V 1.5
Lupilu LBP 864 A1
Table of Contents
1. Intended use ......................................................................................................... 3
2. Package contents ................................................................................................. 4
3. Controls and displays ........................................................................................... 4
4. Technical specifications ......................................................................................... 6
5. Safety instructions ................................................................................................ 7
5.1 Operating environment ......................................................................................................................... 9
6. Before you start .................................................................................................. 10
6.1 Inserting the batteries ......................................................................................................................... 10
6.2 Connecting the power adapter ......................................................................................................... 11
6.3 Battery charging function / mains power ......................................................................................... 12
7. Getting started ................................................................................................... 12
7.1 Switching on the baby monitor / Selecting the channel .................................................................. 13
7.2 Switching the baby monitor off .......................................................................................................... 13
8. Use ..................................................................................................................... 13
9. After use ............................................................................................................. 14
9.1 Maintenance/cleaning ...................................................................................................................... 14
10. Troubleshooting ............................................................................................... 14
11. Environmental regulations and disposal inform ation ........................................ 15
12. Conformity notes .............................................................................................. 16
13. Warranty information ...................................................................................... 16
2 - English
Lupilu LBP 864 A1
Congratulations!
By purchasing the Lupilu LBP 864 A1 baby monitor, hereinafter referred to as the baby monitor, you
have opted for a quality product.
Before first using it, familiarise yourself with the way the baby monitor works and read these operating
instructions through carefully. Be careful to follow the safety instructions and only use the baby monitor
as described in the operating instructions and for the applications given.
Keep these operating instructions in a safe place. If you pass the baby monitor on to someone else,
make sure to give them all the relevant documents with it.
1. Intended use
This baby monitor is a communications technology device. The baby monitor may only be used for
private use, not industrial or commercial use. It may not be used in tropical climates. Only cables and
external devices that comply with safety standards and the electromagnetic compatibility and shielding
quality of this device may be used.
This baby monitor fulfils all relevant norms and standards associated with CE Conformity. Any
modifications to the baby monitor may result in these directives no longer being met. The manufacturer
shall not be liable for any damage or malfunctions resulting from such modifications. Only use
accessories recommended by the manufacturer.
The baby monitor is used to monitor noise from a child’s room. When the baby wakes up and makes
noise, this is transmitted to the parent receiver unit. Any use other than that mentioned above does not
correspond to the intended use.
This baby monitor is suitable exclusively for use indoors, in dry, enclosed spaces.
Observe the regulations and laws in the country of use.
Predictable misuse
The baby monitor is only designed to monitor the sleep of small children. It is not for monitoring or
listening in on other people.
The baby monitor is not a medical device and may not be used for monitoring patients or other persons
dependent on care.
The baby monitor aims to reassure parents looking after their small children. It is no substitute for
responsible supervision.
English - 3
Lupilu LBP 864 A1
2. Package contents
Remove the baby monitor and all accessories from the packaging. Remove the packaging material and
check that all components are complete and undamaged. Keep the packaging material away from
children and dispose of appropriately. If you find anything missing or damaged, please contact the
manufacturer.
Parent receiver unit
Baby transmitter unit
2 power adapters
User's Manual
If any items are missing or damaged, please phone our hotline. You will find the phone number in the
last chapter “Warranty information”.
3. Controls and displays
These operating instructions have a fold-out cover. On the inside of the cover, the baby monitor is shown
with figures indicated. The meanings of the numbers are as follows:
A: Parent receiver unit
1 Speaker
2 Indicator light
See also the table for a description of the indicator light in the “Switching on the baby monitor /
Selecting the channel” section on page 13.
3 Volume control
Rotate the volume adjustment knob anticlockwise to increase the sound volume. Rotate the
volume adjustment knob clockwise to decrease the sound volume.
4 Channel selector switch/Off
Slide the channel selector switch to the middle position to switch the parent receiver unit off.
Push the channel selector switch left to switch the device on and receive on Channel A. The baby
transmitter unit should also be set to Channel A.
Push the channel selector switch right to switch the device on and receive on Channel B. The
baby transmitter unit should also be set to Channel B.
5 Twisting handle
Twist the handle up to hang the parent receiver unit, on the wall, for example.
Twist the handle down to place the parent receiver unit on a table or other surface, or to wear it
on a belt.
4 - English
Lupilu LBP 864 A1
6 Battery compartment cover
DANGER! The cover of the battery compartment must be secured using the screw
provided to ensure that small children cannot remove the batteries. Swallowing the batteries
could be fatal!
7 DC 6V
Power adapter input, polarity
B: Baby transmitter unit
8 Night light
9 Microphone
10 Indicator light
See also the table for a description of the indicator light in the “Switching on the baby monitor /
Selecting the channel” section on page 13.
11 Channel selector switch/Off
Slide the channel selector switch to the middle position to switch off the baby transmitter unit.
Push the channel selector switch left to switch the device on and send on Channel A. The parent
receiver unit should also be set to Channel A.
Push the channel selector switch right to switch the device on and send on Channel B. The parent
receiver unit should also be set to Channel B.
12 Night light button
Press and hold this button for about 3 seconds to power the night light on or off.
13 Twisting handle
Twist the handle up to hang the baby transmitter unit, on the wall, for example.
Twist the handle down to place the baby transmitter unit on a table or other surface.
14 Battery compartment cover
DANGER! The cover of the battery compartment must be secured using the screw
provided to ensure that small children cannot remove the batteries. Swallowing the batteries
could be fatal!
15 DC 6V
Power adapter input, polarity
English - 5
Lupilu LBP 864 A1
4. Technical specifications
General technical data
Wireless transmission frequency: 864 MHz
Range: up to 300 m (without obstructions)
Operating temperature, humidity: 5 to 40°C, max. 90 % relative humidity
Storage temperature, humidity: 5 to 40°C, max. 90 % relative humidity
Baby transmitter unit
Dimensions: 100 x 74 x 43 mm ( H x W x D )
Weight: 78 g (without batteries)
Power supply: 3 type AAA batteries, 1.5 V or 3 rechargeable type AAA NiMH batteries, 1.2 V, 600
mAh or power adapter 6 V (DC)
Runtime with rechargeable or conventional batteries, approx. 10-11 hours
Transmission power: < 10 mW
Channels: 2, switchable using channel selector switch (11)
Parent receiver unit
Dimensions: 100 x 74 x 43 mm ( H x W x D )
Weight: 78 g (without batteries)
Power supply: 3 type AAA batteries, 1.5 V or 3 rechargeable type AAA NiMH batteries, 1.2 V, 600
mAh or power adapter 6 V (DC)
Loud-speaker output power: 0.1 W
Runtime with rechargeable or conventional batteries, approx. 10-12 hours
Channels: 2, switchable using channel selector switch (4)
Power adapters
Manufacturer: Shenzhen Nalin Elec Tech Company, Ltd.
Model: NLA030060W1E6
Dimensions: 75 x 36 x 61 mm ( H x W x D )
Weight: 72 g
Input: 100–240 V~ (AC), 50/60 Hz
Output: 6 V (DC), 300 mA, polarity
Protection Class II
The technical data and design may be changed without prior notice.
6 - English
Lupilu LBP 864 A1
5. Safety instructions
Before you use this baby monitor for the first time, please read the following notes and heed all
warnings, even if you are familiar with handling electronic devices. Keep this manual safe for future
reference. If you sell the device or pass it on, it is essential that you also hand over this manual, as it is
part of the product.
DANGER! This symbol and the word “Danger” alert you to a potentially dangerous
situation. Ignoring it can lead to severe injury or even death.
DANGER! This symbol warns of risks which could, if left unheeded, cause damage to life
and limb through electric shock.
WARNING! This symbol and the word “Warning” denote important information
required for the safe operation of the product and for the safety of its users.
This symbol denotes further information on the topic.
DANGER! Children and persons with disabilities
Electrical devices are not suitable for children. Also persons with reduced physical, sensory or mental
capabilities should only use electrical devices in appropriate circumstances. Never allow children or
persons with disabilities to use electrical devices unsupervised, unless they are instructed accordingly
and supervised by a competent person responsible for their safety. Children should always be
supervised to ensure that they do not play with the product.
DANGER! There is a risk of suffocation.
Small parts can be fatal if swallowed.
Keep the baby transmitter unit (B) and its power adapter at least 1 m away from your baby or
toddler.
Keep the packaging away from children and persons with disabilities.
Do not use any extension cords.
DANGER! Batteries and rechargeable batteries
Insert the battery with the correct polarity. Never try to recharge normal batteries and under no
circumstances throw them into fire. Do not mix batteries (old and new or carbon and alkaline, etc.).
Batteries are not a toy. If a battery is swallowed, seek medical help immediately. The cover of the
battery compartment (6, 14) must be secured using the screw provided to ensure that small children
cannot remove the batteries. Batteries must never be opened or modified. Otherwise there is a risk of
leaking chemicals. If the chemicals come into contact with your skin or eyes, rinse with plenty of fresh
water immediately and seek medical aid. Remove the batteries when the device is not to be used for an
extended period. Improper use could cause explosions or leaks.
English - 7
Lupilu LBP 864 A1
DANGER! Power adapter
Please only use the power adapter provided (manufacturer: Shenzhen Nalin Elec Tech Company, Ltd. /
Type designation: NLA030060W1E6) to power the baby monitor.
Only plug the power adapter into a suitable and easily accessible power socket. Do not touch the
power adapter with wet hands, as this could cause an electric shock.
To unplug the power adapter from the power socket, always hold its casing and never pull from the
cable. Unplug the power adapter from the mains in the following circumstances:
in any dangerous situation.
if the power adapter makes an unusual noise or gives off smoke.
before a storm and/or thunderstorm.
if the power adapter is damaged.
if the power adapter has been exposed to rain, liquids or high levels of humidity.
before a prolonged absence, e.g. holiday.
when you wish to clean it.
The power adapter consumes electricity even in standby mode. In order to completely disconnect
the device from the mains, the power adapter must be pulled out from the mains socket.
Please follow these instructions to avoid risk of potential fatal injury or fire! Never cover the power
adapter, otherwise there is a risk of fire. Do not attempt to open the housing of the power adapter. This
could result in potentially fatal electrocution.
WARNING! Cables
Unplug all cables by holding the plugs and never pull on the cables themselves. Never place pieces of
furniture or other heavy objects on the cables and take care that they do not become damaged,
especially at the plugs and sockets. Never install the cables around hot or sharp objects to avoid
damaging them. Never tie knots in cables and do not tie them to other cables. All cables should be
positioned so that nobody can trip over them or be obstructed by them.
DANGER! Cables
Keep all cables at least 1 m away from the baby. There is a risk of suffocation.
DANGER! Radio interface
Turn the device off when on board an aircraft, in a hospital, in an operating theatre or in the vicinity of
electronic medical equipment. The RF signals may interfere with the functionality of sensitive devices.
Keep the device at least 20 cm (8 inches) away from pacemakers, as the RF signals could interfere with
the functionality of the pacemaker. The RF signals transmitted can interfere with hearing aids. If the
wireless mode is switched on, do not place the device near flammable gases or in a potentially
explosive area (e.g. a paint shop), as the RF signals transmitted could cause explosions or fire. The
8 - English
Lupilu LBP 864 A1
range of the radio frequency signals depends on environmental conditions. If data is transmitted via a
wireless connection, it can also be received by unauthorised parties. Targa GmbH is not liable for any
interference caused to RF or TV signals through unauthorised modification to this device. Furthermore,
Targa accepts no liability for replacing any devices that have not been specifically approved by Targa
GmbH. The user is solely responsible and liable for remedying any interference caused by such
unauthorised modification of this device and for replacing appliances.
WARNING! Repairs
Repairs are required when this device has been damaged in any way, for example when liquid has
entered the product, when the product has been exposed to rain or moisture, when the product does not
work normally or if the product has been dropped. If smoke, unusual noises or smells are noticed, power
off the device immediately, disconnect the power adapter from the mains and remove the rechargeable
or conventional batteries. If this occurs, do not continue to use the device and have it checked out by an
expert. All repair work must be carried out by qualified personnel. Never open the housing of the
device, or the accessories. You can only open the cover of the battery compartment (6, 14) in order to
insert or remove batteries.
WARNING! Make sure that:
- no direct heat sources (e.g. radiators) affect the device
- no direct sunlight or bright artificial light reaches the device
- contact with spray and dripping water and abrasive liquids is avoided and the device is never
operated near water, and, most importantly, is never immersed (do not place any objects filled with
liquids such as vases or drinks on or near the device)
- there is clearance of at least one metre from radio frequency and magnetic sources (e.g. TV,
speakers, mobile phones, etc.) to avoid any malfunction. In case of malfunction, install the device at
a different place.
- never place the device in the immediate vicinity of magnetic fields (e.g. loudspeakers)
- do not place any fire sources (e.g. burning candles) on or near the device
- no foreign bodies can penetrate into the device
- the device is not exposed to any extreme temperature fluctuations as this can cause moisture
through condensation and cause short-circuits. If the device has been exposed to strong temperature
variations, wait for it to reach the ambient temperature before switching it on (about 2 hours)
- the device should not be subjected to excessive shocks and vibrations
5.1 Operating environment
Position the device on a stable, flat surface and do not place any objects on the device. The device is
not for use in rooms with a high temperature or humidity (e.g. bathrooms), and must be kept free of dust.
Operating temperature and operating humidity: 5°C to 40°C, max. 90% rel. humidity.
English - 9
Lupilu LBP 864 A1
Copyright
All the contents of these operating instructions are protected by copyright and provided to the reader for
information only. Copying data and information without the prior explicit written consent of the author is
strictly forbidden. This also applies to any commercial use of the contents and information. All texts and
diagrams are up-to-date as of the date of printing. Subject to change without notice.
6. Before you start
Unpack all the devices and use the package contents checklist on page 4 to verify that you have
received all items listed. Next remove all package material. If you find anything missing or damaged,
please contact Customer Service (see “Warranty information” on page 16).
DANGER! There is a risk of suffocation.
Keep the packaging material away from children and dispose of appropriately.
You can power your baby monitor using conventional batteries, rechargeable batteries or using the
power adapters provided. If you use rechargeable batteries, you can charge them directly in the baby
monitor by connecting it to the mains power via the power adapters.
6.1 Inserting the batteries
No rechargeable or conventional batteries are provided with the baby monitor. If you do
not wish to power the baby monitor, i.e. the parent receiver unit (A) or the baby
transmitter unit (B) from the mains, you need to buy batteries.
WARNING!
If you wish to use rechargeable or conventional batteries, make sure that you only use
AAA NiMH batteries with 1.2 V and 600 mAh. (You can also use NiMH batteries with
higher capacity, but this does extend the charging time.) If using rechargeable or
conventional batteries with a different voltage or chemical composition (e.g. NiCd), there
is a risk of overheating and explosion!
DANGER! When powering the baby monitor with the power adapter, no conventional
(non-rechargeable) batteries must be inserted. Otherwise there is a risk of explosion as
well as a risk of injury and damage to property.
First, insert the batteries into the parent receiver unit (A) and the baby transmitter unit (B) (see diagram
below).
10 - English
Loading...
