Taylor 518 User Manual

Digital Folding
Probe Thermometer

518

Leading the Way in Accuracy

Instruction Manual

®

The Connoisseur Series thermometers by Taylor® represent the epitome of
precision accuracy, innovation, style and heritage. Since 1851, Taylor®
has crafted precision measurement instruments with unmatched accuracy
and readability for optimal performance. We combine that with a distinc­tive new style for a professional thermometer that delivers quality...day
after day...season after season.

Please read this instruction manual carefully before use. Keep these
instructions handy for future reference.

Battery Information

The thermometer operates on 2 AAA batteries (installed). If readings
grow dim or irregular, the batteries may need to be replaced. To replace
the batteries:

1. Use 2- AAA batteries. Always replace both batteries at the same time;
do not combine old and new batteries. Do not mix Alkaline, carbon­zinc (standard) or Nickel- Cadmium (rechargeable) batteries.

2. Unscrew the 2 screws securing the battery compartment cover, locat­ed on the back of the unit. Take care not to misplace the screws.

3. Place the batteries into the compartment as indicated by the polarity
symbols marked inside the battery compartment.

4. Replace the battery compartment cover and screws.

General Operation

1. Preheat the oven to desired cooking temperature. Place the food in
the preheated oven.

2. Sterilize the metal probe by inserting it into an appropriate solution
such as boiling water for several minutes.

3. Press the “Enter” button to turn the unit on. The LCD screen will turn
on and display the current probe temperature.

4. Your thermometer is preset to read temperatures in Fahrenheit. To
switch to Celsius, press and hold the “°F/°C” button for 3 seconds.

5. Press the “Enter” button to access the Meat Selection screen. The
default setting “Beef Rare140.0°F” appears. The temperature digits
flash.

6. Press the
preprogrammed target temperatures. (See Meat/Temperature Chart.)

▲ or ▼ button to scroll though the 16 meat types and their

7. Press “Enter” to select the displayed meat type. The LCD screen
returns to the current temperature display. The name of the selected
meat appears above the temperature reading.

8. To test the internal temperature of the food, unfold the metal probe
and insert it into the thickest part of the food. Do not come in contact
with bone, fat or gristle, as these areas will not provide accurate tem­perature readings. Take care when moving the probe into position to
avoid injury or damage. DO NOT LEAVE THE THERMOMETER IN
THE OVEN WHILE COOKING, AND DO NOT TOUCH THE HOT
PROBE WITH BARE HANDS.

9. The current internal temperature of the food appears on the LCD
screen.

10. Color coded lights behind the Taylor® logo indicate if the current
temperature is lower, higher, or within 5 degrees of the target temper­ature.

• If the temperature is lower than the target temperature, a blue LED
light flashes.

• When the temperature reaches the target temperature, a green LED
light flashes.

• If the temperature is higher than the target temperature, a red LED
light flashes.

(Note: the temperature must be within 30 degrees of the target tempera­ture for the LED lights to activate. Thus, the blue light may not flash,
even if the current temperature is lower than the target temperature.
The current temperature will still appear on the screen.)

11. When the food is ready, remove it from the oven with a heat resist­ant glove. DO NOT TOUCH THE HOT PROBE OR FOOD WITH
YOUR BARE HANDS!

12. The LCD screen has a convenient backlight feature for easy temper­ature viewing. While the unit is on, press the “°F/°C” button to turn on
the backlight for 10 seconds.

13. Press and hold the “Enter” button for 3 seconds to turn the unit off.
Otherwise, the unit will turn off automatically after 10 minutes if no
buttons are pressed and there is no change in temperature.

Note: when the thermometer turns off, its memory will return to the

default setting “Beef Rare 140.0°F”. If the unit turns off before cook­ing is done, repeat the Meat Selection steps listed above to repro­gram the desired target temperature.

14. Wash the metal probe with hot soapy water. Fold the probe into the
closed position for storage. Take care when moving the probe into
position to avoid injury or damage. Clean the thermometer unit by
hand. Do not completely immerse the thermometer in water.

Meat/Temperature Chart

Following is a chart listing the 16 types of meat and their preset temper­atures.

Meat Type Doneness Level Preset Temperatures

Beef Rare* 140°F

Med Rare 145°F
Med 160°F
Med Well 165°F

Well 170°F
Hamburger Well 160°F
Pork Med 160°F

Well 170°F
Poultry White Meat 165°F

Dark Meat 165°F
Lamb Rare* 140°F

Med Rare 145°F

Med

Med Well 165°F

Well 170°F
Ham Well 140°F

*The USDA does NOT recommend RARE 140ºF as a safe eating tem­perature.

160°F

Specifications:

Temperature Range: 16º to 302ºF or -9º to 150ºC
Resolution: 0.1ºF or ºC full range
16 Preprogrammed Meat Types
Battery: 2 AAA (installed)
Auto Shut-Off: After 10 minutes of nonuse
Response Time: 1 second

Care and Precautions

1. Always read instructions thoroughly to ensure that you have the full

benefit of all the unit's features.

2. Sterilize thermometer probe each time before use.

3. Use caution while handling the thermometer. Take care when moving

the probe into position to avoid injury or damage. Always wear a heat
resistant glove when touching the thermometer during or just after
use. DO NOT TOUCH PROBE WITH BARE HANDS!

4. DO NOT immerse the thermometer unit in liquid, or pour liquid direct-

ly on the thermometer unit, as doing so will cause damage to internal
components and void the warranty. If you spill liquid on it, dry it
immediately with a soft, lintfree cloth.

5. DO NOT wash in a dishwasher. This unit is not dishwasher safe.

Damage will void warranty. Wipe clean with a damp cloth. Grease or
other hard-to remove soil can be removed with a scouring pad. DO
NOT clean the unit with abrasive or corrosive materials. This may
scratch the plastic parts and corrode the electronic circuits.

6. DO NOT use this thermometer in a microwave oven.

7. DO NOT tamper with the unit's internal components. Doing so will

invalidate the warranty on this unit and may cause damage. Other
than replacing the batteries, the unit contains no user-serviceable
parts.

8. DO NOT subject the unit to excessive force, shock, dust, temperature

or humidity. This may result in malfunction, shorter electronic life
span, damaged battery and distorted parts.

9. Do not expose the thermometer unit to: water, direct heat, a hot sur-

face or direct sunlight. This may cause damage to the plastic casing
or the electric circuits and components inside.

10. Do not dispose of batteries in fire. Batteries may explode or leak.

Remove the batteries if the thermometer will not be used for a long
period of time.

11. Over- or under- temperature range displays: If the measured tem-

perature is outside the unit’s temperature range of 16º to 302ºF or -9º
to 150ºC, the LCD will show “HH.H” (higher than the temperature
range) or “LL.L” (lower than the temperature range).

One Year Limited Warranty

Taylor® warrants this product to be free from defects in material or
workmanship for one (1) year for the original purchaser from date of
original purchase. It does not cover damages or wear resulting from
accident, misuse, abuse, commercial use, or unauthorized adjustment
and/or repair.
If service is required, do not return to retailer. Should this product
require service (or replacement at our option), please pack the item
carefully and return it prepaid, along with store receipt showing the date
of purchase and a note explaining reason for return to:

Taylor Precision Products

2220 Entrada Del Sol, Suite A

Las Cruces, New Mexico

There are no expressed warranties except as listed above. This warran­ty gives you specific legal rights, and you may have other rights which
vary from state to state.

© 2007 Taylor Precision Products and its affiliated companies, all rights

reserved. Taylor® and Leading the Way in Accuracy® are registered

trademarks of Taylor Precision Products and its affiliated companies. All

88001

USA

rights reserved.

Made to our exact specifications in China.

www.taylorusa.com

518 1.08
