MP 200
User manual
Page 2
2
Page 3
Welcome
We are delighted that you have decided to purchase a
T+A product. Your new Multi-Source-Player is a Hi-Fi
unit of the highest quality, designed and developed
with a single aim as top priority: to satisfy the requirements of the audiophile music lover.
This unit is the embodiment of innovative thinking
and solid quality, exploiting the nest materials and
components available, and all these factors contribute
to a machine which will satisfy you‘re most stringent
demands and your most searching requirements for a
period of many years.
Our production areas are supervised by highly qualied expert staff, and all nal production units are
checked comprehensively by a fully automated,
computer-controlled system to ensure uniformly high
quality. We guarantee that our products meet our own
specications to the full.
At all stages of production we avoid the use of substances which are environmentally unsound or po-
tentially hazardous to health, such as chlorine-based
cleaning agents and CFCs.
We also aim to avoid the use of plastics in general,
and PVC in particular, in the design of our products.
Instead we rely upon metals and other non-hazardous
materials; metal components are ideal for recycling,
and also provide effective electrical screening.
Our robust all-metal cases exclude any possibility of
external sources of interference affecting the quality
of reproduction. From the opposite point of view our
products’ electro-magnetic radiation (electro-smog) is
reduced to an absolute minimum by the outstandingly
effective screening provided by the metal case.
We would like to take this opportunity to thank you for
the faith you have shown in our company by purchasing this product, and wish you many hours of enjoyment and sheer listening pleasure with your MP 200.
3
Page 4
Content
Safety notes 10
Getting started 12
General information 12
Scope of delivery 12
Set up 12
Connections 12
Wiring diagram 13
Switching on and off 14
Connecting to network 14
Selecting a source 15
Browsing through lists 15
Playback 16
Connections 18
Bluetooth antenna 18
Digital In- and Outputs (S/P-DIF) 18
LAN connection 18
USB input 18
System interfaces 19
Mains input 19
Installation and connection 20
Installation 20
Connection 20
WLAN antenna 20
LAN 20
BLUETOOTH antenna 21
Connection of digital source devices 21
Connected to a DAC 200 or HA 200 21
Operation with other devices 21
Connecting the power cord 21
Controls and functions 22
On / Off switch 22
Front USB socket 22
Function buttons 22
Source selection 23
System and source menu 23
Remote control receiver 23
Menu operation and playback control 23
Display 23
Disc drive 23
4
Page 5
Remote control 24
On / Off Switch 24
Source selection 24
Settings 24
Playback and menu operation 24
Function buttons 25
Replacing the battery 26
Range 26
Important information 26
Settings 27
Menu operation 27
System settings 28
Network conguration 31
General information 31
Menu operation 31
Connection via LAN (cable connection) 31
Connecting to WLAN (radio connection) 32
Source operation 34
Selecting a source 34
Browsing through lists 35
Playback 35
Display 36
Favourites list 38
General information 38
Calling up the Favourites list 38
Adding a favourite 38
Erasing a favourite from the Favourites list 38
Play Favourites 39
Sort Favourites 39
Radio operation 40
General information 40
FM Radio 40
Display 40
Manual station search 41
Automatic station search 41
Mono / Stereo selection 41
Switching Radio Text on and off 41
DAB Radio 42
Display 42
Automatic station search 42
Internet Radio 43
Display 43
Search function 43
Favorites 43
5
Page 6
UPnP, Music services and USB 44
General information 44
Source selection 44
Display 44
Playback of directories 44
CD player operation 45
Source selection 45
Insert and eject a disc 45
Playback mode 45
Playback Program 46
Bluetooth 47
General information 47
Source selection 47
Setting up audio transfer 47
Playback 47
Playback with Roon 48
General information 48
Playback 48
T+A Music Navigator App 48
Download 48
Troubleshooting 49
Notes on energy saving 51
General information 51
Automatic power down function 51
Legal Information 51
Allgemeine Informationen 51
Show licenses 51
Firmware update 53
General information 53
Update procedure 53
Connection and wiring 54
Technical Specications 56
6
Page 7
7
Page 8
Notes
User manual
Text passages marked with this symbol contain important information which must be
observed if the machine is to operate safely and without problems.
This symbol marks text passages which provide supplementary notes and background
j
information; they are intended to help the user understand how to get the best out of the
machine.
Symbols and notes on the back of the MP 200
This symbol marks alternating voltages (AC).
The AC voltage required for the device can be found on the printing at the mains input
socket. Do not connect the device to other power supplies.
This symbol marks the protective earth connector (ground connection).
The unit is designed for operation at a protective earth conductor socket.
The device is designed to operate in altitudes up to 2000 m above sea level.
The device is designed to operate in a temperate climate.
The range of permissible operating temperatures is +10 … +35°C.
The only permissible method of disposing of this product is to take it to your local collection centre for electrical waste.
All the components we use meet the German and European safety norms and standards which are currently valid. This product complies with the EU directives. The
declaration of conformity can be downloaded from www.ta-hi.com/DoC.
This product contains a class 1 laser diode. To ensure continued safety, do not remove
any covers or attempt to gain access to the inside of the product.
Refer all servicing to qualied personnel.
8
Page 9
License notice
Qualcomm is a trademark of Qualcomm Incorporated, registered in the United
States and other countries, used with permission. aptX is a trademark of Qualcomm Technologies International, Ltd., registered in the United States and other
countries, used with permission
The Bluetooth® word mark and logos are registered trademarks owned
by Bluetooth SIG, Inc. and any use of such marks by T+A elektroakustik
is under license. Other trademarks and trade names are those of their
respective owners.
HD Radio Technology manufactured under license from iBiquity Digital
Corporation. U.S. and Foreign Patents. HD Radio™ and the HD, HD Radio,
and “Arc” logos are proprietarytrademarks of iBiquity Digital Corp
This product contains software in form of object code that is partially based on
free software under different licenses, especially the GNU General Public License. You can nd details on this in the License Information which you should have
received with this product.
If you have not received a copy of the GNU General Public License, please see
http://www.gnu.org/licenses/.
For a period of three years after last distribution of this product or its rmware,
T+A offer the right to any third party to obtain a complete machine-readable copy
of the corresponding source code on physical storage medium (DVD-ROM or USB
stick) for a charge of 20€. To obtain such copy of the source code, please write to
the following address including information about product model and rmware
version: T+A elektroakustik, Planckstr. 9-11, 32052 Herford, Germany.
The GPL license and further information about Licenses can be found on the internet under this link:
http://www.ta-hi.com/license-information
It is also possible to retrieve the used licenses directly from the device with the
help of an Internet browser. For details, see the chapter entitled „Legal Information“.
9
Page 10
Safety notes
For your own safety please consider it essential to read these operating instructions right through, and observe in
particular the notes regarding setting up, operation and safety.
The operation instructions, the connection guidance
and the safety notes are for your own good - please
read them carefully and observe them at all times.
The operating instructions are an integral part of this
device. If you ever transfer the product to a new owner
please be sure to pass them on to the purchaser to
guard against incorrect operation and possible hazards.
The device is intended to be connected to a mains outlet with protective earth connector. Please connect it
only with the mains cable supplied to properly installed mains outlets with protective earth connector.
The power supply required for this unit is printed on
the mains supply socket. The unit must never be connected to a power supply which does not meet these
specications.
This device is connected to the power supply as long
as the power cord is connected.
Even if the device is switched off and the status indicators are dark, the device still carries mains voltage
inside. To disconnect the device completely from
mains power supply, the mains plugs must be withdrawn from the wall socket. Please make sure that the
mains plugs are easily accessible. Even when the unit
is in standby mode, it has a low power consumption. If
the unit is not to be used for a long period disconnect
it from the mains supply at the wall socket.
The device is designed to operate in a tem-
Where the equipment is to be used for other purposes,
especially in the medical eld or any eld in which
safety is an issue, it is essential to establish the unit’s
suitability for this purpose with the manufacturer, and
to obtain prior written approval for this usage.
If the unit gets very cold (e. g. when being transported),
condensation may form inside it. Please do not switch
it on until it has had plenty of time to warm up to room
temperature, so that any condensation evaporates
completely.
perate climate and altitudes up to 2000 m
above sea level. The range of permissible
operating temperatures is +10 … +35°C.
This device is designed exclusively for
reproducing sound and/or pictures in the
domestic environment. It is to be used in a
dry indoor room which meets all the recommendations stated in these instructions.
Before placing the unit on sensitive lacquer or wood
surfaces please check the compatibility of the surface
and the unit‘s feet on a non-visible point and if necessary use an underlay. We recommend a surface of
stone, glass, metal or the like.
Please consider the weight of the device. Never place
the device on an unstable surface; the machine could
fall off, causing serious or even fatal injury. Many
injuries, especially to children, can be avoided if the
following simple safety precautions are observed:
•Use only such items of furniture which can safely
bear the weight of the device.
•Ensure that the device does not project beyond the
edges of the supporting furniture.
•Do not place the device on tall furniture (e.g. bookshelves) without securely anchoring both items, i.e.
furniture and device.
•Explain to children the hazards involved in climbing
on furniture to reach the device or its controls.
The unit should be set up in a well ventilated dry site,
out of direct sunlight and away from radiators. The unit
must not be located close to heat producing objects or
devices, or anything which is heat sensitive or highly
ammable.
The ventilation openings must not be covered or
closed. If the system components are to be stacked
then the device must be the top unit. Do not place any
object on the top cover.
When installing the unit on a shelf or in a cupboard
it is essential to provide an adequate ow of cooling
air, to ensure that the heat produced by the unit is
dissipated effectively. Any heat build up will shorten
the life of the unit and could be a source of danger. Be
sure to leave free space of 10 cm around the unit for
ventilation.
Liquid or particles must never be allowed to get inside
the unit through the ventilation slots. Mains voltage is
present inside the unit, and any electric shock could
cause serious injury or death. Never exert undue force
on mains connectors.
Protect the unit from drips and splashes of water; never place ower vases or uid containers on the unit.
Do not place naked ame sources, such as candle
lights on the device.
10
Page 11
Disconnect the mains plug at the wall socket before
cleaning the case.
The surfaces of the case should be wiped clean with a
soft, dry cloth only.
Never use solvent-based or abrasive cleaners!
Before switching the unit on again, check that there
are no short-circuits at the connections, and that all
cables are plugged in correctly.
If the device has been in storage, or has not been used
for a protracted period (> two years), it is essential to
have it checked by a specialist technician before reuse.
The terminals (marked with the -symbol)
Always avoid touching terminals and sockets and
the conductors of cables connected to them. Unless
ready-made cables are used, all cables connected to
these terminals and sockets must always be deployed
by a trained person.
By attaching the CE symbol to the unit T+A declares
its conformity the EC directives and the national laws
based on those directives. The declaration of conformity can be downloaded from www.ta-hi.com/DoC.
The original, unaltered factory serial number must be
present on the outside of the unit and must be clearly
legible! The serial number is a constituent part of our
conformity declaration and therefore of the approval
for operation of the device. The serial numbers on the
unit and in the original T+A documentation supplied
with it (in particular the inspection and guarantee certicates), must not be removed or modied, and must
correspond.
Infringing any of these conditions invalidates T+A
conformity and approval, and the unit may not be operated within the EC. Improper use of the equipment
makes the user liable to penalty under current EC and
national laws.
Any modications or repairs to the unit, or any other
intervention by a workshop or other third party not
authorised by T+A, invalidates the approval and operational permit for the equipment.
Only genuine T+A accessories may be connected to
the unit, or such auxiliary devices which are themselves approved and full all currently valid legal requirements.
can carry high voltages.
In its original condition the unit meets
all currently valid European regulations. It is approved for use as stipulated
within the EC.
The case should only be opened by a qualied specialist technician. Repairs and fuse replacements
should be entrusted to an authorised T+A specialist
workshop. With the exception of the connections and
measures described in these instructions, no work of
any kind may be carried out on the device by unqualied persons.
If the unit is damaged, or if you suspect that it is not
functioning correctly, immediately disconnect the
mains plug at the wall socket, and ask an authorised
T+A specialist workshop to check it.
The unit may be damaged by excess voltage in the
power supply, the mains circuit or in aerial systems, as
may occur during thunderstorms (lightning strikes) or
due to static discharges.
Special power supply units and excess voltage protectors such as the T+A ‚Power Bar‘ mains distribution
panel offer some degree of protection from damage to
equipment due to the hazards described above.
However, if you require absolute security from damage
due to excess voltage, the only solution is to disconnect the unit from the mains power supply and any
aerial systems.
To avoid the risk of damage by overvoltages we recommend to disconnect all cables from this device and
your HiFi system during thunderstorms.
All mains power supply and aerial systems to which
the unit is connected must meet all applicable safety regulations and must be installed by an approved
electrical installer.
The device is not designed for use by children. The
device must not be operated unsupervised. Make sure
that it is out of reach of children.
Batteries shout not be exposed to excessive heat like
sunshine, re or the like.
Very loud continuous listening to program material via
earphones, headphones and loudspeakers can lead to
permanent loss of hearing. Prevent health risks and
avoid permanent hearing at high volume.
If the device has to be stored, place it in its original
packaging and store it in a dry, frost-free location.
Storage temperature range 0...40 °C
The only permissible method of disposing of
this product is to take it to your local collection centre for electrical waste.
Registration according to the EU directive
“Waste Electrical and Electronic Equipment”
WEEE-Reg.-No.: DE 72473830W
11
Page 12
Getting started
General information
For a quick start into the listening pleasure of your new multi-source player, this chapter describes the
most important steps for the rst start-up and basic operation.
A detailed explanation of the operation and all functions can be found in the following chapters.
Scope of delivery
Infrared remote control handset FM200
Power cord
2 antennas for WLAN and Bluetooth
2 antenna bases for the WLAN and Bluetooth antenna
Radio antenna with adapter
USB interface cable for USB-SYS connection (MP 200 to HA 200 or DAC 200)
System interface cable (RJ-45) for the SYS-OUT to SYS-IN connection (MP 200 to HA 200 or DAC 200)
Set up
Set up the device at a appropriate place. Please observe all notes regarding connection and installation in
the chapter Safety notes (pages 10 and 11).
Connections
Establish all connections shown in the connection diagram. If you are operating the MP 200 via the LAN
connection, you do not need to connect the WLAN antenna.
When using the WLAN connection, the two antennas should be positioned as far away from each other as
possible.
Plug all connectors rmly into the corresponding sockets and screw the antenna connectors hand-tight.
The supplied radio antenna (cable antenna incl. adapter) must be unfolded completely and spread out in a
T-shape for proper radio reception.
12
The connection diagram (on the right side) shows the connection of the MP 200 in conjunction with a
j
DAC 200. The HA 200 is connected in the same way.
Please refer to the wiring diagram in the chapter Connection and wiring for connecting the MP 200 to
other devices.
Page 13
Wiring diagram
For the rst use, please establish the necessary connections as shown below.
• WLAN-antenna or network cable to your router
• VHF antenna
• Bluetooth antenna
• USB SYS conection (For operation in combination with a DAC 200 or HA 200)
• SYS OUT to SYS IN connection (For operation in combination with a DAC 200 or HA 200)
• Mains cord
Do not connect the MP 200 and the other components to the power supply until all the necessary
connections between the devices have been made.
VHF + DAB antenna
to Router
*
to wall socket
*
* Depending on which type of network connection you wish to use, connect
the WLAN antenna or a network cable to the router.
Fig. 1
13
Page 14
Switching on and off
• In stand-alone operation and in conjunction with a DAC 200 or HA 200, the MP 200 can be switched on
and off by briey tapping the button on the MP 200.
• When operating in conjunction with a DAC 200 or HA 200, the devices can be switched off together using
the button on the DAC or HA.
• To switch on, either tap the button on the device or the button on the remote control.
• It is also possible to switch on the MP 200 directly with a source selection button on the device or the
source selection rocker on the remote control.
Example:
If you tap the source selection button DISC on the MP 200, it switches on with the source Disc. A possibly
connected DAC 200 or HA 200 is automatically switched on and set to the system input SYS IN for playback.
Source selection rocker
Source selection buttons
Connecting to network
Wired network connection
If the MP 200 will be operated via a LAN connection and not via WLAN, connect the LAN port to an operational network (router) with Internet access as shown in Fig. 1.
After switching on and booting the streaming module, the device will automatically connect to your network.
We recommend a wired network connection via LAN cable for streaming high-resolution music material.
j
Depending on the reception quality and the trafc load from other users, a WLAN connection can reach its capacity limit more quickly, which may lead to playback dropouts.
Set up a WLAN connection automatically via WPS
• Make sure that the WLAN antenna is connected correctly. (Fig. 1)
• Start the WPS function of your router / access point (refer to the router‘s manual for information).
• Now open the system settings by a brieg press on the SYS button on the front panel of the MP 200.
• Select the Network menu item by turning the SELECT knob and conrm by pressing the SELECT knob.
• Then select the WPS Autoconnect menu item by turning the SELECT knob.
• Start the WPS function of the MP 200 by pressing the SELECT knob.
• Wait until the device has automatically connected to the WLAN and the name of the network has been
adopted in to the eld Status.
• Exit the menu by a briey pressing the SYS button again.
14
If you prefer manual setup or setup via access point and our T+A Music Navigator App, you will nd more infor-
j
mation regarding WLAN setup in the chapter Network conguration starting on page 31.
Page 15
Selecting a source
• Select the desired source by pressing the corresponding source
selection button on the device repeatedly, if necessary, or press the
source selection button on the remote control repeatedly until the
source is shown in the display.
• When operating the MP 200 without a DAC 200 or HA 200, the source
can alternatively be selected via the
control (press repeatedly if necessary).
Source selection
rocker
Source selection
buttons
... buttons on the remote
j
If the MP 200 is operated in a system network with a DAC 200 or an HA 200, the source selection buttons
... of the remote control are used for the source selection of the DAC 200 or HA 200 sources. In this case,
source selection at the MP 200 via remote control is done exclusively via source selection rocker.
For a faster and more convenient source selection, not required sources can be deactivated in the system
settings. See chapter System settings.
Browsing through lists
• A folder/title/station/favorite can be selected by turning the SELECT knob on the front panel. The selected list entry is displayed in enlarged form.
• The selected list entry can be opened or played by pressing the SELECT knob depending on the type
(folder/title/station etc.).
• A long press on the SELECT knob jumps back to the previous level (if available).
15
Page 16
• Selects the previous list
• Conrmation button in lists
• Starts playback
• Back to the previous level
• Back to list navigation during
playback
Playback
enty
• Enters the next level during folder
navigation
• Plays selected item
• Selects the next list entry
• A brief press on the SELECT knob starts playback.
• A brief press on the SELECT knob during playback pauses it.
• Press briey again to resume.
• A long press on the SELECT knob stops playback.
Source FM, DAB and DISC:
• Turn the SELECT knob to select the next track/station.
All streaming sources:
• Turn the SELECT knob to return to the selection list during
playback.
• Select the next desired title / station / podcast / etc. for
playback and start playback by a brief press on the SELECT
knob.
• A brief press on the
• Briey pressing the button again during playback pauses it.
• To resume, press the button again briey.
• A long press on the button stops playback.
• Use the buttons to select the next title / station during playback.
button starts playback.
16
Source FM, DISC, UPnP, USB, Tidal and Qobuz:
• Press and hold one of the buttons to start the search in upward or
downward direction.
By pressing the button on the remote control or the button on the MP 200, the display mode can
j
be switched between a large format display with the most important information and a detailed view with
smaller fonts and additional information such as bit rate etc.
Page 17
17
Page 18
Connections
This and the following chapter describe all things of
fundamental importance for
installation and setup that
are not relevant for the daily
use of the device, but which
should be read and observed before the rst use.
1
2
3
Bluetooth antenna
BT ANT
Socket for connecting the bluetooth antenna.
Digital In- and Outputs
DIG OUT
DIG IN
The signals from the selected source are available at this socket. The data can be fed
to another device such as a surround decoder or a DAC.
Inputs for digital source devices with optical and coaxial digital outputs.
The MP 200 accepts digital stereo signals at the inputs according to the S/P-DIF stan-
j
dard with sampling rates from 32 to 192 kHz.
LAN connection
LAN
Socket for connection to a wired LAN (Ethernet) home network.
If a LAN cable is connected this will have priority over wireless WLAN net-works. The
j
WLAN module of the MP 200 will automatically be disabled.
(S/P-DIF)
18
4
USB input
HDD
Socket for a USB memory stick or external hard discs
The storage medium can be formatted with the FAT16, FAT32, NTFS, ext2, ext3
or ext4 le system.
The USB storage medium can be powered directly via the USB port provided
that its current drain is in accordance with the USB norm. Normalised 2.5” USB
hard discs can be connected directly, i.e. without a separate mains PSU.
Page 19
5
Radio antenna
6
7
RADIO ANT
This FM antenna input can be connected to a normal 75 Ohms FM home antenna or to
TV/FM cable networks.
The supplied antenna is suitable for receiving strong local stations. To receive weaker
j
stations, a proper outdoor or roof antenna is required. For rst-class reception quality a
high-performance aerial system, competently installed, is a basic requirement.
System interfaces
USB SYS
SYS OUT
CTRL
Audio connection to the DAC 200 or HA 200. Connect this socket to the USB SYS connector on the DAC 200 or HA 200.
For details please refer to the wiring diagram
Control interface for operation with a DAC 200 or HA 200.
If the MP 200 is operated in combination with a DAC 200 or HA 200, these sockets must
j
be connected to the USB SYS and SYS IN socket of the DAC 200 or HA 200.
Interface for later functions expansions.
Mains input
The mains lead is plugged into this socket.
8
WLAN socket
WLAN
Input socket for WLAN antenna
If no wired LAN connection is found, the MP 3100 HV will automatically activate its
j
WLAN module and it will try to get access to your WLAN network.
19
Page 20
Installation and connection
Installation
Carefully unpack the device and store the original packaging carefully. The carton and packing material
are specially designed for this device and will be a safe container during any later transports. Set up the
device at a proper place. Please observe all notes on connection and set-up in the chapter Safety notes
(pages 10 and 11).
Connection
To use the MP 200 with all its functions and sources, rst you have to make some important connections
and/or connect antennas.
The necessary connections are described below:
Do not connect the MP 200 and the other components to the power supply until all the necessary con-
nections have been established.
WLAN antenna
To connect the MP 200 to your network (router) via WLAN, connect one of the two supplied antennas to the
WLAN socket.
In case of poor reception conditions, the antenna can be
j
mounted on the supplied antenna base and placed freestanding.
This antenna is not required if the device is connected to the Internet via a wired network (LAN).
j
LAN
20
For the connection to your network (router), connect the network cable to the LAN port.
When using the WLAN connection, this socket must remain free!
j
Page 21
BLUETOOTH antenna
For audio streaming via Bluetooth, e.g. from a smartphone to the MP 200 , one of the two antennas must
be connected to the BT socket.
Connection of digital source devices
At the digital inputs of the MP 200 (Digital IN) you can connect devices with electrical coax or optical ber
output.
The MP 200 accepts at all inputs digital stereo signals according to the S/P-DIF standard with sampling rates
j
from 32 kHz to 192 kHz.
Connected to a DAC 200 or HA 200
The MP 200 is designed for operation in conjunction with the DAC 200 or HA 200. For this purpose, the MP
200 is equipped with the system interfaces USB SYS and SYS IN/OUT.
If the MP 200 will be operated in conjunction with a DAC 200 or HA 200, these two interfaces must be connected. See also the wiring diagrams in the chapter Connection and cabling.
Operation with other devices
For operation with other DACs or ampliers, connect the DIG OUT digital output to the corresponding digital input of the device you are using.
Connecting the power cord
Connect the mains cable to the mains socket of the MP 200 and then connect the device to the wall outlet.
To achieve the maximum signal-to-noise ratio, the mains plug should be plugged into the wall outlet in
such a way that the phase is connected to the contact of the mains input socket which is marked with a
dot. The phase of the mains socket can be determined with a measuring device suitable for this purpose.
Please contact your specialist dealer.
21
Page 22
Controls and functions
1
2
3
On / Off switch
A brief press of this button switches the device on and off. When the device is
switched on, the LED above the button lights up.
Front USB socket
USB
Connection socket for a USB memory stick or an external hard drive
The USB storage medium can be powered via the USB socket provided that its current
j
drain meets the USB norm (< 500 mA). Normalised 2.5” USB hard discs can be connected directly to this socket, i.e. they require no mains PSU.
Function buttons
By a brief press on this button, the favorites list created on the MP 200 is called up.
Presets for the sources FM radio, DAB radio and Internet radio can be saved in the
list (please refer to the chapter Favourite lists).
By briey pressing the button, you can cycle through the different display views.
Detailed display with / without CD text / Radiotext (if present) and large display with
/ without CD text / Radiotext (if present).
22
A brief press will eject the inserted CD.
Page 23
4
Source selection
5
DISC
SCL
RADIO
BT
USB
DIG IN
Selects the CD player
Selects the SCL function (e.g. access to music servers, streaming services or similar).
Press this button repeatedly until the desired source appears on the screen.
Selects one of the following radio sources: FM / VHF (FM RADIO source), DAB (DAB
RADIO source), Internet radio (Internet radio source) or Podcasts. Press this button
repeatedly until the desired source is displayed on the screen.
A brief press selects the bluetooth function of the MP 200.
Selects the USB inputs for playback
A brief press on this button selects the digital input you wish to use. Press the button
repeatedly until the desired input is displayed on the screen.
System and source menu
SYS
SRC
A brief press of the button calls up the menu for system settings.
Details about the settings can be found in the chapter Settings.
Opens the setup menu for the currently selected source.
Not all sources have their own setup menu. For this reason, the button has no function
j
for some sources.
6
7
8
Remote control receiver
When operating by remote control, please point the FM200 in the direction of the
receiver.
Menu operation and playback control
SELECT / OK
By turning this knob, a title/track can be selected for playback. The selected title
appears in the display. As soon as the desired title number lights up here, the title can
be started by pressing the control knob. In addition to the title selection, the Select
knob also has other functions such as navigation in lists, menu control, etc.
Display
Selected source
Current playing title
Artist - Album title
Status indicator
9
Disc drive
Playing time indicator
Feed slot for 12 cm discs. Insert the disc with the labeled side facing up until the disc
feeds automatically.
The drive is designed to play standard 12 cm round discs only. Do not insert 8 cm discs or
j
discs with unusual shapes. These may damage the drive.
23
Page 24
Remote control
On / Off Switch
A brief press switches the MP 200 on.
Hold the button pressed in to switch the device off.
Source selection
System
network
Settings
Stand-Alone Source
DISC
UPNP
DEEZER
QOBUZ
TIDAL
ROON READY
FM
DAB
INTERNET RADIO
PODCAST
BLUETOOTH
USB MEDIA
DIGITAL IN 1
DIGITAL IN 2
DIGITAL IN 3
To select the desired
source, press the corresponding source select
button if necessary
repeatedly.
NOTE
Not required sources can
be deactivated in the system settings for an even
more comfortable source
selection.
A brief press
Opens the menu for system settings (see page 28).
A long press
Opens the menu with settings for the currently active source (not
available for all sources).
Playback and menu operation
• Conrmation button in lists.
Starts playback.
• Pauses the current playback
• A long press stops playback and
ejects the CD.
• Returns to list navigation during playback.
• Press and hold to search
backwards.
24
• Selects the previous item within a list.
• Selects the next track/station during
playback.
• Enter the next list level.
• Starts playback.
• Press and hold to search forward.
• Selects the next item within a list.
• Selects the previous track / station
during playback.
Page 25
Menu operation
Use the buttons to select an item in the menu.
Press the button to activate the selected menu item.
Use the buttons to change the settings.
Press the button to conrm the setting.
Press and hold the button to return to the previous menu level.
Alpha-numeric entry
To enter a source name, user data or network parameters, rst activate the relevant input eld with
the button.
If necessary, existing entries can be deleted by pressing the button repeatedly.
Press the buttons on the remote control handset: repeatedly until the desired letter appe-
ars on the screen. Briey press the button to enter the next letter.
Press the button to conrm the entry.
Use the button for toggling between numbers, capitals and lower-case letters. The bottom
line of the screen shows which input mode is currently selected.
123
1234567890
abc
abcdefghijklmnopqrstuvwxyz -*/^={}()[]<>.,?!:;\“´_@$%&#~ 0123456789
ABC
ABCDEFGHIJKLMNOPQRSTUVWXYZ -*/^={}()[]<>.,?!:;\“´_@$%&#~ 0123456789
Function buttons
A brief press
Adds a favorite to the favorites list
In the system conguration menu: Activates a source
A long press
Removes a favorite from the favorites list.
In the system conguration menu: Deactivates a source
A brief press
Cycles through the various screen displays.
Detailed display with / without CD text / Radiotext (if present) and large display with / without CD
text / Radiotext (if present).
Switches between capitals and lower case, and numeric / letters, when entering data.
A long press
When necessary, repeated long presses of the button cycle through the various playback modes
(repeat track, repeat whole disc, etc.).
A brief press
Calls up the Favorites / Presets list for the currently active source (not available for all sources).
A long press
Switching between stereo and mono reception (only available for FM radio)
25
Page 26
Replacing the battery
To change the battery of the remote control, rst remove the two screws shown in Figure 1. Then remove
the battery holder by pulling it downwards. Insert a new CR 2032 battery into the battery holder according
to the marking ( + on the battery facing downwards). Now insert the holder as shown and use two screws
to fasten the holder.
Range
When operating by remote control, please hold the
FM200 in the direction of the remote control receiver.
The range of the remote control is approx. 4..5 m.
The line of sight between FM200 and the remote control
receiver must not be interrupted by obstacles.
The direct incidence of interfering light (e.g. from uorescent and energy-saving lamps) into the receiver should
be avoided at all times, as otherwise the range of the
remote control can be considerably reduced.
Important information
• The remote control handset supplied in the set contains a button cell battery.
j
• Do not swallow the battery: chemical burn hazard. If this button cell is ingested, within two hours it may
cause serious internal chemical burning which could result in death
• If you suspect that someone might have swallowed a battery, or that a battery could have entered any
part of the body, seek immediate medical assistance.
• If the battery is replaced improperly, there is danger of explosion. Always replace batteries by batteries
of the same or an equivalent type.
• Keep new and used batteries well away from children.
• If you cannot close the battery compartment securely, cease using the product, and keep it away from
children.
• Batteries shout not be exposed to excessive heat like sunshine, re or the like.
26
• Very low air pressure may result in explosion of the battery, or leakage of ammable liquids or gases.
• Protect the remote control from humidity, coldness, heat and dust.
• Exhausted batteries must never be thrown into the household waste! They should be returned to the battery
vendor (specialist dealer) or your local toxic waste collection point, so that they can be recycled or disposed
in a proper way. Most local authorities provide collection centres for such waste, and some provide pick-up
vehicles for old batteries.
Page 27
Settings
Menu operation
Operation on the device
• To call up the system settings menu, press
the SYS button 1 on the front of the MP 200.
• Select an item in the menu with the SELECT
knob 2.
• To change a selected menu item, conrm by
pressing the SELECT knob and then change it by
turning the knob.
• To conrm the setting, press the knob again after
the change.
• To cancel a change, you can always press the
SELECT button for a long time or briey press the
SYS button.
• By pressing the SELECT knob for a long time, you
can return to the previous menu level.
• To exit the menu, press the SYS button.
Operation by remote control
• To open the system settings menu, press the
button on the remote control.
• Use the buttons to select an item in the
menu.
• To change a selected menu item, rst press
the button and then use the buttons
to alter the setting.
• To conrm the setting, press the button again
after changing it.
• To cancel a change, you can always abort by a
long button press on or by a brief press on the
button.
• Press and hold the button to return to the
previous menu level.
To exit the menu, press the button..
27
Page 28
System settings
Source
conguration
At this menu item you can activate and disable not used sources, and assign a plain text
name to each source; this name then appears in the screen displays.
You can also assign a plain text name for the display to the external sources (digital inputs and Bluetooth).
When this menu item is called up with the button, a list of all sources of the MP 200
appears.
Each source is followed by the displayed plain text name or the note Enabled for an
active source or Disabled if the source is deactivated.
Deactivate not required sources
A long press on the button deactivates the selected source.
To activate a source, press the button briey.
Change the source name
To change the plain text name, rst select the corresponding source and press the
button.
Delete the previous name by repeatedly pressing the button.
Enter the new name using the cursor keys.
Apply entry
Select letter / number / symbol
Display brightness
Display mode
Delete previous
digit
To switch between numeric and alphanumeric input as well as upper/lower case, press
the button.
If you should wish to restore the factory default source name, erase the whole name
before saving the empty eld with the button: this action resets the display to the
standard source names.
These settings can only be changed by using the remote control.
j
At this point you can adjust the brightness of the integral screen to suit your personal
preference for normal use.
Here you can set whether the display will be switched on permanently or only temporarily, when the device is being operated.
If the setting temporary is selected, the display is switched on during operation of the
MP 200 only and then automatically switched off again after a short delay.
If the Always ON setting is selected, the display remains permanently on.
Next digit
Select letter / number / symbol
28
Page 29
Colour prole
Under this menu item you can adjust the brightness of the status LEDs and the brightness and illumination color of the meters to your personal preferences.
Select the menu item Default colours to reset the displays to the default settings.
Language
Device name
Energy saver
Network
In this menu item you dene the language to be used for the displays on the screen of
the front panel of the MP 200.
The language used for data transferred to the machine, e.g. from an iPod or other Internet radio station, is determined by the supplying device or the radio station; you cannot
dene the language on the MP 200.
This menu point can be used to assign an individual name to the MP 200. In a home network the device then appears under this name.
The energy saving mode can be switched on and off here.
The machine has an Auto Power Down function.
If the ECO option is selected, the MP 200 automatically switches to standby mode if no
music signal and no operation is detected for more than 90 minutes.
If the Comfort setting is selected, the unit remains switched on until it is manually switched to standby mode.
In countries outside the EU where the EuP directive does not apply, the automatic power-off
j
function of the device (ECO setting) can be deactivated if required.
All network settings can be carried out at this menu point. For a detailed description on
setting up a LAN or WLAN connection please also refer to the section entitled Network
conguration on page 31.
Music services
At this point you can enter the access data for the music streaming services Qobuz
and Deezer.
TIDAL uses a special procedure for entering the access data. For this reason, the data
must be entered via the T+A Music Navigator app (please see next page for details). If
necessary, you can delete them later under this menu item.
Entering the user name and password
Apply entry
Delete previous
digit
To switch between numeric and alphanumeric input as well as upper/lower case, press
the
To store the credentials, select the menu item Store and exit? and press the
Deleting the credentials
You can delete the user data completely by selecting the menu item
Remove login and exit? and conrm by pressing the
button.
Select letter / number / symbol
Next digit
Select letter / number / symbol
button.
button.
29
Page 30
TIDAL credentials
To enter the TIDAL credentials, open the T+A Music Navigator App and select the
TIDAL source. Are no credentials stored, an internet browser with the TIDAL log-in
window will open automatically. Enter your credentials here and conrm the entry.
As soon as the login has been successfully completed, you can close the Internet
browser and return to the T+A app. Your data is now automatically saved and TIDAL
is available.
We recommend that you enter your TIDAL credentials via our app.
j
If no mobile device is available, the procedure can alternatively be carried out via the
Internet browser of your PC. For this, call up the TIDAL source on the MP 200 and press
the i button on the remote control or on the device. An Internet address and an activation code are displayed on the MP 200. Enter the address in the browser and open the
page. Enter the activation and conrm. You will be automatically redirected to the TIDAL
log-in page. Log in here with your credentials. The device is now logged in to TIDAL.
Bandwidth limit
Device info
Update
Update package
Main
Client
DAB/FM
Decoder
This menu point can be used to adjust the link speed of the Internet connection. The
bitrate of the Internet radio stations and streaming services is adjusted automatically
to match your chosen setting. If you select no limit for bandwidth limit, the highest available quality is always selected automatically.
At this menu point you will nd information on the status of the installed software and
the factory reset.
A rmware update can be started here
This point displays the currently installed software package
Display of the main control processor software version
Display of the streaming client software version
Display of the tuner software version
Display of the disc decoder software version
30
Bluetooth
Bluetooth pairings
Factory settings
Legal information
Display of the bluetooth software version
All existing Bluetooth pairings can be deleted under this menu item
By calling up and conrming this menu item, all personal settings are deleted and the
delivery status is restored
Information on accessing the legal information and license notices
Page 31
Network conguration
General information
All network settings are carried out in the system settings under the menu item Network.
If the MP 200 is not connected to a wired network via its LAN port, the WLAN module is activated and the
the Network menu displays the menu items for setting up the WLAN connection.
If you want to connect the MP 200 to the home network via WLAN, the LAN port must remain free.
j
Menu operation
• Open the system settings menu by pressing the button on the remote control.
• Select the Network menu item with the buttons and conrm with the button.
• In the network menu, select the network parameter to be changed with the buttons and activate
the entry with the button.
• Now you can change the setting depending on the type with the following buttons:
buttons at simple selection (ON/OFF)
buttons at IP addresses and alphanumeric input of text.
• After the setting has been made or the address has been entered completely, conrm the entry with
the button.
The network parameters can only be set using the remote control.
j
Connection via LAN (cable connection)
• Connect the MP 200 to an operational network (router) or power line modem via the rear LAN port.
• Switch on the MP 200.
• Usually, an IP address is automatically assigned to
the MP 200 by your router (via DHCP) and the MP 200
is ready for operation after the start-up process of
the streaming module.
• If this is not the case, open the network menu (Network) and set the network parameters listed below
according to your network settings.
Menu item Setting / Explanation
MAC The MAC address is a hardware address which uniquely identies your machi-
ne. The address displayed is determined by the manufacturer, and cannot be
altered
Conncetion state Shows the connection state: WLAN, LAN or not connected
31
Page 32
DHCP on
If your network includes a DHCP server, please select the ON setting at this
point. In this mode an IP address is automatically assigned to the MP 200 by
the router. The screen shows only the MAC address and the message DHCP
state ON. In this case the address input elds shown in the illustration do not
appear in the menu.
off
If your network does not include a DHCP server, please select the OFF setting. In this mode you must congure the following network settings manually.
Please ask your network administrator for the addresses to be entered for your
network.
IP IP Adress of the MP 200
Subnet mask Network mask
Gateway IP Adress for the router
DNS Name / IP of the name server (optional)
Store and exit? Stores the network parameters, and restarts the MP 200 with the new settings
Discard and exit? Closes the menu: data already entered is discarded
Connecting to WLAN (radio connection)
• Connect the supplied WLAN antenna to the WLAN
socket on the back of the MP 200. Depending on your
reception and set-up situation, the antenna can be
mounted directly on the socket on the back or together with the magnetic base supplied (see g.).
• Switch on the MP 200.
• Open the menu for system settings and then the
menu item Network.
Menu item Setting / Explanation
MAC The MAC address is a hardware address which uniquely identies your machi-
ne. The address displayed is determined by the manufacturer, and cannot be
altered.
Conncetion state Shows the connection state: WLAN, LAN or not connected.
WPS autoconnect Activates the WPS function to connect the MP 200 to the WLAN via WPS. See
chapter Setup via the WPS function.
32
Scan for WLAN Starts the scan for WLAN networks that are within reception range.
WLAN access point Starts the access point mode to set up the WLAN connection via the T+A App TA
Music Navigator. See chapter Conguration via Access Point.
All other menu items are the same as for the connection via LAN. See above for more information.
j
Page 33
Conguration using the WPS function
• First activate the WPS-function of the Router or Repeater to which you wish the MP 200 to be connected. For details please refer the manual of the device in question.
• Start the WPS-Autoconnect function of the MP 200 within 2 minutes.
• Use the buttons to select the menu point “WPS-Autoconnect”, then conrm your choice
with the button.
• After the connection is established, the line Status shows the connected WLAN network.
• Finally select the “Store and exit?” menu point and press the button to accept the settings.
Manual setup of the WLAN connection
• First select the Scan for WLAN menu item and conrm it with the button.
• A list of the WLANs found appears.
• Use the buttons to select the WLAN to which you wish the MP 200 to be connected, and conrm
your choice with the button.
• Enter the network password (passphrase) and conrm your entry with .
• Conrm and store the settings by selecting the item Store and exit? and pressing .
• Finally, select the menu item Store and exit? again and conrm the settings with the button again.
Setting up the WLAN connection via the T+A app (TA Music Navigator)
The MP 200 supports setting up the WLAN connection via an access point. This means that the MP 200
provides its own WLAN for the duration of the conguration of the WLAN settings. As soon as the conguration is complete, this WLAN is deactivated again. The MP 200 restarts and connects to the WLAN congured via the app.
• Turn on the MP 200 and open the system conguration menu by pressing the button on the remote
control or the SYS button on the front of the MP 200.
• Use the buttons to select the menu point Network, then conrm your choice with the button.
• Use the buttons to select the menu point Access Point, then conrm your choice with the button.
• The MP 200 activates the WLAN access point.
• The following steps must be performed within approximately 5 minutes. After this time, the MP 200 will
exit access point mode automatically.
• Connect the smartphone or Tablet PC on which the T+A-app is installed to the WLAN access point. The
network name (SSID) is „T+A AP MP 200“ and the passphrase is “01234567”.
• Start the T+A-app for operation.
• The app recognizes the access point and starts automatically with the setup wizard.
• To set up the WLAN, go through the individual steps of the app‘s setup wizard.
• Quit the app, then connect your phone or tablet to your previously set up wireless LAN.
• After restarting the app the MP 200 will be detected automatically.
• Once the MP 200 is detected, it can be selected for playback.
33
Page 34
Source operation
Selecting a source
• Select the desired source by pressing the corresponding source
selection button on the device repeatedly, if necessary, or press the
source selection button on the remote control repeatedly until the
source is shown in the display.
• When operating the MP 200 without a DAC 200 or HA 200, the source
can alternatively be selected via the
control ( press) repeatedly if necessary.
Source selection
rocker
Source selection
buttons
... buttons on the remote
j
If the MP 200 is operated in a system network with a DAC 200 or an HA 200, the source selection buttons
... of the remote control are used for the source selection of the DAC 200 or HA 200 sources. In this case,
source selection at the MP 200 via remote control is done exclusively via source selection rocker.
For a faster and more convenient source selection, not required sources can be deactivated in the system
settings. See chapter System settings.
As soon as you have selected the desired source on the MP 200, a connected DAC 200 or HA 200 automatically
selects its system input for playback. The display of the DAC 200 or HA 200 now shows SYS IN.
If the MP 200 is already set to the correct source, but another source has been selected for playback on the
DAC 200 or HA 200 in the meantime, it is possible to switch to the system input of the DAC 200 or HA 200 by
briey pressing the source selection button of the MP 200 once again.
34
Page 35
Browsing through lists
• Conrmation button in lists
• Starts playback
• A folder/title/station/favorite can be selected by turning the
SELECT knob on the front panel. The selected list entry is
displayed in enlarged form.
• The selected list entry can be opened or played by pressing
the SELECT knob depending on the type (folder/title/station
etc.).
• A long press on the SELECT knob takes you back to the previous level (if available).
• Selects the previous list
enty
• Back to the previous level
• Back to list navigation during
playback
Playback
• Enters the next level during folder
navigation
• Plays selected item
• Selects the next list entry
• A brief press on the SELECT knob starts playback.
• A brief press on the SELECT knob during playback pauses
it.
• Press briey again to resume.
• A long press on the SELECT knob stops playback.
Source FM, DAB and DISC:
• Turn the SELECT knob to select the next track/station.
All streaming sources:
• Turn the SELECT knob to return to the selection list during
playback.
• Select the next desired title / station / podcast / etc. for
playback and start playback by a brief press on the SELECT
knob.
35
Page 36
Display
The MP 200 features different screen views for the internal sources (streaming, CD player radio sources,
Bluetooth and USB) for playback
• A brief press on the button starts playback.
• Briey pressing the button again during playback pauses it.
• To resume, press the button again briey.
• A long press on the button stops playback.
• Use the buttons to select the next title / station during playback.
Source FM, DISC, UPnP, USB, Tidal and Qobuz:
• Press and hold one of the buttons to start the search in upward or
downward direction.
Detailed view:
Display with smaller font and a lot of
additional information like bitrate etc.
Enlarged view:
Large-format display of the most important information, easy to read even
from a greater distance.
You can toggle between the display modes by pressing the j button on the front of the MP 200 or by
pressing the button on the remote control. The change of the setting is only visible during playback.
36
Page 37
37
Page 38
Favourites list
General information
The MP 200 includes the facility to create Favourites lists. The purpose of these lists is to store radio
stations and podcasts, so that they can be accessed swiftly.
Each of the sources FM radio, DAB radio, and Internetradio features its own Favourites list.
Once stored, the favourites can either be selected from the Favourites list, or called up directly by
entering the program location number. The option of selecting using the location number is particularly useful when you wish to call up favourites when the screen is not in view (e.g. from an adjacent
room) or using a house control system.
Favourites lists for the various music services (TIDAL etc.) are not supported.
j
Instead it is usually possible to add Favourites and Playlists on-line via the provider’s account. These can then
be called up and played via the MP 200.
Calling up the Favourites list
• The rst step is to switch to one of the sources listed above.
• Press the
Here the program location number is displayed within the list. Since it is possible to
1
erase individual list items, the numbering may not be continuous.
Position display in the Favourites list.
2
The selected list entry is displayed in enlarged form.
3
button to call up the Favourites list.
Adding a favourite
If you especially enjoy the piece of music or radio station to which you are currently listening,
simply press the
sponding Favourites list.
button on the remote control; this action stores the station in the corre-
Erasing a favourite from the Favourites list
Open the Favourites list by pressing the button. Use the buttons to select the station in the
list which you wish to erase, then hold the button pressed in; this action removes the item from the
Favourites list.
38
Page 39
Play Favourites
Call up the favourites list by pressing the button on the remote control or the button on the MP
200‘s front panel.
Select a stored favourite from the favourites list using the buttons or by turning the SELECT knob on
the MP 200. The selected favourite is displayed enlarged.
By pressing the
Sort Favourites
The sequence of items in the Favourites list you have created can be altered in any way you wish. This is
the procedure for changing the order of the list:
button or by pressing the SELECT knob, the favourite is selected for playback.
• First, call up the Favourites list by briey pressing the
on the MP 200.
• Select the favourite that you wish to change the position of with the
or by turning the SELECT knob on the MP 200. The selected favourite is displayed enlarged.
• Pressing the
for the selected favourite. The favourite is highlighted.
• Now move the activated favourite to the desired position in the favourites list using the
the remote control or by turning the SELECT knob on the MP 200.
• Pressing the
position.
button on the remote control or the j button on the MP 200 activates the sort function
/ j key again deactivates the sorting function. The favourite is now stored at the new
button on the remote control or the button
buttons on the remote control
buttons on
• The favourite is now stored at the new position. To close the favourites list, briey press the
button again.
If you have previously erased a number of favourites, you may well nd that some program locations in the
j
Favourites list are missing (empty). Nevertheless, the favourites can still be moved to any location in the list!
/
39
Page 40
Radio operation
General information
The MP 200 features an FM Tuner (VHF radio) with HD Radio™ technology*, a DAB / DAB+ reception section (digital radio) and also includes the facility to stream Internet radio. The following section describes in
detail how to operate the individual radio sources.
HD Radio technology enables radio stations to transmit analogue and digital programmes on the same
frequency simultaneously.
The integral DAB+ receiving section is backwards-compatible with DAB, to ensure that you have access to
a wide range of stations.
FM Radio
Press the RADIO button on the front panel of the MP 200 or the button on the FM 200
remote control repeatedly if necessary until the source FM Radio is shown in the display.
* HD Radio™ technology only available in US-version.
Display
1
2
3
4
Displays the selected radio source.
Here the music type or style is displayed, e.g. Pop Music.
This information is only displayed if the transmitting station broadcasts it as part
of the RDS system. If you are listening to a station which does not support the RDS
system, or only supports it in part, these information elds remain empty.
The frequency and / or the station name is displayed in enlarged form. If a station name is displayed,
its frequency is shown in area 5.
These lines display information which is broadcast by the station (e.g. Radiotext).
40
Display of Stereo / Mono
5
The eld strength and therefore the reception quality to be expected from the set transmitting
6
station can be assessed from the eld strength.
FM Radio: when receiving an HD Radio broadcast, here the currently selected programme from
the total number of programmes available is displayed too (left side), e.g. programme 2 of total 3
available.
Page 41
Manual station search
Operation by remote control
Press and hold one of the
downward direction. The station search stops automatically at the next station found. By repeatedly short
presses on the buttons on the remote control, it is possible to select a specic frequency.
Once the desired station has been selected, it can be added to the Favourites list by pressing the
ton. (see also chapter „Favourite lists“)
Operation at the device
Manual selection of a specic frequency is also possible via the SELECT knob on the device. By pressing
the SELECT knob several times, if necessary, you can switch between the functions of the SELECT knob for
a short time. The currently selected operating mode is shown at the bottom left of the display (only in the
detailed display setting). The following functions can be selected:
Display indicator Function
Freq Manual frequency tuning
Fav Selecting a stored favourite
None (Standard setting) Selecting a station from the station list
HD HD Radio programme selection (if available)
buttons on the remote control to start the station search in upward or
but-
The method of searching for an HD Radio station is the same as for an analogue FM station search. As soon
j
as you select a station with a HD Radio programme, playback automatically switches to the digital programme.
Automatic station search
A brief press on the SRC button on the MP 200‘s front panel or a long press on the button on the
remote control opens the station list menu. The following menu items are available:
• If you wish to create a new station list, select the item “Create new list” and conrm your choice
with
• The station search begins, and automatically searches for all radio stations which the machine is
able to pick up.
• If you wish to update an existing list, select the item “Add new stations”.
• The menu item “Sort stations by …” allows you to sort the stored list by any of several criteria.
.
Mono / Stereo selection
By a long press on the button of the remote control, the FM tuner of the MP 200 can be switched between stereo and mono reception. The reception mode is shown in the display:
Switching Radio text on and off
The Radio text function can be switched on and off by briey pressing the button on the remote
control handset.
41
Page 42
DAB Radio
Press the RADIO button on the front panel of the MP 200 or the button on the FM 200
remote control repeatedly if necessary until the source DAB Radio is shown in the display.
Display
1
Displays the selected radio source.
Here the music type or style is displayed, e.g. Pop Music.
2
This information is only displayed if the transmitting station broadcasts it as part
of the RDS system. If you are listening to a station which does not support the RDS
system, or only supports it in part, these information elds remain empty.
Display of the station name
3
Display of Stereo / Mono
4
These lines display information which is broadcast by the station (e.g. Radiotext).
5
The eld strength and therefore the reception quality to be expected from the set transmitting
6
station can be assessed from the eld strength.
Bit-rate of the broadcasting station when listening to DAB radio.
7
* The higher the bit-rate, the better the station’s sound quality.
Automatic station search
A brief press on the SRC button on the MP 200‘s front panel or a long press on the button on the remote control opens the station list menu. The following menu items are available:
42
• If you wish to create a new station list, select the item “Create new list” and conrm your choice
with
• The station search begins, and automatically searches for all radio stations which the machine is
able to pick up.
• If you wish to update an existing list, select the item “Add new stations”.
• The menu item “Sort stations by …” allows you to sort the stored list by any of several criteria.
.
Page 43
Internet Radio
Press the RADIO button on the front panel of the MP 200 or the button on the FM 200 re-
mote control repeatedly if necessary until the source Internet Radio is shown in the display.
Display
Search function
• Select the entry Search in the selection list with the buttons and conrm with the button.
• A pop-up window with the message Search appears in the display. While the pop-up window is display-
ed, enter a letter using the buttons on the remote control. Press the button repeatedly until the
desired letter appears in the display.
• To enter the next letter, press the button.
• To delete a letter, press the button.
• Press the
• After a short delay, a list with the search results appears.
Favorites
In addition to the Favorites list provided by the device (see also chapter Favorites lists on page 38), the
Internet radio source also has a Favorites folder in the root folder of the Internet radio source. This favorites folder is provided by the Internet radio provider and is independent of the favorites list in the device.
To save a favorite in this folder, tap the
the favorite from the folder, tap the
button to start the search.
icon in the T+A Music Navigator app during playback. To delete
icon.
43
Page 44
UPnP, Music services and USB
General information
The MP 200 includes a streaming client (SCL).
This enables music playback from network servers (NAS), a directly connected USB storage device or
music streaming services e.g. Tidal and Qobuz.
To make use of music services you may need to take out a paid subscription with the appropriate provider.
j
Use of music services requires the input of access data (username and password. These access data can be
stored separately for each provider in the Music services menu item within the settings menu (Page 29).
The memory medium can be formatted with any of the following le systems:
FAT16, FAT32, NTFS, ext2, ext3 or ext4.
The exact form of the list format and the preparation of the content depends mainly on the capabilities of the
server / music streaming service.
Source selection
Press the SCL button on the front panel of the MP 200 or the button on the FM 200 re-
mote control repeatedly if necessary until the desired source is shown in the display.
Display
Playback of directories
In addition to the facility to play back individual folder content, it is
also possible to play back entire directories. This is accomplished
by selecting the folder of the directory to be played, then pressing
the
rst entry in the list of content to be played. If an entry in the list
should contain a folder with additional sub-folders, the content
of the lowest folder is always played rst. This is followed by the
content of the next higher folder level, etc. (see diagram right).
button to start playback. Playback commences with the
44
Only possible with UPnP and USB.
j
Page 45
CD player operation
Source selection
Press the DISC button on the front panel of the MP 200 or the button on the FM 200
remote control repeatedly if necessary until the source DISC is shown in the display.
Insert and eject a disc
• Select Disc as source.
• Insert the disc into the drive with the label
side facing up until the disc is automatically
pulled in (see illustration).
• Briey press the
• As soon as the disc has been ejected, it can
be removed.
The disc mechanism is designed to play round 12 cm standard discs only. Do not insert 8 cm discs or discs
j
with unusual shapes. These may damage the drive.
Playback mode
The CD player in the MP 200 features various playback modes. During playback the current playback mode
is shown on the screen.
Big display view
The playback mode can be set with the remote control only. Long presses on the button on the FM 200
select the playback mode. Press repeatedly if neccessary.
button to eject the CD.
Detailed display view
The following modes are available:
No indicator Normal playback of the whole disc, or normal program playback.
The tracks of the CD or a playback program are continuously repeated
The track of the CD or a playback program which has just been played is continuously
repeated.
45
Page 46
Playback Program
Creating a Playback Program
A playback program consists of up to thirty tracks of a CD stored in any order you like. This can be useful,
for example, when you are preparing a cassette recording. A playback program can only be created for
the CD currently in the disc drawer of the MP 200. The program remains stored until it is erased again, or
until the CD drawer is opened.
After loading the CD, the display shows the total
number of tracks on the inserted CD, e.g.: ‚15 tracks
65:42‘.
Programming is only possible when the disc is stopped and only by remote control.
Activate playback programming by a brief
press on the
The display shows ‚Add track 1‘ and ‚0 tracks / 0:00
programme duration‘.
button.
Adds title to the
programme
Use the
Press the
The display shows the number of titles and the total playing time of the programme. Select all other titles
in the same way and conrm by pressing the
When all the titles have been selected for the playback programme, press and hold the
the programme.
Erasing a playback program
If you press the
The programme can also be deleted by a long press on the
buttons to select the desired title.
button to add the selected title to the playback programme.
button on the MP 200, the CD is ejected and the playback programme is deleted.
Selects a title
Selects a title
button.
button to save
button.
46
Page 47
Bluetooth
General information
The MP 200 integral Bluetooth interface provides a
means of transferring music wirelessly from devices
such as smart-phones, tablet PCs, etc. to the MP 200.
Source selection
Press the BT button on the front panel of the MP 200 or the button on the FM 200 remo-
te control repeatedly if necessary until the source BLUETOOTH is shown in the display.
Setting up audio transfer
Before music from a Bluetooth-capable device can be
played through the MP 200, the external device must
rst be registered to the MP 200. As long as the MP 200
is switched on and no device is connected, it is always
ready to receive. In this state the screen displays the
message not connected.
To establish a connection, carry out the following steps:
• Start the search for Bluetooth devices on your mobile device.
• If the MP 200 is found, select it for pairing.
Socket for the
Bluetooth antenna
If the connection is successfully established, the device name of the connected device is shown at the
bottom right of the display.
Playback
Information on the piece of music currently being played is displayed on the screen of the MP 200 if this
function is supported by the device connected to the unit.
The behaviour and method of operating the connected mobile device are determined by the device itself.
Usually, playback can be controlled via the buttons on the remote control (start/stop, pause, skip).
To control the MP 200 the mobile device must be conform to the Bluetooth AVRCP protocol.
j
Qualcomm is a trademark of Qualcomm Incorporated, registered in the United States and other countries,
used with permission. aptX is a trademark of Qualcomm Technologies International, Ltd., registered in the
United States and other countries, used with permission
47
Page 48
Playback with Roon
General information
The MP 200 supports playback via Roon.
Roon is a fee required software solution that manages and organizes your music stored on a server. Furthermore the streaming service TIDAL and Qobuz can be integrated.
Playback
The operation is exclusively done via the Roon-App. The MP 200 is recognized as a playback device (client)
and can be selected for playback in the app. As soon as Roon is used for playback, ROON appears on the
MP 200 display as source.
Further information about Roon and its operation can be found at:
https://roonlabs.com
T+A Music Navigator App
Download
wo Apps are available for controlling the sound system using the Apple iOS and Android operating
systems. Please download the appropriate version from the Appstore and install it on your tablet PC or
smartphone.
You will nd the App under the name “TA MUSIC NAVIGATOR” in the Appstore.
Alternatively you can scan the QR code printed below.
Android Version Apple iOS Version
48
Page 49
Troubleshooting
Many problems have a simple cause and a correspondingly simple solution. The following section describes a few
difculties you may encounter, and the measures you need to take to cure them. If you nd it impossible to solve
a problem with the help of these notes please disconnect the unit from the mains and ask your authorised T+A
specialist dealer for advice.
Machine does not switch on
Cause:
Mains leads not plugged in correctly.
Remedy:
Check connection, push connector in rmly.
Device responds correctly to operation via the buttons directly on the device, but
cannot be operated by remote control
Cause:
The battery of the FM200 remote control is completely discharged.
Remedy:
Insert a new battery as described in the Remote control chapter.
The RDS station name and/or the Radio Text does not appear in the display.
Cause 1:
Reception is poor, interference is severe, or the eld strength (signal strength) is low.
Remedy:
Select only those stations which can be received with a strong signal: hiss-free and without interference.
Cause 2:
The display view is in the large format setting.
Remedy:
Switch to the detailed display view using the i key on the device. If necessary, tap several times to switch
on the radio text.
One or more sources cannot be selected via the source selection buttons on the
device and the remote control
Cause :
The source in question has been disabled.
Remedy:
Enter the system settings menu and enable the disabled source.
49
Page 50
Transmission interruptions occur when listening to internet radio stations.
Cause:
The capacity of the internet radio station‘s server is at its limit.
Remedy:
Choose a different station.
The streaming client cannot connect to a network.
Cause 1 (cable LAN):
Network cable not properly connected
Remedy:
Connect network cable, check connection to router
Cause 2 (wireless LAN):
WLAN antenna not connected or placed in a location with bad reception quality
Remedy:
Connect WLAN antenna properly and nd a location with good reception quality.
Set the transmission power output of your WLAN router to maximum.
Try to establish a network connection rst in a location close to the WLAN router. If this succeeded try
to connect to WLAN from a more remote location. Experiment with antenna position and try to nd a
location with better reception quality.
Cause 3 (wireless LAN):
WLAN reception quality bad (low eld strength). Possibly too much attenuated by walls/ceilings on the
transmission path.
Remedy:
Optimize location of receiver and transmitter antennas.
Alternative:
If transmission problems persist a so called ‚Power Line‘ network might be good alternative to establish
a good and stable network connection.
The best, safest and most secure network however will always be a cable LAN network.
Cause 4:
Network parameters not properly congured.
Remedy:
Congure the network parameters correctly (see chapter ‚Network conguration‘).
Cause 5 (operation without network connection):
For proper operation the MP 200 needs at least one properly connected network device. This can be a
LAN or WLAN network or a USB storage device.
Remedy:
If the MP 200 shall be operated without network (LAN / WLAN) please connect at least a USB stick.
USB Storage device is not recognised
Cause 1:
The storage device (especially USB hard discs without separate power supply) draws more electrical current from the USB interface than is permitted by the USB standard.
Remedy:
Only use USB storage devices that conform to the USB standard or use storage devices with own power
supplies.
Cause 2:
The storage device is not formatted with an appropriate le system.
Remedy:
The MP 200 accepts storage devices with FAT16 or FAT32, NTFS, Ext2, Ext3, Ext4 le systems.
50
Page 51
Notes on energy saving
General information
The MP 200 satises the requirements of the latest directives concerning energy-saving measures (EuP
directive). The modern design of the mains power supply makes an important contribution to this.
The internal micro-processor constantly ensures that sub-assemblies which are not currently required
are automatically switched off. The micro-processor itself operates in stand-by mode at a relatively low
clock speed, and only responds to the remote control receiver.
In stand-by mode the current drain of the MP 200 is less than 0.5 Watt.
If you intend not to use the device for a long period, it should be disconnected from the mains socket, i.e.
the mains plug should be withdrawn from the wall socket.
Automatic power down function
The device features an automatic power-down function. If the MP 200 detects no operation or no music
signal for a period longer than 90 minutes, it automatically switches to stand-by mode
In countries outside the EU, in which the EuP directive has no validity, the automatic power-down feature can
j
be disabled if necessary. See chapter „System settings“.
Legal Information
Allgemeine Informationen
This product contains software in form of object code that is partially based on free software under different licenses. Details of the licenses used can be viewed on the device website using an Internet browser.
Show licenses
To access the devices web page, enter the IP address of the device and „/licensens/“ in the address bar of
the browser you are using.
For example http://192.168.178.100/licenses/
You can view the exact address as follows:
• Call up the system conguration menu by pressing the SYS button on the MP 200.
• Then navigate to the Device Info menu item.
• Open it by pressing the SELECT knob and then navigate to the Legal Information menu item and open it
by pressing the SELECT knob again.
• The address of your device is displayed in the pop-up window that now opens.
The address is only displayed in the pop-up window if the device has a correctly congured network connec-
j
tion. For details on network conguration, see the „Network Conguration“ section.
To view the devices website, the device on which the internet browser is launched must be connected to the
same network as the device.
51
Page 52
52
Page 53
Firmware update
General information
For updating the rmware of the MP 200 there is a convenient method which requires an existing Internet
connection
If you are operating the MP 200 in conjunction with a DAC 200 or HA 200, the machine can also be updated
via the SYS-Link connection.
The wiring diagram for the machine is shown in the chapter Connection and wiring.
The following section describes the exact method of updating the rmware in detail.
To avoid malfunctions after updating the MP 200, all devices in the system should always be checked for any
j
available updates and installed if they are available.
Update procedure
• The basic requirement is a functioning network with router and access to a broadband Internet connection; the system must be operating.
• Switch the machine on.
• Call up the System menu by pressing the SYS-button on the front panel.
• Rotate the SELECT knob on the front panel to select the Device info menu point, and conrm your selec-
tion by pressing the SELECT knob.
• If the MP 200 is connected to a DAC 200 or a HA 200 via the SYS-Link connection, the device selection
menu appears at this point. In this case select the device to be updated by turning the SELECT knob,
then press the SELECT knob to conrm your choice.
• (If the MP 200 is not connected to a DAC 200 or a HA 200, the Software Update menu of the MP 200 appears directly.)
• Select the Update menu point by rotating the SELECT knob, then press the SELECT knob to conrm your
choice.
• The select option WEB should now be active (highlighted).
• The rmware update can now be started by pressing the SELECT knob.
• The screen displays the current state of progress of the update.
• Once the update has been completed (duration 10 - 40 minutes) the device automatically switches itself
off and restarts.
• When the machine has restarted, the update is complete.
• To ensure that the update was successful, access the Device Info menu point mentioned above, and
check the new rmware status.
Instead of starting the update process directly on the device, it is also possible to operate the update process
j
via the FM200 remote control.
53
Page 54
Connection and wiring
MP 200 in combination with DAC 200 or HA 200
54
Page 55
MP 200 in combination with another DAC or amplier with digital input
55
Page 56
Technical Specications
CD-Player
Formats CD/DA, CD-R, CD-RW, CD-text
Frequency response and dynamic range 2 Hz – 20 kHz / 100 dB
Streaming Client
Formats MP3, AAC, OGG-Vorbis, FLAC, WAV, AIFF, ALAC
PCM 32 … 192 kHz, 16/24 Bit; MP3 bis 320 kBit
Supported media servers UPnP 1.1, UPnP AV and DLNA kompatible Server, Microsoft
Features Auto Network Cong., Internet Radio Station database
Interfaces LAN: Fast Ethernet 10/100 Base-T,
Tuner (FM)
Frequency range FM Radio 87,5 – 108 MHz (Europa / US); 76 – 90 MHz (Japanese
Sensitivity Mono (26dB S/N) 0,9 µV, Stereo (46 dB S/N) 40 µV
Overload margin 103 dB µV,
Stereo channel separation 50dB
RDS Functions Stationname, Radio text
Tuner (DAB)
Windows Media Connect Server (WMDRM10, DLNA compatible
servers
(automatic updates)
WLAN: 2,4 GHz, +20 dBm (100 mW), IEEE 802.11 b/g/n
2x USB 2.0 Mastermode
version))
Reception standard DAB, DAB+
Freqency band 168 – 240 MHz (Band III)
Overload margin 103 dB µV,
Sensitivity (BER = 10 – 4) 2,5 µV
Bluetooth
Supported audio formats APT-X, MP3, AAC, SBC
Freqency band 2,4 GHz: 2042Mhz ... 2480Mhz
Max. transmission power <10 dBm (EIRP)
RC protocol AVRCP
56
Page 57
Inputs
SP/DIF (16-24bit): 2x coax (192kHz), 1x TOS-Link (96kHz)
Outputs
Digital output coax (IEC 60958), SYS-LINK USB output
Mains in 115 – 240 V, 50 – 60 Hz, 25 Watts
Normal operation (max.) 25 W
Standby (ECO) < 0,5 W
Automatic power down After 90 Minutues without music signal
Dimensions (WxHxD) 10 × 32 × 34 cm
Accessories Remote control handset FM200, Mains cord, USB-SYS-ca-
Weight 4,4 kg
ble and RJ-45 SYS-Link-cable for connection of a DAC 200
or HA 200, WLAN and Bluetooth antenna, FM antenna
We reserve the right to alter specications.
57
Page 58
58
Page 59
T+A elektroakustik GmbH & Co. KG
Planckstraße 9 – 11
32052 Herford | Germany
T +49 5221 76760
F +49 5221 767676
info@ta-hi.com
www.ta-hi.com
Page 60
T+A elektroakustik GmbH & Co. KG
Planckstraße 9 – 11
32052 Herford | Germany
T +49 5221 76760
F +49 5221 767676
info@ta-hi.com
www.ta-hi.com
9103 - 0588Software V 1.0
Loading...
