execute the

available options.

Main Menu

Name Default Description Status

DESIGN
HOTKEY

FACTORY
MENU

SHOP
INIT

OTHER

SERVICE
MENU

PARAM
SETTING

HOTEL
MENU

PRELIMINARY INFORMATION ----- SUBJECT TO CHANGE

OFF Design Menu shortcut button switch

The item must be disabled (OFF) after production

>>> Access to Factory Menu OK

>>> Contain many options which can be chosen according to the

requirements of customers as default settings when leave factory.
See details below.

>>> The item includes a number of functions offering convenience for

R&D engineer to solve problems. It is exclusively used by R&D.

>>> Provide many useful information for aftersale service

Please reference to SERVICE MENU submenu

>>> Include volume, brightness, contrast, saturation, hue, sharpness,

backlight, volume, overscan Adjustment etc. Please reference to
PARAM SETTING submenu.

>>> Include special functions which bring benefits to hotel management.

The item is accessible only when HOTEL ENABLE item is enabled
(ON).

OK

OK

OK

OK

OK

OK

7

MS82S-AP/LA Chassis Software Upgrade Guidance

3.2 SHOP MENU

Contain many options which can be chosen according
to the requirements of customers as default settings

when leave factory. Press the
control to select certain item and

among the available options..

button in remote

to toggle

SHOP MENU

Name Default Description Status

VOLUME 30 Volume setting, 0~100 adjustable OK

PIC MODE STANDARD Picture mode. Options:

SOUND
MODE

STEREO Sound effects. Options:

BRIGHT, SOFT, PERSONAL,STANDARD

STAREO MISIC, MOVIE, NEWS

OK

OK

CH NUMBER 199 Maximum number of accessible channel NG

OSD
LANGUAGE
Preset CH 0 Preset channel. 0~199 optional OK

ENGLISH AP: English, French, Vietnamese, Russian, Arabic, Farsi, Hebrew,

Thai, Portuguese, Mongolian, LA: English, Portuguese, Spanish

OK

COLOR
TEMP

NORMAL Color temperature. Option: NORMAL, WARM, COOL OK

PRELIMINARY INFORMATION ----- SUBJECT TO CHANGE

8

MS82S-AP/LA Chassis Software Upgrade Guidance

3.3 Other Menu

Press the
certain item and to toggle among the available

options..

button in remote control to select

Other Menu

Name Default Description Status

VIF1 Exclusively used by R&D. OK

VIF2 Exclusively used by R&D. OK

VIF3 Exclusively used by R&D. OK

QMAP
ADJUST

SSC Spectrum Spread Control.

DBC
ENABLE

BP Parameter of DBC

CP Parameter of DBC

DBC MODE DBC Mode. Exclusively used by R&D. OK

MU0 DQS0 Manually adjust DQS1 phase of DDR2

PRELIMINARY INFORMATION ----- SUBJECT TO CHANGE

Exclusively used by R&D. OK

OK

Exclusively used by R&D.

Dynamic Backlight Enable

Exclusively used by R&D.

Exclusively used by R&D.

Exclusively used by R&D.

Exclusively used by R&D

OK

OK

OK

OK

9

MS82S-AP/LA Chassis Software Upgrade Guidance

MU1 DQS1 Manually adjust DQS1 phase of DDR1

Exclusively used by R&D

TTX ON ON: enable teletext OFF: Disable teletext OK

OK

3.4 SERVICE MENU

Press the
item and

button in remote control to select certain

to toggle among the available options..

SERVICE MENU (Product Info)

Name Default Description Status

SW NO. Software virtual code of Main Software OK

DATE Release date, time OK

Project Name Model of product OK

SIACP
Version

Chassis MS82S-AP/MS82S-LA Chassis name OK

Serial port remote control protocol

OK

P ANEL NAM E Panel code OK

PROJECT ID Select project parameters through project ID. OK

USB UPDATE USB upgrade. OK

HOTEL
ENABLE

Switch of Hotel Menu. OK

PRELIMINARY INFORMATION ----- SUBJECT TO CHANGE

10

MS82S-AP/LA Chassis Software Upgrade Guidance

ERROR
CODE

TCL_LOGO Display TCL Logo or not. On : display,

LOGO_LIGHT OK

TCL_SHOW DEMO function ON/OFF OK

NG

OK

Off: not display

3.5 PARAM SETTING MENU

Press the
and

button in remote control to select certain item

to enter menu.

PARAM SETTING MENU (Setting menu)

Name Default Description Status

Brightness
Curve

Contrast
Curve

Saturation
Curve

>>> Brightness curve. Exclusively used by R&D. OK

>>> Contrast curve. Exclusively used by R&D. OK

>>> Saturation curves. Exclusively used by R&D. OK

Hue Curve >>> Hue Curve Exclusively used by R&D. OK

Volume
Curve

>>> Volume curve. Exclusively used by R&D. OK

Backlight
Curve

OverScan >>> Overscan adjustment. Exclusively used by R&D. OK

PRELIMINARY INFORMATION ----- SUBJECT TO CHANGE

>>> Backlight curve. Exclusively used by R&D. OK

11

MS82S-AP/LA Chassis Software Upgrade Guidance

3.6 HOTEL MENU

Press the
certain item and

button in remote control to select

to enter submenu.

Name Default Description Status

POWER
LOGO

CH LOCK OFF Channel scan lock. OK

ON LOGO select OK

HOTEL MENU

MAX VOL 100 Max volume OK

AUTO SET OFF The switch of PIC, SOUND etc.

PIC MODE Standard Picture mode. OK

SOUND
MODE

POWER
VOL.

POWER
SIGNAL

POWER
CHANNEL

KEY LOCK OFF Lock the keys. OK

SA VE DATA
TO

WRITE
DATA TO

PRELIMINARY INFORMATION ----- SUBJECT TO CHANGE

STEREO Sound mode OK

50 Default volume when power on OK

ATV Default signal source when power on OK

0 Default channel no. when power on OK

DO Save the settings of Hotel M enu to USB OK

DO Copy the settings of Hotel Menu from USB OK

When it is ON, these items are selectable.

OK

12

MS82S-AP/LA Chassis Software Upgrade Guidance

g

p

g

ging

4. The steps of debuggin

4.1 Device

Color Analyzer CA-210. Video Pattern Generator Chroma2329. Color TV Pattern
Generator PM5418, VGA cable, AV cable(RCA),YPBPR(RCA) cable.

。

Chroma2329

4.2 ste

s of debu

Fluke5418 CA-210

：

According to the requirement of order, we suggest take the below steps to finish
the appropriate settings.
A enter the Factory Menu, enable FAC HOTKEY
B Check the version of software, release date displayed at the bottom of Factory

Menu. If the information is correct, you can ignore step C and D.
C Enter Factory Main Menu, choose SERVICE MENU->PROJECT ID, choose

corresponding Project ID number of the product (Please refer to the description in
BOM about Project ID number).

D return to Factory Menu, check the Product model.
E choose Factory Menu-> NVM RESET and press and wait until prompt OK

appears.
F restart the set
G according to the requirement of order, set the items of Shop Menu and Hotel

Menu etc.
H After aging under normal temperature, calibrate ADC and adjust white balance.

I choose Factory Menu-> SHOP INIT and press button of remote control to

initialize the set.
Note: after step I (execute SHOP INIT), Hotel Menu will be disabled by default.
Therefore, if order requires hotel function, it is necessary to enable hotel function by

Factory Main Menu-> Service Menu->HOTEL ENABLE to ON.

set

4.3 ADC Calibration

Ⅰ.signal and generator

VGA: Chroma2329 Pattern42, Timing 14(1024x768@60Hz 5 MOSAIC)
YPBPR: Chroma2329 Pattern103, Timing 79(100% Color Bar, 720p)

5 MOSAIC 100% Color Bar

PRELIMINARY INFORMATION ----- SUBJECT TO CHANGE

13

MS82S-AP/LA Chassis Software Upgrade Guidance

Ⅱ.steps of debug:

1) Access to the Factory menu->ADC

2) Select PC source

3) Select AUTO ADC，Press button in your remote control to calibrate the

ADC automatically.

4) Select YPBPR source

5) Repeat step 3.

6) When the OK appears the calibration has been finished successfully.

VGA calibration YPBPR calibration

4.4 White Balance adjustment (Manual)

Before adjustment, you must ensure Color Analyzer has been calibrated. Only AV1,
YPBPR, VGA , HDMI 1 need to be adjusted. It is necessary to adjustment HDMI 1
firstly.

a. signal and generator

The pattern of the signal should be used are White (Chroma2329 pattern113) and
Grey (pattern 114).The format of signal are respectively 720p for HDMI1
(Chroma2329 Timing 69), NTSC for AV1 (Chroma2329 Timing 37),1024×768@60Hz

(Chroma2329 Timing 14) for VGA and 720p (Chroma2329 Timing 79)for YPBPR

b. steps of adjustment

1) enter the factory menu->WHITE BALANCE, select source HDMI 1 and COLORTEMP
normal.

2) input grey signal in 720p format

3) change R OFFSET and B OFFSET to make sure the value of color coordination
equal to the value required by enterprise standard (x, y).

PRELIMINARY INFORMATION ----- SUBJECT TO CHANGE

14

MS82S-AP/LA Chassis Software Upgrade Guidance

4) input white signal in 720p format

5) change R Gain and B Gain to make sure the value of color coordination equal to

(x, y).

6) repeat step 2~5 until both of the value of color coordination of white and grey
equal to (x, y).
In addition to select COLORTEMP COOL/WARM, the adjustment method of COOL

and WARM color temperature is same with that of NORMAL. The color coordination
we recommend is as follows:

Device：CA-210； Accuracy：±0.015

Color Temperature

x

LCD

y
x

LED

y

WARM NORMAL COOL

0.300 0.280 0.270

0.305 0.290 0.270

0.302 0.282 0.272

0.317 0.302 0.282

HDMI White Balance adjustment

PRELIMINARY INFORMATION ----- SUBJECT TO CHANGE

15

MS82S-AP/LA Chassis Software Upgrade Guidance

4.5 ADC Calibration and White Balance Adjustment (automatic)

The process of adjusting ADC and White Balance automatically is out of the range
of this file. Please refer to the relevant technical file of HuiZhou factory of TCL

5. Chip list of software programming before SMT

Following chips must be programmed before SMT by ALL-11 or other tools.

Position Chip type Chip name Part number Software

description

1 U502 Flash

2 U503 E2PROM M24C64 13-M24C64-W6B HDCP KEY SO-8

Note:

1) The software for U502 and U503 can be program using ISP tool.

2) Every set has its unique HDCP key which is purchased from suppliers or HDCP

certification authority. Please check HDCP function in the process of production.

3) Once in a while, the software of main board may be upgraded. Please pay attention to

use the latest software before production.

EN25Q3 13-EN25Q3-2AB

main software SO-8

Decal

PRELIMINARY INFORMATION ----- SUBJECT TO CHANGE

16

MS82S-AP/LA Chassis Software Upgrade Guidance

Appendix:

1. Software upgrade through USB disk

1) Please ensure the software you are using has a correct file name
TCL_MS82_UPDATE.bin, then copy it to the root directory of a USB disk.

2) Insert the USB disk to the USB socket of the set for which you are
going to upgrade program.

3) Enter the Factory Menu (you can choose either a or b way below)
a. In the first place, press Menu button of remote
control, then select Contrast item of Picture
submenu. Finally, press 9, 7, 3, 5 consecutively.
b. When the Factory hotkey ite m of Factory Menu
is enabled (ON), press Return button of remote
control.

4) select USB UPDATE, press buttonof remote control, a pop menu
will appear prompting whether start upgradeor not. Press Yes to start upgrade,
press No to canel. Please wait patiently until the set restart automatically after

upgrade. Do not cut off the power supply during the process.

Upgrade Main Software

PRELIMINARY INFORMATION ----- SUBJECT TO CHANGE

17

MS82S-AP/LA Chassis Software Upgrade Guidance

2. Check software version, release date and Project ID

After upgrading, sometimes you may not certain whether the new software has
been successfully updated or not. In this case, you can check the software version
and release date in Factory Main Menu to make sure the success of upgrading.
In addition, for the convenience of software management, many models of same
chassis may share a same software, but are allocated with different Project ID.
In another words, every model has its unique Project ID. Obviously, Both software
version and Project ID are highly critical to ensure the set work properly. Therefore,
after upgrading software,we suggest you check these information by following
method.

1) Enter the Factory Main Menu(you can choose either a or b way below
a In the first place, press Menu button of remote control, then select Contrast item
of Picture submenu. Finally, press 1, 9 5, 0 consecutively.
b. When the DESIGN HOTKEY item of Factory Main Menu is enabled (ON), press

Return button of remote control.

2) Check the version of software, release date displayed at the bottom of Factory
Main Menu. If the information is correct, you can ignore step C and D.

3) choose SERVICE MENU->PROJECT ID, choose corresponding Project ID number of

the product (Please refer to the description in BOM about Project ID number).

4) choose Factory Menu and press OK button of the remote. Next, select NVM RESET

and press and wait until prompt OK appears.

5) choose SHOP INIT and press

button of remote control to initialize the set.
Note: after step I (execute SHOP INIT), Hotel Menu will be disabled by default.
Therefore, if order requires hotel function, it is necessary to enable hotel function by
set

Factory Main Menu-> Service Menu->HOTEL ENABLE to ON.

6) restart the set.

PRELIMINARY INFORMATION ----- SUBJECT TO CHANGE

18

MS82S-AP/LA Chassis Software Upgrade Guidance

Product
Information

Check product information

Remote Control name

Power Supply name

Audio Channel number

Change project ID

PRELIMINARY INFORMATION ----- SUBJECT TO CHANGE

19

MS82S-AP/LA Chassis Software Upgrade Guidance

3. FAQ

1) Why there is no picture after upgrading software or changing project ID?
It may be caused by fault of project ID. You can try below method to fix
the problem.
a. If the resolution of the panel of your set is 1366×768(HD panel), you can press

Menu, and 4976 of remote control in series after turning on.

b. If the resolution of the panel of your set is 1920×1080(FHD panel), you

can press Menu, and 4973 in series after turning on.
c. If you can see the picture at this time, please recheck the project ID again. If
the project ID is still wrong, correct it reference to above description.

PRELIMINARY INFORMATION ----- SUBJECT TO CHANGE

20

TU1

TUNER

AP：07-380FI5-NK4G

LA：TBD

TU1_IF­TU1_IF+

Tuner I2C BUS

Band Pass Filter

RF_AGC

TU1_IF- IN

TU1_IF+ IN

AMP L/R

Q601/Q602

Audio Amplifier

VIDEO OUTPUT

Q300/Q301

Video Amplifier

U602

Earphone AMP

13-DRV632-00B

U601

Audio Amplifier Power

13-TPA311-D2B

SPDIF OUTPUT

VIDEO OUTPUT V/ L/R

Earphone L/R

P603:47-EAR030-XX0

L Channel
R Channel

>32': 8W
<26': 5W

P305:47-RCA301-XB0G

P400:47-VGA021-XX0

P302:47-RCA303-XG0G

P301:47-RCA302-XR0G

P300:47-RCA303-XY0G

P401:47-HDI011-KS0

P402:47-HDI011-KS0

P403:47-HDI011-KS0

P303:47-USB002-XX0

PC/VGA/YPBPR/AV2 Audio INPUT

HDMI 1 INPUT

HDMI 2 INPUT

HDMI 3 INPUT

PC/VGA INPUT：R/G/B/HS/VS

YPBPR/AV2(Video) INPUT

AV1 INPUT

U400

HDMI SW

13-T6633E-00B

USB INPUT

TMDS/DDC/DET

U500

Main－chipset

AUDIO OUTPUT

LVDS Odd Signal

LVDS Even Signal

SPI BUS

I2C BUS

Q302/Q303

Audio Amplifier

U501

DDR2 SDRAM

13-K4T511-F7B

U502

FLASH MEMORY

13-EN25Q3-2AB

U503

EEPROM

13-M24C64-W6B

LCD Panel

BL_ON

DIM

P304:47-EAR032-XX0

12V or 5V

24V

3V3STB

Power

AC

Supply

DC 12V

Unit

DC 24V

Note:
Some PSU output DC 24V&3V3STB, some output
DC 12V&3V3STB.

PW_ON/OFF

EARPHONE_MUTE

DC 24V

DIM

AMP-MUTE

PANEL_ON/OFF

Power Supply Block Diagram

U100

DC/DC

13-RT8110-B0B

24/12V-SW

Q104

PW_ON/OFF

BL_ON

LED_OUT

HDMI_DET

Q100

MOSFET

12-04822A-0BX

U601

Audio Amplifier Power

13-TPA311-D2B

IR_IN

LIGHTSENSOR

HWRESET

DC 12V

12V

or 5V

KEY IN

RXD/TXD

3V3STB/1V28/1V8/2V5/3V3

12V 5V

U101

DC/DC

13-MP1482-DSB

Panel_Vcc -SW

Q106

PANEL_ON

Panel_Vcc

U105

LDO

13-AS1117-33B

U103

LDO

13-AS1117-25B

U106

LDO

13-AS1117-18B

U104

DC/DC

13-MP2127-DQB

Low Pass Filter

+3V3(225mA)

+2V5(210mA)

+1V8(200mA)

VDDC-1V28(680mA)

TUNER_5V(80mA)

MS82S (AP&LA) Chassis Block Diagram

First Issued V0.1
ZCX 2011-09-07

7

D D

6

MODEL:

5 4 3 2 1

01-MS82S0-MAC2XG

DESCRIPITION:

C C

DRAWN:

B B

CHECK:

APPR:

A

THIS DRAWING CANNOT BE COMMUNICATED TO UNAUTHORIZED PERSONS COPIEDUNLESS PERMITTED IN WRITING

7

6

5 4 3 2 1

DATE:

DATE:

DATE:

TCL

WW R&D CENTER TCL MULTIMEDIA TECHNOLOGY HOLDING LTD.
5TH FLOOR.TCL BUILDING.SOUTH NANHAI ROAD
NANSHAN DISTRICT.SHENZHEN.GUANGDONG 518067 CHINA
TEL:[phone]

NOTE:

...........

PAGE: OF

FORMAT DIN A4

A

12 11 10 9 8 7 6 5 4 3 2 1

H

24/12V_IN

BL_ON/OFF

C124

3_3V/5VSB

T

C101

0.1U

DIM

GND7

T

DGND

10P

R152

0R

DIM

DIM_PWM

3.3V/5VSB
DGND

DGND

24V/12V

T

DGND

P100

11

9
7
5
3
1 2

G

DGND

T

P_ON/OFF

T

12
10

8

DGND

6
4

BL_ON

POWER_ON

DIM_DC

24V/12V

24V/12V

C100

DGND

DGND

T

0.1U

DIM_DC

T

L108

33R

L109

33R

24/12V_IN

35-392170-00X

L112

33R
L114

33R

12V

12V

V_AUDIO

L107

R102

NC/0R

R103

NC/0R

1%

1%

12V

24/12V_IN

0.1U

C105

DGND

C106

0.1U

RT8110B

BOOTFBUGATE

5

VIN

7
8

LL4148

D102

GNDPHASE

LGATE

VCC

U100

A04822A

G2

4
36
2
1

DGND

C107

2U2

4

S2

3

G1
S1

2
1

Q100

D2B
D2A
D1B

D1A

5

6
7
8

R101
10R

C122

C104

R104
10R

1000P

0.1U
NC/

24V

T

C102

DGND

220U

35V

C110 0.1U

T

10U

C109

DGND

12V

C108

220U

16V

1U

C103

L104

10UH

VOUT=0.8X(1200+820+27)/(820+27)=12.13V

VOUT=12.13V

R106

12K

R107R108

820R

150P

C126

12V

12V

C114

DGND

0.1U

0.047U

C115

2K2

R109

DGND

C116

0.1U

H

12V

R110

100K

U101

8

SS

7

EN

5

FB

MP1484

VOUT=0.923X(51+11)/11=5.2V

BS

SWCOMP

GND

1
2

IN

36
4

DGND

0.1UC113

L100

15UH

0.1UC112

R111

R112

DGND

DGND

51K

11K

10U

C111

C117 0.1U

C120
16V

NC/

DGND

220U

10U

C118

5V

C119

16V

470U

5V

5V

T

G

C131

GND/ADJ

1

R192
10R

DGND

Need PCB Heatsink

T

2V5

2U2

0.1U
C132

Need PCB Heatsink

T

R193

NC

C168

0.1U

+1V8

C170

210mA

C133

16V

100U

+2V5

6M48:469mA

6M182:200mA??

C171

16V

10U

100U

+1V8

DGND

27R

5V

5V

C165

DGND

10U

C135

0.1U

3.3V/5VSB

3.3V/5VSB

4

5

PGOOD

6

MP2127

PVIN

VIN

3

IN OUT

0.1U

C123

NC/

SW

GND

FB

U104

R121

0R

U102

RT9166-33

GND

1

NC

F

VDDC-1V28

1_28V

10U

T

VOUT=1.285V

C140
6V3

470U

VDDC-1V28

680mA

L106

33K

R126

R127

3K3

4.7UH

DGND

22K

R128

0.1U

C141

DGND

VOUT=0.8X(22+33+3.3)/(33+3.3)=1.285V

C142

3

2

1

E

DGND

+3_3VSTB

+3_3VSTB2

2U2

NC/

C127

16V

100U

T

D

2

C125

0.1U

100mA

C177

24V/12V

Q104

1

S1

2

22K

R138

C148

DGND

B

0.1U

NC/

NC/

R168

C

E

R140

DGND

4K7
NC/

Q103

C124ET

1K
NC/

/NC

F

POWER_ON_OUT

(5)

R118

1K

B

+3V3

+3V3

C

E

DGND

Q101

BT3904

R113

10K

+3V3

+3V3

R114

4K7

10K R115

NC

E

BL_ON_OUT

R190
NC/10K

3.3V/5VSB

R136

R130

100R

10K

NC/

R137

NC/

BL_ON

C143

4K7

0.01U

R169

3K3

NC/

S2

3

S3

4

G

NC/

C149

NC/

D

R178

(5)

DIM_OUT

R179

10K

1K

R173

1K

DIM

2U2

C159

DIM_DC

PMK50XP

0.1U

8

D1

7

D2

6

D3

5

D4

1

C145

4

GND/ADJ

2

2U2

NC/

4

OUT

3

U105

AS1117-3.3

VIN

0.1U

C146

+3V3

T

C147

2U2

+3V3

+3V3

225mA

C172

16V

100U

Need PCB Heatsink

5V

5V

0.1U

C144

DGND

DGND

AS1117-2.5

5V3

T

5V

R191&R194 PCB overlap

5V

R191

NC/2W

3R3

R194

2R7

U103

C130

U106

AS1117-1.8

5V-DDR

T

VIN

3

0.1U

DGND

2U2

C167

NC/

4

4

OUT

2

VIN

3

C166

0.1U

GND/ADJ

1

10R

R123

4

4

OUT

2

SENSOR

T

R149

NC/

IR

100P

4K7

5V

C154

R151

NC/

R155

0R

0.1U

10R

0.1U

C150

NC/

DGND

5V2

T

LOGO

T

LED

T

T

GND2

F100

C151

DGND

0.1U
NC/

T

C153

LIGHTSENSOR_OUT

LOGO_OUT

+3_3VSTB

(5)

LED

IR

C155

DGND

R154
4K7

0.1U
NC/

+3_3VSTB

R153
4K7

R162

100R

R163

100R

DGND

IR_IN

LED_OUT

(5)

(5)

P102

4
3
2
1

GND3

T

5VOUT

DGND

F101

DGND

+3_3VSTB1

T

5V4

T

KEY_IN

DGND

DGND

+3_3VSTB

R167

NC/

R166

NC/

C157

DGND

10R

4K7

1000P

LOGO_OUT

KEY_IN

5V

(5)

R164

T

KEY

0.1U

C156

NC/

100K

+3_3VSTB

DGND

0.1U
NC/

R165

4K7

C152

C

R186

0.1U

B

DGND

22K

4K7

R189

C

E

R185

Q106

PMV65XP

Q107

BT3904

1K8

PANEL_VCC

PANEL_VCC

T

D

S

G

C163

0.1U

PANEL_VCC

P101

7
6
5
4
3
2

+3_3V-STB

1

+3_3VSTB3

DGND

IR

T

L_SENSOR

LOGO

5V

LED

DGND

DGND

5V

12V

C

P103

PANEL_ON

(5)

B

5V

3K3

R180

R188

NC/0R

R187
0R

1%

1%

C161

3
2
1

R183

4K7

1K

DGND

R120

100R

POWER_ON_OUT

(5)

DGND

+3_3VSTB

R116

A

THIS DRAWING CANNOT BE COMMUNICATED TO UNAUTHORIZED PERSONS COPIED UNLES S PERMITTED IN WRITING

POWER_ON

C164

DGND

0.1U

...

...

...
...

Index-Lab

Last saved :

DD-MM
DD-MM

DD-MM
DD-MM

...
...

...

...

...

...

SBU :
TCLNO:

TCL

ADDRESS1

...

...

...

.............

ADDRESS2

A

ADDRESS3

...

...

NAME Last modifDESCRIPTIONDATE

8-11-2011_18:06

...

DESIGNATION

...........

ON:
BY:

33312841

DRAWN

CHECKED

DD-MM-YY

ON:
BY:

......

PAGE:
OF :

123456789101112

8 7 6 5 4 3 2 1

DGND

C216

0R

C213

33R

NC

F

E

TU1

NC1

1

+30V

T

NC2

2

AGC

T

TU1_VCC

NC3

RF-AGC

3

4

TU1_BT

TU1_RFAGC

T

B+

SDA

596

TU1_SDA

TUNER_5V

SCL

NC4

7

8

T

TU1_SCL

SDA1

T

NC5

SCL1

IF+

IF-

10

11

TU1_IF-

T

TU1_IF-

T

TU1_IF+

TU1_IF+

C204

56P

NC/

56P

C205

NC/

TU1_IF-

TU1_IF+

C203

0.1U

C206

0.1U

L201

L203

0R

0R

NC

L202

NC

C207

C210

L206

NC

0R

L204
NC

C220=220PF,BPF FOR 38.9MHz OR 38MHz,PAL

C220=120PF,BPF FOR 45.75MHz,NTSC

L208

C221

33R

L207

NC

NC

0.1UH

L209

C217C220

220P

NC

C224

DGND

C218

C219

51R

51R

D

C222

C223

0.1U

0.1U

L211

L210

0R

0R

TU1_IF-_IN

F

TU1_IF+_IN

E

D

DGND

Near Tuner

Near Tuner

R201
100R

TU1_RFAGC

C

0.1U

C201

DGND

B

RFAGC

TUNER_5V

TUNER_5V

0.1U

C202

DGND

C208

10U

C233

6V3

470U

L212

NC/100UH

R203

2R2

R202

2R2

5V

TU1_SCL

TU1_SDA

TUNER_5V

R213

4K7

22P

C214

R214

4K7

22P

C215

DGND

R215

100R

R216

100R

C

TUNER_SCL

TUNER_SDA

B

A

THIS DRAWING CANNOT BE COMMUNICATED TO UNAUTHORIZED PERSONS COPIED UNLES S PERMITTED IN WRITING

...

...

...
...

DD-MM
DD-MM
DD-MM
DD-MM

DATE DESCRIPTION Last modifNAMEIndex-Lab

Last saved :

...
...
...
...

...
...

...

...

4-14-2009_15:30

45678

...

...
...
...

TCL MULTIMEDIA TECHNOLOGY HOLDINGS LTD

SBU :
TCLNO:

.............

DESIGNATION

01-MS8200-MAA2XG

ADDRESS1

ADDRESS2

ADDRESS3

TELEPHONE

DRAWN

ON:
BY:

TCL

CHECKED

DD-MM-YY

ON:
BY:

......

A

PAGE:

OF :

123

FORMAT DIN A3

8 7 6 5 4 3 2 1

YELLOW

F

WHITE

E

D

AVOUT1_V

C

AV IN 1

P300

RED

R340

75R

6

5

4

3

2

1

BT3906

Q300

GND6

T

F300

AV1_V

T

AV1_V

F301

E

C

AV1_L

T

AV1_L

T

AV1_R

F302

B

BT3904
R341

180R

AV1_R

R342

Q301

75R

R306

3K3

R343

150R

DGND

E

C

R301

10K

R302

10K

DGND

B

close to IC

R300

33R

12K

R307

33K

R345

68K

C325

12K

C300 470P

R344

0.047U

C326

C327

R308

0.1U

C315

DGND

2U2

2U2

C301

470P

R351
10R

AV1_V_IN

AV1_L_IN

AV1_R_IN

5V

C317

100U

16V

R359

NC/

15K

(5)

(5)

(5)

YPBPR_IN

RED

WHITE

P301

RED

BLUE

GREEN

CVBS_OUT

(5)

P302

1

2

3

4

1

2

3

4

5

6

GND9

T

DGND

HD_R

F303

HD_L

F304

HD_PR

F305

HD_PB

F306

HD_Y

F307

HD_R

T

HD_R

DGND

DGND

75R

R324

75R

R328

75R

R333

close to IC

T

HD_L

R303

10K

R304

10K

HD_YHD_L

T T

HD_Y

HD_PB

R318

12K

C302 470P

R322

12K

C303 470P

R305

33R

R309
33R

R310

33R

33R

R311

33R

R312

12V

HD_PRHD_PB

T

HD_PR

C328

C330

C331

C332

C333
C322

R346

470R

AVOUT1_L

2U2

C329

2U2

close to IC

0.047U

0.047U

0.047U

1000P

0.047U

DGND

HD1_R_IN

HD1_L_IN

HD1_PR_IN

HD1_PB_IN

HD1_Y_IN+

HD1_SOG_IN

AV2_V_IN

C319

16V

100U

Q302

BT3904

E

USB1_5V1

5V

T

P303

1

VCC-1

2

DNEG-1

3

DPOS-1

4

GND-1

5
6

MNT-HOLE1

MNT-HOLE2

F

(5)

(5)

(5)

USB1_D-_IN

(5)

USB1_D+_IN

(5)

USB

22P

C308

5V

DGND

22P

R338
2R2

2R2

R339

C309

USB1_DP

USB1_D­USB1_D+

GND5

DGND

USB1_DM

T

T

T

E

(5)

(5)

(5)

(5)

1K

R347

22K

R348

B

R352

7K5

6K8

R361

C

10K

R362

C306

16V

220U

DGND

AVOUT1_L_OUT

(5)

0.1U

C307

AVOUT1_R

Q303

BT3904

1K

R355

C

E

B

R357

7K5

6K8

R360

USB1_D-

F308

DGND

22K

USB1_D+

F309

R356

10K

R363

D

AVOUT1_R_OUT

(5)

C

(5)

SPDIF_OUT

C344

0.1U

F312

F313

AV_OUT1

T

AVOUT1_V

AV_L_OUT

T

AV_R_OUT

T

AVOUT1_L

AVOUT1_R

B

T

GND9

CVBS

GND

1

R

2
3

L

4
5

P304

220R

close to IC

SPDIF

R364

33P

C345

DGND

A

F314

DGND

THIS DRAWING CANNOT BE COMMUNICATED TO UNAUTHORIZED PERSONS COPIED UNLES S PERMITTED IN WRITING

R365

120R

GND10

T

SPDIF

F315

T

SPDIF

...

...

...
...

Last saved :

P305 and P307 compatible placement

DD-MM
DD-MM
DD-MM
DD-MM

DATE DESCRIPTION Last modifNAMEIndex-Lab

1

2

...
...
...
...

BLACK

P305

...
...

...

...

7-18-2011_20:33

45678

DGND

...

...
...
...

SBU :
TCLNO:

.............

DESIGNATION

...........

DGND

ADDRESS1

ADDRESS2

ADDRESS3

TELEPHONE

DRAWN

ON:
BY:

TCL

CHECKED

DD-MM-YY

ON:
BY:

......

PAGE:

OF :

B

A

10

3

123

FORMAT DIN A3

8 7 6 5 4 3 2 1

H1_5VH1_5V

H1_5V

T

C404

ARC

0.047U

CEC

H1_RXC-_IN

H1_RXC+_IN

H1_RX0-_IN

H1_RX0+_IN

H1_RX1-_IN

H1_RX1+_IN

H1_RX2-_IN

H1_RX2+_IN

H2_5V

T

R417

H2_5VH2_5V

10K

H1_SDA
H1_SCL

33R

R419

10K

R418

H1_SDA

H1_SCL

H1_ARC_OUT

H2_HPD

NC/BT3904

R428

C

E

DGND

H1_5V

H2_5VH2_5V

NC/1K

B

Q401

R456

4K7

H2_5V

R429

NC/4K7

R457

DGND

H1_5V

R427

H1_DET

10K

R442

H2_5VH2_5V

NC/10K

HDMI_HPD

10K

R440

H2_5V

H2_SDA
H2_SCL

R443

DGND

10K

R458

4K7

H2_RXC-_IN

H2_RXC+_IN

H2_RX0-_IN

H2_RX0+_IN

22K

H2_RX1-_IN

H2_RX1+_IN

HDMI_3V3

H2_RX2-_IN

H2_RX2+_IN

R441

22K

DGND

17

H2_DET

10K

R459

DGND

H2_HPD

R421
R422 22R

R444

R472

H1_HPD

H:reset i2c register

HDMI_3V3

HDMI_3V3

GND400

T

VGA_TX

19
18
17
16
15

H1_ARC

14
13
12
11
10

9
8
7
6
5
4
3
2
1

GND401

T T

H1_HPD

H1_HPD

HPD

VCC

GND5

F

DDCDA

DDCCLK

NC2

NC1

RXC-

GND4

RXC+

RX0-

E

GND3

RX0+

RX1-

GND2

RX1+

RX2-

GND1

RX2+

P401

D

H2_HPD

DGND

GND402

T T

6

HPD

VCC

C

GND5

DDCDA

DDCCLK

NC2

NC1

RXC-

GND4

RXC+

B

RX0-

GND3

RX0+

RX1-

GND2

RX1+

RX2-

GND1

RX2+

A

P402

19
18
17
16
15
14
13
12
11
10

9
8
7
6
5
4
3
2
1

H2_HPD

H2_SDA
H2_SCL

H1_ARC

H2_RXC-_IN

H2_RXC+_IN

H2_RX0-_IN

H2_RX0+_IN

H2_RX1-_IN

H2_RX1+_IN

H2_RX2-_IN

H2_RX2+_IN

R431 10K

CEC

1

3 6

1
2 7

4 5

10K

R432

R425 NC/33R

HDMI_DDC_SDA

HDMI_DDC_SCL

R426 NC/33R

R423

NC/10R

R424

8

63

NC/10R

8

RXC­RXC+

72

RX0+

54

RX1­RX1+
RX2­RX2+

RX0-

P400

11

1
7

12

2
8

13

3
9

14

4
10
15

5
16

VGA_SCL

T

VGA_SCL

VGA_BLU

DGND

DGND

THIS DRAWING CANNOT BE COMMUNICATED TO UNAUTHORIZED PERSONS COPIED UNLES S PERMITTED IN WRITING

0R

DGND

0

T

VGA_R

T

VGA_SDA

T

VGA_SDA

VGA_GRN

VGA_HS

75R

R400

U400

1
2

22R

3
4
5
6
7
8

9
10
11
12
13
14
15
16

C405

1U

R412

22K

VGA_TXD

VGA_HS

75R

R401

R402

H3_5V

R445

10K

DGND

C4182U2

H3_RX2-_IN

H3_RX2+_IN

63

62

64

61

A34

B34

CEXT

HPD2
SDA2
SCL2
B21
A21
POW2
B22
A22
GND1
B23
A23
VCC1
B24
A24
POW1

I2C_RST

HPD1

PS331

17

SDA1

SCL1

18

R413

22R

B11

19

R414

22R

DGND

H1_SCL

H1_SDA

VGA_RED

VGA_G

T

VGA_B

T

T

T

VGA_VS

VGA_VS

VGA_RXD

10K

75R

R403

10K

DGND

DATE DESCRIPTION Last modifNAMEIndex-Lab

Last saved :

H3_RX1-_IN

HDMI_3V3

H3_RX0+_IN

H3_RX1+_IN

DGND

57

60

59

58

A32

A33

B33

VCC4

GND4

13-PS3310-00B

VCC2

B12

A12

A11

21

24

20

23

22

HDMI_3V3

H1_RX0-_IN

H1_RXC-_IN

H1_RX0+_IN

H1_RXC+_IN

DGND

R433
33R

R434
R410

R409

R435

R405

T

VGA_RX

R404

R446 22K

R447

0R

H3_RX0-_IN

H3_RXC-_IN

H3_RXC+_IN

54

53

56

55

52

A31

B31

B32

POW3

GND2

NC1

B13

B14

A13

27

26

25

28

H1_RX1-_IN

H1_RX1+_IN

C400 0.047U

C401 0.047U

33R

C402 1000P

33R

68R

C403 0.047U

33R

68R

VGA_SDA
VGA_SCL

VGA_TXD

VGA_RXD

DGND

H3_SCL

H3_SDA

R438

R439

22R

51

SCL3

A14

30

29

HDMI_PWR

H3_HPD

22R

50

SDA3

HPD3

SDA_SINK

POW_SINK

SCL_SINK

HPD_SINK

I2C_ADDR

SCL_CTL
SDA_CTL

POWDN

REXT

324931

GND3

VCC3

Z1
Y1

Z2
Y2

Z3
Y3

Z4
Y4

R407
100K

48
47
46
45
44
43
42
41
40
39
38
37
36
35
34
33

DGND

47K

R448

SCL
SDA

H:power down

R411
510R

H1_RX2-_IN

H1_RX2+_IN

DGND

DGND

R416
27K

Place these capacitor close to IC

VGA_RED_INVGA_RED_IN

VGA_GRN_INVGA_GRN_IN
VGA_SOG_INVGA_SOG_IN

VGA_HS_INVGA_HS_IN
VGA_BLU_INVGA_BLU_IN

VGA_VS_INVGA_VS_IN

45678

5V

47K

I2C Address:0x94/96

EDID I2C Address:0x96/97

R449

R450

R451

HDMI_3V3

22R
22R

RXC-

RXC+

RX0-

RX0+

RX1-

DGND

RX1+

RX2-

RX2+

HDMI_DDC_SDA
HDMI_DDC_SCL

DGND

R452

UART_TX

100R
R453
100R

R454
100R

R455
100R

UART_RX

UART_TX

UART_RX

SBU :
TCLNO:

R460

H3_5V

4K7

HDMI_HPD

100K

DGND

VGA_TXD

VGA_RED

DGND

40-MS8200-MAA2XG

DESIGNATION

DESIGNATION

R461

DGND

R406

VGA_SDA

+3V3

H3_DET

10K

DDCCLK

VGA_HS

VGA_GRN

L401
220R

HPD

VCC

GND5

DDCDA

NC1

RXC-

GND4

RXC+

RX0-

GND3

RX0+

GND2

RX1+

RX2-

GND1

RX2+

P403

VGA_VS

VGA_BLU

VGA_RXD

F421F420F419F418

ON:
BY:

DGND

NC2

RX1-

VGA_SCL

F423F422F426F425F424

DRAWN

C4112U2

C412

0.1U

H3_HPD

19

C413

0.1U

C416

0.1U

GND403

T T

H3_HPD

C417

0.1U

H3_5V

T

18
17
16
15
14
13
12
11
10

9
8
7

CEC

H3_RXC-_IN

H3_RXC+_IN

H3_RX0-_IN

H3_RX0+_IN

H3_RX1-_IN

6
5
4
3
2
1

H3_RX1+_IN

H3_RX2-_IN

H3_RX2+_IN

DGND

H1_HPD

H3_HPD

H2_HPD

H1_SCL

H1_SDA

H2_SDA

DGND

F404F402F400 F406 F410

F401

F403 F405 F409

TCL Thomson Electronics Singapore Pte. Ltd.

8 Jurong Town Hall Road #28-01/06
The JTC Summit SINGAPORE 609434
Tel [phone] Fax [phone]

CHECKED

ON:
BY:

HDMI_3V3

H3_5VH3_5V

10K

R436

H3_SCL

H2_SCL

H3_SDA

F407

PAGE:

OF :

H2_5V

F408

123

10K

R437

H1_5V

4

10

H3_SDAH3_SDA
H3_SCLH3_SCL

H3_5V

F411

F

E

D

C

H1_ARC

B

F412

A

FORMAT DIN A3

12 11 10 9 8 7 6 5 4 3 2 1

T

0.1U

C504

+3_3VSTB

220R

L509

DGND

22P

C505

SPI_SCK

T

SPI_SDI

T

H

SPI_FLASH_SCK
SPI_FLASH_SDI

+3_3VSTB

R500

H

+3_3VSTB

0R

1M

R501

1U

C500

1

3

D500

0BAV99

R502

4K7

+3_3VSTB

NC

VCC_SPI

8
7
6
5

DI

4K7

2

MCU_RESET

T

E

BT3906

B

Q500

C

10U

C501

DGND

R503

1K

HWRESET

SPI_FLASH_SDI
SPI_FLASH_SDO

SPI_FLASH_CZ1

6 3

8

22R

RP500

SPI_FLASH_SCK

45

27
1

PM_SPI_SCK

PM_SPI_SDI
PM_SPI_SDO
PM_SPI_CZ1

SPI_WP0N

R504

1K

0.1U

C503

R505

SPI_SDO

T T

10K

SPI_FLASH_CZ1

NC/

T

10K

R506

WP

SPI_FLASH_SDO

SPI_CZ1

T

R507

EN25Q32A

1
2
3
4

GND_SPI

U502

CS
DO
WP
VSS

VCC

CLK

DGND

1000P

R552

100K

C502

DGND

DGND

DGND

DGND

G

G

+3_3VSTB

UART_TX UART_RX

P501

4

F

3
2
1

E

R531

68R

R532

68R

C515

DGND

DGND

0.1U

C573

0.047U

C510

0.047U

120R

L510

DGND

D

C

B

DGND

10U

C574

C506

33P

C507

(4)
(4)
(4)

(4)

(3)

X24M

33P

TT

R519
4K7

HWRESET

HDMI_HPD

RXC-

RXC+

RX0-

RX0+

AVDD_ADC

RX1-

RX1+

HDMI_DDC_SDA

RX2-

RX2+

HDMI_DDC_SCL

H1_ARC_OUT

VGA_BLU_IN

VGA_SOG_IN

VGA_GRN_IN

VGA_RED_IN

(3)

HD1_PB_IN

HD1_SOG_IN

HD1_Y_IN+

(3)

HD1_PR_IN

(3)

(3)

AV1_V_IN

(3)

AV2_V_IN

(3)

CVBS_OUT

(3)

HD1_L_IN

(3)

HD1_R_IN

AUVRM
AUVRP
AUVAG

10U

0.1U

C578

C575

CLOSE TO IC

24M

GND501

DGND

XTALO

R541

1M

XTALI

GIN0M

R518
4K7

UART_TX

UART_RX

T

VDDC-1V28

VGA_HS_IN

VGA_BLU_IN

VGA_SOG_IN
VGA_GRN_IN

VGA_RED_IN

VGA_VS_IN

VDDC-1V28

AVDD_25

HD1_PB_IN

HD1_SOG_IN

HD1_Y_IN+

GIN2M

HD1_PR_IN

AVDD_ADC

AV1_V_IN

AV2_V_IN

VCOM0

CVBS_OUT

HD1_L_IN

HD1_R_IN

AVDD_AU25

MST6M182VS

+3V3

1
2
3
4
5
6
7
8

9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54

DGND

HWRESET
HOTPLUGA
RXACKN
RXACKP
RXA0N
RXA0P
AVDD_33A
RXA1N
RXA1P
DDCDA_DA
RXA2N
RXA2P
DDCDA_CK
ARC
NC1
NC2
NC3
NC4
NC5
NC6
NC7
NC8
NC9
VDDC
HSYNC0
BIN0P
SOGIN0
GIN0P
GIN0M
RIN0P
VSYNC0
AVDD_126
AVDD_25
BIN1P
SOGIN1
GIN1P
GIN1M
RIN1P
AVDD_33B
CVBS4
CVBS3
CVBS2
CVBS1
CVBS0
VCOM
CVBSOUT0
AUL0
AUR0
AUL1
AUR1
GND1
AUVRP
AUVAG
AVDD_AU25

(6)

AMP_MUTE

(1)

DGND

UART_TX

(1)

UART_RX

(1)

C508

(1)

(1)

IR_IN

LED_OUT

SPI_WP0N

POWER_ON_OUT

R521

100R

LIGHTSENSOR_OUT

KEY_IN

R522

100R

PM_SPI_CZ1

HP_DET

PM_SPI_SDO

PM_SPI_SDI

PM_SPI_SCK

DGND

2U2

SCL

SDA

VDD33

AVDD_ADC

DVDD_NODIE_1.2V

USB1_D-_IN

USB1_D+_IN

A_MADR13

A_MADR11

A_MADR8

A_MADR6

VDDC-1V28

+1V8

A_MADR4

A_MADR2

A_MADR0

A_MCLKZ

A_MCASZ

A_MRASZ

A_MODT

+1V8

A_MCLK

A_MDATA5

+1V8

A_MDATA2

EARPHONE_MUTE

217

SDI

IRIN

CEC

E-PAD

HDMIB

HDMIA

GPIO6

GPIO7

GPIO8

GPIO9

DDCA_CK

DDCA_DA

PM UART SARx3 SPI I2CMUSB0 DDR2

SAR2

GPIO10

SAR0

SAR1

SCZ

SDO

SCK

GND3

BYPASS

USB0_DP

USB0_DM

AVDD_ALIVE

195

GND2

VDDP3

DDCR_DA

DDCR_CK

VDDC4

MADR[13]

MADR[6]

MADR[8]

MADR[11]

MADR[2]

MADR[4]

AVDD_DDR8

RASZ

CASZ

MADR[0]

ODT

MCLKZ

AVDD_DDR7

MCLK

MDATA[5]

AVDD_DDR6

Data & Addr

174

175

176

177

178

179

180

181

182

183

184

185

186

187

188

189

190

191

192

193

194

196

197

198

199

200

201

202

203

204

205

206

207

208

209

210

211

212

213

214

215

216

U500

RGBx2

CVBSx5

Audio-Inx5

Audio-Outx3 VIF & SIF I2S Out & GPIO

AUL2

AUR2

AUL3

AUR3

AUL4

AUR4

AVDD_AU33

AUOUTL1

AUOUTR1

AUOUTL0

AUOUTR0

NC10

NC11

NC12

XIN

XOUT

AVDD_DMPLL

AVDD_REF

PGA_COM

VIFM

VIFP

AVDD_PGA

SIFP

SIFM

TAGC

I2S_OUT_WS

I2S_OUT_SD

GPIO24

GPIO25

SPDIFI

SPDIFO

VDDC1

VDDP1

GPIO28

555657585960616263646566676869707172737475767778798081828384858687888990919293949596979899

VDD33

L_OUT

AV1_L_IN

MIC_L_IN

AV1_R_IN

MIC_R_IN

AV1_L_IN

(3)

AVOUT1_L_OUT

AV1_R_IN

(3)

R_OUT

AVOUT1_R_OUT

AVOUT1_L_OUT

AVOUT1_R_OUT

(3)

(3)

XTALO

XTALI

AVDD_REF_2V5

AVDD_DMPLL

ADC2P5

AVSS_PGA

TU1_IF-_IN

TU1_IF+_IN

(2)

(2)

TUNER_SDA

TUNER_SCL

RFAGC_OUT

EEPROM-WP

I2S_MCK

VDD33

VDDC-PIN86

SPDIF_OUT

PANEL_ON

(1)

USB2

I2S_OUT_MCK

I2S_OUT_BCK

GPIO36

GPIO37

GPIO38

H3_DET

I2S_BCK

HDMI_PWR

USB1_DM

USB1_DP

PWM2

DIM_OUT

NC13

TXE4+_OUT

A_MDATA13

A_MDATA7

A_MDATA0

170

171

172

173

MVREF

MDATA[7]

MDATA[0]

MDATA[2]

LVDSx2

10Bit

LVA4P

LVA4M

LVA3P

LVA3M

100

101

102

TXE3-_OUT

TXE4-_OUT

TXE3+_OUT

TXEC+_OUT

+1V8

A_MDATA10

A_MDATA8

A_MDATA15

A_MDQSUZ

166

167

168

169

MDATA[8]

MDATA[15]

MDATA[10]

MDATA[13]

AVDD_DDR5

LVACKP

LVACKM

LVA2P

LVA2M

LVA1P

103

104

105

106

TXE2-_OUT

TXE1+_OUT

TXEC-_OUT

TXE2+_OUT

VDD33

A_MDQSU

163

164

165

DQSU

DQSUZ

AVDD_MEMPLL

DVDD_DDR

AVDD_DDR4

AVDD_DDR3

AVDD_DDR2

AVDD_DDR1

I2S_OUT_MUTE

I2S_IN_BCK

AVDD_LPLL

AVDD_MOD2

LVA1M

AVDD_MOD1

107

108

ADC2P5

TXE1-_OUT

DQSLZ

DQSL

DQML

DQMU

MDATA[14]

MDATA[9]

MDATA[12]
MDATA[11]

MDATA[6]
MDATA[1]
MDATA[3]

MDATA[4]

WEZ

MCLKE
BADR[1]
BADR[0]

BADR[2]

MADR[1]

MADR[10]

MADR[3]
MADR[5]
MADR[7]
MADR[9]

MADR[12]

VDDC3

PWM1
PWM0

VDDP2

I2S_IN_SD

I2S_IN_WS

VDDC2

LVB0M

LVB0P

LVB1M

LVB1P

LVB2M

LVB2P

LVBCKM

LVBCKP

LVB3M

LVB3P

LVB4M

LVB4P

LVA0M

LVA0P

162
161
160
159
158
157
156
155
154
153
152
151
150
149
148
147
146
145
144
143
142
141
140
139
138
137
136
135
134
133
132
131
130
129
128
127
126
125
124
123
122
121
120
119
118
117
116
115
114
113
112
111
110
109

RFAGC

C516

0.022U

DGND

H1_DET
H2_DET

DVDD_DDR_1.2V

A_MDQSLZ

A_MDQSL

+1V8

A_MDQML
A_MDQMU
A_MDATA14

A_MDATA9

A_MDATA12

+1V8

A_MDATA11
A_MDATA6
A_MDATA1
A_MDATA3

+1V8

A_MDATA4

A_MWEZ

A_MCKE

A_MBADR1
A_MBADR0

+1V8

A_MBADR2
A_MADR1
A_MADR10
A_MADR3
A_MADR5
A_MADR7
A_MADR9

A_MADR12

VDDC-1V28

CFG-PWM1
CFG-PWM0

VDD33

BL_ON_OUT
LOGO_OUT

VDD33

ADC2P5

VDDC-1V28

TXO0-_OUT

TXO0+_OUT

TXO1-_OUT

TXO1+_OUT

TXO2-_OUT
TXO2+_OUT
TXOC-_OUT
TXOC+_OUT

TXO3-_OUT
TXO3+_OUT
TXO4-_OUT
TXO4+_OUT

TXE0-_OUT
TXE0+_OUT

TUNER_5V

R554
10K

Near IC PIN

Chip Config

(1)

(1)

R537

10K

RFAGC_OUT

0.01U

C511

DGND

100R

100R

R523

R524

1%

1%

DGND

A_MODT

A_MCLK
A_MCLKZ

A_MCKE

A_MRASZ
A_MCASZ

A_MWEZ

A_MBADR2
A_MBADR1
A_MBADR0

A_MADR13
A_MADR12
A_MADR11
A_MADR10
A_MADR9
A_MADR8
A_MADR7
A_MADR6
A_MADR5

A_MADR4

A_MADR3
A_MADR2
A_MADR1
A_MADR0

DGND

R7
R3
R8

M2

N7
N3
N8
N2
M7
M3
M8

D2
D8

H2
H8

N1

K9

J8
K8
K2
L8
K7
L7

L1
L3
L2

R2
P7

P3
P8
P2

B2
B8

E7
F2
F8

E3

J3
P9

J7

A2

U501

ODT
CKP
CKN
CKE
CSN
RASN
CASN

NC1
BA1
BA0
NC2
NC3
NC4
A12
A11
A10
A9
A8
A7
A6
A5
A4
A3
A2
A1
A0

VSSQ1
VSSQ2
VSSQ3
VSSQ4
VSSQ5
VSSQ6
VSSQ7
VSSQ8
VSSQ9

VSS1
VSS2
VSS3
VSS4

VSSDL

NC5

K4T51163QI

DQ15
DQ14
DQ13
DQ12

UDQSP

UDQSN

UDMWEN

DQ11
DQ10

DQ9
DQ8

DQ7
DQ6
DQ5
DQ4

LDQSP
LDQSN

LDM
DQ3

DQ2
DQ1
DQ0

VDDQVSSQ
VDDQ1
VDDQ2
VDDQ3
VDDQ4
VDDQ5
VDDQ6
VDDQ7
VDDQ8
VDDQ9

VDDVSS
VDD1
VDD2
VDD3
VDD4

VDDDL

VREF

NC6

+1V8

B9
B1
D9
D1

B7
A8
B3K3

D3
D7
C2
C8

F9
F1
H9
H1

F7
E8
F3

H3
H7
G2
G8

A9A7
C1
C3
C7
C9
E9
G1
G3
G7
G9

A1A3
E1
J9
M9
R1

J1
J2

E2

2U2

C520

DGND

+1V8

A_MDATA15
A_MDATA14

A_MDATA13

A_MDATA12

A_MDQSU

A_MDQSUZ

A_MDQMU

A_MDATA11

A_MDATA10

A_MDATA9

A_MDATA8

A_MDATA7
A_MDATA6
A_MDATA5
A_MDATA4

A_MDQSL

A_MDQSLZ

A_MDQML

A_MDATA3
A_MDATA2
A_MDATA1
A_MDATA0

A-MVREF

R534

0.1U

C512

DGND

DGND

C521 0.1U

2U2

C537

DGND

+1V8

R533

1K

1%

1K

1%

1V8-DDR2

0.1U

0.1U

C523

C522

AVDD_DDR_1V8

0.1UC538

0.1UC539

+1V8

T

CLOSE TO DDR POWER PIN

0.1U

C526 0.1U

0.1U

C527

0.1UC542

0.1U

C528

0.1U

C543

C529

0.1U

C544

0.1U

0.1U

C525

C524

T

CLOSE TO SOC POWER PIN

0.1U

C541 0.1U

C540

C530 0.1U

0.1UC545

0.1U

C531

0.1U

C532

0.1U

C533

0.1U

C534

+3V3

0.1U

C535

C536 0.1U

L504
120R

VDD33

2U2

C546

0.1UC547

+3_3VSTB

0.1U

0.1U

C549

C548

DGND

0.1U

C550

220R

220R

0.1U

C551

L500

L501

AVDD_ADC

10U

C552

AVDD_DMPLL

C556

0.1U

VDDC-1V28

DIM_OUT

SDA

SCL

0.1U

C554 0.1U

C553

DGND

T

AVDD_DMPLL

R525

R526

C555 0.1U

L505

DVDD_DDR_1.2V

220R

C568

2U2

NC/

NC/

NC/

DGND

SDA

SCL

T

100R
100R
100RR527

VDDC-1V28

2U2

C557

DGND

C569

0.1U

DIM_OUT

T

T

CORE POWER

0.1U

C558 0.1U

C559

0.1U

C560

+2V5

C561

TXO0+_OUT

TXO1+_OUT

TXO2+_OUT

TXOC+_OUT
TXO3+_OUT
TXO4+_OUT

SYNC
M_SDA

M_SCL

TXE0+_OUT
TXE1+_OUT

TXE2+_OUT

TXEC+_OUT

TXE3+_OUT

TXE4+_OUT

VDDC-1V28

0.1U

L506

120R

P500
39
37
35
33
31
29 30
27
25
23
21
19
17
15
13
11

9
7
5
3
1 2

L502

VDDC-PIN86

120R

0.1U

C562

DGND

AVDD_AU25

0.1U

C570

DGND

12V

40

TXO0-_OUT

38

TXO1-_OUT

36

TXO2-_OUT

34

TXOC-_OUT

32

0.1U

C576

DGND

+3V3

TXO3-_OUT

TXO4-_OUT

28
26

ROTATE

T

R508
1K

NC

24

T

FORMAT

GND13

T

PANEL_VCC

0.1U

R555

100R

DGND

DGND

R509
10K

NC

FORMAT

22

TXE0-_OUT

20

TXE1-_OUT

18

TXE2-_OUT

16

TXEC-_OUT

14

TXE3-_OUT

12

TXE4-_OUT

10
8
6
4

C509

DGND

ADC2P5

L503

+2V5

120R

2U2

C563

L507

+2V5 +2V5

AVDD_REF_2V5

120R

0.1U

C571

0.1U

C564

0.1U

C565

DGND

0.1U

C566

L508

120R

0.1U

C572

DGNDDGND

ADC2P5

0.1U

C567

AVSS_PGA

R530

0R

DGNDDGND

AVDD_25

F

E

D

C

E2P_VCC

T

U503

M24C64

1

E0/NC

2

E1/NC

3

A

E2/NC

4

VSS

VCC

WC

SCL

SDA

8
7
6
5

DGND

T

SDA2

DGND

C581

2U2

47P

C579

SCL2

T

47P

C580

4K7

R542

R545
100R

100R
R546

4K7

R543

4K7

R544

EEPROM-WP

T

100R

R547

SCL

SDA

EEPROM-WP

DGND

THIS DRAWING CANNOT BE COMMUNICATED TO UNAUTHORIZED PERSONS COPIED UNLES S PERMITTED IN WRITING

Near IC PIN

C582

0.047U

R553

68R

VCOM0

DGND

I2S_BCK

R548 4K7

DGND

I2S_MCK

CFG-PWM1

4K7

4K7

R550

R549

CFG-PWM0

4K7

R551

...

...

...
...

Index-Lab

Last saved :

DD-MM
DD-MM

DD-MM
DD-MM

...
...

...
...

...

...

SBU :
TCLNO:

TCL

ADDRESS1

...

...

...

.............

ADDRESS2

A

ADDRESS3

...

...

NAME Last modifDESCRIPTIONDATE

4-14-2009_15:30

...

DESIGNATION

...........

TELEPHONE

DRAWN

ON:
BY:

CHECKED

DD-MM-YY

ON:
BY:

......

PAGE:
OF :

123456789101112

FORMAT DIN A1

12V

R601

470R

C601

100U

16V

DGND

R_OUT

L_OUT

C602

NC/2U2

R604
10K

R608

10K

OP_VCC

C603

NC/0.1U

22K

C620

NC/1000P

DGND

22K

C621

NC/1000P

DGND

R602

R603

OP_VCC

1K

R607

R611

1K

R605

6K8

R609

6K8

AMP_R

R606

DGND

AMP_L

R610

DGND

B

7K5

B

7K5

C

E

DGND

C

E

DGND

Q601
BT3904

Q602
BT3904

+3V3

DGND

V_AUDIO

R613 10K

R612

AMP_L

R620

DGND

AMP_R

0R

10R

R618

100R

C622
C623
C624

R621

100R

GAIN0

C606

1000P

DGND

C625

1000P

MUTE

1U

1U

DGND

R628

22U

50V

DGND

C604

C605

1U

1U

C617 1U
C607 1U

R647

4K7

15K

C637

R617

1K

R622
10K

1U

GAIN0

PLIMIT

DGND

PLIMIT

R645

15K

R636

Q604

BT3906

1
2
3
4
5
6
7
8

9
10
11
12
13
14

Q603

C

B

0R

R643

10K

R642

47K

DGND

FAULT

LINP

LINN

GAIN0

GAIN1

AVCC

AGND

GVDD

PLIMIT

RINN

RINP

NC

PBTL

TPA3113D2

R616

10K

E

BT3906

E

B

C

R619
100K

U601

R646

22K

PVCCL2SD

PVCCL1

BSPL

OUTPL

PGND2

OUTNL

BSNL

BSNR

OUTNR

PGND1

OUTPR

BSPR

PVCCR2

PVCCR1

R615

1K

R644

22K

28
27
26
25
24
23
22
21
20
19
18
17
16
15

C609

1000P

C612

C615

C608

1000P

DGND

C613
C614

4K7

R635

NC/

V_AUDIO

C610

0.1U

0.22U

DGND

0.22U

0.22U

DGND

0.22U
L611 22UH/NC

C616

0.1U

DGND

D601

DGND

(5)

AMP_MUTE

C618

220U

35V

R623 NC/10R

220R

L604

L605

22UH/NC

R624

NC/10R

L606 220R

L607 22UH/NC

NC/10R

R625

L608 220R

L609 22UH/NC

R626 NC/10R

220R

L610

V_AUDIO

C611

220U

35V

R633

NC/2K2

10VNC/

R627

2K2

C627

C630
C631

C633

R637

C626

NC/330P

0.1U

C628

NC/330P

NC/330P

0.1U

C632

NC/330P

0.1U

12V

10K

D602

DGND

C629

DGND

V_AUDIO

4K7

R639

DGND

LL4148

0.1U

R638

L+

L-

R-

R+

+3_3VSTB

4K7

R640

C

B

E

10K

Q605

BT3904

EARPHONE_MUTE

L+

T T

L+

L-

R+

R-

R- R+

T

R641

100R

10U

C638

NC/

T

L-

1

2

1

2

MUTE

R663

4K7

D603

LL4148

P602

P601

4K7

R664

R665

DGND

+3_3VSTB

R666

C

B

E

10K

4K7

Q606
BT3904

R667

100R

PHONE_MUTE

L_OUT

R_OUT

R648

1K

R649

C647

47P

1K

C648

47P

DGND

DGND

C634

2U2

C635

2U2

R650

33K

R651

33K

DGND

DGND

R652

33K

R653

C636

1500P

C639

1500P

1K

R654

1K

R655

33K

PHONE_MUTE

C640

150P

U602

DRV632

C646
150P

R656

1K

1

2

-INR

+INR

-INL

+INL

13

14

C645

NC/1000P

3

OUTR

OUTL

12

DGND

DGND

4

11

5

SGND

UVP

10

DGND

DGND

6

MUTE

PGND

9

R657

10K

C641

7

PVSS

PVDD

8

1U

CN

CP

5V

R658

3K3

R659

3K3

C644

1U

DGND

C642

0.1U

+3V3

DGND

C643

16V

100U

PHONE_R

T

PHONE_DET

T

T

PHONE_L

+3V3

F601 F602 F603

PHONE_L

PHONE_DET

PHONE_R

R660

10K

R661

NC/10K

DGND

DGND

T

C649

0.1U

DGND

(BLACK)

5
4

Y/AV

PR/L

3

PB/R

2

GND

1

HP_GND

R662
100R

P603

HeadPhone

HP_DET

DGND

signal of main

1、 Can not switch on：

i

Check PW

Check reset

NO

Y

Check signal P—ON，

DIMBL—ON of main IC link

Trouble shooting

no switch on

Check 3.3V/12V/24V of power supply

Only 3.3V

to PW

N

Check the peripheral circuit

of mail IC,check solder of

main IC,check data fo NVM

and reset it

Check crystal frequence

yes

Check DC-DC

part,check

Y

Check IIC bus

ndividual signal source

2、abnormal picture ：

I

bad

Check the path with this

signal source

Abnormal picture

Check the peripheral circuit

of mail IC,updating SW,reset

NVM,replace main IC

Check crystal frequence？

All signal source bad

Check panel ID？

Check LVDS signal to main

IC？check LVDS cable?

3、 Abnormal sound：

Individual sound

signal source

Check the sound signal

link to main IC

Check the peripheral

circuit of main IC,SW

Abnormal sound

N

Check the power of

Check the mute

sound IC

function

Check all sound

source

Check sound IC

N

Y

Check wave filter and

speaker？

Y

H3-42E53E3-SRNC0AA
L42E5300F/MS82S-AP/AUTM E20 V1

parent child description BOM text
H3-42E53E3-SRNC0AA 64-C60100-105G SCREW 6MM 10MM ISO 53 R=Y
H3-42E53E3-SRNC0AA 64-B50120-104G SCREW 5MM 12MM 53 R=Y
H3-42E53E3-SRNC0AA 64-B30080-105G SCREW 3MM 8MM R=Y
H3-42E53E3-SRNC0AA 64-B30080-105G SCREW 3MM 8MM R=Y
H3-42E53E3-SRNC0AA 64-B30060-104G M/C SCREW B 3 X 6
H3-42E53E3-SRNC0AA 64-B30060-104G M/C SCREW B 3 X 6
H3-42E53E3-SRNC0AA 63-W3012T-BF5G SCREW-ST 3MM 12MM ISO 19 R=Y
H3-42E53E3-SRNC0AA 63-W3012T-BF5G SCREW-ST 3MM 12MM ISO 19 R=Y
H3-42E53E3-SRNC0AA 63-W3012T-BF5G SCREW-ST 3MM 12MM ISO 19 R=Y
H3-42E53E3-SRNC0AA 63-S5015T-BT4G SCREW-ST 5MM ISO R=Y
H3-42E53E3-SRNC0AA 63-S3010T-BF4G SCREW-ST 3MM 10MM ISO R=Y
H3-42E53E3-SRNC0AA 63-B4012T-BF4G SCREW-ST 4MM 12MM ISO R=Y
H3-42E53E3-SRNC0AA 63-B4012T-BF4G SCREW-ST 4MM 12MM ISO R=Y
H3-42E53E3-SRNC0AA 63-B3008T-BF4G SCREW-ST 3MM 8MM ISO R=Y
H3-42E53E3-SRNC0AA 63-B3008T-BF4G SCREW-ST 3MM 8MM ISO R=Y
H3-42E53E3-SRNC0AA 63-B3008T-BF4G SCREW-ST 3MM 8MM ISO R=Y
H3-42E53E3-SRNC0AA 63-B3008T-BF4G SCREW-ST 3MM 8MM ISO R=Y
H3-42E53E3-SRNC0AA 63-B30060-BF4G SCREW
H3-42E53E3-SRNC0AA V6-PROJECT-ID027 SOFTWARE PROJECT ID: 27
H3-42E53E3-SRNC0AA 89-BX8915-JZ0U SUNDRIES-TAPE ADHESIVE 18MMX55M -­H3-42E53E3-SRNC0AA 76-941130-0AT RAW CARTON-BOX 42E5300-EU KXKXK 00 00 00
H3-42E53E3-SRNC0AA 75-941120-EC0 RAW POLYFOAM BOTTOM-EPS 42E5300-EU -- 00
H3-42E53E3-SRNC0AA 75-941110-EC0 RAW POLYFOAM TOP-EPS 42E5300-EU -- 00 00
H3-42E53E3-SRNC0AA 74-120080-50HEM DEC BAG -- R=N
H3-42E53E3-SRNC0AA 74-022032-5WEEM DEC BAG -- R=Y
H3-42E53E3-SRNC0AA 74-008010-12C RAW BAG PE 80MM×100MM (AUTO LOCK) -- 0
H3-42E53E3-SRNC0AA 72-MS82SA-EAP1B PRI -- IB MS82S-AP TCL ENG R=Y
H3-42E53E3-SRNC0AA 71-BAR006-0A9 TV PRI LABEL E001 -- R=N
H3-42E53E3-SRNC0AA 70-STDE53-EEMAD TV PRI ADDENDUM SHEET E5300F STAND ASSY
H3-42E53E3-SRNC0AA 67-M93408-0G0 RAW SUPPORT VESA -- 00 00 00 R=Y
H3-42E53E3-SRNC0AA 67-M93407-0G0 RAW SUPPORT METAL SHEET -- 00 00 00 R=Y
H3-42E53E3-SRNC0AA 67-M93405-0G0 RAW SUPPORT PSU-METAL-SHEET -- 00 00 00
H3-42E53E3-SRNC0AA 67-M93404-2G0 RAW SUPPORT STD-BKT -- 00 00 00 R=Y
H3-42E53E3-SRNC0AA 67-M93200-7G0 RAW SUPPORT MS82 -- 00 00 00 R=Y
H3-42E53E3-SRNC0AA 67-911120-0G001 DEC STAND CONNECTER -- 00 00 00 R=N
H3-42E53E3-SRNC0AA 62-934280-0UN RAW SUPPORT 42E5300 POWER -- 0UN 00 00 R
H3-42E53E3-SRNC0AA 47-PWS041-LX7 SOCKET AC SOCKET ST N ACT1DF-02BT3P010
H3-42E53E3-SRNC0AA 46-MM012L-02PN1G WIRE KEY BOARD TO SWITCH BOARD LINE 120M
H3-42E53E3-SRNC0AA 46-LL045L-12X01G WIRE POWER SULLPY WIRE FOR MAIN BOARD 45
H3-42E53E3-SRNC0AA 46-FM080L-04P01G KEY WIRE 800MM 4 A2008 A1250/1255 2.0
H3-42E53E3-SRNC0AA 46-FM060L-07P01G IR WIRE 600MM 7 A200
H3-42E53E3-SRNC0AA 46-FL015L-28XN1G WIRE DRIVER LINE 150MM 14PIN PH(LOCK) PH
H3-42E53E3-SRNC0AA 46-CV025L-02J01G WIRE SPEAKER WIRE 250MM 2PIN TJC3(LOCK)
H3-42E53E3-SRNC0AA 46-BV030L-02J01G WIRE SPEAKER WIRE 300MM 2PIN TJC3(LOCK)
H3-42E53E3-SRNC0AA 46-60FA40-BFB01G WIRE LVDS 400MM 40-51PIN FI-X30HL PHD 2.
H3-42E53E3-SRNC0AA 42-WDF720-XX2G SPEAKER 16OHM 8W 78 100HZ RECTANGLE 22MM
H3-42E53E3-SRNC0AA 41-UK0150-0KK02 WIRE 2.6MM 0D2.6/7.8(9/0.10BC+S25/0.10BC
H3-42E53E3-SRNC0AA 08-RT421C0-DR200AA DRT4210
08-RT421C0-DR200AA 25-NEF331-M1X CAP.ELE 105DEGREE C 0.00033F 20% 35V 103 C601
08-RT421C0-DR200AA 25-KJF470-M1X CAP.ELE 105DEGREE C 0.000047F +20% 160V C620
08-RT421C0-DR200AA 25-KJF470-M1X CAP.ELE 105DEGREE C 0.000047F +20% 160V C603
08-RT421C0-DR200AA 19-CD0478-JTX R-SMD 0.47OHM 5% 1/4W 1206 WW12XR470JTL R605

08-RT421C0-DR200AA 19-CD0478-JTX R-SMD 0.47OHM 5% 1/4W 1206 WW12XR470JTL R654
08-RT421C0-DR200AA 19-CD0271-JTX SMD. RES 270 OHM 1/4W +/-5% 1206 R619
08-RT421C0-DR200AA 19-CD0271-JTX SMD. RES 270 OHM 1/4W +/-5% 1206 R664
08-RT421C0-DR200AA 19-CD0271-JTX SMD. RES 270 OHM 1/4W +/-5% 1206 R609
08-RT421C0-DR200AA 19-CD0271-JTX SMD. RES 270 OHM 1/4W +/-5% 1206 R665
08-RT421C0-DR200AA 19-CD0271-JTX SMD. RES 270 OHM 1/4W +/-5% 1206 R622
08-RT421C0-DR200AA 19-CD0271-JTX SMD. RES 270 OHM 1/4W +/-5% 1206 R666
08-RT421C0-DR200AA 19-CD0228-JTX R-SMD 0.22OHM 5% 1/4W 1206 WW12XR220JTL R652
08-RT421C0-DR200AA 19-CD0228-JTX R-SMD 0.22OHM 5% 1/4W 1206 WW12XR220JTL R608
08-RT421C0-DR200AA 19-CD0228-JTX R-SMD 0.22OHM 5% 1/4W 1206 WW12XR220JTL R606
08-RT421C0-DR200AA 19-CD0228-JTX R-SMD 0.22OHM 5% 1/4W 1206 WW12XR220JTL R653
08-RT421C0-DR200AA 19-CD0228-JTX R-SMD 0.22OHM 5% 1/4W 1206 WW12XR220JTL R651
08-RT421C0-DR200AA 19-CD0228-JTX R-SMD 0.22OHM 5% 1/4W 1206 WW12XR220JTL R607
08-RT421C0-DR200AA 19-BC0750-JTX SMD.RES 75 OHM 1/8W +/-5% R601
08-RT421C0-DR200AA 19-BC0750-JTX SMD.RES 75 OHM 1/8W +/-5% R638
08-RT421C0-DR200AA 46-40336W-14XG CONN PH 14 2.0MM FEMALE R P601
08-RT421C0-DR200AA 46-40336W-10XG CONN PH 10 2.0MM FEMALE R P602
08-RT421C0-DR200AA 33-WLL330-MTX SMD.COIL SLF12575T-330M3R2-PF L603
08-RT421C0-DR200AA 33-WLL330-MTX SMD.COIL SLF12575T-330M3R2-PF L602
08-RT421C0-DR200AA 33-WLL330-MTX SMD.COIL SLF12575T-330M3R2-PF L601
08-RT421C0-DR200AA 33-WLL330-MTX SMD.COIL SLF12575T-330M3R2-PF L604
08-RT421C0-DR200AA 28-BC0105-KBX CAP.CER,SMD 1UF 16V 0805 - C624
08-RT421C0-DR200AA 28-BC0105-KBX CAP.CER,SMD 1UF 16V 0805 - C611
08-RT421C0-DR200AA 28-BB0473-KBX CAP.CER,SMD 47N0F 50.0V 0805 - C626
08-RT421C0-DR200AA 28-BB0473-KBX CAP.CER,SMD 47N0F 50.0V 0805 - C606
08-RT421C0-DR200AA 28-BB0331-JCX SMD. CAP 330 PF 50V C 0805 C623
08-RT421C0-DR200AA 28-BB0331-JCX SMD. CAP 330 PF 50V C 0805 C610
08-RT421C0-DR200AA 28-BB0224-KBX CAP.CER,SMD 220N0F 50V DCV 0805 - C612
08-RT421C0-DR200AA 28-BB0224-KBX CAP.CER,SMD 220N0F 50V DCV 0805 - C625
08-RT421C0-DR200AA 28-BB0102-KBX CAP.CER,SMD 1NF 50.0V 0805 - +/-10% R=Y C627
08-RT421C0-DR200AA 28-BB0102-KBX CAP.CER,SMD 1NF 50.0V 0805 - +/-10% R=Y C613
08-RT421C0-DR200AA 26-AIC102-KBX CAP.CER 1N0F 500VV - C628
08-RT421C0-DR200AA 26-AIC102-KBX CAP.CER 1N0F 500VV - C605
08-RT421C0-DR200AA 19-BC0474-FTX SMD.RES 0805,1/8W,±1%,470KΩ R662
08-RT421C0-DR200AA 19-BC0223-JTX SMD.RES 0805,1/8W,±5%,22KΩ R639
08-RT421C0-DR200AA 19-BC0223-JTX SMD.RES 0805,1/8W,±5%,22KΩ R603
08-RT421C0-DR200AA 19-BC0220-JTX SMD.RES 0805,1/8W,±5%,22Ω R636
08-RT421C0-DR200AA 19-BC0220-JTX SMD.RES 0805,1/8W,±5%,22Ω R634
08-RT421C0-DR200AA 19-BC0109-JTX SMD. RES 1 OHM 1/8W +/-5% R644
08-RT421C0-DR200AA 19-BC0109-JTX SMD. RES 1 OHM 1/8W +/-5% R647
08-RT421C0-DR200AA 19-BC0109-JTX SMD. RES 1 OHM 1/8W +/-5% R645
08-RT421C0-DR200AA 19-BC0109-JTX SMD. RES 1 OHM 1/8W +/-5% R646
08-RT421C0-DR200AA 19-BC0102-FTX R-SMD 1KOHM +/-1% 1/8W 0805 - R657
08-RT421C0-DR200AA 19-BC0102-FTX R-SMD 1KOHM +/-1% 1/8W 0805 - R621
08-RT421C0-DR200AA 19-BC0000-JTX SMD.RES 0 OHM 1/8W +/-5% R690
08-RT421C0-DR200AA 12-0D4454-0BX MOSFET-SMD N 150V 20A 20V 94MOHM 100W AO Q602
08-RT421C0-DR200AA 12-0D4454-0BX MOSFET-SMD N 150V 20A 20V 94MOHM 100W AO Q601
08-RT421C0-DR200AA 09-S4200H-STX D-BR,SMD 200V 4A 0.82V 100A 1UA 25NSEC 2 D610
08-RT421C0-DR200AA 09-S4200H-STX D-BR,SMD 200V 4A 0.82V 100A 1UA 25NSEC 2 D601
08-RT421C0-DR200AA 09-38C5V6-DTX D-ZENER, SMD 5.6VV /A 0.3W BZX384-C5V6 D606
08-RT421C0-DR200AA 09-38C5V6-DTX D-ZENER, SMD 5.6VV /A 0.3W BZX384-C5V6 D607
08-RT421C0-DR200AA 09-0BAV70-ATX D,SMD 75VV 125MA_A 715MVV 4N 0.25W SOT23 D611
08-RT421C0-DR200AA 09-0BAV70-ATX D,SMD 75VV 125MA_A 715MVV 4N 0.25W SOT23 D602
08-RT421C0-DR200AA 09-0BAS21-ATX DIO SIG SM BAS21 D603
08-RT421C0-DR200AA 09-0BAS21-ATX DIO SIG SM BAS21 D612
08-RT421C0-DR200AA 19-BC0474-FTX SMD.RES 0805,1/8W,±1%,470KΩ R628
08-RT421C0-DR200AA 19-BC0473-FTX SMD.RES 0805,1/8W,±1%,47KΩ R625

08-RT421C0-DR200AA 19-BC0473-FTX SMD.RES 0805,1/8W,±1%,47KΩ R656
08-RT421C0-DR200AA 19-BC0473-FTX SMD.RES 0805,1/8W,±1%,47KΩ R624
08-RT421C0-DR200AA 19-BC0473-FTX SMD.RES 0805,1/8W,±1%,47KΩ R655
08-RT421C0-DR200AA 19-BC0472-JTX SMD. RES 4.7K OHM 1/8W +/-5% R611
08-RT421C0-DR200AA 19-BC0472-JTX SMD. RES 4.7K OHM 1/8W +/-5% R612
08-RT421C0-DR200AA 19-BC0471-JTX SMD.RES 470 OHM 1/8W +/-5% R604
08-RT421C0-DR200AA 19-BC0471-JTX SMD.RES 470 OHM 1/8W +/-5% R640
08-RT421C0-DR200AA 19-BC0471-JTX SMD.RES 470 OHM 1/8W +/-5% R659
08-RT421C0-DR200AA 19-BC0470-JTX SMD.RES 0805,1/8W,±5%,47Ω R637
08-RT421C0-DR200AA 19-BC0470-JTX SMD.RES 0805,1/8W,±5%,47Ω R602
08-RT421C0-DR200AA 19-BC0334-FTX SMD. RES 330K OHM 1/8W +/-1% R663
08-RT421C0-DR200AA 19-BC0334-FTX SMD. RES 330K OHM 1/8W +/-1% R629
08-RT421C0-DR200AA 19-BC0334-FTX SMD. RES 330K OHM 1/8W +/-1% R630
08-RT421C0-DR200AA 19-BC0334-FTX SMD. RES 330K OHM 1/8W +/-1% R658
08-RT421C0-DR200AA 19-BC0302-JTX SMD.RES 3K OHM 1/8W +/-5% R661
08-RT421C0-DR200AA 19-BC0302-JTX SMD.RES 3K OHM 1/8W +/-5% R631
08-RT421C0-DR200AA 19-BC0225-JTX SMD.RES 2.2M OHM 1/8W +/-5% R672
08-RT421C0-DR200AA 19-BC0225-JTX SMD.RES 2.2M OHM 1/8W +/-5% R673
08-RT421C0-DR200AA 19-BC0225-JTX SMD.RES 2.2M OHM 1/8W +/-5% R674
08-RT421C0-DR200AA 19-BC0225-JTX SMD.RES 2.2M OHM 1/8W +/-5% R671
08-RT421C0-DR200AA 33-NLL330-MTX IND-SMD 0.15OHM 40 1.7A TAPE VLC6045T-33 L606
08-RT421C0-DR200AA 25-GJF220-M1X CAP.ELE 5MM 22UF 160V 10*20 105 B43044S1 C604
08-RT421C0-DR200AA 28-BB0102-KBX CAP.CER,SMD 1NF 50.0V 0805 - +/-10% R=Y C631
08-RT421C0-DR200AA 28-BB0102-KBX CAP.CER,SMD 1NF 50.0V 0805 - +/-10% R=Y C633
08-RT421C0-DR200AA 28-BB0102-KBX CAP.CER,SMD 1NF 50.0V 0805 - +/-10% R=Y C630
08-RT421C0-DR200AA 33-NLL330-MTX IND-SMD 0.15OHM 40 1.7A TAPE VLC6045T-33 L605
08-RT421C0-DR200AA 28-BB0104-KBX CAP.CER,SMD 100N0F 50V DCV 0805 - C632
08-RT421C0-DR200AA 25-GJF220-M1X CAP.ELE 5MM 22UF 160V 10*20 105 B43044S1 C602
08-RT421C0-DR200AA 19-BC0473-FTX SMD.RES 0805,1/8W,±1%,47KΩ R660
08-RT421C0-DR200AA 19-CD0228-JTX R-SMD 0.22OHM 5% 1/4W 1206 WW12XR220JTL R680
08-RT421C0-DR200AA 19-CD0228-JTX R-SMD 0.22OHM 5% 1/4W 1206 WW12XR220JTL R650
08-RT421C0-DR200AA 40-RT4611-DRB2XG PCB DRT4611 210X150MM 3PC DOUBLESIDED 1. PCB
08-RT421C0-DR200AA 28-BB0474-KBX CAP.CER,SMD 0.47UF 10% 50V 0.1 0805 CL21 C670
08-RT421C0-DR200AA 13-MP3204-TTB IC LED DRIVER IC MAP3204T U602
08-RT421C0-DR200AA 13-MP3204-TTB IC LED DRIVER IC MAP3204T U601
H3-42E53E3-SRNC0AA 08-PE371C1-PW200AA ASS'Y - POWER BD(PE371C0)
08-PE371C1-PW200AA 08-PE371C1-PW300AA PE371C0(电源板）
08-PE371C1-PW300AA 28-BB0151-JCX SMD. CAP 150PF 50V +/-5% C306
08-PE371C1-PW300AA 28-BB0104-ZFX CAP.CER,SMD 100N0F 50V DCV 0805 - C402
08-PE371C1-PW300AA 28-BB0104-ZFX CAP.CER,SMD 100N0F 50V DCV 0805 - C215
08-PE371C1-PW300AA 28-BB0104-ZFX CAP.CER,SMD 100N0F 50V DCV 0805 - C419
08-PE371C1-PW300AA 28-BB0104-ZFX CAP.CER,SMD 100N0F 50V DCV 0805 - C303
08-PE371C1-PW300AA 28-BB0104-KBX CAP.CER,SMD 100N0F 50V DCV 0805 - C415
08-PE371C1-PW300AA 28-BB0103-KBX CAP.CER,SMD 10NF 50.0V 0805 - +/-10% R=Y C217
08-PE371C1-PW300AA 28-BB0102-KBX CAP.CER,SMD 1NF 50.0V 0805 - +/-10% R=Y C213
08-PE371C1-PW300AA 28-BB0102-KBX CAP.CER,SMD 1NF 50.0V 0805 - +/-10% R=Y C304
08-PE371C1-PW300AA 28-BB0102-KBX CAP.CER,SMD 1NF 50.0V 0805 - +/-10% R=Y C416
08-PE371C1-PW300AA 28-BB0102-KBX CAP.CER,SMD 1NF 50.0V 0805 - +/-10% R=Y C407
08-PE371C1-PW300AA 28-BB0101-JCX SMD CAP. 100 PF 50V C 0805 C410
08-PE371C1-PW300AA 28-BA0475-KBX CAP.CER,SMD 4U7F 10V DCV 0805 188605656 C418
08-PE371C1-PW300AA 28-BA0106-KBX CAP.CER,SMD 10U0F 10V DCV 0805 - C408
08-PE371C1-PW300AA 36-LIF210-JX0 COILS AND INDUCTORS 12MH 1500V FILTER 1. LF2
08-PE371C1-PW300AA 36-LIF210-JX0 COILS AND INDUCTORS 12MH 1500V FILTER 1. LF3
08-PE371C1-PW300AA 36-LIF209-JX0 COILS AND INDUCTORS 1.5MH 1500V FILTER 3 LF1
08-PE371C1-PW300AA 34-R129K2-1BX IND-F 0.0000012H 10% 7200EA 2A 0.01OHM L L201
08-PE371C1-PW300AA 28-BD0105-ZFX CAP.CER,SMD 1U0F 25V DCV 0805 - C218
08-PE371C1-PW300AA 28-BD0105-ZFX CAP.CER,SMD 1U0F 25V DCV 0805 - C308

08-PE371C1-PW300AA 28-BD0105-ZFX CAP.CER,SMD 1U0F 25V DCV 0805 - C427
08-PE371C1-PW300AA 28-BD0105-ZFX CAP.CER,SMD 1U0F 25V DCV 0805 - C403
08-PE371C1-PW300AA 28-BD0105-ZFX CAP.CER,SMD 1U0F 25V DCV 0805 - C212
08-PE371C1-PW300AA 28-BB0474-ZFX CAP.CER,SMD 470N0F 50V DCV 0805 - C302
08-PE371C1-PW300AA 28-BB0473-KBX CAP.CER,SMD 47N0F 50.0V 0805 - C202
08-PE371C1-PW300AA 28-BB0391-JCX SMD. CAP 390 PF 50V +/-5% C305
08-PE371C1-PW300AA 28-BB0222-KBX SMD CAP 0.0022UF 50V +/-10% C409
08-PE371C1-PW300AA 28-BB0220-JCX SMD.CAP 22 PF 50V C 0805 C311
08-PE371C1-PW300AA 25-TFB220-M1X CAP.ELE 5MM 22UF 50V 6.3 * 7 105 CD70H C204
08-PE371C1-PW300AA 25-TFB220-M1X CAP.ELE 5MM 22UF 50V 6.3 * 7 105 CD70H C205
08-PE371C1-PW300AA 25-TFB220-M1X CAP.ELE 5MM 22UF 50V 6.3 * 7 105 CD70H C401
08-PE371C1-PW300AA 25-NEF102-M1X CAP.ELE 5MM 1000UF 35V 10*33.5 105 CD284 C411
08-PE371C1-PW300AA 25-GNF689-M1X CAP.ELE 105DEGREE C 6.8UF 20% 450V 120MA CE1
08-PE371C1-PW300AA 25-GNF470-M1S CAP.ELE 105DEGREE C 47UF 20% 450V 500MA CE2
08-PE371C1-PW300AA 25-GNF470-M1S CAP.ELE 105DEGREE C 47UF 20% 450V 500MA CE3
08-PE371C1-PW300AA 25-GEF471-M1X CAP.ELE 5MM 470UF 35V 10 105 CD263 C413
08-PE371C1-PW300AA 25-GCB471-M1X CAP.ELE 5MM 470UF 16V 8X12 105 / C208
08-PE371C1-PW300AA 25-GCB221-M1X CAP.ELE 5MM 220UF 16VV 6.3*11 105 \ C210
08-PE371C1-PW300AA 22-VDR561-XG3 VDR 460V 2500A Y 14D561K-W RV1
08-PE371C1-PW300AA 22-NTC509-XX1 NTC DTC5D2-11 RN1
08-PE371C1-PW300AA 19-CD0624-FTX SMD.RES 620k OHM 1/4W +/-1% R303
08-PE371C1-PW300AA 19-CD0624-FTX SMD.RES 620k OHM 1/4W +/-1% R302
08-PE371C1-PW300AA 28-BA0106-KBX CAP.CER,SMD 10U0F 10V DCV 0805 - C417
08-PE371C1-PW300AA 27-MGC683-J0B FILM CAPACITOR 68NF 5MM 250V CL23B 5% C301
08-PE371C1-PW300AA 27-AWK105-J0XT FILM CAPACITOR 1UF 5% 450V 0.1% C372S105 C101
08-PE371C1-PW300AA 27-AQK334-KV6T 0.33UF 10% AC275V </=0.1% MPX-334K27L15L CX2
08-PE371C1-PW300AA 27-AQK224-KV6T 0.22UF 10% AC275V </=0.1% MPX-224K27L15L CX1
08-PE371C1-PW300AA 27-AKK223-J0B FILM CAPACITOR 22NF 15MM 1000V C82 C406
08-PE371C1-PW300AA 26-APK471-KB4A CAP.CER 470PF 10% 400ACV 10%PPM 2.5% CD CY4
08-PE371C1-PW300AA 26-APK471-KB4A CAP.CER 470PF 10% 400ACV 10%PPM 2.5% CD CY1
08-PE371C1-PW300AA 26-APK471-KB4A CAP.CER 470PF 10% 400ACV 10%PPM 2.5% CD CY2
08-PE371C1-PW300AA 26-APK102-ME4A CAP.CER 1000PF 20% 400ACV +20%-55%PPM 2. CY3
08-PE371C1-PW300AA 26-AKC221-KRX CAP.CER 220P0F 1K0V - C201
08-PE371C1-PW300AA 26-AKC221-KRX CAP.CER 220P0F 1K0V - C405
08-PE371C1-PW300AA 26-AKC221-KRX CAP.CER 220P0F 1K0V - C203
08-PE371C1-PW300AA 26-AKC221-KRX CAP.CER 220P0F 1K0V - C310
08-PE371C1-PW300AA 36-PFC002-BX0 COILS AND INDUCTORS 280UH 500V PFC INDUC LP1
08-PE371C1-PW300AA 66-20516X-1B0 RAW HOLDER FUSE -- 01 00 R=Y FOR F1
08-PE371C1-PW300AA 64-Z30080-114G Screws FOR DS2
08-PE371C1-PW300AA 64-Z30080-114G Screws FOR QW2
08-PE371C1-PW300AA 57-893390-0UG RAW HOLDER SPACE -- 00 00 R=Y A4
08-PE371C1-PW300AA 57-893390-0UG RAW HOLDER SPACE -- 00 00 R=Y A2
08-PE371C1-PW300AA 57-893390-0UG RAW HOLDER SPACE -- 00 00 R=Y A5
08-PE371C1-PW300AA 50-03150D-6GS3G FUSE 3.15A 250V F1
08-PE371C1-PW300AA 46-40338W-28XG CONN PHD 28 2.0MM FEMALE R P5
08-PE371C1-PW300AA 46-40338W-12XG CONN PHD 12 2.0MM FEMALE R P4
08-PE371C1-PW300AA 46-39219W-03XG PIN BASE VH-3AW CN1
08-PE371C1-PW300AA 41-WJ0195-B00 WIREBAREJUMPER19.5MM J7
08-PE371C1-PW300AA 41-WJ0175-B00 WIREBAREJUMPER17.5MM J29
08-PE371C1-PW300AA 41-WJ0175-B00 WIREBAREJUMPER17.5MM J10
08-PE371C1-PW300AA 41-WJ0150-B00 WIREBAREJUMPER15MM J3
08-PE371C1-PW300AA 67-H88056-BA0 RAW HEATSINK PE3210 BA0 00 R=Y FOR DS2
08-PE371C1-PW300AA 67-H88056-BA0 RAW HEATSINK PE3210 BA0 00 R=Y FOR QW2
08-PE371C1-PW300AA 66-343740-0B0 HOLLOW RIVET (2.3MMX4.0MMX3.5MM) FOR CN1
08-PE371C1-PW300AA 66-343730-0B0 HOLLOW RIVET 1.6MMX3.0MMX3.2MM FOR QW4
08-PE371C1-PW300AA 66-343730-0B0 HOLLOW RIVET 1.6MMX3.0MMX3.2MM FOR QW2
08-PE371C1-PW300AA 66-343730-0B0 HOLLOW RIVET 1.6MMX3.0MMX3.2MM FOR C101

08-PE371C1-PW300AA 66-343730-0B0 HOLLOW RIVET 1.6MMX3.0MMX3.2MM FOR CX1
08-PE371C1-PW300AA 66-343730-0B0 HOLLOW RIVET 1.6MMX3.0MMX3.2MM FOR DS2
08-PE371C1-PW300AA 66-343730-0B0 HOLLOW RIVET 1.6MMX3.0MMX3.2MM FOR QW3
08-PE371C1-PW300AA 66-343730-0B0 HOLLOW RIVET 1.6MMX3.0MMX3.2MM FOR LF3
08-PE371C1-PW300AA 66-343730-0B0 HOLLOW RIVET 1.6MMX3.0MMX3.2MM FOR LF2
08-PE371C1-PW300AA 66-343730-0B0 HOLLOW RIVET 1.6MMX3.0MMX3.2MM FOR TS2
08-PE371C1-PW300AA 66-343730-0B0 HOLLOW RIVET 1.6MMX3.0MMX3.2MM FOR RN1
08-PE371C1-PW300AA 66-343730-0B0 HOLLOW RIVET 1.6MMX3.0MMX3.2MM FOR LF1
08-PE371C1-PW300AA 41-WJ0060-B00 WIRE-BARE L301
08-PE371C1-PW300AA 41-WJ0060-B00 WIRE-BARE J5
08-PE371C1-PW300AA 41-WJ0060-B00 WIRE-BARE J16
08-PE371C1-PW300AA 41-WJ0060-B00 WIRE-BARE J39
08-PE371C1-PW300AA 41-WJ0060-B00 WIRE-BARE J38
08-PE371C1-PW300AA 41-WJ0060-B00 WIRE-BARE J36
08-PE371C1-PW300AA 41-WJ0060-B00 WIRE-BARE J12
08-PE371C1-PW300AA 41-WJ0060-B00 WIRE-BARE J40
08-PE371C1-PW300AA 41-WJ0060-B00 WIRE-BARE J37
08-PE371C1-PW300AA 41-WJ0060-B00 WIRE-BARE J14
08-PE371C1-PW300AA 40-E371C0-PWH1XG PCB 40-E371C0-PWH1XG 300X215MM 2PC SINGL
08-PE371C1-PW300AA 36-WID808-XX1 OTHER-CI 0.84UH 30% 100KHZ 20MOHM 1V 5A L401
08-PE371C1-PW300AA 36-TRF361-HX0 TRANSFORMER TRANSFORMER 24V 24V EM43 BCK TS2
08-PE371C1-PW300AA 36-TRF360-BX0 TRANSFORMER STANDBY MODE TRANSFORMER 3.3 TS1
08-PE371C1-PW300AA 41-WJ0150-B00 WIREBAREJUMPER15MM J6
08-PE371C1-PW300AA 41-WJ0150-B00 WIREBAREJUMPER15MM J15
08-PE371C1-PW300AA 41-WJ0140-B00 WIREBAREJUMPER14MM J26
08-PE371C1-PW300AA 41-WJ0125-B00 WIREBAREJUMPER12.5MM J8
08-PE371C1-PW300AA 41-WJ0125-B00 WIREBAREJUMPER12.5MM J11
08-PE371C1-PW300AA 41-WJ0115-B00 WIREBAREJUMPER11.5MM J42
08-PE371C1-PW300AA 41-WJ0100-B00 WIREBAREJUMPER10MM J9
08-PE371C1-PW300AA 41-WJ0090-B00 WIREBAREJUMPER9MM J24
08-PE371C1-PW300AA 41-WJ0090-B00 WIREBAREJUMPER9MM J41
08-PE371C1-PW300AA 41-WJ0075-B00 WIREBAREJUMPER7.5MM J28
08-PE371C1-PW300AA 41-WJ0070-B00 WIREBAREJUMPER7MM J23
08-PE371C1-PW300AA 41-WJ0070-B00 WIREBAREJUMPER7MM J2
08-PE371C1-PW300AA 41-WJ0060-B00 WIRE-BARE J4
08-PE371C1-PW300AA 41-WJ0060-B00 WIRE-BARE J22
08-PE371C1-PW300AA 19-CD0479-JTX SMD.RES 4.7 OHM 1/4W +/-5% R301
08-PE371C1-PW300AA 19-BC0100-JTX SMD. RES 10 OHM 1/8W +/-5% R405
08-PE371C1-PW300AA 19-BC0100-JTX SMD. RES 10 OHM 1/8W +/-5% R406
08-PE371C1-PW300AA 19-BC0000-JTX SMD.RES 0 OHM 1/8W +/-5% J21
08-PE371C1-PW300AA 19-BC0000-JTX SMD.RES 0 OHM 1/8W +/-5% J17
08-PE371C1-PW300AA 19-BC0000-JTX SMD.RES 0 OHM 1/8W +/-5% J1
08-PE371C1-PW300AA 18-NG0108-JHXL RESISTOR 0.1OHM 5% 2W NKNP R322
08-PE371C1-PW300AA 13-VIPER1-7LP IC-PS POWER IC VIPER17LN R=N U201
08-PE371C1-PW300AA 13-TCP781-D4P OPTICOUP 80V TLP781F PC3
08-PE371C1-PW300AA 13-TCP781-D4P OPTICOUP 80V TLP781F PC2
08-PE371C1-PW300AA 13-TCP781-D4P OPTICOUP 80V TLP781F PC1
08-PE371C1-PW300AA 13-NCP160-7BB IC PWL4222 PFC IC TAPE & REEL SO-8 NCP16 U301
08-PE371C1-PW300AA 13-NCP139-7AB IC PE121C0 POWER MANAGEMENT IC TAPE & RE U401
08-PE371C1-PW300AA 13-AZ431L-E1T IC SECOND EXPLOITATION VOLTAGE ADJUSTER U202
08-PE371C1-PW300AA 13-AZ431A-ZAT IC AZ431AZ-ATRE1 U402
08-PE371C1-PW300AA 19-BC0153-FTX SMD.RES 15K OHM 1/8W +/-1% R410
08-PE371C1-PW300AA 19-BC0122-FTX SMD. RES 1.2K OHM 1/8W +/-1% R220
08-PE371C1-PW300AA 19-BC0104-JTX SMD.RES 0805,1/8W,±5%,100KΩ R443
08-PE371C1-PW300AA 19-BC0103-JTX SMD. RES 10K OHM 1/8W +/-5% R319
08-PE371C1-PW300AA 19-BC0103-JTX SMD. RES 10K OHM 1/8W +/-5% R422
08-PE371C1-PW300AA 19-BC0103-JTX SMD. RES 10K OHM 1/8W +/-5% R419

08-PE371C1-PW300AA 19-BC0103-JTX SMD. RES 10K OHM 1/8W +/-5% R227
08-PE371C1-PW300AA 19-BC0102-JTX SMD.RES 1K OHM 1/8W +/-5% R216
08-PE371C1-PW300AA 19-BC0102-JTX SMD.RES 1K OHM 1/8W +/-5% R228
08-PE371C1-PW300AA 19-BC0102-FTX R-SMD 1KOHM +/-1% 1/8W 0805 - R426
08-PE371C1-PW300AA 19-BC0101-JTX SMD.RES100 OHM 1/8W +/-5% R420
08-PE371C1-PW300AA 19-BC0101-JTX SMD.RES100 OHM 1/8W +/-5% R417
08-PE371C1-PW300AA 19-BC0101-JTX SMD.RES100 OHM 1/8W +/-5% R431
08-PE371C1-PW300AA 19-BC0101-JTX SMD.RES100 OHM 1/8W +/-5% R324
08-PE371C1-PW300AA 10-1N5406-EPX D-VC 3A 600V 1V /A 150A /SEC /W 1N5406 BD2
08-PE371C1-PW300AA 10-1N5406-EPX D-VC 3A 600V 1V /A 150A /SEC /W 1N5406 BD1
08-PE371C1-PW300AA 10-1N4007-EBX DIODE 1N4007 D209
08-PE371C1-PW300AA 10-1N4007-EBX DIODE 1N4007 D211
08-PE371C1-PW300AA 10-1N4007-EBX DIODE 1N4007 D201
08-PE371C1-PW300AA 10-0SR160-SBX D-PIN 0.7VV 1_A 60VV / /W DO-41 SR160 DS1
08-PE371C1-PW300AA 09-52HC15-DTX D-ZENER, SMD 15V /A 0.375W BZT52HC15 D208
08-PE371C1-PW300AA 09-0BAV99-ATX D,SMD 70.0V 200MI0_A 855MI0V 4N 0.25W SO D403
08-PE371C1-PW300AA 09-0BAV70-ATX D,SMD 75VV 125MA_A 715MVV 4N 0.25W SOT23 D303
08-PE371C1-PW300AA 09-0BAV70-ATX D,SMD 75VV 125MA_A 715MVV 4N 0.25W SOT23 D402
08-PE371C1-PW300AA 09-0BAV70-ATX D,SMD 75VV 125MA_A 715MVV 4N 0.25W SOT23 D404
08-PE371C1-PW300AA 09-0BAS21-ATX DIO SIG SM BAS21 D202
08-PE371C1-PW300AA 09-0BAS21-ATX DIO SIG SM BAS21 D204
08-PE371C1-PW300AA 09-0BAS21-ATX DIO SIG SM BAS21 D212
08-PE371C1-PW300AA 12-S4160T-0BX TR-SMD NPN 60VV 1A_A 220MHZ 0.27W SOT23 Q205
08-PE371C1-PW300AA 12-BT3904-0BX TR-SMD NPN 40VV 200MA_A 300HZ 0.25W SOT2 Q407
08-PE371C1-PW300AA 12-BT3904-0BX TR-SMD NPN 40VV 200MA_A 300HZ 0.25W SOT2 Q301
08-PE371C1-PW300AA 11-DF7N50-0CX MOSFET N 500V 7A 30V 0.9OHM 36W MDF7N50 QW3
08-PE371C1-PW300AA 11-DF7N50-0CX MOSFET N 500V 7A 30V 0.9OHM 36W MDF7N50 QW4
08-PE371C1-PW300AA 11-DF12N5-0CX MOSFET N 500V 12A 30V 0.65OHM 42W MDF12N QW2
08-PE371C1-PW300AA 10-MUR460-FB6 ULTRAFAST PLASTIC RECTIFIER MUR460 D301
08-PE371C1-PW300AA 10-MUR160-FBX VLTRAFAST PLASTIC REITFIER MUR160 D405
08-PE371C1-PW300AA 10-79C9V1-DBX D-PR /A /_V 9.1V BZX79C9V1 D401
08-PE371C1-PW300AA 10-79C18V-DBX D-PR /A /_V 18V BZX79C18 D203
08-PE371C1-PW300AA 10-79C18V-DBX D-PR /A /_V 18V BZX79C18 D205
08-PE371C1-PW300AA 10-20100T-SNX D-PIN 0.8V 20_A 100V 20N 16W ITO-220S MB DS2
08-PE371C1-PW300AA 10-1N5406-EPX D-VC 3A 600V 1V /A 150A /SEC /W 1N5406 BD3
08-PE371C1-PW300AA 10-1N5406-EPX D-VC 3A 600V 1V /A 150A /SEC /W 1N5406 BD4
08-PE371C1-PW300AA 19-BC0183-FTX SMD.RES 0805,1/8W,±1%,18KΩ R428
08-PE371C1-PW300AA 19-CD0220-JTX SMD. RES 22 OHM 1/4W +/-5% 1206 R409
08-PE371C1-PW300AA 19-CD0205-FTX SMD.RES 2M OHM 1206 +/-1% R446
08-PE371C1-PW300AA 19-CD0205-FTX SMD.RES 2M OHM 1206 +/-1% R445
08-PE371C1-PW300AA 19-CD0205-FTX SMD.RES 2M OHM 1206 +/-1% R447
08-PE371C1-PW300AA 19-CD0105-FTX SMD.RES 1M OHM 1/4W +/-1% 1206 R444
08-PE371C1-PW300AA 19-CD0105-FTX SMD.RES 1M OHM 1/4W +/-1% 1206 RD5
08-PE371C1-PW300AA 19-CD0105-FTX SMD.RES 1M OHM 1/4W +/-1% 1206 RD2
08-PE371C1-PW300AA 19-CD0105-FTX SMD.RES 1M OHM 1/4W +/-1% 1206 R305
08-PE371C1-PW300AA 19-CD0105-FTX SMD.RES 1M OHM 1/4W +/-1% 1206 R304
08-PE371C1-PW300AA 19-CD0105-FTX SMD.RES 1M OHM 1/4W +/-1% 1206 RD3
08-PE371C1-PW300AA 19-CD0105-FTX SMD.RES 1M OHM 1/4W +/-1% 1206 RD6
08-PE371C1-PW300AA 19-CD0104-JTX RES.SMD 100KOHM 1/4W +/-5% R204
08-PE371C1-PW300AA 19-CD0104-JTX RES.SMD 100KOHM 1/4W +/-5% R203
08-PE371C1-PW300AA 19-CD0102-JTX SMD. RES 1000 OHM 1/4W +/-5% R403
08-PE371C1-PW300AA 19-CD0473-JTX SMD. RES 47K OHM 1/4W +/-5% R326
08-PE371C1-PW300AA 19-CD0472-JTX SMD. RES 4.7K OHM 1/4W 5% R423
08-PE371C1-PW300AA 19-CD0472-JTX SMD. RES 4.7K OHM 1/4W 5% R425
08-PE371C1-PW300AA 19-CD0472-JTX SMD. RES 4.7K OHM 1/4W 5% R451
08-PE371C1-PW300AA 19-CD0471-JTX SMD. RES 470 1/4W 5% R207
08-PE371C1-PW300AA 19-CD0279-JTX SMD. RES 2.7 OHM 1/4W +/-5% 1206 R202

08-PE371C1-PW300AA 19-CD0279-JTX SMD. RES 2.7 OHM 1/4W +/-5% 1206 R201
08-PE371C1-PW300AA 19-CD0279-JTX SMD. RES 2.7 OHM 1/4W +/-5% 1206 R229
08-PE371C1-PW300AA 19-CD0279-JTX SMD. RES 2.7 OHM 1/4W +/-5% 1206 R407
08-PE371C1-PW300AA 19-CD0279-JTX SMD. RES 2.7 OHM 1/4W +/-5% 1206 R205
08-PE371C1-PW300AA 19-CD0279-JTX SMD. RES 2.7 OHM 1/4W +/-5% 1206 R206
08-PE371C1-PW300AA 19-CD0273-JTX SMD. RES 27K OHM 1/4W +/-5% 1206 R415
08-PE371C1-PW300AA 19-CD0273-JTX SMD. RES 27K OHM 1/4W +/-5% 1206 R416
08-PE371C1-PW300AA 19-CD0222-JTX RES.SMD 2.2K OHM 1/4W 5% R412
08-PE371C1-PW300AA 19-BC0391-FTX SMD.RES 0805,1/8W,±1%,390Ω R307
08-PE371C1-PW300AA 19-BC0334-JTX SMD.RES 0805,1/8W,±5%,330KΩ R439
08-PE371C1-PW300AA 19-BC0333-FTX SMD. RES 33K OHM 1/8W +/-1% R219
08-PE371C1-PW300AA 19-BC0333-FTX SMD. RES 33K OHM 1/8W +/-1% R308
08-PE371C1-PW300AA 19-BC0332-FTX SMD.RES 0805,1/8W,±1%,3.3KΩ R432
08-PE371C1-PW300AA 19-BC0303-FTX SMD.RES 0805,1/8W,±1%,30KΩ R433
08-PE371C1-PW300AA 19-BC0242-JTX SMD.RES 2.4K OHM 1/8W +/-5% R411
08-PE371C1-PW300AA 19-BC0223-FTX SMD. RES 22K OHM 1/8W +/-1% R437
08-PE371C1-PW300AA 19-BC0222-FTX SMD. RES 2.2K OHM 1/8W +/-1% R430
08-PE371C1-PW300AA 19-BC0220-JTX SMD.RES 0805,1/8W,±5%,22Ω R317
08-PE371C1-PW300AA 19-BC0203-FTX SMD.RES 0805,1/8W,±1%,20KΩ R306
08-PE371C1-PW300AA 19-BC0202-FTX SMD.RES 0805,1/8W,±1%,2KΩ R218
08-PE371C1-PW300AA 19-BC0202-FTX SMD.RES 0805,1/8W,±1%,2KΩ R442
08-PE371C1-PW300AA 19-BC0184-FTX SMD.RES 0805,1/8W,±1%,180KΩ R209
08-PE371C1-PW300AA 19-CD0101-JTX SMD. RES 100 OHM 1/4W +/-5% 1206 R318
08-PE371C1-PW300AA 19-CD0000-JTX RES.SMD 0 OHM 1206 J13
08-PE371C1-PW300AA 19-BC0824-FTX SMD. RES 820K OHM 1/8W +/-1% R208
08-PE371C1-PW300AA 19-BC0822-FTX SMD.RES 8.2K OHM 1/8W +/-1% R435
08-PE371C1-PW300AA 19-BC0821-FTX SMD. RES 820 OHM 1/8W +/-1% R440
08-PE371C1-PW300AA 19-BC0683-FTX SMD.RES 0805,1/8W,±1%,68KΩ R429
08-PE371C1-PW300AA 19-BC0562-JTX SMD.RES 0805,1/8W,±5%,5.6KΩ R438
08-PE371C1-PW300AA 19-BC0512-FTX SMD.RES 0805,1/8W,±1%,5.1KΩ R210
08-PE371C1-PW300AA 19-BC0474-JTX SMD.RES 0805,1/8W,±5%,470KΩ R441
08-PE371C1-PW300AA 19-BC0472-JTX SMD. RES 4.7K OHM 1/8W +/-5% R217
08-PE371C1-PW300AA 19-BC0472-JTX SMD. RES 4.7K OHM 1/8W +/-5% R427
08-PE371C1-PW300AA 19-BC0471-FTX SMD.RES 0805,1/8W,±1%,470Ω R323
08-PE371C1-PW300AA 19-BC0470-JTX SMD.RES 0805,1/8W,±5%,47Ω R222
08-PE371C1-PW300AA 19-BC0393-FTX SMD.RES 39K OHM 1/8W +/-1% R436
08-PE371C1-PW300AA 10-HS18VC-DBX DIODE 500MW 18HSC D205
08-PE371C1-PW300AA 10-HS18VC-DBX DIODE 500MW 18HSC D203
08-PE371C1-PW300AA 36-TRF360-LX0 TRANSFORMER TRANSFORMER 0.0028H 3.3V 10. TS1
08-PE371C1-PW300AA 26-APK102-ME9A CAP.CER 1000PF 250V HJE102MB4B3.5W 20% B CY3
08-PE371C1-PW300AA 26-APK471-KB9A CAP.CER 470PF 250V HJB471KB4B3.5W 10% B% CY2
08-PE371C1-PW300AA 26-APK471-KB9A CAP.CER 470PF 250V HJB471KB4B3.5W 10% B% CY1
08-PE371C1-PW300AA 26-APK471-KB9A CAP.CER 470PF 250V HJB471KB4B3.5W 10% B% CY4
08-PE371C1-PW300AA 36-TRF361-BX0 TRANSFORMER LLC TRANSFORMER 24V 24V EM43 TS2
08-PE371C1-PW300AA 27-AQK334-KV3 FILM CAPACITOR 0.33UF 15MM 275V C42(MKP6 CX2
08-PE371C1-PW300AA 27-AQK224-KV3T 0.22UF 10% AC250V </=0.1% C42P2224K6SC00 CX1
08-PE371C1-PW300AA 13-TV816M-DTP IC LTV-816-DT PC2
08-PE371C1-PW300AA 13-TV816M-DTP IC LTV-816-DT PC1
08-PE371C1-PW300AA 13-TV816M-DTP IC LTV-816-DT PC3
08-PE371C1-PW300AA 36-PFC002-LX0 COILS AND INDUCTORS 280H 500V INDUCTANCE LP1
08-PE371C1-PW300AA 36-TRF360-SX0 TRANSFORMER TRANSFORMER 0.0028H 3.3V 10. TS1
08-PE371C1-PW200AA 71-PHIBAR-NUL1A TV PRI LABEL BARCODE -- R=Y
H3-42E53E3-SRNC0AA 08-MS82S01-MA200AA ASS'Y - MAIN BD
08-MS82S01-MA200AA 08-0MS8210-V800010 ASS'Y-软件组件
08-0MS8210-V800010 V8-0MS8201-LF1V001 SOFT CN MS182 FLASH
08-MS82S01-MA200AA 08-MS82S01-MA300AA MS82S-AP/24V&3V3S/12V/TPA3113D2/3-HDMI
08-MS82S01-MA300AA 28-BB0105-KBX CAP.CER,SMD 1UF 10% 50V 0.2 0805 CL21B10 C622

08-MS82S01-MA300AA 28-BB0224-KBX CAP.CER,SMD 220N0F 50V DCV 0805 - C612
08-MS82S01-MA300AA 28-BB0224-KBX CAP.CER,SMD 220N0F 50V DCV 0805 - C613
08-MS82S01-MA300AA 28-BB0105-KBX CAP.CER,SMD 1UF 10% 50V 0.2 0805 CL21B10 C103
08-MS82S01-MA300AA 28-BA0106-KBX CAP.CER,SMD 10U0F 10V DCV 0805 - C118
08-MS82S01-MA300AA 28-BA0106-KBX CAP.CER,SMD 10U0F 10V DCV 0805 - C574
08-MS82S01-MA300AA 28-BA0106-KBX CAP.CER,SMD 10U0F 10V DCV 0805 - C552
08-MS82S01-MA300AA 28-BB0224-KBX CAP.CER,SMD 220N0F 50V DCV 0805 - C614
08-MS82S01-MA300AA 28-BB0224-KBX CAP.CER,SMD 220N0F 50V DCV 0805 - C615
08-MS82S01-MA300AA 28-BC0106-KBX CAP.CER,SMD 10UF 16V 0805 08053R106K160B C109
08-MS82S01-MA300AA 28-BC0106-KBX CAP.CER,SMD 10UF 16V 0805 08053R106K160B C111
08-MS82S01-MA300AA 28-HB0101-JCX CAP.CER,SMD 100P0F 50V DCV 0402 - C124
08-MS82S01-MA300AA 28-HB0101-JCX CAP.CER,SMD 100P0F 50V DCV 0402 - C153
08-MS82S01-MA300AA 28-HB0102-KBX CAP.CER,SMD 1N0F 50V DCV 0402 - C402
08-MS82S01-MA300AA 28-BA0106-KBX CAP.CER,SMD 10U0F 10V DCV 0805 - C501
08-MS82S01-MA300AA 28-AB0104-KBX CAP.CER,SMD 100NF 50.0V 0603 - +/-10% R= C633
08-MS82S01-MA300AA 28-AC0105-KBX SMD.CAP 16V 1UF +/-10% C623
08-MS82S01-MA300AA 28-AC0105-KBX SMD.CAP 16V 1UF +/-10% C624
08-MS82S01-MA300AA 28-AC0105-KBX SMD.CAP 16V 1UF +/-10% C405
08-MS82S01-MA300AA 28-AC0105-KBX SMD.CAP 16V 1UF +/-10% C500
08-MS82S01-MA300AA 28-AC0105-KBX SMD.CAP 16V 1UF +/-10% C604
08-MS82S01-MA300AA 28-AC0105-KBX SMD.CAP 16V 1UF +/-10% C617
08-MS82S01-MA300AA 28-AC0105-KBX SMD.CAP 16V 1UF +/-10% C607
08-MS82S01-MA300AA 28-AC0105-KBX SMD.CAP 16V 1UF +/-10% C605
08-MS82S01-MA300AA 28-BA0106-KBX CAP.CER,SMD 10U0F 10V DCV 0805 - C575
08-MS82S01-MA300AA 28-BA0106-KBX CAP.CER,SMD 10U0F 10V DCV 0805 - C142
08-MS82S01-MA300AA 28-BA0106-KBX CAP.CER,SMD 10U0F 10V DCV 0805 - C165
08-MS82S01-MA300AA 28-BA0106-KBX CAP.CER,SMD 10U0F 10V DCV 0805 - C170
08-MS82S01-MA300AA 28-BA0106-KBX CAP.CER,SMD 10U0F 10V DCV 0805 - C208
08-MS82S01-MA300AA 28-HB0102-KBX CAP.CER,SMD 1N0F 50V DCV 0402 - C502
08-MS82S01-MA300AA 28-HB0330-JCX CAP.CER,SMD 33PF 50V DCV 0402 - C345
08-MS82S01-MA300AA 28-HB0470-JCX CAP.CER,SMD 47PF 50V 0402 - C579
08-MS82S01-MA300AA 28-HB0470-JCX CAP.CER,SMD 47PF 50V 0402 - C580
08-MS82S01-MA300AA 28-HB0471-KBX CAP.CER,SMD 470P0F 50V DCV 0402 - C301
08-MS82S01-MA300AA 28-HB0471-KBX CAP.CER,SMD 470P0F 50V DCV 0402 - C302
08-MS82S01-MA300AA 28-HB0471-KBX CAP.CER,SMD 470P0F 50V DCV 0402 - C303
08-MS82S01-MA300AA 28-HB0471-KBX CAP.CER,SMD 470P0F 50V DCV 0402 - C300
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C144
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C143
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C135
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C131
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C130
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C125
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C101
08-MS82S01-MA300AA 28-HB0330-JCX CAP.CER,SMD 33PF 50V DCV 0402 - C507
08-MS82S01-MA300AA 28-HB0102-KBX CAP.CER,SMD 1N0F 50V DCV 0402 - C333
08-MS82S01-MA300AA 28-HB0102-KBX CAP.CER,SMD 1N0F 50V DCV 0402 - C606
08-MS82S01-MA300AA 28-HB0102-KBX CAP.CER,SMD 1N0F 50V DCV 0402 - C122
08-MS82S01-MA300AA 28-HB0102-KBX CAP.CER,SMD 1N0F 50V DCV 0402 - C608
08-MS82S01-MA300AA 28-HB0102-KBX CAP.CER,SMD 1N0F 50V DCV 0402 - C609
08-MS82S01-MA300AA 28-HB0102-KBX CAP.CER,SMD 1N0F 50V DCV 0402 - C625
08-MS82S01-MA300AA 28-HB0103-KBX CAP.CER,SMD 10N0F 50V DCV 0402 - C511
08-MS82S01-MA300AA 28-HB0151-JCX CAPACITORS 0402 50V 150P ±5% C126
08-MS82S01-MA300AA 28-HB0220-JCX CAP.CER,SMD 22P0F 50V DCV 0402 - C215
08-MS82S01-MA300AA 28-HB0220-JCX CAP.CER,SMD 22P0F 50V DCV 0402 - C505
08-MS82S01-MA300AA 28-HB0220-JCX CAP.CER,SMD 22P0F 50V DCV 0402 - C214
08-MS82S01-MA300AA 28-HB0221-JCX CAP.CER,SMD 220P0F 50V DCV 0402 - C220
08-MS82S01-MA300AA 28-HB0330-JCX CAP.CER,SMD 33PF 50V DCV 0402 - C506

08-MS82S01-MA300AA 28-AB0104-KBX CAP.CER,SMD 100NF 50.0V 0603 - +/-10% R= C114
08-MS82S01-MA300AA 25-TCB101-M1X CAP.ELE 5.0MM 100UF 16V 6.3*7 105 LELON C171
08-MS82S01-MA300AA 25-TCB101-M1X CAP.ELE 5.0MM 100UF 16V 6.3*7 105 LELON C317
08-MS82S01-MA300AA 25-TCB101-M1X CAP.ELE 5.0MM 100UF 16V 6.3*7 105 LELON C319
08-MS82S01-MA300AA 25-TCB101-M1X CAP.ELE 5.0MM 100UF 16V 6.3*7 105 LELON C601
08-MS82S01-MA300AA 25-TCB101-M1X CAP.ELE 5.0MM 100UF 16V 6.3*7 105 LELON C172
08-MS82S01-MA300AA 25-TCB101-M1X CAP.ELE 5.0MM 100UF 16V 6.3*7 105 LELON C127
08-MS82S01-MA300AA 25-TCS221-M1X CAP.ELE 3.5MM 220UF 16V 8*7 105 LELON C306
08-MS82S01-MA300AA 25-TCS221-M1X CAP.ELE 3.5MM 220UF 16V 8*7 105 LELON C120
08-MS82S01-MA300AA 28-AA0225-KBX CAP.CER,SMD 2U2F 10V DCV 0603 - C411
08-MS82S01-MA300AA 28-AA0225-KBX CAP.CER,SMD 2U2F 10V DCV 0603 - C329
08-MS82S01-MA300AA 28-AA0225-KBX CAP.CER,SMD 2U2F 10V DCV 0603 - C328
08-MS82S01-MA300AA 28-AA0225-KBX CAP.CER,SMD 2U2F 10V DCV 0603 - C327
08-MS82S01-MA300AA 28-AA0225-KBX CAP.CER,SMD 2U2F 10V DCV 0603 - C326
08-MS82S01-MA300AA 25-TCB101-M1X CAP.ELE 5.0MM 100UF 16V 6.3*7 105 LELON C133
08-MS82S01-MA300AA 19-GA0683-JTX SMD.RES 68K OHM 1/16W +/-5% R344
08-MS82S01-MA300AA 19-GA0752-JTX R-SMD 7.5KOHM +/-5% 1/16W 0402 - R610
08-MS82S01-MA300AA 19-GA0752-JTX R-SMD 7.5KOHM +/-5% 1/16W 0402 - R606
08-MS82S01-MA300AA 19-GA0752-JTX R-SMD 7.5KOHM +/-5% 1/16W 0402 - R357
08-MS82S01-MA300AA 19-GA0752-JTX R-SMD 7.5KOHM +/-5% 1/16W 0402 - R352
08-MS82S01-MA300AA 23-D08220-JBX NETWORK RES. 22 OHM 1/16W +/-5% RP500
08-MS82S01-MA300AA 25-BAS471-M1X9 CAP.ELE 3.5MM 470UF 6.3V 8*9 85 LELON C140
08-MS82S01-MA300AA 25-BAS471-M1X9 CAP.ELE 3.5MM 470UF 6.3V 8*9 85 LELON C233
08-MS82S01-MA300AA 25-BCB471-M1X9 CAP.ELE 5.00MM 470UF 16V 10*9 85 LELON C119
08-MS82S01-MA300AA 25-BEB221-M1L CAP.ELE 5.0MM 220UF 35V 10 85 REA221M1VS C102
08-MS82S01-MA300AA 25-BEB221-M1L CAP.ELE 5.0MM 220UF 35V 10 85 REA221M1VS C611
08-MS82S01-MA300AA 25-BEB221-M1L CAP.ELE 5.0MM 220UF 35V 10 85 REA221M1VS C618
08-MS82S01-MA300AA 28-AA0225-KBX CAP.CER,SMD 2U2F 10V DCV 0603 - C159
08-MS82S01-MA300AA 28-AB0104-KBX CAP.CER,SMD 100NF 50.0V 0603 - +/-10% R= C106
08-MS82S01-MA300AA 28-AB0104-KBX CAP.CER,SMD 100NF 50.0V 0603 - +/-10% R= C110
08-MS82S01-MA300AA 28-AB0104-KBX CAP.CER,SMD 100NF 50.0V 0603 - +/-10% R= C112
08-MS82S01-MA300AA 28-AB0104-KBX CAP.CER,SMD 100NF 50.0V 0603 - +/-10% R= C629
08-MS82S01-MA300AA 28-AB0104-KBX CAP.CER,SMD 100NF 50.0V 0603 - +/-10% R= C627
08-MS82S01-MA300AA 28-AB0104-KBX CAP.CER,SMD 100NF 50.0V 0603 - +/-10% R= C616
08-MS82S01-MA300AA 28-AB0104-KBX CAP.CER,SMD 100NF 50.0V 0603 - +/-10% R= C610
08-MS82S01-MA300AA 28-AB0104-KBX CAP.CER,SMD 100NF 50.0V 0603 - +/-10% R= C504
08-MS82S01-MA300AA 28-AB0104-KBX CAP.CER,SMD 100NF 50.0V 0603 - +/-10% R= C315
08-MS82S01-MA300AA 28-AB0104-KBX CAP.CER,SMD 100NF 50.0V 0603 - +/-10% R= C163
08-MS82S01-MA300AA 28-AB0104-KBX CAP.CER,SMD 100NF 50.0V 0603 - +/-10% R= C161
08-MS82S01-MA300AA 28-AB0104-KBX CAP.CER,SMD 100NF 50.0V 0603 - +/-10% R= C141
08-MS82S01-MA300AA 28-AB0104-KBX CAP.CER,SMD 100NF 50.0V 0603 - +/-10% R= C117
08-MS82S01-MA300AA 28-AB0104-KBX CAP.CER,SMD 100NF 50.0V 0603 - +/-10% R= C116
08-MS82S01-MA300AA 28-AB0104-KBX CAP.CER,SMD 100NF 50.0V 0603 - +/-10% R= C105
08-MS82S01-MA300AA 28-AA0225-KBX CAP.CER,SMD 2U2F 10V DCV 0603 - C147
08-MS82S01-MA300AA 28-AA0225-KBX CAP.CER,SMD 2U2F 10V DCV 0603 - C132
08-MS82S01-MA300AA 28-AA0225-KBX CAP.CER,SMD 2U2F 10V DCV 0603 - C581
08-MS82S01-MA300AA 28-AA0225-KBX CAP.CER,SMD 2U2F 10V DCV 0603 - C107
08-MS82S01-MA300AA 28-AA0225-KBX CAP.CER,SMD 2U2F 10V DCV 0603 - C568
08-MS82S01-MA300AA 28-AA0225-KBX CAP.CER,SMD 2U2F 10V DCV 0603 - C563
08-MS82S01-MA300AA 28-AA0225-KBX CAP.CER,SMD 2U2F 10V DCV 0603 - C557
08-MS82S01-MA300AA 28-AA0225-KBX CAP.CER,SMD 2U2F 10V DCV 0603 - C546
08-MS82S01-MA300AA 28-AA0225-KBX CAP.CER,SMD 2U2F 10V DCV 0603 - C537
08-MS82S01-MA300AA 28-AA0225-KBX CAP.CER,SMD 2U2F 10V DCV 0603 - C520
08-MS82S01-MA300AA 28-AA0225-KBX CAP.CER,SMD 2U2F 10V DCV 0603 - C508
08-MS82S01-MA300AA 28-AB0104-KBX CAP.CER,SMD 100NF 50.0V 0603 - +/-10% R= C631
08-MS82S01-MA300AA 28-AB0104-KBX CAP.CER,SMD 100NF 50.0V 0603 - +/-10% R= C113
08-MS82S01-MA300AA 28-AB0104-KBX CAP.CER,SMD 100NF 50.0V 0603 - +/-10% R= C100

08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C532
08-MS82S01-MA300AA 28-HC0473-KBX CAP.CER,SMD 47NF 16V 0402 - C582
08-MS82S01-MA300AA 33-KLN121-NTX CHIP BEAD 120 OHM +/-25% L507
08-MS82S01-MA300AA 33-KLN121-NTX CHIP BEAD 120 OHM +/-25% L502
08-MS82S01-MA300AA 33-KLN121-NTX CHIP BEAD 120 OHM +/-25% L503
08-MS82S01-MA300AA 33-KLN121-NTX CHIP BEAD 120 OHM +/-25% L504
08-MS82S01-MA300AA 33-KLN121-NTX CHIP BEAD 120 OHM +/-25% L506
08-MS82S01-MA300AA 33-KLN121-NTX CHIP BEAD 120 OHM +/-25% L510
08-MS82S01-MA300AA 33-KLN121-NTX CHIP BEAD 120 OHM +/-25% L508
08-MS82S01-MA300AA 28-HC0473-KBX CAP.CER,SMD 47NF 16V 0402 - C400
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C533
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C146
08-MS82S01-MA300AA 28-HC0473-KBX CAP.CER,SMD 47NF 16V 0402 - C330
08-MS82S01-MA300AA 28-HC0473-KBX CAP.CER,SMD 47NF 16V 0402 - C325
08-MS82S01-MA300AA 28-HC0473-KBX CAP.CER,SMD 47NF 16V 0402 - C322
08-MS82S01-MA300AA 28-HC0473-KBX CAP.CER,SMD 47NF 16V 0402 - C115
08-MS82S01-MA300AA 28-HC0473-KBX CAP.CER,SMD 47NF 16V 0402 - C332
08-MS82S01-MA300AA 28-HC0473-KBX CAP.CER,SMD 47NF 16V 0402 - C331
08-MS82S01-MA300AA 28-HC0473-KBX CAP.CER,SMD 47NF 16V 0402 - C510
08-MS82S01-MA300AA 28-HC0473-KBX CAP.CER,SMD 47NF 16V 0402 - C404
08-MS82S01-MA300AA 28-HC0473-KBX CAP.CER,SMD 47NF 16V 0402 - C403
08-MS82S01-MA300AA 28-HC0473-KBX CAP.CER,SMD 47NF 16V 0402 - C401
08-MS82S01-MA300AA 33-KLN221-NTX CHIP BEAD 0603 220 OHM L509
08-MS82S01-MA300AA 46-40337W-02XG CONN TJC3 2PIN 2.5MM MALE ST XHK-2AW-DK P602
08-MS82S01-MA300AA 46-40338W-12XG CONN PHD 12 2.0MM FEMALE R P100
08-MS82S01-MA300AA 46-40338W-40XG CONN PHD 40 2.0MM FEMALE R P500
08-MS82S01-MA300AA 47-EAR032-XX0 AV SOCKET R NO MSJ-1637-Y-AG-PBT(B22 P304
08-MS82S01-MA300AA 47-HDI011-KS0 SOCKET HDMI ST N A111989-F-15-R P402
08-MS82S01-MA300AA 47-HDI011-KS0 SOCKET HDMI ST N A111989-F-15-R P403
08-MS82S01-MA300AA 47-HDI011-KS0 SOCKET HDMI ST N A111989-F-15-R P401
08-MS82S01-MA300AA 47-RCA301-XB0G SOCKET-RCA N BK 1PIN R N AV-3.2-1W89 P305
08-MS82S01-MA300AA 47-RCA302-XR0G SOCKET-RCA N RD-WH 2PIN R N AV-3.2-2W72 P301
08-MS82S01-MA300AA 47-RCA303-XG0G SOCKET-RCA N RD-BU-GN 3PIN R N AV-3.2-3W P302
08-MS82S01-MA300AA 47-RCA303-XY0G SOCKET-RCA N RD-WH-YE 3PIN R N AV-3.2-3W P300
08-MS82S01-MA300AA 47-USB002-XX0 USB SOCKET USB-1W-B P303
08-MS82S01-MA300AA 47-VGA021-XX0 SOCKET VGA R NO LK-VGA021500-0003 P400
08-MS82S01-MA300AA 46-40337W-02X01G CONN R XH-2AW-DK-1（RED） P601
08-MS82S01-MA300AA 33-KLN221-NTX CHIP BEAD 0603 220 OHM L500
08-MS82S01-MA300AA 33-KLN221-NTX CHIP BEAD 0603 220 OHM L501
08-MS82S01-MA300AA 33-KLN221-NTX CHIP BEAD 0603 220 OHM L505
08-MS82S01-MA300AA 33-MLL150-MTA IND-SMD 15UH 20% 2.8A L100
08-MS82S01-MA300AA 33-NLL479-MTX IND-SMD 0.023OHM 40 3.8A TAPE VLC6045-4R L106
08-MS82S01-MA300AA 33-WLL100-MTX IND-SMD 0.0187OHM / 5.4A / SLF12575T-100 L104
08-MS82S01-MA300AA 35-392170-00X FERR.COIL BF-I35050C-683 L107
08-MS82S01-MA300AA 45-OSC24M-0Y2 CRYSTAL 24MHZ X24M
08-MS82S01-MA300AA 46-40336W-04XG CONN PH 4 2.0MM FEMALE R P102
08-MS82S01-MA300AA 46-40336W-07XG CONN PH 7 2.0MM FEMALE R P101
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C154
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C565
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C564
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C562
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C561
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C560
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C559
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C558
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C522
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C556

08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C521
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C512
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C509
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C503
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C417
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C566
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C529
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C528
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C527
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C526
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C524
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C523
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C578
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C576
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C573
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C572
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C571
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C570
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C569
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C567
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C416
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C222
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C206
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C203
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C202
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C201
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C168
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C166
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C164
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C543
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C542
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C541
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C540
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C539
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C538
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C223
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C413
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C412
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C344
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C555
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C554
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C553
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C551
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C550
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C549
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C548
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C547
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C545
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C307
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C544
08-MS82S01-MA300AA 19-GA0100-JTX SMD. RES 10 OHM 1/16W +/-5% R123
08-MS82S01-MA300AA 19-GA0101-FTX SMD.RES 100 OHM 1/16W +/-1% R524
08-MS82S01-MA300AA 19-GA0101-FTX SMD.RES 100 OHM 1/16W +/-1% R523
08-MS82S01-MA300AA 19-GA0101-JTX SMD. RES 100 OHM 1/16W +/-5% R454
08-MS82S01-MA300AA 19-GA0101-JTX SMD. RES 100 OHM 1/16W +/-5% R120
08-MS82S01-MA300AA 19-GA0101-JTX SMD. RES 100 OHM 1/16W +/-5% R130
08-MS82S01-MA300AA 19-GA0101-JTX SMD. RES 100 OHM 1/16W +/-5% R162

08-MS82S01-MA300AA 19-GA0101-JTX SMD. RES 100 OHM 1/16W +/-5% R163
08-MS82S01-MA300AA 19-GA0101-JTX SMD. RES 100 OHM 1/16W +/-5% R201
08-MS82S01-MA300AA 19-GA0101-JTX SMD. RES 100 OHM 1/16W +/-5% R215
08-MS82S01-MA300AA 19-GA0101-JTX SMD. RES 100 OHM 1/16W +/-5% R216
08-MS82S01-MA300AA 19-GA0101-JTX SMD. RES 100 OHM 1/16W +/-5% R452
08-MS82S01-MA300AA 19-GA0101-JTX SMD. RES 100 OHM 1/16W +/-5% R453
08-MS82S01-MA300AA 19-GA0101-JTX SMD. RES 100 OHM 1/16W +/-5% R455
08-MS82S01-MA300AA 19-GA0100-JTX SMD. RES 10 OHM 1/16W +/-5% R192
08-MS82S01-MA300AA 19-AB0750-JTX SMD. RES 75 OHM 1/10W 0603 R324
08-MS82S01-MA300AA 19-AB0750-JTX SMD. RES 75 OHM 1/10W 0603 R306
08-MS82S01-MA300AA 19-AB0821-FTX SMD. RES 820 OHM 1/10W +/-1% 0603 R107
08-MS82S01-MA300AA 19-CD0279-JTX SMD. RES 2.7 OHM 1/4W +/-5% 1206 R194
08-MS82S01-MA300AA 19-GA0000-JTX SMD. RES 0 OHM 1/16W +/-5% R155
08-MS82S01-MA300AA 19-GA0000-JTX SMD. RES 0 OHM 1/16W +/-5% R447
08-MS82S01-MA300AA 19-GA0000-JTX SMD. RES 0 OHM 1/16W +/-5% R472
08-MS82S01-MA300AA 19-GA0000-JTX SMD. RES 0 OHM 1/16W +/-5% R500
08-MS82S01-MA300AA 19-GA0000-JTX SMD. RES 0 OHM 1/16W +/-5% R530
08-MS82S01-MA300AA 19-GA0000-JTX SMD. RES 0 OHM 1/16W +/-5% R636
08-MS82S01-MA300AA 19-GA0000-JTX SMD. RES 0 OHM 1/16W +/-5% C210
08-MS82S01-MA300AA 19-GA0000-JTX SMD. RES 0 OHM 1/16W +/-5% C216
08-MS82S01-MA300AA 19-GA0000-JTX SMD. RES 0 OHM 1/16W +/-5% R152
08-MS82S01-MA300AA 19-GA0000-JTX SMD. RES 0 OHM 1/16W +/-5% R444
08-MS82S01-MA300AA 19-GA0102-JTX SMD. RES 1K OHM 1/16W +/-5% R503
08-MS82S01-MA300AA 19-GA0102-JTX SMD. RES 1K OHM 1/16W +/-5% R116
08-MS82S01-MA300AA 19-GA0102-JTX SMD. RES 1K OHM 1/16W +/-5% R617
08-MS82S01-MA300AA 19-GA0102-JTX SMD. RES 1K OHM 1/16W +/-5% R347
08-MS82S01-MA300AA 19-GA0102-JTX SMD. RES 1K OHM 1/16W +/-5% R118
08-MS82S01-MA300AA 19-GA0102-JTX SMD. RES 1K OHM 1/16W +/-5% R173
08-MS82S01-MA300AA 19-GA0102-JTX SMD. RES 1K OHM 1/16W +/-5% R355
08-MS82S01-MA300AA 19-GA0103-JTX SMD. RES 10K OHM 1/16W +/-5% R179
08-MS82S01-MA300AA 19-GA0103-JTX SMD. RES 10K OHM 1/16W +/-5% R113
08-MS82S01-MA300AA 19-GA0103-JTX SMD. RES 10K OHM 1/16W +/-5% R643
08-MS82S01-MA300AA 19-GA0103-JTX SMD. RES 10K OHM 1/16W +/-5% R638
08-MS82S01-MA300AA 19-GA0103-JTX SMD. RES 10K OHM 1/16W +/-5% R637
08-MS82S01-MA300AA 19-GA0103-JTX SMD. RES 10K OHM 1/16W +/-5% R622
08-MS82S01-MA300AA 19-GA0102-JTX SMD. RES 1K OHM 1/16W +/-5% R504
08-MS82S01-MA300AA 19-GA0101-JTX SMD. RES 100 OHM 1/16W +/-5% R521
08-MS82S01-MA300AA 19-GA0101-JTX SMD. RES 100 OHM 1/16W +/-5% R641
08-MS82S01-MA300AA 19-GA0101-JTX SMD. RES 100 OHM 1/16W +/-5% R621
08-MS82S01-MA300AA 19-GA0101-JTX SMD. RES 100 OHM 1/16W +/-5% R618
08-MS82S01-MA300AA 19-GA0101-JTX SMD. RES 100 OHM 1/16W +/-5% R555
08-MS82S01-MA300AA 19-GA0101-JTX SMD. RES 100 OHM 1/16W +/-5% R547
08-MS82S01-MA300AA 19-GA0101-JTX SMD. RES 100 OHM 1/16W +/-5% R546
08-MS82S01-MA300AA 19-GA0101-JTX SMD. RES 100 OHM 1/16W +/-5% R545
08-MS82S01-MA300AA 19-GA0101-JTX SMD. RES 100 OHM 1/16W +/-5% R522
08-MS82S01-MA300AA 19-GA0102-FTX SMD.RES 1K OHM 1/16W +/-1% R534
08-MS82S01-MA300AA 19-GA0102-FTX SMD.RES 1K OHM 1/16W +/-1% R533
08-MS82S01-MA300AA 19-GA0102-JTX SMD. RES 1K OHM 1/16W +/-5% R607
08-MS82S01-MA300AA 19-GA0102-JTX SMD. RES 1K OHM 1/16W +/-5% R602
08-MS82S01-MA300AA 19-AB0750-JTX SMD. RES 75 OHM 1/10W 0603 R328
08-MS82S01-MA300AA 12-BT3906-0BX TR-SMD PNP 40V 200MI0_A 250MHZ 225MI0W S Q604
08-MS82S01-MA300AA 12-MV65XP-0BX MOSFET-SMD P 20V 3.9A 1.92W SOT23 PMV65X Q106
08-MS82S01-MA300AA 13-AS1117-18B ICSOT-223 AS1117-18CX U106
08-MS82S01-MA300AA 13-AS1117-25B IC SOT-223 AS1117-25 CX U103
08-MS82S01-MA300AA 13-AS1117-33B IC 3.3V SOT-223 AS1117-33 CX U105
08-MS82S01-MA300AA 13-EN25Q3-2AB IC MS48 FLASH tube SOP8 EN25Q32A-100HIP U502(CPP)
08-MS82S01-MA300AA 13-K4T511-F7B IC DDR K4T51163QI-HCF7 U501

08-MS82S01-MA300AA 13-M24C64-W6B IC-EEPROM M24C64-WMN6T R=Y U503(CPP)
08-MS82S01-MA300AA 13-MP1482-DSB IC DC RECTIFIED STEP-DOWN CONVERTER U101
08-MS82S01-MA300AA 13-MP2127-DQB IC RT26 DC-DC QFN6-3X3 QFN6-3X3 MP2127 U104
08-MS82S01-MA300AA 13-RT8110-B0B IC MS58 DC/DC convert IC SMT tape TSOT R U100
08-MS82S01-MA300AA 19-AB0000-FTX SMD.RES 0 OHM 1/10W +/-1% 0603 R187
08-MS82S01-MA300AA 12-BT3906-0BX TR-SMD PNP 40V 200MI0_A 250MHZ 225MI0W S Q603
08-MS82S01-MA300AA 09-0BAV99-ATX D,SMD 70.0V 200MI0_A 855MI0V 4N 0.25W SO D500
08-MS82S01-MA300AA 09-LL4148-ATX SMD. SWITCHING DIODE LL4148 D602
08-MS82S01-MA300AA 09-LL4148-ATX SMD. SWITCHING DIODE LL4148 D102
08-MS82S01-MA300AA 12-04822A-0BX MOSFET-SMD N 30V 8A 1.8V 0.018OHM 2W AO4 Q100
08-MS82S01-MA300AA 12-BT3904-0BX TR-SMD NPN 40VV 200MA_A 300HZ 0.25W SOT2 Q302
08-MS82S01-MA300AA 12-BT3904-0BX TR-SMD NPN 40VV 200MA_A 300HZ 0.25W SOT2 Q301
08-MS82S01-MA300AA 12-BT3904-0BX TR-SMD NPN 40VV 200MA_A 300HZ 0.25W SOT2 Q107
08-MS82S01-MA300AA 12-BT3904-0BX TR-SMD NPN 40VV 200MA_A 300HZ 0.25W SOT2 Q101
08-MS82S01-MA300AA 12-BT3904-0BX TR-SMD NPN 40VV 200MA_A 300HZ 0.25W SOT2 Q602
08-MS82S01-MA300AA 12-BT3904-0BX TR-SMD NPN 40VV 200MA_A 300HZ 0.25W SOT2 Q303
08-MS82S01-MA300AA 12-BT3904-0BX TR-SMD NPN 40VV 200MA_A 300HZ 0.25W SOT2 Q601
08-MS82S01-MA300AA 12-BT3904-0BX TR-SMD NPN 40VV 200MA_A 300HZ 0.25W SOT2 Q605
08-MS82S01-MA300AA 12-BT3906-0BX TR-SMD PNP 40V 200MI0_A 250MHZ 225MI0W S Q500
08-MS82S01-MA300AA 12-BT3906-0BX TR-SMD PNP 40V 200MI0_A 250MHZ 225MI0W S Q300
08-MS82S01-MA300AA 19-AB0000-JTX RES SMD 0 OHM 1/10W +/-5% 0603 L201
08-MS82S01-MA300AA 19-AB0222-JTX RES SMD 2.2K OHM 1/10W 0603 R109
08-MS82S01-MA300AA 19-AB0223-FTX SMD. RES 22K OHM 1/10W +/-1% R128
08-MS82S01-MA300AA 19-AB0270-JTX R-SMD 27R0OHM 5% 1/10W 0603 - R108
08-MS82S01-MA300AA 19-AB0332-FTX SMD.RES 3.3K OHM 1/10W +/-1% 0603 R127
08-MS82S01-MA300AA 19-AB0333-FTX SMD. RES 33K OHM 1/10W +/-1% 0603 R126
08-MS82S01-MA300AA 19-AB0471-JTX SMD. RES 470 OHM 1/10W +/-5% R346
08-MS82S01-MA300AA 19-AB0471-JTX SMD. RES 470 OHM 1/10W +/-5% R601
08-MS82S01-MA300AA 19-AB0513-FTX SMD.RES 51K OHM 1/10W +/-1% R111
08-MS82S01-MA300AA 19-AB0750-JTX SMD. RES 75 OHM 1/10W 0603 R402
08-MS82S01-MA300AA 19-AB0750-JTX SMD. RES 75 OHM 1/10W 0603 R401
08-MS82S01-MA300AA 19-AB0750-JTX SMD. RES 75 OHM 1/10W 0603 R400
08-MS82S01-MA300AA 19-AB0750-JTX SMD. RES 75 OHM 1/10W 0603 R340
08-MS82S01-MA300AA 19-AB0750-JTX SMD. RES 75 OHM 1/10W 0603 R333
08-MS82S01-MA300AA 19-AB0123-FTX SMD. RES 12K OHM 1/10W +/-1% 0603 R106
08-MS82S01-MA300AA 19-AB0000-JTX RES SMD 0 OHM 1/10W +/-5% 0603 L203
08-MS82S01-MA300AA 19-AB0000-JTX RES SMD 0 OHM 1/10W +/-5% 0603 L210
08-MS82S01-MA300AA 19-AB0000-JTX RES SMD 0 OHM 1/10W +/-5% 0603 L211
08-MS82S01-MA300AA 19-AB0000-JTX RES SMD 0 OHM 1/10W +/-5% 0603 R121
08-MS82S01-MA300AA 19-AB0100-JTX RES SMD 10 OHM 1/10W +/-5% R101
08-MS82S01-MA300AA 19-AB0100-JTX RES SMD 10 OHM 1/10W +/-5% R104
08-MS82S01-MA300AA 19-AB0100-JTX RES SMD 10 OHM 1/10W +/-5% R620
08-MS82S01-MA300AA 19-AB0100-JTX RES SMD 10 OHM 1/10W +/-5% R351
08-MS82S01-MA300AA 19-AB0104-JTX SMD. RES 100K OHM 1/10W 0603 R110
08-MS82S01-MA300AA 19-AB0105-JTX RES SMD 1M OHM 1/10W 0603 R501
08-MS82S01-MA300AA 19-AB0105-JTX RES SMD 1M OHM 1/10W 0603 R541
08-MS82S01-MA300AA 19-AB0109-JTX RES SMD 1 OHM 1/10W +/-5% R203
08-MS82S01-MA300AA 19-AB0109-JTX RES SMD 1 OHM 1/10W +/-5% R202
08-MS82S01-MA300AA 19-AB0113-FTX SMD.RES 1/10W 11KOHM +/-1% R112
08-MS82S01-MA300AA 19-GA0103-JTX SMD. RES 10K OHM 1/16W +/-5% R616
08-MS82S01-MA300AA 19-GA0332-JTX SMD. RES 3.3K OHM 1/16W +/-5% R180
08-MS82S01-MA300AA 19-GA0332-JTX SMD. RES 3.3K OHM 1/16W +/-5% R342
08-MS82S01-MA300AA 19-GA0333-JTX SMD. RES 33K OHM 1/16W +/-5% R345
08-MS82S01-MA300AA 19-GA0472-JTX SMD. RES 4.7K OHM 1/16W +/-5% R114
08-MS82S01-MA300AA 19-GA0472-JTX SMD. RES 4.7K OHM 1/16W +/-5% R519
08-MS82S01-MA300AA 19-GA0472-JTX SMD. RES 4.7K OHM 1/16W +/-5% R153
08-MS82S01-MA300AA 19-GA0472-JTX SMD. RES 4.7K OHM 1/16W +/-5% R154

08-MS82S01-MA300AA 19-GA0472-JTX SMD. RES 4.7K OHM 1/16W +/-5% R647
08-MS82S01-MA300AA 19-GA0472-JTX SMD. RES 4.7K OHM 1/16W +/-5% R640
08-MS82S01-MA300AA 19-GA0472-JTX SMD. RES 4.7K OHM 1/16W +/-5% R639
08-MS82S01-MA300AA 19-GA0472-JTX SMD. RES 4.7K OHM 1/16W +/-5% R551
08-MS82S01-MA300AA 19-GA0472-JTX SMD. RES 4.7K OHM 1/16W +/-5% R550
08-MS82S01-MA300AA 19-GA0472-JTX SMD. RES 4.7K OHM 1/16W +/-5% R549
08-MS82S01-MA300AA 19-GA0472-JTX SMD. RES 4.7K OHM 1/16W +/-5% R548
08-MS82S01-MA300AA 19-GA0330-JTX SMD. RES 33 OHM 1/16W +/-5% R305
08-MS82S01-MA300AA 19-GA0229-JTX SMD.RES 1/16W 2.2 OHM ±5% R339
08-MS82S01-MA300AA 19-GA0330-JTX SMD. RES 33 OHM 1/16W +/-5% R410
08-MS82S01-MA300AA 19-GA0330-JTX SMD. RES 33 OHM 1/16W +/-5% C221
08-MS82S01-MA300AA 19-GA0330-JTX SMD. RES 33 OHM 1/16W +/-5% R435
08-MS82S01-MA300AA 19-GA0330-JTX SMD. RES 33 OHM 1/16W +/-5% R434
08-MS82S01-MA300AA 19-GA0330-JTX SMD. RES 33 OHM 1/16W +/-5% R433
08-MS82S01-MA300AA 19-GA0330-JTX SMD. RES 33 OHM 1/16W +/-5% R419
08-MS82S01-MA300AA 19-GA0330-JTX SMD. RES 33 OHM 1/16W +/-5% C213
08-MS82S01-MA300AA 19-GA0330-JTX SMD. RES 33 OHM 1/16W +/-5% R311
08-MS82S01-MA300AA 19-GA0330-JTX SMD. RES 33 OHM 1/16W +/-5% R310
08-MS82S01-MA300AA 19-GA0330-JTX SMD. RES 33 OHM 1/16W +/-5% R309
08-MS82S01-MA300AA 19-GA0472-JTX SMD. RES 4.7K OHM 1/16W +/-5% R544
08-MS82S01-MA300AA 19-GA0473-JTX SMD.RES 47K OHM 1/16W +/-5% R449
08-MS82S01-MA300AA 19-GA0473-JTX SMD.RES 47K OHM 1/16W +/-5% R642
08-MS82S01-MA300AA 19-GA0510-JTX R-SMD 51OHM +/-5% 1/16W 0402 - C219
08-MS82S01-MA300AA 19-GA0510-JTX R-SMD 51OHM +/-5% 1/16W 0402 - C218
08-MS82S01-MA300AA 19-GA0511-JTX SMD.RES 0402 1/16W 510 OHM +/-5% R411
08-MS82S01-MA300AA 19-GA0680-JTX SMD.RES 68 OHM 1/16W +/-5% R531
08-MS82S01-MA300AA 19-GA0680-JTX SMD.RES 68 OHM 1/16W +/-5% R532
08-MS82S01-MA300AA 19-GA0680-JTX SMD.RES 68 OHM 1/16W +/-5% R553
08-MS82S01-MA300AA 19-GA0680-JTX SMD.RES 68 OHM 1/16W +/-5% R409
08-MS82S01-MA300AA 19-GA0680-JTX SMD.RES 68 OHM 1/16W +/-5% R405
08-MS82S01-MA300AA 19-GA0682-JTX SMD.RES 6800 OHM 1/16W +/-5% R361
08-MS82S01-MA300AA 19-GA0682-JTX SMD.RES 6800 OHM 1/16W +/-5% R605
08-MS82S01-MA300AA 19-GA0682-JTX SMD.RES 6800 OHM 1/16W +/-5% R609
08-MS82S01-MA300AA 19-GA0682-JTX SMD.RES 6800 OHM 1/16W +/-5% R360
08-MS82S01-MA300AA 19-GA0473-JTX SMD.RES 47K OHM 1/16W +/-5% R448
08-MS82S01-MA300AA 19-GA0472-JTX SMD. RES 4.7K OHM 1/16W +/-5% R543
08-MS82S01-MA300AA 19-GA0472-JTX SMD. RES 4.7K OHM 1/16W +/-5% R542
08-MS82S01-MA300AA 19-GA0472-JTX SMD. RES 4.7K OHM 1/16W +/-5% R518
08-MS82S01-MA300AA 19-GA0472-JTX SMD. RES 4.7K OHM 1/16W +/-5% R507
08-MS82S01-MA300AA 19-GA0472-JTX SMD. RES 4.7K OHM 1/16W +/-5% R502
08-MS82S01-MA300AA 19-GA0472-JTX SMD. RES 4.7K OHM 1/16W +/-5% R460
08-MS82S01-MA300AA 19-GA0472-JTX SMD. RES 4.7K OHM 1/16W +/-5% R458
08-MS82S01-MA300AA 19-GA0472-JTX SMD. RES 4.7K OHM 1/16W +/-5% R456
08-MS82S01-MA300AA 19-GA0472-JTX SMD. RES 4.7K OHM 1/16W +/-5% R214
08-MS82S01-MA300AA 19-GA0472-JTX SMD. RES 4.7K OHM 1/16W +/-5% R213
08-MS82S01-MA300AA 19-GA0472-JTX SMD. RES 4.7K OHM 1/16W +/-5% R189
08-MS82S01-MA300AA 19-GA0472-JTX SMD. RES 4.7K OHM 1/16W +/-5% R183
08-MS82S01-MA300AA 19-GA0229-JTX SMD.RES 1/16W 2.2 OHM ±5% R338
08-MS82S01-MA300AA 19-GA0103-JTX SMD. RES 10K OHM 1/16W +/-5% R418
08-MS82S01-MA300AA 19-GA0103-JTX SMD. RES 10K OHM 1/16W +/-5% R417
08-MS82S01-MA300AA 19-GA0103-JTX SMD. RES 10K OHM 1/16W +/-5% R404
08-MS82S01-MA300AA 19-GA0103-JTX SMD. RES 10K OHM 1/16W +/-5% R403
08-MS82S01-MA300AA 19-GA0103-JTX SMD. RES 10K OHM 1/16W +/-5% R363
08-MS82S01-MA300AA 19-GA0103-JTX SMD. RES 10K OHM 1/16W +/-5% R362
08-MS82S01-MA300AA 19-GA0103-JTX SMD. RES 10K OHM 1/16W +/-5% R304
08-MS82S01-MA300AA 19-GA0103-JTX SMD. RES 10K OHM 1/16W +/-5% R303
08-MS82S01-MA300AA 19-GA0103-JTX SMD. RES 10K OHM 1/16W +/-5% R302

08-MS82S01-MA300AA 19-GA0103-JTX SMD. RES 10K OHM 1/16W +/-5% R301
08-MS82S01-MA300AA 19-GA0104-JTX SMD. RES 100K OHM 1/16W +/-5% R552
08-MS82S01-MA300AA 19-GA0104-JTX SMD. RES 100K OHM 1/16W +/-5% R164
08-MS82S01-MA300AA 19-GA0104-JTX SMD. RES 100K OHM 1/16W +/-5% R619
08-MS82S01-MA300AA 19-GA0104-JTX SMD. RES 100K OHM 1/16W +/-5% R406
08-MS82S01-MA300AA 19-GA0103-JTX SMD. RES 10K OHM 1/16W +/-5% R431
08-MS82S01-MA300AA 19-GA0103-JTX SMD. RES 10K OHM 1/16W +/-5% R554
08-MS82S01-MA300AA 19-GA0103-JTX SMD. RES 10K OHM 1/16W +/-5% R537
08-MS82S01-MA300AA 19-GA0103-JTX SMD. RES 10K OHM 1/16W +/-5% R506
08-MS82S01-MA300AA 19-GA0103-JTX SMD. RES 10K OHM 1/16W +/-5% R461
08-MS82S01-MA300AA 19-GA0103-JTX SMD. RES 10K OHM 1/16W +/-5% R459
08-MS82S01-MA300AA 19-GA0103-JTX SMD. RES 10K OHM 1/16W +/-5% R457
08-MS82S01-MA300AA 19-GA0103-JTX SMD. RES 10K OHM 1/16W +/-5% R445
08-MS82S01-MA300AA 19-GA0103-JTX SMD. RES 10K OHM 1/16W +/-5% R442
08-MS82S01-MA300AA 19-GA0103-JTX SMD. RES 10K OHM 1/16W +/-5% R440
08-MS82S01-MA300AA 19-GA0103-JTX SMD. RES 10K OHM 1/16W +/-5% R437
08-MS82S01-MA300AA 19-GA0103-JTX SMD. RES 10K OHM 1/16W +/-5% R436
08-MS82S01-MA300AA 19-GA0103-JTX SMD. RES 10K OHM 1/16W +/-5% R432
08-MS82S01-MA300AA 19-GA0104-JTX SMD. RES 100K OHM 1/16W +/-5% R407
08-MS82S01-MA300AA 19-GA0220-JTX SMD. RES 22 OHM 1/16W +/-5% R413
08-MS82S01-MA300AA 19-GA0220-JTX SMD. RES 22 OHM 1/16W +/-5% R451
08-MS82S01-MA300AA 19-GA0221-JTX SMD. RES 220 OHM 1/16W +/-5% R364
08-MS82S01-MA300AA 19-GA0223-JTX SMD. RES 22K OHM 1/16W +/-5% R446
08-MS82S01-MA300AA 19-GA0223-JTX SMD. RES 22K OHM 1/16W +/-5% R186
08-MS82S01-MA300AA 19-GA0223-JTX SMD. RES 22K OHM 1/16W +/-5% R348
08-MS82S01-MA300AA 19-GA0223-JTX SMD. RES 22K OHM 1/16W +/-5% R646
08-MS82S01-MA300AA 19-GA0223-JTX SMD. RES 22K OHM 1/16W +/-5% R644
08-MS82S01-MA300AA 19-GA0223-JTX SMD. RES 22K OHM 1/16W +/-5% R611
08-MS82S01-MA300AA 19-GA0223-JTX SMD. RES 22K OHM 1/16W +/-5% R603
08-MS82S01-MA300AA 19-GA0223-JTX SMD. RES 22K OHM 1/16W +/-5% R443
08-MS82S01-MA300AA 19-GA0223-JTX SMD. RES 22K OHM 1/16W +/-5% R441
08-MS82S01-MA300AA 19-GA0223-JTX SMD. RES 22K OHM 1/16W +/-5% R412
08-MS82S01-MA300AA 19-GA0223-JTX SMD. RES 22K OHM 1/16W +/-5% R356
08-MS82S01-MA300AA 19-GA0220-JTX SMD. RES 22 OHM 1/16W +/-5% R414
08-MS82S01-MA300AA 19-GA0121-JTX SMD.RES 120 OHM 1/16W +/-5% R365
08-MS82S01-MA300AA 19-GA0123-JTX SMD. RES 12K OHM 1/16W +/-5% R307
08-MS82S01-MA300AA 19-GA0123-JTX SMD. RES 12K OHM 1/16W +/-5% R318
08-MS82S01-MA300AA 19-GA0123-JTX SMD. RES 12K OHM 1/16W +/-5% R322
08-MS82S01-MA300AA 19-GA0123-JTX SMD. RES 12K OHM 1/16W +/-5% R308
08-MS82S01-MA300AA 19-GA0151-JTX R-SMD 150R0OHM 5% 1/16W 0402 - R343
08-MS82S01-MA300AA 19-GA0153-JTX R-SMD 15K0OHM 5% 1/16W 0402 - R645
08-MS82S01-MA300AA 19-GA0181-JTX SMD. RES 180 OHM 1/16W +/-5% R341
08-MS82S01-MA300AA 19-GA0182-JTX SMD.RES 1800 OHM 1/16W +/-5% R185
08-MS82S01-MA300AA 19-GA0220-JTX SMD. RES 22 OHM 1/16W +/-5% R450
08-MS82S01-MA300AA 19-GA0220-JTX SMD. RES 22 OHM 1/16W +/-5% R439
08-MS82S01-MA300AA 19-GA0220-JTX SMD. RES 22 OHM 1/16W +/-5% R438
08-MS82S01-MA300AA 19-GA0220-JTX SMD. RES 22 OHM 1/16W +/-5% R422
08-MS82S01-MA300AA 19-GA0220-JTX SMD. RES 22 OHM 1/16W +/-5% R421
08-MS82S01-MA300AA 19-GA0102-JTX SMD. RES 1K OHM 1/16W +/-5% R649
08-MS82S01-MA300AA 19-GA0103-JTX SMD. RES 10K OHM 1/16W +/-5% R660
08-MS82S01-MA300AA 19-GA0102-JTX SMD. RES 1K OHM 1/16W +/-5% R653
08-MS82S01-MA300AA 19-GA0102-JTX SMD. RES 1K OHM 1/16W +/-5% R654
08-MS82S01-MA300AA 19-GA0103-JTX SMD. RES 10K OHM 1/16W +/-5% R656
08-MS82S01-MA300AA 19-GA0103-JTX SMD. RES 10K OHM 1/16W +/-5% R657
08-MS82S01-MA300AA 19-GA0332-JTX SMD. RES 3.3K OHM 1/16W +/-5% R658
08-MS82S01-MA300AA 19-GA0332-JTX SMD. RES 3.3K OHM 1/16W +/-5% R659
08-MS82S01-MA300AA 19-GA0333-JTX SMD. RES 33K OHM 1/16W +/-5% R650

08-MS82S01-MA300AA 19-GA0333-JTX SMD. RES 33K OHM 1/16W +/-5% R651
08-MS82S01-MA300AA 19-GA0333-JTX SMD. RES 33K OHM 1/16W +/-5% R652
08-MS82S01-MA300AA 19-GA0333-JTX SMD. RES 33K OHM 1/16W +/-5% R655
08-MS82S01-MA300AA 25-TCB101-M1X CAP.ELE 5.0MM 100UF 16V 6.3*7 105 LELON C643
08-MS82S01-MA300AA 28-AA0105-KBX CAP.CER,SMD 1UF 10V 0603 -- +/-10% R=Y C641
08-MS82S01-MA300AA 28-AA0105-KBX CAP.CER,SMD 1UF 10V 0603 -- +/-10% R=Y C644
08-MS82S01-MA300AA 28-AA0225-KBX CAP.CER,SMD 2U2F 10V DCV 0603 - C634
08-MS82S01-MA300AA 28-AA0225-KBX CAP.CER,SMD 2U2F 10V DCV 0603 - C635
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C649
08-MS82S01-MA300AA 28-HB0102-KBX CAP.CER,SMD 1N0F 50V DCV 0402 - C645
08-MS82S01-MA300AA 28-HB0151-JCX CAPACITORS 0402 50V 150P ±5% C640
08-MS82S01-MA300AA 28-HB0151-JCX CAPACITORS 0402 50V 150P ±5% C646
08-MS82S01-MA300AA 28-HB0152-KBX 0402 CHIP CAPACITORS 50VDC 1500PF +/-10% C636
08-MS82S01-MA300AA 28-HB0152-KBX 0402 CHIP CAPACITORS 50VDC 1500PF +/-10% C639
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C642
08-MS82S01-MA300AA 47-EAR030-XX0 AV SOCKET R NO MSJ-1637-AG-PBT(B225) P603
08-MS82S01-MA300AA 28-HC0473-KBX CAP.CER,SMD 47NF 16V 0402 - C515
08-MS82S01-MA300AA 28-HC0223-KBX CAP.CER,SMD 22N0F 16V DCV 0402 - C516
08-MS82S01-MA300AA 19-GA0000-JTX SMD. RES 0 OHM 1/16W +/-5% R612
08-MS82S01-MA300AA 28-HB0470-JCX CAP.CER,SMD 47PF 50V 0402 - C647
08-MS82S01-MA300AA 19-GA0102-JTX SMD. RES 1K OHM 1/16W +/-5% R648
08-MS82S01-MA300AA 19-GA0101-JTX SMD. RES 100 OHM 1/16W +/-5% R662
08-MS82S01-MA300AA 13-DRV632-00B IC 2-VRMS AUDIO LINE DRIVER DRV632 U602
08-MS82S01-MA300AA 19-GA0153-JTX R-SMD 15K0OHM 5% 1/16W 0402 - R628
08-MS82S01-MA300AA 19-AB0222-JTX RES SMD 2.2K OHM 1/10W 0603 R627
08-MS82S01-MA300AA 33-NLL220-MTX IND-SMD 0.1OHM 40 1.7A SMD VLC6045T L611
08-MS82S01-MA300AA 33-NLL220-MTX IND-SMD 0.1OHM 40 1.7A SMD VLC6045T L609
08-MS82S01-MA300AA 33-NLL220-MTX IND-SMD 0.1OHM 40 1.7A SMD VLC6045T L607
08-MS82S01-MA300AA 33-NLL220-MTX IND-SMD 0.1OHM 40 1.7A SMD VLC6045T L605
08-MS82S01-MA300AA 13-TPA311-D2B IC MT23H AUDIO POWER AMPLIFIER BULK 28 P U601
08-MS82S01-MA300AA 19-GA0101-JTX SMD. RES 100 OHM 1/16W +/-5% R149
08-MS82S01-MA300AA 28-HB0470-JCX CAP.CER,SMD 47PF 50V 0402 - C648
08-MS82S01-MA300AA 25-TFB220-M1X CAP.ELE 5MM 22UF 50V 6.3 * 7 105 CD70H C637
08-MS82S01-MA300AA 13-MN6E18-2VB IC LCD TV MS82S CHASSIS SOC/MST6E182VS M U500
08-MS82S01-MA300AA 13-T6633E-00B IC 3 TO 1 HDMI SWITCH IT6633E-P U400
08-MS82S01-MA300AA 09-LL4148-ATX SMD. SWITCHING DIODE LL4148 D603
08-MS82S01-MA300AA 12-BT3904-0BX TR-SMD NPN 40VV 200MA_A 300HZ 0.25W SOT2 Q606
08-MS82S01-MA300AA 19-BC0100-JTX SMD. RES 10 OHM 1/8W +/-5% R623
08-MS82S01-MA300AA 19-BC0100-JTX SMD. RES 10 OHM 1/8W +/-5% R624
08-MS82S01-MA300AA 19-BC0100-JTX SMD. RES 10 OHM 1/8W +/-5% R625
08-MS82S01-MA300AA 19-BC0100-JTX SMD. RES 10 OHM 1/8W +/-5% R626
08-MS82S01-MA300AA 28-HB0331-KBX SMD. CAP 330 PF 50V +/-10% 0402 C626
08-MS82S01-MA300AA 28-HB0331-KBX SMD. CAP 330 PF 50V +/-10% 0402 C628
08-MS82S01-MA300AA 28-HB0331-KBX SMD. CAP 330 PF 50V +/-10% 0402 C630
08-MS82S01-MA300AA 28-HB0331-KBX SMD. CAP 330 PF 50V +/-10% 0402 C632
08-MS82S01-MA300AA 19-GA0103-JTX SMD. RES 10K OHM 1/16W +/-5% R665
08-MS82S01-MA300AA 19-GA0682-JTX SMD.RES 6800 OHM 1/16W +/-5% R608
08-MS82S01-MA300AA 19-GA0101-JTX SMD. RES 100 OHM 1/16W +/-5% R312
08-MS82S01-MA300AA 19-GA0101-JTX SMD. RES 100 OHM 1/16W +/-5% R300
08-MS82S01-MA300AA 19-GA0472-JTX SMD. RES 4.7K OHM 1/16W +/-5% R664
08-MS82S01-MA300AA 19-GA0472-JTX SMD. RES 4.7K OHM 1/16W +/-5% R663
08-MS82S01-MA300AA 19-GA0472-JTX SMD. RES 4.7K OHM 1/16W +/-5% R666
08-MS82S01-MA300AA 19-GA0101-JTX SMD. RES 100 OHM 1/16W +/-5% R667
08-MS82S01-MA300AA 19-GA0102-JTX SMD. RES 1K OHM 1/16W +/-5% R615
08-MS82S01-MA300AA 19-GA0682-JTX SMD.RES 6800 OHM 1/16W +/-5% R604
08-MS82S01-MA300AA 33-KLN121-NTX CHIP BEAD 120 OHM +/-25% L401
08-MS82S01-MA300AA 25-TCS221-M1X CAP.ELE 3.5MM 220UF 16V 8*7 105 LELON C108

08-MS82S01-MA300AA 19-GA0472-JTX SMD. RES 4.7K OHM 1/16W +/-5% R166
08-MS82S01-MA300AA 19-GA0221-JTX SMD. RES 220 OHM 1/16W +/-5% R178
08-MS82S01-MA300AA 19-GA0103-JTX SMD. RES 10K OHM 1/16W +/-5% R165
08-MS82S01-MA300AA 28-HC0104-KBX CAP.CER,SMD 100NF 16V 0402 - C157
08-MS82S01-MA300AA 33-KLL108-MTA IND-SMD 0.1UH 10% 0.05A 15 1608(0603) 0. L209
08-MS82S01-MA300AA 13-DRK4T5-JBB IC DDR2 SDRAM K4T51163QJ-BCF7 U501
08-MS82S01-MA300AA 13-EN25Q3-2BBEO IC 32M BIT SERIAL FLASH EN25Q32B U502(CPP)
08-MS82S01-MA300AA 40-MS82S0-MAD2XG PCB MA 161.5X246.5MM 2PC DOUBLESIDED 1.6
08-MS82S01-MA300AA 33-KLN330-NJX FB-SMD -OHM -% -A -OHM 1608（0603） - L109
08-MS82S01-MA300AA 33-KLN330-NJX FB-SMD -OHM -% -A -OHM 1608（0603） - L108
08-MS82S01-MA300AA 33-KLN330-NJX FB-SMD -OHM -% -A -OHM 1608（0603） - L112
08-MS82S01-MA300AA 33-KLN330-NJX FB-SMD -OHM -% -A -OHM 1608（0603） - L114
08-MS82S01-MA300AA 46-40336W-06XG CONN PH 6 2.0MM FEMALE R P502
08-MS82S01-MA300AA 19-GA0101-JTX SMD. RES 100 OHM 1/16W +/-5% R512
08-MS82S01-MA300AA 19-GA0101-JTX SMD. RES 100 OHM 1/16W +/-5% R511
08-MS82S01-MA300AA 19-GA0101-JTX SMD. RES 100 OHM 1/16W +/-5% R510
08-MS82S01-MA300AA 13-W9751G-6JB IC DDR2 SDRAM W9751G6JB-25 U501
08-MS82S01-MA300AA 07-380FI5-NAJG TUNER A PAL 38HZ IEC SIDE F35WT-3-E TU1
08-MS82S01-MA200AA 71-LC0913-001 LABEL
08-MS82S01-MA200AA 71-PHIBAR-NUL01 PRI LABEL BARCODE -- R=Y
H3-42E53E3-SRNC0AA 08-42E5300-LPC001A LVF420AUTM E20 V1
08-42E5300-LPC001A 08-32E5301-SW300AA 开关板组件
08-32E5301-SW300AA 40-E5300A-SWA2XG PCB UL 124.8X127MM 32PC DOUBLESIDED 1.6M
08-32E5301-SW300AA 46-GHSR01-02SG CONN SMT 2 1.25MM FEMALE WH ST P1
08-42E5300-LPC001A 08-42E5305-RC200AA ASS'Y - REAR CABINET
08-42E5305-RC200AA 55-933640-3HL6R RAW BACKCOVER 42E5300 -- 00 00 00 R=N
08-42E5300-LPC001A 08-42E5314-FC200AA ASS'Y - FRONT CABINET
08-42E5314-FC200AA 67-L71621-4N002 DEC LOGO TCL 8.9MM 04 00 00 R=Y
08-42E5314-FC200AA 63-B2004T-BF4G SCREW-ST 2MM 4MM ISO R=Y
08-42E5314-FC200AA 48-MTD010-XX0 SWITCH DOME FOR KEYS 939010
08-42E5314-FC200AA 57-463420-00001 DEC DECOR BAR -- 00 00 00 R=Y
08-42E5314-FC200AA 54-934470-500 SPONGE STRIPE -- R=Y
08-42E5314-FC200AA 54-934480-500 SPONGE STRIPE -- R=Y
08-42E5314-FC200AA 89-0AS003-PF006 SUNDRIES-TAPE ADHESIVE 6MM*0.05MM*100MMM
08-42E5314-FC200AA 55-933630-6UK1G RAW FRONTPANEL 42E5300 -- 00 00 00 R=Y
08-42E5300-LPC001A 08-AU42TML-LC219AA LVF420AUTM E20 --42E5300搭配 T420HW09 V2 O
08-AU42TML-LC219AA 08-42LEDTM-BL401AE 42E5300-AAUO 09V2 CELL
08-42LEDTM-BL401AE 64-B30060-104G M/C SCREW B 3 X 6
08-42LEDTM-BL401AE 63-A3012T-BF5G SCREW-ST 3MM 8MM ISO R=Y
08-42LEDTM-BL401AE 54-939060-000 SPONGE STRIPE -- R=Y
08-42LEDTM-BL401AE 54-936150-000 RAW ADHESIVE TAPE 3M8805/8810 R=Y
08-42LEDTM-BL401AE 4C-LP420P-DT1 LGP PRINT 3MM X_475.16MM 946.24MM
08-42LEDTM-BL401AE 4C-LB4252-UN1 LIGHTBAR SIDE IN 42INCH 20.5W 52LEDS R=Y
08-42LEDTM-BL401AE 4C-KF420T-SH1 FILM DIFFUSER 0.21MM 539.26MM 945.24MM
08-42LEDTM-BL401AE 4C-DF420T-3M3 FILM DBEF 42INCH 0.34MM 945.2MM 539.76MM
08-42LEDTM-BL401AE 46-DF150L-10X01G WIRE CABLE 1500+600MM 6PIN A2004 A1002
08-42LEDTM-BL401AE 4C-RF420T-JF3 FILM REFLECTOR 42INCHINCH 3MM 945MM 540M
08-42LEDTM-BL401AE 4C-LP420P-DT2 LGP PRINT 3 X_475.16MM 946.24MM R=Y
08-42LEDTM-BL401AE 63-V3008T-BF5G SCREW-ST 3MM 12MM ISO 19 R=Y
08-42LEDTM-BL401AE 4C-KF420T-TX1 FILM REFLECTOR 42INCH 0.215MM 539.26MM 9
08-42LEDTM-BL401AE 54-939060-000 SPONGE STRIPE -- R=Y
08-42LEDTM-BL401AE 4C-PF420T-SH8 FILM PRISM 42INCH 0.285MM 945.24MM 539.2
08-42LEDTM-BL401AE 67-H93412-1A0 RAW HEATSINK 42E5300 00 00 R=Y
08-42LEDTM-BL401AE 67-M93409-0E0 TV RAW SPRING CLUTCH R=Y
08-AU42TML-LC219AA 08-AU42CFN-OC401AA 42寸AUO T420HW09 V2 OPENCELL组件
08-AU42CFN-OC401AA 4A-LCD42O-AU5 42INCH 60HZ FHD T420HW09 V2 OPENCELL
08-AU42CFN-OC401AA 02-TCNC13-XX0 OCA AUO T420HW09 V2 OPENCELL TCON 55.42

08-AU42CFN-OC401AA 02-TCNC13-TD1 AUO T420HW09 V2 OPENCELL TCON -WITH FFC
08-AU42TML-LC219AA 46-YY008C-60Z01G WIRE FFC 75MM 60PIN 0.5 0.5 0.5MM UL2086
08-AU42TML-LC219AA 08-42E5312-MC200AA 42E5300MID-FRAME
08-42E5312-MC200AA 62-933710-2UFG RAW SUPPORT PLASTIC-FRAME-B -- 00 00 00
08-42E5312-MC200AA 62-933700-1UFG RAW SUPPORT PLASTIC-FRAME-T -- 00 00 00
08-42E5312-MC200AA 62-933690-3UFG RAW SUPPORT PLASTIC-FRAME-R -- 00 00 00
08-42E5312-MC200AA 62-933680-3UFG RAW SUPPORT PLASTIC-FRAME-L -- 00 00 00
08-42E5312-MC200AA 59-934530-000 RAW BUFFER 42E5300 0 0 R=Y
08-42E5312-MC200AA 59-934500-000 RAW BUFFER 42E5300 0 0 R=Y
08-42E5312-MC200AA 59-959830-100 RAW BUFFER BUBBER UD 0 0 R=Y
08-42E5300-LPC001A 71-L42E53-PIN1H PRI LABEL LABEL -- R=Y
08-42E5300-LPC001A 71-BAR011-0A9 TV PRI LABEL -- WHITE & BLACK R=Y
08-42E5300-LPC001A 63-B3008T-BF4G SCREW-ST 3MM 8MM ISO R=Y
08-42E5300-LPC001A 89-BX8915-JZ0U SUNDRIES-TAPE ADHESIVE 18MMX55M -­H3-42E53E3-SRNC0AA 08-42E5300-KE300AA ASS'Y - KEY BD
08-42E5300-KE300AA 48-TAC001-DX0 TACT SWITCH KQS-902 K4
08-42E5300-KE300AA 48-TAC001-DX0 TACT SWITCH KQS-902 K5
08-42E5300-KE300AA 48-TAC001-DX0 TACT SWITCH KQS-902 K2
08-42E5300-KE300AA 48-TAC001-DX0 TACT SWITCH KQS-902 K3
08-42E5300-KE300AA 48-TAC001-DX0 TACT SWITCH KQS-902 K1
08-42E5300-KE300AA 48-TAC001-DX0 TACT SWITCH KQS-902 K6
08-42E5300-KE300AA 46-GHSS02-04SG CONN SMT 4 1.25MM FEMALE WHITE R P1
08-42E5300-KE300AA 19-AB0471-FTX RES SMD 470 OHM 1/10W +/-1% 0603 R2
08-42E5300-KE300AA 19-AB0471-FTX RES SMD 470 OHM 1/10W +/-1% 0603 R1
08-42E5300-KE300AA 19-AB0471-FTX RES SMD 470 OHM 1/10W +/-1% 0603 R7
08-42E5300-KE300AA 19-AB0471-FTX RES SMD 470 OHM 1/10W +/-1% 0603 R3
08-42E5300-KE300AA 19-AB0471-FTX RES SMD 470 OHM 1/10W +/-1% 0603 R4
08-42E5300-KE300AA 19-AB0471-FTX RES SMD 470 OHM 1/10W +/-1% 0603 R6
08-42E5300-KE300AA 19-AB0471-FTX RES SMD 470 OHM 1/10W +/-1% 0603 R5
08-42E5300-KE300AA 46-GHSS02-02SG CONN SMT 2 1.25MM FEMALE WH R P2
08-42E5300-KE300AA 19-AB0472-JTX RES SMD 4.7K OHM 1/10W 0603 R9
08-42E5300-KE300AA 19-AB0221-JTX RES SMD 220 OHM 1/10W 0603 R8
08-42E5300-KE300AA 12-BT3906-0BX TR-SMD PNP 40V 200MI0_A 250MHZ 225MI0W S Q1
08-42E5300-KE300AA 46-GHSS02-02SG CONN SMT 2 1.25MM FEMALE WH R P3
08-42E5300-KE300AA 40-E5300A-KEC2XG PCB UL 141.5 X 121.5 MM 11PC DOUBLESIDED
H3-42E53E3-SRNC0AA 08-42E5300-IR300AA ASS'Y - INFRARED RECEIVE BD
08-42E5300-IR300AA 28-BA0106-KBX CAP.CER,SMD 10U0F 10V DCV 0805 - C3
08-42E5300-IR300AA 46-GHSS02-07SG CONN SMT 7 1.25MM FEMALE WH R P1
08-42E5300-IR300AA 19-AB0220-JTX SMD RES 22 OHM 1/10W 0603 R1
08-42E5300-IR300AA 19-AB0101-JTX RES SMD 100 OHM 1/10W 0603 R3
08-42E5300-IR300AA 28-AB0104-KBX CAP.CER,SMD 100NF 50.0V 0603 - +/-10% R= C2
08-42E5300-IR300AA 02-IRR012-XX2 IR RECEIVER 38KHZ 2.7V HS0038S4 G1
08-42E5300-IR300AA 40-E5300A-IRC2XG PCB UL 134.5X135MM 40PC DOUBLESIDED 1.6M
H3-42E53E3-SRNC0AA 62-934270-0UN RAW SUPPORT 42E5300 POWER -- 0UN 00 00 R
H3-42E53E3-SRNC0AA 58-LE53MP-JKL1E PRI OVERLAY REAR WARNING -- 00 00 00 R=Y
H3-42E53E3-SRNC0AA 58-906090-JKL1R RAW OVERLAY SIDE AV (RIGHT) -- 00 00 00
H3-42E53E3-SRNC0AA 58-906080-JKL1T RAW OVERLAY SIDE AV (DOWN) -- 00 00 00 R
H3-42E53E3-SRNC0AA 56-934660-0VH02 DEC SUPPORT STAND NECK -- 00 00 00 R=N
H3-42E53E3-SRNC0AA 56-934290-0VH01 PRI LENS IR -- 00 00 00 R=N
H3-42E53E3-SRNC0AA 56-933670-0HZ6R DEC COVER SOURCE COVER R -- 00 00 00 R=
H3-42E53E3-SRNC0AA 56-933660-0HZ6R DEC COVER SOURCE COVER L -- 00 00 00 R=N
H3-42E53E3-SRNC0AA 56-910940-0HQL1 PRI COVER STAND COVER -- 00 00 00 R=N
H3-42E53E3-SRNC0AA 56-898140-1HA1C DEC SUPPORT KEY CLUSTER -- 00 00 00 R=N
H3-42E53E3-SRNC0AA 56-898130-1HA6R RAW KEY CLUSTER L19P31 R=N
H3-42E53E3-SRNC0AA 55-933650-2HZ6R DEC BACKCOVER 42E5300A/MS99 -- 00 00 00
H3-42E53E3-SRNC0AA 54-808040-0U0 SPONGE -- 1000MM X_10MM 1.5MM 0MM R=N
H3-42E53E3-SRNC0AA 54-808040-0U0 SPONGE -- 1000MM X_10MM 1.5MM 0MM R=N

H3-42E53E3-SRNC0AA 54-717920-0X0 FELT TAPE
H3-42E53E3-SRNC0AA 51-DCN180-0AR0FG POWER CORD BS 8字尾 2 1800MM H03VVH2-F 0.7
H3-42E53E3-SRNC0AA 49-R03P80-BAT BATTERY 1.5V
H3-42E53E3-SRNC0AA 49-911100-1001A RAW STAND BASE -- 00 00 00 R=Y
H3-42E53E3-SRNC0AA 54-903400-000 RAW CLOTH FLOCKED FABRIC -- 00 00 00 R=Y
H3-42E53E3-SRNC0AA 67-M93406-5G0 RAW SUPPORT CHISSIS-METAL-SHEET -- 00 00
H3-42E53E3-SRNC0AA 06-RC3000M-RM2FCAA RCT OR BLACK 3VV 小于50MAA 小于3UAA 0
H3-42E53E3-SRNC0AA 47-PWS041-DX7 SOCKET 150MM R N SA-2S-453-14-GP
