Targus Rechargeable wireless desktop, AMW10US User Manual

Visit our Website at www.targus.com
Features and specifications subject to change without notice.
© 2007 Targus Group International, Inc. and Targus, Inc.

AMW10US / 410-0085-001B

USER GUIDE

rechargeable
wireless
desktop mouse

30

Introduction

Package Contents

• Wireless Rechargeable Mouse

• USB Receiver

• 2 AA NiMH Rechargeable Batteries

• USB Extension Seat

• USB Charge Cable

• User Guide

TARGUS 5-BUTTON

RECHARGEABLE

WIRELESS MOUSE

Congratulations on your purchase of the Targus
5-button Rechargeable Wireless Mouse. This mouse
offers a charge cable to ensure continuous use without
power interruption and an extension seat that allows
connectivity for the receiver and the charge cable. The 4th
& 5th buttons are pre-programmed to provide Internet
Back-ward and Internet Forward under Windows

®

2000/XP.

1

Targus 5-button Rechargeable Wireless Mouse

System Requirements

Hardware

• USB version 1.1 or 2.0 interface

Operating System

• Windows® 2000/XP

Using the Extension Seat

An extension seat is provided to minimize interference
from other wireless devices. This extension seat allows
you to place the receiver closer to your mouse while in
use.

1 Connect the extension seat to an available USB port

on your Desktop PC or Notebook.

2 Plug the receiver into the USB port labeled 'receiver'

located at the top of the seat.

3 Connect the USB end of the charge cable to the port

labeled 'charge' on the extension seat.

• Windows Vista

TM

2

Targus 5-button Rechargeable Wireless Mouse

Your computer’s operating system automatically
detects the new hardware and begins installing the
appropriate drivers.

4 If applicable, follow any on-screen instructions to

complete the driver installation.

F

OR BEST RESULTS, YOU SHOULD CHARGE THE MOUSE VIA THE SUPPLIED USB

CHARGE CABLE FOR AT LEAST 8 HOURS BEFORE USING IT.SEE “CHARGING THE

MOUSE” ON PAGE 7.

Installing the Batteries

1 Remove the battery cover from the bottom of the

mouse by pressing the tab located on the bottom and
lifting it off.

Charge port

computer

Extension seat

To

Charge
cable

Notebook

Desktop

3

Targus 5-button Rechargeable Wireless Mouse

2 2 AA NiMH rechargeable batteries are included. Insert

the supplied batteries, making sure that the positive
(+) and negative (-) ends of each battery match the
polarity indicators inside the battery housing.

WARNINGS: U

SE ONLY HEAVY-DUTY NIMH BATTERIES.NEVER USE

ALKALINE IF YOU INTEND TO USE THE RECHARGING FEAT URE

.

A

VOID MIXING NEW AND USED BATTERIES IN A DEVICE.

3 Slide the battery cover back into position until it

“clicks” firmly into place.

The optical sensor, located on the bottom of the mouse,
glows red.

4
