USER’S GUIDE

®

TARGUS WIRELESS

CALCULATOR KEYPAD

Introduction

Congratulations on your purchase of a Targus Wireless
Calculator Keypad.This wireless calculator/keypad
combines special Tax, Euro and Currency rate calculating
functions. The keypad is designed with a built-in cavity to
store the USB receiver, eliminating the potential
misplacement of the receiver and to provide ease of
traveling with the keypad.

Contents

In addition to this user’s guide, this package contains:

› Targus Wireless Calculator Keypad

› USB Receiver

› USB extension cable

› 2 AAA batteries

System Requirements

To use the calculator/keypad, your computer must meet the
following hardware requirements and run one of the
operating systems listed below.

Hardware

• PC with an Intel® Pentium® processor or equivalent

• USB 1.1 or 2.0 interface

Operating System

•Windows® 98/Me/2000/XP

2

Targus Wireless Calculator Keypad

Installing the Batteries

Receiver

Battery

Cover

Calculator/Keypad - back view

1 Remove the battery cover from the back of the keypad.

2 Insert the supplied batteries, making sure that the

positive (+) and negative (-) ends of each battery match
the polarity indicators inside the battery housing.

WARNINGS: When replacing the batteries, you may use
alkaline or other heavy-duty NiMH batteries. Never
combine an alkaline with a NiMH battery in a device.

Avoid mixing new and used batteries in a device.

3 Slide the battery cover back into position until it “clicks”

firmly into place.

3

Targus Wireless Calculator Keypad

Connecting the Receiver and
Installing the Default Drivers

To connect the receiver:

1 Remove the receiver from the back of the keypad.

2 Plug the USB receiver into an available USB port on

your computer.

For Windows® 98, follow any on-screen instructions to
complete the default driver installation.

For Windows® Me/2000/XP, the “Found New
Hardware” or “Auto-detect of a HID device” message
will appear to indicate the installation of the default
driver.

NOTE: You may need to establish a communication link

between the keypad and the receiver. See “Establishing

a Communications Link” on page 5.

Turning the Calculator/Keypad On
and Off

To power on the batteries, use the on/off switch located
on the back of the keypad.

To turn on the keypad, press the CE/AC key, located
directly above the number seven key.

To turn off the keypad in calculator mode, press the CE/AC
key for 2 seconds.

To power off the batteries, use the on/off switch located
on the back of the keypad.

4

Targus Wireless Calculator Keypad

Establishing a Communications Link

After your computer detects the USB receiver and the
default driver software is installed, you may need to
establish a communications link between the receiver and
the keypad before you can use it.

1 Plug the receiver into your computer's USB port and turn

on the keypad.

NOTE: Make sure that your computer and keypad are
turned on and your computer has detected the USB
receiver before you establish a communications link.

Reset

Connection button

On/Off switch

The LED on the receiver will flash for 30 seconds to
indicate ID search mode.

2 During this time, press and release the connection

button on the back of the calculator/keypad.

When a communications link is established, the LED on
the receiver will stop flashing.

You are now ready to use the calculator/keypad.

5

Targus Wireless Calculator Keypad

Using the Calculator/Keypad

Switching Between Calculator and Keypad
Mode

To switch between the two modes, press the Mode key.
The mode you are in will be displayed on the LCD.

Battery low

indicator

NumLock key

Calculator/Keypad - front view

To turn off the keypad while in calculator mode, press the
NumLock key for 2 seconds.

NOTES: R

INDICATOR LED STARTS FLASHING.

O POWER OFF, USE THE ON/OFF SWITCH LOCATE D ON THE

T

BACK OF THE KEYPAD.

EPLACE THE BATTERIES WHEN THE BATTERY LOW

Mode key

6

Targus Wireless Calculator Keypad

Function Keys in Calculator Mode Only:

Key Function

M+

MRC

DEC Specifies the number of decimal places

+/-

CUR Currency and exchange rate setting

MODE

SEND Send calculation results to your computer

Tax -

Tax+ Price-plus-tax calculation.

Adds the current display to the content of
memory

Subtracts the current display from the content

M-

of memory

Pressing once transfers the memory contents
onto the display. Pressing a second time
clears the memory.

Switches the displayed value between
positive (+) and negative (-)

% Performs percentages

€ Setting Euro rate

Extracts the square root of a positive number
displayed

Switches between calculator and keypad
modes

Fn Combination key with Tax- and Tax+ function

Price-less-tax calculation (Displayed amount
less the tax rate input)

NOTE: The NumLock key on your computer will not
affect the NumLock status of the keypad.

7

Targus Wireless Calculator Keypad

Function Keys in Keypad Mode Only:

Key Function

MODE

DEC Emulates TAB key

Switches between calculator and keypad
modes

€ Input Euro symbol

Definition of the Keypad Keys:

.

NumLock on - inserts a decimal point

Del

End

PgDn



NumLock off - deletes a number

0

NumLock on - enters "0" on the display

Ins

NumLock off - emulates the Insert key

00

NumLock on - enters “00”

,

NumLock off - inserts a comma ( , )

1

NumLock on - enters "1" on the display
NumLock off - emulates the End key

2 NumLock on - enters "2" on the display



NumLock off - moves the cursor down one line
of text

3

NumLock on - enters "3" on the display
NumLock off - emulates the Page Down key

NumLock on - enters "4" on the display

4

NumLock off - moves one character to the left
of the cursor position

NumLock on - enters "5" on the display

5

NumLock off - No function

8

Targus Wireless Calculator Keypad

NumLock on - enters "6" on the display

6

NumLock off - moves one character to the



right of the cursor position

7

NumLock on - enters "7" on the display

Home

PgUp

NumLock off - emulates the Home key

NumLock on - enters "8" on the display

8

NumLock off - moves the cursor up one line of



text

9

NumLock on - enters "9" on the display
NumLock off - emulates the Page Up key

About the Display

The display shows the number you input, calculation results,
and various indicators showing the status of the calculator.

-MINUS Negative value indicator

MEM Independent memory indicator

ERR Error Indicator

‘ 3-digit separator

CALC Indicates calculator mode

KEYPAD Indicates keypad mode

GT Grand total

CUR Currency calculation

EURO Euro calculation

9

Targus Wireless Calculator Keypad

Rounding & Decimal Place Selectors

Rounding Selector

F

0, 2, 4

A

Floating decimal point system - displays the value
without rounding

Number of decimal places for the 5/4 setting of
the Rounding Selector

The "Auto-format Mode" automatically adds a
decimal point and two decimal places to all
values, even if you don't input a decimal point.
This mode is very useful when performing
calculations in dollars or other monetary systems
that require two decimal places. Two decimal
places are not added in this mode if you press
the DEL key while inputting a value, or for any
operation other than addition and subtraction.

Setting CUR and EURO Functions (in
Calculator mode)

CUR Function

1 Press CUR key for 1.5~2 seconds

The "CUR" indicator on the LCD will start flashing.

2 Input your desired parameter then press the CUR key

again.

The "CUR" indicator will disappear to indicate the
setting is accomplished.

When the LCD displays "0", you can press the "CUR" to
enable or disable the indicator on the LCD.

With your parameter numerals displayed on the LCD, press
the "CUR" button and it will exchange to the currency.

10

Targus Wireless Calculator Keypad

Example: The parameter is 34 and the currency amount
you want to convert is 180.

A With the "CUR" indicator displayed

› Enter 180 and press the CUR key to calculate 180*

34. The calculation result will be 6120.

B With the "CUR" indicator not displayed

› Enter 180 and press the CUR key to calculate 180/

34. The result will be 5.29.

on the LCD:

on the LCD:

Euro Function:

1 Press the € key for 1.5~2 seconds

The "Euro" indicator on the LCD will start flashing.

2 Input your desired parameter then press the € key again.

The "Euro" indicator will disappear to indicate the setting
is accomplished.

When the LCD displays "0", you can press the "€" to
enable or disable the indicator on the LCD.

With your parameter numerals displayed on the LCD, press
the "Euro" button and it will exchange to the tax rate.

Example: The Euro parameter is 105 and the currency
amount you want to convert is 180.

1 With the "Euro" indicator displayed

a Press Euro key to calculate 180*105. The result will

be 18900.

2 The "Euro" indicator not displayed

a Press the Euro key to calculate 180/105. The result

will be 1.71.

11

on the LCD:

on the LCD:

Targus Wireless Calculator Keypad

Setting the Tax Function

1 Press "%" key for 1~1.5 seconds

The "TAX" indicator on the LCD will start flashing.

2 Input your desired parameter and press "%" again.

The "TAX" indicator will disappear to indicate the setting
is accomplished.

Example: The Tax parameter is 10 and the sales price is

180.
a Enter 180 and press < Fn+Tax+ >. The calculation

result will be 198 (180 * (1+0.1)).

b Enter 180 and press < Fn+Tax- >. The calculation

result will be 163.63 (180/(1+0.1))

Sending Calculation Results from the
Calculator to Your Computer

When the device is in calculator mode, you can send
calculation results to the cursor location in the active
program on your computer. To do this, after calculating your
equation, press the SEND key.

NOTE: The Send feature automatically sends all
calculation results as positive factors. To send a
calculation result as a negative factor, you must set
the Send feature to negative mode.

Operating Hints

For optimal performance and RF reception:

• Place the receiver at least 8 inches (20 cm) away from all

electrical devices, such as your monitor, speakers or
external storage devices.

12

Targus Wireless Calculator Keypad

• If necessary, use the supplied extension cable

to keep the receiver away from the computer. Plug the
receiver into the extension cable, and the extension cable
to the computer.

Things to Remember

Power Management

• To extend the life of your batteries, power off the battery

with the on/off switch located on the back of the keypad
while traveling or when you’re not using it.

• Battery Low Indicator: LED flashes

NOTE: Please replace the batteries when the Battery
low LED starts flashing.

• The keypad’s power saving mode feature activates after 4

minutes of non-operation. To activate the keypad, press
the NumLock key.

Specifications

Operation
Frequency 27 MHz

Operating Distance Up to 3.3 feet (1 m)

Operating Voltage Calculator/Keypad: 2.4V

Receiver: 5V

Operating Current Calculator/Keypad: 10mA maximum

Receiver: 16mA maximum

Suspend Mode Calculator/Keypad: Below 300 uA

13

Targus Wireless Calculator Keypad

Dimensions Calculator/Keypad: 6.3 x 3.5 x 1 inches

(161 x 90 x 26.5 mm)
Receiver: 3.75 x 0.9 x 0.5 inches
(95 x 22 x 12.7 mm)

Weight Calculator/Keypad: 6.3 ounces (180 g)

Receiver: 0.35 ounces (10g)

Troubleshooting

What do I do if the keypad does not work?

• Make sure that the polarity of the batteries is correct. The

positive (+) and negative (-) ends of each battery must
match the positive (+) and negative (-) connections in the
battery housing.

• Check that the receiver’s USB connector is firmly

attached to the USB port on your computer.

• Verify that the device drivers are installed.

• Make sure you have established a communication link.

See “Establishing a Communications Link” on page 5.

When I use the calculator/keypad, other wireless
devices work more slowly or fail temporarily – what
should I do?

• The calculator/keypad may cause interference with any

cordless, radio-based device that operates at 27 MHz,
such as a telephone, baby monitor, or toy. To reduce
interference, move the calculator/keypad’s receiver and
the base unit of the affected device as far away from each
other as possible.

• You can also reset the calculator/keypad’s identification

code. To do this, see “Establishing a Communications
Link” on page 5.

14

Targus Wireless Calculator Keypad

What do I do if the response time of the calculator/
keypad is slow or it intermittently stops working?

Try one or more of the following:

• Increase the distance between the receiver and the rest

of your computer equipment.

• Increase the distance between the receiver and the base

units of other wireless devices.

• Turn off any wireless devices and their base units that are

near the keypad’s receiver.

• If you are using the keypad on a metal surface, move it

and the receiver to a non-metal surface. Metals, such as
iron, aluminum or copper, shield the radio frequency
transmission and may slow down the keypad’s response
time or cause the keypad to fail temporarily.

• Replace the batteries.

Technical Support

For technical questions, please visit:

US

Internet: http://www.targus.com/support.asp

Australia

Internet: www.targus.com.au

Email: [e-mail]

Monday through Friday, 8:30 a.m. (08:30) to 5:30 p.m.
(17:30) Eastern time: 1-800-641-645

New Zealand

Monday through Friday, 8:30 a.m. (08:30) to 5:30 p.m.
(17:30) Eastern time: 0800-633-222

15

Targus Wireless Calculator Keypad

Product Registration

Targus recommends that you register your Targus accessory shortly
after purchasing it.

To register your Targus accessory, go to:

http://www.targus.com/registration.asp

You will need to provide your full name, email address, phone
number, and company information (if applicable).

Warranty

Targus warrants this product to be free from defects in materials and
workmanship for one year. If your Targus accessory is found to be
defective within that time, we will promptly repair or replace it. This
warranty does not cover accidental damage, wear and tear, or
consequential or incidental loss. Under no conditions is Targus liable
for loss of, or damage to a computer; nor loss of, or damage to,
programs, records, or data; nor any consequential or incidental
damages, even if Targus has been informed of their possibility. This
warranty does not affect your statutory rights.

Warranty Registration at:

http://www.targus.com/registration.asp

Regulatory Compliance

This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) This device must accept any
interference received, including interference that may cause
undesired operation.

FCC Statement

Tested to Comply

This equipment has been tested and found to comply with the limits
of a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and if not
installed and used in accordance with the instructions, may cause

16

Targus Wireless Calculator Keypad

harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:

• Reorient or relocate the receiving antenna

• Increase the separation between the equipment and receiver

• Move the computer away from the receiver

• Connect the equipment into an outlet on a circuit different from

that to which the receiver is connected.

Features and specifications subject to change without notice. All t rademarks and
registered trademarks are the property of their respective owners. © 2004, Targus Group
International and Targus, Inc., Anaheim, CA 92806 USA

.

17
