Sylvania 6519DB User Manual

OWNER’S

If you need additional assistance for set-up or operating after reading owner’s manual, please call

TOLL FREE : 1-800-968-3429

Please read before using this equipment.

MANUAL

19-INCH COLOR TV/DVD

6519DB

INSTRUCCIONES EN ESPAÑOL INCLUIDAS.

SUPPLIED ACCESSORIES

ACCESSORIES Remote Control Unit Batteries

PART NO. N0287UD 2 AA Batteries

WARNING:TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE

TO RAIN OR MOISTURE.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The caution marking is located on the rear of the cabinet.

IMPORTANT SAFEGUARDS

1.Read instructions-All the safety and operating instructions

should be read before the appliance is operated.

2.Retain Instructions-The safety and operating instructions

should be retained for future reference.

3.Heed Warnings-All warnings on the appliance and in the

operating instructions should be adhered to.

4.Follow Instructions-All operating and use instructions

should be followed.

5.Cleaning-Unplug TV/DVD from the wall outlet before

cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning. EXCEPTION: A product that is meant for uninterrupted service and, that for some specific reason, such as the possibility of the loss of an authorization code for a CATV converter, is not intended to be unplugged by the user for cleaning or any other purpose, may exclude the reference to unplugging the appliance in the cleaning description otherwise required in item 5.

6.Attachments-Do not use attachments not recommended by

the TV/DVD manufacturer as they may cause hazards.

7.Water and Moisture-Do not use this TV/DVD near water-

for example, near a bath tub, wash bowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool, and the like.

8.Accessories-Do not place this TV/DVD on an unstable cart,

stand, tripod, bracket, or table. The TV/DVD may fall, causing serious injury to someone, and serious damage to the appliance. Use only with a cart, stand, tripod, bracket, or table recommended by the manufacturer, or sold with the TV/DVD. Any mounting of the appliance should follow the manufacturer’s instructions and should use a mounting accessory recommended by the manufacturer. An appliance and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the appliance and cart combination to overturn.

PORTABLE CART WARNING

AVERTISSEMENT POUR UNE

TABLE ROULANTE PORTATIVE

S3126A

THIS SYMBOL INDICATES THAT DANGEROUS VOLTAGE CONSTITUTING A RISK OF ELECTRIC SHOCK IS PRESENT WITHIN THIS UNIT.

THIS SYMBOL INDICATES THAT THERE ARE IMPORTANT OPERATING AND MAINTENANCE INSTRUCTIONS IN THE LITERATURE ACCOMP ANYING THE APPLIANCE.

Accessoires- Ne placez pas cette TV/DVD sur une table roulante, un support, un trépied, une console ou une table instable. Cette TV/DVD risquerait de tomber, pouvant gravement blesser quelqu'un et l'appareil même pourrait être sérieusement endommagé. N'utilisez qu'une table roulante, un support, un trépied, une console ou une table recommandé par le fabriquant, ou vendu avec la TV/DVD. Pour n'importe quelle installation de l'appareil, on devra suivre les instructions du fabriquant et l'on devra utiliser les accessoires d'installation recommandés par le fabriquant. L'ensemble combiné de l'appareil avec une table roulante devra être déplacé avec précaution. Des arrêts brusques, une force excessive et des surfaces inégales peuvent provoquer le renversement de l'ensemble combiné de l'appareil/table roulante.

9.Ventilation-Slots and openings in the cabinet and the back

or bottom are provided for ventilation and to ensure reliable operation of the TV/DVD and to protect it from overheating, and these openings must not be blocked or covered. The openings should never be blocked by placing the TV/DVD on a bed, sofa, rug, or other similar surface. This TV/DVD should never be placed near or over a radiator or heat register. This TV/DVD should not be placed in a builtin installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instructions have been adhered to.

10.Power Sources-This TV/DVD should be operated only

from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your appliance dealer or local power company. For TV/DVDs intended to operate from battery power, or other sources, refer to the operating instructions.

11.Grounding orPolarization-This TV/DVD is equipped

with a polarized alternating-current line plug(a plug having one blade wider than the other). This plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.

–2–

0C28

EXAMPLE OF ANTENNA GROUNDING AS PER

NATIONAL ELE CTRICAL CODE

S2898A

FIGURE A

ELECTRIC SERVICE EQUIPMENT

NEC - NATIO NAL EL ECTR ICAL CODE

GROUND

CLAMP

ANTENNA

LEAD IN WIRE

ANTENNA

DISCHARGE UNI T (NEC SECTIO N 810 -20)

GROUNDING CONDUCTORS (NEC SECTIO N 810 -21)

GROUND CL AMPS

POWER SERVICE GRO UNDING ELECTRODE SYSTEM (NEC ART 250, PART H)

12.Power-Cord Protection-Power-supply cords should be

routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the appliance.

13.Outdoor Antenna grounding-If an outside antenna or

cable system is connected to the TV/DVD, be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and built-up static charges. Article 810 of the National Electrical Code, ANSI/NFPA No. 70, provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding electrode. (Fig. A)

14.Lightning-For added protection for this TV/DVD receiver

during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the TV/DVD due to lightning and power-line surges.

15.Power Lines-An outside antenna system should not be

located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.

16.Overloading-Do not overload wall outlets and extension

cords as this can result in a risk of fire or electric shock.

17.Object and Liquid Entry-Never push objects of any kind

into this TV/DVD through openings as they may touch dangerous voltage points or short out parts that could result in a fire or electric shock. Never spill liquid of any kind on the TV/DVD.

18.Servicing-Do not attempt to service this TV/DVD yourself

as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

19.Damage Requiring Service-Unplug this TV/DVD from

the wall outlet and refer servicing to qualified service per-

sonnel under the following conditions: a. When the power-supply cord or plug is damaged or frayed. b. If liquid has been spilled, or objects have fallen into the

TV/DVD. c. If the TV/DVD has been exposed to rain or water. d. If the TV/DVD does not operate normally by following the

operating instructions. Adjust only those controls that are

covered by the operating instructions, as improper adjust-

ment of other controls may result in damage and will often

require extensive work by a qualified technician to restore

the TV/DVD to its normal operation. e. If the TV/DVD has been dropped or damaged in any way. f. When the TV/DVD exhibits a distinct change in perfor-

mance-this indicates a need for service.

20.Replacement Parts-When replacement parts are required,

be sure the service technician has used replacement parts

specified by the manufacturer that have the same character-

istics as the original part. Unauthorized substitutions may

result in fire, electric shock, injury to persons or other haz-

ards.

21.Safety Check-Upon completion of any service or repairs to

this TV/DVD, ask the service technician to perform routine

safety checks to determine that the TV/DVD is in proper

operating condition.

22.Heat-This TV/DVD product should be situated away from

heat sources such as radiators, heat registers, stoves, or

other products (including amplifiers) that produce heat.

–3–

0C28

PRECAUTIONS

IMPORTANT COPYRIGHT INFORMATION

Unauthorized copying, broadcasting, public performance and lending of discs are prohibited.

FCC WARNING- This equipment may generate or use radio frequency energy. Changes or modifications to this equipment may cause harmful interference unless the modifications are expressly approved in the instruction manual. The user could lose the authority to operate this equipment if an unauthorized change or modification is made.

RADIO-TV INTERFERENCE

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

1) Reorient or relocate the receiving antenna.

2) Increase the separation between the equipment and receiver.

3) Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

4) Consult the dealer or an experienced radio/TV technician for help.

LASER SAFETY

This unit employs a laser. Only a qualified service person should remove the cover or attempt to service this device, due to possible eye injury.

CAUTION: USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

CAUTION: VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN AND INTERLOCK DEFEATED. DO NOT STARE INTO BEAM.

LOCATION: INSIDE, NEAR THE DECK MECHANISM.

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

CAUTION: TO PREVENT ELECTRIC SHOCK,

MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

ATTENTION: POUR ÉVITER LES CHOC ÉLECTRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU’AU FOND.

–4–

0C28

LOCATION

WARNING

For safe operation and satisfactory performance of your TV/DVD, keep the following in mind when selecting a place for its installation:

Shield it from direct sunlight and keep it away from

•

sources of intense heat. Avoid dusty or humid places.

•

Avoid places with insufficient ventilation for proper

•

heat dissipation. Do not block the ventilation holes at the top and bottom of the unit. Do not place the unit on a carpet because this will block the ventilation holes.

Install unit in a horizontal position.

•

Avoid locations subject to strong vibration.

•

Do not place the TV/DVD near strong magnetic fields.

•

Avoid moving TV/DVD to locations where temper-

•

ature differences are extreme.

AVOID THE HAZARDS OF

ELECTRICAL SHOCK AND FIRE

Do not handle the power cord with wet hands.

•

Do not pull on the power cord when disconnecting

•

it from an AC wall outlet. Grasp it by the plug. If, by accident, water is spilled on your unit, unplug

•

the power cord immediately and take the unit to our Authorized Service Center for servicing.

Do not put your fingers or objects into the

•

TV/DVD disc loading tray. Do not place anything directly on top of the unit.

•

Moisture condensation may occur inside the unit when it is moved from a cold place to a warm place, or after heating a cold room or under conditions of high humidity. If a DVD is played in a TV/DVD which has moisture, it may damage the DVD and TV/DVD. Therefore when the condensation occurs inside the unit, turn the POWER button on and allow at least 2 hours for the unit to dry out.

A NOTE ABOUT RECYCLING

This product’s packaging materials are recyclable and can be reused. Please dispose of any materials in accordance with your local recycling regulations.

Batteries should never be thrown away or incinerated but disposed of in accordance with your local regulations concerning chemical wastes.

The serial number of this product may be found on the back of the unit. No other TV/DVD has the same serial number as yours. You should record the number and other vital information here and retain this book as a permanent record of your purchase to aid identification in case of theft. Serial numbers are not kept on file.

Date of Purchase Dealer Purchase from Dealer Address Dealer Phone No. Model No. Serial No.

–5–

0C28

TABLE OF CONTENTS

C IMPORTANT SAFEGUARDS . . . . . . . . . . . . .2

C PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . .4

LOCATION . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

AVOID THE HAZARDS OF ELECTRICAL

SHOCK AND FIRE . . . . . . . . . . . . . . . . . . . . . .5

WARNING . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

C FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

C SUPPLIED ACCESSORIES . . . . . . . . . . . . . . .7

C OPERATING CONTROLS AND FUNCTIONS 8

C PREPARATION FOR USE . . . . . . . . . . . . . . .10

ANTENNA/CABLE CONNECTIONS . . . . . . .10

INSTALLING THE BATTERIES . . . . . . . . . . .12

CONNECTING TO EXTERNAL INPUT JACKS .12 CONNECTING TO A STEREO SYSTEM (for DVD) CONNECTING TO AN AMPLIFIER

EQUIPPED WITH DIGITALINPUT JACKS,

MD DECK OR DAT DECK (for DVD) . . . . . .13

CONNECTING TO ADOLBY DIGITAL DECODER OR DTS DECODER (for DVD) . .14

TV SECTION

C SET UP FOR USE . . . . . . . . . . . . . . . . . . . . .15

LANGUAGE SELECTION . . . . . . . . . . . . . . .15

CHANNEL PRESETTING . . . . . . . . . . . . . . .15

C OPERATIONS . . . . . . . . . . . . . . . . . . . . . . . . .16

WATCHING A TV PROGRAM . . . . . . . . . . . .16

SELECTING THE SLEEP TIMER . . . . . . . . .16

CLOSED CAPTION . . . . . . . . . . . . . . . . . . . .16

PICTURE ADJUSTMENT . . . . . . . . . . . . . . . .17

V-CHIP SET UP . . . . . . . . . . . . . . . . . . . . . . . .18

VD SECTION

C ABOUT THE DISCS . . . . . . . . . . . . . . . . . . . .20

PLAYABLE DISCS . . . . . . . . . . . . . . . . . . . . .20

DISC TYPES . . . . . . . . . . . . . . . . . . . . . . . . . .20

SYMBOLS USED IN THIS MANUAL . . . . . .20

C PLAYING A DISC . . . . . . . . . . . . . . . . . . . . . .21

PLA YING ADVD VIDEO OR AN AUDIO CD

USING THE DVD MENUS . . . . . . . . . . . . . . .21

USING THE TITLE MENU . . . . . . . . . . . . . . .22

.13

.21

PAUSING PLAYBACK OR DISPLAYING

A STILL PICTURE . . . . . . . . . . . . . . . . . . . . .22

RESUMING PLAYBACK FROM THE

POINT WHERE PLAYBACK STOPPED . . . .22

STEPPING THROUGH FRAMES . . . . . . . . . .22

FAST FORWARD/REVERSE . . . . . . . . . . . . .23

SLOW MOTION . . . . . . . . . . . . . . . . . . . . . . .23

STARTING FROM A DESIRED TRACK . . . .23

STARTING FROM A DESIRED TIME COUNT PLAYING FROM ADESIRED TITLE OR

CHAPTER . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

RANDOM (Audio CD) . . . . . . . . . . . . . . . . . .24

REPEAT . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

A-B REPEAT . . . . . . . . . . . . . . . . . . . . . . . . . .25

PROGRAM (Audio CD) . . . . . . . . . . . . . . . . .25

C SETTINGS . . . . . . . . . . . . . . . . . . . . . . . . . . .26

CHANGING THE AUDIO LANGUAGE OR

SOUND MODE . . . . . . . . . . . . . . . . . . . . . . . .26

CHANGING THE SUBTITLE LANGUAGE . .27 CHANGING THE CAMERA ANGLE

(Multi-Angle Pictures) . . . . . . . . . . . . . . . . . . .27

CHANGING THE ON-SCREEN DISPLAY . . .28

C CHANGING THE SETUP ITEMS . . . . . . . . .29

LANGUAGE SETTINGS . . . . . . . . . . . . . . . .29

VIDEO SETTINGS . . . . . . . . . . . . . . . . . . . . .30

AUDIO SETTINGS . . . . . . . . . . . . . . . . . . . . .30

PARENTAL LOCK . . . . . . . . . . . . . . . . . . . . .31

OTHER SETTINGS . . . . . . . . . . . . . . . . . . . . .32

C LANGUAGE CODE LIST . . . . . . . . . . . . . . . .33

C TROUBLESHOOTING GUIDE . . . . . . . . . . .34

C MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . .37

DISC HANDLING . . . . . . . . . . . . . . . . . . . . . .37

C SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . .38

C WARRANTY . . . . . . . . . . . . . . . . . . .Back Cover

.23

–6–

0C28

This unit employs TruSurround system of SRS Labs, Inc. as virtual

technology. TruSurround and the symbol are trademarks of

SRS Labs, Inc. TruSurround technology is incorporated under license

from SRS Labs, Inc.

¡Tinted, Bright Black Matrix Picture Tube ¡181 Channel Selection

All VHF/UHF channels plus up to 125 cable channels.

¡PLL Frequency Synthesized Tuning

The latest PLL frequency synthesized electronic tuning system provides free and easy channel selection, and lets you tune directly to any channel using the channel number buttons (0~9 and +100-key) on the remote control.

¡On-Screen Function Display. ¡Full-Function Remote Control ¡Sleep Timer ¡Closed Caption Decoder

You may view specially labeled (cc) TV programs, movies, news, prerecorded tapes, etc. with either a dialogue caption or text display added to the program.

¡Auto Shut Off Function

If there is no air signal input from the antenna terminal and no operation for 15 minutes, the TV will turn itself off automatically.

¡V-CHIP

Enables parents to prevent their children from watching inappropriate material on TV.

DVD

¡Dolby Digital sound

This player can handle Dolby Digital surround sound having 5.1 channels when connected to a Dolby Digital decoder.

¡Still/fast/slow/step playback

Various playback modes are available including still pictures, fast forward/reverse, slow motion and step frames.

¡Random playback for audio CD

This player can shuffle the order of tracks to play them in random order.

¡Program playback for audio CD

You can program the order of tracks to play them in any desired order.

¡DVD menus in a desired language

You can display DVD menus in a desired language, if available on a DVD.

¡Screen saver/Auto power-off functions

The screen saver program starts when there is no input from the player for five minutes in the stop mode. When the screen saver program is activated for 30 minutes, the power is automatically turned off.

¡Subtitles in a desired language

You can select a desired language for the display subtitles, if that language is available on a disc.

¡Selecting a camera angle

You can select the desired camera angle, if a disc contains sequences recorded from different angles.

¡Choices for audio language and sound mode

You can select the desired audio language and sound mode, if different languages and modes are available on a disc.

FEATURES

¡Parental lock

You can set the control level to limit playback of discs which may not be suitable for children.

¡Automatic detection of discs

This player automatically detects if a loaded disc is DVD or audio CD.

¡On-screen display

Information about the current operation can be displayed on a TV screen, allowing you to confirm the currently active functions (such as program playback), on the TV screen using the remote control.

¡DTS (Digital Theater System)

Sound system different from Dolby Digital sound system

¡Search

Chapter search: Search for the chapter designated by user Title search: Search for the title designated by user is Track search: Search for the track designated by user is Time search: Search for the time designated by user is

¡Repeat

Chapter: Repeated playback of the chapter of the Title: Repeated playback of the title of the disc Track: Repeated playback of the track of the disc

(audio CD)

Disc

A-B: The part between A and B designated by

¡Zoom

4-time magnified screen can be displayed.

¡Marker

The part designated by user can be called back.

¡Resume Play

User can resume to playback from the part at which the play was stopped.

¡SRS T ruSurround

You can enjoy stereophonic virtual space on your existing stereo system.

¡Dimmer

Brightness of the display can be varied.

¡Bit rate indication ¡Dynamic range control

–7–

is possible. possible. possible. possible.

disc being played is possible. being played is possible. being played is possible.

: Repeated playback of the entire disc being

played is possible.

user is possible.

0C28

L-AUDIO-RVIDEO

STOP

PLAY

SKIPSKIP

PAUSE

HEADPHONE

POWER

VOLUME CHANNEL

OPEN/CLOSE

7421 8 181018 1213 14653

REV

PLAY

STOP

FWD

ENTER

PAUSE

DISC

RETURNTITLESETUP

REPEATSEARCH MODE

CLEAR

MODE

ANGLESUBTITLEAUDIO

DISPLAY

SKIP

SELECT

POWER PICTURE

OPEN/ CLOSE

CH.

VOL.

MUTEZOOM

SLEEP

123 456 789

0 +10

+100

17 18

12 23

20 22

15 25

13 34

OPERATING CONTROLS AND FUNCTIONS

TV/DVD FRONT PANEL

[Fig. 2]

REMOTE CONTROL

2.VIDEO input jack

Disc loading tray

Connect to the video output jack of a video camera or VCR.

AUDIO L/R input jacks

Connect to the audio output jacks of a video camera or VCR.

POWER button

Press to turn the power on and off.

[Fig. 1]

VOLUME K/L buttons

Press to control the volume level for the DVD and TV.

6.CHANNEL K/L buttons

Press to select memorized channel. Press to change to TV mode when DVD mode.

Remote Sensor Window

8.STOP button

Stops operation of the disc.

REV button

Fast reverses playback to a desired point.

PLAY button

10.

Starts playback of the disc contents. Press to change to DVD mode when TV mode.

FWD button

11.

Fast forwards playback to a desired point.

PAUSE button

12.

Pauses the current disc operation.

OPEN/CLOSE button

13.

Press to insert discs into or remove them from the tray.

HEADPHONE jack

14.

To connect headphone (not supplied) for personal listening.

MODE button

15.

Activates program playback or random playback mode.

16.NUMBER button

TV Mode:

Press two digits to directly access the desired channel. Remember to press a "0" before a single digit channel.

+100 button–

Press to select cable channels which are equal or greater than number 100.

DVD Mode:

Press to enter the desired number.

+10 button–

Press to enter the desired numbers which are equal or greater than number 10.

–8–

0C28

AUDIO OUT

DIGITAL OUT

COAXIAL

38 403937

ANT.

REAR VIEW

[Fig. 3]

17.

SLEEP button

Press the SLEEP button to display the sleep timer and start the function. The shut off time can be determined by the number of times you press the button. (0, 10, 20, 30,..90, 0 minutes)

SKIP buttons

18.

Skip chapters or tracks to a desired point.

ZOOM Button

19.

Enlarges part of a DVD-reproduced image.

20.SETUP button

Press to enter or exit the TV menu or DVD setup mode.

TITLE button

21.

Displays the title menu.

CLEAR button

22.

Resets a setting.

DISPLAY button

23.

TV Mode:

Press to display the channel number on the screen. If you press it again, the channel number will disappear.

DVD Mode:

Displays the current status on the TV screen for checking purposes.

SEARCH MODE button

24.

Press to locate a desired point.

AUDIO button

25.

Press to select a desired audio language or sound mode.

SUBTITLE button

26.

Press to select a desired subtitle language.

REPEAT button

27.

Repeats playback of the current disc, title, chapter or track.

ANGLE button

28.

Press to change the camera angle to see the sequence being played back from a different angle.

29.A-B REPEAT button

Repeats playback of a selected section.

RETURN button

30.

Returns to the previous operation.

31.ENTER button

Press to accept a setting.

Arrow buttons

32.

TV Mode:

Press to select a setting mode from the menu on the TV screen. Press to select or adjust from a particular menu.

DVD Mode:

Use when making settings while watching the display on a TV screen.

DISC MENU button

33.

Displays the menus in the DVD.

SELECT button

34.

Press to change to TV mode, external input mode or DVD mode.

MUTE button

35.

Press the MUTE button to turn off the sound portion of the TV program. (Volume level display turns LIGHT RED from LIGHT BLUE.) Press the MUTE button again or press the VOL(ume) K or L button to restore sound.

PICTURE button

36.

Press to enter picture adjustment mode.

Power cord

37.

Connect to a standard AC outlet (120V/60Hz).

NOTE: Remove the power cord from the hook to

avoid breaking a wire before you connect to a standard AC outlet.

COAXIAL digital audio out jack

38.

Connect to the digital input of an external amplifier or decoder.

AUDIO L/R output jack

39.

Connect to the analog audio input of an external amplifier or decoder.

NOTE: The AUDIO output jacks (red/white) on

the rear panel serve to give out DVD sound, not TV sound and external input sound.

ANT. in jack

40.

Connect to an antenna, cable system, or satellite system.

–9–

0C28

AUDIO OUT

DIGITAL OUT COAXIAL

ANT.

AUDIO OUT

DIGITAL OUT COAXIAL

ANT.

PREPARATION FOR USE

ANTENNA/CABLE CONNECTIONS

VHF/UHF COMBINED ANTENNA

The VHF/UHF Rod Antenna (not supplied) is detachable. Insert the stem of the antenna into the hole on the upper-back portion of the TV/DVD. Connect the VHF/UHF Rod Antenna or VHF/UHF Combination Antenna to the ANT. terminal of the TV/DVD as shown in the diagram below. For the best reception, fully extend the VHF/UHF Rod Antenna and make the necessary adjustments. (Avoid touching the top section when adjusting.)

NOTE:

Before plugging the Rod antenna into antenna terminal, check that the pin is not bent. If it is bent, straighten the pin as illustrated, then plug the pin into antenna terminal.

Bent pin

Cable Plug

(Needs to be straightened)

(Straight pin)

Rod Antenna (Not supplied)

VHF/UHF Antenna (Not supplied)

NOTE:

The connection of an indoor antenna may not always give acceptable TV reception.

VHF/UHF SEPARATE ANTENNAS

In some areas it will be necessary to use an outdoor antenna.

VHF Antenna (Not supplied)

VHF/UHF Combiner (Not supplied)

Flat twin-lead cable

–10–

[Fig. 4]

UHF Antenna (Not supplied)

[Fig. 5]

0C28

AUDIO OUT

DIGITAL OUT COAXIAL

OUT

ANT.

CABLE WITHOUT CONVERTER/

AUDIO OUT

DIGITAL OUT

COAXIAL

ANT.

DESCRAMBLER BOX

Use this connection if your cable system connects directly to your TV/DVD without a converter box.

From Cable System

75-ohm Coaxial Cable (Not supplied)

[Fig. 6]

CABLE WITH CONVERTER/ DESCRAMBLER BOX OR SATELLITE BOX

If your cable service supplies you with a converter box or if you use a satellite system, you can use the basic connection shown here.

Satellite Box or Cable Box (Not supplied)

From Cable System or Satellite Dish

75-ohm Coaxial Cable (Not supplied)

[Fig. 7]

Note to CATV system installer:

This reminder is provided to call the CATV system installer ’s attention to Article 820-40 of the NEC that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building as close to the point of cable entry as practical.

–11–

0C28

INSTALLING THE BATTERIES

L-AUDIO-RVIDEO

1)Open the battery compartment cover by pressing the cover on the remote unit in the direction of the arrow.

2)Insert 2 "AA" penlight batteries into the battery compartment in the direction indicated by the polarity (+/-) markings.

3)Replace the cover.

CONNECTING TO EXTERNAL INPUT JACKS

When you watch a program recorded on an another source (VCR or video camera), use the audio/video input jacks on the front of the TV/DVD.

Connect the audio/video output jacks of another source to the AUDIO L/R and VIDEO jacks of this TV/DVD. Then press the SELECT button until "VIDEO" appears on the screen.

NOTE:

When you connect a monaural VCR (another source) to this TV/DVD, connect the Audio output jack of the

•

monaural VCR (another source) to the AUDIO L jack of this TV/DVD. The audio will output in both L and R channel equally.

To the audio output jacks

[Another source]

Audio/Video coaxial cable (not supplied)

etc.

To the video output jack

Antenna/Cable Connections Continued on the Next Page.

[Front of the TV/DVD]

[Fig. 8]

–12–

0C28

CONNECTING TO A STEREO SYSTEM (for DVD)

AUDIO OUT

DIGITAL OUT

COAXIAL

ANT.

To Right (red) and Left (white) AUDIO OUT jacks (only DVD AUDIO OUT)

Stereo system

T o ANALOG AUDIO INPUT jacks

AUDIO OUT

DIGITAL OUT

COAXIAL

ANT.

Amplifier equipped with digital

input jacks, MD deck,

DAT deck, etc.

To COAXIAL DIGITAL AUDIO INPUT jack

To DIGITAL AUDIO OUT (PCM/BITSTREAM) COAXIAL jack

(only DVD AUDIO OUT)

NOTES:

Be sure to turn off the power to all components in the system before connecting another component.

•

Refer to the Owner's Manuals for your, stereo system and any other components to be connected to the

•

TV/DVD. The AUDIO output jacks (red/white) on the rear panel serve to give out DVD sound, not TV sound and

•

external input sound.

CONNECTING TO AN AMPLIFIER EQUIPPED WITH DIGITAL

INPUT JACKS, MD DECK OR DAT DECK (for DVD)

[Fig. 9]

Use an audio coaxial digital cable (commercially available) for the audio connections.

NOTES:

The audio source on a disc in a 5.1 channel Dolby Digital surround format cannot be recorded as digital

•

sound by an MD or DAT deck. Be sure to turn off the power to all components in the system before connecting another component.

•

Refer to the Owner's Manuals for the components to be connected to the TV/DVD.

•

Set DOLBY DIGITAL and DTS to OFF for audio output in the setup mode. Playing a TV/DVD using

•

incorrect settings may generate noise distortion, and may also damage the speakers. When DOLBY DIGITAL is set to OFF and VIRTUAL 3D to ON for audio output in the setup mode and

•

you select the audio source in a 5.1 channel Dolby Digital surround format, the audio will be muted.

–13–

[Fig. 10]

0C28

CONNECTING TO A DOLBY DIGITALDECODER

AUDIO OUT

DIGITAL OUT

COAXIAL

ANT.

Front speaker

(left)

Center

speaker

Front speaker

(right)

Surround

speaker

(left)

Surround

speaker

(right)

Subwoofer

To DIGITAL AUDIO OUT (PCM/BITSTREAM) COAXIAL jack

To COAXIAL DIGITAL AUDIO INPUT jack

Dolby Digital

or DTS decoder

OR DTS DECODER (for DVD)

If using this TV/DVD to play back a TV/DVD in a 5.1 channel Dolby Digital surround or DTS surround format, the TV/DVD outputs a Dolby Digital or DTS data stream from its COAXIAL digital audio out jack. By hooking the player up to a Dolby Digital or DTS decoder, you can enjoy a more convincing, realistic ambience with powerful and high-quality surround sound of a professional standard such as can be heard in movie theaters.

Use audio coaxial digital cables (commercially available) for the audio connections.

[Fig. 11]

NOTES:

Be sure to turn off the power to all components in the system before connecting another component.

•

Refer to the Owner's Manuals for the components to be connected to the TV/DVD.

•

If connected to a Dolby Digital decoder, set DOLBY DIGITAL to ON for audio output in the setup mode.

•

If connected to a DTS decoder, set DTS to ON for audio output in the setup mode.

•

Unless connected to a Dolby Digital decoder or a DTS decoder, set DOLBY DIGITAL and DTS to OFF for

•

audio output in the setup mode. Playing a TV/DVD using incorrect settings may generate noise distortion, and may also damage the speakers.

When DOLBY DIGITAL is set to OFF and VIRTUAL 3D to ON for audio output in the setup mode and

•

you select the audio source in a 5.1 channel Dolby Digital surround format, the audio will be muted.

“DTS”and “DTS Digital Out”are trademarks of Digital Theater Systems, Inc.

–14–

0C28

+ 30 hidden pages
