Congratulations on your purchase of the Sony Ericsson K630i.
For additional phone content, go to www.sonyericsson.com/fun.
Register now to get free online storage and special offers at
www.sonyericsson.com/myphone.
For product support, go to www.sonyericsson.com/support.
Accessories – More for your phone
Music Remote Control MRC-60
Listen to music with hi-fi sound quality
and adjust music settings with a remote
control.
Stereo Bluetooth™ Headset
HBH-DS200
Enjoy wireless music without missing
a call.
Portable Speakers MPS-70
Small yet powerful speakers that fit
in your pocket.
These accessories can be purchased separately but may not be available in every
market. To view the full range go to www.sonyericsson.com/accessories.
Contents
Getting started ................... 5
Assembly ........................................ 5
Turning on the phone ..................... 6
Help in your phone ........................ 6
Charging the battery ....................... 7
Phone overview .............................. 8
Menu overview .............................. 10
Navigation .................................... 12
File manager ................................ 12
Phone language ........................... 13
Entering text ................................. 13
Calling ............................... 14
Making and receiving calls ........... 14
Contacts ....................................... 16
Call list .......................................... 19
Speed dial ..................................... 19
Voicemail ...................................... 20
Voice control ................................ 20
Messaging ........................ 22
Text messages .............................. 22
Picture messages ......................... 23
Email ............................................ 24
My friends ..................................... 25
Imaging ............................ 26
Camera and video recorder ......... 26
Using the camera .......................... 26
Camera icons and settings ........... 27
Transferring pictures ..................... 27
Pictures ......................................... 28
Entertainment ................. 28
Stereo portable handsfree ............ 28
Music and video players ............... 28
TrackID™ ...................................... 29
Radio ........................................... 29
PlayNow™ .................................... 30
Ringtones and melodies ............... 31
Sound recorder ............................. 31
1Contents
Connectivity ...................... 32
Settings ........................................ 32
Web feeds ..................................... 32
Bluetooth™ wireless technology . 33
Using the USB cable .................... 34
Update service ............................. 36
Troubleshooting ............... 37
Common questions ...................... 37
Error messages ............................. 38
Important information ...... 40
Guidelines for Safe and Efficient Use
42
End User Licence Agreement ....... 46
Limited Warranty .......................... 47
FCC Statement ............................. 49
Declaration of Conformity ............. 49
Index ................................. 50
2 Contents
Sony Ericsson K630i
UMTS 2100 GSM 900/1800/1900
This User guide is published by Sony Ericsson
Mobile Communications AB or its local affiliated
company, without any warranty. Improvements
and changes to this User guide necessitated by
typographical errors, inaccuracies of current
information, or improvements to programs and/or
equipment, may be made by Sony Ericsson Mobile
Communications AB or its local affiliated company
at any time and without notice. Such changes will,
however, be incorporated into new editions of this
User guide.
All rights reserved.
©Sony Ericsson Mobile Communications AB, 2007
Publication number: 1201-0276.1
Please note:
Some of the services in this User guide are not
supported by all networks. This also applies to the
GSM International Emergency Number 112.
Please contact your network operator or service
provider if you are in doubt whether you can use
a particular service or not.
Please read the Guidelines for safe and efficient use
and the Limited warranty chapters before you use
your mobile phone.
Your mobile phone has the capability to download,
store and forward additional content, e.g. ringtones.
The use of such content may be restricted
or prohibited by rights of third parties, including
but not limited to restriction under applicable
copyright laws. You, and not Sony Ericsson, are
entirely responsible for additional content that you
download to or forward from your mobile phone.
Prior to your use of any additional content, please
verify that your intended use is properly licensed
or is otherwise authorized. Sony Ericsson does not
guarantee the accuracy, integrity or quality of any
additional content or any other third party content.
Under no circumstances will Sony Ericsson be liable
in any way for your improper use of additional
content or other third party content.
Bluetooth™ is a trademark or registered trademark
of Bluetooth SIG Inc.
The liquid identity logo, PlayNow, and TrackID
are trademarks or registered trademarks of
Sony Ericsson Mobile Communications AB.
Sony, Memory Stick Micro™ and M2™ are
trademarks or registered trademarks of Sony
Corporation.
Ericsson is a trademark or registered trademark
of Telefonaktiebolaget LM Ericsson.
Adobe® Photoshop® Album Starter Edition
is a registered trademark of Adobe Systems
Incorporated.
ActiveSync, Microsoft, Windows, PowerPoint,
Outlook and Vista are trademarks or registered
trademarks of Microsoft Corporation in the US
and other countries.
T9™ Text Input is a trademark or a registered
trademark of Tegic Communications. T9™ Text
Input is licensed under one or more of the following:
U.S. Pat. Nos. 5,818,437, 5,953,541, 5,187,480,
5,945,928, and 6,011,554; Canadian Pat. No.
1,331,057, United Kingdom Pat. No. 2238414B;
Hong Kong Standard Pat. No. HK0940329;
Republic of Singapore Pat. No. 51383; Euro.Pat.
No. 0 842 463(96927260.8) DE/DK, FI, FR, IT, NL,
PT, ES, SE, GB; and additional patents are pending
worldwide.
Java and all Java based trademarks and logos
are trademarks or registered trademarks of Sun
Microsystems, Inc. in the U.S. and other countries.
End-user license agreement for Sun™ Java™
J2ME™.
3
Restrictions: Software is confidential copyrighted
information of Sun and title to all copies is retained
by Sun and/or its licensors. Customer shall not
modify, decompile, disassemble, decrypt, extract,
or otherwise reverse engineer Software. Software
may not be leased, assigned, or sublicensed,
in whole or in part.
Export Regulations: Software, including technical
data, is subject to U.S. export control laws, including
the U.S. Export Administration Act and its associated
regulations, and may be subject to export or import
regulations in other countries. Customer agrees
to comply strictly with all such regulations and
acknowledges that it has the responsibility to obtain
licenses to export, re-export, or import Software.
Software may not be downloaded, or otherwise
exported or re-exported (i) into, or to a national
or resident of, Cuba, Iraq, Iran, North Korea, Libya,
Sudan, Syria (as such listing may be revised from
time to time) or any country to which the U.S. has
embargoed goods; or (ii) to anyone on the U.S.
Treasury Department's list of Specially Designated
Nations or the U.S. Commerce Department's Table
of Denial Orders.
Restricted Rights: Use, duplication or disclosure
by the United States government is subject to the
restrictions as set forth in the Rights in Technical
Data and Computer Software Clauses in DFARS
252.227-7013(c) (1) (ii) and FAR 52.227-19(c) (2)
as applicable.
Other product and company names mentioned
herein may be the trademarks of their respective
owners.
Any rights not expressly granted herein are reserved.
All illustrations are for illustration only and may not
accurately depict the actual phone.
Instruction symbols
These symbols appear in the User guide.
Note
Tip
Warning
A service or function is networkor subscription-dependent.
Contact your network operator
for details.
> Use a selection or navigation
key to scroll and select. See
Navigation on page 12.
4
Getting started
Assembly
Before you start using your phone,
you need to insert a SIM card and the
battery.
To insert the SIM card
1 Remove the battery cover.
2 Slide the SIM card forward (1), and
then backwards under the holder (2) with the gold-coloured contacts facing
down.
To insert the battery
1 Insert the battery with the label side up
and the connectors facing each other.
2 Close and slide the battery cover into
place.
5Getting started
Turning on the phone
To turn on the phone
1 Press and hold down .
2 Select a mode:
• Normal – full functionality.
• Flight mode – limited functionality.
3 Enter your SIM card PIN, if requested
and select OK.
4 Select a language.
5 Select Continue > Yes to use the setup
wizard while settings are downloaded.
If you want to correct a mistake when
you enter your PIN, press .
Standby
After you have turned your phone
on and entered your PIN, the name
of the network operator appears. This
view is called standby.
Help in your phone
Help and information are available
in your phone. See Navigation on
page 12.
To use the setup wizard
1 From standby select Menu > Settings
> the General tab > Setup wizard.
2 Select an option.
To view information about functions
• Scroll to a function and select Info,
if available. In some cases, Info appears
under Options.
To view the phone demonstration
• From standby select Menu
> Entertainment > Demo tour.
To view status information
• From standby press the volume key up.
6 Getting started
Charging the battery
The phone battery is partly charged
when you buy it.
To charge the battery
2.5 h.
1 Connect the charger to the phone.
It takes approximately 2.5 hours to fully
charge the battery. Press a key to view
the screen.
2 Remove the charger by tilting the plug
upwards.
You can use your phone while it is
charging. You can charge the battery
at any time and for more or less than
2.5 hours. You can interrupt the charging
without damaging the battery.
7Getting started
Phone overview
10
11
12
14
13
3
8
4
5
6
7
2
1
9
1 Video call camera
2 Ear speaker
3 Screen
4 Selection keys
5 Call key
6 Activity menu
7 Navigation key
8 Keylock key
9 Volume, digital zoom keys
10 End key
11 Camera key
12 C key (Clear)
13 Silent key
14 Connector for charger,
handsfree and USB cable
8 Getting started
17
16
15
15 On/off key
16
Camera lens
17 Memory card slot
9Getting started
Menu overview
PlayNow™* Internet* Entertainment
Online services*
Games
TrackID™
VideoDJ™
PhotoDJ™
MusicDJ™
Remote control
Record sound
Demo tour
Camera Messaging Media
Write new
Inbox
Email
Web feeds
Drafts
Outbox
Sent messages
Saved messages
My friends*
Call voicemail
Templates
Manage msgs
Settings
Alarms Contacts
Myself
New contact
Radio
10 Getting started
Calls** Organizer
File manager**
All Answered Dialled Missed
Applications
Video call
Calendar
Tasks
Notes
Synchronization
Timer
Stopwatch
Calculator
Code memo
Settings**
General
Profiles
Time & date
Language
Update service
Voice control
New events
Shortcuts
Flight mode
Security
Setup wizard
Accessibility*
Phone status
Master reset
* Some menus are operator-, network- and subscription-dependent.
** You can use the navigation key to scroll between tabs in submenus. For more information, see Navigation
on page 12.
Sounds & alerts
Ring volume
Ringtone
Silent mode
Increasing ring
Vibrating alert
Message alert
Key sound
Display
Wallpaper
Themes
Startup screen
Screen saver
Clock size
Brightness
Edit line names*
Calls
Speed dial
Smart search
Divert calls
Switch to line 2*
Manage calls
Video share*
Time & cost*
Show/hide my no.
Handsfree
Connectivity*
Bluetooth
USB
Phone name
Network sharing
Synchronization
Device mgmt
Mobile networks
Internet settings
Streaming settings
Message settings*
Accessories
11Getting started
Navigation
The main menus are shown as icons.
Some submenus include tabs.
To navigate the phone menus
Centre navigation key
1 From standby select Menu.
2 Use the navigation key to move through
the menus.
To scroll between the tabs
• Scroll to a tab by pressing the navigation
key left or right.
To view options for an item
• Select Options to, for example, edit.
To return to standby
• Press .
To end a function
• Press .
To navigate your media
1 From standby select Media.
2 Use the navigation key to move up,
down, left and right through the menus.
To delete items
• Press to delete items such as
numbers, letters, pictures and sounds.
File manager
You can use the file manager to handle
files saved in the phone memory or on
a memory card.
You may have to purchase a memory
card separately.
Handling files
You can move and copy files between
your phone, a computer and a memory
card. Files are saved on the memory
card first and then in the phone memory.
Unrecognized files are saved in the
Other folder.
To move a file in the file manager
1 From standby select Menu > Organizer
> File manager.
2 Find a file and select Options > Manage
file > Move.
3 Select an option.
12 Getting started
To select more than one file
in a folder
1 From standby select Menu > Organizer
> File manager.
2 Scroll to a folder and select Open.
3 Select Options > Mark > Mark several.
4 For each file you want to mark, scroll
to the file and select Mark.
To delete a file from the file manager
1 From standby select Menu > Organizer
> File manager.
2 Find the file and press .
Phone language
You can select a language to use
in your phone.
To change the phone language
1 From standby select Menu > Settings
> the General tab > Language > Phone
language.
2 Select an option.
Entering text
You can use multitap text input or T9™
Text Input to enter text. The T9 Text
Input method uses a built-in dictionary.
To change text input method
• When you enter text, press and hold
down .
To shift between capitals and
lower-case letters
• When you enter text, press .
To enter numbers
• When you enter text, press and hold
down – .
To enter full stops and commas
• When you enter text, press .
To enter text using T9™ Text Input
1 From standby select, for example,
Menu > Messaging > Write new > Text
message.
2 If is not displayed, press and hold
down to change to T9 Text Input.
3 Press each key only once, even if the
letter you want is not the first letter
on the key. For example, to write the
word “Jane”, press , , ,
. Write the whole word before
looking at the suggestions.
4 Use or to view suggestions.
5 Press to accept a suggestion.
13Getting started
To enter text using multitap
1 From standby select, for example,
Menu > Messaging > Write new > Text
message.
2 If is displayed, press and hold down
to change to multitap text input.
3 Press – repeatedly until the
desired letter appears.
4 When a word is written, press
to add a space.
To add words to the built-in dictionary
1 When you enter text using T9 Text
Input, select Options > Spell word.
2 Write the word using multitap input
and select Insert.
Calling
Making and receiving calls
You need to turn on your phone and
be within range of a network.
To make a call
1 From standby enter a phone number
with international country code and
area code, if applicable.
2 Press .
You can call numbers from your contacts
and call list. See Contacts on page 16,
and Call list on page 19. You can also
use your voice to make calls. See Voice
control on page 20.
To make international calls
1 From standby press until a “+”
sign appears.
2 Enter the country code, area code
(without the first zero) and phone
number.
3 Press .
To re-dial a number
• When Retry? appears select Ye s.
Do not hold your phone to your ear
when waiting. When the call connects,
your phone gives a loud signal.
14 Calling
To answer a call
• Press .
To reject a call
• Press .
To change the ear speaker volume
during a call
• Press the volume key up or down.
To mute the microphone during a call
1 Press and hold down .
2 Press and hold down again
to resume.
To turn the loudspeaker on during
a call
• Select SpkrOn.
Do not hold your phone to your ear
when using the loudspeaker. This could
damage your hearing.
To view missed calls from standby
• Press and scroll to the New events
tab and select a number.
• Press to open the call list.
Emergency calls
Your phone supports international
emergency numbers, for example,
112 and 911. These numbers can
normally be used to make emergency
calls in any country, with or without
the SIM card inserted, if a 3G (UMTS)
or GSM network is within range.
In some countries, other emergency
numbers may also be promoted.
Your network operator may therefore
have saved additional local emergency
numbers on the SIM card.
To make an emergency call
• From standby enter 112 (the
international emergency number)
and press .
To view your local emergency
numbers
1 From standby select Menu
> Contacts.
2 Scroll to New contact and select
Options > Special numbers >
Emergency nos.
15Calling
Loading...
