Targus Optical Mouse User Manual

Mini Trackball

Optical Mouse

Features and specifications are subject to change without notice. © 2003 Targus Corp.

Visit our Web site at: www.targus.com

400-0122-001B

BRUSSELS HANNOVER BARCELONA TOKYO MILANO AMSTERDAM SINGAPORE LONDON PARIS NEW YORK LOS ANGELES TORONTO HONG KONG SYDNEY

USER’S GUIDE

MINI TRACKBALL

OPTICAL MOUSE

Introduction

Congratulations on your purchase of the Targus Mini Trackball
Optical Mouse. This ergonomically designed mouse connects
directly to your computer’s USB port and allows you to:

• Alternate between the trackball and mouse modes, which
ever best suits your needs

• Enhance your Internet browsing capabilities

• Quickly access program feature options supported under the
Windows® operating system

This user’s guide describes how to connect the mouse to your
computer, install the device drivers and personalize the mouse
features.

In addition to this guide, this package contains:

• Targus Mini Trackball Optical Mouse

• Driver software CD-ROM

System Requirements

To use the mouse, your computer must meet the following
hardware requirements and run one of the operating systems
listed.

2

Mini Trackball Optical Mouse

Hardware

• 64 MB RAM or higher, depending on the operating system

• CD-ROM drive

• USB version 1.1 port

Operating System

• Windows® Me/2000/XP

Connecting the Mouse

To connect the mouse to an available USB port, plug the
standard USB end of the cable into an available USB port on
your computer.

You are now ready to install the device drivers for your
operating system.

Installing the Device Drivers

To install the supplied device driver:

1 Turn on your computer.

2 Insert the driver software CD into your computer’s

CD-ROM drive.

3Click Start, Run, then enter D:\Setup.exe (where D:

is the path of your CD-ROM drive) and then click OK.

The Welcome screen appears.

4 Follow the on-screen instructions.

5Click Finish to complete the driver installation and restart

your computer.

Once your computer restarts, the mouse icon appears in the
system tray.

3

Mini Trackball Optical Mouse

Activating the Trackball Feature

The mouse’s default setting is mouse mode, where the
trackball functions as a standard scroll wheel.

To enable the trackball mode:

1 Press and hold down the middle mouse button (the

trackball) and the right mouse button at the same time.

2 Release both buttons.

You are now able to control your cursor by moving the
trackball while the mouse is stationary or held in your hand.

To disable the trackball mode:

1 Press and hold down the middle mouse button (the

trackball) and the left mouse button at the same time.

2 Release both buttons.

NOTE: Turning off your computer or disconnecting and
reconnecting the mouse automatically disables the trackball
mode.

Personalizing the Mouse Features

NOTE: You may have to remove previously installed mouse or
touchpad software from your computer to fully customize the
mouse features.

You can assign functions to the scroll ball and third mouse
button and control cursor movement by personalizing the
mouse features from the Mouse Properties screen. To do this:

1Click Start, Settings and Control Panel.

2 Double-click the Mouse icon.

The Mouse Properties screen appears.

4
