English ................................................................................................................... |
2 |
Deutsch................................................................................................................ |
82 |
V 3.9
SilverCrest SWV 733 A2 |
|
Content |
|
Intended use............................................................................................................. |
6 |
Supplied items .......................................................................................................... |
7 |
Overview ................................................................................................................. |
8 |
LED indicators ................................................................................................................................................ |
9 |
Technical data......................................................................................................... |
10 |
Safety instructions .................................................................................................. |
11 |
Storage when not in use ......................................................................................... |
18 |
Copyright ............................................................................................................... |
18 |
Prior to use ............................................................................................................. |
19 |
First use .................................................................................................................. |
20 |
Setting mode............................................................................................................................................... |
20 |
2 - English
|
SilverCrest SWV 733 A2 |
Repeater mode ........................................................................................................................................... |
21 |
WPS - The easiest type of configuration.............................................................................................. |
23 |
Manual configuration ........................................................................................................................... |
25 |
Client mode ................................................................................................................................................ |
32 |
WPS - The easiest type of configuration.............................................................................................. |
34 |
Manual configuration ........................................................................................................................... |
36 |
Access Point (AP) mode (Router mode).................................................................................................... |
42 |
WPS - Connect to the AP (Router mode) ............................................................................................. |
52 |
Manual connection to the AP............................................................................................................... |
53 |
Configuration menu of the dual-band Wi-Fi range extender .................................................................. |
54 |
Status...................................................................................................................................................... |
58 |
Wizard ................................................................................................................................................... |
60 |
Wi-Fi ....................................................................................................................................................... |
61 |
Setup ...................................................................................................................................................... |
66 |
English - 3
SilverCrest SWV 733 A2 |
|
Environmental and disposal information ................................................................ |
76 |
Information on the EU Declaration of Conformity ................................................... |
77 |
Troubleshooting ..................................................................................................... |
77 |
Warranty and servicing advice............................................................................... |
80 |
4 - English
SilverCrest SWV 733 A2
Congratulations!
By purchasing the SilverCrest dual-band Wi-Fi range extender SWV 733 A2, hereinafter referred to as dual-band Wi-Fi range extender, you have opted for a high-quality product.
Familiarise yourself with the dual-band Wi-Fi range extender before using it for the first time, and read these operating instructions carefully. Pay particular attention to the safety instructions and use the dualband Wi-Fi range extender only as described in these operating instructions and for the specified range of applications.
Keep these operating instructions in a safe place. Include all documents when passing on the dual-band Wi-Fi range extender to someone else. The operating instructions are an integral part of the product.
If you pass on the dual-band Wi-Fi range extender, the factory defaults must be loaded, and please also refer to the section "Backup/Restore" on page 71.
English - 5
SilverCrest SWV 733 A2
Intended use
This dual-band Wi-Fi range extender is an information technology device. It increases the range of an existing wireless network. The dual-band Wi-Fi range extender can also be used as an access point (AP), for example, to use a router without its own wireless network as a "wireless router". In addition, the dualband Wi-Fi range extender can be connected as a client to end devices with a LAN interface (for example, computer, notebook or TV set), which do not have their own wireless network. It is only designed for private use and not for industrial or commercial purposes. Furthermore, the dual-band Wi-Fi range extender may not be used outdoors or in tropical climates. Any other use is not as intended. This device complies with all standards and directives specified in the Declaration of Conformity. In the event of any modification to the dual-band Wi-Fi range extender that was not approved by the manufacturer, compliance with these standards is no longer guaranteed. The manufacturer does not accept any liability for any resulting damage or faults in such cases. Please observe the regulations and laws in the country of use.
6 - English
SilverCrest SWV 733 A2
Supplied items
Take the dual-band Wi-Fi range extender and the accessories out of the packaging and remove all packaging material completely. Check the contents to ensure they are complete. You must notify our Customer Service immediately if parts are missing.
A SilverCrest dual-band Wi-Fi range extender SWV 733 A2
B2 network cables
CThese operating instructions (symbolic representation) "GNU General Public License" flyer (not illustrated)
A separate flyer relating to the "GNU General Public License" is enclosed with this dual-band Wi-Fi range extender. This flyer can also be downloaded at www.lidlservice.com.
English - 7
SilverCrest SWV 733 A2
Overview
These operating instructions have a fold-out cover. The dual-band Wi-Fi range extender is illustrated with numbers on the inside cover. The numbers indicate the following:
1 Field strength indicator
2 WAN/LAN LED
3LAN LED
4 Power/WPS LED
5Reset button
6 WAN/LAN socket (network socket, RJ-45)
7 LAN socket (network socket, RJ-45)
8 Mode selector
9 WPS button
10 Main switch
8 - English
|
|
|
|
SilverCrest SWV 733 A2 |
|
|
LED indicators |
|
|
|
|
|
|
|
|
|
|
|
LED |
|
Status |
Meaning |
|
|
Field strength |
|
lights up |
The more bars that light up, the better the reception |
|
|
indicator (1) |
|
|
(all bars light up in AP mode) |
|
|
|
|
|
|
|
|
|
|
flashes |
No reception |
|
|
|
|
|
|
|
|
WAN/LAN (2) |
|
lights up |
Connection is established |
|
|
|
|
|
|
|
|
|
|
off |
Connection is not established |
|
|
|
|
|
|
|
|
|
|
flashes |
Data is being transferred |
|
|
|
|
|
|
|
|
LAN (3) |
|
lights up |
Connection is established |
|
|
|
|
|
|
|
|
|
|
off |
Connection is not established |
|
|
|
|
|
|
|
|
|
|
flashes |
Data is being transferred |
|
|
|
|
|
|
|
|
Power/WPS (4) |
|
flashes rapidly |
WPS connection is being established or WPS signal of |
|
|
|
|
|
another device is expected |
|
|
|
|
|
|
|
|
|
|
lights up |
The dual-band Wi-Fi range extender is switched on |
|
|
|
|
|
|
|
|
|
|
off |
The dual-band Wi-Fi range extender is switched off |
|
|
|
|
|
|
|
English - 9
SilverCrest SWV 733 A2
Technical data
Input voltage |
100-240V~, 50/60Hz |
|
|
Power consumption |
max. 100mA |
|
|
Transmission power |
max. 100mW (2.4GHz / 5GHz) |
|
|
WLAN standards |
802.11b, 802.11g, 802.11n, 802.11ac |
|
|
Frequency band |
2.4GHz / 5GHz |
|
|
Data transfer rate |
up to 300Mbit/s in the n standard / |
|
up to 733Mbit/s in the ac standard |
|
|
Encryption |
WPA, WPA2, WEP (128/64) * |
|
|
Dimensions (W x H x D) |
approx. 53 x 76 x 79mm |
|
|
Weight |
approx. 80g |
|
|
Operating temperature, air humidity |
5 to 35°C; max. 85% rel. humidity |
|
|
Storage temperature, air humidity |
-20 to 60°C; max. 90% rel. humidity |
|
|
* WEP (128/64) encryption only with 802.11b/g.
The technical data and design may be changed without notification.
10 - English
SilverCrest SWV 733 A2
Safety instructions
Before using the device for the first time, please read the following instructions carefully even if you are familiar with using electronic devices. Store these operating instructions in a safe place for future reference.
DANGER! This symbol in conjunction with the "danger" note indicates an imminent dangerous situation which, if not prevented, could result in serious injury or even death.
WARNING! This symbol in conjunction with the "warning" note indicates important information for safe operation of the device and the safety of the user.
This symbol indicates other important information on the topic.
English - 11
SilverCrest SWV 733 A2
Operating environment
This dual-band Wi-Fi range extender must be used indoors only. The dual-band Wi-Fi range extender is not designed for use in environments with a high temperature or humidity (e.g. bathrooms), and must be kept free from dust. Operating temperatures and operating air humidity: 5°C to 35°C, max. 85% rel. humidity.
Please always maintain the dual-band Wi-Fi range extender at a minimum distance of 20cm from the body to avoid exposure to radio radiation.
DANGER! Ensure that
no direct heat sources (e.g. heating) can affect the device
no direct sunlight or bright artificial light reaches the device
the device is not in the immediate vicinity of magnetic fields (e.g. speakers)
no fire sources (e.g. burning candles) are placed on or near the device
no foreign objects penetrate the device
12 - English
SilverCrest SWV 733 A2
contact with sprayed and dripping water and corrosive liquids is avoided and the device is never operated near water; in particular it should never be immersed (do not place any objects filled with liquids, for example, vases or drinks, on or near the device)
the device is not subjected to any extreme temperature fluctuations as this could result in condensation and electrical short circuits. If the device was subjected to extreme temperature fluctuations, however, wait (approx. 2 hours) until the device has reached ambient temperature before use
the device is never subjected to excessive shocks and vibrations
the device is never touched with wet hands as there is a risk of an electric shock
the housing openings, which ventilate the dual-band Wi-Fi range extender, are never covered or enclosed as there is a risk of fire
If the aforementioned instructions are not observed, it poses a risk to your health or the device could be damaged.
DANGER! Operational safety
Only connect the dual-band Wi-Fi range extender to a freely accessible socket so that it can be quickly disconnected from the mains in the event of danger (smoke, fumes or smell of burning). The socket must always be easily accessible during operation also.
English - 13
SilverCrest SWV 733 A2
The main switch (10) of this device does not fully disconnect the device from the mains. Even if the device is not being used, it consumes minimal power. Disconnect the dual-band Wi-Fi range extender from the mains if the device will not be used for a prolonged period (e.g. during holidays). This minimises the risk of fire or smouldering, which always exists when an electrical device is connected to the mains power supply. To disconnect the dual-band Wi-Fi range extender completely from the power supply, you must remove its mains plug from the socket.
Always disconnect the dual-band Wi-Fi range extender from the mains power supply before a storm or thunderstorm if there is the risk of lightning as the dual-band Wi-Fi range extender can be irreparably damaged by high voltage surges if lightning strikes.
Never use any adapter plugs or extension cables which are damaged or which do not comply with valid safety standards.
Never open the housing of the device as there is a risk of a fatal electric shock when the housing is open.
DANGER! Children and persons with disabilities
Electrical devices do not belong in the hands of children. Persons with physical, mental or sensory disabilities should also only use electrical devices within the scope of their abilities. Never allow children
14 - English
SilverCrest SWV 733 A2
or persons with disabilities to use electrical devices unsupervised, unless they have been instructed accordingly or are supervised by a person responsible for their safety. Children should always be supervised to ensure that they do not play with this device. Small parts can be fatal if swallowed. Always keep plastic packaging out of reach.
DANGER! It poses a suffocation risk.
DANGER! Radio interface
Do not use the device on aircraft, in hospitals, operating rooms or in the vicinity of medical electronic systems. The transmitted radio waves can impair the functionality of sensitive devices. Keep the device at least 20 cm away from any pacemakers or implantable cardioverter defibrillators because the proper functioning of the pacemaker or implantable cardioverter defibrillator can be impaired by radio waves. The transmitted radio waves can cause interference in hearing aids. Do not place the device in the vicinity of flammable gases or in a potentially explosive environment (e.g. paint shop) when the radio components are switched on because the transmitted radio waves can cause an explosion or a fire. The
English - 15
SilverCrest SWV 733 A2
range of the radio waves is dependent on conditions in the surrounding environment. In the event of data traffic via a wireless connection, it is also possible for unauthorised third parties to receive data. Targa GmbH is not responsible for radio or television interference caused by unauthorised changes to this device. In addition, Targa assumes no responsibility for the replacement or exchange of connecting lines and devices not indicated by Targa GmbH. The user is solely responsible for the elimination of interference caused by such unauthorised changes and for the replacement or exchange of the devices.
WARNING! Cables
Always handle the cables by the plug and do not pull on the cables themselves. Never place furniture or other heavy objects on the cables and take care that the cables are not kinked, especially near the plug and connection sockets. Never tie a knot in a cable and do not tie cables together. Ensure that all cables are placed so that no one can trip over them and they do not cause an obstruction.
16 - English
SilverCrest SWV 733 A2
WARNING! Maintenance / cleaning
It is necessary to repair the device if it has been damaged in any way, for example, if the housing is damaged, if liquid or objects have penetrated the device or if the product has been exposed to rain or moisture. Repair work is also required if the device is not working properly or has been dropped. If smoke is produced, or there are any unusual sounds or smells, the device must be switched off immediately and its mains plug must be removed from the socket. In such cases, the device should not be used until it has been inspected by authorised service personnel. Only have the device repaired by qualified personnel. Never open the housing of the device. Only use a clean, dry cloth for cleaning and never use any corrosive liquids. Never try to open the housing of the device. This would void your warranty.
English - 17
SilverCrest SWV 733 A2
Storage when not in use
If the device will not be used for a long period of time, disconnect the dual-band Wi-Fi range extender from the mains power supply. Ensure that the storage temperature remains between -20°C and 60°C. The air humidity should not exceed 90% rel. humidity.
Note: the temperature range and relative air humidity for storage and use are quite different; thus observe the information in the "Operating environment" section on page 12.
Copyright
All information contained in these instructions is subject to copyright and is provided for information purposes only.
It is only permitted to copy or duplicate data and information with the express and written consent of the author. This also includes commercial use of the content and data.
The text and illustrations are based on the state of the art at the time of printing.
18 - English
SilverCrest SWV 733 A2
Prior to use
Check the dual-band Wi-Fi range extender for signs of damage. The dual-band Wi-Fi range extender must not be used if it is damaged.
The dual-band Wi-Fi range extender increases the range of your wireless network. The dual-band Wi-Fi range extender supports the following three modes:
Repeater
The range of your wireless network (WLAN) is extended. Thus wireless devices, which are outside the range of your wireless network, can be connected to the network via the dual-band Wi-Fi range extender.
Client
You can connect an end device with a LAN interface (for example, computer, notebook or TV set), which has no own wireless network, to the dual-band Wi-Fi range extender via the LAN cable (network cable). The dual-band Wi-Fi range extender can now connect your end device wirelessly to an existing wireless router.
As we cannot guarantee compatibility with all devices, please read the operating instructions for your device.
English - 19
SilverCrest SWV 733 A2
Access Point (AP)
This mode can be used, for example, to enable a router without its own wireless network to be used as a "wireless router". The router must be connected to the dual-band Wi-Fi range extender via the LAN cable (network cable, see "Supplied items").
First use
Setting mode
Select the desired mode using the mode selector (8). To do so, move the mode selector (8) to the desired position (Access Point, Repeater or Client).
20 - English
SilverCrest SWV 733 A2
Repeater mode
Repeater mode is used to extend the range of your wireless network. Wireless devices, which are outside the range of your wireless network, can be connected to the network via the dual-band Wi-Fi range extender.
Range without dual-band Wi-Fi range extender |
Range with dual-band Wi-Fi range extender |
|
|
The mode selector (8) must be set to the "Repeater" position for Repeater mode.
The dual-band Wi-Fi range extender should be placed near (approx. 2-3 metres) the wireless router the first time it is used.
English - 21
SilverCrest SWV 733 A2
Insert the dual-band Wi-Fi range extender into a socket that is always easily accessible.
Then switch on the dual-band Wi-Fi range extender by turning the main switch (10) to the "ON" position. The dual-band Wi-Fi range extender requires a certain amount of time (boot time) after it is switched on before it is ready to use. After switching the device on, wait for approximately 30 seconds before using the dual-band Wi-Fi range extender.
There are two different ways to configure the dual-band Wi-Fi range extender. If your wireless router supports WPS, you can use this simple function to easily set up the Wi-Fi range extender. If you would like to use a wireless router without WPS, you must connect the dual-band Wi-Fi range extender via network cable or wireless network to your computer and configure it.
22 - English
SilverCrest SWV 733 A2
WPS - The easiest type of configuration
This is the easiest way to configure the dual-band Wi-Fi range extender. First, check whether your wireless router supports WPS. For further details, please read the operating instructions for your wireless router.
1.Press the WPS button (9) on the dual-band Wi-Fi range extender for at least 5 seconds. After you have released the WPS button (9), the Power/WPS LED (4) will flash rapidly for approx. 2 minutes.
2.Within these 2 minutes, please press the connection button (WPS) on your wireless router. For further details, please read the operating instructions for your wireless router.
English - 23
SilverCrest SWV 733 A2
(Symbolic representation, connection button (WPS) can be differently arranged and referred to depending on the router model.)
The dual-band Wi-Fi range extender then automatically connects to your wireless router and copies all of the settings. It may take up to a minute for the connection to be established. Once the connection has been successfully established, the field strength indicator (1) displays the signal strength. The dual-band Wi-Fi range extender can then be used. The dual-band Wi-Fi range extender can now be accessed via the SSID (Wi-Fi name) and the network key of your wireless router.
You can then use the dual-band Wi-Fi range extender where the wireless signal is to be extended. The optimal location for the dual-band Wi-Fi range extender is exactly in the middle between your wireless router and the wireless devices which are to be connected to the network using the dual-band Wi-Fi range extender. Test other locations if the dual-band Wi-Fi range extender does not work there. Insert the dual-band Wi-Fi range extender only into a socket that is always easily accessible.
24 - English
SilverCrest SWV 733 A2
It is possible to configure multiple dual-band Wi-Fi range extenders. These should be configured one after the other.
If your wireless router does not support WPS or the connection fails for some other reason, you must manually configure the dual-band Wi-Fi range extender.
Manual configuration
There are two different ways to configure the dual-band Wi-Fi range extender.
If you are not using the network default settings on your computer and have manually set an IP address, you must restore the network settings to Automatically obtain an IP address. For further details, please read the operating instructions for your computer.
1.You can then configure the dual-band Wi-Fi range extender via the network cable. If you want to configure the dual-band Wi-Fi range extender via the network cable, you must connect the dualband Wi-Fi range extender to your computer. Use the network cable included with the device for this purpose. Insert one end of the network cable into the WAN/LAN socket (6) or the LAN socket
(7) of the dual-band Wi-Fi range extender and the other end into the LAN socket of your computer.
English - 25
SilverCrest SWV 733 A2
2.Alternatively, you can perform the configuration via a wireless network. To do so, start the search for available wireless networks on your computer. The network SWV 733 A2 2.4G or SWV 733 A2 5G is displayed in the list of available wireless networks. Select the network SWV 733 A2 2.4G or SWV 733 A2 5G and click on the Connect button to connect wirelessly with the dual-band Wi-Fi range extender. The dual-band Wi-Fi range extender is secured in its factory defaults by a network key. After having entered the network key (9426824723156819), you may have to click the option Connect without configuring the network. The message "Limited network connection" may be displayed.
Open the Internet browser on your computer. Enter http://repeater.setup in the address line of the Internet browser and confirm the entry with the Enter button.
The login window of the dual-band Wi-Fi range extender opens. Select the desired language and enter the user name and password (factory default for both: admin). The connection to the dual-band Wi-Fi range extender is established in an encrypted manner. If you want to establish an unencrypted connection (not recommended), deselect Security (Private SSL). Then click on the Login button. A message may be displayed that the certificate might not be secure. Please accept the certificate as it is from the manufacturer and is secure. The configuration menu of the dual-band Wi-Fi range extender now opens.
26 - English
SilverCrest SWV 733 A2
If you are opening the configuration menu of the dual-band Wi-Fi range extender for the first time, you will be prompted to change the user name and password.
The user name must consist of at least 8 characters in a combination of upper case and lower case. Numbers and special characters are optional.
The password must consist of at least 10 characters in a combination of upper case, lower case, numbers and special characters.
Take particular note of the user name and password or keep it in a safe place!
The configuration is started automatically via the Wizard. If the Wizard does not start automatically, click on the Wizard button.
English - 27
SilverCrest SWV 733 A2
From the list, select a wireless network whose range you want to extend. If the desired wireless network is not displayed, update the list by pressing the
symbol.
28 - English
