OWNER’S
MANUAL
COLOR TV/DVD
6513DF (13 inch)
INSTRUCCIONES EN ESPAÑOL INCLUIDAS.
If you need additional operating assistance after reading this owner’s manual or to order replacement accessories, please call
TOLL FREE : 1-800-968-3429.
Or visit our WEB SITE at http://www.SylvaniaConsumerElectronics.com
Please read before using this equipment
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The caution marking is located on the rear of the cabinet.
THIS SYMBOL INDICATES THAT DANGEROUS VOLTAGE CONSTITUTING A RISK OF ELECTRIC SHOCK IS PRESENT WITHIN THIS UNIT.
THIS SYMBOL INDICATES THAT THERE ARE IMPORTANT OPERATING AND MAINTENANCE INSTRUCTIONS IN THE LITERATURE ACCOMPANYING THE APPLIANCE.
IMPORTANT SAFEGUARDS
1.Read instructions-All the safety and operating instructions should be read before the appliance is operated.
2.Retain Instructions-The safety and operating instructions should be retained for future reference.
3.Heed Warnings-All warnings on the appliance and in the operating instructions should be adhered to.
4.Follow Instructions-All operating and use instructions should be followed.
5.Cleaning-Unplug the unit from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.
EXCEPTION: A product that is meant for uninterrupted service and, that for some specific reason, such as the possibility of the loss of an authorization code for a CATV converter, is not intended to be unplugged by the user for cleaning or any other purpose, may exclude the reference to unplugging the appliance in the cleaning description otherwise required in item 5.
6.Attachments-Do not use attachments not recommended by the unit manufacturer as they may cause hazards.
7.Water and Moisture-Do not use this unit near water-for example, near a bath tub, wash bowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool, and the like.
8.Accessories-Do not place this unit on an unstable cart, stand, tripod, bracket, or table. The unit may fall, causing serious injury to someone, and serious damage to the appliance. Use only with a cart, stand, tripod, bracket, or table recommended by the manufacturer, or sold with the unit. Any mounting of the appliance
should follow the manufacturer’s instructions and should use a mounting accessory recommended by the
manufacturer. An appliance and cart combination should be moved with
care. Quick stops, excessive force,
and uneven surfaces may cause the appliance and cart combination to
overturn.
AMEUBLES- Cet appareil ne doit être placé que sur un meuble (avec ou sans roulettes) recommandé par le fabricant. Si vous l’installez sur un meuble à roulettes, déplacez les deux ensembles avec précaution.
Un arrêt brusque, l’utilisation d’une force excessive et des surfaces irrégulières risquent de déstabiliser l’ensemble et de le renverser.
SYMBOLE D'AVERTISSEMENT POUR
LES COMPOSANTES
APPAREIL ET MEUBLE A ROULETTES
S3126A
9.Ventilation-Slots and openings in the cabinet and the back or bottom are provided for ventilation and to ensure reliable operation of the unit and to protect it from overheating, and these openings must not be blocked or covered. The openings should never be blocked by placing the unit on a bed, sofa, rug, or other similar surface. This unit should never be placed near or over a radiator or heat register. This unit should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instructions have been adhered to.
10.Power Sources-This unit should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your appliance dealer or local power company. For the units intended to operate from battery power, or other sources, refer to the operating instructions.
11.Grounding or Polarization-This unit is equipped with a polarized alternating-current line plug(a plug having one blade wider than the other). This plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.
12.Power-Cord Protection-Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the appliance.
- 2 - |
EN |
FIGURE A
EXAMPLE OF ANTENNA GROUNDING AS PER
NATIONAL ELECT RICAL CODE
|
|
|
|
|
|
ANTENNA |
|
|
|
|
|
|
L EAD I N |
|
|
|
|
|
|
W I R E |
|
GROUND |
|||||
|
C L A M P |
|||||
|
|
|
|
|
|
ANTENNA |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
DI SCHARG E UN I T |
|
|
|
|
|
|
(NEC SECTION 8 10 -2 0) |
EL ECTRI C |
|
|
|
|
|
|
SE RV I CE |
|
|
|
|
|
|
EQ U I PMEN T |
|
|
|
|
|
|
|
|
|
|
|
|
G RO UNDI NG CO NDUCTORS |
|
|
|
|
|
|
(NEC SECTION 8 10 -2 1) |
|
|
|
|
|
G RO UND CL AMPS |
|
NEC - NATI O NAL EL ECTRI CAL CO DE |
|
|
POWER SERVI C E G RO UNDI NG |
|||
|
|
|
EL EC TR O DE SYSTEM |
|||
S2 8 9 8 A |
|
|
(NEC ART 2 50 , PART H) |
|||
13.Outdoor Antenna grounding-If an outside antenna or cable system is connected to the unit, be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and built-up static charges. Article 810 of the National Electrical Code, ANSI/NFPA No. 70, provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding electrode. (Fig. A)
14.Lightning-For added protection for this unit receiver during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the unit due to lightning and power-line surges.
15.Power Lines-An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.
16.Overloading-Do not overload wall outlets and extension cords as this can result in a risk of fire or electric shock.
17.Object and Liquid Entry-Never push objects of any kind into this unit through openings as they may touch dangerous voltage points or short out parts that could result in a fire or electric shock. Never spill liquid of any kind on the unit.
18.Servicing-Do not attempt to service this unit yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.
19.Damage Requiring Service-Unplug this unit from the wall outlet and refer servicing to qualified service personnel under the following conditions:
a.When the power-supply cord or plug is damaged or frayed.
b.If liquid has been spilled, or objects have fallen into the unit.
c.If the unit has been exposed to rain or water.
d.If the unit does not operate normally by following the operating instructions. Adjust only those controls that are covered by the operating instructions, as improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the unit to its normal operation.
e.If the unit has been dropped or damaged in any way.
f.When the unit exhibits a distinct change in performance, this indicates a need for service.
20.Replacement Parts-When replacement parts are required, be sure the service technician has used replacement parts specified by the manufacturer that have the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock, injury to persons or other hazards.
21.Safety Check-Upon completion of any service or repairs to this unit, ask the service technician to perform routine safety checks to determine that the unit is in proper operating condition.
22.Heat-This unit product should be situated away from heat sources such as radiators, heat registers, stoves, or other products (including amplifiers) that produce heat.
- 3 - |
EN |
PRECAUTIONS
IMPORTANT COPYRIGHT INFORMATION
Unauthorized copying, broadcasting, public performance and lending of discs are prohibited.
This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual property rights. Use of this copyright protection technology must be authorized by Macrovision, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision. Reverse engineering or disassembly is prohibited.
FCC WARNINGThis equipment may generate or use radio frequency energy. Changes or modifications to this equipment may cause harmful interference unless the modifications are expressly approved in the instruction manual. The user could lose the authority to operate this equipment if an unauthorized change or modification is made.
RADIO-TV INTERFERENCE
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
1)Reorient or relocate the receiving antenna.
2)Increase the separation between the equipment and receiver.
3)Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
4)Consult the dealer or an experienced radio/TV technician for help.
LASER SAFETY
This unit employs a laser. Only a qualified service person should remove the cover or attempt to service this device, due to possible eye injury.
CAUTION: USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
CAUTION: VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN AND INTERLOCK DEFEATED. DO NOT STARE INTO BEAM.
LOCATION: INSIDE, NEAR THE DECK MECHANISM.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
ATTENTION: POUR ÉVITER LES CHOCS ÉLECTRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU’AU FOND.
A NOTE ABOUT RECYCLING
Batteries should never be thrown away or incinerated but disposed of in accordance with your local regulations concerning chemical wastes.
The serial number of this product may be found on the back of the unit. No other unit has the same serial number as yours. You should record the number and other vital information here and retain this book as a permanent record of your purchase to aid identification in case of theft. Serial numbers are not kept on file.
Date of Purchase
Dealer Purchase from
Dealer Address
Dealer Phone No.
Model No.
Serial No.
- 4 - |
EN |
LOCATION |
|
WARNING |
|
|
|
For safe operation and satisfactory performance of your unit, keep the following in mind when selecting a place for its installation:
•Shield it from direct sunlight and keep it away from sources of intense heat.
•Avoid dusty or humid places.
•Avoid places with insufficient ventilation for proper heat dissipation. Do not block the ventilation holes at the top or bottom of the unit. Do not place the unit on a carpet because this will block the ventilation holes.
•Install unit in a horizontal position.
•Avoid locations subject to strong vibration.
•Do not place the unit near strong magnetic fields.
•Avoid moving the unit to locations where temperature differences are extreme.
•Be sure to remove disc and unplug the AC power cord from the outlet before carrying the unit.
AVOID THE HAZARDS OF ELECTRICAL SHOCK AND FIRE
•Do not handle the power cord with wet hands.
•Do not pull on the power cord when disconnecting it from an AC wall outlet. Grasp it by the plug.
•If by accident, water is spilled on your unit, unplug the power cord immediately and take the unit to our Authorized Service Center for servicing.
•Do not put your fingers or objects into the unit disc loading tray.
•Do not place anything directly on top of the unit.
Moisture condensation may occur inside the unit when it is moved from a cold place to a warm place or after heating a cold room or under conditions of high humidity. If a DVD is played in a unit which has moisture, it may damage the DVD and the unit. Therefore when the condensation occurs inside the unit, turn the unit on and allow at least 2 hours for the unit to dry out.
SYMBOLS USED IN THIS MANUAL
The following symbols below appear in some headings and notes in this manual, with the following meanings.
TV
:Description refers to TV operation (in the TV mode).
DVD-V
:Description refers to playback of DVD video discs (in the DVD mode).
CD
:Description refers to playback of Audio CDs (in the DVD mode).
QUICK
:Description refers to the items to be set by the QUICK mode (in the DVD mode).
SUPPLIED ACCESSORIES
Remote Control Unit |
Batteries |
Owner’s Manual |
|
|
Owner's Manual |
(NE207UD) |
2 AA Batteries |
(1EMN20238) |
•If you need to replace these accessories, please refer to the PART NO. under the illustrations and call our help line mentioned on the front page.
•Depending on your antenna system, you may need different types of Combiners (Mixer) or Separators (Splitter). Contact your local electronics store for these items.
- 5 - |
EN |
TABLE OF CONTENTS
C IMPORTANT SAFEGUARDS . . . . .2
C PRECAUTIONS . . . . . . . . . . . . . . . .4
LOCATION . . . . . . . . . . . . . . . . . . .5
AVOID THE HAZARDS OF ELECTRICAL SHOCK AND FIRE .5
WARNING . . . . . . . . . . . . . . . . . . . .5
SYMBOLS USED IN THIS MANUAL . . . . . . . . . . . . . . . . . . . . .5
C SUPPLIED ACCESSORIES . . . . . . .5
C TABLE OF CONTENTS . . . . . . . . . .6
C FEATURES . . . . . . . . . . . . . . . . . . . .7
C OPERATING CONTROLS AND
FUNCTIONS . . . . . . . . . . . . . . . . . . .8
C PREPARATION FOR USE . . . . . . .10
ANTENNA/CABLE
CONNECTION . . . . . . . . . . . . . . . .10
CONNECTING TO FRONT A/V INPUT JACKS . . . . . . . . . . . . . . . .11
CONNECTING TO A STEREO AMPLIFIER EQUIPPED WITH DIGITAL INPUT JACKS (for DVD) .11
CONNECTING TO A DOLBY
DIGITAL DECODER (for DVD) . .12
INSTALLING THE BATTERIES . .12
TV SECTION
C TV OPERATION AND SETTINGS .13
WATCHING A TV PROGRAM . . .13 DEGAUSSING . . . . . . . . . . . . . . . .13 PICTURE CONTROL . . . . . . . . . . .13 SLEEP TIMER . . . . . . . . . . . . . . . .14 CLOSED CAPTION SYSTEM . . . .14 CHANNEL SET UP . . . . . . . . . . . .15 V-CHIP SET UP . . . . . . . . . . . . . . .16
TV RATING SET UP . . . . . . . . .16 MPAA RATING SET UP . . . . . .17 CHANGE ACCESS CODE . . . . .17 MENU LANGUAGE . . . . . . . . . . .17
C CABLE CHANNEL
DESIGNATIONS . . . . . . . . . . . . . .18
DVD SECTION
C ABOUT THE DISCS . . . . . . . . . . . .19
PLAYABLE DISCS . . . . . . . . . . . .19 UNPLAYABLE DISCS . . . . . . . . . .19
C PLAYING A DISC . . . . . . . . . . . . . .20
BASIC PLAYBACK . . . . . . . . . . . .20 GENERAL FEATURES . . . . . . . . .20 DISC MENU . . . . . . . . . . . . . . . . .20 TITLE MENU . . . . . . . . . . . . . . . . .20 RESUME . . . . . . . . . . . . . . . . . . . .21 PAUSE . . . . . . . . . . . . . . . . . . . . . .21 STEP BY STEP PLAYBACK . . . . .21
FAST FORWARD /
FAST REVERSE . . . . . . . . . . . . . .21
SLOW FORWARD /
SLOW REVERSE . . . . . . . . . . . . . .21 ZOOM . . . . . . . . . . . . . . . . . . . . . .21
C SEARCH FUNCTION . . . . . . . . . . .22
TRACK SEARCH . . . . . . . . . . . . .22 TITLE / CHAPTER SEARCH . . . .22 TIME SEARCH . . . . . . . . . . . . . . .22 MARKER SETUP SCREEN . . . . . .22
C SPECIAL PLAYBACK FUNCTION . . .23
REPEAT . . . . . . . . . . . . . . . . . . . . .23 PROGRAM . . . . . . . . . . . . . . . . . . .23 RANDOM PLAYBACK . . . . . . . . .23
C CHANGING THE SETTINGS . . . .24
SUBTITLE LANGUAGE . . . . . . . .24 AUDIO LANGUAGE . . . . . . . . . . .24 STEREO SOUND MODE . . . . . . . .24 CAMERA ANGLE . . . . . . . . . . . . .24 BLACK LEVEL SETTING . . . . . . .24 VIRTUAL SURROUND . . . . . . . . .25
C THE ON-SCREEN INFORMATION . . .25
C CHANGING THE DVD SET UP
ITEMS . . . . . . . . . . . . . . . . . . . . . . .26
CUSTOM MENU . . . . . . . . . . . . . .26 LANGUAGE SETTING . . . . . . . .26 DISPLAY SETTING . . . . . . . . . .27 AUDIO SETTINGS . . . . . . . . . . .27 PARENTAL CONTROL . . . . . . . .28 OTHER SETTINGS . . . . . . . . . . .28
INITIALIZE . . . . . . . . . . . . . . . . . .28
C TROUBLESHOOTING GUIDE . . .29
C MAINTENANCE . . . . . . . . . . . . . . .32
DISC HANDLING . . . . . . . . . . . . .32
C SPECIFICATIONS . . . . . . . . . . . . .33
C ESPAÑOL . . . . . . . . . . . . . . . . . . . .34
C WARRANTY . . . . . . . . . . .Back Cover
- 6 - |
EN |
FEATURES
TV Mode
•Infrared remote control
•Trilingual on screen TV setup display selectable in English, Spanish or French
•181 channel capability PLL frequency synthesizer tuner with direct station call (A converter may be necessary to view scrambled cable channels.)
•Closed Caption Decoder–You may view specially labeled (cc) TV programs, movies, news, etc. with either a dialogue caption or text display added to the program.
DVD Mode
¡Dolby Digital sound
This unit can handle Dolby Digital surround sound having 5.1 channels when connected to a Dolby Digital decoder.
¡Still/fast/slow/step playback
Various playback modes are available including still pictures, fast forward/reverse, slow motion and step frames.
¡Random playback for Audio CD
This unit can shuffle the order of tracks to play them in random order.
¡Program playback for Audio CD
You can program the order of tracks to play them in any desired order.
¡DVD menus in a desired language
You can display DVD menus in a desired language, if available on a DVD.
¡Screen saver/Auto power-off functions
The screen saver program starts when there is no input from the unit for 5 minutes in the stop mode. After the screen saver program is activated for 15 minutes, the power automatically turns off.
¡Subtitles in a desired language
You can select a desired language for the display subtitles, if that language is available on a disc.
¡Selecting a camera angle
You can select the desired camera angle, if a disc contains sequences recorded from different angles.
¡Choices for audio language and sound mode
You can select the desired audio language and sound mode, if different languages and modes are available on a disc.
•Auto power off system–If there is no air signal input from the antenna terminal and no operation for 15 minutes, the unit will turn itself off automatically.
•Sleep timer–Allows you to have the unit automatically turn off at a desired time.
•V-CHIP–Enables parents to prevent their children from watching inappropriate material on TV.
¡Parental lock
You can set the control level to limit playback of discs which may not be suitable for children.
¡Automatic detection of discs
This unit automatically detects if the loaded disc is DVD or Audio CD.
¡On-screen display
Information about the current operation can be displayed on a TV screen, allowing you to confirm the currently active functions (such as program playback), on the TV screen using the remote control.
¡Search
Chapter search / Title search / Track search / Time search
¡Repeat
Chapter / Title / Track / All / A-B
¡Zoom
Magnified screen can be displayed.
¡Marker
The part designated by user can be called back.
¡Resume Play
User can resume to playback from the part at which
the play was stopped.
¡Virtual Surround
¡Bit rate indication
¡DRC (Dynamic range control)
You can control the range of sound volume.
- 7 - |
EN |
OPERATING CONTROLS AND FUNCTIONS
- FRONT PANEL - [Fig.1]
VIDEO |
L –AUDIO– R |
POWER |
L VOLUME K L CHANNEL K |
C STOP H SKIP B PLAY SKIP G F PAUSE A OPEN/CLOSE HEADPHONE |
|
|
|
|
E – SEARCH – D |
|
|
1 |
2 |
3 |
4 |
5 |
6 |
7 |
8 |
9 10 |
9 11 12 13 |
- REMOTE CONTROL - [Fig. 2] |
|
|
|
|
8. C STOP Button [P.20] |
||||||
|
|
|
|
|
|
|
|
|
|
Stops operation of the disc. |
|
|
|
|
|
|
|
|
|
|
9. SKIP H / G Buttons [P.22] |
||
|
|
|
|
|
|
|
|
|
|
Press once to skip chapters or tracks to a desired |
|
|
POWER PICTURE |
SELECT |
CLOSE |
|
|
|
|
|
point. |
|
|
|
|
|
|
OPEN/ |
|
|
|
|
|
|
|
4 |
|
|
|
|
|
12 |
|
|
|
SEARCH h / g Buttons (Front panel) [P.21] |
|
14 |
1 |
2 |
3 |
|
|
35 |
|
|
|
Press and hold to change forward or reverse |
|
|
|
|
|
|
|
|
playback speed. |
||||
|
|
|
|
CH. |
|
6 |
|
|
|
||
15 |
4 |
5 |
6 |
|
|
|
|
10. B PLAY Button [P.20] |
|||
|
|
|
|
|
|||||||
|
7 |
8 |
9 |
|
|
|
|
|
|
Starts playback of the disc. |
|
|
|
|
5 |
|
|
11. F PAUSE Button [P.21] |
|||||
|
SLEEP |
|
+100 |
VOL. |
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
16 |
|
0 |
+10 |
|
|
|
|
|
|
Pauses the current disc operation. |
|
|
SKIP |
|
ZOOM |
MUTE |
|
34 |
|
|
12. A OPEN/CLOSE Button [P.20] |
||
|
|
|
|
|
|
|
|
|
Hit to insert a disc into or remove it from the |
||
9 |
|
|
|
|
|
33 |
|
|
|
||
10 |
|
PLAY |
|
|
32 |
|
|
|
tray. |
|
|
|
REV |
|
FWD |
|
|
|
|
13. HEADPHONE Jack |
|||
|
|
|
|
|
|
|
|
|
|||
|
|
STOP |
|
8 |
|
PAUSE |
SLOW |
DISC |
|
11 |
MENU |
31 |
||
|
|
|
||
17 |
DISPLAY |
|
|
30 |
|
ENTER |
|
||
18 |
SETUP |
TITLE |
RETURN |
29 |
|
|
|
28 |
|
19 |
|
|
|
|
CLEAR |
SEARCH MODE REPEAT |
A-B |
27 |
|
20 |
|
AUDIO SUBTITLE |
ANGLE |
|
21 |
MODE |
26 |
||
|
|
|
||
22 |
|
|
|
25 |
23 |
|
|
|
24 |
1.Disc loading tray
2.VIDEO input Jack
Connect to the video output jack of a video camera or VCR.
3.AUDIO L/R input Jacks
Connect to the audio output jacks of a video camera or VCR.
4.POWER Button [P.13]
Hit to turn the power on and off.
5.VOLUME (VOL.) K / L Buttons [P.13]
Press to control the volume level for the DVD and TV.
6.CHANNEL (CH.) K / L Buttons [P.13]
Press to select memorized channels.
To connect headphone (not supplied) for personal listening.
14.PICTURE Button [P.13]
Hit to adjust the picture.
15.Number Buttons
TV Mode:[P.13]
Press two digits to directly access the desired channel.
Remember to hit [0] before a single digit channel.
+100 Button–
Hit to select cable channels which are higher than 99.
DVD Mode:[P.22]
Hit to enter the desired number.
+10 Button–
Hit to enter the desired numbers which are higher than 9.
16.SLEEP Button [P.14]
Sets the Sleep Timer.
17.DISPLAY Button TV Mode:
Displays the current channel number on the TV screen.
DVD Mode: [P.25]
Displays the current status on the TV screen.
7. Remote sensor window
- 8 - |
EN |
- REAR PANEL - [Fig.3]
A N T .
COAXIAL
36 |
37 |
38 |
18.SETUP Button [P.26]
Hit to enter or exit the setup menu of TV or DVD.
19.TITLE Button [P.20]
Displays the title menu.
20.CLEAR Button [P.22]
Hit to clear or cancel a setting currently entered.
21.MODE Button [P.23, 24, 25]
Hit to call up the program screen or the random screen in the stop mode.
Hit to call up the Black Level Setting screen or the Virtual Surround screen during playback.
22.SEARCH MODE Button [P.22]
Hit to locate a desired point.
23.AUDIO Button [P.24]
Hit to select a desired audio language or sound mode.
24.SUBTITLE Button [P.24]
Hit to select a desired subtitle language.
25.REPEAT Button [P.23]
Repeats playback of the current disc, title, chapter, or track.
26.ANGLE Button [P.24]
Hit to change the camera angle to see the sequence being played back from a different angle (if available).
27.A-B Button [P.23]
Repeats playback of a selected section.
28.RETURN Button [P.22]
Returns to the previous screen in the setup menu.
29.ENTER Button [P.15]
Hit to accept a setting.
NOTE:
30. K / L / { / B Buttons TV Mode: [P.13]
Press to select a setting mode from the menu on the TV screen.
Press to select or adjust from a particular menu.
DVD Mode: [P.20]
Press to select a menu item.
31.DISC MENU Button [P.20]
Calls up the DVD menu.
32.REV h Button [P.21]
Hit to view the DVD picture in fast reverse or slow reverse motion.
FWD g Button [P.21]
Hit to view in fast or slow forward motion.
33.ZOOM Button [P.21]
Enlarges part of a DVD-reproduced image.
34.MUTE Button [P.13]
Mutes the sound. Hit it again to restore sound.
35.SELECT Button [P.11]
Hit to change to TV mode, external input mode or DVD mode.
36.COAXIAL Jack [P.11]
Connect to the digital input of an external amplifier or decoder (for DVD Audio only).
37.ANT(ENNA). Jack [P.10]
Connect to an antenna, cable system or satellite system.
38.Power cord [P.13]
Connect to a standard AC outlet (120V/60Hz).
NOTE:
•Remove the power cord from the hook to avoid breaking a wire before you connect to a standard AC outlet.
•We do not recommend the use of universal remote controls. Not all of the functions may be controlled with a universal remote control.
If you decide to use a universal remote control with this unit, please be aware that the code number given may not operate this unit. In this case, please call the manufacturer of the universal remote control.
- 9 - |
EN |
PREPARATION FOR USE
ANTENNA/CABLE CONNECTION
Cables used here are commercially available.
[ANTENNA CONNECTION]
75-ohm Coaxial Cable
VHF/UHF
OR
VHF/UHF VHF Combiner
UHF |
|
Flat twin- |
OR |
lead cable |
|
VHF |
Adaptor |
|
|
or |
|
UHF |
|
[CATV/SATELLITE CONNECTION]
CATV Box or |
|
|
Satellite Box * |
|
|
OUT |
IN |
|
COAXIAL A N T . |
From Cable System or |
|
|
Satellite Antenna |
|
ANT. |
75-ohm |
|
OR |
Coaxial Cable |
|
|
From Cable System |
|
*Some cable TV systems use scrambled signals and |
[Fig. 4] |
|
|
||
require a special converter to receive these channels. |
|
|
Consult your local cable company. |
|
|
Note to CATV system installer:
This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the NEC that provides guidelines for proper grounding and in particular, specifies that the cable ground shall be connected to the grounding system of the building as close to the point of cable entry as practical.
NOTE: |
Bent pin |
|
• Before plugging the antenna into the ANT. jack of the unit, check that the pin is |
Cable |
|
not bent. If it is bent, straighten the pin as illustrated, then plug the pin into the |
|
|
ANT. jack of the unit. |
Plug |
|
(Needs to be |
(Straight pin) |
|
|
straightened) |
|
VHF/UHF COMBINED ANTENNA
A VHF UHF 75 ohm combination antenna can be connected to ANT. jack of the unit.
VHF/UHF SEPARATE ANTENNAS
In some areas it will be necessary to use an outdoor antenna.
CABLE WITHOUT CONVERTER/ DESCRAMBLER BOX
Use this connection if your cable system connects directly to the unit without a converter box.
CABLE WITH CONVERTER/DESCRAMBLER BOX OR SATELLITE BOX
If your cable service supplies you with a converter box or if you use a satellite system, you can use the basic connection shown above.
Channel selection must be made with the converter box or satellite box. This means that channels cannot be changed using the remote control of this unit.
NOTE:
•For your safety and to avoid damages to the unit, unplug the antenna cable from the ANT. jack before moving the unit.
- 10 - |
EN |
CONNECTING TO FRONT A/V INPUT JACKS
When you watch a program recorded on another source (VCR or video camera), use the |
AUX |
AUDIO/VIDEO input jacks on the front of the unit. |
Connect the Audio/Video output jacks of another source to the AUDIO L/R and VIDEO jacks of this unit.
Then press [SELECT] or [CH. K / L] until “AUX” appears on the screen.
VIDEO |
L –AUDIO– R |
POWER |
L VOLUME K L CHANNEL K |
C STOP H SKIP B PLAY SKIP G F PAUSE A OPEN/CLOSE HEADPHONE |
|
|
|
|
E – SEARCH – D |
|
|
ex. |
|
|
To the Audio output jacks |
VCR or video camera, etc. |
|
|
|
||
(IN) |
Audio Cable |
(OUT) |
|
(commercially available) |
|||
|
|||
VIDEO L –AUDIO– R |
|
|
|
[Front of the unit] |
To the Video output jack |
|
|
(IN) |
Video Cable |
(OUT) |
|
|
(commercially available) |
[Fig. 5] |
|
|
|
NOTE:
•When you connect a monaural VCR (another source) to this unit, connect the Audio output jack of the monaural VCR (another source) to the AUDIO L jack of this unit. The audio will output in both L and R channel equally.
CONNECTING TO A STEREO AMPLIFIER EQUIPPED WITH
DIGITAL INPUT JACKS (for DVD)
Use an audio coaxial digital cable (commercially available) for the audio connections. Connect to an amplifier equipped with digital input jacks such as MD Deck or DAT Deck.
|
A N |
|
|
|
COAXIAL |
|
|
ex. |
|
|
|
MD deck, DAT deck, etc. |
(OUT) |
To COAXIAL jack |
|
|
|
||
|
|
(Only DVD AUDIO OUT) |
|
|
To Coaxial digital |
|
|
|
Audio input jack |
|
|
(IN) |
Audio coaxial digital cable |
[Fig. 6] |
|
|
(commercially available) |
|
|
NOTES:
•The audio source on a disc in a 5.1 channel Dolby Digital surround format cannot be recorded as digital sound by an MD or DAT deck.
•Be sure to turn off the power to all components in the system before connecting another component.
•Refer to the Owner’s Manuals for the components to be connected to the unit.
•Set “DOLBY DIGITAL” to “PCM” for audio output in the setup mode. Playing a unit using incorrect settings may generate noise distortion and may also damage the speakers. (Refer to page 27.)
- 11 - |
EN |
CONNECTING TO A DOLBY DIGITAL DECODER (for DVD)
If using this unit to play a DVD disc in a 5.1 channel Dolby Digital surround format, the unit outputs a DOLBY DIGITAL Data stream from its COAXIAL jack. By hooking the unit up to a Dolby Digital decoder, you can enjoy a more convincing, realistic ambience with powerful and high-quality surround sound as enjoyed in movie theaters.
Use audio coaxial digital cables (commercially available) for the audio connections.
Center |
|
|
|
speaker |
Front speaker |
A N T . |
|
Front speaker |
COAXIAL |
|
|
(left) |
(right) |
|
|
Dolby Digital |
|
(OUT) |
To COAXIAL jack |
|
(Only DVD AUDIO OUT) |
||
decoder |
To Coaxial digital |
|
|
|
Audio input jack |
|
|
Surround |
Surround |
Subwoofer |
(IN) |
Audio Coaxial digital cable |
|
(commercially available) |
|||||
speaker |
speaker |
|
|
||
|
|
|
|||
(left) |
(right) |
|
|
|
[Fig. 7]
NOTES:
•Be sure to turn off the power to all components in the system before connecting another component.
•Refer to the Owner’s Manuals for the components to be connected to the unit.
•If connected to a Dolby Digital decoder, set “DOLBY DIGITAL” to “BITSTREAM” for audio output in the setup mode. (Refer to page 27.)
•Unless connected to a Dolby Digital decoder, set “DOLBY DIGITAL” to “PCM” for audio output in the setup mode. Playing a unit using incorrect settings may generate noise distortion and may also damage the speakers. (Refer to page 27.)
Manufactured under license from Dolby Laboratories. “Dolby” and the double-D symbol are trademarks of Dolby Laboratories.
INSTALLING THE BATTERIES
1)Open the battery compartment cover by pressing the cover on the remote unit in the direction of the arrow.
2)Insert 2 “AA” penlight batteries into the battery compartment in the direction indicated by the polarity (+/-) markings.
3)Replace the cover.
[BATTERY PRECAUTIONS]
•Be sure to follow the correct polarity as indicated in the battery compartment. Reversed batteries may cause damage to the device.
•Do not mix different types of batteries together (e.g. Alkaline and Carbon-Zinc) or old batteries with fresh ones.
•If the device is not to be used for a long period of time, remove the batteries to prevent damage or injury from possible battery leakage.
•Do not try to recharge batteries not intended to be recharged; they can overheat and rupture.
- 12 - |
EN |
Loading...
